cplint Manual

SWI-Prolog Version

Fabrizio Riguzzi

fabrizio.riguzzi@unife.it

April 26, 2019

1 Introduction

cplint is a suite of programs for reasoning with LPADs/CP-logic programs [23], [24],

[21], [22]. It contains modules for both inference and learning.

cplint is available in two versions, one for Yap Prolog and one for SWI-Prolog.

They diﬀer slightly in the features oﬀered. This manual is about the SWI-Prolog

version. You can ﬁnd the manual for the Yap version at http://ds.ing.unife.it/

~friguzzi/software/cplint/manual.html.

2 Installation

cplint is distributed as a pack of SWI-Prolog. To install it, use

?- pack_install(cplint).

Moreover, in order to make sure you have a foreign library that matches your archi-

tecture, run

?- pack_rebuild(cplint).

3 Syntax

cplint permits the deﬁnition of discrete probability distributions and continuous

probaility densities.

3.1 Discrete Probability Distributions

LPAD and CP-logic programs consist of a set of annotated disjunctive clauses. Disjunc-

tion in the head is represented with a semicolon and atoms in the head are separated

from probabilities by a colon. For the rest, the usual syntax of Prolog is used. A

general CP-logic clause has the form

h1:p1 ; ... ; hn:pn :- Body.

where Body is a conjunction of goals as in Prolog. No parentheses are necessary. The

pi are numeric expressions. It is up to the user to ensure that the numeric expressions

are legal, i.e. that they sum up to less than one.

If the clause has an empty body, it can be represented like this

h1:p1 ; ... ; hn:pn.

If the clause has a single head with probability 1, the annotation can be omitted and

the clause takes the form of a normal prolog clause, i.e.

h1 :- Body.

stands for

h1:1 :- Body.

The coin example of [24] is represented as (ﬁle coin.pl)

heads(Coin):1/2 ; tails(Coin):1/2 :-

toss(Coin),\+biased(Coin).

heads(Coin):0.6 ; tails(Coin):0.4 :-

toss(Coin),biased(Coin).

fair(Coin):0.9 ; biased(Coin):0.1.

toss(coin).

The ﬁrst clause states that if we toss a coin that is not biased it has equal probability

of landing heads and tails. The second states that if the coin is biased it has a

slightly higher probability of landing heads. The third states that the coin is fair with

probability 0.9 and biased with probability 0.1 and the last clause states that we toss

a coin with certainty.

Moreover, the bodies of rules may contain built-in predicates, predicates from the

libraries lists,apply and clpr/nf_r plus the predicate

average/2

that, given a list of numbers, computes its arithmetic mean.

The body of rules may also contain the predicate prob/2 that computes the probabil-

ity of an atom, thus allowing nested probability computations. For example (meta.pl)

a:0.2:-

prob(b,P),

P>0.2.

is a valid rule.

Moreover, the probabilistic annotations can be variables, as in (flexprob.pl)

red(Prob):Prob.

draw_red(R, G):-

Prob is R/(R + G),

red(Prob).

Variables in probabilistic annotations must be ground when resolution reaches the end

of the body, otherwise an exception is raised.

Alternative ways of specifying probability distribution include

A:discrete(Var,D):-Body.

A:finite(Var,D):-Body.

where Ais an atom containg variable Var and Dis a list of couples Value:Prob assigning

probability Prob to Value. Moreover, you can use

A:uniform(Var,D):-Body.

where Ais an atom containg variable Var and Dis a list of values each taking the same

probability (1 over the length of D).

3.1.1 ProbLog Syntax

You can also use ProbLog [6] syntax, so a general clause takes the form

p1::h1 ; ... ; pn::hn :- Body

where the pi are numeric expressions.

3.1.2 PRISM Syntax

You can also use PRISM [19] syntax, so a program is composed of a set of regular

Prolog rules whose body may contain calls to the msw/2 predicate (multi-ary switch).

A call msw(term,value) means that a random variable associated to term assumes

value value. The admissible values for a discrete random variable are speciﬁed using

facts for the values/2 predicate of the form

values(T,L).

where Tis a term (possibly containing variables) and Lis a list of values. The distri-

bution over values is speciﬁed using directives for set_sw/2 of the form

:- set_sw(T,LP).

where Tis a term (possibly containing variables) and LP is a list of probability val-

ues. Remember that usually in PRISM each call to msw/2 refers to a diﬀerent ran-

dom variable, i.e., no memoing is performed, diﬀerently from the case of LPAD/CP-

Logic/ProbLog. This behavior can be changed with the setting prism_memoization:

if set to true then memoization is performed. Its default value is false, i.e., no

memoization.

For example, the coin example above in PRISM syntax becomes (coinmsw.pl)

values(throw(_),[heads,tails]).

:- set_sw(throw(fair),[0.5,0.5]).

:- set_sw(throw(biased),[0.6,0.4]).

values(fairness,[fair,biased]).

:- set_sw(fairness,[0.9,0.1]).

res(Coin,R):- toss(Coin),fairness(Coin,Fairness),msw(throw(Fairness),R).

fairness(_Coin,Fairness) :- msw(fairness,Fairness).

toss(coin).

3.2 Continuous Probability Densities

cplint handles continuous or integer random variables as well with its sampling infer-

ence module. To specify a probability density on an argument Var of an atom Ayou

can used rules of the form

A:Density:- Body

where Density is a special atom identifying a probability density on variable Var and

Body (optional) is a regular clause body. Allowed Density atoms are

•uniform(Var,L,U):Var is uniformly distributed in [L, U]

•gaussian(Var,Mean,Variance):Var follows a Gaussian distribution with mean

Mean and variance Variance. The distribution can be multivariate if Mean is a

list and Variance a list of lists representing the mean vector and the covariance

matrix. In this case the values of Var are lists of real values with the same length

as that of Mean

•dirichlet(Var,Par):Var is a list of real numbers following a Dirichlet distri-

bution with αparameters speciﬁed by the list Par

•gamma(Var,Shape,Scale) Var follows a gamma distribution with shape param-

eter Shape and scale parameter Scale.

•beta(Var,Alpha,Beta) Var follows a beta distribution with parameters Alpha

and Beta.

•poisson(Var,Lambda) Var follows a Poisson distribution with parameter Lambda

(rate).

•binomial(Var,N,P) Var follows a binomial distribution with parameters N(num-

ber of trials) and P(success probability).

•geometric(Var,P) Var follows a geometric distribution with parameter P(suc-

cess probability).

•exponential(Var,Lambda) Var follows an exponential distribution with param-

eter Lambda (rate, or inverse scale).

•pascal(Var,R,P) Var follows an exponential distribution with parameters R

(number of failures) and P(success probability).

For example

g(X): gaussian(X,0, 1).

states that argument Xof g(X) follows a Gaussian distribution with mean 0 and

variance 1, while

g(X): gaussian(X,[0,0], [[1,0],[0,1]]).

states that argument Xof g(X) follows a Gaussian multivariate distribution with mean

vector [0,0] and covariance matrix

1 0

0 1 

For example, gaussian mixture.pl deﬁnes a mixture of two Gaussians:

heads:0.6;tails:0.4.

g(X): gaussian(X,0, 1).

h(X): gaussian(X,5, 2).

mix(X) :- heads, g(X).

mix(X) :- tails, h(X).

The argument Xof mix(X) follows a distribution that is a mixture of two Gaussian,

one with mean 0 and variance 1 with probability 0.6 and one with mean 5 and variance

2 with probability 0.4.

The parameters of the distribution atoms can be taken from the probabilistic atom,

the example gauss mean est.pl

val(I,X) :-

mean(M),

val(I,M,X).

mean(M): gaussian(M,1.0, 5.0).

val(_,M,X): gaussian(X,M, 2.0).

states that for an index Ithe continuous variable Xis sampled from a Gaussian whose

variance is 2 and whose mean is sampled from a Gaussian with mean 1 and variance

Any operation is allowed on continuous random variables. The example below

(kalman filter.pl) encodes a Kalman ﬁlter:

kf(N,O, T) :-

init(S),

kf_part(0, N, S,O,T).

kf_part(I, N, S,[V|RO], T) :-

I < N,

NextI is I+1,

trans(S,I,NextS),

emit(NextS,I,V),

kf_part(NextI, N, NextS,RO, T).

kf_part(N, N, S, [],S).

trans(S,I,NextS) :-

{NextS =:= E + S},

trans_err(I,E).

emit(NextS,I,V) :-

{NextS =:= V+X},

obs_err(I,X).

init(S):gaussian(S,0,1).

trans_err(_,E):gaussian(E,0,2).

obs_err(_,E):gaussian(E,0,1).

Continuous random variables are involved in arithmetic expressions (in trans/3 and

emit/3). It is often convenient, as in this case, to use CLP(R) constraints (by including

the directive :- use_module(library(clpr)).) as in this way the expressions can be

used in multiple directions and the same clauses can be used both to sample and to

evaluate the weight of the sample on the basis of evidence, otherwise diﬀerent clauses

have to be written. In case random variables are not suﬃciently instantiated to exploit

expressions for inferring the values of other variables, inference will return an error.

Moreover, user deﬁned distributions are allowed with the syntax:

A:user(Var,Density):-Body.

where Var appears in Aand will contain the sampled value and Density is an atom

of the form predicate(Parameters). If predicate in predicate(Parameters) has

arity n, then the user has to deﬁne predicate predicate/n+1 such that

predicate(Parameters,Var)

called with Parameters instantiated, returns in Var a value sampled from the user

deﬁned density. The deﬁnition of predicate/n+1 should appear after :- end_lpad.

