CHAPTER

2-1

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Instant Access (IA)

•Prerequisites for Instant Access, page 2-1

•Restrictions for Instant Access, page 2-2

•Information About Instant Access, page 2-6

•Default Settings for Instant Access, page 2-6

•How to Configure Instant Access, page 2-7

Note • For complete syntax and usage information for the commands used in this chapter, see these

publications:

http://www.cisco.com/en/US/products/ps11846/prod_command_reference_list.html

•Cisco IOS Release 15.1SY supports only Ethernet interfaces. Cisco IOS Release 15.1SY does not

support any WAN features or commands.

Prerequisites for Instant Access

•An IA parent—A VSS-mode Catalyst 6800 switch or a VSS-mode Catalyst 6500 switch equipped

with a Supervisor Engine 2T and one or more WS-X6904-40G-2T switching modules, configured

to support 10GE links.

•IA clients—Catalyst 6800ia access switches

See this publication for more information:

http://www.cisco.com/en/US/prod/collateral/switches/ps10902/ps715/ps13198/data_sheet_c78-72

8230.html

•See this publication for more information about Instant Access:

http://www.cisco.com/en/US/prod/collateral/switches/ps10902/ps715/ps13198/white_paper_c11-7

28265.html

2-2

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

Restrictions for Instant Access

•For image download during ISSU upgrade, remove ip tftp source-interface config on IA Parent,

and add a static route to copy image through mgmt intf.

Restrictions for Instant Access

•The IA parent must operate in VSS mode.

Note • You can enable VSS mode on a single chassis to support IA clients.

• The VSS Quad-Sup SSO (VS4O) feature is supported with IA clients from Release

15.1(2)SY2.

•The IA parent-client connection is supported on links between WS-X6904-40G-2T switching

module 10GE ports and Catalyst 6800ia access switch 10GE ports.

–

You can use up to 6 IA client 10GE ports in the IA parent-client link. See this document for

information about WS-X6904-40G-2T switching module port configuration:

http://www.cisco.com/en/US/prod/collateral/switches/ps5718/ps708/white_paper_c11-696669

.html

–

IA client 10-Gigabit Ethernet ports require no configuration.

–

UDLD, LLDP, and CDP are not supported on the A parent-client link.

–

Instant Access does not use STP on the IA parent-client connection.

–

Use only XL based modules for scale FEX QoS configuration to prevent issues with TCAM

(ternary content-addressable memory) utilization. When QoS policy is configured on 1500 FEX

host ports, the first 511 interfaces share the TCAM utilization. But, remaining ports will start

using new TCAM entries for each interface and will exhaust non-XL TCAM utilization.

•IA client maximum values:

•IA client ports do not support these features:

Value Description: Maximum Value

Maximum IA client ports 1008 ports across 21 Catalyst 6800ia access switches

Maximum IA client stacks 12 (defined by IA client FEX number 1–12 range.)

Maximum Catalyst 6800ia access switches

per IA client stack

•An IA client stack acts as single switch unit.

•Instant access only supports connection with stacking

cables to form a stack.

•With an IA client that has multiple Catalyst 6800ia

access switches, the switches in the stack assign

incrementing switch numbers to themselves

(automatic stacking capability).

•If you add Catalyst 6800ia access switches to a

configured IA client, the additional switches assign

incrementing switch numbers to themselves.

•The IA client configuration does not persist if the

access switch number changes.

2-3

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

Restrictions for Instant Access

–

Configuring EtherChannels with combination of FEX Ports from different FEX-IDs or

combination of FEX ports with IA parent switch linecard ports is not supported. However, FEX

host port channel from the same FEX is supported.

–

FEX host port EtherChannel load balancing is not supported.

