PLUMED User’s Guide
A portable plugin for free-energy calculations
with molecular dynamics
Version 1.3.0 – Nov 2011
Contents
1 Introduction 5
1.1 What is PLUMED? ......................... 5
1.2 Supportedcodes.......................... 6
1.3 Features .............................. 7
1.4 Newinversion1.3 ........................ 8
1.5 Restrictions ............................ 9
1.6 The PLUMED package ....................... 9
1.7 Onlineresources.......................... 10
1.8 Credits............................... 11
1.9 Citing PLUMED ........................... 11
1.10License............................... 11
2 Installation 13
2.1 Compiling PLUMED ......................... 13
2.1.1 Compiling the ACEMD plugin with PLUMED ...... 17
2.2 Including reconnaissance metadynamics . . . . . . . . . . . . . 18
2.3 Testing the installation . . . . . . . . . . . . . . . . . . . . . . 19
2.4 Back to the original code . . . . . . . . . . . . . . . . . . . . . 21
2.5 The Python interface to PLUMED ................. 21
3 Running free-energy simulations 23
3.1 How to activate PLUMED ..................... 23
3.2 Theinputfile ........................... 25
3.3 Anoteonunits.......................... 27
3.4 Metadynamics........................... 27
3.4.1 Typical output . . . . . . . . . . . . . . . . . . . . . . 27
3.4.2 Bias potential . . . . . . . . . . . . . . . . . . . . . . . 28
3.4.3 Well-tempered metadynamics . . . . . . . . . . . . . . 29
1
3.4.4 Restarting a metadynamics run . . . . . . . . . . . . . 30
3.4.5 Using GRID ........................ 30
3.4.6 Multiple walkers . . . . . . . . . . . . . . . . . . . . . 35
3.4.7 Monitoring a collective variable without biasing it . . . 35
3.4.8 Defining an interval . . . . . . . . . . . . . . . . . . . . 36
3.4.9 Inversion condition . . . . . . . . . . . . . . . . . . . . 38
3.5 Running in parallel . . . . . . . . . . . . . . . . . . . . . . . . 40
3.6 Replica exchange methods . . . . . . . . . . . . . . . . . . . . 40
3.6.1 Parallel tempering metadynamics . . . . . . . . . . . . 41
3.6.2 Bias exchange simulations . . . . . . . . . . . . . . . . 42
3.7 Umbrella sampling . . . . . . . . . . . . . . . . . . . . . . . . 45
3.8 SteeredMD ............................ 46
3.8.1 Steerplan ......................... 46
3.9 Adiabatic Bias MD . . . . . . . . . . . . . . . . . . . . . . . . 48
3.10 External potentials . . . . . . . . . . . . . . . . . . . . . . . . 50
3.10.1 Walls............................ 50
3.10.2 Tabulated potentials . . . . . . . . . . . . . . . . . . . 50
3.11 Commitment analysis . . . . . . . . . . . . . . . . . . . . . . . 53
3.12 Projection of gradients . . . . . . . . . . . . . . . . . . . . . . 53
3.13 Reconnaissance metadynamics . . . . . . . . . . . . . . . . . . 54
3.13.1 Typical output . . . . . . . . . . . . . . . . . . . . . . 54
3.13.2 Controlling the clustering . . . . . . . . . . . . . . . . 56
3.13.3 Controlling the bias . . . . . . . . . . . . . . . . . . . . 57
3.13.4 Restarting a simulation . . . . . . . . . . . . . . . . . . 58
3.13.5 Using a subset of the defined cvs . . . . . . . . . . . . 59
3.14 Driven Adiabatic Free Energy Dynamics (d-AFED) . . . . . . 60
3.14.1 Input for d-AFED . . . . . . . . . . . . . . . . . . . . 61
3.14.2 Typical output for d-AFED . . . . . . . . . . . . . . . 62
4 Collective variables 64
4.1 Absolute position . . . . . . . . . . . . . . . . . . . . . . . . . 66
4.2 Distance.............................. 67
4.3 Minimum distance . . . . . . . . . . . . . . . . . . . . . . . . 68
4.4 Angles............................... 69
4.5 Torsion............................... 70
4.6 Coordination number . . . . . . . . . . . . . . . . . . . . . . . 70
4.7 Hydrogenbonds.......................... 71
4.8 Interfacialwater.......................... 73
2
4.9 Radius of gyration . . . . . . . . . . . . . . . . . . . . . . . . 74
4.9.1 Gyration tensor based CVs . . . . . . . . . . . . . . . . 75
4.10Dipole ............................... 76
4.11 Dihedral correlation . . . . . . . . . . . . . . . . . . . . . . . . 77
4.12 Alpha-beta similarity . . . . . . . . . . . . . . . . . . . . . . . 77
4.13Alpharmsd............................. 78
4.14Antibetarmsd ........................... 79
4.15Parabetarmsd........................... 80
4.16 Electrostatic potential . . . . . . . . . . . . . . . . . . . . . . 81
4.17 Puckering coordinates . . . . . . . . . . . . . . . . . . . . . . 82
4.18 Path collective variables . . . . . . . . . . . . . . . . . . . . . 83
4.18.1 Mean square deviation . . . . . . . . . . . . . . . . . . 85
4.18.2 Distance mean square deviation . . . . . . . . . . . . . 87
4.18.3 Contact map distances . . . . . . . . . . . . . . . . . . 87
4.18.4 Using path variables as MSD, DMSD and CMAP and
the TARGETED statement ................. 91
4.19ContactMap ........................... 92
4.20Energy............................... 93
4.21Helixloops............................. 93
4.22PCAprojection.......................... 94
4.23 SPRINT topological variables . . . . . . . . . . . . . . . . . . 96
4.24 Radial distribution function . . . . . . . . . . . . . . . . . . . 97
4.25 Angular distribution function . . . . . . . . . . . . . . . . . . 98
4.26 Polynomial combination of CVs . . . . . . . . . . . . . . . . . 99
4.27FunctionofCVs..........................100
4.28 A note on periodic boundary conditions . . . . . . . . . . . . . 101
5 Postprocessing 103
5.1 Estimating the free energy after a metadynamics run . . . . . 103
5.1.1 Installation instructions . . . . . . . . . . . . . . . . . 103
5.1.2 Usage ...........................103
5.2 Evaluating collective variables on MD trajectories . . . . . . . 106
5.2.1 Installation instructions . . . . . . . . . . . . . . . . . 106
5.2.2 Usage ...........................106
5.3 Processing COLVAR files......................108
5.4 PLUMED as a standalone program . . . . . . . . . . . . . . . . . 109
5.4.1 Installation instructions . . . . . . . . . . . . . . . . . 109
5.4.2 Usage ...........................110
3
![](asset-6.png)
Chapter 1
Introduction
1.1 What is PLUMED?
PLUMED[1] is a plugin for free-energy calculations in molecular systems. It
works with some of the most popular classical molecular dynamics (MD)
codes, such as GROMACS [2], NAMD [3], DL POLY [4] , LAMMPS [5]
and the SANDER module in AMBER [6]. It also works with the very fast
CUDA/GPU MD code ACEMD [7] and, more recently, it has been extended
to work with ab initio MD codes, such as Quantum-ESPRESSO [8] and
CPMD.
Free-energy calculations can be performed as a function of many order
parameters, with a particular focus on biological problems, and using state-
of-the-art methods such as metadynamics [9], umbrella sampling [10, 11, 12]
and Jarzynski-equation based steered MD [13, 14].
Here is a brief outline of this guide:
•In this chapter we give an overview of the features and restrictions of
the current release of PLUMED.
•In the second chapter we describe the procedure for installing the plugin
and testing the correct installation.
•The third chapter explains how PLUMED can be used to perform free-
energy calculations, setting up the input file and analyzing the output.
•The fourth chapter contains a list of collective variables (CVs) which
are implemented and allow a wide variety of physical and chemical
problems to be addressed.
5
![](asset-7.png)
•The fifth chapter is dedicated to postprocessing. It explains how to
reconstruct the free-energy profile from the output of a metadynamics
run and how to extract the CV values from MD trajectories.
1.2 Supported codes
PLUMED works as an add-on to some of the most popular MD codes: NAMD,
GROMACS, SANDER, DL POLY, Quantum-ESPRESSO, ACEMD, LAMMPS
and CPMD. These codes are not distributed with the PLUMED package, but
they must be obtained separately.
NAMD 2.6/2.7/2.8
http://www.ks.uiuc.edu/Research/namd/
GROMACS 4.0/4.5.x
http://www.gromacs.org/
AMBER 10/11
http://ambermd.org/
DL POLY 2.20
http://www.cse.scitech.ac.uk/ccg/software/DL POLY/
Quantum-ESPRESSO 4.3.2
http://www.quantum-espresso.org/
ACEMD 1.2
http://multiscalelab.org/acemd
LAMMPS 27-Oct-2011
http://lammps.sandia.gov
CPMD 3.15.1
http://www.cpmd.org
Note that at the moment of this release of PLUMED, only those specific
versions of the listed codes have been tested. Moreover, some other codes
are available through the Python interface provided by Rosa Bulo.
Amsterdam Density Functional (ADF)
http://www.scm.com/
6
and all the codes supported by
Atomic Simulation Environment (ASE)
https://wiki.fysik.dtu.dk/ase/
Additionally there exist some porting to
FHI-AIMS
https://aimsclub.fhi-berlin.mpg.de/
which is not directly mantained by the PLUMED developer team. Addi-
tional information have to be retrieved by the developers of AIMS them-
selves.
1.3 Features
PLUMED can perform several different types of calculation:
•Metadynamics with a large variety of CVs [9];
•Well-tempered metadynamics [15];
•Multiple walkers metadynamics [16];
•Combined parallel tempering and metadynamics [17];
•Bias-exchange metadynamics [18];
•Reconaissance metadynamics [19];
•Steered MD;
•Umbrella sampling;
•Adiabatic biased molecular dynamics [20];
•Commitment analysis.
7
1.4 New in version 1.3
PLUMED version 1.3 presents several new features, including new collective
variables and support to new codes. Among these:
•Reconaissance Metadynamics [19];
•Driven adiabatic free energy dynamics (d-AFED, contributed by Michel
Cuendet)
•Definition of CVs as Polynomial combination of CVs and Function on
CVs;
•New INTERVAL keyword to limit a region to be sampled using Meta-
dynamics (contributed by Alessandro Laio)
•Better scalability with Gromacs;
•New collective variables: Projection on PCA eigenvectors (contributed
by Ludovico Sutto), SPRINT topological variable and gyration tensor
based CVs;
•New tool: reweight well-tempered metadynamics simulations [21];
•Added support to ACEMD 1.2, Lammps (27-oct-2011), Quantum Espresso
4.3.2, CPMD 3.15.1, NAMD 2.8, Gromacs 4.5.x and Amber11;
•Python interface (contributed by Rosa Bulo);
•New tool to perform bias-exchange simulations via the linux shell with
any MD code;
•Bugs have been fixed and the manual has been improved thanks to the
feedbacks of many users.
A full list including also the bug fixed in the current release can be found
in the CHANGES file distributed with the package.
8
![](asset-a.png)
1.5 Restrictions
The current release of PLUMED has a few restrictions:
•Parallel tempering plus metadynamics and bias-exchange metadynam-
ics are available only in the GROMACS version (however a tool allows
bias-exchange simulations via linux shell with any MD engine);
•The patched version of GROMACS cannot perform hamiltonian (lambda)
replica exchange;
•The ENERGY collective variable is available only for GROMACS, AM-
BER and DL POLY and cannot be used with multiple time step algo-
rithm;
•Only orthorhombic cells are supported in ACEMD and DRIVER;
•Only orthorhombic and truncated octahedron cells are supported in
AMBER;
•Only Car-Parrinello and Born-Oppenheimer simulations are supported
in CPMD;
•Only NVT simulations are supported because the contribution to the
virial is not calculated.
1.6 The PLUMED package
The plugin package has the following directory structure:
•common_files. The directory containing all the basic routines.
•tests. A variety of examples of different CVs and free-energy methods
provided with topology and input files for the supported codes. These
examples, combined with a script adapted from CP2K [22], work also
as a regtest for the plugin.
•patches. A collection of patches to interface PLUMED with different
codes.
•utilities. A few small utilities:
9
–sum_hills is a post-processing program which reads the HILLS
file produced by the plugin in a metadynamics simulation and
returns the free energy by summing the Gaussians that have been
deposited.
–driver is a tool that calculates the value of selected CVs along a
MD trajectory. It requires a PDB file, a trajectory in DCD format
and a file with the same syntax of the PLUMED input file.
–standalone is a program to run PLUMED as a standalone code.
–plumedat.sh is a shell script to extract information from PLUMED
output files.
–reweight is a tool to calculate the unbiased probability distribu-
tion of variables other than the CVs in well-tempered metady-
namics simulations
–python_interface a set of tools that enables to use PLUMED with
Python (hey, a Python which is plumed with feathers is a really
weird animal!).
–bias-exchange a set of tools that allow to use PLUMED to perform
bias-exchange simulations via the linux shell using any MD engine.
•manual. This manual.
•ACEMD. It contains the files needed to compile the plugin for ACEMD.
•tutorial. It contains the resources of the PLUMED tutorial 2010 (http:
//sites.google.com/site/plumedtutorial2010/)
•recon_src. It contains the source files specific for the Reconaissance
Metadynamics.
1.7 Online resources
You can find more information on the web:
http://www.plumed-code.org
For any questions, please subscribe to our mailing list:
plumed-users@googlegroups.com
10
1.8 Credits
PLUMED has been developed by Massimiliano Bonomi, Davide Branduardi,
Giovanni Bussi, Carlo Camilloni, Davide Provasi, Paolo Raiteri, Davide
Donadio, Fabrizio Marinelli, Fabio Pietrucci, Francesco Luigi Gervasio and
others. However, this work would not have been possible without the joint
effort of many people. Among these, we would like to thank (in alphabetical
order): Alessandro Barducci, Anna Berteotti, Rosa Bulo, Matteo Ceccarelli,
Michele Ceriotti, Paolo Elvati, Antonio Fortea-Rodriguez, Alessandro Laio,
Matteo Masetti, Fawzi Mohamed, Ferenc Molnar, Gabriele Petraglio, Jim
Pfaendtner and Federica Trudu. Francesco Marini is kindly acknowledged
for his technical support and Joost VandeVondele for permission to use his
regtest script.
Some PLUMED users have also contributed to the implementation of new
features and the debugging of old bugs. Among these, we would like to thank:
Toni Giorgino, Marcello Sega, Emmanuel Autieri, Gareth Tribello, Andrea
Coletta, Ludovico Sutto, Layla Martin-Samos, Walter Rocchia, Alessio Lodola,
Luigi Capoferri, Michel Cuendet, Jiri Vymetal, Fahimeh Baftizadeh, and
Katsumasa Kamiya.
1.9 Citing PLUMED
You may wish to cite the following reference if you have utilized PLUMED in
your work:
M. Bonomi, D. Branduardi, G. Bussi, C. Camilloni, D. Provasi, P. Raiteri,
D. Donadio, F. Marinelli, F. Pietrucci, R.A. Broglia and M. Parrinello.
PLUMED: a portable plugin for free-energy calculations with molecular
dynamics, Comp. Phys. Comm. 2009 vol. 180 (10) pp. 1961-1972.
1.10 License
PLUMED is free software: you can redistribute it and/or modify it under the
terms of the GNU Lesser General Public License as published by the Free
Software Foundation, either version 3 of the License, or (at your option)
any later version. PLUMED is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See
11
![](asset-e.png)
Chapter 2
Installation
The plugin installation requires the molecular dynamics code to be recom-
piled after the calls to the plugin routines have been inserted at the appro-
priate places in the original program. For a list of the supported molecular
dynamics codes see Sec. 1.2.
All the basic plugin routines are contained in the common files folder of
the PLUMED distribution package. The insertions are automatically performed
by a series of scripts provided in the patches directory.
In the following we will briefly describe the procedure for applying these
patches to the different MD codes supported by PLUMED. We will refer to the
root directory of the distribution package as PLUMED root.
2.1 Compiling PLUMED
A similar procedure can be followed for all the supported codes except
ACEMD. When code-specific procedures are needed, we state it explicitely.
A different proceedure is required for ACEMD (see below).
Different patches are available for different code versions. The name of
the suitable patch is plumedpatch CODENAME CODEVERSION.sh. If the patch
corresponding to the exact CODEVERSION that you are using is not avail-
able, choose the closest match. In the following, we shall indicate with
plumedpatch.sh the proper patch script.
•Extract the source code from its archive and then move into its root
directory.
13
![](asset-f.png)
•Configure the code as usual (not necessary for DL POLY)
•NAMD and LAMMPS only: In the plumedpatch script, modify the
myarch variable to match your architecture.
•Set the environmental variable plumedir to point to PLUMED root.
•Copy or link the plumedpatch.sh file from the patches folder to the
current directory.
•Execute the script: ”./plumedpatch.sh -patch ”.
•DL POLY-only: copy the proper Makefile from build/ to srcmod/ (or
src/ in older versions)
•CPMD only: you may need to change variables cxx, cxxflag, extraflag
in the plumedpatch script depending on your computer architecture:
see the examples below.
•Compile the code as usual.
Further details can be found in the patches/README file.
Example.
This is the procedure for compiling the serial version of AMBER 10 with PLUMED using g95 in the Bourne
shell.
tar zxf AMBER10.tgz
cd amber10/
export plumedir="PLUMED root"
cp $plumedir/patches/plumedpatch sander 10.sh .
cd src/
./configure g95
cd ..
./plumedpatch sander 10.sh -patch
make
14
![](asset-10.png)
Example.
This is the procedure for compiling the serial version of GROMACS, using the GNU compilers.
tar zxf gromacs-4.0.5.tar.gz
cd gromacs-4.0.5
export plumedir="PLUMED root"
cp $plumedir/patches/plumedpatch gromacs 4.0.4.sh .
CC=gcc CXX=g++ ./configure
./plumedpatch gromacs 4.0.4.sh -patch
make
make install
Example.
This is the procedure for compiling NAMD on an Intel Mac using the GNU g++ compiler and the FFTW.
tar zxf NAMD 2.6 Source.tar.gz
cd NAMD 2.6 Source
export plumedir="PLUMED root"
cp $plumedir/patches/plumedpatch namd 2.6.sh .
./config fftw MacOSX-i686-g++
Edit ./plumedpatch namd 2.6.sh by setting the myarch variable to MacOSX-i686-g++.
./plumedpatch namd 2.6.sh -patch
cd MacOSX-i686-g++
make
Example.
This is a sample procedure for compiling the scalar version of DL POLY 2.20 with the gfortran compiler
in the Bourne Shell environment.
tar zxf dl poly 2.20.tar.gz
cd dl poly 2.20
export plumedir=PLUMED root
cp $plumedir/patches/plumedpatch dlpoly 2.20.sh .
./plumedpatch dlpoly 2.20.sh -patch
cp build/MakeSEQ srcmod/Makefile
cd srcmod
make gfortran
15
![](asset-11.png)
Example.
This is a sample procedure for compiling the openmpi version of LAMMPS with the mpic++ compiler in
the Bourne Shell environment. Please, note that the LAMMPS tarball comes with the download date but
unless major changes are done in the host code, the patching procedure will stay unchanged and the
latest available patching file has to be used.
tar xvf lammps-15Jan10.tar
cd lammps-15Jan10/
Edit ./src/MAKE/Makefile.openmpi to suit your machine.
export plumedir="PLUMED root"
cp $plumedir/patches/plumedpatch lammps 15-01-2010.sh ./
Edit ./plumedpatch lammps 15-01-2010.sh to set myarch to openmpi.
./plumedpatch lammps 15-01-2010.sh -patch
cd src
make openmpi
16
![](asset-12.png)
Example.
This is a sample procedure for compiling CPMD-3.15.1 under different computer architectures.
tar zxvf cpmd-v3 15 1.tgz
cd CPMD
Generate a valid Makefile for your machine using the script ./mk config.sh, e.g.:
./mk config.sh PC-GFORTRAN > Makefile
export plumedir="PLUMED root"
cp $plumedir/patches/plumedpatch cpmd-3.15.1.sh .
If necessary, modify the variables cxx (a valid C++ compiler), cxxflag (the corresponding flag to
avoid exception handling), and extraflag (see below) in the script plumedpatch cpmd-3.15.1.sh, e.g.
for GNU compilers:
cxx="mpiCC"
cxxflag="-fno-exceptions"
for IBM machines like AIX-power7:
cxx="xlc r -c"
cxxflag="-qnoeh"
for IBM BlueGene:
cxx="bgxlc++ r -c -O"
cxxflag="-qnoeh"
for PGI compilers:
cxx="pgCC"
cxxflag="--no exceptions"
To successfully compile on some IBM architectures you may also need to set one or both of the
following extra flags:
extraflag="-DPLUMED CPMD NOUNDERSCORE -DPLUMED AIXXLF"
Finally, patch and compile:
./plumedpatch cpmd-3.15.1.sh -patch
make
2.1.1 Compiling the ACEMD plugin with PLUMED
PLUMED works with ACEMD 1.2. As the source code for ACEMD is not
available, PLUMED will work as a plug-in. For this reason the compilation
will be slightly different from that of the other codes. Moreover, given the
unavailability of source code, this version of PLUMED will not be supported
by the PLUMED development team.
•Extract the source code from its archive.
•Set the environmental variable plumedir to point to PLUMED root.
17
![](asset-13.png)
•Use make to compile the plugin inside the plumedir/ACEMD folder.
Example.
This is a sample procedure for compiling the ACEMD plug-in in the Bourne Shell environment.
export plumedir=PLUMED root
cd $plumedir ACEMD
make
Once the plumed.so is compiled, copy it where you will run ACEMD. Add
the following lines to the ACEMD input file:
pluginload testplug ./plumed.so
pluginarg testplug input META_INP
pluginarg testplug boxx xx
pluginarg testplug boxy yy
pluginarg testplug boxz zz
pluginfreq 1
where META INP is the PLUMED input file and xx,yy,zz are the box di-
mensions. At this time the support of the ACEMD plugin will be provided
by the ACEMD developers. Please note that only orthorhombic cells are
available in ACEMD 1.2.
2.2 Including reconnaissance metadynamics
The reconnaissance metadynamics routines (see section 3.13 included in PLUMED
make use of the C++ standard library and lapack. On some machines these
libraries are not installed. Hence, PLUMED has been written so that by default
no attempt to compile reconnaissance metadynamics is made. Consequen-
tially, if you wish to perform reconnaissance metadynamics you must patch
PLUMED slightly differently.
To include reconnaissance metadynamics in your patched MD code is
simply a matter of, during the patching procedure, telling PLUMED the lo-
cation of the C standard library, the location of lapack and the location of
18
![](asset-14.png)
a c++ compiler. This is done by making some small modifications to the
plumedpatch file. If this file is opened using a text editor you will notice at
least one of the following two lines:
RECON_LIBS=
RECON_CPP=
If at least one of these lines is not present then reconnaissance metady-
namics is not implemented for the particular code you are patching. The
first of these two lines tells PLUMED the locations of the lapack and c stan-
dard libraries. If the space after the equal sign is left blank PLUMED patches
in its default fashion and no attempt is made to compile the reconnaissance
metadynamics routines. By contrast if there is any character after the equals
sign PLUMED will endeavor to compile the reconnaissance metadynamics rou-
tines. For a correct compilation the RECON_LIBS}variable should indicate the
locations of the lapack (i.e. -llapack) and c standard libraries (i.e. -lstdc++).
The RECON_CPP= variable should be set equal to a c++ compiler (e.g. g++).
Example.