If likelihood weighting or particle ﬁltering will be used for inference, then the user has

to deﬁne also predicate predicate/n+2 such that predicate(Parameters,Var,Dens),

when called with Parameters and Var instantiated, returns in Dens the value of

the probability density of Var. The deﬁnition of predicate/n+2 should appear af-

ter :- end_lpad. Moreover, if the density is discrete, the program must include the

fact

disc(predicate).

also after :- end_lpad.

See for example gauss mean est user.pl and binomial user.pl.

3.2.1 Distributional Clauses Syntax

You can also use the syntax of Distributional Clauses (DC) [13]. Continuous random

variables are represented in this case by term whose distribution can be speciﬁed with

density atoms as in

T~Density’ := Body.

Here := replaces the implication symbol, Tis a term and Density’ is one of the density

atoms above without the Var argument, because Titself represents a random variables.

In the body of clauses you can use the inﬁx operator ~= to equate a term representing

a random variable with a logical variable or a constant as in T ~= X. Internally cplint

transforms the terms representing random variables into atoms with an extra argument

for holding the variable. DC can be used to represent also discrete distributions using

T~uniform(L) := Body.

T~finite(D) := Body.

where Lis a list of values and Dis a list of couples P:V with Pa probability and V

a value. If Body is empty, as in regular Prolog, the implication symbol := can be

omitted.

The Indian GPA problem from http://www.robots.ox.ac.uk/~fwood/anglican/

examples/viewer/?worksheet=indian-gpain distributional clauses syntax (https:

//github.com/davidenitti/DC/blob/master/examples/indian-gpa.pl) takes the

form (indian gpadc.pl):

is_density_A:0.95;is_discrete_A:0.05.

% the probability distribution of GPA scores for American students is

% continuous with probability 0.95 and discrete with probability 0.05

agpa(A): beta(A,8,2) :- is_density_A.

% the GPA of American students follows a beta distribution if the

% distribution is continuous

american_gpa(G) : finite(G,[4.0:0.85,0.0:0.15]) :- is_discrete_A.

% the GPA of American students is 4.0 with probability 0.85 and 0.0

% with

% probability 0.15 if the

% distribution is discrete

american_gpa(A):- agpa(A0), A is A0*4.0.

% the GPA of American students is obtained by rescaling the value of

% agpa

% to the (0.0,4.0) interval

is_density_I : 0.99; is_discrete_I:0.01.

% the probability distribution of GPA scores for Indian students is

% continuous with probability 0.99 and discrete with probability

% 0.01

igpa(I): beta(I,5,5) :- is_density_I.

% the GPA of Indian students follows a beta distribution if the

% distribution is continuous

indian_gpa(I): finite(I,[0.0:0.1,10.0:0.9]):- is_discrete_I.

% the GPA of Indian students is 10.0 with probability 0.9 and 0.0

% with

% probability 0.1 if the

% distribution is discrete

indian_gpa(I) :- igpa(I0), I is I0*10.0.

% the GPA of Indian students is obtained by rescaling the value

% of igpa

% to the (0.0,4.0) interval

nation(N) : finite(N,[a:0.25,i:0.75]).

% the nation is America with probability 0.25 and India with

% probability 0.75

student_gpa(G):- nation(a),american_gpa(G).

% the GPA of the student is given by american_gpa if the nation is

% America

student_gpa(G) :- nation(i),indian_gpa(G).

% the GPA of the student is given by indian_gpa if the nation

%is India

See

4 Semantics

The semantics of LPADs for the case of programs without functions symbols can

be given as follows. An LPAD deﬁnes a probability distribution over normal logic

programs called worlds. A world is obtained from an LPAD by ﬁrst grounding it, by

selecting a single head atom for each ground clause and by including in the world the

clause with the selected head atom and the body. The probability of a world is the

product of the probabilities associated to the heads selected. The probability of a

ground atom (the query) is given by the sum of the probabilities of the worlds where

the query is true.

If the LPAD contains function symbols, the deﬁnition is more complex, see [15, 20,

17].

For the semantics of programs with continuous random variables, see [10] that de-

ﬁnes the probability space for Ncontinuous random variables by considering the Borel

σ-algebra over RNand deﬁnes a Lebesgue measure on this set as the probability mea-

sure. The probability space is lifted to cover the entire program using the least model

semantics of constraint logic programs. Alternatively, [13] deﬁnes the semantics of

distributional clauses by resorting to a stochastic T p operator. cplint allows more

freedom than distributional clauses in the use of continuous random variables in expres-

sions, for example kalman filter.pl would not be allowed by distributional clauses.

5 Inference

cplint answers queries using the module pita or mcintyre. The ﬁrst performs the

program transformation technique of [18]. Diﬀerently from that work, techniques

alternative to tabling and answer subsumption are used. The latter performs approx-

imate inference by sampling using a diﬀerent program transformation technique and

is described in [16]. Only mcintyre is able to handle continuous random variables.

For answering queries, you have to prepare a Prolog ﬁle where you ﬁrst load the infer-

ence module (for example pita), initialize it with a directive (for example :- pita) and

then enclose the LPAD clauses in :-begin_lpad. or :-begin_plp. and :-end_lpad.

or :-end_plp. For example, the coin program above can be stored in coin.pl for

performing inference with pita as follows

:- use_module(library(pita)).

:- pita.

:- begin_lpad.

heads(Coin):1/2 ; tails(Coin):1/2:-

toss(Coin),\+biased(Coin).

heads(Coin):0.6 ; tails(Coin):0.4:-

toss(Coin),biased(Coin).

fair(Coin):0.9 ; biased(Coin):0.1.

toss(coin).

:- end_lpad.

The same program for mcintyre is

:- use_module(library(mcintyre)).

:- mc.

:- begin_lpad.

heads(Coin):1/2 ; tails(Coin):1/2:-

toss(Coin),\+biased(Coin).

heads(Coin):0.6 ; tails(Coin):0.4:-

toss(Coin),biased(Coin).

fair(Coin):0.9 ; biased(Coin):0.1.

toss(coin).

:- end_lpad.

You can have also (non-probabilistic) clauses outside :-begin/end_lpad. These are

considered as database clauses. In pita subgoals in the body of probabilistic clauses

can query them by enclosing the query in db/1. For example (testdb.pl)

:- use_module(library(pita)).

:- pita.

:- begin_lpad.

sampled_male(X):0.5:-

db(male(X)).

:- end_lpad.

male(john).

male(david).

You can also use findall/3 on subgoals deﬁned by database clauses (persons.pl)

:- use_module(library(pita)).

:- pita.

:- begin_lpad.

male:M/P; female:F/P:-

findall(Male,male(Male),LM),

findall(Female,female(Female),LF),

length(LM,M),

length(LF,F),

P is F+M.

:- end_lpad.

male(john).

male(david).

female(anna).

female(elen).

female(cathy).

Aggregate predicates on probabilistic subgoals are not implemented due to their high

computational cost (if the aggregation is over natoms, the values of the aggregation

are potentially 2n). The Yap version of cplint includes reasoning algorithms that

allows aggregate predicates on probabilistic subgoals, see http://ds.ing.unife.it/

~friguzzi/software/cplint/manual.html.

In mcintyre you can query database clauses in the body of probabilistic clauses

without any special syntax. You can also use findall/3.

To run a query, you can simply load the Prolog ﬁle, for example coin.pl, as

?- [coin].

Note that supplying coin.pl as an argument to the swipl command currently returns

errors due to bad interaction between pita and the top-level. The program is loaded

correctly anyway but it is recommended to load it from the top-level to avoid these

errors.

5.1 Unconditional Queries

The unconditional probability of an atom can be asked using pita with the predicate

prob(:Query:atom,-Probability:float) is nondet

as in

?- prob(heads(coin),P).

If the query is non-ground, prob/2 returns in backtracking the successful instantiations

together with their probability.

When using mcintyre, the predicate for querying is

mc_prob(:Query:atom,-Probability:float,+Options:list) is det

where Options is a list of options, the following are recognised by mc_prob/3:

•bar(-BarChar:dict) BarChart is a dict for rendering with c3 as a bar chart

with a bar for the number of successes and a bar for the number of failures.

For example

?- mc_prob(heads(coin),P,[]).

You can also use

mc_prob(:Query:atom,-Probability:float) is det

which is equivalent to mc_prob/3 with an empty option list. In general, all the predi-

cates that admit a list of options as an argument have a corresponding version without

the list of options that is equivalente to calling the ﬁrst with an empty option list.

With mcintyre, you can also take a given number of samples with

mc_sample(:Query:atom,+Samples:int,-Probability:float,

Options:list) is det

where Options is a list of options, the following are recognised by mc_sample/4:

•successes(-Successes:int) Number of succesess

•failures(-Failures:int) Number of failures

•bar(-BarChar:dict) BarChart is a dict for rendering with c3 as a bar chart

with a bar for the number of successes and a bar for the number of failures.

For example (coinmc.pl)

?- mc_sample(heads(coin),1000,P,[successes(S),failures(F)]).

that samples heads(coin) 1000 times and returns in Sthe number of successes, in

Fthe number of failures and in Pthe estimated probability (S/1000). As another

example, the call

?- mc_sample(heads(coin),1000,Prob).

samples heads(coin) 1000 times and returns the estimated probability that a sample

is true.

