Intel® Trusted Execution
Technology (Intel® TXT)
Software Development Guide
Measured Launched Environment Developer’s Guide
August 2016
Revision 013
2 315168-013
You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning
Intel products described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter
drafted which includes subject matter disclosed herein.
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.
Intel technologies’ features and benefits depend on system configuration and may require enabled hardware, software or service
activation. Performance varies depending on system configuration. No computer system can be absolutely secure. Check with
your system manufacturer or retailer or learn more at intel.com.
Intel technologies may require enabled hardware, specific software, or services activation. Check with your system manufacturer
or retailer.
The products described may contain design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
Intel disclaims all express and implied warranties, including without limitation, the implied warranties of merchantability, fitness
for a particular purpose, and non-infringement, as well as any warranty arising from course of performance, course of dealing, or
usage in trade.
All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest Intel
product specifications and roadmaps
Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-
4725 or visit www.intel.com/design/literature.htm.
Intel, Pentium, Intel Xeon, Intel NetBurst, Intel Core Solo, Intel Core Duo, Intel Pentium D, Itanium, MMX, and VTune are
trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copyright © 2006-2016 Intel Corporation
315168-013 3
Contents
1 Overview ........................................................................................................ 9
1.1 Measurement and Intel® Trusted Execution Technology (Intel® TXT) ............. 9
1.2 Dynamic Root of Trust ......................................................................... 10
1.2.1 Launch Sequence ................................................................... 10
1.3 Storing Measurement ........................................................................... 11
1.4 Controlled Take-down .......................................................................... 11
1.5 SMX and VMX Interaction ..................................................................... 11
1.6 Authenticated Code Module ................................................................... 11
1.7 Chipset Support .................................................................................. 12
1.8 TPM Usage ......................................................................................... 12
1.9 Hash Algorithm Support ....................................................................... 13
1.10 PCR Usage ......................................................................................... 14
1.10.1 Legacy Usage ........................................................................ 14
1.10.2 Details and Authorities Usage ................................................... 16
1.10.3 PCR 18 (Authorities) ............................................................... 16
1.11 DMA Protection ................................................................................... 17
1.11.1 DMA Protected Range (DPR) .................................................... 17
1.11.2 Protected Memory Regions (PMRs) ............................................ 17
1.12 Intel® TXT Shutdown ........................................................................... 18
1.12.1 Reset Conditions .................................................................... 18
2 Measured Launched Environment (MLE) ............................................................ 19
2.1 MLE Architecture Overview ................................................................... 19
2.2 MLE Launch ........................................................................................ 22
2.2.1 Intel® TXT Detection and Processor Preparation .......................... 22
2.2.2 Detection of Previous Errors ..................................................... 23
2.2.3 Loading SINIT AC Module ........................................................ 24
2.2.4 Loading the MLE and Processor Rendezvous ............................... 29
2.2.5 Performing a Measured Launch ................................................. 32
2.3 MLE Initialization ................................................................................. 34
2.4 MLE Operation .................................................................................... 39
2.4.1 Address Space Correctness ...................................................... 40
2.4.2 Address Space Integrity .......................................................... 40
2.4.3 Physical RAM Regions ............................................................. 40
2.4.4 Intel® Trusted Execution Technology Chipset Regions .................. 40
2.4.5 Device Assignment ................................................................. 41
2.4.6 Protecting Secrets .................................................................. 41
2.4.7 Model Specific Register Handling .............................................. 41
2.4.8 Interrupts and Exceptions ........................................................ 42
2.4.9 ACPI Power Management Support ............................................. 42
2.4.10 Processor Capacity Addition (aka CPU Hotplug) ........................... 45
2.5 MLE Teardown .................................................................................... 45
2.6 Other Considerations ........................................................................... 48
2.6.1 Saving MSR State Across Measured Launch ................................ 48
3 Verifying Measured Launched Environments ....................................................... 50
3.1 Overview ........................................................................................... 50
3.1.1 Versions of LCP Components .................................................... 51
4 315168-013
3.2 LCP Components, V2 (TPM 1.2) ............................................................. 51
3.2.1 LCP Policy ............................................................................. 52
3.2.2 PolicyControl Field for LCP_POLTYPE_LIST .................................. 53
3.2.3 PolicyHash Field for LCP_POLTYPE_LIST ..................................... 54
3.2.4 LCP Policy Data ...................................................................... 54
3.2.5 LCP Policy Element ................................................................. 56
3.2.6 Signed Policies ....................................................................... 56
3.2.7 Supported Cryptographic Algorithms ......................................... 57
3.2.8 Policy Engine Logic ................................................................. 57
3.2.9 Allow Any Policy ..................................................................... 59
3.2.10 Policy with LCP_POLICY_DATA ................................................. 59
3.2.11 Force Platform Owner Policy ..................................................... 60
3.2.12 Platform Owner Index ............................................................. 60
3.3 LCP Components, V3 (TPM2.0) .............................................................. 61
3.3.1 TPM NV RAM .......................................................................... 61
3.3.2 LCP Policy 2 ........................................................................... 62
3.3.3 LCP Policy Data ...................................................................... 63
3.3.4 LCP Policy Elements ................................................................ 63
3.3.5 List Signatures ....................................................................... 63
3.3.6 PCR Extend Policy .................................................................. 63
3.3.7 V3 Policy Engine Logic. ............................................................ 64
3.3.8 Combining Policies .................................................................. 65
3.3.9 Measuring the Enforced Policy .................................................. 65
3.3.10 Effective TPM NV info Hash ...................................................... 68
3.4 Combined Policy Engine Processing Logic ................................................ 69
3.4.1 Overall Topological Changes .................................................... 69
3.4.2 Processing of Policy Data Files .................................................. 69
3.4.3 TPM 1.2 mode ....................................................................... 71
3.4.4 TPM 2.0 Mode ........................................................................ 71
3.5 Revocation ......................................................................................... 75
3.5.1 SINIT Revocation ................................................................... 75
4 Development and Deployment Considerations .................................................... 77
4.1 Launch Control Policy Creation .............................................................. 77
4.2 Launch Errors and Remediation ............................................................. 77
4.3 Determining Trust ............................................................................... 78
4.3.1 Migration of SEALed Data ........................................................ 78
4.4 Deployment ........................................................................................ 79
4.4.1 LCP Provisioning ..................................................................... 79
4.4.2 SINIT Selection ...................................................................... 80
4.5 SGX Requirement for TXT Platform ........................................................ 80
Appendix A Intel® TXT Execution Technology Authenticated Code Modules .............................. 83
A.1 Authenticated Code Module Format ........................................................ 83
A.1.1 Memory Type Cacheability Restrictions ...................................... 91
A.1.2 Authentication and Execution of AC Module ................................ 92
Appendix B SMX Interaction with Platform .......................................................................... 93
B.1 Intel® Trusted Execution Technology Configuration Registers ..................... 93
B.1.1 TXT.STS – Status ................................................................... 93
B.1.2 TXT.ESTS – Error Status ......................................................... 94
B.1.3 TXT.ERRORCODE – Error Code ................................................. 95
B.1.4 TXT.CMD.RESET – System Reset Command ............................... 96
B.1.5 TXT.CMD.CLOSE-PRIVATE – Close Private Space Command .......... 97
315168-013 5
B.1.6 TXT.VER.FSBIF – Front Side Bus Interface ................................. 97
B.1.7 TXT.DIDVID – TXT Device ID ................................................... 97
B.1.8 TXT.VER.QPIIF – Intel® QuickPath Interconnect Interface ............. 98
B.1.9 TXT.CMD.UNLOCK-MEM-CONFIG – Unlock Memory Config
Command ............................................................................. 98
B.1.10 TXT.SINIT.BASE – SINIT Base Address ...................................... 99
B.1.11 TXT.SINIT.SIZE – SINIT Size ................................................... 99
B.1.12 TXT.MLE.JOIN – MLE Join Base Address ..................................... 99
B.1.13 TXT.HEAP.BASE – TXT Heap Base Address ................................ 100
B.1.14 TXT.HEAP.SIZE – TXT Heap Size .............................................. 100
B.1.15 TXT.DPR – DMA Protected Range ............................................. 100
B.1.16 TXT.CMD.OPEN.LOCALITY1 – Open Locality 1 Command ............. 101
B.1.17 TXT.CMD.CLOSE.LOCALITY1 – Close Locality 1 Command ........... 101
B.1.18 TXT.CMD.OPEN.LOCALITY2 – Open Locality 2 Command ............. 101
B.1.19 TXT.CMD.CLOSE.LOCALITY2 – Close Locality 2 Command ........... 102
B.1.20 TXT.PUBLIC.KEY – AC Module Public Key Hash ........................... 102
B.1.21 TXT.CMD.SECRETS – Set Secrets Command .............................. 102
B.1.22 TXT.CMD.NO-SECRETS – Clear Secrets Command ...................... 103
B.1.23 TXT.E2STS – Extended Error Status ......................................... 103
B.2 TPM Platform Configuration Registers .................................................... 103
B.3 Intel® Trusted Execution Technology Device Space .................................. 104
Appendix C Intel® TXT Heap Memory ............................................................................... 105
C.1 Extended Data Elements ..................................................................... 106
C.1.1 HEAP_END_ELEMENT ............................................................. 106
C.1.2 HEAP_CUSTOM_ELEMENT ....................................................... 107
C.2 BIOS Data Format .............................................................................. 107
C.2.1 HEAP_BIOS_SPEC_VER_ELEMENT ............................................ 109
C.2.2 HEAP_ACM_ELEMENT ............................................................. 109
C.2.3 HEAP_STM_ELEMENT ............................................................. 109
C.3 OS to MLE Data Format ....................................................................... 110
C.4 OS to SINIT Data Format .................................................................... 110
C.4.1 HEAP_TPM_EVENT_LOG_ELEMENT ........................................... 111
C.4.2 HEAP_EVENT_LOG_POINTER_ELEMENT2 .................................. 111
C.4.3 HEAP_EVENT_LOG_POINTER_ELEMENT2_1 ............................... 112
C.5 SINIT to MLE Data Format ................................................................... 113
C.5.1 HEAP_MADT_ELEMENT ........................................................... 115
C.5.2 HEAP_MCFG_ELEMENT ........................................................... 116
Appendix D LCP v2 Data Structures .................................................................................. 117
D.1 LCP_POLICY ...................................................................................... 117
D.2 LCP_POLICY_DATA ............................................................................. 117
D.3 LCP_POLICY_LIST .............................................................................. 118
D.3.1 List Signatures ...................................................................... 118
D.3.2 LCP_POLICY_LIST Structure .................................................... 118
D.4 LCP_POLICY_ELEMENT ........................................................................ 119
D.4.1 LCP_MLE_ELEMENT ............................................................... 119
D.4.2 LCP_PCONF_ELEMENT ............................................................ 120
D.4.3 LCP_SBIOS_ELEMENT ............................................................ 120
D.4.4 LCP_CUSTOM_ELEMENT ......................................................... 121
D.5 Structure Endianness .......................................................................... 122
Appendix E LCP Data Structures, v3 ................................................................................. 123
E.1 NV Index LCP Policy ............................................................................ 123
6 315168-013
E.2 LCP Policy Data .................................................................................. 125
E.2.1 LCP_LIST ............................................................................. 125
E.2.2 LCP_POLICY_DATA2 .............................................................. 125
E.3 LCP_POLICY_LIST2 ............................................................................. 125
E.3.1 List Signatures ...................................................................... 126
E.3.2 Signature Format .................................................................. 127
E.4 New Policy Elements ........................................................................... 128
E.4.1 LCP_Hash ............................................................................ 128
E.4.2 MLE Element ........................................................................ 128
E.4.3 SBIOS Element ..................................................................... 128
E.4.4 STM Element ........................................................................ 129
E.4.5 PCONF Element ..................................................................... 129
E.5 NV AUX Index Data Structure ............................................................... 130
E.6 Structure Endianness .......................................................................... 131
Appendix F Platform State upon SINIT Exit and Return to MLE ............................................. 132
Appendix G TPM Event Log .............................................................................................. 134
G.1 TPM 1.2 Event Log .............................................................................. 134
G.1.1 PCR Events ........................................................................... 135
G.2 TPM 2.0 Event Log .............................................................................. 137
G.2.1 TrEE Event Logging Structures ................................................ 137
G.2.2 TPM 2.0 Event Log Pointer Element .......................................... 138
G.2.3 TCG Compliant Event Logging Structures .................................. 139
G.2.4 Event Types Changed and Added for TPM2.0 ............................. 141
Appendix H ACM Hash Algorithm Support .......................................................................... 144
H.1 Supported Hash Algorithms ................................................................. 144
Appendix I ACM Error Codes ........................................................................................... 146
Appendix J TPM NV ....................................................................................................... 152
Appendix K Detailed LCP Checklists .................................................................................. 156
K.1 Policy Validation Checklist .................................................................... 156
K.1.1 TPM NV AUX Index ................................................................ 156
K.1.2 TPM NV PS Index .................................................................. 156
K.1.3 TPM NV PO Index .................................................................. 157
K.1.4 NPW Mode ........................................................................... 157
K.1.5 Policy Data Files .................................................................... 157
K.1.6 PS Policy Data File if Exists ..................................................... 157
K.1.7 PO Policy Data File if Exists ..................................................... 158
K.1.8 PS Policy Data File List Integrity .............................................. 158
K.1.9 PO Policy Data File List Integrity .............................................. 159
K.2 Policy Enforcement Checklist ................................................................ 159
K.2.1 Effective Policies ................................................................... 159
K.2.2 Handling of Ignore_PS_EltType Bits ......................................... 159
K.2.3 Policy type handling by SINIT and BIOSAC ................................ 160
K.2.4 MLE Element Enforcement ...................................................... 160
K.2.5 PCONF Element Enforcement .................................................. 161
K.2.6 BIOSAC SBIOS Element Enforcement ....................................... 163
K.2.7 SINIT SBIOS Element Enforcement .......................................... 165
K.2.8 STM Element Enforcement ...................................................... 166
315168-013 7
Figures
Figure 3-1. Launch Control Policy Components ................................................... 51
Figure 3-2. LCP_POLICY Structure .................................................................... 52
Figure 3-3. LCP_POLICY_DATA Structure ........................................................... 55
Figure 3-4. LCP_POLICY_ELEMENT Structure ...................................................... 56
Tables
Table 2-1. MLE Header Structure ...................................................................... 19
Table 2-2. MLE/SINIT Capabilities Field Bit Definitions ......................................... 20
Table 3-1. Truth Table of PCONF Evaluation ....................................................... 74
Table 4-1. SGX Index Content ......................................................................... 81
Table 4-2. IA32_SE_SVN_STATUS MSR (0x500) ................................................. 81
8 315168-013
Revision History
Revision
Number Description Revision Date
-001 • Initial release. May 2006
-002 • Established public document number
• Edited throughout for clarity. August 2006
-003 • Added launched environment consideration
• Renamed LT to Intel® TXT October 2006
-004 • Updated for production platforms
• Use MLE terminology August 2007
-005 • Updated for latest structure versions and new RLP wakeup mechanism
• Added Launch Control Policy information
• Removed TEP Appendix
• Many miscellaneous changes and additions
June 2008
-006 • Miscellaneous errata
• Added definition of LCP v2
• Multiple processor support
December 2009
-007 • Miscellaneous errata
• Documented ProcessorIDList support
• Described CPU Hotplug handling
• Updated TXT configuration registers
• Documented new TXT Heap structures
• Added LCP_SBIOS_ELEMENT
• Documented processor and system state after SENTER/RLP wakeup
March 2011
-008 • Format updates June 2011
-009 • Numerous updates from prior author
• Added text for LCP details/authorities
• Corrected osinitdata offset 84 for versions 6+
April 2013
-010 • Corrections to data structures, algorithm detail versus prior versions
• Inclusion of TPM 2.0 changes and additions March 2014
-011 • Update TPM_PCR_INFO_SHORT structure and TPMS_QUOTE_INFO
structure Endianness May 2014
-012 • Added SGX requirement for TXT platform
• Updated LCP changes of TPM2.0 transitions
• Added TCG compliant TXT event log formats
• Documented TPM NV definitions
• Inclusion of detailed LCP checklists
July 2016
-013 • Added each MTRRs base must be the multiple of that MTRR's Prior to
GETSEC[SENTER] Execution August 2016
§ §
Overview
315168-013 9
1 Overview
Intel’s technology for safer computing, Intel® Trusted Execution Technology
(Intel® TXT), defines platform-level enhancements that provide the building blocks for
creating trusted platforms.
Whenever the word trust is used, there must be a definition of who is doing the
trusting and what is being trusted. This enhanced platform helps to provide the
authenticity of the controlling environment such that those wishing to rely on the
platform can make an appropriate trust decision. The enhanced platform determines
the identity of the controlling environment by accurately measuring the controlling
software (see section 1.1).
Another aspect of the trust decision is the ability of the platform to resist attempts to
change the controlling environment. The enhanced platform will resist attempts by
software processes to change the controlling environment or bypass the bounds set by
the controlling environment.
What is the controlling environment for this enhanced platform? The platform is a set
of extensions designed to provide a measured and controlled launch of system
software that will then establish a protected environment for itself and any additional
software that it may execute.
These extensions enhance two areas:
• The launching of the Measured Launched Environment (MLE)
• The protection of the MLE from potential corruption
The enhanced platform provides these launch-and-control interfaces using Safer Mode
Extensions (SMX).
The SMX interface includes the following functions:
• Measured launch of the MLE
• Mechanisms to ensure the above measurement is protected and stored in a secure
location
• Protection mechanisms that allow the MLE to control attempts to modify itself
1.1 Measurement and Intel® Trusted Execution
Technology (Intel® TXT)
Intel® TXT uses the term measurement frequently. Measuring software involves
processing the executable such that the result (a) is unique and (b) indicates changes
in the executable. A cryptographic hash algorithm meets these needs.
A cryptographic hash algorithm is sensitive to even one-bit changes to the measured
entity. A cryptographic hash algorithm also produces outputs that are sufficiently large
so the potential for collisions (where two hash values are the same) is extremely
small. When the term measurement is used in this specification, the meaning is that
the measuring process takes a cryptographic hash of the measured entity.
Overview
10 315168-013
The controlling environment is provided by system software such as an OS kernel or
VMM. The software launched using the SMX instructions is known as the Measured
Launched Environment (MLE). MLEs provide different launch mechanisms and
increased protection (offering protection from possible software corruption).
1.2 Dynamic Root of Trust
A central objective of the Intel® TXT platform is to provide a measurement of the
launched execution environment.
One measurement is made when the platform boots, using techniques defined by the
Trusted Computing Group (TCG). The TCG defines a Root of Trust for Measurement
(RTM) that executes on each platform reset; it creates a chain of trust from reset to
the measured environment. As the measurement always executes at platform reset,
the TCG defines this type of RTM as a Static RTM (SRTM).
Maintaining a chain of trust for a length of time may be challenging for an MLE meant
for use in Intel® TXT; this is because an MLE may operate in an environment that is
constantly exposed to unknown software entities. To address this issue, the enhanced
platform provides another RTM with Intel® TXT instructions. The TCG terminology for
this option is Dynamic Root of Trust for Measurement (DRTM). The advantage of a
DRTM (also called the ‘late launch’ option) is that the launch of the measured
environment can occur at any time without resorting to a platform reset. It is possible
to launch an MLE, execute for a time, terminate the MLE, execute without
virtualization, and then launch the MLE again. One possible sequence is:
1. During the BIOS load: (a) launch an MLE for use by the BIOS, (b) terminate the
MLE when its work is done, (c) continue with BIOS processing and hand off to an
OS.
2. Then, the OS loads and launches a different MLE.
In both instances, the platform measures each MLE and ensures the proper storage of
the MLE measurement value.
1.2.1 Launch Sequence
When launching an MLE, the environment must load two code modules into memory.
One module is the MLE. The other is known as an authenticated code (AC) module.
The AC module (also referred to as ACM) is only in use during the measurement and
verification process and is chipset-specific. The chipset vendor digitally signs it; the
launch process must successfully validate the digital signature before continuing.
With the AC module and MLE in memory, the launching environment can invoke the
GETSEC[SENTER] instruction provided by SMX.
GETSEC[SENTER] broadcasts messages to the chipset and other physical or logical
processors in the platform. In response, other logical processors perform basic
cleanup, signal readiness to proceed, and wait for messages to join the environment
created by the MLE. As this sequence requires synchronization, there is an initiating
logical processor (ILP) and responding logical processor(s) (RLP(s)). The ILP must be
the system bootstrap processor (BSP), which is the processor with IA32_APIC_BASE
MSR.BSP = 1. RLPs are also often referred to as application processors (APs).
Overview
315168-013 11
After all logical processors signal their readiness to join and are in the wait state, the
initiating logical processor loads, authenticates, and executes the AC module. The AC
module tests for various chipset and processor configurations and ensures the
platform has an acceptable configuration. It then measures and launches the MLE.
The MLE initialization routine completes system configuration changes (including
redirecting INITs, SMIs, interrupts, etc.); it then issues a new SMX instruction that
wakes up the responding logical processors (RLPs) and brings them into the measured
environment. At this point, all logical processors and the chipset are correctly
configured.
At some later point, it is possible for the MLE to exit and then be launched again,
without issuing a system reset.
1.3 Storing Measurement
SMX operation during the launch provides an accurate measurement of the MLE. After
creating the measurement, the initiating logical processor stores that measurement in
the trusted platform module (TPM), defined by the TCG. An enhanced platform
includes mechanisms that ensure that the measurement of the MLE (completed during
the launch process) is properly reported to the TPM.
With the MLE measurement in the TPM, the MLE can use the measurement value to
protect sensitive information and detect potential unauthorized changes to the MLE
itself.
1.4 Controlled Take-down
Because the MLE controls the platform, exiting the MLE is a controlled process. The
process includes: (a) shutting down any guest virtual machines (VMs) if they were
created; (b) ensuring that memory previously used does not leak sensitive
information.
The MLE cleans up after itself and terminates the MLE control of the environment. If a
virtual machine manager (VMM) was running, the MLE may choose to turn control of
the platform over to the software that was running in one of the VMs.
1.5 SMX and VMX Interaction
A VM abort may occur while in SMX operation. This behavior is described in the Intel
64 and IA-32 Software Developer Manual, Volume 3B. Note that entering
authenticated code execution mode or launching of a measured environment affects
the behavior and response of the logical processors to certain external pin events.
1.6 Authenticated Code Module
To support the establishment of a measured environment, SMX enables the capability
of an authenticated code execution mode. This provides the ability for a special code
module, referred to as an authenticated code module (ACM, also frequently referred to
as “SINIT”), to be loaded into internal RAM (referred to as authenticated code
Overview
12 315168-013
execution area) within the processor. The AC module is first authenticated and then
executed using a tamper resistant mechanism.
Authentication is achieved through the use of a digital signature in the header of the
AC module. The processor calculates a hash of the AC module and uses the result to
validate the signature. Using SMX, a processor will only initialize processor state or
execute the AC module if it passes authentication. Since the authenticated code
module is held within the internal RAM of the processor, execution of the module can
occur in isolation with respect to the contents of external memory or activities on the
external processor bus.
1.7 Chipset Support
One important feature the chipset provides is direct memory access (DMA) protection
via Intel® Virtualization Technology (Intel® VT) for Directed I/O (Intel® VT-d). Intel®
VT-d, under control of the MLE, allows the MLE to protect itself and any other software
such as guest VMs from unauthorized device access to memory. Intel VT-d blocks
access to specific physical memory pages and the enforcement of the block occurs for
all DMA access to the protected pages. See Chapter 1.11 for more information on DMA
protection mechanisms.
The Intel® TXT architecture also provides extensions that access certain chipset
registers and TPM address space.
Chipset registers that interact with SMX are accessed from two regions of memory by
system software using memory read/write protocols. These two memory regions,
Intel® TXT Public space and Intel® TXT private space, are mappings to the same set
of chipset registers but with different read/write permissions depending on which
space the memory access came through. The Intel® TXT Private space is not
accessible to system software until it is unlocked by SMX instructions.
The sets of interface registers accessible within a TPM device are grouped by a locality
attribute and are a separate set of address ranges from the Intel® TXT Public and
Private spaces. The following localities are defined:
• Locality 0 : Non-trusted and legacy TPM operation
• Locality 1 : An environment for use by the Trusted Operating System
• Locality 2 : MLE access
• Locality 3 : Authenticated Code Module
• Locality 4 : Intel® TXT hardware use only
Similar to Intel® TXT Public and Private space, some of these localities are only
accessible via SMX instructions and others are not accessible by software until
unlocked by SMX instructions.
1.8 TPM Usage
Intel® TXT makes extensive use of the trusted platform module (TPM) defined by the
Trusted Computing Group (TCG) in the TCG TPM Specification, Version 1.2 and the
successor TCG TPM Specification 2.0. The TPM provides a repository for
measurements and the mechanisms to make use of the measurements. The system
Overview
315168-013 13
makes use of the measurements to both report the current platform configuration and
to provide long-term protection of sensitive information.
The TPM stores measurements in Platform Configuration Registers (PCRs). Each PCR
provides a storage area that allows an unlimited number of measurements in a fixed
amount of space. They provide this feature by an inherent property of cryptographic
hashes. Outside entities never write directly to a PCR register, they “extend” PCR
contents. The extend operation takes the current value of the PCR, appends the new
value, performs a cryptographic hash on the combined value, and the hash result is
the new PCR value. One of the properties of cryptographic hashes is that they are
order dependent. This means hashing A then B produces a different result from
hashing B then A. This ordering property allows the PCR contents to indicate the order
of measurements.
Sending measurement values from the measuring agent to the TPM is a critical
platform task. The Dynamic Root of Trust for Measurement (DRTM) requires specific
messages to flow from the DRTM to the TPM. The Intel® TXT DRTM is the
GETSEC[SENTER] instruction and the system ensures GETSEC[SENTER] has special
messages to communicate to the TPM. These special messages take advantage of TPM
localities 3 and 4 to protect the messages and inform the TPM that GETSEC[SENTER]
is sending the messages.
With the release of the TPM 2.0 specification and supporting devices, many changes
may be required for TXT launch. TPM 2.0 devices can support a variety of
cryptographic algorithms, and a single device will often support multiple digest and
asymmetric signature algorithms. For the purposes of this document, TPM 1.2 and
2.0 devices will be referred to as two distinct families. The MLE and ACM determine
that the platform TPM is either 1.2 or 2.0 family. In subsequent discussion, we will
refer to actions and structures in the presence of a 1.2 or 2.0 TPM as TPM1.2 mode
and TPM2.0 mode, respectively.
1.9 Hash Algorithm Support
TPM 2.0 family devices provide PCRs in banks—that is, one bank of PCRs for each
supported digest algorithm. For example, a TPM that supports three hashing
algorithms will have three banks of PCRs and thus “measuring an object into PCRn”
implies hashing that object using each of the three hashing algorithms and extending
that hash digest into PCRn of the appropriate bank. The TPM 2.0 specification
enumerates all the hash algorithms it allows; of those, the current TXT components
support at most SHA1, SHA256, SHA384, SHA512, and SM3_256.
TPM 2.0 devices support algorithm agile commands. These “event” commands extend
measurements into all existing PCR banks. Measuring objects of significant size using
event commands may incur performance penalties.
Alternatively, embedded software can be used to compute hashes, and the results
then extended into PCRs using non-agile commands. While this may be more
efficient, software support for all the hashing algorithms supported by the TPM may
not be present. In this situation, PCRs in banks utilizing algorithms unsupported by
the software present will be capped with the value “1”.
Whether extend calculations will be done using TPM hardware event commands or
software implementations is an MLE decision, and will be communicated to the
launched ACM via the “flags” field in Table .
Overview
14 315168-013
TPM 1.2 devices only support SHA1 as digest method. To simplify discussion, for both
device families, digest methods will be denoted as DIGEST. For TPM1.2 this means
SHA1. For TPM2.0, this means all of the methods supported by the device.
In TPM1.2 mode certain values are extended into PCRs without hashing. Some of
them are extended this way historically; other are using extends of zero digests or
constant values as an indication of various platform states or events.
These extends will continue to be supported in TPM1.2 mode without changes to
ensure backwards compatibility.
In TPM2.0 this practice is discouraged and simply cannot be supported when
Maximum Agility Extend Policy is enforced. Therefore in all above cases we will not
extend constant values as is but will measure them instead – that is we will hash
these constant values and extend resultant hashes into PCRs.
All such cases are flagged in the explanation of details/authorities measurements
below.
1.10 PCR Usage
As part of the measured launch, Intel® TXT will extend measurements of the
elements and configuration values of the dynamic root of trust into certain TPM PCRs.
The values comprising these measurements (indicated below) are provided in the
SinitMleData structure described in section C.5.
While the MLE may choose to extend additional values into these PCRs, the values
described below are those present immediately after the MLE receives control
following the GETSEC[SENTER] instruction.
Since these values are arrived at by a series of measurement and extend operation
combinations, determining their derivation requires a trace or log of the extending
steps executed. These steps are recorded in the TPM Event Log, described in
Appendix G.
1.10.1 Legacy Usage
Legacy—or original—PCR usage separates the values in the PCRs according to
platform elements and MLE. The platform elements of the trusted computing base
(TCB), such as SINIT and launch control policy (LCP), are put into PCR 17 and the MLE
is extended into PCR 18. The exact contents of PCRs 17 and 18 are specified below.
Legacy usage corresponds to a value of 0 in bit 4 of the Capabilities field (see Table
2-2). Because this needs to be compatible with earlier versions of the Capabilities
field, for which bit 4 was reserved, inverse logic is used to represent this.
Legacy usage is not supported when the TPM present is a 2.0 family device. Hence
the discussion in this section refers to SHA1 explicitly.
1.10.1.1 PCR 17
PCR 17 is initialized using the TPM_HASH_START/TPM_HASH_END sequence. The
HASH_DATA provided in this sequence is the concatenation of the hash of the SINIT
Overview
315168-013 15
ACM that was used in the launch process and the 4 byte value of the SENTER
parameters (in the EDX register and also in SinitMleData.EdxSenterFlags). As part of
this sequence, PCRs 17-23 are reset to 0. The hash of SINIT is also stored in the
SinitMleData.SinitHash field. If the SINIT to MLE Data Table (section C.5) version is 7
or greater, the hash of the SINIT ACM is performed using SHA-256, otherwise using
SHA1. If a SHA256 hash was used, the SinitMleData.SinitHash field will contain the
value of PCR 17 after the initial extend operation (see below for more details).
PCR 17 is then extended with the SHA1 hash of the following items concatenated in
this order:
BIOS ACM ID – SinitMleData.BiosAcmID (20 bytes)
System Management Interrupt (SMI) Transfer Monitor (STM) opt-in indicator –
SinitMleData.MsegValid (8 bytes)
SHA1 (secure hash algorithm v1) hash of the STM (or all 0s if opt-out) –
SinitMleData.StmHash (20 bytes)
LCP Control Field of used policy (PS or PO) – SinitMleData.PolicyControl (4 bytes)
SHA1 hash of used policy (or all 0s if chosen not to be extended) –
SinitMleData.LcpPolicyHash (20 bytes)
MLE-chosen Capabilities (or all 0s if chosen not to be extended) –
OsSinitData.Capabilities (4 bytes)
If the SINIT to MLE Data Table (section C.5) version is 8 or greater, an additional
4 byte field representing processor-based S-CRTM status is concatenated. This
field represents whether the S-CRTM (Static Core Root of Trust for Measurement)
was implemented in the processor hardware (1) or in BIOS (0).
If SinitMleData.Version = 6, PCR 17’s final value will be:
Extend (SHA1(SinitMleData.SinitHash | SinitMleData.EdxSenterFlags) )
Extend (SHA1 ( SinitMleData.BiosAcm.ID | SinitMleData.MsegValid |
SinitMleData.StmHash | SinitMleData.PolicyControl | SinitMleData.LcpPolicyHash |
(OsSinitData.Capabilities, 0) ) )
If SinitMleData.Version = 7, PCR 17’s final value will be:
SHA1 ( SinitMleData.SinitHash | SHA1 ( SinitMleData.BiosAcm.ID |
SinitMleData.MsegValid | SinitMleData.StmHash | SinitMleData.PolicyControl |
SinitMleData.LcpPolicyHash | (OsSinitData.Capabilities, 0) ) )
If SinitMleData.Version >= 8, PCR 17’s final value will be:
SHA1 (SinitMleData.SinitHash | SHA1 (SinitMleData.BiosAcm.ID |
SinitMleData.MsegValid | SinitMleData.StmHash | SinitMleData.PolicyControl |
SinitMleData.LcpPolicyHash | (OsSinitData.Capabilities, 0) |
SinitMleData.ProcessorSCRTMStatus) )
Where the Extend() operation is a SHA1 hash of the previous value in the PCR
concatenated with the value being extended (the previous value is 20 bytes of 0s in
the case of the first extend to a PCR).
Overview
16 315168-013
1.10.1.2 PCR 18
PCR 18 will be extended with the SHA1 hash of the MLE, as reported in the
SinitMleData.MleHash field.
Thus, PCR 18’s final value will be:
Extend (SinitMleData.MleHash)
1.10.2 Details and Authorities Usage
This usage of the PCRs separates the values in the PCRs according to whether the
value extended is the actual measurement of a given entity (a detail) or represents
the authority for the given entity (an authority). Details are extended to PCR 17 and
authorities to PCR 18. Evaluators who do not care about rollback can use the
authorities PCR (18) and it should remain the same even when elements of the TCB
are changed.
This usage corresponds to a value of 1 in bit 5 of the Capabilities field (see Table 2-2).
Note: in the following sections DIGEST value is obtained as a result of hashing of
respective data. Used hash algorithm is determined by respective PCR bank.
1.10.2.1 PCR 17 (Details)
“Details” measurements include hashes of all components participating in establishing
of trusted execution environment and due to very nature of hash algorithm change of
any component entail change of final PCR17 value.
The following hashes are extended to PCR17 in the order given:
BIOS AC registration info retrieved from AUX Index. In TPM 1.2 mode, 20
bytes of that data, in TPM 2.0 mode, DIGEST of 32 bytes of that data.
DIGEST of Processor S-CRTM status coded as DWORD.
DIGEST of PolicyControl field of used policy (PS or PO) coded as DWORD
DIGEST of all matching elements used by the policy. If there is no policy
used, for 1.2 family, this digest is zero; for 2,0 family, this is DIGEST(0x0)
DIGEST of STM. If STM is not enabled, for 1.2 family, this digest is zero; for
2.0 family, this is DIGEST(0x0)
DIGEST of Capability field of OsSinitData table, coded as DWORD
DIGEST of MLE.
1.10.3 PCR 18 (Authorities)
“Authority” measurements include hashes of some unique identifying properties of
signing authorities such as public signature verification keys. This enables the same
authority to issue an update of component without affecting the final PCR18 value,
because the signing authority is unchanged.
The following hashes are extended to PCR18 in the order given:
Overview
315168-013 17
DIGEST of public key modulus used to verify SINIT signature.
DIGEST of Processor S-CRTM status coded as DWORD – same value as
extended to PCR17.
DIGEST of Capability field of OsSinitData table, coded as DWORD – same
value as extended to PCR17.
DIGEST of PolicyControl field of used policy (platform supplier (PS) or platform
owner (PO)) coded as DWORD – same value as extended to PCR17.
DIGEST of LCP – DIGEST of concatenation of hashes of lists containing
matching elements. If no policy, for 1.2 family, this digest is zero; for 2.0
family, it is DIGEST(0x0)
1.11 DMA Protection
This chapter briefly describes the two chipset mechanisms that can be used to protect
regions of memory from DMA access by bus master devices. More details on these
mechanisms can be found in the External Design Specification (EDS) of the targeted
chipset family and Intel® Virtualization Technology for Directed I/O Architecture
Specification.
1.11.1 DMA Protected Range (DPR)
The DMA Protected Range (DPR) is a region of contiguous physical memory whose last
byte is the byte before the start of TXT segment (TSEG), and which is protected from
all DMA access. The DPR size is set and locked by BIOS. This protection is applied to
the final physical address after any other translations (e.g. Intel VT-d, graphics
address remapping table (GART), etc.).
The DPR covers the Intel® TXT heap and SINIT AC Module reserved memory (as
specified in the TXT.SINIT.BASE/TXT.SINIT.SIZE registers). On current systems it is
no less than 3MB in size, and though this may change in the future it will always be
large enough to cover the heap and SINIT regions.
The MLE itself may reside in the DPR as long as it does not conflict with either the
SINIT or heap areas. If it does reside in the DPR then the Intel VT-d Protected
Memory Regions need not cover it.
1.11.2 Protected Memory Regions (PMRs)
The Intel® VT-d Protected Memory Regions (PMRs) are two ranges of physical
addresses that are protected from DMA access. One region must be in the lower 4GB
of memory and the other may be anywhere in address space. Either or both may be
unused.
The use of the PMRs is not mutually exclusive of DMA remapping. If the MLE enables
DMA remapping, it should place the Intel VT-d page tables within the PMR region(s) in
order to protect them from DMA activity prior to turning on remapping. While it is not
required that PMRs be disabled once DMA remapping is enabled, if the MLE wants to
manage all DMA protection through remapping tables then it must explicitly disable
the PMR(s).
Overview
18 315168-013
The MLE may reside within one of the PMR regions. If the MLE is not within the DPR
region then it must be within one of the PMR regions, else SINIT will not permit the
environment to be launched.
For more details of the PMRs, see the Intel® Virtualization Technology for
Directed I/O Architecture Specification.
1.12 Intel® TXT Shutdown
1.12.1 Reset Conditions
When an Intel® TXT shutdown condition occurs, the processor or software writes an
error code indicating the reason for the failure to the TXT.ERRORCODE register. It
then writes to the TXT.CMD.RESET command register, initiating a platform reset. After
the write to TXT.CMD.RESET, the processor enters a shutdown sleep state with all
external pin events, bus or error events, machine check signaling, and
MONITOR/MWAIT event signaling masked. Only the assertion of reset back to the
processor takes it out of this sleep state. The Intel® TXT error code register is not
cleared by the platform reset; this makes the error code accessible for post-reset
diagnostics.
The processor can generate an Intel® TXT shutdown during execution of certain
GETSEC leaf functions (for example: ENTERACCS, EXITAC, SENTER, SEXIT), where
recovery from an error condition is not considered reliable. This situation should be
interpreted as an abort of authenticated execution or measured environment launch.
A legacy IA-32 triple-fault shutdown condition is also converted to an Intel® TXT
shutdown sequence if the triple-fault shutdown occurs during authenticated code
execution mode or while the measured environment is active. The same is true for
other legacy non-SMX specific fault shutdown error conditions. Legacy shutdown to
Intel® TXT shutdown conversions are defined as the mode of operation between:
• Execution of the GETSEC functions ENTERACCS issued by software and EXITAC
issued by the ACM at completion
• Recognition of the message signaling the beginning of the processor rendezvous
after GETSEC[SENTER] and the message signaling the completion of the processor
rendezvous
Additionally, there is a special case. If the processor is in VMX operation while the
measured environment is active, a triple-fault shutdown condition that causes a guest
exiting event back to the Virtual Machine Monitor (VMM) supersedes conversion to the
Intel® TXT shutdown sequence. In this situation, the VMM remains in control after the
error condition that occurred at the guest level and there is no need to abort
processor execution.
Given the above situation, if the triple-fault shutdown occurs at the root level of the
MLE or a virtual machine extensions (VMX) abort is detected, then an Intel® TXT
shutdown sequence is signaled. For more details on a VMX abort, see Chapter 23, “VM
Exits,” in the Intel 64 and IA-32 Software Developer Manuals, Volume 3B.
§ §
Measured Launched Environment (MLE)
315168-013 19
2 Measured Launched
Environment (MLE)
Intel® TXT can be used to launch any type of code. However, this section describes
the launch, operation and teardown of a Virtual Machine Monitor (VMM) using Intel®
TXT; any other code would have a similar sequence.
2.1 MLE Architecture Overview
Any Measured Launched Environment (MLE) will generally consist of three main
sections of code: the initialization, the dispatch routine, and the shutdown. The
initialization code is run each time the Intel® TXT environment is launched. This code
includes code to setup the MLE on the ILP and join code to initialize the RLPs.
After initialization, the MLE behaves like the unmeasured version would have; in the
case of a VMM, this is trapping various guest operations and virtualizing certain
processor states.
Finally the MLE prepares for shutdown by again synchronizing the processors, clearing
any state and executing the GETSEC[SEXIT] instruction.
Table 2-1 shows the format of the MLE Header structure stored within the MLE image.
The SINIT AC module uses the MLE Header structure to set up the correct initial MLE
state and to find the MLE entry point. The header is part of the MLE hash.
Table 2-1. MLE Header Structure
Field Offset Size
(bytes) Description
UUID (universally unique
identifier) 0 16 Identifies this structure
HeaderLen 16 4 Length of header in bytes
Version 20 4 Version number of this structure
EntryPoint 24 4 Linear entry point of MLE
FirstValidPage 28 4 Starting linear address of (first valid
page of) MLE
MleStart 32 4 Offset within MLE binary file of first byte
of MLE, as specified in page table
MleEnd 36 4 Offset within MLE binary file of last byte
+ 1 of MLE, as specified in page table
Capabilities 40 4 Bit vector of MLE-supported capabilities
CmdlineStart 44 4 Starting linear address of command line
CmdlineEnd 48 4 Ending linear address of command line
Measured Launched Environment (MLE)
20 315168-013
UUID: This field contains a UUID which uniquely identifies this MLE Header Structure.