To include the reconnaissance metadynamics routines in the PLUMED compilation the use must change
the values of RECON LIBS and RECON CPP in the plumedpatch file:
RECON LIBS=”-llapack -lstdc++”
RECON CPP=”g++”
There are some differences between the procedures for patching PLUMED+
reconnaissance metadynamics in the different MD codes between the different
codes. This is because some of the codes already have lapack included or are
compiled with a c++ compiler. These differences are described in table 2.1:
2.3 Testing the installation
Once the installation process has been completed successfully, the user is
encouraged to test the chosen MD package for any problems. The tests
directory contains regtest scripts for the different MD codes. These also
serve as a regularity test in case the user implements his own modifications
and as a basic illustration of the capabilities of the plugin. The user should
19
![](asset-15.png)
Code Reconnaissance C++ compiler Lapack lstc++
implemented required required required
NAMD yes no yes yes
GROMACS yes yes no yes
AMBER no - - -
DL POLY yes yes yes yes
Q-ESPRESSO yes yes no yes
ACEMD no - - -
LAMMPS no - - -
CPMD yes yes no yes
Table 2.1: Details on compiling PLUMED compilation with the various codes
edit the test script, setting up the path where the test suite is found and
giving the location of the executable.
For GROMACS users only. Please note that:
•The tests for GROMACS are designed for and should be executed with
the double-precision version of the code;
•Biasxmd, ptmetad, dd and pd are designed for the parallel version of
GROMACS. The user should specify in the test script the location of
the parallel executable and the version of GROMACS used. These tests
will fail if the parallel version of GROMACS has not been compiled.
Example.
In the case of NAMD, the regtest script is called do regtest namd.sh. Here, the user should modify the
dir base and the namd prefix:
dir base=/Programs/md meta/tests/namd
namd prefix=/chicco/bin/namd plugin/namd2.
Regtest scripts for the other programs require an identical procedure.
The script executes a list of tests and then compares the results with the
outcome of previously run simulations. Please note that when the script is
run for the first time it produces the reference. Finally, the script produces
a summary of the results. The test result can be one of the following:
20
![](asset-16.png)
•’OK’ if the results match those of a previous run precisely. The execu-
tion time is also given.
•’NEW’ if they have not been executed previously. The reference result
is generated automatically in this run. Tests can also be ’NEW’ if they
have been reset, i.e. been newly added to the TEST FILES RESET
files.
•’RUNTIME FAILURE’ if they stopped unexpectedly (e.g. core dump,
or stop).
•’WRONG RESULT’ if they produce a result that deviates from an old
reference.
The last two options generally mean that a bug has been introduced,
which requires investigation. Since regtesting only yields information relative
to a previously known result, it is most useful to do a regtest before and after
you make changes.
2.4 Back to the original code
At any time the user may want to ”unpatch” the MD code and revert back
to the original distribution. To do so, the user should go to the directory
where the PLUMED patch has been copied and type ./plumedpatch -revert.
2.5 The Python interface to PLUMED
Starting from version 1.3 PLUMED has also a Python interface contributed by
Rosa Bulo. It is possible to find it in the utilities/python_interface
directory. Inside it you might find a README file and a Makefile . After
copying (or linking) all the *.c and *.h files from the common_files direc-
tory you can immediately do:
make gnu
if you want to compile with gnu compilers. Intel compilers are also avail-
able. This creates a file that is libplumed.so that will be loaded runtime
by Python. You need to add the directory where this file resides into the
LD LIBRARY PATH so that Python will be able to find it and load it runtime.
The extension amber is only reflecting the fact that the interface is built by
21
![](asset-17.png)
exploiting the simple AMBER interface. Therefore the limitiations regarding
AMBER in the functionalities apply also here.
For MacOSX users the compiler flags should be changed accordingly. For
gnu compilers it requires to change the linking flags from
-shared -Wl,-soname,libplumed.so
to
-bundle -flat namespace -undefined suppress.
Next, in the directory
utilities/python_interface/pylib
you can find the file plumedamberlib.py which is the actual Python mod-
ule that will deal of loading libplumed.so and create the suitable Python
interface. This provides the init metadyn and cv calculation methods
that one can practically use through Python.
A practical use of this shown by the Python script
/utilities/python interface/test/run water amber.py
where a water molecule is simply displaced and the collective coordinates are
updated at each step. Notably, this interface is embodied in the Python tools
provided with the Amsterdam Density Functional code (also called ADF, see
http://www.scm.com/).
Additionally Rosa provided an interface with the powerful Atomic Simulation
Environment ( see https://wiki.fysik.dtu.dk/ase/ ). This enable PLUMED
to be interfaced with plenty of DFT and ab-initio codes. Some examples
are present in the directory utilities/python interface/test and are
ASEmd plumed emt water.py and ASEnvt plumed emt water.py .
Many thanks to Rosa for the contribution!
22
![](asset-18.png)
Chapter 3
Running free-energy
simulations
In this chapter we describe how to activate PLUMED and how to create the
correct PLUMED input file for a specific type of free energy calculation. The
typical output of these calculations is also explained in detail.
3.1 How to activate PLUMED
PLUMED input is contained in one single file, named plumed.dat by default,
which defines the CVs, the type of run to be performed and the parameters
for the bias potential generation.
•The users of NAMD, SANDER and DL POLY can instruct the code
to parse the PLUMED input file by setting the PLUMED variable to on (or
1 for SANDER) in the MD input file. It is also possible to change
the default name for the PLUMED input file by setting the plumedfile
variable in the MD input;
•GROMACS users should activate PLUMED on the command line by spec-
ifying the flag -plumed followed by the input file name. The extension
of such a file must be .dat;
•Quantum-ESPRESSO users should activate PLUMED on the command
line by specifying the flag -plumed. The name of the PLUMED input file
is hardcoded as plumed.dat;
23
![](asset-19.png)
•In LAMMPS, PLUMED is activated using the fix plumed. The input file
is specified by plumedfile, the output file by outfile;
•In CPMD, PLUMED is activated on the command line by specifying the
flag -plumed after the CPMD input file and the pseudopotential direc-
tory. The PLUMED input file name is plumed.dat.
Example.
A typical SANDER input file for a metadynamics calculation:
METADYNAMICS TEST
&cntrl
imin=0, irest=0, ntx=1, ig=71278,
nstlim=1001, dt=0.0002,
ntc=1, ntf=1,
ntt=3, gamma ln=5,
tempi=300.0, temp0=300.0,
ntpr=200, ntwx=0,
ntb=0, igb=0,
cut=999.,
plumed=1 , plumedfile=’plumed.dat’
/
Example.
The NAMD and DL POLY input file should contain, in addition to the usual keywords defining the run, the
following lines;
plumed on
plumedfile plumed.dat
Example.
To perform a free-energy calculation with GROMACS, PLUMED must be activated on the command line:
mdrun -plumed plumed.dat ...
Example.
To perform a free-energy calculation with Quantum-ESPRESSO, PLUMED must be activated on the
command line:
pw.x -plumed ...
24
![](asset-1a.png)
Example.
The LAMMPS input file should contain, in addition to the usual keywords defining the run, the following
line;
fix 3 all plumed plumedfile plumed.dat outfile metaout.dat
Example.
To perform a free-energy calculation with LAMMPS the file should contain, in addition to the usual
keywords defining the run, the following command:
fix ID all plumed plumedfile plumed.inp outfile plumed.out
where ID is the user assigned fix name.
Example.
To perform a free-energy calculation with CPMD, PLUMED must be activated on the command line:
cpmd.x input . -plumed
where input is the CPMD input file, ”.” is the current directory (if pseudopotentials are located
elsewhere, substitute with the right location), and the PLUMED input file is called plumed.dat.
3.2 The input file
In the following sections we describe the syntax used in the PLUMED input file.
The commands contained in this file can be divided in two groups according
to the functionality required. A first group of commands defines the type of
simulation (metadynamics, steering and umbrella sampling, replica exchange
methods) and the parameters needed for the chosen algorithm. These are
described in this chapter. A second part defines the degrees of freedom on
which the algorithms operate, the so-called collective variables or CVs. The
details of such commands are described in the next chapter.
As a general rule, each setting is defined by a principal keyword that
must be placed at the beginning of the line, in upper case. Additional input
pertaining to the setting can be specified on the same line, using additional
25
![](asset-1b.png)
keywords that can be added in any order. A line can be continued to the
next one by adding a backslash or an ampersand as a last character in the
line. Three kinds of keyword may exist: the directives, which must be placed
at the beginning of a line and define the argument of the line, the keywords,
which specify the attributes of the different fields in the line and flags, which
simply turn a given option on or off.
Example.
The following is an example of a complete PLUMED input file. In this case the input defines a well-tempered
metadynamics run with two CVs; the first is the distance between two atoms, and the second a dihedral
angle.
# general options
HILLS HEIGHT 0.1 W STRIDE 100
WELLTEMPERED SIMTEMP 300 BIASFACTOR 10
# print each 50 time units and add a time offset of 20.0 to COLVAR
PRINT W STRIDE 50 T OFFSET 20.0
# definition of CVs
NOTE distance between hydrogens
DISTANCE LIST 13 46 SIGMA 0.35
NOTE torsional angle
TORSION LIST 1 4 65 344 SIGMA 0.1
# wall on the CV
UWALL CV 1 LIMIT 15.0 KAPPA 100.0 EXP 4.0 EPS 1.0 OFF 0.0
ENDMETA
The ENDMETA directive is the last line read from the PLUMED input file and
any line added after this keyword will be ignored.
The symbol #allows the user to comment any line in the input file. The
directive NOTE allows the user to place comments which are copied to the
PLUMED log file.
The PRINT allows to dump a file called COLVAR (see more in 3.4) which is
written each W STRIDE timesteps and (optional) a time offset can be specified
through the TOFFSET keyword. To append the colvar values to an existing
COLVAR file, the flag APPEND can be used.
26
![](asset-1c.png)
3.3 A note on units
The values in the PLUMED input file are read in the internal units for the MD
engine. For DL POLY the energy in input can be in different user-specified
units; to be consistent, the values in the PLUMED input file must be in the
same units specified in the FIELD file.
3.4 Metadynamics
The metadynamics algorithm applies additional forces to a standard molec-
ular dynamics simulation [9, 23, 24]. In this case, the PLUMED input file must
contain the definition of at least one CV (see chapter 4 for the required
syntax), and the HILLS keyword which defines the details of the bias poten-
tial (see section 3.4.2). In this case the biasing potential will be calculated
and applied to the microscopic degrees of freedom during the run. Before
discussing the additional optional commands (section 3.4.2), we give a brief
overview of the file produced in a typical metadynamics run.
3.4.1 Typical output
Standard metadynamics will produce, in addition to the usual output files
generated by the MD engine, a file called COLVAR that contains the following
data:
•The first column contains the time step;
•The following dcolumns contain the values of the CV(s);
•Two additional columns contain the value V(s, t) of the bias potential
at the given point and time, and the potential due to the walls (if
defined).
Since PLUMED 1.2, a more flexible format for COLVAR has been introduced.
Here, the first line of the COLVAR file is a header. The line begins with #,
so as to be ignored by plotting programs such as gnuplot and xmgrace. A
small script plumedat.sh to interpret this file is provided in the utilities.
27
![](asset-1d.png)
Another file, called HILLS, contains the information of the biasing poten-
tial needed to estimate the free-energy, and to restart metadynamics runs.
The bias potential is given by:
V(~s, t) = X
kτ <t
W(kτ) exp
−
d
X
i=1
(si−s(0)
i(kτ))2
2σ2
i
.(3.1)
Specifically,
•The first column contains the time step at which the contribution to
the bias potential was added, τ, 2τ, etc.;
•The following dcolumns contain the values ~s(0)(t) specifying the posi-
tion of the centroid of the Gaussian;
•The next dcolumns contain the values ~σ specifying the Gaussian width
along the different directions in the CV space;
•The last column but one contains the value Wof the Gaussian height;
•The last column contains the bias factor defined in well-tempered meta-
dynamics.
Please refer to section 5.1 for a description of how the potential in equation
3.1 can be computed from the HILLS file.
It is important to note that a metadynamics run should typically start
from an equilibrated system. The equilibration protocol can be applied with-
out resorting to the PLUMED input file. However, in order to gain important
information concerning the behavior of the run and the tuning of the pa-
rameters of the metadynamics biasing potential, it is useful to monitor the
behavior of the CVs during the equilibration run. To this aim, just skip the
HILLS directive: in this way, only the COLVAR file will be generated.
3.4.2 Bias potential
The HILLS directive is used to define the details of the biasing potential. It
must be followed by the definition of the weight factor W, preceded by the
keyword HEIGHT (see the note on units in section 3.3). Also the frequency at
which the Gaussians are deposited and written into the HILLS file must be set
using W STRIDE followed by the number of MD steps between two successive
28
![](asset-1e.png)
depositions. The Gaussian width must be set in the proper CV line using
the keyword SIGMA.
Notice that the HILLS directive is not compatible with the COMMITMENT di-
rective.
Example.
The following line switches on metadynamics with Gaussian height of 0.1 (in energy unit of the MD code)
and deposition stride of 1000 MD steps.
HILLS HEIGHT 0.1 W STRIDE 1000
3.4.3 Well-tempered metadynamics
The WELLTEMPERED directive activates well-tempered metadynamics [15] which,
by rescaling the Gaussian weight factor, guarantees the theoretical conver-
gence of metadynamics. In the well-tempered algorithm, the rate at which
the bias potential is added is decreased during the simulation proportionally
to e−V(s,t)/∆T, where ∆Tis a characteristic energy:
V(s, t) =
t0<t
X
t0=0,τG,2τG,...
W e−V(s(q(t0),t0)/∆Texp −
d
X
i=1
(si(q)−si(q(t0))2
2σ2
i!,(3.2)
where W=τGωis the height of a single Gaussian.
For a given temperature of the system T(specified with the keyword SIMTEMP),
the CVs are sampled at a fictitious higher temperature T+ ∆Tdetermined
by the bias factor (T+ ∆T)/T . The user must specify this bias factor using
the keyword BIASFACTOR.
Example.
The following commands define a well-tempered metadynamics run, in which the CVs are sampled at the
higher temperature of 3000 K. The initial Gaussian height is 0.1 (in energy unit of the MD code) and the
deposition stride is 1000 MD steps.
HILLS HEIGHT 0.1 W STRIDE 1000
WELLTEMPERED SIMTEMP 300 BIASFACTOR 10
It should be noted that, in the case of well-tempered metadynamics, in
the output printed on the HILLS file the Gaussian height is rescaled using
the bias factor. This is done in order to directly obtain the free energy (and
not the bias), when summing all the Gaussians deposited during the run.
29
![](asset-1f.png)
3.4.4 Restarting a metadynamics run
In order to restart a metadynamics run, the flag RESTART must be added on
the line of the directive HILLS. It allows a metadynamics simulation to be
restarted after an interruption or after a run has finished. The HILLS files
will be read at the beginning of the simulation and the bias potential applied
to the dynamics. Note that the presence of the RESTART flag only affects
the metadynamics part of the simulation, and thus the usual procedure for
restarting a MD run must be followed. This depends on the particular MD
engine used and can be found in the relative documentation.
Example.
The following is an example of input file for restarting a metadynamics simulation.
HILLS RESTART HEIGHT 0.1 W STRIDE 1000
In case of well-tempered metadynamics, the Gaussians height is rescaled
in input according to the bias factor. This is done assuming that the sum
of the Gaussians stored in the HILLS file is an estimate of the (negative)
free energy landscape. Since the estimate of the free energy is in principle
independent from the choice of the bias factor, it is correct to restart a
well-tempered simulation with a different bias factor or even restart from a
non-well-tempered simulation.
3.4.5 Using GRID
Normally the additional forces of metadynamics are calculated every MD
step by summing the contribution coming from the Gaussians deposited up
to this point, following Eq. 3.2. As the simulation goes on, the computational
time spent in the evaluation of these forces becomes larger and larger and
eventually comparable with the time needed to calculate the contribution
of the force field itself. This effect is particularly visible when the system
simulated is small or when using a simplified coarse grained potential.
A possible solution is to store an array containing the current value of the
bias potential (and of the derivatives with respect to the CVs) on a grid. In
this way the computational cost of metadynamics becomes constant all over
the simulation and corresponds to the cost of evaluating a single Gaussian
function on the whole grid with a frequency given by the stride between
30
![](asset-20.png)
subsequent hills. This approach is similar to that proposed in Ref. [25],
but has the advantage that the grid spacing is independent on the Gaussian
width.
This operation can be demanding if the number of collective variable
and/or the number of grid bins is high. However, the cost of adding the
Gaussian on the grid can be substantially reduced taking into account that
this function is almost zero outside a characteristic range determined by
the Gaussian sigma. In PLUMED this interval is calculated once (or at every
modification of sigma) and used to build a smaller sub-grid on which the
potential is updated.
In order to use the grid, the directive GRID must be added together with
the keyword CV to specify the collective variable, MIN and MAX to fix the CV
interval, NBIN for the number of bins and the flag PBC if the CV is periodic.
Example.
In this example we run metadynamics using only one CV, a distance between two atoms, and we put the
bias potential on a grid of 200 bins in the interval between 0.0 and 10.0.
HILLS HEIGHT 0.1 W STRIDE 1000
PRINT W STRIDE 50
DISTANCE LIST 13 46 SIGMA 0.35
GRID CV 1 MIN 0.0 MAX 10.0 NBIN 200
ENDMETA
Special labels can be used in the definition of the interval with MIN and
MAX, such as -pi, +pi, +2pi, -2pi, pi, 2pi. These labels may be par-
ticularly useful with the CVs ANGLE or TORSION.
Example.
In this example we run metadynamics using a dihedral angle and putting the bias potential on a periodic
grid of 200 bins in the interval between -pi and pi.
HILLS HEIGHT 0.1 W STRIDE 1000
PRINT W STRIDE 50
TORSION LIST 13 15 17 19 SIGMA 0.35
GRID CV 1 MIN -pi MAX +pi NBIN 200 PBC
ENDMETA
As in standard metadynamics, a HILLS file containing the list of Gaussians
deposited is produced. This file is needed for restarting a metadynamics
31
![](asset-21.png)
simulation also when using GRID.
The bias potential in a generic point is calculated by a polynomial inter-
polation which has the proper values of the function and of its derivatives
in 2dpoints, where dis the number of collective variables. The forces are
then obtained as the analytical derivatives of the bias. You can switch off
the use of splines by using the directive NOSPLINE. In this case, the bias and
forces are simply taken at a close grid point (this requires a much denser grid).
Please also note that:
•GRID must be activated (or switched off) on ALL the CVs;
•GRID can be used together with multiple walkers metadynamics, bias-
exchange and parallel tempering metadynamics;
•For a correct calculation of the potential and forces, the bin size must
be smaller than half the Gaussian sigma. If a larger size is used, the
code will stop.
•If the simulation goes out of the grid, the code will stop. Please increase
MIN or MAX and restart metadynamics.
Writing a GRID to file
The directive WRITE GRID allows to save on a file the grid on which the bias
potential is stored and the relative forces. The keyword W STRIDE can be
used to specify the writing stride and FILENAME the name of the file. Since
saving the entire grid on file may take some time, a reasonable writing stride
should be used.
Example.
The following command controls a metadynamics calculation using as CV the distance between two
atoms. The bias potential is stored on a grid and saved to the file bias.dat every 100000 steps.
HILLS HEIGHT 0.1 W STRIDE 1000
DISTANCE LIST 10 12 SIGMA 3.0
GRID CV 1 MIN 0.0 MAX 10.0 NBIN 10
WRITE GRID FILENAME bias.dat W STRIDE 100000
The file on which the grid is saved has a specific format. A header contains
information about the presence of force data, the number and type of CVs,
32
![](asset-22.png)
the grid dimension and boundaries and whether the CVs are periodic or not.
The rest of the file contains for each grid point the value of the bias potential
and forces (i.e. minus the derivative of the potential with respect to the
CVs).
Example.
The header states that force data are on file, only one CV is present (a distance, see Tab. 3.1 for a
legend). The grid is made of 10 bins ranging from 0 to 10 in unit of the CV. This CV is not periodic.
#! FORCE 1
#! NVAR 1
#! TYPE 1
#! BIN 10
#! MIN 0.000000
#! MAX 10.000000
#! PBC 0
0.000000 0.998838 -0.016081
1.000000 0.960195 0.091229
2.000000 0.825978 0.170252
3.000000 0.635806 0.201699
4.000000 0.437950 0.187594
5.000000 0.269942 0.145621
6.000000 0.148888 0.096861
7.000000 0.073484 0.055971
8.000000 0.032454 0.028326
9.000000 0.012826 0.012620
10.000000 0.004536 0.004967
This file can be used to plot the free energy resulting from a metadynamics
simulation instead of summing the Gaussians stored on the HILLS file with the
post-processing code sum_hills. When using well-tempered metadynamics,
please remember that the bias potential does not compensate exactly the
underlying free energy [15]. In this case, the potential written on file must
be rescaled accordingly.
Reading a GRID from file
The bias potential stored on file can be used to restart a metadynamics simu-
lation by specifying the directive READ GRID and the file name with FILENAME.
33
![](asset-23.png)
Example.
The following command controls a metadynamics calculation using as CV the distance between two
atoms. The initial bias potential is read from the file bias.dat.
HILLS HEIGHT 0.1 W STRIDE 1000
DISTANCE LIST 10 12 SIGMA 3.0
GRID CV 1 MIN 0.0 MAX 10.0 NBIN 10
READ GRID FILENAME bias.dat
Please also note that:
•The CV number and type in the header must be consistent with what
declared in the PLUMED input file;
•The number of bins and the boundaries in the header can be different
from what declared in the PLUMED input file. In this case the parameters
of the PLUMED input file will be used and the grid present on file will be
interpolated to fit the new dimensions;
•If force data are not present on file, they will be calculated from the
bias potential using finite differences;
•READ GRID is not compatible with the MULTIPLE WALKERS directive.
Restarting a metadynamics run from a grid written on file is fully com-
patible with the standard restart by reading a HILLS file created in a previous
run.
Example.
The following command controls a metadynamics calculation using as CV the distance between two
atoms. The initial bias potential is read from the file bias.dat. To this initial bias, the Gaussians de-
posited on the HILLS file are added.
HILLS RESTART HEIGHT 0.1 W STRIDE 1000
DISTANCE LIST 10 12 SIGMA 3.0
GRID CV 1 MIN 0.0 MAX 10.0 NBIN 10
READ GRID FILENAME bias.dat
34
![](asset-24.png)
3.4.6 Multiple walkers
The MULTIPLE WALKERS directive sets the multiple walkers [16] running mode.
All the processes must have the same CVs, in the same order. Each process
will write its own bias potential in the directory specified by the HILLS DIR
keyword and in a file named HILLS.0,HILLS.1, etc etc. Multiple pro-
cesses must be launched independently and must point to the same directory
HILLS DIR, so that each one will contribute to the total bias potential.
The keyword NWALKERS sets the total number of walkers. This can be set
to a value greater than the actual number of processes running and it can be
increased during the run. ID determines a unique id of the walker, starting
from 0. The R STRIDE keyword sets the stride (in time steps) at which each
individual bias potential is updated by reading all the HILLS files contained
in HILLS DIR.
Example.
The following command controls a multiple walkers calculation using a maximum of 10 walkers. Gaussians
are added every 1000 steps and updated every 5000 steps.
HILLS HEIGHT 0.1 W STRIDE 1000
MULTIPLE WALKERS HILLS DIR /scratch/HILLS R STRIDE 5000 NWALKERS 10 ID 0
3.4.7 Monitoring a collective variable without biasing
it
The directive NOHILLS can be used to monitor a CV during a metadynamics
run without applying a bias on it. The keyword CV must be specified to select
the CV to be monitored. This directive must be used for metadynamics
simulations with Bias-Exchange.
