User Manual:
Open the PDF directly: View PDF
.
Page Count: 52
- Introduction
- Installing and Running JFlex
- A simple Example: How to work with JFlex
- Lexical Specifications
- Encodings, Platforms, and Unicode
- Conformance with Unicode Regular Expressions UTS#18
- A few words on performance
- Porting Issues
- Working together
- Bugs and Deficiencies
- Copying and License
Contents
1 Introduction 4
1.1 Design goals ..................................... 4
1.2 About this manual ................................. 4
2 Installing and Running JFlex 5
2.1 Installing JFlex ................................... 5
2.1.1 Windows .................................. 5
2.1.2 Mac/Unix with tar ............................. 5
2.2 Running JFlex ................................... 6
2.3 Maven plugin .................................... 7
2.3.1 Usage .................................... 7
2.3.2 Versions ................................... 10
2.4 JFlex Ant Task ................................... 10
2.4.1 Parameters ................................. 10
2.4.2 Example ................................... 11
3 A simple Example: How to work with JFlex 12
3.1 Code to include ................................... 14
3.2 Options and Macros ................................ 14
3.3 Rules and Actions ................................. 16
3.4 How to get it building ............................... 17
4 Lexical Specifications 17
4.1 User code ...................................... 18
4.2 Options and declarations .............................. 18
4.2.1 Class options and user class code ..................... 18
4.2.2 Scanning method .............................. 20
4.2.3 The end of file ............................... 21
4.2.4 Standalone scanners ............................ 22
4.2.5 CUP compatibility ............................. 22
4.2.6 BYacc/J compatibility ........................... 23
4.2.7 Input Character sets ............................ 24
4.2.8 Line, character and column counting ................... 24
4.2.9 Obsolete JLex options ........................... 25
4.2.10 State declarations ............................. 25
4.2.11 Macro definitions .............................. 25
4.3 Lexical rules ..................................... 26
4.3.1 Syntax .................................... 26
4.3.2 Semantics .................................. 29
4.3.3 How the input is matched ......................... 32
4.3.4 The generated class ............................ 33
4.3.5 Scanner methods and fields accessible in actions (API) ......... 34
5 Encodings, Platforms, and Unicode 36
5.1 The Problem .................................... 36
2
5.2 Scanning text files ................................. 37
5.3 Scanning binaries .................................. 38
6 Conformance with Unicode Regular Expressions UTS#18 38
6.1 RL1.1 Hex Notation ................................ 38
6.2 RL1.2 Properties .................................. 38
6.3 RL1.2a Compatibility Properties ......................... 39
6.4 RL1.3 Subtraction and Intersection ........................ 39
6.5 RL1.4 Simple Word Boundaries .......................... 39
6.6 RL1.5 Simple Loose Matches ........................... 39
6.7 RL1.6 Line Boundaries ............................... 40
6.8 RL1.7 Supplementary Code Points ........................ 40
7 A few words on performance 40
8 Porting Issues 42
8.1 Porting from JLex ................................. 42
8.2 Porting from lex/flex ................................ 42
8.2.1 Basic structure ............................... 43
8.2.2 Macros and Regular Expression Syntax ................. 43
8.2.3 Character Classes ............................. 43
8.2.4 Lexical Rules ................................ 44
9 Working together 44
9.1 JFlex and CUP ................................... 44
9.1.1 CUP2 .................................... 44
9.1.2 CUP version 0.10j and above ....................... 44
9.1.3 Custom symbol interface .......................... 44
9.1.4 Using existing JFlex/CUP specifications with CUP 0.10j and above . 45
9.2 JFlex and BYacc/J ................................. 46
9.3 JFlex and Jay .................................... 48
10 Bugs and Deficiencies 51
10.1 Deficiencies ..................................... 51
10.2 Bugs ......................................... 51
11 Copying and License 51
3
1 Introduction
JFlex is a lexical analyser generator for Java
1
written in Java. It is also a rewrite of the tool
JLex [
3
] which was developed by Elliot Berk at Princeton University. As Vern Paxson states
for his C/C++ tool flex [8]: they do not share any code though.
A lexical analyser generator takes as input a specification with a set of regular expressions
and corresponding actions. It generates a program (a lexer) that reads input, matches the
input against the regular expressions in the spec file, and runs the corresponding action if a
regular expression matched. Lexers usually are the first front-end step in compilers, matching
keywords, comments, operators, etc, and generating an input token stream for parsers. They
can also be used for many other purposes.
1.1 Design goals
The main design goals of JFlex are:
•Unicode support
•Fast generated scanners
•Fast scanner generation
•Convenient specification syntax
•Platform independence
•JLex compatibility
1.2 About this manual
This manual gives a brief but complete description of the tool JFlex. It assumes that you are
familiar with the topic of lexical analysis in parsing. The references [
1
] and [
2
] provide a good
introduction.
The next section of this manual describes installation procedures (Section 2) for JFlex. Working
with JFlex - an example (Section 3) runs through an example specification and explains how
it works. The section on Lexical specifications (Section 4) presents all JFlex options and
the complete specification syntax; Encodings, Platforms, and Unicode (Section 5) provides
information about Unicode and scanning text vs. binary files. A few words on performance
(Section 7) gives tips on how to write fast scanners. The section on porting scanners (Section 8)
shows how to port scanners from JLex, and from the
lex
and
flex
tools for C. Finally, working
together (Section 9) discusses interfacing JFlex scanners with the LALR parser generators
CUP, CUP2, BYacc/J, Jay.
1
Java is a trademark of Sun Microsystems, Inc., and refers to Sun’s Java programming language. JFlex is not
sponsored by or affiliated with Sun Microsystems, Inc.
4
2 Installing and Running JFlex
2.1 Installing JFlex
2.1.1 Windows
To install JFlex on Windows, follow these three steps:
1.
Unzip the file you downloaded into the directory you want JFlex in. If you unzipped it
to say C:\, the following directory structure should be generated:
C:\jflex-1.7.0\
+--bin\ (start scripts)
+--doc\ (FAQ and manual)
+--examples\
+--byaccj\ (calculator example for BYacc/J)
+--cup-maven\ (calculator example for cup and maven)
+--interpreter\ (interpreter example for cup)
+--java\ (Java lexer specification)
+--simple-maven\ (example scanner built with maven)
+--standalone-maven\ (a simple standalone scanner,
built with maven)
+--zero-reader\ (Readers that return 0 characters)
+--lib\ (precompiled classes)
+--src\
+--main\
+--config\ (PMD source analyzer configuration)
+--cup\ (JFlex parser spec)
+--java\
+--jflex\ (source code of JFlex)
+--anttask\ (source code of JFlex Ant Task)
+--gui\ (source code of JFlex UI classes)
+--unicode\ (source code for Unicode properties)
+--jflex\ (JFlex scanner spec)
+--resources\ (messages and default skeleton file)
+--test\ (unit tests)
2.
Edit the file
bin\jflex.bat
(in the example it’s
C:\jflex-1.7.0\bin\jflex.bat
) such
that
•JAVA_HOME
contains the directory where your Java JDK is installed (for instance
C:\java) and
•JFLEX_HOME the directory that contains JFlex (in the example: C:\jflex-1.7.0)
3.
Include the
bin\
directory of JFlex in your path. (the one that contains the start script,
in the example: C:\jflex-1.7.0\bin).
2.1.2 Mac/Unix with tar
To install JFlex on a Mac or Unix system, follow these two steps:
5
•
Decompress the archive into a directory of your choice with GNU tar, for instance to
/usr/share:
tar -C /usr/share -xvzf jflex-1.7.0.tar.gz
(The example is for site wide installation. You need to be root for that. User installation
works exactly the same way — just choose a directory where you have write permission)
•Make a symbolic link from somewhere in your binary path to bin/jflex, for instance:
ln -s /usr/share/jflex-1.7.0/bin/jflex /usr/bin/jflex
If the Java interpreter is not in your binary path, you need to supply its location in the
script bin/jflex.
You can verify the integrity of the downloaded file with the SHA1 checksum available on the
JFlex download page. If you put the checksum file in the same directory as the archive, and
run:
shasum --check jflex-1.7.0.tar.gz.sha1
it should tell you
jflex-1.7.0.tar.gz: OK
2.2 Running JFlex
You run JFlex with:
jflex <options> <inputfiles>
It is also possible to skip the start script in
bin/
and include the file
lib/jflex-1.7.0.jar
in
your CLASSPATH environment variable instead.
Then you run JFlex with:
java jflex.Main <options> <inputfiles>
or with:
java -jar jflex-1.7.0.jar <options> <inputfiles>
The input files and options are in both cases optional. If you don’t provide a file name on the
command line, JFlex will pop up a window to ask you for one.
JFlex knows about the following options:
-d <directory>
writes the generated file to the directory <directory>
--encoding <name>
uses the character encoding
<name>
(e.g.
utf-8
) to read lexer specifications and write java files.
--skel <file>
uses external skeleton
<file>
. This is mainly for JFlex maintenance and special low level
customisations. Use only when you know what you are doing! JFlex comes with a skeleton
file in the
src
directory that reflects exactly the internal, pre-compiled skeleton and can be
used with the -skel option.
6
--nomin
skip the DFA minimisation step during scanner generation.
--jlex
tries even harder to comply to JLex interpretation of specs.
--dot
generate graphviz dot files for the NFA, DFA and minimised DFA. This feature is still in alpha
status, and not fully implemented yet.
--dump
display transition tables of NFA, initial DFA, and minimised DFA
--legacydot
dot (.) meta character matches [ˆ\n] instead of
[ˆ\n\r\u000B\u000C\u0085\u2028\u2029]
--verbose or -v
display generation progress messages (enabled by default)
--quiet or -q
display error messages only (no chatter about what JFlex is currently doing)
--warn-unused
warn about unused macros (by default true in verbose mode and false in quiet mode)
--no-warn-unused
do not warn about unused macros (by default true in verbose mode and false in quiet mode)
--time
display time statistics about the code generation process (not very accurate)
--version
print version number
--info
print system and JDK information (useful if you’d like to report a problem)
--unicodever <ver>
print all supported properties for Unicode version <ver>
--help or -h
print a help message explaining options and usage of JFlex.
2.3 Maven plugin
The plugin reads JFlex grammar definition files (
.jflex
) and generates a corresponding Java
parser (in target/generated-source/jflex by default).
2.3.1 Usage
Minimal configuration
This configuration generates java code of a parser for all grammar
files (*.jflex,*.jlex,*.lex,*.flex) found in src/main/jflex/ and its sub-directories.
7
The name and package of the generated Java source code are the ones defined in the grammar.
The generated Java source code is placed in
target/generated-source/jflex
, in sub-directories
following the Java convention on package names.
Update the pom.xml to add the plugin:
<project>
<!-- ... -->
<build>
<plugins>
<plugin>
<groupId>de.jflex</groupId>
<artifactId>jflex-maven-plugin</artifactId>
<version>1.7.0</version>
<executions>
<execution>
<goals>
<goal>generate</goal>
</goals>
</execution>
</executions>
</plugin>
</plugins>
<!-- ... -->
</build>
<!-- ... -->
</project>
More complex configuration
This example generates the source for the two grammars
src/main/lex/preprocessor.jflex
and
/pub/postprocessor.jflex
, as well as all grammar files
found in
src/main/jflex
(and its sub-directories). The generated Java code is placed into
src/main/java instead of target/generated-sources/jflex.
