VMware HTML Console SDK

Programming Guide



For vSphere 5.5 and later (General Availability)

and vCloud Director (Tech Preview)



October2016



Page2



VMwareHTMLConsoleSDK

ProgrammingGuide

TableofContents

SupportedBrowsers(includingoniOSandAndroid)..........................................................4

StepsforusingtheHTMLConsoleSDKAPI.........................................................................4

Placingtheconsoleonawebpage...............................................................................................................................5



ConnectingtoaRemoteVM.............................................................................................................................................5



DisconnectandDestroy.....................................................................................................................................................6



ThefactorymethodoftheWMKS......................................................................................6

createWMKS()........................................................................................................................................................................6



CreateOptions........................................................................................................................................................................6



LikewebMKSembeddedinthevSpherewebclient,WMKSalsohasmultipleoptionsthatcanbe

usedtocontrolitsbehavior.HereisthecomparisonbetweentheSDKandwebMKSembeddedin

thevSpherewebclient:.......................................................................................................................................................6



rescale.........................................................................................................................................................................................6



position.......................................................................................................................................................................................7



changeResolution..................................................................................................................................................................7



audioEncodeType..................................................................................................................................................................7



useNativePixels.......................................................................................................................................................................7



useUnicodeKeyboardInput................................................................................................................................................7



useVNCHandshake................................................................................................................................................................7



sendProperMouseWheelDeltas.......................................................................................................................................7



reverseScrollY.........................................................................................................................................................................7



retryConnectionInterval....................................................................................................................................................8



ignoredRawKeyCodes..........................................................................................................................................................8



fixANSIEquivalentKeys.......................................................................................................................................................8



keyboardLayoutId.................................................................................................................................................................8



VCDProxyHandshakeVmxPath........................................................................................................................................9



HandlingWMKSEvents....................................................................................................10

ListofWMKSEvents........................................................................................................................................................10



connectionstatechange....................................................................................................................................................10



screensizechange................................................................................................................................................................10



fullscreenchange.................................................................................................................................................................10



error.........................................................................................................................................................................................10



Keyboardledschanged......................................................................................................................................................11



heartbeat................................................................................................................................................................................11



audio.........................................................................................................................................................................................11



copy...........................................................................................................................................................................................11



toggle.......................................................................................................................................................................................11



SettingHandlersforWMKSEvents...........................................................................................................................11



register()................................................................................................................................................................................11



unregister()...........................................................................................................................................................................12



GeneralAPIs.........................................................................................................................................................................12



getVersion()..........................................................................................................................................................................12



Page3



getConnectionState().......................................................................................................................................................12



Lifecycle‐relatedAPIs......................................................................................................................................................13



connect()................................................................................................................................................................................13



disconnect()..........................................................................................................................................................................13



destroy().................................................................................................................................................................................13



Display‐relatedAPIs.........................................................................................................................................................13



setRemoteScreenSize()....................................................................................................................................................13



getRemoteScreenSize()...................................................................................................................................................14



updateScreen()....................................................................................................................................................................14



Full‐screen‐relatedAPIs.................................................................................................................................................14



canFullScreen()...................................................................................................................................................................14



isFullScreen().......................................................................................................................................................................15



enterFullScreen()...............................................................................................................................................................15



exitFullScreen()...................................................................................................................................................................15



Input‐relatedAPIs.............................................................................................................................................................15



sendInputString()...............................................................................................................................................................15



sendKeyCodes()...................................................................................................................................................................15



sendCAD()..............................................................................................................................................................................16



Mobile‐relatedAPIs..........................................................................................................................................................16



enableInputDevice().........................................................................................................................................................16



disableInputDevice()........................................................................................................................................................16



showKeyboard()..................................................................................................................................................................16



hideKeyboard()...................................................................................................................................................................16



toggleExtendedKeypad()................................................................................................................................................17



toggleTrackpad()...............................................................................................................................................................17



toggleRelativePad()..........................................................................................................................................................17



Option‐relatedAPIs..........................................................................................................................................................18



setOption().............................................................................................................................................................................18



Appendix................................................................................................................................................................................18



ConstantsusedinWMKS...............................................................................................................................................18







Page4



HTMLConsole(WMKS)SDK

Overview



TheHTMLConsoleSDKisaJavaScriptlibraryimplementedbasedonwebmks(WMKS),

which can provide mouse, keyboard, touch input processing and handling as well as

screenupdatesandcursorchangestoadesktopsessionfromabrowser.Applications

runninginthebrowsercanuseJavaScripttoaccessvirtualmachineconsolefunctions

byusingtheHTMLConsoleSDKAPI.