You can also sample using Gibbs sampling with

mc_gibbs_sample(:Query:atom,+Samples:int,-Probability:float,

+Options:list) is det

where Options is a list of options, the following are recognised by mc_gibbs_sample/4:

•block(+Block:int) Perform blocked Gibbs: Block variables are sampled to-

gether, default value 1

•mix(+Mix:int) The ﬁrst Mix samples are discarded (mixing time), default value

•successes(-Successes:int) Number of succesess

•failures(-Failures:int) Number of failures

mc_gibbs_sample/3 is equivalent to mc_gibbs_sample/4 with an empty option list.

Moreover, you can sample arguments of queries with

mc_sample_arg(:Query:atom,+Samples:int,?Arg:var,

-Values:list,+Options:list) is det

The predicate samples Query a number of Samples times. Arg should be a variable

in Query. The predicate returns in Values a list of couples L-N where Lis the list of

values of Arg for which Query succeeds in a world sampled at random and Nis the

number of samples returning that list of values. If Lis the empty list, it means that

for that sample the query failed. If Lis a list with a single element, it means that for

that sample the query is determinate. If, in all couples L-N,Lis a list with a single

element, it means that the clauses in the program are mutually exclusive, i.e., that in

every sample, only one clause for each subgoal has the body true. This is one of the

assumptions taken for programs of the PRISM system [20]. For example pcfglr.pl

and plcg.pl satisfy this constraint while markov chain.pl and var obj.pl doesn’t.

Options is a list of options, the following are recognised by mc_sample_arg/5:

•successes(-Successes:int) Number of succeses

•failures(-Failures:int) Number of failueres

•bar(-BarChar:dict) BarChart is a dict for rendering with c3 as a bar chart

with with a bar for each possible value of L, the list of values of Arg for which

the query succeeds in a world sampled at random. The size of the bar is the

number of samples returning that list of values.

An example of use of mc_sample_arg/4 is

?- mc_sample_arg(reach(s0,0,S),50,S,Values).

of markov chain.pl that takes 50 samples of Lin findall(S,(reach(s0,0,S),L).

You can sample arguments of queries also with

mc_sample_arg_raw(:Query:atom,+Samples:int,?Arg:var,

-Values:list) is det

that samples Query a number of Samples times The predicate returns in Values a list

of values of Arg returned as the ﬁrst answer by Query in a world sampled at random.

The value is failure if the query fails.

The predicate

mc_sample_arg_first(:Query:atom,+Samples:int,?Arg:var,

-Values:list,+Options:list) is det

samples Query a number of Samples times and returns in Values a list of couples V-N

where Vis the value of Arg returned as the ﬁrst answer by Query in a world sampled

at random and Nis the number of samples returning that value. Vis failure if the

query fails. mc_sample_arg_first/5 diﬀers from mc_sample_arg/5 because the ﬁrst

just computes the ﬁrst answer of the query for each sampled world.

Options is a list of options, the following are recognised by mc_sample_arg_first/5:

•bar(-BarChar:dict) BarChart has a bar for each value of Arg returned as a

ﬁrst answer for the query in a world sampled at random. The size of the bar is

the number of samples that returned that value.

The predicate

mc_sample_arg_one(:Query:atom,+Samples:int,?Arg:var,

-Values:list,+Options:list) is det

samples Query a number of Samples times and returns in Values a list of couples V-N

where Vis a value sampled with uniform probability from those returned by Query in

a world sampled at random and Nis the number of samples returning that value. Vis

failure if the query fails.

Options is a list of options, the following are recognised by mc_sample_arg_one/5:

•bar(-BarChar:dict) BarChart has a bar for each value of Arg returned by

sampling with uniform probability one answer from those returned by the query

in a world sampled at random. The size of the bar is the number of samples.

The predicate

mc_gibbs_sample_arg(:Query:atom,+Samples:int,?Arg:var,-

Values:list,+Options:list) is det

samples an argument of the query using Gibbs sampling. The same options as those

of mc_gibbs_sample/4 are recognized.

Finally, you can compute expectations with

mc_expectation(:Query:atom,+N:int,?Arg:var,-Exp:float) is det

that computes the expected value of Arg in Query by sampling. It takes Nsamples of

Query and sums up the value of Arg for each sample. The overall sum is divided by N

to give Exp.

An example of use of the above predicate is

?- mc_expectation(eventually(elect,T),1000,T,E).

of pctl slep.pl that returns in Ethe expected value of Tby taking 1000 samples.

The predicate

mc_gibbs_expectation(:Query:atom,+N:int,?Arg:var,

-Exp:float) is det

computes an expectation with Gibbs sampling.

5.1.1 Drawing BDDs

With pita, you can obtain the BDD for a query with the predicates

bdd_dot_file(:Query:atom,+FileName:string,-Var:list) is nondet

bdd_dot_string(:Query:atom,-DotString:string,-Var:list) is nondet

The ﬁrst write the BDD to a ﬁle, the latter returns it as a string. The BDD is

represented in the dot format of graphviz. Solid edges indicate 1-children, dashed

edges indicate 0-children and dotted edges indicate 0-children with negation applied

to the sub BDD. Each level of the BDD is associated to a variable of the form XI J

indicated on the left: I indicates the multivalued variable index and J the index of

the Boolean variable of rule I. The hexadecimal number in each node is part of its

address in memory and is not signiﬁcant. The table Var contains the associations

between the rule groundings and the multivalued variables: the ﬁrst column contains

contains the multivalued variable index, the second column contains the rule index,

corresponding to its position in the program, and the last column contains the list of

constants grounding the rule, each replacing a variable in the order of appearance in

the rule.

The BDD can be drawn in cplint on SWISH by using the graphviz renderer by

including

:- use_rendering(graphviz).

before :- pita.

For example (coin.pl)

?- bdd_dot_string(heads(coin),BDD,Var).

returns the BDD for the query heads(coin) and the list of associations between rule

groundings and multivalued variables.

5.2 Conditional Queries on Discrete Variables

The conditional probability of an atom query given another atom evidence can be

asked using pita with the predicate

prob(:Query:atom,:Evidence:atom,-Probability:float) is nondet

as in

?- prob(heads(coin),biased(coin),P).

If the query/evidence are non-ground, prob/3 returns in backtracking ground instanti-

ations together with their probability. The query and the evidence can be conjunctions

of literals (positive or negative).

You also have

prob(:Query:atom,:Evidence:atom,-Probability:float,

+Options:list) is nondet

where Options is a list of options, the following are recognised by prob/4:

•bar(-BarChar:dict) BarChart is a dict for rendering with c3 as a bar chart

with a bar for the number of successes and a bar for the number of failures.

as in

?- prob(heads(coin),biased(coin),P,[bar(Chart)}).

prob/3 is equivalent to prob/4 with an empty option list.

When using mcintyre, you can ask conditional queries with rejection sampling,

Metropolis-Hastings Markov Chain Monte Carlo or Gibbs sampling. In rejection sam-

pling [25], you ﬁrst query the evidence and, if the query is successful, query the goal in

the same sample, otherwise the sample is discarded. In Metropolis-Hastings MCMC,

mcintyre follows the algorithm proposed in [12] (the non adaptive version). A Markov

chain is built by building an initial sample and by generating successor samples.

The initial sample is built by randomly sampling choices so that the evidence is

true. This is done with a backtracking meta-interpreter that starts with the goal and

randomizes the order in which clauses are selected during the search so that the initial

sample is unbiased. Each time the meta-interpreter encounters a probabilistic choice,

it ﬁrst checks whether a value has already been sampled, if not, it takes a sample and

records it. If a failure is obtained, the meta-interpreter backtracks to other clauses but

without deleting samples. Then the goal is queries using regular MCINTYRE.

A successor sample is obtained by deleting a ﬁxed number (parameter Lag) of sam-

pled probabilistic choices. Then the evidence is queried using regular MCINTYRE

starting with the undeleted choices. If the query succeeds, the goal is queried using

regular MCINTYRE. The sample is accepted with a probability of min{1,N0

N1}where

N0is the number of choices sampled in the previous sample and N1is the number of

choices sampled in the current sample. In [12] the lag is always 1 but the proof in [12]

that the above acceptance probability yields a valid Metropolis-Hastings algorithm

holds also when forgetting more than one sampled choice, so the lag is user deﬁned in

cplint.

Then the number of successes of the query is increased by 1 if the query succeeded

in the last accepted sample. The ﬁnal probability is given by the number of successes

over the total number of samples.

You can take a given number of sample with rejection sampling using

mc_rejection_sample(:Query:atom,:Evidence:atom,+Samples:int,

-Probability:float,+Options:list) is det

where Options is a list of options, the following are recognised by mc_sample_arg/5:

•successes(-Successes:int) Number of succeses

•failures(-Failures:int) Number of failueres

as in (coinmc.pl)

?- mc_rejection_sample(heads(coin),biased(coin),1000,P,

[successes(S),failures(F)]).

that takes 1000 samples where biased(coin) is true and returns in Sthe number of

samples where heads(coin) is true, in Fthe number of samples where heads(coin)

is false and in Pthe estimated probability (S/1000).

The query and the evidence can be conjunctions of literals.

You can take a given number of sample with Metropolis-Hastings MCMC using

mc_mh_sample(:Query:atom,:Evidence:atom,+Samples:int,

-Probability:float,+Options:list) is det

where Lag (that is set with the options, default value 1) is the number of sampled

choices to forget before taking a new sample.

Options is a list of options, the following are recognised by mc_mh_sample/5:

•mix(+Mix:int) The ﬁrst Mix samples are discarded (mixing time), default value

•lag(+Lag:int) lag between each sample, Lag sampled choices are forgotten,

default value 1

•successes(-Successes:int) Number of succeses

•failures(-Failures:int) Number of failueres

•bar(-BarChar:dict) BarChart is a dict for rendering with c3 as a bar chart

with a bar for the number of successes and a bar for the number of failures.

