MD 425 Dynamic Super-Cardioid Microphone
The MD 425 is a high quality dynamic super-cardioid microphone. Due to its excellent acoustic
properties, the MD 425 is especially suitable for vocal and speech applications in all areas of
public address and sound recording.
Features—Benefits
• Exceptionally good feedback rejection
• Very good rejection of handling noise
• Lockable, noiseless reed on/off switch
• Integral pop filter
• Sophisticated design—provides low profile on-camera look
• Metal Construction—rugged and reliable
Technical Data
Pick-up pattern super-cardioid
Frequency response 40–18,000 Hz
Sensitivity (free field, no load) 1.6 mV/Pa at 1 kHz, nominal
Nominal impedance 350 Ω
Min. terminating impedance 1 k
Dimensions in inches 1.73 x 8.07
Weight approx. 11.29 oz
MD 425
Architect’s Specifications
The unit shall be a super-cardioid speech and vocal microphone, with a frequency response
of 40–18,000 Hz. The sensitivity shall be (free field, no load) 1.6 mV/Pa at 1 kHz, and nominal
impedance of 350 Ω.The min. terminating impedance shall be1 k, The dimensions shall be
1.73 x 8.07 inches, and weight approx. 11.29 oz. the unit shall be a Sennheiser MD 425.
Supplied Accessories
1 Microphone clip
Optional Accessories
Grey foam windscreen MZW 4032
21' XLR microphone cable MC21N
Stand adapter (included) MZA 4032
