eIDAS-Node Migration Guide
Version 2.1
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 2 of 13
Document history
Version
Date
Modification reason
Modified by
1.4
Pre
release
31/08/2017
Origination
DIGIT
1.4
Official
release
06/10/2017
Minor update to section 3.7
DIGIT
2.0
27/03/2018
New document for software version
2.0.0, please see content
DIGIT
2.1
12/07/2018
New document for software version
2.1, please see contents
DIGIT
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 3 of 13
Disclaimer
This document is for informational purposes only and the Commission cannot be held
responsible for any use which may be made of the information contained therein.
References to legal acts or documentation of the European Union (EU) cannot be
perceived as amending legislation in force or other EU documentation.
The document contains information of a technical nature and does not supplement or
amend the terms and conditions of any procurement procedure; therefore, no
compensation claim can be based on the contents of this document.
© European Union, 2018
Reuse of this document is authorised provided the source is acknowledged. The Commission's reuse policy is
implemented by Commission Decision 2011/833/EU of 12 December 2011 on the reuse of Commission
documents.
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 4 of 13
Table of contents
DOCUMENT HISTORY ....................................................................................... 2
TABLE OF CONTENTS ....................................................................................... 4
1. INTRODUCTION ........................................................................................ 5
1.1. Document structure .......................................................................... 5
1.2. Document aims ................................................................................ 5
2. PREREQUISITES ....................................................................................... 6
3. CHANGES ................................................................................................ 7
3.1. Summary of changes ........................................................................ 7
3.2. Remove xsi:type from LOA's metadata's attribute value ........................ 7
3.2.1. Code changes ....................................................................... 7
3.2.2. Configuration changes ........................................................... 7
3.3. Use of SingleSignOnService instead of hardcoded URLs ......................... 7
3.3.1. Code changes ....................................................................... 7
3.3.2. Configuration changes ........................................................... 8
3.4. Usage of simple DSI keys in SAML messages ....................................... 8
3.4.1. Code changes ....................................................................... 8
3.4.2. Configuration changes ........................................................... 9
3.5. eIDAS protocol versioning ................................................................. 9
3.5.1. Code changes ....................................................................... 9
3.5.2. Configuration changes ........................................................... 9
3.6. Change in Gender allowed values ...................................................... 10
3.6.1. Code changes ...................................................................... 10
3.6.2. Configuration changes .......................................................... 10
3.7. Check of metadata signing certificate against a Trust Chain .................. 10
3.7.1. Code changes ...................................................................... 10
3.7.2. Configuration changes .......................................................... 11
3.8. Corrected reference key name related to TLS cipher suites ................... 12
3.8.1. Configuration changes .......................................................... 12
3.9. Other fixes/improvements requiring no action ..................................... 12
3.9.1. Build separation between Demo and Node modules .................. 12
3.9.2. Increase the preference of the relevant configurer using the
order property ..................................................................... 12
3.9.3. eIDAS flow with JavaScript off ............................................... 12
3.9.4. Update copyright headers and remove authorship .................... 12
3.9.5. Implemented CRLF protection for audit logs. Small correction in
comment in external config file .............................................. 13
3.9.6. Change of error code/message when metadata cannot be read.. 13
3.9.7. Change the order of validation when processing the SP request . 13
3.9.8. Fix Junit failing tests due to validUntil in the past ..................... 13
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 5 of 13
1. Introduction
This document is intended for a technical audience consisting of developers,
administrators and those requiring detailed technical information on how to configure,
build and deploy the eIDAS-Node application.
The purpose of this document is to facilitate migration from eIDAS-Node v2.0 to eIDAS-
Node v2.1.
1.1. Document structure
This document is divided into the following sections:
Chapter 1 Introduction: this section.
Chapter 2 Prerequisites: Identifies any prerequisites that are required before
migrating your eIDAS-Node to version 2.1.
Chapter 3 Changes: Contains detailed information about the changes that
should be taken into consideration when migrating to eIDAS-Node version 2.1.
1.2. Document aims
The main aim of this document is to provide information on all the changes requiring
your action when migrating to eIDAS-Node version 2.1, including:
configuration changes; and
changes to code.
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 6 of 13
2. Prerequisites
Before starting your migration to eIDAS-Node version 2.1 you should have:
already implemented eIDAS-Node version 2.0;
downloaded the eIDAS-Node v2.1 Integration Package; and
downloaded the latest documentation.
