FREE TO AIR
Satellite Receiver
SRT-3000
1Year
Guarantee
》FREE TO AIR / SRT-3000
Fully DVB-S/MPEG-2 compliant
Max 5000 channels. 64 satellites memory space
6 Favorite channel groups
Input fequency 950-2150 MHz
Symbol Rate 2-45 MB/S
SCPC & MCPC received from C/Ku band satellites
Channel search type automatic manual, blind scan
256 colors on screen display (OSD)
PAL-NTSC auto-conversion system
Multi-language audio. Simple RF
DiSEqC 1.0/1.1/1.2, Voltage (14/18V), Tone (22KHz) and
0/12 LNB switching support (optional)
Multi-language OSD (English, Farsi, French, Arabic,
Portuguese, Russian)
Picture in graphic (PIG) support
Multi Channel Grid function
Timer function support automatic turn o
Easy and fast software upgrade through RS-232 port
between the receivers
Twin protocol (sssp)
Block B, Hytera Tech-Zone, 4th Baolong Road, Longgang,
Shenzhen, China P.C.: 518116
www.x2sat.com / http://x-square-tech.en.alibaba.com
Cell：+86-138 2528 3505 ／ E-mail: square.yuan@yahoo.com
》FREE TO AIR / SRT-3000 SPECIFICATION
General information
- Free to Air , Auto Scan/TP Scan/ Blind Scan
- High Speed searching program
- Receiving Standard Definition Satellite TV Channels and Radio channels
- Number of channels: MAX 5000 memory store
- EPG: up to 7-days based on SI information Physical Specification
- Teletext supported, Support Favorites Group
- Energy saving, Standby mode less than 1W
- Multi-Languages Support, PAL & NTSC Auto conversion
- Software update over RS-232 Serial Port
Satellite Front-End
- Modulation: Fully Compliant with DVB-S (MPEG2)
- Input connector: F-connector LNB IN (KU/C BAND)
- Frequency range: 950-2150 MHz
- Symbol rate range: 2-45 Mbps
- Input level: - 25 to - 65 dBm
- LNB voltage: 13/18 V max 400 mA
- Tone control: 22 KHZ
- LNB Control: DiSEqC 1.0/1.2
- KU/C Band Supported
Video Decoding & Audio Decoding
- Audio Channel: Mute, Left, Right and Stereo, Joint Stereo
- Audio Decoding: MPEG-1 & MPEG-2 layer I and II
- Video Resolution: Standard Definition
Rear panel Interfaces Input connector
- Satellite IF Input : F-type (LNB IN)
- 2 x Audio L/R (RCA)
- 1 x Video Signal (RCA)
- 1 x RS-232 (9-pin D-sub male)
- Power Button
Front & Upper panel Interfaces
- Standby, Menu, Ok, Volume up/down
- Channel up/down and menu navigation keys
- 4-character LED digits display
- 1 Standby LED Indicator
- 1 Signal LED Indicator
- IR Sensor
Power Requirements
- Mains input voltage: 100V~240v
- Mains input frequency: 50 / 60 Hz
- Power consumption: Typ.: 12W MAX
Physical Specification
- Operating temperature: +5°C to +45°C
- Storage temperature: -20°C to +65°C
ACCESSORIES RCA Cable 3 v 3 RCU
Size (L x W x H): 260 x 200 x 58 mm
