GENESIS 1.3

Version 4.0.2 - beta

User Manual

Feb-18

Contents

About this Manual 5

Installation 7

The Source Code Distribution .............................. 7

Compilation ....................................... 7

Running Genesis 1.3 9

The Main Input File 11

setup ........................................ 11

alter setup ..................................... 12

lattice ....................................... 13

time ........................................ 14

proﬁles ....................................... 15

beam ........................................ 16

ﬁeld ........................................ 17

importdistribution ................................. 18

importbeam .................................... 19

importﬁeld ..................................... 20

eﬁeld ........................................ 20

sponrad ....................................... 20

sort ......................................... 20

write ........................................ 21

track ........................................ 21

The Lattice File 23

Undulator ..................................... 23

Drift ........................................ 24

Quadrupole ..................................... 24

Corrector ...................................... 24

Chicane ....................................... 24

Phaseshifter .................................... 25

Marker ....................................... 25

Line ........................................ 25

Output and Input Files 27

Main Output File .................................... 27

Particle and Field Dump ................................. 28

Particle Distribution ................................... 28

The Postprocessor XGENESIS 29

xgeninit ....................................... 29

xgenplot ...................................... 29

xgenwigner ..................................... 30

Where to Find Further Information 31

About this Manual

This manual covers the FEL simulation code GENESIS 1.3, Version 4. It explains how to

compile the code and gives the description of the namelist elements in the main input deck

and the deﬁnition of the lattice.

The source code can be found in a git repository

https://gitlab.ethz.ch/Genesis/Genesis4

Throughout this document diﬀerent fonts are used to distinguish text from the plain text of

the manual. The italic font and Greek symbols refer to mathematical and physical constants

or expression, e.g.

E=mc2

Sample input and output ﬁles as well as all names referring directly to GENESIS 1.3 are

written in typewriter-style such as GAMMA0 or XLAMD.

6GENESIS 1.3 – Manual

Installation

Version 4 of the code Genesis 1.3 is written fully in C++, avoiding the hybrid compilation of

the previous versions. The only required libraries are OpenMPI and HDF5 with the support

of parallel ﬁle input and output. This is typically guaranteed when HDF5 has been compiled

with the support of OpenMPI. OpenMPI supports also the proﬁling and tracing of the code

since it includes the library VampirTrace, which comes with the OpenMPI distribution. Note

that proﬁling will not be necessary for the normal user and that it requires a commercial

program to analyze the traces suﬃciently.

The Source Code Distribution

Genesis is solely distributed by source text, its free, non-commercial and falls under the

public license agreement. The distribution is in a compressed tar archive. To unpack, type

at the location, where you want to have the source code installed:

gunzip ﬁlename.tar.gz

tar xvf ﬁlename.tar

where ﬁlename is the root name of the ﬁle of the source code package. There should be

several directories installed. The most important are include and src to hold the include-

and source-ﬁles, xgenesis the postprocessor ﬁles for Matlab, benchmark some sample ﬁles

to run with Genesis and sdds2hdf some utility programs to convert Elegant distribution in

SDDS format into HDF5 ﬁles, which can be parsed by Genesis.

Compilation

In the root directory there is the ﬁle Makefile which is the makeﬁle for the compilation

on Unix machines. This ﬁle can be used to help setting up the installation. In the ﬁle

there is the OBJECTS list which contains all required source code ﬁles. There are located

in several directories in the subfolder src. To ﬁnd them the compiler search path has to

be extended as with the VPATH directive under unix. The compilation instruction should

convert each individual source ﬁle into objects ﬁle and then link them with the HDF5 and

OpenMPI libraries. Note that at some systems the required deﬁnition of the include and

libraries ﬁles are wrapped in the compiler executive. E.g. in the given Makeﬁle the compiler

h5c++ supports directly both required libraries. If this does not exist on your system and

8GENESIS 1.3 – Manual

both libraries (HDF5 and OpenMPI) are not supported by the standard search path, they

have to be set explicitly with the -I,-L, and -l directive for the include search path, library

search path and the library name, respectively. To enable support for VampirTrace proﬁling,

the corresponding compiler has to be used. Genesis supports some manual proﬁling, such

as entry and exit points of the core functions to propagate the beam and ﬁeld or to write

data to ﬁles. For that the Macro VTRACE has to be set during compilation with the directive

-DVTRACE.

If the make ﬁle is set-up correctly, type make under Unix systems to compile, which should

produce the executable gencore in the local directory. If source ﬁles has been changed

then the code can be compiled again. Only ﬁles, which have been edited will be recompiled

and then linked with the unchanged object ﬁles. If some include ﬁles have been changed

it is recommended to recompile from scratch. The command make clean will clean up the

directory by deleting all object ﬁles and the current executable. To install into your local

library, which is the bin folder in your home directory, just type make install. You can

edit the makeﬁle to ﬁt your system.

On platforms, which do not support gnu compiler directly, you have to build up your com-

pilation instruction according to the Makeﬁle.

To complete the installation it is recommended to install the scripts in the directory sdds2hdf5

in a directory (e.g. /bin), which is included in your search path. The ﬁles will convert El-

egant output distribution into HDF5 format. More info can be found later in the manual.

Also, the directory xgenesis includes some functions, which allows Matlab to parse the

output ﬁle of Genesis and to plot the results. They are not required for running Genesis

itself. To use them add the given folder to your Matlab Path or place the ﬁle in a directory,

which is already in the search path.