The UUID is defined as follows:
ULONG UUID0; // 9082AC5A
ULONG UUID1; // 74A7476F
ULONG UUID2; // A2555C0F
ULONG UUID3; // 42B651CB
This UUID value should only exist in the MLE (binary) in this field of the MLE header.
This implies that this UUID should not be stored as a variable nor placed in the code
to be assigned to this field. This can also be ensured by analyzing the binary.
HeaderLen: this field contains the length in bytes of the MLE Header Structure.
Version: this field contains the version of the MLE header, where the upper two bytes
are the major version and the lower two bytes are the minor version. Changes in the
major version indicate that an incompatible change in behavior is required of the MLE
or that the format of this structure is not backwards compatible. Version 2.1
(20001H) is the currently supported version.
EntryPoint: this field is the linear address, within the MLE’s linear address space, at
which the ILP will begin execution upon successful completion of the GETSEC[SENTER]
instruction.
FirstValidPage: this field is the starting linear address of the MLE. This will be
verified by SINIT to match the first valid entry in the MLE page tables.
MleStart / MleEnd: these fields are intended for use by software that needs to know
which portion of an MLE binary file is the MLE, as defined by its page table. This
might be useful for calculating the MLE hash when the entire binary file is not being
used as the MLE.
Capabilities: this bit vector represents TXT-related capabilities that the MLE
supports. It will be used by the SINIT AC module to determine whether the MLE is
compatible with it and as needed for any optional capabilities. The currently defined
bits for this are:
Table 2-2. MLE/SINIT Capabilities Field Bit Definitions
Bit
position Description
0 Support for GETSEC[WAKEUP] for RLP wakeup
All MLEs should support this.
1 = supported/requested
0 = not supported
1 Support for RLP wakeup using MONITOR address (SinitMleData.RlpWakeupAddr)
All MLEs should support this.
1 = supported/requested
0 = not supported
Measured Launched Environment (MLE)
315168-013 21
Bit
position Description
2 The ECX register will contain the pointer to the MLE page table on return from
SINIT to the MLE EntryPoint
1 = supported/requested
0 = not supported
3 STM support
1 = supported/requested
0 = not supported
4 TPM 1.2 family: Legacy PCR usage support (negative logic is used for backward
compatibility)
0 = supported/requested
1 = not supported
TPM 2.0 family: reserved/ignored
5 TPM 1.2 family: Details/authorities PCR usage support
This usage takes precedence over legacy usage if both are requested
1 = supported/requested
0 = not supported
TPM 2.0 family: reserved/ignored
7-6 Platform Type
00: legacy / platform undefined
01: client platform ACM
10: server platform ACM
11: reserved / illegal
8 MAXPHYADDR supported
0: 36 bits MTRR masks computed, regardless of actual width
1: actual width MTRR masks computed as reported by CPUID function
0x80000008
9 Supported format of TPM 2.0 event log:
= 0 – Original TXT TPM 2.0 Event Log
= 1 – TCG PC Client Platform. EFI Protocol Specification Rev 4” compatible Event
Log
31:10 Reserved (must be 0)
Note: Legacy TBOOT computes MTRR masks assuming 36 bits width of address bus.
This may lead to creation of potentially disjoint WB cache ranges and violation of
CRAM protections. To remedy case and support legacy MLE/SINIT behavior the
following has been added:
BIT8 of Capabilities field in ACM info table and MLE header was defined to indicate use
of bus width method. Both MLE and SINIT will examine this bit in counterpart module
and amend execution as follows in Truth Table.
Measured Launched Environment (MLE)
22 315168-013
Table 3-1: Truth Table of SINIT / MLE functionality
MLE SINIT Functionality
Legacy
BIT8 = 0 Legacy
BIT8 = 0 Both use 36 bits
New BIT8
= 1 Legacy
BIT8 = 0 MLE sees BIT==0 and prepares 36-bit MTRR masks. Legacy
SINIT ignores BIT8 in MLE header
Legacy
BIT8 = 0 New BIT8
= 1 Legacy MLE ignores BIT8 in SINIT ACM Info Table and prepares
36-bit MTRR masks. SINIT checks MLE header and validates
masks as 36 bits
New BIT8
= 1 New BIT8
= 1 Both use actual bus width.
CmdlineStart / CmdlineEnd: these fields are intended for use by software that
needs to calculate the MLE hash, for MLEs that include their command lines in their
identity. These are linear addresses within the MLE of the beginning and end of a
buffer that will contain the command line. The buffer is padded with bytes of 0x0 at
the end. MLEs that do not include the command line in their identity should set these
fields to 0.
2.2 MLE Launch
At some point system software will start an Intel® TXT measured environment. This
may be done at operating system loader time or could be done after the operating
system boots. From this point on we will assume that the operating system is starting
the Intel® TXT measured environment and refer to this code as the system software.
After the measured environment startup, the application processors (RLPs) will not
respond to system inter-processor interrupts (SIPIs) as they did before SENTER. Once
the measured environment is launched, the RLPs cannot run the real-mode MP startup
code and their startup must be initiated by an alternate method. The new MP startup
algorithm does not allow the RLPs to leave protected mode with paging on. The OS
may also be required to detect whether a measured environment has been established
and use this information to decide which MP startup algorithm is appropriate (the
standard MP startup algorithm or the modified algorithm).
This section shows the pseudocode for preparing the system for the SMX measured
launch. The following describes the process in a number of sub-sections:
• Intel® TXT detection and processor preparation
• Detection of previous errors
• Loading the SINIT AC module
• Loading the MLE and processor rendezvous
• Performing a measured launch
2.2.1 Intel® TXT Detection and Processor Preparation
Lines 1 - 4: Before attempting to launch the measured environment, the system
software should check that all logical processors support VMX and SMX (the check for
VMX support is not necessary if the environment to be launched will not use VMX).
Measured Launched Environment (MLE)
315168-013 23
For single processor socket systems, it is sufficient if this action is only performed by
the ILP. This includes physical processors containing multiple logical processors. In
order to correctly handle multiple processor socket systems, this check must be
performed on all logical processors. It is possible that two physical processor within
the same system may differ in terms of SMX and VMX capabilities.
For details on detecting and enabling VMX see chapter 19, “Introduction to Virtual-
Machine Extensions”, in the Intel 64 and IA-32 Software Developer Manuals, Volume
3B. For details on detecting and enabling SMX support see chapter 6, “Safer Mode
Extensions Reference”, in the Intel 64 and IA-32 Software Developer Manuals, Volume
2B.
Lines 5 - 9: System software should check that the chipset supports Intel® TXT prior
to launching the measured environment. The presence of the Intel® TXT chipset can
be detected by executing GETSEC[CAPABILITIES] with EAX=0 & EBX=0. This
instruction will return the ‘Intel® TXT Chipset’ bit set in EAX if an Intel® TXT chipset
is present. The processor must enable SMX before executing the GETSEC instruction.
Lines 10 – 12: System software should also verify that the processor supports all of
the GETSEC instruction leaf indices that will be needed. The minimal set of
instructions required will depend on the system software and MLE, but is most likely
SENTER, SEXIT, WAKEUP, SMCTRL, and PARAMETERS. The supported leaves are
indicated in the EAX register after executing the GETSEC[CAPABILITIES] instruction as
indicated above.
Listing 1. Intel® TXT Detection Pseudocode
//
// Intel® TXT detection
// Execute on all logical processors for compatibility with
// multiple processor systems
//
1. CPUID(EAX=1);
2. IF (SMX not supported) OR (VMX not supported) {
3. Fail measured environment startup;
4. }
//
// Enable SMX on ILP & check for Intel® TXT chipset
//
5. CR4.SMXE = 1;
6. GETSEC[CAPABILITIES];
7. IF (Intel® TXT chipset NOT present) {
8. Fail measured environment startup;
9. }
10. IF (All needed SMX GETSEC leaves are NOT supported) {
11. Fail measured environment startup;
12. }
2.2.2 Detection of Previous Errors
In order to prevent a cycle of failures or system resets, it is necessary for the system
software to check for errors from a previous launch. Errors that are detected by
system software prior to executing the GETSEC[SENTER] instruction will be specific to
Measured Launched Environment (MLE)
24 315168-013
that software and, if persistent, will be in a manner specific to the software. Errors
generated during execution of the GETSEC[SENTER] instruction result in a system
reset and the error code being stored in the TXT.ERRORCODE register. Possible
remediation steps are described in section 4.2.
Lines 1 - 3: The error code from an error generated during the GETSEC[SENTER]
instruction is stored in the TXT.ERRORCODE register, which is persistent across soft
resets. Non-zero values other than 0xC000001 indicate an error. Error codes are
specific to an SINIT AC module and can be found in a text file that is distributed with
the module. Errors that are not AC-module specific are listed in Appendix I
Lines 4 - 6: If the TXT_RESET.STS bit of the TXT.ESTS register is set, then in order to
maintain TXT integrity the GETSEC[SENTER] instruction will fail. System software
should detect this condition as early as possible and terminate the attempted
measured launch and report the error. The cause of the error must be corrected if
possible, and the system should be power-cycled to clear this bit and permit a launch.
Listing 2. Error Detection Pseudocode
//
// Detect previous GETSEC[SENTER] failures
//
1. IF (TXT.ERRORCODE != 0 && TXT.ERRORCODE != SUCCESS) {
2. Terminate measured launch ;
3. Report error ;
4. If remedial action known {
5. Take remedial action ;
6. Power-cycle system ;
7. }
8. }
//
// Detect previous TXT Reset
//
9. IF (TXT.ESTS[TXT_RESET.STS] != 0) {
10. Report error ;
11. Terminate measured launch ;
12. }
2.2.3 Loading SINIT AC Module
This action is only performed by the ILP.
BIOS may already have the correct SINIT AC module loaded into memory or system
software may need to load the SINIT code from disk into memory. The system
software may determine if an SINIT AC module is already loaded by examining the
preferred SINIT load location (see below) for a valid SINIT AC module header.
System software should always use the most recent version of the SINIT AC module
available to it. It can determine this by comparing the Date fields in the AC module
headers.
Measured Launched Environment (MLE)
315168-013 25
System software should also match a prospective SINIT AC module to the chipset
before loading and attempting to launch the module. This is described in the next two
sections of this document.
System software owns the policy for deciding which SINIT module to load. In many
case, it must load the previously loaded SINIT AC module in order to unseal data
sealed to a previously launched environment. If an SINIT AC module is to be changed
(e.g. upgraded to the latest version), any secrets sealed to the current measured
launch may require migration prior to launching via an updated SINIT AC module. It
should be noted that server platforms typically carry an appropriate SINIT AC module
within their BIOS, and that a BIOS update may result in an SINIT AC module update
outside of system software control. For further discussion on this issue, see 4.3.1.
The BIOS reserves a region of physically contiguous memory for the SINIT AC
module, which it specifies through the TXT.SINIT.BASE and TXT.SINIT.SIZE Intel®
TXT configuration registers. By convention, at least 192 KBytes of physically
contiguous memory is allocated for the purpose of loading the SINIT AC module; this
has increased to 320 Kbytes for latest generation processors. System software must
use this region for any SINIT AC module that it loads.
The SINIT AC module must be located on a 4 KBytes aligned memory location. The
SINIT AC module must be mapped WB using the MTRRs and all other memory must
be mapped to one of the supportable memory types returned by
GETSEC[PARAMETERS]. The MTRRs that map the SINIT AC module must not overlap
more than 4 KBytes of memory beyond the end of the SINIT AC image. See the
GETSEC[ENTERACCS] instruction and the Authenticated Code Module Format, section
A.1, for more details on these restrictions.
The pages containing the SINIT AC module image must be present in memory before
attempting to launch the measured environment. The SINIT AC module image must
be loaded below 4 GBytes. System software should check that the SINIT AC module
will fit within the AC execution region as specified by the GETSEC[PARAMETERS] leaf.
System software should not utilize the memory immediately after the SINIT AC
module up to the next 4 KBytes boundary. On certain Intel® TXT implementations,
execution of the SINIT AC module will corrupt this region of memory.
2.2.3.1 Matching an AC Module to Platform
As part of system software loading an SINIT AC module, the system software should
first verify that the file to be loaded is really an SINIT AC module. This may be done at
installation time or runtime. Lines 1 - 13 in Listing 3 below show how to do this.
Each AC module is designed for a specific chipset or set of chipsets, platform type,
and, optionally, processor(s). Software can examine the Chipset ID and Processor ID
Lists embedded in the AC module binary to determine which chipsets and processors
an AC module supports. Software should read the chipset’s TXT.DIDVID register and
parse the Chipset ID List to find a matching entry. If the AC module also contains a
Processor ID List, then software should also match the AC module against the
processor CPUID and IA32_PLATFORM_ID MSR. If the ACM Info Table version is 5 or
greater, software should verify that the Platform Type bits within the Capabilities field
match that of the current platform (server versus client). Attempting to execute an
AC module that does not match the chipset and processor, and platform type when
specified, will result in a failure of the AC module to complete normal execution and
an Intel® TXT Shutdown.
Measured Launched Environment (MLE)
26 315168-013
Listing 3. AC Module Matching Pseudocode
TXT_ACM_HEADER *AcmHdr; // see Table A-
TXT_CHIPSET_ACM_INFO_TABLE *InfoTable; // see Table A-3
//
// Find the Chipset AC Module Information Table
//
1. AcmHdr = (TXT_ACM_HEADER *)AcmImageBase;
2. UserAreaOffset = (AcmHdr->HeaderLen + AcmHdr->ScratchSize)*4;
3. InfoTable = (TXT_CHIPSET_ACM_INFO_TABLE *)(AcmBase +
UserAreaOffset);
//
// Verify image is really an AC module
//
4. IF (InfoTable->UUID0 != 0x7FC03AAA) OR
5. (InfoTable->UUID1 != 0x18DB46A7) OR
6. (InfoTable->UUID2 != 0x8F69AC2E) OR
7. (InfoTable->UUID3 != 0x5A7F418D) {
8. Fail: not an AC module;
9. }
//
// Verify it is an SINIT AC module
//
10. IF (AcmHdr->ModuleType != 2) OR
11. (InfoTable->ChipsetACMType != 1) {
12. Fail: not an SINIT AC module;
13. }
//
// Verify that platform type and platform match, if specified
//
14. IF (InfoTable->Version > 5) {
15. IF (InfoTable->Capabilities[7:6] != 01 AND
16. PlatformType == CLIENT) {
17. Fail: Non-client ACM on client platform
18. }
19. IF (InfoTable->Capabilities[7:6] != 10 AND
20. PlatformType == SERVER) {
21. Fail: Non-server ACM on server platform
22. }
23. }
//
// Verify AC module and chipset production flags match
//
24. IF (TXT.VER.FSBIF != 0xFFFFFFFF) {
25. IF (AcmHdr->Flags[15] == TXT.VER.FSBIF[31]) {
26. Fail: production flags mismatch;
27. }
Measured Launched Environment (MLE)
315168-013 27
28. }
29. ELSE IF (AcmHdr->Flags[15] == TXT.VER.EMIF[31]) {
30. Fail: production flags mismatch;
31. }
//
// Match AC module to system chipset
//
TXT_ACM_CHIPSET_ID_LIST *ChipsetIdList; // see Table A-
TXT_ACM_CHIPSET_ID *ChipsetId; // see Table A-
32. ChipsetIdList = (TXT_ACM_CHIPSET_ID_LIST *)
33. (AcmImageBase + InfoTable->ChipsetIdList);
//
// Search through all ChipsetId entries and check for a match.
//
34. FOR (i = 0; i < ChipsetIdList->Count; i++) {
35. //
36. // Check for a match with this ChipsetId entry.
37. //
38. ChipsetId = ChipsetIdList->ChipsetIDs[i];
39. IF ((TXT.DIDVID[VID] == ChipsetId->VendorId) &&
40. (TXT.DIDVID[DID] == ChipsetId->DeviceId) &&
41. ((((ChipsetId->Flags & 0x1) == 0) &&
42. (TXT.DIDVID[RID] == ChipsetId->RevisionId)) ||
43. (((ChipsetId->Flags & 0x1) == 0x1) &&
44. (TXT.DIDVID[RID] & ChipsetId->RevisionId != 0)))) {
45. AC module matches system chipset;
46. GOTO CheckProcessor;
47. }
48. }
49. Fail: AC module does not match system chipset;
CheckProcessor:
//
// Match AC module to processor
//
TXT_ACM_PROCESSOR_ID_LIST *ProcessorIdList; // see Table A-
TXT_ACM_PROCESSOR_ID *ProcessorId; // see Table A-
50. ProcessorIdList = (TXT_ACM_PROCESSOR_ID_LIST *)
51. (AcmImageBase + InfoTable->ProcessorIdList);
//
// Search through all ProcessorId entries and check for a match.
//
52. FOR (i = 0; i < ProcessorIdList->Count; i++) {
53. //
54. // Check for a match with this ProcessorId entry.
55. //
56. ProcessorId = ProcessorIdList->ProcessorIDs[i];
57. IF (ProcessorId->FMS ==
Measured Launched Environment (MLE)
28 315168-013
58. (cpuid[1].EAX & ProcessorId->FMSMask)) &&
59. (ProcessorId->PlatformID ==
60. (IA32_PLATFORM_ID MSR & ProcessorId->PlatformMask))
61. AC module matches processor;
62. }
63. }
64. Fail: AC module does not match processor;
2.2.3.2 Verifying Compatibility of SINIT with MLE
Over time, new features and capabilities may be added to the SINIT AC module that
can be utilized by an MLE that is aware of those features. Likewise, features or
capabilities may be added that require an MLE to be aware of them in order to
interoperate properly. In order to expose these features and capabilities and permit
the MLE and SINIT to determine whether they support a compatible set, the MLE
header contains a Capabilities field (see Table 2-1) that corresponds to the
Capabilities field in the SINIT AC module Information Table (see Table A-3).
In addition, the MinMleHeaderVer field in the AC module Information Table allows
SINIT to indicate that it requires a certain minimal version of an MLE. This allows for
new behaviors or features requiring MLE support that may not be present in older
versions.
Listing 4 shows the pseudocode for the MLE to determine if it is compatible with the
provided SINIT AC module.
While lines 4 – 6 may be redundant with current SINIT AC modules if the MLE
supports both RLP wakeup mechanisms, they permit graceful handling of future
changes.
Listing 4. SINIT/MLE Compatibility Pseudocode
//
// Check that SINIT supports this version of the MLE
//
1. IF (InfoTable->MinMleHeaderVer > MleHeader.Version) {
2. Fail: SINIT requires a newer MLE
3. }
//
// Check that the known RLP wakeup mechanisms are supported
//
4. IF (MLE does NOT support at least one RLP wakeup mechanism
specified in InfoTable->Capabilities) {
5. Fail: RLP wakeup mechanisms are incompatible
6. }
Measured Launched Environment (MLE)
315168-013 29
2.2.4 Loading the MLE and Processor Rendezvous
2.2.4.1 Loading the MLE
System software allocates memory for the MLE and MLE page table. The MLE is not
required to be loaded into physically contiguous memory. The pages containing the
MLE image must be pinned in memory and all these pages must be located in physical
memory below 4 GBytes.
System software creates an MLE page table structure to map the entire MLE image.
The pages containing the MLE page tables must be pinned in memory prior to
launching the measured environment. The MLE page table structure must be in the
format of the IA-32 Physical Address Extension (PAE) page table structure.
The MLE page table has several special requirements:
• The MLE page tables may contain only 4 KByte pages.
• A breadth-first search of page tables must produce increasing physical addresses.
• Neither the MLE nor the page tables may overlap certain regions of memory:
device memory (PCI, PCIe*, etc.)
addresses between [640k, 1M] or above Top of Memory (TOM)
ISA hole (if enabled)
the Intel® TXT heap or SINIT memory regions
Intel VT-d DMAR tables
• There may not be any invalid (not-present) page table entries after the first valid
entry (i.e. there may not be any gaps in the MLE’s linear address space).
• The Page Directories must be in a lower physical address than the Page Tables.
• The Page-Directory-Pointer-Table must be in a lower physical address than the
Page-Directories.
• The page table pages must be in lower physical addresses than the MLE.
Later, the SINIT AC module will check that the MLE page table matches these
requirements before calculating the MLE digest. The second rule above implies that
the MLE must be loaded into physical memory in an ordered fashion: a scan of MLE
virtual addresses must find increasing physical addresses. The system software can
order its list of physical pages before loading the MLE image into memory.
The MLE is not required to begin at linear address 0. There may be any number of
invalid/not-present entries in the page table prior to the beginning of the MLE pages
(i.e. first valid page). The starting linear address should be placed in the
FirstValidPage field of the MLE header structure (see section 2.1).
If the MLE will use this page table after launch then it needs to ensure that the entry
point page is identity-mapped so that when it enables paging post-launch, the
physical address of the instruction after paging is enabled will correspond to its linear
address in the paged environment.
System software writes the physical base address of the MLE page table’s page
directory to the Intel® TXT Heap. The size in bytes of the MLE image is also written to
the Intel® TXT Heap, see 0.
Measured Launched Environment (MLE)
30 315168-013
2.2.4.2 Intel® Trusted Execution Technology Heap Initialization
Information can be passed from system software to the SINIT AC module and from
system software to the MLE using the Intel® TXT Heap. The SINIT AC module will also
use this region to pass data to the MLE.
The system software launching the measured environment is responsible for
initializing the following in the Intel® TXT Heap memory (this initialization must be
completed before executing GETSEC[SENTER]):
• Initialize contents of the Intel® TXT Heap Memory (see 0)
• Initialize contents of the OsMleData (see 0) and OsMleDataSize (with the size of
the OsMleData field + 8H) fields.
• Initialize contents of the OsSinitData (see section C.4) and OsSinitDataSize (with
the size of the OsSinitData field + 8H) fields.
The OsMleData structure has fields for specifying regions of memory to protect from
DMA (PMR Low/High Base/Size) using Intel VT-d. As described in section 1.11, the
MLE must be protected from DMA by being contained within either the DMA Protected
Range (DPR) or one of the Intel VT-d Protected Memory Regions (PMRs). If the MLE
resides within the DPR then the PMR fields of the OsMleData structure may be set to
0. Otherwise, these fields must specify a region that contains the MLE and the page
tables. However, the PMR fields can specify a larger region (and separate region,
since there are two ranges) than just the MLE if there is additional data that should be
protected.
If the system software is using Intel VT-d DMA remapping to protect areas of memory
from DMA then it must disable this before it executes GETSEC[SENTER]. In order to
do this securely, system software should determine what PMR range(s) are necessary
to cover all of the address range being DMA protected using the remapping tables. It
should then initialize the PMR(s) appropriately and enable them before disabling
remapping. The PMR values it provides in the OsSinitData PMR fields must correspond
to the values that it has programmed. Once the MLE has control, it can re-enable
remapping using the previous tables (after validating them).
If the MLE or subsequent code will be enabling Intel VT-d DMA remapping then the
DMAR information that will be needed should be protected from malicious DMA activity
until the remapping tables can be established to protect it. The SINIT AC module
makes a copy of the DMAR tables in the SinitMleData region (located at an offset
specified by the SinitVtdDmarTable field). Because this region is within the TXT heap,
it is protected from DMA by the DPR. If the MLE or subsequent code does not use this
copy of the DMAR tables, then it should protect the original tables (within the ACPI
area) with the PMR range specified to SINIT. Likewise, the memory range used for
the remapping tables should also be protected with the PMRs until remapping is
enabled.
If the Platform Owner TXT Launch Control Policy (see section 3.2.1 for more details
about TXT Launch Control Policy) is of type POLTYPE_LIST then there must be an
associated data file that contains the remainder of the policy. This policy data file
must be placed in memory by system software and its starting address and size
specified in the LCP PO Base and LCP PO Size fields of the OsSinitData structure. The
data must be wholly contained within a DMA protected region of memory, either
within the DPR (e.g. in the TXT heap) or within the bounds specified for the PMRs.
Measured Launched Environment (MLE)
315168-013 31
2.2.4.3 Rendezvousing Processors and Saving State
Listing 5 shows the pseudo-code for rendezvousing and saving states of all
processors.
Line 1: If launching the measured environment after operating system boot, then all
processors should be brought to a rendezvous point before executing
GETSEC[SENTER]. At the rendezvous point each processor will set up for
GETSEC[SENTER] and save any state needed to resume after the measured launch. If
processors are not rendezvoused before executing SENTER, then the processors that
did not rendezvous will lose their current operating state including possibly the fact
that an in-service interrupt has not been acknowledged.
Lines 2 – 7: All processors check that they support SMX and enable SMX in
CR4.SMXE.
Lines 8 - 10: The MLE should preserve machine check status registers if bit 6 in the
TXT Extension Flags returned by GETSEC[PARAMETERS] (see section 2.2.5.1 for
details) is set. If this bit returns 0 or parameter type ‘5’ is not supported, the MLE
must log and clear machine check status registers.
Line 11: Check that certain CR0 bits are in the required state for a successful
measured environment launch.
Line 12: System software allocates memory to save its state for restoration post
measured launch. The OsMleData portion of the Intel® TXT Heap has been reserved
for this purpose (see section C.2), though the size must be set appropriately for the
memory to be available.
Line 13: The ILP saves enough state in memory to allow a return to OS execution
after the measured launch and then continues launch execution. The RLPs save
enough state in memory to allow return to OS execution after measured launch then
execute HLT or spin waiting for transition to the measured environment.
Certain MSRs are modified by executing the GETSEC[SENTER] instruction. For
example, bits within the IA32_MISC_ENABLE and IA32_DEBUGCTL MSRs are set to
predetermined values. It may be desirable to restore certain bits within these MSRs to
their pre-launch state after the MLE launch. If this is desired, then before executing
GETSEC[SENTER], software should save the contents of these MSRs in the OsMleData
area. The launched software can restore the original values into these MSRs after the
GETSEC[SENTER] returns or, alternatively, the MLE can restore these MSRs with their
original values during MLE initialization.
It is expected that most MLEs will want to restore the MTRR and IA32_MISC_ENABLE
MSR states after the MLE launch, to provide optimal performance of the system.
Listing 5. Pseudo-code for Rendezvousing Processors and Saving State
1. Rendezvous all processors;
//
// The following code is run on all processors
//
// Enable SMX
//
Measured Launched Environment (MLE)
32 315168-013
2. CPUID(EAX=1);
3. IF (SMX not supported) OR (VMX not supported) {
4. Fail measured environment startup;
5. } ELSE {
6. CR4.SMXE = 1;
7. }
8. IF (GETSEC[PARAMETERS](type=5)[6] == 1) {
9. Clear Machine Check Status Registers;
10. }
11. Ensure CR0.CD=0, CR0.NW=0, and CR0.NE=1;
//
// Save current system software state in Intel® TXT Heap
//
12. Allocate memory for OsMleData;
13. Fill in OsMleData with system software state (including MTRR
and IA32_MISC_ENABLE MSR states);
2.2.5 Performing a Measured Launch
2.2.5.1 MTRR Setup Prior to GETSEC[SENTER] Execution
System software must set up the variable range MTRRs to map all of memory (except
the region containing the SINIT AC module) to one of the supported memory types as
returned by GETSEC [PARAMETERS] before executing GETSEC [SENTER]. System
software first saves the current MTRR settings in the OsMleData area and verifies that
the default memory type is one of the types returned by GETSEC [PARAMETERS]
(default memory type is specified in the IA32_MTRR_DEF_TYPE MSR). Next the
variable range MTRRs are set to map the SINIT AC module as WB. Make sure each
variable MTRR base must be a multiple of that MTRR's size. The SINIT AC module
must be covered by the MTRRs such that no more than (4K-1) bytes after the module
are mapped WB. For example, if an SINIT AC module is 11K bytes in size, an 8K and a
4K or three 4K MTRRs should be used to map it, not a single 32K MTRR. Any unused
variable range MTRRs should have their valid bit cleared. If the 8th bit of the ACM’s
Info Table Capabilities field is clear, the mask MTRRs covering the SINIT AC module
should not set any bits beyond bit 35 (which corresponds to a 36 bit physical address
space), or SINIT will treat this as an error condition. If that bit is set, the mask
should cover the full range indicated by the MAXPHYADDR MSR
Listing 6 shows the pseudo-code for correctly setting the ILP and RLP MTRRs. This
code follows the recommendation in the IA-32 Software Developer’s Manual.
After MTRR setup is complete, the RLPs mask interrupts (by executing CLI), signal the
ILP that they have interrupts masked, and execute halt. Before executing GETSEC
[SENTER], the ILP waits for all RLPs to indicate that they have disabled their
interrupts. If the ILP executed a GETSEC [SENTER] while an RLP was servicing an
interrupt, the interrupt servicing would not complete, possibly leaving the interrupting
device unable to generate further interrupts.
Measured Launched Environment (MLE)
315168-013 33
Listing 6. MTRR Setup Pseudo-code
//
// Pre-MTRR change
//
1. Disable interrupts (via CLI);
2. Wait for all processors to reach this point;
3. Disable and flush caches (i.e. CRO.CD=1, CR0.NW=0, WBINVD);
4. Save CR4
5. IF (CR4.PGE == 1) {
6. Clear CR4.PGE
7. }
8. Flush TLBs
9. Disable all MTRRs (i.e. IA32_MTRR_DEF_TYPE.e=0)
//
// Use MTRRs to map SINIT memory region as WB, all other regions
// are mapped to a value reported supportable by
// GETSEC[PARAMETERS]
//
10. Set default memory type (IA32_MTRR_DEF_TYPE.type) to one
reported by GETSEC[PARAMETERS];
11. Disable all fixed MTRRs (IA32_MTRR_DEF_TYPE.fe=0);
12. Disable all variable MTRRs (clear valid bit);
13. Read SINIT size from the SINIT AC header;
14. Program variable MTRRs to cover the AC execution region,
memtype=WB (re-enable each one used),make sure each variable
MTRRs base must be a multiple of that MTRR's size;
//
// Post-MTRR changes
//
15. Flush caches (WBINVD);
16. Flush TLBs;
17. Enable MTRRs (i.e. MTRRdefType.e=1);
18. Enable caches (i.e. CRO.CD=0, CR0.NW=0);
19. Restore CR4;
20. Wait for all processors to reach this point;
21. Enable interrupts;
//
// RLPs stop here
//
22. IF (IA32_APIC_BASE.BSP != 1) {
23. CLI;
24. set bit indicating we have interrupts disabled;
25. HLT;
26. }
Measured Launched Environment (MLE)
34 315168-013
27. Wait for all RLPs to signal that they have their interrupts
disabled
2.2.5.2 Selection of Launch Capabilities
System software must select the capabilities that it wishes to use for the launch. It
must choose a subset of the capabilities supported by the SINIT AC module. For
mandatory capabilities, such as the RLP wakeup mechanism, one of the supported
options must be chosen.
28. OsSinitData.Capabilities = selected capabilities;
2.2.5.3 TPM Preparation
System software must ensure that the TPM is ready to accept commands and that
there is no currently active locality (TPM.ACCESS_x.activeLocality bit is clear for all
localities) before executing the GETSEC[SENTER] instruction.
29. Read TPM Status Register until it is ready to accept a
command
30. 32.For all localities x, ensure that ACCESS_x.activeLocality
is 0
2.2.5.4 Intel® Trusted Execution Technology Launch
The ILP is now ready to launch the measuring process. System software executes the
GETSEC[SENTER] instruction. See chapter 6, “Safer Mode Extensions Reference”, in
the Intel 64 and IA-32 Software Developer Manuals, Volume 2B for the details of
GETSEC[SENTER] operation.
31. EBX = Physical Base Address of SINIT AC Module
32. ECX = size of the SINIT AC Module in bytes
33. EDX = 0
34. GETSEC[SENTER]
2.3 MLE Initialization
This section describes the initialization of the MLE. Listing 7 shows the pseudo-code
for MLE initialization.
The MLE initialization code is executed on the ILP when the SINIT AC module executes
the GETSEC[EXITAC] instruction—the MLE initialization code is the first MLE code to
run after GETSEC[SENTER] and within the measured environment. The SINIT AC
module obtains the MLE initialization code entry point from the EntryPoint field in the
MLE Header data structure whose address is specified in the OsSinitData entry in the
Intel® TXT Heap. The MLE initialization code is responsible for setting up the
protections necessary to safely launch any additional environments or software. The
initialization includes Intel® TXT hardware initialization, waking and initializing the
RLPs, MLE software initialization and initialization of the STM (if one is being used).
This section describes the details of MLE initialization.
Measured Launched Environment (MLE)
315168-013 35
During MLE initialization, the ILP executes the GETSEC[WAKEUP] instruction, bringing
all the RLPs into the MLE initialization code. Each RLP gets its initial state from the
MLE JOIN data structure (see the Intel 64 and IA-32 Software Developer Manual,
Volume 2B, Table 6-11). The ILP sets up the MLE JOIN data structure and loads its
physical address in the TXT.MLE.JOIN register prior to executing GETSEC[WAKEUP].
Generally the RLP initialization code will be very similar to the ILP initialization code.
If the MLE restores any state from the environment of the launching system software
then it must first validate this state before committing it. This is because state from
the environment prior to the GETSEC[SENTER] instruction is not considered
trustworthy and could lead to loss of MLE integrity.
Lines 1 – 8: The MLE loads CR3 with the MLE page directory physical address and
enables paging. The SINIT AC module has just transferred control to the MLE with
paging off, now the MLE must setup its own environment. The MLE’s GDT is loaded at
line 3 and the MLE does a far jump to load the correct MLE CS and cause a fetch of
the MLE descriptor from the GDT. At line 5 a stack is setup for the MLE initialization
routine and, at line 6, the MLE segment registers are loaded. Next the MLE loads its
IDT and initializes the exception handlers.
All of the instructions and data that are used before paging is enabled must reside on
the same physical page as the MLE entry point and must access data with relative
addressing. This is because the page tables may have been subverted by untrusted
code prior to launch and so the MLE entry point’s page may have been copied to a
different physical address than the original. The MLE must also verify that this page is
identity mapped prior to enabling paging (to ensure that the linear address of the
instruction following enabling of paging is the same as its physical address).
If the MLE cannot guarantee that it was loaded at a fixed address, then it must create
the identity mapping dynamically. Because the physical address of the identity page
could overlap with the virtual address range that the MLE wants to use in its page
tables, the MLE may need to create a trampoline page table. In such a case, the
trampoline page table would consist of an identity-mapped page for the physical
address of the MLE entry point and a virtual address mapping of that page which is
guaranteed not to be within the desired address range (i.e. a trampoline page). That
virtual address mapping would also need to be added to the page table that the MLE
ultimately wants to run on. In this way the MLE can enable paging to the trampoline
page table (at the identity mapped address) and then jump to the trampoline page’s
address and then switch page tables (CR3’s) to the final table where it will begin
executing at the virtual address of the trampoline page but in the final page table.
If the MLE does not enable paging then it must also validate that the physical
addresses specified in the page table used for the launch are the expected ones. And
as above, it must do this in code that resides on the same physical page as the MLE
entry point and uses only relative addressing. The reason for this validation is that
the page table could have been altered to place the MLE pages at different physical
addresses than expected, without having altered the MLE measurement.
Because the MLE page table that was used for measurement does not contain pages
other than those belonging to the MLE, if it wishes to continue to run in a paged
environment it will need to either extend the page tables to map the additional
address space needed (e.g. TXT configuration space, etc.) or to create new page
tables. This should be done after it has finished establishing a safe environment. The
cacheability requirements for the address space of any MLE-established page tables
must follow the guidelines below.
Measured Launched Environment (MLE)
36 315168-013
Line 9: The MLE checks the MTRRs which were saved in the OsMleData area of the
Intel® TXT Heap (see 0). It looks for overlapping regions with invalid memory type
combinations and variable MTRRs describing non-contiguous memory regions. If either
of these checks fails the MLE should fail the measured launch or correct the failure.
Before the original MTRRs are restored, the MLE must ensure that all its own pages
will be mapped with defined memory types once the variable MTRRs are enabled. The
MLE must ensure that the combined memory type as specified by the page table entry
and variable MTRRs results in a defined memory type.
The MLE must also ensure that the TXT Device Space (0xFED20000 – 0xFED4FFFF) is
mapped as UC so that accesses to these addresses will be properly handled by the
chipset.
Line 10: The MLE should check that the system memory map that it will use is
consistent with the memory regions and types as specified in the Memory Descriptor
Records (MDRs) returned in the SinitMleData structure. Alternately, the MLE may use
this table as its map of system memory. This check is necessary as the system
memory map is most likely generated by untrusted software and so could contain
regions that, if used for trusted code or secrets, might lead to compromise of that
data. If the MLE will be using PCI Express* devices, it should verify that it is accessing
their configuration space through the address range specified by the PCIE MDR type
(3).
Line 11: The MLE should also verify that the Intel VT-d PMR settings that were used
by SINIT to program the Intel VT-d engines, as specified in the OsSinitData structure,
contain the expected values. While the MLE can only be launched if the settings cover
itself and its page tables (or the pages fall within the DPR), settings beyond these
regions could have been subverted by untrusted code prior to the launch.
Line 12: The ILP must re-enable SMIs that were disabled as part of the SENTER
process; most systems will not function properly if SMIs are disabled for any length of
time. It is recommended that the MLE enable SMIs on the ILP before enabling them
on the RLPs, since some BIOS SMI handlers may hang if they receive an SMI on an AP
and cannot generate one on the BSP to rendezvous all threads. Newer CPUs may
automatically enable SMIs on entry to the MLE; for such CPUs there is no harm in
executing GETSEC[SMCTRL].
Lines 13 – 17: If this is the ILP then the MLE does the one-time initialization, builds
the MLE JOIN data structure and wakes the RLPs. This structure contains the physical
addresses of the MLE entry point and the MLE GDT, along with the MLE GDT size and
must be located in the lower 4GB of memory. The ILP writes the physical address of
this structure to the TXT.MLE.JOIN register. An RLP will read the startup information
from the MLE JOIN data structure when it is awakened. The MLE writer should ensure
that the MLE JOIN data structure does not cross a page boundary between two non-
contiguous pages. The MLE image must be built or loaded such that its GDT is located
on a single page. Enough of the RLP entry point code must be on a single page to
allow the RLPs to enable paging.
Lines 18 – 27: The MLE must look at the OsSinitData.Capabilities field to see which
RLP wakeup mechanism was chosen by the pre-SENTER code and thus used by SINIT.
If the MLE wants to enforce that certain capabilities or wakeup mechanism was used
then it can choose to error if it finds that not to be the case. For future compatibility,
MLEs should support both RLP wakeup mechanisms.
Measured Launched Environment (MLE)
315168-013 37
Line 30: The MLE checks several items to ensure they are consistent across all
processors:
• All processors must have consistent SMM Monitor Control MSR settings. The
processors must all be opt-in and have the same MSEG region or the processors
must be all opt-out.
• Ensure all processors have compatible VMX features. The compatible VMX features
will depend on the specific MLE implementation. For example, some
implementation may require all processors support Virtual Interrupt Pending.
• Ensure all processors have compatible feature sets. Some MLE implementations
may depend on certain feature being available on all processors. For example,
some MLE implementation may depend on all processors supporting SSE2.
If the MLE will use VMX then it should verify that bit 1 (VMX in SMX operation) in
the IA32_FEATURE_CONTROL MSR is set. Bit 2 (VMX outside SMX operation) may
also be set depending on the BIOS being used and on whether TXT has been
enabled.
• Ensure all processors have a valid microcode patch loaded or all processors have
the same microcode patch loaded. This check will depend on the specific MLE
implementation. Some MLE implementations may require the same patch be
loaded on all processors, other MLE implementations may contain a microcode
patch revocation list and require all processors have a microcode patch loaded
which is not on the revocation list.
Line 31: The MLE must wakeup the RLPs while the memory type for the SINIT AC
module region is WB cache-able. This is a requirement of the MONITOR mechanism
for RLP wakeup. Since this is not guaranteed to be true of the original MTRRs, it is
safest to wait until after the RLPs have been awakened before restoring the MTRRs to
their pre-SENTER values. Alternatively, the MLE could ensure that this is the case and
adjust the MTRRs if it is not. It could then restore the MTRRs before waking the RLPs.
In either case, when restoring the MTRRs they should be made the same for each
processor.
Line 32: The MLE should restore the IA32_MISC_ENABLE MSR to the value saved in
the OsMleData structure. This MSR was set to predefined values as part of SENTER in
order to provide a more consistent environment to the authenticated code module.
Most MLEs should be able to safely restore the previous value without any need to
verify it. The MLE should wait until the RLPs are awakened before restoring the MSR
in case the original MSR did not have the Enable MONITOR FSM bit (18) set. See
Appendix F for the processor state of the ILP after SENTER and the states of the RLPs
after waking.
