NITRO API

Citrix NetScaler SDX - NITRO Python -

Getting Started Guide

Citrix® NetScaler® SDX 10.5

OR TRANSMITTED IN ANY FORM OR BY ANY MEANS OR USED TO MAKE DERIVATIVE WORK (SUCH AS

TRANSLATION, TRANSFORMATION, OR ADAPTATION) WITHOUT THE EXPRESS WRITTEN PERMISSION OF

CITRIX SYSTEMS, INC.

ALTHOUGH THE MATERIAL PRESENTED IN THIS DOCUMENT IS BELIEVED TO BE ACCURATE, IT IS

PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE ALL

RESPONSIBILITY FOR THE USE OR APPLICATION OF THE PRODUCT(S) DESCRIBED IN THIS MANUAL.

CITRIX SYSTEMS, INC. OR ITS SUPPLIERS DO NOT ASSUME ANY LIABILITY THAT MAY OCCUR DUE TO THE

USE OR APPLICATION OF THE PRODUCT(S) DESCRIBED IN THIS DOCUMENT. In no event shall Citrix, its agents,

officers, employees, licensees or affiliates be liable for any damages whatsoever (including, without limitation, damages

for loss of profits, business information, loss of information) arising out of the information or statements contained in the

publication, even if Citrix has been advised of the possibility of such loss or damages. INFORMATION IN THIS

DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. COMPANIES, NAMES, AND DATA USED IN

EXAMPLES ARE FICTITIOUS UNLESS OTHERWISE NOTED.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his or her own expense.

Pursuant to the rules and regulations of the Federal Communications Commission, changes or modifications to this

product not expressly approved by Citrix Systems, Inc., could void your authority to operate the product. Note the FCC

rules and regulations are not included for software products, such as virtual appliances.

AppCache, AppCompress, AppDNA, App-DNA, AppFlow, AppScaler, Apptitude, Citrix, Citrix Access Gateway, Citrix

Application Firewall, Citrix Cloud Center, Citrix Systems, Citrix XenApp, CloudGateway, CloudBridge, CloudPortal,

CloudStack, EdgeSight, Flex Tenancy, HDX, ICA, MPX, nCore, NetScaler, NetScaler App Delivery Controller, NetScaler

Access Gateway, NetScaler App Firewall, NetScaler CloudConnector, NetScaler Gateway, NetScaler SDX, Netviewer,

Network Link, SecureICA, VMLogix LabManager, VMLogix StageManager, VPX, Xen, Xen Source, XenApp,

XenAppliance, XenCenter, XenClient, XenDesktop, XenEnterprise, XenServer, XenSource, Xen Data Center, and

Zenprise are trademarks of Citrix Systems, Inc. and/or one of its subsidiaries, and may be registered in the U.S. Patent

and Trademark Office and other countries. Other product and company names mentioned herein may be trademarks of

their respective companies.

Last Updated: March 2014

Document code: June 15 2014 23:52:35

Contents

NITRO API................................................................................................5

Obtaining the NITRO Package................................................................5

How NITRO Works............................................................................ 6

API Categorization.............................................................................6

System APIs..............................................................................7

Configuration APIs........................................................................7

Exception Handling......................................................................11

iii

Contents

NITRO API

The Citrix NetScaler SDX NITRO protocol allows you to configure and monitor the

NetScaler SDX appliance programmatically.

NITRO exposes its functionality through Representational State Transfer (REST)

interfaces. Therefore, NITRO applications can be developed in any programming

language. Additionally, for applications that must be developed in Java or .NET or

Python, the NITRO protocol is exposed as relevant libraries that are packaged as

separate Software Development Kits (SDKs).

Note: You must have a basic understanding of the NetScaler SDX appliance before

using NITRO.

To use the NITRO protocol, the client application needs the following:

wAccess to a NetScaler SDX appliance.

wTo use REST interfaces, you must have a system to generate HTTP or HTTPS requests

(payload in JSON format) to the NetScaler SDX appliance. You can use any

programming language or tool.

wFor Java clients, you must have a system where Java Development Kit (JDK) 1.5 or

above version is available. The JDK can be downloaded from http://

www.oracle.com/technetwork/java/javase/downloads/index.html.

wFor .NET clients, you must have a system where .NET framework 3.5 or above

version is available. The .NET framework can be downloaded from http://

www.microsoft.com/downloads/en/default.aspx.

wFor Python clients, you must have a system where Python 2.7 or above version and

the Requests library (available in <NITRO_SDK_HOME>/lib) is installed.

