The PowerEdge R630 server is versatile and highly
congurable for a variety of solutions, delivering the
latest Intel® Xeon® processor E5-2600 v3 product
family, 24 DIMMs of high-performance DDR4
memory and a broad range of local storage options.
Deliver peak performance
Build a blazingly fast transactional database with
the R630 24 all-ash drive conguration. Combine
the density, scalability and performance of 24 1.8”
SSDs with dual-PERC capability to deliver a superior
solution that can boost performance by storing an
entire database. When combined with the SanDisk®
DAS Cache solution, the R630 can help increase
OLTP transactions and concurrent usage for
latency-sensitive applications, such as e-commerce
or nancial trading.
Discover greater versatility
With up to 24 DIMMs of memory, and congured
with up to 10 2.5” drives, the R630 can provide
a dense, resource-rich midsized virtualization
environment to drive business Intelligence applications,
from customer relationship management (CRM) to
enterprise-resource planning (ERP), while it saves on
space, energy and capital costs.
You can also increase the speed of data access using
up to four NVMe PCIe Express Flash devices with
Fluid Cache technology – and share that caching
advantage across other networked servers.
Maximize operational eciency
Quickly and securely monitor or modify critical
server settings “at the box” with the
iDRAC Quick Sync bezel with embedded near eld
communication (NFC) capability. Use a handheld
device with the bezel to quickly check system
health details, and use iDRAC Direct to easily deploy
or modify settings across multiple servers with a
USB key or laptop, eliminating the potential for
conguration errors.
Innovative management with
intelligent automation
The Dell OpenManage systems management
portfolio includes innovative solutions that simplify
and automate essential server lifecycle management
tasks – making IT operations more ecient and
Dell servers the most productive, reliable and cost
eective. Leveraging the incomparable agent-free
capabilities of the PowerEdge embedded integrated
Dell Remote Access Controller (IDRAC) with
Lifecycle Controller technology, server deployment,
conguration and updates are streamlined across
the OpenManage portfolio and through integration
with third-party management solutions.
Monitoring and control of Dell and third-party
data center hardware is provided by OpenManage
Essentials and with anytime, anywhere mobile
access, through OpenManage Mobile. OpenManage
Essentials now also delivers Server Conguration
Management capabilities that automate one-many
PowerEdge bare-metal server and OS deployments,
quick and consistent replication of congurations
and ensure compliance to a predened baseline
with automated drift detection.
PowerEdge R630
PowerEdge R630
• Latest Intel Xeon E5-2600 v3
processors — up to 18 cores
• Up to 24 DIMMs high-capacity
DDR4 memory
• Up to 24 1.8” SSDs (23TB)
• Up to 3 PCIe 3.0 expansion
slots
• Up to 4 Express Flash NVMe
PCIe SSDs
With computing capability previously only seen in 2U servers, the ultra-dense
PowerEdge R630 two-socket 1U rack server delivers an impressive solution for
virtualization environments, large business applications or transactional databases.
Learn More at Dell.com/PowerEdge.
Feature PowerEdge R630 technical specication
Form factor 1U rack
Processor Intel® Xeon® processor E5-2600 v3 product family
Processor sockets 2
Dimensions 24 x 1.8” and 10 x 2.5” drive conguration: H: 4.28 cm (1.68 in.) x W: 48.23 cm (18.98 in.) x D: 75.51 cm (29.72 in.)
8 x 2.5” drive conguration: H: 4.28 cm (1.68 in.) W: 48.23 cm (18.98 in.) D: 70.05 cm (27.57 in.)
