Spec Sheet / IBR1100/IBR1150 7/13/17
COR Series
Router
IBR1100 / IBR1150
Spec Sheet
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 2
Spec Sheet / IBR1100/IBR1150 7/13/17
INTRODUCTION
WHAT’S IN THE BOX
KEY FEATURES
• Ruggedized router with integrated business-class 3G/4G modem; includes integrated mounting plate
• Two meter locking power and GPIO cable (direct wire)
• Quick Start Guide with warranty information
NOTE: Due to the diverse needs of customers, the COR IBR1100/IBR1150 package does not include a power adapter or
antennas. See the Accessories section below for several power and antenna options.
WAN
• Dual-modem capable with optional IBR1100/IBR1150 Dual-Modem Dock
• LP6: LTE Advanced LTE/HSPA+ (SIM-based Auto-Carrier Selection for all North American and European carriers)
• LPE: 4G LTE/HSPA+/EVDO (multi-carrier)
• LP3: 4G LTE/HSPA+ (Europe, EMEA, and Australia/New Zealand)
• WiFi as WAN¹, with WPA2 Enterprise Authentication for WiFi-as-WAN³
• Failover/Failback
• Load Balancing
• Advanced Modem Failure Check
• WAN Port Speed Control
•
• IP Passthrough
• Standby
LAN
• VLAN 802.1Q
• DHCP Server, Client, Relay
• DNS and DNS Proxy
• DynDNS
• UPnP
• DMZ
• Multicast/Multicast Proxy
• QoS (DSCP and Priority Queuing)
• MAC Address Filtering
WIFI1
• Dual-Band Dual-Concurrent
• 802.11 a/b/g/n/ac
• Up to 128 connected devices (64 per radio – 2.4 GHz and 5 GHz)
• Multiple SSIDs: 2 per radio (4 total)
• WPA2 Enterprise (WiFi)
• Hotspot/Captive Portal
• SSID-based Priority
•
MANAGEMENT
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 3
Spec Sheet / IBR1100/IBR1150 7/13/17
• Cradlepoint NetCloud Manager²
• Web UI, API, CLI
• Active GPS support on all models
• Data Usage Alerts (router and per client)
• Advanced Troubleshooting (support)
• Device Alerts
• SNMP
• SMS control
• Serial Redirector
• Auto APN Recovery
VPN AND ROUTING
•
• L2TP³
• GRE Tunnel
• OSPF/BGP/RIP³
•
• Per-Interface Routing
• Routing Rules
• Policy-based Routing
• NAT-less Routing
• Virtual Server/Port Forwarding
• NEMO/DMNR³
• IPv6
• VRRP³
• STP³
• NHRP³
• VTI Tunnel support
• OpenVPN support
• CP Secure VPN compatible
• Serial PAD Mode
SECURITY
• RADIUS and TACACS+ support*
• 802.1x authentication for Ethernet
• Zscaler integration³
•
• ALGs
• MAC Address Filtering
• Advanced Security Mode (local user management only)
• Per-Client Web Filtering
• IP Filtering
• Content Filtering (basic)
• Website Filtering
• Zone-Based Object Firewall with host address (IP or FQDN), port, and mac address
*-Native support for authentication. Authorization and accounting support through hotspot/captive portal services.
