Package ‘jubilee’
September 1, 2018
Type Package
Title Forecast Long-Term Growth of the U.S. Stock Market
Version 0.2.3
Date 2018-09-01
Author Stephen H-T. Lihn [aut, cre]
Maintainer Stephen H-T. Lihn <stevelihn@gmail.com>
Description
A long-term forecast model called ``Jubilee-Tectonic model'' is implemented to forecast future re-
turns of the U.S. stock market, Treasury yield, and gold price. The five-factor model can fore-
cast the 10-year and 20-year future equity returns with high R-squared above 80 per-
cent. It is based on linear growth and mean reversion characteristics in the U.S. stock mar-
ket. In addition, this model enhances the CAPE model of Robert Shiller by introducing the hy-
pothesis that there are fault lines in the historical CAPE, which can be calibrated and cor-
rected through statistical learning.
URL https://ssrn.com/abstract=3156574
Depends R (>= 3.3.0)
Imports stats, yaml, utils, xts, zoo, splines, parallel, graphics,
methods, readxl, data.table, lmtest
Suggests knitr, R.rsp, testthat, roxygen2, scales, shape
VignetteBuilder R.rsp
License Artistic-2.0
Encoding UTF-8
LazyData true
RoxygenNote 6.1.0
Collate 'daily2fraction-method.R' 'fraction2daily-method.R'
'jubilee-adj-fault-line-method.R' 'jubilee-calc-cape-method.R'
'jubilee-package.R' 'jubilee-class.R' 'jubilee-constructor.R'
'jubilee-eqty-ols-method.R' 'jubilee-forward-rtn-method.R'
'jubilee-fred-data-method.R' 'jubilee-locate-file.R'
'jubilee-mcsapply-method.R' 'jubilee-ols-method.R'
'jubilee-predict-method.R' 'jubilee-read-fred-file.R'
'jubilee-repo-class.R' 'jubilee-repo-config.R'
'jubilee-repo-constructor.R' 'jubilee-std-fault-line-method.R'
'tri-wave-class.R' 'tri-wave-constructor.R' 'tri-wave-model.R'
NeedsCompilation no
1
2jubilee-package
Rtopics documented:
jubilee-package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
daily2fraction........................................ 3
fraction2daily........................................ 3
jubilee............................................ 4
jubilee-class......................................... 5
jubilee.adj_fault_line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
jubilee.calc_cape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
jubilee.eqty_ols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
jubilee.forward_rtn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
jubilee.fred_data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
jubilee.locate_file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
jubilee.mcsapply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
jubilee.ols.......................................... 10
jubilee.predict........................................ 11
jubilee.read_fred_file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
jubilee.repo ......................................... 13
jubilee.repo-class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
jubilee.repo.config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
jubilee.std_fault_line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
tri.wave ........................................... 15
tri.waveclass ........................................ 16
triangle ........................................... 16
Index 18
jubilee-package jubilee: A package to forecast long-term growth of the US stock mar-
ket.
Description
The jubilee package provides the core class and functions to forecast long-term growth of the U.S.
stock market. A tutorial is provided to demonstrate how to use this package and explain the relation
between the mathematical notations and the functions and data columns in this package.
Author(s)
Stephen H-T. Lihn
References
Stephen H.T. Lihn, "Jubilee Tectonic Model: Forecasting Long-Term Growth and Mean Rever-
sion in the U.S. Stock Market." Available at SSRN: https://ssrn.com/abstract=3156574 or DOI:
http://dx.doi.org/10.2139/ssrn.3156574
daily2fraction 3
daily2fraction Converter from daily Date to fraction
Description
Utility to convert from daily Date (R’s Date object) to fraction.
Usage
daily2fraction(d)
Arguments
darray of Date object, or string in ISO yyyy-mm-dd format
Value
numeric, year in fraction convention
Author(s)
Stephen H. Lihn
Examples
daily2fraction(as.Date("2017-01-15")) # 2017.038
daily2fraction(as.Date("2017-02-14")) # 2017.122
daily2fraction(as.Date("2017-07-15")) # 2017.538
fraction2daily Converter from fraction to daily Date
Description
Utility to convert from fraction to daily Date (R’s Date object).
Usage
fraction2daily(fraction)
Arguments
fraction numeric, representing year in fraction convention.