Line 33: The machine-check exceptions flag (CR4.MCE) is cleared by the
GETSEC[SENTER] instruction. If the MLE supports the machine-check architecture
then it should initialize the exception mechanism and enable exception reporting.
Line 34: The MLE enables SMIs on each RLP.
Line 35: The MLE enables VMX in the CR4 register. This is required before any VMX
instruction can be executed.
Line 36: The MLE allocates and sets up the root controlling VMCS then executes
VMXON, enabling VMX root operation.
Measured Launched Environment (MLE)
38 315168-013
Lines 37 – 41: The MLE sets up the guest VM. At line 37 the MLE allocates memory for
the guest VMCS. This memory must be 4K byte aligned. The MLE executes VMCLEAR
with a pointer to this VMCS in order to mark this VMCS clear and allow a VMLAUNCH
of the guest VM. At line 39 the MLE executes VMPTRLD so that it can initialize the
VMCS at line 40. Now at line 41 the guest VM is launched for the first time.
Note: On the last extend of the TPM by the SINIT AC module, it may not wait to see if
the command is complete – so the MLE needs to make sure that the TPM is ready
before using it.
Listing 7: MLE Initialization Pseudo-code
//
// MLE entry point – ILP and RLP(s) enter here
//
1. Load CR3 with MLE page table pointer (OsSinitData.MLE
PageTableBase);
2. Enable paging;
3. Load the GDTR with the linear address of MLE GDT;
4. Long jump to force reload the new CS;
5. Load MLE SS, ESP;
6. Load MLE DS, ES, FS, GS;
7. Load the IDTR with the linear address of MLE IDT;
8. Initialize exception handlers;
//
// Validate state
//
9. Check MTRR settings from OsMleData area;
10. Validate system memory map against MDRs
11. Validate VT-d PMR settings against expected values
//
// Enable SMIs
//
12. execute GETSEC[SMCTRL];
//
// Wake RLPs
//
13. IF (ILP) {
14. Initialize memory protection and other data
structures;
15. Build JOIN structure;
16. TXT.MLE.JOIN = physical address of JOIN structure;
17. IF (RLP exist) {
18. IF (OsSinitData.Capabilities is set to MONITOR
wakeup mechanism) {
19. SinitMleData.RlpWakeupAddr = 1;
20. }
21. ELSE IF (OsSinitData.Capabilities is set to GETSEC
wakeup mechanism) {
Measured Launched Environment (MLE)
315168-013 39
22. GETSEC[WAKEUP];
23. }
24. ELSE {
25. Fail: Unknown RLP wakeup mechanism;
26. }
27. }
28. }
29. Wait for all processors to reach this point;
30. Do consistency checks across processors;
31. Restore MTRR settings on all processors;
32. Restore IA32_MISC_ENABLE MSR from OsMleData
33. Enable machine-check exception handling
34. RLPs execute GETSEC[SMCTRL]
//
// Enable VMX
//
35. CR4.VMXE = 1;
//
// Start VMX operation
//
36. Allocate and setup the root controlling VMCS, execute
VMXON(root controlling VMCS);
//
// Set up the guest container
//
37. Allocate memory for and setup guest VMCS;
38. VMCLEAR guest VMCS;
39. VMPTRLD guest VMCS;
40. Initialize guest VMCS from OsMleData area;
//
// All processors launch back into guest
//
41. VMLAUNCH guest;
2.4 MLE Operation
The dispatch routine is responsible for handling all VMExits from the guest. The guest
VMExits are caused by various situations, operations or events occurring in the guest.
The dispatch routine must handle each VMExit appropriately to maintain the measured
environment. In addition, the dispatch routine may need to save and restore some of
processor state not automatically saved or restored during VM transitions. The MLE
must also ensure that it has an accurate view of the address space and that it restricts
access to certain of the memory regions that the GETSEC[SENTER] process will have
enabled. The following subsections describe various key components of the MLE
dispatch routine.
Measured Launched Environment (MLE)
40 315168-013
2.4.1 Address Space Correctness
It is likely that most MLEs will rely on the e820 memory map to determine which
regions of the address space are physical RAM and which of those are usable (e.g. not
reserved by BIOS). However, as this table is created by BIOS it is not protected from
tampering prior to a measured launch. An MLE, therefore, cannot rely on it to contain
an accurate view of physical memory.
After a measured launch, SINIT will provide the MLE with an accurate list of the actual
RAM regions as part of the SinitMleData structure of the Intel® TXT Heap (see section
C.5). The SinitMDR field of this data structure specifies the regions of physical
memory that are valid for use by the MLE. This data structure can also be used to
accurately determine SMRAM and PCIe extended configuration space, if the MLE
handles these specifically.
2.4.2 Address Space Integrity
There are several regions of the address space (both physical RAM and Intel® TXT
chipset regions) that have special uses for Intel® TXT. Some of these should be
reserved for the MLE and some can be exposed to one or more guests/VMs.
2.4.3 Physical RAM Regions
There are two regions of physical RAM that are used by Intel® TXT and are reserved
by BIOS prior to the MLE launch. These are the SINIT AC module region and the
Intel® TXT Heap. Each region’s base address and size The Intel® TXT configuration
registers (e.g. TXT.SINIT.BASE and TXT.SINIT.SIZE) specify each region’s base
address and size.
The SINIT and Intel® TXT Heap regions are only required for measured launch and
may be used for other purposes afterwards. However, if the measured environment
must be re-launched (e.g. after resuming from the S3 state), the MLE may wish to
reserve and protect these regions.
2.4.4 Intel® Trusted Execution Technology Chipset Regions
There are two Intel® TXT chipset regions: Intel® TXT configuration register space
and Intel® TXT Device Space. These regions are described in 0.
2.4.4.1 Intel® Trusted Execution Technology Configuration Space
The configuration register space is divided into public and private regions. The public
region generally provides read only access to configuration registers and the MLE may
choose to allow access to this region by guests. The private region allows write
access, including to the various command registers. This region should be reserved to
the MLE to ensure proper operation of the measured environment.
Measured Launched Environment (MLE)
315168-013 41
2.4.4.2 Intel® Trusted Execution Technology Device Space
The Intel® TXT Device Space supports access to TPM localities. Localities three and
four are not usable by the MLE even after the measured environment has been
established, and so do not need any special treatment. Locality two is unlocked when
the Intel® TXT private configuration space is opened during the launch process.
Locality one is not usable unless it has been explicitly unlocked (via the
TXT.CMD.OPEN.LOCALITY1 command). If the MLE wants to reserve access to locality
two for itself then it needs to ensure that guest/VM access to these regions behaves
as a TPM abort, as defined by TCG for non-accessible localities. This behavior is that
memory reads return FFh and writes are discarded. The MLE can provide this
behavior by any one of the following:
• Trapping guest/VM accesses to the regions and emulating the defined behavior.
• Instead, it could map these regions onto one of the hardware-reserved localities
(three or four) and let the hardware provide the defined behavior.
• If the MLE does not need access to locality 2 then it can close this locality
(TXT.CMD.CLOSE.LOCALITY2) so neither itself nor guests will have access to it.
Note: Addresses FED45000H – FED7FFFFH are Intel reserved for expansion.
2.4.5 Device Assignment
If the MLE exposes devices to untrusted VMs, it must take care to completely protect
itself from any affects (either intentional or otherwise) of these devices. For devices
which use DMA to access memory, the MLE can protect itself through the use of Intel®
VT for Directed IO (Intel® VT-d) to prevent unwanted access to memory and through
VMX to manage access to device configuration space. For other types of devices, their
interactions with, and affects on, the system should be fully understood before
allowing an untrusted VM to access them.
2.4.6 Protecting Secrets
If there will be data in memory whose confidentiality must be maintained, then the
MLE should set the Intel® TXT secrets flag so that the Intel® TXT hardware will
maintain protections even if the measured environment is lost before performing a
shutdown (e.g. hardware reset). Writing to the TXT.CMD.SECRETS configuration
register can do this. The teardown process will clear this flag once it has scrubbed
memory and removed any confidential data.
2.4.7 Model Specific Register Handling
Model Specific Registers (MSRs) pose challenges for a measured environment. Certain
MSRs may directly leak information from one guest to another. For example, the
Extended Machine Check State registers may contain secrets at the time a machine
check is taken. Other MSRs might be used to indirectly probe trusted code. The non-
trusted guest could use the Performance Counter MSRs, for example, to determine
secrets (e.g. keys) used by the trusted code. Other MSRs can modify the MLE’s
operation and destroy the integrity of the measured environment.
The VMX architecture allows the MLE to trap all guest MSR accesses. Certain VMX
implementations will also allow the MLE to use a bitmap to selectively trap MSR
Measured Launched Environment (MLE)
42 315168-013
accesses. The MLE must use these VMX features to check certain guest MSR accesses,
ensuring that no secrets are leaked and that MLE operation is not compromised.
An MLE might virtualize some of the MSRs. The VMX architecture provides a
mechanism to automatically save selected guest MSRs and load selected MLE MSRs on
VMEXIT. Selected guest MSRs may be automatically loaded on VMENTER. These
features allow the MLE to virtualize MSRs, keeping a separate MSR copy for the guest
and MLE. Note that using this feature will slow VMEXIT and VMENTER times. The VMX
architecture provides a separate set of VMCS registers for the automatic saving and
restoring of the fast system call MSRs.
There is a limit to the number of MSRs that can be swapped during a VMX transition.
Bits 27:25 of the VMX_BASE_MSR+5 indicate the recommended maximum number of
MSRs that can be saved or loaded in VMX transition MSR-load or MSR-store lists.
Specifically, if the value of these bits is N, then 512 * (N + 1) is the recommended
maximum number of MSRs referenced in each list. If the limit is exceeded, undefined
processor behavior may result (including a machine check during the VMX transition).
There are certain MSRs that cannot be included in the MSR-load or MSR-store lists. In
the initial VMX implementations, IA32_BIOS_UPDT_TRIG and IA32_BIOS-SIGN_ID
may not be loaded as part of a VM-Entry or VM-Exit. The list of MSRs that cannot be
loaded in VMX transitions is implementation specific.
The MLE must contain a built-in policy for handling guest MSR accesses. This MSR
handling policy must deal with all architectural MSRs that might be accessed by guest
code. The built-in MSR policy must deny access to all non-architectural MSRs.
2.4.8 Interrupts and Exceptions
To preserve the integrity of the measured environment, the MLE must be careful in
how it handles exceptions and interrupts. It needs to ensure that its IDT (Interrupt
Descriptor Table) has a handler for all exceptions and interrupts. The MLE should also
ensure that if it uses interrupts for internal signaling that it does so securely.
Likewise, it is best if exception handlers do not try and recover from the exception but
instead properly terminate the environment.
2.4.9 ACPI Power Management Support
Certain ACPI power state transitions may remove or cause failure to the Intel® TXT
protections. The MLE must control such ACPI power state transitions. The following
sections describe the various ACPI power state transitions and how the MLE must deal
with these state transitions.
2.4.9.1 T-state Transitions
T-states allow reduced processor core temperature through software-controlled clock
modulation. T-state transitions do not affect the Intel® TXT protections, so the MLE
does not need to control T-state transitions. The MLE may wish to control T-state
transitions for other purposes, e.g. to enforce its own power management or
performance policies.
Measured Launched Environment (MLE)
315168-013 43
2.4.9.2 P-State Transitions
P-state transitions allow software to change processor operating voltage and
frequency to improve processor utilization and reduce processor power consumption.
On some systems, where the processor does not enforce allowed combinations, the
MLE must ensure software does not write an invalid combination into the GV3 MSRs.
2.4.9.3 C-State Transitions
C-states allow the processor to enter lower power state. The C0 state is the only C-
state where the processor is actually executing code – in the remaining C-states the
processor enters a lower power state and does not execute code. In these lower
power C-states the Intel® TXT protections remain intact; therefore the MLE does not
need to monitor or control the C-state transitions. The MLE may wish to control C-
state transitions for other purposes, e.g. to enforce its own power management or
scheduling policy.
2.4.9.4 S-State Transitions
The S0 state is the system working state – the remaining S-states are low-power,
system-wide sleep states. Software transitions from the S0 working state to the other
S-states by writing to the PM1 control register (PM1_CNT) in the chipset. Since the
Intel® TXT protections are removed when the system enters the S3, S4 or S5 states,
and the BIOS will gain control of the system on resume from these states, the MLE
must remove secrets from memory before allowing the system to enter one of these
sleeps states. Note that entering S1 does not remove Intel® TXT protections and Intel
chipsets do not support the S2 sleep state.
The Intel® TXT chipset provides hardware to detect when the software attempts to
enter a sleep state while the secrets flag is set (the TXT.SECRETS.STS bit of the
TXT.E2STS register). The Intel® TXT chipset will reset the system if it detects a write
to the PM1_CNT register that will force the system into S3, S4 or S5 while the secrets
flag is set. If the Intel® TXT chipset does detect this situation and resets the system,
then the BIOS AC module (or on servers, code within Trusted BIOS) ensures that
memory is scrubbed before passing control onward. To avoid this reset and scrubbing
process, the MLE should remove secrets from memory and teardown the Intel® TXT
environment before allowing a transition to S3, S4 or S5.
Before tearing down the Intel® TXT environment, the MLE may remove secrets from
memory (clearing pages with secrets) or encrypt secrets for later use (e.g. for a later
measured environment launch). Once this operation is complete the MLE must issue
the TXT.CMD.NO-SECRETS command to clear the secrets flag. After this command is
issued, the MLE may allow a transition to a S3, S4 or S5 sleep state. The MLE
teardown procedure is described in more detail in section 2.5.
2.4.9.4.1 S3
The S3 state provides special challenges for the MLE because the resume process uses
the in-memory state from when S3 was entered. This means that unlike a normal
boot process where trust is established as each component launches, the trust that
existed at entry to S3 must be maintained/verified on resume.
Since the TXT environment must be torn down before entering S3, it will have to be
re-established on resume. This part of the S3 resume process is nearly identical to the
Measured Launched Environment (MLE)
44 315168-013
original launch. Because S3 resume should leave the platform in the same state as
before S3 was entered, the PCRs should also have the same values. This means that
the MLE launched on resume should be the same as the initial one launched, which
means that the code/data being measured cannot include any state from before
entering S3. If some state from before entering S3 is needed on resume, then it must
be validated post-launch (since it is not being measured).
The MLE needs to ensure that the integrity of the TCB will be maintained across the
transition. There are two possible sources for loss of integrity across S3: malicious
DMA and compromise of the in-memory BIOS image. The initial, pre-S3 TXT launch
process protects against DMA and so the S3 resume process should maintain such
protection. Most BIOS will execute portions of their S3 resume code from their in-
memory image without first re-copying it from flash. Since this in-memory image
could have been modified by any privileged software or firmware that executed as
part of the original, pre-S3 boot process (e.g. option ROMs, bootloader, etc.), this too
needs to be defended against.
The TXT launch process done as part of S3 resume ensures integrity and DMA
protection for the measured part of the MLE itself. For the remainder of the TCB this
can be accomplished by creating a memory integrity code for the TCB and sealing it to
the MLE’s launch-time measurements just before the TXT protections are removed
prior to entering S3 (the sealed data creation attributes should include a locality that
is only available to the TCB). On resume and after a successful launch, the MLE can
re-calculate the value for the memory image and compare it with the sealed value to
determine if the memory image has been compromised).
If there were additional measurements extended to the DRTM PCRs as part of the
original boot process, these will need to be re-established since these PCRs are
cleared when the MLE is re-launched. The entity that makes the measurements should
seal the measurement values (not the resulting PCR values) to the PCRs values in
effect just before it extends the measurements into the PCRs (the sealed data creation
attributes should include a locality that is only available to software trusted by the
entity). On resume from S3, when that entity is resumed it will unseal the values and
re-extend them into the appropriate PCRs.
It may be necessary for the MLE to seal additional information that is required to
securely re-establish the trusted environment. For instance, the portion of the TCB
needed to re-establish final DMA protections (e.g. with VT-d DMA remapping) will
need to be DMA protected by the MLE as part of the post-resume launch. The MLE
may need to save the bounds of this region prior to entering S3 (both in plain text and
sealed). It would then use the plain text saved bounds to determine the PMR values
to specify as part of the re-launch. Post-launch the MLE would unseal the bounds
information and verify it against the bounds specified in the launch.
Because the boot process on resuming from an S3 state does not re-measure the
elements of the SRTM, software prior to entering the S3 state must execute the
appropriate TPM command for the current TPM mode to inform the TPM to preserve
the state of its PCRs: for 1.2 this is TPM_SaveState; for 2.0 this is TPM2_Shutdown
(requesting state). Upon resume from S3, the BIOS must provide a flag to
TPM_Startup to indicate that the TPM is to restore the saved state. If the TPM’s state
is not saved prior to entering S3, then the TPM will be non-functional after resuming.
Normally an OS TPM driver would perform the TPM state preservation command when
the OS indicated that it was entering S3. However, if the MLE cannot be sure that the
environment it establishes will perform this command, it may wish to do so itself prior
to entering S3. If the MLE alters the TPM state (e.g. extending to PCRs, etc.) after
Measured Launched Environment (MLE)
315168-013 45
TPM state preservation command has been issued then the TPM may invalidate the
previously saved state. In such cases, the MLE must also perform this command and it
should be the last TPM command that is executed, in order to ensure that the state is
not changed afterwards. There is no harm if this command is executed multiple times
prior to S3.
2.4.10 Processor Capacity Addition (aka CPU Hotplug)
VMMs and OS kernels not accommodating or executing within an Intel® TXT
measured launch assume control of application processors during boot using INIT-
SIPI-SIPI mechanism. Upon receipt of a SIPI, the processor resumes execution at the
specified SIPI vector.
On the other hand, an MLE issues GETSEC[WAKEUP] (or a write to the wakeup
address) to assume control of application processors (RLPs) following SENTER. The
RLPs begin execution at an address pointed to by the MLE JOIN data structure. Intel®
TXT for multiprocessor platforms enables processor capacity addition (also known as
CPU hotplug or hotadd) after the Intel® TXT environment has been launched.
Processor capacity addition can be a result of physical addition of a processor package
to a running system or bringing a processor package online that was previously
inactive. The Intel® TXT processor capacity addition flow makes use of INIT-SIPI-SIPI
as the RLP wakeup mechanism, but the hot added logical processors use the MLE JOIN
data structure to determine their entry point.
The processor capacity addition flow for an MLE is documented below:
1. New processors are released from reset. They execute measured BIOS code.
2. BIOS configures the new processors. At the end of configuration, BIOS clears the
BSP flag in the APICBASE register of new processors and leaves them in a CLI/HLT
loop.
3. The MLE is notified of this event via the standard ACPI mechanism.
4. Some MLEs may choose to allow write access to the Intel® TXT public
configuration region by guests. However, during the processor capacity addition
flow, the MLE must prevent guests from writing to the public region in order to
prevent them from modifying the TXT.MLE.JOIN register in the middle of this flow.
5. The MLE must prepare the MLE JOIN data structure for the new processors. It may
choose to use the same values as it did for the initial RLPs or it may use different
ones. In either case, they are subject to the same restrictions as for the initial RLP
wakeup. The MLE then writes the physical address of the JOIN data structure into
the TXT.MLE.JOIN register.
6. The MLE issues the INIT–SIPI-SIPI sequence to each newly added logical
processor to take control of these processors.
7. In response to the SIPI, each new processor will detect that this is a capacity
addition to an existing measured environment and resume execution at the entry
point specified in the MLE JOIN data structure. The processor will ignore the SIPI
vector that may have been supplied. The new processor gets its initial state from
the MLE JOIN data structure just like an RLP would during the MLE launch process.
2.5 MLE Teardown
This section describes an orderly measured environment teardown. This occurs when
the guest OS or the MLE decides to tear down the measured environment (for
Measured Launched Environment (MLE)
46 315168-013
example prior to entering an ACPI sleep state such as S3). The listing below shows
the pseudo-code for teardown of the measured environment.
Line 1: Rendezvous all processors at “exiting Intel® TXT environment” point in guest.
No need for the guests to save their state as their state will be stored in a VMCS on
VMEXIT to the monitor.
Lines 2 and 3: After all processors in the guest rendezvous, all processors execute a
VMCALL to the teardown routine in the MLE. Once in the MLE, each processor
increments a counter in trusted memory. All processors except the BSP/ILP (the
processor with IA32_APIC_BASE MSR.BSP=1) wait on a memory barrier. The ILP
waits for all other processors to enter MLE teardown routine then signals the other
processors to resume with teardown.
If not all processors reach the rendezvous in the guest, the ILP may timeout and
VMCALL to the MLE teardown routine. If not all processors arrive in the MLE teardown
routine, the ILP forces all other processors into the MLE with an NMI IPI. Both these
conditions are treated as errors – the ILP should proceed with the measured
environment teardown but log an error.
At line 4, each processor reads all guest state from its VMCS and stores this data in
memory, since after VMXOFF the processors will no longer be able to access data in
their VMCS. This state will be needed to restore the guest execution after teardown.
The MLE automatically saves certain guest state (general purpose registers which are
not part of the VMCS guest area) on VM Exit. The MLE may need to restore this state
when it reenters the guest after the GETSEC[SEXIT].
Line 5: Once all processors are in the MLE and have saved guest state from the VMCS,
all processors clear their appropriate registers to remove secrets from these registers.
Lines 6: All processors flush VMCS contents to memory using VMCLEAR. The MLE
must flush any VMCS that might contain secrets – this would include all guest VMCSes
in a multi-VM environment.
Line 7: The processors wait until all processors have reached this point before
resuming execution. This allows all the VMCS flushes to complete before the ILP
encrypts or scrubs secrets. Processors should execute an SFENCE to ensure all writes
are completed before continuing.
Line 9: The ILP encrypts and stores exposed secrets from all trusted VMs. Note that
encrypted secrets will have to be stored in memory until the OS can put them to disk.
This will require extra memory above and beyond the memory holding secrets. This
step assumes that the RLPs do not have secrets that are not visible to the ILP.
Therefore when the ILP scrubs/encrypts all secrets, this will deal with secrets in the
RLP caches also.
Line 10: The ILP again clears appropriate registers to remove any secrets from those
registers.
Line 11: The ILP scrubs all trusted memory (except the teardown routine itself and
encrypted memory). Note that the scrub itself clears secrets still held in the cache.
Line 12: The ILP executes WBINVD to invalidate its caches (to ensure last few pages
of zeros actually get to memory).
Measured Launched Environment (MLE)
315168-013 47
Lines 13 - 16: If the MLE is going to enter the S3 state, the ILP calculates a memory
integrity code and seals it.
Line 17: The ILP caps, or extends, the dynamic PCRs with some value. This prevents
an attacker from unsealing the secrets after the teardown using the same PCRs, since
the dynamic PCRs are not reset after GETSEC[SEXIT].
Line 18: The ILP writes the NoSecrets in memory command. (TXT.CMD.NO-SECRETS)
Line 19: The ILP should unlock the system memory configuration (TXT.CMD.UNLOCK-
MEM-CONFIG) (that was locked by SINIT) once secrets have been removed from
memory. This will facilitate re-launching the MLE and may be necessary for a graceful
shutdown of the system.
Line 20: The ILP closes Intel® TXT private configuration space.
Line 23: The RLPs wait while the ILP encrypts and scrubs secrets from memory.
Line 25: Each processor then disables processor virtualization. If an STM was
launched then it must be torn down before VMX is disabled. See section 25.15.7 of the
Intel 64 and IA-32 Software Developer Manual, Volume 3B for more information.
Lines 26 - 31: The RLPs wait on a memory barrier while the ILP executes the
GETSEC[SEXIT] instruction to initiate the teardown of SMX operation.
At end of GETSEC[SEXIT], the ILP simply continues to the next instruction (still
running in monitor’s context – paging on). The ILP signals the RLPs to continue.
Lines 32 and 33: The former monitor code now restores guest state left behind when
the guest executed the VMCALL to enter the MLE teardown routine. All processors
perform the transition to guest OS, now operating as normal environment rather than
guest.
The guest MSRs must be restored when restarting the guest OS. The MLE can restore
the MSRs with information in the VMCS (VM-exit MSR store count) and the VM-exit
MSR store area, or the guest OS could save important MSR settings before calling the
teardown routine and restore its own MSR settings after resuming after teardown.
If the MLE is going to return control to a designated guest after tearing down then the
MLE must ensure that no interrupts are left pending or not serviced before returning
control to the designated guest. Any interrupts left pending or not serviced may
prevent further interrupt servicing once the designated guest is restarted.
Listing 8. Measured Environment Teardown Pseudo-code
1. Rendezvous processors in guest OS;
2. All processors VMCALL teardown in MLE;
3. Rendezvous all processors in MLE teardown routine;
4. All processors read guest state from VMCS, store values in
memory;
//
// Remove and encrypt all secrets from registers and memory
//
5. All processors clear their appropriate registers;
6. All processors flush VMCS contents to memory using VMCLEAR;
Measured Launched Environment (MLE)
48 315168-013
7. Wait for all processors to reach this point;
8. IF (ILP) {
9. Encrypt and store secrets in memory;
10. Again clear appropriate registers to remove secrets;
11. Scrub all trusted memory;
12. WBINVD caches;
13. IF (S3) {
14. Create memory integrity code
15. Seal memory integrity code
16. }
17. “cap” dynamic TPM PCRs;
18. Write to TXT.CMD.NO-SECRETS;
19. Unlock memory configuration
20. Close private Intel® TXT configuration space;
21. Signal RLPs that scrub is complete;
22. } ELSE { // RLP
23. Wait for ILP to signal completion of memory scrub;
24. }
//
// Stop VMX operation
//
25. VMXOFF;
//
// RLPs wait while ILP executes SEXIT
//
26. IF (ILP) {
27. GETSEC[SEXIT];
28. signal completion of SEXIT;
29. } ELSE {
30. wait for ILP to signal completion of SEXIT;
31. }
//
// Transition back to the guest OS
//
32. Restore guest OS state from device memory;
33. Transition back to guest OS context;
2.6 Other Considerations
2.6.1 Saving MSR State Across Measured Launch
Execution of the GETSEC[SENTER] instruction loads certain MSRs with pre-defined
values. For example, GETSEC[SENTER] will load IA32_DEBUGCTL MSR with 0H and
will load the GV3 MSR with a predetermined value. The software can deal with this in
several different ways. The launching software may save the state of these MSRs
before measured launch and restore the state after the launch returns. In this case
Measured Launched Environment (MLE)
315168-013 49
the MLE will need to check the values that are restored. Another approach is to have
the launch software save the desired state and have the MLE restore the values before
resuming the guest. The software could also leave these MSRs in the state established
by GETSEC[SENTER].
The IA32_MISC_ENABLE MSR should be saved and restored around measured launch
and teardown.
§ §
Verifying Measured Launched Environments
50 315168-013
3 Verifying Measured Launched
Environments
Launch Control Policy (LCP) is the verification mechanism for the Intel® TXT verified
launch process. LCP is used to determine whether the current platform configuration
or the environment to be launched meets a specified criteria. Policies may be defined
by the Platform Owner, and/or, as a default set by the Platform Supplier.
The policy described in this section applies to TXT-capable platforms produced in 2009
and later. Policy definitions for earlier platforms can be found in earlier versions of
this document. The discussion below is separated into coverage of TPM1.2 (LCP v2.2
structure) implementation and deltas for TPM2.0 (LCP v3.0 structure) in the
respective subsections.
3.1 Overview
The Launch Control Policy architecture consists of the following components:
• LCP Policy Engine – part of the SINIT ACM and enforces the policies stored on the
platform
• LCP Policies – stored in the TPM, they specify the policies SINIT ACM will enforce.
• LCP PolicyData objects – referenced by the Policy structures in the TPM; each
contains a list of valid policy elements, such as measurements of MLEs or platform
configurations.
Figure 3-1 shows how these components relate to each other. The figure also shows
that there are two possible policies available on the platform: the Platform Supplier
policy, as established by the manufacturer, OEM, ODM, etc., and the Platform Owner’s
policy.
When the platform boots, its state is measured and recorded by the Static Root of
Trust for Measurement (SRTM) and the other components which make up the static
chain of trust; these events occur from when the platform is powered on until the
Intel® TXT measured launch (or until some component breaks the static chain). At
this point GETSEC[SENTER] is invoked, and control is passed through the
authenticated code execution area to the SINIT authenticated code module. The LCP
engine in SINIT reads the LCP Policy Indices in the TPM NV, decides which policy to
use, and checks the Platform Configuration and the Measured Launched Environment
as required by the chosen policy. The measured environment is then launched if the
policy is satisfied.
Verifying Measured Launched Environments
315168-013 51
Figure 3-1. Launch Control Policy Components
3.1.1 Versions of LCP Components
The following two sections 3.2 and 3.3 provide detailed description of two versions of
LCP components – version 2 (V2) related to components used with TPMs of 1.2 family
and version 3 (V3) applicable to TPMs of 2.0 family. Early version 1 of LCP
components is no longer supported by TXT architecture.
Despite that in general both versions of components are disjoint, there is one cross-
section area where LCP engine operating in TPM 1.2 mode must be aware of V3
structures. As will be shown in section 3.3.4.1 V3 policy lists are allowed to contain
mixture of V2 and V3 policy elements. Therefore policy engine operating in TPM 1.2
mode must be able to a) recognize and browse V3 policy lists; b) validate all types of
V3 style signatures and c) be able to compute hashes of such lists for the purpose of
verifying the hash value stored LCP policy.
3.2 LCP Components, V2 (TPM 1.2)
The description of the policy that the SINIT AC module implements consists of two
policies, named for the entity that sets them: Platform Supplier (PS) and Platform
Owner (PO). Both policies are stored in the non-volatile store of the Trusted Platform
Module (TPM NV). By storing the policy in the TPM NV, access controls can be applied
to it; it also enables the policy to persist across platform power cycles.
Besides of PS/PO TPM NV indices, Intel® TXT also uses other TPM NV indices:
auxiliary TXT index (AUX) and Software Guard Extension index (SGX).
AUX index is used as internal inter ACM communication area. Main data it contains is:
• BIOAS ACM version extended by SINIT into PCR17. This extend is necessary since
BIOS ACM is in TXT Trusted Computing Base (TCB).
Platform Supplier
LCP_Policy
Platform Owner
LCP_Policy
…
…
TPM
PCRs
TPM NV Ram
PS
LCP_POLICY_DATA PO
LCP_POLICY_DATA
Static Chain
of Trust MLE
SINIT(LCP)
Execution Control
Write/Read Operation
Data Reference
Verifying Measured Launched Environments
52 315168-013
• Auto-promotion Digest is hash used by server startup ACM to validate integrity of
BIOS image. More information can be found in Appendix K
• Revocation data described in section 3.5
SGX index is used as BIOS / MLE inter-communication area. Its usage is described
in section 4.5
3.2.1 LCP Policy
The LCP_POLICY structure (for a full listing see section D.1) is used for both the
Platform Supplier and the Platform Owner policies. The size of the structure currently
needs to be kept to a minimum in order to preserve the scarce resources of the TPM
NV storage, which is why additional structures for both Supplier and Owner policies
(LCP_POLICY_DATA) that can persist elsewhere are provided to handle additional
information.
Figure 3-2. LCP_POLICY Structure
Figure 3-2 diagrammatically illustrates the LCP_POLICY structure (fields not to scale):
Version specifies the version of the LCP_POLICY structure and, implicitly, of the policy
engine semantics. It is of the format <major>.<minor> where the major version is
the MSB of the field and the minor version is the LSB. All minor versions of a given
major version will be backwards compatible. If new fields are added they will be at the
end and the semantics of all previous minor versions are maintained (though they can
be extended). Major version are not guaranteed to be backwards compatible with
each other and so SINIT will fail to launch if it finds a major version that it is not
compatible with. The version of the LCP_POLICY structure defined here is 2.2 (202H)
or 2.3 (203H) – see section 3.4.2.
HashAlg identifies the hashing algorithm used for the PolicyHash field. If the algorithm
type is not supported by ACM processing the policy, then it shall stop processing the
policy and fail.
PolicyType indicates whether an additional LCP_POLICY_DATA structure is required.
• If the PolicyType field is LCP_POLTYPE_ANY then the value in the PolicyHash field
is ignored and the environment to be launched is simply measured before
Version HashAlg PolicyType SINITMinVersion
Reserved3
DataRevocationCounters[] PolicyControl
PolicyHash
Reserved1
MaxSinitMinVersion MaxBiosacMinVersion
Reserved2
Verifying Measured Launched Environments
315168-013 53
execution control is passed to it. No corresponding LCP_POLICY_DATA is
expected.
• If the PolicyType field is LCP_POLTYPE_LIST then the value of PolicyHash is the
result of computing a hash over the LCP_POLICY_DATA structure per the rules
below.
If the type specified is not supported by the ACM processing the policy then it shall
stop processing the policy and fail.
SINITMinVersion specifies the minimum version of SINIT that can be used. This value
corresponds to the AcmVersion field in the AC module Information Table (see Table
A-3). This value must be less than or equal to the value of AcmVersion in the
executing SINIT image for that SINIT to continue; otherwise SINIT will fail the launch.
There is no revocation policy mechanism for non-SINIT ACMs that is currently
employed; some provision has been made for future revocation of BIOS ACMs via the
MaxBiosacMinVersion field. If there is a LCP_MLE_ELEMENT element in a policy then
the SINITMinVersion in that element will be combined with the value in the
LCP_POLICY, per the description in section D.4.1. If there is no LCP_MLE_ELEMENT
element in the policy then the value in the LCP_POLICY will be used.
The DataRevocationCounters field specifies, for each LCP_POLICY_LIST, the minimum
counter value, from the RevocationCounter field of that list, which will be accepted. If
the value in the RevocationCounter field is less than this value then SINIT will fail the
launch. For LCP_POLICY_LISTs that are not signed, the corresponding
DataRevocationCounters index will be ignored. For each LCP_POLICY_LIST that is
signed, it must set the DataRevocationCounters element at the index corresponding to
its own index in PolicyLists[]. E.g. if PolicyLists[0] is signed, PolicyLists[1] unsigned,
and PolicyLists[2] signed, then the revocation counter for PolicyLists[0] will be
DataRevocationCounters[0], the counter for PolicyLists[2] will be
DataRevocationCounters[2], and DataRevocationCounters[1] will be ignored. Values in
indices greater than the number of lists will be ignored.
The PolicyControl field is deciphered in section 3.2.2
The MaxSinitMinVersion field specifies the maximum value this policy will allow a
revocation utility to set the AUX.AUXRevocation.SinitMinVer to “0” means the SINIT
minimum version may not be changed. “0xff” allows unconditional changes to the
SINIT minimum version. This field is ignored by ACMs.
The MaxBiosacMinVersion is currently unused, but its meaning and purpose are
analogous to those of MaxSinitMinVersion.
3.2.2 PolicyControl Field for LCP_POLTYPE_LIST
The PolicyControl field differs between versions 2.2 and 2.3 and consists of control bits
defined as:
• Bits 31:4 Reserved and should be set to zero
If LCP_POLICY.Version == 2.2
• Bit 20:16 Reserved and should be set to zero
If LCP_POLICY.Version == 2.3 bits 20:16 are defined as follows. These bits are moved
from PolEltControl field of LCP_ELEMENT structure. Setting of these bits will effectively
prevent LCP engine to scan PS policy data file:
Verifying Measured Launched Environments
54 315168-013
• Bit 20 Is Ignore_PS_STM bit
• Bit 19:18 Reserved should be set to zero
• Bit 17 Is Ignore_PS_PCONF bit
• Bit 16 Is Ignore_PS_MLE bit.
• Bit 3 Signifies whether an Owner policy is required by SINIT. Setting it to 1 will
cause SINIT to fail the launch if there is no Platform Owner policy. If there are
both Supplier and Owner policies, they will be evaluated according to the rules
below (this bit has no effect on that). This bit will be ignored in the Platform
Owner policy.
• Bit 2 Identifies whether the OsSinitData.Capabilities field will be extended into PCR
17 (if set to 1 then it will be extended).
• Bit 1 Identifies whether the platform will allow AC Modules marked as pre-
production to be used to launch the MLE. If this bit is 0 and a pre-production AC
Module has been invoked, it will cause a TXT reset during GETSEC[SENTER].
Note: The use of any pre-production AC Module will result in PCRs 17 and 18
being capped with random values.
• Bit 0 is reserved and must be set to 0
3.2.3 PolicyHash Field for LCP_POLTYPE_LIST
For policies of type LCP_POLTYPE_LIST, the LCP_POLICY_DATA may contain multiple
lists, some of which are signed and some of which are not. In order to realize the
value of signed policies, PolicyHash can’t be a simple hash over the entire
LCP_POLICY_DATA or even changes to signed policy lists would cause a change in the
measurement of the policy.
The measurement of a policy list depends on whether the list is signed. For a list
signed using any algorithm supported by the ACM, the measurement is the hash (as
specified by the HashAlg field of the corresponding LCP_POLICY) of the public
(verification) key in the PubkeyValue member of the Signature field for RSA, or the Qx
and Qy public coordinates for elliptic curve signatures. For unsigned lists
(LCP_POLSALG_NONE), the measurement is the hash (also as specified by the
HashAlg field of the corresponding LCP_POLICY) of the entire list (LCP_POLICY_LIST).
The value of the PolicyHash field will be the hash of all of the policy list measurements
concatenated (there is no end padding if the number of lists present is less than
LCP_MAX_LISTS), even if there is only one list measurement. For example, if there is
only a single list then the value of PolicyHash will be SHA1(SHA1(list)).
3.2.4 LCP Policy Data
The purpose of the LCP_POLICY_DATA structure is to provide the additional data
needed to enforce the policy but in a separate entity that doesn’t have to consume
TPM NV space. A full description of LCP_POLICY_DATA can be found in Appendix D.
Verifying Measured Launched Environments
315168-013 55
Figure 3-3. LCP_POLICY_DATA Structure
The PolicyLists[] field allows the object to contain a number of lists. A list may be
either signed or unsigned and can contain any type of LCP_POLICY_ELEMENT
structures (e.g. for MLE policy, platform configuration policy, etc.).
LCP_POLICY_DATA
UUID
Reserved[3]
NumLists
PolicyLists[]
LCP_POLICY_LIST
LCP_POLICY_LIST
Version
Reserved
SigAlgorithm
PolicyElementsSize
PolicyElements[]
[Signature]
LCP_MLE_ELEMENT
LCP_PCONF_ELEMENT
Size
Type
PolEltControl
Size
Type
PolEltControl
SINITMinVersion
HashAlg
NumHashes
Hashes[]
Hash
Hash
. . . .
NumPCRInfos
PCRInfos[]
PCRInfo
PCRInfo
. . . .
Verifying Measured Launched Environments
56 315168-013
3.2.5 LCP Policy Element
Policy elements are the self-describing entities that contain the actual policy
conditions. Since they are self-describing, policy engines can ignore the elements that
they don’t understand or support. This allows for adding new element types without
breaking backwards compatibility.
Figure 3-4. LCP_POLICY_ELEMENT Structure
Size Type PolEltControl Data[Size - 12]
Figure 3-4 diagrammatically illustrates the LCP_POLICY_ELEMENT structure (fields not
to scale):
Size is the size (in bytes) of the entire LCP_POLICY_ELEMENT structure, including the
type-specific Data and the Size field itself. A policy engine can use this to skip over
an element that it does not understand or support.
The PolEltControl provides a number of control bits divided into two groups of 16 bits
each. One is specific to the element type and the other applies to all element types
and is defined as:
• Bits31:16 Reserved for element type –specific uses and should set to zero
• Bits15:2 Reserved and should set to zero
• Bit 1 If set to 1 requires STM to be enabled. Defined in LCP_MLE_ELEMENT
structure only and is reserved in all other element type structures.
If LCP_POLICY_LIST.Version == 1.0
• Bit 0 If set to 1 specifies that this policy element type in the Owner policy
unconditionally overrides (i.e. ignores) any policy elements of the same type in
the Supplier policy (when both policies are present). This Supplier policy element
type is overridden if this bit is set in any elements of this type in the Owner policy.
In order to keep the same behavior as that of the previous version of LCP, and to
ensure that if the Supplier policy is of type LCP_POLTYPE_ANY that the Owner
policy will have control, the default setting of the bit in Owner policies should be 1.
This bit will be ignored in the Platform Supplier policy.
If LCP_POLICY_LIST.Version == 1.1 Bit 0 functionality is moved to LCP_POLICY
structure.
• Bit 0 Reserved and must be set to 0
The contents of the Data[] field are dependent of the type of the element and are
described for each type in the subsections of section D.4.
3.2.6 Signed Policies
The purpose of signed policies is to provide a mechanism that allows policy authors to
update the list of permissible environments without having to update the TPM NV
(note that if revocation is used that the TPM NV must be updated to increment the
revocation counter). This allows updates to be simple file pushes rather than physical
or remote platform touches. It also facilitates sealing against the policy, as sealed
data does not have to be migrated when the policy is updated.
Verifying Measured Launched Environments
315168-013 57
The use of this mechanism places certain responsibilities on policy authors:
• The private signature key needs to be kept secure and under the control of the
key owner at all times.
• The private signature key needs to be strong enough for the full lifetime of the
policy [for the Platform Supplier we have estimated up to seven years].