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 7 of 13
3. Changes
3.1. Summary of changes
In eIDAS-Node version 2.1 there are several changes that affect your implementation.
The main changes are:
Remove xsi:type from LOA's metadata's attribute value(see section Error!
Reference source not found.);
Use of SingleSignOnService instead of hardcoded URLs (see section Error!
Reference source not found.);
Implement usage of simple DSI keys in SAML messages
For other fixes and improvements requiring no action, please see section 3.9.
3.2. Remove xsi:type from LOA's metadata's attribute value
Removed xsi:type from LOA's metadata's attribute value when the parameter
metadata.hide.loatype from eidas.xml is set to true.
Code changes
Methods setHideLoaType, isHideLoaType have been added to Interface
EidasMetadataParametersI.
Field hideLoaType has been added to class EidasMetadataParameters.
Field hideLoaType has been added to class EidasMetadata.
The field EIDAS_METADATA_HIDE_LOA("metadata.hide.loatype") has been added to
EIDASValues enum.
Configuration changes
The following entry has been added to eidas.xml
metadata.hide.loatype
3.3. Use of SingleSignOnService instead of hardcoded URLs
This has changed the behaviour of the Connector to always go to the URL fetched from
SingleSignOnService.
Code changes
In EidasNodeValidationUtil, new methods have been introduced that perform the
validation of the url from metadata against a hard coded list specified in eidas.xml.
In AUCONNECTORSAML, url is read from metadata instead of eidas.xml.
In EIDASValues, new fields were introduced:
EIDAS_CONNECTOR_REDIRECT_URIDEST("connector.url.redirect.location.whitelist"),
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 8 of 13
EIDAS_CONNECTOR_POST_URIDEST("connector.url.post.location.whitelist").
Configuration changes
Removal of entries from eidas.xml:
servicex.url
New entries in eidas.xml:
connector.url.redirect.location.whitelist
connector.url.post.location.whitelist
3.4. Usage of simple DSI keys in SAML messages
Added the option to the eidas-node to sign the (and conversely verify the signature on)
Authentication Request with a simple public RSAKey instead of the full X509Certificate.
See EID-570.
Code changes
EIDAS-SAMLEngine SignatureKey.java
EIDAS-SAMLEngine KeyStoreSignatureConfigurator.java
EIDAS-SAMLEngine SignatureConfiguration.java
Added required logic and variables to make effective the configuration flags
request.sign.with.key.value, response.sign.with.key.value
EIDAS-SAMLEngine ProtocolSignerI.java
EIDAS-SAMLEngine AbstractProtocolSigner.java
Overloaded the existing
T sign(@Nonnull T signableObject) throws EIDASSAMLEngineException;
With
T sign(@Nonnull T signableObject, boolean onlyKeyInfoNoCert) throws
EIDASSAMLEngineException;
Added getter for the newly added flag of this feature
boolean isRequestSignWithKey();
boolean isResponseSignWithKey();
Added utility method to retrieve X509SecurityCerificate based on the incoming
RSAKeyValue
X509Credential getTrustedCertificateFromRSAKeyValue(RSAKeyValue
signatureRsaKeyValue) throws SecurityException, EIDASSAMLEngineException;
EIDAS-SAMLEngine ProtocolEngine.java
EIDAS-SAMLEngine AbstractProtocolEngine.java
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 9 of 13
Modified signing and verifying the signature of the Authentication request to implement
the feature protected AuthnRequest signRequest(@Nonnull AuthnRequest request)
throws EIDASSAMLEngineException
public IAuthenticationRequest unmarshallRequestAndValidate(@Nonnull byte[]
requestBytes, @Nonnull String citizenCountryCode)
EIDAS-Encryption CertificateUtil.java
overloaded the existing
public static String getCountry(KeyInfo keyInfo) with versions accepting
X509Cetificate as parameter.
Configuration changes
New entries in eidas.xml:
request.sign.with.key.value set to true to have the eidas-node sign
Authentication Requests it's originating , with the simple public RSAKey, as
opposed to incorporating the full X509Certificate in the signature
response.sign.with.key.value set to true to have the eidas-node sign
Authentication Responses it's originating , with the simple public RSAKey, as
opposed to incorporating the full X509Certificate in the signature
3.5. eIDAS protocol versioning
In order to facilitate interoperability between different implementations of eIDAS-Nodes,
the eIDAS-Node deployment version (aka. protocol versioning) was implemented. This
implementation follows the definition in draft 1.6 of eIDAS message format 1.2. These
values will appear in the eIDAS node’s metadata.