–

Port debounce timer

–

UDLR tunnel ARP and IGMP proxy

–

Uni-Directional Link Routing (UDLR)

–

IEEE 802.1Q tunneling

–

VLAN Mapping

–

VLAN Translation

–

IEEE 802.1Q custom ethertypes

–

L2PT - Layer 2 protocol tunneling

–

L2PT - Layer 2 protocol tunneling on trunk ports

–

802.1ad tunnelling

–

Port security on 802.1Q tunnel ports

–

Private VLANs (PVLAN)

–

VACL capture

–

Per-VLAN load balancing for Advanced QinQ service mapping

–

Cisco TrustSec NDAC (Network Device Admission Control)

–

Cisco TrustSec security association protocol (SAP) for MACSec encryption

–

Cisco TrustSec confidentiality and integrity with MACsec (IEEE 802.1AE)

–

Cisco TrustSec identity port mapping

–

Network edge authentication topology (NEAT)

–

AutoQoS

–

MQC queuing policy support

–

Priority queueing (PQ)

–

QoS aggregated DSCP values for WRED

–

QoS aggregated precedence values for WRED

–

Class based weighted fair queuing (CBWFQ)

–

Class-based shaping

–

DiffServ-compliant dWRED

–

Diffserv-compliant WRED

–

Selective packet discard (SPD)

Maximum number of VLANs

per IA client stack

You can set upto 1,000 VLANs, we recommend to set not

more than 20 VLANs per FEX.

Maximum Number of Port Channels 512

Value Description: Maximum Value

2-4

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

Restrictions for Instant Access

–

Strict priority low latency queueing (LLQ)

–

Weighted fair queueing (WFQ)

–

Weighted RED (WRED)

–

QoS policer rate increase to 256G

–

Ethernet over MPLS (EoMPLS) - IEEE 802.1q Tag Stacking

–

H-VPLS N-PE redundancy for QinQ access

–

Connectivity fault management (CFM)

–

Ethernet connectivity fault management (E-CFM)

–

Ethernet local management interface (LMI) at provider edge (PE)

–

Ethernet operations, administration, and Maintenance (OAM)

–

Ethernet-OAM 3.0: CFM over BD, Untagged

–

IEEE 802.1ag - D8.1 standard Compliant CFM, Y.1731 multicast LBM / AIS / RDI / LCK, IP

SLA for Ethernet

–

IEEE 802.1ag Compliant CFM (D8.1)

•To use an IA client port as a SPAN destination, add the IA client port VLAN to the SPAN allowed

VLAN list with the switchport trunk allowed vlan command.

•When FEX IA parent-client link portchannel is configured as SPAN source in Tx direction or both

directions, the SPAN destination should not be on the same FEX. This is applicable for both stacked

and standalone FEX.

•To enable formation of ISIS adjacencies on IA client ports, configure an explicit connectionless

network service (CLNS) MTU size on the IA client and peer ports. The maximum MTU value that

can be configured for CLNS is 9216. The CLNS MTU size should be the same on both sides of the

ISIS link.

This example shows how to configure the default MTU size on an IA client port:

Router# configure terminal

Router(config)# interface interface Gig118/1/0/1

Router(config-if)# ip router isis

Router(config-if)# clns mtu 1497

2-5

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

Restrictions for Instant Access

•IA client port QoS:

–

Configure ingress QoS on the IA parent port-channel interface.

–

The egress QoS configuration on IA client ports is not configurable.

–

Port architecture (Rx/Tx): 1p3q3t

1p3q3t strict-priority egress queue (queue 1) CoS Not supported

DSCP 32, 33, 40–47

Tail-drop 100% (nonconfigurable)

WRED-drop Not supported

1p3q3t standard egress queue 2

(high priority)

Threshold 1 CoS Not supported

DSCP 16–23, 26–31, 34–39

Tail-drop Disabled; 100%

WRED-drop Not supported

Thresholds 2 CoS Not supported

DSCP 24

Tail-drop Disabled; 100%

WRED-drop Not supported

Thresholds 3 CoS Not supported

DSCP 48-63

Tail-drop Disabled; 100%

WRED-drop Not supported

1p3q3t standard egress queue 3

(medium priority)

Threshold 1 CoS Not supported

DSCP 25

Tail-drop Disabled; 70%

WRED-drop Not supported

Threshold 2 CoS Not supported

DSCP None.

