UNA-CLAD™ Metal Roof Systems

Code Approval Guide

You must verify the included assemblies in the charts below with the

associated Firm’s (UL, FM, etc). Not all of the information included

in the RoofNav assemblies will be listed in the charts below.

You must verify that all assemblies meet Firestone Building Products

warranty requirements with the associated regions technical team.

2 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Table of Contents

EXTERNAL FIRE RATINGS ......................................................................................................................... 5

UL Fire Rated Roof Assemblies .................................................................................................................... 6

UL Class A – External Fire Rated Assemblies: .............................................................. 6

UL Class B – External Fire Rated Assemblies: .............................................................. 8

UL – Impact Resistance ................................................................................................................................ 9

UL Impact Resistance Rated Panels............................................................................ 9

TGAM.R14751 Roof-covering Materials, Impact Resistance ........................................... 9

(only Steel, copper or aluminum, any thickness) ......................................................... 9

UL – Wind Uplift Ratings ............................................................................................................................... 9

UL 580, Class 90 Rated Roof Deck Constructions ..................................................................................... 10

UC-3 Constructions: .............................................................................................. 10

UC-4 Constructions: .............................................................................................. 15

UC-6 Constructions: .............................................................................................. 20

UC-7 Constructions: .............................................................................................. 23

UC-14 Constructions: ............................................................................................. 23

5V Crimp Constructions: ........................................................................................ 33

UL 1897 Testing: ......................................................................................................................................... 34

UC-3 .................................................................................................................... 34

UC-4 .................................................................................................................... 36

UC-6 .................................................................................................................... 38

UC-7 .................................................................................................................... 38

UC-14 .................................................................................................................. 39

Internal Fire (“P” Assemblies) ..................................................................................................................... 39

STATE OF FLORIDA and MIAMI-DADE APPROVALS ............................................................................. 40

Table 1.05a .......................................................................................................... 40

State of Florida Product Approval ............................................................................ 40

Table 1.05b .......................................................................................................... 40

Miami-Dade Notice of Acceptance ............................................................................ 40

Energy Star Approvals - As Currently Listed at www.energystar.gov ........................................................ 40

Table 1.06 ............................................................................................................ 40

Energy Star Approvals ........................................................................................... 40

CRRC Rated Panels ................................................................................................................................... 41

CRRC Rated Panels ................................................................................................ 41

Air Infiltration & Water Penetration .............................................................................................................. 42

Table 1.08a .......................................................................................................... 42

ASTM E283 and E1680 Air Infiltration Tests .............................................................. 42

3 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Table 1.08b .......................................................................................................... 43

ASTM E331 and E1646 Water Penetration Tests ........................................................ 43

Structural Performance ............................................................................................................................... 44

Table 1.09a .......................................................................................................... 44

ASTM E330 Structural Performance Tests ................................................................. 44

Table 1.09a (Cont.) ............................................................................................... 45

ASTM E330 Structural Performance Tests ................................................................. 45

Table 1.09b ............................................................................................................ 45

ASTM E1592 Structural Performance Tests ......................................................... 45

Table 1.09b (Cont.) ................................................................................................... 46

ASTM E1592 Structural Performance Tests ......................................................... 46

1.11 Concentrated Load Testing ................................................................................................................. 53

Table 1.11 Concentrated Load Testing ...................................................................... 53

4 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Not all of the information included in the

assemblies will be listed in the charts below. Verify

ALL assemblies in this document with the

associated Firm’s (UL, FM, etc) database or QBS.

Verify that ALL assemblies meet Firestone Building

Products warranty requirements with QBS.

Codes information is time sensitive and may

change without notice. It is the responsibility of

the user to complete the above verifications

BEFORE bidding the project in order to assure

accuracy.

5 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

EXTERNAL FIRE RATINGS

1. All regional building codes and most local building code officials require that roofing systems meet minimum performance

requirements when exposed to external fire sources. The accepted method for measuring external fire resistance is ASTM

Standard E-108. This test standard, and closely related standards such as Underwriters Laboratories UL-790 and Uniform

Building Code 15-2, is used to determine the ability of a roof system to hinder the horizontal spread or vertical penetration

of an external fire source.

A. Noncombustible Roof Decks (Steel, Concrete, and Poured Gypsum) require testing for horizontal spread of flame.

B. Combustible Roof Decks (Wood, Plywood, and Tectum) require testing for both horizontal spread and vertical penetra-

tion of flame.

2. ASTM E-108, UL-790 and UBC 15-2. All classified roof covering assemblies fall into one of the three following categories:

CLASS A: “... includes roof coverings which are effective against

severe fire exposures...” (See Note 1)

CLASS B: “... includes roof coverings which are effective against

moderate fire exposures...” (See Note 1)

CLASS C: “... includes roof coverings which are effective against

light fire exposures...” (See Note 1)

3. For insulated assemblies over non-combustible roof decks, any classified roofing assembly may be installed over a new

roof deck, an existing roof deck or over an existing roofing assembly. Underwriters Laboratories states that “any classified

roofing system may be applied over a pre-existing roof system (Class A, B, C, verifiable or not) of the same deck type

and establishes for that roof the classification of the new system”. Also, an assembly classified over a combustible deck

may be installed over an existing non-combustible deck and establish for the assembly the rating of the new system. A

non-combustible deck rated assembly must be tested and classified over a combustible deck in order to obtain the desired

classification of the new assembly. Total insulation thickness of combined existing and new roofing systems may not

exceed the total maximum allowable for the new roofing system, and non-insulated systems are not intended for use over

insulated systems.

4. The class of roof covering required by each regional building code depends upon many factors, including the use and

location of the building and the type of construction. The local building authority should always be consulted as to what the

roofing assembly classification will need to be for each roofing project.

5. It should be noted that these classifications apply to roofing assemblies, and NOT the metal roofing panel. A metal

roofing panel that is classified as part of a Class A assembly when installed over a particular insulated or non-insulated

construction may not qualify as part of a Class A assembly if you make changes within the insulated or non-insulated

construction.

6 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UL Fire Rated Roof Assemblies

The following UL Fire Rated Roof Assemblies can be found and verified using the following hyperlink:

- TGFU.R14751 – Roofing Systems

Please utilize the UL website to verify the assembly number associated with each listed assembly.

UL Class A – External Fire Rated Assemblies:

Construction: New, Retrofit

UL # Deck, Slope

& Class

Assembly

1. Deck:

C-15/32

Slope: Unlimited

Class: A

Insulation (Optional):

—

Any thickness Firestone "ISO 95+GL", RESISTA, ISOGARD HD,

ISOGARD, HD Composite

Barrier Board: — G-P Products "DensDeck® ", 1/4 in. thick min, or 1/2 in. thick min UL

Classified gypsum board with joints in barrier board offset 6 in. with joints in deck, or minimum

one layer GAF Materials Corp. "VersaShield Solo Fire Resistant Slipsheet" CLAD-GARD SA-FR

Underlayment

Ply Sheet (Optional): — One or more layers CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD

R, CLAD GARD MA (not UL Classified) or CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, copper, zinc or aluminum.

1A. Deck:

C-15/32

Slope: Unlimited

Class: A

Barrier Board:

—

P Products "DensDeck®", 1/4 in. thick min, or 1/2 in. thick min UL Classified

gypsum board with joints in barrier board offset 6 in. with joints in deck, or minimum one layer

GAF Materials Corp. "VersaShield Solo Fire Resistant Slipsheet" or minimum one layer of CLAD-

GARD SA-FR Underlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL" RESISTA, ISOGARD HD,

ISOGARD HD Composite or "HailGard"

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, copper, zinc or aluminum.

1B. Deck:

C-15/32

Slope: Unlimited

Class: A

Barrier Board:

—

P Products "DensDeck®", 1/4 in. thick min, or 1/2 in. thick min UL Classified

gypsum board with joints in barrier board offset 6 in. with joints in deck, or minimum one layer

GAF Materials Corp"VersaShield Underlayment" or minimum one layer of CLAD-GARD SA-FR

Underlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL", RESISTA, ISOGARD HD,

ISOGARD HD Composite or "HailGard",

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, copper.

2. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Underlayment:

—

CLAD

GARD SA

FR Underlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL", RESISTA, "ISOGARD HD",

ISOGARD HD Composite or "HailGard"

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel or copper.

3. Deck:

C-15/32

Slope: Unlimited

Class: A

Underlayment:

—

CLAD

GARD SA

FR Unde

rlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL", RESISTA, "ISOGARD HD",

ISOGARD HD Composite or "HailGard"

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

7 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

(not UL Classified) or CLAD

GARD SA

FR Un

derlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" aluminum.

4. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Underlayment:

—

CLAD

GARD SA

FR Underlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL", RESISTA,"ISOGARD HD",

ISOGARD HD Composite or "HailGard"

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR, "HR", "VR", 5V Crimp, "NB1", "NB2"

steel or copper.

5. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Underlayment:

—

CLAD

GARD SA

FR Underlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL", RESISTA, "ISOGARD HD",

ISOGARD HD Composite or " HailGard"

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, fastened to 2x2 wood battens.

6. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Underlayment:

—

CLAD

GARD SA

FR Underlayment.

Insulation (Optional): — Any thickness Firestone "ISO 95+ GL", RESISTA" ISOGARD HD",

ISOGARD HD Composite or "HailGard"

Ply Sheet (Optional): — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment.

Ply Sheet: — One layer Type 30 base sheet or "VersaShield", mechanically fastened.

Surfacing: — "5-V-Crimp ".

7. Deck:

C-15/32

Slope: Unlimited

Class: A

Insulation (Optional):

—

Firestone "ISO 95+ GL (any thickness), RESISTA

Insulation: — min. ½ in. "ISOGARD HD" OR ISOGARD HD Composite

Ply Sheet: — CLAD-GARD SA-FR Underlayment.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel or copper.

8. Deck:

C-15/32

Slope: Unlimited

Class: A

Insulation (Optional):

—

Firestone "ISO 95+GL" or RESISTA

Barrier Board: — G-P Products "DensDeck® ", 1/4 in. thick min, or 1/2 in. thick min UL

Classified gypsum board with joints in barrier board offset 6 in. with joints in deck, or minimum

one layer CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA (not UL Classified)

or CLAD-GARD SA-FR Underlayment".

Ply Sheet (Optional) — CLAD-GARD SA-N, CLAD-GARD SA-S, CLAD-GARD R, CLAD-GARD MA

(not UL Classified) or CLAD-GARD SA-FR Underlayment".

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, copper or aluminum.

9. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Insulation (Optional):

—

Firestone "ISO 95+GL"," ISOGARD HD", RESISTA or "HailGard"

Underlayment: — CLAD-GARD SA-FR Underlayment

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel or copper.

10. Deck:

C-15/32

Insulation (Optional):

—

Firestone "ISO 95+GL", "ISOGARD HD", RESISTA, ISOGARD H

Composite or "HailGard"

8 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Slope: Unlimited

Class: A

Underlayment: — CLAD-GARD SA-FR Underlayment

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" aluminum.

11. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Insulation (Optional):

—

Any thickness Firestone "ISO 95+GL", "ISOGARD HD", RESISTA,

ISOGARD HD Composite or "HailGard"

Underlayment: — CLAD-GARD SA-FR Underlayment

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR, "HR", "VR", 5V Crimp, "NB1", "NB2"

steel or copper.

12. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Insulation (Optional):

—

Firestone "ISO 95+GL", "ISOGARD HD", RESISTA, ISOGARD HD

Composite or "HailGard"

Underlayment: — CLAD-GARD SA-FR Underlayment

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, fastened to 2x2 wood battens.

13. Deck:

C-15/32 or

Spaced

Sheathing

Slope: Unlimited

Class: A

Insulation (Optional):

—

Firestone "ISO 95+GL", "ISOGARD HD"

, RESISTA, ISOGARD HD

Composite or "HailGard"

Underlayment: — One layer GAF Materials Corp "VersaShield Underlayment", mechanically

fastened.

Ply Sheet: — One layer Type 30 base sheet or "VersaShield Underlayment", mechanically

fastened.

Surfacing: — "5-V-Crimp".

14. Deleted

15. Deck:

Slope: Unlimited

Class: A

Insulation (Optional):

—

Any thickness Firestone "ISO 95+GL", Resista, Firestone HailGard, Any

UL Classified insulation any thickness.

Cover Board (Optional): — Firestone ISOGARD HD, G-P Products "DensDeck®", 1/4 in. thick

min, 7/16 inch OSB, 1/2 in. high density wood fiber board or 15/32 in. plywood.

Ply Sheet (Optional): — Firestone Clad Gard SA-N, Clad-Gard SA-S, Clad Gard R or Clad-Gard

MA (not UL Classified). CLAD-GARD SA-FR Underlayment

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC-14", "UC-600",

"UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V, Crimp, "NB1", "NB2" steel, copper

or aluminum.

UL Class B – External Fire Rated Assemblies:

Construction: New, Retrofit

1. Deck:

C-15/32

Slope:

Unlimited

Class:B

Underlayment:

—

One layerGAF Materials Corp "VersaShield Underlayment", mechanically

fastened.

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6","UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel, copper or aluminum.

2. Deck:

Spaced

Sheathing

Slope:

Unlimited

Class: B

Underlayment:

—

One layer GAF Materials Corp "VersaShield Underlayment".

Surfacing: — "UC-1", "UC-2", "UC-3", "UC-4", "UC-6", "UC-6 HD", "UC-7 ", "UC9", "UC11", "UC-

14", "UC-600", "UC-601", "UC750", "UC-500", "UC-501", "UR", "HR", "VR", 5V Crimp, "NB1",

"NB2" steel or copper.

9 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UL – Impact Resistance

(TGAM.GuideInfo)

Testing to UL 2218, “Impact Resistance of Prepared Roof Covering Materials”, results in Classifications for impact

resistance that are expressed as Class 1, 2, 3 or 4 which relate to a roof covering’s ability to withstand impacts

from 1-1/4, 1-1/2, 1-3/4 and 2 inch diameter steel balls , respectively. The acceptance criteria to metal roof panels

is as follows: withstand the assigned class designation impact without visible evidence of tearing, fracturing,

cracking, splitting, rupturing, crazing or other opening of the roof covering layer. Classification is for metal panels

placed over solid wood decking (3/8” or greater in thickness).

MPACT

ESISTANCE

ATED

ANELS

TGAM.R14751

OOF

COVERING

ATERIALS

MPACT

ESISTANCE

(

ONLY

TEEL

COPPER OR ALUMINUM

ANY THICKNESS

)

Class 4 ratings were achieved for the following panels designations:

UC-3, UC-4, UC-6, UC-7, UC-14 UC-500, UC-501, UC-600, UC-601 5-V Crimp, UR, HR, VR

UL – Wind Uplift Ratings

UPLIFT RESISTANCE CLASSIFIED

TGKX.GuideInfo - Roof Deck Constructions

Roof Deck Constructions Classified for Uplift Resistance have been investigated for damageability from both

external and internal pressures on the deck associated with high velocity winds. Uplift Classifications are derived

from tests conducted in accordance with the Standard for "Tests For Uplift Resistance of Roof Assemblies"

, ANSI/UL 580. The ANSI/UL 580 test method subjects a 10 ft by 10 ft test sample to various static and oscillating

air pressures to index performance under uplift loads imposed on roof decks.

The magnitude of the wind velocity across a roof deck and the resulting uplift pressures on a roof deck are

dependent upon many factors such as wind gusts, the shape of the roof deck, edge configuration and the

landscape surrounding the roof deck installation. A method to calculate the uplift pressures on roof decks is

contained in the American Society of Civil Engineers (ASCE) Standard 7-95, Minimum Design Loads for Buildings

and Other Structures.

The nominal static uplift pressure, the oscillating uplift pressures and the maximum static uplift pressure for each

Class are:

Class

Nom Static

Uplift Pressure psf

Range of

Oscillating Pressure psf

Max Static

Uplift Pressure psf

15 15 11 to 21 23

30 30 22 to 42 45

60 60 44 to 83 75

90 90 66 to 90 105

The static pressures are maintained for a 5 min period and the oscillating pressures are applied at a 10 plus or

minus 2 s frequency and are maintained for a 60 min period for each Class. An assembly rated Class 60 has

successfully withstood pressures imposed during Class 30 and Class 60 tests. An assembly rated Class 90 has

successfully withstood pressures imposed during Class 30, Class 60 and Class 90 tests.

NOTE: Please utilize the UL website to verify the Construction Number associated with each listed assembly. A

hyperlink has been embedded in each assembly using the ‘Construction No. ###’. By clicking on this text you can

open the hyperlink that will direct you to the current UL construction assembly and details.

10 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UL 580, Class 90 Rated Roof Deck Constructions

The following UL 580, Class 90 Rated Roof Deck Constructions can be found and verified using the following

hyperlink:

- TJPV-R14751 – Metal Roof Deck Panels

UC-3 Constructions:

UC-3 – Construction No. 512A

Uplift – Class 30*, Class 90

1. Panel: Width 12 in. min to 20 in. max with 1-1/2 in. high legs. No. 24 MSG min thick coated steel, or 0.032 in. min thick

aluminum. Panels continuous over three or more clips with no end laps. Panel ribs double seamed with an

electric seaming tool with seaming operation to include upper tabs of panel clips (Item 2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

2. Roof Deck

Fasteners*

(Panel Clips):

Two part assembly, base 3 in. wide, 5/8 in. high, with a 7/8 in. wide base leg having two 3/16 in. embossed guide

holes. Upper tab 1/2 in. wide folded over base forming two tabs. Both parts fabricated from 0.015 in. min thick

stainless steel. Clips spaced 12 in. OC. (Metal Roof Deck Panels (Item 1) limited to 16 inches wide when UC-3

Super Clip used at 36 inches oc for Class 30. Metal Roof Deck Panels).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Expansion Clip", UC-3 Super Clip

3. Fasteners

(Screws):

Fasteners used to attach panel clips (Item 2) to plywood decking (Item 5) to be No. 10-12 by minimum 1 in. long,

without insulation and/or cover board, 10 x 1" PC PD WOW T17 steel or 10 x 1" PC T WOW T17 stainless steel

screws. Two screws used per clip inserted into clip guide holes.

4. Underlayment: (Optional) — Underlayment attached over Foamed Plastic (Item 5A and/or 5B) or Decking (Item 5) or Cover

Board (Item 9)As an alternate, a self-adhering modified bitumen waterproofing membrane may be used. Installed

per manufacturer's recommendations. When alternate is used, plywood joints need not be sealed.