Value
array of Date object
Author(s)
Stephen H. Lihn
4jubilee
Examples
fraction2daily(2017.038) # 2017-01-15
fraction2daily(2017.125) # 2017-02-15
jubilee Constructor of the jubilee class
Description
Construct an jubilee object which holds raw and derived data, channel regression results, and other
derived analytical quantities. This object is the main object to perform various forecasts and analy-
ses.
Usage
jubilee(dtb, lookback.channel = 45, fwd.rtn.duration = 20)
Arguments
dtb data.table from the jubilee.repo object, typically it is the ie slot. The user is
allowed to provide custom data object to research different markets, as long as
the column names are compliant.
lookback.channel
numeric, look-back channel in years to calculate mean-reversion. Default is 45.
fwd.rtn.duration
numeric, forward return duration in years. Default is 20.
Value
an object of the jubilee class
Author(s)
Stephen H. Lihn
Examples
## Not run:
repo <- jubilee.repo(online=FALSE)
ju <- jubilee(repo@ie, 45, 20)
## End(Not run)
jubilee-class 5
jubilee-class The jubilee class
Description
This S4 class stores raw and derived data, channel regression settings and results.
Slots
call the match.call slot.
lookback.channel numeric, the look-back channel in years.
fwd.rtn.duration numeric, the forward return duration in years.
reg.dtb data.table, contains the regression data.
dtb data.table, contains the consolidated market data.
rate.spread.mean numeric, the mean of the yield spread, used to calculate rate.spread.norm
column.
create.time POSIXct, records the creation time of this object.
jubilee.adj_fault_line
Adjust the time series by fault lines
Description
This utility is used to adjust the time series by the provided fault lines.
Usage
jubilee.adj_fault_line(fraction, ts, fl, months = 1)
Arguments
fraction numeric, representing year in fraction convention.
ts numeric, time series to be adjusted, typically it is log.cape10 or log.cape20.
fl the fault line matrix. See jubilee.std_fault_line() for more detail. If it is
provided as character string, it will be looked up as the name of data set in the
standard fault line library. If it is provided as numeric array, it will be converted
to a matrix.
months interval in months to ramp up the fault line. Default is 1.
Value
numeric, ts adjusted by fault lines
Author(s)
Stephen H. Lihn
6jubilee.calc_cape
Examples
## Not run:
repo <- jubilee.repo(online=FALSE)
dj <- jubilee(repo@ie, 45, 10)@reg.dtb
dj$log.cape10.adj <- jubilee.adj_fault_line(dj$fraction, dj$log.cape10, "r_nom_f10_5ftr_4fl")
## End(Not run)
jubilee.calc_cape Internal utility to calculate n-year CAPE
Description
This CAPE calculator replicates the methodology of Shiller, so that one can calculate n-year CAPE,
e.g. n=20. This utility has been calibrated by original 10-year CAPE data from Shiller.
Usage
jubilee.calc_cape(dtb, period, tol.frac = 1/6)
Arguments
dtb data.table
period numeric, the backward-looking regression period
tol.frac numeric, tolerance of missing data in the beginning of the time series, expressed
as fraction. Default is 1/6, that is, two months.
Value
numeric, the same length as dtb$fraction.
Author(s)
Stephen H. Lihn
Examples
## Not run:
dtb <- jubilee.repo(online=FALSE)@ie
cape10 <- jubilee.calc_cape(dtb, 10)
cape20 <- jubilee.calc_cape(dtb, 20)
## End(Not run)
jubilee.eqty_ols 7
jubilee.eqty_ols Internal utility to calculate OLS regression for log total return index
Description
Calculate the OLS regression for log total return index
Usage
jubilee.eqty_ols(dtb, end.frac, lookback.channel, tol.frac = 1/6)
Arguments
dtb data.table that contains fraction and log.tri columns.
end.frac numeric, the ending fraction of regression.
lookback.channel
numeric, the backward-looking regression period
tol.frac numeric, tolerance of missing data in the beginning, expressed as fraction. De-
fault is 1/6, that is, two months.
Value
two-element array c(a,R) if end.frac is length-one; data.table with end.frac as fraction column
if end.frac is an array.
