User Guide

Peter Mills

peteymills@hotmail.com

October 5, 2018

CONTENTS

1 INSTALLATION 3

2 FILE FORMATS 4

3 COMMAND PARAMETERS 8

4 COMMAND LINE EXECUTABLES 12

4.1 Direct routines . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.2 Binary classiﬁcation . . . . . . . . . . . . . . . . . . . . . . . . 12

4.3 Multi-class classiﬁcation . . . . . . . . . . . . . . . . . . . . . 13

4.4 Testing/validation . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.5 Clustering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.6 Experimental . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.7 Pre-/post-processing . . . . . . . . . . . . . . . . . . . . . . . 14

4.8 File conversion . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.9 Commands used by other commands . . . . . . . . . . . . . . 15

4.10 Deprecated . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5 ERROR CODES AND DIAGNOSTICS 16

6 MULTI-BORDERS CLASSIFICATION 18

6.1 Multi-borders classiﬁcation the easy way . . . . . . . . . . . . 18

6.2 Multi-borders classiﬁcation the hard way . . . . . . . . . . . . 19

6.3 Multi-borders with external binary classiﬁers . . . . . . . . . . 21

7 EXAMPLES 26

7.1 examples/class borders . . . . . . . . . . . . . . . . . . . . . . 26

7.2 examples/humidity data . . . . . . . . . . . . . . . . . . . . . 26

7.3 examples/Landsat . . . . . . . . . . . . . . . . . . . . . . . . . 27

BIBLIOGRAPHY 27

1 INSTALLATION

First, make sure you have the required dependencies. You will need the

GNU Scientiﬁc Library (GSL). If it is not already installed on your system,

download and install it. Take note of the location of the compiled libraries

and include ﬁles. You will also need to install libpetey, another, much smaller

numerical library–this now comes bundled with libAGF.

Download the source from Github (https://github/peteysoft/libmsci)

or your favourite mirror. Unzip and unpack the tarball to the desired direc-

tory. Modify the makeﬁle with the appropriate directories, compiler names

and compiler ﬂags. Type make from inside the libagf directory to perform

the build and make install to copy the executables, libraries and include

ﬁles to the appropriate directories.

A conﬁgure script is not supplied: please refer to the Peteysoft coding

standards coding_standards.txt in the base of the installation directory

(https://github.com/peteysoft/libmsci/blob/master/doc/coding_standards.

txt).

Make sure the following macros have been set properly in the make ﬁle:

LIB_PATH = location of your compiled libraries

BIN_PATH = location of binary executables

INCLUDE_PATH = location of your include ﬁles

GSL_LIB = location of the GSL libraries (if diﬀerent from above)

GSL_INCLUDE = location of the GSL include ﬁles (if diﬀerent from above)

CC = name of your C++ compiler

There are two ways to change the optimisation of the binaries. If you

would like multiple versions with diﬀerent levels of optimisation, be sure to

change the OPT VER macro. This will append the optimisation ﬂag to all

the object ﬁles, libraries and executables. If you only want one version, then

modify the CFLAGS macro in the usual manner.

To test the resulting executables, type, make test. To see the resulting

comparison summary, it may be necessary to type it twice. Overall accuracies

of all the classiﬁcation algorithms should be around 90 % and the uncertainty

coeﬃcients should be over 0.5, while the conﬁdence ratings should roughly

match the accuracies. When comparing one algorithm to another, accuracies

should be around 99% and uncertainty coeﬃcients around 0.92, while the

conﬁdence ratings should be 1. or close to it, regardless of accuracy. Prob-

ability density comparisons should be around r={0.98,0.99,0.97,0.99}for

KNN and AGF for the ﬁrst class and KNN and AGF for the second class,

respectively.

2 FILE FORMATS

The programs accept three types of ﬁles with very simple, binary formats.

Although portability is sometimes an issue, the binary formats are easy to

generate and allow for rapid access and compact storage. For vector data,

use the extension, .vec. Vector ﬁles have a four byte header (by default, see

next paragraph) that indicates the dimensionality of the data. After that,

each vector is stored one after the other as arrays of four byte ﬂoats. To

write such a ﬁle in C++, you can use the following commands:

#include <stdio.h>

#include <stdint.h>

int main() {

FILE *fs;

float ** data; //array of vectors

int32_t n; //number of vectors

int32_t D; //number of dimensions

n=100; //(e.g.)