CLOUD OPTIMIZED IP COMMUNICATIONS
• Automated WAN Failover/Failback support
•
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 4
Spec Sheet / IBR1100/IBR1150 7/13/17
SPECIFICATIONS
WAN:
• Dual-modem capable with optional IBR1100/IBR1150 Dual-Modem Dock
• Integrated LP6 Category 6 LTE Advanced LTE modem (with DC-HSPA+ failover) or LPE 4G LTE modem (with HSPA+/
EVDO/3G and 2G failover) or LP3 4G LTE modem (with HSPA+ and 2G failover)
• Three LAN/WAN switchable 10/100 Ethernet ports – one default WAN (cable/DSL/T1/satellite/Metro Ethernet)
• WiFi as WAN, Metro WiFi; 2x2 MIMO “N” 2.4 GHz or 5 GHz; 802.11 a/b/g/n/ac (IBR1100 only)
LAN:
• Dual-band dual-concurrent WiFi; 802.11 a/b/g/n/ac (IBR1100 only)
• Three LAN/WAN switchable 10/100 Ethernet ports – two default LAN
• Serial console support for out-of-band management of a connected device
PORTS:
• Power
• 2-wire GPIO
• Add three more GPIO ports with optional Serial-to-GPIO cable (see Accessories section below)
• USB 2.0
• Three Ethernet LAN/WAN
• Two cellular antenna connectors (SMA)
• One active GPS antenna connector (SMA)
• Two WiFi antenna connectors (R-SMA)
• Serial DE-9 (commonly called “DB-9”) connector – RS-232 (out-of-band management of an external device
requires a null modem adapter/cable)
TEMPERATURE:
•
•
•
HUMIDITY (non-condensing):
• 5% to 95% operating
• 5% to 95% storage
POWER:
• DC input steady state voltage range: 9–36 VDC (requires inline fuse for vehicle installations)
• For 9–24 VDC installations, use a 3 A fuse
• For > 24 VDC installations, use a 2.5 A fuse
• Reverse polarity and transient voltage protection per ISO 7637-2
• Ignition sensing (automatic ON and time-delay OFF)
• Power consumption:
• Idle: typical = 400 mA @ 12 VDC (4.8 W); worst case = 800 mA @ 12 VDC (9.6 W)
• Advanced VPN connectivity options to HQ
•
• MAC Address Filtering
• 802.1p/q for LAN QoS segmentation and treatment of VoIP on LAN
• Private Network support (wired and 4G WAN)
• Cloud-based management²
1 – WiFi-related functions are only supported on IBR1100 models
2 – NetCloud Manager requires a subscription
3 – Requires an Extended Enterprise License or NetCloud Manager PRIME
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 5
Spec Sheet / IBR1100/IBR1150 7/13/17
• Tx/Rx: typical = 650 mA @ 12 VDC (7.8 W); worst case = 1300 mA @ 12 VDC (15.6 W)
• 12VDC 2A adapter recommended
WIFI POWER:
• 2.4 GHz band: 17 dBm conducted
• 5 GHz band: 15 dBm conducted
SIZE: 5.3 × 4.4 × 1.4 in (134 × 112 × 35 mm)
WEIGHT: 16.1 oz (457 g)
CERTIFICATIONS:
• FCC, CE, IC
•
• Safety: UL/CUL, CB Scheme, EN60950-1
• Hazardous Locations: Class I, Div. 2
• Shock/Vibration/Humidity: compliant with MIL STD 810G and SAEJ1455
• Ingress Protection: compliant with IP64 (includes protection from dust and splashing water)
• Materials: WEEE, RoHS, RoHS-2, California Prop 65
• Vehicle: E-Mark, compliant with ISO 7637-2
• Telecom: PTCRB/CTIA, GCF-CC
GPS
• GPS Protocols: TAIP and NMEA 0183 V3.0
• Satellite channels: Maximum 30 channels (16 GPS, 14 GLONASS), simultaneous tracking
• Concurrent standalone GPS, GLONASS, BeiDou and Galileo (LP6 models only)
• 1 Hz refresh rate
• Accuracy:
• < 2 m: 50%
• < 5 m: 90%
• Horizontal: < 2 m (50%); < 5 m (90%)
• Altitude: < 4 m (50%); < 8 m (90%)
• Velocity: < 0.2 m/s
• Acquisition (measured with signal strength = -135 dBm):
• Hot start: 1 second
• Warm start: 29 seconds
• Cold start: 32 seconds
• Sensitivity
•
an in-view satellite 50% of the time when in sequential tracking mode)
•
device can still detect an in-view satellite 50% of the time)
• Operational limits: altitude < 6000 m or velocity < 100 m/s (either limit may be exceeded, but not both)
ACCESSORIES
Because of the diversity of customer needs, the COR IBR1100/IBR1150 does NOT include a power adapter or antennas
options for dual-modem capability, power and antennas:
DUAL-MODEM DOCK
IBR1100/IBR1150 Dual-Modem Dock (Part # 170675-000), FirstNet/Band 14 ready integrated 4G LTE modem:
• MC400L2 (FirstNet/Band 14 LTE modem)
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 6
Spec Sheet / IBR1100/IBR1150 7/13/17
• MC400LP6 (North America, Europe)
• MC400LP4 (AT&T, Verizon, T-Mobile and Canada)
• MC400LPE-VZ (Verizon)
• MC400LPE-AT (AT&T)
• MC400LPE-SP (Sprint)
• MC400LPE-GN (generic – for use on T-Mobile in the U.S. and Rogers, Bell, & TELUS in Canada)
• MC400LP3-EU (Europe)
POWER
Wall options
•
line cord (Part # 170648-001)
• Line cord for North America (Part # 170623-001)
• Line cord for EU (Part # 170623-002)
• Line cord for UK (Part # 170623-003)
•
170584-002)
NOTE: Cradlepoint primarily recommends the extended temperature adapter because it covers the COR IBR1100/
IBR1150 full temperature range of −30 °C to 70 °C. Cost-sensitive customers that intend to use the IBR1100/IBR1150 in
temperature-controlled office environments can order the 170584-002 adapter, but it limits the operating temperature
range to 0 °C to 40 °C.
