Guide to the csound~ Sources: Davis Pyon
csound~ (v1.0.7) – by Davis Pyon
These are the instructions for building the csound~ MaxMSP external on Windows or Mac
OS X. The build process is different on each platform. For the latest news and downloads
concerning csound~, visit http://www.davixology.com/csound~.html.
Dependencies
You will need to install Csound 5 (http://sourceforge.net/projects/csound).
You will need the MaxMSP SDK (http://cycling74.com/products/sdk/).
Mac OS X
To build csound~, you will need Xcode 2.4 or later. Install Xcode from the Mac OS X
Install DVD or get it from http://developer.apple.com/technologies/xcode.html.
Windows
To build csound~, you will need Visual C++ 2005 or later. The free Express Edition of
Visual C++ can be obtained at http://www.microsoft.com/express/Downloads/.
Download the pexports command line tool from:
http://www.emmestech.com/software/pexports-0.43/download_pexports.html.
Download win32 pthreads at http://sourceware.org/pthreads-win32/.
Download libsndfile at http://www.mega-nerd.com/libsndfile/#Download.
Building csound~
Mac OS X
After installing Csound 5 and the MaxMSP SDK, make sure the /Library/Frameworks
folder contains:
CsoundLib.Framework or CsoundLib64.Framework
MaxAPI.framework
MaxAudioAPI.framework
CsoundLib.Framework is installed automatically by Csound5.pkg or CsoundLib.pkg
These packages are found in the Csound 5 disk images for Mac OS X.
Also, make sure that libsndfile.1.dylib (a symbolic link to the actual libsndfile dynamic
library) exists in /usr/local/lib.
Open csound~.xcodeproj in the src folder.
Under Groups & Files → Targets, double-click either csound~ float or csound~ double,
depending on which version of Csound 5 you installed. Select the Release configuration.
Under General → Search Paths → Header Search Paths, change the paths to match your
installations.
Under General → Build Locations, change Build Products Path and Intermediate Build
Files Path to reflect your externals folder and build folder locations. The externals folder
is typically:
/Applications/Max5/Cycling '74/msp-externals/_my_externals
Press Cmd + Shift + B, or select Build → Build Results from the menu.
Set Active Target to csound~ float or csound~ double depending on which version of
Csound 5 you installed.
Set Active Build Configuration to Release.
Press Cmd + B, or select Build → Build from the menu.
Windows
Update your PATH variable so that you can run lib.exe. It is typically located at:
C:\Program Files\Microsoft Visual Studio 9\VC\bin
To update you PATH variable on Vista or Windows 7:
a) Press Windows + R
b) Type “sysdm.cpl”, then press enter
c) Go to “Advanced” tab
d) Click “Environment Variables...”
e) Under “System Variables”, double click “Path”
f) At the end of the string, enter “;C:\Program Files\Microsoft Virual Studio 9\VC\bin”
Copy pexports.exe to one of the directories listed in your PATH variable.
Open Command Prompt (not Cygwin or Msys). Then type the following commands:
$ vcvars32.bat
$ cd C:\Program Files\Csound\bin
$ pexports csound__.dll.5.1 > csound__.def
$ lib /machine:i386 /def:csound__.def
replacing "__" with "32" or "64". The numbers stand for bits. So, if you downloaded
Csound5 floats version, then it's 32bit. For Csound5 doubles version, it's 64bit. The
Csound5 installer file will give a hint in the name with the letter 'd' or 'f'.
Open csound~.vcproj in the src directory.
Press Alt + F7, or select the menu item Project → Properties.
Go to Configuration Properties → C/C++ → General → Additional Include Directories.
Change all include paths to match your installations (Max, Csound5, pthreads, libsndfile).
Go to Configuration Properties → Linker → Input → Additonal Dependencies. Change all
lib paths to match your installations (Max, Csound5, pthreads, libsndfile).
If using MaxSDK version 5 or later, go to Configuration Properties → Linker → Input →
Ignore Specific Library. Then add maxcrt.lib.
Go to Configuration Properties → Build Events → Post-Build Event → Command Line.
Change the destination directory to match your MaxMSP installation. You may need to
change the permissions on the destination directory or run VC++ as Admin. Or, you can
just delete the copy command and copy the resulting .mxe file manually after building.
Press F7 to compile csound~.
If you deleted the copy command, copy csound~.mxe from the src\build directory to:
C:\Program Files\Cycling '74\Max 5.0\Cycling '74\msp-externals\.
If you get an error like "stdint.h not found”, download stdint.h from:
http://en.wikipedia.org/wiki/Stdint.h
and move it to:
C:\Program Files\Csound\include
If you get an error like “__int64_t not defined”, open stdint.h and add the line:
typedef __int64 __int64_t;
Running csound~
In order to run csound~, you must have MaxMSP 4.6.3 or later installed. After csound~.mxe
or csound~.mxo is built and in the proper location, you can open one of the Max patches
contained in examples or help_files folders. Max patches end with .maxpat or .maxhelp.
Known Issues
On Windows, fluidOpcodes.dll can cause MaxMSP to crash. Typically, you will encounter
a crash when clicking on a non-MaxMSP window after stopping a Csound performance,
deleting a csound~ instance, or closing a patch that contains csound~. This may be fixed in a
future release of Csound 5, but as of version 5.11.1, the bug still exists. To fix, move or
delete fluidOpcodes.dll from the Csound 5 plugins or plugins64 directory (e.g. C:\Program
Files\Csound\bin\plugins64).