TheHTMLConsoleSDKAPIcontainsvariousmethodsthatcanbeused toconnectto

and communicate with a virtual machine. It also triggers eventstonotifyusersof

changestothevirtualmachine’sstate.Youcanusethesemethodsandcallbackstogive

enduserstheabilitytoremotelymanageavirtualmachinefromanysystemwiththe

appropriatewebbrowserandoperatingsystem.



SupportedBrowsers(includingoniOSandAndroid)

 InternetExplorer10+

 Firefox24+

 Chrome30+

 Safari6.1+



StepsforusingtheHTMLConsoleSDKAPI

To use the HTML Console SDK API, a web‐based application must typically do the

followingthings:



1. LoadtheHTMLConsoleSDKJavaScriptlibraryfiles.

2. CreatetheWMKScoreobjectbyusingthefactorymethodcreateWMKS()witha

givendivelementIDinthedocumentDOMandthecreateoptions.

3. RegisterJavaScriptcallbackstorespondtoWMKStriggeredEvents.

4. UsetheHTMLConsoleSDKconnect()methodtoconnecttoatarget virtual

machine.

5. Use the HTML Console SDK methods to interact with the connectedvirtual

machine.

6. UsetheHTMLConsoleSDKmethoddisconnect()todisconnecttheconnection(if



Page5



active)andremovethewidgetfromtheassociatedelement.

Placingtheconsoleonawebpage

The HTML Console SDK is available in the Downloads section of www.vmware.com:

DriversandToolsforvSphere,vCloudDirector,vRealizeAutomation,andvCloudAir.

A minified wmks.min.js and an un‐minified wmks.js are both provided in each build.

TheHTMLConsoleSDKusesjQuerywidgettodisplaytheVMconsole,andtherefore

thejQueryrelatedlibraryneedstobeincludedfirst.Hereisanexample:

1. Include jQuery and jQuery UI Javascript components in script tags, and the

correspondingjQuerycssfileinlinkstylesheettag.

2. Include wmks.js (or wmks.min.js) in a script tag, and the wmks‐all.css in link

stylesheettag.

3. Provideadivwithanappropriateid.

4. CreatetheWMKScoreobjectwithfactorymethodWMKS.createWMKS().

5. BindthecallbacksforWMKSevents.

6. ConnectwiththeappropriatedestinationURL.

ConnectingtoaRemoteVM

ThewaystoconnecttoaremoteVM:

WMKSisusableasacomponentindeliveringapureweb‐basedconsoleconnectionto

vCenterServer‐managedVMsbyusinganintermediaryproxytohandle the

authenticationrequirements.



ConnecttotheVMusingthefollowingmethod:



<linkrel="stylesheet"type="text/css"href="wmks‐all.css"/>



<scripttype="text/javascript"src="jquery‐1.8.3.min.js"></script>

<scripttype="text/javascript"src="jquery‐ui.1.8.16.min.js"></script>

<scripttype="text/javascript"src="wmks.js"type="text/javascript"></script>

<script>

 varwmks=WMKS.createWMKS("wmksContainer",{})

.register(WMKS.CONST.Events.CONNECTION_STATE_CHANGE,

function(event,data){

if(data.state==cons.ConnectionState.CONNECTED)

{

console.log("connectionstatechange:connected");

}

});

wmks.connect(“ws://127.0.0.1:8080”);

</script>

<divid=”wmksContainer”style=”position:absolute;width:100%;height:100%”></div>

wmks.connect(url);



Page6



TheURLshouldbeinthisscheme:



DisconnectandDestroy

CallthiswhenyouaredonewiththeWMKScomponent.DestroyingtheWMKSwillalso

resultinadisconnect(ifactive)andremovethewidgetfromtheassociatedelement.



ThefactorymethodoftheWMKS

createWMKS()

ThisshouldbethefirstmethodwhenyouusetheHTMLConsoleSDK.Usingthis

methodgeneratesthewidget,whichcandisplaytheremotescreen,andthenreturnthe

WMKScoreobjectwhichcanusealltheHTMLConsoleSDKAPIstoconnecttoaVMand

performoperations.