Running Genesis 1.3

Genesis 1.3 is a command line executable and requires a single input argument, which is the

ﬁlename of the input deck:

genesis4 ﬁlename

Any further information must be provided within the input deck. Starting Genesis in this

way will eﬀectively invoke a parallel job with only one single core. To start the code with

just more than one core the launching command mpirun needs to be called, including the

number of cores. In its simplest call it would be:

mpirun -np ## genesis4 ﬁlename

where ## is the number of cores to be requested.

Once Genesis started the master core, which is the core with the MPI rank 0, will provide

the output. The output can vary for diﬀerent output decks. Normally it is reported, once

the code generates or alters particle distributions or the radiaiton ﬁeld, tracks the beam

through the lattice or when a time window is speciﬁed.

The execution produces output ﬁles whenever a tracking command is issued or a ﬁeld or

particle dumped is requested. All in common is the root ﬁlename which is deﬁned in the input

deck. Normal output ﬁles have the extension .out.h5 for the ﬁrst tracking or .Run#.out.h5

for the #th run (except for the ﬁrst, where the addition of ’Run’ is omitted). The ﬁle format

is HDF5. The explicit format is described in a later chapter of this manual. Field or particle

dumps are using as well the root ﬁlename as default but under certain circumstances this

behavior can be overruled. For more information see the corresponding namelist elements

in the next chapter.

For time-dependent simulations the code requires a large amount of memories to keep the

entire radiation ﬁeld and particle distribution in memory. This is the signiﬁcant diﬀerence

to previous versions where the code was able to progress through the bunch sequentially.

However this excludes eﬀects such long range ﬁelds, exchanging particles between slices, and

large delaying chicanes. For an estimate of the memory demand the radiation ﬁeld requires

Nb=ns∗n2

g∗16 Bytes,

where nsis the number of slices and ngnumber of grid points. For the electron distribution

it is

Nb=ns∗ne∗48 Bytes,

with nethe number of macro particles per slice.

10 GENESIS 1.3 – Manual

Both numbers should be added up and for safety multiplied by a factor of 2 for some

overhead (aligning arrays in memory, temporary working arrays, arrays to buﬀer the output

information etc.). This will be distributed equally over all nodes. Non time-dependent

simulation should be small enough to run on any computer.

The Main Input File

Unlike older version, which supported only a single namelist as input, the latest version splits

up the namelist and processes them sequentially as they appear in the ﬁle. Therefore the

order is important, e.g. you cannot deﬁne a time window after the electron beam or the ﬁeld

has been already generated. On the other hand the code supports multiple tracking in one

run. For that the particle and ﬁeld distribution is kept in memory and then reused in the

next tracking. If a fresh bunch is required the old has to be discarded and then a new one

has to be generated. In that sense it is possible to combine steady-state and time-dependent

run in one input deck by the sequence: generate ﬁeld, generate beam, track, deﬁne time

window, generate beam, generate ﬁeld, and track.

The namelists themselves always start with the ampersand & and the name of the name

list and are terminated with &end. Each line consists out of an assignment of a supported

variable, e.g npart = 2048 in the namelist &setup. Empty lines and lines, starting with

the pound symbol # are ignored. If the same variable occurs more than once the latest

occurrence is used for the calculation. If Genesis encounters a variable name, which it does

not recognize it stops execution and prints out a list of the supported variables.

The following describes all supported namelist with their variables, including its required

format and default value)

setup

The namelist setup is a mandatory namelist and should be the ﬁrst in the input deck. It

contains the basic parameters to control the simulations. It can only be called once. If the

user want to change some parameter the namelist alter setup should be used.

•rootname (string, <empty >): The basic string, with which all output ﬁles will start,

unless the output ﬁlename is directly overwritten (see write namelist)

•lattice (string, <empty >): The name of the ﬁle which contains the undulator lattice

description. This can also include some relative paths if the lattice ﬁle is not in the

same directory as the input ﬁle.

•beamline (string, <empty >): The name of the beamline, which has to be deﬁned

within the lattice ﬁle. For more information on the lattice ﬁle, see the next chapter.

•gamma0 (double, 11350.3): The reference energy in unites of the electron rest mass.

This is the reference energy which is used in the code at various place, mostly in the

12 GENESIS 1.3 – Manual

calculation of the matching condition, the reference focusing strength of quadrupoles

and undulator as well as the default value if an electron distribution is generated.

•lambda0 (double, 1e-10): The reference wavelength in meter, which is used as the

reference wavelength in steady-state simulation or for deﬁning the sample distance in

time-dependent runs. It also acts as the default value when ﬁeld distributions are

generated.

•delz (double, 0.015): Preferred integration stepsize in meter. Note that this is not a

strict value because Genesis tries to optimized the stepsize according to the elements

it can resolve. E.g. if an undulator is 1.99 m long but the preferred stepsize is 2 cm

than it uses a stepsize which is the closest to preserve the number of integration step.

In this case the preferred stepsize gives 99.5 steps which is than rounded to 100 and

thus resulting in an actual stepsize of 1.99 cm. Note that outside of the undulator,

which are free drifts for the radiation ﬁeld, Genesis progresses the electron beam and

radiation ﬁeld in larger steps, namely one step per resolved element (drift, quadrupole,

phase shifter).

•seed (int, 123456789): Seed to initialize the random number generator, which is used

for shot noise calculation and undulator lattice errors, though it is recommended that

the random number generator seed is redeﬁned explicitly for undulator errors in its

corresponding namelist.

•npart (int, 8192): Number of macro particles per slice. Note that the number must

be a multiple of the used bins nbins otherwise Genesis will exit with an error. If

one-for-one simulations are used, this parameter has no meaning.