With Mix speciﬁed it takes Mix+Samples samples and discards the ﬁrst Mix.

For example (arithm.pl)

?- mc_mh_sample(eval(2,4),eval(1,3),10000,P,

[successes(T), failures(F)]).

takes 10000 accepted samples and returns in Tthe number of samples where eval(2,4)

is true, in Fthe number of samples where eval(2,4) is false and in Pthe estimated

probability (T/10000).

The predicate

mc_gibbs_sample(:Query:atom,:Evidence:atom,+Samples:int,

-Probability:float,+Options:list) is det

performs Gibbs sampling. Options is a list of options, the following are recognised by

mc_gibbs_sample/5:

•block(+Block:int) Perform blocked Gibbs: Block variables are sampled to-

gether, default value 1

•mix(+Mix:int) The ﬁrst Mix samples are discarded (mixing time), default value

•successes(-Successes:int) Number of succesess

•failures(-Failures:int) Number of failures

Moreover, you can sample arguments of queries with rejection sampling, Metropolis-

Hastings MCMC or Gibbs sampling using

mc_rejection_sample_arg(:Query:atom,:Evidence:atom,

+Samples:int,?Arg:var,-Values:list,+Options:list) is det

mc_mh_sample_arg(:Query:atom,:Evidence:atom,

+Samples:int,?Arg:var,-Values:list,+Options:list) is det

mc_gibbs_sample_arg(:Query:atom,+Samples:int,

?Arg:var,-Values:list,+Options:list) is det

that return the distribution of values for Arg in Query in Samples of Query given that

Evidence is true. Options is a list of options, the following are recognised:

•mix(+Mix:int) The ﬁrst Mix samples are discarded (mixing time), default value

0 (only MH and GIbbs)

•lag(+Lag:int) lag between each sample, Lag sampled choices are forgotten,

default value 1 (only MH)

•block(+Block:int) Perform blocked Gibbs: Block variables are sampled to-

gether, default value 1 (only Gibbs)

•bar(-BarChar:dict) BarChart is a bar chart of the possible values

The predicates return in Values a list of couples L-N where Lis the list of values of

Arg for which Query succeeds in a world sampled at random where Evidence is true

and Nis the number of samples returning that list of values.

mc_gibbs_sample_arg(:Query:atom,+Samples:int,

?Arg:var,-Values:list,+Options:list) is det

An example of use of the above predicates is

?- mc_mh_sample_arg(eval(2,Y),eval(1,3),1000,Y,V,[]).

of arithm.pl.

To compute conditional expectations, use

mc_rejection_expectation(:Query:atom,:Evidence:atom,+N:int,

?Arg:var,-Exp:float) is det

mc_mh_expectation(:Query:atom,:Evidence:atom,+N:int,

?Arg:var,-Exp:float,+Options:list) is det

mc_gibbs_expectation(:Query:atom,:Evidence:atom,+N:int,

?Arg:var,-Exp:float,+Options:list) is det

where Options is a list of options, the same as those of the predicates for conditional

argument sampling are recognised. For example

?- mc_mh_expectation(eval(2,Y),eval(1,3),1000,Y,E,[]).

of arithm.pl computes the expectation of argument Yof eval(2,Y) given that eval(1,3)

is true by taking 1000 samples using Metropolis-Hastings MCMC.

Note that conditional inference is not allowed for PRISM programs with the setting

prism_memoization set to false, as sampled values are not stored in that case and

conditioning would have no eﬀect.

5.3 Conditional Queries on Continuous Variables

When you have continuous random variables, you may be interested in sampling argu-

ments of goals representing continuous random variables. In this way you can build a

probability density of the sampled argument. When you do not have evidence or you

have evidence on atoms not depending on continuous random variables, you can use

the above predicates for sampling arguments.

For example

?- mc_sample_arg(val(0,X),1000,X,L).

from (gauss mean est.pl)) samples 1000 values for Xin value(0,X) and returns them

in L.

When you have evidence on ground atoms that have continuous values as arguments,

you cannot use rejection sampling or Metropolis-Hastings, as the probability of the

evidence is 0. For example, the probability of sampling a speciﬁc value from a Gaussian

is 0. Continuous variables have probability densities instead of distributions as discrete

variables. In this case, you can use likelihood weighting or particle ﬁltering [9, 11, 13]

to obtain samples of continuous arguments of a goal.

For each sample to be taken, likelihood weighting uses a meta-interpreter to ﬁnd a

sample where the goal is true, randomizing the choice of clauses when more than one

resolves with the goal in order to obtain an unbiased sample. This meta-interpreter is

similar to the one used to generate the ﬁrst sample in Metropolis-Hastings.

Then a diﬀerent meta-interpreter is used to evaluate the weight of the sample. This

meta-interpreter starts with the evidence as the query and a weight of 1. Each time the

meta-interpreter encounters a probabilistic choice over a continuous variable, it ﬁrst

checks whether a value has already been sampled. If so, it computes the probability

density of the sampled value and multiplies the weight by it. If the value has not been

sampled, it takes a sample and records it, leaving the weight unchanged. In this way,

each sample in the result has a weight that is 1 for the prior distribution and that may

be diﬀerent from the posterior distribution, reﬂecting the inﬂuence of evidence.

In particle ﬁltering, the evidence is a list of atoms. Each sample is weighted by the

likelihood of an element of the evidence and constitutes a particle. After weighting,

particles are resampled and the next element of the evidence is considered.

The predicate

mc_lw_sample(:Query:atom,:Evidence:atom,+Samples:int,

-Prob:float) is det

samples Query a number of Samples times given that Evidence (a conjunction of

atoms is allowed here) is true. The predicate returns in Prob the probability that

the query is true. It performs likelihood weighting: each sample is weighted by the

likelihood of evidence in the sample. For example

?- mc_lw_sample(nation(a),student_gpa(4.0),1000,P).

from indian gpa.pl samples 1000 times the query nation(a) given that student_gpa(4.0)

has been observed.

The predicate

mc_lw_sample_arg(:Query:atom,:Evidence:atom,+N:int,?Arg:var,

-ValList) is det

returns in ValList a list of couples V-W where Vis a value of Arg for which Query

succeeds and Wis the weight computed by likelihood weighting according to Evidence

(a conjunction of atoms is allowed here). For example

?- mc_lw_sample_arg(val(0,X),(val(1,9),val(2,8)),100,X,L).

from gauss mean est.pl samples 100 values for Xin val(0,X) given that val(1,9)

and val(2,8) have been observed.

You can compute conditional expectations using likelihood weighting with

mc_lw_expectation(:Query:atom,Evidence:atom,+N:int,?Arg:var,

-Exp:float) is det

that computes the expected value of Arg in Query given that Evidence is true. It takes

Nsamples of Arg in Query, weighting each according to the evidence, and returns their

weighted average.

The predicate

mc_particle_sample_arg(:Query:atom,+Evidence:list,

+Samples:int,?Arg:var,-Values:list) is det

samples argument Arg of Query using particle ﬁltering given that Evidence is true.

Evidence is a list of goals and Query can be either a single goal or a list of goals. When

Query is a single goal, the predicate returns in Values a list of couples V-W where Vis

a value of Arg for which Query succeeds in a particle in the last set of particles and Wis

the weight of the particle. For each element of Evidence, the particles are obtained by

sampling Query in each current particle and weighting the particle by the likelihood

of the evidence element.

When Query is a list of goals, Arg is a list of variables, one for each query of Query

and Arg and Query must have the same length of Evidence.Values is then list of

the same length of Evidence and each of its elements is a list of couples V-W where V

is a value of the corresponding element of Arg for which the corresponding element of

Query succeeds in a particle and Wis the weight of the particle. For each element of

Evidence, the particles are obtained by sampling the corresponding element of Query

in each current particle and weighting the particle by the likelihood of the evidence

element.

For example

?-[O1,O2,O3,O4]=[-0.133, -1.183, -3.212, -4.586],

mc_particle_sample_arg([kf_fin(1,T1),kf_fin(2,T2),kf_fin(3,T3),

kf_fin(4,T4)],

[kf_o(1,O1),kf_o(2,O2),kf_o(3,O3),kf_o(4,O4)],100,

[T1,T2,T3,T4],[F1,F2,F3,F4]).

from kalman filter.pl performs particle ﬁltering for a Kalman ﬁlter with four obser-

vations. For each observation, the value of the state at the same time point is sampled.

The list of samples is returned in [F1,F2,F3,F4], with each element being the sample

for a time point.

The predicate

mc_particle_sample(:Query:atom,:Evidence:list,

+Samples:int,-Prob:float) is det

samples Query a number of Samples times given that Evidence is true using particle

ﬁltering. Evidence is a list of goals. The predicate returns in Prob the probability

that the query is true.

You can compute conditional expectations using particle ﬁltering with

mc_particle_expectation(:Query:atom,Evidence:atom,+N:int,

?Arg:var,-Exp:float) is det

that computes the expected value of Arg in Query given that Evidence is true. It uses

Nparticles.

5.4 Causal Inference

pita and mcintyre support causal reasoning, i.e., computing the eﬀect of actions using

the do-calculus [14].

Actions in this setting are represented as literals of action predicates, that must be

declared as such with the directive

:- action predicate1/arity1,...,predicaten/arityn.