MethodcreateWMKS(id,options)

Parameter1id(string):theidofdivelement,thiselementwouldbethe

containerofcanvaswhichusedtoshowremotescreen.

Parameter2options:(jsonobject):createoptionswouldaffectthe

behavior of the WMKS. Empty means “use all the default

options.”

ReturnValueTheWMKScoreobject,whichcouldusealltheWMKSAPIto

connecttoaVMandperformoperations.

ExampleCallvarwmks=WMKS.createWMKS(“container”,{});



CreateOptions

Like webMKS embedded in the vSphere web client, WMKS also has multiple options

thatcanbeusedtocontrolitsbehavior.HereisthecomparisonbetweentheSDKand

webMKSembeddedinthevSpherewebclient:

rescale

Boolean:defaultistrue,andindicateswhethertorescaletheremotescreentofitthe

container'sallocatedsize.

<ws|wss>://<host:port>/<path>/?<authenticationinfo>



Page7



position

Anenum:couldbeanyvalueofWMKS.CONST.Position,defaultvalue is

WMKS.CONST.Position.CENTER.  It indicates which position (centerortopleft)the

remotescreenshouldbeinthecontainer.

changeResolution

Boolean:defaultistrue.WhentheoptionchangeResolutionistrue,WMKSwouldsend

thechangeresolutionrequesttotheconnectedVM,withtherequested resolution

(width&height)beingthesameasthecontainer'sallocatedsize.



Thesethreeoptionsfollowaspecificorderofprocedurebasedontheirpriority.



1. Check changeResolution,andiftrue,webmkswouldsendthechange

resolutionrequesttotheconnectedVM.

2. Iftherequestfails,theoperationsrescaleandpositioncanbeusedtomake

thecorrespondingchanges.



audioEncodeType

It'sanenum:couldbeanyvalueofWMKS.CONST.AudioEncodeType.Itindicateswhich

typeofaudioencodemethodisbeingused:vorbis,opusoraac.

useNativePixels

Boolean:defaultisfalse.Enablestheuseofnativepixelsizesonthedevice.OniPhone

4+oriPad3+,turningthisonwillenable"Retinamode",whichprovidesmorescreen

spacefortheguest,makingeverythingappearsmaller.

useUnicodeKeyboardInput

Boolean:defaultisfalse.Foralltheuserinput,WMKScouldsendtwokindsmessageto

server:keyboardscancodes,orUnicode.HeretruemeansclientshoulduseUnicodeif

possible.

useVNCHandshake

Boolean:defaultistrue.EnablesastandardVNChandshake.Thisshouldbeusedwhen

theendpointisusingstandardVNCauthentication.Settofalseifconnectingtoaproxy

thatauthenticatesthroughauthdanddoesnotperformaVNChandshake.

sendProperMouseWheelDeltas

Boolean:defaultisfalse.Previousversionsofthelibrarywouldnormalizemousewheel

eventdeltasintooneofthreevalues:[‐1,0,1].Whenthisissettotrue,theactualdeltas

fromthebrowseraresenttotheserver.

reverseScrollY

Boolean:defaultisfalse.Ifthisflagsettotrue,itwouldsendtheoppositevalueofthe

mousewheeltotheconnectedVM.



Page8



retryConnectionInterval

Integer:defaultvalueis‐1.Theinterval(inmilliseconds)forreattemptingtoconnect

whenthefirstattempttosetupaconnectionbetweenwebclient and server fails.  A

valuelessthan0means“won'tretry.”

ignoredRawKeyCodes

Array:defaultisempty.Allthesekeycodeswouldbeignoredandnotsendtotheserver.

fixANSIEquivalentKeys

Boolean:defaultisfalse.Enablesfixingofanynon‐ANSIUSlayoutskeyCodestomatch

ANSI US layout keyCodes equivalents. It attempts to fix any keys pressed where the

client's international keyboard layout has a key that is also present on the ANSI US

keyboard,butisinadifferentlocationordoesn'tmatchtheSHIFTorNOSHIFTstatusof

anANSIUSkeyboard.



keyboardLayoutId

String:defaultvalueis'en‐US’(U.S.English).Thisprovidesdifferentlanguagekeyboard

setupsfortheguest.Usersneedtodeterminewhatthekeyboardlayoutis,andkeepthe

remotedesktopandlocaldesktopkeyboardlayoutthesame.Inthisversionofthe

HTMLconsoleSDK,VMwaredoesnotsupportmobiledevices.There'retwokindsof

codesbeingsenttotheGuestOS.Whatwesupportforinternationalmappingis

vScancode.