•nbins (int, 4): Number of macro particles, which are grouped into beamlets for gener-

ating the correct shot noise. For one-for-one simulations this parameter has no meaning

•one4one (bool, false): Flag to enable or disable simulation to resolve each electron

in the simulation. This is mandatory for certain features, such as sorting or slicing of

particle distributions. If set to true other parameters such as npart and nbins are

obsolete and do not need to be deﬁned. It is recommended to estimate the number

of electrons, which are generated in the simulations, because this can easily required

memory beyond what is available on the computer.

•shotnoise (bool, true): Flag to enable the calculation of shotnoise per each slice during

generation of the electron distribution. It is recommended to set the value to false

for steady-state or scan simulations.

alter setup

A namelist to change some parameters within the simulation, which have been deﬁned alread

by the setup namelist. The change values are stored in the setup module so that for

The Main Input File 13

another invocation of alter setup some defaults values are use which have been deﬁned in

the preceding call of alter setup

•rootname (string, <taken from SETUP >): The basic string, with which all output

ﬁles will start, unless the output ﬁlename is directly overwritten (see write namelist)

•beamline (string, <empty >): The name of the beamline, which has to be deﬁned

within the lattice ﬁle. This way another beamline can be selected in the case the

simulation has multiple stages

•delz (double, <taken from SETUP >): Preferred integration stepsize in meter. Note

that this is not a strict value because Genesis tries to optimized the stepsize according

to the elements it can resolve. E.g. if an undulator is 1.99 m long but the preferred

stepsize is 2 cm than it uses a stepsize which is the closes to preserve the number

of integration step. In this case the preferred stepsize gives 99.5 steps which is than

rounded to 100 and thus resulting in an actual stepsize of 1.99 cm. Note that outside

of the undulator Genesis, which are free drifts for the radiation ﬁeld, it progress the

electron beam and radiation ﬁeld in larger steps, namely one step per resolved element

(drift, quadrupole, phase shifter).

•harmonic (int, 1): If the value is not 1 than a harmonic conversion is done. This has

several consequences. The reference wave length in setup is divided by the harmonic

number, the sample rate in time is multiplied by the harmonic number, the pondero-

motive phases of all macro particles are scaled with the harmonic number, all radiation

ﬁelds, which are not identical to the harmonic numbers are deleted, while an existing

harmonic ﬁeld is changed to be at the fundamental wavelength

•subharmonic (int, 1): If the value is not 1 than a down conversion is done. It is

similar to the action of harmonics but in the opposite directions. For the radiation

ﬁeld all ﬁeld deﬁnitions are deleted except for the fundamental, which is converted

to a harmonic. In this case the fundamental ﬁeld needs to be deﬁned before another

tracking is called.

•resample (bool, false): If this is set to true and only if one-for-one simulations are

used the harmonic and subharmonic conversion can re-sample to the new wavelength.

In the case of up-conversion the slices are split and the total number of slices increases.

Same with the radiation ﬁeld. An previously existing harmonic ﬁeld, which is now

becoming the fundamental, is interpolated between the existing sample points (needs

check whether this has been implemented). If a new ﬁeld is generated it has automat-

ically the new number of slices. If also prevents that the sample rate is changed, but

instead remains unchanged.

lattice

This namelist is used to change the raw lattice from the lattice ﬁle, such as generating errors

in the position of the elements. At the moment almost nothing has been implemented but

14 GENESIS 1.3 – Manual

will be implemented in the future

•zmatch (double, 0) If the position within the undulator in meter is non-zero than

Genesis tries to calculate the matched optics function for a periodic solution. In the

case that it cannot ﬁnd a solution than it will report it. Found solution will also be the

default values for a succeeding beam generation, so that no explicit optical functions

need to be deﬁned any longer. If the lattice is highly non-periodic it is recommended

to ﬁnd the matching condition with an external program such as MAdX.

time

This namelist deﬁnes the time window/range for simulation with more than just one slice.

For reference the complementary axis to the undulator axis, which is normally the position

in the time frame, is expressed in a position s. Normally everything is aligned to the

origin s= 0, in particular when external distributions are imported. Note that for parallel

execution the number of slices per core should be the same for an eﬃcient writing of the

output ﬁles. Therefore Genesis extends the time-window to symmetrize the number of slices

per core by extending it towards larger values of s. As an example with XLAMDS=1e-6 and

a length SLEN=20e-6 a call of Genesis with 24 cores would generate a time-window of 24

microns because each core would have one slice, while 15 cores would expand it to 30 microns

with 2 slices per core each.

this module deﬁnes also scans in either ﬁeld or beam parameters if the corresponding ﬂag

is set. Technically it generates the beam and ﬁeld as for time-dependence but disables

slippage during simulations. That way the radiation ﬁeld is kept in the same slice, acting as

steady-state simulations.

•s0 (double, 0): Starting point of the time-window in meters.

•slen (double, 0): Length of the time window in meters. Note that for parallel jobs this

might be adjusted towards larger values.

•sample (int, 1)): Sample rate in units of the reference wavelength from the setup

namelist, so that the number of slices is given by SLEN / LAMBDA0/SAMPLE after SLEN

has been adjusted to ﬁt the cluster size.

•time (bool, true): Flag to indicate time-dependent run. Note that time-dependent

simulations are enabled already by using this namelist. This ﬂag has the functionality

to diﬀerentiate between time-dependent run and scans, which disable the slippage in

the tracking. To restrict the simulation to steady-state the time namelist has to be

omitted from the input deck.