D=2;

data=new float * [n];

for (int32_t i=0; i<n; i++) data[i]=new float[D];

//... commands to fill the matrix ...

fs=fopen("data.vec", "w");

fwrite(&D, sizeof(D), 1, fs);

for (int32_t i=0; i<n; i++) fwrite(data[i], sizeof(float), D, fs);

fclose(fs);

for (int32_t i=0; i<n; i++) delete [] data[i];

delete [] data;

}

In IDL (Interactive Data Language):

n=100 ;(e.g.)

d=2 ;(e.g.)

data=fltarr(d, n)

;... commands to fill the matrix ...

openw, 1, "data.vec"

writeu, 1, d, data

close, 1

In Fortran:

parameter(n=100)

parameter(d=2)

real data(d, n)

...

open(10, file="data.vec", form="binary")

write(10) d

do j=0, n

write(10) (data(i, j), i=1,d)

enddo

close(10)

For scalar data, the programs use a straight binary dump of the data.

By default, four byte (32 bit) integers are used for class data and four byte

(32 bit) ﬂoating point variables are used for continuous data. (To change the

types used by the command-line programs, edit the header agf_defs.h.)

For class data, use the extension .cls and for ﬂoating point data, use the

extension, .dat. Scalar data always corresponds to vector data and is ordered

accordingly.

To write such data in C++, you can use the following commands:

#include <stdio.h>

#include <stdint.h>

int main() {

FILE *fs;

int32_t *data;

int32_t n;

n=100; //(e.g)

data=new long[n];

//... commands to fill array ...

fs=fopen("data.cls", "w");

fwrite(data, sizeof(int32_t), n, fs);

fclose(fs);

delete [] data;

}

In IDL:

data=lonarr(100)

;...

openw, 1, "data.cls"

writue, 1, data

close, 1

In Fortran:

parameter(n=100)

integer data(n)

...

open(10, file="data.cls", form="binary")

write(10) (data(i), i=1,n)

close(10)

Note that the class indices must go from 0 to Nc−1, where Ncis the

number of classes. The classiﬁcation routines will output two binary ﬁles con-

taining scalar data: one with the extension, .cls containing class estimates,

and one with the extension .con containing “conﬁdence ratings” which are

simply conditional probabilities re-scaled in the following manner:

c=NcP(c|~x)−1

Nc −1(1)

where P(c|~x) is the conditional probability of the “winning” class. A

conﬁdence rating of one indicates theoretically perfect knowledge of the true

class, while a value of zero indicates that the result is little better than

chance. If conditional or joint probabilities are needed for all the classes,

they are written to standard out.

To read the output ﬁles, examine the routines read_clsfile for read-

ing class data, read_vecfile for reading vector data and read_datfile for

reading scalar ﬂoating point data, contained in the source ﬁle, agf_util.cc,

or you can use them directly. Note that vector data is allocated in one con-

tiguous block, meaning that it can also be read and written in one contiguous

block. It can also be deleted very simply using two commands:

float ** data;

nel_ta n;

dim_ta D;

data=read_vecfile(data, n, D);

delete [] data[0];

delete [] data;

In addition, the sparse satellite library contains a utility called sparse_calc

that can operate on both types of binary ﬁles containing ﬂoating point data

(but not class data). To read in and print a ﬁle of vector data called, foo.vec

type the following commands:

$>sparse_calc

%s%c>print full(foo.vec)

To read in and print a ﬁle of scalar data called, bar.dat, type the follow-

ing:

%s%c>print vector(bar.dat)

Some users may prefer to use ASCII ﬁle formats to store their data.

If this is the case, there are a number of ﬁle conversion utilities included

for comparison with other algorithms. See Section 4, COMMAND LINE

EXECUTABLES.

Sometimes it’s desireable to normalize the data before performing classiﬁ-

cations. Normalization in libagf has now been generalized to linear transfor-

mation and includes singular value decomposition as well as feature selection.

The command, agf_precondition, is used to perform linear transformations

on test and training (features) data and store the resulting transformation

matrix in the same binary format for vector data as described above. The

default name is the same as before with the extension .std appended to the

output base ﬁle name. Features data can still be transformed directly within

the machine learning routines using the command options -n,-S and -a: see

Section 3, COMMAND PARAMETERS. By default, pre-trained model data

is stored in the normalized coordinates; to store it in the non-normalized

coordinates, use the command switch, -u.

3 COMMAND PARAMETERS

Most of the commands have the following syntax:

command [options] model [test_data] output

where model is the base name of the ﬁles containing either a set of training

data or a pre-trained model, test_data is the ﬁle containing test data and

output is the base name of the ﬁles in which to store the ﬁnal estimates.