InternetExplorer/Firefox/ChromearesupportedonWindows,andChrome/Safarion

Macaresupported.

Pleaseaddaselectlistinhtmlorusesomeotherwayforuserstochoosewhatlanguage

theyareusing.Injsfile,pleaseusesetOptionAPIasbelow:



<selectid="selectLanguage">

 <optionvalue="en‐US">English</option>

 <optionvalue="ja‐JP_106/109">Japanese</option>

 <optionvalue="de‐DE">German</option>

 <optionvalue="it‐IT">Italian</option>

<optionvalue="es‐ES">Spanish</option>

 <optionvalue="pt‐PT">Portuguese</option>

 <optionvalue="fr‐FR">French</option>

<optionvalue="fr‐CH">Swiss‐French</option>

<optionvalue="de‐CH">Swiss‐German</option>

</select>



Page9



VCDProxyHandshakeVmxPath

String:defaultvalueisnull.PasstotheVNCprotocolwhenconnecting.vncProtocol

willrespondtoaconnectionrequestforaVMXpathwiththeprovided

VCDProxyHandshakeVmxPathwhenconnectingtovCloudDirector.



enableUint8Utf8

Boolean:defaultvalueisfalse.Iftheprojectdoesnothaveworkingsupportforthe

binaryprotocol,theenableUint8Utf8optionisneededtoenabletheolduint8utf8

protocol.



$('#selectLanguage').change(function(){

if(!wmks)return;

varkeyboardLayoutId=$(this).find(":selected").val();

wmks.setOption('keyboardLayoutId',keyboardLayoutId);

});



Page10



HandlingWMKSEvents

ListofWMKSEvents

WebMKS generates events when the state of the currently connectedvirtualmachine

changes, or in response to messages from the currently connected virtual

machine.AlltheWMKSeventsarelistedinWMKS.CONST.Events.



Alltheeventhandlershavetwoparameters:eventanddata.EventisajQueryevent,

andalltheevents’specialparametersarestoredindata.

connectionstatechange

Theconnectionstatechangeeventisgeneratedinresponsetoachangeintheconnection

state,suchasfrom‘disconnected’to‘connecting’,from‘connecting’to‘connected’.



Parametersindata:

 state:couldbeanyvalueinWMKS.CONST.ConnectionStatecanbe:

1. "connecting"

2. "connected"

3. "disconnected"

 IfstateisWMKS.CONST.ConnectionState.CONNECTING,therearetwo more

parametersvvcandvvcSessionindata.

 If state is WMKS.CONST. ConnectionState. DISCONNECTED, there are two more

parametersreasonandcodeindata.

screensizechange

Thescreensizechangeeventisgeneratedinresponsetochangesinthescreensizeofthe

currentlyconnectedvirtualmachine.

Parametersindata:

 width:thewidth(inpixels)ofthecurrentlyconnectedvirtualmachine.

 Height:theHeight(inpixels)ofthecurrentlyconnectedvirtualmachine.

fullscreenchange

The fullscreenChange event is generated when the WMKS console exits or enters

fullscreenmode.

Parametersindata:

 isFullScreen:Boolean,truemeanenterfullscreen,falsemeansexitfullscreen.

error

The error event is generated when an error occurs, such as authentication failure,

websocketerrororprotocolerror.



Parametersindata:

 errorType:couldbeanyvalueinWMKS.CONST.Events.ERROR:

1. AUTHENTICATION_FAILED:"authenticationfailed",

2. WEBSOCKET_ERROR:"websocketerror",

3. PROTOCOL_ERROR:"protocolerror"



Page11



Keyboardledschanged

ThekeyboardledschangedeventisgeneratedwhentheremoteVM’skeyboardLEDlock

statechanges.



Parametersindata:

 Dataisaninteger:1meansScrollLock,2meansNumLock,4meansCapsLock.

heartbeat

Theheartbeateventisgeneratedwhenaserversideheartbeatmessageisreceived.