The Main Input File 15

proﬁles

Proﬁles are deﬁning a dependence on the position in the time frame, which then can be used

to deﬁned the behavior of various parameters such as slice emittance, energy spread etc. All

proﬁles are in common that they have to have a label with which they are referred to in

other namelists. To indicate the reference to a proﬁle and thus allows to distinguish Genesis

between normal numbers the label name must have the additional character ’@’ in front.

E.g. if the name of the label is energy then in the beam name list it is referred to by gamma

= @energy.

proﬁle const

•label (string, <empty >): Name of the proﬁle, which is used to refer to it in later

calls of namelists

•c0 (double, 0): constant value to be used.

proﬁle gauss

•label (string, <empty >): Name of the proﬁle, which is used to refer to it in later

calls of namelists

•c0 (double, 0): Maximum function value of the Gaussian distribution

•s0 (double, 0): Center point of the Gaussian distribution

•sig (double, 0): Standard deviation of the Gaussian distribution

proﬁle step

•label (string, <empty >): Name of the proﬁle, which is used to refer to it in later

calls of namelists

•c0 (double, 0): Constant term

•s start (double, 0): Starting point of the step function

•s end (double, 0): Ending point of the step function

16 GENESIS 1.3 – Manual

proﬁle polynom

•label (string, <empty >): Name of the proﬁle, which is used to refer to it in later

calls of namelists

•c0 (double, 0): Constant term

•c1 (double, 0): Term proportional to s

•c2 (double, 0): Term proportional to s2

•c3 (double, 0): Term proportional to s3

•c4 (double, 0): Term proportional to s4

proﬁle ﬁle

•label (string, <empty >): Name of the proﬁle, which is used to refer to it in later

calls of namelists

•xdatal (string, <empty >): Points to a dataset in an HDF5 ﬁle to deﬁne the s-

position for the look-up table. The format is ﬁlename/group1/.../groupn/datasetname,

where the naming of groups is not required if the dataset is at root level of the HDF5

ﬁle

•ydata (string, <empty >): Same as y data but for the function values of the

look-up table.

•isTime (bool, false): If true the s-position is a time variable and therefore multiplied

with the speed of light cto get the position in meters.

•reverse (bool, false): if true the order in the look-up table is reverse. This is sometimes

needed because time and spatial coordinates diﬀer sometimes by a minus sign.

beam

This namelist initiates the generation of the particle distribution to be kept in memory. Any

time-dependence has to be deﬁned before calling this namelist.

•gamma (double, gamma0 or proﬁle label): Mean energy in units of the electron rest

mass. If default value is given by the reference energy from the setup namelist.

•delgam (double, 0 or proﬁle label): RMS energy spread in units of the electron rest

mass.

•current (double, 1000 or proﬁle label): Current in Amperes.

The Main Input File 17

•ex (double, 0.3e-6 or proﬁle label): Normalized emittance in x in units of meters

•ey (double, 0.3e-6 or proﬁle label): Normalized emittance in y in units of meters

•betax (double, 15 or matched value or proﬁle label): Initial beta-function in x in

meters. If the matched command has been invoked before the default values are set to

the results.

•betay (double, 15 or matched value or proﬁle label): Initial beta-function in y in

meters. If the matched command has been invoked before the default values are set to

the results.

•alphax (double, 0 or matched value or proﬁle label): Initial alpha-function in x. If the

matched command has been invoked before the default values are set to the results.

•alphay (double, 0 or matched value or proﬁle label): Initial alpha-function in y. If the

matched command has been invoked before the default values are set to the results.

•xcenter (double, 0 or proﬁle label): Initial centroid position in x in meter.

•ycenter (double, 0 or proﬁle label): Initial centroid position in y in meter.

•pxcenter (double, 0 or proﬁle label): Initial centroid momentum in x in units of γβx.

•pycenter (double, 0 or proﬁle label): Initial centroid momentum in y in units of γβy.

•xcenter (double, 0 or proﬁle label): Initial centroid position in x in meter.

•bunch (double, 0 or proﬁle label): Initial bunching value

•bunchphase (double, 0 or proﬁle label): Initial phase of the bunching

•emod (double, 0 or proﬁle label): Initial energy modulation in units of the electron

rest mass

•emodphase (double, 0 or proﬁle label): Initial phase of the energy modulation

ﬁeld

This namelist initiate the generation of the ﬁeld distribution. It diﬀers in one point from the

generation of the beam. It can be called multiple times. If the variable accumulate is set

to true, it does not delete the previous distribution but adds up the wavefronts. That way

higher mode content in either spatial and time direction can be created.

•lambda (double, lambda0): Central frequency of the radiation mode. The default

value is the reference wavelength from the setup namelist.

•power (double, 0 or proﬁle label): Radiation power in Watts

18 GENESIS 1.3 – Manual

•phase (double, 0 or proﬁle label): radiation phase in rads. Not that a linear proﬁle

results in a shift in the radiation wavelength, which is also the method if for the variable

lambda a diﬀerent value than the reference wavelength is used. In case of conﬂicts the

proﬁle for the phase deﬁnition has priority.

•waist pos (double, 0 or proﬁle label): Position where the focal point is located relative

to the undulator entrance. Negative values place it before, resulting in a diverging

radiation ﬁeld.