To get a summary of the syntax and parameters, simply type the com-

mand name with no arguments, e.g.:

> classify_b

Syntax: classify_b [-n] [-u] [-a normfile] border test output

where:

border files containing class borders:

.brd for vectors

.bgd for gradients

.std for variable normalisations (unless -a specified)

test file containing vector data to be classified

output files containing the results of the classification:

.cls for classes, .con for confidence ratings

options:

-n option to normalise the data

-u normalize borders data (stored in un-normalized coords)

-a normfile file containing normalization data

Here is a list of all the options, although not all commands support all

options:

Option Function

– External command to train a binary classiﬁer.

-+ Extra options to pass to binary training command.

-ˆ External command to convert data formats for above.

-0 Read from stdin.

-1 Write to stdout.

-a Name of ﬁle containing normalization data.

-A Use ASCII ﬁles instead of binary.

-b Short output (cls_comp_stats)

-B Sort by class/ordinate.

-c Algorithm selection:

nfold cross-validation:

0=AGF borders (default) classiﬁcation

1=AGF classiﬁcation

2=KNN classiﬁcation

3=AGF interpolation

4=KNN interpolation

5=AGF borders multi-class

PDF validation:

6=AGF PDF estimation

7=KNN PDF estimation

-C No class data.

-d Number of divisions in cross-validation scheme.

-D Generate ROC curve by varying the discrimination border.

-e Return error estimates.

-E Value for missing data.

-f For validation schemes: fraction of training data to use for

testing.

-F Select features.

-g Use lograthmic progression.

-h Relative diﬀerence for calculating numerical derivatives.

-H Omit header data.

-i Class borders: maximum number of iterations in supernewton.

-I Weights calculation: maximum number of iterations in supernewton.

-j Print joint instead of conditional probabilities to stdout.

-k Number of k-nearest-neighbours to use in the estimate

-K Keep temporary ﬁles (do not delete on exit).

-l Tolerance of W.

-L Floating point ordinates.

-m Type of metric to use. Only works for knn classiﬁcation.

-M Get min. and max./LIBSVM format.

-n Takes averages and standard deviations of the training data and

normalizes both the training and test data.

-N Maximum number of iterations in supernewton.

-o Name of log ﬁle.

-O External command for binary classiﬁcation prediction.

-p Threshold density in clustering algorithm.

-P Calculate correlation/covariance matrix.

-q Number of trials/divisions.

-Q Algorithm selection:

optimal AGF: how to calculate the ﬁlter variances

0=halving max ﬁlter variance (default);

1=ﬁlter variance min and max;

2=total weight min and max

non-hierarchical multi-class classiﬁcation:

0=constrained inverse (not always optimal)

1=linear least squares, no constraints or re-normalization

2=voting from pdf, no re-normalization

3=voting from class label, no re-normalization

4=voting from pdf overrides least squares, conditional

probabilities are adjusted and re-normalized

5=voting from class overrides least squares, conditional

probabilities are adjusted and re-normalized

6=experimental

7=constrained inverse (may be extremely ineﬃcient)

-r Class borders: value of conditional prob. at discrimination border.

-R For random sampling.

-s Number of times to sample the class border.

-S Singular value decomposition: number of singular values to keep.

-t Desired tolerance when searching for class borders.

-T Class threshold for class-borders calculation.

-u Store borders data in non-normalized coordinates.

-U Re-label classes to go from [0, nc).

-v First ﬁlter variance bracket.

-V Second ﬁlter variance bracket/initial ﬁlter variance.

-w Lower bound for W in AGF optimal/constraint weight

-W Parameter Wc–equivalent to k in a k-nearest-neighbours scheme.

See paper describing the theory.

-x Run in background.

-X Ratio between sizes of sample classes (P(2)/P (1)).

-z Randomize data.

-Z In-house LIBSVM codes.

4 COMMAND LINE EXECUTABLES

This is a list of commands and their function:

4.1 Direct routines

Direct, non-parametric classiﬁcation, interpolation/regression, pdf estima-

tion using variable-bandwidth kernel estimation:

agf Uses adaptive Gaussian ﬁltering

knn Uses k-nearest neighbours

All the direct kernel estimation operations have been collected into two ex-

ecutables: one for AGF called, agf, and one for k-nearest-neighbours called,

knn. Both of them take an extra argument which speciﬁes which operation

to perform: classify,interpol or pdf.

4.2 Binary classiﬁcation

Two-class classiﬁcation by training a model:

class_borders Searches for the class borders using AGF.

classify_b Performs classiﬁcations using a set of border samples.

4.3 Multi-class classiﬁcation

Multi-class classiﬁcation using a series of class-borders:

multi_borders Trains a multi-class model based on a control ﬁle.

classify_m: Performs classiﬁcations using model output from multi_borders.

svm_accelerate: Trains a multi-borders model from a native LIBSVM model.