 Dataisanintegerthatindicatestheintervaloftheheartbeat.

audio

Theaudioeventisgeneratedwhenanaudiomessageisreceivedfromtheserver.

Parametersindata:

 sampleRate

 numChannels

 containerSize

 sampleSize

 length

 audioTimestampLo

 audioTimestampHi

 frameTimestampLo

 frameTimestampHi

 flags

 data

copy

Thecopyeventisgeneratedwhentheserversendsacuttextevent.

 Dataisthestringbeingcopied.

toggle

Thetoggleeventisgeneratedwhenshoworhidekeyboard,extendedkeyboardor

trackpad.

Parametersindata:

 type:couldbe“KEYBOARD”,"EXTENDED_KEYPAD","TRACKPAD"

 visibility:Boolean,truemean“show”,andfalsemeans“hide”.

SettingHandlersforWMKSEvents

InHTMLConsoleSDK,provideregister()andunregistermethodtoaddandremove

handlersforWMKSevents.

ThismethodusedtoregistereventhandlerfortheWMKS.



Method

(eventName,eventHandler)

Parameter1 eventName( Constant, any value of WebMKS.Events)

Parameter2 eventHandler( javascript callback function)

Return Value None

Example Call var connectionStateHandler = function(event, data){};

wmks.register(WebMKS.Events.CONNECTION_STATE_CHANGE,



Page12



connectionStateHandler);



unregister()

ThismethodisusedtounregistertheeventhandlerforWMKS.

Ifthismethodtakenoparameters,itwouldremovealltheeventhandlers.

If there is only one parameter, it would remove all the event handlers to that given

eventName.



Method

unregister

(eventName,eventHandler)

Parameter1 eventName(Constant,anyvalueofWebMKS.Events)

Parameter2 eventHandler( javascript callback function)

Return Value None

Example Call wmks.unregister(WebMKS.Events.CONNECTION_STATE_CHANGE,

connectionStateHandler);



MethodsoftheHTMLConsoleSDKObject



AfterinvokingthemethodcreateWMKS(),youwouldgetacoreWMKSobjectwhichcan

useWMKSAPItoconnecttoaVMandperformoperations.Inthis example, we will

nametheWMKSobject“wmks”.



GeneralAPIs

General‐purpose API methods provide information about WMKS. These methods can be

called at any time, including before you connect to target VM.

getVersion()

Retrieves the current version number of the HTMLConsoleSDK.

Method getVersion()

Parameters None

Return Value String. Contains the full version number of HTML Console SDK.

Example Call var version = wmks.getVersion();



getConnectionState()

Retrievesthecurrentconnectionstate.



Method getConnectionState()

Parameters None

Return Value Constant. Any value in WMKS. CONST.ConnectionState.

Example Call var state = wmks.getConnectionState();



Page13



Lifecycle‐relatedAPIs

connect()

ConnectstheWMKStoaremotevirtualmachinebytheWebSocketURL,andsetsupthe

UI.



Method connect()

Paramete

WebSocket URL, type is string in format:

Return Value none

Example Call wmks.connect(“ws://localhost:8080”);



disconnect()

DisconnectsfromtheremotevirtualmachineandteardowntheUI.



Method disconnect()

Paramete

None

Return Value None

Example Call wmks.disconnect();

destroy()

Terminates the connection (if active) with the VM and removesthe widget from the

associatedelement.Consumersshouldcallthisbeforeremovingtheelementfromthe

DOM.



Method disconnect()

Paramete

None

Return Value None

Example Call wmks.destroy();



Display‐relatedAPIs

setRemoteScreenSize()

SendsarequesttosetthescreenresolutionofthecurrentlyconnectedVM.Here,ifthe

parameterswidthandheightthatarepassedarelargerthanthoseoftheWMKSwidget

allocatedsize,thesizingwouldbenormalized.



Note:this methodcouldworkproperlyonlywhentheoption changeResolutionsetto

true.



Method setRemoteScreenSize(width,height)

Paramete

1 width(int)represents the desired width of the connected vm, in pixel

Parameter2 height(int) represents the desired height of the connected vm, in pixel

Return Value None

Example Call wmks.setRemoteScreeSize(800,600);



Page14



getRemoteScreenSize()

RetrievesthescreenwidthandheightinpixelsofcurrentlyconnectedVM.