When performing causal reasoning, action literals must be enclosed in the do/1 functor

and included in the evidence conjunction. More than one action can be included (each

with in a separate do/1 term) and actions and observations can be freely mixed. All

conditional inference goals can be used except those for particle ﬁltering.

For example

?- prob(recovery,do(drug),P).

from simpson.swinb computes the probability of recovery of a patient given that the

action of administering a drug has been performed.

5.5 Graphing the Results

In cplint on SWISH you can draw graphs for visualizing the results either with C3.js

or with R. Similar predicates are avaiiable for the two methods. There are two types of

graphs: those that represent individual probability values with a bar chart and those

that visualize the results of sampling arguments.

5.5.1 Using C3.js

You can draw the probability of a query being true and being false as a bar chart using

the predicates

bar1(+Probability:float,-Chart:dict) is det

bar(+Probability:float,-Chart:dict) is det

bar(+Successes:int,+Failures:int,-Chart:dict) is det

argbar(+Values:list,-Chart:dict) is det

They return a dict for rendering with C3.js as a bar chart: the ﬁrst returns bar chart

with a single bar for the probability, the second a chart with bar for the probability

and a bar for one minus the probability, the third a chart with a bar for the number

of successes and a bar for the number of failures, and the fourth a chart with a for

bar each value, where Values is a list of couples V-N where Vis the value and Nis the

number of samples returning that value.

To render C3.js charts you have to include

:- use_rendering(c3).

before :- pita.

You can also use the bar(-Chart:dict) option of many predicates as in

?- prob(heads(coin),biased(coin),P,[bar(Chart)]).

Pwill be instantiated with a chart with a bar for the probability of heads(coin) true

and a bar for the probability of heads(coin) false, given that biased(coin) is true.

Another example is

?- mc_prob(heads(coin),P,[bar(Chart)]).

that returns a chart representation of the probability.

?- mc_sample(heads(coin),1000,P,[bar(Chart)]).

returns in Chart a diagram with one bar for the number of successes and one bar for

the number of failures.

The options of mc_sample_arg/5,mc_sample_arg_first/5,mc_mh_sample_arg/6,

mc_rejection_sample_arg/6, can be used for visualizing the results of sampling ar-

guments.

An example is

?- mc_sample_arg(reach(s0,0,S),50,S,ValList,[bar(Chart)]).

of markov chain.pl.

The same result can be achieved with

?- mc_sample_arg(reach(s0,0,S),50,S,ValList),argbar(ValList,Chart)

Drawing a graph is particularly interesting when sampling values for continuous argu-

ments of goals. In this case, you can use the samples to draw the probability density

function of the argument. The predicate

histogram(+List:list,-Chart:dict,+Options:list) is det

draws a histogram of the samples in List that must be a list of couples of the form

[V]-W or V-W where Vis a sampled value and Wis its weight. This is the format of the

list of samples returned by argument sampling predicates.

The predicate

density(+List:list,-Chart:dict,+Options:list) is det

draws a line chart of the density of the samples in List that must take the same form

as for histogram/3.

In histogram/3 and density/3 Options is a list of options, the following are recog-

nised:

•min(+Min:float) the minimum value of domain, default value the minimum in

List

•max(+Max:float) the maximum value of domain, default value the maximum in

List

•nbins(+NBins:int) the number of bins for dividing the domain, default value

In this way you can specify the limits and the number of intervals of the X.

The predicate

densities(+PriorList:list,+PostList:list,-Chart:dict,

+Options:list) is det

draws a line chart of the density of two sets of samples, usually prior and post ob-

servations. The samples in PriorList and PostList can be either couples [V]-W or

V-W where Vis a value and Wits weight. The same options as for histogram/3 and

density/3 are recognized.

For example, the query

?- mc_sample_arg(value(0,X),1000,X,L0,[]),

histogram(L0,Chart,[]).

from gauss mean est.pl, takes 1000 samples of argument Xof value(0,X) and draws

the density of the samples using an histogram.

Instead

?- mc_sample_arg(value(0,Y),1000,Y,L0,[]),

mc_lw_sample_arg(value(0,X),

(value(1,9),value(2,8)),1000,X,L),

densities(L0,L,Chart).

from gauss mean est.pl takes 1000 amples of argument Xof value(0,X) before and

after observing (value(1,9),value(2,8) and draws the prior and posterior densities

of the samples using a line chart.

Predicates histogram/3,density/3 and densities/4 each have a version with one

argument less that is equivalent to the predicate called with an empty option list.

5.5.2 Using R

You have to load library cplint r (a SWI-Prolog pack) with

:- use_module(library(cplint_r)).

Then you can use predicates

bar_r/1

bar_r/2

argbar_r/1

that work as their C3.js counterpart but do not return the graph as an argument as

the graph is printed with a diﬀerent mechanism.

You also have

histogram_r(+List:list,+Options:list) is det

that works as histogram/3.

density_r(+List:list) is det

is like density/3 with the number of bins is determined by R.

densities_r(+PriorList:list,+PostList:list) is det

is like densities/3 with the number of bins is determined by R.

See gauss mean est R.pl for an example of use of these predicates.

5.6 Parameters

The inference modules have a number of parameters in order to control their behavior.

They can be set with the directive

:- set_pita(<parameter>,<value>).

:- set_mc(<parameter>,<value>).

after initialization (:-pita. or :-mc.) but outside :-begin/end_lpad. The current

value can be read with

?- setting_pita(<parameter>,Value).

?- setting_mc(<parameter>,Value).

from the top-level. The available parameters common to both pita and mcintyre are:

•epsilon_parsing: if (1 - the sum of the probabilities of all the head atoms)

is larger than epsilon_parsing, then pita adds the null event to the head.

Default value 0.00001.

•single_var: determines how non ground clauses are treated: if true, a single

random variable is assigned to the whole non ground clause, if false, a diﬀerent

random variable is assigned to every grounding of the clause. Default value

false.

Moreover, pita has the parameters

•depth_bound: if true, the depth of the derivation of the goal is limited to the

value of the depth parameter. Default value false.

•depth: maximum depth of derivations when depth_bound is set to true. Default

value 5.

•prism_memoization:false: original prism semantics, true: semantics with

memoization

If depth_bound is set to true, derivations are depth-bounded so you can query also

programs containing inﬁnite loops, for example programs where queries have an inﬁnite

number of explanations. However the probability that is returned is guaranteed only

to be a lower bound, see for example markov chaindb.pl

mcintyre has the parameters

•min_error: minimal width of the binomial proportion conﬁdence interval for the

probability of the query. When the conﬁdence interval for the probability of the

query is below min_error, the computation stops. Default value 0.01.

•k: the number of samples to take before checking whether the the binomial pro-

portion conﬁdence interval is below min_error. Default value 1000.max_samples:

the maximum number of samples to take. This is used when the probability of

the query is very close to 0 or 1. In fact mcintyre also checks for the valid-

ity of the the binomial proportion conﬁdence interval: if less than 5 failures or

successes are sampled, even if the width of the conﬁdence interval is less than

min_error, the computation continues. This would lead to non-termination in

cases where the probability is 0 or 1. max_samples ensures termination. Default

value 10e4.

•prism_memoization:false: original prism semantics, true: semantics with

memoization

The example markov chain.pl shows that mcintyre can perform inference in presence

of an inﬁnite number of explanations for the goal. Diﬀerently from pita, no depth

bound is necessary, as the probability of selecting the inﬁnite computation branch

is 0. However, also mcintyre may not terminate if loops not involving probabilistic

predicates are present.

If you want to set the seed of the random number generator, you can use SWI-Prolog

predicates setrand/1 and getrand/1, see SWI-Prolog manual.

5.7 Tabling

You can also use tabling in inference to speed up the computation and/or avoid loops,

see the SWI-Prolog manual.

To do so you have to use the tabling library module and declare some of the pred-

icates as tabled. The tabling declarations go after the :-pita. or :- mc. directives.

For example, to compute the probability of paths in undirected graphs you can use

the program (path tabling.swinb)

:- use_module(library(pita)).

:- use_module(library(tabling)).

:- pita.

:- table path/2.

:- begin_lpad.

path(X,X).

path(X,Y):-

path(X,Z),edge(Z,Y).

edge(X,Y):-arc(X,Y).

edge(X,Y):-arc(Y,X).

arc(a,b):0.2.

arc(b,e):0.5.

arc(a,c):0.3.

arc(c,d):0.4.

arc(d,e):0.4.

arc(a,e):0.1.

:- end_lpad.

Then you can compute the probability that aand eare connected with

prob(path(a,e),Prob).

This programs has loops so if you run the above query without tabling pita would

loop forever.

You can use tabling with both pita and mcintyre.

6 Learning

The following learning algorithms are available:

•EMBLEM (EM over Bdds for probabilistic Logic programs Eﬃcient Mining):

an implementation of EM for learning parameters that computes expectations

directly on BDDs [3], [1], [2]

•SLIPCOVER (Structure LearnIng of Probabilistic logic programs by searChing

OVER the clause space): an algorithm for learning the structure of programs by

searching the clause space and the theory space separately [4]

•LEMUR (LEarning with a Monte carlo Upgrade of tRee search): an algorithm

for learning the structure of programs by searching the clase space using Monte-

Carlo tree search [8]

6.1 Input

To execute the learning algorithms, prepare a Prolog ﬁle divided in ﬁve parts

•preamble

•background knowledge, i.e., knowledge valid for all interpretations

•LPAD/CPL-program for you which you want to learn the parameters (optional)

•language bias information

•example interpretations

The preamble must come ﬁrst, the order of the other parts can be changed.