Example.
In this example we run metadynamics using only one CV, a distance between two atoms. During the
simulation we monitor the behavior of another CV, the dihedral defined by a set of four atoms, without
putting a bias on it.
HILLS HEIGHT 0.1 W STRIDE 1000
PRINT W STRIDE 50
DISTANCE LIST 13 46 SIGMA 0.35
TORSION LIST 1 4 65 344 SIGMA 0.1
NOHILLS CV 2
ENDMETA
35
![](asset-25.png)
As an alternative you may also avoid the SIGMA value in the CV. This
will be understood as a directive that no hills must be put on this CV. The
previous example therefore becomes:
Example.
HILLS HEIGHT 0.1 W STRIDE 1000
PRINT W STRIDE 50
DISTANCE LIST 13 46 SIGMA 0.35
TORSION LIST 1 4 65 344
ENDMETA
where the NOHILLS keyword for CV 2 has been omitted as implicitly included
by the missing SIGMA parameter.
Avoiding systematic errors at the boundaries
Metadynamics is often used to reconstruct the free energy as a function of
intrinsically limited CVs (like e.g. COORD and ALPHABETA, see chapter 4) or
articially limited CVs (using for example an external potential, see section
3.10). In this case the finite-width Gaussians used in metadynamics can
induce systematics errors at the boundaries. These errors become more and
more severe with time, and are due to the fact that a sum of a finite number
of Gaussians can not reproduce a free-energy profile with large or infinite
derivative. However, PLUMED implements two different procedures aimed at
avoiding the onset of these systematic errors, activated respectively by the
keyword INTERVAL and by the keyword INVERT.
3.4.8 Defining an interval
With the keyword INTERVAL one changes the metadynamics algorithm set-
ting the bias force equal to zero beyond a boundary [26]. If, for example,
metadynamics is performed on a CV sand one is interested only to the free
energy for s > sw, the history dependent potential is still updated according
36
![](asset-26.png)
to Eq. 3.1, but the metadynamics force is set to zero for s < sw:
∂VG(s, t)
∂s = 0 ∀s < sw
Notice that Gaussians are added also if s < sw, as the tails of these Gaussians
influence VGin the relevant region s > sw. In this way, the force on the system
in the region s > swcomes from both metadynamics and the force field, in the
region s < swonly from the latter. This approach allows obtaining a history-
dependent bias potential VGthat fluctuates around a stable estimator, equal
to the negative of the free energy far enough from the boundaries [26].
•In order to obtain a parallel growing VG, one should place the interval
limit swin a region where the free energy derivative is not large. For
example, if one uses the keyword with a coordination number CV (see
Section 4.6), that is intrinsically limited to s > 0, the correct choice for
swis not 0, but a number of the order of the width of the Gaussians
(σin Eq. 3.1).
•This remedy has the advantage of being robust and parameter-free, but
works only for one-dimensional biases.
•If in the region s < swthe system has a free energy minimum, the
INTERVAL keyword should be used together with a soft wall at sw
(keyword LWALL, see section 3.10), namely a time-indipendent exter-
nal potential that prevents the system from going there and remaining
trapped in the minimum. An example is provided below.
Example.
The following input file contains the interval condition in presence of soft walls:
HILLS HEIGHT 0.1 W STRIDE 500
COORD LIST <g1> <g2> NN 8 MM 12 D 0 0 R 0 0.25 SIGMA 0.15
g1->
26 27
g1<-
g2->
29 30
g2<-
INTERVAL CV 1 LOWER LIMIT 0.2 UPPER LIMIT 2.8
UWALL CV 1 LIMIT 2.8 KAPPA 3000.0
LWALL CV 1 LIMIT 0.2 KAPPA 3000.0
ENDMETA
37
3.4.9 Inversion condition
The INVERT keyword activates the inversion condition near predefined bound-
aries LIMIT1,LIMIT2[27]. To simplify the notation, we here assume the CVs
space is one-dimensional with the boundary at s= 0. The inversion condition
ensure that near s= 0 the bias potential satisfy the following relation:
V(−s, t)≈2V(0, t)−V(s, t) (3.3)
This property ensures that, at stationary conditions, the history-dependent
potential is approximately linear close to the boundary, but it does not im-
pose the value of its derivative, that is iteratively determined by the thermo-
dynamic bias. In practice this is achieved by adding extra Gaussians out of
the boundaries according to the following roles:
•An interval centered in 0 is chosen, whose width χ1is of the order of σ
(Gaussian width for the selected CV; SIGMA).
•If s < χ1another Gaussian centered in −sand with the same width
and height is added.
•If s > χ1another Gaussian centered in −sand with the same width is
added. In this case, the height of the extra Gaussians depends on V
and is given by:
w= [2V(0, t)−V(−s, t)−V(s, t)] y(s),(3.4)
where y(s) = 1/h1+(s/(χ2χ1))10iand χ2> χ1
The second factor in Eq. (3.4) is approximately one for |s|< χ2χ1and goes
to zero for |s|> χ2χ1. This ensures that Vgoes smoothly to zero out of the
boundaries. χ2χ1thus defines the width of the inversion interval and χ2is
a scaling factor regulated by the keyword INVERSION.χ1is regulated by the
keyword REFLECTION (χ1is in σunits). The keyword MAXHEIGHT defines the
largest |w|in gaussian height units and it regulates the speed of variation
of Vout of the boundaries. The INVERT keyword can be used in presence of
an external potential that limits the CVs space exploration (see section 3.10)
like in the example below;
38
![](asset-28.png)
Example.
The following input file contains the inversion condition in presence of soft walls:
HILLS HEIGHT 0.1 W STRIDE 500
COORD LIST <g1> <g2> NN 8 MM 12 D 0 0 R 0 0.25 SIGMA 0.15
g1->
26 27
g1<-
g2->
29 30
g2<-
INVERT CV 1 REFLECTION 1.6 INVERSION 6 MAXHEIGHT 4 LIMIT1 0.2 LIMIT2 2.8
UWALL CV 1 LIMIT 2.8 KAPPA 3000.0
LWALL CV 1 LIMIT 0.2 KAPPA 100000.0
ENDMETA
or if an intrinsically limited CV is used (see chapter 4):
Example.
The following input file contains the inversion condition in presence of an intrinsically limited CV, such as
ALPHABETA:
HILLS HEIGHT 0.1 W STRIDE 250
ALPHABETA NDIH 1 SIGMA 0.05
5 12 14 23 -3.14159
INVERT CV 1 REFLECTION 1.6 INVERSION 6 MAXHEIGHT 4 LIMIT1 0.0 LIMIT2 1.0
ENDMETA
If INVERT is used in presence of soft walls it is recommended to use
KAPPA larger than KT/σEXP, where EXP is the exponent defined for the
wall (see section 3.10). Much smaller values for KAPPA in fact do not effi-
ciently prevent the exploration of CVs regions that are located at more than
σbeyond the bounduaries and this may lead to systematics errors. It is worth
to note that LIMIT1 and LIMIT2 must not be in unphysical regions of the
CVs space, i.e. they must be visited during the simulation. The present im-
plementation does not remove systematics errors for multidimensional meta-
dynamics in regions of the CVs space that are near crossing boundaries (e.g.
if LIMIT1=0 for CV 1 and LIMIT1=0 for CV 2 there still can be systematic
error near (0,0) ). The values for the REFLECTION,INVERSION and MAXHEIGHT
keywords chosen in the examples are also their default values (if not specified
the program selects automatically their default values). They were chosen in
other to minimize the free energy error at the boundaries for several different
test cases. Further information can be found in ref.[27].
39
![](asset-29.png)
3.5 Running in parallel
Simulations of large systems can often accelerated by using parallel machines.
The behavior of PLUMED in parallel simulations is dependent on the host code:
•NAMD: the present version of PLUMED is fully compatible with NAMD
for parallel simulations. However, since PLUMED runs on the first pro-
cessor only, the computational effort required to evaluate the collective
variables and their derivatives, as well as the history dependent poten-
tial in metadynamics simulations, should be kept lower than 1/Npof
the total computational effort, where Npis the number of processors.
Thus, pay attention to heavy variables and metadynamics simulations
with many hills.
•GROMACS, DL POLY, AMBER and LAMMPS: the present version
of PLUMED is fully compatible with these codes for parallel simulations.
Consider the following notes:
–The coordinates of the particles involved in collective variables are
replicated over all nodes at every step. If you don’t want to slow
down your simulation, minimize the number of involved atoms.
–The computational effort required to evaluate the collective vari-
ables and their derivatives is replicated on all processors, thus is
effectively not scaling. Pay attention to heavy variables (such as
coordination numbers with long lists).
–The computational effort required to evaluate the history depen-
dent potential in metadynamics simulations is spread over proces-
sors, thus should scale linearly.
–With GROMACS and domain decomposition, pay attention to
periodic boundary conditions (see Section. 4.28).
–With DL POLY, use the patched version of MakePAR to compile
PLUMED.
3.6 Replica exchange methods
When combined with GROMACS (both version 4.0 and 4.5), PLUMED can
perform replica–exchange simulations coupled with metadynamics in two
40
![](asset-2a.png)
different ways: parallel tempering metadynamics (PTMetaD) [17, 28] and
bias-exchange metadynamics (BE-META) [18].
3.6.1 Parallel tempering metadynamics
Parallel tempering metadynamics (currently implemented only for the GRO-
MACS engine) is selected using the PTMETAD directive.
To run parallel tempering simulations with metadynamics, one has to
follow the standard GROMACS procedure for parallel tempering (see GRO-
MACS manual). A binary topology .tpr file must be prepared for each
replica, while only one plugin input file is required.
Example.
The following input file defines a parallel-tempering metadynamics:
# switching on metadynamics and Gaussian parameters
HILLS HEIGHT 0.1 W STRIDE 500
# switching on parallel tempering
PTMETAD
# instruction for CVs printout
PRINT W STRIDE 50
# the CV: radius of gyration
RGYR LIST <CA> SIGMA 0.1
CA->
20 22 26 30 32
CA<-
# end of the input
ENDMETA
The PTMETAD directive switches on parallel tempering. All replicas have
the same CVs, in this particular case the radius of gyration defined by the
group of atoms <CA> .
The Gaussian height set by the keyword HEIGHT is automatically rescaled
with temperature, following Wi=W0Ti
T0, where iis the index of a replica and
Tiits temperature.
Similarly, the simulation temperature needed to use the well-tempered
algorithm (which, for non-parallel simulations is set with the SIMTEMP key-
word) is here taken directly from the GROMACS input at each replica. As
a result, the value of ∆Tfor the well-tempered algorithm is rescaled across
the replicas.
The plugin will produce one COLVAR file and one HILLS file for each
replica.
41
3.6.2 Bias exchange simulations
Bias exchange simulations must be run using the BIASXMD directive. Only
the GROMACS engine currently has this feature implemented within a single
parallel run, whereas the bias-exchange tool in the directory utilities al-
lows to perform bias-exchange simulations with any MD engine via the linux
shell (see Section 5.6).
The procedure for running bias-exchange simulations is similar to the
one described earlier for parallel tempering (i.e., add -multi nrep -replex
nexch to the mdrun command line, where nrep is the number of replicas and
nexch is the number of steps between attempting exchanges). One plugin
input and one binary topology file must be provided for each replica. These
files must be named with the replica index (e.g., plumed0.dat,plumed1.dat,
..., md0.tpr,md1.tpr, ...). Each plugin input file must contain the directive
BIASXMD and the same list of CVs, in the same order. Each replica usually
has only one (or few) of the CVs active: use a NOHILLS directive for each
of the inactive CVs (or do not specify SIGMA for them). It is also possible
to have replicas with all CVs inactive: such unbiased replicas can exchange
with biased ones, jumping in this way beyond free-energy barriers, but since
they are not subject to the hills they tend to populate the free-energy basins
according to equilibrium statistics.
42
![](asset-2c.png)
Example.
The following two input files define a bias-exchange metadynamics run:
# --- input file plumed0.dat ---
# switching on metadynamics and Gaussian parameters
HILLS HEIGHT 0.1 W STRIDE 500
# switching on bias-exchange
BIASXMD
# instruction for CVs printout
PRINT W STRIDE 50
# instruction for labeling of COLVAR and HILLS files
HILLS LABEL A
# the CVs: dihedral angles
TORSION LIST 1 5 11 13 SIGMA 0.314
TORSION LIST 11 13 15 21 SIGMA 0.314
# in this replica we bias only CV 1:
NOHILLS CV 2
# end of the input
ENDMETA
# --- input file plumed1.dat ---
# switching on metadynamics and Gaussian parameters
HILLS HEIGHT 0.1 W STRIDE 500
# switching on bias-exchange
BIASXMD
# instruction for CVs printout
PRINT W STRIDE 50
# instruction for labeling of COLVAR and HILLS files
HILLS LABEL B
# the CVs: dihedral angles
TORSION LIST 1 5 11 13 SIGMA 0.314
TORSION LIST 11 13 15 21 SIGMA 0.314
# in this replica we bias only CV 2:
NOHILLS CV 1
# end of the input
ENDMETA
In bias-exchange runs, the plugin will produce one COLVAR file and one
HILLS file for each replica. What is actually exchanged between replicas are
the atomic coordinates, not the bias, so that replica 0 (printing out COLVAR0)
will always be biased by HILLS0, replica 1 (printing out COLVAR1) will always
be biased by HILLS1,) and likewise for the other replicas.
In the example above, note the use of the keyword HILLS LABEL: this will
print a comment line ”#! ACTIVE 1 1 A” in files COLVAR0 and HILLS0 and
”#! ACTIVE 1 2 B” in files COLVAR1 and HILLS1, indicating the number of
active CVs, their index, and the chosen label. This facilitates the reconstruc-
tion of the multidimensional free-energy landscape from the bias-exchange
simulation according to the weighted-histogram algorithm in Ref. [29], e.g.
43
![](asset-2e.png)
3.7 Umbrella sampling
The directive UMBRELLA allows umbrella sampling calculations to be per-
formed on the CV specified by the parameter keyword CV. The position s0
of the umbrella restraint is determined by the keyword AT, and the spring
constant k- in internal unit of the main code - by the keyword KAPPA. Op-
tionally, also a constant force mcan be specified by the keyword SLOPE. This
turns on a potential of the following functional form:
Vumb(s) = 1
2k(s−s0)2+m(s−s0).(3.5)
Example.
The following input file defines an umbrella potential acting on the first CV and centered in s0=−1.0.
TORSION LIST 13 15 17 1
UMBRELLA CV 1 KAPPA 200 AT -1.0
PRINT W STRIDE 100
ENDMETA
In the case of umbrella sampling runs, the value of the CVs is printed on
the COLVAR file with a stride fixed by the directive PRINT and the keyword
W STRIDE. The file contains the time, the CV values, the metadynamics po-
tential, the harmonic potential of umbrella sampling, the CV on which the
restraint acts and the position of the restraint. The final calculation of the
free energy as a function of this CV can be done using the weighted histogram
analysis method, choosing one of the many possible implementations, for in-
stance the wham code by Alan Grossfield [31]. The directive UMBRELLA can
be used multiple times in the case of multidimensional umbrella sampling
calculations (one directive for each CV).
The keyword RESTART can be used when restarting an umbrella sampling
calculation to append the value of the CVs on the COLVAR file.
45
![](asset-2f.png)
3.8 Steered MD
PLUMED can be used to drag a system to a target value in CV space using
an harmonic potential moving at constant speed. If the process is reversible,
i.e. for velocities tending to zero, the work done in the dragging corresponds
to the free energy. In the case of finite velocity it is possible to obtain an
estimate of the free-energy from the work distribution using Jarzynski [13]
or Crooks [14] relations.
The directive STEER activates the steering on the collective variable spec-
ified by the keyword CV. The target value is determined by the keyword TO,
the velocity, in the same unit as the corresponding CV every 1000 steps, by
VEL and the spring constant by KAPPA. An additional keyword FROM can be
used to specify the starting point of the dragging, otherwise the CVs values
at the first step are taken as the starting point. The functional form of the
dragging potential is the same as the one of formula 3.5, with the reference
position s0moving at the specified velocity.
The keyword RESTART can be used when restarting a steered MD calcu-
lation to append the value of the CVs on the COLVAR file.
Example.
The following input file defines a steered MD on the angle CV to a target value of 3.0 rad.
ANGLE LIST 13 15 17
STEER CV 1 TO 3.0 VEL 0.5 KAPPA 500.0
PRINT W STRIDE 100
ENDMETA
3.8.1 Steerplan
PLUMED can be used to drag a system on a pathway that is composed of
successive steering runs on chosen degrees of freedom in a planned fashion.
While the directive STEER is rather easy and intuitive, STEERPLAN is more
flexible and it allows to avoid a lot of scripting whenever you plan to simulate
complex transitions by means of out-of-equilibrium runs.
The directive STEERPLAN activates this option and reads the name of a
file that contains the plan as an input.
46
![](asset-30.png)
Example.
The following input file contains many collective variables and a steerplan directive.
PRINT W STRIDE 5
#
# these CVs are put here just to show that you may use more variable than the
# ones defined in the steerplan
#
TARGETED TYPE MSD FRAMESET restrained.pdb
TARGETED TYPE MSD FRAMESET waters.pdb
TARGETED TYPE MSD FRAMESET ref H.pdb
#
# difference of distances for proton transfers
#
DISTANCE LIST 53 703 DIFFDIST 703 702
DISTANCE LIST 702 913 DIFFDIST 913 912
#
# steer plan read from file myplan
#
STEERPLAN myplan
ENDMETA
The steerplan file myplan contains the control sequence of the steerplan
and it is composed as follows. The first column contains the time (in timeu-
nits of the program) at which a particular action is planned. The following
columns are composed in blocks of five. Each block contains: the CV key-
word, the index of the CV to be used, the spring constant at a given time,
the value of the center of the spring potential and a keyword among CENTRAL
(the potential is a normal parabolic shape), POSITIVE (the potential with
parabolic shape is applied only when the CV value is higher than the center
of the spring) and NEGATIVE (the potential with parabolic shape is applied
only when the CV value is lower than the center of the spring). A Block
of four columns without the latter keyword is also accepted. In this case
CENTRAL is assumed. Wildcards (*) are also accepted for the position. Their
meaning is much clearer in the following example. Comments are allowed
(#) .
47
![](asset-31.png)
Example.
An example of steerplan file.
# Bring CV 4 from wherever it is (*) to -0.5 at 2 ps by increasing
# gradually the spring constant from 0 to 800. CV 5 does the same and goes to -0.64.
0.00 CV 4 000.0 * POSITIVE CV 5 000.0 * POSITIVE
2000.00 CV 4 800.0 -0.5 POSITIVE CV 5 800.0 -0.64 POSITIVE
# Now in 400 fs keep CV 4 at its value while releasing the other
# slowly to 0 spring constant.
2400.00 CV 4 800.0 -0.5 POSITIVE CV 5 0.0 -0.64 POSITIVE
# Now drag back only CV 4 to 1.4 with a value that acts only
# on the negative part. The potential on CV 5 is off.
8400.00 CV 4 800.0 1.4 NEGATIVE CV 5 0.0 -0.64 POSITIVE
Please note that the wildcards have particular meaning:
Example.
Here the dragging force starts from whatever value the system assumes at 0 fs and drags it to -0.5 at 2
ps. The spring constant is linearly increasing from 0.0 to 800.0. When the starting point is a wildcard this
takes the current value.
0.00 CV 4 000.0 * POSITIVE
2000.00 CV 4 800.0 -0.5 POSITIVE
Here the center of the harmonic potential follows the system at each step from 0 to 2 ps. When the
position of the ending point is a wildcard then the potential will follow the coordinates (this means that the
potential is not applied as the force is zero everywhere).
0.00 CV 4 800.0 * POSITIVE
2000.00 CV 4 800.0 * POSITIVE
This case is considered identical as the one before
0.00 CV 4 800.0 0.5 POSITIVE
2000.00 CV 4 800.0 * POSITIVE
3.9 Adiabatic Bias MD
PLUMED can be used to evolve a system towards a target value in CV space
using an harmonic potential moving with the thermal fluctuations of the
CV[20, 32, 33].
The directive ABMD activates the biasing on the collective variable specified
by the keyword CV. The target value is determined by the keyword TO, the
48
![](asset-32.png)
spring constant by KAPPA. The biasing potential is implemented as
V(ρ(t)) = (α
2(ρ(t)−ρm(t))2, ρ(t)> ρm(t)
0, ρ(t)≤ρm(t),(3.6)
where
ρ(t) = (CV (t)−T O)2(3.7)
and
ρm(t) = min
0≤τ≤tρ(τ).(3.8)
The method is based on the introduction of a biasing potential which is
zero when the system is moving towards the desired arrival point and which
damps the fluctuations when the system attempts at moving in the opposite
direction. As in the case of the ratchet and pawl system, propelled by thermal
motion of the solvent molecules, the biasing potential does not exert work
on the system.
The keyword RESTART can be used when restarting an adiabatic bias MD
calculation to append the value of the CVs on the COLVAR file and to set the
best value previously reached.
Example.
The following input file defines an adiabatic biased MD on the angle CV to a target value of 3.0 rad.
ANGLE LIST 13 15 17
ABMD CV 1 TO 3.0 KAPPA 500.0
PRINT W STRIDE 100
ENDMETA
The corresponding
COLVAR will look like:
#! FIELDS time cv1 vbias vwall vext XX XX ABMD1
0.000 1.884703657 0.000000000 0.000000000 0.000000000 ABMD 1 1.243885933
0.200 2.353724409 0.000000000 0.007812004 0.000000000 ABMD 1 0.412082147
0.400 2.433164746 0.000000000 0.000000000 0.000000000 ABMD 1 0.321302206
0.600 2.608463835 0.000000000 0.004202352 0.000000000 ABMD 1 0.149200641
0.800 2.818935636 0.000000000 0.009463992 0.000000000 ABMD 1 0.026631583
1.000 2.831631093 0.000000000 0.147609095 0.000000000 ABMD 1 0.004049192
1.200 2.583559043 0.000000000 7.171877688 0.000000000 ABMD 1 0.004049192
1.400 2.841442463 0.000000000 0.121111568 0.000000000 ABMD 1 0.003130352
1.600 2.794514101 0.000000000 0.382087213 0.000000000 ABMD 1 0.003130352
1.800 2.634418597 0.000000000 4.258829096 0.000000000 ABMD 1 0.003130352
2.000 2.861303394 0.000000000 0.086113847 0.000000000 ABMD 1 0.000677239
where the last column is ρm(t).
49
![](asset-33.png)
3.10 External potentials
3.10.1 Walls
The UWALL and LWALL keywords define a wall for the value of the CV swhich
limits the region of the phase space accessible during the simulation. The
restraining potential starts acting on the system when the value of the CV is
greater (in the case of UWALL) or lower (in the case of LWALL) than a certain
limit LIMIT minus an offset OFF.
The functional form of this potential is the following:
Vwall(s) = KAPPA s−LIMIT +OFF
EPS EXP
,(3.9)
where KAPPA is an energy constant in internal unit of the code, EPS a rescaling
factor and EXP the exponent determining the power law.
By default: EXP = 4,EPS = 1.0,OFF = 0.
Example.