Author(s)
Stephen H. Lihn
Examples
## Not run:
dtb <- jubilee.repo(online=FALSE)@ie
jubilee.eqty_ols(dtb, 1970, 50) # c(11.8671626, 0.1008371)
## End(Not run)
jubilee.forward_rtn Internal utility to calculate annualized forward and backward return
Description
Calculate the annualized forward and backward return on the given time series. The forward return
is typically the response variable in a forecast. The backward return is often used as explanatory
variable in a regression.
Usage
jubilee.forward_rtn(fraction, ts, fwd.rtn.duration, tol.frac = 1/12)
jubilee.backward_rtn(fraction, ts, bwd.rtn.duration, tol.frac = 1/12)
8jubilee.fred_data
Arguments
fraction numeric, the ending fraction of regression
ts numeric, the time series data
fwd.rtn.duration
numeric, the forward-looking regression period
tol.frac numeric, tolerance of missing data in the beginning, expressed as fraction. De-
fault is 1/12, that is, one month.
bwd.rtn.duration
numeric, the backward-looking regression period
Value
numeric, the same length as fraction
Author(s)
Stephen H. Lihn
Examples
## Not run:
dtb <- jubilee.repo(online=FALSE)@ie
dtb$fwd.rtn.10 <- jubilee.forward_rtn(dtb$fraction, dtb$log.tri, 10)
dtb$bwd.rtn.10 <- jubilee.backward_rtn(dtb$fraction, dtb$log.tri, 10)
head(subset(dtb, fraction >= 1990),1)$fwd.rtn.10 # 1/1990+10y: 0.16745
tail(subset(dtb, fraction <= 2000+1/12),1)$bwd.rtn.10 # the same as above
## End(Not run)
jubilee.fred_data Internal utility to download time series data from FRED
Description
This utility downloads time series from FRED. Many time series that this package uses are available
on FRED. Therefore, this utility is used to provide daily or monthly updates by concatenating live
data to the internal static data.
Usage
jubilee.fred_data(symbol, col_out = "Close")
Arguments
symbol character, the name of the time series
col_out character, the name of the output closing price column. Default is "Close"
Value
The xts object for the time series
jubilee.locate_file 9
Examples
## Not run:
jubilee.fred_data("VIXCLS") # VIX
## End(Not run)
jubilee.locate_file Internal utility to locate static file
Description
This utility returns the path to internal file
Usage
jubilee.locate_file(local_file, stop = TRUE)
Arguments
local_file character, the file name of an internal file.
stop logical, whether to stop if file can’t be located. Default is TRUE.
Value
The path to the file, or else, an empty string
Author(s)
Stephen H. Lihn
Examples
jubilee.locate_file("UNRATE.csv")
jubilee.mcsapply Wrapper to calculate sapply using multi-core
Description
This utility calculates sapply using multi-core capability. It is a simple wrapper on simplify2array
and parallel::mclapply. It is particularly convenient on Linux and Mac when parallelism saves
significant amount of computing time.
Usage
jubilee.mcsapply(x, FUN, ...)
10 jubilee.ols
Arguments
xnumeric
FUN the function to be applied to each element of x
... optional arguments to FUN
Value
numeric
Author(s)
Stephen H. Lihn
Examples
a <- seq(1,100)
jubilee.mcsapply(a, function(x) x^2) # use multi-core!
jubilee.ols Internal utility to calculate OLS regression
Description
Calculate the OLS regression for a given time series and fraction
Usage
jubilee.ols(fraction, ts, lookback.channel, tol.frac = 1/6)
Arguments
fraction numeric, the ending fraction of regression
ts numeric, the time series data
lookback.channel
numeric, the backward-looking regression period
tol.frac numeric, tolerance of missing data in the beginning, expressed as fraction. De-
fault is 1/6, that is, two months.
Value
data.table with columns of fraction, lm.a, lm.y, lm.r
Author(s)
Stephen H. Lihn
References
See Section 2.3 of Stephen H.T. Lihn, "Jubilee Tectonic Model: Forecasting Long-Term Growth and
Mean Reversion in the U.S. Stock Market." Available at SSRN: https://ssrn.com/abstract=3156574
or http://dx.doi.org/10.2139/ssrn.3156574
jubilee.predict 11
Examples
## Not run:
dtb <- jubilee.repo(online=FALSE)@ie
df <- jubilee.ols(dtb$fraction, dtb$log.tri, 50)
subset(df, fraction > 1970 & fraction < 1970.05)
# fraction lm.a lm.r lm.y
# 1970.042 11.86401 0.1007617 0.02103105
## End(Not run)
jubilee.predict Make prediction based on linear regression
Description
Make prediction based on the linear regression of the forward return. Refer to the tutorial for more
detail.