Code changes
The interface EidasMetadataParametersI was modified, setters and getters related to
protocol version and application identifier. EidasNodeMetadataGenerator was also
modified to retrieve the mentioned entries from the Node Properties. The generation of
EntityAttributes was also refactored and the code grouped inside method
generateEntityAttributes.
Also in EidasMetadata, the code inside method generateExtensions was refactored:
methods were created to contain the generation of child elements of Extensions element.
Examples of newly added methods are: generateSigningMethods, generateSpType.
Configuration changes
Two new entries were introduced in eidas.xml:
<entry key="eidas.protocol.version">1.1</entry>
<entry key="eidas.application.identifier">CEF:eIDAS-ref:2.1</entry>
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 10 of 13
These properties allow configuring the values of protocol version and application
identifier, which will be displayed in the eIDAS Node's metadata.
When none of these entries is present, none of the XML elements related to eidas
deployment versioning (AKA protocol versioning) will be displayed in the eIDAS Node's
Metadata.
3.6. Change in Gender allowed values
In version 2.0 a bug prevented to set the gender other that Male or Female. Therefore,
neither values mentioned in the specification: "Unspecified" or " Not Specified" were
possible. This issue was fixed.
At the present, the possible values for Gender were clarified in the eIDAS specifications
meetings and only "Male", "Female" and "Unspecified" are possible values. However, to
prevent interoperability issues the change regarding Gender was done to allow also "Not
Specified".
Code changes
To allow the "Not Specified" value for gender, the Gender class was changed and " Not
Specified" constant was added and the PATTERN_GENDER_EIDAS in
EidasAttributeValidator class was adjusted. Schema files saml_eidas_natural_person.xsd
and saml_eidas_representative_natural_person.xsd were also modified to allow this
value.
Configuration changes
The file user.properties was changed and a new user genderu was added to test sending
the "Unspecified" value.
3.7. Check of metadata signing certificate against a Trust Chain
The possibility to check a certificate against its trust chain was implemented. It is now
possible to check the validity of the signed metadata using a certificate that belongs to
the trust chain of the certificate that related to the key that signs the metadata. This
change was done taking also in consideration compatibility with version 1.4.1 of the
eIDAS Node.
Code changes
CertificateUtil was modified; the ExplicitKeyTrustEvaluator was replaced by the
CertPathPKIXTrustEvaluator in the validation of the signing credential to allow validation
with other certificates in the chain. Also method toCertificate(@Nonnull KeyInfo keyInfo)
was changed so that, the signing certificate is assumed is the first appearing inside the
KeyInfo element. The order how certificates in the chain are published was changed so
that the one that relates to the signing key certificate is the first followed by his signer,
etc., until it reaches the root of the chain. This was done to allow interoperability with
1.4.1 versions.
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 11 of 13
In the SignatureConfiguration class the signature of the constructor changed and
ImmutableSet<X509Certificate> metadataKeystoreCertificates was introduced as a
parameter. This parameter contains all the metadata certificates contained in the
kesytore related to the metadata signature functionality. Related to this change, the
corresponding getter was added, getMetadataKeystoreCertificates, and the hashCode and
toString was also adjusted.
The KeyStoreSignatureConfigurator class was updated due to the changes in the
SignatureConfiguration. Also, a new method was added so that the certificates from a
keystore can be retrieved as an ImmutableSet<X509Certificate>.
The AbstractProtocolSigner constructors were also modified and the
ImmutableSet<X509Certificate> metadataKeystoreCertificates parameter was added.
The metadata signing credentials are now set with its certificate chain. The order is
reversed so that it allows compatibility with 1.4.1 version.
In the AbstractProtocolSigner, a new method of checkValidTrust was introduced that
depending on the certificate chain of the signature consumed, and on the existence of
the metadata key signing certificate as a trusted entry, performs validation using the
ExplicitKeyTrustEvaluator or performs validation of trust chain using
CertPathPKIXTrustEvaluator. New methods of hasLeaf and getIssuerX509Certificate were
also added to check the existence of the signing certificate as trusted and for retrieving
the issuer certificate from the trusted entries.