Multi-borders classiﬁcation represents a signiﬁcant step forward with this

library. The operation of these programs, called from the command line using

multi_borders and classify_m is quite involved and is described in detail

in Section, 6, MULTI-BORDERS CLASSIFICATION.

4.4 Testing/validation

cls_comp_stats Calculates the accuracy of classiﬁcation results.

nfold Performs n-fold cross-validation for the three diﬀerent

classiﬁcation algorithms or for the interpolation routines.

agf_preprocess: Splits a dataset for validation schemes.

pdf_sim Generates a synthetic dataset with the same approximate

PDF as the training data.

validate_pdf.sh Validates probability density function (PDF) estimates.

agf_correlate Correlates two binary ﬁles containing scalar

ﬂoating point data.

roc_curve Computes the receiver operatoring characteristic

(ROC) using three diﬀerent methods.

4.5 Clustering

cluster_knn Uses k-nearest neighbours and a threshold density

to perform a clustering analysis. See description,

below.

browse_cluster_tree Create a dendrogram and manually browse through

it and assign classes.

The ﬁrst clustering algorithm works by calculating the density of each

training samples. If the density is larger than a certain threshold, a class

number is assigned and the program recursively calculates the densities of all

the samples in the vicinity, based on its k neighbours, and assigns the same

class number to each if they also exceed the threshold. Samples lower than

the threshold are assigned the class label of 0, while clusters are assigned

consecutive values starting at 1. This is far simpler than a dendrogram, but

somewhat less general although the ﬁnal result should be similar. But, we’ve

added a dendrogram anyway.

4.6 Experimental

Continuum extension : Programs that extend the classiﬁcation algo-

rithms to work with continuous data:

c_borders.sh Trains a continuum classiﬁcation model.

classify_c Returns coninuum extension estimates.

Discrete Bayesian modelling : programs that model the probability

distributions through binning.

sort_discrete_vectors Sorts a set of discrete vectors.

search_discrete_vectors Searches within a set of discrete vectors and

estimates the probability density.

4.7 Pre-/post-processing

agf_procondition Performs linear transformations on coordinate (feature)

data and outputs the transformation matrix. Normalization,

singular-value-decomposition (SVD) and feature selection

are supported.

agf_preprocess Processes both coordinate data and class data.

Supports class selection, re-labelling and partitioning,

ﬁle splitting for validation and cross-correlation calculation.

4.8 File conversion

lvq2agf Converts the LVQPAK (ASCII) ﬁle format to the binary format

accepted by libagf. Many users may ﬁnd these ASCII formats

easier to work with.

svm2agf LIBSVM format to libAGF.

svmout2agf Converts (ASCII) output from LIBSVM to binary libAGF format.

agf2ascii Converts binary libAGF format to ASCII (LVQPAK or LIBSVM)

format.

C2R Converts a two-class classiﬁcation to a diﬀerence in conditional

probabilites. The equation is:

R= (2c−1)C

where c is the class and C is the conﬁdence rating.

mbh2mbm: Collates a multi-ﬁle multi-borders model into a single

ASCII ﬁle.

float_to_class: Converts ﬂoating point data into class data by

binning it into discrete ranges.

class_to_float: Converts class data into ﬂoating point.

The LVQPAK ﬁle format is probably the easiest to work with. There is

one header with the number of dimensions, followed by a listing of the vectors,

one vector per line, each column is a dimension except for the last one which

is the class. The sample_class program prints its results to standard out in

an LVQPAK-compatible format–see Section 7, EXAMPLES.

4.9 Commands used by other commands

Note that some commands call other commands, therefore these latter com-

mands must be in your path.

agf_precondition Called by all the machine learning programs if one or

more of the -a,-n or -S switches are used

pdf_agf,pdf_knn still used by validate_pdf.sh

4.10 Deprecated

classify_a,classify_knn,int_agf,int_knn,test_classify,test_classify_b,

test_classify_knn

To compile and install older routines, type, make old.

5 ERROR CODES AND DIAGNOSTICS

All commands will return “0” upon successful completion or one of the fol-

lowing error codes:

Code Meaning

1 Wrong or unsuﬃcient number of arguments.

101 Unable to open ﬁle for reading.

111 File read error.

256 File read warning.

303 Allocation failure.

201 Unable to open ﬁle for writing.

211 File write error.

512 File write warning.

401 Dimension mismatch.

411 Sample count mismatch.

501 Numerical error.

511 Syntax error.

503 Maximum number of iterations exceeded.

768 Parameter out of range.

1024 Command option parse error.

21 Fatal command option parse error.

901 Internal error.

911 Other error.

1280 Other warning.

Note that warnings are always divisible by 256 so that when passed back

to the command line return a 0 exit status so as not to interupt running

scripts. Error codes are also listed in the include ﬁle, error_codes.h in the

libpetey distribution. Note that non-fatal errors reduce to ’0’ if passed to

the command line.