For example, consider the Bongard problems of [7]. bongard.pl and bongardkeys.pl

represent a Bongard problem for SLIPCOVER. bongard.pl and bongardkeys.pl rep-

resent a Bongard problem for LEMUR.

6.1.1 Preamble

In the preamble, the SLIPCOVER library is loaded with (see bongard.pl):

:- use_module(library(slipcover)).

Now you can initialize SLIPCOVER with

:- sc.

At this point you can start setting parameters for SLIPCOVER such as for example

:- set_sc(megaex_bottom,20).

:- set_sc(max_iter,2).

:- set_sc(max_iter_structure,5).

:- set_sc(verbosity,1).

We will see later the list of available parameters.

In the preamble, the LEMUR library is loaded with (see bongard.pl):

:- use_module(library(lemur)).

Now you can initialize LEMUR with

:- lemur.

At this point you can start setting parameters for LEMUR such as for example

:- set_lm(verbosity,1).

A parameter that is particularly important for both SLIPCOVER and LEMUR is

verbosity: if set to 1, nothing is printed and learning is fastest, if set to 3 much

information is printed and learning is slowest, 2 is in between. This ends the preamble.

6.1.2 Background and Initial LPAD/CPL-program

Now you can specify the background knowledge with a fact of the form

bg(<list of terms representing clauses>).

where the clauses must be deterministic. Alternatively, you can specify a set of clauses

by including them in a section between :- begin_bg. and :- end_bg. For example

:- begin_bg.

replaceable(gear).

replaceable(wheel).

replaceable(chain).

not_replaceable(engine).

not_replaceable(control_unit).

component(C):-

replaceable(C).

component(C):-

not_replaceable(C).

:- end_bg.

from the mach.pl example. If you specify both a bg/1 fact and a section, the clauses

of the two will be combined.

Moreover, you can specify an initial program with a fact of the form

in(<list of terms representing clauses>).

The initial program is used in parameter learning for providing the structure. Remem-

ber to enclose each clause in parentheses because :- has the highest precedence.

For example, bongard.pl has the initial program

in([(pos:0.197575 :-

circle(A),

in(B,A)),

(pos:0.000303421 :-

circle(A),

triangle(B)),

(pos:0.000448807 :-

triangle(A),

circle(B))]).

Alternatively, you can specify an input program in a section between :- begin_in.

and :- end_in., as for example

:- begin_in.

pos:0.197575 :-

circle(A),

in(B,A).

pos:0.000303421 :-

circle(A),

triangle(B).

pos:0.000448807 :-

triangle(A),

circle(B).

:- end_in.

If you specify both a in/1 fact and a section, the clauses of the two will be combined.

The annotations of the head atoms of the initial program can be probabilities, as

in the example above, in this case the parameters do not matter as they are ﬁrst

randomized. The type of randomization depends on the setting alpha. If it takes value

0, a truncated Dirichlet process is used to initialize the parameters: the probability

of being true of each Boolean random variable used to represent multivalued random

variables is sampled and independently uniformly in [0,1].

If it takes a value ≥0, the parameters are sampled from a symmetric Dirichlet

distribution, i.e. a Dirichlet distribution with vector of parameters (α, . . . , α).

The annotations of the head atoms of the initial program can also be p(<prob>)

with <prob> a probability, in this case the parameter is ﬁxed so it is not tuned by

learning, as in

in([(pos:0.5 :-

circle(A),

in(B,A)),

(pos:p(0.5) :-

circle(A),

triangle(B))]).

The annotations of the head atoms of the initial program can also be t(<prob>,<args>)

with <prob> either a probability, in this case it is the initial value of the parameter,

or a variable, in this case the parameter is initially randomized, and <args> a tuple of

variables that also appear in the clause. In this case a diﬀerent parameter is learned

for every grounding of <args> that make the body true.

For example, we can set the initial value of the parameter of the second clause to

0.9 with

in([(pos:0.5 :-

circle(A),

in(B,A)),

(pos:t(0.9) :-

circle(A),

triangle(B))]).

With the program below we learn a diﬀerent parameter for every instantiation of Cin

the second clause:

in([(pos:0.5 :-

circle(A),

in(_B,A)),

(pos:t(_,C) :-

triangle(A),

config(A,C))]).

6.1.3 Language Bias

The language bias part contains the declarations of the input and output predicates.

Output predicates are declared as

output(<predicate>/<arity>).

and indicate the predicate whose atoms you want to predict. Derivations for the atoms

for this predicates in the input data are built by the system. These are the predicates

for which new clauses are generated.

Input predicates are those whose atoms you are not interested in predicting. You

can declare closed world input predicates with

input_cw(<predicate>/<arity>).

For these predicates, the only true atoms are those in the interpretations and those

derivable from them using the background knowledge, the clauses in the input or in the

hypothesized program are not used to derive atoms for these predicates. Moreover,

clauses of the background knowledge that deﬁne closed world input predicates and

that call an output predicate in the body will not be used for deriving examples.

Open world input predicates are declared with

input(<predicate>/<arity>).

In this case, if a subgoal for such a predicate is encountered when deriving a subgoal

for the output predicates, both the facts in the interpretations, those derivable from

them and the background knowledge, the background clauses and the clauses of the

input program are used.

Then, you have to specify the language bias by means of mode declarations in the

style of Progol.

modeh(<recall>,<predicate>(<arg1>,...)).

speciﬁes the atoms that can appear in the head of clauses, while

modeb(<recall>,<predicate>(<arg1>,...)).

speciﬁes the atoms that can appear in the body of clauses. <recall> can be an integer

or *.<recall> indicates how many atoms for the predicate speciﬁcation are retained

in the bottom clause during a saturation step. *stands for all those that are found.

Otherwise the indicated number is randomly chosen.

For SLIPCOVER, two specialization modes are available: bottom and mode. In

the ﬁrst, a bottom clause is built and the literals to be added during reﬁnement are

taken from it. In the latter, no bottom clause is built and the literals to be added

during reﬁnement are generated directly from the mode declarations. LEMUR has

only specialization mode.

Arguments of the form

+<type>

speciﬁes that the argument should be an input variable of type <type>, i.e., a variable

replacing a +<type> argument in the head or a -<type> argument in a preceding literal

in the current hypothesized clause.

Another argument form is

-<type>

for specifying that the argument should be a output variable of type <type>. Any

variable can replace this argument, either input or output. The only constraint on

output variables is that those in the head of the current hypothesized clause must

appear as output variables in an atom of the body.

Other forms are

#<type>

for specifying an argument which should be replaced by a constant of type <type> in

the bottom clause but should not be used for replacing input variables of the following

literals when building the bottom clause or

-#<type>

for specifying an argument which should be replaced by a constant of type <type> in

the bottom clause and that should be used for replacing input variables of the following

literals when building the bottom clause.

for specifying a constant.

Note that arguments of the form #<type> -#<type> are not available in specializa-

tion mode mode, if you want constants to appear in the literals you have to indicate

them one by one in the mode declarations.

An example of language bias for the Bongard domain is

output(pos/0).

input_cw(triangle/1).

input_cw(square/1).

input_cw(circle/1).

input_cw(in/2).

input_cw(config/2).

modeh(*,pos).

modeb(*,triangle(-obj)).

modeb(*,square(-obj)).

modeb(*,circle(-obj)).

modeb(*,in(+obj,-obj)).

modeb(*,in(-obj,+obj)).

modeb(*,config(+obj,-#dir)).

SLIPCOVER and LEMUR also require facts for the determination/2 Aleph-style

predicate that indicate which predicates can appear in the body of clauses. For example

determination(pos/0,triangle/1).

determination(pos/0,square/1).

determination(pos/0,circle/1).

determination(pos/0,in/2).

determination(pos/0,config/2).

state that triangle/1 can appear in the body of clauses for pos/0.

SLIPCOVER and LEMUR also allow mode declarations of the form

modeh(<r>,[<s1>,...,<sn>],[<a1>,...,<an>],[<P1/Ar1>,...,<Pk/Ark>]).

These mode declarations are used to generate clauses with more than two head atoms.

In them, <s1>,...,<sn> are schemas, <a1>,...,<an> are atoms such that <ai> is

obtained from <si> by replacing placemarkers with variables, <Pi/Ari> are the pred-

icates admitted in the body. <a1>,...,<an> are used to indicate which variables

should be shared by the atoms in the head. An example of such a mode declaration

(from uwcselearn.pl) is

modeh(*,

[advisedby(+person,+person),tempadvisedby(+person,+person)],

[advisedby(A,B),tempadvisedby(A,B)],

[professor/1,student/1,hasposition/2,inphase/2,

publication/2,taughtby/3,ta/3,courselevel/2,yearsinprogram/2]).

If you want to specify negative literals for addition in the body of clauses, you should

deﬁne a new predicate in the background as in

not_worn(C):-

component(C),

\+ worn(C).

one_worn:-

worn(_).

none_worn:-

\+ one_worn.

from mach.pl and add the new predicate in a modeb/2 fact

modeb(*,not_worn(-comp)).

modeb(*,none_worn).

Note that successful negative literals do not instantiate the variables, so if you want a

variable appearing in a negative literal to be an output variable you must instantiate

before calling the negative literals. The new predicates must also be declared as input

input_cw(not_worn/1).

input_cw(none_worn/0).

Lookahead can also be speciﬁed with facts of the form

lookahead(<literal>,<list of literals>).

In this case when a literal matching <literal> is added to the body of clause during

reﬁnement, then also the literals matching <list of literals> will be added. An

example of such declaration (from muta.pl) is

lookahead(logp(_),[(_=_))]).

