KSM141 Dual-pattern End-Address Condenser Microphone
KSM141
Overview
Features
Specifications
The Shure KSM141 is a small diaphragm end-addressed condenser microphone with a rotating collar allowing easy switching between a highly
consistent cardioid or true omnidirectional polar pattern for smooth and extremely focused sound reproduction. Designed for studio use, yet rugged
enough for live applications, the KSM141 can withstand extremely high sound pressure levels (SPL). Its low self-noise and extended frequency
response make it ideal for recording musical instruments. Versatile, durable, and precise, the KSM141 is an outstanding microphone for both live and
studio applications.
• A mechanical polar pattern switch for highly consistent cardioid and true omnidirectional polar patterns. Provides flexibility in a wide variety of
recording applications.
• Ultra-thin, 2.5 μm 24 karat gold-layered, low mass Mylar® diaphragm for superior transient response.
• Class A, discrete, transformerless preamplifier for transparency, extremely fast transient response, no crossover distortion, and minimal harmonic
and intermodulation distortion.
• Premium electronic components, including gold-plated internal and external connectors.
• Subsonic filter eliminates low-frequency rumble (less than 17 Hz) caused by mechanical vibration.
• Three-position switchable pad (0 dB, 15 dB, and 25 dB) for handling extremely high sound pressure levels (SPLs).
• Three-position switchable low-frequency filter reduces background noise and counteracts proximity effect.
Available Models
Product Specifications
www.shure.com ©2015 Shure Incorporated
KSM141/SL Includes Stand Adapter, Windscreen, and Carrying Case
KSM141/SL STEREO Includes two KSM141, two Stand Adapters, two Windscreens, A27M Stereo Microphone Adapter and Carrying Case
Cartridge Type Electret Condenser
Frequency Response 20 to 20,000 Hz
Output Impedance 150 ohms (actual)
Power Requirements 48 Vdc phantom, 4.7 mA
Common Mode Rejection >50 dB, 50 Hz to 20 kHz
Polarity Positive pressure on front diaphragm produces positive voltage on output pin 2 relative to pin 3
Polar Patterns Cardioid, Omnidirectional
Sensitivity
(typical; at 1000 Hz;
1 Pa = 94 dB SPL)
-37 dBV/Pa
Self-noise
(typical, equivalent SPL;
A-weighted, IEC 651)
14 dB
Maximum SPL @ 1000 Hz
5000 ohms load
2500 ohms load
1000 ohms load
134 dB (159 dB, -25 Pad)
139 dB (164 dB, -25 Pad)
134 dB (159 dB, -25 Pad)
Output Clipping Level
5000 ohms load
2500 ohms load
1000 ohms load
15 dBV
9 dBV
3 dBV
Dynamic Range
5000 ohms load
2500 ohms load
1000 ohms load
131 dB
125 dB
120 dB
Signal to Noise ratio 80 dB
Weight Net: 156 g (5.5 oz.)
Switch Attenuator: 0, −15, −25 dB
Low Frequency Response: flat; -6 dB/octave below 115 Hz; -18 dB/octave below 80 Hz
Furnished Accessories
Omnidirectional
Cardioid
A100G Case A100WS Windscreen
A27M Stereo Microphone Adapter A57F Stand Adapter
150°
120°
150°
120°
180°
30°
0°
60°
90°
30°
60°
90°
–10 dB
–20 dB
–15 dB
–5 dB
+5 dB
15 cm
60 cm
60 cm
Polar Pattern Frequency Response