To run a well-tempered metadynamics simulation using as CV the distance between one atom and the
center of mass of a group of atoms and limiting its value below 15 ˚
A, you have to use the following input
file:
HILLS HEIGHT 0.1 W STRIDE 100
WELLTEMPERED SIMTEMP 300 BIASFACTOR 10
PRINT W STRIDE 50
DISTANCE LIST 13 <g1> SIGMA 0.35
g1->
17 20 22 30
g1<-
UWALL CV 1 LIMIT 15.0 KAPPA 100.0
ENDMETA
3.10.2 Tabulated potentials
An external potential of generic form can be added to any collective variables
using the directive EXTERNAL. The user must specify the total number of
CVs on which the potential acts with the keyword NCV and the variables
with CV. The external potential must be provided in a tabulated form in the
file specified by FILENAME. The format used for the external potential is the
same as the one described in 3.4.5 for the case of metadynamics potential on
aGRID.
50
![](asset-34.png)
Example.
The following input file controls a simulation with an external potential acting on two collective variables.
The tabulated potential is provided in the file external.dat.
PRINT W STRIDE 100
DISTANCE LIST 13 20
TORSION LIST 5 8 10 12
EXTERNAL NCV 2 CV 1 2 FILENAME external.dat
Every collective variables implemented in PLUMED has a unique ID. This
number must be used to define the type of CV in the header of the external
potential file and must match the CV activated in the PLUMED input file. In
Tab. 3.1 we provide a legend.
Example.
The header of the external potential file of the previous example looks like this:
#! FORCE 1
#! NVAR 2
#! TYPE 1 5
#! BIN 100 100
#! MIN 0.0 -3.14159
#! MAX 10.0 3.14159
#! PBC 0 1
If force data are not present on file, they will be calculated from the
tabulated potential using finite differences.
51
![](asset-35.png)
ID CV
1 Distance
2 Minimum distance
3 Coordination number
4 Angle
5 Torsion
6 Alpha-beta similarity
7 Hydrogen bonds
8 Dipole
11 Radius of gyration
16 Dihedral correlation
20 Interfacial water
30 Path collective variable S
31 Path collective variable Z
32 Absolute position
33 Electrostatic potential
34 Puckering coordinates
35 Energy
36 Helix loops
37 Alpha helix rmsd
38 Antiparallel beta rmsd
39 Parallel beta rmsd
42 PCA projection
45 Contact Map
55 SPRINT
Table 3.1: ID of the collective variables implemented in PLUMED.
52
![](asset-36.png)
3.11 Commitment analysis
The COMMITMENT directive is used to run commitment analysis. The keyword
NCV determines the total number of CVs for the analysis, while CV must
be used to specify the variable id. Following this line, NCV lines must be
provided, each of which containing the upper and lower limits of the Aand
Bbasins for the i-th variable.
Example.
The following line defines a commitment analysis on the first two collective variables s1and s2, while the
third is only monitored. The commitment basins are defined as A={(s1, s2)|s1∈(0,1), s2∈(−1,1)},
and B={(s1, s2)|s1∈(1,2), s2∈(−1,1)}.
COMMITMENT NCV 2 CV 1 2
0.0 1.0 1.0 2.0
-1.0 1.0 -1.0 1.0
DISTANCE LIST 12 30
DISTANCE LIST 20 24
TORSION LIST 14 16 20 22
ENDMETA
3.12 Projection of gradients
The keyword PROJ GRAD is enable one to calculate the projection of the gra-
dient in this way:
Pij(R) =
NAT
X
n∇nsi(R)· ∇nsj(R) (3.10)
where si(R) and sj(R) are two collective coordinates defined in input. The
output is stored into the COLVAR file in the form of upper diagonal matrix.
The initial line of COLVAR file describes the output in detail.
Example.
The following line instructs plumed to calculate the projection of two collective variables s1and s2.
DISTANCE LIST 1 2
TORSION LIST 1 2 3 4
TORSION LIST 2 3 4 8
PROJ GRAD CV <g1>
g1->
2 3
g1<-
ENDMETA
53
![](asset-37.png)
In the COLVAR file you find a PROJ GRAD keyword followed by N(N+ 1)/2
elements that constitute the upper diagonal matrix (diagonal elements in-
cluded) of the projection. It is important to know that PROJ GRAD is NOT
supporting the LIST keyword therefore all the variables that one needs to
use must be included in a ”group” as reported in the example above.
3.13 Reconnaissance metadynamics
Reconnaissance metadynamics is a self-learning algorithm for accelerated dy-
namics that is able to work with a very large number of collective coordinates.
Acceleration of the dynamics is achieved by constructing a bias potential in
terms of a patchwork of one-dimensional, locally valid collective coordinates.
To understand the details of the methodology please read reference [19]. Fur-
thermore, as detailed in section 2.2, by default PLUMED compiles without re-
connaissance metadynamics and so some slight modifications in compilation
are required if you wish to run this type of simulation.
For a reconnaissance metadynamics simulation the PLUMED input must
contain the definition of at least one CV (see chapter 4 for the required
syntax) and the RECONNAISSANCE,BASINS,ONIONS and CLUSTER keywords.
These keywords provide the parameters for reconnaissance metadynamics
simulations and are described in sections 3.13.2 and 3.13.3.
3.13.1 Typical output
A reconnaissance metadynamics simulation produces at least four output
files. These files are called BASINS,ONIONS,PPCA DIAGNOSTICS and CLUSTER DATA.0.
The first of these files contains the locations of the various basins found dur-
ing cluster analysis and their shapes. This data is formatted as follows:
•The first column contains the basin number
•The second column contains the timestep at which the basin was cre-
ated
•The following dcolumns contain the values of the collective coordinates
at the basin center
•The next d2columns contain the covariance of the collective coordinates
inside the basin
54
![](asset-38.png)
•The final column contains the value of the “diffusion constant” in this
particular basin.
The second file, ONIONS, gives the details of the bias. In reconnaissance
metadynamics the bias consists of Gaussian functions that are added to the
distance from basin centers. These Gaussian functions are only added when
one is within a certain distance of the basin center, the basin size. This
basin size changes as the simulation progresses and the ONIONS file stores the
details of all basin expansion events as well as the details of the hill addition
events. Each event is recorded on a single line of the ONIONS file, which is
formatted as follows:
•The first column contains the time step at which the contribution to
the bias potential was added.
•The second column contains the number of the basin to which this
particular Gaussian was added
•The third column contains the distance from the basin center specified
in column 2 at which the centroid of the Gaussian is to be found
•The fourth column contains the width of the Gaussian
•The fifth column contains the height of the Gaussian
•The final column contains the current size of the basin specified in
column 2.
Basin expansion events can be distinguished from hill addition events as
in the former case the height of the “Gaussian” in column 4 is zero.
The PPCA DIAGNOSTICS file contains a information on how successful the
PPCA algorithm, that is used for clustering, has been. By default fits of the
data are performed with 1 to 10 Gaussian functions. Bayesian information
criteria ( −log(L) + nplog(M), log(L), npand Mbeing the log likelyhood,
number of parameters and number of datapoints respectively) and fuzzy vol-
umes ( PN
n=1 q|Σn|) are reported for each fit. The best fit to the data is the
one with the minimum value for the Bayesian Criterion and it is from this
fit that the bias is constructed. In our early applications of the methodology
we have found that the if a large number of Gaussian is regularly needed to
fit the collected data the method will not be successful. However, a change
55
![](asset-39.png)
of cvs can often resolve this problem. After the PPCA DIAGNOSTICS file has
reported on the quality of the fits with different numbers of Gaussians the
weights of the various Gaussians in the best fit to the data are reported along
with information on which Gaussians have been accepted into the biassing
strategy.
All the remaining files produced during a reconnaissance metadynamics
simulation are only required to restart simulations.
Unlike in normal metadynamics one cannot obtain the free energy surface
from an examination of the bias potential at the end of the simulation. How-
ever, a graphical tool that can be added to vmd is available from the PLUMED
website. With this tool one can visualize the results from from reconnaissance
metadynamics simulation.
3.13.2 Controlling the clustering
As discussed in reference [19] in reconnaissance metadynamics one periodi-
cally analyses the trajectory in order to obtain collective coordinates to bias.
The frequency of these analyses are controlled by the CLUSTER keyword. The
line containing this keyword should also contain an integer, which controls
the frequency at which the values of the cvs are stored for subsequent cluster
analysis and a integer than controls the frequency of clustering. The first
of these quantities should be proceeded by STORE FREQ and the second by
RUN FREQ. One may cluster over multiple timescales separately by including
this line multiple times.
Example.
The following lines tell PLUMED to run cluster analyses every 10000 steps and every 100000 steps
RECONNAISSANCE
CLUSTER RUN FREQ 100000 STORE FREQ 100
CLUSTER RUN FREQ 1000000 STORE FREQ 1000
Once the clustering has finished PLUMED must make certain decisions on
how these basins should be incorporated into the biassing strategy. The
parameters controlling these decisions are given on the line starting with the
BASINS keyword. This line provides three parameters:
•BASIN TOL - the fraction of the trajectory that must be within a cluster
in order for it to be used for biassing.
56
![](asset-3a.png)
•INITIAL SIZE - the initial size of the basin
•EXPAND PARAM - the parameter that controls the basin expansion
Guidance on how to set the value of BASIN TOL is provided in the sup-
plementary information of reference [19]. The supplementary information
also shows how, when the angular variables of a multivariate Gaussian are
integrated out, the resulting probability distribution as a function of r(the
distance from the center of the basin in the metric of the basin) is equal to a
Gaussian with standard deviation 1
√2centered at √d−1. With this in mind
the initial size of basins is set equal to √d−1 + the value of the initial size
parameter. Therefore a sensible value for this parameter is around 1.5 - i.e.
approximately two standard deviations.
The final parameter described above EXPAND PARAM controls the way basins
change size as a function of time. As discussed in the supplementary informa-
tion of reference [19] we introduce a probabilistic criterion for basin expansion
that is derived using ideas from the theory of diffusion. Since writing that
paper we have slightly changed the way that this parameter functions. In
particular we realized that the diffusion constant in a given basin could be
also be fit from the data using:
D=1
d∆t(M−1)
M
X
i=2 |si−si−1|2(3.11)
where Mis the number of vectors used for clustering, dis the dimension-
ality, ∆tis the STORE FREQ parameter and the squared differences between
vectors of CVs in the sum are calculated in the metric of the basin. The
EXPAND PARAM provided in the input should be a number between 0 and 1.
It is used to scale this estimate value and expresses the level of confidence a
user has in the fitting. In practice this parameter gives some control over the
rate of exploration of phase space. If it is large phase space will be explored
rapidly, while if it is small phase space will be explored more slowly.
3.13.3 Controlling the bias
The bias in reconnaissance metadynamics consists of a number of Gaussian
functions that are periodically added to the potential. These Gaussians are
different from those added in normal metadynamics because they act added
57
![](asset-3b.png)
on the distance from the center of a basin. Hence, the keyword that controls
the hill addition in reconnaissance metadynamics is ONIONS and NOT HILLS.
However, the syntax for ONIONS is the same as the syntax for HILLS. That is
to say one must provide:
•HEIGHT - The height of the Gaussian functions.
•W STRIDE - The frequency with which to attempt hill addition.
•WIDTH - The width of the Gaussian functions.
Once again guidelines as to how to set these parameters are provided in
the supplementary information of reference [19].
Bringing all of the above together a typical input file for a reconnaissance
metadynamics simulation should look like this:
Example.
Typical input for a reconnaissance metadynamics simulation
RECONNAISSANCE
ONIONS HEIGHT 1.0 W STRIDE 1000 WIDTH 1.5
BASINS BASIN TOL 0.2 EXPAND PARAM 0.3 INITIAL SIZE 3.0
CLUSTER RUN FREQ 500000 STORE FREQ 250
TORSION LIST 13 15 17 19
TORSION LIST 15 17 19 21
3.13.4 Restarting a simulation
To restart a reconnaissance metadynamics simulation, the flag RESTART must
be added on the line containing the directive RECONNAISSANCE. This allows
one to restart the simulation after an interruption or after a run has termi-
nated. At the start of the simulation the BASINS,ONIONS and CLUSTER DATA.*
files are read in so the bias can be restarted. Data from the restarted simula-
tion will then be appended to the BASINS and ONIONS files. Please note that
the RESTART flag is a directive to PLUMED to restart the reconnaissance meta-
dynamics simulation. It not an instruction to restart the MD run. Hence, to
restart the simulation one must also follow the usual procedure for restarting
the MD run. This will depend on the particular MD engine you are using -
58
![](asset-3c.png)
details can be found in the documentation for the particular MD code you
are using.
Example.
A sample input file for restarting a reconnaissance metadynamics simulation
RECONNAISSANCE RESTART
ONIONS HEIGHT 1.0 W STRIDE 1000 WIDTH 1.5
BASINS BASIN TOL 0.2 EXPAND PARAM 0.3 INITIAL SIZE 3.0
CLUSTER RUN FREQ 500000 STORE FREQ 250
TORSION LIST 13 15 17 19
TORSION LIST 15 17 19 21
3.13.5 Using a subset of the defined cvs
By default reconnaissance metadynamics is performed using all the collective
coordinates defined in the PLUMED input file. However, there may be occasions
where it is desirable to include some constraints to prevent exploration of the
uninteresting parts of phase space. In these cases it would also be desirable to
not include these cvs in the reconnaissance metadynamics. Consequentially,
a keyword exists which allows one to explicitly specify which of the CVs are
to be used in the reconnaissance metadynamics. This keyword is CV LIST
and it should be added to the line containing the directive RECONNAISSANCE.
It should be followed by a tag which gives the name of a list of the cvs to
be used for reconnaissance. This list should be specified using the syntax
described in section 4.
Example.
A sample input file for a reconnaissance metadynamics simulation using only three of the four collective
coordinates specified in the PLUMED input file
RECONNAISSANCE CV LIST <cvlist>
ONIONS HEIGHT 1.0 W STRIDE 1000 WIDTH 1.5
BASINS BASIN TOL 0.2 EXPAND PARAM 0.3 INITIAL SIZE 3.0
CLUSTER RUN FREQ 500000 STORE FREQ 250
TORSION LIST 13 15 17 19
TORSION LIST 15 17 19 21
TORSION LIST 17 19 21 23
TORSION LIST 19 21 23 25
cvlist->
1 2 3
cvlist<-
59
![](asset-3d.png)
3.14 Driven Adiabatic Free Energy Dynam-
ics (d-AFED)
The driven adiabatic free energy (d-AFED) algorithm [34] is a variant of
the earlier AFED method [35, 36], which required cumbersome coordinates
transformations. In the d-AFED method, an extra dynamical variable Sis
coupled to a collective variable s(r), where rrepresents the coordinates of
a number of atoms in the system. The coupling is mediated by a potential
energy function with harmonic constant κ,
V(S, s(r)) = 1
2κ(S−s(r))2.(3.12)
The dynamics of the Smeta-variable is adiabatically decoupled from the
dynamics of the underlying physical system by choosing a large mass mS
¯m, where ¯mis a typical mass of the physical system. Thanks to the adiabatic
separation, a temperature TS> T can be assigned to the Smeta-variable.
With this choice of msand Ts, the physical system will evolve fast at room
temperature Taround the instantaneous value of s(r) = S. On the other
hand, Swill evolve slowly, but have a temperature large enough to drive the
system over high free energy barriers.
In the limit of κ→ ∞, it can be shown that the free energy surface
at temperature Tcan be recovered from the density ρadb(S) sampled at
temperature TSduring the adiabatic d-AFED simulation using
∆G(S) = −kBTSlog ρadb(S).(3.13)
This result generalizes well to the case where more than one collective variable
is used and ∆G(S) is a multi-dimensional free energy surface. Note that
the d-AFED method is similar to the Temperature Accelerated Molecular
Dynamics (TAMD) method devised by other authors[37].
The d-AFED method requires very efficient thermostatting of the meta-
variable S. Therefore, in the present implementation, Sis coupled to a
Generalized Gaussian Moment Thermostat (GGMT) [38]. The meta-variable
is coupled to two thermostatting variables pηand pζ, with associated masses
Qηand Qζ, respectively. Given a typical time scale τof the thermostated
system, optimal masses are Qη=kBTSτ2and Qζ=8
3(kBTS)3τ2. The order-2
GGMT dynamics for one degree of freedom is
˙pS=V(S, s(r)) −pη
Qη
pS−pζ
Qζ"kBTS+1
3
p2
S
mS#pS,(3.14)
60
![](asset-3e.png)
˙pη=p2
S
mS−kBTS,(3.15)
˙pζ=1
3"p2
S
mS#2
−(kBTS)2,(3.16)
˙
S=pS
mS
,˙η=pη
Qη
,˙
ζ=pζ
Qζ
.(3.17)
If multiple reaction coordinates are used, one separate GGMT thermostat
is associated to each of them. The implemented integrator for the dynamics
above is based on a Trotter decomposition of the corresponding Liouville
operator [34]. The quality of the integration can be monitored using the
quantity HS, which would be conserved if the dynamics of Swas decoupled
from the physical system,
HS(S, pS, η, pη, ζ, pζ) = p2
S
2mS
+V(S)+ p2
η
2Qη
+p2
ζ
2Qζ
+kBTS(η+ζ) (3.18)
The heat transfer WSfrom the meta-variable to the physical system can be
calculated,
WS=Zt
0dt0κ(S−s(r)) pS
mS
(3.19)
The effective adiabaticity of the coupling can thus be asserted. In addition,
for each collective variable, the quantity HS−WSshould be strictly conserved
and provides a quality check for the simulation.
3.14.1 Input for d-AFED
For each CV, a DAFED directive is used to define the parameters of the cor-
responding dynamics. On the same line, the number of the CV to which the
directive applies is specified after the keyword CV. The temperature TSin
K is given after keyword TEMPERATURE. The thermostat time constant τis
given in ps after keyword TAUTHERMO. The mass mSand harmonic constant
κ, are given after the keywords MASS and KAPPA, respectively. The units of κ
and mSdepend on the nature of the CV. They should always be such that
κS2and m˙
S2are both in units of energy (kJ/mol= amu nm2/ ps2), see the
example below.
In addition, tow optional keywords can be used with the DAFED directive.
First, for periodic CVs such as torsion angles, the Svariable should also
61
![](asset-3f.png)
evolve on a periodic interval. This is specified by the keyword PERIODIC,
followed by two numbers for the lower and upper bounds. The numbers can
be replaced by MINUS PI,PLUS PI, or PLUS 2PI to specify −π, +π, or +2π,
respectively.
The optional keyword JACOBIAN FORCE causes a bias force F=−2kBT/S
to be applied to the dynamics of S. This is useful with distance CVs in order
to counterbalance the effect of the Jacobian factor and sample a more uniform
distribution along the CV.
Example.
The following lines couple CV 1 (a distance in nm) to a meta-variable of mass 105amu with a harmonic
constant of 106kJ/mol/nm2and CV 2 (a unitless number) to a meta-variable with mass 103amu*nm2
with a harmonic constant of 104kJ/mol. For both CV, the d-AFED temperature is 600 K and the GGMT
thermostat time constant is 0.2 ps. See text for the optional keywords JACOBIAN FORCE and PERIODIC.
DISTANCE LIST 1 34
TORSION LIST 5 15 29 36
DAFED CV 1 TEMPERATURE 600 MASS 1e5 KAPPA 1e6 TAUTHERMO 0.2 JACOBIAN FORCE
DAFED CV 2 TEMPERATURE 600 MASS 1e3 KAPPA 1e4 TAUTHERMO 0.2 PERIODIC MINUS PI PLUS PI
DAFED CONTROL RESTART checkpoint file WRITE STATE -1 N RESPA 1
PRINT W STRIDE 100
ENDMETA
A separate DAFED CONTROL directive contains general controls for the d-
AFED simulation. The d-AFED dynamics, including all variables described
in Eqs. (3.14 - 3.17) can be restarted exactly from a previous run using a
checkpoint file. Following the WRITE STATE keyword appears the number of
steps after which a checkpoint file is saved. A value of −1 implies that a
checkpoint file is written only when GROMACS saves its own checkpoint
file, i.e. at regular wall clock time intervals. The checkpoint file is saved in
the current directory with default name DAFED STATE. The optional keyword
RESTART is used to specify the path to the checkpoint file from which to
restart.
3.14.2 Typical output for d-AFED
WIth the d-AFED method, the COLVAR file will contain the following data,
if dcollective variables are used:
62
![](asset-40.png)
•time step
•value of the collective variable s1(r)...sd(r)
Then for each of the Sj, j = 1...d, appears a set of 4 columns with :
•the meta-variable S
•the instantaneous temperature of Sin K
•the conserved quantity HS, see Eq. 3.18, in kJ/mol
•the work WSfrom Sto the physical system, see Eq. 3.19, in kJ/mol
These fields are labeled sj,T sj,E sj, and W sj, respectively, in the
COLVAR header line, j= 1...d. Additional collective variables can be moni-
tored during a d-AFED run, in which case more columns will appear before
the first d-AFED keyword.
Note that for each extended variable Sj, the quantity HSj+WSjshould
be conserved, j= 1...d. Let Hbe the pseudo-energy of the physical system
including the associated thermostats and barostats. Then the total energy
of the simulation, H+Pd
j=1 HSj, should be conserved as well. In addition,
considering the physical system only, the quantity H − Pd
j=1 WSjshould be
conserved.
63
Chapter 4
Collective variables
PLUMED contains implementations of a large number of CVs so one can prop-
erly describe the processes involved in a wide variety of interesting problems.
In the following chapter we describe all the CVs, which are implemented in
PLUMED together with their analytic first derivative.
In general to instruct PLUMED to use a particular CV a line starting with
the keyword indicating the CV type must be included in the input file. This
keyword should then be followed by the various pieces of CV-specific infor-
mation required to calculate the variable along with the keywords that tell
PLUMED how this particular CV is to be employed. (N.B. unless stated ex-
plicitly these pieces of data can be specified in any order)
For metadynamics the lines defining the variables on which the user desires
there to be a biasing potential should contain the SIGMA keyword. This
keyword should then be followed by the width of the Gaussian hills (in the
units of the CV) on that particular CV. This keyword serves two functions;
namely, it instructs PLUMED to use metadynamics and tells it the widths of
the hills. Obviously the SIGMA keyword is not only required if you are running
metadynamics and is not required with other methods.
Specifying lists of atoms
Most collective variables require the user to specify one or several groups of
atoms in their definition. Whenever a set of atom groups is required, the LIST
keyword must be used. This keyword is then followed a set of tags which
specify the number and order of the groups of atoms to be employed. The
atoms involved in each of the groups invoked must be specified somewhere in
64
![](asset-42.png)
the input file. These group specifications must then start with the the name
of the group followed by the -> sign and finish with the same name followed
by the <- sign. Between these two delimiters the indices of the atoms which
comprise the group must then be listed, separated by spaces or line feeds.
Example.
The following syntax instructs PLUMED to use the distance between the center of mass of atoms 6 and 10
and the center of mass of atoms 8, 15 and 21 as a CV:
DISTANCE LIST <g1> <g2> SIGMA 1.0
g1->
6 10
g1<-
g2->
8 15 21
g2<-
Inside the group definition blocks, one can either specify the atom num-
bers explicitly, or one can use the LOOP keyword to define a regular sequence
of indices with a given starting number, end number and stride.
Example.
The following two commands are equivalent definitions of the group g1:
g1->
10 12 14 16 18 20
g1<-
g1->
LOOP 10 20 2
g1<-
For the special, and rather common, case of a group composed of a single
atom the user can specify the number of the atom of interest rather than the
corresponding <g> tag.
65
![](asset-43.png)
Example.