Tail-drop Disabled; 100%

WRED-drop Not supported

Thresholds 3 CoS Not supported

DSCP 0–7

Tail-drop Disabled; 100%

WRED-drop Not supported

2-6

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

Information About Instant Access

The Instant Access (IA) feature supports multiple Catalyst 6800ia access switches that function as

clients of the IA parent switch. The IA parent and client switches form a single extended switch with a

single management domain, managed by the IA parent.

The IA parent uses the Satellite Discovery Protocol (SDP) and the Satellite Registration Protocol (SRP)

to automatically discover IA clients when they connect and monitor the IA client-parent link. The

IA parent upgrades the IA client software image if it is not the same as the parent.

The IA parent features are applied to IA client traffic. The IA clients do not perform any local packet

forwarding. All traffic originating from IA client ports are sent to the IA parent, which makes all the

switching and forwarding decisions.

These online diagnostic tests support Instant Access clients:

•TestFexModeLoopback, page 1-4

•TestFexFabricLinkStatus, page 1-39

Default Settings for Instant Access

By default, these configurations are present on each interface:

switchport

switchport trunk allowed vlan 1

switchport mode dynamic auto

1p3q3t standard egress queue 4

(lowest priority)

Threshold 1 CoS Not supported

DSCP 8, 9, 11, 13, 15

Tail-drop Disabled; 70%

WRED-drop Not supported

Threshold 2 CoS Not supported

DSCP 10, 12, 14

Tail-drop Disabled; 100%

WRED-drop Not supported

Threshold 3 CoS Not supported

DSCP None.

Tail-drop Disabled; 100%

WRED-drop Not supported

2-7

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

•Configure Instant Access Staggered Initialization Mode, page 2-7

•Enable IA Client Preprovisioning, page 2-7

•Configure Instant Access Port-Channel Interfaces, page 2-8

•Configure Instant Access Channel Groups, page 2-8

•Identify Connected IA Client Stack Modules, page 2-9

•Renumbering FEX Switch-ID, page 2-10

•Configure IA Clients, page 2-12

•Display or Clear SDP and SRP Traffic, page 2-13

•Configure Optional Parameters for an IA Client, page 2-13

Configure Instant Access Staggered Initialization Mode

Instant Access staggered initialization mode avoids any excessively high CPU utilization that might

occur if multiple IA clients attempt to initialize simultaneously. To configure Instant Access staggered

initialization mode, perform this task:

This example shows how to configure Instant Access staggered mode:

Router# configure terminal

Router(config)# fex stagger 120

Enable IA Client Preprovisioning

To allow IA client port configuration before the IA client is connected, perform this task:

Command Purpose

Router(config)# fex stagger delay_value Configures Instant Access staggered initialization

mode. The delay_value can be 0 through 500.

Note The recommended delay_value is 120.

Command Purpose

Router# module provision create fex fex_number

type {C6800IA-48FPD |C6800IA-48TD | C6800IA-48FPDR}

[slot switch_number]

Enables IA client port configuration before the IA client is

connected. Enter the slot switch_number keyword and

argument to enable configuration of a specific

IA client stack member or an additional stack member

before it is added to the IA client stack.

2-8

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

Configure Instant Access Port-Channel Interfaces

To create a port channel interface to support IA clients, perform this task:

This example shows how to create port channel interface 1 and configure it to support

IA FEX number 118:

Router# configure terminal

Router(config)# interface port-channel 118

Router(config-if)# switchport

Router(config-if)# switchport mode fex-fabric

Router(config-if)# fex associate 118

Configure Instant Access Channel Groups

To configure channel groups to support IA clients, perform this task for the 10 Gigabit Ethernet LAN

ports that connect to IA clients:

Note More links can be added to the channel group at any time.

Command Purpose

Step 1 Router(config)# interface port-channel group_number Creates the port channel interface. There can be up to a

maximum of 512 port-channel interfaces

(12 port-channel interfaces can be used to support IA

clients).