Usage
jubilee.predict(object, lm, data)
jubilee.predict_real(object, lm, data)
Arguments
object object of jubilee class
lm the linear model
data data used to predict (similar to newdata of stats::predict)
Value
data.table containing the prediction
Author(s)
Stephen H. Lihn
References
See Section 7 of Stephen H.T. Lihn, "Jubilee Tectonic Model: Forecasting Long-Term Growth and
Mean Reversion in the U.S. Stock Market." Available at SSRN: https://ssrn.com/abstract=3156574
or http://dx.doi.org/10.2139/ssrn.3156574
12 jubilee.read_fred_file
jubilee.read_fred_file
Internal utility to read FRED file
Description
This utility reads the internal static file, optionally amends with FRED online data, and returns the
values of a given symbol.
Usage
jubilee.read_fred_file(fraction, local_file, symbol, online = FALSE,
daily_symbol = NULL)
Arguments
fraction numeric, the fraction to return the value. The utility will lookup within a month
to find value. For debug purpose, set it to NULL, and the intermediate data table
will be returned.
local_file character, the file name of an internal file. For debug purpose, set it to NULL,
and the process will initiate the source data from FRED via symbol, instead of
a local file.
symbol character, the FRED symbol.
online logical, whether to fetch online data from FRED. Default is FALSE.
daily_symbol character, the FRED symbol to read daily data that supplements the monthly
data. Default is NULL.
Value
The values of the symbol, numeric with the same length as fraction.
Author(s)
Stephen H. Lihn
Examples
repo <- jubilee.repo(online=FALSE)
a <- jubilee.read_fred_file(repo@ie$fraction, "BAA.csv", "BAA")
tail(a)
jubilee.repo 13
jubilee.repo Constructor of jubilee.repo class
Description
Construct a jubilee.repo class by combining data from that of Robert Shiller since 1871, his-
torical stock market data from 1802 to 1987 by William Schwert, 3-month Treasury bill rate, gold
price, and several other economic time series from FRED. Optionally, this function can fetch more
recent data from the website of Robert Shiller and Federal Reserve FRED website if the R session
has connection to the internet.
Usage
jubilee.repo(online = TRUE)
Arguments
online logical, indicating whether to fetch data from online resource or not. Default is
TRUE.
Value
An object of jubilee.repo class
Author(s)
Stephen H. Lihn
Examples
repo <- jubilee.repo(online=FALSE)
dtb <- repo@ie
tail(dtb,1)
jubilee.repo-class The jubilee repository class
Description
This S4 class stores the raw data for the jubilee package
Slots
call The match.call slot
ie data.table, contains the combined data from ie.raw,ws, and inflation.
yield.inversion numeric, the fractions of yield curve inversion
raw.ie data.table, contains the data from ie_data.xls of Robert Shiller
ws data.table, contains the historical market return data from William Schwert
14 jubilee.std_fault_line
inflation data.table, contains the historical inflation data from Minneapolis FED
comm.int data.table, contains the historical commercial interest rate
tb3ms data.table, contains the historical 3-month Treasury bill rate
gold data.table, contains the historical monthly gold prices
gold2 data.table, contains the historical annual gold prices
create.time POSIXct, records the creation time of this object.
jubilee.repo.config Configuration of jubilee’s data repository
Description
This utility stores the data configuration for the jubilee’s data repository. This is used internally
to provide proper abstraction to the data sources, such as file name, URL, FRED symbol, column
name, decimal format, etc.
Usage
jubilee.repo.config()
Value
The list of data elements and their attributes.
Author(s)
Stephen H. Lihn
Examples
c <- jubilee.repo.config()
c$ie$url
jubilee.std_fault_line
Standard fault line data sets
Description
This method defines a collection of standard fault line data sets that have been analyzed and opti-
mized in the research. It is intended for end users to produce standard regressions, forecasts, and
charts quickly.
