All product names referenced herein are trademarks of their respective companies.
© Copyright 2007 Attachments International, Inc., San Mateo, CA 277
Lifecore Restore and Sustain
ifecore Biomedical, Inc., headquartered in Chaska, Minnesota, develops and manufactures
a wide array of medical devices, including an extensive line of dental restorative comp-
nents, implants and surgical tools.
Several implant systems are offered by Lifecore: Restore, Sustain, Stage-1, Renova and the
new internal connection Prima. Restore with an external hex, is offered as a self-tapping
threaded implant in Ti, TPS or RBM coating in small (SD), regular (RD) or wide (WD) diame-
ters. Restore is also available as an external hex cylinder implant in TPS or HA coating in
three diameters.
Sustain, with an HA coating, is available as an external hex, threaded or cylindrical implant
in small, medium and wide diameters. An Internal Bevel Cylindrical Sustain implant is
offered as well in three diameters.
The Stage-1 implant has an internal locking mortice taper with an RBM or TPS coating.
Components are compatible with the standard Straumann ITI components listed in the ITI
section of this manual.
The Renova has an internal hex with either a straight or tapered design.
The Prima is offered either as the Solo-a one-piece tapered design or as the Connex-with a
proprietary 6-lobed internal connection.
All RD diameter Restore and Sustain external hex implant components are Branemark
Regular Platform compatible. For a complete listing of Branemark compatible components,
refer to the Branemark section of this manual.
Implants Restoratively Compatible To
nRestore SD
threaded or cylinder ex hex 3.3 or 3.4
Sustain SD 3.3, 3.4
nSustain SD
threaded or cylinder ex hex 3.3 or 3.4
Restore SD 3.3, 3.4
nRestore RD
threaded or cylinder ex hex 3.75 or 4.0
Branemark, Regular Platform 4.1
nSustain RD
threaded or cylinder ex hex 3.75, 4.0, 4.2
3i Miniplant & Standard Osseotite
IMZ Hex Head 3.3 & 4.0
Innova Entegra 3.25 & 4.0
REmark-ST RP
Steri-Oss Hex-Loc 3.8 & 4.5
nRestore WD
threaded 5.0, 5.5, 6.0 or cylinder ex hex 5.0
Sustain WD ex hex 5.0
nSustain WD
threaded or cylinder ex hex 5.0
Restore WD ex hex 5.0, 5.5, 6.0
nSustain
internal bevel cylindrical 3 diameters
none
nStage-1
internal locking mortice taper
ITI
nRenova
internal hex
none
nPrima Solo
one-piece tapered design
none
nPrima Connex
proprietary 6-lobed internal connection
none
Restore threaded
Sustain threaded
Restore cylinder
Sustain cylinder
Stage-1
Restore
ex hex
cylinder
Sustain
ex hex
cylinder
Sustain
Internal bevel
cylinder
Restore
ex hex
cylinder
Sustain
ex hex
cylinder
Sustain
Internal bevel
cylinder
Refer to Branemark section
for compatible
components.
L
All RD diameter Restore and Sustain external hex implant components are
Branemark Regular 4.1 Platform compatible. For a complete listing of Branemark
compatible components, refer to the Branemark section of this manual.
n
Restore & Sustain
External Hex
LIFECORE
All product names referenced herein are trademarks of their respective companies.
© Copyright 2007 Attachments International, Inc., San Mateo, CA 278
Terminology of Components
Restore or Sustain
Restorative Components:
The restorative components are the elements used to fabricate a restoration that
will be connected to the implant(s). The restoration may also be attached to an
intermediate component called a tissue extension or abutment which in turn is
connected to the implant(s).
Tissue Extension:
The TE (Tissue Extension) also referred to as an abutment, is the intermediate
connector between the implant and the restoration, it may extend above the
tissue. In some instances, a TE extension is subgingival, to provide a more
esthetic restoration.
Implant Body:
The implant body is placed into the bone for approximately 4-6 months to allow for
osseointegration. The implants should not be loaded prior to osseointegration.
Compatibility:
Implants Restoratively Compatible To
nRestore SD threaded or cylinder ex hex 3.3 or 3.4 Sustain SD 3.3, 3.4
nSustain SD threaded or cylinder ex hex 3.3 or 3.4 Restore SD 3.3, 3.4
nRestore RD threaded or cylinder ex hex 3.75 or 4.0 Branemark, Regular Platform 4.1
nSustain RD threaded or cylinder ex hex 3.75, 4.0, 4.2 3i Miniplant & Standard Osseotite
IMZ Hex Head 3.3 & 4.0
Innova Entegra 3.25 & 4.0
Steri-Oss Hex-Loc 3.8 & 4.5
nRestore WD
threaded 5.0, 5.5, 6.0 or cylinder ex hex 5.0
Sustain WD ex hex 5.0
nSustain WD threaded or cylinder ex hex 5.0 Restore WD ex hex 5.0, 5.5, 6.0
nSustain internal bevel cylindrical 3 diameters none
n
Stage-1 internal locking mortice taper ITI Original
nRenova
internal hex
none
nPrima Solo
one-piece tapered design
none
nPrima Connex
proprietary 6-lobed internal connection
none
Implant Standardization:
The UMA tissue extension, compatible with the RP Restore and Sustain external
hex only, was developed to standardize the many different implant companies'
components and instruments for a more economically controlled inventory and for
simplicity of restorative procedures. Its tapered/hexagon fitting surface is identi-
cal, regardless of the size or type of implant employed, while its screw-in base is
implant specific.
Refer to Branemark
section for compatible
components.