5. Plywood

Decking and

Insulation

Options:

Note:

Foamed

Plastic*

Deck to be 7/16 inch OSB, 15/32 inch plywood, 19/32 inch plywood; Exposure 1, APA rated sheathing (42/20) or

(32/16) respectively, square edged. Roof Deck Panels (Item 1) to be maximum 16 inches wide when fastened

into 7/16 OSB or 15/32 plywood decking, and UC-3 Expansion Clip (Item 2) is to be maximum 18 inch oc. Roof

Deck Panels greater than 16 inches to follow 12 inch oc spacing noted in Item 2. Butt joints to be located over

purlins, side joints not blocked. All butt and side joints to be sealed with a one part urethane caulk sealant-

feathered outward from joint (note exception under Item 4 alternate).

A: Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10 in.

thick combination of Item 5B. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

5B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 5A. Maximum 10-in

thick combination of Item 5A . Bearing plates required under panel attachment points. Bearing plates not

required if foamed plastic not used (Item 5A or 5B).

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

5C. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel

plate (for use with coated steel panels) or stainless steel plate (for use with aluminum panels). Two 1/4 in. guide

holes located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

5D. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood

fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat

Board" or "SECUROCK Roof Board" applied over the plywood decking (Item 5) or Foamed Plastic (Items 5A

and/or 5B). When used or used over Foamed Plastic bearing plate not required.

6. Pulins – Deck

Supports:

Spaced a max of 24 in. OC. Any of the following types may be used:

A. No. 16 MSG min thick coated steel. (Min yield strength 33,000 psi).

B. Nom 2 by 6 in. (1-1/2 by 5-1/4 in. actual) No. 2 grade or better S-P-F, Hemlock Fir, Douglas Fir or Southern

Yellow Pine or equivalent.

C. Wood Trusses with a nom 2 by 4 in. (1-1/2 by 3-1/4 in. actual) upper chord of same grade as Item B.

7. Plywood

Fasteners:

Fasteners used to attach plywood deck to supports to be used as follows:

A. For plywood to steel supports, to be No. 8-20 by 1-1/4 in. long No. 2 Phillips Drive Bugle Head Steel screws

with an S-12 TEKS 3 Super Point.

B. For plywood to wood supports to be No. 8-18 by 1-7/8 in. long No. 2 Phillips Drive Bugle Head, "Hi-Low"

thread pattern with an "S" point. Spacing for all fastener types to be 6 in. OC at the edges and 12 in. OC in the

interior.

* Indicates such products shall bear the UL or cUL Cer

tification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

11 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-3 – Construction No. 623

Uplift – Class 90

1. Panel: Width 16 in. max with 1-1/2 in. high legs. Min 0.027 in. thick RHEINZINK (zinc). Panels continuous over three or

more clips with no end laps. Panel ribs double seamed with an electric or manual seaming tool with seaming

operation to include upper tabs of panel clips (Item 2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

2. Roof Deck

Fasteners*

(Panel Clips):

Two part assembly, base 5 in. long, 1 in. wide, 0.42 in. high. Fabricated from min 0.0225 in. thick 304 stainless

steel. Upper tab 3 in. long, 0.42 in. wide, 1.786 in. high. Fabricated from min 0.0172 in. thick 304 stainless steel.

Spaced a maximum of 12 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Super Clip"

3. Fasteners

(Screws):

Fasteners used to attach panel clips (Item 2) to plywood deck (Item 7) to be No. 10 by 1-1/2 in. long pancake

head stainless steel screws. Two screws used per clip inserted into clip guide holes.

4. Ventilation Mat: One layer Colbond "Enkamat 7010", loose laid.

5. Underlayment*: One layer Elk "VersaShield" with 2 in. side lap, loose laid.

6. Underlayment: One layer Type 30 organic felt with 2 in. side lap. Mechanically fastened to the plywood deck (Item 7) per

manufacturers recommendations. Spaced 6 in. OC at the perimeter and 12 in. OC staggered in the field.

7. Plywood

Decking:

Deck to be nominal 5/8 in. (19/32 in. actual) or ½-in (15/32-in actual) thickn PS-1 rated plywood.

8. Pulins – Deck

Supports:

Spaced a maximum of 2 ft OC. Any of the following types may be used:

A. No. 16 MSG min thick coated steel (33,000 psi min yield strength).

B. Graded dimension lumber, No. 2 or better.

9. Plywood

Fasteners:

Fasteners used to attach plywood deck (Item 7) to supports (Item 8) to be as follows:

A. For plywood to steel supports, to be No. 8-20 by 1-1/4 in. long No. 2 Phillips Drive Bugle Head steel screws

with an S-12 TEKS 3 Super Point.

B. For plywood to wood supports, to be 8d by 2-½ in. long ring shank common nails or no. 8-18 by 1-7/8 in. long

no. 2 Phillips Drive Bugle Head, "Hi Low" thread pattern steel screws with an "S" point.

Note: Spacing for all fastener types to be 6 in. OC at the edges and 12 in. OC in the interior. Refer to General

Information, Roof Deck Constructions for items not evaluated.

* Indicates such products shall bear the UL or cUL Certificatio

n Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-3 – Construction No. 656

Uplift – Class 90

1. Wood

Supports

(Joist):

Nominal 2 by 10 in. graded dimensional lumber, No. 2 or better. Spaced 24 in. OC max.

2. Deck: Nominal 5/8 in. (19/32 in. actual) or ½-in (15/32-in actual) plywood, Grade B-C, PS-1 rated. Fastened to

supports (joists) using 8d by 2-1/2 in. long ring shank nails. Spaced 6 in. OC max at the butt ends and 6 in. OC

max in the field.

3. Foamed

Plastic:

3. (Rigid Insulation) — Applied flat or tapered to maximum 10-in thick combination of Item 3A. Bearing plates

required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL"

3A. (Rigid Insulation — Optional) — Placed on top of Item 3. Maximum 10-in thick combination of Item 3 .

Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — “ISOGARD HD” or “Resista”

4. Vapor Barrier:

(Optional)

—

Self-adhered modified bitumen membrane per manufacturer's instructions.

Panel: Min 24 MSG steel; width 20 in. max., 1-1/2 in. high at the ribs. Panels continuous over three or more clips with

no end-laps. A bead of sealant may be used at panel ribs. Panel ribs seamed with an electric seamer with

seaming operation to include upper portion of panel clip (Item 5).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

6. Roof Deck

Fasteners*

(Panel Clips):

Two part assembly, base 3 in. wide, 5/8 in. high, with a 7/8 in. wide base leg having two 3/16 in. embossed

guide holes. Upper tab 1/2 in. wide folded over base forming two tabs. Both parts fabricated from 0.015 in. min

thick stainless steel. Clips spaced 24 in. OC. with seaming operation to include upper tabs of panel clips. Plates

used with panel screw fasteners (Item 6) under panel clip to be 4 in. by 4 in. min No. 26 gauge stainless steel or

min No. 26 gauge galvanized steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Expansion Clip"

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

7. Panel

Fasteners

(Screws):

Fasteners used to attach the panel clips to the plywood decking to be No. 12 pancake wafer head steel screws.

Length to penetrate plywood decking a minimum of 3/4 in. Two screws are to be used per clip.

8. Cover Board:

(Optional)

— Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be used) or min

7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in. min thickness G-

12 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or "SECUROCK Roof Board"

applied over the plywood deck (Item 2) or Foamed Plastic (Items 3 and/or 3A). When used or used over Foamed

Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the U

L or cUL

Certification (such as Canada), respectively.

UC-3 – Construction No. 622

Uplift – Class 90

1. Panel*: Width 16 in. max with 1-1/2 in. high legs. No. 24 MSG min thick coated steel. Panels continuous over three or

more clips with no end laps. Panel ribs double seamed with an electric or manual seaming tool with seaming

operation to include upper tabs of panel clips (Item 2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

2. Roof Deck

Fasteners*:

2. (Panel Clips)

—

Two part assembly, base 5 in. long, 1 in. wide, 0.42 in. high. Fabricated from No. 22 MSG

min thick coated steel. Upper tab 3 in. long, 0.42 in. wide, 1.79 in. high. Fabricated from No. 24 MSG min thick

coated steel. Spaced a maximum of 30 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Super Clip"

2A. Bearing Plate (Not Shown) — Plates used with panel screw fasteners (Item 3) under panel clip (Item 2) to

be 4 in. by 4 in. min No. 26 gauge stainless steel or min No. 26 gauge galvanized steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

2B. Plywood - (Optional) - (Not Shown) — As an alternate to the bearing plates (Item 2A), ½ in. thick (15/32

in. actual) thickness plywood, APA rated sheathing, square edged may be used to cover the entire deck.

3. Fasteners

(Screws):

Fasteners used to attach panel clips (Item 2) to liner panel (Item 7) to be No. 12 pancake wafer head steel

screws. Length to penetrate liner panel (Item 7) a minimum of ¾ in. Two screws used per clip inserted into clip

guide holes.

4. Underlayment*:

(Optional)

—

One layer Elk "VersaShield" with 2 in. side lap, loose laid.

5. Underlayment:

(Optional)

— One layer Type 30 organic felt with 2 in. side lap. Mechanically fastened to the liner panel (Item 7)

per manufacturers recommendations. As an alternate, a self-adhering modified bitumen waterproofing

membrane may be used per manufacturer's installation.

6. Foamed

Plastic*:

6. Rigid Insulation

—

Applied flat or tapered to maximum 10-in thick combination of Item 6A. Bearing plates

required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "Resista" or "HD Board"

6A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 6. Maximum 10-in

thick combination of Item 6. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD", Resista" or "HD

Board"

7. Liner Panel: 7. No. 22 MSG min thick coated steel (min yield strength 33,000 psi). Min depth 1-½ in., max pitch 6 in.

fabricated to various profiles.

7A. Liner Panel Fasteners (Not Shown) — Liner panels (Item 7) to be fastened to structural supports (Item 8)

with puddle welds at every other valley, 12 in. OC.

8. Supports: Type K open web steel joists, 4 ft OC.

9. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in. min

thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or "SECUROCK

Roof Board" applied over the liner panel (Item 7) or Foamed Plastic (Items 6 and/or 6A). When used or used

over Foamed Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or

cUL

Certification (such as Canada), respectively.

UC-3 – Construction No. 512

Uplift – Class 90

1. Panel: Width 12 in. min to 20 in. max with 1-1/2 in. high legs. No. 24 MSG min. thick coated steel, or 0.032 in. min

thick aluminum.

Width 16-in. max with 1-1/2 in high legs, min 0.022 in. (16 oz) copper. Panels continuous over three or more

clips with no end laps. Panel ribs double seamed with an electric seaming tool with seaming operation to

include upper tabs of panel clips (Item 2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

2. Panel

Fasteners*

Two part assembly, base 3 in. wide, 5/8 in. high, with a 7/8 in. wide base leg having two 3/16 in. embossed

guide holes. Upper tab 1/2 in. wide folded over base forming two tabs. Both parts fabricated from 0.015 in. min

13 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

(Panel Clips): thick stainless steel. Clips spaced 12 in. OC. with seaming operation to include upper tabs of panel clips (Item

2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Expansion Clip"

3. Fasteners

(Screws):

3. Fasteners used to attach panel clips (Item 2) to liner panels (Item 5) to be No. 12-13, No. 3 Phillips drive,

truss-head, coated steel screws with an "S" point or FirestoneAll-Purpose Stainless Steel Fasteners. Length to

be 3/4 in. longer than overall thickness of roof deck. Two screws used per clip inserted into clip and bearing

plate (Item 7) guide holes.

3A. Fasteners used to attach panel clips to plywood or OSB cover board (Item 5A) to be 10 x 1" PC PD WOW

T17 steel or 10 x " PC T WOW T17 stainless steel screws.

3B. Fasteners used to attach plywood or OSB cover board to Liner Panel (item 5 below) when attaching clips to

plywood or OSB to be Firestone HD HailGard Fastener in a pattern of 24 screws per 4-ft by 8-ft cover board.

3C. Fasteners used to attach panel clips (Item 2) to HailGard composite insulation board (Item 6B) No. 10 1-in.

long stainless steel, two screws used per clip.

3D. Fasteners used to attach HailGard (Item 6B) composite insulation board to liner panels (Item 5) to be

Firestone HD HailGard Fastener in a pattern of 24 screws per 4-ft by 8-ft board.

4. Underlayment:

(Optional)

—

Underlayment attached over foamed plastic (Item 6).

5. Liner Panel: 5. No. 22 MSG min thick coated steel (33,000 psi min yield strength). Min depth 1-1/2 in., max pitch 6 in.

Fabricated to various profiles. Fastened to supports 6 in. OC.

5A. Cover Board — (Optional — Not Shown) — Min ½ in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated ½ in. thick, ½ in. thick gypsum board,

½ in. wood fiberboard, ¼ in. min thickness G-P Gypsum “DensDeck”, ¼ in. min thick USG “SECUROCK Glass

Mat Board” or “SECUROCK Roof Board” applied over the liner panel (Item 5) or Foamed Plastic (Items 6

and/or 6A). When used or used over Foamed Plastic bearing plate not required.

6. Foamed

Plastic

Insulation*:

6. (Rigid Insulation)*

—

Applied flat or tapered to maximum 10-in thick in combination with Item 6A or 6B.

Bearing plates required under panel attachment points. Optional if Cover Board (Item 5A) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "ISOGARD HD

Composite Board" or "Resista"

6A. Foamed Plastic (Rigid Insulation) — (Optional — Not Shown) — Placed on top of Item 6. Maximum 10

in. thick combination of Item 6. Bearing plates required under panel attachment points. Optional if Cover Board

(Item 5A) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — ISOGARD HD

6B. Foamed Plastic (Composite Board) — (Optional - Not Shown) ---Placed on top of "ISO 95+GL" (Item 6).

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — HailGard

7. Panel

Fasteners*

(Bearing

Plates*):

Plates to be 4 by 4 in. by No. 26 MSG min thick formed galvanized or stainless steel. Two 1/4 in. guide holes

located inline with panel clip guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

8. Purlins: No. 16 MSG min coated steel (33,000 psi min yield strength) spaced max 24 in. OC.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-3 – Construction No. 624

Uplift – Class 90

1. Panel*: Width 16 in. max with 1-1/2 in. high legs. Min 0.027 in. thick Rheinzink (zinc). Panels continuous over three or

more clips with no end laps. Panel ribs double seamed with an electric or manual seaming tool with seaming

operation to include upper tabs of panel clips (Item 2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

2. Panel

Fasteners*:

(Panel Clips)

—

Two part assembly, base 5 in. long, 1 in. wide, 0.42 in. high. Fabricated from min 0.0225 in.

thick 304 stainless steel. Upper tab 3 in. long, 0.42 in. wide, 1.786 in. high. Fabricated from min 0.0172 in. thick

304 stainless steel. Spaced a maximum of 12 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Stainless Steel Super Clip"

2A. Bearing Plate (Not Shown) — Plates used with panel screw fasteners (Item 3) under panel clip (Item 2)

to be 4 in. by 4 in. min No. 26 gauge stainless steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

3. Panel Clip

fasteners:

Fasteners used to attach panel clips (Item 2) to liner panel (Item 8) to be No. 12 pancake wafer head steel

screws. Length to penetrate steel deck a minimum of ¾ in. Two screws used per clip inserted into clip guide

holes.

4. Ventilation Mat: (Optional) — One layer Colbond "Enkamat 7010", loose layed.

14 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

5. Underlayment*: (Optional) — One layer Elk "VersaShield" with 2 in. side lap, loose laid.

6. Underlayment: (Optional) — One layer Type 30 organic felt with 2 in. side lap. Mechanically fastened to the liner panel (Item

8) per manufacturers recommendations.

7. Foamed

Plastic*:

7. (Rigid Insulation) — Applied flat or tapered to maximum 10-in thick combination of Item 7A. Bearing plates

required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

7A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 7. Maximum 10-

in thick combination of Item 6 . Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

7B. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board" applied over the liner panel (Item 8) or Foamed Plastic (Items 7

and/or 7A). When used or used over Foamed Plastic bearing plate not required.

8. Liner Panel: 8. No. 22 MSG min thick coated steel (min yield strength 33,000 psi). Min depth 1-½ in., max pitch 6 in.

fabricated to various profiles.

8A. Liner Panel Fasteners (Not Shown) — Liner panels (Item 8) to be fastened to structural supports (Item 9)

with puddle welds at every other valley, 12 in. OC.

9. Supports: Type K open web steel joists, 4 ft OC.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-3 – Construction No. 658

Uplift – Class 90

1. Purlin: Purlins used for liner panel (Item 2) support to be cold formed steel sections. As alternatives, structural

components (hot rolled beams, channels, open web joists, etc.) may be used. Min gauge and yield to depend

on design considerations for uplift loading. Purlins spaced max 6 ft. OC.

2. Liner Panel:

Optional:

Gypsum

Board

2. No. 22 MSG min thick coated steel (33,000 psi min yield strength). Min depth 1-1/2 in., max pitch 6 in.

Fabricated to various profiles. Fastened to supports 6 in. OC.

2A. Gypsum Board (Optional not shown) — Max thickness 5/8 in. Fastened to steel deck with same

fasteners (Item 6) used to attach the panel clips (Item 5) to the steel decking.

3. Insulation:

Optional:

Underlayment

3. (Rigid Insulation) — Applied flat or tapered to maximum 10-in thick combination of Item 3A. Bearing plates

required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "ISOGARD HD

Composite Board" or "Resista"

3A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 6. Maximum 10-in

thick combination of Item 3 . Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

3B. Underlayment (Optional not shown) — Underlayment attached over foamed plastic per manufacturer's

installation instructions.

4. Panels*: Min 24 MSG steel; width 20 in. max., 1-1/2 in. high at the ribs. Panels continuous over three or more clips with

no end-laps. A bead of sealant may be used at panel ribs. Panel ribs seamed with an electric seamer with

seaming operation to include upper portion of panel clip (Item 5).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

5. Panel Clips*: Two part assembly, base 3 in. wide, 5/8 in. high, with a 7/8 in. wide base leg having two 3/16 in. embossed

guide holes. Upper tab 1/2 in. wide folded over base forming two tabs. Both parts fabricated from 0.015 in. min

thick stainless steel. Clips spaced 24 in. OC. with seaming operation to include upper tabs of panel clips.

Bearing plates used with panel screw fasteners (Item 6) under panel clip to be 4 in. by 4 in. min No. 26 gauge

stainless steel or min No. 26 gauge galvanized steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Expansion Clip"

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

6. Panel

Fasteners:

(Screws)

—

Fasteners used to attach the panel clips to the steel decking to be No. 12 pancake wafer head

steel screws. Length to penetrate steel deck a minimum of 1/2 in. Two screws are to be used per clip.

7. Cover Board: (Optional) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be used) or min

7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in. min thickness

G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or "SECUROCK Roof Board"

applied over the liner panel (Item 2) or Foamed Plastic (Items 63and/or 3A). When used or used over Foamed

Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification M

ark for jurisdictions employing the UL or cUL

15 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Certification (such as Canada), respectively.