Obtaining the NITRO Package

The NITRO package is available as a tar file on the Downloads page of the NetScaler

SDX appliance's configuration utility. You must download and un-tar the file to a folder

on your local system. This folder is referred to as <NITRO_SDK_HOME> in this

documentation.

The folder contains the NITRO libraries in the lib subfolder. The libraries must be

added to the client application classpath to access NITRO functionality. The

<NITRO_SDK_HOME> folder also provides samples and documentation that can help

you understand the NITRO SDK.

Note:

wThe REST package contains only documentation for using the REST interfaces.

wFor the Python SDK, the library must be installed on the client path. For

installation instructions, read the <NITRO_SDK_HOME>/README.txt file.

How NITRO Works

The NITRO infrastructure consists of a client application and the NITRO Web service

running on a NetScaler appliance. The communication between the client application

and the NITRO web service is based on REST architecture using HTTP or HTTPS.

Figure 1-1. NITRO execution flow

As shown in the above figure, a NITRO request is executed as follows:

1. The client application sends REST request message to the NITRO web service.

When using the SDKs, an API call is translated into the appropriate REST request

message.

2. The web service processes the REST request message.

3. The NITRO web service returns the corresponding REST response message to the

client application. When using the SDKs, the REST response message is translated

into the appropriate response for the API call.

To minimize traffic on the network, you retrieve the whole state of a resource from the

server, make modifications to the state of the resource locally, and then upload it back

to the server in one network transaction.

Note: Local operations on a resource (changing its properties) do not affect its state

on the server until the state of the object is explicitly uploaded.

NITRO APIs are synchronous in nature. This means that the client application waits for

a response from the NITRO web service before executing another NITRO API.

API Categorization

NetScaler SDX NITRO APIs are categorized depending on the scope and purpose of the

APIs into system APIs and configuration APIs. You can also troubleshoot NITRO

operations.

NITRO API

System APIs

The first step towards using NITRO is to establish a session with the NetScaler SDX

appliance and then authenticate the session by using the administrator's credentials.

You must create an object of the nitro_service class by specifying the IP address of

the appliance and the protocol to connect to the appliance (HTTP or HTTPS). You then

use this object and log on to the appliance by specifying the user name and the

password of the administrator.

Note: You must have a user account on that appliance. The configuration operations

that you can perform are limited by the administrative role assigned to your account.

The following sample code connects to a NetScaler SDX appliance with IP address

10.102.31.16 by using HTTPS protocol:

# Specify the IP address of the appliance and service type

nitroservice = nitro_service ("10.102.31.16", "https")

# Specify the login credentials

nitroservice.login("nsroot", "verysecret")

Note: You must use the nitro_service object in all further NITRO operations on

the appliance.

To disconnect from the appliance, invoke the logout() method as follows:

nitroservice.logout()

Configuration APIs

The NITRO protocol can be used to configure resources of the NetScaler SDX appliance.

The APIs to configure a resource are grouped into packages or namespaces that have

the format

sdxsrc.com.citrix.sdx.nitro.resource.config.<resource_type>. Each of

these packages or namespaces contain a class named <resource_type> that provides

the APIs to configure the resource.

For example, the NetScaler resource has the

sdxsrc.com.citrix.sdx.nitro.resource.config.ns package or namespace.

A resource class provides APIs to perform other operations such as creating a resource,

retrieving resource details and statistics, updating a resource, deleting resources, and

performing bulk operations on resources.

Creating a Resource

Citrix NetScaler SDX - NITRO Python - Getting Started Guide

To create a new resource (for example, a NetScaler instance) on the NetScaler SDX

appliance, do the following:

1. Set the value for the required properties of the resource by using the

corresponding property name. The result is a resource object that contains the

details required for the resource.

Note: These values are set locally on the client. The values are not reflected on

the appliance till the object is uploaded.

2. Upload the resource object to the appliance, using the static add() method.

The following sample code creates a NetScaler instance named "ns_instance" on the

NetScaler SDX appliance:

newns = ns()

# Set the properties of the NetScaler locally

newns.name = "ns_instance"

newns.ip_address = "10.70.136.5"

newns.netmask = "255.255.255.0"

newns.gateway = "10.70.136.1"

newns.image_name = "nsvpx-9.3.45_nc.xva"

newns.profile_name = "ns_nsroot_profile"

newns.vm_memory_total = 2048.0

newns.throughput = 1000.0

newns.pps = 1000000.0

newns.license = "Standard"

newns.username = "admin"

newns.password = "admin"

# Here number_of_interfaces we have considered is 2

interface_array=[]

interface_array = [network_interface() for _ in range(2)]

# Adding 10/1

interface_array[0].port_name = "10/1"

# Adding 10/2

interface_array[1].port_name = "10/2"

newns.network_interfaces = interface_array

# Upload the NetScaler instance

result = ns.add(nitroservice, newns)

Retrieving Resource Details

To retrieve the properties of a resource on the NetScaler SDX appliance, do the

following:

1. Retrieve the configurations from the appliance by using the get() method. The

result is a resource object.