•waist size (double, 100e-9 or proﬁle label): Waist size according to the deﬁnition of

w0according to Siegman’s ’Laser’ handbook

•xcenter (double, 0): Center position in x in meter of the Gauss-Hermite mode

•ycenter (double, 0): Center position in y in meter of the Gauss-Hermite mode

•xangle (double, 0): Injection angle in x in rad of the Gauss-Hermite mode

•yangle (double, 0): Injection angle in y in rad of the Gauss-Hermite mode

•dgrid (double, 1e-3 or by existing ﬁeld): Grid extension from the center to one edge.

The whole grid is twice as large with 0 as the center position

•ngrid (int, 151 or by existing ﬁeld): Number of grid points in one dimension. This

value should be odd to enforce a grid point directly on axis. Otherwise the convergence

in the simulations could be worse.

•harm (int, 1): Harmonic number of the radiation ﬁeld with respect to the reference

wavelength.

•nx (int, 0): Mode number in x of the Gauss-Hermite mode

•ny (int, 0): Mode number in y of the Gauss-Hermite mode

•accumulate (bool, false): If set the generated ﬁeld is added to an existing ﬁeld instead

of overwriting it.

importdistribution

This namelist controls the import of an external distribution which are generated from

Elegant. This can be directly in SDDS format or converted to HDF5 format, which is done

automatically by Genesis if the SDDS ﬁle format is indicated. However it is recommended

to do the conversion manually before the start of genesis. The distribution has to provide all

6 dimensions while the charge is supplied in this namelist. When imported the longitudinal

position is changed so that the last particles is at s= 0 micron.

Note that this namelist will be expanded in the future, to enable tilts and match/center to

a core part of the beam

The Main Input File 19

•ﬁle (string, <empty >): The ﬁle name of the distribution, including possible relative

directories.

•sdds (bool, false): If set to true, the ﬁle is converted ﬁrst to an HDF5 ﬁle by the shell

script sdds2hdf5-dist.sh. A new ﬁle is generated with the additional extension .h5

and then used for the parsing.

•charge (double, 0): Total charge of the distribution to calculate the current and

individual charge per macro particle.

•slicewidth (double, 0.01): the fraction in length of the distribution which is used for

reconstruction. E.g if the length is 10 micron and slic ewidth 0.02 then the reconstruc-

tion at the position s= 4 micron is using the particle in the distribution, which are

located in the slice from 3.9 microns to 4.1 microns.

•output (bool, false). If set to true an output ﬁle is generated with the extension’.ana.h5’

which contains the slice parameters of the particle distribution after the import and

conversion has ﬁnished. Note that this option is obsolete because the same output is

also included in the main output. Therefore this feature will be disabled soon.

•center (bool, false): If set to true the particle distribution is recentered in transverse

position, momenta and energy.

•gamma0 (double, gamma0 from setup): If centering is enabled, new center in energy

in units of electron rest mass.

•x0 (double, 0): If centering is enabled, new center in x in meter.

•y0 (double, 0): If centering is enabled, new center in y in meter.

•px0 (double, 0): If centering is enabled, new mean momentum in x in γβx.

•py0 (double, 0): If centering is enabled, new mean momentum in y in γβy.

•match (bool, false): If set to true the particle distribution is matched to new optical

function values.

•betax (double, 15 or matched value): If matching is enabled, new beta function in x

in meter.

•betay (double, 15 or matched value): If matching is enabled, new beta function in y

in meter.

•alphax (double, 0 or matched value): If matching is enabled, new alpha function in x.

•alphay (double, 0 or matched value): If matching is enabled, new alpha function in y.

importbeam

Not yet working. Needs ﬁxing

20 GENESIS 1.3 – Manual

importﬁeld

Not yet working Needs ﬁxing.

eﬁeld

This namelist controls the short range space charge on a length scale of the resonant wave-

length or shorter. The calculation is done on a radial azimuthal grid, centered to the centroid

position of the electron slice

•rmax (double, 0): Scaling factor to deﬁne the grid size, which is given by the product

of rmax and the maximum oﬀset of the macro particles from its centroid

•nz (int, 0): Number of longitudinal Fourier component of the space charge ﬁeld. Note

that this should be not in conﬂict with the beamlet size.

•nphi (int, 0): Number of azimuthal modes in the calculation of the space charge ﬁeld.

•ngrid (int, 100): Number of grid points of the radial grid.

sponrad

This enables the eﬀect of spontaneous radiation outside of the frequency band of the FEL

simulation.

•seed (int, 1234): Seed for random number generator to model the quantum ﬂuctuation

of hard photons.

•doLoss (bool, false): If set to true, electrons will loose energy due to the emission of

spontaneous radiation within the undulator

•doSpread (bool, false): If set to true, the energy spread will increase due to the

ﬂuctuation in the emission of hard photons of the spontaneous radiation.

sort

An empty namelist with no variables. It initiates the sorting and redistribution of particles

only if one-for-one simulation is enabled. Note that harmonic conversion will automatically

invokes sorting and therefore does not need to be called explicitly.

The Main Input File 21

write

With this name list the ﬁeld or particle distributions are dumped.

•ﬁeld (string, <empty >): if a ﬁlename is deﬁned, Genesis writes out the ﬁeld distri-

bution of all harmonics. The harmonics are indicated by the suﬃc ’.h#.’ where # is

the harmonic number. The ﬁlename gets the extension .fld.h5’ automatically

•beam (string, <empty >): if a ﬁlename is deﬁned, Genesis writes out the particle

distribution. The ﬁlename gets the extension .par.h5 automatically

track

This namelist initiate the actually tracking through the undulator and then writing out the

results.Normally all parameter should be deﬁned before or deﬁned in the lattice but the

namelist allows some ’last minute’ change of the behavior of the code

•zstop (double, 1e9): If zstop is shorter than the lattice length the tracking stops at

the speciﬁed position

•output step (int, 1): Deﬁnes the number of integration steps before the particle and

ﬁeld distribution is analyzed for output.