3.2.7 Supported Cryptographic Algorithms
The following algorithms are defined for version V2 of the Launch Control Policy:
Hashing – SHA1
Signature – RSA PKCS V1.5
As version V2 and V3 elements may both be present in a V3 list being processed in
TPM 1.2 mode, all V3 style list signatures supported by the ACM will be validated.
It is the responsibility of the policy author to ensure that their policy uses an
algorithm supported by the version of the AC module being used. If the policy
specifies an unsupported algorithm, the policy will fail and, depending on the ACM
evaluating the policy, the environment will not be permitted to launch or the platform
will not boot.
3.2.8 Policy Engine Logic
3.2.8.1 Policies
Before evaluating a policy, the policy engine must first verify the policy’s integrity. For
policy of type LCP_POLTYPE_LIST, the engine must verify each LCP_POLICY_LIST in
the LCP_POLICY_DATA. In the signed list case, the signature must be verified. For an
unsigned list, the hash of the list must be calculated. The hash of the
LCP_POLICY_DATA structure is calculated per section 3.2.3 above and then compared
with the hash in the LCP_POLICY that was read from the TPM NVRAM.
The policy engine must scan the policy for each policy element that it supports. When
a policy contains multiple lists in its LCP_POLICY_DATA, the policy engine will evaluate
each list sequentially. As soon as it finds a match that satisfies the policy element
being evaluated (e.g. MLE, platform configuration, etc.) it will stop evaluating further
elements and lists.
For a policy of type LCP_POLTYPE_ANY, the policy engine will treat that policy as
successfully evaluating every policy element type.
For a policy of type LCP_POLTYPE_LIST, for every policy element type supported by
the ACM evaluating the policy that is present in any of the lists, at least one instance
of that element type must evaluate successfully in order for the policy to succeed. If
a particular policy element type is not in any of the lists then that condition is not
evaluated and any state is accepted. For instance:
If SINIT is processing a policy that contains two lists, the first containing only an
LCP_MLE_ELEMENT and the second containing only a LCP_PCONF_ELEMENT, then
the MLE being launched must appear in the first list’s LCP_MLE_ELEMENT and the
Verifying Measured Launched Environments
58 315168-013
current platform configuration must satisfy the second list’s
LCP_PCONF_ELEMENT; otherwise the launch will fail.
If SINIT is processing a policy that contains two lists, each containing only an
LCP_MLE_ELEMENT element, then the MLE being launched must appear in at least
one list’s LCP_MLE_ELEMENT. Since no other element types are present, any
other platform condition or state is acceptable (e.g. any PCR values).
3.2.8.2 Combining Policies
When both the Platform Supplier and the Platform Owner have established policies on
the platform, the two policies are combined to give a resultant policy that the LCP
policy engine will enforce.
For every policy element that the policy engine evaluates, the policy engine will
consider the evaluation successful if either the Supplier or Owner policy evaluates that
element successfully (evaluated per the rules above), unless Ignore_PS_EltType bit is
set. (any of the Owner policy element instances has set bit 0 of the PolEltControl field
of its element instance or Ignore_PS_EltType bit in LCP_POLICY). If
Ignore_PS_EltType is set then only the Owner policy for that policy element will be
evaluated. This permits the Platform Owner to prevent rollback of signed Platform
Supplier policies and also allows the Platform Owner final control of the platform’s
policy. As such, policy engines should evaluate the Owner policy first, if it exists.
For policy elements that only appear in one policy, that policy will be used.
If there is no Owner policy then only the Supplier policy is evaluated and it is
evaluated per the rules of section 3.2.8.1. However, the policy engine must permit
any MLE to launch, regardless of whether it is in the Supplier policy. This is to permit
the Platform Supplier to include an LCP_MLE_ELEMENT (in order to allow launching of
an MLE provided by the Platform Supplier even if an Owner policy did not include that
MLE on its own list) but still permit the Platform Owner to launch any MLE without
having to provision an Owner policy. This preserves the same Owner-visible behavior
as the case where the Platform Supplier did not provide an LCP_MLE_ELEMENT. Note
that all other element types are evaluated as expected.
The following table shows which policy will be evaluated for all combinations of
policies and types. This is not the same as which policy is actually executed, since a
policy may not contain any elements that are understood by the policy engine and
thus that policy would not actually be executed (same as None).
No PS PS type
ANY PS type
LIST
No PO None Note1 PS PS Note 2
PO type
ANY PO PO PO
PO type
LIST PO PO Both Note 3
Note 1: If no policy is evaluated then all platform and software configurations are
permitted.
Note 2: Per above, any MLE will be allowed to launch regardless of the Supplier
policy.
Verifying Measured Launched Environments
315168-013 59
Note 3: This is effectively a union of the two policies (caveat Ignore_PS_EltType bit).
As can be seen from this table, if the Owner has installed a policy of type ANY then it
will override all policy elements in the Supplier policy, including any PCONF or SBIOS
elements intended to restrict the BIOS. If the owner is only interested in making sure
that any MLE can launch, then there is no need for a PO policy, as that is already the
behavior (see above).
3.2.8.3 Measuring the Enforced Policy
The LCP engine in SINIT will extend to PCR 17 a hash value which represents the
policy or policies against which the environment was launched. This hash value is
determined by the rules in the following sections.
It is important that for all policy cases that a measurement will always be extended to
PCR 17 in order to prevent the MLE from later extending a value of a policy that was
not evaluated. This is an issue because PCR 17 is open to locality 2 extends and the
MLE executes with locality 2 access. If this were not done, such an MLE could get
access to data that were sealed against some known policy by another MLE.
As a matter of integrity, the LCP_POLICY::PolicyControl field will always be extended
into PCR 17. If an Owner policy exists, its PolicyControl field will be extended;
otherwise the Supplier policy’s will be. If there are no policies, 32 bits of 0s will be
extended.
Other ACMs’ policy engines do not extend to the DRTM PCRs.
3.2.8.4 No Policy Data
When no policy is executed (includes all ACMs per above; there may be Supplier
and/or Owner policies but none of their policy elements are understood by the ACMs’
policy engines or they contain no policy elements), 20 bytes of 0s will be extended to
PCR 17.
3.2.9 Allow Any Policy
If an Owner policy exists and is of type LCP_POLTYPE_ANY, or no Owner policy exists
and the Supplier policy is of type LCP_POLTYPE_ANY, then 20 bytes of 0s will
extended to PCR 17.
3.2.10 Policy with LCP_POLICY_DATA
Because the measurement may contain the measurements of more than one policy
list, it is important that the SINIT ACMs for all platforms order the list measurements
in the same way so that identical policy evaluations will extend PCR 17 with the same
value.
The policy engine will order the policy list measurements according to the order in
which it evaluates policy elements. For this version of the specification, the following
policy element types are evaluated in this order: LCP_POLELT_TYPE_MLE,
LCP_POLELT_TYPE_PCONF, LCP_POLELT_TYPE_SBIOS, LCP_POLTYPE_STM. If
Verifying Measured Launched Environments
60 315168-013
additional policy element types are supported in the future, their evaluation order will
be specified.
The policy engine will not measure duplicate policy lists, so if the same list is
evaluated for more than one policy element then it will only be measured the first
time.
Policy engine will not allow more than one list to be signed with the same signature
key and will abort if such lists are found.
The value that will be extended to PCR 17 will be the hash of the concatenation of all
policy list measurements used.
If an Owner policy exists and is of type LCP_POLTYPE_LIST, no Owner policy exists
and the Supplier policy is of type LCP_POLTYPE_LIST, or both the Owner and Supplier
policies exist and are of type LCP_POLTYPE_LIST, then the value extended to PCR 17
is calculated as described above.
3.2.11 Force Platform Owner Policy
Whether the Platform Supplier policy indicates that the Platform Owner policy must be
present (via bit 3 of its PolicyControl field) or not does not affect the measurement of
the enforcing policy. The measurement will be calculated as indicated above.
3.2.12 Platform Owner Index
The Platform Owner policy index is intended to represent the policy defined by the
owner of the platform, and as such should be provisioned with access control
permissions that enforce that control over the policy remains with the platform owner.
The following attribute settings are required:
Index Value: 0x40000001
Size: 54 bytes
Read Locality: 3 (can be others as well)
Read Auth: None
PCR Read: None
The simplest access control setting that maintains platform owner control is to set the
Write Auth to Owner. However, this also means that updating the policy requires the
owner authorization. As the owner authorization can be used for almost all TPM
management operations, it may be desirable to limit its use.
Another possibility would be to use a separate authorization just for this index. That
would eliminate having to provide the owner authorization just to update the policy.
If trusted software, running in the context of the MLE or with access to TPM locality 2,
needs to be able to update the policy, then it would be possible to have no Write Auth
but set the Write Locality to 2. This would permit whatever software was able to
successfully launch to update the policy.
Note that it is not advisable to use PCR Write controls, since it would mean that the
specified PCR could not change over time (e.g. if the software measured into it was
Verifying Measured Launched Environments
315168-013 61
upgraded). This is because the index attributes cannot be changed once the index is
created.
3.3 LCP Components, V3 (TPM2.0)
The changes required from version V2 to effect launch control in TPM 2.0 mode are
defined and described in this section.
3.3.1 TPM NV RAM
Launch Control Policy in TPM 2.0 mode will continue to use the legacy TPM NV RAM
index names of AUX, PS and PO. Purposes of these indices remain the same but
attributes, sizes and layout change. Properties and owning authorities change as well,
as described below.
3.3.1.1 nameAlg Support
When defining a TPM NV index, the nameAlg parameter specifies the Hashing
algorithm used by the policy controlling that index and therefore the cryptographic
strength used to protect that index’s data.
There must be constraints on what nameAlg may be used for TPM NV indices. The
Platform Supplier or Platform Owner is free to select one from among those supported
by the TPM (TPM_HashAlgIDList from H.3) that meet cryptographic strength
constraints for intended use.
PS / PO indices cannot contain any settings controlling the strength of their own
protection, as these would be self-referential and impossible to configure initially. An
insufficiently strong nameAlg may lead to insufficient policy protection of index access,
making the contents of such an index vulnerable. Refer to 3.3.6 for specific nameAlg
requirements.
ACMs will be built requiring a minimum bit-length for allowed hash algorithms. For
example, if this built-in minimum requirement was 256 bits, then SHA256 and SM3
would satisfy it.
The nameAlg parameter for AUX, PS and PO indices must meet this requirement, or
the ACM will generate a reset. The exception to this is when the nameAlg is the only
supported algorithm on the platform, even if it does not meet the minimum.
Note that when the nameAlg for an index meets the minimum requirement,
algorithms used within the index need not; that index’s contents will be trusted,
irrespective of the strength of internal protections for contained items.
3.3.1.2 Platform Owner Index
Platform Owner (PO) index purpose and usage remains the same as in V2 LCP – see
section 3.2.12, but its definition for TPM 2.0 must be changed. New PO index
attributes are specified in Table
PO index size depends on the hash algorithm specified in its HashAlg field (see
Appendix D.1 and Appendix E.1).
Verifying Measured Launched Environments
62 315168-013
3.3.2 LCP Policy 2
LCP_POLICY structure (renamed as LCP_POLICY2) has been modified from the V2
version as described here. For a full listing, see Appendix E.
Version is now 3.0 or 3.1 (300H, or 301). Version 3.0 employs original layout of
PolicyControl field with bits 20:16 reserved. Version 3.1 uses new format of
PolicyControl field with bits 20:16 defined as Ignore_PS_EltType bits.
HashAlg grows to 16 bits and the 8-bit Reserved1 is deleted. This field now uses
TPM2.0 numeric values.
PolicyControl has the same basic content as specified in section 3.2.2 with the
changes as indicated in 3.3.2.1.
• It adds an overloaded definition to bit 3 when the type is PO: PS_Pconf_Enforced.
• Bit 31 is used by platform manufacturer for platform refurbishing
New fields are added after MaxBiosacMinVer, consuming the space from Reserved3:
LcpHashAlgMask: mask of approved hash algorithms for LCP evaluation.
LcpSignAlgMask: mask of approved signature schemes for LCP evaluation.
AuxHashAlgMask: mask of approved hash algorithms for auto-promotion hash, which
is only valid in PS index.
PolicyHash is an LCP_HASH2 versus LCP_HASH as in V2.
For more information about the use of these masks and policy control bits, see 3.3.4
and 3.3.10.
3.3.2.1 PolicyControl Field for LCP_POLTYPE_LIST
The PolicyControl field differs between versions 3.0 and 3.1 and consists of control bits
defined as:
• Bit 31 is used by platform manufacturer for platform refurbishing. Must be zero for
normal execution mode.
• Bits 30:4 Reserved and should be set to zero
If LCP_POLICY2.Version == 3.0
• Bit 20:16 Reserved and should be set to zero
If LCP_POLICY2.Version == 3.1 bits 20:16 are identical to V2 definition – see 3.2.2
• Bit 3 in PS policy is identical to V2 definition.
• Bit 3 in PO policy is defined as PS_PCONF_ENFORCED bit. When set to 1 it
requires PCONF match to be found in both Platform Owner and Platform Supplier
policy files – see full description in section 3.4.4.3
• Other bits are identical to V2 definitions – see section 3.2.2
Verifying Measured Launched Environments
315168-013 63
3.3.3 LCP Policy Data
This structure matches that for V2, but the LCP_POLICY_LIST element has been
replaced by LCP_LIST – see E.2.1, a union of LCP_POLICY_LIST and
LCP_POLICY_LIST2. This allows V3 policy data to contain a mixture of V2 and V3
policy lists.
3.3.4 LCP Policy Elements
Additional policy element types have been defined for TPM2.0 mode. These new
element types are enhancements to the TPM1.2 elements with augmentations for
algorithm agility. These new elements are defined in Appendix E.
For PolEltControl, please see 3.2.5 for more information, it is the same as for V2
structure.
3.3.4.1 LCP Element Structures
The LCP structures used for TPM 1.2 are not articulate enough to support the
algorithmic agility possible with TPM 2.0 devices. New elements based on the existing
elements have been defined to add such support. The changes have been designed to
allow lists comprised of both TPM 1.2 and TPM 2.0 elements. This minimizes space
requirements for NV RAM, allows to maintain the same number of authorities (8) since
no authority will have to supply separate lists for V2 and V3 elements, and simplifies
processing logic. Where possible, the new element structures use constants as
defined in the TCG 2.0 specification. See Appendix E.
3.3.5 List Signatures
HashAlgIDs accepted in RSA and ECC signatures will be limited to those included in
the LcpSignAlgMask defined in Appendix E.1.
3.3.6 PCR Extend Policy
TPM 2.0 family of devices support different sets of commands to extend
measurements into PCR banks:
• Extend command allows to extend already computed digest(s) into one or several
selected PCR banks;
• Event and Event Sequence commands allow sending of data stream to TPM which
will then compute digests and extend them into all existing banks of PCRs at once.
Since expected performance of these sets of commands is different, ACM will support
Extend Policy prescribing set of commands used to extend PCRs
Two policy settings will be supported:
1 Maximum Agility (MA). When this policy is selected ACM will extend PCRs
using commands TPM2_PCR_Event; TPM2_HashSequenceStart;
TPM2_HashUpdate; TPM2_EventSequenceComplete. These commands will
extend all existing PCR banks at the expense of possible performance loss.
Verifying Measured Launched Environments
64 315168-013
2 Maximum Performance (MP). When this policy is selected ACM will use
embedded SW to compute hashes and then will use TPM2_PCR_Extend
commands to extend them into PCRs. If PCRs utilizing hash algorithms not
supported by SW are discovered, they will be capped with “1” value. This
policy when selected will ensure maximum possible performance at the
expense of possible capping of some of the PCRs.
Policy is delivered to SINIT via Os to SINIT Data heap table – see C.4
3.3.6.1 SINIT Policy Selection
ISVs supplying MLE solutions can retrieve information of SINIT supported embedded
SW algorithms from TPM Info List Table (see Table A-7. TXT_ACM_PROCESSOR_ID
Format) and also examine capabilities of installed TPM to make a comprehensive
choice.
Currently MLE and SINIT operations are not perceived to be time critical and therefore
MA Extend Policy setting is envisioned to be suitable in all cases and can be statically
chosen.
Nevertheless, possibility to apply installation time logic based on discovered
capabilities remains a possibility for MLE developers. If all of the TPM PCR banks are
supported by SINIT embedded SW, MP Extend Policy can be chosen. Otherwise MA
Extend Policy has to be a choice. Chosen policy may be delivered to MLE via
configuration setting.
3.3.7 V3 Policy Engine Logic.
V3 policy engine logic is successor of principles defined for V2 engine and described in
section 3.2.8. Obvious differences are related to TPM algorithm agility peculiar to TPM
2.0 family of devices, new format of LCP structures, and new data combining
possibilities. The following sections will describe deltas in policy engines behavior.
3.3.7.1 General V3 LCP Evaluation Principles
ACMs’ ability to evaluate LCP elements present in data files depends on its hashing
capabilities originated from two sources - embedded software and TPM hashing
commands. Based on these two sources ACM builds lists of supported hashing
algorithms following logic described in Appendix H. Using of these lists for evaluation
of different element types is described in the following sections.
3.3.7.1.1 Evaluation of MLE, STM, and SBIOS policy elements
The evaluation of MLE, STM, and SBIOS policy elements is determined by the
EFF_HashAlgIDList as described in H.3. Elements of the above types hashed with
HashAlgIDs not in this list will cause Policy Engine abort.
Use of EFF_HashAlgIDList list is not Extend Policy dependent.
Verifying Measured Launched Environments
315168-013 65
3.3.7.1.2 Evaluation of PCONF LCP Elements
The evaluation of PCONF elements depends on TPM capabilities, and will be limited
only by PCR banks supported by given TPM i.e. by PCR_HashAlgIDList as described in
H.3.
Hash algorithm used to compute composite digest will be also determined by
LCP_TPM_HashAlgIDList as described in H.3, ensuring that the HashAlgID associated
with such elements is permitted by PS / PO policies and that the PCRs implementing
the PCONF HashAlgID indeed exist.
Use of LCP_TPM_HashAlgIDList list is not Extend Policy dependent.
3.3.7.2 Policies
V3 policy engine supports the same polices as its V2 counterpart – see section 3.2.8.1
3.3.8 Combining Policies
Principles of combining remain the same as described in section 3.2.8.2
Combining of new elements not present in V2 LCP structures is described below.
• If PO index is provisioned then its LcpHashAlgMask and LcpSignAlgMask are
effective, otherwise LcpHashAlgMask and LcpSignAlgMask defined in PS index are
effective
• AuxhashAlgMask defined in PS index is always effective since it is undefined in PO
index.
• Ignore_PS_* bits defined in PO index are always effective since they are
undefined in PS index.
3.3.9 Measuring the Enforced Policy
The updated LCP structures described in Appendix E require changes in how effective
LCP hashes are computed for extension into PCR 17 and 18.
3.3.9.1 Effective LCP Policy Details
The Effective LCP Policy Details Hash represents all of the elements contributing to the
currently established policy. As in v2.2, this is a hash of the concatenation of
descriptors per element type, extended into PCR 17. However, the size of the digests
encountered may vary, and it is no longer possible to allocate a single fixed size for all
of the descriptors.
The following data structures address this issue.
#define ELT_IND UINT8
#define POL_CONTROL UINT32
typedef struct {
ELT_IND EltIndicator; // Boolean presence indicator == “1”
Verifying Measured Launched Environments
66 315168-013
POL_CONTROL PolControl;
TPMT_HA EffEltDigest; // Standard TPM 2.0 library
structure
} EFF_ELT_PRESENT_DESCRIPTOR;
typedef struct {
ELT_IND EltIndicator; // Boolean presence indicator == “0”
} EFF_ELT_ABSENT_DESCRIPTOR;
typedef union {
EFF_ELT_PRESENT_DESCRIPTOR PresDescr;
EFF_ELT_ABSENT_DESCRIPTOR AbsDescr;
}EFF_ELT_DESCRIPTOR, E_E_D;
EltIndicator is byte size Boolean value initialized to “1” to indicate that given element
type contributed to established policy. In this case it is followed by details of satisfying
policy element. EltIndicator is initialized to “0” to indicate that given element type was
not found in policy files and was satisfied by default.
PolControl is PolEltControl field of satisfying policy element
EffEltDigest is a standard TPM 2.0 Library structure describing the matching digest
value of satisfying policy element. It contains HashAlgId and digest value.
For each of the elements involved, this last structure will be initialized to {1,
EffPolicyControl, EffEltDigest} if matched, or {0} if not. The concatenation to be
hashed will then be:
Concat = E_E_DMLE | E_E_DPO_PCONF | E_E_DPS_CONF | E_E_DSBIOS | E_E_DSTM
And the value extended into PCR 17 will be:
LcpEffPolicyDetails = HASHHashAlgID(Concat)
If LCP policy was “ANY”, a single byte of “0” will be measured into PCR 17 instead.
3.3.9.2 Effective LCP Policy Authorities
The Effective LCP Authorities Hash provides aggregated information about all of the
authorities (policy lists) contributing to the currently established policy. It will be
computed as follows: each authority will be described using the LIST_DSCR structure
defined below; all authority descriptors will be concatenated into a byte stream; that
byte stream will be hashed using the rule described below and extended into PCR 18.
If the LCP Policy evaluates to “ANY”, a single byte of “0” will be measured into PCR 18
instead.
3.3.9.2.1 List Descriptor
Each signed list will be represented using the following structure:
typedef struct {
UINT16 SignAlg;
UINT16 HashAlg;
Verifying Measured Launched Environments
315168-013 67
UINT16 PubKeySize;
TPMT_HA EffAuthDigest;
} LIST_SIGN_DSCR;
SignAlg is one of the supported signature algorithms, either TPM_ALG_RSADSA,
TPM_ALG_ECDSA or SM3.
HashAlg is the algorithm paired with the signature algorithm used to compute the
digest.
PubKeySize is the public key size in bytes.
EffAuthDigest is a standard TPM2.0 library structure describing the digest of the public
key of this authority. It includes the hash algorithm ID used to hash this Authority,
concatenated with the digest value of the public key field used for the list’s signature
in memory.
• For RSASSA signatures, the PubKeyValue[PubkeySize] field of
LCP_RSA_SIGNATURE is hashed using the HashAlg specified in the related PS or
PO NV Index. The size of the hashed data is PubkeySize.
• For ECDSA or SM2 signatures, the Qx[PubkeySize] and Qy[Pubkeysize]
components of LCP_ECC_SIGNATURE are hashed using the HashAlg specified in
the related PS or PO TPM NV Index. The size of the hashed data in PubkeySize *
2.
Each unsigned list will be represented using the following structure:
typedef struct {
UINT16 SignAlg;
TPMT_HA EffAuthDigest;
} LIST_UNSIGN_DSCR;
SignAlg is TPM_ALG_NULL.
EffAuthDigest is a standard TPM 2.0 library structure describing the digest of the
entire unsigned list. The entire list will be hashed using the HashAlg in the related PS
or PO TPM NV Index. The size of the hashed data is the size of the unsigned list itself.
Any list will be represented by the following structure:
typedef union {
LIST_SIGN_DSCR SignedList;
LIST_UNSIGN_DSCR UnsignedList;
} LIST_DSCR;
3.3.9.2.2 LcpEffPolicyAuthoritiesData byte stream
The method for constructing the data byte stream is straightforward. For each
authority, if it contains a matching element and is unique, its representation will be
derived from LIST_DSCR; if not, an empty buffer will represent it.
For signed elements, EffListData is constructed by concatenating:
• The signature algorithm ID
Verifying Measured Launched Environments
68 315168-013
• The hash algorithm ID associated with the signature
For RSASSA this is the hash algorithm used to create the encoded message—it is
extracted from the encoded message during signature verification in DER-encoded
form, and then converted to its TPM2.0-compliant 16-bit ID.
For ECDSA this is the hash algorithm used to create the message digest. For P-
256 signatures, it is SHA256; for P-384 it is SHA384; for SM2 it is SM3.
• The PubkeySize taken from the LCP_SIGNATURE2 structure
• EffAuthDigest as computed according to 3.3.9.2.1
For unsigned elements, EffListData is constructed by concatenating the signature
algorithm ID TPM_ALG_NULL and the EffAuthDigest data as computed according to
3.3.9.2.1.
These representations (EffListData) are then concatenated:
LcpEffPolicyAuthoritiesData = EffListDataMLE | EffListDataPO_PCONF |
EffListDataPS_PCONF | EffListDataSBIOS | EffListDataSTM
Note that authorities providing a match of PCONF elements in Platform Supplier and
Platform Owner data files are included individually. This is done to cover the case
when PCONF elements of both data files are required to match – see
PS_PCONF_ENFORCED bit description in 3.3.2.1
All signed LCP lists in each of the LCP Policy Data Files must use unique signing keys.
If authority needs to supply more than one signed LCP list, it must maintain unique
signing key for each of the lists.
3.3.10 Effective TPM NV info Hash
For an attester evaluating the trustworthiness of a platform/environment, the
properties of the TPM NV indices used by Intel® TXT are of considerable interest.
Therefore, SINIT will extend these properties into PCRs 17 and 18 and log the
extension process into the event log in a form that facilitates inspection.
TPMS_NV_PUBLIC structure is used as the descriptor of TPM NV index properties.
Based on that, the following structures are built:
#define IDX_IND UINT8
typedef struct {
IDX_IND IndexIndicator;
TPMS_NV_PUBLIC IndexProperties;
} EFF_IDX_PRESENT_DESCRIPTOR;
typedef struct {
IDX_IND IndexIndicator;
} EFF_IDX_ABSENT_DESCRIPTOR;
IndexIndicator is a Boolean byte size value initialized to “1” to indicate that index has
been provisioned and to “0” if not.
IndexProperties is a standard TPM 2.0 library structure fully describing index
properties.
Verifying Measured Launched Environments
315168-013 69
typedef union {
EFF_IDX_PRESENT_DESCRIPTOR PresDescr;
EFF_IDX_ABSENT_DESCRIPTOR AbsDescr;
} EFF_IDX_DESCRIPTOR, E_I_D;
For each of the indices:
• If present, its E_I_D = {1, PresDescr}
• If absent, its E_I_D = {0}
The data to be hashed will be:
LcpEffNvInfoData = E_I_DAUX | E_I_DPS | E_I_DPO
The data extended into PCR 17 and 18 will be:
LcpEffNvInfoHash = HASHHashAlgId (LcpEffNvInfoData)
3.4 Combined Policy Engine Processing Logic
The new structures defined for LCP v3 require changes in the processing engine logic
for both TPM1.2 and TPM2.0 mode. They are enumerated in this section.
In the following description legacy structures represent version 2 of LCP while new
structures represent version 3 of LCP (are denoted as V2 and V3 style structures
respectively.
3.4.1 Overall Topological Changes
1 V3 style LCP Policy Data Files can contain combination of V2 and V3 policy lists
2 V3 style policy lists can contain combination of V2 and V3 policy elements.
Purpose of such combining is to allow Authorities to maintain single Policy
Data Files covering TPM1.2 and TPM2.0 modes of execution.
3 V2 style lists can contain only V2 style policy elements.
3.4.2 Processing of Policy Data Files
1 De-jure we recognize V2 and V3 Policy Data Files but de-facto structures of
these files are identical. The only what makes Policy Data File to be V3 is
presence of V3 style lists. Policy Engine logic will not differentiate V2 and V3
style files.
2 Policy Engine in TPM1.2 mode will process V2 and V3 policy lists looking for V2
style elements only. All unrecognized elements including all V3 elements are
ignored in this mode;
3 Policy Engine in TPM2.0 mode will process only V3 policy elements. All
unrecognized elements including all V2 elements are ignored in this mode.
4 Policy Engine processes data files twice – first time to perform integrity
verification (validation), second time to enforce (evaluate) policy.
Verifying Measured Launched Environments
70 315168-013
5 During integrity verification phase Policy Engine will process each of Policy
Data Files separately. All of the lists in each of the files will be validated in the
order of appearance.
6 During policy enforcement phase Policy Engine will process files lists and
elements in the following order:
a. PO Policy Data File is evaluated first if present, then PS Policy Data
File if present.
b. Policy lists in each of data files are processed in the order of
appearance.
c. Elements are sought for match in the following order: MLE; PCONF;
SBIOS; STM
d. Elements of each type will be evaluated in the order of appearance in
Policy Data File, irrespective to hash algorithms they are using.
7 Policy Engine will continue to observe Ignore_PS_* bits during policy
enforcement phase in all modes but location of these bits has changed.
Originally they were defined as LCP_POLICY_ELEMENT.PolEltControl [0] bits
located in each of the element type related structure.
Now they are moved into PO index to make them available when no respective
element type structure exist and are positioned as PO.PolicyControl [20:16]
bits – see 3.2.1 and 3.3.2.
To reflect the change minor versions of respective structures have been
updated:
LCP_POLICY – 2.2 2.3;
LCP_POLICY_LIST – 1.0 1.1;
LCP_POLICY2 – 3.0 3.1;
LCP_POLICY_LIST2 – 2.0 2.1
a. Policy Engine must process both legacy and new location of
Ignore_PS_EltType bits in a legacy fashion.
b. Engine will assume consistency of the above versions (no mix-and-
match) but will not enforce it explicitly. Instead it will assume
placement of Ignore_PS_EltlType bits based on versions of
LCP_POLICY(2) structures only. Discovered versions 2.3 & 3.1 will
lead to use of PO.PolicyControl [20:16] bits, otherwise
Ignore_PS_EltType bits located in LCP_POLICY_LIST(2) structures will
be used.
8 Any integrity error causes platform reset.
9 There are three possible results of policy enforcement:
a. Successful policy evaluation a.k.a. all required matches found. Control
is passed to further module tasks;
b. Assumed successful policy evaluation. Some of the element types
were not found at all and are assumed to be successfully evaluated.
Control is passed to further module tasks;
c. No match error. Platform is reset
Verifying Measured Launched Environments
315168-013 71
3.4.3 TPM 1.2 mode
3.4.3.1 Supported Cryptographic Algorithms
There are no changes in supported algorithms.
3.4.3.2 Integrity Verification
In TPM1.2 mode logic of engine will remain the same as today but one not customer
visible change is required.
Since both legacy and new lists will be present in updated policy file, and since version
of V3 style lists is promoted it will be not recognized by TPM1.2 compatible engine. It
will stop evaluation and will abort with error when such list is met.
To prevent this TPM1.2 evaluation logic must be changed to recognize new V3 style
lists and evaluate them seeking legacy V2 style elements only. This also implies that
engine in TPM1.2 mode must be able to validate all forms of signatures supported in
TPM2.0 mode.
1 Policy Engine must validate all kinds of signatures including those supported in
V3 style lists. Policy engine must exit with error if signature cannot be
validated by any reason.
3.4.3.3 Policy Enforcement
There are no differences in legacy policy enforcement.
3.4.4 TPM 2.0 Mode
3.4.4.1 Supported Cryptographic Algorithms
1. There are two sources of supported crypto-graphical algorithms for signature
verification and hashing – embedded SW and TPM. List of currently supported
algorithms is presented in E.1
2. For the sake of performance TPM based services must be used only if
embedded SW lacks required support.
3.4.4.2 Integrity Verification
3.4.4.2.1 TPM NV Indices
Policy engine will perform the same verification steps as in TPM 1.2 mode and some
additional checks outlined below.
1 nameAlg strength check.
a. When each of the indices is verified, Policy Engine will compare
nameAlg of the index to the minimal required and abort with error if it
has lesser than required strength.
Verifying Measured Launched Environments
72 315168-013
b. Minimal required nameAlg is SHA256 or SM3 if they are supported by
current TPM. If the only TPM supported algorithm is SHA1, it will be
accepted by Policy Engine and will not generate an error.
2 LCP Policy Engine must ensure that PS.PolicyControl.AUXDeletionControl = 0.
If not – it must abort with error.
3 Policy Engine must ensure as a matter of integrity for each of the indices that
(note that PX below refers to PO or PS index):
a. PX.LcpHashAlgMask, PX.LcpSignAlgMask are not empty;
i. Each bit set in a PX.LcpHashAlgMask mask means that
relevant hash algorithm is permitted.
ii. Each bit set in PX.LcpSignAlgMask mask means that relevant
combination of signature algorithm, key size hash algorithm
and curve is permitted.
b. All hash algorithms permitted by PX.LcpHashAlgMask and
PX.LcpSignAlgMask are supported by ACM – see E.1 and E.3.1;
c. PS.AuxHashAlgMask index selects single hash algorithm permitted by
PS.LcpHashAlgMask (note that PO.AuxHashAlgMask is reserved and
ignored);
d. PX.HashAlg is permitted by PX.LcpHashAlgMask.
3.4.4.2.2 Policy Lists
1. When verifying RSA signatures Policy Engine will decrypt signature to obtain
encoded message. It will then use DER encoding to identify hash algorithm
(HashAlgID) used to hash plain text message.
2. Policy Engine will validate signatures of all signed lists – both V2 and V3 style
in all of available Policy Data Files and will reset platform if verification fails for
any reason.
a. Possible causes of errors include: signature of hash algorithm not
supported by ACM; not supported key size, not supported curve;
signature verification failure.
Note 1. Abort in case when signature algorithm is not supported by ACM
is needed to thwart attack when adversary intentionally changes signature
algorithm ID of the list to appear it to be not supported with intention to
cause fallback to ANY policy.
Note 2. Despite that V3 style elements cannot be present in V2 style lists
signature of V2 style lists still must be verified. This is needed to thwart
attack when adversary changes revision of V3 list to make it appear as V2
list.
3. Policy Engine will check revocation counters associated with lists and will abort
with error if any of the lists is revoked. Note that revocation counters located
in PS index are used to check revocation status of PS Policy Data File.
Revocation counters located in PO index are used respectively.
4. Policy Engine will check hash algorithms of all elements in all lists and abort
with error if finds one not supported by ACM.
Verifying Measured Launched Environments
315168-013 73
a. “Not supported” in this context must be understood as not supported
by ACM only if support provided by embedded SW or not supported by
TPM if ACM chooses to use TPM assistance.
b. This requirement is necessary because otherwise special form of ACM
substitution attack is possible when ACM is substituted by analogous
ACM but lacking support of some of the crypto-algorithms.
3.4.4.3 Policy Enforcement
1. If PO Index exists, both PO index and PS index will have LcpHashAlgMask and
LcpSignAlgMask. Based on this definition effective masks must be derived.
Method to obtain effective LcpHashAlgMask and LcpSignAlgMask mask is the
same as currently used for defining of effective PolicyControl:
a. If only the PS index exists – its LcpHashAlgMask and LcpSignAlgMask
masks are treated as effective;
b. If PO index exists its LcpHashAlgMask and LcpSignAlgMask masks are
treated as effective and PS masks are ignored;
c. AuxHashAlgMask is valid in PS index only and is reserved in PO index
and therefore it is treated as effective.
Note that effective masks will be henceforth denoted as
Eff.LcpHashAlgMask etc.
2. When evaluating list signatures if combination of signature algorithm, key
size, hash algorithm, and curve is not permitted by Eff.LcpSignAlgMask the list
will be skipped from enforcement and its entire content ignored.
3. For each found element engine will consult Eff.LcpHashAlgMask. It will process
element only if its HashAlgID is permitted by mask and will skip element
otherwise.
4. Engine must follow current implementation logic:
a. It must record each new element type as “required” when it is first
discovered if its hash algorithm is permitted by effective
Eff.LcpHashAlgMask. Element types filtered out by Eff.LcpHashAlgMask
will not trigger “required” assertion.
b. If at the end of evaluation match for “required” element type is not
found, error must be generated.
c. If any of the element types was not discovered at all – it must be
assumed to be evaluated successfully.
5. AuxHashAlgMask is used by Startup ACM and by client BIOSAC ACHECK
function.
a. Startup ACM will use this algorithm to compute Startup BIOS digest
which later will be stored in AUX index to be used for auto-promotion
– see also Appendix K, SBIOS element handling.
b. BIOSAC ACHECK function will use this algorithm to create and store
digest of selected memory controller registers.
6. New PO.PolicyControl bit is defined in PO index only and occupies the same bit
position as “PO is required” bit defined for PS index only. The purpose of this
bit “PS_Pconf_Enforced” bit is to change the way of combining of PCONF
elements coming from different authorities.
Verifying Measured Launched Environments
74 315168-013
Current logic when any element is evaluated is either/or – when first matching
element is found in any of the lists evaluation stops. This makes just single
element to be effective. Even when both PS and PO data files are defined and
are combined to produce effective policy, only single element will be enforced.
This logic is not very flexible as applied to PCONF elements. It forces Platform
Owner to include PCR0 values describing BIOS into own PCONF element also
including values of PCR2, 4 to have sufficient platform description. This is
onerous since PCR0 values come from OEM and IBV and describe BIOS while
PCR2, 4 come from Platform Owner (Data Center) which is different authority
and forces Platform Owner to recreate LCP data file after each BIOS update.
a. The above bit when set changes Policy Engine logic in the following
way.
i. It both LCP data files are present Engine processes PO data
file first – as today.
ii. If match is found – evaluation of PO data file stops and
evaluation of PS data file starts.
iii. If PCONF elements are not found in PS data file – evaluation is
considered a success and only PCONF element found in PO
data file is enforced.
iv. If PCONF elements are found in PS data file but match is not
found – it is an error and Engine will abort SINIT flow.
v. In all other cases logic is unchanged.
vi. The following truth table illustrates effect of
PS_Pconf_Enforced bit:
Table 3-1. Truth Table of PCONF Evaluation
PS_Pconf_Enforced
1 / 0
PO
PCONF
present:
Y / N (or
no PO
file)
PS
PCONF
present:
Y / N (or
no PS
file)
PO
PCONF
match
found
Y / N
PS
PCONF
match
found
Y / N
Exit
0 N N N N Success
0 N Y N N Failure
Y Success
0 Y N N N Failure
Y Success
0 Y Y N N Failure
Y N Success
N Y Success
Y Y Not
possible –
exit after
first match
Verifying Measured Launched Environments
315168-013 75
PS_Pconf_Enforced
1 / 0
PO
PCONF
present:
Y / N (or
no PO
file)
PS
PCONF
present:
Y / N (or
no PS
file)
PO
PCONF
match
found
Y / N
PS
PCONF
match
found
Y / N
Exit
1 N N N N Success
1 N Y N N Failure
Y Success
1 Y N N N Failure
Y Success
1 Y Y N N Failure
Y N Failure
N Y Failure
Y Y Success
b. The PS_Pconf_Enforced bit when set logically conflicts with the action
of “Ignore PS Element type bit” if latter is also set – see 3.2.2 and
3.2.5.
To avoid this conflict policy engine will detect that both bits are set to
“1” and flag this setting as error.
3.5 Revocation
3.5.1 SINIT Revocation
LCP also enables a limited self-revocation mechanism for SINIT. SINIT itself enforces
this on launch and a failure (i.e. the executing SINIT was revoked) results in a TXT
reset with an error code stored in the TXT.ERRORCODE register. The algorithm or
process that SINIT uses to determine whether it has been revoked is described in text
on the SINITMinVersion field in section 3.2.1. The rationale for this decision-making
process follows.
The ACM Info Table of an SINIT module contains that module’s version number, per
Table A-3. The SINITMinVersion field of the PS Index defines the minimum version of
an SINIT module that is allowed to execute to completion. SINIT verifies that its
version meets that required, and performs a self-revocation (via LT-RESET) if it does
not. This mechanism allows the OEM (platform supplier) to restrict execution of SINIT
versions prior to one they specify.
An SINIT version satisfying a platform SINITMinVersion may be found to have a
security flaw resulting in platform vulnerabilities after the OEM has provisioned the PS
Index. An orthogonal self-revocation mechanism is provided for this case. In addition
to its version number, each SINIT has a security version number (SVN). The platform
AUX Index contains a reference value this field can be verified against. If the SVN is
below the required version, SINIT performs a self-revocation as above.
Verifying Measured Launched Environments
76 315168-013
This AUX Index field is only updatable from locality 3, and hence can only be modified
by a special “revocation” ACM or by adding of respected functionality to select set of
BIOS ACM functions. Such a revocation or BIOS ACM would increase the AUX Index
SVN requirement to a new target value, precluding execution by SINIT modules with
lower SVN values, effectively revoking them. Misuse or misapplication of such a
revocation / BIOS ACM could impact platform functionality adversely. For example,
the AUX Index SVN bound could be elevated to a new value for which no ACMs having
a sufficiently high SVN exist for the affected platform.
The MaxSinitMinVersion field in the PO Index allows the platform owner or user to
control such revocation. Unless this field is set to 0xff, the value given is the
maximum value a revocation ACM may set the AUX index required SVN to.
§ §
Development and Deployment Considerations
315168-013 77
4 Development and Deployment
Considerations
4.1 Launch Control Policy Creation
Depending on the usage model, it may be desirable to create a Launch Control Policy
at the time the MLE is built. This would apply in the cases where only one MLE is
expected to run on the system. In such cases, the policy can be pre-created and
provisioned during the installation of the MLE.
If multiple MLEs are expected to run on the system, or if there is to be a platform
configuration policy, then it is likely that the policy will need to be created at the time
of deployment. As each element type is allowed in a policy list, each MLE will have its
own list if any of its list elements must differ from those of others.