The following two commands are equivalent ways instruct PLUMED to use the distance between atom 5
and group <g1> as a CV:
DISTANCE LIST <g1> <g2> SIGMA 1.0
g1->
10 12 14 16 18 20
g1<-
g2->
5
g2<-
DISTANCE LIST <g1> 5 SIGMA 1.0
g1->
10 12 14 16 18 20
g1<-
4.1 Absolute position
The POSITION keyword instructs PLUMED to use the absolute position of an
atom or a group of atoms, specified by using the LIST keyword, as a CV.
This CV accepts several options that allow the user to restrict the bias to
a given direction, e.g. z, to bias the position of the particle as projected on
a selected line segment or, in analogy with the path CV, to bias the atoms’
distance from a line segment. The keyword DIR accepts as input X, Y or Z
and limits the restraint to the chosen direction.
Example.
The following line instructs PLUMED to use the ycoordinate of atom 13 as a CV.
POSITION LIST 13 SIGMA 0.35 DIR Y
The keyword LINE POS instructs PLUMED to use the projection of the
atoms position on a line as a CV, while the keyword LINE DIST instructs
PLUMED to use the distance from the line as a CV. In both these cases the
line is defined by stating its start and end points. The line can then either
be in constrained to be in the XY, XZ or YZ planes (keywords (XY, XZ or
YZ respectively) or it can have an arbitrary orientation in space (keyword
XYZ). Obviously if the line is constrained to the XY, XZ or YZ planes then
the start and end points are two dimensional vectors whereas if it has an
arbitrary orientation these vectors have three components.
66
![](asset-44.png)
Example.
The following lines instruct PLUMED to use the projection and distance of the coordinates of atom 13 on
a generic line segment defined by the start and end points (0,0,0) and (2,3,4) respectively as the two
collective coordinates.
POSITION LIST 13 SIGMA 0.35 LINE POS XYZ 0. 0. 0. 2. 3. 4.
POSITION LIST 13 SIGMA 0.35 LINE DIST XYZ 0. 0. 0. 2. 3. 4.
4.2 Distance
The DISTANCE keyword instructs PLUMED to use the distance between the
center of mass of two groups of atoms as a CV. Two groups must be defined
using the LIST keyword and the syntax described in section 4.
Example.
The following lines instruct PLUMED to use the distance between atom number 13 and the center of mass
of the four atoms in list <g1> as a CV.
DISTANCE LIST 13 <g1> SIGMA 0.35
g1->
17 20 22 30
g1<-
The optional flag NOPBC can be used to calculate the distance without
applying periodic boundary conditions. This should be done only if all the
atoms in the groups are part of the same molecule. See also Sec. 4.28.
The keyword DIR can be used to calculate the component of this distance
along the cartesian axes (X, Y or Z) and or the component in the planes
(XY, XZ or YZ).
Example.
The following line instruct PLUMED to use the X-component of the distance between atom number 20 and
25 as a CV.
DISTANCE LIST 20 25 DIR X SIGMA 0.35
Whenever one wants to use the difference between two distances one may
use the keyword DIFFDIST. This may turn to be useful in bond breaking/
bond formation.
67
![](asset-45.png)
Example.
The following line instruct PLUMED to use the difference between the distance between 20 and 25 and the
distance between 30 and 31 as CV.
DISTANCE LIST 20 25 DIFFDIST 30 31
Groups are also accepted as input instead of two atoms.
Other two useful variants are the following: the distance of a point from
an axis and the projection of the point on the axis. The first is introduced by
the additional keyword POINT FROM AXIS followed by the atom or the group
defining the point respect to which the distance has to be calculated. The
axis is defined through the standard two groups appearing in the definition
of the distance collective variable.
Example.
The following line instruct PLUMED to use the distance between one atom, 26 and the axis defined by the
two atoms 20 and 25 as CV.
DISTANCE LIST 20 25 POINT FROM AXIS 26
In a similar way it is possible to calculate the projection of this point on
an axis to be used as a CV by using the keyword PROJ ON AXIS.
Example.
The following line instruct PLUMED to use the projection of the coordinate if atom 26 on the axis defined by
the two atoms 20 and 25 as CV.
DISTANCE LIST 20 25 PROJ ON AXIS 26
Similarly to all the other variables, these two keywords may accept groups
instead of atom indexes.
4.3 Minimum distance
The MINDIST keyword instructs PLUMED to use the minimum distance between
two groups of atoms as a CV. To ensure differentiability, this quantity is
implemented as:
s=β
log Pij exp(β/||rij||),
68
![](asset-46.png)
where by default β= 500. The value of βcan however be tuned if needed
by using the optional keyword BETA. Much like the distance variable when
calculating the minimum distance one must define two groups using the LIST
keyword and the syntax described in section 4.
Example.
The following lines instruct PLUMED to use the minimum distance between atom number 13 and the set of
atoms in list <g1> as a CV.
MINDIST LIST 13 <g1> SIGMA 0.35 BETA 500.
g1->
17 20 22 30
g1<-
The optional flag NOPBC can be used to calculate the distance without
applying periodic boundary conditions. This should be only be done if all
the atoms in the groups are part of the same molecule. See also Sec. 4.28.
4.4 Angles
The ANGLE keyword instructs PLUMED to use the angle defined by the centers
of mass of three groups of atoms as a CV. The compulsory LIST keyword
must be followed by three properly defined groups (see Section 4).
Example.
The following lines instruct PLUMED to use the angle defined by atom number 102 and the centers of mass
of the atoms in groups g1 and g2 as a CV.
ANGLE LIST <g1> <g2> 102 SIGMA 0.05
g1->
13 15
g1<-
g2->
LOOP 1000 3000 3
g2<-
It is also possible to use the sine or cosine of the angle as a collective
coordinate by including the SIN or COS keywords respectively similarly to
what is done for TORSION.
69
![](asset-47.png)
4.5 Torsion
The TORSION keyword instructs PLUMED to use a dihedral angle as the CV.
This angle can either be defined by four atoms or, more generally, by the
positions of the centers of mass of four groups of atoms. The compulsory
LIST keyword must be followed by four properly defined groups (see Section
4).
Example.
The following lines instruct PLUMED to use to the torsion angle about the centers of mass of the four groups
<g1>,<g2>,<g3>,<g4> as a CV.
TORSION LIST <g1> <g2> <g3> <g4> SIGMA 0.35
It is also possible to use the sine or cosine of the torsional angle as a
collective coordinate by including the SIN or COS keywords respectively.
Example.
The following line instructs PLUMED to use the cosine of the torsion angle about the centers of mass of the
four groups <g1>,<g2>,<g3>,<g4> as a CV.
TORSION LIST <g1> <g2> <g3> <g4> COS SIGMA 0.35
4.6 Coordination number
The COORD keyword instructs PLUMED to use the total number of contacts be-
tween the atoms in group G1and those in group G2- the coordination number
between these two groups. To ensure differentiability, this is implemented as
the sum:
s=X
i∈G1X
j∈G2
sij,
where this sum is extended to all pairs of atoms with i∈ G1and j∈ G2. The
individual contributions sij are defined using a switching function, which, in
the present case, is given by:
sij =
1 for rij ≤0
1−(rij
r0)n
1−(rij
r0)mfor rij >0
70
![](asset-48.png)
where rij =|ri−rj|−d0. The user must supply the r0,d0,nand mparame-
ters, using the additional keywords R 0,D 0,NN and MM respectively and thus
has a great deal of control over the definition of the switching function. In
general a good first guess for these parameters can be achieved by looking at
the pair distribution function and setting d0equal to the position of the first
peak in the pair distribution function, r0as the full width at half maximum
of the peak and nand mto force sij '0 at the first minimum of the pair
distribution function. However, oftentimes different choices for these param-
eters will lead to better results because of certain specific properties of the
system of interest. An optional keyword PAIR treats the atoms in a pairwise
fashion so that instead of simply counting the number of bonds between two
groups of atoms one can define which precise bonds between the two groups
should be monitored. In this case the groups, <g1> and <g2> must have
the same number of atoms as the switching functions are on the distances
between the ith atom of group <g1> and the ith atom of group <g2>.
Example.
The following lines instruct PLUMED to use the coordination of the atoms in group g1 – 13 and 15 – with
the atoms in group solvent as the CV.
COORD LIST <g1> <solvent> NN 6 MM 12 D 0 2.5 R 0 0.5 SIGMA 0.35
g1->
13 15
g1<-
solvent->
LOOP 1000 3000 3
solvent<-
The optional flag NOPBC can be used to calculate the distance without
applying periodic boundary conditions. This should only be done when all
the atoms are part of the same molecule. See also Sec. 4.28.
4.7 Hydrogen bonds
HBONDS is the keyword for a variable that counts the number of intra-molecular
hydrogen bonds between a group of hydrogen bond donors and a group of
hydrogen bond acceptors. This is defined as:
s=X
ij
1−(dij
r0)n
1−(dij
r0)m,
71
![](asset-49.png)
where i∈ D is the group of donors and j∈ A are the acceptors.
The two groups must be defined using the compulsory LIST keyword fol-
lowed by two groups (see Section 4). PLUMED then assumes that there is only
one donor/acceptor per residue and, that within the list, the donor/acceptor
atoms on neighboring residues are consecutive. The values of r0,nand m
can be specified using the R 0,NN and MM keywords. If no value is given for
r0,nand mthe default values of r0= 2.5, n= 6 and m= 12 are assumed.
The TYPE keyword selects which residues to include in the count:
•With TYPE 0, all donor-acceptor pairs are included;
•If TYPE 1 is specified only those donor-acceptor pairs separated by an
odd number of residues greater than 4 are counted. This allows one to
monitor parallel β-sheet formations.
•If TYPE 2 is specified only those donor-acceptor pairs that are separated
by exactly 4 residues are included. This allows the formation of α-
helical conformations (αtype) to be monitored;
•If TYPE 3 is specified, only those donor-acceptor pairs that are sepa-
rated by an even number of residues greater than 4 are counted. This
allows anti-parallel β-sheet formations (β-even type) to be monitored.
•If TYPE 4 is specified, only the first donor and the first acceptor and so
on are counted. This allows to monitor a set of native hydrogen bonds.
•If TYPE 5 is specified, only hydrogen bonds between atoms belonging to
different residues are counted. Moreover, pairs with an index difference
less than 5 are also discarded, so as to avoid counting H and a O that
are in the same peptide group (NH-C=O) (contributed by M. Cuendet).
This option requires the user to specify to which residue each atom is
belonging using the RESLIST keyword (see example below).
72
![](asset-4a.png)
Example.
The following lines instruct PLUMED to use the count of the total number of hydrogen bonds between the
pairs in groups Hand Oas a CV. The default switching function with r0= 2.5,n= 6 and m= 12 is
implied.
HBONDS LIST <H> <O> TYPE 0 SIGMA 0.1
H->
6 10
H<-
O->
8 12
O<-
In the following example, a modified switching function is employed.
HBONDS LIST <H> <O> TYPE 0 SIGMA 0.1 NN 8 MM 20 R 0 2.5
In the following example, inter-residue hydrogen bond are counted
HBONDS LIST <H> <O> RESLIST <resH> <resO> TYPE 5
H-> 1 9 17 H<-
O-> 5 13 21 O<-
resH-> 1 2 3 resH<-
resO-> 1 2 3 resO<-
The optional flag NOPBC can be used to calculate the distance without
applying periodic boundary conditions. This should be done only when the
atoms are part of the same molecule. See also Sec. 4.28.
4.8 Interfacial water
WATERBRIDGE is the keyword for a CV that counts the number of interfacial
contacts. This variable does this by calculating the number of atoms from
group G0that are simultaneously in contact with atoms from both groups
G1and G2. A typical application of this CV is to count the number of water
molecules at the interface of two surfaces. This is calculated using:
sWatBr =
n0
X
i
n1
X
j
1−(|ri−rj|
r0)n
1−(|ri−rj|
r0)m
n2
X
j
1−(|ri−rj|
r0)n
1−(|ri−rj|
r0)m
.
The syntax of the command requires the user to specify three groups of atoms
after the keyword LIST starting with the G1and G2groups and closing with
73
![](asset-4b.png)
the G0group. (see Section 4). The parameters of the switching function are
then defined using the usual NN,MM and R 0 keywords.
Example.
The following command instructs PLUMED to use the number of atoms in the solvent group that are
simultaneously in contact with either atom 6 or 10 and either atom 8, 15 or 21 as a CV.
WATERBRIDGE LIST <type1> <type2> <solvent> NN 8 MM 12 R 0 4.0 SIGMA 0.1
type1->
6 10
type1<-
type2->
8 15 21
type2<-
solvent->
LOOP 100 1000 3
solvent<-
4.9 Radius of gyration
One can employ the radius of gyration of a group of atoms defined with the
compulsory additional keyword LIST by using the RGYR directive. The LIST
keyword (see Section 4) must be followed by only one properly defined group.
This CV is calculated using :
sGyr =Pn
i|ri−rCOM|2
Pn
imi1/2,
where the sums are over the natoms in group Gand the center of mass is
defined using:
rCOM =Pn
irimi
Pn
imi
.
Example.
The following lines instruct PLUMED to use the radius of gyration of the group <g1> as a CV.
RGYR LIST <g1> SIGMA 0.35
N.B. The radius of gyration is calculated without applying periodic bound-
ary conditions so the atoms in group <g1> should all be part of the same
molecule. See also Sec. 4.28.
74
![](asset-4c.png)
4.9.1 Gyration tensor based CVs
The RGYR directive can be used also to access to a number of CVs based on
gyration tensor [39]:
S=1
N
Px2
iPxiyiPxizi
PxiyiPy2
iPyizi
PxiziPyiziPz2
i
,(4.1)
which describes the spatial distribution of mass in a molecule or com-
plex of molecules. Alternatively, tensor of inertia may be used for the same
purpose:
I=
Pmi(y2
i+z2
i)P−mixiyiP−mixizi
P−mixiyiPmi(x2
i+z2
i)P−mixizi
P−mixiziP−miyiziPmi(x2
i+y2
i)
.(4.2)
The weighting of atomic contribution is controlled by keyword MASS-WEIGHTED
(default) and NO-WEIGHTED. When MASS-WEIGHTED directive is applied, the
individual atomic contribution to the gyration tensor is weighted by miN
Pmi
and the center of mass is used as origin of the system. If NO-WEIGHTED op-
tion is chosen, coordinates are related to the geometrical center of object and
no mass-weighting is performed in calculation of CV.
Diagonalizing of gyration tensor provides the principal moments of gyra-
tion - S1,S2,S3and three eigenvectors corresponding to the principal axes of
inertia. The individual gyration tensor based CVs are available by specifying
the directive RGYR and the keyword TYPE followed by one of the following:
•TRACE: trace of inertia tensor
•GTPC 1: the largest eigenvalue of gyration tensor. The square root
S0
1=√S1of principal moment S1is used as CV. If we approximate
the shape and mass distribution of the object with an ellipsoid, S0
1
corresponds to the largest radius of this ellipsoid.
•GTPC 2: the middle principal moment of gyration tensor, S0
2=√S2.
•GTPC 3: the smallest principal moment of gyration tensor, S0
3=√S3.
•RGYR 1: the largest radius of gyration around principal axes of inertia,
rg1=√S1+S2.
75
![](asset-4d.png)
•RGYR 2: the middle radius of gyration around principal axes of inertia,
rg2=√S1+S3.
•RGYR 3: the smallest radius of gyration around principal axes of inertia,
rg3=√S2+S3.
•ASPHERICITY: the deviation of mass distribution from spherical sym-
metry. The modified version of asphericity was implemented as a
CV: b0=√b, where original Suter’s [40] asphericity is given by b=
S1−1
2(S2+S3).
•ACYLINDRICITY: the deviation from cylindrical symmetry. Again the
modified version c0=√cis used as a CV rather then original form [40]
c=S2−S3.
•KAPPA2: the relative shape anisotropy[40] κ2= 1 −3S1S2+S1S3+S2S3
(S1+S2+S3)2re-
flects both symmetry and dimensionality of an object. Limited between
values of 0 and 1, κ2reaches 1 for an ideal linear arrangement and drops
to zero in case of highly symmetric configurations (at least tetrahedral
symmetry).
Example.
The following lines instruct PLUMED to use the trace of the inertia tensor of the group <g1> as a CV.
RGYR TYPE INERTIA LIST <g1> SIGMA 0.35
Example.
The following lines instruct PLUMED to use the asphericity of the group <g1> as a CV.
RGYR TYPE ASPHERICITY LIST <g1> SIGMA 0.35
76
![](asset-4e.png)
4.10 Dipole
DIPOLE instructs PLUMED to use the electrical dipole generated by a group of
atoms as a CV:
sdipole =|
n
X
i
riqi|.
Only the LIST keyword followed by one properly defined group is required
to define this CV (see Section 4).
Example.
The following lines instruct PLUMED to use the dipole of the group <g1> as a CV.
DIPOLE LIST <g1> SIGMA 0.35
4.11 Dihedral correlation
DIHCOR is the keyword for a CV that measures the similarity between adjacent
dihedral angles:
sDC =
ND
X
i=2
1
2(1 + cos (φi−φi−1)) .
The syntax for this CV requires the user to specify the number of dihedrals
NDand, in the subsequent NDlines, the indices of the four atoms defining
each dihedral φi.
Example.
The following lines instruct PLUMED to use the dihedral correlation for the 3 dihedrals listed as a CV.
DIHCOR NDIH 3 SIGMA 0.1
168 170 172 188
170 172 188 190
172 188 190 197
77
![](asset-4f.png)
4.12 Alpha-beta similarity
ALPHABETA is a keyword for a CV that measures the similarity of dihedral
angles to a reference value (see also ??). It is calculated using:
sαβ =1
2
ND
X
i=1 1 + cos φi−φRef
i.
The syntax for this CV requires the user to specify the number of dihedrals
NDand, in the subsequent NDlines, the indices of the four atoms defining
each dihedral followed by the value of the dihedral in the reference confor-
mation φRef
i.
Example.
The following lines instruct PLUMED to use the Alpha-beta similarity of three dihedrals as a CV.
ALPHABETA NDIH 3 SIGMA 0.1
168 170 172 188 3.14
170 172 188 190 .56
188 190 192 230 3.14
4.13 Alpharmsd
ALPHARMSD is the keyword for a CV that counts the number of 6-residue
segments in the protein chain that resemble an ideal alpha helix (i.e. the
average experimental structure). This CV is calculated using:
sαrmsd =X
α
nhRMSD {Ri}i∈Ωα,nR0oi,
where nis the coordination (switching) function defined in Sec. 4.6. The sum
over αin the above runs over all the 6-residue segments in the protein chain,
where each of the residues is defined based on the positions of the backbone
atoms N, CA, C, O and CB, Ωα. The distance used in the switching function
is then the root mean square difference between the distance matrix of the
atoms in the set Ωαwith the corresponding distances between these atoms
in the ideal alpha helix {R0}:
RMSD {Ri}i∈Ωα,nR0o=v
u
u
t
1
Npairs X
i,j∈Ωαdij −d0
ij2.
78
![](asset-50.png)
See Ref.[41] for more details (although note that in PLUMED the RMSD be-
tween distance matrices is used rather than the cartesian RMSD. However,
these two measures are essentially equivalent).
To use this CV the syntax requires the user to specify the coordination
function parameters R0,D 0,NN and MM (see Sec. 4.6) (we suggest val-
ues of R 0=0.8 Angstrom, NN=8, MM=12, D 0=0), and a conversion factor
ANGSTROM SCALE which converts the ideal alpha positions from Angstrom to
the length units of the MD code (e.g. in Gromacs units are nanometers
therefore ANGSTROM SCALE is 0.1). In addition a list of list of atom indices for
the N, CA, C, O and CB (in this order) for each residue must be provided
for all the consecutive residues (in ascending order) which form the chain.
For those residues, such as glycine, which do not have a CB the atom index
for the corresponding hydrogen should be used.
Important note: for those MD codes which, like Gromacs4, do not keep
the protein whole but instead split it by the PBC, ALPHARMSD requires the
additional option NOPBC, together with the ALIGN ATOMS command for all the
atoms employed in the ALPHARMSD.
Example.
The following lines define an Alpharmsd CV for all 16 consecutive residues of a protein in the MD code
Gromacs4 (which uses nanometers as the length unit).
ALPHARMSD LIST <ncacocb> SIGMA 0.5 R 0 0.08 NN 8 MM 12 ANGSTROM SCALE 0.1 NOPBC
ncacocb->
1 5 23 24 7
25 27 42 43 29
44 54 56 57 51
58 68 70 71 65
72 74 77 78 76
79 81 101 102 83
103 105 116 117 107
118 120 138 139 122
140 142 162 163 144
164 166 179 180 168
181 183 190 191 185
192 194 214 215 196
216 218 225 226 220
227 229 236 237 231
238 240 243 244 242
245 247 267 268 249
ncacocb->
79
![](asset-51.png)
4.14 Antibetarmsd
ANTIBETARMSD counts the number of pairs of 3-residue segments in the pro-
tein chain which are similar to the ideal antiparallel beta (i.e. the average
experimental structure). See Ref.[41] for details (but remember that here the
RMSD among distance matrices is used instead of the cartesian RMSD as the
two are basically equivalent). The definition, input parameters and syntax
for this CV are the same as for the ALPHARMSD and again we suggest values
of R0=0.8 Angstrom, NN=8, MM=12, D 0=0 for the parameters. The only
difference in the implementation is the additional option STRANDS CUTOFF
which allows the user to specify a threshold distance beyond which pairs of
3-residue segments are considered far. This option considerably speeds up
the computation (often 1 nm is good choice for this quantity).
Important note: for those MD codes which, like Gromacs4, do not keep
the protein whole but instead split it by the PBC, ANTIBETARMSD requires
the additional option NOPBC, together with the ALIGN ATOMS command for
all the atoms employed in the ANTIBETARMSD.
Example.
The following lines define an Antibetarmsd CV for all 16 consecutive residues of a protein in the MD code
Gromacs4 (which uses nanometers as the length unit).
ANTIBETARMSD LIST <ncacocb> SIGMA 0.5 R 0 0.08 NN 8 MM 12 ANGSTROM SCALE 0.1
STRANDS CUTOFF 1. NOPBC
ncacocb->
1 5 23 24 7
25 27 42 43 29
44 54 56 57 51
58 68 70 71 65
72 74 77 78 76
79 81 101 102 83
103 105 116 117 107
118 120 138 139 122
140 142 162 163 144
164 166 179 180 168
181 183 190 191 185
192 194 214 215 196
216 218 225 226 220
227 229 236 237 231
238 240 243 244 242
245 247 267 268 249
ncacocb->
80
![](asset-52.png)
4.15 Parabetarmsd
PARABETARMSD counts the number of pairs of 3-residue segments in the protein
chain which are similar to the ideal parallel beta (i.e. the average experimen-
tal structure). See Ref.[41] for details (but remember that here the RMSD
among distance matrices is used instead of the cartesian RMSD as the two are
basically equivalent). The definition, input parameters, and syntax are the
same as for theALPHARMSD and again we suggest values of R0=0.8 Angstrom,
NN=8, MM=12, D 0=0 for the parameters. The only difference in the imple-
mentation is the additional option STRANDS CUTOFF which allows the user to
specify a threshold distance beyond which pairs of 3-residue segments are
considered far. This option considerably speeds up the computation (often
1 nm is good choice for this quantity).
Important note: for those MD codes which, like Gromacs4, do not keep
the protein whole but instead split it by the PBC, PARABETARMSD requires
the additional option NOPBC, together with the ALIGN ATOMS command for
all the atoms employed in the PARABETARMSD.
Example.
The following lines define a Parabetarmsd CV for all 16 consecutive residues of a protein in the MD code
Gromacs4 (which uses nanometers as the length unit).