<plugin>
<groupId>de.jflex</groupId>
<artifactId>jflex-maven-plugin</artifactId>
<version>1.6.0</version>
<executions>
<execution>
<goals>
<goal>generate</goal>
</goals>
<configuration>
<outputDirectory>src/main/java</outputDirectory>
<lexDefinitions>
<lexDefinition>src/main/jflex</lexDefinition>
<lexDefinition>src/main/lex/preprocessor.jflex</lexDefinition>
<lexDefinition>/pub/postprocessor.jflex</lexDefinition>
</lexDefinitions>
</configuration>
</execution>
8
</executions>
</plugin>
Even more complex configuration, using several executions
This generates the source for
•all files found in src/main/lex/, using strict JLex compatibility.
•and all files found in src/main/jflex, in verbose mode.
<plugin>
<groupId>de.jflex</groupId>
<artifactId>jflex-maven-plugin</artifactId>
<version>1.6.0</version>
<executions>
<execution>
<id>strict jlex</id>
<goals>
<goal>generate</goal>
</goals>
<configuration>
<lexDefinitions>
<lexDefinition>src/main/lex</lexDefinition>
</lexDefinitions>
<jlex>true</jlex>
</configuration>
</execution>
<execution>
<id>jflex</id>
<goals>
<goal>generate</goal>
</goals>
<configuration>
<lexDefinitions>
<lexDefinition>src/main/jflex</lexDefinition>
</lexDefinitions>
<verbose>true</verbose>
</configuration>
</execution>
</executions>
</plugin>
More documentation on the configuration options can be found in the description for the
mojo:
mvn help:describe -DgroupId=de.jflex -DartifactId=maven-jflex-plugin -Ddetail
More information in the POM reference guide on plugins.
9
2.3.2 Versions
Which version of the plugin is best for you?
•
jflex-maven-plugin-1.7.0 depends on 1.7.0 and requires Java 7 when you
mvn jflex:generate
•
jflex-maven-plugin-1.7.0 depends on 1.7.0 and requires Java 7 when you
mvn jflex:generate
•
jflex-maven-plugin-1.6.1 depends on JFlex 1.6.1 and requires Java 5 when you
mvn
jflex:generate
•
jflex-maven-plugin-1.5.0 depends on JFlex 1.5.0 and requires Java 5 when you
mvn
jflex:generate
•maven-jflex-plugin-1.4.3-r1 depends on JFlex 1.4.3 and requires Java 1.3 when you mvn
jflex:generate
2.4 JFlex Ant Task
JFlex can easily be integrated with the Ant build tool. To use JFlex with Ant, simply copy
the
lib/jflex-1.7.0.jar
file to the
$ANT_HOME/lib/
directory or explicitly set the path to
lib/jflex-1.7.0.jar in the task definition (see example below).
The JFlex Ant Task invokes JFlex on a grammar file.
To use the JFlex task, place the following line in the Ant build file:
<taskdef classname="jflex.anttask.JFlexTask" name="jflex" />
Or, setting the path to the JFlex jar explicitly:
<taskdef classname="jflex.anttask.JFlexTask" name="jflex"
classpath="path-to-jflex.jar" />
The JFlex task requires the
file
attribute to be set to the source grammar file (
*.flex
).
Unless the target directory is specified with the
destdir
option, the generated class will be
saved to the same directory where the grammar file resides. Like
javac
, the JFlex task creates
subdirectories in destdir according to the generated class package.
This task only invokes JFlex if the grammar file is newer than the generated files.
2.4.1 Parameters
The following attributes are available for invoking the JFlex task.
•file="file"
The grammar file to process. This attribute is required.
•destdir="dir"
The directory to write the generated files to. If not set, the files are written to the
directory containing the grammar file. Note that unlike JFlex’s
-d
command line
option,
destdir
causes the generated file to be written to
{destdir}/{packagename}
.
This behaviour is similar to ‘javac -d dir.
10
•outdir="dir"
The directory to write the generated files to. If not set, the files are written to the
directory containing the grammar file. This options works exactly like JFlex’s
-d
command line option, it causes the output file to be written to
dir
regardless of the
package name.
•verbose (default "off")
Display generation process messages.
•encoding (if unset uses the JVM default encoding)
The character encoding to use when reading lexer specifications and writing java files.
•dump (default "off")
Dump character classes, NFA and DFA tables.
•time or timeStatistics (default "off")
Display generation time statistics.
•nomin or skipMinimization (default "off")
Skip DFA minimisation step.
•skel="file" or skeleton="file"
Use external skeleton file.
•dot or generateDot (default "off")
Write graphviz .dot files for the generated automata.
•nobak (default "off")
Do not make a backup if the generated file exists.
•jlex (default "off")
Use JLex compatibility mode.
•legacydot (default "off")
The dot
.
meta-character matches
[ˆ\n]
instead of
[ˆ\n\r\u000B\u000C\u0085\u2028\u202
9]
•unusedwarning (default "true")
Warn about unused macro definitions in the lexer specification.
2.4.2 Example
After the task definition, the <jflex ..> task is available in Ant. For example:
<jflex
file="src/parser/Parser.flex"
destdir="build/generated/"
/>
JFlex generates the scanner for
src/parser/Scanner.flex
and saves the result to
build/generated/parser/
,
providing Scanner.flex is declared to be in package parser.
11
<jflex
file="src/parser/Scanner.flex"
destdir="build/generated/"
/>
<javac
srcdir="build/generated/"
destdir="build/classes/"
/>
The same as above plus compile generated classes to build/classes
3 A simple Example: How to work with JFlex
To demonstrate how a lexical specification with JFlex looks like, this section presents a part
of the specification for the Java language. The example does not describe the whole lexical
structure of Java programs, but only a small and simplified part of it (some keywords, some
operators, comments and only two kinds of literals). It also shows how to interface with the
LALR parser generator CUP [
6
] and therefore uses a class
sym
(generated by CUP), where
integer constants for the terminal tokens of the CUP grammar are declared. JFlex comes with
a directory
examples
, where you can find a small standalone scanner that doesn’t need other
tools like CUP to give you working example code without dependencies.
The
examples
directory also contains a complete JFlex specification of the lexical structure
of Java programs together with the CUP parser specification for Java by C. Scott Ananian,
obtained from the CUP [
6
] web site (modified to interface with the JFlex scanner). Both
specifications adhere to the Java Language Specification [5].
/* JFlex example: partial Java language lexer specification */
import java_cup.runtime.*;
/**
* This class is a simple example lexer.
*/
%%
%class Lexer
%unicode
%cup
%line
%column
%{
StringBuffer string = new StringBuffer();
private Symbol symbol(int type) {
return new Symbol(type, yyline, yycolumn);
}
private Symbol symbol(int type, Object value) {
return new Symbol(type, yyline, yycolumn, value);
}
12
%}
LineTerminator = \r|\n|\r\n
InputCharacter = [^\r\n]
WhiteSpace = {LineTerminator} | [ \t\f]
/* comments */
Comment = {TraditionalComment} | {EndOfLineComment} | {DocumentationComment}
TraditionalComment = "/*" [^*] ~"*/" | "/*" "*"+ "/"
// Comment can be the last line of the file, without line terminator.
EndOfLineComment = "//" {InputCharacter}* {LineTerminator}?
DocumentationComment = "/**" {CommentContent} "*"+ "/"
CommentContent = ( [^*] | \*+ [^/*] )*
Identifier = [:jletter:] [:jletterdigit:]*
DecIntegerLiteral = 0 | [1-9][0-9]*
%state STRING
%%
/* keywords */
<YYINITIAL> "abstract" { return symbol(sym.ABSTRACT); }
<YYINITIAL> "boolean" { return symbol(sym.BOOLEAN); }
<YYINITIAL> "break" { return symbol(sym.BREAK); }
<YYINITIAL> {
/* identifiers */
{Identifier} { return symbol(sym.IDENTIFIER); }
/* literals */
{DecIntegerLiteral} { return symbol(sym.INTEGER_LITERAL); }
\" { string.setLength(0); yybegin(STRING); }
/* operators */
"=" { return symbol(sym.EQ); }
"==" { return symbol(sym.EQEQ); }
"+" { return symbol(sym.PLUS); }
/* comments */
{Comment} { /* ignore */ }
/* whitespace */
{WhiteSpace} { /* ignore */ }
}
<STRING> {
\" { yybegin(YYINITIAL);
return symbol(sym.STRING_LITERAL,
string.toString()); }
[^\n\r\"\\]+ { string.append( yytext() ); }
13
\\t { string.append(’\t’); }
\\n { string.append(’\n’); }
\\r { string.append(’\r’); }
\\\" { string.append(’\"’); }
\\ { string.append(’\\’); }
}
/* error fallback */
[^] { throw new Error("Illegal character <"+
yytext()+">"); }
From this specification JFlex generates a
.java
file with one class that contains code for the
scanner. The class will have a constructor taking a
java.io.Reader
from which the input is
read. The class will also have a function
yylex()
that runs the scanner and that can be used
to get the next token from the input (in this example the function actually has the name
next_token() because the specification uses the %cup switch).
As with JLex, the specification consists of three parts, divided by %%:
•usercode (Section 3.1),
•options and declarations (Section 3.2) and
•lexical rules (Section 3.3).
3.1 Code to include
Let’s take a look at the first section, user code: The text up to the first line starting with
%%
is copied verbatim to the top of the generated lexer class (before the actual class declaration).
Next to
package
and
import
statements there is usually not much to do here. If the code ends
with a
javadoc
class comment, the generated class will get this comment, if not, JFlex will
generate one automatically.
3.2 Options and Macros
The second section options and declarations is more interesting. It consists of a set of options,
code that is included inside the generated scanner class, lexical states and macro declarations.
Each JFlex option must begin a line of the specification and starts with a
%
. In our example
the following options are used:
•%class Lexer
tells JFlex to give the generated class the name
Lexer
and to write the
code to a file Lexer.java.
•%unicode
defines the set of characters the scanner will work on. For scanning text files,
%unicode
should always be used. The Unicode version may be specified, e.g.
%unicode
4.1
. If no version is specified, the most recent supported Unicode version will be used -
in JFlex 1.7.0, this is Unicode 9.0. See also Encodings (Section 5) for more information
on character sets, encodings, and scanning text vs. binary files.
•%cup switches to CUP compatibility mode to interface with a CUP generated parser.
14
•%line
switches line counting on (the current line number can be accessed via the variable
yyline)
•%column switches column counting on (the current column is accessed via yycolumn)
The code between
%{
and
%}
is copied verbatim into the generated lexer class source. Here
you can declare member variables and functions that are used inside scanner actions. In
our example we declare a
StringBuffer string
in which we will store parts of string literals
and two helper functions
symbol
that create
java_cup.runtime.Symbol
objects with position
information of the current token (see also JFlex and CUP (Section 9.1) for how to interface
with the parser generator CUP). As with all JFlex options, both
%{
and
%}
must begin a line.
The specification continues with macro declarations. Macros are abbreviations for regular
expressions, used to make lexical specifications easier to read and understand. A macro
declaration consists of a macro identifier followed by
=
, then followed by the regular expression
it represents. This regular expression may itself contain macro usages. Although this allows a
grammar-like specification style, macros are still just abbreviations and not non-terminals –
they cannot be recursive. Cycles in macro definitions are detected and reported at generation
time by JFlex.