In either case, it is advisable that the policy should contain a SINITMinVersion value
that corresponds to the lowest versioned SINIT that is required. In the case of a
system that supports multiple MLEs, a different SINITMinVersion may be specified
with each MLE’s policy element. The effective SINITMinVersion value will be the
highest of the values in the PS policy, PO policy, and matching MLE element (for each
one that exists). This effective SINITMinVersion will be compared to the AcmVersion of
the SINIT being used. Setting the SINITMinVersion value in the policy prevents an
attacker from substituting an older version of SINIT (if there is one for a given
platform) that may have security issues.
4.2 Launch Errors and Remediation
If there is an error during a measured launch, the platform will be reset and an error
code left in the TXT.ERRORCODE register. It is important for MLE vendors to consider
how their software will handle such errors and allow users or administrators to
remediate them.
If an MLE is launched automatically either as part of the boot process or as part of an
operating system’s launch process, it needs to be able to detect a previous failure in
order to prevent a continuous cycle of boot failures. Such failures may occur as part
of the loading and preparation for the GETSEC[SENTER] instruction or they may occur
during the processing of that instruction before the MLE is given control.
In the former case, it is the MLE launching software that is detecting the error
condition (e.g. a mismatched SINIT ACM, TXT not being enabled, etc.) and that
software can use whatever mechanism it chooses to persist the error or to handle it at
that time. In the latter case, the system will be reset before the MLE launching
software can handle the error and so that software should be able to detect the error
in the TXT.ERRORCODE register and take appropriate action.
The particular remediation action needed will depend on the error itself. If the MLE
launch happens early in the boot process, the launching software may need a way of
booting into a remediation operating system. If the launch happens within an
Development and Deployment Considerations
78 315168-013
operating system environment, the software may be able to remediate in that
environment.
4.3 Determining Trust
While a TXT Launch Control Policy can be used to prevent software use of TPM locality
2 and access to TXT private space, it is not a general mechanism to prevent unwanted
software from executing on a system. Consequently, an MLE cannot itself determine
whether it is running in a TXT measured environment (it could be running on an
emulator that spoofs PCR values, chipset registers, etc.).
In order to gain trust in an MLE (or rather, in software that uses TXT with the
intention of being an MLE), the PCR values for the MLE (PCRs 17 and 18) must be
used to make the trust “decision”. The trust “decision” must either be made by a
party external to the MLE’s system (i.e. remote attestation) or by the release of some
data that is not available to untrusted software (i.e. local attestation).
Remote attestation involves a remote party requesting the MLE to provide a TPM
quote of the PCRs needed to determine trust (at least 17 and 18) and that remote
party verifying the quote and making a trust determination of the PCR values. The
remote party can then act on the trust level in various ways (disconnect the MLE
system from the network, not provide it with network credentials, etc.). The details
involved in the remote attestation process can be found at the Trusted Computing
Group’s (TCG) website (http://www.trustedcomputinggroup.org/).
Local attestation, also known as SEALing, uses the TPM to encrypt some data bound
to certain PCR values (and/or locality). The data is typically SEALed by the MLE
system when the system is in a trusted state (there are multiple ways to establish an
initial trusted state) and the PCR/binding made to values that represent the desired
trusted state (the initial and final states don’t have to be the same as long as they are
both trusted). The SEALed data is then persistently stored, so it can be retrieved and
UNSEALed when the trusted MLE is running. The specifics of SEALing can also be
found on the TCG website.
4.3.1 Migration of SEALed Data
If SEALing/local attestation is used to protect data, then the MLE must be able to
accommodate the upgrading/changing of components whose measurements are in the
PCRs being SEALed to. Since PCRs 17 and 18 contain the TCB for the MLE, at a
minimum this would include SINIT, LCP, the MLE, etc. (see section 1.9 for the
complete contents of these PCRs). If data is SEALed to additional PCRs then changes
to the entities that are measured into these other PCRs must also be handled. While
data may be sealed to PCRs, locality, or an auth value, or any combination thereof,
migration is only an issue when PCRs are sealed to.
When one of the elements of the SEALed data’s PCRs is changed, the TPM will no
longer UNSEAL that data. So if no migration or backup of the plaintext data is made,
then after the next measured launch that data will not be available to the new MLE.
And unless the original MLE can be re-launched, the data will be lost. Thus, some
provision for making the data available to the new MLE must be made while the data
is still available in plaintext form (UNSEALed), i.e. in the original MLE.
Development and Deployment Considerations
315168-013 79
The most seamless and secure method for migrating the data to the new environment
is for the original environment to re-SEAL the data to the new environment. This
requires the original environment to calculate what the PCR values will be in the new
environment. For PCRs 17 and 18, this can be done using the information in section
1.9, coupled with knowing or being able to calculate the constituent values for the
new components. Alternately, if the new environment were run on a trusted system
(so that nothing would tamper with the measurements), the PCR values could then be
collected from that system and used directly as the new values without having to
calculate them from the components.
Other methods, such as password-based recovery, key escrow, etc. would be the
same as for any other encrypted data and have similar tradeoffs.
4.4 Deployment
4.4.1 LCP Provisioning
4.4.1.1 TPM Ownership
Because creation and writing to the Platform Owner policy TPM NV index requires the
TPM owner authorization credential, the installation program should accommodate
differing IT policies for how and when TPM ownership is established. In some
enterprises, IT may take ownership before a system is deployed to an end user. In
others, the TPM may be un-owned until the first application that requires ownership
establishes it.
Since the TPM owner authorization credential will be required to modify the Platform
Owner policy, if the installation program creates the credential it should provide a
mechanism for securely saving that credential either locally or remotely.
4.4.1.2 Policy Provisioning
The Platform Owner policy TPM NV index will need to be created by the MLE
installation program (or other TPM management software) if does not already exist.
This can be done with the TPM_NV_DefineSpace or TPM2_NV_DefineSpace command
or corresponding higher-level TPM interface (e.g. via a TCG Software Stack or TSS).
Once the index has been created, the installation program can write the policy into the
index using the TPM_NV_WriteValue or TPM2_NV_Write command or corresponding
higher-level TPM interface (e.g. via a TCG Software Stack or TSS).
Because creating and writing to the Platform Owner policy index requires the TPM
owner authorization credential, care should be taken to protect the credential when it
is being used and to erase or delete it from memory as soon as it is no longer needed.
Ideally, policy provisioning would occur in a secure environment or be performed by
an agent that can be verified as trustworthy. An example of the former would be on
an isolated network immediately after receiving the system. Another would be
booting from a CD containing provisioning software. An example of the latter would
be to use Intel® TXT to launch a provisioning MLE or agent that was then attested to
by a remote entity which could provide the owner authorization credential upon
successful attestation.
Development and Deployment Considerations
80 315168-013
4.4.2 SINIT Selection
Because the SINIT AC module is specific to a chipset, different platforms may have
different SINIT ACMs. If an MLE is intended to run on multiple platforms with different
chipsets, the MLE installation program will need to determine which SINIT ACM to
install if the platform BIOS does not provide the SINIT ACM or if the MLE wants to use
a later version.
Comparing the chipset compatibility information in the SINIT ACM’s Chipset ID List
with the corresponding information for the platform accomplishes this. This would be
identical to the process for verifying SINIT ACM compatibility at launch time, as
described in section 2.2.3.1.
4.5 SGX Requirement for TXT Platform
Software Guard Extensions (SGX) is a set of instructions and mechanisms for memory
accesses added to Intel® Architecture processors. These extensions allow an
application to instantiate a protected container, referred to as an enclave. An enclave
is a protected area in the application’s address space, which provides confidentiality
and integrity even in the presence of privileged malware. Accesses to the enclave
memory area from any software not resident in the enclave are prevented. For more
details about SGX, please reference Intel SGX Programming Reference Guide
Since TXT ACMs are in Trusted Computing Base (TCB) of SGX, SGX SW must be made
aware of the SGX Security Version Numbers (SGX SVN) of all of the ACMs in the
system. Passing of ACM SGX SVNs to SGX SW is performed via dedicated
BIOS_SE_SVN MSR programming of which is the BIOS responsibility. This BIOS task
is trivial if all of the ACMs in the system are carried in BIOS flash, but presents a
special challenge to client platforms carrying SINIT ACM on HDD where it is not
available for BIOS examination.
In order to avoid ungraceful resets resulted from mismatch of expected and actual
SVN (security version number) of SINIT ACM during launch of SGX and TXT,
requirements of SGX, TXT and BIOS interface developed for client platforms should be
followed.
The interface allows the TXT runtime software to convey to BIOS the value of SINIT
SVN to be used at next POST. In worst case one additional system reboot after update
of SINIT in TXT software stack is required.
The Interface is based on a mailbox mechanism implemented as SGX TPM NV index
with unrestricted read and write capabilities. TXT runtime software will write into this
index with SGX SVN discovered in SINIT ACM and BIOS will read this index and
program into SINIT_SVN field of BIOS_SE_SVN MSR.
SGX TPM NV Index is mandatory on the client platforms supporting TXT. If this index
doesn’t exist, SINIT_SVN field of BIOS_SE_SVN MSR will remain as default 0xFF value
and this will cause TXT shutdown when GETSEC[SENTER] is executed after first non-
faulty SGX instruction. The Index size is 8 bytes.
Details of SGX index definition for V2 and V3 structures can be found in Table and
Table respectively.
The following must be noted for TPM 2.0 index definition:
Development and Deployment Considerations
315168-013 81
1. authValue of index by convention must remain at default value “empty
buffer”. This will enable unrestricted access by any agent from any locality.
2. Deletion of index can be performed under control of OEM policy only –
analogously to other TXT indices.
Table 4-1. SGX Index Content
Bytes 1 - 7. Reserved, must be zero. Byte 0. SGX SINIT_SVN.
Saved by MLE of specially defined tool. Must
be initialized to default value “1”
Table 4-1. SGX Index Content diagrammatically illustrates the SGX index structure
Table 4-2 shows content of IA32_SE_SVN_STATUS MSR used by software
components:
Table 4-2. IA32_SE_SVN_STATUS MSR (0x500)
Bits Name Comment
0 Lock 0 – BIOS_SE_SVN MSR can be floated down.
Launching a
properly signed ACM will not lead to LT
shutdown irrespective of its SE SVN
1 - BIOS_SE_SVN MSR is locked. Launching
of ACM with SGX SVN lower than value of
SINIT_SVN field will LT reset platform.
15:1 Reserved
23:16 SINIT_SVN Reflect values of bits 23:16 of BIOS_SE_SVN
MSR (SINIT_SVN) on CPUs that enumerate
CPUID.feature_flags.SMX as 1.
On CPUs that enumerate
CPUID.feature_flags.SMX as 0, these bits are
reserved (0).
63:24 reserved
This is read only MSR.
Line 1: SINIT may be present in BIOS flash as is practice for server platforms, and
workstations. In this case BIOS is responsible for finding SINIT module,
decompressing it and placing in heap SINIT memory. It also has to program
BiosSinitSize field in BIOS Data table – see Table .
Lines 2, 3: If SINIT is present in BIOS flash as signaled by value of BiosSinitSize field,
MLE may exit this flow since BIOS has all of the necessary information to program
BIOS_SE_SVN MSR. SGX index may not exist and is ignored if exists and MLE shall
not generate any SGX index related errors.
Lines 4, 5: MLE shall exit this flow if SGX is not supported by CPU
Line 7: SGX SVN value is located in SINIT header in a word at offset 0x1E
Development and Deployment Considerations
82 315168-013
Lines 8, 9: Architectural IA32_SE_SVN_STATUS MSR carries the same SINIT SGX
information which is programmed into BIOS_SE_SVN MSR. MLE shall avoid accessing
non-architectural BIOS_SE_SVN MSR. It shall retrieve programmed SINIT SGX SVN
value from IA32_SE_SVN_STATUS MSR instead. If value retrieved from
IA32_SE_SVN_STATUS MSR differs from SINIT SGX SVN, value of SGX index has to
be updated and system reset to let BIOS use updated information.
Lines 10, 11: If BIT 0 of IA32_SE_SVN_STATUS MSR is “0” SGX is not active and MLE
may continue to launch SINIT. If BIT 0 of IA32_SE_SVN_STATUS MSR is “1” SGX is
active and attempt to launch SINIT will lead to ungraceful platform reset. MLE shall
avoid it by one of the possible actions: It may post message to user and reset
platform after a short delay to let BIOS use correct SINIT SGX SVN number at next
boot. Alternatively it may post message to user and let him reset platform manually at
proper time.
Listing 9. SGX Support on TXT Platform Pseudo code
1. Find appropriate SINIT for platform.
2. If SINIT is already present in SINIT memory
3. Exit this flow
//
// Enumerate SGX support. Analyze CPUID.feature_flags.SE bit
// (leaf 7, sub-leaf 0, EBX.bit2).
//
4. If CPUID.feature_flags.SE bit is not set {
5. Exit this flow
6. }
7. Read SINIT_SVN 16-bit value from SINIT header offset 0x1E
8. If IA32_SE_SVN_STATUS[23:16] != SINIT_SVN {
//
// Write SINIT_SVN value from ACM header into SGX TPM NV index
//
9. SGX TPM NV index SINIT_SVN
//
// Read IA32_SE_SVN_STATUS MSR, lock bit (Bit 0)
//
10. If IA32_SE_SVN_STATUS MSR[0] == 1 { // SGX is active
11. Reset platform
12. }
13. }
§ §
Intel® TXT Execution Technology Authenticated Code Modules
315168-013 83
Appendix A Intel® TXT Execution
Technology Authenticated Code
Modules
A.1 Authenticated Code Module Format
An authenticated code module (AC module) is required to conform to a specific
format. At the top level the module is composed of three sections: module header,
internal working scratch space, and user code and data. The module header contains
critical information necessary for the processor to properly authenticate the entire
module, including the encrypted signature and RSA based public key. The processor
also uses other fields of the AC module for initializing the remaining processor state
after authentication.
The format of the authenticated-code module is in Table A-. This definition represents
Revision 0.0 of the AC module header version (defined in the HeaderVersion field).
Table A-1. Authenticated Code Module Format
Field Offset Size (bytes) Description
ModuleType 0 2 Module type
ModuleSubType 2 2 Module sub-type
HeaderLen 4 4 Header length (in multiples of four
bytes)
(161 for version 0.0)
HeaderVersion 8 4 Module format version
ChipsetID 12 2 Module release identifier
Flags 14 2 Module-specific flags
ModuleVendor 16 4 Module vendor identifier
Date 20 4 Creation date (BCD format:
year.month.day)
Size 24 4 Module size (in multiples of four
bytes)
TXT SVN 28 2 TXT Security Version Number
SE SVN 30 2 Software Guard Extensions (Secure
Anclaves) Security Version Number
CodeControl 32 4 Authenticated code control flags
Intel® TXT Execution Technology Authenticated Code Modules
84 315168-013
Field Offset Size (bytes) Description
ErrorEntryPoint 36 4 Error response entry point offset
(bytes)
GDTLimit 40 4 GDT limit (defines last byte of GDT)
GDTBasePtr 44 4 GDT base pointer offset (bytes)
SegSel 48 4 Segment selector initializer
EntryPoint 52 4 Authenticated code entry point offset
(bytes)
Reserved2 56 64 Reserved for future extensions
KeySize 120 4 Module public key size less the
exponent (in multiples of four bytes)
(64 for version 0.0)
ScratchSize 124 4 Scratch field size (in multiples of four
bytes)
(2 * KeySize + 15 for version 0.0)
RSAPubKey 128 KeySize * 4 Module public key
RSAPubExp 384 4 Module public key exponent
RSASig 388 256 PKCS #1.5 RSA Signature
End of AC module header
Scratch 644 ScratchSize * 4 Internal scratch area used during
initialization (needs to be all 0s)
User Area 644 +
ScratchSize*4 N * 64 User code/data (modulo-64 byte
increments)
ModuleType
Indicates the module type. The following module types are defined:
2 = Chipset authenticated code module.
Only ModuleType 2 is supported by GETSEC functions SENTER and ENTERACCS.
ModuleSubType
Indicates whether the module is capable of being executed at processor reset.
0 = ACM cannot be executed at processor reset
1 = ACM is capable of being executed at processor reset
ModuleSubType 1 is not supported for use by the GETSEC[SENTER] instruction.
HeaderLen
Length of the authenticated module header specified in 32-bit quantities. The
header spans the beginning of the module to the end of the signature field. This is
fixed to 161 for AC module version 0.0.
Intel® TXT Execution Technology Authenticated Code Modules
315168-013 85
HeaderVersion
Specifies the AC module header version. Major and minor vendor field are
specified, with bits 15:0 holding the minor value and bits 31:16 holding the major
value. This should be initialized to zero for header version 0.0. The processor will
reject unsupported header versions, resulting in an abort during authentication.
ChipsetID
Module-specific chipset identifier.
Flags
Module-specific flags. The following bits are currently defined:
Table A-2. AC module Flags Description
Bit position Description
13:0 Reserved (must be 0)
14 Production (0) or pre-production (1)
15 Production (0) or debug (1) signed
ModuleVendor
Module creator vendor ID. Use the PCI SIG* assignment for vendor IDs to define
this field. The following vendor ID is currently recognized:
00008086H = Intel
Date
Creation date of the module. Encode this entry in the BCD format as follows:
year.month.day with two bytes for the year, one byte for the day, and one byte
for the month. For example, a value of 20131231H indicates module creation on
December 31, 2013.
Size
Total size of module specified in 32-bit quantities. This includes the header,
scratch area, user code and data.
TXT SVN
TXT Security Version Number
SE SVN
Software Guard Extensions (a.k.a. Secure Enclaves) Security Version Number
CodeControl
Authenticated code control word. Defines specific actions or properties for the
authenticated code module.
Intel® TXT Execution Technology Authenticated Code Modules
86 315168-013
ErrorEntryPoint
If bit 0 of the CodeControl word is 1, the processor will vector to this location if a
snoop hit to a modified line was detected during the load of an authenticated code
module. If bit 0 is 0, then enabled error reporting via bit 1 of a HITM during ACEA
load will result in an abort of the authentication process and signaling of an Intel®
Trusted Execution Technology shutdown condition.
GDTLimit
Limit of the GDT in bytes, pointed to by GDTBasePtr. This is loaded into the limit
field of the GDTR upon successful authentication of the code module.
GDTBasePtr
Pointer to the GDT base. This is an offset from the authenticated code module
base address.
SegSel
Segment selector for initializing CS, DS, SS, and ES of the processor after
successful authentication. CS is initialized to SegSel while DS, SS, and ES are
initialized to SegSel + 8.
EntryPoint
Entry point into the authenticated code module. This is an offset from the module
base address. The processor begins execution from this point after successful
authentication.
Reserved2
Reserved. Should contain zeros.
KeySize
Defines the width the RSA public key in dwords applied for authentication, less the
size of the exponent. The information in this field is intended to support external
software parsing of an AC module independent of the module version. It is the
responsibility of the developer to reflect an accurate KeySize. This field is not
checked for consistency by the processor.
ScratchSize
Defines the width of the scratch field size specified in 32-bit quantities. For version
0.0 of the AC module header, ScratchSize is defined by KeySize * 2 + 15. The
information in this field is intended to support external software parsing of an AC
module independent of the module version. It is the responsibility of software to
reflect an accurate ScratchSize. The processor does not check this field.
RSAPubKey
Contains a public key plus a fixed 32-bit exponent to be used for decrypting the
signature of the module. The size of this field is defined by the previously defined
AC module field, KeySize + 1.
Intel® TXT Execution Technology Authenticated Code Modules
315168-013 87
RSASig
The PKCS #1.5 RSA Signature of the module. The RSA Signature signs an area
that includes the some of the module header and the USER AREA data field (which
represents the body of the module). Parts of the module header not included are:
the RSA Signature, public key, and scratch field.
Scratch
Used for temporary scratch storage by the processor during authentication. This
area can be used by the user code during execution for data storage needs.
User Area
User code and data represented in modulo-64 byte increments. In addition, the
boundary between data and code should be on at least modulo-1024 byte
intervals. The user code and data region is allocated from the first byte after the
end of the Scratch field to the end of the AC module.
The chipset AC module information table is located at the start of the User Area
and contains supplementary information that is specific to chipset AC modules.
The chipset ID list is described in more detail in section 2.2.3.1.
Table A-3. Chipset AC Module Information Table
Field Offset
(Bytes) Width
(Bytes) Description
UUID 0 16 UUID of the Chipset AC module information table
defined as:
ULONG UUID0; // 0x7FC03AAA
ULONG UUID1; // 0x18DB46A7
ULONG UUID2; // 0x8F69AC2E
ULONG UUID3; // 0x5A7F418D
This UUID is used to identify a file/memory
image as being a chipset AC module.
ChipsetACMType 16 1 Module type (00h = BIOS; 01h = SINIT)
Bit 3, if set, flags the ACM as a revocation module,
hence “8” is a BIOS revocation AC, “9” is an SINIT
revocation AC.
Version 17 1
Version of this table. Table versions are always
backwards compatible. The highest version
defined is currently 6. Version 5 included all
changes added to suport TPM 2.0 family.
Version 6 is added to cover addition of ACM
Revision field.
Length 18 2 Length of this table in bytes.
ChipsetIDList 20 4 Location of the Chipset ID list used to identify
chipsets supported by this AC Module. This field is
an offset in bytes from the start of the AC Module.
See Table A- for details.
Intel® TXT Execution Technology Authenticated Code Modules
88 315168-013
Field Offset
(Bytes) Width
(Bytes) Description
OsSinitDataVer 24 4 Indicates the maximum version number of the OS
to SINIT data structure that this module supports.
It is assumed that the module is backward
compatible with previous versions.
MinMleHeaderVer 28 4 Indicates the minimum version number of the MLE
Header data structure that this module
supports/requires. MLEs with more recent header
versions are responsible for determining whether
they can support this version of the ACM.
Capabilities 32 4 Bit vector of supported capabilities. The values
match those of the Capabilities field in the MLE
header. This can be used by an MLE to determine
whether the ACM is compatible with it and to
determine any optional capabilities it might
support. See Table 2-2.
AcmVersion 36 1 Version of this AC Module. It is compared against
the SINITMinVersion field in LCP to determine if
the module is revoked.
ACM Revision 37 3 ACM Revision in the format:
<Major>.<Minor>.<Build> = XX.YY.ZZ
where X, Y and Z are hexadecimal digits.
Range for each of the fields is therefore 0 –
FF. It is assumed that this revision will be
added by BIOS to the list of records and will
be examined by tools such as TXTInfo and
Brand Verification.
ProcessorIDList 40 4 Location of the Intel® TXT Processor ID list used
to identify Intel® TXT processors supported by this
AC Module. This field is an offset in bytes from the
start of the AC Module. See Table A- for details.
Version >= 5
TPMInfoList 44 4 Location of table of TPM capabilities supported by
ACM. This field is an offset in bytes from ACM
start.
Table A-4. Chipset ID List
Field Offset Width (Bytes) Description
Count 0 4 Number of entries in the array ChipsetID
ChipsetIDs[] 4 Count *
sizeof(TXT_ACM
_CHIPSET_ID)
An array of count entries of the structure
TXT_ACM_CHIPSET_ID (see Table A-).
Intel® TXT Execution Technology Authenticated Code Modules
315168-013 89
Table A-5. TXT_ACM_CHIPSET_ID Format
Field Offset Width
(Bytes
)
Description
Flags 0 4 Set of flags to further describe functions of the
chipset ID structure.
Bit Description:
[0]: RevisionIdMask – if 0, the RevisionId field
must exactly match the TXT.DIDVID.RID field. If
1, the RevisionId field is a bitwise mask that can
be used to test for any bits set in the
TXT.DIDVID.RID field. If any bits are set, the
RevisionId is a match.
[31:1]: Reserved for future use. Must be 0.
VendorID 4 2 Indicates the chipset vendor this AC Module is
designed to support. This field is compared
against the TXT.DIDVID.VID field.
DeviceID 6 2 Indicates the chipset vendor’s device that this AC
Module is designed to support. This field is
compared against the TXT.DIDVID.DID field.
RevisionID 8 2 Indicates the revision of the chipset vendor’s
device that this AC module is designed to
support. This field is used according to the
RevisionIdMask bit in the Flags field.
Reserved 10 6 Reserved for future use.
Table A-6. Processor ID List
Field Offset Width (Bytes) Description
Count 0 4 Number of entries in the array
ProcessorID
ProcessorIDs[] 4 Count *
sizeof(TXT_ACM
_PROCESSOR_I
D)
An array of count entries of the structure
TXT_ACM_PROCESSOR_ID (see next
table).
Table A-7. TXT_ACM_PROCESSOR_ID Format
Field Offset Width
(Bytes
)
Description
FMS 0 4 Indicates the Family/Model/Stepping of the
processor this AC Module is designed to support.
This field is compared against the corresponding
value returned from the CPUID instruction.
FMSMask 4 4 Mask to apply to FMS
PlatformID 8 8 Indicates the Platform ID of the processor this AC
Module is designed to support. This field is
compared against the value in the
IA32_PLATFORM_ID MSR.
Intel® TXT Execution Technology Authenticated Code Modules
90 315168-013
Field Offset Width
(Bytes
)
Description
PlatformMask 16 8 Mask to apply to Platform ID
Table A-8. TPM Info List
Field Offset Width
(Bytes
)
Description
TPM Capabilities 0 4 TPM supported capabilities (described below)
Count 4 2 Number of entries in AlgortihmID[]
AlgorithmID[] 6 Count *
UINT16
An array of “Count” entries of algorithm IDs
supported by SINIT ACM per the TPM2
specification enumeration in Part 2, Table 7:
TPM_ALG_RSA == 0x0001
TPM_ALG_SHA1 == 0x0004
TPM_ALG_SHA256 == 0x000B
TPM_ALG_SM3_256 == 0x0012
Etc.
Table A-9. TPM Capabilities Field
Bit Position Description
1:0 TPM2 PCR Extend Policy Support
00: illegal
01: Maximum Agility Policy. Measurements are done using TPM PCR
event and sequence commands when a PCR algorithm is not included in
the embedded set of algorithms.
10: Maximum performance Policy. Measurements are done using
embedded fixed set of algorithms and TPM PCR extend commands
11: Both policies types are supported
5:2 TPM family support
0000: illegal
0001: discrete TPM 1.2 supported
0010: discrete TPM 2.0 supported
1000: firmware TPM 2.0 supported
Above settings can be combined to indicate multiple support options
6 TPM NV index set supported:
0 : Initial TPM 2.0 TPM NV index set out of 0x180_xxxx and 0x140_xxxx
ranges
1: TCG compliant TPM 2.0 TPM NV index set out of Intel Reserved range
of indices 0x1C1_0100 – 0x1C1_00x13F
31:7 Reserved, must be zero
Intel® TXT Execution Technology Authenticated Code Modules
315168-013 91
Notes on TPM2 PCR Extend Policy:
TPM2 PCR Extended Policy Support is a field describing ACM policy in regards to
integrity collection commands used:
Maximum Agility PCR Extend Policy: ACM can support algorithm agile
commands TPM2_PCR_Event; TPM2_HashSequenceStart; TPM2_HashUpdate;
TPM2_EventSequenceComplete. When this policy is selected ACM will use
aforementioned commands if not all PCR algorithms are covered by embedded
set of algorithms and will extend all existing PCR banks. Side effect of this
policy is possible performance loss.
Maximum Performance PCR Extend Policy: ACM can support a number of
hash algorithms via embedded SW. When this policy is selected, ACM will use
embedded SW to compute hashes and then will use TPM2_PCR_Extend
commands to extend them into PCRs. If PCRs utilizing hash algorithms not
supported by SW are discovered, they will be capped with “1” value. This
policy when selected will ensure maximum possible performance but has side
effect of possible capping of some of the PCRs.
For an ACM that supports both extend policies, it will use the one indicated in the flags
field in the OsSinitData structure (Table ).
Notes on TPM family:
0001 - Discrete TPM 1.2 supported: this includes all FIFO interfaces that are used with
this family – TIS 1.21, and TIS 1.3
0010 - Discrete TPM 2.0 supported: this includes all interfaces that are supported with
this family – TIS1.3, and PTP2.0.
0011 – Both combinations above are supported
1000 – TPM2.0 family is supported over CRB interface.
1010 – TPM2.0 family is supported over FIFO and CRB interfaces, etc.
A.1.1 Memory Type Cacheability Restrictions
Prior to launching the authenticated execution environment using the GETSEC leaf
functions ENTERACCS or SENTER, processor MTRRs (Memory Type Range Registers)
must first be initialized to map out the authenticated RAM addresses as WB (write-
back). Failure to do so may affect the ability for the processor to maintain isolation of
the loaded authenticated code module. The processor will signal an Intel® TXT
shutdown condition with error code #BadACMMType during the loading of the
authenticated code module if non-WB memory is detected.
Note that despite that CPU enforces only 4 KBytes SINIT alignment, such allocation
may require too many MTRRs to provide aforementioned WB cache-ability. It is
suggested then that BIOS actually allocate SINIT memory on 128 KBytes boundary.
This combined with specially selected SINIT sizes will allow using of minimal number
of MTRRs (up to 3)
While physical addresses within the load module must be mapped as WB, the memory
type for locations outside of the module boundaries must be mapped to one of the
supported memory types as returned by GETSEC[PARAMETERS] (or UC as default).
Intel® TXT Execution Technology Authenticated Code Modules
92 315168-013
This is required to support inter-operability across SMX capable processor
implementations.
A.1.2 Authentication and Execution of AC Module
Authentication is performed after loading of the code module into the authenticated
code execution area. Information from the authenticated code module header is used
to support the authentication process. The RSAPubKey header field contains a public
key plus a 32-bit exponent used for decrypting the signature of the authenticated
code module. The signature is held in encrypted form in the RSASig header field and it
represents the PKCS #1.5 RSA Signature of the module. The RSA Signature signs an
area that includes the sum of the module header and the entire USER AREA data field,
which represents the body of the module. Those parts of the module header not
included are: the RSA Signature, the public key, and the scratch field. An inconsistent
authenticated code module format, inconsistent comparison of the public key hash, or
mismatch of the decrypted signature against the computed hash of the authenticated
module or a corrupted signature padding value results in an abort of the
authentication process and signaling of an Intel® TXT shutdown condition. As part of
the authentication step, the processor stores the decrypted signature of the AC
module in the first 20 or 32 bytes (depending on the SINIT AC Module) of the
‘Scratch’ field of the AC module header.
After authentication has completed successfully, the private configuration space of the
Intel® TXT-capable chipset is unlocked. At this point, only the authenticated code
module or system software executing in authenticated code execution mode is allowed
to gain access to the restricted chipset state for the purpose of securing the platform.
The architectural state of the processor is partially initialized from contents held in the
header of the authenticated code module. The processor GDTR, CS, and DS selectors
are initialized from fields within the authenticated code module. Since the
authenticated code module must be relocatable, all address references must be
relative to the authenticated code module base address in EBX. The processor GDTR
base value is initialized to the AC module header field GDT BasePtr + module base
address held in EBX and the GDTR limit is set to the value in the GDT Limit field. The
CS selector is initialized to the AC module header SegSel field, while the DS selector is
initialized to CS + 8. The segment descriptor fields are implicitly initialized to BASE=0,
LIMIT=FFFFFh, G=1, D=1, P=1, S=1, read/write access for DS, and execute/read
access for CS. The processor begins the authenticated code module execution with the
EIP set to the AC module header EntryPoint field + module base address (EBX). The
AC module based fields used for initializing the processor state are checked for
consistency and any failure results in a shutdown condition.
§ §
SMX Interaction with Platform
315168-013 93
Appendix B SMX Interaction with
Platform
B.1 Intel® Trusted Execution Technology
Configuration Registers
Intel® TXT configuration registers are a subset of chipset registers. These registers
are mapped into two regions of memory, representing the public and private
configuration spaces. Registers in the private space can only be accessed after a
measured environment has been established and before the TXT.CMD.CLOSE-PRIVATE
command has been issued. The private space registers are mapped to the address
range starting at FED20000H. The public space registers are mapped to the address
range starting at FED30000H and are available before, during and after a measured
environment launch. All registers are defined as 64 bits and return 0’s for the
unimplemented bits. The offsets in the table are from the start of either the public or
private spaces (all registers are available within both spaces, though with different
permissions).
After writing to one of the command registers (e.g. TXT.CMD.SECRETS), software
should read the corresponding status flag for that command (e.g. TXT.E2STS
[SECRETS.STS]) to ensure that the command has completed successfully.
B.1.1 TXT.STS – Status
Description This is the general status register. AC modules and the MLE use this read-only
register to get the status of various Intel® TXT features.
Offset 000H
Pub Attribs
Priv Attribs
RO
RO
Bits Field Name Field Description
0 SENTER.DONE.
STS The chipset sets this bit when it sees all of the threads have done
an TXT.CYC.SENTER-ACK.
When any of the threads does the TXT.CYC.SEXIT-ACK the
TXT.THREADS.JOIN and TXT.THREADS.EXISTS registers will not
be equal, so the chipset will clear this bit.
1 SEXIT.DONE.
STS This bit is set when all of the bits in the TXT.THREADS.JOIN
register are clear. Thus, this bit will be set immediately after
reset (since the bits are all 0).
Once all threads have done an TXT.CYC.SEXIT-ACK, the
TXT.THREAD.JOIN register will be 0, so the chipset will set this
bit.
5:2 Reserved Reserved
SMX Interaction with Platform
94 315168-013
Bits Field Name Field Description
6 MEM-CONFIG-
LOCK.STS This bit will be set to 1 when the memory configuration has been
locked.
Cleared by TXT.CMD.UNLOCK.MEMCONFIG or by a system reset.
7 PRIVATE-
OPEN.STS This bit will be set to 1 when TXT.CMD.OPEN-PRIVATE is
performed.
Cleared by TXT.CMD.CLOSE-PRIVATE or by a system reset.
14:8 Reserved Reserved
15 TXT.LOCALITY1.O
PEN.STS This bit is set when the TXT.CMD.OPEN.LOCALITY1 command is
seen by the chipset. It is cleared on reset or when
TXT.CMD.CLOSE.LOCALITY1 is seen.
16 TXT.LOCALITY2.O
PEN.STS This bit is set when either the TXT.CMD.OPEN.LOCALITY2
command or the TXT.CMD.OPEN.PRIVATE is seen by the chipset.
It is cleared on reset, when either TXT.CMD.CLOSE.LOCALITY2 or
TXT.CMD.CLOSE.PRIVATE is seen, and by the GETSEC[SEXIT]
instruction.
63:17 Reserved Reserved
B.1.2 TXT.ESTS – Error Status
Description This is the error status register that contains status information associated
with various error conditions. The contents of this register are preserved
across soft resets.
Offset 008H
Pub Attribs
Priv Attribs
RO
RO
Bits
Field Name
Field Description
0 TXT_RESET.
STS This bit is set to ‘1’ to indicate that an event occurred which may
prevent the proper use of TXT (possibly including a TXT reset).
To maintain TXT integrity, while this bit is set a TXT measured
environment cannot be established; consequently Safer Mode
Extension (SMX) instructions GETSEC[ENTERACCS] and GETSEC
[SENTER] will fail.
This bit is sticky and will only be cleared on a power cycle.
7:1 Reserved Reserved
SMX Interaction with Platform
315168-013 95
B.1.3 TXT.ERRORCODE – Error Code
Description This register holds the Intel® TXT shutdown error code. A soft reset does not
clear the contents of this register; a hard reset/power cycle will clear the
contents. This was formerly labeled the TXT.CRASH register.
Offset 030H
Pub Attribs
Priv Attribs
RO
RW
Bits
Field Name
Field Description
3:0 Type2 /Module
Type 0 = BIOS ACM
1= SINIT
9:4 Type2 / Class Code 0-0x3f = Class code clusters several congeneric errors into a
group
14:10 Type2 /Major Error
Code 0-0x1f = Error Code within current Class Code.
15 Software Source 0 = Authenticated Code Module
1 = MLE
27:16 Type1 /Minor Error
Code This Field value depends on Class Code and / or Major Error Code.
29:28 Type1/Reserved This is implementation and source specific. Provides details on the
failure condition.
30 Processor/Software 0 = Error condition reported by processor (see Table )
1 = Error condition reported by software
31 Valid/Invalid 0 = Register content invalid, the rest of the register contents
should be ignored.
1 = Valid error
Note 1: Upon successful execution, SINIT will put 0xC0000001 in the register.
Note 2: The format of the Type field for errors reported by SINIT is defined in an
errors text file included with each SINIT AC module. This file also includes
the definition of the error codes produced by that version of SINIT. Error
definitions which are stable across SINIT AC Modules can be found in
Appendix I.
Table B-1. Type Field Encodings for Processor-Initiated Intel® TXT Shutdowns
Type Error condition Mnemonic
0 Legacy shutdown #LegacyShutdown
1-4 Reserved Reserved
5 Load memory type error in
Authenticated Code Execution Area #BadACMMType
6 Unrecognized AC module format #UnsupportedACM
7 Failure to authenticate #AuthenticateFail
SMX Interaction with Platform
96 315168-013
Type Error condition Mnemonic
8 Invalid AC module format #BadACMFormat
9 Unexpected snoop hit detected #UnexpectedHITM
10 Invalid event #InvalidEvent Note 2
11 Invalid MLE JOIN format #BadJOINFormat
12 Unrecoverable machine check
condition #UnrecovMCError
13 VMX abort error occurred #VMXAbort
14 Authenticated code execution area
corruption #ACMCorrupt
15 Invalid voltage/bus ratio #InvalidVIDBRatio
16 – 65535 Reserved Reserved
Note 1: The conditions under which most of these errors are generated can be found
in the pseudo code of the SMX instructions in Chapter 6, “Safer Mode
Extensions Reference”, of the Intel 64 and IA-32 Software Developer Manuals,
Volume 2B.
Note 2: #InvalidEvent can be generated by the following:
A CPU reset which is not caused by a TXT Reset
A non-virtualized INIT event
During RLP wakeup, bit 0 of the RLPs’ IA32_SMM_MONITOR_CTL MSR does
not match that of the ILP
An SENTER/SEXIT/WAKEUP event is received post-VMXON
A thread wakes from the wait-for-SIPI state while another thread in the same
CPU is executing an AC Module
B.1.4 TXT.CMD.RESET – System Reset Command
Description A write to this register causes a system reset. The processor performs this as
part of an Intel® TXT shutdown, after writing to the TXT.ERRORCODE register.
Offset 038H
Pub Attribs
Priv Attribs
-
WO
Bits Field Name Field Description
7:0
SMX Interaction with Platform
315168-013 97
B.1.5 TXT.CMD.CLOSE-PRIVATE – Close Private Space
Command
Description A write to this register causes the Intel® TXT-capable chipset private
configuration space to be locked. Locality 2 will also be closed. Once locked,
conventional memory read/write operations can no longer be used to access
these registers. The private configuration space can only be opened for the
MLE by successfully executing GETSEC[SENTER].
Offset 048H
Pub Attribs
Priv Attribs
WO (a serializing operation, such as a read of the register, is required
after the write to ensure that any future chipset operations see the
write)
Bits Field Name Field Description
7:0
B.1.6 TXT.VER.FSBIF – Front Side Bus Interface
Description This register identifies whether the chipset is debug or release fused.
On certain chipsets, a 4-byte read to this address will return either
0xFFFF_FFFF or 0x0000_0000. In these cases, the MLE should read an
alternate offset (TXT.VER.EMIF, 200H) to capture this information.
Offset 100H
Pub Attribs
Priv Attribs
RO
RO
Bits Field Name Field Description
30:0 Reserved Reserved
31 DEBUG.FUSE 0 = Chipset is debug fused
1 = Chipset is production fused
B.1.7 TXT.DIDVID – TXT Device ID
Description This register contains the vendor, device, and revision IDs for the memory
controller or chipset.
Offset 110H
Pub Attribs
Priv Attribs
RO
RO
Bits Field Name Field Description
15:0 VID Vendor ID: 8086 for Intel® components
31:16 DID Device ID: specific to the chipset/platform
SMX Interaction with Platform
98 315168-013
Bits Field Name Field Description
47:32 RID Revision ID: specific to the chipset/platform
63:48 ID-EXT Extended ID: specific to the chipset/platform
B.1.8 TXT.VER.QPIIF – Intel® QuickPath Interconnect
Interface
Description This register identifies whether the memory controller or chipset is debug or
release fused.
On certain chipsets, a 4-byte read to TXT.VER.FSBIF will return 0xFFFF_FFFF
or 0x0000_0000. In these cases, the MLE should read this register to
determine if the chipset is debug or release fused.
Offset 200H
Pub Attribs
Priv Attribs
RO
RO
Bits Field Name Field Description
30:0 Reserved Reserved
31 DEBUG.FUSE 0 = Chipset is debug fused
1 = Chipset is production fused
B.1.9 TXT.CMD.UNLOCK-MEM-CONFIG – Unlock Memory
Config Command
Description When this command is invoked, the chipset unlocks all memory configuration
registers.