Vehicle options
• Vehicle locking power adapter for COR (Part # 170635-000)
• Two meter locking power and GPIO cable (direct wire) for replacement – included by default (Part # 170585-000)
Adapters
• Barrel to 4-pin power adapter (Part # 170665-000)
• Serial-to-GPIO cable (Part # 170676-000)
ANTENNAS – 3G/4G Modem, WiFi, & GPS
• 700 MHz – 2700 MHz Wide Band Directional Antenna (Yagi/Log- Periodic) Part #: 170588-000
• 12” Mag-Mount Antenna with SMA Male Connector Part #: 170605-000
• 4” Mini Mag-Mount Antenna with SMA Male Connector Part #: 170606-000
• 2.4/5 GHz Dual-band Dual-concurrent WiFi Antenna Part #: 170628-000 (WiFi models only)
• Universal 3G/4G/LTE Modem Antenna Part #: 170649-000
• GPS Screw-Mount Antenna Part #: 170651-000
• GPS Mag-Mount Antenna Part #: 170652-000
• Multi-Band Omni-Directional Antenna Part #: 170668-000
• Indoor/Outdoor Panel Patch Part #: 170669-000
Vehicle Antennas
• 3-in-1 GPS & Modem Screw-Mount Part #: 170653-000
• 3-in-1 Adhesive-Mount Antenna Part #: 170653-001
• 5-in-1 GPS, Modem & WiFi Screw-mount Part #: 170654-000
•
001
See the Cradlepoint antenna accessories page for more information about antennas. Also see the Antenna Ordering
and Installation Guide, available as a PDF in the Resources section of antenna and router product pages.
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 7
Spec Sheet / IBR1100/IBR1150 7/13/17
BUSINESS-GRADE MODEM SPECIFICATIONS
COR IBR1100/IBR1150 LP6 models include an integrated LTE Advanced Category 6 4G LTE modem. The LP6 modems
support SIM-Based Auto-Carrier selection so there is only one model for all of North America. Simply insert the SIM
and wait for the router to automatically detect the SIM and establish a connection.
COR IBR1100LP6-NA, COR IBR1150LP6-NA, COR IBR1100LP6-EU
• Technology: LTE Advanced, DC-HSPA+
• Downlink Rates: LTE 300 Mbps, DC-HSPA+ 42.2 Mbps
• Uplink Rates: LTE 50 Mbps, DC-HSPA+ 5.76 Mbps
• Frequency Bands:
• LTE Bands 1-5, 7, 8, 12, 13, 17, 20, 25, 26, 29, 30, 41
• Verizon: 2, 4, 5, 13 (XLTE support w/carrier aggregation)
• AT&T: 2, 4, 5, 12/17, 29, 30
• Sprint: 25, 26, 41 (LTE Plus Support)
• T-Mobile: 2, 4, 12 (T-Mobile Wideband LTE Support)
• Carrier Aggregation:
• 1+ 8
• 2+ 2/5/12 (17 w/MFBI)/13/29
• 3+ 7/20
• 4+ 4/5/12 (17 w/MFBI)/13/29
• 5+ 2/4/30
• 7+ 3/7/20
• 8+ 1
• 12 (17 w/MFBI) + 2/4/30
• 13+ 2/4
• 20+ 3/7
• 30+ 5/12 (17 w/MFBI)
• 41+ 41
• Fallback: WCDMA/DC-HSPA+ (42/5.76 Mbps): Bands 1, 2, 3, 4, 5, 8
• Power: LTE 23 dBm ± 1, DC-HSPA+ 23 dBm ± 1
• Antennas: )
• GPS: active GPS support
• SMS: SMS support
• Industry Standards & Certs: CE, FCC, GCF-CC, IC, PTCRB, AT&T, Sprint, Verizon
COR IBR1100/IBR1150 LPE models
modem (e.g., the COR IBR1100LPE-VZ includes a Verizon LTE modem).
frequency bands in bold below are supported by the listed provider.