Note that <list of literals> is copied with copy_term/2 before matching, so vari-

ables in common between <literal> and <list of literals> may not be in common

in the reﬁned clause.

It is also possible to specify that a literal can only be added together with other

literals with facts of the form

lookahead_cons(<literal>,<list of literals>).

In this case <literal> is added to the body of clause during reﬁnement only together

with literals matching <list of literals>. An example of such declaration is

lookahead_cons(logp(_),[(_=_))]).

Also here <list of literals> is copied with copy_term/2 before matching, so vari-

ables in common between <literal> and <list of literals> may not be in common

in the reﬁned clause.

Moreover, we can specify lookahead with

lookahead_cons_var(<literal>,<list of literals>).

In this case <literal> is added to the body of clause during reﬁnement only together

with literals matching <list of literals> and <list of literals> is not copied

before matching, so variables in common between <literal> and <list of literals>

are in common also in the reﬁned clause. This is allowed only with specialization

set to bottom. An example of such declaration is

lookahead_cons_var(logp(B),[(B=_))]).

6.1.4 Example Interpretations

The last part of the ﬁle contains the data. You can specify data with two modalities:

models and keys. In the models type, you specify an example model (or interpretation

or megaexample) as a list of Prolog facts initiated by begin(model(<name>)). and

terminated by end(model(<name>)). as in

begin(model(2)).

pos.

triangle(o5).

config(o5,up).

square(o4).

in(o4,o5).

circle(o3).

triangle(o2).

config(o2,up).

in(o2,o3).

triangle(o1).

config(o1,up).

end(model(2)).

The interpretations may contain a fact of the form

prob(0.3).

assigning a probability (0.3 in this case) to the interpretations. If this is omitted,

the probability of each interpretation is considered equal to 1/n where nis the total

number of interpretations. prob/1 can be used to set a diﬀerent multiplicity for the

interpretations.

The facts in the interpretation are loaded in SWI-Prolog database by adding an extra

initial argument equal to the name of the model. After each interpretation is loaded,

a fact of the form int(<id>) is asserted, where id is the name of the interpretation.

This can be used in order to retrieve the list of interpretations.

Alternatively, with the keys modality, you can directly write the facts and the ﬁrst

argument will be interpreted as a model identiﬁer. The above interpretation in the

keys modality is

pos(2).

triangle(2,o5).

config(2,o5,up).

square(2,o4).

in(2,o4,o5).

circle(2,o3).

triangle(2,o2).

config(2,o2,up).

in(2,o2,o3).

triangle(2,o1).

config(2,o1,up).

which is contained in the bongardkeys.pl This is also how model 2above is stored

in SWI-Prolog database. The two modalities, models and keys, can be mixed in the

same ﬁle. Facts for int/1 are not asserted for interpretations in the key modality but

can be added by the user explicitly.

Note that you can add background knowledge that is not probabilistic directly to

the ﬁle writing the clauses taking into account the model argument. For example

(carc.pl) contains

connected(_M,Ring1,Ring2):-

Ring1 \= Ring2,

member(A,Ring1),

member(A,Ring2), !.

symbond(Mod,A,B,T):- bond(Mod,A,B,T).

symbond(Mod,A,B,T):- bond(Mod,B,A,T).

where the ﬁrst argument of all the atoms is the model.

Example registration.pl contains for example

party(M,P):-

participant(M,_, _, P, _).

that deﬁnes intensionally the target predicate party/1. Here Mis the model and

participant/4 is deﬁned in the interpretations. You can also deﬁne intensionally the

negative examples with

neg(party(M,yes)):- party(M,no).

neg(party(M,no)):- party(M,yes).

Then you must indicate how the examples are divided in folds with facts of the form:

fold(<fold_name>,<list of model identifiers>), as for example

fold(train,[2,3,...]).

fold(test,[490,491,...]).

As the input ﬁle is a Prolog program, you can deﬁne intensionally the folds as in

fold(all,F):-

findall(I,int(I),F).

fold/2 is dynamic so you can also write (registration.pl)

:- fold(all,F),

sample(4,F,FTr,FTe),

assert(fold(rand_train,FTr)),

assert(fold(rand_test,FTe)).

which however must be inserted after the input interpretations otherwise the facts for

int/1 will not be available and the fold all would be empty. This command uses

sample(N,List,Sampled,Rest) exported from slipcover that samples Nelements

from List and returns the sampled elements in Sampled and the rest in Rest. If List

has Nelements or less, Sampled is equal to List and Rest is empty.

6.2 Commands

6.2.1 Parameter Learning

To execute EMBLEM, prepare an input ﬁle in the editor panel as indicated above and

call

?- induce_par(<list of folds>,P).

where <list of folds> is a list of the folds for training and Pwill contain the input

program with updated parameters.

For example bongard.pl, you can perform parameter learning on the train fold

with

?- induce_par([train],P).

6.2.2 Structure Learning

To execute SLIPCOVER, prepare an input ﬁle in the editor panel as indicated above

and call

induce(+List_of_folds:list,-P:list) is det

where List_of_folds is a list of the folds for training and Pwill contain the learned

program.

For example bongard.pl, you can perform structure learning on the train fold with

?- induce([train],P).

A program can also be tested on a test set with test/7 or test_prob/6 as described

below.

Between two executions of induce/2 you should exit SWI-Prolog to have a clean

database.

To execute LEMUR, prepare an input ﬁle in the editor panel as indicated above and

call

induce_lm(+List_of_folds:list,-P:list) is det

where List_of_folds is a list of the folds for training and Pwill contain the learned

program.

For example bongard.pl, you can perform structure learning on the train fold with

?- induce_lm([train],P).

Between two executions of induce_lm/2 you should exit SWI-Prolog to have a clean

database.

6.2.3 Testing

A program can also be tested on a test set in SLIPCOVER and LEMUR with

test(+Program:list,+List_of_folds:list,-LL:float,

-AUCROC:float,-ROC:list,-AUCPR:float,-PR:list) is det

test(+Program:list,+List_of_folds:list,-NPos:int,-NNeg:int,

-LL:float,-ExampleList:list) is det

where Program is a list of terms representing clauses and List_of_folds is a list of

folds.

test/7 returns the log likelihood of the test examples in LL, the Area Under the ROC

curve in AUCROC, a dictionary containing the list of points (in the form of Prolog pairs

x-y) of the ROC curve in ROC, the Area Under the PR curve in AUCPR, a dictionary

containing the list of points of the PR curve in PR.

test_prob/6 returns the log likelihood of the test examples in LL, the numbers of

positive and negative examples in NPos and NNeg and the list ExampleList containing

couples Prob-Ex where Ex is afor aa positive example and \+(a) for aa negative

example and Prob is the probability of example a.

Then you can draw the curves in cplint on SWISH using C3.js using

compute_areas_diagrams(+ExampleList:list,

-AUCROC:float,-ROC:dict,-AUCPR:float,-PR:dict) is det

(from pack auc) that takes as input a list ExampleList of pairs probability-literal of

the form that is returned by test_prob/6.

For example, to test on fold test the program learned on fold train you can run

the query

?- induce_par([train],P),

test(P,[test],LL,AUCROC,ROC,AUCPR,PR).

Or you can test the input program on the fold test with

?- in(P),

test(P,[test],LL,AUCROC,ROC,AUCPR,PR).

In cplint on SWISH, by including

:- use_rendering(c3).

:- use_rendering(lpad).

in the code before :- sc. the curves will be shown as graphs using C3.js and the

output program will be pretty printed.

You can also draw the curves in cplint on SWISH using R by loading library

cplint rwith

:- use_module(library(cplint_r)).

and using

test_r(+Program:list,+List_of_folds:list,-LL:float,

-AUCROC:float,-AUCPR:float) is det

or predicate

compute_areas_diagrams_r(+ExampleList:list,

-AUCROC:float,-AUCPR:float) is det

that takes as input a list ExampleList of pairs probability-literal of the form that is

returned by test_prob/6.

6.3 Parameters

Parameters are set with commands of the form

:- set_sc(<parameter>,<value>).

The available parameters are:

•specialization: (values: {bottom,mode}, default value: bottom, valid for

SLIPCOVER) specialization mode.

•depth_bound: (values: {true,false}, default value: true) if true, the depth

of the derivation of the goal is limited to the value of the depth parameter.

•depth (values: integer, default value: 2): depth of derivations if depth_bound is

set to true

•single_var (values: {true,false}, default value: false): if set to true, there

is a random variable for each clause, instead of a diﬀerent random variable for

each grounding of each clause

•epsilon_em (values: real, default value: 0.1): if the diﬀerence in the log likeli-

hood in two successive parameter EM iteration is smaller than epsilon_em, then

EM stops

•epsilon_em_fraction (values: real, default value: 0.01): if the diﬀerence in

the log likelihood in two successive parameter EM iteration is smaller than

epsilon_em_fraction*(-current log likelihood), then EM stops

•iter (values: integer, defualt value: 1): maximum number of iteration of EM

parameter learning. If set to -1, no maximum number of iterations is imposed

•iterREF (values: integer, defualt value: 1, valid for SLIPCOVER and LEMUR):

maximum number of iteration of EM parameter learning for reﬁnements. If set

to -1, no maximum number of iterations is imposed.