UC-3 – Construction No. 663

Uplift – Class 90

1. Panel*: Width 16 in. max with 1-1/2 in. high legs. No. 24 MSG min thick coated steel. Panels continuous with no end

laps. Panel ribs single seamed with an electric seaming tool with seaming operation to include upper tabs of

panel clips (Item 2).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3"

2. Fasteners: (Panel Clips) — Two part assembly, base 3 in. wide, 5/8 in. high, with a 7/8 in. wide base leg having two 3/16

in. embossed guide holes. Upper tab 1/2 in. wide folded over base forming two tabs. Both parts fabricated from

0.015 in. min thick stainless steel. Clips spaced maximum 18 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-3 Expansion Clip"

3. Fasteners: (Screws) — Fasteners used to attach panel clips (Item 2) to plywood decking (Item 5) to be No. 10 by minimum

1 in. long, without insulation and/or cover board, Pancake Type A. Two screws used per clip inserted into clip

guide holes.

4. Underlayment: (Optional — Not Shown) — Underlayment attached over Foamed Plastic (Item 8 and/or 8A) or Decking (Item 5)

or Cover Board (Item 9) Installed per manufacturer's recommendations.

5. Decking: Deck to be nominal 5/8 in. (19/32 in. actual) or ½-in (15/32-in actual) thickn plywood; Exposure 1, Grade B-C,

APA rated sheathing, confirming to requirements of DOC PS-1, with butt joints to be located over wood

supports (joist).

6. Deck

Fasteners

Fasteners used to attach plywood deck to supports to be 8d by 2-½ in. long ring shank common nails. Spacing

to be 6 in. OC at the edges and 6 in. OC in the interior.

7. Support Joist

& Fasteners*:

7. Nom 2 by 10 in. (1-1/2 by 9-1/8 in. actual) 42/20 square edged. No. 2 grade or better S-P-F, Hemlock Fir,

Douglas Fir or Southern Yellow Pine or equivalent. Spaced a max of 24 in. OC.

7A. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized or

stainless steel. Two 1/4 in. guide holes located in line with panel clip (Item 2) guide holes.

8. Insulation*: 8. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10-in thick combination of

Item 8A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

8A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 8. Maximum 10-in

thick combination of Item 8 . Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

9. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 5) or Foamed Plastic (Items 8 and/or 8A).

When used or used over Foamed Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions em

ploying the UL or cUL

Certification (such as Canada), respectively.

UC-4 Constructions:

UC-4 – Construction No. 376

Uplift – Class 90

1. Panel*: Width 12 min to 18 in. max with 1-1/2 in. high female legs; No. 24 MSG min thickness coated steel. A mounting

flange roll formed into male side of panel. Panels continuous over two or more spans with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-4"

2. Panel

Fasteners:

Fasteners used to attach the panels to the plywood deck to be No. 10-12 by minimum 1 in. long, without

insulation and/or cover board, No. 2 Phillips Drive, wafer-head, coated steel screws. A 5/8 in. OD nylon or other

plastic type washer, 0.030 in. thick to be used with each panel fastener. Fasteners spaced 18 in. OC with two

fasteners used at each location driven through adjacent guide holes in mounting flange.

3. Underlayment: (Optional) Underlayment attached over Foamed Plastic (Item 7and/or 7A) or Decking (Item 4) or Cover Board

(Item 9).

As an alternate, a self-adhering modified bitumen water proofing membrane may be used. Installed per

manufacturer's recommendations. When alternate is used, plywood joints need not be sealed.

4. Decking: Deck to be min 5/8 in. nom (19/32 in. actual) thickness plywood; Exposure 1, APA rated sheathing (42/20)

square edged. Butt joints to be located over purlins, side joints not blocked. All butt and side joints to be sealed

with a one part urethane caulk sealant - feathered outward from joint (note exception under Item 3 alternate).

5. Purlins:

Deck Supports

—

Spaced a max of 24 in. OC. Any of the following types may be used.

A. No. 18 MSG min thickness coated steel. (Min yield strength 33,000 psi).

16 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

B. Nom 2 by 6 in. (1-1/2 by 5-1/4 actual) No. 2 grade or better S-P-F, Hemlock Fir, Douglas Fir or Southern

Yellow Pine or equivalent.

C. Wood Trusses with a nom 2 by 4 in. (1-1/2 by 3-1/4 actual) upper chord of same grade as Item B.

6. Deck

Fasteners:

Fasteners used to attach plywood deck to supports to be used as follows:

A. For plywood to steel supports, to be No. 8-20 by 1-1/4 in. long No. 2 Phillips Drive Bugle Head Steel screws

with a S-12 TEKS 3 Super Point.

B. For plywood to wood support to be No. 8-18 by 1-7/8 in. long No. 2 Phillips Drive Bugle Head, "Hi-Low"

thread pattern with an "S" point.

Spacing for all fastener types to be 6 in. OC at the edges and 12 in. OC in the interior.

Refer to General Information, Roof Deck Construction (Roofing Materials and Systems) for Items not evaluated.

7. Insulation*: (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 7. Maximum 10 in. thick combination of

Item 7. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

8. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 4) or Foamed Plastic (Items 7 and/or 7A).

When used or used over Foamed Plastic bearing plate not required.

9. Plate

Fasteners*:

(Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

* Indicates such products shall bear the

UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-4 – Construction No. 399

Uplift – Class 90

1. Panel*: 0.021 in. thick copper (16 oz), width 12 to 14 in., 1-1/2 in. high female leg. A mounting flange roll-formed into

male side of panel. Panels continuous with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-4"

2. Panel

Fasteners:

(Screws)

—

Fasteners used to attach the panels to the plywood deck to be No. 10-12 by minimum 1 in. long,

without insulation and/or cover board, No. 2 Phillips Drive, wafer-head, stainless steel screws. A 5/8 in. OD by

0.030 in. nylon washer to be used with each panel fastener. Fasteners spaced 9 in. OC with fasteners inserted

in guide holes in mounting flange.

3. Red Rosin

Paper:

Rosin paper 9 mil thick. Side lap min 3 in. stapled to insulation with random spacing.

4. Underlayment: Optional — Underlayment attached over Foamed Plastic (Item 8 and/or 8A) or Decking (Item 5) or Cover Board

(Item 9).

5. Deck: Deck to be 3/4 in. nominal (23/32 in. actual) thickness plywood; Exposure 1, APA rated sheathing (42/20),

square edged. Butt joints to be located over purlins, side joints not blocked. All butt and side joints to be sealed

with a one part urethane caulk sealant — feathered outward from joint (note exception under Item 4 alternate).

6. Purlins:

Deck supports

—

Spaced a max of 24 in. OC. Any of the following types may be used:

A. No. 18 MSG min thickness coated steel (Min yield strength 33,000 psi).

B. Nominal 2 by 6 in. (1-1/2 by 5-1/4 actual) No. 2 grade or better S-P-F, Hemlock Fir, Douglas Fir or Southern

Yellow Pine or equivalent.

C. Wood trusses with a nominal 2 by 4 in. (1-1/2 by 3-1/4 actual) upper chord of same grade as Item B.

7. Deck

Fasteners:

Plywood Fasteners

—

Fasteners used to attach plywood deck to supports to be used as follows:

A. For plywood to steel supports, No. 8-20 by 1-1/4 in. long No. 2 Phillips Drive Bugle Head Steel screws with a

S-12 TEKS 3 Super Point.

B. For plywood to wood supports, No. 8-18 by 1-7/8 in. long No. 2 Phillips Drive Bugle Head, "Hi-Low" thread

pattern with an "S" point.

Spacing for all fastener types to be 6 in. OC at the edges and 12 in. OC in the interior.

Refer to General Information, Roof Deck Construction (Roofing Materials and Systems) for items not evaluated.

8. Insulation*: 8. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10 in. thick combination of

Item 8A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

8A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 8. Maximum 10-in

thick combination of Item 8. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

9. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

17 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 5) or Foamed Plastic (Items 8 and/or 8A).

When used or used over Foamed Plastic bearing plate not required.

10. Plate

Fasteners*:

(Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-4 – Construction No. 513A

Uplift – Class 60, Class 90

1. Panel*: Minimum No. 24 MSG thick coated steel or 0.032 inch thick aluminum maximum 18 inches wide with 1-1/2 inch

high legs. A mounting flange is formed into the male side of the panel. Panels continuous over three or more

panel screw fastener locations (Item 2) with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-4"

2. Panel

Fasteners:

Fasteners used to attach the panels (Item 1) to plywood deck (Item 4) to be 10 x 1" PC PD NW T17 steel or 10

x 1 PC T NW T17 stainless steel. Fasteners spaced maximum18 inches OC for Class 90, 30 inches OC for

Class 60 for aluminum panels in Item 1. Fasteners spaced 24 inches OC for Class 90, 30 inches OC for Class

60 for steel panels in Item 1.A total of two fasteners must be used in consecutive slots along fastener flange.

3. Underlayment: (Optional) — Underlayment attached over Foamed Plastic (Item 4A and/or 4B) or Decking (Item 4) or Cover

Board (Item 4C) —As an alternate, a self-adhering modified bitumen water proofing membrane may be used.

Underlayment is to be installed as per manufacturer's recommendations. When alternate is used, plywood

joints need not be sealed.

4. Deck,

Insulation* and

Fasteners*:

Plywood Decking

—

Minimum 7/16 OSB or 15/32 inch thick plywood; Exposure 1, APA rated sheathing

(42/20) or (32/16) respectively, square edged. Butt joints are to be located over purlins (Item 5). Side joints not

blocked. All butt and side joints to be sealed with a one part urethane caulk sealant-feathered outward from

joint (note exception under Item 3 alternate).

4A. Foamed Plastic* — (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10

in. thick combination of Item 4A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or

"Resista"

4B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4A. Maximum 10-

in thick combination of Item 4A . Bearing plates required under panel attachment points. Bearing plates not

required if foamed plastic not used (Item 4A or 4B).

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

4C. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board" applied over the plywood decking (Item 4) or Foamed Plastic (Items

4A and/or 4B). When used or used over Foamed Plastic bearing plate not required.

4D. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized

steel plate (for use with coated steel panels) or stainless steel plate (for use with aluminum panels). Two 1/4 in.

guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

5. Purlins:

Deck Supports

—

Spaced a max of 24 in. OC. Any of the following types may be used:

A. No. 16 MSG min thick coated steel. (33,000 psi min yield strength).

B. Nom 2 by 6 in. (1-1/2 by 5-1/4 in. actual). No. 2 grade or better S-P-F, Hemlock Fir, Douglas Fir or Southern

Yellow Pine or equivalent.

C. Wood trusses with a nom 2 by 4 in. (1-1/2 in. by 3-1/4 in. actual) upper chord of same grade as Item B.

6. Deck

Fasteners:

Fasteners used to attach plywood deck (Item 4) to supports (Item 5) to be as follows:

A. For plywoood to steel supports, to be No. 8-20 by 1-1/4 in. long No. 2 Phillips drive, bugle head steel screws

with an S-12 TEKS® 3 Super Point.

B. For plywood to wood supports to be No. 8-18 by 1-7/8 in. long No. 2 Phillips drive, bugle head steel screws

with a "Hi-Low" thread pattern and an "S" point.

Spacing for all fastener types to be 6 in. OC at the edges and 12 in. OC in the interior.

Refer to General Information Roof Deck Construction, fors items not evaluated.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

18 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-4 – Construction No. 377

Uplift – Class 90

1. Panels*: Width 12 min to 18 in. max; with 1-1/2 in. high female leg. No. 24 MSG min coated steel. A mounting flange is

roll formed into male side of panel. Panels continuous over two or more spans with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-4"

2. Panel

Fasteners:

Fasteners used to attach the panels to the steel deck to be No. 12-15 No. 3 Phillips Drive Truss head steel

screws with a "S" point. Length to be 3/4 in. longer than overall thickness of roof deck length. A 5/8 in. OD

nylon or other plastic type washer, 0.030 in. thick to be used with each panel fastener. Fasteners spaced 18 in.

OC with two fasteners used at each location. Fasteners used with a bearing plate (Item No. 6).

3. Underlayment: (Optional)—Underlayment attached over Foamed Plastic (Item 5 or 5A), Liner Panel (Item 4) or Cover Board

(Item 5B).

4. Deck:

Liner Panel

—

Min thickness No. 22 MSG coated steel (33,000 min yield strength). Min depth 1-1/2 in., max

pitch 6 in. Fabricated to various profiles.

5. Insulation:

5. Foamed Plastic

—

(Rigid Insulation) — (Optional, not shown) — Applied flat or tapered to maximum 10 in.

thick combination of Item 5A. Bearing plates required under panel attachment points. Optional if Cover Board

(Item 5B) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "ISOGARD

HD Composite Board" or "Resista"

5A. Foamed Plastic — (Rigid Insulation) — (Optional, not shown) — Placed on top of Item 5. Maximum 10 in.

thick combination of Item 5. Bearing plates required under panel attachment points. Optional if Cover Board

(Item 5B) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

5B. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board"applied over the liner panel (Item 4) or Foamed Plastic (Items 5 and/or

5A). When used or used over Foamed Plastic bearing plate not required.

6. Plates*: (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

7. Purlins: No. 18 MSG min coated steel (min yield strength 33,000 psi) spaced max 24 in. OC.

Refer to General Information, Roof Deck Constructions, (Roofing Materials and Systems Directory) for items

not evaluated.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-4 – Construction No. 657

Uplift – Class 90

1. Supports: (Joists, not shown) — Nominal 2 by 10 in. graded dimensional lumber, No. 2 or better. Spaced 24 in. OC max.

2. Deck: Nominal 5/8 in. (19/32 in. actual) or ½-in (15/32-in actual) plywood, Grade B-C, APA rated. Fastened to

supports (joists) using 8d by 2-1/2 in. long ring shank nails. Spaced 6 in. OC max at the butt ends and 6 in. OC

max in the field. As an alternate 7/16 in. thick PS-2 rated oriented strand board OSB. Fastened to supports

(joists) using No. 8 by 2-1/2 in. long coarse thread steel screws. Spaced 12 in. OC max. at the butt ends and 12

in. OC max. in the field.

3. Vapor Barrier: (Optional) — Underlayment attached over Foamed Plastic (Item 6 and/or 6A) or Decking (Item 2) or Cover

Board (Item 8).

4. Panels*: Min 26 MSG steel or min 0.032 in. thick aluminum; width 9-3/4 in. max, 1-3/8 in. high at the ribs. A bead of

sealant may be used at panel ribs.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-4"

5. Panel

Fasteners:

(Screws) — Fasteners used to attach the panels to the plywood or OSB decking to be minimum 1 in. long,

without insulation and/or cover board, 10 x 1" PC PD NW T17 steel or 10 x 1" PC T NW T17 stainless steel

screws used with a 5/8 in. OD nylon or other plastic washer 0.030 in. thick. Two screws are to be used at 12 in.

O.C.

6. Insulation*: 6. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10-in thick combination of

Item 6A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or

"Resista"

6A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 6. Maximum 10-in

thick combination of Item 6 . Bearing plates required under panel attachment points. Bearing plates not

required if foamed plastic no used Item 6 or 6A)

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

7. Bearing (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel plate (for use with coated

19 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Plates*: Steel panels) or stainless steel plate (for use with aluminum panels). Two 1/4 in. guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

8. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the decking (Item 2) or Foamed Plastic (Items 6 and/or 6A). When

used or used over Foamed Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-4 – Construction No. 513

Uplift – Class 90

1. Panel*: Width 12 in. min to nominal 18 in. max with 1-1/2 in. high legs. Minimum No. 24 MSG thick coated steel or

minimum 0.032 in. thick aluminum. A mounting flange is formed into the male side of the panel. Panels

continuous over three or more panel screw fastener locations (Item 2) with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-4"

2. Fasteners:

2. (Screws)

—

Fasteners used to attach the panels (Item 1) to liner panels (Item 4) to be No. 12-15, No. 3

Phillips drive, truss-head, coated steel screws with an "S" point. Length to be 3/4 in. longer than overall

thickness of roof deck. A 5/8 in. OD nylon or other plastic washer 0.030 in. thick to be used with each screw.

Fasteners spaced 12 in. OC with two fasteners used at each location. Fasteners used to attach liner panels to

supports (Item 7) to be No. 12-14 by 1 in. long self-drilling, self-tapping, hex-washer-head plated steel screws.

Fasteners spaced 6 in. OC.

2A. Fasteners (Screws) — Fasteners used to attach the panels (Item 1) to HailGard Insulation (Item 5B) to be

10 x 1" PC PD WOW T17 steel or 10 x " PC T WOW T17 stainless steel screws.

3. Underlayment

& Thermal

Barrier:

3. Underlayment

—

(Optional) — Underlayment attached over Foamed Plastic (Item 5 or 5A), Liner Panel

(Item 4) or Cover Board (Item 6A) —Installed per manufacturer's recommendations.

3A. Gypsum Board — (Optional Not Shown) — Max thickness 5/8 in. Fastened to steel deck with same panel

fasteners used to attach the metal roof deck panels to the steel decking (Item 4).

4. Deck:

Liner Panel

—

No. 22 MSG min thick coated steel (33,000 psi min yield strength). Min depth 1-1/2 in., max

pitch 6 in. fabricated to various profiles. Fastened to supports 6 in. OC.

5. Insulation*: 5. (Rigid Insulation) — Applied flat or tapered to maximum 10 in. thick combination of Item 5A. Bearing plates

required under panel attachment points. Optional if Cover Board (Item 6A) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "ISOGARD

HD Composite Board" or "Resista"

5A. Insulation* — (Rigid Insulation) — (Optional, Not Shown) — Placed on top of Item 5. Max 10 in. thick

combination of Item 5. Bearing plates required under panel attachment points. Optional if Cover Board (Item

6A) is used.

5B. Insulation* — (Rigid Insulation) — (Optional, Not Shown) — HailGard placed on top of Item 4 or Item 5 is

mechanically fastened into Item 4 with 8 Firestone HailGard HD Fasteners per 4X8 board. Max 10 in. thick in

combination of Item 5.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

6. Bearing

Plates* &

Cover Board:

6. (Bearing Plates)*

—

Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel plate (for use with coated

steel panels) or stainless steel plate (to be used with aluminum panels). Two 1/4 in. guide holes. Two 1/4 in.

guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

6A. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board" applied over the plywood decking (Item 4) or Foamed Plastic (Items 5

and/or 5A). When used or used over Foamed Plastic bearing plate not required.