Offset 218H
Pub Attribs
Priv Attribs
-
WO (a serializing operation, such as a read of the register, is required after the
write to ensure that any future chipset operations see the write)
Bits Field Name Field Description
7:0
SMX Interaction with Platform
315168-013 99
B.1.10 TXT.SINIT.BASE – SINIT Base Address
Description This register contains the physical base address of the memory region set
aside by the BIOS for loading an SINIT AC module. If BIOS has provided an
SINIT AC module, it will be located at this address. System software that
provides an SINIT AC module must store it to this location.
Offset 270H
Pub Attribs
Priv Attribs
RW
RW
Bits Field Name Field Description
31:0
B.1.11 TXT.SINIT.SIZE – SINIT Size
Description This register contains the size (in bytes) of the memory region set
aside by the BIOS for loading an SINIT AC module. This register is
initialized by the BIOS.
Offset 278H
Pub Attribs
Priv Attribs
RW
RW
Bits Field Name Field Description
31:0
B.1.12 TXT.MLE.JOIN – MLE Join Base Address
Description Holds a physical address pointer to the base of the join data structure used to
initialize RLPs in response to GETSEC[WAKEUP].
Offset 290H
Pub Attribs
Priv Attribs
RW
RW
Bits Field Name Field Description
31:0
SMX Interaction with Platform
100 315168-013
B.1.13 TXT.HEAP.BASE – TXT Heap Base Address
Description This register contains the physical base address of the Intel® TXT
Heap memory region. The BIOS initializes this register.
Offset 300H
Pub Attribs
Priv Attribs
RW
RW
Bits Field Name Field Description
31:0
B.1.14 TXT.HEAP.SIZE – TXT Heap Size
Description This register contains the size (in bytes) of the Intel® TXT Heap memory
region. The BIOS initializes this register.
Offset 308H
Pub Attribs
Priv Attribs
RW
RW
Bits Field Name Field Description
31:0
B.1.15 TXT.DPR – DMA Protected Range
Description This register defines the DMA Protected Range of memory in which the TXT
heap and SINIT region are located.
Offset 330H
Pub Attribs
Priv Attribs
RW
RW
Bits Field Name Field Description
0 Lock Bits 19:0 are locked down in this register when this bit is set.
3:1 Reserved Reserved
11:4 Size This is the size of memory, in MB, that will be protected from
DMA accesses. A value of 0x00 in this field means no additional
memory is protected.
The DPR range works independently of any other DMA
protections, such as VT-d, and is done post any VT-d translation
or TXT checks.
19:12 Reserved Reserved
31:20 Top Top address + 1 of DPR. This is the base of TSEG.
SMX Interaction with Platform
315168-013 101
B.1.16 TXT.CMD.OPEN.LOCALITY1 – Open Locality 1
Command
Description Writing to this register “opens” the TPM locality 1 address range, enabling
decoding by the chipset and thus access to the TPM.
This locality is not automatically opened after GETSEC[SENTER] and must be
opened explicitly.
This locality will not be closed by the TXT.CMD.CLOSE-PRIVATE command.
Offset 380H
Pub Attribs
Priv Attribs
-
WO
Bits Field Name Field Description
7:0
B.1.17 TXT.CMD.CLOSE.LOCALITY1 – Close Locality 1
Command
Description Writing to this register “closes” the TPM locality 1 address range, disabling
decoding by the chipset and thus access to the TPM.
This locality will not be closed by the TXT.CMD.CLOSE-PRIVATE command.
Offset 388H
Pub Attribs
Priv Attribs
-
WO
Bits Field Name Field Description
7:0
B.1.18 TXT.CMD.OPEN.LOCALITY2 – Open Locality 2
Command
Description Writing to this register “opens” the TPM locality 2 address range, enabling
decoding by the chipset and thus access to the TPM.
This locality is automatically opened after GETSEC[SENTER].
This locality will be closed by the TXT.CMD.CLOSE-PRIVATE command.
Offset 390H
Pub Attribs
Priv Attribs
-
WO
Bits
Field Name
Field Description
7:0
SMX Interaction with Platform
102 315168-013
B.1.19 TXT.CMD.CLOSE.LOCALITY2 – Close Locality 2
Command
Description Writing to this register “closes” the TPM locality 2 address range, disabling
decoding by the chipset and thus access to the TPM.
This locality will be closed by the TXT.CMD.CLOSE-PRIVATE command or by
the GETSEC[SEXIT] instruction.
Offset 398H
Pub Attribs
Priv Attribs
-
WO
Bits Field Name Field Description
7:0
B.1.20 TXT.PUBLIC.KEY – AC Module Public Key Hash
Description This register contains the hash of the public key used for the verification of AC
Modules. The size, hash algorithm, and value are specific to the memory
controller or chipset.
Offset 400H
Pub Attribs
Priv Attribs
RO
RO
Bits Field Name Field Description
255:0
B.1.21 TXT.CMD.SECRETS – Set Secrets Command
Description Writing to this register indicates to the chipset that there are secrets in
memory. The chipset tracks this fact with a sticky bit. If the platform reboots
with this sticky bit set the BIOS AC module (or BIOS on multiprocessor TXT
systems) will scrub memory. The chipset also uses this bit to detect invalid
sleep state transitions. If software tries to transition to S3, S4, or S5 while
secrets are in memory then the chipset will reset the system.
The MLE issues the TXT.CMD.SECRETS command prior to placing secrets in
memory for the first time.
Offset 8E0H
Pub Attribs
Priv Attribs
-
WO
Bits Field Name Field Description
7:0
SMX Interaction with Platform
315168-013 103
B.1.22 TXT.CMD.NO-SECRETS – Clear Secrets Command
Description Writing to this register indicates there are no secrets in memory.
The MLE will write to this register after removing all secrets from memory as
part of the TXT teardown process.
Offset 8E8H
Pub Attribs
Priv Attribs
-
WO
Bits Field Name Field Description
7:0
B.1.23 TXT.E2STS – Extended Error Status
Description This register is used to read the status associated with various errors that
might be detected. The contents of this register are preserved across soft
resets.
Offset 8F0H
Pub Attribs
Priv Attribs
RO
RW
Bits Field Name Field Description
0 Reserved Reserved
1 SECRETS.STS 0 = Chipset acknowledges that no secrets are in memory
1 = Chipset believes that secrets are in memory and will provide
reset protection
63:2 Reserved Reserved
B.2 TPM Platform Configuration Registers
The TPM contains Platform Configuration Registers (PCRs). The purpose of a PCR is to
contain measurements. From a TPM standpoint, the TPM does not care what entity
uses a PCR to store a measurement.
The TPM provides two types of PCRs: static and dynamic. Static PCRs only reset on
system reset; dynamic PCRs reset upon request. Static PCRs are written by the static
root of trust for measurement (SRTM). In the PC, the SRTM begins with the BIOS boot
block. The dynamic PCRs are written by the dynamic root of trust for measurement
(DRTM). In the PC, the DRTM is the process initiated by GETSEC[SENTER].
A PC TPM requires a minimum of 24 PCRs. The first 16 are designated the static Root
of Trust and the next eight are designated the dynamic Root of Trust. Intel® TXT uses
PCRs 17 and 18 within the dynamic Root of Trust to measure the MLE.
All PCRs for TPM 1.2 devices, static or dynamic, have the same size and same
updating mechanism. The size is 160 bits. This size allows the PCRs to contain a SHA1
SMX Interaction with Platform
104 315168-013
hash digest value. Storing a measurement value in the PCRs involves a TPM_Extend
operation, which is itself a hash operation.
PCRs for TPM 2.0 devices will be sized appropriately for the largest digest resulting
from algorithms they support, typically 256 bits or greater. This is elaborated in 1.8,
1.9, and 1.10 above.
B.3 Intel® Trusted Execution Technology
Device Space
There are several memory ranges within Intel® TXT address space provided to access
Intel® TXT related devices. The first range is 0xFED4_xxxx that is divided up into 16
pages. Each page in the FED4 range has specific access attributes. A page in this
region may be accessed by Intel® TXT cycles only, by Intel® TXT cycles and via
private space, or by Intel® TXT cycles, private and public space.
Table B-2. TPM Locality Address Mapping
Address Range TPM Locality
FED4 0xxxH Locality 0 (fully public)
FED4 1xxxH Locality 1 (trusted OS)
FED4 2xxxH Locality 2 (MLE access only)
FED4 3xxxH Locality 3 (AC modules access only)
FED4 4xxxH Locality 4 (Hardware or microcode access only)
All others Reserved
The first five pages of the 0xFED4_xxxx region are used for TPM access. Each page
represents a different locality to the TPM. Locality is an attribute used by the TPM to
define how it treats certain transactions. The address range used for commands sent
to the TPM defines locality. All Intel® TXT chipsets must support all localities. Locality
0 is considered public and accesses it is accepted by the chipset under all
circumstances. Accesses to locality 0 are sent to the ICH even if Intel® TXT is
disabled, there has been no SENTER, or private space is closed. Locality 4 is never
open, but may only be accessed with Intel® TXT cycles. There are Intel® TXT
commands that will open localities 1 through 3. Localities 2-3 require that both
LocalityX.OPEN and TXT.CMD.OPEN-PRIVATE be done before allowing accesses in that
range to be accepted. At reset, localities 1 through 3 are closed.
No status read check of the TPM is performed by the processor GETSEC [SENTER]
instruction ahead of the TPM.HASH write sequence. If the TPM is not in acquiesced
state at this time, then the PCRs 17-20 reset and hash registration to PCR 17 may not
succeed. To insure reliable system software functionality for TPM support, it is
recommended that the GETSEC [SENTER] instruction only be executed once the TPM
has acquiesced and ownership has been established in the context of the SENTER
initiating process.
Upon successful execution of GETSEC [SENTER] and relinquishment of control by
SINIT, the TPM’s private space and locality 2 should be left open. No locality should
be active.
§ §
Intel® TXT Heap Memory
315168-013 105
Appendix C Intel® TXT Heap Memory
Intel® TXT Heap memory is a region of physically contiguous memory that is set aside
by BIOS for the use of Intel® TXT hardware and software. The system software that
launches the measured environment passes data to both the SINIT AC module and
the MLE using Intel® TXT Heap memory. The system software is responsible for filling
in the table contents prior to executing the SENTER instruction. An incorrect format or
incorrect content of this table or tables described by this table will result in failure to
launch the protected environment.
Table C-1. Intel® Trusted Execution Technology Heap
Offset Length
(bytes) Name Description
0 8 BiosDataSize Size in bytes of the Intel® TXT
specific data passed from the
BIOS to system software for
the purposes of launching the
MLE. This size includes the
number of bytes for this field,
so this field cannot be less than
a value of 8. Note 1.
8 BiosDataSize - 8 BiosData BIOS specific data. The format
of this data is described below
in Table .
BiosDataSize 8 OsMleDataSize Size in bytes of the data passed
from the launching system
software to the MLE. This size
includes the number of bytes
for this field, so this field
cannot be less than a value of
8. Note 1.
BiosDataSize + 8 OsMleDataSize –
8 OsMleData System software -specific data.
Format of data in this field is
considered specific to the
system software vendor.
BiosDataSize +
OsMleDataSize 8 OsSinitDataSize Size in bytes of the data passed
from the launching system
software to the SINIT AC
module. This size includes the
number of bytes for this field,
so this field cannot be less than
a value of 8. Note 1.
BiosDataSize +
OsMLEDataSize +
8
OsSinitDataSize
– 8 OsSinitData System software data passed
to the SINIT AC module. The
format of this data is described
below in Table .
Intel® TXT Heap Memory
106 315168-013
Offset Length
(bytes) Name Description
BiosDataSize +
OsMleDataSize +
OsSinitDataSize
8 SinitMleDataSize Size in bytes of the data passed
from the launched SINIT AC
module to the MLE. This size
includes the number of bytes
for this field, so this field
cannot be less than a value of
8. Note 1.
BiosDataSize +
OsMleDataSize +
OsSinitDataSize +
8
SinitMleDataSize
– 8 SinitMleData SINIT data passed to the MLE.
The format of this data is
described below in Table .
Note 1: For proper data alignment on 64bit processor architectures this field must be a
multiple of 8 bytes. OsMleDataSize + OsSinitDataSize + SinitMleDataSize must be less than
or equal to TXT.HEAP.SIZE.
C.1 Extended Data Elements
Extended data elements are self-describing data structures that will be used for all
future extensions to TXT heap tables. The ExtDataElements[] field in each of the heap
tables is an array/list of individual elements, terminated by a HEAP_END_ELEMENT:
ExtDataElements[] ::= <HEAP_EXT_DATA_ELEMENT>* |
<HEAP_END_ELEMENT>
Each element consists of the following data structure:
typedef struct {
UINT32 Type; // one of HEAP_EXTDATA_TYPE_*
UINT32 Size;
UINT8 Data[Size – 8];
} HEAP_EXT_DATA_ELEMENT;
The extended data element structures in the following sub-sections (named
HEAP_*_ELEMENT) correspond to the contents of the Data field for the specific type of
element.
While not required, it is recommended that Size be a 4-byte multiple.
Entities that use the ExtDataElements[] fields must ignore element types that they do
not understand or care about. This allows forward and backward compatibility of
these fields.
C.1.1 HEAP_END_ELEMENT
#define HEAP_EXTDATA_TYPE_END 0
typedef struct {
UINT32 Type; // = 0
UINT32 Size; // = 8
} HEAP_END_ELEMENT;
Intel® TXT Heap Memory
315168-013 107
The HEAP_END_ELEMENT represents the terminating element of a given
ExtDataElements[] list. It contains no Data[] field.
C.1.2 HEAP_CUSTOM_ELEMENT
#define HEAP_EXTDATA_TYPE_CUSTOM 4
typedef struct {
UINT32 data1;
UINT16 data2;
UINT16 data3;
UINT16 data4;
UINT8 data5[6];
} UUID;
typedef struct {
UUID Uuid;
UINT8 Data[];
} HEAP_CUSTOM_ELEMENT;
The HEAP_CUSTOM_ELEMENT allows for platform suppliers to communicate supplier-
specific data through a standard location and mechanism. Software wishing to use
this data must understand its format.
Uuid is a UUID value that uniquely identifies the format of the Data field. It is
important to generate the UUID value using a process that will provide a statistically
unique value.
The platform supplier defines the Data field’s contents. The size of this data must be
included within the size of the HEAP_EXTDATA_ELEMENT::Size field.
C.2 BIOS Data Format
The format of the data passed from the BIOS to the system software for the purposes
of launching the measured environment is shown in the below table.
Table C-2. BIOS Data Table
Offset Length
(bytes) Name Description
0 4 Version Version number of the BiosData table. The
current value is 5 for TPM 1.2 family. TPM 2.0
requires version 6 (versions < 2 are not
supported). This value is incremented for any
change to the definition of this table. Future
versions will always be backwards compatible
with previous versions (new fields will be added
at the end).
Intel® TXT Heap Memory
108 315168-013
Offset Length
(bytes) Name Description
4 4 BiosSinitSize This field indicates the size of the SINIT AC
module provided by system BIOS. A value of 0
indicates the BIOS is not providing an SINIT AC
module for system software use. A non-0 value
indicates that the AC module will be at the
location specified by the TXT.SINIT.BASE
register and be of the specified size.
8 8 LcpPdBase Physical base address of the Platform Default
Launch Control Policy, LCP_POLICY_DATA
structure. Ignored if Platform Default Policy does
not require additional data or does not exist.
16 8 LcpPdSize Size of the Launch Control Policy Platform
Default Policy Data. Ignored if Platform Default
Policy does not require additional data or does
not exist.
24 4 NumLogProcs This is the total number of logical processors in
the system. The minimum value in this register
must be at least 1.
Versions >= 3 && < 5
28 4 SinitFlags BIOS-provided information for SINIT AC module
consumption. Bit definition will be dependent on
the chipset.
Versions >= 5 with updates in version 6
32 4 MleFlags BIOS-provided information for system software
and the MLE, about TXT capabilities of the BIOS.
See Table .
Versions >= 4
36 BiosDataSi
ze - 36 ExtDataElement
s[] Array/list of extended data element structures.
See below for element definitions.
Table C-3. MLE Flags Field Bit Definitions
Bit position Description
Versions >= 5
0 Support for TXT/VT-x/VT-d ACPI PPI specification (1)
Versions >= 6
2:1 00: legacy state/ platform undefined
01: client platform, client SINIT is required
10: server platform, server SINIT is required
11: Reserved/illegal, must be ignored
All versions
31:3 Reserved, must be zero
Intel® TXT Heap Memory
315168-013 109
C.2.1 HEAP_BIOS_SPEC_VER_ELEMENT
#define HEAP_EXTDATA_TYPE_BIOS_SPEC_VER 1
typedef struct {
UINT16 SpecVerMajor;
UINT16 SpecVerMinor;
UINT16 SpecVerRevision;
} HEAP_BIOS_SPEC_VER_ELEMENT;
The HEAP_BIOS_SPEC_VER_ELEMENT contains fields that indicate the version of the
TXT BIOS specification to which this platforms BIOS corresponds. This element type
is mainly useful for diagnostic tools.
C.2.2 HEAP_ACM_ELEMENT
#define HEAP_EXTDATA_TYPE_ACM 2
typedef struct {
UINT32 NumAcms;
UINT64 AcmAddrs[NumAcms]; // phys addr of ACM
} HEAP_ACM_ELEMENT;
The HEAP_ACM_ELEMENT allows BIOS to indicate the ACMs that it contains and their
locations in memory.
BIOSes that support this element type should report all ACMs that they carry; both
BIOS ACMs and SINIT ACMs.
Note: For SINIT ACM address in the AcmAddrs array shall point to the uncompressed
module image in the TXT heap memory (Same as in TXT.SINIT.BASE register – see
B.1.10).
Since the TXT architecture requires that BIOS provide at least one BIOS ACM,
NumAcms must always be greater than 0.
AcmAddrs[] is an array of physical addresses of each of the ACMs.
C.2.3 HEAP_STM_ELEMENT
#define HEAP_EXTDATA_TYPE_STM 3
typedef struct {
UINT8 Data[];
} HEAP_STM_ELEMENT;
The HEAP_STM_ELEMENT allows BIOS to indicate to the MLE STM related BIOS
properties. Its format is specified in STM specification.
The platform supplier defines the Data field’s contents. The size of this data must be
included within the size of the HEAP_EXTDATA_ELEMENT::Size field.
Intel® TXT Heap Memory
110 315168-013
C.3 OS to MLE Data Format
Each system software vendor may have a different format for this data, and any MLE
being launched by system software must understand the format of that software’s
handoff data.
C.4 OS to SINIT Data Format
Table defines the format of the data passed from the launching system software to
the SINIT AC module in the OsSinitData field.
Table C-4. OS to SINIT Data Table
Offset Length
(bytes) Name Description
0 4 Version Version number of the OsSinitData table.
Current values are 4 through 6 (versions <
4 are not supported) for TPM 1.2 family.
TPM 2.0 family version must be 7. This
value is incremented for any change to the
definition of this table. Future versions will
always be backwards compatible with
previous versions (new fields will be added
at the end).
4 4 Version <= 6,
Reserved
Version = 7
Flags
For future use
Bit 0: PCR Extend Policy Control
0 – Maximum Agility Policy
1 – Maximum Performance Policy
8 8 MLE PageTableBase Physical address of MLE page table (the MLE
page directory pointer table address)
16 8 MLE Size Size in bytes of the MLE image
24 8 MLE HeaderBase Linear address of MLE header (linear
address within the MLE page tables)
32 8 PMR Low Base Physical base address of the PMR Low
region (must be 2MB aligned). Can be set
to zero if not desired to be enabled by
SINIT. The MVMM must be loaded in one of
the DPR, PRM low, or the PMR high regions.
40 8 PMR Low Size Size of the PMR Low Region (must be 2MB
granular). Set to zero if not desired to be
enabled by SINIT.
48 8 PMR High Base Physical base address of the PMR High
region (must be 2MB aligned). Can be set
to zero if not desired to be enabled by
SINIT.
Intel® TXT Heap Memory
315168-013 111
Offset Length
(bytes) Name Description
56 8 PMR High Size Size of the PMR HIGH Region (must be 2MB
granular). Set to zero if not desired to be
enabled by SINIT.
64 8 LCP PO Base Physical base address of the Platform
Owner’s Launch Control Policy,
LCP_POLICY_DATA structure.
72 8 LCP PO Size Size of the Launch Control Policy Platform
Owner’s Policy Data.
80 4 Capabilities Bit vector of capabilities that SINIT is
requested to use. This must be a subset of
the ones SINIT supports. Note that for TPM
2.0 family, bits 5:4 must be zero, since D/A
mapping is required.
Version = 5
84 8 EFI RSDT Pointer Physical address of RSDT table when an EFI
boot was performed. This will be ignored if
SINIT finds the standard ACPI RSDT table.
Versions >= 6
84 8 EFI RSDP Pointer Physical address of RSDP when an EFI boot
was performed. This will be ignored if SINIT
finds the standard ACPI RSDP pointer.
92 OsSinitD
ataSize -
92
ExtDataElements[] Array/list of extended data element
structures. See below for element
definitions. Note that for TPM2, there must
be at least one
HEAP_EVENT_LOG_POINTER_ELEMENT2
structure with a HEAP_END_ELEMENT
terminating the list. For TPM1.2, the list
can be empty.
C.4.1 HEAP_TPM_EVENT_LOG_ELEMENT
#define HEAP_EXTDATA_TYPE_TPM_EVENT_LOG_PTR 5
typedef struct {
UINT64 EventLogPhysAddr;
} HEAP_TPM_EVENT_LOG_ELEMENT;
The HEAP_TPM_EVENT_LOG_ELEMENT is used for system software to inform SINIT of
the location of the TPM PCR event log that the system software has allocated. See
Appendix G for additional information about the log.
EventLogPhysAddr is the physical address of the event log structure. The event log
structure must be completely below 4GB.
C.4.2 HEAP_EVENT_LOG_POINTER_ELEMENT2
typedef struct {
UINT16 HashAlgID;
Intel® TXT Heap Memory
112 315168-013
UINT16 Reserved;
UINT64 PhysicalAddress;
UINT32 AllocatedEventContainerSize;
UINT32 FirstRecordOffset;
UINT32 NextrecordOffset;
} HEAP_EVENT_LOG_DESCR;
#define HEAP_EXTDATA_TYPE_EVENT_LOG_POINTER2 7
typedef struct {
UINT32 Count; // Number of EventLogDescr entries
HEAP_EVENT_LOG_DESCR EventLogDescr[count];
// Eventlog descriptor structure
} HEAP_EVENT_LOG_POINTER_ELEMENT2;
Count: count of elements in EventLogDescr array
EventLogDescr – array of HEAP_EVENT_LOG_DESCR structures each describing one of
the event logs.
SINIT in TPM2.0 mode will require HEAP_EVENT_LOG_POINTER_ELEMENT2 to be
present with at least one HEAP_EVENT_LOG_DESCR entry. This is justified by the
need to have event log for attestation since support of many of the SinitMleData table
fields is removed in TPM2.0 mode – see Table .
Pre-MLE SW may use HEAP_EVENT_LOG_POINTER_ ELEMENT2 to request what kind
of log it wants SINIT to create. It will be not an error to request event log for just one
of supported HashAlgIDs.
SINIT will verify that requested event log(s) correspond to HashAlgID for which
dynamic PCRs are actually extended. This requirement means that all requested
HashAlgID of event logs must belong to PCR_HashAlgIDList.
SINIT will abort with error if this condition is not met.
See Appendix G for definition of HEAP_EVENT_LOG_DESC and further explanation.
C.4.3 HEAP_EVENT_LOG_POINTER_ELEMENT2_1
#define HEAP_EXTDATA_TYPE_EVENT_LOG_POINTER2_1 8
typedef struct {
UINT64 PhysicalAddress;
UINT32 AllocatedEventContainerSize;
UINT32 FirstRecordOffset;
UINT32 NextrecordOffset;
} HEAP_EVENT_LOG_POINTER_ELEMENT2;
PhysicalAddress: Physical address of the event log base.
AllocatedEventContainerSize: Size of allocated event log memory.
FirstRecordOffset: Offset of the first record in event log.
Intel® TXT Heap Memory
315168-013 113
NextRecordOffset: Offset of the free memory beyond the end of last entered record.
SINIT in TPM2.0 mode will require HEAP_EVENT_LOG_POINTER_ELEMENT2_1 to be
present since event log is required for attestation and many of the SinitMleData table
fields carrying similar data are removed in TPM2.0 mode – see Table .
See Appendix G for further explanation.
C.5 SINIT to MLE Data Format
Table below defines the format of the SINIT data presented to the MLE.
Table C-5. SINIT to MLE Data Table
Offset Length
(bytes) Name Description
0 4 Version Version number of the SinitMleData table.
Current values are 6 through 9 (versions < 5 are
not supported). Supported value for TPM 2.0 is
9. This value is incremented for any change to
the definition of this table. Future versions will
always be backwards compatible with previous
versions (new fields will be added at the end).
Versions <= 8
4 20 BiosAcmID ID of the BIOS AC module in the system
24 4 EdxSenterFlags Value of EDX SENTER control flags
28 8 MsegValid MSEG MSR (Valid bit only)
36 20 SinitHash SHA1 hash of the SINIT AC module
56 20 MleHash SHA1 hash of the MLE
76 20 StmHash SHA1 hash of STM. This is only valid if MsegValid
= 1, else will contain zero
96 20 LcpPolicyHash SHA1 Hash of the LCP policy that was enforced;
if no hash is needed based on the LCP policy
control field this will contain zero
116 4 PolicyControl Taken from the LCP policy used
Versions >= 9
4 20 Reserved Must be zero
24 4 Reserved Must be zero
28 8 Reserved Must be zero
36 20 Reserved Must be zero
56 20 Reserved Reserved
76 20 Reserved Must be zero
96 20 Reserved Must be zero
116 4 Reserved Must be zero
Intel® TXT Heap Memory
114 315168-013
Offset Length
(bytes) Name Description
Versions >= 7
120 4 RlpWakeupAddr MONITOR physical address used for waking up
RLPs (write 32bit non-0 value)
124 4 Reserved Reserved for future use
128 4 NumberOfSinitM
drs Number of SINIT Memory Descriptor Records
132 4 SinitMdrTableOff
set Offset (in bytes, from start of this table) to
the start of an array of SINIT Memory
Descriptor Records as defined below. Each
record describes a memory region as
defined by the SINIT AC module (see Note:
Maximum version generated by SINIT in
TPM 1.2 mode must be 8. In TPM 2.0 mode
SINIT must generate version 9.
Table ).
136 4 SinitVtdDmarTab
leSize Length of the Intel® Virtualization Technology
(Intel® VT) for Directed I/O (Intel® VT-d) DMAR
table pointed to by the SinitVtdDmarTable field
140 4 SinitVtdDmarTab
leOffset Offset (in bytes, from start of this table) to the
start of the SINIT provided DMAR table dump for
the MLE.
Versions >= 8
144 4 ProcessorSCRTM
Status Bit 0 - 1 if PCR 0 measurement for this boot was
rooted in processor hardware. This is possible
only if all logical processors implement S-CRTM
and the platform is designed to take advantage
of that capability.
Bit 0 - 0 if PCR0 measurement for this boot was
rooted in BIOS.
Bits 31:1 – Reserved for future use
The ProcessorSCRTMStatus field is reflected in
PCR 17 measurement. See section 1.10.1
Versions >= 9
148 SinitMle
DataSize
- 148
ExtDataElement
s[] Array/list of extended data element structures.
See below for element definitions.
Note: Maximum version generated by SINIT in TPM 1.2 mode must be 8. In TPM 2.0
mode SINIT must generate version 9.
Intel® TXT Heap Memory
315168-013 115
Table C-6. SINIT Memory Descriptor Record
Offset Length
(bytes) Name Description
0 8 Address Physical address of the memory range described in
this record.
8 8 Length Length of the memory range.
16 1 Type Memory range type. Valid values:
0 Usable, good memory
1 SMRAM– Overlayed – deprecated
2 SMRAM– Non-Overlayed – deprecated
3 PCIe*- PCIe Extended Configuration Region
4 Persistent memory
5–255 Reserved
17 7 Reserved Reserved for future use
The array of Memory Descriptor Records (MDRs) is not necessarily ordered and some
MDRs may be of 0 length, in which case they should be ignored.
Memory of type 0 is usable for the MLE and any code or data that it may load. SINIT
will verify that the MLE and its page table are located in memory of this type.
Memory types 1 and 2 are deprecated in future versions of SINIT, as SMRAM regions
are not of use to the MLE.
Memory of type 3 is the PCI Express extended configuration region. The MLE may use
this to verify that the PCIE configuration specified in the ACPI tables is using the
appropriate address space.
Memory of type 4 is persistent, saving content in NV memory persisting over reset.
MLE shall not place secrets into this memory since it will be not scrubbed by BIOS
ACM.
C.5.1 HEAP_MADT_ELEMENT
#define HEAP_EXTDATA_TYPE_MADT 6
typedef struct {
UINT8 MadtData[];
} HEAP_MADT_ELEMENT;
The HEAP_MADT_ELEMENT contains a copy of the ACPI MADT table
MadtData contains a validated copy of the ACPI MADT table. Its size is specified in
the MADT header as well as the Size field of the element. The format of the MADT
table is described in the version of the Advanced Configuration and Power Interface
Specification implemented by the platform.
Intel® TXT Heap Memory
116 315168-013
C.5.2 HEAP_MCFG_ELEMENT
#define HEAP_EXTDATA_TYPE_MADT 9
typedef struct {
UINT8 McfgData[];
} HEAP_MCFG_ELEMENT;
The HEAP_MCFG_ELEMENT contains a copy of the ACPI MCFG table
McfgData contains a validated copy of the ACPI MCFG table. Its size is specified in the
MCFG header as well as the Size field of the element. The format of the MCFG table is
described in the version of the Advanced Configuration and Power Interface
Specification implemented by the platform.
§ §
LCP v2 Data Structures
315168-013 117
Appendix D LCP v2 Data Structures
D.1 LCP_POLICY
Both the Platform Owner and Platform Supplier policy structures are of the type
LCP_POLICY. These objects are stored in the TPM NV. The required fields for
LCP_POLICY are as follows:
#define LCP_POLHALG_SHA1 0
#define LCP_POLTYPE_LIST 0
#define LCP_POLTYPE_ANY 1
typedef struct {
UINT8 Sha1[20];
} LCP_HASH;
#define LCP_MAX_LISTS 8
typedef struct {
UINT16 Version;
UINT8 HashAlg; // one of LCP_POLHALG_*
UINT8 PolicyType; // one of LCP_POLTYPE_*
UINT8 SINITMinVersion;
UINT8 Reserved1;
UINT16 DataRevocationCounters[LCP_MAX_LISTS];
UINT32 PolicyControl;
UINT8 MaxSinitMinVer;
UINT8 MaxBiosacMinVer;
UINT16 Reserved2;
UINT32 Reserved3;
LCP_HASH PolicyHash;
} LCP_POLICY;
D.2 LCP_POLICY_DATA
For each policy of type LCP_POLTYPE_LIST, there must exist a block of data which the
SINIT policy engine will process. Where this data resides on the platform is platform
dependent, but it must provisioned into the Intel® TXT heap data structures (see C.2
and C.4) before executing the GETSEC[SENTER] instruction. While not required, it is
recommended that software place the LCP_POLICY_DATA on a 4-byte aligned
boundary to reduce access alignment penalties.
typedef struct {
char FileSignature[32];
UINT8 Reserved[3];
UINT8 NumLists;
LCP_POLICY_LIST PolicyLists[NumLists];
} LCP_POLICY_DATA
LCP v2 Data Structures
118 315168-013
FileSignature is the string “Intel(R) TXT LCP_POLICY_DATA\0\0\0\0”, where ‘\0’ is a
single byte whose value is 0x00. This field is intended for use by software that needs
to determine if a given file is an LCP_POLICY_DATA file.
The Reserved field must be set to all 0s.
The NumLists field must be less than or equal to LCP_MAX_LISTS.
Each list in PolicyLists may be either signed or unsigned.
D.3 LCP_POLICY_LIST
D.3.1 List Signatures
#define LCP_POLSALG_NONE 0
#define LCP_POLSALG_RSA_PKCS_15 1
typedef struct {
UINT16 RevocationCounter;
UINT16 PubkeySize;
UINT8 PubkeyValue[PubkeySize];
UINT8 SigBlock[PubkeySize];
} LCP_SIGNATURE, LCP_RSA_SIGNATURE;
The RevocationCounter field is a monotonically increasing value that can be used, in
conjunction with the corresponding index of the DataRevocationCounters field in
LCP_POLICY, to provide a method of revoking (or preventing rollback of) signed
policies.
Supported public key sizes are 1024, 2048 and 3072 bits. It is recommended that a
public key size of at least 2048 bits be used. Larger sizes may take longer to verify.
The exponent is fixed and must be 65537.
As specified for all policy data, both the PubkeyValue and SigBlock must be in little-
endian byte order. This may require tools that generate policies to reverse the byte
order of keys and signatures produced by tools that use the ASN.1/big-endian format.
D.3.2 LCP_POLICY_LIST Structure
typedef struct {
UINT16 Version;
UINT8 Reserved;
UINT8 SigAlgorithm; // one of SIGALG_*
UINT32 PolicyElementsSize;
LCP_POLICY_ELEMENT PolicyElements[];
optionally LCP_SIGNATURE Signature;
} LCP_POLICY_LIST;
The Reserved field must be set to 0.
LCP v2 Data Structures
315168-013 119
PolicyElementsSize specifies the size (in bytes) of all of the LCP_POLICY_ELEMENTS
structures in the object. It may be 0. A LCP_POLICY_LIST with no elements can be
used as a “placeholder” signed list that can be updated at runtime with the actual
signed data but without having to re-provision the LCP_POLICY in TPM NV.
If SigAlgorithm is SIGALG_RSA_PKCS_15 then the Signature field must be present
(else it must not). For a signed list, the RSA signature will be calculated over the
entire LCP_POLICY_LIST structure, including the Signature member, except for the
SigBlock field.
The version of the LCP_POLICY_LIST structure defined here is 1.0 (100H).
D.4 LCP_POLICY_ELEMENT
typedef struct {
UINT32 Size;
UINT32 Type;
UINT32 PolEltControl;
UINT8 Data[Size – 12];
} LCP_POLICY_ELEMENT;
The structures in the following sub-sections correspond to the contents of the Data
field for the specific type of element.
While not required, it is recommended that Size be a 4-byte multiple.
D.4.1 LCP_MLE_ELEMENT
#define LCP_POLELT_TYPE_MLE 0
typedef struct {
UINT8 SINITMinVersion;
UINT8 HashAlg; // one of LCP_POLHALG_*
UINT16 NumHashes;
LCP_HASH Hashes[NumHashes];
} LCP_MLE_ELEMENT;
The LCP_MLE_ELEMENT represents a list of the acceptable MLEs, as measured by their
hashes. An MLE will match the policy if its hash (as calculated when traversing its
pages in the MLE page table; not the value of PCR 18 after it has been extended)
matches any hash within the list.
SINIT will use the largest of the SINITMinVersion fields (the one in LCP_POLICY and
the one in the LCP_MLE_ELEMENT which contains the matching MLE hash) to
determine the minimum allowable version of SINIT.
HashAlg specifies the hash algorithm to use when measuring the MLE and also of the
values in Hashes[].
If NumHashes is 0 then this element will evaluate to false for all MLEs.
LCP v2 Data Structures
120 315168-013
D.4.2 LCP_PCONF_ELEMENT
#define LCP_POLELT_TYPE_PCONF 1
typedef struct {
UINT16 NumPCRInfos;
TPM_PCR_INFO_SHORT PCRInfos[NumPCRInfos];
} LCP_PCONF_ELEMENT;
The LCP_PCONF_ELEMENT represents a list of acceptable PCR values on the platform
at the time of launch. The platform will satisfy the policy if the PCR values at the time
of launch match any of the PCRInfos within the list. When processing the platform
configuration list the LCP engine reads the appropriate PCR’s as defined by the first
TPM_PCR_INFO_SHORT value in the list and concatenates them and cryptographically
hashes them together. The result is compared to the hash value in the
TPM_PCR_INFO_SHORT. If there is no match this process is repeated for each and
every member of the list. As soon as a match is found, the LCP engine proceeds.
Additionally, it is recommended, although not necessary, that all
TPM_PCR_INFO_SHORT structures in the platform configuration list test the same set
of PCR values.
If NumPCRInfos is 0 then this element will evaluate to false for all platform
configurations.
The various TPM_* structures have been copied below to facilitate understanding of
the list structure.
typedef struct tdTPM_PCR_INFO_SHORT{
TPM_PCR_SELECTION pcrSelection;
TPM_LOCALITY_SELECTION localityAtRelease;
TPM_COMPOSITE_HASH digestAtRelease;
} TPM_PCR_INFO_SHORT;
typedef struct tdTPM_PCR_SELECTION {
UINT16 sizeOfSelect;
[size_is(sizeOfSelect)] BYTE pcrSelect[];
} TPM_PCR_SELECTION;
#define TPM_LOCALITY_SELECTION BYTE // each bit is the
// corresponding locality
typedef struct tdTPM_DIGEST{
BYTE digest[digestSize];
} TPM_DIGEST;
typedef TPM_DIGEST TPM_COMPOSITE_HASH; // hash of
// TPM_PCR_COMPOSITE
// object
D.4.3 LCP_SBIOS_ELEMENT
LCP v2 Data Structures
315168-013 121
#define LCP_POLELT_TYPE_SBIOS 2
typedef struct {
UINT8 HashAlg; // one of LCP_POLHALG_*
UINT8 Reserved1[3];
LCP_HASH FallbackHash;
UINT16 Reserved2;
UINT16 NumHashes;
LCP_HASH Hashes[NumHashes];
} LCP_SBIOS_ELEMENT;
The LCP_SBIOS_ELEMENT represents a list of the acceptable startup BIOSes (that
portion of BIOS measured by the BIOS ACM), as measured by their hashes.
HashAlg specifies the hash algorithm to use when measuring the startup BIOS and
also of the values in Hashes[] and FallbackHash.
The FallbackHash field represents a version of the startup BIOS that is always
acceptable, regardless of the contents of the Hashes[] field or lack thereof. The
expected use is for OEMs that do not wish to sign their BIOS (i.e. not sign the
LCP_POLICY_LIST for the Supplier Policy) and thus will use auto-promotion for their
startup BIOS policy. In that case, they would specify NumHashes as 0 and set a valid
FallbackHash to correspond to their fallback or recovery BIOS. This hash would be
valid regardless of the current value of the auto-promotion hash. If not used (i.e. the
OEM is providing the hash in the Hashes[] field) then it can be set to anything.
If NumHashes is not 0 then the current startup BIOS must be specified by one of the
hashes in Hashes[] or by the FallbackHash otherwise the BIOS ACM will fail to boot
that processor. If NumHashes is 0 then the BIOS ACM will use the auto-promotion
method for startup BIOS policy.
The Reserved1 and Reserved2 fields must be set to 0.
D.4.4 LCP_CUSTOM_ELEMENT
#define LCP_POLELT_TYPE_CUSTOM 3
typedef struct {
UINT32 data1;
UINT16 data2;
UINT16 data3;
UINT16 data4;
UINT8 data5[6];
} UUID;
typedef struct {
UUID Uuid;
UINT8 Data[];
} LCP_CUSTOM_ELEMENT;
The LCP_CUSTOM_ELEMENT allows for users, ISVs, IT, etc. to define policy-related
data which can then be carried as part of a policy and interpreted by user/ISV/IT
software. Because the data is contained within a policy, its integrity will be verified by
SINIT as part of policy processing.
LCP v2 Data Structures
122 315168-013
Uuid is a UUID value that uniquely identifies the format of the Data field. This field
will be used by all custom software that may have its own policy data. It is thus
important to generate the UUID value using a process that will provide a statistically
unique value.
The Data field’s contents are defined by the entity that “owns” the UUID of the
element. The size of this data must be included within the size of the
LCP_POLICY_ELEMENT::Size field.
D.5 Structure Endianness
Endianness deals with the sequencing order of stored bytes. There are two common
sequencing orders: Little Endian (format used by Intel) and Big Endian. All structures
and data are in Little Endian format, even LCP_POLICY.
TPM_PCR_INFO_SHORT structure in PCONF TPM1.2 definition is a standard TPM 1.2
structure; it should be in Big Endian format, while the rest of PCONF structure is in
Little Endian format.
§ §
LCP Data Structures, v3
315168-013 123
Appendix E LCP Data Structures, v3
E.1 NV Index LCP Policy
HashAlg is now 16 bits, and uses the encoding defined by the TPM2.0 specification as
repeated here for reference:
#define TPM_ALG_SHA1 0x0004
#define TPM_ALG_SHA256 0x000B
#define TPM_ALG_SHA384 0x000C
#define TPM_ALG_SHA512 0x000D
#define TPM_ALG_NULL 0x0010
#define TPM_ALG_SM3_256 0x0012
Additionally, LcpSignAlgMask uses the following encodings (also defined by the
TPM2.0 specification) for signing algorithms:
#define TPM_ALG_RSA 0x0001
#define TPM_ALG_SM2 0x001B
#define TPM_ALG_ECC 0x0023
As described in 3.3.2, two new 16-bit fields (LcpHashAlgMask and AuxHashAlgMask)
and one new 32-bit field (LcpSignAlgMask) are added to the LCP_POLICY structure for
Platform Owner and Platform Supplier.