Note If desired, you can configure the group_number

to match the IA client FEX number.

Step 2 Router(config-if)# switchport Configures the port channel interface for Layer 2 switching.

Step 3 Router(config-if)# switchport mode fex-fabric Configures the port channel interface to support IA clients.

Step 4 Router(config-if)# fex associate fex_number Configures the IA client FEX number.

•The valid value range is 101–199.

•Maximum of 12 IA client FEX numbers.

Command Purpose

Step 1 Router(config)# interface range first_10ge_port, last_10ge_port Selects the ports to configure.

Step 2 Router(config-if)# switchport Configures the port channel interface for

Layer 2 switching.

Step 3 Router(config-if)# switchport mode fex-fabric Configures the port channel interface to

support IA clients.

Step 4 Router(config-if)# channel-group group_number mode on Configures the LAN port in an IA Client

port channel and configures the mode

as on.

2-9

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

This example shows how to configure 10 Gigabit Ethernet ports 1/2/5 and 2/2/5 into port channel 118

with mode on:

Router# configure terminal

Router(config)# interface range tengigabitethernet 1/2/5, 2/2/5

Router(config-if)# switchport

Router(config-if)# switchport mode fex-fabric

Router(config-if)# channel-group 118 mode on

Router(config-if)# end

This example shows how to verify the IA configuration when the IA client is connected:

Router# show fex 118 detail

FEX: 118 Description: FEX0118 state: online

FEX version: version_string

Extender Model: C6800IA-48TD, Extender Serial: serial_number

FCP ready: yes

Image Version Check: enforced

Fabric Portchannel Ports: 2

Fabric port for control traffic: Te1/2/5

Fabric interface state:

Po20 - Interface Up.

Te1/2/5 - Interface Up. state: bound

Te2/2/5 - Interface Up. state: bound

Identify Connected IA Client Stack Modules

•Identify IA Client Stack Modules by Serial Number, page 2-9

•Identify IA Client Modules by Beacon LED, page 2-9

Identify IA Client Stack Modules by Serial Number

This example shows how to identify IA client stack modules by serial number:

Router# show interface fex

Fabric Fabric Port FEX FEX

FEX Port State Uplink Model Serial

---------------------------------------------------------------------

101 Te1/2/5 bound Te1/0/1 C6800IA-48FPD FHH1707P00S

101 Te1/2/13 bound Te2/0/1 C6800IA-48FPD FHH1707P00S

101 Te2/2/5 bound Te1/0/2 C6800IA-48FPD FHH1707P00S

101 Te2/2/13 bound Te2/0/2 C6800IA-48FPD FHH1707P00S

102 Te1/2/6 bound Te1/0/2 C6800IA-48TD FOC1709Z2V9

102 Te2/2/17 bound Te2/0/2 C6800IA-48TD FOC1709Z2V9

Identify IA Client Modules by Beacon LED

Router(config)# hw-module fex <> slot <> led beacon

This example shows how to activate the beacon LED on IA client 118, slot 1:

Router(config)# hw-module fex 118 slot 1 led beacon

This example shows how to verify the beacon LED on IA client 118, slot 1:

Router(config)# show hw-module fex led beacon

C6K FEX BLUE BEACON CONFIG

----------------------------------

hw-module fex 118 slot 1 led beacon

2-10

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

Renumbering FEX Switch-ID

The renumbering of IA clients can be managed using switch-id allocation from controller, after stack

boot up. Also, a priority can be assigned to the FEX members to take over as the master switch.

The following conditions must exist for successful execution of FEX switch-id allocation:

–

For renumbering, the source slot should be online and the target slot should be offline.

–

If the source slot FEX type is different than target slot FEX type, the interface configurations

will be lost if you proceed with renumbering.

–

Same target slot cannot be used for renumbering multiple source slots.

–

Same source slot cannot be renumbered to multiple target slot.

–

You can enter multiple renumbering entries along with different swapping scenarios.

–

When priority is modified for a member IA, the whole stack will reload.