AGF routines also return a set of diagnostics, for example:

diagnostic parameter min max average

iterations in supernewton:** 4 52 11.8

tolerance of samples: 0 3.53e-05 2.59e-06

** total number of iterations: 1178

number of bisection steps: 276

number of convergence failures: 0

diagnostic parameter min max average

iterations in agf_calc_w: 2 6 3.73

value of f: 2.6e-13 0.284 0.00146

value of W: 20.00 20.00 20.00

total number of calls: 1430

The ﬁrst parameter indicates the number of iterations required to reach

the correct value for the total of the weights, W. For eﬃciency reasons, this

should be as small as possible, however the super-linear convergence of the

root-ﬁnding algorithm (“supernewton”) means that the brackets can be quite

far away without much eﬀect on eﬃciency. To change the values of the ﬁlter

variance used to bracket the root, use -v for the lower bracket and -V for the

upper bracket. Normally the defaults should work just ﬁne but to decrease

the number of iterations, they should be narrowed. If they fail to bracket the

root, the oﬀending bracket is pushed outward. These changes are “sticky”,

so the brackets can, in fact, be set arbritrarily narrow and even quite far

from the root.

To change the tolerance of W, use the -l switch. To change the maximum

number of iterations, use the -i or -I switch.

The second parameter is the number of iterations required to converge

to the class border, excluding convergence failures. This is only applicable

when searching for the class borders. To change the maximum number of

iterations (default is 100) in the root-ﬁnding algorithm, use the -i or -N

parameter.

The third parameter is the value of the minimum ﬁlter weight divided

by the maximum and is only applicable when the -k option (selecting a

number of nearest neighbours) has been set. Ideally, it should be as small

as possible, although values as large as 0.2 often produce reasonable results.

Be sure to experiment with your own particular problem. To decrease it,

increase the number of nearest neighbours used in the calculations which

has the undesirable side eﬀect of increasing computation time. In general, k

should be a fair bit larger than W.

The tolerance of the samples only applies when searching for class borders.

It shows how close the value of R=P(2|~x)−P(1|~x) (diﬀerence in conditional

probabilities) is to zero at each border sample. This is set using the -t option

and the diagnostic should be close to the set value. It is sometimes larger

because the convergence test of the root-ﬁnding routine looks at tolerance

along the independent variable as well as the dependent variable–whichever

is better.

To best understand how to interpret the diagnostics and use these to set

the operational parameters, be sure to read the paper entitled, “Adaptive

Guassian Filters: a powerful new method for supervised learning”, in the

doc/ sub-directory of this installation or Mills (2011) which is a more ﬂeshed-

out version of it.

6 MULTI-BORDERS CLASSIFICATION

Multi-borders is an algorithm that generalizes the AGF-borders binary clas-

siﬁcation algorithm to multiple classes. It is a means of specifying the

conﬁguration of the class borders using a recursive control language. The

multi_borders command is used for training a multi-borders model and has

the following syntax:

multi_borders [options] control-in train model control-out

where:

•control-in is the input or training control ﬁle;

•train is the base-name of the binary ﬁles containing the training data

•model is the base-name for the ﬁles that will contain each of the binary

classiﬁcation models and

•control-out is the output or classiﬁcation control ﬁle which is passed

to the classiﬁcation program, classify_m.

6.1 Multi-borders classiﬁcation the easy way

To train a four-class one-versus-one multi-class class borders classiﬁcation

model, use the print_control command to generate one of several standard

multi-class models and pass it directly to the multi_borders command:

$>print_control -Q 6 4 | multi_borders foo bar foobar.txt

The training data is contained in foo; the trained binary classiﬁcation

models are output in a series of ﬁles (six in this case) starting with bar. The

output control ﬁle, foobar.txt, tells the prediction program, classify_m

how the binary classiﬁers are conﬁgured:

$>classify_m foobar.txt test.vec results

Where test.vec contains the test points while the results are stored in

result.cls and result.con. The -Q options determines the multi-class

model used: type print_control with no arguments to get a list of sup-

ported models.