Here some of the example macros in more detail:
•LineTerminator
stands for the regular expression that matches an ASCII
CR
, an ASCII
LF or a CR followed by LF.
•InputCharacter stands for all characters that are not a CR or LF.
•TraditionalComment
is the expression that matches the string
/*
followed by a character
that is not a
*
, followed by anything that does not contain, but ends in
*/
. As this
would not match comments like
/****/
, we add
/*
followed by an arbitrary number
(at least one) of
*
followed by the closing
/
. This is not the only, but one of the
simpler expressions matching non-nesting Java comments. It is tempting to just write
something like the expression
/* .* */
, but this would match more than we want. It
would for instance match the entire input
/* */ x = 0; /* */
, instead of two comments
and four real tokens. See the macros
DocumentationComment
and
CommentContent
for an
alternative.
•CommentContent
matches zero or more occurrences of any character except a
*
or any
number of *followed by a character that is not a /
•Identifier
matches each string that starts with a character of class
jletter
followed
by zero or more characters of class
jletterdigit
.
jletter
and
jletterdigit
are pre-
defined character classes.
jletter
includes all characters for which the Java function
Character.isJavaIdentifierStart
returns
true
and
jletterdigit
all characters for that
Character.isJavaIdentifierPart returns true.
The last part of the second section in our lexical specification is a lexical state declaration:
state STRING
declares a lexical state
STRING
that can be used in the lexical rules part of the
specification. A state declaration is a line starting with
%state
followed by a space or comma
separated list of state identifiers. There can be more than one line starting with %state.
15
3.3 Rules and Actions
The lexical rules section of a JFlex specification contains regular expressions and actions (Java
code) that are executed when the scanner matches the associated regular expression. As the
scanner reads its input, it keeps track of all regular expressions and activates the action of the
expression that has the longest match. Our specification above for instance would with input
breaker
match the regular expression for
Identifier
and not the keyword
break
followed by
the Identifier
er
, because rule
{Identifier}
matches more of this input at once than any other
rule in the specification. If two regular expressions both have the longest match for a certain
input, the scanner chooses the action of the expression that appears first in the specification.
In that way, we get for input break the keyword break and not an Identifier break.
In addition to regular expression matches, one can use lexical states to refine a specification. A
lexical state acts like a start condition. If the scanner is in lexical state
STRING
, only expressions
that are preceded by the start condition
<STRING>
can be matched. A start condition of a
regular expression can contain more than one lexical state. It is then matched when the lexer
is in any of these lexical states. The lexical state
YYINITIAL
is predefined and is also the state
in which the lexer begins scanning. If a regular expression has no start conditions it is matched
in all lexical states.
Since there often are sets of expressions with the same start conditions, they can be grouped:
<STRING> {
expr1 { action1 }
expr2 { action2 }
}
means that both expr1 and expr2 have start condition <STRING>.
The first three rules in our example demonstrate the syntax of a regular expression preceded
by the start condition <YYINITIAL>.
<YYINITIAL> "abstract" { return symbol(sym.ABSTRACT); }
matches the input
abstract
only if the scanner is in its start state
YYINITIAL
. When the string
abstract
is matched, the scanner function returns the CUP symbol
sym.ABSTRACT
. If an action
does not return a value, the scanning process is resumed immediately after executing the
action.
The rules enclosed in
<YYINITIAL> { ...
demonstrate the abbreviated syntax and are also only matched in state YYINITIAL.
Of these rules, one is of special interest:
\" { string.setLength(0); yybegin(STRING); }
16
If the scanner matches a double quote in state
YYINITIAL
we have recognised the start of a string
literal. Therefore we clear our
StringBuffer
that will hold the content of this string literal
and tell the scanner with
yybegin(STRING)
to switch into the lexical state
STRING
. Because we
do not yet return a value to the parser, our scanner proceeds immediately.
In lexical state
STRING
another rule demonstrates how to refer to the input that has been
matched:
[^\n\r\"\\]+ { string.append( yytext() ); }
The expression
[ˆ\n\r\"\\]+
matches all characters in the input up to the next backslash
(indicating an escape sequence such as
\n
), double quote (indicating the end of the string), or
line terminator (which must not occur in a Java string literal). The matched region of the
input is referred to by
yytext()
and appended to the content of the string literal parsed so far.
The last lexical rule in the example specification is used as an error fallback. It matches any
character in any state that has not been matched by another rule. It doesn’t conflict with any
other rule because it has the least priority (because it’s the last rule) and because it matches
only one character (so it can’t have longest match precedence over any other rule).
3.4 How to get it building
•Install JFlex (Section 2)
•
If you have written your specification file (or chosen one from the
examples
directory),
save it (say under the name java-lang.flex).
•Run JFlex with
jflex java-lang.flex
•
JFlex should then show progress messages about generating the scanner and write the
generated code to the directory of your specification file.
•
Compile the generated
.java
file and your own classes. (If you use CUP, generate your
parser classes first)
•That’s it.
4 Lexical Specifications
As shown above, a lexical specification file for JFlex consists of three parts divided by a single
line starting with %%:
UserCode
%%
Options and declarations
%%
Lexical rules
In all parts of the specification comments of the form
/* comment text */
and Java-style
end-of-line comments starting with
//
are permitted. JFlex comments do nest - so the number
of /* and */ should be balanced.
17
4.1 User code
The first part contains user code that is copied verbatim to the beginning of the generated
source file before the scanner class declaration. As shown in the example spec, this is the
place to put
package
declarations and
import
statements. It is possible, but not considered
good Java style to put helper classes, such as token classes, into this section; they are usually
better declared in their own .java files.
4.2 Options and declarations
The second part of the lexical specification contains options and directives to customise
the generated lexer, declarations of lexical states (Section 4.2.10) and macro definitions
(Section 4.2.11).
Each JFlex directive must sit at the beginning of a line and starts with the
%
character.
Directives that have one or more parameters are described as follows.
%class "classname"
means that you start a line with
%class
followed by a space followed by the name of the class
for the generated scanner (the double quotes are not to be entered, see also the example
specification (Section 3)).
4.2.1 Class options and user class code
These options regard name, constructor, API, and related parts of the generated scanner class.
•%class "classname"
Tells JFlex to give the generated class the name
classname
and to write the generated
code to a file
classname.java
. If the
-d <directory>
command line option is not used,
the code will be written to the directory where the specification file resides. If no
%class
directive is present in the specification, the generated class will get the name
Yylex
and
will be written to a file
Yylex.java
. There should be only one
%class
directive in a
specification.
•%implements "interface 1"[, "interface 2", ..]
Makes the generated lexer class implement the specified interfaces. If more than one
%implements directive is present, all specified interfaces will be implemented.
•%extends "classname"
Makes the generated class a subclass of the class
classname
. There should be only one
%extends directive in a specification.
•%public
Makes the generated class public (the class is only accessible in its own package by
default).
18
•%final
Makes the generated class final.
•%abstract
Makes the generated class abstract.
•%apiprivate
Makes all generated methods and fields of the class private. Exceptions are the con-
structor, user code in the specification, and, if
%cup
is present, the method
next_token
.
All occurrences of
public
(one space character before and after
public
) in the skeleton
file are replaced by
private
(even if a user-specified skeleton is used). Access to the
generated class is expected to be mediated by user class code (see next switch).
•%{
...
%}
The code enclosed in
%{
and
%}
is copied verbatim into the generated class. Here you
can define your own member variables and functions in the generated scanner. Like all
options, both
%{
and
%}
must start a line in the specification. If more than one class
code directive
%{...%}
is present, the code is concatenated in order of appearance in the
specification.
•%init{
...
%init}
The code enclosed in
%init{
and
%init}
is copied verbatim into the constructor of
the generated class. Here, member variables declared in the
%{...%}
directive can be
initialised. If more than one initialiser option is present, the code is concatenated in
order of appearance in the specification.
•%initthrow{
"exception1"[, "exception2", ...]
%initthrow}
or (on a single line) just
%initthrow "exception1" [, "exception2", ...]
Causes the specified exceptions to be declared in the
throws
clause of the constructor. If
more than one
%initthrow{ ... %initthrow}
directive is present in the specification, all
specified exceptions will be declared.
•%ctorarg "type" "ident"
Adds the specified argument to the constructors of the generated scanner. If more than
one such directive is present, the arguments are added in order of occurrence in the
specification. Note that this option conflicts with the
%standalone
and
%debug
directives,
because there is no sensible default that can be created automatically for such parameters
in the generated
main
methods. JFlex will warn in this case and generate an additional
default constructor without these parameters and without user init code (which might
potentially refer to the parameters).
19
•%scanerror "exception"
Causes the generated scanner to throw an instance of the specified exception in case
of an internal error (default is
java.lang.Error
). Note that this exception is only for
internal scanner errors. With usual specifications it should never occur (i.e. if there is an
error fallback rule in the specification and only the documented scanner API is used).
•%buffer "size"
Set the initial size of the scan buffer to the specified value (decimal, in bytes). The
default value is 16384.
•%include "filename"
Replaces the %include verbatim by the specified file.
4.2.2 Scanning method
This section shows how the scanning method can be customised. You can redefine the name
and return type of the method and it is possible to declare exceptions that may be thrown in
one of the actions of the specification. If no return type is specified, the scanning method will
be declared as returning values of class Yytoken.
•%function "name"
Causes the scanning method to get the specified name. If no
%function
directive is
present in the specification, the scanning method gets the name
yylex
. This directive
overrides settings of the
%cup
switch. The default name of the scanning method with the
%cup
switch is
next_token
. Overriding this name might lead to the generated scanner
being implicitly declared as
abstract
, because it does not provide the method
next_token
of the interface
java_cup.runtime.Scanner
. It is of course possible to provide a dummy
implementation of that method in the class code section if you still want to override the
function name.
•%integer
%int
Both cause the scanning method to be declared as returning Java type
int
. Actions in
the specification can then return
int
values as tokens. The default end of file value under
this setting is
YYEOF
, which is a
public static final int
member of the generated class.
•%intwrap
Causes the scanning method to be declared as of the Java wrapper type
Integer
. Actions
in the specification can then return
Integer
values as tokens. The default end of file
value under this setting is null.
•%type "typename"
Causes the scanning method to be declared as returning values of the specified type.
Actions in the specification can then return values of
typename
as tokens. The default end
of file value under this setting is
null
. If
typename
is not a subclass of
java.lang.Object
,
you should specify another end of file value using the
%eofval{ ... %eofval}
directive
or the
<<EOF>>
rule (Section 4.3.1). The
%type
directive overrides settings of the
%cup
switch.
20
•%yylexthrow{
"exception1" [, "exception2", ... ]
%yylexthrow}
or, on a single line, just
%yylexthrow "exception1" [, "exception2", ...]
The exceptions listed inside
%yylexthrow{ ... %yylexthrow}
will be declared in the
throws clause of the scanning method. If there is more than one
%yylexthrow{ ...
%yylexthrow} clause in the specification, all specified exceptions will be declared.
4.2.3 The end of file
There is always a default value that the scanning method will return when the end of file has
been reached. You may however define a specific value to return and a specific piece of code
that should be executed when the end of file is reached.
The default end of file value depends on the return type of the scanning method:
•
For
%integer
, the scanning method will return the value
YYEOF
, which is a
public static
final int member of the generated class.
•For %intwrap,
•for no specified type at all, or
•for a user defined type, declared using %type, the value is null.