7. Purlins: No. 116 MSG min coated steel (33,000 psi min yield strength) spaced max 24 in. OC.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

20 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-4 – Construction No. 378

Uplift – Class 90

1. Panels*: Width 12 min to 18 in. max with 1-1/2 in. high female legs; No. 24 MSG min thickness coated steel. A mounting

flange roll formed into male side of panel. Panels continuous over two or more spans with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-4"

2. Panel

Fasteners:

Fasteners used to attach panels to hat channels (Item No. 3) to be No. 10-16 by 1 in. long self-drilling, self-

tapping, hex-head plated steel screws. Fasteners spaced 18 in. OC with two fasteners used at each location

driven through adjacent guide holes in mounting flange. A 5/8 in. OD nylon or other plastic type washer, 0.030

in. thick to be used with each fastener.

3. Hat Channel: No. 16 MSG min thickness coated steel. Channels 1 in. deep and 3-1/4 in. total width. Flanges, 3/4 in. web, 1-

3/4 in. (min yield strength 33,000 psi). Spaced 18 in. OC hat channels fastened to purlins (Item No. 5) with 2

No. 12-14 by 3/4 in. self-drilling, self-tapping, hex-head plated steel screws.

4. Vapor

Retarder:

(Optional — Not Shown) — Min 3 mil vinyl sheeting.

5. Purlins: No. 18 MSG min gauge coated steel (33,000 psi min yield strength).

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-6 Constructions:

UC-6 – Construction No. 655

Uplift – Class 90

1. Joists: (Joists, not shown) — Nominal 2 by 10 in. graded dimensional lumber, No. 2 or better. Spaced 24 in. OC max.

2. Deck: Nominal 5/8 in. (19/32 in. actual) plywood, Grade B-C, APA rated. Fastened to supports (joists) using No. 8 by

2-1/2 in. long coarse thread steel screws. Spaced 6 in. OC max. at the butt ends and 12 in. OC max. in the

field. When installed with aluminum roofing panels ½-in (15/32-in actual) B-C exterior plywood can be used.

3. Panels*,

Underlayment

& Insulation:

3. Panels – Min 24 MSG steel or min 0.032 in. thick aluminum; width 18 in. max., 2 in. high at the ribs. Panels

continuous over three or more clips with no end-laps. A bead of sealant may be used at panel ribs. Panel ribs

seamed with an electric seamer with seaming operation to include upper portion of panel clip (Item 4).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6", "UC-6 HD"

3A. Underlayment — (Optional — Not Shown) — Underlayment attached over deck as per manufacturer's

installation instructions.

3B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10-

in thick combination of Item 3C , placed on top of the wooden deck. Bearing plates required under panel

attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "ISOGARD HD

Composite Board" or "Resista"

3C. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 3. Maximum 10-in

thick combination of Item 3B . Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD".

4. Fasteners*:

(Panel Clips)

—

Two piece assembly; a base of stainless or coated steel and an interlocking upper tab

fabricated from stainless or coated steel. Two 1/4 in. guide holes located in the base. Clips spaced 30 in. OC

max when used with aluminum panels or 36 in. OC max when used with steel panels. Bearing plates (Item 6)

required when Foamed Plastic is used without cover board (Item 7).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — ""UC-6 Low Float Clip", "UC-6 Super Clip""

5. Panel

Fasteners:

(Screws) — Fasteners used to attach the panel clips to the plywood decking to be No. 12 steel

screws, long enough to penetrate the wood deck by 1". Two screws are to be used per clip.

6. Bearing

Plates:

(Not Shown) — Bearing plate 4-in by 4-in by min 26 MSG galvanized or stainless steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

7. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the roof deck (item 2) or Foamed Plastic. When used or used over

Foamed Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

21 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-6 – Construction No. 652

Uplift – Class 90

1. Panels*: No. 24 MSG min gauge coated steel. Panel width 18 in. max; height at female rib 2 in., at male rib 1-3/4 in.

Panels seamed with an electric or hand seamer to 180°. A bead of sealant may be used at ribs.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6", "UC-6 HD"

2. Fasteners*: (Panel Clips) Two piece assembly; a base of stainless or coated steel and an interlocking upper tab fabricated

from stainless or coated steel. Two 1/4 in. guide holes located in the base. Clips spaced 30 in. OC located over

bearing plate (Item 5).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6 Low Float Clip", "UC-6 Super Clip"

3. Fasteners:

(Screws)

—

Fasteners used to attach the panel clips to the liner panel (Item 6) to be No.12 self-drilling, self-

tapping, pancake head plated steel screws. Two fasteners used per clip. Fasteners shall be of sufficient length

to penetrate the liner panel (Item 6) by min 3/4 in.

4. Insulation*: 4. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10-in thick combination of

Item 4A. Bearing plates required under panel attachment points. Optional if Cover Board (Item 7) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL", "ISOGARD

HD Composite Board" or "Resista"

4A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4.

Maximum 10-in thick combination of Item 4 . Bearing plates required under panel attachment

points. Optional if Cover Board (Item 7) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

5. Bearing Plate: Bearing Plate 4-in by 4-in by min 26 MSG galvanized steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

6. Deck:

Liner Panel

—

Structural steel deck, No. 22 MSG min thick, coated steel (33,000 psi min yield strength). Min

depth 1-1/2 in.

7. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck ", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the liner panel (Item 6) or Foamed Plastic (Items 4 and/or 4A). When

used or used over Foamed Plastic bearing plate not required.

* Indica

tes such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-6 – Construction No. 653

Uplift – Class 90

1. Panels*: Min 0.032 in aluminum or 24 MSG steel. Panel width 18 in max; height at female rib 2 in., at male rib 1-3/4 in.

Panels seamed with an electric or hand seamer to 180°. A bead of sealant may be used at ribs.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-6", "UC-6 HD"

2. Fasteners*: (Panel Clips) Two piece assembly; a base of stainless or coated steel and an interlocking upper tab fabricated

from stainless or coated steel. Two 1/4 in. guide holes located in the base. Clips spaced 30 in. OC located over

plywood or OSB cover board (Item 5)

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6 Low Float Clip", "UC-6 Super Clip"

3. Fasteners:

(Screws)

—

Fasteners used to attach the panel clips (item 2) to the plywood or OSB cover board (item 5) to be

No.10- 10x1 - AS 1-in or 1-1/2 in. steel screws. Two fasteners used per clip. Fasteners used to attach plywood

or OSB (Item 5) to liner panel (Item 6) HD Hailgard Fasteners with pattern of 24 per 4-ft by 8-ft board.

4. Insulation*:

4. (Rigid Insulation)*

—

Min thickness 1-in. Joints of multiple layers staggered between layers.

4A. Foamed Plastic* — (Rigid Insulation) — Applied flat or tapered to maximum 10-in thick combination of

Item 4B.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

4B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4A. Maximum 10-

in thick combination of Item 4A.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

5. Cover Board: Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be used) or min 7/16 in thick

OSB, DOC PS-2 rated.

6. Deck:

Liner Panel

—

Structural steel deck consisting of No. 22 MSG min thick coated steel (33,000 psi min yield

strength). Min depth 1-1/2 in.

7. Opt. Cover

Board:

(Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the liner panel (Item 6) under or in lieu of Items 4, 4A and 4B.

22 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

8. Bearing Plate: (Optional) — Bearing Plate 4-in by 4-in by min 26 MSG galvanized steel for use with clip fasteners (Item 3).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — UC Bearing Plate

* Indicates such products shall bear th

e UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-6 – Construction No. 571A

Uplift – Class 90

1. Panel*: Min 0.040 in. thick aluminum. Panel width 16 in., height of female rib 2 in., at male rib 1-3/4 in. Panels

continuous over two or more spans with no end laps. Panels seamed with an electric or hand seamer to 180°.

A bead of sealant may be used at ribs.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6", "UC-6 HD"

2. Fasteners*: (Panel Clips)—Two piece assembly; a base of stainless or coated steel and an interlocking upper tab,

fabricated from stainless or coated steel. Two 1/4 in. guide holes located in the base. Clips spaced 36 in. OC

located over purlins.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6 Low Float Clip", "UC-6 Super Clip"

3. Fasteners:

(Screws)

—

Fasteners used to attach the panel clips (Item 2) to the purlins (Item 4) to be No. 1/4-14 by 7/8 in.

long, self-drilling, self-tapping, hex-washer head plated steel screws. Two fasteners used per clip.

4. Purlins: No. 16 MSG min gauge steel (50,000 psi min yeld strength). Spacing to be maximum 3 ft, 0 in. OC.

* Indicates such product

s shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-6 – Construction No. 571

Uplift – Class 90

1. Panel*: No. 22 MSG min gauge coated steel. Panel width 16 in.; height at female rib 2 in., at male rib 1-3/4 in. Panels

continous over two or more spans with no end laps. Panels seamed with an electric or hand seamer to 180°. A

bead of sealant may be used at ribs.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6", "UC-6 HD"

2. Fasteners*: (Panel Clips) Two piece assembly; a base of stainless or coated steel and an interlocking upper tab , fabricated

from stainless or coated steel. Two 1/4 in. guide holes located in the base. Clips spaced 48 in. OC located over

purlins.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6 Low Float Clip" , "UC-6 Super Clip"

3. Fasteners:

(Screws)

—

Fasteners used to attach the panel clips (item 2) to the purlins (item 4) to be No. 1/4 - 14 by 7/8 in.

long, self-drilling, self-tapping, hex-washer head plated steel screws. Two fasteners used per clip.

4. Purlins: No. 16 MSG min gauge steel (50,000) psi. min yield strength). Spacing to be maximum 4 ft, 0 in. OC.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-6 – Construction No. 670

Uplift – Class 90

1. Fasteners*:

(Panel Clips)

—

One piece assembly, No. 24 MSG min thickness, 3-1/2 in. wide, 1-15/16 in. high. Clip spacing

to be 30 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6 HI-Float Clip"

2. Panel*: No. 24 MSG min gauge coated steel. Panel width 18 in. max., 10 in. min. Rib height 1-3/4 in. at female side. A

bead of sealant may be used at panel side joints. Panels continuous over three or more clips with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-6"

3. Fasteners: For attaching panel clips to steel deck, two number 12 by 1 inch Phillips Head TEK3 self-tapping corrosion

resistant coated steel screws supplied by roof deck manufacturer. Screws shall penetrate steel deck min 1/2 in.

4. Steel ZEE

Purlins:

16 gage ZEEs purlins 10" by 2-1/2" were placed 30" OC. Purlin clips were used to fasten the ZEE purlins

(joists) to the surrounding CEE Purlins.

5. Steel CEE

Purlins:

(Not Shown) 16 gage ZEEs purlins 10" by 2-1/2" were placed 30" OC. Purlin clips were used to fasten the ZEE

purlins (joists) to the surrounding CEE Purlins.

6. Purlin Clips: (Not Shown) 16 gage Purlin clips were used to fasten the ZEE purlins (joists) to the surrounding CEE Purlins.

The clips are typically welded to the CEE Purlin and the ZEE purlins can be either bolted or welded to the clips.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

23 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-7 Constructions:

UC-7 – Construction No. 660

Uplift – Class 90

1. Joists: (Joists, not shown) — Nominal 2 by 10 in. graded dimensional lumber, No. 2 or better. Spaced 24 in. OC max.

2. Deck: Nominal 5/8 in. (19/32 in. actual) or ½-in (15/32-in actual) plywood, Grade B-C, APA rated. Fastened to

supports (joists) using No. 8 by 2-1/2 in. longcoarse thread steel screws. Spaced 6 in. OC max. at the butt ends

and 6 in. OC max. in the field.

3. Underlayment:

(Optional)

—

Underlayment attached over deck as per manufacturer's installation instructions.

4. Panels*: Min 24 MSG steel width 12 in. max., 2 in. high at the ribs. Panels continuous over three or more clips with no

end-laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-7"

5. Fasteners*: (Panel Clips) — One piece assembly 3 in. long fabricated from No. 24 MSG coated steel. Two 1/4 in. guide

holes located in the base. Clips spaced 12 in. OC max.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-7 Clip"

6. Fasteners: (Screws) — Fasteners used to attach the panel clips to the plywood decking to be minimum 10 x 1" PC PD

WOW T17 steel screws. Two screws are to be used per clip.

7. Insulation*: 7. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10-in thick combination of

Item 7A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or

"Resista"

7A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 7. Maximum 10-in

thick combination of Item 7. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

8. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 2) or Foamed Plastic (Items 7 and/or 7A).

When used or used over Foamed Plastic bearing plate not required.

9. Fasteners*: Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

* Indicates such products shall bear the UL or cUL Certification Mark for

jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 Constructions:

UC-14 – Construction No. 414

Uplift – Class 90

1. Panels*: No. 24 MSG min coated steel panels, 18 in. max width, 1-3/4 in. high at female side rib. Panels continuous over

three or more clips with no endlaps. A bead of sealant may be used at panel side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 in. wide, 1-7/8 in. high. Min thickness 18 MSG. Clips spaced 36 in.

OC, max, fastened to plywood deck.

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item 2) to plywood to be No. 10-12 by minimum 1 in. long,

without insulation and/or cover board, pancake head, No. 2 Phillips drive, A-point, coated steel screw. Min two

fasteners per clip to be used.

4. Underlayment: (Optional) — Underlayment attached over Foamed Plastic (Item 8 and/or 8A) or Decking (Item 5) or Cover

Board (Item 10).

As an Alternate-A self-adhering modified bitumen water proofing membrane may be used, installed per

manufacturer's instructions. Note - when alternate is used the plywood joints need not be sealed.

5. Deck: Plywood decking to be graded per PS-1 specifications, 19/32 in. thick, exposure 1, APA Rated Sheating

(42/20) square edged. Butt ends not blocked. All butt and side joints to be sealed with a one part urethane

caulk sealant applied with a caulking gun and feathered outward from the joint. (Note exception under Item No.

4, Alternate).

6. Supports: Spaced max of 24 in. OC. Any of the following types may be used to support the plywood decking:

a) Nom 2 by 6 in., No. 2 grade or better S-P-F, Hemlock Fir, Douglas Fir or Southern Yellow Pine or equivalent.

b) Wood trusses with a nom 2 by 4 in. upper chord of the same grade as Item a.

c) No. 22 MSG min cold formed coated steel (min yield to be 33,000 psi).

7. Fasteners: Fasteners used to attach the plywood deck to the supports to be as follows:

a) For plywood-to-wood supports No. 8-18 by 1-7/8 in. long bugle-head steel screws with a No. 2 Phillips drive,

a "Hi-Low" thread pattern and an "S-Point" .

24 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

b) As an alternate to Item a, 8d common nails may be used.

c) For plywood-to-steel supports for a steel thickness less than No. 20 MSG No. 7-19 by 1-1/4 in. long bugle-

head steel screws with a No. 2 Phillips head drive "Hi-Low" threads and an "S-Point" . For a steel thickness

greater than No. 20 MSG to No. 16 MSG, No. 6-20 by 1-1/4 in. long bugle-head steel screws with a No. 2

Phillips drive and a S12 (TEKS/3) (R) point.

Spacing: Fastener spacing for all fastener types to be 6 in. OC at the plywood edges and 12 in. OC in the

interior.

8. Insulation* 8. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10 in. thick combination of

Item 8A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or

"Resista"

8A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4A. Maximum 10-

in thick combination of Item 8 . Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

9. Fasteners*: (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes

located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC Bearing Plate"

10. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 5) or Foamed Plastic (Items 8 and/or 8A).

When used or used over Foamed Plastic bearing plate not required.

* Indicates such products sha

ll bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 436

Uplift – Class 90

1. Panels*: No. 24 MSG min coated steel. Max panel width 18 in., rib height 1-3/4 in. Panels continuous over two or more

spans. Endlap for panels to be overlapped 6 in. A bead of sealant may be used at panel ends and side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Cl

ips)

—

One piece assembly, 3-1/2 in. wide by 1-7/8 in high. Clip spacing to be 48 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

3. Fasteners:

(Screws)

—

Screws used to attach the panel clips to Substructure (Item 4) to be No. 10 by minimum 1 in long,

without insulation and/or cover board, Pancake head wood screws with a No. 2 Phillips head or 10x1 in., 1/4 in.

Hex Head Woodgrip. Two screws per clip.

Screws used to attach Substructure (Item 4) to wood trusses or joists (Item 6) to be No. 8 by 2 in. Bugle head

screws. As an optional fastener, 2-1/2 in. long 8d common deformed shank nails may be used. Fasteners used

at endlaps to be 14x1 in. Type AB or 10x1 in. woodgrip.

When light gauge structural steel joists are used, screws to be No. 12 by 1-5/8 in. long with a Phillips head.

Spacing of screws to be 6 in. OC at plywood or OSB ends and 12 in. OC at interior joists.

4. Substructure:

(Plywood or OSB)

—

Plywood decking (PS-1) or oriented strand board (OSB) (PS-2) to be a nom 5/8 in. thick,

exposure sheathing span C-D, 40/20 plywood. (All butt joints to be sealed against leakage by using tape and/or

caulking). In lieu of plywood, 1 in. tongue and groove decking may be used.

5. Moisture

Barrier:

(Optional) — Any suitable membrane to protect Substructure (Item 4).

6. Joists: Joists, spaced at 2 ft, 0 in. OC max (when tongue and groove decking is used, joist spacing may be 30 in. OC

max), may be one of the following:

A. Nom 2 by 6 in. wood joists, No. 2 or better.

B. Nom 2 by 4 in wood when used on a top chord of a wood truss, No. 2 or better.

C. Light gauge structural steel framing with the member against the plywood to be a min No. 22 MSG coated

steel.

7. Batten Clips

and Cap*

The followed items may be used in conjuction with the "Design-Lok" panel (Item 1).

A. Batten Clips* — Slipped over ribs formed by roof deck panels. One piece assembly formed to engage ribs

of "Design-Lok" panels (Item 1) and " Design-Lok Batten Cap" (Item B) spaced 48 in. OC.

METAL SALES MANUFACTURING CORPORATION (View Classification) — Vertical Seam

Batten Clip

B. Batten Cap* — Slipped over batten clip (Item A), formed to snap over and engage batten clip.METAL

SALES MANUFACTURING CORPORATION (View Classification) — Vertical Seam Batten Cap

8. Insulation*: 8. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10 in. thick combination of

Item 8A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — " ISO 95+ GL" or "Resista"

25 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

8A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 8. Maximum 10-in

thick combination of Item 8. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — " ISOGARD HD"

9. Fasteners*: (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes

located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

10. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 4) or Foamed Plastic (Items 8 and/or 8A).