Usage
jubilee.std_fault_line(name)
tri.wave 15
Arguments
name character, the name of the collection. If "list" is supplied, the list of names will
be returned. If a numeric array is supplied, it will be converted to a matrix
format.
Value
numeric, pairs of fault lines, each is c(year, delta)
Author(s)
Stephen H. Lihn
Examples
jubilee.std_fault_line("r_nom_f10_5ftr_4fl")
jubilee.std_fault_line("r_nom_f20_5ftr_2fl")
jubilee.std_fault_line("r_nom_f20_5ftr_2fl_ramp5y")
tri.wave Constructor of tri.wave class
Description
Construct an tri.wave object to simulate the triangular wave model.
Usage
tri.wave()
Value
an object of tri.wave class
Author(s)
Stephen H. Lihn
Examples
w <- tri.wave()
16 triangle
tri.wave class The triangular wave model class
Description
This S4 class defines the parameters in the triangular wave model.
Slots
call the match.call slot.
a.t numeric, the look-back channel in years
a0 numeric, the look-back channel in years
s1 numeric, the forward return duration in years
s2 numeric, the start fraction of in-sample training period
y.mean numeric, the end fraction of in-sample training period
y.amp numeric, the end fraction of in-sample training period
y.t numeric, the end fraction of in-sample training period
y.p numeric, the end fraction of in-sample training period
References
See Section 4 of Stephen H.T. Lihn, "Jubilee Tectonic Model: Forecasting Long-Term Growth and
Mean Reversion in the U.S. Stock Market." Available at SSRN: https://ssrn.com/abstract=3156574
or http://dx.doi.org/10.2139/ssrn.3156574
triangle Methods of triangular wave model
Description
Methods of triangular wave model
Usage
triangle(t, p)
tri.wave.s(object, t)
tri.wave.a(object, t)
tri.wave.y(object, t)
tri.wave.x(object, t)
tri.wave.logr.y(object, t, p)
tri.wave.logr(object, t, p)
triangle 17
tri.wave.logr.semi(object, t)
tri.wave.logr.quarter(object, t)
Arguments
tthe time vector in fraction
pthe period of the triangle wave
object the object of tri.wave class
Value
numeric
Author(s)
Stephen H. Lihn
References
See Section 4 of Stephen H.T. Lihn, "Jubilee Tectonic Model: Forecasting Long-Term Growth and
Mean Reversion in the U.S. Stock Market." Available at SSRN: https://ssrn.com/abstract=3156574
or http://dx.doi.org/10.2139/ssrn.3156574
Examples
w <- tri.wave()
t <- seq(1900, 2000, by=1)
tri.wave.y(w, t)
Index
∗Topic class
jubilee-class,5
jubilee.repo-class,13
tri.wave class,16
∗Topic constructor
jubilee,4
jubilee.repo,13
tri.wave,15
∗Topic data
jubilee.fred_data,8
jubilee.locate_file,9
jubilee.read_fred_file,12
jubilee.repo.config,14
∗Topic model
jubilee.adj_fault_line,5
jubilee.predict,11
jubilee.std_fault_line,14
triangle,16
∗Topic utility
daily2fraction,3
fraction2daily,3
jubilee.calc_cape,6
jubilee.eqty_ols,7
jubilee.forward_rtn,7
jubilee.mcsapply,9
jubilee.ols,10
daily2fraction,3
fraction2daily,3
jubilee,4
jubilee-class,5
jubilee-package,2
jubilee.adj_fault_line,5
jubilee.backward_rtn
(jubilee.forward_rtn),7
jubilee.calc_cape,6
jubilee.eqty_ols,7
jubilee.forward_rtn,7
jubilee.fred_data,8
jubilee.locate_file,9
jubilee.mcsapply,9
jubilee.ols,10
jubilee.predict,11
jubilee.predict_real (jubilee.predict),
11
jubilee.read_fred_file,12
jubilee.repo,13
jubilee.repo-class,13
jubilee.repo.config,14
jubilee.std_fault_line,14
tri.wave,15
tri.wave class,16
tri.wave.a (triangle),16
tri.wave.logr (triangle),16
tri.wave.s (triangle),16
tri.wave.x (triangle),16
tri.wave.y (triangle),16
triangle,16
18

Navigation menu