PARABETARMSD LIST <ncacocb> SIGMA 0.5 R 0 0.08 NN 8 MM 12 ANGSTROM SCALE 0.1
STRANDS CUTOFF 1. NOPBC
ncacocb->
1 5 23 24 7
25 27 42 43 29
44 54 56 57 51
58 68 70 71 65
72 74 77 78 76
79 81 101 102 83
103 105 116 117 107
118 120 138 139 122
140 142 162 163 144
164 166 179 180 168
181 183 190 191 185
192 194 214 215 196
216 218 225 226 220
227 229 236 237 231
238 240 243 244 242
245 247 267 268 249
ncacocb->
81
![](asset-53.png)
4.16 Electrostatic potential
Using the ELSTPOT keyword one can instruct PLUMED to use the electrostatic
potential exerted by a group of atoms on the center of mass of a second group
of atoms (or single atom) as a CV. This CV is calculated using:
sELST =
NA
X
i
qi
|ri−rCOM|∗f(|ri−rCOM|, R0, CU T )
where
rCOM =PNB
irimi
PNB
imi
.
Here the sum in the first equation above is over the NAatoms in the group
whose charges exert the electric potential, while in the second equation the
sum is over the NBatoms in the group that defines the point at which this
potential is felt. f(x) is a smoothing function defined as:
f(x, R0, CUT ) =
1.0x<R0
cos πx
2(CU T −R0)R0≤x≤CUT
0x > CUT
where R0is the onset and CUT is a cutoff distance.
Example.
The following lines instruct PLUMED to use the electrostatic potential exerted by the atoms in group2 on the
center of mass of the atoms in group1 as a CV:
ELSTPOT LIST <group1> <group2> R 0 4.0 CUT 12.0 SIGMA 0.01
group1->
LOOP 1 8 1
group1<-
group2->
LOOP 9 16 1
group2<-
4.17 Puckering coordinates
PUCKERING refers to the set of collective coordinates for 6-membered rings in
polar coordinates [42]. Given the coordinates zj, that represent the displace-
ments of the j−th atom from the mean ring plane, three variables Q, θ, φ can
be obtained starting from the general definition for 6-membered rings
82
![](asset-54.png)
q2cos φ2=s1
3
6
X
j=1
zjcos 2π
3(j−1)
q2sin φ2=−s1
3
6
X
j=1
zjsin 2π
3(j−1)
q3=s1
6
6
X
j=1
(−1)j−1zj
as
Q=qq2
2+q2
3≥0
θ= arctan (q2/q3)∈[0, π]
φ=φ2∈[0,2π)
Each one can be selected as a TYPE of PUCKERING. The CV accept the
LIST and SIGMA keywords. As of now LIST accept only 6 atoms. The atoms
in the list have to be enumerated following the chemical sequence (although
the numbering scheme in the topology does not have to be sequential). In
order to fulfill IUPAC convention for sugar hexopyranose rings the first atom
in the list has to be the ring oxygen, followed by the anomeric carbon. Qis
in general a fast degree of freedom.
Example.
The following lines define a PUCKERING CV:
PUCKERING LIST <group1> TYPE PHI SIGMA 0.1
group1->
1 2 3 4 5 6
group1<-
4.18 Path collective variables
One can instruct PLUMED to use path collective variables [43] using the S PATH
and Z PATH keywords. In this scheme one defines a path as a set of Nreference
conformations that define the path in configuration space Xfrom some initial
83
![](asset-55.png)
state to some final state. The svariable (defined with S PATH) then measures
the position along the path, and is defined as:
s=Z−1
N
X
i=1
ie−λd(Xi,X(t)),
where X(t) is the configuration of the system at any given time, d:X ×X →
R+
0is a metric on X, and Z=PN
i=1 e−λd(Xi,X(t)) is a normalization factor in
which the prefactor, λ, should be chosen so as to have λd(Xi, Xi±1)'2.3 on
average.
By contrast the zvariable (defined with Z PATH) measures the position
off the path, and is defined as:
z=−λ−1log Z.
For both S PATH and Z PATH the following keywords must be used:
•TYPE, which defines the metric used to calculate distances in configu-
ration space. The following sections provide more details on this but,
suffice to say, currently one can use either MSD (mean square deviation
see section 4.18.1), DMSD (distance root mean squared deviation see sec-
tion 4.18.2) or CMAP (the distance between contact matrices see section
4.18.3) [44].
•NFRAMES which sets the number of reference structures, N, that are
used in the definition of the path.
•LAMBDA, the prefactor λin the exponential term of the equation that
defines both sand z.
•Optionally, you can also use NEIGHLIST which defines a neighbor list on
the closest frames to speed up the calculation followed by the number of
steps in which the list must be calculated and the number of elements
it must contain (e.g. NEIGHLIST 50 10 means that each 50 steps the
neighbour list must be calculated and it will contain the 10 closest
elements to the current molecular dynamic snapshots. All the other
are discarded up to the next neighbor list calculation.).
Other keywords are specific to the type of path variable being defined
(i.e. mean square displacement in Cartesian coordinates, MSD in distances
or contact map distance).
84
![](asset-56.png)
An important change occurred from the version 1.2 to 1.3 : the conven-
tion for the names has changed the former RMSD has been replaced by MSD.
Similarly DRMS has been changed into DMSD. This was done since many users
noticed the inconsistencybetween the definitions and the related keywords.
N.B. before using this feature please ensure that the parameters in metadyn.h
(common files directory) are set properly. In particular look for the section
containing:
// path dimensions
#define MAXATOMS PATH 230
#define NMAX PATH 8
#define MAXFRAMES PATH 22
#define MAXATOMS RMSD 230
#define MAXCHARS PATH 40
// cmap
#define MAXDIM CMAP 3800
#define MAXNUM GROUP 10
#define MAXATOM GROUP 30
and ensure that MAXATOMS PATH is greater than or equal to the number
of atoms per frame involved in your path and MAXFRAMES PATH is greater
than or equal to the number of frames you are using to define your path. In
addition NMAX PATH maximum number of path variables that you can use
simultaneously. If you change any of these values you must subsequently
recompile all the MD codes in which you have implemented PLUMED in order
for your changes to take effect.
4.18.1 Mean square deviation
As already briefly mentioned, when using the path collective coordinates
S PATH and Z PATH, the command MSD after the TYPE keyword instructs
PLUMED to the the mean square deviation of a subset of the atoms in the
system (the displacement set B) calculated after the system has been aligned
to another subset of the atoms (the alignment set A) as the metric used in
the definition of the path. This quantity is calculated using
d(Xj, Xi) =
NB
X
a=1
wj
wT OT
(X(j)
a−Mij({z})X(i)
a)2,
85
![](asset-57.png)
where Mij({z}) is the roto-translation matrix calculated using the Kears-
ley [45] algorithm and wjis the number specified (called the displacement
parameter) for the beta column in the provided input PDB. If this is one
then wj=1 and wT OT =N(while differently wT OT =PN
iwi). The weights for
the alignment are actually taken into account when forming the alignment
matrix that compose the Mij({z}) and are denoted here with the set {z}
defined by the beta column in the reference PDB.
To use path CVs the user must specify the coordinates of the atoms in
each of the reference frames of the path in a set of supplementary input files.
The user should specify the basename of these files (¡basename¿) after the
keyword FRAMESET and be aware that PLUMED then will expect to find N
files named ¡basename¿.i.pdb, which contain the coordinates of the atoms
in both the displacement and alignment sets for the ith frame in the path.
The particular set/s each atom is involved in is specified using the the last
two numerical fields of the frameset file. Values of 1.0 and 0.0 indicate that
the atom is to be used in the alignment set only, while values of 0.0 and 1.0
indicates that the atom is to be used in the displacement set only. Values of
1.0 and 1.0 indicate that the atom is to be used in both the alignment and
displacement sets.
Version 1.1 and higher allow these alignment and displacement indicators to
be non-integer. This allows users to perform a weighted alignment in cases
where the alignment of one region of system is considered more important
and a weighted displacement evaluation in cases where the displacement of a
particular atom/s is though to be of particular importance. Be aware how-
ever that this feature can produce strange numbers that are not trivial to
interpret and is thus perhaps best left to experienced users.
N.B. PLUMED contains a hard coded limit on the number of atoms that can
be used in the alignment so, like in the previous section, users should ensure
that the value of this hard limit (MAXATOMS RMSD in metadyn.h) is sufficiently
large for their needs prior to compilation.
The unit of distance in the PDB files is ˚
Angstrom. Engines like GROMACS,
whose internal units are different, will perform appropriate conversions au-
tomatically.
Clearly, the atom indices in these PDB files must be the same as the indices
of the atoms they refer to in the system topology. It is therefore likely that
the atom indices in the frameset files may be non-consecutive.
Additional keywords are supported: NO ROT and NO CENTER. These two key-
words prevent the rotation and the center of mass alignment respectively
86
![](asset-58.png)
whenever one uses MSD.
Example.
The following command defines a path using MSD metrics. 2 frames are used to define the path, which
has λ= 9.0.
SPATH TYPE MSD FRAMESET frame NFRAMES 2 LAMBDA 9.0 SIGMA 0.1
Z PATH TYPE MSD FRAMESET frame NFRAMES 2 LAMBDA 9.0 SIGMA 0.1
Two PDB files must be provided: frame 1.pdb and frame 2.pdb. The last two columns of these files specify
which atoms are to be used for alignment and which are to be used to calculate the MSD.
ATOM 1 C ALA 2 -0.186 -1.490 -0.181 1.00 0.00
ATOM 2 O ALA 2 -0.926 -2.447 -0.497 1.00 1.00
ATOM 15 N ALA 2 0.756 0.780 -0.955 1.00 0.00
ATOM 17 CA ALA 2 0.634 -0.653 -1.283 1.00 1.00
ATOM 19 CB ALA 2 2.063 -1.233 -1.286 1.00 1.00
END
4.18.2 Distance mean square deviation
Instead of using the MSD in the definition of the metric for the path in the
S PATH and Z PATH CVs the command DMSD after the TYPE keyword allows
one to use a metric based on the mean square deviation of the distances
between a subset of the atoms in the system:
d(Xj, Xi) = 2
NA(NA−1)
NA−1
X
a=1
NA
X
b=a+1
(r(j)
ab −r(i)
ab )2,
where r(j)
ab is the distance of atoms aand bin the j-th reference frame. For this
metric the coordinates of the atoms in the reference frames of the path are
specified using the keyword FRAMESET along with a set of pdb files containing
the atom coordinates. This is the same way that they are specified when the
root mean square deviation metric is used (see section 4.18.1).
4.18.3 Contact map distances
The final choice one can employ to define the metric for the path in the
S PATH and Z PATH CVs is to use the command CMAP after the TYPE keyword.
87
![](asset-59.png)
This sets the metric for the path to be the distance between the contact
matrices for a given subset of the atoms in the system:
d(Xj, Xi) = ||D(j)
ab −D(i)
ab ||.
Given two sets of atoms a, b ∈ J, this contact matrix Dab is calculated using:
Dab(X) = θ(cab −rab)wab 1−(rab/r(0)
ab )n
ab
1−(rab/r(0)
ab )m
ab,
where θ(x) is a step function which vanishes if x < 0.
As with other variables, the parameters r(0)
ab ,nab and mab allow for a
great freedom in the definition of the switching function. What is more the
parameter cab allows one to set the values of the switching function to zero at
large separations. Finally, if the formation of particular contacts is deemed
to be of great importance the weights wab can be used to change their relative
importance.
Like the other metrics for the path collective variables to use path col-
lective variables with a contact map metric information must be provided in
supplementary files about the frames that make up the path. The syntax
requires the user to specify a file name for the indices of the atoms and the
parameters defining the calculation of the contact matrix (after the keyword
INDEX) and another filename for the values of the reference matrices D(i)
ab ,
after the keyword MAP.
The index file, specified after the INDEX keyword, must contain one line for
each of the elements in the contact matrix Dab, which specified how that
particular contact should be calculated. Each of these lines should begin
with the CONTACT keyword followed by a numerical label for the contact.
The next two fields are the indices a, b of the two atoms that make up the
contact, which are followed by the values of r(0)
ab ,nab,mab,cab and wab in the
switching function.
The values file, specified after the keyword MAP, contains the values of the
reference matrices D(i)
ab used in the definition of the path. Each line in this file
corresponds to one element in the contact matrix. These lines are formatted
with the numerical label for the contact as the first field. This is followed by
the indices of the two atoms that make up the contact a, b and finally the
value of this particular switching function in the reference frame. Unlike the
MSD and DMSD metrics all the reference frames are placed in a single file
with each reference frame separated by the END keyword.
88
![](asset-5a.png)
The optional flag NOPBC can be used to calculate the distance without
applying periodic boundary conditions. This should be done only if all the
atoms in the groups are part of the same molecule. See also Sec. 4.28.
Example.
The following command defines a path using the contact map metric. 2 frames are used to define the path
with λset equal to 0.1.
SPATH TYPE CMAP NFRAMES 2 INDEX fr.ndx MAP fr.mps LAMBDA 0.1 SIGMA 1. NOPBC
The fr.ndx file should contain the details on how each of the switching functions in the contact matrix
should calculated:
CONTACT 1 1 2 3.0 6 10 100.0 1
CONTACT 2 1 15 3.0 6 10 100.0 1
CONTACT 3 17 2 3.0 6 10 100.0 1
CONTACT 4 15 19 3.0 6 10 100.0 1
The fr.mps file contains the values of the reference matrices:
1 1 2 0.99491645
2 1 15 0.76586085
3 17 2 0.79183088
4 15 19 0.81924184
END
1 1 2 0.99369661
2 1 15 0.76748693
3 17 2 0.76454272
4 15 19 0.72917217
END
One can also use contact matrices that involve contacts between the cen-
ters of mass of groups of atoms. However, in this case, a further additional
file containing the definition of the groups must be provided. The name of
this file is specified in the PLUMED input file, using the GROUP keyword. Then
within the specified file each group is defined on a single line starting with
the GROUP keyword. This keyword is followed by a numerical label for the
group, the number of atoms in the group and then a list of the indices of
the various atoms that make up the group. To instruct PLUMED to use these
group contacts rather than atomic contacts one must use lines starting with
the keyword GROUP in the index file. The remainder of the format of the
lines in the index file and the format of the corresponding lines in the map
file are identical to the lines used to specify atomic contacts. However, the
indices that would have specified the indices of the atoms involved in the
atomic contact must be replaced with the indices from the group file of the
two groups that make up the contact.
89
![](asset-5b.png)
Example.
The following command defines a path using the contact matrix metrics. 2 frames are used to define the
path, and a value of λ= 0.1is set.
S PATH TYPE CMAP NFRAMES 2 INDEX fr.ndx MAP fr.mps GROUP fr.grp LAMBDA 0.1 SIGMA 1.
The file fr.grp defines three groups of atoms:
GROUP 1 4 23 43 56 457
GROUP 2 5 76 47 97 322 695
GROUP 3 4 17 15 19 2
The fr.ndx file contains the parameters of the contacts between groups:
GROUP 1 1 2 3.0 6 10 100.0 1
GROUP 2 1 3 3.0 6 10 100.0 1
GROUP 3 2 3 3.0 6 10 100.0 1
Finally, the fr.mps has the values of the contact matrix in the reference positions:
1 1 2 0.9949
2 1 3 0.7658
3 2 3 0.7918
END
1 1 2 0.9936
2 1 3 0.6674
3 2 3 0.8645
END
It is possible to have maps in which there are both atomic and group
contacts. However, be aware that, in the index files in which the switching
functions are specified, the definitions of the group contacts MUST follow
the definitions of the atomic CONTACT functions.
Example.
An example of an index file containing both atom-atom contacts and group contacts:
CONTACT 1 123 545 7.0 6 10 100.0 0.50
CONTACT 2 224 244 8.5 6 10 100.0 0.50
GROUP 3 1 2 3.0 6 10 100.0 1.00
90
![](asset-5c.png)
4.18.4 Using path variables as MSD, DMSD and CMAP
and the TARGETED statement
If one defines a zpath collective variable with a single frame it is clear from
the definition
z=−λ−1log Z=−λ−1log X
f
e−λdf
that this is equivalent to using to the squared distance of the current config-
uration from a reference structure in the chosen metric. This CV can thus
be used in simulations which employ the standard MSD, distance DMSD or
CMAP distance from a single frame as a collective coordinate. However, in
this case we recommend use of the alias TARGETED instead, which defines the
exact same CV but with a far simpler syntax.
Example.
The following command instructs PLUMED to do steered MD towards a target frame using MSD metrics.
PRINT W STRIDE 10
TARGETED TYPE MSD FRAMESET ref frame.pdb
STEER CV 1 TO 3.0 VEL 0.5 KAPPA 500.0
ENDMETA
A single PDB file must be provided: ref frame.pdb, in which the last two columns specify which of the
atoms are to be used for alignment and which are to be used to calculate the MSD/DMSD (see section
4.18.1).
ATOM 1 C ALA 2 -0.186 -1.490 -0.181 1.00 0.00
ATOM 2 O ALA 2 -0.926 -2.447 -0.497 1.00 1.00
ATOM 15 N ALA 2 0.756 0.780 -0.955 1.00 0.00
ATOM 17 CA ALA 2 0.634 -0.653 -1.283 1.00 1.00
ATOM 19 CB ALA 2 2.063 -1.233 -1.286 1.00 1.00
END
In the case of CMAP the input for PLUMED is
PRINT W STRIDE 10
TARGETED TYPE CMAP INDEX CMAPINDEX MAP CMAPVALUES
STEER CV 1 TO 3.0 VEL 0.5 KAPPA 500.0
ENDMETA
where the CMAPVALUES file contains only one map (for details on the format of the CMAPINDEX and
CMPAVALUES file see section 4.18.3).
Additionally one can specify another keyword SQRT that transform the
metrics in its square root, namely the mean square deviation would be
91
![](asset-5d.png)
changed into the more commonly used root mean square deviation. Simi-
larly it applies to DMSD and CMAP. It should be stressed that the use of this
keyword is particularly dangerous especially for values close to zero since the
square root has a cusp there. The former example would look like:
Example.
PRINT W STRIDE 10
TARGETED TYPE MSD SQRT FRAMESET ref frame.pdb
STEER CV 1 TO 3.0 VEL 0.5 KAPPA 500.0
ENDMETA
4.19 Contact Map
The Contact Map is defined as the sum of the contacts between a number
of atom pairs specified by the user. A contact is defined in terms of the
switching functions introduced for the coordination number CV in section
4.6. Each contact can have its own set of parameters, which are defined in
a file specified by the keyword INDEX. See the documentation in paragraph
4.18.3 for a detailed explanation of the index file syntax.
As for PCV in contact map space (see paragraph 4.18.3), one can define
contacts between the centers of mass of groups of atoms. The name of the
file in which groups are defined is specified by using the GROUP keyword. See
the documentation in paragraph 4.18.3 for additional details.
The optional flag NOPBC can be used to calculate distances without ap-
plying periodic boundary conditions.
Example.
The following command defines the CV Contact Map. Distances are calculated without periodic boundary
conditions.
CMAP INDEX fr.ndx SIGMA 1. NOPBC
The fr.ndx file should contain the details on how each of the switching functions in the contact matrix
should calculated:
CONTACT 1 1 2 3.0 6 10 100.0 1
CONTACT 2 1 15 3.0 6 10 100.0 1
CONTACT 3 17 2 3.0 6 10 100.0 1
CONTACT 4 15 19 3.0 6 10 100.0 1
92
![](asset-5e.png)
4.20 Energy
The ENERGY keyword instructs PLUMED to use the total potential energy of
the system [46, 47, 48, 49] as a CV. Currently this CV is available only in
GROMACS4, AMBER and DL POLY.
Example.
The following lines instruct PLUMED to use the potential energy of the system as a CV.
ENERGY SIGMA 100.0
4.21 Helix loops
The HELIX keyword instructs PLUMED to use the number of α-helix loops as a
CV. A helix loop is formed when the pair of dihedral angles (Φ,Ψ) for three
consecutive residues along the chain all adopt a particular pair of reference
values (¯
Φ,¯
Ψ). Typically in an alpha helix ¯
Φ and ¯
Ψ have values of -1.200 and
-0.785 respectively. Having specified reference values for the dihedrals the
total number of loops is calculated using:
s=
N−1
X
i=2
i+1
Y
j=i−1
1
4hcos(Φj−¯
Φi)+1ihcos(Ψj−¯
Ψi)+1i,(4.3)
where Nis the total number of residues. This CV requires the user to specify
the number of loops with the NLOOP keyword. Then for each loop the user
should provide three sets of four atoms that define the dihedrals Φi−1,Φi,Φi+i
and a reference value for the dihedral ¯
Φialong with three sets of four atoms
that define the dihedrals Ψi−1,Ψi,Ψi+iand a reference value the dihedral ¯
Ψi.
Example.
The following lines instruct PLUMED to use the number of α-helix loops as a CV.
HELIX NLOOP 2 SIGMA 0.1
10 12 14 20 20 22 24 35 35 37 39 49 -1.200 12 14 20 22 22 24 35 37 37 39 49 51 -0.785
20 22 24 35 35 37 39 49 49 51 53 59 -1.200 22 24 35 37 37 39 49 51 51 53 59 61 -0.785
93
4.22 PCA projection
The PCA keyword instructs PLUMED to use as CV the projection of a set
of atoms on a previously calculated Principal Components Analysis (PCA)
eigenvector[50]. A typical application of this CV is to explore the system
along its principal directions of fluctuations [51].
The current conformation Xis first aligned to a reference structure Xref
(except if the optional NOALIGN keyword is used) and then projected on the
specified eigenvector e0. The set of atoms used for alignment must be the
same as the one the eigenvector refers to. The user should specify the filename
of the reference structure after the keyword FRAME and the filename of the
eigenvector after the keyword EIGENVEC.
If the optional DIFF keyword is used, the difference between the current
(aligned) conformation and the centered reference structure is projected on
the eigenvector.
The CV is calculated as :
sP CA(X, Xref , e0) =
N
X
i=1
<Rref (Xi−XCM ), e0
i>
or, when using the DIFF keyword, as :
sP CA(X, Xref , e0) =
N
X
i=1
<Rref (Xi−XCM )−Xref
0, e0
i>
where Nis the number of atoms used to align and project, Rref is the 3×3
rotation matrix, calculated using the Kearsley [45] algorithm, that optimally
overlaps the current centered set of atoms (Xi−XCM ) into the centered
reference set of atoms Xref
0,XCM is the current centroid of conformation X
(i.e. identical masses are assumed) and <, > denotes the usual inner product.
If the optional NOALIGN keyword is used, no alignment is performed (i.e.
the above rotation matrix Ris the identity). This latter keyword is supported
mainly for debug purposes.
94
![](asset-60.png)
Example.
The following command defines a CV as projection, along the eigenvector listed in egv0.dat, of the current
conformation aligned to the reference structure specified in ref.dat:
PCA FRAME ref.dat EIGENVEC egv0.dat SIGMA 0.1
where ref.dat contains the reference structure in the format ATOMID X Y Z:
# my reference structure
2 1.324 1.045 1.550
5 1.316 1.174 1.469
6 1.345 1.174 1.350
7 1.287 1.286 1.538
and egv0.dat contains the eigenvector in the same format:
# my first PCA eigenvector
2 0.12 3.28 0.19
5 0.53 1.37 1.10
6 -0.23 1.93 0.33
7 5.32 -2.56 1.44
More eigenvectors can be used with additional PCA keywords as additional
CVs, nevertheless, the set of atoms and the reference structure must be the
same for all of them.
Example.