When used or used over Foamed Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 508

Uplift – Class 90

1. Panel*: 0.032 in. min thick aluminum; 16 in. wide, 1-3/4 in. high at the rib. Panels continuous over three or more clips

with no end laps. A bead of sealant may be used at panel side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 in. wide, 1-7/8 in. high with a 1-3/8 in. wide horizontal leg. No. 18

MSG min thick galvanized or stainless steel. Two 1/4 in. guide holes located in horizontal leg. Clips spaced 18

in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item 2) to plywood (Item 5) to be No. 10-12 by minimum 1 in.

long, without insulation and/or cover board, No. 1 Phillips drive, bugle head coated steel wood screws. Two

screws used per clip inserted through 1/4 in. diameter guide holes.

4. Underlayment: (Optional) — Underlayment attached over Foamed Plastic (Item 8 and/or 8A) or Decking (Item 5) or Cover

Board (Item 10).

5. Decking: Plywood decking to be rated per PS - 1 specification, nominal 5/8-in (19/32 in. actual) or ½-in (15/32-in. actual)

thick. Butt ends not blocked.

6. Supports: Spaced max 24 in. OC. Any of the following types may be used to support the plywood decking:

a) 2 by 6 in., min No. 2 grade A.F.P.A. S-P-F Hemlock Fir, Douglas Fir or Southern Pine or equivalent.

b) Wood trusses with a nominal 2 by 4 in. upper chord of the same grade as Item a.

c) No. 22 MSG min thick cold formed coated steel (min yield strength to be 33,000 psi).

7. Deck

Fasteners:

(Not Shown) — Fasteners used to attach the plywood deck to the supports to be as follows:

a) For plywood-to-wood supports, No. 8-18 by 1-7/8 in. long bugle-head steel screws with a No. 2 Phillips drive,

a "Hi-Low" thread pattern and an "S-Point" .

b) As an alternate to Item a, 8d by 2-1/2 in. long deformed shank common nails may be used.

c) For plywood-to-steel supports for a steel thickness less than No. 20 MSG, No. 7-19 by 1-1/4 in. long bugle-

head steel screws with a No. 2 Phillips head drive "Hi-Low" threads and an "S=Point" . For a steel thickness

greater than No. 20 MSG to No. 16 MSG, No. 6-20 by 1-1/4 in. long bugle-head steel screws with a No. 2

Phillips drive and an S12 (TEKS/3) ® point.

Spacing: Fastener spacing for all fastener types to be 6 in. OC at the plywood edges and 12 in. OC in the

interior.

8. Insulation*: 8. (Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10 in. thick combination of

Item 8A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

8A. Foamed Plastic — (Optional — Not Shown) — Placed on top of Item 8. Maximum 10-in thick combination

of Item 8. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

9. Fasteners*: (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel.Two 1/4 in. guide holes

located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

10. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 5) or Foamed Plastic (Items 8 and/or 8A).

When used or used over Foamed Plastic bearing plate not required.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

26 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-14 – Construction No. 303

Uplift – Class 90

1. Panels*: No. 24 MSG min thickness coated steel. Panel width 18 in. max., 10 in. min. ribs height 1-3/4 in. at female side.

Panels continuous over three or more clips with no end laps. A bead of sealant may be used at panel side

joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

2. (Panel Clips)

—

One piece assembly, No. 24 MSG min thickness, 3-1/2 in. wide, 1-15/16 in. high. Clip

spacing to be 48 in. OC. Clips to interface with Item 2A (bearing plate).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

2A. Roof Deck Fasteners* — (Bearing Plate) — One piece assembly, No. 24 MSG min thickness steel, 4-1/2

in. wide, 6 in. long or No. 24 MSG minimum thickness, 5 in. wide, 3-7/8 in. long.

2B. Bearing Plate — (Not Shown) — To be used with "Lock-Seam UL 90 Clip", "Permaseam Clip", "K-Lok

Structural Clips" or "MP-175 Clip" only, (Item 2). Bearing plates to be 16 MSG min coated steel, 3-7/8 wide by 5

in long (50,000 psi min yield strength).

2F. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized

steel. Two 1/4 in. guide holes located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

3. Fasteners: 3.

Panel Fasteners

—

(Screws)

—

Fasteners used to attach panel clips and bearing plates (Items 2 & 2A)

through rigid insulation and optional Cover Board (Item 7) into light gauge steel deck (Item No. 5) to be No. 14

truss head type with No. 3 Phillips drive, self-drilling steel screws. Two screws per clip to be used, inserted

through 1/4 in. diam guide holes. Fasteners to penetrate liner panel 3/4 in. min.

3A. Panel Fasteners — (Screws) — (Not Shown) — When no Rigid Insulation (Item 4) is used, No. 10-16 by

min 1 in. long TEK 3 Carbon pancake head, self-drilling, self-tapping screws to be used. When rigid insulation

is used, No. 14-13 by varying lengths, DP1, carbon, pancake-head, Square/Phillips Head screws to be used.

Two fasteners per clip to be used for either type.

4. Insulation*: 4.

Foamed Plastic

—

(Rigid Insulation)

—

Min thickness 1 in., max thickness 4-1/2 in. Density to be a min of

1.8 pcf. or see products Classified under TJBX Category.

4A. Foamed Plastic* — (Rigid Insulation) — In lieu of Item 4, applied flat or tapered to maximum 10 in. thick

combination of Item 4B. Bearing plates required under panel attachment points. Optional if Cover Board (Item

7) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

4B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4A. Maximum 10

in. thick combination of Item 4A. Bearing plates required under panel attachment points. Optional if Cover

Board (Item 7) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

5. Deck:

Liner Panel

—

Min thickness No. 22 MSG. Coated steel (33000 psi) min yield strength min depth 1-1/2 in.,

max pitch 6 in. fabricated to various profiles.

6. Underlayment: (Not Shown) — One ply of 30 lb roofing felt or one layer of bituminous resin type water proofing membrane or

self-adhering underlayment, installed per manufacturer's instructions.

7. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the liner panel (Item 5) in lieu of Foamed Plastic (Item 4) or over

Foamed Plastic (Items 4, 4A and/or 4B and 4C). When used or used over Foamed Plastic bearing plate not

required.

8. Supports: (Not Shown) — Used to support liner panels, spaced per deck manufacturer's specifications for uplift.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 448

Uplift – Class 90

1. Panels*: No. 24 MSG min coated steel. Max panel width 18 in., rib height 1-3/4 in. Panels continuous over three or more

spans. Endlaps for panels to be overlapped 6 in. and to include back up plate (Item 2B). A bead of sealant may

be used at panel ends and side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

2. (Panel Clips)

—

One piece assembly, 3-1/2 in. wide by 1-7/8 in. high. Clip spacing to be 48 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

27 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Classification) — "UC-14 Clip"

2A. Bearing Plate — (Optional) — To be used in lieu of plywood or OSB (Item 4A) with rigid insulation (Item 4).

Bearing plates to be 16 MSG min coated steel or No. 24 MSG minimum thickness, 5 in. wide, 3-7/8 in. long.

Located under each clip (Item 2) for support.

2B. Endlap Back-Up Plate — (Not Shown) — No. 16 MSG min coated steel, width of back up plate to

correspond to width of panel. Two 1 in. wide by 3/4 in. long tabs are used for sliding over end of panels.

3. Fasteners:

Panel Fasteners

–

(Screws)

—

Screws used to attach the panel clips and bearing plates (Items 2 and 2A)

through rigid insulation and into metal deck (Item 5). Screws to be No. 14 Truss head with No. 3 Phillips drive.

Length to be a min of 1/2 in. longer than thickness of rigid insulation and metal deck. Two screws per clip.

Fasteners used at endlaps to be one of the following: 14x1 in. Type AB self-tapper; 14x1-1/4 in. Hex washer

head self-driller; 14x1 in. Type AB Phillips stainless steel self-tapper.

4. Insulation*: 4.

Rigid Insulation

—

(Optional) — Foamed plastic, max thickness 10 in. Density to be a min of 1.5 PCF.

4A. Foamed Plastic* — (Rigid Insulation — Optional) — In lieu of Item 4, applied flat or tapered to maximum

10 in. thick combination of Item 4B. Bearing plates required under panel attachment points. Optional if Cover

Board (Item 4D) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

4B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4A. Maximum 10-

in thick combination of Item 4A. Bearing plates required under panel attachment points. Optional if Cover Board

(Item 4D) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

4C. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized

steel. Two 1/4 in. guide holes located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

4D. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board" applied over the liner panel (Item 5) in lieu of Foamed Plastic (Item 4)

or over Foamed Plastic (Items 4, 4A and/or 4B). When used or used over Foamed Plastic bearing plate not

required.

5. Deck: No. 22 MSG min thickness coated steel. Min yield strength 33 KSI. Min depth 1-1/2 in. Max pitch 6 in.

6. Vapor Barrier: 6.

Vapor Barrier

—

(Optional) — Installed on top of metal deck (Item 5) or on top of gypsum wallboard (Item

4B) if used. Min 6 mil plastic sheet.

6A. Waterproof Membrane — (Optional) — (Not Shown) — Used to protect plywood or OSB (Item 4A).

Installed under panels (Item 1).

7. Supports: (Not Shown) — Used to support metal deck, spaced per deck manufacturer's specifications.

8. Batten Clips

and Cap*:

The followed items may be used in conjunction with the "Design-Lok" panel (Item 1).

A. Batten Clips* — Slipped over ribs formed by roof deck panels. One piece assembly formed to engage ribs

of "Design-Lok" panels (Item 1) and "Design-Lok Batten Cap" (Item B) spaced 48 in. OC.

METAL SALES MANUFACTURING CORPORATION (View Classification) — Vertical Seam Batten Clip

B. Batten Cap* — Slipped over batten clip (Item A), formed to snap over and engage batten clip.

METAL SALES MANUFACTURING CORPORATION (View Classification) — Vertical Seam Batten Cap

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 664

Uplift – Class 90

1. Purlins: (Not shown) Purlins used for liner panel (Item 2) support to be cold formed steel sections. As alternatives,

structural components (hot rolled beams, channels, open web joists, etc.) may be used. Min gauge and yield to

depend on design considerations for uplift loading. Purlins spaced max 6 ft. OC.

2. Deck: No. 22 MSG min thick coated steel (33,000 psi min yield strength). Min depth 1-1/2 in., max pitch 6 in.

Fabricated to various profiles. Fastened to supports 6 in. OC.

3. Insulation*:

Foamed Plastic*

—

(Rigid Insulation — Optional) — Applied flat or tapered to maximum 10 in. thick

combination of Item 3A. Bearing plates required under panel attachment points. Optional if Cover Board (Item

3B) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

3A. Foamed Plastic — (Rigid Insulation — Optional, Not Shown) — Placed on top of Item 3. Max 10-in thick

combination of Item 3 . Bearing plates required under panel attachment points. Optional if Cover Board (Item

3B) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

28 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

3B. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board" applied over the plywood decking (Item 2) or Foamed Plastic (Items 3

and/or 3A). When used or used over Foamed Plastic bearing plate not required.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

4. Panels*: No. 24 MSG min thick coated steel panels or 0.032 in. min thick aluminum panels, 18 in. wide max. 1-3/4 in.

high at female side rib. Panels continuous over three or more clips with no end laps. A bead of sealant may be

used at panel side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-14"

5. Fasteners*:

(Panel

Clips)

—

One piece assembly, 3-1/2 in. wide, 1-7/8 in. high. No. 18 MSG min thick coated steel. Clips

spaced 18 in. OC max. Fasteners used to attach the panel clips. Bearing plates are used with panel screw

fasteners (Item 6) under panel clip to be 4 in. by 4 in. min No. 26 gauge stainless steel or min No. 20 gauge

galvanized steel. Bearing plates are optional if foamed plastic is used.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "UC-14 Clip", "UC Bearing Plate"

6. Fasteners:

(Screws not shown)

—

Fasteners used to attach the panel clips to the steel decking to be No. 12 steel

screws. Length to penetrate steel deck a minimum of 1/2 in. Two screws are to be used per clip.

* Indicates such products s

hall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 342

Uplift – Class 90

1. Panels*: No. 24 MSG min gauge coated steel. Panel width 18 in. max., 10 in. min. Rib height 1-3/4 in. at female side. A

bead of sealant may be used at panel side joints. Panels continuous over three or more clips with no end laps.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Pa

nel Clips)

—

One piece assembly, No. 24 MSG min thickness, 3-1/2 in. wide, 1-15/16 in. high. Clip spacing

to be 48 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

3. Thermal

Barrier*:

(Mineral Board)

—

Min thickness 1/2 in. Opposite side edges have a tongue and groove configuration. Butt

(end) joints to be staggered and occur over steel deck crests. Wallboard installed perpendicular to steel deck

corrugations.

LOADMASTER SYSTEMS INC (View Classification) — "Mineral Board"

4. Vapor Barrier: (Optional) — Installed on top of metal deck (Item 8) or on top of gypsum wallboard (Item 3). Minimum 6 mil

plastic sheet.

5. Joint Tape: (Not Shown) — All wallboard joints shall be taped with 2.5 in. wide joint tape supplied by the manufacturer.

6. Insulation:

(Rigid Insulation)

—

(Optional) — Expanded polystyrene supplied in 4 by 8 ft sheets, min thickness 13/16 in.,

min density 1.0 pcf, or (Rigid Insulation) Polyisocyanurate supplied in 4 by 8 ft sheets or (Rigid Insulation)

Phenolic supplied in 4 by 8 ft sheets. All end joints to be staggered with respect to adjoining rows. All joints to

be offset from joints in mineral board (Item 3).

7. Fasteners: 7. For attaching panel clips to steel deck to be two 0.140 in. diam threaded shank Phillips, bugle or trumpet

head, self-drilling, self-tapping corrosion resistant coated steel screws supplied by roof deck manufacturer.

Screws shall penetrate steel deck min 1/2 in.

7A. Fasteners — For attaching wallboard to steel deck (Item 8) to be min 0.140 in. diam threaded shank

Phillips, bugle or trumpet head, self-drilling, self-tapping, corrosion resistant coated steel screws supplied by

the manufacturer. Screws are installed into top corrugations of steel deck through nom 3 by 3 in. corrosion

resistant steel roof deck plates, spaced in a pattern as determined by the pitch of the steel deck with the min

density of 21 fasteners per 4 by 8 ft sheet (Item 3).

7B. Panel Fasteners — (Screws) — As an alternate, when no Rigid Insulation (Item 4) is used, No. 10-16 by

min 1 in. long TEK 3 Carbon pancake head, self-drilling, self-tapping screws to be used. When rigid insulation

is used, No. 14-13 by varying lengths, DP1, carbon, pancake-head, Square/Phillips Head screws to be used.

Two fasteners per clip to be used for either type. See Item 8 for steel deck thickness.

8. Deck: 8. Fabricated to various profiles, min yield strength 33,000 psi. Steel deck profile, support spacing and method

of positioning (end and side laps) and fastening of deck to supports to be per deck manufacturers requirements

for uplift loading. Deck thickness to accommodate panel clip screw fastener pullout strength. When fasteners

described in Item 7B are used, min thickness to be No. 22 MSG

8A. Deck Fasteners — Steel deck panels to be fastened to structural supports and at laps using ARC spot

welds with weld washers or screw fasteners per deck manufacturer's requirements for uplift loading.

9. Purlins: 9.

Purlins

—

16 MSG min gauge steel (min yield strength 50,000 PSI) or min Type H open web joists.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

29 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-14 – Construction No. 486

Uplift – Class 90

1. Panels*: No. 24 MSG min coated steel, 18 in. max width, 1-3/4 in. high at the ribs. Panels continuous over three or more

spans. Endlaps for panel to be overlapped 6 in. and to include back-up plate (Item 2A). A bead of sealant may

be used at panel end joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*: 2.

Roof Deck Fasteners*

—

One piece assembly, 3-1/2 in. wide, 1-7/8 in. high, thickness 0.048 in. Clip

spacing to be 48 in. OC.

2A. Endlap Back-Up Plate — (Not Shown) — No. 16 MSG min coated steel, width of back-up plate to

correspond to width of panel. Two 1 in. wide by 3/4 in. long tabs are used for sliding over end of panels.

3. Gypsum

Board*:

(Mineral Board)

—

Min thickness 1/2 in. Opposite side edges have a tongue and groove configuration. Butt

(end) joints to be staggered and occur over steel deck crests. Wallboard installed perpendicular to steel deck

corrugations.

GEORGIA-PACIFIC GYPSUM L L C (View Classification) — "DensDeck®", "DensDeck Prime®"

4. Vapor Barrier: Single ply used between the wallboard (Item 3) and the metal roof deck panels (Item 1).

5. Joint Tape: (Not Shown) — 2-1/2 in. wide tape supplied by manufacturer to be used at all wallboard joints.

6. Insulation:

(Rigid Insulation)

—

(Optional) — Expanded polystyrene or polyisocyanurate supplied in 4 by 8 ft sheets, min

thickness 13/16 in. min density 1.0 pcf. All end joints to be staggered with respect to adjacent rows. All joints to

be offset from joints in mineral board (Item 3).

7. Fasteners: 7.

Fasteners

—

Screws used to fasten panel clips (Item 2) to steel deck (Item 8) to be No. 14 Truss head with

No. 3 Phillips drive. Length to be min 1/2 in. longer than thickness of wallboard, rigid insulation and metal deck.

Two screws per clip. Fasteners used at endlaps to be one of the following: 14x1 in. Type AB self-tapper; 14x1-

1/4 in. Hex washer head self-driller; 14x1 Type AB Phillips stainless steel self-tapper.

7A. Fasteners — For attaching in wallboard to steel deck to be min 0.140 in diam threaded shank Phillips,

bugle or trumpet head, self-drilling, self-tapping, corrosion resistance coated steel screws supplied by

manufacturer. Screws are installed into top corrugations of steel roof deck through nom 3 by 3 in. corrosion

resistant steel roof deck plates, spaced in a pattern as determined by the pitch of the steel deck with a min of

21 fasteners per 4 by 8 ft sheet (Item 3).

8. Deck: 8.

Steel Deck

—

Fabricated to various profiles, min yield strength 33,000 psi. Steel deck profile, thickness,

support spacing and method of positioning (end and side laps) and fastening deck to supports to be per deck

manufacturers requirements for uplift loading.

8A. Deck Fasteners — Steel deck panels to be fastened to structural supports and at laps using puddle welds

with weld washers or screw fasteners per deck manufactures requirements for uplift loading.

9. Purlins: 16 MSG min coated steel, min yield strength 50,000 psi or Type H open web joists.

* Indicates such products

shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 254

Uplift – Class 90

1. Panels*: No. 22 MSG or No. 24 MSG min thickness coated steel panels. Panels 12 in. wide, 1-3/4 in. high at the ribs.

Panels continuous over two or more spans. A bead of sealant may be used at panel side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*: 2. One piece assembly, 3-1/2 in. wide, 1-7/8 in. high, thickness 0.048 in. One panel clip located at each purlin

intersection.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

2A. Roof Deck Fasteners (Bearing Plate) — (Not Shown) — No. 16 MSG coated steel, 4 in. by 5 in. with

guide holes. Used when Rigid Insulation (Item 5) is used.