Method getRemoteScreenSize()

Paramete

None

Return Value Object in format of {width:, height:}

Example Call var size = wmks.getRemoteScreenSize();



updateScreen()

Changes the resolution or rescale the remote screen to match the currently allocated

size.



The behavior of updateScreen depends on the option changeResolution, rescale, and

position:



1)IftheoptionchangeResolutionistrue,itwouldsendthechange resolution

requesttotheconnectedVM,therequestresolution(width&height)isthesame

asthecontainer'sallocatedsize.



2)Check rescale option: if true, rescale the remote screen tofitthecontainer's

allocatedsize.



3)Checkpositionoption:Iftheremotescreen'ssizeisnot the same as the

container'sallocatedsize,thentheremotescreenwillbeplacedinthecenteror

topleftofthecontainerbasedonitsvalue.



Method updateScreen()

Paramete

None

Return Value None

Example Call wvmrc.updateScreen();



Full‐screen‐relatedAPIs

canFullScreen()

Indicates if the fullscreen feature is enabled on this browser.  Fullscreen mode is

disabled on Safari as it does not support keyboard input in fullscreen for security

reasons.



Method canFullScreen()

Paramete

None

Return Value Boolean. True mean can, false not.

Example Call wmks.canFullScreen();



Page15



isFullScreen()

Informsifthebrowserisinfullscreenmode.



Method isFullScreen()

Paramete

None

Return Value Boolean. True mean in full screen mode, false not.

Example Call wmks.isFullScreen

()

;



enterFullScreen()

Forcesthebrowserenterfullscreenmodeifsupported.Inthefullscreenmode,onlythe

remotescreenwouldbedisplayed.



Method enterFullScreen()

Paramete

None

Return Value None

Example Call wmks.enterFullScreen();



exitFullScreen()

Forcesthebrowsertoexitfullscreenmode.



Method exitFullScreen()

Paramete

None

Return Value None

Example Call wmks.exitFullScreen();



Input‐relatedAPIs

sendInputString()

Sendsastringaskeyboardinputtotheserver.



Method sendInputString(string)

Parameters String

Return Value None.

Example Call wmks.sendInputString(“test”);



sendKeyCodes()

SendsaseriesofspecialkeycodestotheVM.Thistakesanarrayofspecialkeycodes

andsendskeydownsforeachintheorderlisted.Itthensendskeyupsforeachin

reverseorder.ThiscanbeusedtosendkeycombinationssuchasControl‐Alt‐Delete.



Method sendKeyCodes ()

Parameters Array. Each element in the array could be a keycode or a Unicode.

Keycode for none printable key, Unicode for printable character. If using

Unicode, negative it, such as -118 means “v”



Page16



Return Value None.

Example Call wmks.sendKeyCodes([17,18,46]) ; // Ctrl + Alt + Delete



sendCAD()

SendsaControl‐Alt‐Deletekeysequencetothecurrentlyconnectedvirtualmachine.



Method sendCAD()

Parameters None.

Return Value None.

Example Call wmks.sendCAD();



Mobile‐relatedAPIs

enableInputDevice()

Enablestheinputdevice(keyboard,extendedkeyboard,trackpad)onthemobiledevice,

andinitialthemforuse.



Method enableInputDevice (deviceType)

Parameters deviceType:(Constant) Any value in WMKS.CONST.InputDeviceType.

Return Value None.

Example Call wmks.enableInputDevice(WMKS. CONST .InputDeviceType.



KEYBOARD) ;



disableInputDevice()

Disables the input device (keyboard,extendedkeyboard,trackpad) on the mobile

device,anddestroysthem.



Method disbleInputDevice (deviceType)

Parameters deviceType:(Constant) Any value in WMKS.CONST.InputDeviceType.

Return Value None.

Example Call wmks.disableInputDevice(WMKS. CONST .InputDeviceType.



KEYBOARD) ;



showKeyboard()

Showsthekeyboardonamobiledevice.



Method showKeyboard()

Parameters None

Return Value None.

Example Call wmks.showKeyboard();



hideKeyboard()

Hidesthekeyboardonamobiledevice.



Page17



Method hideKeyboard()

Parameters None.

Return Value None.

Example Call wmks.hideKeyboard();



toggleExtendedKeypad()

Shows/hidestheextendedKeypadonthemobiledevicedependonthecurrentvisibility.