6.2 Multi-borders classiﬁcation the hard way

Consider the following control ﬁle (test_multi5.txt):

"-s 100" {

"." {0 1}

"" 0 1 / 2;

"-s 75" 0 / 1 2;

{

"-s 50" {2 3}

4 5

}

When passed to multi_borders as follows:

$>multi_borders -n -s 125 test_multi5.txt foo bar foobar.txt

runs the following set of statements:

agf_precondition -a bar.std -n foo.vec bar.139397543805655.vec

cp foo.cls bar.139397543805655.cls

class_borders -s 100 bar.139397543805655 bar.00 0 / 1

class_borders -s 50 bar.139397543805655 bar.01.00 2 / 3

class_borders -s 125 bar.139397543805655 bar.01-00 2 3 4 / 5

class_borders -s 75 bar.139397543805655 bar.01-01 2 3 / 4 5

class_borders -s 100 bar.139397543805655 bar 0 1 / 2 3 4 5

rm bar.139397543805655.vec

rm bar.139397543805655.cls

Initial versions printed these commands to standard out with running

them the job of the user. Now they are executed directly with the option of

running them in the background using the -x switch. It is still possible to

print out the commands only using the -0 or -K switch.

The contents of foobar.txt are as follows:

bar {

bar.00 {

}

bar.01-00 0 1 / 2;

bar.01-01 0 / 1 2;

{

bar.01.00 {

}

Note that each of the names in this ﬁle correspond to pairs of ﬁles gen-

erated by the commands in the previous script. To classify the data in a ﬁle

named test.vec use the following command:

$>classify_m -n foobar.txt test.vec result

There are two types of multi-borders classiﬁcation: hierarchical and non-

hierarchical. In non-hieararchical multi-borders classiﬁcation, all the classes

are partitioned in multiple ways using a binary classiﬁer and the equations

relating the conditional probabilities of each class to those of the binary

classiﬁers are solved returning all of the conditional probabilities. In the

hierarchical method (also called a decision tree), the classes are partitioned

using either a binary classiﬁer or a non-hierarchical multi-classiﬁer, then

each of those partions are partitioned again and so on until there is only

one class left in each of the partions. Hierarchical classiﬁcation returns only

the conditional probability of the winning class. The classify_m method

automatical detects whether a control ﬁle uses the hierarchical method or

only the non-hierarchical method(that is it has only one level) and prints out

conditional probabilities as appropriate.

The parameters for training each binary classiﬁer are contained in double

quotes in the training control ﬁle. To take parameters from the command

line, use the null string ("") while a period (".") tells the program to use the

last set of parameters at the same level or below. A series of statements for

training each of the binary classiﬁers are generated and executed using the

“system” command. Once the commands are run, these binary classiﬁers will

be stored in a pair of uniquely named ﬁles, the base-names of which replace,

in the ﬁnal control ﬁle, the quoted parameter lists from the training control

ﬁle.

In the control language, going up a level in the hierarchical scheme is

denoted by a left curly brace ({) while going down is denoted by a right

curly brace (}). In a non-hierarchical model, we specify the parameters (ﬁle

name) of each of the binary partitions followed by the partitions themselves:

two lists of classes separated by a forward slash (/). Class labels for non-

hierarchical partitions are relative, that is they go from 0 to the number of

classes in the non-hierarchical model less one. Class labels in the top level

partitions are absolute, therefore must be unique. These should also go from

0 to one less than the total number of classes in the over-all model, but need

not.

In this example, there are six classes. They are ﬁrst partioned into a

group of two and a group of four. The group of four is partitioned into three

parts, the ﬁrst of which is partitioned into two classes and the second and

third of which are single classes. The print_control command can be used

to generate common control ﬁles.

A good way to understand the “multi-borders” paradigm is to look at

the example cases in the examples/humidity data directory. There is also

a draft paper contained in the docs/ sub-directory.

6.3 Multi-borders with external binary classiﬁers

The multi-borders routines can now interface with external binary classiﬁca-

tion software, speciﬁcally, either LIBSVM, or a pair of programs that have

the same calling conventions. For training, use the -- switch to pass the

command name to multi_borders. Consider the above control ﬁle as an

example, but without any of the control switches:

"" {

"" {0 1}

"" 0 1 / 2;

"" 0 / 1 2;

{

"" {2 3}

4 5

}

We pass the LIBSVM command, svm-train, to multi_borders, as fol-

lows:

$>multi_borders -M -- "svm-train -b 1" -+ "-h 0 -c 25" \

test_multi.txt foo.svm bar foobar.txt

which will execute the following statements:

agf_preprocess -A -M foo.svm bar.00.2367545368.tmp 0 / 1

svm-train -b 1 -h 0 -c 25 bar.00.2367545368.tmp bar.00

rm -f bar.00.2367545368.tmp

agf_preprocess -A -M foo.svm bar.01.00.2367545368.tmp 2 / 3

svm-train -b 1 -h 0 -c 25 bar.01.00.2367545368.tmp bar.01.00

rm -f bar.01.00.2367545368.tmp

agf_preprocess -A -M foo.svm bar.01-00.2367545368.tmp 2 3 4 / 5

svm-train -b 1 -h 0 -c 25 bar.01-00.2367545368.tmp bar.01-00

rm -f bar.01-00.2367545368.tmp

agf_preprocess -A -M foo.svm bar.01-01.2367545368.tmp 2 3 / 4 5

svm-train -b 1 -h 0 -c 25 bar.01-01.2367545368.tmp bar.01-01

rm -f bar.01-01.2367545368.tmp

agf_preprocess -A -M foo.svm bar.2367545368.tmp 0 1 / 2 3 4 5

svm-train -b 1 -h 0 -c 25 bar.2367545368.tmp bar

rm -f bar.2367545368.tmp

Several things should be noted:

•the -b switch is required and tells svm-train to generate probability

estimates

•the -+ option passes any other switches to use as “defaults”

•when used in this way, training data must be in ASCII format: -M

switch for the same format as LIBSVM, otherwise it uses the same

format as LVQPAC (see File Conversion, above)

•the output control ﬁle is the same as before

The training command, passed through --, should have the following

syntax:

train [options] data model/

where:

•train is the training command

•options are a set of options passed through the control ﬁle, through

the -+ option, or directly from the end of the command line or through

the command name

•data is the training data in LVQ or SVM ASCII format

•model is the output model reconizable to the prediction command, see

below.

Once the training has completed, classiﬁcations are performed by passing

the prediction command, svm-predict, from LIBSVM to classify_m using

the -O option:

$>classify_m -M -O "svm-predict -b 1" foobar.txt test.svm output.svmout

Once again, when paired with an external command, classify_m oper-

ates on ASCII ﬁles as opposed to the native AGF binary format. Output ﬁle

format is the same as LIBSVM: a header consisting of the word, “labels”,

followed by a list of labels, then one class label per line, followed by the condi-

tional probabilities in the same order as the class labels in the header. Since

“hierarchical” classiﬁcation generates only one probability per estimate, in

this case only one is written per line. While this is not LIBSVM conformant,

the ﬁle conversion utility, svmout2agf, nonetheless recognizes it.

The prediction command, passed by -O, should have the following syntax:

predict test model output

where:

•predict is the command name–if there are options they must be passed

directly as part of this name;

•test is the test data in LVQ or SVM ASCII format;

•model is the binary classiﬁcation model;

•output are the predicted classes plus both conditional probabilities in

the format described above.

Note that the order of the ﬁrst two arguments are reversed as compared to

the libAGF convention in classify_b and classify_m.

LIBSVM tends to be slow, especially if you have a lot of training data.

There are currently three ways of converting LIBSVM models into bor-

ders models: the ﬁrst two use the multi_borders command and work on

LIBSVM/multi-borders hybrid models. First, you can used the -O switch to

pass the prediction command (svm-predict -b 1 for LIBSVM models) to

multi_borders so that it can train a faster multi-borders model. This solu-

tion has the advantage that it can work with any external binary classiﬁer,

not just LIBSVM. It has the disadvantage, however, that gradient vectors

are calculated numerically, so is not very accurate.

A better solution is the -Z switch which tells multi_borders to use the

“in-house” SVM codes. To accelerate the previous model, pass the output

classiﬁcation control ﬁle from the previous pass:

$>multi_borders -Z foobar.txt foo bar2 foobar2.txt

which executes the following statements:

class_borders -Z bar.00 foo bar2.00

class_borders -Z bar.01.00 foo bar2.01.00

class_borders -Z bar.01-00 foo bar2.01-00

class_borders -Z bar.01-01 foo bar2.01-01

class_borders -Z bar foo bar2

Note how we’re using class_borders to perform the training: it uses

SVM as a source of conditional probabilities and ﬁnds a series of roots (ze-

roes) to sample the border between the two classes, just as it would with

AGF estimates. To facilitate this, an extra parameter is included in the

class_borders command: in addition to the output ﬁle name in the last

parameter, the ﬁrst parameter is the name of the model used to predict the

probabilities, while the second parameter is a ﬁle containing training data

which is used to sample the space while searching for roots.