The following command defines two CVs as projections, along two distinct eigenvectors listed in egv0.dat
and egv1.dat, of the difference between the current aligned conformation and the reference structure
specified in ref.dat:
PCA FRAME ref.dat EIGENVEC egv0.dat DIFF SIGMA 0.1
PCA FRAME ref.dat EIGENVEC egv1.dat DIFF SIGMA 0.1
Some final notes :
•the atom and eigenvector coordinates should be in engine units (e.g. in
nm for GROMACS)
•the alignment is not mass-weighted (identical masses for all the involved
atoms are assumed), and since the routine used for the alignment is the
same as the one used to calculate the RMSD, the same cautions hold. In
particular, (i) users should ensure that the value of the hardcoded limit
(MAXATOMS RMSD in metadyn.h) is sufficiently large for their needs prior
to compilation, (ii) the use of double precision code is recommended as
well as (iii) the use of the directive ALIGN ATOMS. See also 4.28.
95
![](asset-61.png)
•starting the simulation from the identical conformation used for align-
ment should be avoided since it could generate numerical instabilities
in the calculation of the rotation matrix, possibly leading to a crash of
the simulation.
•comments line beginning with ’#’ are allowed but blank lines must be
avoided from the input files.
4.23 SPRINT topological variables
The SPRINT keyword instructs PLUMED to use as CV the “Social PeRmutation
INvarianT” coordinates described in Ref. [52]:
Si=√N λmax vmax,sorted
i
where λmax and vmax
iare the largest eigenvalue and the corresponding
eigenvector of the N×Ncontact matrix among Natoms:
N
X
j=1
Cij vmax
j=λmax vmax
i
and Cij is the same coordination function defined for the CV COORD in Sec-
tion 4.6, with the corresponding parameters specified by the keywords R 0,
D0(both in units of the host MD code, e.g. Bohr for CPMD), NN, and MM.
In Sithe eigenvector components are sorted from the smallest to the largest,
so that S1< S2< S3< ... < SN. Which Sihas to be used as CV is specified
by the keyword INDEX: e.g. INDEX 2 means that the 2nd one has to be used,
namely S2. Note that the sorting of the eigenvector is performed only within
sets of atoms of the same element (automatically identified in PLUMED by
the atomic mass): if the list of Natoms includes e.g. two carbon and four
hydrogen atoms, the SPRINT coordinates are sorted only within carbon atoms
and within hydrogen atoms, without mixing the two elements (since atoms of
different elements are not indistinguishable). Due to this, after keyword R0
it must be specified the number of different element pairs and the R 0-value
for each possible pair of elements. The same holds for D 0. See below for an
example.
96
![](asset-62.png)
Example.
The following command defines a SPRINT CV S2from a set of two carbon (1,2) and four hydrogen atoms
(3,4,5,6):
SPRINT LIST <all> NN 6 MM 12 R 0 3 5.0 4.2 4.2 INDEX 2 SIGMA 1.0
all->
1 2 3 4 5 6
all<-
In the example above R 0 3 5.0 4.2 4.2 refers to the three pairs of
elements C-C, C-H, and H-H.
Note that it is desirable to keep a tail of the coordination function long
enough so that the system appears formally as a single connected cluster of
atoms. If a part is disconnected from the rest, the Perron-Frobenius theo-
rem does not hold anymore and several Sicomponents will go to zero (see
Ref. [52]).
4.24 Radial distribution function
The keyword RDF instructs plumed to use the number of distances between
atoms in a given range as a collective variable. A recent paper [53] showed
how a number of such collective variables could be used to define the instan-
taneous radial distribution function and how this description of the structure
of small clusters could be used to enhance sampling in reconnaissance meta-
dynamics simulations.
The number of distances within a given range is calculated using:
s=X
i,j Zb
aw(r−rij)dr(4.4)
where rij is the distance between atoms iand jand wis a Gaussian win-
dow function with width σ. When using multiple such CVs calculating the set
of distances separately for each bead in the RDF would be computational
expensive and counterproductive. As such all RDF collective coordinates
that involve the same atoms are calculated at the same time. In order that
multiple RDF collective coordinates can be used in a single calculation RDF
beads are labeled using the RDF LABEL keyword. Obviously if all your
RDF CVs come from the same RDF the RDF LABEL should be 1 for all
your RDF coordinates. An example input for this type of CV is as follows:
97
![](asset-63.png)
Example.
The following command instructs plumed to calculate two collective coordinates the number of distances
between 3.0 and 3.5 and the number of distances between 3.5 and 4.0. The value of σin this calculation
is 0.25.
RDF RDF LABEL 1 LIST <all> <all> RANGE 3.0 3.5 WIDTH 0.25
RDF RDF LABEL 1 LIST <all> <all> RANGE 3.5 4.0 WIDTH 0.25
all->
1 2 3 4 ...
all<-
Example.
The following command instructs plumed to calculate two collective coordinates the number of distances
between atoms in group ¡all¿ between 3.0 and 3.5 and the number of distances in group ¡all2¿ between
3.5 and 4.0. The value of σin this calculation is 0.25.
RDF RDF LABEL 1 LIST <all> <all> RANGE 3.0 3.5 WIDTH 0.25
RDF RDF LABEL 2 LIST <all2> <all2> RANGE 3.5 4.0 WIDTH 0.25
all->
1 2 3 4 ...
all<-
all2->
5 6 7 8 ...
all2-<
4.25 Angular distribution function
Rather than using the radial distribution function as a collective variable one
can use the distribution of angles between central atoms and the atoms in
the first hydration sphere [53]. Once again angular distribution functions of
this type have been combined employed successfully with the reconnaissance
metadynamics algorithm. The number of angles within a given range is
calculated using:
w=
N
X
i=1
N
X
j=1
N
X
k=1
σ(rij)σ(rik)Zb
aw(θ−θjik)dθ(4.5)
where σ(r) = 1−r−d0
r0n
1−r−d0
r0m(4.6)
98
![](asset-64.png)
where wis once again a Gaussian window function with width σ. The
two switching functions σ(rij ) and σ(rik) are used to make sure that one only
takes angles in the first hydration sphere. A detailed description of how to set
the parameters in these functions can be found in the section of this manual
on coordination numbers. Much as was described above for the RDF the
RDF LABEL keyword ensures that the code does not waste time calculating
all the angles involved in these ADF beads multiple times. If all your ADF
CVs are based on the positions of the same atoms then RDF LABEL should
be 1 for all your ADF coordinates. In other words this keyword should be
used to differentiate between the various angular distributions functions you
are calculating in input.
Example.
The following command instructs plumed to use the number of angles in the first coordination sphere that
are between 0.5 and 1.0 radians as a CV. The value of σin this calculation is 0.25.
ADF RDF LABEL 1 LIST <all> <all> <all> RANGE 0.5 1.0 WIDTH 0.25 R 0 3.0 NN 6 MM 12 D 0
1.5
all->
1 2 3 4 ...
all<-
4.26 Polynomial combination of CVs
Polynomial combinations of collective variables, given by the functional form
k
X
i=1
ci(CVi−si)ni
can be defined using the POLY directive, followed by the TERMS keyword that
specifies the number kof terms to be included in the sum. In the next k
lines, the compulsory keyword CV defines the number CViof the collective
variable in the i-th term; optionally the values of ci,siand nican be specified
preceded respectively by the keywords COEFF,SHIFT and EXP. If not speci-
fied they assume the default values of ci= 1 si= 0 ni= 1. Fractional and
negative values of the exponent are allowed, but singularities should be care-
fully avoided by imposing restraints on the regions explored by the collective
variables involved.
99
![](asset-65.png)
Warning! To combine more than 20 collective variables (k > 20), the hardset allocation for intpar
and vecpar in metadyn.h should be increased accrdingly and the code recompiled.
Example.
The following command defines a new CV as CV1−CV2
2:
POLY TERMS 2 SIGMA 1.0
CV 1
CV 2 COEFF -1 EXP 2
More complicated functions might need multiple auxiliary CVs to be de-
fined.
Example.
The following command defines a new CV as √3CV1+ CV2
POLY TERMS 2
CV 1 COEFF 3
CV 2
NOHILLS CV 3
POLY TERMS 1 SIGMA 1.0
CV 3 EXP 0.5
4.27 Function of CVs
General function of CVs with arbitrary form can be defined using the FUNCTION
directive. You should define this function AFTER you defined the variables
you are combining.
This function, still experimental, makes use of libmatheval library that
you should download from http://www.gnu.org/software/libmatheval/
and compile along with them. You may find useful infos on the syntax in
http://www.gnu.org/software/libmatheval/manual/. It is still experi-
mental so if you want to compile it you should hack your Makefile after
patching. I tried in NAMD2.7. You should change a couple of lines in the
Makefile.
Example.
in the Makefile (dots represent the arguments that you already find in the Makefile)
CXXBASEFLAGS = ... $(COPTI)/my/path/to/matheval/install dir x86 64/include
and later
namd2: -L/my/path/to/matheval/install dir x86 64/include/lib -lmatheval ...
100
![](asset-66.png)
while in SANDER (v10) I had to change
Example.
in $AMBERHOME/src/config amber.h I added the needed stuff:
AMBERBUILDFLAGS=-DAMBER -DHAVE MATHEVAL -L/my/path/to/matheval/install dir x86 64/lib
-lmatheval -I/my/path/to/matheval/install dir x86 64/include
It is crucial to put the function of CVs after all the cvs you use to define it!!!!
Example.
The following command defines a new CV as function of the two angles
PRINT W STRIDE 1
ANGLE LIST 7 9 15
ANGLE LIST 9 15 17
FUNCTION " 2*CV 1 + (CV 2+CV 1)0.2 "
Additional note is that the function is not periodic.
4.28 A note on periodic boundary conditions
PLUMED is designed so that for the majority of the CVs implemented the
periodic boundary conditions are treated in the same manner as they would
be treated in the host code. However, there are some exceptions; namely:
•Average coordinate of a group of atoms;
•RGYR;
•DISTANCE,MINDIST,COORD,HBONDS, and path collective variables S PATH
and Z PATH with contact map metrics (TYPE CMAP), if the NOPBC flag is
used;
•Path Collective Variables S PATH and Z PATH with RMSD (TYPE RMSD);
101
![](asset-67.png)
•ALPHARMSD,ANTIBETARMSD,PARABETARMSD.
In all these cases, it is essential that the atoms involved in the definition
of the CV are all part of a single, unbreakable object such as a molecule.
Furthermore, it is essential that in the coordinates passed to PLUMED the
molecules are kept intact. We are aware of at least two cases where this
condition is not satisfied; namely, when using domain decomposition or the
option for periodic molecules within the host code GROMACS4.
In these cases one must use the additional directive ALIGN ATOMS, which
takes the LIST keyword. By using this command the user can define an or-
dered group of atoms, which are to be aligned such that the distance between
adjacent atoms in the list is minimized. In the majority of cases, the atoms
in this list should be in the same order as they appear in the pdb file as
usually these files are arranged in way that reflects how close together atoms
are in the molecular topology. As for the number of atoms that must be
specified in this list it is often sufficient to just specify those atoms involved
in the CVs. However, in cases where the atoms involved are separated by
a large distances along a chain alignment of intermediate atoms will also be
required.
Example.
Input for running a metadynamics simulation using the end-to-end distance in a protein as a CV with
GROMACS4 and domain decomposition:
PRINT W STRIDE 10
HILLS HEIGHT 2.0 W STRIDE 10
DISTANCE LIST 9 238 SIGMA 0.35 NOPBC
ALIGN ATOMS LIST <C-alpha>
C-alpha->
9 16 31 55 69 90 102 114 124 138 160 174 194 208 224 238
C-alpha<-
ENDMETA
102
![](asset-68.png)
Chapter 5
Postprocessing
5.1 Estimating the free energy after a meta-
dynamics run
The program sum hills.f90 is a tool for summing up the Gaussians laid
during the metadynamics trajectory and obtaining the free energy surface.
5.1.1 Installation instructions
As sum hills.f90 is a simple fortran 90 program, the installation is straight-
forward so long as you have a fortran compiler available on your machine. As
an example, with the gnu g95 compiler one would compile sum hills.f90
using the following command:
g95 -O3 sum hills.f90 serial.f90 -o sum hills.x
For post processing of large HILLS files we recommend that, if you have a
multicore machine available, you use the parallel version, which is compiled
thus:
mpif90 -O3 sum hills.f90 parallel.f90 -o sum hills mpi.x
5.1.2 Usage
The sum hills program takes its input parameters from the command line.
If run without options, this brief summary of options is printed out.
103
![](asset-69.png)
Example.
USAGE: sum hills.x -file HILLS -out fes.dat -ndim 3 -ndw 1 2 -kt 0.6 -ngrid 100 100 100
-ndim 3 number of collective variables NCV
-ndw 1 ... CVs for the free-energy surface
-ngrid 50 ... mesh dimension. DEFAULT :: 100
-dp ... size of the mesh of the output free energy
-fix 1.1 ... optional definition of the FES domain
-stride 10 how often the FES is written
-cutoff e 1.e-6 the hills are cut off at 1.e-6
-cutoff s 6.25 the hills are cut off at 6.25 std dev from the center
-2pi x [0; 2π]periodicity on the x CV,
if -fix is not used 2pi is used
-pi x [−π;π]periodicity on the x CV,
if -fix is not used 2pi is used
-kt 0.6 kT in the energy units
-grad apply periodicity using degrees
-bias <biasfact>writing output the bias for a well tempered mtd
-file HILLLS input file
-out fes.dat output file
-hills nhills number of Gaussians that are read
-aver naver time-average the bias profile over the last naver Gaussians
The program works in the following way.
Using the -file and -out flags one tells the program the names of the
input file containing the Gaussian hills file and the name of the file in which
the free-energy will be outputted. In the absence of any instruction sum hills
assumes these files are to be called HILLS and fes.dat.
The number of CVs in the HILLS file is specified using -ndim whilst the
number of CVs the output free energy surface is to be plotted as a function
of is controlled by -ndw followed by the list of CVs in the desired order. Note
that after being read the CV are reordered in the code according to ndw. As
a direct result EVERY output uses this new order. If the number of CVs
requested using -ndw is less than the number of CVs in in HILLS file the CVs
not specified for output will be integrated out with the Boltzmann weight
KbTspecified by -kt (kT must be given in the energy units that were used
by in the code in which the simulation was performed)
The position, width and height of the Gaussians are read from the file
specified by the -file option (HILLS is the default) and the free-energy
surface is printed out on a grid in gnuplot format with a blank line added
after each block of data. Gnuplot is very handy for quick visualization of 3D
data (e.g. the FES as a function of 2 CVs).
For efficiency, the Gaussians are truncated at a certain distance from their
center before being placed on the grid. -cutoff sand -cutoff e allow one
104
![](asset-6a.png)
to tune this cutoff distance. With -cutoff s the value read specifies this
truncation distance in terms of the number of standard deviations from the
center. For consistency this should be set equal to the DP2CUTOFF used
in the metadynamics simulation (the default value for this parameter is 6.25
both in PLUMED and in sum hills). Alternatively, the user may specify this
cutoff distance as the distance at which the energy of the Gaussian hill falls to
less than some critical value specified using the -cutoff e flag. The energy
specified after this flag must be in the units used during the metadynamics
simulation. N.B. if the cutoff used in post-processesing is different to that
used during the simulation the calculated free energy differs from the bias
which was actually applied during the metadynamics simulation.
The size of the output grid can be controlled either with -ngrid followed
by the number of grid points in each CV direction or by -dp followed by
the size of the voxel in each CV direction. If neither of these options are
specified, the grid size is assumed to be 100 in each direction and the voxel
size is calculated such that all the input Gaussians fit into the grid. The
-fix option allow one to fix the boundaries of the output free energy and
after this flag. two real numbers are expected for each CV.
-stride allows one to print out the evolution of the free-energy as a
function of time, i.e. as a function of the index of the Gaussian. -stride
expects an integer which specifies how many Gaussians are added to the
calculated free energy surface between print outs. The progressive free energy
is printed in files named fes.dat.XXX where XXX is an increasing counter.
The final free-energy is printed in fes.dat. This is useful for creating movies
of the how the free-energy wells fill as a function of time.
-hills is used to integrate only a part of the Gaussian files. It expects
an integer that specifies the maximum number of Gaussians to be read from
input.
-naver is used to plot the time average of the bias profile over the last
given number of hills (see Eq. 33 in Ref. [23])
When periodic CVs like angles and dihedrals are used as CVs, periodicity
options must be specified. The flags -pi and -2pi, which are followed by
the CV index, specify that that the CV is periodic between [-pi;pi] or [0;2pi]
respectively. The -grad flag specifies that the CV values are being given
degrees rather than radians.
105
![](asset-6b.png)
5.2 Evaluating collective variables on MD tra-
jectories
The program driver can be used to evaluate the value of any of the CVs
implemented in PLUMED for all the structures in a given trajectory file.
For GROMACS users: note that driver has some limitation in the choice
of the simulation box shape. With GROMACS, it could be convenient to use
the -rerun option of mdrun together with PLUMED.
5.2.1 Installation instructions
Before compiling driver, the files contained in the common files directory
must be linked to the utilities/driver directory (i.e. this can be done
using ./getlinks.sh).
To compile using g95/gcc, type:
make arch=g95
To compile with gfortran/gcc, type:
make arch=gfortran
To compile with gfortran/gcc on a 64 bit machine, type:
make arch=gfortan 64
To compile with ifort/icc Intel compilers, type:
make arch=intel
To use other compilers and/or compiler flags you will need to modify the
Makefile.
5.2.2 Usage
This program takes its input parameters from the command line. If run
without options, this brief summary of options is printed out.
106
![](asset-6c.png)
Example.
Invoking driver without arguments prints a list of the available options:
USAGE :
driver -pdb PDB FILE -dcd DCD FILE -plumed PLUMED FILE -ncv
(-interval min1 max1 min2 max2 -out OUT FILE -nopbc -cell CELLX CELLY CELLZ)
-pdb pdb (one frame) connected to dcd file
-dcd trajectory file
-plumed PLUMED-like input file
-ncv number of collective variables
-out pdb output filename for clustering format (optional)
-interval extract frames with CV in this interval (optional)
-nopbc don’t apply pbc (optional)
-cell provide fixed box dimension in Angstrom
for orthorhombic PBC (optional)
The user must provide a structure file in PDB format (only one frame,
not a movie), within which the atoms’ masses and charges are inserted in
the occupancy field and in the B-factor field respectively. This data must be
provided as it is required for the calculation of certain collective variables,
such as the center of masses or dipoles.
The trajectory file must be a CHARMM format DCD file (also NAMD
2.1 and later). To convert other trajectory files into this format, the user can
download the utility CatDCD from:
http://www.ks.uiuc.edu/Development/MDTools/catdcd/.
Within the input file driver the user can specify a printing stride (in
number of DCD frames) using the keyword W STRIDE and the list CVs he/she
wishes to calculate. This file has the same syntax as the PLUMED input file.
The CVs value will be printed on the COLVAR file. For a complete list of the
CVs driver can calculate, please see section 4.
Example.
If you wish to evaluate the distance between atom 13 and 17 for every frame in your trajectory file, the
input file for driver would be as follows:
PRINT W STRIDE 1
DISTANCE LIST 13 17
ENDMETA
By default, driver uses orthorhombic periodic boundary conditions and
looks for cell information in the DCD file. If these are not present, you must
107
![](asset-6d.png)
either provide the fixed dimensions of the box in Angstrom (only orthorhom-
bic PBCs are allowed) using the keyword -cell CELLX CELLY CELLZ or
switch off the pbc using the -nopbc flag.
Driver can also be used to extract frames in a specific window of the CVs
space and write these extracted frames to a PDB file. To use this functional-
ity use the option -out output.pdb and specify the interval with -interval
CVmin CVmax.
Example.
To extract those frames in which the distance between two specified atoms is between 10.0 and 12.0 ˚
A
while the angle defined by three specified atoms is between 2.0 and 2.3 rad, the user should prepare the
following input file (named plumed.dat):
PRINT W STRIDE 1
DISTANCE LIST 13 17
ANGLE LIST 19 20 22
ENDMETA
and then invoke driver using the following command:
./driver -pdb dialanine.pdb -dcd dialanine.dcd -plumed plumed.dat -ncv 2 -out
window.pdb -interval 10.0 12.0 2.0 3.0
The output file window.pdb is written in a format appropriate for use with the GROMACS tool g cluster,
which can be used to perform a cluster analysis on your set of frames.
5.3 Processing COLVAR files
Since PLUMED 1.2, a more flexible format has been adopted for COLVAR files.
These files can be parsed with the simple plumedat.sh tool. If run it without
options, this brief summary of options is printed out.
108
![](asset-6e.png)
Example.
Invoking plumedat.sh without arguments prints a list of the available options:
syntax:
plumedat.sh f1 f2 ... < file
or
plumedat.sh -l < file
file is the name of the COLVAR file
f1, f2, ... are the names of the required fields
if a required field is not available in the COLVAR file, "NA" is written in the output
with -l, the available choices are listed
example:
plumedat.sh time temp < COLVAR
prints a two-column file, with the time in the first column and the temperature in the
second column
5.4 PLUMED as a standalone program
PLUMED can be run as a standalone program so that it can be easily integrated
in a script. This is particularly useful whenever the time between one PLUMED
call and the other is large (e.g. in ab initio programs) and one aims at mini-
mizing the time needed for implementation. plumed standalone consists in
a simple program, very much like the driver tool, that reads the configura-
tion and prints out the forces to be added and the other various output files
typical of PLUMED.
5.4.1 Installation instructions
Before compiling plumed standalone, the files contained in the common files
directory must be linked to the utilities/standalone directory (i.e. this
can be done using ./getlinks.sh).
To compile using g95/gcc, type:
make arch=g95
To compile with gfortran/gcc, type:
make arch=gfortran
To compile with gfortran/gcc on a 64 bit machine, type:
make arch=gfortan 64
To compile with ifort/icc Intel compilers, type:
109
![](asset-6f.png)
make arch=intel
To use other compilers and/or compiler flags you will need to modify the
Makefile. In this way you may obtain an executable which is plumed standalone.
5.4.2 Usage
PLUMED standalone expects a standard PLUMED input, a configuration file for
your system (much in the format of xyz) and gives a screen output. The
configuration file has the following format:
Example.
Example of plumed standalone input configuration
TIME 0.100000 100
AMPLI 1.000000
BOLTZ 0.001987
BOX 1000.000000 1000.000000 1000.000000
-13.523670417 0.140088464 4.263822219 131.207999 0.000000
-9.821878867 -0.695171589 5.042585958 101.119998 0.000000
-7.193416272 -2.392065561 2.830069705 163.190996 0.000000
-3.844793108 -3.737129154 4.056782255 129.197997 0.000000
.
.
.
The configuration file must have the keyword TIME followed by the step
length (in the units of the program) and AMPLI which is the conversion factor
between ˚
A and the actual length unit in the configuration file. This is needed
when a RMSD calculation with respect to a pdb file in ˚
A must be performed.
In this case, if the configuration is in Bohr, the AMPLI factor must be set
equal to 1.889725989. BOLTZ is the Boltzmann factor in the chosen units and
BOX followed by three numbers specifies the dimensions of the orthorombic
simulation box.
The following lines specify the configuration. The first three columns are
the x, y and z coordinates, the fourth is the mass in units of the program
(in the case above a coarse grained program takes the mass of all the single
residues) and in the last column you may put the charge (in the code above
it was not needed). PLUMED invocation may be done with command line:
110
![](asset-70.png)
Example.
Example of invocation of PLUMED standalone
./plumed standalone -coord x.xyz -plumed plumed input.cfg
plumed standalone returns back a file named plumed forces.dat which
contains the additional energy and forces from the bias potential calculated
by the PLUMED module. Eventually, these must be summed to the ones of the
original program.