2. Extract the required property from the object by using the corresponding property

name.

NITRO API

The following sample code retrieves the details of all NetScaler resources:

# Retrieve the resource object from the NetScaler SDX appliance

returned_ns = ns.get(nitroservice)

# Extract the properties of the resource from the object

for i in range(0,len(returned_ns)):

print returned_ns[i].ip_address

print returned_ns[i].netmask

Retrieving Resource Statistics

A NetScaler SDX appliance collects statistics on the usage of its features. You can

retrieve these statistics using NITRO.

The following sample code retrieves statistics of a NetScaler instance with ID 123456a:

obj = ns()

obj.id = "123456a"

stats = ns.get(nitroservice, obj)

print "CPU Usage:" + stats.ns_cpu_usage

print "Memory Usage:" + stats.ns_memory_usage

print "Request rate/sec:" +stats.http_req

Updating a Resource

To update the properties of an existing resource on the appliance, do the following:

1. Set the id property to the ID of the resource to be updated.

2. Set the value for the required properties of the resource by using the

corresponding property name. The result is a resource object.

Note: These values are set locally on the client. The values are not reflected on

the appliance till the object is uploaded.

3. Upload the resource object to the appliance, using the update() method.

The following sample code updates the name of the NetScaler instance with ID 123456a

to 'ns_instance_new':

update_obj = ns()

# Set the ID of the NetScaler to be updated

update_obj.id = "123456a"

# Get existing NetScaler details

update_obj = ns.get(nitroservice, update_obj)

# Update the name of the NetScaler to "ns_instance_new" locally

update_obj.name = "ns_instance_new"

# Upload the updated NetScaler details

result = ns.update(nitroservice, update_obj)

Citrix NetScaler SDX - NITRO Python - Getting Started Guide

Deleting a Resource

To delete an existing resource, invoke the static method delete() on the resource

class, by passing the ID of the resource to be removed, as an argument.

The following sample code deletes a NetScaler instance with ID 1:

obj = ns()

obj.id = "123456a"

ns.delete(nitroservice, obj)

Bulk Operations

You can query or change multiple resources simultaneously and thus minimize network

traffic. For example, you can add multiple NetScaler appliances in the same operation.

Each resource class has methods that take an array of resources for adding, updating,

and removing resources. To perform a bulk operation, specify the details of each

operation locally and then send the details at one time to the server.

To account for the failure of some operations within the bulk operation, NITRO allows

you to configure one of the following behaviors:

wExit. When the first error is encountered, the execution stops. The commands that

were executed before the error are committed.

wContinue. All the commands in the list are executed even if some commands fail.

Note: You must configure the required behavior while establishing a connection with

the appliance, by setting the onerror param in the nitro_service() method.

The following sample code adds two NetScalers in one operation:

newns=[]

newns = [ns() for _ in range(2)]

# Specify details of first NetScaler

newns[0].name = "ns_instance1"

newns[0].ip_address = "10.70.136.5"

newns[0].netmask = "255.255.255.0"

newns[0].gateway = "10.70.136.1"

# Specify details of second NetScaler

newns[1].name = "ns_instance2"

newns[1].ip_address = "10.70.136.8"

newns[1].netmask = "255.255.255.0"

newns[1].gateway = "10.70.136.1"

# Upload the details of the NetScalers to the NITRO server

result = ns.add(nitroservice, newns)

NITRO API

Exception Handling

The errorcode field indicates the status of the operation.

wAn errorcode of 0 indicates that the operation is successful.

wA non-zero errorcode indicates an error in processing the NITRO request.

The error message field provides a brief explanation and the nature of the failure.

All exceptions in the execution of NITRO APIs are caught by the

sdxsrc.com.citrix.sdx.nitro.exception.nitro_exception class. To get

information about the exception, you can use the getErrorCode() method.

For a more detailed description of the error codes, see the API reference available in

the <NITRO_SDK_HOME>/doc folder.

Citrix NetScaler SDX - NITRO Python - Getting Started Guide

Getting Started Guide Python

Navigation menu

Versions of this User Manual:

Views

Navigation