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item 2) to purlins (Item 4) when no rigid insulation (Item 5) is

used to be No. 10-16 by 1 in. long, self-drilling, self-tapping, pancake head, No. 3 point, plated steel screws.

When rigid insulation is used, No. 14-13 DPI carbon, pancake head combination Square/Phillips Drive screws

to be used. Length to penetrate steel minimum of 5/8 in. Two screws per clip to be used, inserted through panel

clip guide holes.

4. Purlins: No. 16 MSG min thickness steel (50,000 psi min yield strength).

Spacing — For 22 MSG thickness panels - 60 in. OC

For 24 MSG thickness panels - 48 in. OC

5. Insulation:

(Rigid Insulation)

—

(Optional) — Not Shown — Maximum thickness 4 in. Located over purlins (Item 4)

Density to be minimum 1.8 pcf. Compliant with ASTM C1289 or ASTM C578 Standards, Types IV, X or XII.

* Indicates such products shall be

ar the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

30 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-14 – Construction No. 255

Uplift – Class 90 and 60 (See Item No. 4)

1. Panels*: No. 24 MSG min thickness coated steel. Panel width 18 in. max., 10 in. min. Rib height 1-3/4 in. at female side.

Panels continuous over two or more spans. A bead of sealant may be used at panel side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*: 2. (Panel Clips) — One piece assembly, 3-1/2 in. wide, 1-7/8 in. high. One panel clip located at each purlin

intersection.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

2A. (Bearing Plate) — (Not Shown) — No. 16 MSG coated steel, 4 in. by 5 in. with guide holes. Used when

Rigid Insulation (Item 5) is used.

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item 2) to purlins (Item 4) when no rigid insulation (Item 5) is

used to be No. 10-16 by 1 in. long, self-drilling, self-tapping, pancake head, No. 3 point, plated steel screws.

When rigid insulation is used, No. 14-13 DP1 carbon, pancake head combination Square/Phillips Drive screws

to be used. Length to penetrate steel minimum of 5/8 in. Two screws per clip to be used, inserted through panel

clip guide holes.

4. Purlins: No. 16 MSG min thickness steel (50,000 psi min yield strength).

Spacing for Class 90 to be 48 in. OC: For Class 60 to be 60 in. OC

5. Insulation:

(Rigid In

sulation)

—

(Optional) — Not Shown — Maximum thickness 4 in. Located over purlins (Item 4)

Density to be minimum 1.8 pcf. Compliant with ASTM C1289 or ASTM C578 Standards, Types IV, X or XII.

* Indicates such products shall bear the UL or cUL Certificati

on Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 261

Uplift – Class 90 or 60

1. Panels*: 0.032 in. thick aluminum or No. 24 MSG min thickness coated steel. Panels 10-1/2 in. wide, 1-3/4 in. high at the

ribs. Panels continuous over two or more spans. A bead of sealant may be used at panel side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fastener*:

(Panel Clips)

—

One piece assembly, 3-1/8 in. wide, 1-7/8 in. high. One panel clip located at each purlin

intersection. Min thickness 0.048 in. (No. 18 MSG).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item 2) to purlins (Item 4) when no rigid insulation (Item 5) is

used to be No. 10-16 by 1 in. long, self-drilling, self-tapping, pancake head, No. 3 point, plated steel screws.

When rigid insulation is used, No. 14-13 DP1 carbon, pancake head combination Square/Phillips Drive screws

to be used. Length to penetrate steel minimum of 5/8 in. Two screws per clip to be used, inserted through panel

clip guide holes.

4. Purlins: No. 16 MSG min thickness steel (50,000 psi min yield strength).

Spacing —

For aluminum panels: For Class 90 to be 36 in. OC.

For Class 60 to be 48 in. OC.

For steel panels: 22 MSG thick to be 60 in. OC.

24 MSG thick to be 48 in. OC

5. Insulation:

(Rigid Insulation)

—

(Optional) — Not Shown — Maximum thickness 4 in. Located over purlins (Item 4)

Density to be minimum 1.8 pcf. Compliant with ASTM C1289 or ASTM C578 Standards, Types IV, X or XII.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing t

he UL or cUL

Certification (such as Canada), respectively.

31 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-14 – Construction No. 445

Uplift – Class 90

1. Panels*: No. 24 MSG min coated steel. Max panel width 12 in., rib height 1-3/4 in. Panels continuous over two or more

spans. No endlaps. A bead of sealant may be used at panel ends and side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 in. wide by 1-7/8 in. high. Clip spacing to be 48 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

3. Fasteners:

(Screws)

—

Screws used to attach panel clips (Item 2) to purlins (Item 4) to be No. 10x1 in. long No. 3 self-

drilling point, No. 2 Phillips Pancake head. Two screws per clip.

4. Purlins: No. 16 MSG min thickness steel (min yield 50 ksi).

Spacing

—

For 22 MSG thickness panels - 60 in. OC.

For 24 MSG thickness panels - 48 in. OC.

5. Insulation: (Optional) — (Not Shown) — 3 in. thick vinyl faced blanket insulation. To be installed between metal panels

(Item 1) and purlins (Item 4).

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 446

Uplift – Class 90

1. Panels*: No. 24 MSG min coated steel. Max panel width 18 in., rib height 1-3/4 in. Panels continuous over two or more

spans. No endlaps. A bead of sealant may be used at panel ends and side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 in. wide by 1-7/8 in. high. Clip spacing to be 48 in. OC.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

3. Fasteners:

(Screws)

—

Screws used to attach panel clips (Item 2) to purlins to be No. 10 by 1 in. long No. 3 self-drilling

point, No. 2 Phillips Pancake head. Two screws per clip.

4. Purlins: No. 16 MSG min thickness steel (min yield 50 ksi) spaced 48 in. OC.

5. Insulation: 5.

Insulation

–

(Optional) — (Not Shown) — 3 in. thick vinyl faced blanket insulation. To be installed between

metal panels (Item 1) and purlins (Item 4).

5A. Insulation — (Optional) — (Not Shown) — 1/4 in. thick closed/microcellular polyethylene insulation with foil

facing designated "Low-E Insulation™." To be installed between metal panels (Item 1) and purlins (Item 4).

* Indicates such products shall bear the UL o

r cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 447

Uplift – Class 90

1. Panels*: 0.032 in. thick aluminum or No. 24 MSG min thickness coated steel. Panels 10 in. wide, 1-3/4 in. high at the

ribs. Panels continuous over two or more spans. No endlaps. A bead of sealant may be used at panel side

joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 in. wide by 1-7/8 in. high. One panel clip located at each purlin

intersection.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

3. Fasteners:

(Screws)

—

Screws used to attach panel clips (Item 2) to purlins (Item 4) to be No. 10x1 in. long No. 3 self-

drilling point. No. 2 Phillips Pancake head. Two screws per clip.

4. Purlins: No. 16 MSG min thickness steel (min yield 50 ksi).

Spacing —

For 0.032 in. thick aluminum panels 36 in. OC.

For 22 MSG thickness panels 60 in. OC.

For 24 MSG thickness panels 48 in. OC.

5. Insulation: (Optional) — (Not Shown) — 3 in. thick vinyl faced blanket insulation. To be installed between metal panels

(Item 1) and purlins (Item 4).

* I

ndicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

32 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UC-14 – Construction No. 543

Uplift – Class 90

1. Panels*: No. 24 MSG (minimum) thickness coated steel. Maximum panel width 18 inches by 1-3/4 inches high at the

ribs. Panels continuous over two or more spans with no end laps. A bead of sealant may be used at the panel

side joint.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 inches wide, 1-7/8 inches high. Minimum thickness No. 18 MSG.

One clip located at each purlin intersection.

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item No. 2) to purlins to be No 10-16 by 1 inch long plated

steel pancake head No. 2 Phillips drive with a No. 3 self-drilling point or 1/4-14 x 1 inch DP3 coated steel

screws, Square/Phillips drive head, self drilling. Two screws per clip.

4. Purlins: No. 16 MSG minimum thickness steel with a minimum yield strength of 50,000 psi. Purlin spacing as follows:

a) 48 inch purlin spacing for class 90 rating for No. 24 MSG panels in all widths.

b) 60 inch purlin spacing for class 90 rating for No. 22 MSG 12 inch wide panels only.

c) 60 inch purlin spacing for class 60 rating for No. 22 MSG panels in all widths.

5. Insulation: (Optional) — Any compressible blanket insulation, 3 inches max. thickness when located between panels (Item

No. 1) and purlin (Item No. 4).

* Indicates su

ch products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

UC-14 – Construction No. 544

Uplift – Class 90

1. Panels*: No. 24 MSG min. Coated steel. Max. panel width 18 inches and rib height 1-3/4 inches. Panels continuous over

two or more spans. Endlap for panels to be overlapped 6 in. A bead of sealant may be used at panel ends and

side joints.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14"

2. Fasteners*:

(Panel Clips)

—

One piece assembly, 3-1/2 inches wide, 1-7/8 inches high. Minimum thickness No. 18 MSG.

One clip to be used at each purlin. Maximum clip spacing to be 48 inches O.C. Clips to interface with bearing

plates (Item No. 2A).

2A. Bearing Plate — No. 24 MSG minimum gauge coated steel, 5 inches wide by 3-7/8 inches long (50,000

psi minimum yield strength).

2B. Roof Deck Fasteners* — (Panel Clips) — One piece assembly, 3-1/2 in. wide by 1-7/8 in. high. Clip

spacing to be 48 in. OC. Clips to interface with bearing plates (Item No. 2C).

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC-14 Clip"

2C. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized

steel. Two 1/4 in. guide holes located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

3. Fasteners:

(Screws)

—

Fasteners used to attach panel clips (Item No. 2) and bearing plates (Item No. 2A) through rigid

board insulation (Item No. 4), light gauge steel deck (Item No. 5) and into purlins (Item No.7) to be No. 14 self-

tapper. Two screws per clip to be used. Length to be a minimum of 1/2 inch longer than the combined thickness

of the liner panel (Item No. 5), rigid insulation (Item No. 4), gypsum wall board (Item No. 4B) and plywood or

oriented strand board (Item No. 4A).

4. Insulation: 4.

Foamed Plastic

—

(Rigid Insulation) — Minimum thickness 1 inch, maximum thickness 10 inches. Density

to be a minimum of 1.5 pcf.

4A. Foamed Plastic* — (Rigid Insulation — Optional) — In lieu of Item 4, applied flat or tapered to maximum

10-in thick combination of Item 4B. Bearing plates required under panel attachment points. Optional if Cover

Board (Item 4D) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

4B. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 4A. Maximum 10-

in thick combination of Item 4A. Bearing plates required under panel attachment points. Optional if Cover Board

(Item 4D) is used.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

4C. Roof Deck Fasteners* — (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized

steel. Two 1/4 in. guide holes located in line with panel clip (Item 2) guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

4D. Cover Board — (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated

(square edged may be used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in.

33 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

wood fiberboard, 1/4 in. min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass

Mat Board" or "SECUROCK Roof Board" applied over the liner panel (Item 5) in lieu of Foamed Plastic (Item 4)

or over Foamed Plastic (Items 4, 4A and/or 4B). When used or used over Foamed Plastic bearing plate not

required.

5. Deck:

Liner Panel

—

(Optional) — (Required when Items 4, 4A, 4B, 4C and 4D are used) — No. 29 MSG minimum

steel. Minimum yield strength 80,000 psi, minimum depth 9/16 inches, maximum pitch 2.6667 inches O.C.

6. Underlayment: (Optional — Not Shown) — Underlayment attached over Foamed Plastic (Item 4, 4A or 4B), Liner Panel (Item

5) or Cover Board (Item 4D) installed per manufacturer's recommendations.

7. Supports:

(Purlins)

—

(Not Shown) — No. 16 MSG minimum thickness coated steel with a minimum yield strength of

50,000 psi. Or minimum "H" series open-web joists. Maximum spacing "48" O.C.

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or

cUL

Certification (such as Canada), respectively.

5V Crimp Constructions:

5V Crimp – Construction No. 629

Uplift – Class 90

1. Joist: Graded dimension lumber, No. 2 or better. Spaced a maximum of 24 in. OC.

2. Deck: Min. 5/8 in., Type CDX APA Rated plywood sheathing.

3. Underlayment: 3.

Underlayment

—

(Optional) — One layer of Type 30, fastened per manufacturer's installation instructions.

3A. Underlayment (Not shown) — (Optional) — One layer UL Classified Elk "VersaShield" with 2 in. side lap,

loose laid.

4. Panels*: Width 22-1/2 in. by No. 26 MSG coated steel.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO

LLC (View Classification) — "5-V-Crimp"

5. Fasteners:

(Screws)

—

Fasteners for attaching panels to the decking, No. 9 by minimum 1-1/2 in. long, without insulation

and/or cover board, hex head steel screws with a bonded washer. Fasteners spaced 24 in. O.C. and located on

the top part of the panel v-crimp. Fasteners for attaching decking to joists, 2 in. long, No. 8 coarse thread

screws spaced 6 in. OC at the edges and 12 in. OC in the field.

6. Insulation*: 6.

Foamed Plastic*

—

(Rigid Insulation — Optional — Not Shown) — Applied flat or tapered to maximum 10-in

thick combination of Item 6A. Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISO 95+ GL" or "Resista"

6A. Foamed Plastic — (Rigid Insulation — Optional — Not Shown) — Placed on top of Item 6. Maximum 10-in

thick combination of Item 6 . Bearing plates required under panel attachment points.

FIRESTONE BUILDING PRODUCTS CO L L C (View Classification) — "ISOGARD HD"

7. Cover Board: (Optional — Not Shown) — Min 1/2 in. thick (15/32 in. actual) plywood, DOC PS-1 rated (square edged may be

used) or min 7/16 in thick OSB, DOC PS-2 rated, 1/2 in. thick gypsum board, 1/2 in. wood fiberboard, 1/4 in.

min thickness G-P Gypsum "DensDeck", 1/4 in. min thick USG "SECUROCK Glass Mat Board" or

"SECUROCK Roof Board" applied over the plywood decking (Item 2) or Foamed Plastic (Items 6 and/or 6A).

When used or used over Foamed Plastic bearing plate not required.

8. Fasteners*: (Bearing Plates) — Plates to be 4 in by 4 in. by No. 26 MSG min galvanized steel. Two 1/4 in. guide holes.

FIRESTONE METAL PRODUCTS, A DIV OF FIRESTONE BUILDING PRODUCTS CO LLC (View

Classification) — "UC Bearing Plate"

* Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL

Certification (such as Canada), respectively.

34 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

UL 1897 Testing:

Test is conducted in accordance with UL 1897 “Uplift Test for Roof Covering Systems”. The test method

subjects a minimum 10 ft by 10 ft sample to various short term (one minute increments) static air pressure

to index performance under uplift loads imposed on a roofing system’s securement to a specified roof

deck.

IRESTONE

UILDING

RODUCTS HAS POSTED ALL OF THE AVAILABLE

EPORTING IN THE

ODES

ECTION OF THE

FBP

WEBSITE

LEASE COPY AND PASTE THE FOLLOWING LINK INTO A WEB BROWSER TO VISIT OUR WEBSITE AND REVIEW

IRESTONE

UILDING

RODUCTS

VALUATION

EPORTS

HTTP

://

DATABASE

COM

CGI

BIN

/XYV/

TEMPLATE

/LISEXT/1FRAME/

SHOWPAGE

HTML

NAME

=TGIK.R14751&

CCNSHORTTITLE

OOFING

YSTEMS

,+U

PLIFT

ESIST

ANCE

OBJID

=1075607477&

CFGID

=1073741824&

VERSION

VERSIONLESS

PARENT

=1073993603&

SEQUENCE

Please utilize the UL website to verify the assembly number associated to each listed assembly.

Table 1.03c

UL 1897 Tested Roof Constructions

Deck

Thermal

Board Insulation Underlayment

Panel Type

and Width Clips and/or Fasteners

Wind

Uplift

UC-3

Assembly No. 2

Steel:

Min. No. 22 MSG

N/A

Foamed Plastic (Rigid

Insulation):

Min. 1”, max. 4” thickness.

Joints staggered between

layers. Mechanically

fastened to the steel deck

per manufacturer’s

recommendation.

Underlayment #1:

One layer Type 30

organic felt with 2”

side laps.

Mechanically

fastened to the steel

deck per

manufacturers

recommendations.

Underlayment #2:

One layer UL

Classified ELK

“VersaShield” with 2”

side laps, loose laid.

Width:

Max. 16”

With 1-1/2”

high legs

Metal:

Min. No. 24

MSG coated

steel.

Panels must

be continuous

over three or

more clips

with no end

laps. Panel

ribs seamed

with an

electric

seaming tool

with seaming

operation to

include upper

tabs of panel

clips.

Identified as

“UC-3”.

Clips:

UC-3 Expansion Clip

Two part assembly, base 5”

long, 1” wide, 0.42” high.

Fabricated from No. 22 MSG

min. thick coated steel. Upper

tab 3” long, 0.42” wide, 1.786”

high. Fabricated from No. 24

MSG min. thick coated steel.

Clip Spacing:

12” o.c. max.

Bearing Plates:

Plates used with panel screw

fasteners under panel to be 4”

by 4” min. 26 gauge stainless

steel.

As an alternate, 1/2” thick

(15/32” actual) plywood, APA

rated sheathing, square

edged may be used.

Fasteners:

Fasteners used to attach

panel clips to steel deck to be

No. 12 pancake wafer head

steel screws. Length to

penetrate steel deck a min.

3/4”. Two fasteners used per

clip.

142 PSF

Assembly No. 3

Plywood:

Min 19/32” thick CDX

N/A N/A

Underlayment #1:

One layer Type 30

organic felt with 2”

side lap. Fastened to

the plywood deck

per manufacturer’s

recommendations.

Underlayment #2:

One layer UL

Classified Elk

“VersaShield” with 2”

side lap, loose laid.

Vapor Barrier: One

layer of Colbond

“Enkamat 7010”,

loose laid

Width:

Max. 16”

With 1-1/2”

high legs

Metal:

Min. 0.027”

RHEINZINK

Panels

continuous

over three or

more clips

with no end

laps. Panels

ribs double

seamed with

and electric

seaming tool

Clips:

UC-3 Expansion Clip

Two part assembly, base 5”

long, 1” wide, 0.42” high.

Fabricated from min. 0.0225”

thick 304 stainless steel.

Upper tab 3” long, 0.42” wide,

1.786” high. Fabricated from

min. 0.0172” thick 304

stainless steel.

Clip Spacing:

12” o.c. max.