•In CUP compatibility mode, using %cup, the value is
new java_cup.runtime.Symbol(sym.EOF)
User values and code to be executed at the end of file can be defined using these directives:
•%eofval{
...
%eofval}
The code included in
%eofval{ ... %eofval}
will be copied verbatim into the scanning
method and will be executed each time the end of file is reached (more than once is
possible when the scanning method is called again after the end of file has been reached).
The code should return the value that indicates the end of file to the parser. There
should be only one
%eofval{ ... %eofval}
clause in the specification. The
%eofval{ ...
%eofval}
directive overrides settings of the
%cup
switch and
%byaccj
switch. There is
also an alternative, more readable way to specify the end of file value using the
<<EOF>>
rule (Section 4.3.1).
•%eof{
...
%eof}
The code included in
%{eof ... %eof}
will be executed exactly once, when the end
of file is reached. The code is included inside a method
void yy_do_eof()
and should
not return any value (use
%eofval{...%eofval}
or
<<EOF>>
for this purpose). If more
21
than one end of file code directive is present, the code will be concatenated in order of
appearance in the specification.
•%eofthrow{
"exception1" [,"exception2", ... ]
%eofthrow}
or, on a single line:
%eofthrow "exception1" [, "exception2", ...]
The exceptions listed inside
%eofthrow{...%eofthrow}
will be declared in the throws
clause of the method
yy_do_eof()
. If there is more than one
%eofthrow{...%eofthrow}
clause in the specification, all specified exceptions will be declared.
•%eofclose
Causes JFlex to close the input stream at the end of file. The code
yyclose()
is appended
to the method
yy_do_eof()
(together with the code specified in
%eof{...%eof}
) and the
exception
java.io.IOException
is declared in the throws clause of this method (together
with those of %eofthrow{...%eofthrow})
•%eofclose false
Turns the effect of
%eofclose
off again (e.g. in case closing of input stream is not wanted
after %cup).
4.2.4 Standalone scanners
•%debug
Creates a main function in the generated class that expects the name of an input file on
the command line and then runs the scanner on this input file by printing information
about each returned token to the Java console until the end of file is reached. The
information includes: line number (if line counting is enabled), column (if column
counting is enabled), the matched text, and the executed action (with line number in
the specification).
•%standalone
Creates a main function in the generated class that expects the name of an input file on
the command line and then runs the scanner on this input file. The values returned by
the scanner are ignored, but any unmatched text is printed to the Java console instead.
To avoid having to use an extra token class, the scanning method will be declared as
having default type
int
, not
YYtoken
(if there isn’t any other type explicitly specified).
This is in most cases irrelevant, but could be useful to know when making another
scanner standalone for some purpose. You should consider using the
%debug
directive, if
you just want to be able to run the scanner without a parser attached for testing etc.
4.2.5 CUP compatibility
You may also want to read the CUP section (Section 9.1) if you are interested in how to
interface your generated scanner with CUP.
22
•%cup
The
%cup
directive enables CUP compatibility mode and is equivalent to the following
set of directives:
%implements java_cup.runtime.Scanner
%function next_token
%type java_cup.runtime.Symbol
%eofval{
return new java_cup.runtime.Symbol(<CUPSYM>.EOF);
%eofval}
%eofclose
The value of
<CUPSYM>
defaults to
sym
and can be changed with the
%cupsym
directive.
In JLex compatibility mode (
--jlex
switch on the command line),
%eofclose
will not
be turned on.
•%cup2
The
%cup2
directive is similar to CUP mode, just for the CUP2 generator from TU
Munich at http://www2.in.tum.de/cup2. It does the following:
–adds CUP2 package import declarations
–implements the CUP2 scanner interface
–switches on line and column count
–sets the scanner function to readNextTerminal
–sets the token type to ScannerToken<? extends Object>
–returns the special CUP2 EOF token at end of file
–switches on unicode
•%cupsym "classname"
Customises the name of the CUP generated class/interface containing the names of
terminal tokens. Default is
sym
. The directive should not be used after
%cup
, only before.
•%cupdebug
Creates a main function in the generated class that expects the name of an input file
on the command line and then runs the scanner on this input file. Prints line, column,
matched text, and CUP symbol name for each returned token to standard out.
4.2.6 BYacc/J compatibility
You may also want to read JFlex and BYacc/J (Section 9.2) if you are interested in how to
interface your generated scanner with Byacc/J.
•%byacc
The
%byacc
directive enables BYacc/J compatibility mode and is equivalent to the
following set of directives:
%integer
%eofval{
return 0;
%eofval}
%eofclose
23
4.2.7 Input Character sets
•%7bit
Causes the generated scanner to use an 7 bit input character set (character codes 0-127).
If an input character with a code greater than 127 is encountered in an input at runtime,
the scanner will throw an
ArrayIndexOutofBoundsException
. Not only because of this,
you should consider using the
%unicode
directive. See also Encodings (Section 5) for
information about character encodings. This is the default in JLex compatibility mode.
•%full
%8bit
Both options cause the generated scanner to use an 8 bit input character set (character
codes 0-255). If an input character with a code greater than 255 is encountered in an
input at runtime, the scanner will throw an
ArrayIndexOutofBoundsException
. Note that
even if your platform uses only one byte per character, the Unicode value of a character
may still be greater than 255. If you are scanning text files, you should consider using
the
%unicode
directive. See also section Econdings (Section 5) for more information
about character encodings.
•%unicode
%16bit
Both options cause the generated scanner to use the full Unicode input character set,
including supplementary code points: 0-0x10FFFF.
%unicode
does not mean that the
scanner will read two bytes at a time. What is read and what constitutes a character
depends on the runtime platform. See also section Encodings (Section 5) for more
information about character encodings. This is the default unless the JLex compatibility
mode is used (command line option --jlex).
•%caseless
%ignorecase
This option causes JFlex to handle all characters and strings in the specification as if
they were specified in both uppercase and lowercase form. This enables an easy way
to specify a scanner for a language with case insensitive keywords. The string
break
in
a specification is for instance handled like the expression
[bB][rR][eE][aA][kK]
. The
%caseless
option does not change the matched text and does not affect character classes.
So
[a]
still only matches the character
a
and not
A
. Which letters are uppercase and
which lowercase letters, is defined by the Unicode standard. In JLex compatibility mode
(
--jlex
switch on the command line),
%caseless
and
%ignorecase
also affect character
classes.
4.2.8 Line, character and column counting
•%char
Turns character counting on. The
int
member variable
yychar
contains the number of
characters (starting with 0) from the beginning of input to the beginning of the current
token.
24
•%line
Turns line counting on. The
int
member variable
yyline
contains the number of lines
(starting with 0) from the beginning of input to the beginning of the current token.
•%column
Turns column counting on. The
int
member variable
yycolumn
contains the number of
characters (starting with 0) from the beginning of the current line to the beginning of
the current token.
4.2.9 Obsolete JLex options
•%notunix
This JLex option is obsolete in JFlex but still recognised as valid directive. It used
to switch between Windows and Unix kind of line terminators (
\r\n
and
\n
) for the
$
operator in regular expressions. JFlex always recognises both styles of platform
dependent line terminators.
•%yyeof
This JLex option is obsolete in JFlex but still recognised as valid directive. In JLex it
declares a public member constant YYEOF. JFlex declares it in any case.
4.2.10 State declarations
State declarations have the following form:
%s[tate] "state identifier" [, "state identifier", ... ] for inclusive or
%x[state] "state identifier" [, "state identifier", ... ] for exclusive states
There may be more than one line of state declarations, each starting with
%state
or
%xstate
.
State identifiers are letters followed by a sequence of letters, digits or underscores. State
identifiers can be separated by white-space or comma.
The sequence
%state STATE1
%xstate STATE3, XYZ, STATE_10
%state ABC STATE5
declares the set of identifiers
STATE1, STATE3, XYZ, STATE_10, ABC, STATE5
as lexical states,
STATE1
,
ABC
,
STATE5
as inclusive, and
STATE3
,
XYZ
,
STATE_10
as exclusive. See also How the
Input is Matched (Section 4.3.3) on the way lexical states influence how the input is matched.
4.2.11 Macro definitions
A macro definition has the form
macroidentifier = regular expression
25
That means, a macro definition is a macro identifier (letter followed by a sequence of letters,
digits or underscores), that can later be used to reference the macro, followed by optional
white-space, followed by an
=
, followed by optional white-space, followed by a regular expression
(see Lexical Rules (Section 4.3) for more information about the regular expression syntax).
The regular expression on the right hand side must be well formed and must not contain the
ˆ
,
/
or
$
operators. Differently to JLex, macros are not just pieces of text that are expanded by
copying - they are parsed and must be well formed.
This is a feature.
It eliminates some very hard to find bugs in lexical specifications (such
like not having parentheses around more complicated macros - which is not necessary with
JFlex). See Porting from JLex (Section 8) for more details on the problems of JLex style
macros.
Since it is allowed to have macro usages in macro definitions, it is possible to use a grammar-like
notation to specify the desired lexical structure. However, macros remain just abbreviations of
the regular expressions they represent. They are not non-terminals of a grammar and cannot
be used recursively. JFlex detects cycles in macro definitions and reports them at generation
time. JFlex also warns you about macros that have been defined but never used in the lexical
rules section of the specification.
4.3 Lexical rules
The lexical rules section of a JFlex specification contains a set of regular expressions and actions
(Java code) that are executed when the scanner matches the associated regular expression.
The
%include
directive may be used in this section to include lexical rules from a separate file.
The directive will be replaced verbatim by the contents of the specified file.
4.3.1 Syntax
The syntax of the lexical rules section is described by the following EBNF grammar (terminal
symbols are enclosed in ’quotes’):
LexicalRules ::= (Include|Rule)+
Include ::= ’%include’ (’ ’|’\t’|’\b’)+ File
Rule ::= [StateList] [’^’] RegExp [LookAhead] Action
| [StateList] ’<<EOF>>’ Action
| StateGroup
StateGroup ::= StateList ’{’ Rule+ ’}’
StateList ::= ’<’ Identifier (’,’ Identifier)* ’>’
LookAhead ::= ’$’ | ’/’ RegExp
Action ::= ’{’ JavaCode ’}’ | ’|’
RegExp ::= RegExp ’|’ RegExp
| RegExp RegExp
| ’(’ RegExp ’)’
| (’!’|’~’) RegExp
| RegExp (’*’|’+’|’?’)
| RegExp "{" Number ["," Number] "}"
26
| CharClass
| PredefinedClass
| MacroUsage
| ’"’ StringCharacter+ ’"’
| Character
CharClass ::= ’[’ [’^’] CharClassContent* ’]’
| ’[’ [’^’] CharClassContent+
CharClassOperator CharClassContent+ ’]’
CharClassContent ::= CharClass | Character |
Character’-’Character |
MacroUsage | PredefinedClass
CharClassOperator ::= ’||’ | ’&&’ | ’--’ | ’~~’
MacroUsage ::= ’{’ Identifier ’}’
PredefinedClass ::= ’[:jletter:]’
| ’[:jletterdigit:]’
| ’[:letter:]’
| ’[:digit:]’
| ’[:uppercase:]’
| ’[:lowercase:]’
| ’\d’ | ’\D’
| ’\s’ | ’\S’
| ’\w’ | ’\W’
| ’\p{’ UnicodePropertySpec ’}’
| ’\P{’ UnicodePropertySpec ’}’
| ’\R’
| ’.’