Cache 2.5MB per core; core options: 4, 6, 8, 10, 12, 16, 18
Chipset Intel C610 series chipset
Memory1Up to 768GB (24 DIMM slots): 4GB/8GB/16GB/32GB DDR4 up to 2133MT/s
I/O slots Up to 3 x PCIe 3.0 slots plus dedicated PERC slot
RAID controllers
Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
External HBAs (RAID): PERC H830
External HBAs (non-RAID): 12Gbps SAS HBA
Drive bays
Internal hard drive bay and hot-plug backplane:
Up to 24 x 1.8” SATA SSD
Up to 10 x 2.5” HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, Up to 4 NVMe PCIe
Up to 8 x 2.5” HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
Maximum internal
storage1
HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, NVMe PCIe
24 x 1.8” SSD – up to 23TB via 0.96 TB hot-plug SATA SSD
10 x 2.5” – up to 18TB via 1.8TB hot-plug SAS HDD
8 x 2.5” – up to 14TB via 1.8TB hot-plug SAS HDD
Embedded NIC 4 x 1Gb, 2 x 1Gb + 2 x 10Gb, 4 x 10Gb
Power supplies Titanium eciency 750W AC power supply; 1100W DC power supply; Platinum eciency 495W, 750W, 1100W
Availability
ECC memory, hot-plug hard drives, hot-plug redundant cooling, hot-plug redundant power, internal dual SD
module, single device data correction (SDDC), spare rank, support for high availability clustering and virtualization,
proactive systems management alerts
Systems management
Systems management: IPMI 2.0 compliant;
Dell OpenManage Essentials; Dell OpenManage Mobile;
Dell OpenManage Power Center
Remote management iDRAC8 with Lifecycle Controller,
iDRAC8 Express (default), iDRAC8 Enterprise (upgrade)
8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
iDRAC Quick Sync
Dell OpenManage Integrations:
• Dell OpenManage Integration Suite for
Microsoft® System Center
• Dell OpenManage Integration for VMware®
vCenter™
Dell OpenManage Connections:
• HP Operations Manager, IBM Tivoli® Netcool®
and CA Network and Systems Management
• Dell OpenManage Plug-in for Oracle® Database
Manager
Rack support ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled
mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm.
Operating systems
Microsoft Windows Server® 2008/2012 SP2, x86/x64 (x64
includes Hyper-V®)
Microsoft Windows Server 2008/2012 R2, x64 (includes
Hyper-V)
Microsoft Windows HPC Server 2008
Novell® SUSE® Linux Enterprise Server
Red Hat® Enterprise Linux
Optional embedded hypervisors:
Citrix® XenServer®
VMware vSphere® ESXi™
For more information on the specic versions and
additions, visit Dell.com/OSsupport.
OEM-ready version
available
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For
more information, visit Dell.com/OEM.
Recommended
support
Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your
PowerEdge solution. Consulting and deployment oerings are also available. Contact your Dell representative
today for more information. Availability and terms of Dell Services vary by region. For more information, visit
Dell.com/ServiceDescriptions.
1 GB equals 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
End-to-end technology solutions
Reduce IT complexity, lower costs and eliminate ineciencies by making IT and business solutions work harder for you.
You can count on Dell for end-to-end solutions to maximize your performance and uptime. A proven leader in Servers,
Storage and Networking, Dell Enterprise Solutions and Services deliver innovation at any scale. And if you’re looking to
preserve cash or increase operational eciency, Dell Financial Services™ has a wide range of options to make technology
acquisition easy and aordable. Contact your Dell Sales Representative for more information.**
©2014 Dell Inc. All rights reserved. Dell, the DELL logo, the DELL badge, PowerEdge, and OpenManage are trademarks of Dell Inc. Other trademarks and trade
names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the
marks and names of others. This document is for informational purposes only. Dell reserves the right to make changes without further notice to any products
herein. The content provided is as is and without express or implied warranties of any kind. **Leasing and nancing provided and serviced by Dell Financial
Services L.L.C. or its aliate or designee (“DFS”) for qualied customers. Oers may not be available or may vary in certain countries. Where available, oers
may be changed without notice and are subject to product availability, credit approval, execution of documentation provided by and acceptable to DFS, and
may be subject to minimum transaction size. Oers not available for personal, family or household use. Dell and the DELL logo are trademarks of Dell Inc.
September 2014 | Version 1.0