COR IBR1100LPE-VZ, COR IBR1150LPE-VZ – 4G LTE/HSPA+/EVDO for Verizon
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 8
Spec Sheet / IBR1100/IBR1150 7/13/17
• Antennas: )
• GPS: active GPS support
• Industry Standards & Certs: FCC, Verizon
COR IBR1100LPE-AT, COR IBR1150LPE-AT – 4G LTE/HSPA+/EVDO for AT&T
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
• Antennas:)
• GPS: active GPS support
• Industry Standards & Certs: PTCRB, FCC, IC, AT&T
COR IBR1100LPE-SP, COR IBR1150LPE-SP – 4G LTE/HSPA+/EVDO for Sprint
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
• Antennas:)
• GPS: active GPS support
• Industry Standards & Certs: FCC, Sprint
COR IBR1100LP3-EU, COR IBR1150LP3-EU – 4G LTE/HSPA+ for Europe
• Technology: LTE, HSPA+
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical)
• Frequency Bands:
• LTE Band 1 (2100 MHz), Band 3 (1800 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 20 (800 MHz)
• HSPA+/UMTS (800/850/900/1900/2100 MHz)
• GSM/GPRS/EDGE Quad-Band (850/900/1800/1900 MHz)
• Power: LTE Band 1/3/8/20 – 23 dBm ± 1; LTE Band 7 – 22 dBm ± 1, HSPA+ 23 dBm ± 1 (typical conducted)
• Antennas:)
• GPS: active GPS support
• Industry Standards & Certs: CE, GCF-CC
COR IBR1100LPE-GN, COR IBR1150LPE-GN – 4G LTE/HSPA+/EVDO (generic – for use on T-Mobile and U.S. Cellular in
the U.S. and Rogers, Bell, & TELUS in Canada)
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 (AWS), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700 MHz), Band 25
(1900 MHz)
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 9
Spec Sheet / IBR1100/IBR1150 7/13/17
HARDWARE
3G/4G Antenna
Connector (SMA)
3G/4G Antenna Connector
(SMA)
RS-232 Port
(female)
Reset
Button
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
• Antennas:)
• GPS: active GPS support
• Industry Standards & Certs: PTCRB, FCC, IC
GPS Connector (SMA)
WiFi Antenna Connector*
(Reverse SMA)
USB 2.0
Port
LAN or WAN Default: WAN
10/100 Ethernet Ports
Default: LAN)
Power Port
WiFi Antenna Connector*
(Reverse SMA)
* - only on IBR1100
©2017 Cradlepoint. All Rights Reserved. | +1.855.813.3385 | cradlepoint.com 10
Spec Sheet / IBR1100/IBR1150 7/13/17
CradleCare Support available in the US and Canada with technical support, software upgrades, and advanced hardware
exchange – 1-, 3-, and 5-year options.
Three-year limited hardware warranty available world-wide on IBR1100/IBR1150 series products when purchased from
an approved Cradlepoint Partner or Distributor – extend warranty to 5 years.
SUPPORT AND WARRANTY
LEDS
SIGNAL STRENGTH Blue LED bars indicate the active modem’s signal strength.
• 4 Solid Bars = Strongest signal.
• 1 Blinking Bar = Weakest signal. (A blinking bar indicates half of a bar.)
POWER
The Cradlepoint IBR1100/IBR1150 must be powered using an approved 9-36 VDC power
source.
• Blue = Powered ON.
• No Light = Not receiving power. Check the power switch and the power source connection.
• Flashing Amber = Attention. Open the administration pages and check the router status.
WiFi BROADCAST These two LEDs indicate activity on the WiFi broadcast for both the 2.4
GHz and 5 GHz bands.
• 2.4GHz (green) = 2.4 GHz WiFi is on and operating normally.
• 5GHz (blue) = 5 GHz WiFi is on and operating normally.
EXTERNAL USB MODEM Indicates the status of external USB modem.
Both internal and external USB modems have the following LED indicators:
• Green = Modem has established an active connection.
• Blinking Green = Modem is connecting.
• Amber = Modem is not active.
• Blinking Amber = Data connection error. No modem connection possible.
• Blinking Red = Modem is in the process of resetting.
ADDITIONAL LED INDICATIONS
•
• Two of the modem LEDs blink red in unison for 10 seconds when there is an error during NCOS
upgrade.
EC
2.4GHz
5GHz
INTEGRATED MODEM
Indicates information about the integrated modem.
• Green = Connected to integrated modem.
