HomeLinkTM Phoneline
10M Ethernet Bridge
he Linksys HomeLink Phoneline 10M Ethernet
Bridge offers a complete Internet connection solu-
tion for your phoneline network. The HomeLink 10M
Bridge makes sharing your broadband access easier than
ever. This unique new device features a
10BaseT/100BaseTX RJ-45 Ethernet port, an Uplink port,
and a HomeLink RJ-11 port. Plug in your cable modem or
DSL modem’s 10BaseT connection, then attach your
Bridge to the nearest telephone jack using standard
phone cables,and any PC on your phoneline network will
be able to access the Internet.
Do you want to share your cable or DSL modem on your
10/100 Ethernet network? You can add a PC at any time
by connecting it to any telephone jack in your wall—or
you can uplink an entire 10/100 Ethernet network for
instant communication. The groundbreaking technology
inside every HomeLink Bridge delivers communication
between home phoneline networks and Ethernet net-
works. With your HomeLink 10M Ethernet Bridge, that
means instant Internet sharing across both networks at
blazing broadband speeds.
• Share High-Speed Internet Access On Your
Network Using Your Existing Telephone Line
• Share a Cable Modem or DSL Service Without
Disrupting Normal Telephone Service
• Seamlessly Integrates a 10/100 Ethernet
Network with a Phoneline Network
• Stand-alone Device with a 10BaseT/
100BaseTX RJ-45 Port, a Shared Uplink Port
and a RJ-11 Telephone Port
• Bridges a Cable Modem or DSL Connection to
Your Home Phoneline 1Mbps or 10Mbps
Connection
• Fully HomePNA 1.0 and 2.0-Compatible
• Easy Installation—No Software Required
• Free Technical Support—24 Hours a Day,
7 Days a Week for North America Only
• 1-Year Limited Warranty
• Perfect For Sharing a Broadband Internet
Device Across a Home Phoneline
Network
• Stand-Alone Unit Attaches Directly to
Broadband Modem and Home Phoneline
Network for Seamless Integration
• Bridges a Cable Modem or DSL
Connection to a Home Phoneline 1Mbps or
10Mbps Connection
• Fully HomePNA 1.0 and 2.0-Compatible
• Free Technical Support—24 Hours a Day,
7 Days a Week for North America Only
• 1-Year Limited Warranty
HHoommeeLLiinnkk™™ PPhhoonneelliinnee 1100MM EEtthheerrnneett BBrriiddggee
((HHPPBB220000))
T
Bringing Broadband to Your HomePNA
and Ethernet Networks
Features
Features
Benefits
Benefits
Package Contents
Specifications
Model Number: HPB200
Standards: IEEE 802.3, IEEE 802.3u,
HPNA 1.0, 1.1,and 2.0
Protocol: CSMA/CD
Ports: One RJ-11 Standard Telephone Port,
One 10BaseT/100BaseTx RJ-45 Port,
One Shared Uplink Port
Cabling Type: Phoneline: Standard Telephone Cable
10BaseT: UTP Category 3 or better
100BaseTx: UTP Category 5 or better
Topology: Star or Daisy Chain
Speed (Mbps): Phoneline: 1 or 10
10BaseT: 10 or 20
100BaseTX: 100 or 200
LEDs: Power
Phoneline: Link,Tx, Rx
LAN: Link,Tx, Rx
Environmental
Dimensions: 7.31" x 6.16" x 1.88" (186mm x 154mm x 48mm)
Unit Weight: 12 oz. (0.34 kg)
Power Input: External, 5V DC, 3A
Certifications: FCC Class B, CE Mark Commercial
Operating Temp: 32°F to 122°F (0°C to 50°C)
Storage Temp: -4°F to 158°F (-20°C to 70°C)
Operating Humidity: 10% to 85% Non-condensing
Operating Humidity: 5% to 90% Non-condensing
HomeLink™ Phoneline 10M Ethernet Bridge
• One HomeLink Phoneline 10M
Ethernet Bridge
• One AC Adapter and Power Cord
• One User Guide and Registration Card
Model Number: HPB200