•random_restarts_number (values: integer, default value: 1, valid for EMBLEM,

SLIPCOVER and LEMUR): number of random restarts of parameter EM learn-

ing

•random_restarts_REFnumber (values: integer, default value: 1, valid for SLIP-

COVER and LEMUR): number of random restarts of parameter EM learning

for reﬁnements

•seed (values: seed(integer) or seed(random), default value seed(3032)): seed

for the Prolog random functions, see SWI-Prolog manual

•c_seed (values: unsigned integer, default value 21344)): seed for the C random

functions

•logzero (values: negative real, default value log(0.000001)): value assigned to

log 0

•max_iter (values: integer, default value: 10, valid for SLIPCOVER): number of

interations of beam search

•max_var (values: integer, default value: 4, valid for SLIPCOVER and LEMUR):

maximum number of distinct variables in a clause

•beamsize (values: integer, default value: 100, valid for SLIPCOVER): size of

the beam

•megaex_bottom (values: integer, default value: 1, valid for SLIPCOVER): num-

ber of mega-examples on which to build the bottom clauses

•initial_clauses_per_megaex (values: integer, default value: 1, valid for SLIP-

COVER): number of bottom clauses to build for each mega-example (or model

or interpretation)

•d(values: integer, default value: 1, valid for SLIPCOVER): number of saturation

steps when building the bottom clause

•mcts_beamsize (values: integer, default value: 3, valid for LEMUR): size of the

Monte-Carlo tree search beam

•mcts_visits (values: integer, default value: +1e20, valid for LEMUR): maxi-

mum number of visits

•max_iter_structure (values: integer, default value: 10000, valid for SLIP-

COVER): maximum number of theory search iterations

•background_clauses (values: integer, default value: 50, valid for SLIPCOVER):

maximum numbers of background clauses

•maxdepth_var (values: integer, default value: 2, valid for SLIPCOVER and

LEMUR): maximum depth of variables in clauses (as deﬁned in [5]).

•mcts_max_depth (values: integer, default value: 8, valid for LEMUR): maximum

depth of default policy search

•mcts_c (values: real, default value: 0.7, valid for LEMUR): value of parameter

Cin the computation of UCT

•mcts_iter (values: integer, default value: 20, valid for LEMUR): number of

Monte-Carlo tree search iterations

•mcts_maxrestarts (values: integer, default value: 20, valid for LEMUR): max-

imum number of Monte-Carlo tree search restarts

•neg_ex (values: given,cw, default value: cw): if set to given, the negative

examples in testing are taken from the test folds interpretations, i.e., those ex-

amples ex stored as neg(ex); if set to cw, the negative examples are generated

according to the closed world assumption, i.e., all atoms for target predicates

that are not positive examples. The set of all atoms is obtained by collecting the

set of constants for each type of the arguments of the target predicate.

•alpha (values: ﬂoating point ≥0, default value: 0): parameter of the symmetric

Dirichlet distribution used to initialize the parameters. If it takes value 0, a

truncated Dirichlet process is used to sample parameters: the probability of being

true of each Boolean random variable used to represent multivalued random

variables is sampled uniformly and independently in [0,1]. If it takes a value

≥0, the parameters are sampled from a symmetric Dirichlet distribution, i.e. a

Dirichlet distribution with vector of parameters (α, . . . , α).

•verbosity (values: integer in [1,3], default value: 1): level of verbosity of the

algorithms.

6.4 Files

The pack/cplint/prolog/examples folder in SWI-Prolog home contains some ex-

ample programs. The subfolder learning contains some learning examples. The

pack/cplint/doc folder in SWI-Prolog home contains this manual in latex, html and

pdf.

7 License

cplint follows the Artistic License 2.0 that you can ﬁnd in cplint root folder. The

The library CUDD for manipulating BDDs has the following license:

Redistribution and use in source and binary forms, with or without modiﬁcation,

are permitted provided that the following conditions are met:

•Redistributions of source code must retain the above copyright notice, this list

of conditions and the following disclaimer.

•Redistributions in binary form must reproduce the above copyright notice, this

list of conditions and the following disclaimer in the documentation and/or other

materials provided with the distribution.

•Neither the name of the University of Colorado nor the names of its contributors

may be used to endorse or promote products derived from this software without

speciﬁc prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CON-

TRIBUTORS ”AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, IN-

CLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MER-

CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DIS-

CLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIB-

UTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,

EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIM-

ITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF

USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAU-

SED

AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT

LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING

IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGE.

References

[1] Elena Bellodi and Fabrizio Riguzzi. EM over binary decision diagrams for prob-

abilistic logic programs. In Proceedings of the 26th Italian Conference on Com-

putational Logic (CILC2011), Pescara, Italy, 31 August 31-2 September, 2011,

2011.

[2] Elena Bellodi and Fabrizio Riguzzi. EM over binary decision diagrams for proba-

bilistic logic programs. Technical Report CS-2011-01, Dipartimento di Ingegneria,

Universit`a di Ferrara, Italy, 2011.

[3] Elena Bellodi and Fabrizio Riguzzi. Expectation Maximization over binary

decision diagrams for probabilistic logic programs. Intelligent Data Analysis,

17(2):343–363, 2013.

[4] Elena Bellodi and Fabrizio Riguzzi. Structure learning of probabilistic logic pro-

grams by searching the clause space. Theory and Practice of Logic Programming,

15(2):169–212, 2015.

[5] William W. Cohen. Pac-learning non-recursive prolog clauses. Artif. Intell.,

79(1):1–38, 1995.

[6] L. De Raedt, A. Kimmig, and H. Toivonen. ProbLog: A probabilistic Prolog and

its application in link discovery. In International Joint Conference on Artiﬁcial

Intelligence, pages 2462–2467, 2007.

[7] L. De Raedt and W. Van Laer. Inductive constraint logic. In Proceedings of

the 6th Conference on Algorithmic Learning Theory (ALT 1995), volume 997 of

LNAI, pages 80–94, Fukuoka, Japan, 1995. Springer.

[8] Nicola Di Mauro, Elena Bellodi, and Fabrizio Riguzzi. Bandit-based Monte-Carlo

structure learning of probabilistic logic programs. Mach. Learn., 100(1):127–156,

July 2015.

[9] Robert M Fung and Kuo-Chu Chang. Weighing and integrating evidence for

stochastic simulation in bayesian networks. In Fifth Annual Conference on Un-

certainty in Artiﬁcial Intelligence, pages 209–220. North-Holland Publishing Co.,

1990.

[10] Muhammad Asiful Islam, CR Ramakrishnan, and IV Ramakrishnan. Inference

in probabilistic logic programs with continuous random variables. Theory and

Practice of Logic Programming, 12:505–523, 7 2012.

[11] D. Koller and N. Friedman. Probabilistic Graphical Models: Principles and Tech-

niques. Adaptive computation and machine learning. MIT Press, Cambridge, MA,

2009.

[12] Arun Nampally and CR Ramakrishnan. Adaptive mcmc-based inference in prob-

abilistic logic programs. arXiv preprint arXiv:1403.6036, 2014.

[13] Davide Nitti, Tinne De Laet, and Luc De Raedt. Probabilistic logic programming

for hybrid relational domains. Mach. Learn., 103(3):407–449, 2016.

[14] J. Pearl. Causality. Cambridge University Press, 2000.

[15] David Poole. The independent choice logic for modelling multiple agents under

uncertainty. Artiﬁcial Intelligence, 94(1-2):7–56, 1997.

[16] Fabrizio Riguzzi. MCINTYRE: A Monte Carlo system for probabilistic logic

programming. Fundamenta Informaticae, 124(4):521–541, 2013.

[17] Fabrizio Riguzzi. The distribution semantics is well-deﬁned for all normal pro-

grams. In Fabrizio Riguzzi and Joost Vennekens, editors, Proceedings of the 2nd

International Workshop on Probabilistic Logic Programming (PLP), volume 1413

of CEUR Workshop Proceedings, pages 69–84, Aachen, Germany, 2015. Sun SITE

Central Europe.

[18] Fabrizio Riguzzi and Terrance Swift. Tabling and Answer Subsumption for Rea-

soning on Logic Programs with Annotated Disjunctions. In Technical Commu-

nications of the International Conference on Logic Programming, volume 7 of

Leibniz International Proceedings in Informatics (LIPIcs), pages 162–171. Schloss

Dagstuhl–Leibniz-Zentrum fuer Informatik, 2010.

[19] Taisuke Sato and Yoshitaka Kameya. Prism: A language for symbolic-statistical

modeling. In International Joint Conference on Artiﬁcial Intelligence, pages 1330–

1339, 1997.

[20] Taisuke Sato and Yoshitaka Kameya. Parameter learning of logic programs for

symbolic-statistical modeling. J. Artif. Intell. Res., 15:391–454, 2001.

[21] J. Vennekens, M. Denecker, and M. Bruynooghe. Representing causal information

about a probabilistic process. In Proceedings of the 10th European Conference on

Logics in Artiﬁcial Intelligence, LNAI. Springer, September 2006.

[22] J. Vennekens, Marc Denecker, and Maurice Bruynooghe. CP-logic: A language of

causal probabilistic events and its relation to logic programming. Theory Pract.

Log. Program., 9(3):245–308, 2009.

[23] J. Vennekens and S. Verbaeten. Logic programs with annotated disjunctions.

Technical Report CW386, K. U. Leuven, 2003.

[24] J. Vennekens, S. Verbaeten, and M. Bruynooghe. Logic programs with annotated

disjunctions. In International Conference on Logic Programming, volume 3131 of

LNCS, pages 195–209. Springer, 2004.

[25] John Von Neumann. Various techniques used in connection with random digits.

Nat. Bureau Stand. Appl. Math. Ser., 12:36–38, 1951.

Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