–

During In Service Software Upgrade (ISSU) process, switch-id renumbering or priority changes

are not allowed.

To renumber FEX switch-id and assign priority, perform this task:

Note After the commit operation, you will be prompted whether you want to release the old source-vslot or

not. This confirmation will not be asked only in a switch-id swap scenario (for example, renumber 1 to

2 and renumber 2 to 1) because both renumbering are done in a single commit operation.

To renumber FEX switch-id when scale is set to maximum FEX slots, perform this task:

Command Purpose

Step 1 Switch# module provision update fex fex_id Enters into switch renumber sub-mode.

Step 2 Switch(exec-fex-update)# renumber source_slot to

target_slot

Renumbers source_slot to target_slot

Step 3 Switch(exec-fex-update)# priority source_slot value

number

Assigns the mentioned priority number to the

source_slot.

Step 4 Switch(exec-fex-update)# commit Commits all entries entered under exec-fex-update

sub-mode.

Command Purpose

Step 1 Switch# module provision update fex fex_id

temp-vslot-allow enable

When maximum vslots are already allocated,

temp-vslot-allow will enable the temporary vslot module

to come online.

Step 2 Switch# module provision update fex fex_id Enters into switch renumber sub-mode.

Step 3 Switch(exec-fex-update)# renumber source_slot to

target_slot

Renumbers source_slot to target_slot

Step 4 Switch(exec-fex-update)# priority source_slot value

number

Assigns the mentioned priority number to the

source_slot.

2-11

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

Note After the commit operation, you will be prompted whether you want to release the old source-vslot or

not. This confirmation will not be asked only in a switch-id swap scenario (for example, renumber 1 to

2 and renumber 2 to 1) because both renumbering are done in a single commit operation.

Example: Renumbering FEX switch-id and setting priority

Switch# module provision update fex 101

Switch(exec-fex-update) renumber 3 to 4

Switch(exec-fex-update) priority 2 value 1

%FEX 101 will reload upon commit.

Are you sure you want to proceed? [no]: yes

Switch(exec-fex-update)#commit

%Do you want to release FEX 101 module 3 source interface configs(vslot) after module

offline? [no]: yes

%FEX 101 All modules will reload.

Are you sure you want to proceed? [no]: yes

Example: Identifying if temporary vslot is online

This example shows how to identify when a particular temporary FEX vslot is online:

Switch# show fex system platform usage

FEX id usage details

Fex-ids inuse: 150

Fex-ids online: 150

Total Used Free

----- ---- ----

42 1 41

FEX slot usage details

FEX-id Switch-id Vslot Pslot Status

------ --------- ----- ----- ------

150 3 51 2 In-use

150 3 52 3 In-use

150 3 53 5 Reserved

150 3 55 4 In-use

150 3 92 1 Temp-In-use

Total Used Reserved Temp-Use/Free Free

----- ---- -------- ------------- ----

47 3 1 1/4 42

Current Temp vslot allowed FEXs: 150

Current Temp VSLOT usage:

------------------------

FEX 150 module 1

FEX ports usage details

FEX-id Switch-id Ports

------ --------- -----

150 3 192

Total Used Free

Step 5 Switch(exec-fex-update)# commit Commits all entries entered under exec-fex-update

sub-mode.

Step 6 Switch# module provision update fex fex_id

temp-vslot-allow disable

Disables the temporary vslot module to go offline.

Command Purpose

2-12

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

----- ---- ----

2016 192 1824

Stack members usage details

FEX-id Switch-id Used Free

Example: Identifying FEX IDs where temp-vslot-allow command is enabled

This example verifies the active entries under sub-mode and also the FEX IDs on which

"temp-vslot-allow" is enabled.