New classes TestEidasNodeMetadataTrustChain and
TestEidasNodeFileMetadataProcessorTrustChain were created that contain test cases
related to trust chain possibilities.
Configuration changes
With the introduction of the trust chain support, it is necessary to have specific
configuration for metadata. Therefore, the configuration related to the keystores in both
SignModule_Connector.xml and SignModule_Service.xml need from now on to have the
"metadata." entries defined. So that it references a specific keystore for metadata
signing and trust chain publishing purposes only. A possible configuration is:
<entry
key="metadata.keyStorePath">../keystore/eidasKeyStore_METADATA_TC.jks</en
try>
<entry key="metadata.keyStorePassword">local-demo</entry>
<entry key="metadata.keyPassword">local-demo</entry>
<entry key="metadata.issuer">CN=metadataNode, OU=Node, O=eIDAS,
L=Brussels, ST=BRUSSELS, C=EU</entry>
<entry key="metadata.serialNumber">89e1841a35e10504</entry>
<entry key="metadata.keyStoreType">JKS</entry>
The keystore referred, in the example above, eidasKeyStore_METADATA_TC.jks must
contain the private key that will be used to sign the metadata and all the certificates that
compose its trust chain up to the root certificate or the sub ca that is intended to be
trusted. The new provided demo keystore eidasKeyStore_METADATA_TC.jks, contains
two trusted entries (alias intermediatecametadata and rootcametadata), and the private
key entry that signs the metadata (alias metadatanode).
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 12 of 13
Note that this keystore will be used to get the metadata signing key and to retrieve the
certificates to be published at the Connector and Proxy-Service metadata. Adding an
extra non-related certificate will be published in the eIDAS Metadata URLs. This will give
a wrong impression to the party that consumes the metadata, that it can trust that
certificate. However, in the current version, the certification path will be validated. So
trusting a certificate outside the trust chain, even if published, will result in error.
To validate the metadata signed with the above trust chain, it will be necessary to add as
trusted entry one of the certificates that compose the trust chain. Taking as example
eidasKeyStore_METADATA_TC.jks, one of certificates with alias rootcametadata,
intermediatecametadata or metadatanode will need to be imported into the keystore
used to trust/validate the metadata. In the provided configuration it will be the
eidasKeyStore.jks.
3.8. Corrected reference key name related to TLS cipher suites
The key name in the EIDAS-Config/eidas.xml was corrected from
tls.enabled.cipher.suites to tls.enabled.ciphers, which was used in the code and
mentioned in other documenters e.g. eIDAS-Node Installation and Configuration Guide.
Configuration changes
If you used tls.enabled.cipher.suites in eidas.xml you will need to replace that key name
by tls.enabled.ciphers.
3.9. Other fixes/improvements requiring no action
Build separation between Demo and Node modules
Added NodeOnly and DemoToolsOnly maven profile to EIDAS-Parent pom.xml to build
only the respective modules.
Increase the preference of the relevant configurer using the order
property
The Node applicationContext has some properties with default values. In order to make
these default values work we modified the order of the relevant configurer
placeholderConfig to a negative value at the applicationContext.xml.
<property name="order" value="-2147483648"/>
eIDAS flow with JavaScript off
Refactoring of js pages in order to make the eIDAS flow to work with Javascript turn off.
eIDAS-Node Migration Guide Version 2.1
Copyright European Commission DIGIT Page 13 of 13
Update copyright headers and remove authorship
File types affected: java, xml, jsp, properties, and javascript js.
Implemented CRLF protection for audit logs. Small correction in
comment in external config file
LoggingSanitizer was implemented that contains removeCRLFInjection method to
prevent CRLF injection. This method is executed in AUCONNECTORSAML.java and
AUCONNECTORSAML.java for some fields that are external to the node and are sent to logs
potentially containing CRLF injection.
Change of error code/message when metadata cannot be read
Change done in AUCONNECTORSAML.java to use SAML_ENGINE_NO_METADATA instead
of SPROVIDER_SELECTOR_INVALID_SAML when metadata can not be read.
Change the order of validation when processing the SP request
Moved the validation of country code before the validation of metadata url when
processing the SP request by the Node's connector in AUCONNECTORSAML.
Fix Junit failing tests due to validUntil in the past
Updated ed.xml file used by Junit tests, containing metadata. The validUntil attribute was
updated so it is now in the Future and does not fail validity on this value.

Navigation menu