LcpHashAlgMask identifies the Platform Owner’s / Supplier’s selection of HashAlgIDs
permitted during LCP policy evaluation.
AuxHashAlgMask will have a single bit set identifying the Platform Supplier’s selection
of HashAlgID to be used by the Startup ACM to create the auto-promotion digest.
These bit fields will use the following HashAlgID mask definition:
typedef struct {
UINT16 TPM_ALG_SHA1:1; // BIT0
UINT16 Reserved:2; // BITS 1-2
UINT16 TPM_ALG_SHA256:1; // BIT3
UINT16 Reserved:1; // BIT4
UINT16 TPM_ALG_SM3_256:1; // BIT5
UINT16 TPM_ALG_SHA384:1; // BIT6
UINT16 TPM_ALG_SHA512:1; // BIT7
UINT16 Reserved:8;
} LCP_APPROVED_ALG;
Some of these algorithms are not included in the current TPM2 specification, but are
defined here as placeholders for future use.
LcpSignAlgMask identifies the Platform Owner’s selection of signature algorithms
permitted during LCP policy evaluation. A fully specified signature algorithm definition
is comprised of the signature algorithm and its public key size; the internally used
hash algorithm; and for ECDSA, the curve used.
LCP Data Structures, v3
124 315168-013
typedef struct {
UINT32 TPM_ALG_RSASSA/1024/SHA1:1 // BIT0: Deprecated
UINT32 TPM_ALG_RSASSA/1024/SHA256:1 // BIT1: Deprecated
UINT32 TPM_ALG_RSASSA/2048/SHA1:1 // BIT2: Legacy
UINT32 TPM_ALG_RSASSA/2048/SHA256:1 // BIT3: Suite C
UINT32 Reserved:8 // BITS 4-11
UINT32 TPM_ALG_ECDSA/P-256:1 // BIT12: Suite B
UINT32 TPM_ALG_ECDSA/P-384:1 // BIT13: Suite B
UINT32 Reserved:2 //
UINT32 TPM_ALG_SM2/SM2_CURVE:1 // BIT16: Chinese
requirement
UINT32 Reserved2:15
} LCP_APPROVED_SIGNATURE_ALG;
The PolicyControl DWORD of LCP Policy structure has new bit definitions added to
improve usability of LCP and to control AUX index
More information about the purpose and use of these masks and new policy control
bits can be found in 3.3.2 With the addition of the three above fields, the new TPM NV
LCP Policy structure has the following format:
typedef struct {
UINT16 Version; // 0x0300 == Version 3.0
UINT16 HashAlg; // one of TPM_ALG_*
UINT8 PolicyType; // one of LCP_POLTYPE_*
UINT8 SINITMinVersion;
UINT16 DataRevocationCounters[LCP_MAX_LISTS];
UINT32 PolicyControl;
UINT8 MaxSinitMinVer; // Defined for PO only.
// Reserved for PS
UINT8 MaxBiosacMinVer;// Defined for PO only.
// Reserved for PS
UINT16 LcpHashAlgMask // Mask of approved algorithms
// for LCP evaluation
// (LCP_APPROVED_ALG)
UINT32 LcpSignAlgMask // Mask of approved signature
// algorithms for LCP evaluation
// (LCP_APPROVED_SIGNATURE_ALG)
UINT16 AuxHashAlgMask // Approved algorithm for
// auto-promotion hash
// (LCP_APPROVED_ALG).
UINT16 Reserved2;
LCP_HASH2 PolicyHash;
} LCP_POLICY2;
Note: Minor version 0 is initial version of the structure. Minor version 1 corresponds
to usage of updated PolicyControl structure containing newly defined
Ignote_PS_EltType bits 20:16. Both versions 3.0 and 3.1 must be supported.
The salient changes to this structure, and the PolicyControl DWORD defined below
from V3 are described in 3.3.2.
typedef struct {
UINT32 reserved:1;
LCP Data Structures, v3
315168-013 125
UINT32 NPW_OK:1; // NPW OK
UINT32 OsSinitData_Capabilities:1;
// OsSinitData.Capabilities
// will be extended to PCR17
union {
UINT32 PO_is_Required:1; // PS index only
UINT32 PS_Pconf_Enforced:1; // PO index only
}
UINT32 reserved2:12;
// Bits 20:16 are defined in LCP_POLICY2 version 3.1 only and
// are reserved in version 3.0
UINT32 Ignore_PS_MLE:1 // Bit16. PO index only
UINT32 Ignore_PS_PCONF:1 // Bit17. PO index only
UINT32 Reserved:2 // Bit19:18
UINT32 Ignore_PS_STM:1 // Bit20. PO index only
UINT32 Reserved:10 // Bit30:21
UINT32 AUXDeletionControl:1 // PS index only
} PolicyControl;
E.2 LCP Policy Data
An LCP Policy Data file’s structure has only one change for V3 from V2 [D.2]: mixing
of LCP_POLICY_LIST and LCP_POLICY_LIST2 lists is allowed.
E.2.1 LCP_LIST
typedef union {
LCP_POLICY_LIST TPM12PolicyList; // See Appendix D
LCP_POLICY_LIST2 TPM20PolicyList;
} LCP_LIST;
E.2.2 LCP_POLICY_DATA2
typedef struct {
char FileSignature[32];
UINT8 Reserved[3];
UINT8 NumLists;
LCP_LIST PolicyLists [NumLists];
} LCP_POLICY_DATA2;
E.3 LCP_POLICY_LIST2
The V2 LCP Policy list structure has been modified to V3 to accommodate algorithm
agility.
The V3 LCP list structure has the following format:
typedef struct {
UINT16 Version;
UINT16 SigAlgorithm; // one of TPM_ALG_* above
LCP Data Structures, v3
126 315168-013
UINT32 PolicyElementsSize;
LCP_POLICY_ELEMENT PolicyElements[];
#If (SigAlgorithm != TPM_ALG_NULL)
LCP_SIGNATURE2 Signature;
#endif
} LCP_POLICY_LIST2;
The changes from LCP_POLICY_LIST to LCP_POLICY_LIST2 structures are:
• Version is promoted to 2.0 or 2.1
Version 2.0 is initial version of LCP_POLICY_LIST2 structure
Version 2.1 is version using new LCP_POLICY_ELEMENT structures – with bit 0
reserved.
Both versions must be supported.
• SigAlgorithm field uses TPM2.0 compatible numeric values
• SigAlgorithm field is expanded to UINT16 and reserved field is removed
• Signature field has different format specified in E.3.2.
• Mixture of legacy and new LCP_POLICY_ELEMENT structures is allowed.
Notes:
• It is presumed and required that legacy LCP_POLICY_LIST structures will contain
only legacy LCP_POLICY_ELEMENT definitions
• By allowing a mix of legacy and new LCP_POLICY_ELEMENT structures in the
same list, each Authority is able to create one single list covering both TPM1.2 and
TPM2.0 LCP data
• Since mixed lists of elements are permitted in the version 3.x, use of legacy
LCP_POLICY_LIST structures is not required and is discouraged.
E.3.1 List Signatures
V3 LCP lists may use the following signature algorithms:
• RSASSA (#define TPM_ALG_RSASSA 0x0014)
• ECDSA (#define TPM_ALG_ECDSA 0x0018)
• SM2 (#define TPM_ALG_SM2 0x001B)
For v2 LCP lists, the NULL algorithm is typed as 0x0010.
E.3.1.1 RSASSA
Support will be limited to version RSASSA-PKCS1-v1_5 as defined in [NIST, FIPS
PUB 186-3, Federal Information Processing Standards Publication, Digital
Signature Standard (DSS), June 2009 ] with reference to [RSA Labs, PKCS #1
v2.1: RSA Cryptography Standard, June 14, 2002] and [RSA Labs, PKCS #1
v2.1 Errata,Revision: 2.0, December, 2005]
Signatures will be supported only with the following approved hash functions:
TPM_ALG_SHA1; TPM_ALG_SHA256 TPM_ALG_SHA384, TPM_ALG_SHA512.
LCP Data Structures, v3
315168-013 127
Supported key sizes will remain 1024, 2048 and 3072 bits; use of 1024 bit keys is
deprecated.
E.3.1.2 ECDSA
Implementation will follow the definition in [NIST, FIPS PUB 186-3, Federal
Information Processing Standards Publication, Digital Signature Standard (DSS), June
2009]
Support will imply that:
• Domain parameters are embedded and are not passed to a module as part of
image signature.
• Only prime finite fields and only specific curves will be supported
• For each of the key sizes there will be a single supported curve selected from
curves recommended by [NIST, FIPS PUB 186-3, Federal Information Processing
Standards Publication, Digital Signature Standard (DSS), June 2009], Appendix D.
See also [Certicom Research, Standards For Efficient Cryptography, Sec2:
Recommended Elliptic Curve Domain Parameters, September 2000]
• The following is the set of supported curves: P-256; P-384.
• The following hash algorithms will be associated with the above curves:
SHA256 will be used with P-256;
SHA384 will be used with P-384;
E.3.1.3 SM2
Implementation will follow the definition in [State Cryptography Administration, Public
Key Cryptographic Algorithm SM2 Based on Elliptic Curves, December 2010]
Since SM2 is a variation of ECC, it will share format of signature structure used for
ECCDSA with the following differences:
• It will use the SM3 hash algorithm
• It will default to Fp-256 curve as specified in [Recommended Curve Parameters for
Public Key Cryptographic Algorithm SM2 Based on Elliptic Curves]
E.3.2 Signature Format
The LCP_SIGNATURE structure layout above is unchanged, but was aliased to
LCP_RSA_SIGNATURE for clarity in its use in the new structure:
typedef struct {
UINT16 RevocationCounter;
UINT16 PubkeySize;
UINT32 Reserved; // For future expansion
UINT8 Qx[PubkeySize] // x coordinate Public key
UINT8 Qy[PubkeySize] // y coordinate Public key
UINT8 r[PubkeySize] // r component of Signature
UINT8 s[PubkeySize] // s component of Signature
} LCP_ECC_SIGNATURE;
LCP Data Structures, v3
128 315168-013
typedef union {
LCP_RSA_SIGNATURE RsaSignature;
LCP_ECC_SIGNATURE EccSignature;
} LCP_SIGNATURE2;
E.4 New Policy Elements
The LCP structures used for TPM 1.2 are not articulate enough to support the
algorithmic agility possible with TPM 2.0 devices. New elements based on the existing
elements have been defined to add such support. The changes have been designed to
allow lists comprised of both TPM 1.2 and TPM 2.0 elements. This minimizes space
requirements for NV RAM, and simplifies processing logic. Where possible, the new
element structures use constants as defined in the TCG 2.0 specification.
The overall policy element structure remains unchanged – see D.4
E.4.1 LCP_Hash
typedef union {
UINT8 sha1[SHA1_DIGEST_SIZE];
UINT8 sha256[SHA256_DIGEST_SIZE];
UINT8 sha384[SHA384_DIGEST_SIZE];
UINT8 sha512[SHA512_DIGEST_SIZE];
UINT8 sm3[SM3_256_DIGEST_SIZE];
} LCP_HASH2;
This structure was elaborated to support additional algorithms beyond SHA1.
E.4.2 MLE Element
#define LCP_POLELT_TYPE_MLE2 0x10
typedef struct {
UINT8 SINITMinVersion;
UINT8 Reserved
UINT16 HashAlg; // one of TPM_ALG_*
UINT16 NumHashes;
LCP_HASH2 Hashes[NumHashes];
} LCP_MLE_ELEMENT2;
E.4.3 SBIOS Element
#define LCP_POLELT_TYPE_SBIOS2 0x12
typedef struct {
UINT16 HashAlg; // one of TPM_ALG_*
UINT8 Reserved1[2];
LCP_HASH2 FallbackHash;
UINT16 Reserved2;
LCP Data Structures, v3
315168-013 129
UINT16 NumHashes;
LCP_HASH2 Hashes[NumHashes];
} LCP_SBIOS_ELEMENT2;
E.4.4 STM Element
#define LCP_POLELT_TYPE_STM2 0x14
typedef struct {
UINT16 HashAlg; // one of TPM_ALG_*
UINT16 NumHashes;
LCP_HASH2 Hashes[NumHashes];
} LCP_STM_ELEMENT2;
E.4.5 PCONF Element
The PCONF Element structure is now designed so it can be created using the
TPM2_Quote command and evaluated using the TPM2_PolicyPCR command.
The TPM2_Quote command returns the following structure:
typedef struct {
UINT16 size
TPMS_ATTEST attestationData;
} TPM2B_ATTEST;
Where TPMS_ATTEST has the following form:
typedef struct {
. . . . . . . . ;
TPMU_ATTEST attested; // == TPMS_QUOTE_INFO
} TPMS_ATTEST;
TPMU_ATTEST is a union, where the relevant member within is the
TPMS_QUOTE_INFO structure:
typedef struct {
TPML_PCR_SELECTION pcrSelect;
TPM2B_DIGEST pcrDigest
} TPMS_QUOTE_INFO;
pcrSelect is a TPML_PCR_SELECTION structure denoting the PCRs being quoted, and
the pcrDigest is a TPM2B_DIGEST structure wherein the digest is a composite digest
of the PCRs being quoted.
typedef struct {
UINT16 hash; // One of TPM_ALG_* algorithm IDs
UINT8 sizeofSelect;
UINT8 pcrSelect[sizeofSelect];
} TPMS_PCR_SELECTION;
typedef struct {
UINT32 count; // must be 1 for use in PCONF
LCP Data Structures, v3
130 315168-013
TPMS_PCR_SELECTION pcrSelections;
} TPML_PCR_SELECTION;
typedef struct {
UINT16 size;
UINT8 buffer[size];
} TPM2B_DIGEST;
The new PCONF_ELEMENT structure is then defined as:
#define LCP_POLELT_TYPE_PCONF2 0x11
typedef struct {
UINT16 HashAlg; // one of TPM_ALG_*
UINT16 NumPCRInfos;
TPMS_QUOTE_INFO PCRInfos[NumPCRInfos];
} LCP_PCONF_ELEMENT2;
Since TPMS_QUOTE_INFO is a standard TPM 2.0 structure its fields where applicable
shall be inserted in big endian format. Rest of the LCP_PCONF_ELEMENT2 structure is
in little endian format.
TPML_PCR_SELECTION structure which is sub-component of new
LCP_PCONF_ELEMENT2 definition contains “count” field allowing making multiple PCR
selections using different HashAlgIDs.
“count” field is kept in PCONF element definition to use as much of unmodified
TPM2.0 structures as possible but for the purpose of TXT count will be enforced to be
“1”. SINIT code will validate “count == 1” condition and will abort if it is not met.
E.5 NV AUX Index Data Structure
The AUX Index data structure requires some modification to accommodate
algorithmically agile digests. The modified structure definition follows:
typedef struct {
UINT8 MinVer;
UINT8 Flags;
} ACM_AUX_REVOCATION;
typedef struct {
ACM_AUX_REVOCATION SinitRevocation;
ACM_AUX_REVOCATION Reserved[count]; // count is 1 for TPM 1.2
// and 3 for TPM 2.0
} Revocation Area;
Table E-1. AUX Data Structure
BIOS AC
registration
data
AUX Data
Version AuxHashAlgId Internal TXT
digest area Revocation area
LCP Data Structures, v3
315168-013 131
Table E-1 diagrammatically illustrates the content of AUX index
BIOS AC registration data - contains value uniquely identifying BIOS ACM installed
in the system. This value is extended into PCR 17 by SINIT module since BIOS ACM is
in TXT TCB
AUX Data Version – identifies version of the structure. In TPM 1.2 it can vary
between client and server platforms and between different platform generations. In
TPM 2.0 it is established to be 2.0
AuxHashAlgID - new field for TPM 2.0. It uses TPM 2.0-compatible numeric values
and indicates the HashAlgID of the digests stored in AUX index.
Internal TXT digest area - for server platforms this is AutoPromotion digest, for
clients saved digests are used for housekeeping purposes.
Revocation area – storage containing minimal revisions of modules allowed to run.
For TPM 1.2 area contains two revocation slots. For TPM 2.0 its size increased to 4
slots
E.6 Structure Endianness
Endianness deals with the sequencing order of stored bytes. There are two common
sequencing orders: Little Endian (format used by Intel) and Big Endian. All structures
and data are in Little Endian format, even LCP_POLICY, except situation below:
TPMS_QUOTE_INFO structure in PCONF TPM 2.0 definition is a standard TPM 2.0
structure; it should be in Big Endian format, while the rest of PCONF structure is in
Little Endian format.
§ §
Platform State upon SINIT Exit and Return to MLE
132 315168-013
Appendix F Platform State upon
SINIT Exit and Return to MLE
The following table describes the processor state of the ILP after returning to the MLE
from GETSEC[SENTER] and the RLPs after waking from SENTER. This will be the state
seen by the MLE.
Table E-2. Platform State upon SINIT Exit and Return to MLE
Resource ILP on MLE re-entry point RLP on MLE re-entry
point
CPU
CR0 PG0, AM0,WP0; others
unchanged PG0, CD0, NW0,
AM0, WP0; PE1, NE1
XCR0 AVX State1, SSE State;
others unchanged Unchanged
CR4 0x00004000 0x00004000
EFLAGS 0x000000XX (XX =
Undefined) 0x000000XX (XX =
Undefined)
EIP [MLEHeader.EntryPoint] [TXT.MLE.JOIN + 12]
ESP Undefined Undefined
EBP Undefined Undefined
ECX Ptr to MLE page table Note 1 Undefined
EBX [MLEHeader.EntryPoint] Undefined
EAX, EDI, ESI Undefined Undefined
CS Sel=[SINIT.SegSel], base=0,
limit=0xFFFFF, G=1, D=1,
AR=0x9B
Sel=[TXT.MLE.JOIN + 8],
base=0, limit=0xFFFFF,
G=1, D=1, AR=0x9B
DS, ES, SS Undefined Sel=[TXT.MLE.JOIN + 8] +
8, base=0, limit=FFFFFH,
G=1, D=1, AR=0x93
GDTR Base=[SINIT.GDTBase],
Limit=[SINIT.GDTLimit] Base=[TXT.MLE.JOIN + 4],
Limit=[TXT.MLE.JOIN]
DR7 0x00000400 0x00000400
MMX/XMM registers Values at the SENTER
unchanged. Values at the SENTER
unchanged.
YMM / ZMM Undefined Undefined
IA32_DEBUGCTL MSR 0 0
IA32_EFER MSR 0 0
IA32_MISC_ENABLE MSR IA32_MISC_ENABLE &
0xFFF37CEA Notes 2, 3 IA32_MISC_ENABLE &
0xFEE324A8 Note 3
Platform State upon SINIT Exit and Return to MLE
315168-013 133
Resource ILP on MLE re-entry point RLP on MLE re-entry
point
Performance counters and
counter control registers
0
0
IA32_APIC_BASE MSR
35:12 cleared to 0xFEE00 35:12 cleared to 0xFEE00,
bit 8 (BSP) cleared to 0
LTCS
Private Space
Open
TXT.ERRORCODE
0xC0000001
TPM
Locality
No locality active. Locality 2 open,
PCI
PCI Index/Data ports
0xCF8-0xCFF Undefined
Note 1: If bit 2 of the Capabilities field in SINIT’s Chipset AC Module Information Table is
set then ECX will contain the pointer to the MLE’s page table. If clear, the contents of
ECX are undefined
Note 2: Bit 3 (thermal monitor enable) will be set to 1 if it was previously clear.
Note 3: Bit 18 (MONITOR/MWAIT enable) will be set to 1 if it was previously clear, when bit
1 of OsSinitData.Capabilities (use of MONITOR for RLP wakeup) is set.
Note 4: GDTR on entry to MLE retains values established by SINIT module and therefore
incorrect and unusable for MLE. MLE developers should establish own GDT immediately
The TPM will not have any locality active following SENTER.
§ §
TPM Event Log
134 315168-013
Appendix G TPM Event Log
The TPM Event Log is a data structure that describes the data whose hashes are
extended to the TPM PCR indices. This allows remote attestation verifiers to
reconstruct the PCR values in order to make trust decisions about their components.
This event log is equivalent to the one generated by BIOS (see TCG PC Client Specific
Implementation Specification for Conventional BIOS), but is for the use of system
software and SINIT.
G.1 TPM 1.2 Event Log
The log is allocated by system software and the physical address of the container (see
Table ) provided to SINIT in a HEAP_TPM_EVENT_LOG_ELEMENT in the
OsSinitData.ExtDataElements[] field. An SINIT ACM that supports details/authorities
PCR mappings (see - 1.10.2 and Table 2-2) will support this element type. ACMs that
do not support this element type will ignore it. If system software does not provide
this element to an SINIT ACM that supports it, SINIT will simply not populate a log.
Table E-3. Event Log Container Format
Field Offset Size
(bytes) Description
Signature 0 20 “TXT Event Container\0”
Reserved 20 12 Must be 0
ContainerVerMajor 32 1
Major version number of this structure. The
current value is 1. Different major versions
indicate incompatible structure format and/or
behaviors.
ContainerVerMinor 33 1 Minor version number of this structure. The
current value is 0. Different minor versions
indicate compatible structure format (i.e. new
fields added at the end) and/or behaviors.
PCREventVerMajor 34 1 Major version number of the PCREvent
structure. The current value is 1. Different
major versions indicate incompatible
structure format and/or behaviors.
PCREventVerMinor 35 1 Minor version number of the PCREvent
structure. The current value is 0. Different
minor versions indicate compatible structure
format (i.e. new fields added at the end)
and/or behaviors.
ContainerSize 36 4 Allocated size of container, including
PCREvents[]
PCREventsOffset 40 4 Offset (in bytes, from start of this table) to
the start of PCREvents[] array.
TPM Event Log
315168-013 135
Field Offset Size
(bytes) Description
NextEventOffset 44 4 Offset (in bytes, from start of this table) of
the next byte after the last event in
PCREvents[]. I.e. the offset of the next
available event slot.
PCREvents[] PCREven
tsOffset Container
Size -
PCREvent
sOffset
Array of PCREvent structures (see below)
G.1.1 PCR Events
typedef struct {
UINT32 PCRIndex;
UINT32 Type;
UINT8 Digest[20];
UINT32 Size;
UINT8 Data[Size];
} TPM12_PCREvent;
PCREvents describe the data whose SHA1 hash (Digest[]) was extended into the
specified PCR. Depending on the event Type, the Data[] may be the entire hashed
object or just a description (e.g. version). PCREvents are in the order in which the
PCR extends were performed. Because Data[] is not a fixed size for each event, the
events must be traversed in order.
PCRIndex is the index of the TPM PCR into which the hash of the data was extended.
Type indicates the event type, as described in Table .
Digest is the SHA1 hash that was extended in this event.
Size is the size of the Data.
Data is either the actual data that digested to Digest, or a description of same,
determined by Type.
Table E-4. Table PCR Event Log Structure
Field Offset Size
(bytes) Description
PCRIndex 0 4 The Index of PCR to which this event was extended.
Type 4 4 Event type
Digest 8 20 SHA1 hash.
Size 28 4 The size of the event data.
Data 32 Size The data of the event.
TPM Event Log
136 315168-013
The following event types are defined for SINIT event logging. The calculation of
these fields is described briefly in section 10.1.
Table E-5. Event Types
Event Type Value Digest and Data content Mapping
LG/DA
Note 1
PCR
EVTYPE_BASE 0x400 Base of TXT event types
EVTYPE_PCRMAPPING
EVTYPE_
BASE +
1
Digest = zero digest – 20
bytes of zeros.
Data = DWORD with bits
31:1 all zeros (reserved for
now). Bit 0 = 0 if using
legacy PCR Mapping and 1 if
using D/A mapping.
LG / DA Not
extended
–
informati
ve only.
PCRIndex
field is
set to
0xFF.
EVTYPE_HASH_START
EVTYPE_
BASE +
2
Digest = SHA1(Data)
Data = ACM ID + EDX – 36
bytes total.
LG / DA
17 / 17
EVTYPE_COMBINED_HASH
EVTYPE_
BASE +
3
Digest = SHA1(Data)
Data = Content of
CombinedHashData area
LG
17
EVTYPE_MLE_HASH
EVTYPE_
BASE +
4
Digest = MleHash
Data = none LG / DA
18 / 17
EVTYPE_BIOSAC_REG_DA
TA
EVTYPE_
BASE +
10
Digest = BIOS AC
registration data – 20 bytes
from AUX index
Data = none
DA 17
EVTYPE_CPU_SCRTM_STA
T
EVTYPE_
BASE +
11
Digest = SHA1(Data)
Data = CPU S-CRTM status
DWORD
DA
17 / 18
EVTYPE_LCP_CONTROL_
HASH
EVTYPE_
BASE +
12
Digest = SHA1(Data)
Data = LCP PolControl
DWORD
DA
17 / 18
EVTYPE_ELEMENTS_HASH
EVTYPE_
BASE +
13
Digest = SHA1(Data)
Data = array of matching
LCP elements data as filled
by LCP. Total 4 * (20 + 4) =
96 bytes
DA
17
EVTYPE_STM_HASH
EVTYPE_
BASE +
14
Digest = StmHash
Data = none
Note: This event is created
only if
IA32_SMM_MONITOR_CTL[0
] == 1
DA
17
TPM Event Log
315168-013 137
Event Type Value Digest and Data content Mapping
LG/DA
Note 1
PCR
EVTYPE_OSSINITDATA_CA
P_HASH
EVTYPE_
BASE +
15
Digest = SHA1(Data)
Data =
OsSinitData.Capabilities
DWORD
DA
17 / 18
EVTYPE_SINIT_PUBKEY_
HASH
EVTYPE_
BASE +
16
Digest = SHA1
(ACHeader.RSAPubKey)
Data =none
DA
18
EVTYPE_LCP_HASH
EVTYPE_
BASE +
17
Digest = SHA1(Data)
Data = array of list hashes
containing matching LCP
elements data as filled by
LCP.
Total = [1 – 4] * 20 = 20 –
80 bytes
DA
18
Note 1: LG – Legacy PCR mapping; DA – Details / Authorities PCR mapping.
G.2 TPM 2.0 Event Log
Under TPM 2.0, event logging will follow the direction set by Microsoft’s proposal
outlined in Trusted Execution Environment EFI Protocol, 1.03, March 2013. A
separate log will be maintained for each supported hash algorithm. Below are a few
excerpts from that specification for baseline data structures and definitions, since the
specification is not final and subject to change.
G.2.1 TrEE Event Logging Structures
TCG_PCR_EVENT structure is being replaced by TCG_PCR_EVENT_EX structure
presented below:
typedef struct {
UINT32 PCRIndex;
UINT32 EventType;
BYTE Digest[DigestSize];
UINT32 EventDataSize;
BYTE EventData[];
} TCG_PCR_EVENT_EX;
The only difference from TPM 1.2 version is the size of Digest field which now equals
to digest size of used hash algorithm.
New TCG_LOG_DESCRIPTOR structure is introduced with the following format:
typedef struct {
BYTE[16] Signature;
UINT32 Revision;
UINT32 DigestAlgID;
TPM Event Log
138 315168-013
UINT32 DigestSize;
} TCG_LOG_DESCRIPTOR;
Digest algorithm IDs are defined as follows:
#define DIGEST_ALG_ID_SHA_1 0x00000001
#define DIGEST_ALG_ID_SHA_2_256 0x00000002
#define DIGEST_ALG_ID_SHA_2_384 0x00000003
#define DIGEST_ALG_ID_SHA_2_512 0x00000004
Note that numerical values don’t follow TPM 2.0 numbering.
Fields of TCG_LOG_DESCRIPTOR structure have the following hardcoded values:
Signature = “FRMT ID EVENT00”,0
Revision = 1
DigestAlgID = One of DIGEST_ALG_ID_SHA_*
DigestSize = Length of the TCG_PCR_EVENT_EX.Digest field for all event entries in
the log.
It is required for each of the non-SHA1 event log the first entry to be the following
TPM1.2 style TCG_PCR_EVENT record specifying type of the log:
TCG_PCR_EVENT.PCRIndex = 0
TCG_PCR_EVENT.EventType = 0x03 // EV_NO_ACTION per TCG EFI
// Platform specification
TCG_PCR_EVENT.Digest = {00…00} // 20 zeros
TCG_PCR_EVENT.EventDataSize = sizeof(TCG_LOG_DESCRIPTOR).
TCG_PCR_EVENT.EventData = TCG_LOG_DESCRIPTOR
The digest of this record MUST NOT be extended into any PCR.
G.2.2 TPM 2.0 Event Log Pointer Element
The new pointer element described after Table will be used to support agile event
logging. Each of the logs in this element will be described using the following
structure:
typedef struct {
UINT16 HashAlgID; // HashAlgID of the event log per
// TPM2.0 spec.
UINT16 Reserved;
UINT64 PhysicalAddress; // Event log physical address
UINT32 AllocatedEventContainerSize;
UINT32 FirstRecordOffset;
UINT32 NextRecordOffset;
} HEAP_EVENT_LOG_DESCR;
TPM Event Log
315168-013 139
HashAlgID – hash algorithm ID of event log – all records in log use the same
algorithm ID.
Note: All HashAlgIDs follow numerical values of TPM 2.0 specification. This is in
contrast to values DIGEST_ALG_ID_SHA_* values used in records of event log itself.
PhysicalAddress – address of log in memory
AllocatedEventContainerSize – size in bytes allocated for event log. SINIT will verify
that this size is not less than 1 page = 4KB;
FirstRecordOffset – Offset of first record starting from beginning of log. It is
anticipated to be zero unless in future we will need to add metadata to the beginning
of log.
NextRecordOffset – offset of next free memory spot for record to be added to. Will be
incremented as records are added.
Note: In order to simplify MLE design, first mandatory record containing
TCG_LOG_DESCR structure in non-SHA1 logs will be added by SINIT.
SINIT in TPM2.0 mode will require HEAP_EVENT_LOG_POINTER_ELEMENT2 to be
present with at least one HEAP_EVENT_LOG_DESCR entry. This is justified by the
need to have event log for attestation since support of many of the SinitMleData table
fields is removed in TPM2.0 mode – see Table .
Pre-MLE SW may use HEAP_EVENT_LOG_POINTER_ ELEMENT2 to request what kind
of log it wants SINIT to create. It will be not an error to request event log for just one
of supported HashAlgIDs.
SINIT will verify that requested event log(s) correspond to HashAlgID for which
dynamic PCRs are actually extended. This requirement means that all requested
HashAlgID of event logs must belong to PCR_HashAlgIDList.
SINIT will abort with error if this condition is not met.
There are no requirements for event log to be in DMA protected memory – SINIT will
not enforce this requirement.
G.2.3 TCG Compliant Event Logging Structures
“TCG PC Client Platform. EFI Protocol Specification, rev 4” defined new event logging
structure suitable for multi-algorithm event logging. To maintain TCG compliance,
SINIT modules will support this event log format.
Information below is identical to one presented in TCG specification and is included for
easy reference. In case of any discrepancies information of TCG specification will
prevail.
typedef struct {
UINT32 PCRIndex;
UINT32 EventType;
TPML_DIGEST_VALUES Digest;
UINT32 EventSize;
TPM Event Log
140 315168-013
BYTE Event[EventSize];
} TCG_PCR_EVENT2;
Where TPML_DIGEST_VALUES structure layout is presented below:
Typedef struct {
UINT32 count; // Count of TPMT_HA structures
Struct {
UINT16 AlgorithmID; // Hash algorithm of array element X
// TPMI_ALG_HASH
UINT8 digest[AlgorithmID_DIGEST_SIZE] // Digest value in
// array element X
} TPMT_HA digests[count] // Array of TPMT_HA structures
} TPML_DEGEST_VALUES;
Note that although the type names from TPM 2.0 Library Specification are used, the
encoding of the count member and the AlgorithmID are little-endian as is the rest of
the log format.
First record of the log must follow TCG_PCR_EVENT structure in TPM 1.2 format and
declare revision of the supported EFI Platform specification
typedef struct {
UINT32 PCRIndex; // 0
UINT32 EventType; // 3 == EV_NO_ACTION
UINT8 Digest[20]; // ZeroSha1Digest[20] = {00, 00…00}
UINT32 EventDataSize; // sizeof(EventData[])
UINT8 EventData[]; // TCG_EfiSpecIDEventStruct
} TCG_PCR_EVENT;
typedef struct {
UINT8 signature[16]; // ‘Spec ID Event03’, 00
UINT32 platformClass; // 00 – PC Client Platform Class;
// 01 – Server Platform Class
UINT8 specVersionMinor; // 00 – minor of 2.00
UINT8 specVersionMajor; // 02 – major of 2.00
UINT8 specErrata; // 00 – errata of 2.00
UINT8 uintnSize; // 01 for UINT32; 02 for UINT64
UINT32 numberOfAlgorithms; // Number of hashing algorithms used
// in this event log
TCG_EfiSpecIdEventAlgorithmSize digestSizes[numberOfAlgorithms]
// array/ of value pairs
UINT8 vendorInfoSize; // FF is maximum
UINT8 vendorInfo[VendorInfoSize]; // Vendor specific
} TCG_EfiSpecIDEventStruct;
typedef struct {
UINT16 algorithmId;
UINT16 digestSize;
} TCG_EfiSpecIdEventAlgorithmSize;
The digest of this record MUST NOT be extended into any PCR.
TPM Event Log
315168-013 141
SINIT module will support one the logs – either original as described in section G.2.1
or TCG compliant as described in this section. There is no intention to support both
event log formats in single instance of SINIT.
New bit in capabilities field of ACM Info Table ACMInfoTable.Capabilities[9] has been
added to declare format of supported event log – see Table 2-2. MLE/SINIT
Capabilities Field Bit Definitions.
ACM Info Table version remains 6 and encompasses two updates – aforementioned bit
and ACM Revision – see Table A-3. Chipset AC Module Information Table
G.2.4 Event Types Changed and Added for TPM2.0
In addition to the event types given in Table , the following types may occur in logs
for TPM2 family.
Note 1: For TPM2, legacy mapping is not supported.
Note 2: If log is created using original TXT format per G.2.1 Digest field is computed
using HashAlgID of the log. If log is created using TCG compatible format per G.2.3,
digest field must be computed for each of the AlgorithmId of TPML_DIGEST_VALUES
structure.
Table E-6. Event Types Changed and Specific to TPM2.0
Event Type Value Digest and Event PCR Comments
EVTYPE_PCR_MAPPI
NG EVTYPE_BASE
+1 Digest =
ZeroDigestHashAlgIDSize of
size correponding to hash
algorithm.
EventData = DWORD
with bits 31:1 all zeros
(reserved for now). Bit 0
= 0 if using legacy PCR
Mapping and 1 if using
D/A mapping.
EventDataSize =4
0xFF Not extended –
informative only.
Optional since LG
mapping is not
supported.
EVTYPE_HASH_STAR
T EVTYPE_BASE
+2 Digest=HashHashAlgID
(EventData)
EventData=SinitHash +
EDX.
EventDataSize= 36
17 EventData is
SinitHash and EDX
value stored during
SINIT
authentication
process in ACM
header scratch
area.
EVTYPE_COMBINED_
HASH EVTYPE_BASE
+3 Reserved in TPM2.0
mode
EVTYPE_MLE_HASH EVTYPE_BASE
+4 Digest= HashHashAlgID
(Mle)
EventData=Empty buffer
EventDataSize=0
17
TPM Event Log
142 315168-013
Event Type Value Digest and Event PCR Comments
EVTYPE_BIOSAC_RE
G_DATA EVTYPE_BASE
+10 Digest= HashHashAlgID
(EventData)
EventData=BIOS AC
Registration Data
EventDataSize=32
17 EventData is 32
bytes of AUX index
starting at offset 0
EVTYPE_CPU_SCRTM
_STAT EVTYPE_BASE
+11 Digest= HashHashAlgID
(EventData)
EventData=CPU S-CRTM
Status DWORD
EventDataSize=4
17 &
18
EVTYPE_LCP_CONTR
OL_HASH EVTYPE_BASE
+12 Digest= HashHashAlgID
(EventData)
EventData=LCP
PolControl DWORD
EventDataSize=4
17 &
18 EventData is
effective PolControl
derived from PS
and PO policies.
EVTYPE_ELEMENTS_
HASH EVTYPE_BASE
+13 Reserved in TPM2.0
mode
EVTYPE_STM_HASH EVTYPE_BASE
+14 If STM is present
Digest= HashHashAlgID
(Stm)
If STM is not present
Digest= HashHashAlgID
(0x00)
EventData=Empty buffer
EventDataSize=0
17 If STM is not
present, hash of
single byte with
zero value will be
measured instead
EVTYPE_OSSINITDA
TA_CAP_HASH EVTYPE_BASE
+15 Digest= HashHashAlgID
(EventData)
EventData=OsSinitData
Capabilities DWORD
EventDataSize=4
17 &
18 EventData is
capabilities DWORD
passed to SINIT by
pre-MLE SW
EVTYPE_SINIT_PUBK
EY_HASH EVTYPE_BASE
+16 Digest= HashHashAlgID (CS
PUBKEY)
EventData=Empty buffer
EventDataSize=0
18 CS PUBKEY is
chipset public key.
Hash can be
retrieved from LT
0x400
EVTYPE_LCP_HASH EVTYPE_BASE
+17 Reserved in TPM2.0
mode
TPM Event Log
315168-013 143
Event Type Value Digest and Event PCR Comments
EVTYPE_LCP_DETAIL
S_HASH EVTYPE_BASE
+ 18 Digest= HashHashAlgID
(EventData)
EventData=concatenatio
n of digests and policy
controls of matching
policy elements – see
3.3.9.1
EventDataSize=sizeof(Ev
entData)
If polcy evaluates to ANY
Then
Digest= HashHashAlgID
(0x00)
EventData=0x00
EventDataSize=1
17 EventData is
concatenation of
digests, policy
controls of all
matching elements
contributed to
effective policy –
see 3.3.9.1.
Analogous to event
type 13 but uses
different event
format.
EVTYPE_LCP_AUTHO
RITIES_HASH
EVTYPE_BASE
+ 19 Digest= HashHashAlgID
(EventData)
EventData=concatenatio
n of list descriptors
containing matching
policy elements - see
3.3.9.2
EventDataSize=sizeof(Ev
entData)
If policy evaluates to ANY
Then
Digest= HashHashAlgID
(0x00)
EventData=0x00
EventDataSize=1
18
EventData is
concatenation of
list description
structures of all
lists containing
matching elements
contributed to
effective policy –
see 3.3.9.2
Analogous to event
type 17 but uses
different event
format and hashing
rules.
EVTYPE_NV_INFO_H
ASH
EVTYPE_BASE
+ 20 Digest= HashHashAlgID
(EventData)
EventData=array of
TPMS_NV_PUBLIC
structures of defined
indices - see 3.3.10.
EventDataSize=sizeof(Ev
entData)
17/
18
EventData is
concatenation of
TPMS_NV_PUBLIC
structures of all
defined TPM NV
indices.
EVTYPE_CAP_VALUE
EVTYPE_BASE
+255 Digest= HashHashAlgID
(0x01)
EventData=0x01
EventDataSize=1
17/
18
Caps PCR value if
digest cannot be
computed due to
limited embedded
SW capabilities.
§ §
ACM Hash Algorithm Support
144 315168-013
Appendix H ACM Hash Algorithm
Support
H.1 Supported Hash Algorithms
ACM support will be not restricted to fixed set of hash algorithms. Instead it will
support a variable list of algorithms which may include any algorithms supported by
TPM 2.0 specification limited only by PRD, space and supporting libraries, and defined
on by-project bases.
List of currently supported algorithms is presented in E.1
H.2 Hash Algorithm Lists
Based on the list of TPM 2.0 supported algorithms the ACM creates the following lists
of hash algorithms for different usages:
– TPM_HashAlgIDList - list of TPM supported HashAlgIDs. This is the list of all
HashAlgIDs supported by given entity of the TPM device. Determined
dynamically at run time;
– PCR_HashAlgIDList - list of HashAlgID for which given specimen of TPM
device implements dynamic PCRs 17 & 18. Determined dynamically at run
time;
– ACM_HashAlgIDList - list of ACM Supported HashAlgIDs. This is the list of
HashAlgIDs supported by ACM via embedded SW. It is established at ACM
build time and reported via ACM Info Table – see Table A-7.
TXT_ACM_PROCESSOR_ID Format
– Lcp_HashAlgIDList - List of LCP prescribed HashAlgIDs. This is the list stored
in PS and / or PO TPM NV indices by Platform Supplier / Platform Owner. This
list is described below.
H.3 Hash Algorithm List Subsets
ACM will detect content of all four HashAlgID Lists:
1. TPM_HashAlgIDList will be detected by executing the TPM2_GetCapability()
command, probing every HashAlgID in the TPM2.0 supported list
2. PCR_HashAlgIDList will be created as a subset of TPM_HashAlgIDList via the
TPM2_PCR_Read() command. Both PCR17 and 18 will be read
3. ACM_HashAlgIDList is defined by ACM build options.
4. Lcp_HashAlgIDList – will be read from PS / PO indices after effective LCP policy is
determined based on standard LCP combining principles. This list will represent
Platform Policy.