•ﬁeld dump step (int, 0): Deﬁnes the number of integration steps before a ﬁeld dump

is written. Be careful because for time-dependent simulation it can generate many large

output ﬁles.

•beam dump step (int, 0): Deﬁnes the number of integration steps before a particle

dump is written. Be careful because for time-dependent simulation it can generate

many large output ﬁles.

•sort step (int,0): Deﬁnes the number of steps of integration before the particle dis-

tribution is sorted. Works only for one-4-one simulations.

22 GENESIS 1.3 – Manual

The Lattice Files

In comparison to previous versions of Genesis the deﬁnition of the undulator lattice is now

completely deﬁned in a lattice ﬁle. The main input ﬁle just refers to it and might change

some parameters, such as adding undulator errors etc. Another major change is that the

rigid scheme of ﬁxed integration steps is now broken up. The lattice does not need to be

aligned to a single integration step. Instead the lattice can be closer now to the real lattice.

The format of the lattice ﬁle is similar to other codes such as ELEGANT or MADX, which

makes it somehow easier to convert between the formats. In general the syntax is the

following:

label:element type ={parameter =value [, ···]};

Following beamline elements are currently supported: undulator, quadrupole, drift,

corrector, chicane, phaseshifter and marker. For the parsing of the elements Genesis

only consider the ﬁrst 4 letters. Therefore undulator and undu as element name are both

valid. This applies only for the elements. Other tags, such as labels and parameter have to

be exact. Upper or lower cases are ignored because all letters are converted to lower case

prior to parsing.

Labels are used to identify elements and are referred to in the line element. More information

is given at the end of this section.

Undulator

•aw: The dimensionless rms undulator parameter. For planar undulator this value is

smaller by the factor 1/√2 than its K-value, while for helical undulator rms and peak

values are identical. Default value is zero.

•lambdau: Undulator period length in meter. Default is 0 m.

•nwig: Number of periods

•helical: Boolean ﬂag whether the undulator is planar or helical. Default value is

false, indicating a planar undulator. Note that setting it to true, does not change the

roll-oﬀ parameters. To be consistent they have to be set directly.

•kx: Roll-oﬀ parameter of the quadratic term of the undulator ﬁeld in x. There are

normalized with respect to k2

u. Default is 0

•ky: Roll-oﬀ parameter of the quadratic term of the undulator ﬁeld in y. Default is 1

24 GENESIS 1.3 – Manual

•ax: Oﬀset of the undulator module in x in meter. Default is 0.

•ay: Oﬀset of the undulator module in y in meter. Default is 0.

•gradx: Relative transverse gradient of undulator ﬁeld in x ≡(1/aw)∂aw/∂x. Default

is 0.

•grady: Relative transverse gradient of undulator ﬁeld in y ≡(1/aw)∂aw/∂y. Default

is 0.

Drift

•l: Length of the drift in meter. Default value is 0 m.

Quadrupole

•l: Length of the quadrupole in meter. Default value is 0 m.

•k1: Normalized focusing strength in 1/m. Default value is 0

•dx: Oﬀset in x in meter. Default is zero.

•dy: Oﬀset in y in meter. Default is zero.

Corrector

•l: Length of the corrector in meter. Default value is 0 m.

•cx: Kick angle in x in units of γβx. Default value is 0.

•cy: Kick angle in y in units of γβy. Default value is 0.

Chicane

•l: Length of the chicane, which consists out of 4 dipoles without focusing. The ﬁrst

and last are placed at the beginning and end of the reserved space. The inner ones

are deﬁned by the drift length in between. Any remaining distance, namely the length

subtracted by 4 times the dipole length and twice the drift length are placed between

the second and third dipole. Default value is 0 m.

•lb: Length of an individual dipole in meter. Default value is 0 m

The Lattice File 25

•ld: Drift between the outer and inner dipoles, projected onto the undulator axis. The

actual path length is longer by the factor 1/cos θ, where θis the bending angle of an

individual dipole.

•delay: Path length diﬀerence between the straight path and the actual trajectory in

meters. From this value the bending angle is calculated internally by Genesis. Default

delay is 0 m.

Phaseshifter

•l: Length of the phase shifter in meter. Default value is 0 m.

•phi: Change in the ponderomotive phase of the electrons in units of rad. Default value

is 0. Note that Genesis is doing an autophasing, so that the electrons at reference

energy are not changing in ponderomotive phase in drifts.

Marker

•dumpﬁeld: A non-zero value enforces the dump of the ﬁeld distribution of this zero

length element.

•dumpbeam: A non-zero value enforces the dump of the particle distribution.

•sort: A non-zero value enforces the sorting of particles, if one-for-one simulations are

enabled.

•stop: A non-zero value stops the execution of the tracking module. Note that the

output ﬁle still contains the full length with zeros as output for those integration steps

which are no further calculated.

Line

The line uses the labels to deﬁne the order of the elements in the beam line. Elements can

be referred to multiple times. Each time the line element creates an individual copy so that

they are not treated as a single entity. That allows that in a later stage the elements can be

changed diﬀerently, e.g. when errors in the alignment are generated. The line element can

also contain other line elements. Genesis is unrolling the nested references, however stops

after an iteration depth of 10. This catches the error that one line element uses another and

vice versa.