Fasteners:

Fasteners used to attach

panel clips to plywood deck to

be No. 10x1-1/2” long

pancake head stainless steel

247 PSF

35 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

with seaming

operation to

include upper

tabs of panel

clips.

Identified as

“UC-3”.

screws. Two screws used per

clip.

Assembly No. 4

Steel:

Min. No. 22 MSG

N/A

Foamed Plastic (Rigid

Insulation):

Min. 1”, max. 4” thickness.

Joints staggered between

layers. Mechanically

fastened to the steel deck

per manufacturer’s

recommendation.

Underlayment #1:

One layer Type 30

organic felt with 2”

side laps.

Mechanically

fastened to the steel

deck per

manufacturers

recommendations.

Underlayment #2:

One layer UL

Classified ELK

“VersaShield” with 2”

side laps, loose laid.

Vapor Barrier: One

layer Colbond

“Enkamat 7010”,

loose laid.

Width:

Max. 16”

With 1-1/2”

high legs

Metal:

Min. 0.027”

RHEINZINK

Panels

continuous

over three or

more clips

with no end

laps. Panels

ribs double

seamed with

and electric

seaming tool

with seaming

operation to

include upper

tabs of panel

clips.

Identified as

“UC-3”.

Clips:

UC-3 Expansion Clip

Two part assembly, base 5”

long, 1” wide, 0.42” high.

Fabricated from min. 0.0225”

thick 304 stainless steel.

Upper tab 3” long, 0.42” wide,

1.786” high. Fabricated from

min. 0.0172” thick 304

stainless steel.

Clip Spacing:

12” o.c. max.

Bearing Plates:

Plates used with panel screw

fasteners under panel to be 4”

by 4” min. 26 gauge stainless

steel.

As an alternate, 1/2” thick

(15/32” actual) plywood, APA

rated sheathing, square

edged may be used.

Fasteners:

Fasteners used to attach

panel clips to steel deck to be

No. 12 pancake wafer head

steel screws. Length to

penetrate steel deck a

minimum 3/4”. Two screws

used per clip.

187 PSF

Assembly No. 10

Plywood:

Min. 5/8” nom (19/32”

actual) thick plywood;

Exposure 1, Grade B-C,

APA rated sheathing,

conforming to

requirements of DOC

PS-1, with butt joints to

be located over wood

supports (joist).

Fastened to supports

with 8d x 2-1/2” long ring

shank nails spaced 6”

o.c. at butted ends and

6” o.c. in the field.

N/A N/A

Underlayment: One

layer Type 15 or 30

organic felt with 2”

side lap. Fastened to

the plywood deck

per manufacturer’s

recommendations.

Width:

Max. 16”

With 1-1/2”

high legs.

Metal:

Min. No. 24

MSG coated

steel.

Panel ribs

single

seamed.

Identified as

“UC-3”.

Clips:

UC-3 Expansion Clip

Two part assembly, base 5”

long, 1” wide, 0.42” high.

Fabricated from min. 0.0225”

thick 304 stainless steel.

Upper tab 3” long, 0.42” wide,

1.786” high. Fabricated from

min. 0.0172” thick 304

stainless steel.

Clip Spacing:

18” o.c. max.

Fasteners:

Fasteners used to attach

panel clips to plywood deck to

be No. 10x1” long pancake

head screws. Two screws

used per clip.

157 PSF

Assembly No. 11

Plywood:

Min. 5/8” nom (19/32”

actual) thick plywood;

Exposure 1, Grade B-C,

APA rated sheathing,

conforming to

requirements of DOC

PS-1, with butt joints to

be located over wood

supports (joist).

Fastened to supports

with 8d x 2-1/2” long ring

shank nails spaced 6”

N/A N/A

Underlayment:

One layer Type 30

organic felt with 2”

side lap. Fastened to

the plywood deck

per manufacturer’s

recommendations.

Width:

Max. 16”

With 1-1/2”

high legs

Metal:

Min. No. 24

MSG coated

steel.

Panel ribs

single

seamed.

Identified as

“UC-3”.

Clips:

UC-3 Expansion Clip

Two part assembly, base 5”

long, 1” wide, 0.42” high.

Fabricated from min. 0.0225”

thick 304 stainless steel.

Upper tab 3” long, 0.42” wide,

1.786” high. Fabricated from

min. 0.0172” thick 304

stainless steel.

Clip Spacing:

8” o.c. max.

Fasteners:

202 PSF

36 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

o.c. at butted ends and

6” o.c. in the field.

Fasteners used to attach

panel clips to plywood deck to

be No. 10x1” long pancake

head screws. Two screws

used per clip.

Deck Thermal

Board Insulation Underlayment

Panel Type

and Width Clips and/or Fasteners

Wind

Uplift

UC-4

Assembly No. 6

Plywood:

Min. 19/32” thick APA

rated sheathing Grade

B-C fastened to supports

with 8d x 2-1/2” long ring

shank nails spaced 6”

o.c.

N/A N/A N/A

Width:

Max. 9-3/4”

With 1-1/2”

high legs

Metal:

Min. No. 26

MSG Coated

steel or Min.

0.032” Alum

Panel ribs

single

seamed. A

bead of

sealant may

be used at

panel ribs.

Identified as

“UC-4”.

Fasteners:

Fasteners used to attach

panel to plywood deck to be

No. 10x1” long pancake head

screws.

Fastener Spacing:

12“ o.c. with two fasteners

used at each location.

247 PSF

Assembly No. 7

Plywood:

Min. 19/32” thick APA

rated sheathing Grade

B-C fastened to supports

with 8d x 2-1/2” long ring

shank nails spaced 12”

o.c. in the field and 6”

o.c. along the perimeter.

N/A N/A N/A

Width:

Max. 9-3/4”

With 1-1/2”

high legs

Metal:

Min. No. 26

MSG Coated

steel or Min.

0.032” Alum

Panel ribs

single

seamed. A

bead of

sealant may

be used at

panel ribs.

Identified as

“UC-4”.

Fasteners:

Fasteners used to attach

panel to plywood deck to be

No. 10x1” long pancake head

screws.

Fastener Spacing:

12“ o.c. with two fasteners

used at each location.

217 PSF

Assembly No. 17

Plywood:

Minimum 15/32 inch

APA rated plywood

sheathing Grade B-C,

or minimum 7/16

inch APA rated OSB

fastened to supports

with 8d by 2-1/2 in.

long ring-shank nails

spaced 6 inches on

center.

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2”

high at the

ribs.

Metal:

Min. No. 24

MSG Coated

steel

A bead of

sealant may

be used at

panel ribs.

Identified as

“UC-4”.

Fasteners:

Fasteners used to attach

the panels to the plywood

to be No. 10 coarse thread

steel screws. Two screws

spaced 18 inches on

center.

180 PSF

Assembly No. 18

Plywood:

Minimum 15/32 inch

APA rated plywood

sheathing Grade B-C,

or minimum 7/16

inch APA rated OSB

fastened to supports

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2”

high at the

ribs.

Metal:

Min. No. 24

MSG Coated

Fasteners:

Fasteners used to attach

the panels to the plywood

to be No. 10 coarse thread

steel screws. Two screws

spaced 24 inches on

center.

150 PSF

37 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

with 8d by 2

1/2 in.

long ring-shank nails

spaced 6 inches on

center.

steel

A bead of

sealant may

be used at

panel ribs.

Identified as

“UC-4”.

Assembly No. 19

Plywood:

Minimum 15/32 inch

APA rated plywood

sheathing Grade B-C,

or minimum 7/16

inch APA rated OSB

fastened to supports

with 8d by 2-1/2 in.

long ring-shank nails

spaced 6 inches on

center.

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2”

high at the

ribs.

Metal:

Min. .032 in.

thick

aluminum

A bead of

sealant may

be used at

panel ribs.

Fasteners:

Fasteners used to attach

the panels to the plywood

to be No. 10 coarse thread

steel screws. Two screws

spaced 12 in. on center.

105 PSF

Assembly No. 20

Plywood:

Minimum 15/32 inch

APA rated plywood

sheathing Grade B-C,

or minimum 7/16

inch APA rated OSB

fastened to supports

with 8d by 2-1/2 in.

long ring-shank nails

spaced 6 inches on

center.

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2”

high at the

ribs.

Metal:

Min. .032 in.

thick

aluminum

A bead of

sealant may

be used at

panel ribs.

Fasteners:

Fasteners used to attach

the panels to the plywood

to be No. 10 coarse thread

steel screws. Two screws

spaced 18 inches on

center.

135 PSF

Assembly No. 21

Steel:

Min. No. 22 MSG

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2”

high at the

ribs.

Metal:

Min. .032 in.

thick

aluminum

A bead of

sealant may

be used at

panel ribs.

Fasteners:

Fasteners used to attach

the panels to the plywood

to be No. 10 by 1-1/2 inch

long coarse thread steel

screws. Two screws

spaced 18 inches on

center.

120 PSF

Assembly No. 22

Plywood:

Minimum 15/32 inch

APA rated plywood

sheathing Grade B-C,

or minimum 7/16

inch APA rated OSB

fastened to supports

with 8d by 2-1/2 in.

long ring-shank nails

spaced 6 inches on

center.

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2”

high at the

ribs.

Metal:

Min. 24 MSG

Steel

A bead of

sealant may

be used at

panel ribs.

Fasteners:

Fasteners used to attach

the panels to the plywood

to be No. 10 coarse thread

steel screws. Two screws

spaced 18 inches on

center.

120 PSF

38 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Deck Thermal

Board Insulation Underlayment

Panel Type and

Width Clips and/or Fasteners

Wind

Uplift

UC-6

Assembly No. 1

Supports (Purlins):

No. 16 MSG steel (50ksi

yield strength) spaced

max 3’-0” o.c.

N/A N/A N/A

Width:

Max. 16”

With 2” high

female leg and 1-

3/4” male leg

Metal :

Min. .040” Alum

Panels

continuous over

two or more

spans. Panels

seamed 180º at

ribs with an

electric seamer.

Clips:

UC-6 Clip

Two part assembly. Located

over panel sides, fastened to

supports using two fasteners

per clip.

Fasteners: Used to attach

panel clips to purlins, No. 1/4-

14x7/8” long , self-drilling,

self-taping, hex-head steel.

Two screws used per clip.

165 PSF

Assembly No. 23

Steel:

Min. No. 22 MSG

N/A

Insulation (Optional):

Maximum 10 in. Firestone

ISO 95+ GL, Resista,

ISOGARD HD, ISOGARD

HD Composite or

HailGard HD, loose-laid

Cover Board: Minimum 1

½” thick HailGard

Composite Board,

installed with 8 HD

HailGard Fasteners per

4’x8’ board

N/A

Width:

Max. 18”

With 1.5” high

ribs. A bead of

sealant may be

used at panel

ribs.

Metal :

Min. .032” Alum

Clips:

UC-6 Low-Float Clip

Clip Fasteners:

Fastened to the deck with

Firestone UNA-CLAD #10

fasteners, 1 ½” long (2 per

clip), spaced at 30” o.c.

Panel Fasteners:

No. 10 Coarse thread screws.

Two screws spaced 18” o.c.

105 PSF

Deck Thermal

Board Insulation Underlayment

Panel Type and

Width Clips and/or Fasteners

Wind

Uplift

UC-7

Assembly No. 8

Plywood:

Min. 5/8” APA rated

sheathing Grade B-C

fastened to supports with

No. 8d by 2-1/2” long

steel ring shank nails

spaced 6” o.c. in the field

and 6” o.c. along the

perimeter

N/A N/A N/A

Width:

Max. 12”

With Max. 1”

high legs

Metal :

Min. No. 24

MSG

A bead of

sealant may be

used at panel

ribs.

Clips:

UC-7 Clip

One piece assembly spaced.

Clip Spacing:

12” o.c. max.

Fasteners:

Used to attach panel clips to

deck, No. 12x1” long steel

screws. Two screws used

per clip.

120 PSF

39 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Deck Thermal

Board Insulation Underlayment

Panel Type and

Width Clips and/or Fasteners

Wind

Uplift

UC-14

Assembly No. 9

Steel:

Min. No. 22 MSG

N/A

Optional

Foamed Plastic (Rigid

Insulation):

Max. 4” thickness. Joints

staggered between layers.

N/A

Width:

Max. 18”

With 1-3/4” high

legs

Metal :

Min. No. 24

MSG coated

steel or Min.

0.032 Alum

A bead of

sealant may be

used at panel

side joints.

Clips:

UC-14 Clip

Clip Spacing:

18” o.c. max.

Bearing Plates: Plates used

with panel screw fasteners

under panel to be 4” by 4”

min. 26 gauge stainless

steel. Bearing plate optional

if insulation is not used.

Fasteners:

Fasteners used to attach

panel clips to steel deck to

be No. 12 pancake wafer

head steel screws. Length to

penetrate steel deck a

minimum 1/2” Two screws

used per clip.

105 PSF

Assembly No. 24

Plywood:

Minimum 15/32 inch

APA rated plywood

sheathing Grade B-C,

or minimum 7/16

inch APA rated OSB

fastened to supports

with 8d by 2-1/2 in.

long ring-shank nails

spaced 6 inches on

center.

N/A

Insulation (Optional):

Maximum 10 inch

Firestone ISO 95+ GL,

RESISTA "ISOGARD

HD", ISOGARD HD

Composite or

"HailGard" loose-laid.

N/A

Width:

Max. 18”

With 1-1/2” high

at the ribs

Metal :

Min. No. 24

MSG steel

A bead of

sealant may be

used at panel

side joints.

Clips:

UC-14 Clip

Clip Spacing:

24” o.c. max.

Fasteners:

Fastened to the decked

sheathing with Firestone

UNA-CLAD #10

Fasteners, 11/2 inch long

(2 PER CLIP) clips spaced

24 inches on center.

135 PSF

Internal Fire (“P” Assemblies)

These “P” assemblies can be found using the UL Online Certification Directory report CETW.R14751.

1. The following panel designations can be used in Design Nos.:

P225, P227, P230, P237, P259, P508, P510, P512, P514, P518, P701, P711, P717, P720, P722, P723, P726,P

731, P734, P801, P815, P819.

A. Mechanically Attached Metal Roof Panels – Type UC-3, UC-4, UC-6, UC-7, UC-14, UC-500, UC-501,

UC-600, UC-601, UR, HR, and VR roof panels (26 MSG min gauge coated steel, min 0.020 in. thick copper

or 0.032 min. gauge coated aluminum) placed over specified insulation and/or roof covering for the

respective designs. Panel secured to top layer of 7/16 in. APA-rated oriented strand board (OSB) laminated

to rigid insulation or 5/8 in. plywood over rigid insulation. Refer to individual Roof-Ceiling design under the

appropriate Building Unit item for name of Classified Companies. Panels secured to oriented strand board

or plywood at side ribs with panel clips designed specifically for these panels. Panel clips spaced 18 in. oc

using No. 12-15 No. 3 Phillips self-drilling, self-tapping truss head steel or stainless steel screw. Zinc plated

carbon steel screws. The oriented strand board laminated insulation or plywood covered rigid insulation are

mechanically fastened to steel roof deck and covered with a 30 lb. felt.

B. Mechanically Attached Metal Roof Panels – Type UC-3, UC-4, UC-6, UC-7, UC-14, UC-500, UC-501,

UC-600, UC-601, UR, HR, and VR roof panels (26 MSG min gauge coated steel, min 0.020 in. thick copper

or 0.032 min. gauge coated aluminum) placed over specified insulation and/or roof covering for the

respective designs.

2. Type UC-3, UC-4, UC-6, UC-7, UC-14 are secured by their panel clips with the upper portion of the clip engaging the

panel rib, a 3 in. by 4 in. bearing plate fabricated of nominal 0.018 in. thick coated steel is used under each panel clip.

The bearing plate shall be placed over the specified roof insulation. The fastener shall penetrate the roof deck a min

of ½ in. and shall be spaced 18 in. OC.

3. Type UC-500, UC501, UC-600, UC-601, UR, HR, and VR are screwed into the top of the panel rib through the metal

panels into the specified insulation. Panel clips are attached using No. 12-15 Phillips drive truss head steel or

40 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

stainless steel screw with a “S” point or tek point. Two fasteners per clip are used. The fasteners shall penetrate the

roof deck a min. of ½ in. and shall be spaced 18 in. OC.

STATE OF FLORIDA and MIAMI-DADE APPROVALS

Table 1.05a

State of Florida Product Approval

Specific State of Florida Product Approvals can be viewed by going to

www.florida

buildingcode.org/

FL Product Approval Number

Firestone Metal Products Profile

Type of Metal

FL 13629

3, UC

4, UC

6, UC

7, UC

14,

Crimp See specific product approval

NOTE: Florida Product Approval Numbers FL 175-02, FL 2833-R1, FL 3570-R1, FL 4193-R1, FL 5292-R1, and FL 10601-R2 are

consolidated under FL 13629.

Table 1.05b

Miami-Dade Notice of Acceptance

Specific Miami

Dade N

otice of Acceptance (NOA) can be viewed by

clicking on the hyperlink below.