UnicodePropertySpec ::= BinaryProperty |
EnumeratedProperty (’:’ | ’=’) PropertyValue
BinaryProperty ::= Identifier
EnumeratedProperty ::= Identifier
PropertyValue ::= Identifier
The grammar uses the following terminal symbols:
•File
a file name, either absolute or relative to the directory containing the lexical specification.
•JavaCode
a sequence of
BlockStatements
as described in the Java Language Specification [
5
],
section 14.2.
•Number
a non negative decimal integer.
27
•Identifier
a letter
[a-zA-Z]
followed by a sequence of zero or more letters, digits or underscores
[a-zA-Z0-9_]
•Character
an escape sequence or any unicode character that is not one of these meta characters:
|
(){}[]<>\.*+?ˆ$/."~!
•StringCharacter
an escape sequence or any unicode character that is not one of these meta characters:
\
"
•An escape sequence
–\n \r \t \f \b
–
a
\x
followed by two hexadecimal digits
[a-fA-F0-9]
(denoting an ASCII escape
sequence);
–
a
\u
followed by four hexadecimal digits
[a-fA-F0-9]
, denoting a unicode escape
sequence. Note that these are precisely four digits, i.e.
\u12345
is the character
\u1234 followed by the character 5.
–
a
\U
(note that the ’U’ is uppercase) followed by six hexadecimal digits
[a-fA-F0-9]
,
denoting a unicode code point escape sequence;
–\u{H+( H+)*}
, where
H+
is one or more hexadecimal digits
[a-fA-F0-9]
, each
H+
denotes a code point - note that in character classes, only one code point is allowed;
–
a backslash followed by a three digit octal number from 000 to 377, denoting an
ASCII escape sequence; or
–
a backslash followed by any other unicode character that stands for this character.
Please note that the
\n
escape sequence stands for the ASCII LF character - not for the end of
line. If you would like to match the line terminator, you should use the expression
\r|\n|\r\n
if you want the Java conventions, or
\r\n|[\r\n\u2028\u2029\u000B\u000C\u0085]
(provided
as predefined class \R) if you want to be fully Unicode compliant (see also [4]).
The white-space characters
" "
(space) and
\t
(tab) can be used to improve the readability of
regular expressions. They will be ignored by JFlex. In character classes and strings, however,
white-space characters keep standing for themselves (so the string
" "
still matches exactly
one space character and [ \n] still matches an ASCII LF or a space character).
JFlex applies the following standard operator precedences in regular expression (from highest
to lowest):
•unary postfix operators (*,+,?,{n},{n,m})
•unary prefix operators (!,~)
•concatenation (RegExp::= RegExp Regexp)
•union (RegExp::= RegExp ’|’ RegExp)
So the expression a | abc | !cd* for instance is parsed as (a|(abc)) | ((!c)(d*)).
28
4.3.2 Semantics
This section gives an informal description of which text is matched by a regular expression,
i.e. an expression described by the RegExp production of the grammar above (Section 4.3.1).
A regular expression that consists solely of
•aCharacter matches this character.
•
a character class
[...]
matches any character in that class. A
Character
is considered
an element of a class if it is listed in the class or if its code lies within a listed character
range
Character’-’Character
or Macro or predefined character class. So
[a0-3\n]
for
instance matches the characters
a0123\n
If the list of characters is empty (i.e. just
[]
), the expression matches nothing at all
(the empty set), not even the empty string. This can be useful in combination with the
negation operator !.
Character sets may be nested, e.g. [[[abc]d[e]]fg] is equivalent to [abcdefg].
Supported character set operations:
–
Union (
||
), e.g.
[[a-c]||[d-f]]
, equivalent to
[a-cd-f]
: this is the default character
set operation when no operator is specified.
–Intersection (&&), e.g. [[a-f]&&[f-m]], equivalent to [f].
–Set difference (--), e.g. [[a-z]--m], equivalent to [a-ln-z].
–
Symmetric difference (
~~
): the union of two classes minus their intersection. For
instance
[\p{Letter}~~\p{ASCII}]
is equivalent to
[[\p{Letter}||\p{ASCII}]--[\p{Letter}&&\p{ASCII}]]
the set of characters that are present in either
\p{Letter}
or in
\p{ASCII}
, but not
in both.
•
a negated character class
’[ˆ...]’
matches all characters not listed in the class. If the
list of characters is empty (i.e.
[ˆ]
), the expression matches any character of the input
character set.
•
a string
” StringCharacter+ ”
matches the exact text enclosed in double quotes. All
meta characters apart from
\
and
"
lose their special meaning inside a string. See also
the %ignorecase switch.
•
a macro usage
’{’ Identifier ’}’
matches the input that is matched by the right hand
side of the macro with name Identifier.
•
a predefined character class matches any of the characters in that class. There are the
following predefined character classes:
–
two predefined character classes that are determined by Java library functions in
class java.lang.Character:
29
[:jletter:] isJavaIdentifierStart()
[:jletterdigit:] isJavaIdentifierPart()
–
four predefined character classes equivalent to the following Unicode properties
(described below (Section 4.3.2)):
[:letter:] \p{Letter}
[:digit:] \p{Digit}
[:uppercase:] \p{Uppercase}
[:lowercase:] \p{Lowercase}
–
the following meta characters, equivalent to these (sets of) Unicode Properties
(described below (Section 4.3.2)):
\d \p{Digit}
\D \P{Digit}
\s \p{Whitespace}
\S \P{Whitespace}
\w [\p{Alpha}\p{Digit}\p{Mark}
\p{Connector Punctuation}\p{Join Control}]
\W [^\p{Alpha}\p{Digit}\p{Mark}
\p{Connector Punctuation}\p{Join Control}]
–
Unicode Properties are character classes specified by each version of the Unicode
Standard. JFlex supports a subset of all defined Properties for each supported
Unicode version. To see the full list of supported Properties, give the
–uniprops
<ver>
option on the JFlex command line, where
<ver>
is the Unicode version. Some
Properties have aliases; JFlex recognizes all aliases for all supported properties.
JFlex supports loose matching of Properties: case distinctions, whitespace, hyphens,
and underscores are ignored.
To refer to a Unicode Property, use the
\p{...}
syntax, e.g. the Greek Block can be
referred to as
\p{Block:Greek}
. To match all characters not included in a property,
use the
\P{...}
syntax (note that the ’
P
’ is uppercase), e.g. to match all characters
that are not letters, use \P{Letter}.
See UTS#18 [
4
] for a description of and links to definitions of some supported
Properties. UnicodeSet [
11
] is an online utility to show the character sets corre-
sponding to Unicode Properties and set operations on them, but only for the most
recent Unicode version.
–Dot (.) matches [ˆ\r\n\u2028\u2029\u000B\u000C\u0085].
Use the –legacydot option to instead match [ˆ\n].
–\R matches any newline: \r\n|[\r\n\u2028\u2029\u000B\u000C\u0085].
If aand bare regular expressions, then
•a|b(union)
is the regular expression that matches all input matched by aor by b.
•a b (concatenation)
is the regular expression that matches the input matched by
a
followed by the input
matched by b.
30
•a* (Kleene closure)
matches zero or more repetitions of the input matched by a
•a+ (iteration)
is equivalent to aa*
•a? (option)
matches the empty input or the input matched by a
•!a (negation)
matches everything but the strings matched by
a
. Use with care: the construction of
!a
involves an additional, possibly exponential NFA to DFA transformation on the NFA for
a
. Note that with negation and union you also have (by applying DeMorgan) intersection
and set difference: the intersection of
a
and
b
is
!(!a|!b)
, the expression that matches
everything of anot matched by bis !(!a|b)
•~a (upto)
matches everything up to (and including) the first occurrence of a text matched by
a
.
The expression
~a
is equivalent to
!([ˆ]* a [ˆ]*) a
. A traditional C-style comment is
matched by "/*" ~"*/"
•a {n} (repeat)
is equivalent to
n
times the concatenation of
a
. So
a{4}
for instance is equivalent to the
expression aaaa. The decimal integer nmust be positive.
•a {n,m}
is equivalent to at least
n
times and at most
m
times the concatenation of
a
. So
a{2,4}
for instance is equivalent to the expression
a a a? a?
. Both
n
and
m
are non-negative
decimal integers and mmust not be smaller than n.
•(a)
matches the same input as a.
In a lexical rule, a regular expression
r
may be preceded by a
ˆ
(the beginning of line
operator).
r
is then only matched at the beginning of a line in the input. A line begins after
each occurrence of
\r|\n|\r\n|\u2028|\u2029|\u000B|\u000C|\u0085
(see also [
4
]) and at the
beginning of input. The preceding line terminator in the input is not consumed and can be
matched by another rule.
In a lexical rule, a regular expression
r
may be followed by a look-ahead expression. A
look-ahead expression is either
$
(the end of line operator) or
/
followed by an arbitrary regular
expression. In both cases the look-ahead is not consumed and not included in the matched
text region, but it
is
considered while determining which rule has the longest match (see also
How the input is matched (Section 4.3.3)).
In the
$
case,
r
is only matched at the end of a line in the input. The end of a line is denoted by
the regular expression
\r|\n|\r\n|\u2028|\u2029|\u000B|\u000C|\u0085
. So
a$
is equivalent
to
a / \r|\n|\r\n|\u2028|\u2029|\u000B|\u000C|\u0085
. This is different to the situation
described in [
4
]: since in JFlex
$
is a true trailing context, the end of file does
not
count as
end of line.
31
For arbitrary look-ahead (also called trailing context) the expression is matched only when
followed by input that matches the trailing context.
JFlex allows lex/flex style <<EOF>> rules in lexical specifications. A rule
[StateList] <<EOF>> { action code }
is very similar to the
%eofval
directive. The difference lies in the optional
StateList
that
may precede the
<<EOF>>
rule. The action code will only be executed when the end of file is
read and the scanner is currently in one of the lexical states listed in
StateList
. The same
StateGroup
(see section How the input is matched (Section 4.3.3)) and precedence rules as in
the “normal” rule case apply (i.e. if there is more than one
<<EOF>>
rule for a certain lexical
state, the action of the one appearing earlier in the specification will be executed).
<<EOF>>
rules override settings of the
%cup
and
%byaccj
options and should not be mixed with the
%eofval directive.
An
Action
consists either of a piece of Java code enclosed in curly braces or is the special
|
action. The |action is an abbreviation for the action of the following expression.
Example:
expression1 |
expression2 |
expression3 { some action }
is equivalent to the expanded form
expression1 { some action }
expression2 { some action }
expression3 { some action }
They are useful when working with trailing context expressions. The expression
a|(c/d)
| b is not a syntactically legal regular expression, but can be expressed using the |action:
a |
c / d |
b { some action }
4.3.3 How the input is matched
When consuming its input, the scanner determines the regular expression that matches the
longest portion of the input (longest match rule). If there is more than one regular expression
that matches the longest portion of input (i.e. they all match the same input), the generated
scanner chooses the expression that appears first in the specification. After determining the
active regular expression, the associated action is executed. If there is no matching regular
expression, the scanner terminates the program with an error message (if the
%standalone
directive has been used, the scanner prints the unmatched input to
java.lang.System.out
instead and resumes scanning).
Lexical states can be used to further restrict the set of regular expressions that match the
current input.
32
•
A regular expression can only be matched when its associated set of lexical states includes
the currently active lexical state of the scanner or if the set of associated lexical states is
empty and the currently active lexical state is inclusive. Exclusive and inclusive states
only differ in this one point: rules with an empty set of associated states.
