Datasheet Thinkpad P70
asset-lpn-en-us-slash-en-ca-thinkpad-p-series-thinkpad-p70-datasheet
User Manual:
Open the PDF directly: View PDF
.
Page Count: 2
The Lenovo™ ThinkPad® P70 introduces a 17" mobile workstation to the ThinkPad® family;
designed for high-end professionals across multiple industries. The P70 is the best-performing
system in the ThinkPad® line; certified to run the most demanding Independent Software Vendor (ISV)
applications. Powered by the new Intel® Xeon® processors for mobile workstations and latest
NVIDIA® Quadro® GPUs for unmatched graphics capability. It also comes packed with the most
memory and storage ever found in a mobile workstation to get the job done faster than ever before.
Power defined
Redefining the mobile workstation
WHY YOU SHOULD BUY THE LENOVO™ THINKPAD® P70 MOBILE WORKSTATION
THE LENOVO™ THINKPAD® P70 MOBILE WORKSTATION IS BEST SUITED FOR
Engineers and designers who
have to have the most powerful
system with the newest
technology.
1Users looking for ISV certified
mobile workstation which
ensures superior application
performance.
2Torture-tested to be ThinkPad®
tough; ensuring your system
can withstand the rigors of
day-to-day use in the field.
3
WHAT’S IN A THINKPAD®
Form factors for
all needs
41 The gold standard in
reliability since 1992 2Premium materials and
layers of reinforcement 3Award winning
ergonomic keyboard 5Purposeful design
details
Legendary reliability
Upgraded touchpad resists wear and features
new 3-button functionality. Move huge files in
an instant with the fastest connection using
Intel® Thunderbolt™ 3.
Ultimate user experience
Stunning visuals
Mobile performance
Lenovo™ recommends Windows.
Lenovo™ ThinkPad® P70 Mobile Workstation
Packed with power, including the first
Intel® Xeon® processors for mobile workstations,
latest NVIDIA® Quadro® graphics card, up to
64 GB of memory, and 1 TB of PCIe storage.
Ultra high resolution 4K IPS display with
100% color gamut and X-Rite® Pantone®
color calibration, keeps images vibrant
and accurate.
The ThinkPad® P70 is MIL-SPEC tested.
The new FLEX Performance Cooling gives
users the ability to push their system harder
for longer using dual-fan technology.
©2015 Lenovo. All rights reserved. Availability: Offers, prices, specifications and availability may change without notice. Lenovo is not responsible for photographic or typographic errors. Warranty: For a copy of applicable warranties, write
to: Warranty Information, 500 Park Offices Drive, RTP, NC, 27709, Attn: Dept. ZPYA/B600. Lenovo makes no representation or warranty regarding third-party products or services. Trademarks: Lenovo, the Lenovo logo, Rescue and Recovery,
ThinkPad, ThinkCentre, ThinkStation, ThinkServer, ThinkVantage and ThinkVision are trademarks or registered trademarks of Lenovo. Microsoft, Windows and Vista are registered trademarks of Microsoft Corporation. Intel, the Intel logo, Intel Inside
logo, Intel Atom and Intel Atom Inside are trademarks of Intel Corporation in the U.S. and/or other countries. Other company, product and service names may be trademarks or service marks of others. Battery life (and recharge times) will vary based
on many factors including system settings and usage. Visit Lenovo.com/safecomputing periodically for the latest information on safe and effective computing.
WWW.LENOVOPARTNERNETWORK.COM/THINKPAD-P-SERIES
WWW.LENOVOPARTNERNETWORK.COM/CA/THINKPAD-P-SERIES
RECOMMENDED SERVICES
PRIORITY TECHNICAL SUPPORT3
Makes your priority, our priority. 24x7 priority
call routing to advanced-level technicians,
electronic incident tracking, and rapid response
and resolution.
WARRANTY UPGRADES - ON-SITE AND
NEXT BUSINESS DAY
Maximizes PC uptime and productivity by
providing convenient, fast repair service the next
business day.
WARRANTY EXTENSIONS
(1-TO-4 YEARS TOTAL DURATION)
This fixed-term, fixed-cost service helps
accurately budget for PC expenses, protect your
valuable investment and potentially lower the
cost of ownership over time.
KEEP YOUR DRIVE
Retain your drive if it should happen to fail, giving
you the peace of mind to know that your valuable
data is secure. KYD applies to all drives within
multi hard disk/SSD systems.
Lenovo™ offers a comprehensive portfolio of services to support and protect your ThinkPad® investment.
Focus on your customers and business, not your IT.
3 Not available in all regions.
Lenovo™ recommends Windows.
Lenovo™ ThinkPad® P70 Mobile Workstation
1 Battery life (and recharge times) will vary based on many
factors including system settings and usage. A description
of the environment under which the test was performed
is available upon request.
2 Optional.
PERfORMANCE
Processor
Intel® Xeon® Processors for Mobile Workstations
6th Generation Intel® Core™ Processor
Operating System
Windows 10 Pro
Windows 8.1 Pro
Windows 7 Professional (available through
downgrade rights from Windows 10 Pro)
Graphics
NVIDIA® Quadro®
Memory
4 SODIMM Slots, 64 GB Max., 2133 MHz
Max. Storage Devices - 4
2 TB HDD
1 TB PCIe / SATA SSD
Optical Drive
DVD-RW
Up to 1 TB HDD with Bay Adapter
Up to 512 GB SSD with Bay Adapter Travel Bezel
RAID
0, 1
Power Supply
170 W, 230 W
Battery1
8 Cell (96 WHr)
DESIGN
Dimensions (W x D x H)
(mm) : 416 x 275.5 x 29.9 - 31.5
(inches) : 16.4" x 10.8" x 1.17" - 1.2"
Display
FHD (1920 x 1080) IPS, 300 nits
FHD Touch (1920 x 1080) IPS, 270 nits
4K UHD (3840 x 2160) IPS, 300 nits
Weight
Starting at 7.6 lbs (3.4 kg)
Color Sensor
X-Rite® Pantone®2
Keyboard
ThinkPad® Precision Keyboard with
Numeric Keypad and Backlit2
SPECIFICATIONS
SOfTWARE
• Windows 10 Pro 64-bit
• Windows 10 Home Premium 64-bit
• Windows 10 Home Premium
Single Language 64-bit
• Windows 10 Home
Chinese Language Edition 64-bit
• Windows 7 Professional 64-bit
(pre-installed through downgrade
rights in Windows 10 Pro)
• Windows 7 Professional 64-bit
• Ubuntu® Linux
• RHEL
GREEN CERTIfICATION
• EPEAT™ Gold
• ENERGY STAR® 6.1
• GREENGUARD®
• RoHS Compliant
CONNECTIVITY
Ports
(4) USB 3.0, 1 Always-on Charging
(1) HDMI 1.4
(1) Mini DisplayPort™ 1.2
(2) Thunderbolt™ 3
(1) RJ45 Gigabit Ethernet
(1) Docking Connector
(1) Microphone / Headphone Combo Jack
(1) Smart Card Reader2
(1) ExpressCard / 34 mm
(1) SDXC
WLAN
Intel® 8260 2 x 2 a/c + Bluetooth® 4.1 vPro
Intel® 8260 2 x 2 a/c + Bluetooth® 4.1
WWAN
Sierra EM7445 - 4G LTE-A
Media Card Reader
Integrated 4-in-1 SD Card Reader
(SD, SDHC, SDXC, MMC)
OPTIONS & ACCESSORIES
ThinkPad®
Performance Dock