Switch(exec-fex-update)#show

Current module renumber mappings for FEX 101

--------------------------------------------

renumber 1 to 2

Current module Priority mappings for FEX 101

--------------------------------------------

priority 1 value 15

Temp vslots allowed:YES

Current Temp vslot allowed FEXs:101

Switch(exec-fex-update)#

Configure IA Clients

The configuration for IA clients can be entered on the IA parent before or after the IA clients are

connected. IA client 10-Gigabit Ethernet ports require no configuration. IA client Gigabit Ethernet ports

use this format:

gigabitethernet/fex_number/access_switch_number/0/port_number

–

fex_number—The IA client FEX number:

—Maximum of 12 IA FEX numbers.

—The valid value range is 101–199.

–

access_switch_number—The access switch number:

—The valid values are 1, 2, or 3.

—Multiple-switch stacks assign incrementing switch numbers to themselves.

—See the “Identify Connected IA Client Stack Modules” section on page 2-9.

–

The third interface parameter is always zero.

–

The port_number valid value range is 1–48.

Note • IA client configuration does not persist if the access switch number changes.

•The interface-range configuration mode supports IA clients ports (see “How to Configure a Range

of Interfaces” section on page 10-2)

2-13

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

Display or Clear SDP and SRP Traffic

To display the counters that record the SDP packet traffic on IA client 118, enter the following command:

Router# show fex 118 protocol | incl SDP

130 SDP pkts sent

129 SDP pkts received

130 SDP pkts sent

129 SDP pkts received

Note The command displays a sent and received value for each link in the IA channel group.

To clear the protocol counters, enter the clear fex fex_number {sdp | srp} command.

Configure Optional Parameters for an IA Client

•Enter the IA Client Configuration Mode, page 2-13

•Configure a Description, page 2-13

•Configure the Custom Location Type Feature, page 2-13

•Configure MTU, page 2-14

Enter the IA Client Configuration Mode

To enter the IA client configuration mode, perform this task:

Configure a Description

To configure a description for the IA client or for each module in the IA client stack, perform this task:

Configure the Custom Location Type Feature

You can configure the custom location type feature for the IA client in IA client configuration mode. See

these publications for information about the location command:

http://www.cisco.com/en/US/docs/ios-xml/ios/cether/command/ce-cr-book.html

http://www.cisco.com/en/US/docs/ios-xml/ios/cether/command/ce-e1.html

Command Purpose

Router(config)# fex fex_number

Router(config-fex)#

Enters IA client configuration mode.

Note Sets the IA client description to FEX0fex_number.

Command Purpose

Router(config-fex)# [module module_number] description description_string Configures a description for the IA

FEX number or for a module in the

IA client stack.

2-14

Supervisor Engine 2T Software Configuration Guide, Release 15.1SY

Chapter 2 Instant Access (IA)

How to Configure Instant Access

Note The location commands support the optional fex-location keyword for IA clients.

Configure MTU

You can configure MTU on the IA FEX using the mtu command in fex config mode. In an IA client

stack, the configured MTU value is applied to all the host members in the stack.

To configure MTU for an IA client, perform this task:

If you want to avoid reloading the FEX, you can configure an explicit connectionless network service

(CLNS) MTU size on the IA client and peer ports as shown in the following example:

Router# configure terminal

Router(config)# interface interface Gig118/1/0/1

Router(config-if)# ip router isis

Router(config-if)# clns mtu 1497

Command Purpose

Router# configure terminal Enters the global configuration mode.

Router(config)# fex 110 Enters IA client configuration mode.

Router(config-fex)# mtu 2000 Resets the MTU value for the FEX system. All

the FEX ports will be set to use the new MTU

value.

The default MTU value for a FEX host port is

9216.

Note For Cisco Catalyst C6840 series switch,

the maximum supported MTU for native

interface is 9154.The default MTU

value is 1500. If the MTU of peer

(Catalyst 6880 or Sup2T) is configured

higher than 9154, the packet will not be

processed. When using existing

configuration from a Catalyst 6880 or

Sup2T, ensure that the MTU is reset or

removed.

Router# end Exits the global configuration mode.

Note Reload the FEX for the MTU change to

take effect.

Instant Access 15 1

Navigation menu

Versions of this User Manual:

Views

Navigation