•
The currently active lexical state of the scanner can be changed from within an action
of a regular expression using the method yybegin().
•
The scanner starts in the inclusive lexical state
YYINITIAL
, which is always declared by
default.
•
The set of lexical states associated with a regular expression is the
StateList
that
precedes the expression. If a rule is contained in one or more
StateGroups
, then the
states of these are also associated with the rule, i.e. they accumulate over StateGroups.
Example:
%states A, B
%xstates C
%%
expr1 { yybegin(A); action }
<YYINITIAL, A> expr2 { action }
<A> {
expr3 { action }
<B,C> expr4 { action }
}
The first line declares two (inclusive) lexical states
A
and
B
, the second line an exclusive
lexical state
C
. The default (inclusive) state
YYINITIAL
is always implicitly there and
doesn’t need to be declared. The rule with
expr1
has no states listed, and is thus
matched in all states but the exclusive ones, i.e.
A
,
B
, and
YYINITIAL
. In its action, the
scanner is switched to state
A
. The second rule
expr2
can only match when the scanner
is in state
YYINITIAL
or
A
. The rule
expr3
can only be matched in state
A
and
expr4
in
states A,B, and C.
•
Lexical states are declared and used as Java
int
constants in the generated class under
the same name as they are used in the specification. There is no guarantee that the
values of these integer constants are distinct. They are pointers into the generated DFA
table, and if JFlex recognises two states as lexically equivalent (if they are used with the
exact same set of regular expressions), then the two constants will get the same value.
4.3.4 The generated class
JFlex generates exactly one file containing one class from the specification (unless you have
declared another class in the first specification section).
The generated class contains (among other things) the DFA tables, an input buffer, the lexical
states of the specification, a constructor, and the scanning method with the user supplied
actions.
The name of the class is by default
Yylex
. The name is customisable with the
%class
directive.
The input buffer of the lexer is connected with external input through the
java.io.Reader
object which is passed to the lexer in the generated constructor. If you provide your own
33
constructor for the lexer, you should always chain-call the generated one to initialise the input
buffer. The input buffer should not be accessed directly, but only through the advertised API
(see also Scanner Methods (Section 4.3.5)). Its internal implementation may change between
releases or skeleton files without notice.
The main interface to the outside world is the generated scanning method (default name
yylex
, default return type
Yytoken
). Most of its aspects are customisable (name, return type,
declared exceptions etc.). If it is called, it will consume input until one of the expressions in
the specification is matched or an error occurs. If an expression is matched, the corresponding
action is executed. It may return a value of the specified return type (in which case the
scanning method returns with this value), or, if it does not return a value, the scanner resumes
consuming input until the next expression is matched. If the end of file is reached, the scanner
executes the
EOF
action, and (also upon each further call to the scanning method) returns the
specified EOF value.
4.3.5 Scanner methods and fields accessible in actions (API)
Generated methods and member fields in JFlex scanners are prefixed with
yy
to indicate that
they are generated and to avoid name conflicts with user code copied into the class. Since
user code is part of the same class, JFlex has no language means like the
private
modifier
to indicate which members and methods are internal and which ones belong to the API.
Instead, JFlex follows a naming convention: everything starting with
zz
, such as
zzStartRead
,
is internal and subject to change without notice between JFlex releases. Methods and members
of the generated class that do not have a
zz
prefix, such as
yycharat
, belong to the API that
the scanner class provides to users in action code of the specification. They will remain stable
and supported between JFlex releases as long as possible.
Currently, the API consists of the following methods and member fields:
•String yytext()
returns the matched input text region
•int yylength()
returns the length of the matched input text region as number of Java
chars
(as opposed
to Unicode code points). Does notrequire a String object to be created.
•char yycharat(int pos)
returns the Java
char
at position
pos
from the matched text. It is equivalent to
yytext().charAt(pos), but faster. pos must be a value from 0to yylength()-1.
•void yyclose()
closes the input stream. All subsequent calls to the scanning method will return the end
of file value
•void yyreset(java.io.Reader reader)
closes the current input stream, and resets the scanner to read from a new Reader. All
internal variables are reset, the old Reader cannot be reused (content of the internal
buffer is discarded and lost). The lexical state is set to
YY_INITIAL
. The
%{init
code is
not included in
yyreset
, because it is assumed to run in the context of a constructor,
34
not a normal method. If
%{init
does need to be repeated, consider constructing a new
lexer object instead, or calling a custom function that performs any additional user-level
state reset.
•void yypushStream(java.io.Reader reader)
Stores the current input stream on a stack, and reads from a new stream. Lexical state,
line, char, and column counting remain untouched. The current input stream can be
restored with yypopStream (usually in an <<EOF>> action).
A typical example for this are include files in style of the C pre-processor. The corre-
sponding JFlex specification could look like this:
"#include" {FILE} { yypushStream(new FileReader(getFile(yytext()))); }
...
<<EOF>> { if (yymoreStreams()) yypopStream(); else return EOF; }
This method is only available in the skeleton file
skeleton.nested
. You can find it in
the src directory of the JFlex distribution.
•void yypopStream()
Closes the current input stream and continues to read from the one on top of the stream
stack.
This method is only available in the skeleton file
skeleton.nested
. You can find it in
the src directory of the JFlex distribution.
•boolean yymoreStreams()
Returns true iff there are still streams for
yypopStream
left to read from on the stream
stack.
This method is only available in the skeleton file
skeleton.nested
. You can find it in
the src directory of the JFlex distribution.
•int yystate()
returns the current lexical state of the scanner.
•void yybegin(int lexicalState)
enters the lexical state lexicalState
•void yypushback(int number)
pushes
number
Java
char
s (as opposed to Unicode code points) of the matched text
back into the input stream. They will be read again in the next call of the scanning
method. The number of chars to be read again must not be greater than the length of
the matched text. The pushed back characters will not be included in
yylength()
and
yytext(). Note that in Java strings are unchangeable, i.e. an action code like
String matched = yytext();
yypushback(1);
return matched;
will return the whole matched text, while
yypushback(1);
return yytext();
35
will return the matched text minus the last character.
Note that with Unicode surrogate characters it is possible that expressions such as
[ˆ]
match more than one char.
•int yyline
contains the current line of input (starting with 0, only active with the
lineCounting
directive)
•int yychar
contains the current character count in the input (starting with 0, only active with the
charCounting directive)
•int yycolumn
contains the current column of the current line (starting with 0, only active with the
columnCounting directive)
5 Encodings, Platforms, and Unicode
This section discusses Unicode and encodings, cross platform scanning, and how to deal with
binary data.
5.1 The Problem
Java aims to be implementation platform independent, yet different platforms use different
ways to encode characters. Moreover, a file written on one platform, say Windows, may later
be read by a scanner on another platform, for instance Linux.
If a program reads a file from disk, what it really reads is a stream of bytes. These bytes can
be mapped to characters in different ways. For instance, in standard ASCII, the byte value 65
stands for the character
A
, and in the encoding
iso-latin-1
, the byte value 213 stands for the
umlaut character
ä
, but in the encoding
iso-latin-2
the value 213 is
é
instead. As long as
one encoding is used consistently, this is no problem. Some characters may not be available in
the encoding you are using, but at least the interpretation of the mapping between bytes and
characters agrees between different programs.
When your program runs on more than one platform, however, as is often the case with Java,
things become more complex. Java’s solution to this is to use Unicode internally. Unicode
aims to be able to represent all known character sets and is therefore a perfect base for
encoding things that might get used all over the world and on different platforms. To make
things work correctly, you still have to know where you are and how to map byte values to
Unicode characters and vice versa, but the important thing is, that this mapping is at least
possible (you can map Kanji characters to Unicode, but you cannot map them to ASCII or
iso-latin-1).
36
5.2 Scanning text files
Scanning text files is the standard application for scanners like JFlex. Therefore it should also
be the most convenient one. Most times it is.
The following scenario works fine: You work on a platform X, write your lexer specification
there, can use any obscure Unicode character in it as you like, and compile the program. Your
users work on any platform Y (possibly but not necessarily something different from X), they
write their input files on Y and they run your program on Y. No problems.
Java does this as follows: If you want to read anything in Java that is supposed to contain
text, you use a
FileReader
, which converts the bytes of the file into Unicode characters with
the platform’s default encoding. If a text file is produced on the same platform, the platform’s
default encoding should do the mapping correctly. Since JFlex also uses readers and Unicode
internally, this mechanism also works for the scanner specifications. If you write an
A
in your
text editor and the editor uses the platform’s encoding (say
A
is 65), then Java translates
this into the logical Unicode
A
internally. If a user writes an
A
on a completely different
platform (say
A
is 237 there), then Java also translates this into the logical Unicode
A
internally.
Scanning is performed after that translation and both match.
Note that because of this mapping from bytes to characters, you should always use the
%unicode
switch in you lexer specification if you want to scan text files.
%8bit
may not be
enough, even if you know that your platform only uses one byte per character. The encoding
Cp1252
used on many Windows machines for instance knows 256 characters, but the character
’
with
Cp1252
code
\x92
has the Unicode value
\u2019
, which is larger than 255 and which
would make your scanner throw an ArrayIndexOutOfBoundsException if it is encountered.
So for the usual case you don’t have to do anything but use the
%unicode
switch in your lexer
specification.
Things may break when you produce a text file on platform X and consume it on a different
platform Y. Let’s say you have a file written on a Windows PC using the encoding
Cp1252
.
Then you move this file to a Linux PC with encoding
ISO 8859-1
and there you run your
scanner on it. Java now thinks the file is encoded in
ISO 8859-1
(the platform’s default
encoding) while it really is encoded in
Cp1252
. For most characters
Cp1252
and
ISO 8859-1
are
the same, but for the byte values
\x80
to
\x9f
they disagree:
ISO 8859-1
is undefined there.
You can fix the problem by telling Java explicitly which encoding to use. When constructing
the InputStreamReader, you can give the encoding as argument. The line
Reader r = new InputStreamReader(input, Cp1252);
will do the trick.
Of course the encoding to use can also come from the data itself: for instance, when you
scan an HTML page, it may have embedded information about its character encoding in the
headers.
More information about encodings, which ones are supported, how they are called, and how
to set them may be found in the official Java documentation in the chapter about internation-
alisation. The link
http://docs.oracle.com/javase/7/docs/technotes/guides/intl/
leads to
an online version of this for Oracle’s JDK 1.7.
37
5.3 Scanning binaries
Scanning binaries is both easier and more difficult than scanning text files. It’s easier because
you want the raw bytes and not their meaning, i.e. you don’t want any translation. It’s more
difficult because it’s not so easy to get “no translation” when you use Java readers.
The problem (for binaries) is that JFlex scanners are designed to work on text. Therefore
the interface is the
Reader
class. You can still get a binary scanner when you write your
own custom
InputStreamReader
class that explicitly does no translation, but just copies byte
values to character codes instead. It sounds quite easy, and actually it is no big deal, but
there are a few pitfalls on the way. In the scanner specification you can only enter positive
character codes (for bytes that is
\x00
to
\xFF
). Java’s
byte
type on the other hand is a signed
8 bit integer (-128 to 127), so you have to convert them accordingly in your custom
Reader
.