Method toggleExtendedKeypad()

Parameters A map, could include minToggleTime(ms) such as {minToggleTime: 50} if

the user try to call this toggle method too frequency, the duration less

then the minToggleTime, it would not been executed.

Return Value None.

Example Call wmks.toggleExtendedKeypad();



toggleTrackpad()

Shows/hidesthetrackpadonthemobiledevicedependonthecurrentvisibility.



Method toggleTrackpad()

Parameters A map, could include minToggleTime(ms) such as {minToggleTime: 50} if

the user try to call this toggle method too frequency, the duration less

then the minToggleTime, it would not been executed.

Return Value None.

Example Call wmks.toggleTrackpad();



toggleRelativePad()

Shows/hidestherelativemousetrackpadonthescreen.Willsendrelativemouseevent

insteadofabsolutemouseeventafteropenthisrelativepad.Canbeusedwhenthere’s

noVMwareToolsinstalledintheremoteguestOS.AddatoggleRelativeMousebuttonin

theUI,bindittotoggleRelativePad()API.Afterclickit,therelativetrackpadwilldisplay

and send relative mouse event to the remote guest. This is useful when the guest OS

doesn'tinstallVMwareToolsandcan'tacceptabsolutemouseevent.Becauseifthere's

nocursorimagecomesbackfromtheserver,weneedtodisplaylocalcursorpicture.So

wmks‐all.css under css folderand img folder are necessary to beaddintheproduct.

Theyareallunderwmkssdkfolder.



Method toggleRelativePad ()

Parameters A map, could include minToggleTime(ms) such as {minToggleTime: 50} if

the user try to call this toggle method too frequency, the duration less

then the minToggleTime, it would not been executed.

Return

alue None.

Example Call wmks.



toggleRelativePad ();



Page18



Option‐relatedAPIs

setOption()

Changestheoptionvalue.Onlyoptionslistedbelowcanusethismethod:

 rescale

 position

 changeResolution

 useNativePixels

 reverseScrollY

 fixANSIEquivalentKeys

 sendProperMouseWheelDeltas

 keyboardLayoutId

Method

setOption

(optionName,optionValue)

Parameter1 optionName( string of the option name)

Parameter2 optionValue

Return Value None

Example Call wmks.setOption(“changeResolution”,false);



Appendix



ConstantsusedinWMKS



 Position:WMKSwoulddisplaytheremotescreenofVMinequalproportion.

Thereforeafterrescale,theremotescreensizemaybestillnotthesamewiththe

container’ssize.HerePositionprovidestwopossibleoptionsforputthescreen

atwhichpositionofthecontainer.



 ConnectionState:Thereare3possibleconnectionstateswhentryingto

connecttotheremoteVM.



 Events:AlltheeventnamesthatWMKScantriggerarelistedhere.



 ErrorType:possibleerrortypesinthelifecycleofWMKS.



 InputDeviceType:HTMLConsoleSDKsupportsviewingVMconsolesonmobile

devices,andthisfieldliststhepossibleinputdevices.



(Pleaseseenextpageforlistofconstants)



Page19



Position:{

CENTER:0,

LEFT_TOP:1

},



ConnectionState:{

CONNECTING:"connecting",

CONNECTED:"connected",

DISCONNECTED:"disconnected"

},



Events:{

CONNECTION_STATE_CHANGE:"connectionstatechange",

REMOTE_SCREEN_SIZE_CHANGE:"screensizechange",

FULL_SCREEN_CHANGE:"fullscreenchange",

ERROR:"error",

KEYBOARD_LEDS_CHANGE:"keyboardledschanged",

HEARTBEAT:"heartbeat",

AUDIO:"audio",

COPY:"copy",

TOGGLE:"toggle"

},



ErrorType:{

AUTHENTICATION_FAILED:"authenticationfailed",

WEBSOCKET_ERROR:"websocketerror",

PROTOCOL_ERROR:"protocolerror"

},



AudioEncodeType:{

VORBIS:"vorbis",

OPUS:"opus",

AAC:"aac"

},



InputDeviceType:{

KEYBOARD:0,

EXTENDED_KEYBOARD:1,

TRACKPAD:2

}

WMKS_SDK_Programming_Guidex Html Console Sdk 210 Programmer Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