Elements can be duplicated by a preceding multiplication. The following is an example

26 GENESIS 1.3 – Manual

FODO: Line = {F,DRI,D,DRI};

LAT: Line = {6*FODO};

There is one diﬀerence between Genesis and Elegant/Madx. It allows a superposition of

secondary elements (everything except of undulator modules) so that correction and focusing

can be superimposed onto the undulator ﬁeld. An example is

UND: Undulator = {aw=1, lambdau=0.02, nwig=100};

FODO: Line = {UND,F@0.2,D@1.2};

The postﬁx @ with the position in meter places the element directly there. Note that it also

resets the counter. For a 10 cm long quadrupole the next position after F@0.2 would be 0.3

m. To avoid overlapping with succeeding elements it is better to deﬁne the pointer with a

marker element, e.g. the upper example can be improved with:

UND: Undulator = {aw=1, lambdau=0.02, nwig=100};

FODO: Line = {UND,F@0.2,D@1.2,M@2.0};

LAT: Line = {6*FODO};

If the absolute position places the element outside of an existing element than the missing

space is padded with a drift section.

Output and Input Files

Beside the input and lattice ﬁle, Genesis uses exclusively the HDF5 format for the output

ﬁles, which are the main output ﬁle, and the particle and ﬁeld dump. HDF5 is a well

supported format by many programs or programming languages which makes it easy to read

in the data. As an example, Matlab requires only a single line to read an entire dataset

such as the 2d array for the power, with sample points along the undulator and beam frame,

already converted to the right data type. This should make it easy to write your own

postprocesser. Nevertheless the Genesis distribution comes with some Matlab routines to

ease the parsing and display of the output ﬁles.

Main Output File

The main output ﬁle is written when ever the &track namelist is called. The name is given by

the speciﬁed rootname and the extension ’.out.h5’ for the ﬁrst call. If there are more than

one tracking commands the root is extended by the run number, such as ’.Run3.out.h5’

for the third time of tracking.

In the root level of the HDF5 ﬁles there are multiple groups, to organize the output data.

The group ’Global’ list the basic conﬁguration of the simulation such as reference energy

and wavelength or whether it is a time-dependent or scan run. The group Lattice contains

all lattice information. The undulator strength, quadrupole ﬁeld and other are resolved with

the resolution of the requested integration step size, which is given in the dataset dz. For

the z-position there exist two dataset. The regular one zhas the same length and describes

the lattice quantities from the position z[i] to z[i]+dz[i] of the ith integration step. The

dataset zplot is used for plotting the beam or ﬁeld parameters along the undulator. Note

that those are evalutated before the integration started, so that there can be one more

entry than the lattice datasets. Also if the output is reduced by the output step option in

the tracking command, the length of zplot is shorter because it has to match the length

of the beam and ﬁeld parameters. Another group is Meta which contains some additional

information, which are not stricktly related to the input case. These are the version number,

creation date and user, which has evoked the simulations.

The main data is contained in the Beam and Field record. In the case that additional

harmonics have been selected, there are additional Field groups, where the harmonic number

has been added. As an example Field3 would refer to the third harmonic. In the Beam group

there are parameters, which are evaluated at each integration steps. They are: energy, energy

spread, bunching, bunching phase, centroid position in x, y, px and py and the size in x and

y. Other parameters are only evaluated at the beginning, which are the optical function,

28 GENESIS 1.3 – Manual

emittance and current proﬁle, but in the future they might be becoming also larger, e.g.

when sorting is enabled and the current proﬁle can change. In the Field group one can ﬁnd

the power, position and size in x and y as well as the on-axis intensity and phase in the near

ﬁeld (central grid point) or far ﬁeld (summation over all grid points)

In general the units of the datasets should be given as attributes to the given dataset. This

hasn’t been implemented yet.

Particle and Field Dump

Particle dumps are following the data structure that each slice has its own 6D distribution

with the datasets gamma, theta, x, y, px, and py. In additions the local current value

is written as well. The slice number is encoded in the group name, which is the composition

of slice and the 6 digit representation of the slice numbers. Preceding spaces are changed

to zeros. E.g. the group name of the 7th slice is slice000007. The total number of slices

is given by the dataset slicecount. In addition some extra information is given on the

root level of the reference frame are deﬁned by the starting position refposition and the

sample length per slice slicespacing. The reference length slicelength can be used to

convert the ponderomotive phase into a longitudinal position in units of meter. Whether

the distribution has been generated with beamlets or resolving all electrons are indicated by

the parameters beamletsize and one4one.

In the ﬁeld dump has very similar structure than the beam dump, except that instead of

slicelength the ﬁeld is wavelength to distinguish between the fundamental or harmonic

radiation, while the beam is always measured against the fundamental wavelength for the

ponderomotive phase. The ﬁeld gridsize deﬁnes the extension of the 2D grid from the

origin to the edge along of the major axis. The slice groups contains the real and imaginary

part of the wavefront, however for programming reason the data record is one dimensional

with ngrid2elements. Any processing or display should convert it to a symmetric 2D array.

Particle Distribution

Genesis can import particle distribution which are generated by Elegant.However it does not

support the parsing of SDDS ﬁles directly. Instead it provides a simple shell script to convert

the typical SDDS distribution into a HDF5 ﬁle. This script expects that the SDDS toolkit is

installed because it extracts the columns t, p , x, y, xp, and yp from the SDDS ﬁles and

converts them into datasets with the same name in the HDF5 ﬁle. The short program will

add the extension ’.h5’ to the newly created ﬁle. This format is the one Genesis expects to

be imported. The corresponding charge is supplied in the namelist and therefore does not

need to be part of the HDF5 ﬁle.