Also, you should take care when you write your lexer spec: if you use text in there, it gets
interpreted by an encoding first, and what scanner you get as result might depend on which
platform you run JFlex on when you generate the scanner (this is what you want for text,
but for binaries it gets in the way). If you are not sure, or if the development platform might
change, it’s probably best to use character code escapes in all places, since they don’t change
their meaning.
6 Conformance with Unicode Regular Expressions UTS#18
This section gives details about JFlex 1.7.0’s conformance with the requirements for Basic
Unicode Support Level 1 given in UTS#18 [4].
6.1 RL1.1 Hex Notation
To meet this requirement, an implementation shall supply a mechanism for specify-
ing any Unicode code point (from U+0000 to U+10FFFF), using the hexadecimal
code point representation.
JFlex conforms. Syntax is provided to express values across the whole range, via
\uXXXX
,
where
XXXX
is a 4-digit hex value;
\Uyyyyyy
, where
yyyyyy
is a 6-digit hex value; and
\u{X+(
X+)*}, where X+ is a 1-6 digit hex value.
6.2 RL1.2 Properties
To meet this requirement, an implementation shall provide at least a minimal
list of properties, consisting of the following: General_Category, Script and
Script_Extensions, Alphabetic, Uppercase, Lowercase, White_Space, Nonchar-
acter_Code_Point, Default_Ignorable_Code_Point, ANY, ASCII, ASSIGNED.
The values for these properties must follow the Unicode definitions, and include the
property and property value aliases from the UCD. Matching of Binary, Enumerated,
Catalog, and Name values, must follow the Matching Rules from [UAX44].
38
JFlex conforms. The minimal set of properties is supported, as well as a few others. To see the
full list of supported properties, use the JFlex command line option
--uniprops <ver>
, where
<ver>
is the Unicode version. Loose matching is performed: case distinctions, whitespace,
underscores and hyphens in property names and values are ignored.
6.3 RL1.2a Compatibility Properties
To meet this requirement, an implementation shall provide the properties listed in
Annex C: Compatibility Properties, with the property values as listed there. Such an
implementation shall document whether it is using the Standard Recommendation
or POSIX-compatible properties.
JFlex does not fully conform. The Standard Recommendation version of the Annex C
Compatibility Properties are provided, with two exceptions:
\X
Extended Grapheme Clusters;
and \b Default Word Boundaries.
6.4 RL1.3 Subtraction and Intersection
To meet this requirement, an implementation shall supply mechanisms for union,
intersection and set-difference of Unicode sets.
JFlex conforms by providing these mechanisms, as well as symmetric difference.
6.5 RL1.4 Simple Word Boundaries
To meet this requirement, an implementation shall extend the word boundary
mechanism so that:
1.
The class of
<word_character>
includes all the Alphabetic values from the
Unicode character database, from UnicodeData.txt [UData], plus the decimals
(General_Category = Decimal_Number, or equivalently Numeric_Type =
Decimal), and the U+200C ZERO WIDTH NON-JOINER and U+200D
ZERO WIDTH JOINER (Join_Control=True). See also Annex C: Compati-
bility Properties.
2.
Nonspacing marks are never divided from their base characters, and otherwise
ignored in locating boundaries.
JFlex does not conform: \b does not match simple word boundaries.
6.6 RL1.5 Simple Loose Matches
To meet this requirement, if an implementation provides for case-insensitive match-
ing, then it shall provide at least the simple, default Unicode case-insensitive
matching, and specify which properties are closed and which are not.
To meet this requirement, if an implementation provides for case conversions, then
it shall provide at least the simple, default Unicode case folding.
JFlex conforms. All supported Unicode Properties are closed.
39
6.7 RL1.6 Line Boundaries
To meet this requirement, if an implementation provides for line-boundary testing,
it shall recognize not only CRLF, LF, CR, but also NEL (U+0085), PARAGRAPH
SEPARATOR (U+2029) and LINE SEPARATOR (U+2028).
JFlex conforms.
6.8 RL1.7 Supplementary Code Points
To meet this requirement, an implementation shall handle the full range of Unicode
code points, including values from U+FFFF to U+10FFFF. In particular, where
UTF-16 is used, a sequence consisting of a leading surrogate followed by a trailing
surrogate shall be handled as a single code point in matching.
JFlex conforms.
7 A few words on performance
This section gives tips on how to make your specification produce a faster scanner.
In general, the regular expression matching generated by JFlex has very good performance. It
is DFA-based (deterministic finite automata) and does not require backtracking over alternative
as for instance perl-style regular expression matching does. In the optimal case, each character
is only examined once, in some situations explained below, a small amount of backtracking is
necessary to determine the longest match.
Even within the class of DFA-based scanners, JFlex generated scanners usually show very
good performance without special optimisations. The following lists a few heuristics that can
make a lexical specification produce an even faster scanner. Those are (roughly in order of
performance gain):
•Avoid rules that require backtracking
While there is no backtracking for expressions like
a|b
in JFlex, some backtracking is still
introduced by the longest match rule and occurs for instance on this set of expressions:
averylongkeyword
.
With input
averylongjoke
the scanner has to read all characters up to
’j’
to decide
that rule
.
should be matched. All characters of
verylong
have to be read again for the
next matching process.
From the C/C++ flex [
8
] man page: Getting rid of backtracking is messy and often may
be an enormous amount of work for a complicated scanner. Backtracking can be avoided
in general by adding error rules that match those error conditions
"av"|"ave"|"avery"|"averyl"|..
While this is impractical in most scanners, there is still the possibility to add a catch all
rule for a lengthy list of keywords
40
"keyword1" { return symbol(KEYWORD1); }
..
"keywordn" { return symbol(KEYWORDn); }
[a-z]+ { error("not a keyword"); }
Most programming language scanners already have a rule like this for some kind of
variable length identifiers, which means this kind of backtracking for programming
language scanners often concerns only at most a single character.
•Avoid line and column counting
It costs multiple additional comparisons per input character and the matched text has
to be re-scanned for counting. In most scanners it is possible to do the line counting in
the specification by incrementing
yyline
each time a line terminator has been matched.
Column counting could also be included in actions. This will be faster, but can in some
cases become quite messy.
•Avoid look-ahead expressions and the end of line operator $
In the best case, the trailing context will first have to be read and then (because it is not
to be consumed) re-read again. The cases of fixed-length look-ahead and fixed-length
base expressions are handled efficiently by matching the concatenation and then pushing
back the required amount of characters. This extends to the case of a disjunction of
fixed-length look-ahead expressions such as
r1 / \r|\n|\r\n
. All other cases
r1 / r2
are
handled by first scanning the concatenation of
r1
and
r2
, and then finding the correct
end of
r1
. The end of
r1
is found by scanning forwards in the match again, marking
all possible
r1
terminations, and then scanning the reverse of
r2
backwards from the
end until a start of
r2
intersects with an end of
r1
. This algorithm is linear in the size
of the input (not quadratic or worse as backtracking is), but about a factor of 2 slower
than normal scanning. It also consumes memory proportional to the size of the matched
input for r1 r2.
•Avoid the beginning of line operator ˆ
It costs multiple additional comparisons per match. In some cases one extra look-ahead
character is needed (when the last character read is
\r
, the scanner has to read one
character ahead to check if the next one is an \n or not).
•Match as much text as possible in a rule.
One rule is matched in the innermost loop of the scanner. After each action, setting up
the internal state of the scanner is necessary and induces a small overhead.
Note that writing more rules in a specification does not make the generated scanner slower.
The two main rules of optimisation apply also for lexical specifications:
1. don’t do it
2. (for experts only) don’t do it yet
Some of the performance tips above contradict a readable and compact specification style.
When in doubt or when requirements are not or not yet fixed: don’t use them — the
specification can always be optimised in a later state of the development process.
41
8 Porting Issues
8.1 Porting from JLex
JFlex was designed to read old JLex specifications unchanged and to generate a scanner which
behaves exactly the same as the one generated by JLex with the only difference of being faster.
This works as expected on all well formed JLex specifications.
Since the statement above is somewhat absolute, let’s take a look at what well formed means
for this purpose. A JLex specification is well formed, when it
•generates a working scanner with JLex
•doesn’t contain the unescaped characters !and ~
They are operators in JFlex while JLex treats them as normal input characters. You can
easily port such a JLex specification to JFlex by replacing every
!
with
\!
and every
~
with \~ in all regular expressions.
•has only complete regular expressions surrounded by parentheses in macro definitions
This may sound a bit harsh, but is usually not a big problem – it can also help you find
some disgusting bugs in your specification that went unnoticed so far. In JLex, the right
hand side of a macro is just a piece of text that is copied to the point where the macro
is used. With this, things like
macro1 = ("hello"
macro2 = {macro1})*
were possible (with
macro2
expanding to
("hello")*
). This is not allowed in JFlex and
you will have to transform such definitions. There are more subtle kinds of errors that
can be introduced by JLex macros. Consider a definition such as
macro = a|b
and a
usage like
{macro}*
. This expands in JLex to
a|b*
and not to the probably intended
(a|b)*.
Basically, JLex uses C-preprocessor style macros, whereas JFlex uses grammar definitions.
Most specifications shouldn’t suffer from this problem, because macros often only contain
(harmless) character classes like alpha = [a-zA-Z] and more dangerous definitions like
ident = {alpha}({alpha}|{digit})*
are only used to write rules like
{ident} { .. action .. }
and not more complex expressions like
{ident}* { .. action .. }
where the kind of error presented above would show up.
8.2 Porting from lex/flex
This section gives an incomplete overview of potential pitfalls and steps for porting a lexical
specification from the C/C++ tools
lex
and
flex
[
8
] available on most Unix systems to JFlex.
42
Most of the C/C++ specific features are naturally not present in JFlex, but most “clean”
lex/flex lexical specifications can be ported to JFlex without too much work.
8.2.1 Basic structure
A lexical specification for flex has the following basic structure:
definitions
%%
rules
%%
user code
The
user code
section usually contains C code that is used in actions of the
rules
part of the
specification. For JFlex, this code will have to be translated to Java, and most of it will then
go into the class code %{..%} directive in the options and declarations section.
8.2.2 Macros and Regular Expression Syntax
The
definitions
section of a flex specification is quite similar to the
options and declarations
part of JFlex specs.
Macro definitions in flex have the form:
<identifier> <expression>
To port them to JFlex macros, just insert a =between <identifier> and <expression>.
The syntax and semantics of regular expressions in flex are pretty much the same as in
JFlex. Some attention is needed for escape sequences present in flex (such as
\a
) that are
not supported in JFlex. These escape sequences should be transformed into their unicode
equivalent.
8.2.3 Character Classes
Flex offers the character classes directly supported by C, JFlex offers the ones supported by
Java. These classes will sometimes have to be listed manually.
In flex more special characters lose their meaning in character classes. In particular2:
•
in flex
[][]
is the character class containing
]
and
[
, whereas in JFlex, the expression
means “empty expression” followed by “empty expression”. To get
]
and
[
in JFlex, use
for instance [\]\[].
•the classes [] and [ˆ] are illegal in flex, but have meaning in JFlex.
•in flex ["] is legal, in JFlex you need [\"].
2Thanks to Dimitri Maziuk for pointing these out.
43
8.2.4 Lexical Rules
Since flex is mostly Unix based, the ’
ˆ
’ (beginning of line) and ’
$
’ (end of line) operators,
consider the
\n
character as only line terminator. This should usually not cause much problems,
but you should be prepared for occurrences of
\r
or
\r\n
or one of the characters
\u2028
,
\u2029
,
\u000B
,
\u000C
, or
\u0085
. They are considered to be line terminators in Unicode and
therefore may not be consumed when ˆor $is present in a rule.