Example.
Example of plumed standalone output file. In the first line is the additional bias potential calculated by
PLUMED, followed by the x, y and z components of the force for each atom.
2.35680
3.335998704981455 -3.684076849212145 -16.098665997131253
-0.9064447402311846 2.913567594563722 -1.0502785066801152
-0.7948355287665761 0.9861425018822194 0.6558434539267759
-1.9437110159112139 -0.6087819098852943 2.4119663558915296
.
.
.
5.5 Reweighting well-tempered metadynam-
ics calculations
From a converged metadynamics run we can calculate directly the canonical
probability distribution of the collective variables at a given temperature.
On the contrary, the statistics of other degrees of freedom is somehow dis-
torted by the application, during the simulation, of a time-dependent exter-
nal potential on the CVs. Different possible techniques have been proposed
to reconstruct the probability distribution of variables other than the CVs
[54, 29, 21].
In well-tempered metadynamics, the reconstruction of the distribution of
variables different from the CVs is particularly simple since for long times
the amount of bias added decreases to zero and the system becomes closer
and closer to equilibrium. The algorithm described in Ref. [21] consists of
three different steps:
111
1. Accumulate the histogram of the CVs plus the other variables of inter-
est between two updates of the bias potential;
2. When a new Gaussian is added, evolve the histogram following:
P(R, t + ∆t) = e−β(˙
V(S(R),t)−h ˙
V(S,t)i)∆tP(R, t),(5.1)
where P(R, t) is the biased probability distribution, ˙
V(S(R), t) the
time derivative of the bias potential and the average in the exponent is
calculated in the biased ensemble;
3. At the end of the simulation, the unbiased distribution PB(R) can be
recovered from the histogram collected by using a standard umbrella
sampling reweighting:
PB(R)∝eβV (S(R),t)·P(R, t).(5.2)
5.5.1 Installation instructions
As reweight.f90 is a simple fortran 90 program, the installation is straight-
forward so long as you have a fortran compiler available on your machine.
As an example, with the gnu g95 compiler one would compile reweight.f90
using the following command:
g95 -O3 reweight.f90 -o reweight
112
![](asset-72.png)
5.5.2 Usage
Example.
We performed a metadynamics run with 2 CVs and we are interested in reconstructing the distribution of
a third variable.
reweight -colvar COLVAR -hills HILLS -ncv 2 -nvar 3 -stride 1 -fes 3 -temp 300
-welltemp
-hills HILLS filename
-colvar COLVAR filename
-out FES filename
-ncv number of variables in HILLS
-nvar number of variables in COLVAR
-stride ratio between COLVAR and HILLS stride
-fes ID of the variables for FES in output
-temp temperature in Kelvin
-ngrid histogram grid dimension
-nreject discard initial steps
-timeout stride for FES printout
-pi ID of the variables with [−π;π]periodicity
-welltemp control for well-tempered metadynamics
-kjoule energy in kjoule/mol
The code needs two files with the same format of the PLUMED HILLS and
COLVAR files. In the latter, the metadynamics CVs should appear in the first
dcolumn followed by the variables whose distribution one wants to reweight.
The ratio between the stride in COLVAR and HILLS must be constant and
greater than 1. The more data you have for the histogram, the better.
Some important things to keep in mind:
•For the choice of the bin size, please follow the suggestions described
in section 3.4.5;
•Eq. 5.1 is exact. However, at the beginning of the simulation the
average of ˙
V(S(R), t) can be calculated only approximately. Luckily,
a possible initial error is recovered for long times. Alternatively, one
could discard the first part of the trajectory using the -nreject option.
Please always check that your results are robust to a discard of initial
parts of the trajectory;
•As for the calculation of the FES with sum hills, remember to control
the convergence by plotting the reconstructed distribution at different
times by using -timeout;
113
![](asset-73.png)
5.6 Bias-exchange simulations via the linux
shell
Bias-exchange simulations [18] can be performed using every MD engine,
employing the tool in the directory utilities/bias-exchange. Each replica
(walker) runs independently in a different directory for a duration τexch equal
to the time between two exchanges of the bias. When all runs are finished,
a script called bias-exchange.sh takes care of attempting exchanges of the
bias and re-launching the simulation for each replica.
This procedure via the linux shell can be inefficient in terms of computer
time (due to the need to stop and restart the simulations to perform ex-
changes) if τexch is chosen very short, e.g. <100 timesteps. However in the
literature times larger than 10 ps are typically employed for classical simu-
lations of biomolecules, while for ab-initio simulations this should not be an
issue already for τexch ∼0.1 ps. Note that for GROMACS PLUMED provides
also bias-exchange within a single parallel run, which is computationally more
efficient (see Section 3.6.2).
A simulation proceeds as follows (see also the directory example). First,
the Fortran code exchange-tool.f90 is compiled using the command make
(modify the Makefile if necessary). The script bias-exchange.sh and the
program exchange-tool.x must be copied in a chosen directory BASE DIR,
and the following variables inside the script bias-exchange.sh must be mod-
ified:
•BASE DIR
•NWALKER is the number of replicas
•KBT is the Boltzmann factor kBTin units of the MD engine
•NSIMULATIONS is the maximum number of runs between exchanges for
each walker
Then, inside BASE DIR the user must create NWALKER directories called walker1,
walker2, etc., and in each one the following files must be present:
•an input for restarting an MD simulation of length τexch
•aPLUMED input file called plumed.dat (see example below)
114
![](asset-74.png)
•a script run-walker.sh (see example below)
Finally, the bias-exchange simulation is started by launching the MD runs in
each walker1,walker2, etc. directories using the command ./run-walker.sh
&(the latter script must be executable: it can be made so e.g. using com-
mand chmod a+x run-walker.sh). This script must launch the MD run in
foreground (no &character at the end of the line) and it must end with the
following lines:
touch READY
../bias-exchange.sh &
After a time τexch the runs finish and control passes to the bias-exchange.sh
script (in background), which attempts to exchange the bias (i.e. files HILLS
and plumed.dat, not atomic coordinates) between pairs of randomly chosen
replicas. Detailed output is printed in the file bias-exchange.log.
It is required to employ the keyword HILLS LABEL in each plumed.dat
input file, with a different label for each walker: in this way PLUMED includes
the information (necessary for the bias-exchange tool) about the active CVs
in the COLVAR and HILLS files.
115
![](asset-75.png)
Example.
Example of plumed.dat input file in directory walker1. Note the keyword HILLS LABEL and that only CV
1 is biased.
HILLS RESTART HEIGHT 0.001 W STRIDE 100
PRINT W STRIDE 10
HILLS LABEL A
COORD LIST 1 <g234> NN 6 MM 12 R 0 5.0 SIGMA 0.1
g234->
2 3 4
g234<-
COORD LIST 2 <g134> NN 6 MM 12 R 0 5.0 SIGMA 0.1
g134->
1 3 4
g134<-
COORD LIST 3 <g124> NN 6 MM 12 R 0 5.0 SIGMA 0.1
g124->
1 2 4
g124<-
COORD LIST 4 <g123> NN 6 MM 12 R 0 5.0 SIGMA 0.1
g123->
1 2 3
g123<-
NOHILLS CV 2
NOHILLS CV 3
NOHILLS CV 4
ENDMETA
The other walkers will have a similar plumed.dat input file, but with
different label (e.g. HILLS LABEL B for walker2, etc.) and different active
CV (e.g. the second one in walker2, etc.).
Example.
Example of run-walker.sh script file: the script must be executable.
#!/bin/bash
# note that CPMD is launched in foreground:
cpmd.x input . -plumed >> output
# this creates and empty file called READY,
# telling the bias-exchange tool that the MD run has finished:
touch READY
# note that bias-exchange.sh is launched in background:
../bias-exchange.sh &
116
At the end of the bias-exchange simulation, the multidimensional free-
energy landscape as a function of several CVs can be reconstructed accord-
ing to the weighted-histogram algorithm in Ref. [29], e.g. employing the
METAGUI program [30] downloadable from
http://www.plumed-code.org/contributions
The bias-exchange simulation can be continued, after NSIMULATIONS steps
are reached and all replicas have finished their run, in the following way:
•enlarge NSIMULATIONS in the script bias-exchange.sh
•in each walker-directory, delete the file READY
•in each walker-directory, restart the run using ./run-walker.sh &
117
Bibliography
[1] M. Bonomi, D. Branduardi, G. Bussi, C. Camilloni, D. Provasi, P. Rai-
teri, D. Donadio, F. Marinelli, F. Pietrucci, R. A. Broglia, M. Parrinello,
PLUMED: a portable plugin for free energy calculations with molecular
dynamics, Comp. Phys. Comm. 180 (2009) 1961.
[2] B. Hess, C. Kutzner, D. van der Spoel, E. Lindahl, GROMACS 4: Al-
gorithms for highly efficient, load-balanced, and scalable molecular sim-
ulation, J. Chem. Theory Comput. 4 (3) (2008) 435–447.
[3] J. C. Phillips, R. Braun, W. Wang, J. Gumbart, E. Tajkhorshid, E. Villa,
C. Chipot, R. D. Skeel, L. Kal´e, K. Schulten, Scalable molecular dynam-
ics with NAMD, J. Comput. Chem. 26 (16) (2005) 1781–802.
[4] W. Smith, C. Yong, P. Rodger, Mol. Simulat. 28 (2002) 385–471.
[5] S. J. Plimpton, Fast parallel algorithms for short-range molecular dy-
namics, J. Comp. Phys. 117 (1995) 1–19.
[6] D. A. Case, T. A. Darden, T. E. C. III, C. L. Simmerling, J. Wang,
R. E. Duke, R. Luo, K. M. Merz, D. A. Pearlman, M. Crowley, R. C.
Walker, W. Zhang, B. Wang, S. Hayik, A. Roitberg, G. Seabra, K. F.
Wong, F. Paesani, X. Wu, S. Brozell, V. Tsui, H. Gohlke, L. Yang,
C. Tan, J. Mongan, V. Hornak, G. Cui, P. Beroza, D. H. Mathews,
C. Schafmeister, W. S. Ross, P. Kollman, AMBER 9, University of Cal-
ifornia, San Francisco.
[7] M. Harvey, G. Giupponi, G. D. Fabritiis, ACEMD: Accelerated molecu-
lar dynamics simulations in the microseconds timescale, J. Chem. The-
ory and Comput. 5 (2009) 1632.
118
[8] P. Giannozzi, S. Baroni, N. Bonini, M. Calandra, R. Car, C. Cavaz-
zoni, D. Ceresoli, G. L. Chiarotti, M. Cococcioni, I. Dabo, A. D. Corso,
S. de Gironcoli, S. Fabris, G. Fratesi, R. Gebauer, U. Gerstmann,
C. Gougoussis, A. Kokalj, M. Lazzeri, L. Martin-Samos, N. Marzari,
F. Mauri, R. Mazzarello, S. Paolini, A. Pasquarello, L. Paulatto,
C. Sbraccia, S. Scandolo, G. Sclauzero, A. P. Seitsonen, A. Smogunov,
P. Umari, R. M. Wentzcovitch, QUANTUM ESPRESSO: a modular
and open-source software project for quantum simulations of materials,
J. Phys.: Condens. Matter 21 (2009) 395502.
[9] A. Laio, M. Parrinello, Escaping free energy minima, Proc. Natl. Acad.
Sci. USA 99 (2002) 12562–12566.
[10] G. Torrie, J. Valleau, Nonphysical sampling distributions in monte carlo
free energy estimation: Umbrella sampling, J. Comput. Phys. 23 (1977)
187–199.
[11] S. Kumar, J. M. Rosenberg, D. Bouzida, R. H. Swendsen, P. A. Kollman,
Multidimensional free-energy calculations using the weighted histogram
analysis method, J. Comput. Chem. 16 (1995) 1339–1350.
[12] B. Roux, The calculation of the potential of mean force using computer-
simulations, Comput. Phys. Comm. 91 (1995) 275–282.
[13] C. Jarzynski, Nonequilibrium equality for free energy differences, Phys.
Rev. Lett. 78 (1997) 2690–2693.
[14] G. Crooks, Nonequilibrium measurements of free energy differences for
microscopically reversible markovian systems, J. Stat. Phys. 90 (5-6)
(1998) 1481–1487.
[15] A. Barducci, G. Bussi, M. Parrinello, Well-tempered metadynamics: A
smoothly converging and tunable free-energy method, Phys. Rev. Lett.
100 (2) (2008) 020603.
[16] P. Raiteri, A. Laio, F. Gervasio, C. Micheletti, M. Parrinello, Efficient
reconstruction of complex free energy landscapes by multiple walkers
metadynamics, J. Phys. Chem. B 110 (2006) 3533–3539.
119
[17] G. Bussi, F. L. Gervasio, A. Laio, M. Parrinello, Free-energy landscape
for beta hairpin folding from combined parallel tempering and metady-
namics, J. Am. Chem. Soc. 128 (41) (2006) 13435–41.
[18] S. Piana, A. Laio, A bias-exchange approach to protein folding, J. Phys.
Chem. B 111 (17) (2007) 4553–9.
[19] G. A. Tribello, M. Ceriotti, M. Parrinello, A self-learning algorithm for
biased molecular dynamics, Proc. Natl. Acad. Sci. USA 107 (41) (2010)
17509–17514.
[20] M. Marchi, P. Ballone, Adiabatic bias molecular dynamics: A method
to navigate the conformational space of complex molecular systems, J.
Chem. Phys. 110 (8) (1999) 3697–3702.
[21] M. Bonomi, A. Barducci, M. Parrinello, Reconstructing the equilibrium
Boltzmann distribution from well-tempered metadynamics, J. Comput.
Chem. 30 (11) (2009) 1615–1621.
[22] J. VandeVondele, M. Krack, F. Mohamed, M. Parrinello, Quickstep:
Fast and accurate density functional calculations using a mixed gaussian
and plane waves . . . , Comp. Phys. Comm. 167 (2005) 103–128.
[23] A. Laio, F. L. Gervasio, Metadynamics: a method to simulate rare events
and reconstruct the free energy in biophysics, chemistry and material
science, Rep. Prog. Phys. 71 (2008) 126601.
[24] A. Barducci, M. Bonomi, M. Parrinello, Metadynamics, WIREs Com-
put. Mol. Sci. 1 (2011) 826.
[25] V. Babin, C. Roland, C. Sagui, Adaptively biased molecular dynamics
for free energy calculations, J. Chem. Phys. 128 (2008) 134101.
[26] F. Baftizadeh, P. Cossio, F. Pietrucci, A. Laio, Protein folding and
ligand-enzyme binding from bias-exchange metadynamics simulations,
Current Physical Chemistry (in press).
[27] Y. Crespo, F. Marinelli, F. Pietrucci, A. Laio, Metadynamics con-
vergence law in a multidimensional system, Phys. Rev. E 81 (2010)
055701(R).
120
[28] C. Camilloni, D. Provasi, G. Tiana, R. A. Broglia, Exploring the protein
G helix free-energy surface by solute tempering metadynamics, Proteins
71 (2008) 1647.
[29] F. Marinelli, F. Pietrucci, A. Laio, S. Piana, A kinetic model of trp-
cage folding from multiple biased molecular dynamics simulations, PLoS
Comput. Biol. 5(8) (2009) e100045.
[30] X. Biarnes, F. Pietrucci, F. Marinelli, A. Laio, Metagui. a vmd inter-
face for analyzing metadynamics and molecular dynamics simulations,
Comp. Phys. Comm. 183 (2011) 203.
[31] A. Grossfield, Wham.http://membrane.urmc.rochester.edu/
Software/WHAM/WHAM.html.
[32] D. Provasi, M. Filizola, Putative active states of a prototypic g-protein-
coupled receptor from biased molecular dynamics, Biophys. J. 98 (2010)
2347–2355.
[33] C. Camilloni, R. A. Broglia, G. Tiana, Hierarchy of folding and unfolding
events of protein g, ci2, and acbp from explicit-solvent simulations, J.
Chem. Phys. 134 (2011) 045105.
[34] J. B. Abrams, M. E. Tuckerman, Efficient and direct generation of mul-
tidimensional free energy surfaces via adiabatic dynamics without coor-
dinate transformations, J. Phys. Chem. B 112 (2008) 15742–15757.
[35] L. Rosso, M. E. Tuckerman, An adiabatic molecular dynamics method
for the calculation of free energy profiles, Mol. Sim. 28 (2002) 91–112.
[36] L. Rosso, P. Minary, Z. Zhu, M. E. Tuckerman, On the use of adiabatic
molecular dynamics to calculate free energy profiles, J. Chem. Phys. 116
(2002) 4389–4402.
[37] L. Maragliano, E. Vanden-Eijnden, A temperature accelerated method
for sampling free energy and determining reaction pathways in rare
events simulations, Chem. Phys. Lett. 426 (2006) 168–175.
[38] Y. Liu, M. E. Tuckerman, Generalized gaussian moment thermostatting:
A new continuous dynamical approach to the canonical ensemble, J.
Chem. Phys. 112 (2000) 1685.
121
[39] J. Vymetal, J. Vondrasek, Gyration- and inertia-tensor-based collective
coordinates for metadynamics. application on the conformational be-
havior of polyalanine peptides and trp-cage folding, J. Phys. Chem. A
115 (2011) 11455–11465.
[40] D. N. Theodorou, U. W. Suter, Shape of unperturbed linear polymers:
polypropylene, Macromolecules 18 (6) (1985) 1206–1214.
[41] F. Pietrucci, A. Laio, A collective variable for the efficient exploration
of protein beta-structures with metadynamics: application to sh3 and
gb1, J. Chem. Theory Comput. 5 (9) (2009) 2197–2201.
[42] M. Sega, E. Autieri, F. Pederiva, On the calculation of puckering free
energy surfaces, J. Chem. Phys. 130 (22) (2009) 225102.
[43] D. Branduardi, F. L. Gervasio, M. Parrinello, From A to B in free energy
space, J. Chem. Phys. 126 (5) (2007) 054103.
[44] M. Bonomi, D. Branduardi, F. Gervasio, M. Parrinello, The unfolded
ensemble and folding mechanism of the C-terminal GB1 βhairpin, J.
Am. Chem. Soc. 130 (42) (2008) 13938–13944.
[45] S. K. Kearsley, On the orthogonal transformation used for structural
comparison, Acta Cryst. A 45 (1989) 208–210.
[46] H. Li, D. Min, Y. Liu, W. Yang, Essential energy space random walk via
energy space metadynamics method to accelerate molecular dynamics
simulations, J. Chem. Phys. 127 (9) (2007) 094101.
[47] C. Michel, A. Laio, A. Milet, Tracing the entropy along a reactive path-
way: The energy as a generalized reaction coordinate, J. Chem. Theory
Comput. 5 (9) (2009) 2193–2196.
[48] D. Donadio, P. Raiteri, M. Parrinello, Topological defects and bulk melt-
ing of hexagonal ice, J. Phys. Chem. B 109 (12) (2005) 5421–5424.
[49] M. Bonomi, M. Parrinello, Enhanced sampling in the well-tempered
ensemble, Phys. Rev. Lett. 104 (2010) 190601.
[50] A. Amadei, A. B. M. Linssen, H. J. C. Berendsen, Essential dynamics
of proteins., Proteins Struct. Funct. Genet. 17 (1993) 412–425.
122
[51] L. Sutto, M. D. Abramo, F. L. Gervasio, Comparing the efficiency of bi-
ased and unbiased molecular dynamics in reconstructing the free energy
landscape of met-enkephalin, J. Chem. Theory Comput. 6 (12) (2010)
3640–3646.
[52] F. Pietrucci, W. Andreoni, Graph theory meets ab initio molecular dy-
namics: atomic structures and transformations at the nanoscale, Phys.
Rev. Lett. 107 (2011) 085504.
[53] G. A. Tribello, J. Cuny, H. Eshet, M. Parrinello, Exploring the free
energy surfaces of clusters using reconnaissance metadynamics, J. Chem.
Phys 135 (11) (2011) 114109.
[54] G. Tiana, Estimation of microscopic averages from metadynamics, Eur.
Phys. J. B 63 (2) (2008) 235–238.
123
Index
Absolute position, see Collective vari-
ables, Absolute position
ADF, see Collective variables, ADF
Adiabatic bias molecular dynamics,
48
Alpha-beta similarity, see Collective
variables, Alpha-beta similar-
ity
Alpharmsd, see Collective variables,
Alpharmsd
Angle, see Collective variables, Angle
Antibetarmsd, see Collective variables,
Antibetarmsd
Atom lists, 64
Bias exchange simulations, 42
Bias-exchange simulations via the linux
shell, 114
Collective variables
ADF, 98
Absolute position, 66
Alpha-beta similarity, 77
Alpharmsd, 78
Angle, 69
Antibetarmsd, 79
Contact Matrix distance, 91
Coordination number, 70
DMSD, 91
Difference of distances, 67
Dihedral correlation, 77
Dipole, 76
Distance from an axis, 68
Distance, 67
Electrostatic potential, 81
FUNCTION, 100
Gyration tensor based CVs, 75
Hydrogen bonds, 71
Interfacial water, 73
MSD, 91
Minimal distance, 68
POLY, 99
Parabetarmsd, 80
Path variables, 83
Projection on an axis, 68
Puckering coordinates, 82
RDF, 97
Radius of Gyration, 74
SPRINT, 96
Targeted, 91
Torsion, 70
Contact Matrix distance, see Collec-
tive variables, Contact Matrix
distance
Coordination number, see Collective
variables, Coordination num-
ber
Difference of distances, see Collective
variables, Difference of distances
Dihedral correlation, see Collective vari-
ables, Dihedral correlation
124
![](asset-7e.png)
Dipole, see Collective variables, Dipole
Distance, see Collective variables, Dis-
tance
Distance from an axis, see Collective
variables, Distance from an axis
DMSD, see Collective variables, DMSD
Electrostatic potential, see Collective
variables, Electrostatic poten-
tial
FUNCTION, see Collective variables,
FUNCTION
Grid for metadynamics, 30
Gyration tensor based CVs, see Col-
lective variables, Gyration ten-
sor based CVs
Hydrogen bonds, see Collective vari-
ables, Hydrogen bonds
Interfacial water, see Collective vari-
ables, Interfacial water
Keywords
R 0 , 97
ABMD, 48
ACYLINDRICITY, 76
ALIGN ATOMS, 95, 102
ALPHABETA, 36, 77
ALPHARMSD, 78, 102
ANGLE, 69
ANTIBETARMSD, 79, 102
ASPHERICITY, 76
BASINS, 54, 56
BASIN TOL, 56, 57
BETA, 69
BIASXMD, 42
CLUSTER, 54, 56
CMAP, 92
COEFF, 99
COLVAR, 53, 54, 62, 63
COMMITMENT, 53
COORD, 36, 96, 101
COS, 69, 70
CV LIST, 59
CV, 61, 99
DAFED CONTROL, 62
DAFED STATE, 62
DAFED, 61
DIFF, 94
DIHCOR, 77
DIPOLE, 76
DIR, 67
DISTANCE, 67, 101
DMSD, 84, 92
DRMS, 84
D 0, 96
EIGENVEC, 94
ELSTPOT, 81
ENDMETA, 26
ENERGY, 9, 93
EXPAND PARAM, 57
EXP, 99
EXTERNAL, 50
E sj, 63
FILENAME, 32, 33
FRAME, 94
FUNCTION, 100
GRID, 31, 32
GTPC 1, 75
GTPC 2, 75
GTPC 3, 75
HBONDS, 71, 101
HEIGHT, 58
HELIX, 93
HILLS LABEL, 43, 115
125
![](asset-7f.png)