The Postprocessor XGENESIS

Although the output format of Genesis is HDF5, where entire datasets can be read with

a single line in Matlab, the source code distribution also contains some Matlab functions,

which help with the postprocessing. They can be found in the directory xgenesis from the

root directory of the source code. It is recommended that the search path of Matlab extends

to that directory or that the ﬁles are copied to a locations where the search path already

points to.

The following is a brief description of the existing functions. More will come in the future.

xgeninit

The routine requires only the name of the output ﬁle, which then is parsed for the most

essential data, which is the size in zand sand the dataset tree structure. This function

needs to be called once. All other functions will make use of the data, which has been parsed

here. If another ﬁle needs to be read then xgeninit needs to be called again.

xgenplot

The main routine to display data from the output ﬁle and returns the data. It can generate

multiple plots at the same time and the return data type is a cell array, with each element

referring to a dataset in the plot. The dataset itself is a cell array as well, where the ﬁrst

element is the x-coordinate and the second the y.

The function requires up to three input arguments.In special cases, e.g. results from steady-

state simulations some options are restricted such as plotting along the time-window coor-

dinate is not meaningful and thus not supported.

The ﬁrst element mostly refers to the corresponding dataset in the input deck. The function

uses regular expression to match the dataset names with the requested plot data. As an ex-

ample plotting ’size’ will plot the sizes in x and y of the electron beam and each supported

radiation ﬁeld, so at least 4 plots and even more if harmonics were included. To restrict the

plots the requested plot can be more explicit, according to the tree structure in the output

ﬁle. As an example the input argument ’/Beam/.size’ would plot the x and y sizes of only

the electron beam while ’Field.*/.size does it for the radiation of the fundamental and

all harmonics. Besides the datasets in the output ﬁle there is one derived dataset, which

is the spectrum. The postprocessor can calculate it either from the near ﬁeld intensity and

30 GENESIS 1.3 – Manual

phase on axis or the equivalent pair in the far ﬁeld. If only ’spectrum’ is requested than

both are plotted. To select one of them, just specify as it would be done for the intensity,

e.g. ’spectrum-nearfield’.

If no further arguments are supplied then the ﬁrst slice of the speciﬁed data is plotted

along the undulator axis. This is in particular enforced for any lattice function, such as the

undulator ﬁeld. Also if the output data is from a steady-state ﬁle then the output is always

along undulator axis, despite that a proﬁle might be requested.

The second argument specify the plotting direction: either along undulator direction or

along bunch frame or frequency. If the data is a 2D array, e.g. such as the power after

a time-dependent run, than plotting a line need as the third argument the speciﬁcation of

the orthogonal position. Here the post processor chooses the line, which lies the closest to

the speciﬁed point. The default direction and plotting mode is ’normal’ plotting along

the undulator. To plot the power as an example at 3 microns of the bunch frame the plot

command is

xgeninit(’power’,’normal’,3e-6).

The direction along the bunch frame is indicated with ’profile’ such as

xgeninit(’power’,’profile’,11.5)

to plot around the position 11.5 m within the undulator lattice.

For 2D datasets from time-dependent simulations or scans xgenplot allows some condensed

plotting along the undulator: ’max’ for the maximum value of the given proﬁle, ’mean’ the

mean value, and ’rms’ the rms value. The evolution of the radiation bandwidth is calculated

best, using the ’rms’ option. In fact, RMS values are only meaningful for primary datasets,

which are power proﬁle, spectrum and current proﬁle. For all other parameters, such as

beam size it is recommended to use the mode ’weighted’ which is deﬁned as

P(z) = RP(s, z)·W(s, z)ds

RW(s, z)ds

where Pis the parameter to be display and Wthe weighting function. For electron beam

parameters it is the current while for radiation parameter it is the power proﬁle.

For a two-dimensional output the modes ’2d’ and ’2dnorm’ can be used. The latter diﬀers

from the former that for each step along the undulator the resulting proﬁle is normalized by

its mean value. This allows to exclude the dominant exponential change in some parameters

such as power, bunching or energy.

xgenwigner

This function calculates the 2D wigner distribution at a position within the undulator, which

is supplied as the input argument. The Wigner distribution is a very compact display of

time and spectral properties, namely the projection onto the time axis is the power proﬁle

and the projection on the frequency axis is the power spectrum.

Where to Find Further Information

GENESIS 1.3

https://gitlab.ethz.ch/Genesis/Genesis4

S. Reiche, ”Numerical Studies for a Single Pass High Gain Free-Electron Laser”, DESY

print, DESY-THESIS-2000-012 (2000)

FEL Basics

E.L. Saldin, E.A. Schneidmiller and M.V.Yurkov, ”The Physics of Free Electron Lasers”,

Springer, (2000)

J.B. Murphy and C. Pellegrini, ”Introduction to the Physics of the FEL”, Proceedings of

the South Padre Island Conference, Springer (1986) 163

Numeric Basics

W.H. Press, S.A. Teukolsky, W.T. Vetterling and B.P. Flannery, ”Numerical Recipes in

FORTRAN”, Cambridge University Press, (1988)

W.F. Ames, ”Numerical Methods for Partial Diﬀerential Equations”, Academic Press (1996)

C++

B. Stroustrup, ”C++ Programming Language”, Addison-Wesley (1997)

OpenMPI

https://www.open-mpi.org/

HDF5

https://support.hdfgroup.org/HDF5/

Manual

manual

Navigation menu

Versions of this User Manual:

Views

Navigation