9 Working together
9.1 JFlex and CUP
One of the design goals of JFlex was to make interfacing with the parser generators CUP
[
6
] and CUP2 [
9
] as easy as possible. This has been done by providing the
%cup
and
%cup2
directives in JFlex. However, each interface has two sides. This section concentrates on the
CUP side of the story.
9.1.1 CUP2
Please refer to the CUP2 [
9
] documentation, which provides instructions on how to interface
with JFlex. The CUP2 JFlex patch provided there is not necessary any more for JFlex versions
greater than 1.5.0.
9.1.2 CUP version 0.10j and above
Since CUP version 0.10j, interfacing with JFlex has been simplified greatly by the new
CUP scanner interface
java_cup.runtime.Scanner
. JFlex lexers now implement this interface
automatically when the
%cup
switch is used. There are no special
parser code
,
init code
or
scan with
options any more that you have to provide in your CUP parser specification. You
can just concentrate on your grammar.
If your generated lexer has the class name
Scanner
, the parser is started from the main program
like this:
...
try {
parser p = new parser(new Scanner(new FileReader(fileName)));
Object result = p.parse().value;
}
catch (Exception e) {
...
9.1.3 Custom symbol interface
If you have used the
-symbol
command line switch of CUP to change the name of the generated
symbol interface, you have to tell JFlex about this change of interface so that correct end-of-file
44
code is generated. You can do so either by using an
%eofval{
directive or by using an
<<EOF>>
rule.
If your new symbol interface is called
mysym
for example, the corresponding code in the jflex
specification would be either
%eofval{
return mysym.EOF;
%eofval}
in the macro/directives section of the spec, or it would be
<<EOF>> { return mysym.EOF; }
in the rules section of your spec.
9.1.4 Using existing JFlex/CUP specifications with CUP 0.10j and above
If you already have an existing specification and you would like to upgrade both JFlex and
CUP to their newest version, you will probably have to adjust your specification.
The main difference between the
%cup
switch in JFlex 1.2.1 and lower, and more recent versions
is that JFlex scanners now automatically implement the
java_cup.runtime.Scanner
interface.
This means the scanning function changes its name from yylex() to next_token().
The main difference from older CUP versions to 0.10j is, that CUP now has a default constructor
that accepts a
java_cup.runtime.Scanner
as argument and that uses this scanner as default
(so no scan with code is necessary any more).
If you have an existing CUP specification, it will probably look somewhat like this:
parser code {:
Lexer lexer;
public parser (java.io.Reader input) {
lexer = new Lexer(input);
}
:};
scan with {: return lexer.yylex(); :};
To upgrade to CUP 0.10j, you could change it to look like this:
parser code {:
public parser (java.io.Reader input) {
super(new Lexer(input));
}
:};
If you don’t mind changing the method that is calling the parser, you could remove the
constructor entirely (and if there is nothing else in it, the whole
parser code
section). The
main method calling the parser would then construct the parser as shown in the section above.
The JFlex specification does not need to be changed.
45
9.2 JFlex and BYacc/J
JFlex has built-in support for the Java extension BYacc/J [
7
] by Bob Jamison to the classical
Berkeley Yacc parser generator. This section describes how to interface BYacc/J with JFlex.
It builds on many helpful suggestions and comments from Larry Bell.
Since Yacc’s architecture is a bit different from CUP’s, the interface setup also works in a
slightly different manner. BYacc/J expects a function
int yylex()
in the parser class that
returns each next token. Semantic values are expected in a field
yylval
of type
parserval
where parser is the name of the generated parser class.
For a small calculator example, one could use a setup like the following on the JFlex side:
%%
%byaccj
%{
/* store a reference to the parser object */
private parser yyparser;
/* constructor taking an additional parser object */
public Yylex(java.io.Reader r, parser yyparser) {
this(r);
this.yyparser = yyparser;
}
%}
NUM = [0-9]+ ("." [0-9]+)?
NL = \n | \r | \r\n
%%
/* operators */
"+" |
..
"(" |
")" { return (int) yycharat(0); }
/* newline */
{NL} { return parser.NL; }
/* float */
{NUM} { yyparser.yylval = new parserval(Double.parseDouble(yytext()));
return parser.NUM; }
The lexer expects a reference to the parser in its constructor. Since Yacc allows direct use of
terminal characters like
’+’
in its specifications, we just return the character code for single
char matches (e.g. the operators in the example). Symbolic token names are stored as
public
static int
constants in the generated parser class. They are used as in the
NL
token above.
Finally, for some tokens, a semantic value may have to be communicated to the parser. The
NUM rule demonstrates how.
46
A matching BYacc/J parser specification would look like this:
%{
import java.io.*;
%}
%token NL /* newline */
%token <dval> NUM /* a number */
%type <dval> exp
%left ’-’ ’+’
..
%right ’^’ /* exponentiation */
%%
..
exp: NUM { $$ = $1; }
| exp ’+’ exp { $$ = $1 + $3; }
..
| exp ’^’ exp { $$ = Math.pow($1, $3); }
| ’(’ exp ’)’ { $$ = $2; }
;
%%
/* a reference to the lexer object */
private Yylex lexer;
/* interface to the lexer */
private int yylex () {
int yyl_return = -1;
try {
yyl_return = lexer.yylex();
}
catch (IOException e) {
System.err.println("IO error :"+e);
}
return yyl_return;
}
/* error reporting */
public void yyerror (String error) {
System.err.println ("Error: " + error);
}
/* lexer is created in the constructor */
public parser(Reader r) {
lexer = new Yylex(r, this);
}
/* that’s how you use the parser */
47
public static void main(String args[]) throws IOException {
parser yyparser = new parser(new FileReader(args[0]));
yyparser.yyparse();
}
Here, the customised part is mostly in the user code section. We create the lexer in the
constructor of the parser and store a reference to it for later use in the parser’s
int yylex()
method. This
yylex
in the parser only calls
int yylex()
of the generated lexer and passes the
result on. If something goes wrong, it returns -1 to indicate an error.
Runnable versions of the specifications above are located in the
examples/byaccj
directory of
the JFlex distribution.
9.3 JFlex and Jay
Combining JFlex with the Jay Parser Generator [
10
] is quite simple. The Jay Parser Generator
defines an interface called <parsername>.yyInput. In the JFlex source the directive
%implements <parsername>.yyInput
tells JFlex to generate the corresponding class declaration.
The three interface methods to implement are
•advance()
which should return a boolean that is
true
if there is more work to do and
false if the end of input has been reached,
•token() which returns the last scanned token, and
•value()
which returns an Object that contains the (optional) value of the last read
token.
The following shows a small example with Jay parser specification and corresponding JFlex
code. First of all the Jay code (in a file MiniParser.jay):
%{
//
// Prefix Code like Package declaration,
// imports, variables and the parser class declaration
//
import java.io.*;
import java.util.*;
public class MiniParser
{
%}
// Token declarations, and types of non-terminals
%token DASH COLON
48
%token <Integer> NUMBER
%token <String> NAME
%type <Gameresult> game
%type <Vector<Gameresult>> gamelist
// start symbol
%start gamelist
%%
gamelist: game { $$ = new Vector<Gameresult>();
$<Vector<Gameresult>>$.add($1);
}
| gamelist game { $1.add($2); }
game: NAME DASH NAME NUMBER COLON NUMBER {
$$ = new Gameresult($1, $3, $4, $6); }
%%
// supporting methods part of the parser class
public static void main(String argv[])
{
MiniScanner scanner = new MiniScanner(new InputStreamReader(System.in));
MiniParser parser = new MiniParser();
try {
parser.yyparse (scanner);
} catch (final IOException ioe) {
System.out.println("I/O Exception : " + ioe.toString());
} catch (final MiniParser.yyException ye) {
System.out.println ("Oops : " + ye.toString());
}
}
} // closing brace for the parser class
class Gameresult {
String homeTeam;
String outTeam;
Integer homeScore;
Integer outScore;
public Gameresult(String ht, String ot, Integer hs, Integer os)
{
homeTeam = ht;
outTeam = ot;
homeScore = hs;
outScore = os;
}
}
49
The corresponding JFlex code (MiniScanner.jflex) could be
%%
%public
%class MiniScanner
%implements MiniParser.yyInput
%integer
%line
%column
%unicode
%{
private int token;
private Object value;
// the next 3 methods are required to implement the yyInput interface
public boolean advance() throws java.io.IOException {
value = new String("");
token = yylex();
return (token != YYEOF);
}
public int token() {
return token;
}
public Object value() {
return value;
}
%}
nl = [\n\r]+
ws = [ \t\b\015]+
number = [0-9]+
name = [a-zA-Z]+
dash = "-"
colon = ":"
%%
{nl} { /* do nothing */ }
{ws} { /* happy meal */ }
{name} { value = yytext(); return MiniParser.NAME; }
{dash} { return MiniParser.DASH; }
{colon} { return MiniParser.COLON; }
{number} { try {
value = new Integer(Integer.parseInt(yytext()));
} catch (NumberFormatException nfe) {
// shouldn’t happen
50
throw new Error();
}
return MiniParser.NUMBER;
}
This small example reads an input like
Borussia - Schalke 3:2
ACMilano - Juventus 1:4
10 Bugs and Deficiencies
10.1 Deficiencies
JFlex 1.7.0 conforms with Unicode Regular Expressions UTS#18 [
4
] Basic Unicode Support
Level 1, with a few exceptions - for details see UTS # 18 Conformance (Section 6).
10.2 Bugs
As of 21 September 2018, no major open problems are known for JFlex version 1.7.0.
Please use the JFlex github issue tracker for any problems that have been reported since then.
11 Copying and License
JFlex is free software, published under a BSD-style license.
There is NO WARRANTY for JFlex, its code and its documentation.
See the file COPYRIGHT for more information.
51
References
[1]
Alfred V. Aho, Ravi Sethi, and Jeffrey D. Ullman. Compilers – Principles, Techniques,
and Tools. Addison-Wesley, 1986.
[2] Andrew W. Appel. Modern Compiler Implementation in Java: Basic Techniques. Cam-
bridge University Press, 1998.
[3]
Elliot Berk. JLex: A lexical analyzer generator for Java.
http://www.cs.princeton.edu/
~appel/modern/java/JLex/, 1996.
[4]
Mark Davis and Andy Heninger. Unicode regular expressions.
http://www.unicode.org/
reports/tr18/tr18-17.html, 2013.
[5]
James Gosling, Bill Joy, and Guy Steele. The Java Language Specification. Addison-Wesley,
1996.
[6]
Scott E. Hudson. CUP LALR parser generator for Java.
http://www2.cs.tum.edu/
projects/cup/, 1996.
[7] Bob Jamison. BYacc/J. http://byaccj.sourceforge.net.
[8]
Vern Paxson. flex - the fast lexical analyzer generator.
http://flex.sourceforge.net
,
1995.
[9] Michael Petter. CUP2 user manual. http://www2.in.tum.de/cup2, 2008.
[10]
Axel T. Schreiner. Jay parser generator.
http://www.cs.rit.edu/~ats/projects/lp/doc/
jay/package-summary.html, June 2006.
[11]
Unicode utilities: UnicodeSet.
http://unicode.org/cldr/utility/list-unicodeset.jsp
,
2015.
52