ACM Hash Algorithm Support
315168-013 145
Figure H-1. Hash Algorithm List Selection
Based on the above lists, ACM will create a number of derivative lists to handle
permissible hashing while performing LCP enforcement:
– EFF_HashAlgIDList = (ACM_HashAlgIDList U TPM_HashAlgIDList) ∩
LCP_HashAlgIDList
This list contains all hashes supplied by all crypto-engines available for ACM –
embedded SW and TPM intersected with effective Platform Policy mask. This
list will be used to enforce LCP policy represented by MLE, STM and SBIOS
elements.
– LCP policy enforcement represented by PCONF elements will be as follows:
o PCR Selection used by PCONF element will be limited only by PCR
banks supported by given TPM i.e. by PCR_HashAlgIDList;
o Hash algorithm used to compute composite digest will be handled by
one of two rules:
If composite hash will be handled by TPM2_PolicyPCR
command, permissible algorithm will be one of supported by
TPM and Platform Policy i.e.
LCP_TPM_HashAlgIDList = TPM_HashAlgIDList ∩
LCP_HashAlgIDList.
This option #1 is currently supported by ACM and LCP tools.
If composite hash will be computed by ACM SW, permissible
algorithm will be selected by EFF_HashAlgIDList.
This option #2 is a stretch goal.
– If PCR Extend Policy is selected to be MP, then
ACM_PCR_HashAlgIDList = ACM_HashAlgIDList ∩ PCR_HashAlgIDList
list will represent all extended PCR banks. All PCRs not included in this list will
be capped with value “1”.
– If PCR Extend Policy is selected to be MA, then all TPM PCRs will be extended
and none will be capped.
§ §
PCR Extend Policy = MA
Extended PCRs
TPM_Hash AlgI DL is t
ACM_Hash AlgI DL is t
PCR_Hash AlgI DLis t
PCR Extend Policy = MP
Extended PCRs
PCR Extend Policy = MP
Capped PCRs
LCP Elements:
MLE, STM, SBIOS
LCP_HashAlgIDL is t
PCONF
C ompo si te
Hash
Option 1
PCONF
C ompo si te
Hash
Option 2
PCONF
PCR
Selection
ACM Error Codes
146 315168-013
Appendix I ACM Error Codes
After a successful measured launch, the TXT.ERRORCODE register will contain either
0x0 or 0xc0000001. Failed launches leave other values in this register, which survive
warm resets and may be useful for diagnosis and remediation of the failure’s cause.
The tables below describe the format of this register as written during CPU-initiated
and ACM-initiated shutdowns. The final table describes the mapping of register sub-
field values to meanings for values whose mappings are stable and potentially useful
to the end user.
In order to make updates to this table-set available between releases of this
document, the equivalent of the contents of this appendix can be found at
http://software.intel.com/en-us/articles/intel-trusted-execution-technology.
Table I-1. General TXT.ERRORCODE Register Format
Bit Name Description
31 Valid Valid error when set to 1. The rest of the register contents should be
ignored if '0'.
30 External 0 – induced by processor, 1 – induced by external software.
29:16 Type1 Implementation and source specific
15 SW
source 0 – ACM; 1 – MLE
14:0 Type2 Implementation and source specific. Provides details about cause of
shutdown.
Table I-2. TXT.ERRORCODE Register Format for CPU-initiated TXT-shutdown
Bit Name Value / Error
31 Valid 1
30 External 0
29:24 Reserved 0
23:16 Extended
value All errors except #0x10 == 0
Error #0x10 = ACM SVN
15 Reserved 0
14:0 Type2 0 = Legacy shutdown (non TXT-specific).
1 – 4 = Reserved
5 = Authenticated RAM load memory type error
6 = Unrecognized AC module format
7 = Failure to authenticate
8 = Invalid AC module format
9 = Unexpected snoop hit detected
ACM Error Codes
315168-013 147
Bit Name Value / Error
0xA = Illegal event or IllegalProcessorState – collection of various
illegal causes.
1. A CPU reset occurs during AC-mode or post-SENTER and
LT.E2STS[RESET.STS] == 0 (I.E. reset was not caused by an LT-
shutdown).
2. A non-virtualized INIT event occurs while post-SENTER.
3. LTSX only: During RLP WAKEUP, the RPL thread’s value of MSR bit
IA32_SMM_MONITOR_CTL[0] (aka MSEG valid) does not match
the ILP thread’s value.
4. An SENTER, SEXIT, or WAKEUP doorbell is received while post-
VMXON.
5. A thread wakes from wait-for-SIPI while some other thread in the
same package is in AC-mode.
#1 is by far the most common observed in post-Si debug.
0xB = Invalid JOIN format
0xC = Unrecoverable machine check condition
0xD = VMX abort
0xE = AC memory corruption
0xF = Illegal voltage/bus ratio
0x10 = Low SGX security level post 1st SGX instruction:
0x11-0xFFFF = Reserved
Table I-3. TXT.ERRORCODE Register Format for ACM-initiated TXT-shutdown
Bit Name Description
31 Valid Valid error when set to 1. The rest of the register contents should be
ignored if '0'.
30 External = 1– induced by external software.
29:28 Type1 /
Reserved Free for specific implementation
27:16 Type1 /
Minor Error
Code
Field value depends on Class Code and / or Major Error Code. Several
examples are:
1. If Class Code = “TPM Access” and
Major Error Code = “TPM retuned an error” –
Field value = TPM returned error code
TPM returned error code is posted in different format for TPM 1.2 and
TPM 2.0 modes.
TPM 1.2: If error code is fatal, it occupies bits [23:16] and bit 24
remains clean. For non-fatal error codes lower byte is placed into bits
[23:16] and bit 24 is asserted. For instance error code 0x803 will be
translated into 0x103. This is legacy error code representation.
TPM 2.0: TPM returned error code is posted as is.
2. If Class Code = “Launch Control Policy and
Major Error Code = “Policy Integrity Fail” –
Field value = (LIST_INDEX << 6) + Specific Minor Error Code
ACM Error Codes
148 315168-013
Bit Name Description
3. If Class Code = “Range Check Error” –
Field value = Index of first range in conflict with another range
according to Project Range Table.
15 SW source 0 = ACM; 1 = MLE
14:10 Type2 /
Major Error
Code
0 – 0x1F = Error code within current class code
9:4 Type2 /
Class Code 0 – 0x3F = Class code clusters several congeneric errors into a group.
3:0 Type2 /
Module
Type
0 = BIOS ACM
1 = SINIT
Table I-4. TXT.ERRORCODE Definitions Stable among ACM Modules
Major
Error
Code
Minor
Error
Code
Description
Class code = 1: ACM Entry – BIOS AC and SINIT
1 0-x Error in ACM launching:
SINIT is launched not via SENTER;
Reserved bits in EDX register are not 0;
Minor error code contains additional details.
3 0 Client SINIT detected LTSX fused processor or
Server SINIT detected non- LTSX fused processor
9 0 ACM is revoked
Class code = 2: MTRR Check – BIOS AC and SINIT
1 0 MTRR Rule 1 Error
2 0 MTRR Rule 2 Error
3 0 MTRR Rule 3 Error
4 0 MTRR Rule 4 Error
5 0 MTRR Rule 5 Error
6 0 MTRR Rule 6 Error
7 0 Invalid MTRR mask value
Class code = 4: TPM Access – BIOS AC and SINIT
ACM Error Codes
315168-013 149
Major
Error
Code
Minor
Error
Code
Description
1 TPM
Error
Code
0-0xfff
TPM returned an error. Error is reported as:
TPM 1.2 family error code occupies 9 bits.
Fatal error codes:
[23:16] – error code;
[24] = 0
Non-fatal error codes:
[23:16] – error code & 0xFF;
[24] = 1
TPM 2.0 error code occupies 12 bits.
All error codes are returned unmodified
5 0 TPM 1.2 disabled
6 0 TPM 1.2 deactivated
0xD 0 TPM 2.0 interface type (FIFO/CRB) not supported
0xE 0 TPM family (1.2/2.0) not supported
0xF 0 Discovered number of TPM 2.0 PCR banks exceeds supported maximum
(3)
0x10 0 Required TPM hash algorithm not supported
Class code = 6: Launch Control Policy – BIOS AC and SINIT
2 0-X SINIT version is below minimum specified in TPM NV policy index.
Minor error code contains additional details.
4 0-4 No match is found for Policy Element.
Element type is reported via minor error code.
5 0 Auto-promotion failed.
BIOS hash differs from hash value saved in AUX index.
6 0 Failsafe boot failed. (FIT table not found or corrupted).
7 0-X PO integrity check failed.
Minor error code contains additional details.
8 0-X PS integrity check failed.
Minor error code contains additional details.
9 0 No policies are defined to allow NPW execution
0xA 0 PS TPM NV policy index is required but not defined.
Class code = 9: Heap Table Data -- SINIT
1 0-X Invalid size of one of the heap data tables.
Minor error code contains additional details.
2 0-X Invalid version of one of the heap data tables
Minor error code contains additional details.
3 0 Invalid PMR Low range alignment
4 0 Invalid PMR High range alignment
5 0 Invalid MLE placement (Above 4GB)
6 0 Invalid MLE requested capabilities
ACM Error Codes
150 315168-013
Major
Error
Code
Minor
Error
Code
Description
7 0-X Heap region is overfilled.
Minor error code contains additional details.
8 0 Unsupported heap extended element type.
9 0 Invalid heap extended element size.
0xA 0 Heap table is not terminated by the extended “END” element
0xB 0-X Invalid event log pointer.
Minor error code contains additional details.
0xC 0 Invalid RSDT/RSDP pointer in OsSinitData table
Class code = 0xE: PMR Configuration -- SINIT
1 0 DMA remapping is enabled
2 0 Invalid PMR Low configuration
3 0 Invalid PMR High configuration
Class code = 0xF: MLE Header Check -- SINIT
1 0 MLE Header linear address conversion error
2 0 Invalid MLE GUID
3 0 Invalid MLE version
4 0 Invalid first page address
5 0 Invalid MLE size
6 0 Invalid MLE entry point address
7 0 Incompatible RLM wake-up method
Class code = 0x10: MLE Page Tables Check -- SINIT
1 0 Page placement error:
Incorrect page alignment;
Page is not in usable DMA protected DRAM;
Pages checked are:
PDPT page
PDT page;
PT page;
MLE page
2 0 MLE page order rule failure – next page is not above previous one.
3 0 Discovered big page (2MB)
4 0 Page Table order rule failure – PDPT, PDT, PT, MLE pages are not in
ascending order.
5 0 Invalid MLE hashed size
6 0 Invalid RLP entry point address
Class code = 0x14: Event Log -- SINIT
1 0 Invalid Log Header GUID
ACM Error Codes
315168-013 151
Major
Error
Code
Minor
Error
Code
Description
2 0 Invalid Log Header version
3 0 Inconsistent values of header fields
4 0 Insufficient log size
5 0 Unsupported record version
§ §
TPM NV
152 315168-013
Appendix J TPM NV
Table J-1. TPM Family 1.2 NV Storage Matrix
Name Label Index Value Description Public
Size in
bytes Attributes Read
Auth Write
Auth Locality
Write Locality
Read PCR
Write
or Read
LCP Platform
Supplier PS 0x50000001 LCP Structure for
Platform Supplier Platform
Specific
Size: 54
WRITEDEFINE None None Any Any Any
LCP Platform
Owner PO 0x40000001 LCP Structure for
Platform Owner Platform
Specific
Size: 54
OWNERWRITE None Owner Any Any Any
Launch Auxiliary AUX IVB and before
platforms:
0x50000002
IVB after PRT and
beyond platforms:
0x50000003
Inter – module
mail box
BIOSAC
registration data
Platform
Specific
LT-CX
Size: 64
LT-SX
Size: 96
None None None 3 or 4 Any Any
SGX SVN SGX 0x50000004 BIOS – MLE mail
box. Value of
SINIT SVN and
flags
Platform
Specific
Size: 8
None None None 3 - 0 3 - 0 Any
TPM NV
315168-013 153
Table J-2. TPM Family 2.0 NV Storage Matrix
Name Label Index
Value Description Public Size in bytes Attributes Auth
Value Auth
Policy Locality
Write Locality
Read Locality
Delete
LCP
Platform
Supplier
PS 0x180_0001
OR
0x1C1_0103
Note 3
LCP Structure
for Platform
Supplier
Platform Specific
Size: >= 38 +
HASHALGID_DIGEST_SIZE
Note 1
PS1 attribute set:
TPMA_NV_POLICYWRITE
TPMA_NV_POLICY_DELETE
TPMA_NV_AUTHREAD
TPMA_NV_NO_DA
TPMA_NV_PLATFORMCREATE
Empty
Buffer OEM
policy Any,
controlled by
OEM policy
Any Any,
controlled
by OEM
policy
PS2 attribute set:
TPMA_NV_AUTHWRITE
TPMA_NV_POLICY_DELETE
TPMA_NV_AUTHREAD
TPMA_NV_NO_DA
TPMA_NV_PLATFORMCREATE
TPMA_NV_WRITEDEFINE
Any until
write
protected.
Not writable
after write
protected
LCP
Platform
Owner
PO 0x140_0001
OR
0x1C1_0106
Note 3
LCP Structure
for Platform
Owner
Platform Specific
Size: >= 38 +
HASHALGID_DIGEST_SIZE
Note 1
TPMA_NV_OWNERWRITE
TPMA_NV_POLICYWRITE
TPMA_NV_AUTHREAD
TPMA_NV_NO_DA
Empty
Buffer Owner
policy Any,
controlled
by Owner
choice
Any Any,
controlled
by Owner
choice
Launch
Auxiliary AUX 0x180_0003
OR
0x1C1_0102
Note 3
Inter – module
mail box
BIOSAC
registration data
Platform Specific
Size: >= 40 + 2 *
HASHALGID_DIGEST_SIZE
Note 1
TPMA_NV_POLICYWRITE
TPMA_NV_POLICY_DELETE
TPMA_NV_WRITE_STCLEAR
TPMA_NV_AUTHREAD
TPMA_NV_NO_DA
TPMA_NV_PLATFORMCREATE
Empty
Buffer Fixed
policy
Note 2
3 or 4 Any 3 or 4
SGX SVN
SGX 0x1800004
OR
0x1C1_0104
Note 3
BIOS – MLE mail
box. Value of
SINIT SVN and
flags
Platform Specific
Size: 8 TPMA_NV_AUTHWRITE
TPMA_NV_POLICY_DELETE
TPMA_NV_AUTHREAD
TPMA_NV_NO_DA
TPMA_NV_PLATFORMCREATE
Empty
Buffer OEM
policy Any Any Any,
controlled
by OEM
policy
TPM NV
154 315168-013
Note 1: HASHALGID_DIGEST_SIZE is the size of the digest of respective hash algorithm used to store data in the index.
Respective sizes in bytes for all used algorithms are:
SHA1_DIGEST_SIZE = 20
SHA256_DIGEST_SIZE = 32
SM3_256_DIGEST_SIZE = 32
SHA384_DIGEST_SIZE = 48
SHA512_DIGEST_SIZE = 64
Note 2: Policy digest must match the following:
Let policy A to be:
A = TPM2_PolicyLocality (Locality 3 & Locality 4)
Let policy B to be:
B = TPM2_PolicyCommandCode (TPM_CC_NV_UndefineSpecial)
Let policy C to be:
C = TPM2_PolicyCommandCode (TPM_CC_NV_Write)
Then authPolicy can be computed as:
authPolicy = {{A} AND {C}} OR {{A} AND {B}}
Note 3: Initially TXT used index handles selected from 0x180_xxxx and 0x140_xxxx ranges based on early version of TCG
“Registry of reserved TPM 2.0 handles and localities” and TXT legacy. Later revision of TCG registry repurposed the above
ranges creating mismatch between TXT practice and normative TCG document. Moreover, selection of TXT related NV index
handles from the ranges assigned to OEMs and Users does not guarantee its conflict free usage. In order to address both issues
Intel requested TCG to assign “Intel Reserved” range of indices 0x1C1_0100 - 0x1C1_013F for TXT and other purposes out of
range 0x1C1_xxxx reserved for component vendors.
TXT ACMs will support one of two sets of index handles indicated above. There is no intention to support both at the same time.
Indication of supported set is provided via TPM capabilities – see Table
TPM NV
315168-013 155
Table J-3. AUX DATA structure
Name Size (bytes) Comment
LT-CX and LT-SX specific
data Sizeof (AUX) - sizeof (AUXRevocation) –
see E.5
Where sizeof (AUX):
= 64 – TPM 1.2 clients
= 96 – TPM 1.2 servers
= 104 – TPM 2.0
Content of this area is client and LT-SX specific
AUXRevocation TPM 1.2 family: 4
TPM 2.0 family: 8 AUX Revocation Region. See AUXRevocation structure in
section E.5.
§ §
Detailed LCP Checklists
156 315168-013
Appendix K Detailed LCP Checklists
K.1 Policy Validation Checklist
The following checks must be performed by LCP Policy Engine to validate LCP data
integrity:
K.1.1 TPM NV AUX Index
1. Index must be provisioned
2. Index attributes must be per Table for V2 index and per Table for V3 index.
3. nameAlg hashing algorithm must have at least 256 bit digest e.g. be either
SHA256 / SM3 or stronger
4. Size must be per Table and Table for V2 and V3 structures respectively.
5. Read AUX index data and analyze content.
6. Additional verification steps can be added since AUX index content is platform
specific.
K.1.2 TPM NV PS Index
1. Index must be provisioned
2. Index attributes must be per Table for V2 index and per Table for V3 index.
3. nameAlg hashing algorithm must have at least 256 bit digest e.g. be either
SHA256 / SM3 or stronger
4. Read PS index data and analyze content
5. PS.Version must be per 3.2.1 for V2 index and per 3.3.2 for V3 index
6. PS.HashAlg must be per D.1 for V2 structure and one of the supported
algorithms per E.1 for V3 structure.
7. TPM 2.0 mode: PS.HashAlg must be permitted by PS.LcpHashAlgMask
8. Size must be per Table for V2 structure and per Table for V3 structure. Size
of PS.PolicyHash field must be not less than digest size of PS.HashAlg field.
9. PS.PolicyType must be either LCP_POLTYPE_LIST or LCP_POLTYPE_ANY – see
3.2.1
10. PS.SINITMinVersion must be not greater than value of AcmVersion field in
Table A-
11. If PS.PolicyControl.PoIsRequired bit is set - PO index must be provisioned. This
requirement must be enforced by SINIT Policy Engine and ignored by BIOSAC
Policy Engine.
12. TPM 2.0 mode: algorithm selected by PS.AuxHashAlgMask must be permitted
by PS.LcpHashAlgMask.
Detailed LCP Checklists
315168-013 157
13. TPM 2.0 mode: PS.AuxHashAlgMask must select single algorithm.
14. TPM 2.0 mode: algorithms corresponding to set bits in PS.LcpHashAlgMask
and PS.LcpSignAlgMask must be supported by ACM per E.1 for V3 structure.
15. TPM 2.0 mode: Ps.PolicyControl[AUXDeletionControl] bit must be de-asserted.
K.1.3 TPM NV PO Index
1. Index may be provisioned.
2. Index attributes must be per Table for V2 index and per Table for V3 index.
3. nameAlg hashing algorithm must have at least 256 bit digest e.g. be either
SHA256 / SM3 or stronger
4. Read PO index data and analyze content.
5. PO.Version must be per 3.2.1 for V2 index and per 3.3.2 for V3 index
6. PO.HashAlg must be per D.1 for V2 structure and one of the supported
algorithms per E.1 for V3 structure.
7. TPM 2.0 mode: PO.HashAlg must be permitted by PO.LcpHashAlgMask
8. Size must be per Table for V2 structure and per Table for V3 structure. Size
of PO.PolicyHash field must be equal digest size of PO.HashAlg field.
9. PO.PolicyType must be either LCP_POLTYPE_LIST or LCP_POLTYPE_ANY – see
3.2.1
10. PO.SINITMinVersion must be not greater than value of AcmVersion field in
Table A-
11. TPM 2.0 mode: algorithms corresponding to set bits in PO.LcpHashAlgMask
and PO.LcpSignAlgMask must be supported by ACM per E.1 for V3 structure.
K.1.4 NPW Mode
Detect whether system in NPW mode is allowed to run:
1. System is in NPW mode if NPW bit is asserted in Flags field of ACM header of
any module in the system. Value of AUX.ModuleFlags field may be used to
analyze BIOSACM. If AUX.ModuleFlags value is initial “All Fs” state system is
assumed to be in NPW mode.
2. If system is in NPW mode Eff.PolicyControl.NPW_OK bit must be asserted –
see K.2.1.
K.1.5 Policy Data Files
1. If PS.PolicyType or PO.PolicyType is LCP_POLTYPE_LIST then respective PS or
PO Policy Data File must exist and be accessible.
K.1.6 PS Policy Data File if Exists
1. Loop through all lists as indicated by File.NumberOfLists value
2. Validate signature of each of the lists:
Detailed LCP Checklists
158 315168-013
a. If list is unsigned – skip to step 3 computation of list digest.
b. If list is signed but signature is not supported by Policy Engine – abort
since this prevents validation of data integrity.
c. If list is signed and signature is supported – validate signature.
Supported signature algorithms are listed in D.3.1 for V2 structures
and in E.3.1 for V3 structures.
3. Compute the digest of the list:
a. For unsigned list compute digest as ListDigest[ListNumber] =
PS.HashAlg (ListData), where PS.HashAlg is hashing algorithm in PS
index per D.1 for V2 structure and per E.1 for V3 structure and
hashing is performed over entire unsigned list data.
b. For signed list compute digest as ListDigest[ListNumber] = PS.HashAlg
(ListPublicKey), where PS.HashAlg is hashing algorithm in PS index per
D.1 for V2 structure and per E.1 for V3 structure and ListPublicKey is
either PublicKey field of RSASSA signature or concatenation of Qx|Qy
public key components fields of ECDSA signature – signature formats
in D.3.1 for V2 signed lists and in E.3.1 for V3 signed lists.
4. Compute digest of entire PS Policy Data File by concatenation of all digests of
individual lists and hashing it once more using the same PS.HashAlg e.g.
PS.PolicyDataFileDigest = PS.HashAlg(List0Digest[0]|…|ListDigest[N])
5. Computed PS.PolicyDataFileDigest file digest must match value of
PS.PolicyHash field of PS index.
K.1.7 PO Policy Data File if Exists
1. Repeat all steps for PO Policy Data File analogously to the steps above for PS
Policy Data File.
K.1.8 PS Policy Data File List Integrity
1. List.Version must be per D.3.2 for V2 list and per E.3 for V3 list.
2. Loop through all elements of the list and sum-up their sizes. Obtained value
must match File.PolicyElementsSize field value. Empty list with a
File.PolicyElementsSize == 0 is a valid placeholder. It must contain no
elements.
3. During looping check types of elements: V2 style list must contain only V2
style element types. V3 style list may contain mixture of both element styles.
4. Validate hash algorithms used by elements. Scan through all of the elements
in list checking Elt.HashAlgorithm values. Abort if any is not supported by ACM
per D.1 for V2 structures and in E.1 for V3 structures. In TPM 1.2 mode scan
only V2 style elements while in TPM 2.0 mode scan only V3 style elements.
5. In TPM 2.0 mode only - for V3 style PCONF elements verify that Count field of
TPMS_QUOTE_INFO structure which is part of PCRInfo definition equals 1.
6. If list is signed check the List.RevocationCounter value. If it is lesser than
PS.DataRevocationCounter [ListNumber] abort with error. ListNumber here is
the orderly list number in the PS Policy Data File.
Detailed LCP Checklists
315168-013 159
K.1.9 PO Policy Data File List Integrity
1. Repeat all steps as for PS Policy Data File List Integrity. Check list revocation
status using PO.DataRevocationCounter and abort if revoked.
K.2 Policy Enforcement Checklist
K.2.1 Effective Policies
Requirements of this section are relevant to SINIT only since BIOSAC ignores PO and
its Effective Policy is amounted to PS policy only.
1. Create effective policies via combining of PS and PO contents.
a. Eff.PolicyType = (PO provisioned) ? PO.PolicyType : PS.PolicyType
b. If Eff.PolicyType is LCP_POLTYPE_ANY – ignore all PolicyDataFiles
c. Eff.PolicyControl = (PO provisioned) ? PO.PolicyControl :
PS.PolicyControl
Note: Only PolicyControl.NPW_OK and
PolicyControl.OsSinitData_Capabilities bits are subject of this
combining. Other bits are used in each of the PO and PS indices
separately.
d. Eff.LcpHashAlgMask = (PO provisioned) ? PO.LcpHashAlgMask:
PS.LcpHashAlgMask
e. Eff.LcpSignAlgMask = (PO provisioned) ? PO.LcpSignAlgMask:
PS.LcpSignAlgMask
K.2.2 Handling of Ignore_PS_EltType Bits
Policy enforcement depends on the value of Ignore_PS_EltType bits location of which
can vary – see 3.4.2. The following flow suggests handling of these bits in new as well
as legacy location.
1 Allocate variable holding values of Ignore_PS_EltType bits
2 During either Policy validation scan of PO Policy Data File or policy
enforcement scan, perform the following per each of the element types:
Var.Ignore_PS_EltType |= Elt.Ignore_PS_EltType. After end of scan
Var.Ignore_PS_EltType will reflect state of the ignore bit if it was asserted in
any of the processed elements.
3 Conditionally copy content of PO.Ignore_PS_EltType bits over
Var.Ignore_PS_EltType bits:
a (If TPM 1.2 mode and PO.Version == 2.3) or (TPM 2.0 mode and
PO.Version == 3.1)
copy PO.Ignore_PS_EltType bits over Var.Ignore_PS_EltType bits
b Use Var.Ignore_PS_EltType bits for processing decision.
4 Now Var.Ignore_PS_EltType bits can be used always.
Detailed LCP Checklists
160 315168-013
The flows that follow below will use Var.Ignore_PS_EltType bits as an aggregated
source of Ignore_PS_EltType bit values.
K.2.3 Policy type handling by SINIT and BIOSAC
1. For SINIT module: if Eff.PolicyType (see K.2.1) equals to LCP_POLTYPE_ANY,
allow any platform configuration and any MLE and STM to run. Exit policy
enforcement logic.
2. For BIOSAC module: If PS.PolicyType equals to LCP_POLTYPE_ANY FIT record
type 9 is not required and is ignored if exists. BIOSAC startup function will use
auto-promotion to validate BIOS hash.
K.2.4 MLE Element Enforcement
1. Start of MLE element scan. Process lists and elements in the lists in the order
of appearance. Look for MLE elements. Skip all other element types.
a. TPM 1.2: Scan all V2 and V3 style lists looking for V2 style MLE
elements.
b. TPM 2.0: Scan V3 style lists only looking for V3 style MLE elements.
i. If list is signed and List.SignatureAlgorithm is not permitted by
Eff.LcpSignAlgMask, skip the list.
2. Select PO Policy Data File if exists.
a. Start of PO matching loop.
b. For every MLE type element found do the following:
i. TPM 2.0: Check HashAlgorithm field against
Eff.LcpHashAlgMask value. If not permitted by a mask skip
element.
ii. Record MLE_MATCH_REQUIRED flag;
iii. Try to match element:
1. Scan through all digests in element digest array
comparing digest with computed MLE digest. It is
assumed that MLE digest has been calculated before
LCP execution flow.
2. If match is found
a. Check the value of Elt.SINITMinVersion field. It
must be not greater than value of AcmVersion
field in Table A-. If greater abort with error –
SINIT is revoked.
b. Check PolicyElementControl.STM_is_required
bit of matching element. If asserted but
previous execution has not found STM present,
exit with error.
c. MLE policy is satisfied - continue to the next
element type.
Detailed LCP Checklists
315168-013 161
3. If match is not found yet – continue to the “Start of PO
matching loop”.
c. End of PO matching loop.
d. Match is not found in the PO Policy Data File.
i. If Var.Ignore_PS_MLE bit is asserted (scanning of PS Policy
Data File for MLE elements is prohibited) – go to the “End of
MLE Element Scan”
ii. Otherwise proceed to the “Select PS Policy Data File”
3. Select PS Policy Data File if exists.
4. If PO Policy Data File doesn’t exist and was not processed
a. MLE policy is satisfied - continue to the next element type.
5. If PO Policy Data File exists and was processed
a. Start of PS matching loop
b. Repeat all steps 2-a : 2-c above performed for PO Policy Data File.
i. If match was found, MLE policy is satisfied – continue to the
next element type.
c. End of PS matching loop.
d. Match was not found in PS Policy Data File – go to the “End of MLE
element scan”.
6. End of MLE element scan.
7. If this point is reached – no match was found.
a. If MLE_MATCH_REQUIRED_FLAG is asserted – exit with error.
b. MLE_MATCH_REQUIRED_FLAG is de-asserted, MLE policy is satisfied –
continue to the next element type.
K.2.5 PCONF Element Enforcement
1. Start of PCONF element scan. Process lists and elements in the lists in the
order of appearance. Look for PCONF elements. Skip all other element types.
a. TPM 1.2: Scan all V2 and V3 style lists looking for V2 style PCONF
elements.
b. TPM 2.0: Scan V3 style lists only looking for V3 style PCONF elements.
i. If list is signed and List.SignatureAlgorithm is not permitted by
Eff.LcpSignAlgMask, skip the list.
2. Select PO Policy Data File if exists.
a. Start of PO matching loop.
b. For every PCONF type element found do the following:
i. TPM 2.0: Check HashAlgorithm field against
Eff.LcpHashAlgMask value. If not permitted by a mask skip
element.
Detailed LCP Checklists
162 315168-013
ii. Record PCONF_MATCH_REQUIRED_FLAG;
iii. Try to match element.
1. Scan through all PCRInfo structures in element array,
query PCRs according to PCR Selection structure and
compute relevant Composite Digest of selected PCR
values.
2. Then compare this digest to value stored in element’s
PCRInfo structure.
3. If match is found – record this fact and go to the “End
of PO matching loop”.
4. If match is not found yet – continue to the “Start of PO
matching loop”
c. End of PO matching loop
i. TPM 1.2: If match is found, PCONF policy is satisfied –
continue to the next element type.
ii. TPM 2.0: If both Var.Ignore_PS_PCONF and
PO.PolicyControl.PsPconfEnforced bits are asserted, this
setting is controversial – exit with error.
iii. TPM 2.0: If match is found and
PO.PolicyControl.PsPconfEnforced bit is de-asserted, PCONF
policy is satisfied – continue to the next element type.
iv. TPM 2.0: If match is found and
PO.PolicyControl.PsPconfEnforced bit is asserted then proceed
to scan of PS Policy Data File.
v. If match is not found and Var.Ignore_PS_PCONF bit is
asserted, scanning of PS Policy Data File for PCONF elements
is prohibited – go to the “End of PCONF element scan”
vi. Otherwise proceed to the “Select PS Policy Data File”.
3. Select PS Policy Data File if exists.
a. Start of PS matching loop
b. Repeat all steps 2-a : 2-c above performed for PO Policy Data File.
i. TPM 1.2: If match is found, PCONF policy is satisfied –
continue to the next element type.
ii. TPM 2.0: During scan: If PCONF element found and
PO.PolicyControl.PsPconfEnforced bit is asserted – record this
as PS_PCONF_MATCH_REQUIRED_FLAG because in this case
PCONF elements in PS Policy Data File must be tracked
independently
iii. TPM2.0: Otherwise If PCONF element found and
PO.PolicyControl.PsPconfEnforced bit is de-asserted continue
using PCONF_MATCH_REQUIRED_FLAG.
iv. TPM 2.0: If match is found and
PO.PolicyControl.PsPconfEnforced bit is de-asserted, PCONF
policy is satisfied – continue to the next element type.
Detailed LCP Checklists
315168-013 163
v. TPM 2.0: If match is found and
PO.PolicyControl.PsPconfEnforced bit is asserted – record this
fact and go to the “End of PCONF element scan”.
c. Match was not found during scan of PS Policy Data File – go to the
“End of PCONF element scan”.
4. End of PCONF element scan.
5. TPM 1.2: If this point is reached – no match was found.
a. If PCONF_MATCH_REQUIRED_FLAG is asserted - exit with error
b. If PCONF_MATCH_REQUIRED_FLAG is de-asserted, PCONF policy is
satisfied – continue to the next element type.
6. TPM 2.0: If this point is reached and PO.PolicyControl.PsPconfEnforced bit is
de-asserted – no match was found
a. If PCONF_MATCH_REQUIRED_FLAG is asserted – exit with error
b. If PCONF_MATCH_REQUIRED_FLAG is de-asserted, PCONF policy is
satisfied – continue to the next element type.
7. TPM 2.0: If this point is reached, PO.PolicyControl.PsPconfEnforced bit is
asserted.
a. If PCONF_MATCH_REQUIRED_FLAG is asserted and no match was
found in PO file – exit with error.
b. If PS_PCONF_MATCH_REQUIRED_FLAG is asserted and no match was
found in PS file – exit with error.
c. PCONF policy is satisfied – continue to next element type.
K.2.6 BIOSAC SBIOS Element Enforcement
SBIOS element is recognized and used in PS Policy Data File only. If present in PO
Policy Data File SBIOS element is ignored.
1. Compute Current BIOS digest using FIT Type 7 records and save it in a
temporary location TempCurrentBiosHash.
Note that auto-promotion digest value stored in AUX index at this point
contains BIOS hash of previous boot cycle.
a. TPM 1.2: TempCurrentBiosHash is a set of TXT lockable registers
temporarily holding BIOS digest.
b. TPM 2.0: TempCurrentBiosHash is a CRAM variable allocated by a
Startup function.
2. If TXT.ESTS “secrets” bit is de-asserted – there is no need to validate BIOS.
Exit SBIOS matching flow.
3. TXT.ESTS “secrets” bit is asserted:
a. If PS.PolicyType is ANY – verify BIOS using auto-promotion (see “LT-
SX BIOS Writer’s Guide” for complete flow description). Type 9 record
in this case may not exist and is ignored if exists.
i. For this purpose compare TempCurrentBiosHash to auto-
promotion digest value.
Detailed LCP Checklists
164 315168-013
ii. If match is found – SBIOS policy is satisfied. Unlock memory
and exit SBIOS matching flow.
iii. If no match found – keep memory locked and exit SBIOS
matching flow.
b. If PS.PolicyType is LIST type 9 record must exist and point to PS Policy
Data File.
i. If type 9 record doesn’t exist – keep memory locked and exit
SBIOS matching flow.
c. Start SBIOS element scan. Process lists and elements in the lists in
the order of appearance. Look for SBIOS elements. Skip all other
element types.
i. TPM 1.2: Scan all V2 and V3 style lists looking for V2 style
SBIOS elements.
ii. TPM 2.0: Scan V3 style lists only looking for V3 style SBIOS
elements.
1. If list is signed and List.SignatureAlgorithm is not
permitted by PS.LcpSignAlgMask, skip the list.
d. Start of PS matching loop
e. For every SBIOS type element found do the following:
i. TPM 2.0: Check HashAlgorithm field against
PS.LcpHashAlgMask value. If not permitted by a mask skip
element.
ii. Record SBIOS_PRESENT_FLAG.
iii. Try to match element.
1. Compare Current BIOS digest saved in
TempCurrentBiosHash to values stored in the
Elt.Hashes array and Elt.FallbackHash field of SBIOS
element.
2. If match is found, SBIOS policy is satisfied - unlock
memory and exit SBIOS matching flow.
3. If match is not found check Elt.NumberOfHashes
value. If positive, assert
SBIOS_MATCH_REQUIRED_FLAG.
4. If match is not found yet – continue to the “Start of
PS matching loop”
f. End of PS matching loop.
g. Match is not found in PS Policy Data File
h. If SBIOS_PRESENT_FLAG is de-asserted, no SBIOS elements were
found - validate BIOS using auto-promotion.
i. For this purpose compare TempCurrentBiosHash to auto-
promotion digest value.
ii. If match is found – SBIOS policy is satisfied. Unlock memory
and exit SBIOS matching flow.
Detailed LCP Checklists
315168-013 165
iii. If no match found – keep memory locked and exit SBIOS
matching flow.
i. If SBIOS_MATCH_REQUIRED_FLAG is asserted, SBIOS elements were
found with positive Elt.NumberOfHashes value requiring strong match
but no match was found. Keep memory locked and exit SBIOS
matching flow.
j. If SBIOS_PRESENT_FLAG is asserted and
SBIOS_MATCH_REQUIRED_FLAG is de-asserted all found SBIOS
elements had Elt.NumberOfHashes value equal zero - validate BIOS
using auto-promotion digest value.
i. For this purpose compare TempCurrentBiosHash to auto-
promotion digest value.
ii. If match is found – SBIOS policy is satisfied. Unlock memory
and exit SBIOS matching flow.
iii. If no match – keep memory locked and exit SBIOS matching
flow.
K.2.7 SINIT SBIOS Element Enforcement
1. Start SBIOS element scan. Process lists and elements in the lists in the order of
appearance. Look for SBIOS elements. Skip all other element types.
a. TPM 1.2: Scan all V2 and V3 style lists looking for V2 style SBIOS
elements.
b. TPM 2.0: Scan V3 style lists only looking for V3 style SBIOS elements.
i. If list is signed and List.SignatureAlgorithm is not permitted
by PS.LcpSignAlgMask, skip the list.
2. Select PS Policy Data File if exists.
a. Start of PS matching loop.
b. For every SBIOS type element found do the following:
i. TPM 2.0: Check HashAlgorithm field against PS.LcpHashAlgMask
value. If not permitted by a mask skip element.
ii. Record SBIOS_PRESENT_FLAG;
iii. Try to match element
a. Compare Current BIOS digest saved in auto-promotion
candidate filed of AUX index to values stored in the
Elt.Hashes array and Elt.FallbackHash field of SBIOS
element.
b. If match is found, SBIOS policy is satisfied – continue to
the next element type.
c. If match is not found check Elt.NumberOfHashes value. If
positive, assert SBIOS_MATCH_REQUIRED_FLAG.
d. If match is not found yet – continue to the “Start of PS
matching loop”
3. End of PO matching loop.
Detailed LCP Checklists
166 315168-013
4. Match is not found in the PS Policy Data File
a. If SBIOS_PRESENT _FLAG is de-asserted, no elements were found and
SBIOS policy is satisfied – continue to the next element type.
b. If SBIOS_MATCH_REQUIRED_FLAG is asserted, SBIOS elements were
found with positive Elt.NumberOfHashes value requiring strong match –
exit with error.
c. If SBIOS_PRESENT_FLAG is asserted and
SBIOS_MATCH_REQUIRED_FLAG is de-asserted all found SBIOS elements
had Elt.NumberOfHashes value equal zero, SBIOS policy is satisfied –
continue to the next element type.
K.2.8 STM Element Enforcement
1. If prior execution have not found STM in the system – (based on MSEG enable
status – see Table ) scan of STM elements is not performed. Only if matching
MLE element requires STM this will generate an error exit – see K.2.4.
2. Start of STM element scan. Process lists and elements in the lists in the order
of appearance. Look for STM elements. Skip all other element types.
c. TPM 1.2: Scan all V2 and V3 style lists looking for V2 style STM
elements.
d. TPM 2.0: Scan V3 style lists only looking for V3 style STM elements.
i. If list is signed and List.SignatureAlgorithm is not permitted by
Eff.LcpSignAlgMask, skip the list.
3. Select PO Policy Data File if exists.
a. Start of PO matching loop
b. For every STM type element found do the following:
i. TPM 2.0: Check HashAlgorithm field against
Eff.LcpHashAlgMask value. If not permitted by a mask skip
element.
ii. Record STM_MATCH_REQUIRED flag;
iii. Try to match element:
1. Scan through all digests in element digest array
comparing digest with computed STM digest. It is
assumed that STM digest has been calculated before
LCP execution flow.
2. If match is found, STM policy is satisfied – continue to
the next task. This is the last element type.
3. If match is not found yet – continue to the “Start of PO
matching loop”.
c. End of PO matching loop.
d. Match is not found in the PO Policy Data File
i. If Var.Ignore_PS_STM bit is asserted (scanning of PS Policy
Data File for STM elements is prohibited) – go to the End of
STM element scan”
Detailed LCP Checklists
315168-013 167
ii. Otherwise proceed to the “Select PS Policy Data File”.
4. Select PS Policy Data File if exists.
a. Start of PS matching loop.
b. Repeat all steps 3-a: 3-c above performed for PS Policy Data File.
i. If match was found, STM policy is satisfied – continue to the
next task. This is the last of element types.
c. End of PS matching loop.
d. Match was not found in PS Policy Data File – go to the “End of STM
element scan”.
5. End of STM element scan.
6. If this point is reached – no match was found.
a If STM_MATCH_REQUIRED_FLAG is asserted exit with error since no
match was found
b STM_MATCH_REQUIRED_FLAG is de-asserted and therefore no
elements were found. STM policy is satisfied – continue to the next
task. This is the last element type.
§ §

Navigation menu