Output is in the normal, AGF binary format and classify_m can be

used as normal for classiﬁcation:

$>classify_m foobar2.txt test.vec output

Another way of accelerating LIBSVM models, which only works with

“native” LIBSVM models, is with the svm_accelerate command. Suppose

we’ve trained a LIBSVM model, model.svmmod, as follows:

$>svm-train foo.svm model.svmmod

We can convert it to a multi-borders model as follows:

$>svm2agf foo.svm foo

$>svm_accelerate model.svmmod foo model.mod

where foo.svm contains the training data in LIBSVM format and foo is

the training data in libAGF format. Note that the multi-borders model in

this case is stored in ASCII format all in one ﬁle but is still accepted by

classify_m:

$>classify_m model.mod test.vec output

If a multi-ﬁle, multi-borders model is in one of the following conﬁgura-

tions: one-vs-one, one-vs-the-rest, or partitioning of adjacent classes, then

you can convert it to a single ASCII ﬁle using the mbh2mbm command. The

ﬁle format fairly simple. There is a four line header with the following infor-

mation: type of conﬁguration (“1v1”, “1vR”, ”ADJ”), number of classes, list

of class labels, and “polarities” of each of the binary classiﬁers. Next, all the

binary classiﬁers are listed as pairs of matrices: ﬁrst the border vectors, then

the gradient vectors. Each matrix has a one line header with the number of

vectors plus the size of each vector.

Running the commands, print_control,multi_borders,classify_m,

class_borders,svm_accelerate, or mbh2mbm without arguments prints a

generous help screen including a description of most of the features explained

in this section. There is also an example contained in the second half of

the makeﬁle under the examples/humidity_data directory (see, Section 7,

EXAMPLES, above).

7 EXAMPLES

The examples sub-directory collects together a number of test suites for

comparison, validation and application of AGF. The makeﬁles in these test

cases can give you a good idea of how to use the various components of the

library.

7.1 examples/class borders

The directory examples/class_borders includes a number of routines for

testing the algorithms and comparing them with other, popular classiﬁca-

tion algorithms. The validation exercise is performed on a pair of two-

dimensional, synthetic test classes and is described in Mills (2011). To test

the classiﬁcation algorithms, type, make test. To test the pdf estimation

routines, type, make test_pdf. To test both from the bottom level direc-

tory, type make test. All tests are done on a pair of synthetic test classes,

described in the paper. To generate samples and analytical estimates for

these classes, use the following commands

sample_class Generates random samples of the synthetic test classes.

classify_sc Returns class estimates using analytic/semi-analytic

estimates of the class pdfs; classiﬁcations should

therefore be close to the best possible for any supervised

algorithm.

pdf_sc1 Generates analytic pdf estimates for the ﬁrst class.

pdf_sc2 Generates semi-anaylitic (using quadrature) pdf estimates for

the second class.

sc_borders Find the border between the sample classes using the same

algorithm as that employed for the class_borders command.

To compare the algorithms with LIBSVM (Chang and Lin, 2011) and

Kohonen’s LVQ algorithm (Kohonen, 2000), type, make compare. You must

have both modules installed and the executables in your path.

7.2 examples/humidity data

The test suite in examples/humidity_data tests the multi-borders paradigm

on a discretized sub-set of the satellite humidity data described in Mills

(2009). Use this directory for examples on how to use the multi-borders

multi-class classiﬁcation method.

7.3 examples/Landsat

In the Landsat directory there are a number of scripts for performing surface

classiﬁcations using Landsat data. In particular, there is a simple app that

allows the user to classify pixels by hand. It opens a window with a Landsat

scene in it; clicking one of the three mouse buttons allows you to classify

pixels in the scene. There are three ﬁles that already contain hand-classiﬁed

forest clearcut data.

BIBLIOGRAPHY

Chang, C.-C. and Lin, C.-J. (2011). LIBSVM: A library for support vec-

tor machines. ACM Transactions on Intelligent Systems and Technology,

2(3):27:1–27:27.

Kohonen, T. (2000). Self-Organizing Maps. Springer-Verlag, 3rd edition.

Michie, D., Spiegelhalter, D. J., and Tayler, C. C., editors (1994). Machine

Learning, Neural and Statistical Classiﬁcation. Ellis Horwood Series in

Artiﬁcial Intelligence. Prentice Hall, Upper Saddle River, NJ. Available

online at: http://www.amsta.leeds.ac.uk/~charles/statlog/.

Mills, P. (2009). Isoline retrieval: An optimal method for validation of ad-

vected contours. Computers & Geosciences, 35(11):2020–2031.

Mills, P. (2011). Eﬃcient statistical classiﬁcation of satellite measurements.

International Journal of Remote Sensing, 32(21):6109–6132.

Mills, P. (2014). Multi-borders classiﬁcation. Technical Report

arxiv:1404.4095.

M¨uller, K.-R., Mika, S., R¨atsch, G., Tsuda, K., and Sch¨olkopf, B. (2001).

An introduction to kernel-based learning algorithms. IEEE Transactions

on Neural Networks, 12(2):181–201.

Terrell, D. G. and Scott, D. W. (1992). Variable kernel density estimation.

Annals of Statistics, 20:1236–1265.

Libagf Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