Miami

Dade NOA#

Firestone Metal Products Profile:

Roof System:

0114.01

Min. 0.032” Aluminum, WD, NI

0720.03

Min. 0

.040 Alum., 22 ga steel deck, insulated

0311.0

Min. 16oz Copper, WD, NI

0311.04

Min. 24ga Steel, WD, NI

0114.02

Min. 24ga Steel, WD, NI

0416.03

Min. 0.032 Aluminum

1214.04

Steel, large & small Impact rated

0122.03

Min. 24ga Steel,

WD, NI

0610.02

Min. 24ga Steel, WD, NI

Notes:

See specific Miami-Dade NOA for the maximum pressure allowed for all areas of the roof

WD = wood deck, 19/32” or greater

NI = non-insulated

Energy Star Approvals - As Currently Listed at www.energystar.gov

Table 1.06

Energy Star Approvals

Color Models

Initial Solar

Reflectance

Solar Reflectance after 3

years

Almond SR

3, UC

4, UC

6, UC

, UC

14,

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.57

0.56

Bone White SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.72

0.7

Brandywine SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.25

0.23

Champagne Metallic SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.37

0.36

Charcoal Gray SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.29

0.28

Color Models

Initial Solar

Reflectance

Solar Reflectance after 3

years

Cityscape SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.35

0.34

Classic Copper SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.42

0.40

Colonial Red SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.31

Dark Bronze SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.26

0.25

41 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Dark Ivy SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.25

Hemlock Green SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.32

0.29

Mansard Brown SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.30

0.29

Matte Black SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.25

0.27

Medium Bronze SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.30

0.28

Patina Green SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.26

0.28

Regal Red SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.42

0.41

Sandstone SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.51

0.50

Sherwood Green SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.27

0.26

Sierra Tan SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.35

0.34

Silver Metallic SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.59

0.60

Sky Blue SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.29

0.28

Slate Gray SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, U

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.36

0.33

Stone White SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.57

0.56

Terra Cotta SR

3, UC

4, UC

6, UC

7, UC

14,

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.34

0.33

Tropical Patina SR

3, UC

4, UC

6, UC

7, UC

14, UC

600, UC

601,

5VC, HR Ultra Omega Panel,

VR Classic Omega,

UR Pro Omega

0.28

CRRC Rated Panels

Color Brand

Initial Solar

Reflectance

year Solar

Reflectance

Initial

Emittance

year

Emittance CRRC Product ID

Stone White SR Any panel 0.55 0.55 0.83 0.82 0806-0010

Fluropon Cityscape Any panel 0.35 0.34 0.84 0.83 0806-0004

Fluropon Classic II Silver

Metallic Any panel 0.56 0.55 0.76 0.76 0806-0005

Fluropon Bone White Any panel 0.70 0.69 0.84 0.84 0806-0006

Fluropon Sandstone Any panel 0.51 0.49 0.84 0.83 0806-0007

Classic Copper SR Any panel 0.35 0.35 0.75 0.75 0806-0022

Charcoal Gray SR Any panel 0.25 0.25 0.83 0.82 0806-0021

Mansard Brown SR Any panel 0.25 0.25 0.83 0.83 0806-0019

Hemlock Green SR Any panel 0.25 0.25 0.83 0.83 8060-0015

Patina Green SR Any panel 0.32 0.32 0.83 0.82 0806-0014

Almond SR Any panel 0.55 0.55 0.83 0.82 0806-0013

Medium Bronze SR Any panel 0.25 0.25 0.83 0.83 0806-0011

42 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Slate Gray SR Any panel 0.35 0.35 0.83 0.81 8060-0009

Terra Cotta SR Any panel 0.35 0.35 0.83 0.82 0806-0012

Sky Blue SR Any panel 0.25 0.25 0.83 0.83 0806-0023

Colonial Red SR Any panel 0.25 0.25 0.83 0.82 0806-0016

Air Infiltration & Water Penetration

Table 1.08a

ASTM E283 and E1680 Air Infiltration Tests

Panel System: ASTM E283 ASTM E1680

Static Pressure

Differential (PSF)

Air Infiltration

Rate (CFM/SF)

Preload

Pressure (PSF)

Static Pressure

Differential (PSF)

Air Infiltration Rate

(CFM/SF)

UC-3

24ga Steel & .040” Aluminum

17.75” Wide w/o sealant

1.56 0.03

6.24 0.05

24ga Steel

20” Wide w/o Sealant 12.0 0.044 15±

-1.57 0.011

1.57 0.008

-6.24 0.0138

6.24 0.0333

24ga Steel

18” Wide

w/ Sealant

15+/30- ±1.57 0.0015

±6.24 0.0022

UC-4

24ga Steel & .040” Aluminum

17.75” Wide

1.56 (w/o sealant) 0.22

6.24 (w/o sealant) 0.52

1.56 (w/ sealant) 0.04

6.24 (w/ sealant) 0.17

24ga Steel

18” Wide w/ Sealant 15±

-1.57 0.010

1.57 0.028

-6.24 0.010

6.24 0.099

UC-6

24ga Steel

18” Wide

w/ Sealant

15+/30-

±1.57 0.0031

±6.24 0.0091

Panel System: ASTM E283 ASTM E1680

Static Pressure

Differential (PSF)

Air Infil

tration

Rate (CFM/SF)

Preload

Pressure (PSF)

Static Pressure

Differential (PSF)

Air Infiltration Rate

(CFM/SF)

UC-14

24ga Steel

18” Wide

w/ Sealant

15+/30-

±1.57 0.0017

±6.24

0.0039

UC-500

24 gauge steel and 0.038 Aluminum,

12” wide

1.56 (w/o sealant) 0.07

6.24 (w/o sealant) 0.17

1.56 (w/ sealant) 0.03

6.24 (w/ sealant) 0.11

43 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Table 1.08b

ASTM E331 and E1646 Water Penetration Tests

Panel System: ASTM E331 ASTM E1646

Static Pressure

Differential (PSF)

Water Infiltration

Preload

Pressure (PSF)

Static Pressure

Differential

(PSF)

Water Infiltration

UC-3

24ga Steel &

.040

” Aluminum

17.75” Wide w/o Sealant 10.5 None

24ga Steel

20” Wide w/o Sealant 12.0 None 15± 2.86 None

24ga Steel

18” Wide

w/ Sealant

15+/30- 15.0 None

UC-4

24ga Steel & 0.038” Aluminum

17.75” Wide w/o Sealant 10.5 None

24ga Steel

18” Wide w/ Sealant 12.0 None 15± 2.86 None

UC-6

24ga Steel

16” Wide w/ Sealant 15+/30- 12.0 None

UC-14

24ga Steel

18” Wide w/ Sealant 15+/30- 12.0 None

UC 500

24 gauge steel and 0.038 Aluminum,

12” wide

10.5 sealed No Entry

10.5 unsealed No Entry

44 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Structural Performance

Table 1.09a

ASTM E330 Structural Performance Tests

Product Name Panel width Material type Material thickness Purlin Spacing

Max. T

est

Uplift

Pressure

(psf)

Design Uplift pressure

(psf)

UC-3 17.75” Steel 24 ga. 2.0’ -45

UC-3 17.75” Aluminum 0.038 2.0’ -75

UC-4 17.75” Aluminum 0.038 2.0’ -75

UC-4 17.75” Steel 24 ga. 2.0’ -105

UC-7 12.0” Aluminum 0.032

1.0’ - 104.3 - 41.7

1.25’ - 39.1

1.5’ - 36.5

1.75’ - 33.9

2.0’ - 78.3 - 31.3

2.25’ - 28.8

2.5’ - 26.4

2.75’ - 23.9

3.0’ - 53.95 - 21.5

UC-7 12.0” Aluminum .040

1.0’ - 111.1 - 44.4

1.25’ - 41.1

1.5’ - 37.8

1.75’ - 34.5

2.0’ - 78.3 - 31.3

2.25’ - 28.8

2.5’ - 26.4

2.75’ - 23.9

3.0’ - 53.9 - 21.5

UC-7 16.0” Aluminum 0.032

1.0’ - 72.7 - 29.0

1.25’ -27.3

1.5’ - 25.6

1.75’ - 23.9

2.0’ - 55.5 - 22.2

2.25’ - 20.6

2.5’ - 19.1

2.75’ - 17.6

3.0’ - 40.0 - 16.0

UC-7 16.0” Aluminum .040

1.0’ - 89.0 - 35.6

1.25’ - 33.2

1.5’ - 30.9

1.75’ - 28.6

2.0’ - 65.8 - 26.3

2.25’ - 24.3

2.5’ - 22.3

2.75’ - 20.3

3.0’ - 45.75 - 18.3

UC-7 12.0” Steel 24 ga.

1.0’ - 103.7 - 41.4

1.25’ - 38.3

1.5’ - 35.2

1.75’ - 32.1

2.0’ - 72.9 - 29.1

2.25’ - 28.0

2.5’ - 27.0

2.75’ - 26.0

3.0’ - 62.6 - 25.0

UC-7 12.0” Steel 22 ga.

1.0’ - 157.9 - 63.1

1.25’ - 59.1

1.5’ - 55.2

1.75’ - 51.3

2.0’ - 118.7 - 47.4

2.25’ - 44.1

2.5’ - 40.8

2.75’ - 37.5

3.0’ - 85.6 - 34.2

45 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Table 1.09a (Cont.)

ASTM E330 Structural Performance Tests

Product Name Panel width Material type Material thickness Purlin Spacing

Max. Test

Uplift

Pressure

(psf)

Design Uplift pressure

(psf)

UC-7 16.0” Steel 24 ga.

1.0’ - 66.0 - 26.4

1.25’ - 25.1

1.5’ - 23.9

1.75’ - 22.7

2.0’ - 53.8 - 21.5

2.25’ - 20.8

2.5’ - 20.1

2.75’ - 19.4

3.0’ - 47.17 - 18.8

UC-7 16.0” Steel 22 ga.

1.0’ - 101.0 - 40.4

1.25’ - 38.3

1.5’ - 36.3

1.75’ - 34.3

2.0’ - 80.75 - 32.3

2.25’ - 30.8

2.5’ - 29.3

2.75’ - 27.8

3.0’ - 65.8 - 26.3

UC-500 12.0” Alum 0.038” 2.0’ -105

UC-500 12.0” Steel 22 ga. 4.0’ -38

5.0’ -20

UC-500 12.0” Steel 24 ga. 2.0’ -60

4.0’ -27

UC-500 12.0” Steel 26 ga. 4.0’ -20

ABLE

1.09

ASTM E1592 Structural Performance Tests

Product Name Panel

Width

Material

Type Clip Clip/Purlin Spacing

Max. Test

Uplift

Pressure

(psf)

Design Uplift Pressure

(psf)

UC-3 14.0” 16 oz.

Copper

UC-3 Stainless Steel Expansion

Clip

1.0’ - 100.8 - 61.0

2.5’ - 51.8

3.0’ -42.7

3.5’ - 33.6

4.0’ - 40.4 - 24.4

UC-3 20” 24 ga Steel UC-3 Stainless Steel Expansion

Clip

1.0’ -190.0 -95.0

1.25’ -89.58

1.5’ -84.17

1.75’ -78.75

2.0’ -73.33

2.25’ -67.92

2.5’ -62.50

2.75’ -57.08

3.0’ -51.67

3.25’ -46.25

3.5’ -40.83

3.75’ -35.42

4.0’ -60.0 -30.0

UC-3 20” 0.032”

Aluminum

UC-3 Stainless Steel Expansion

Clip

1.0’ - 150.0

4.0’ - 45.0

UC-4 18” 24 ga Steel N/A 1.0’ - 58.5

4.0’ - 48.1

UC-4 18” 0.032”

Aluminum N/A 1.0’ -55.0

4.0’ -15.0

46 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

ABLE

1.09

ONT

ASTM E1592 Structural Performance Tests

Product Name Panel

Width

Material

Type Clip Clip/Purlin Spacing

Max. Test

Uplift

Pressure

(psf)

Design Uplift Pressure

(psf)

UC-6 18” 24 ga Steel UC-6 Low-Float Clip, Galvanized

Steel

1.0’ -220.0 -110.0

1.25’ -104.69

1.5’ -99.38

1.75’ -94.06

2.0’ -88.75

2.25’ -83.44

2.5’ -78.13

2.75’ -72.81

3.0’ -67.5

3.25’ -62.19

3.5’ -56.88

3.75’ -51.56

4.0’ -46.25

4.25’ -40.94

4.5’ -35.63

4.75’ -30.31

5.0’ -50.0 -25.0

UC-6 16” 0.032”

Aluminum UC-6 Low-Float Clip 1.0’ -114.9

5.0’ -49.9

UC-6 18” 0.032”

Aluminum

UC-6 Low Float Clip, Stainless

Steel

1.0’ -180.0 -90.0

1.25’ -85.94

1.5’ -81.88

1.75’ -77.81

2.0’ -73.75

2.25’ -69.69

2.5’ -65.63

2.75’ -61.56

3.0’ -57.50

3.25’ -53.44

3.5’ -49.38

3.75’ -45.31

4.0’ -41.25

4.25’ -37.19

4.5’ -33.13

4.75’ -29.06

5.0’ -50.0 -25.0

UC-14 16” 24 ga Steel UC-14 Clip, Galvanized Steel

1.0’ -180.0 -50.00

1.25’ -47.92

1.5’ -45.83

1.75’ -43.75

2.0’ -41.67

2.25’ -39.58

2.5’ -37.50

2.75’ -35.42

3.0’ -33.33

3.25’ -31.25

3.5’ -29.17

3.75’ -27.08

4.0’ -50.0 -25.00

UC-14 18” 24 ga steel UC-14 Clip, Galvanized Steel 1.0’ -95.0

4.0’ -40.0

UC-14 18” .032”

Aluminum UC-14 Clip, Stainless Steel 1.0’ -55.0

4.0’ -30.0

47 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Verify all FM approved assemblies on www.RoofNav.com

Factory Mutual – Firestone Building Products Metal Panel Assemblies

Firestone UNA-CLAD UC-3 Metal Panel Uplift Ratings

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and

Attachment

Bearing

Plate

Panel Clip Clip Fastener RoofNav

Assembly

Number

105

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

- Firestone ISO 95+ GL, .5”-1”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

Yes

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #12

nylon washer – 2 per

clip.

259348

1-105

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2”

thickness, 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-1”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

25934

105

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

Firestone ISO 95+ GL, .5”-1”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

Yes

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #12 w/

nylon washer – 2 per

clip.

301645

105

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2”

thickness, 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-1”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

301646

120

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2”

thickness, 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-1”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

301642

120

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2”

thickness, 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-1”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

259347

105

Steel, 22

18 gauge,

33 ksi.

Optional

Polyethylene

(6mil)

Required

Firestone ISO 95+ GL, 1.5”-12”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼” Min.

Yes

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #12 w/

nylon washer – 2 per

clip.

259335

105

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2”

thickness, Firestone HailGard,

1.5”-4” 4’x8’ boards. 24 HD

HailGard Fasteners per 4’x8’

board.

Optional:

Firestone ISO 95+ GL, 1.5”-12”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼”

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

259336

48 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Firestone UNA-CLAD UC-3 Metal Panel Uplift Ratings (Cont.)

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and

Attachment

Bearing

Plate

Panel Clip Clip Fastener RoofNav

Assembly

Number

105

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

Firestone HailGard, 1.5”-4” 4’x8’

boards. 24 HD HailGard

Fasteners per 4’x8’ board.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

259337

105

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

Firestone ISO 95+ GL, 1.5”-12”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼”

Yes

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #12 w/

nylon washer – 2 per

clip.

301628

105

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Opt

ional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2”

thickness, Firestone HailGard,

1.5”-4” 4’x8’ boards 24 HD

HailGard Fasteners per 4’x8’

board.

Optional:

Firestone ISO 95+ GL, 1.5”-12”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼”

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

301631

105

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” 4’x8’

boards 24 HD HailGard Fasteners

per 4’x8’ board.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

301634

120

Steel, 22

18 gauge,

33 ksi.

Optio

nal:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2”

thickness, Firestone HailGard,

1.5”-4” 4’x8’ boards. 16 All-

Purpose Fasteners per 4’x8’

board.

Optional:

Firestone ISO 95+ GL, 1.5”-12”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼”

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

259059

120

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

Firestone HailGard, 1.5”-4” 4’x8’

boards, 16 All-Purpose Fasteners

per 4’x8’ board.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

259334

120

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2”

thickness, Firestone HailGard,

1.5”-4” 4’x8’ boards. 16 All-

Purpose Fasteners per 4’x8’

board.

Optional:

Firestone ISO 95+ GL, 1.5”-12”,

4’x8’ boards, ISOGARD HD, .5”-

1”, DensDeck or Prime ¼”

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

301583

120

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone

CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” 4’x8’

boards, 16 All-Purpose Fasteners

per 4’x8’ board.

3 Stainless

Expansion Clip, 12” oc

w/ 20” max panel.

UNA

CLAD #10

(Stainless or E-

Coated) – 2 per clip.

301625

49 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Firestone UNA-CLAD UC-3 Steel Panel Uplift Ratings (Cont.)

New Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and

Attachment

Bearing

Plate

Panel Clip Clip Fastener RoofNav

Assembly

Number

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2”

thickness, 16 HD HailGard

Fasteners per 4’x8’ board.

Required:

Firestone ISO 95+ GL, ISOGARD

HD Comp., or Resista, 1.5”-1-

12”, 4’x8’ boards

3 Stain

less

Expansion Clip, 12” oc

w/ 16” max panel.

UNA

CLAD #10

(Stainless) – 2 per

clip.

341935

Firestone UNA-CLAD UC-4 Steel Panel Uplift Ratings

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

105

Steel, 22

gauge Min.,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2” thickness, 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc,

9.75” row spacing, 1”

minimum and 1.5”

maximum length.

259351

105

Steel, 22

gauge Min.,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc,

9.75” row spacing, 1”

minimum and 1.5”

maximum length.

301654

165

Steel, 22

gauge Min.,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone ISO 95+ GL, .5”-.1”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #12 (Stainless

or Steel) w/ nylon washer–

12” oc, 9.75” row spacing,

1” minimum and 1.5”

maximum length. 2 per

plate.

*See Comment under

Securement in RoofNav.

301649

165

Steel, 22

gauge Min.,

33 ksi

Optional:

Polyethylene

(6mil)

Required

Firestone ISO 95+ GL, .5”-.1”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #12 (Stainless

or Steel) w/ nylon washer–

12” oc, 9.75” row spacing,

1” minimum and 1.5”

maximum length. 2 per

plate.

*Firestone UC Bearing

Plates - 4 x 4 in. x min

0.028 in. (102 x 120 x

min 0.72 mm) required

between the clip and

rigid insulation.

259350

105

eel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2” thickness, Firestone

HailGard, 1.5”-4” 4’x8’ boards. 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc,

9.75” row spacing, 1”

minimum and 1.5”

maximum length.

259338

105

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, Firestone

HailGard, 1.5”-4” 4’x8’ boards. 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #

10 (Stainless

or E-Coated) – 12” oc,

9.75” row spacing, 1”

minimum and 1.5”

maximum length.

301637

50 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Firestone UNA-CLAD UC-4 Steel Panel Uplift Ratings (Cont.)

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

120

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

Firestone HailGard, 1.5”-4” thickness. 16 All-Purpose

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc,

9.75” row spacing, 1”

minimum and 1.5”

maximum length.

259340

120

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” thickness. 16 All-Purpose

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc,

9.75” row spacing, 1”

minimum and 1.5”

maximum length.

301640

165

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Required

Firestone ISO 95+ GL, 1”-4”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #12 (Stainless

or Steel) w/ nylon washer–

12” oc, 9.75” row spacing,

2 per plate.

*See Comment under

Securement in RoofNav.

259060

165

Steel, 22

18 gauge,

33 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone ISO 95+ GL, 1”-4”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #12 (Stainless

or Steel) w/ nylon washer–

12” oc, 9.75” row spacing,

2 per plate.

*See Comment under

Securement in RoofNav.

301595

Firestone UNA-CLAD UC-6 Steel Panel Uplift Ratings

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

Steel, 22

gauge Min.,

36 ksi.

tional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 2 per clip.

UC-6 Super Clips

(Galvanized or Stainless

Steel).

259407

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 2 per clip.

UC-6 Super Clips

(Galvanized or Stainless

Steel).

301686

105

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness. 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 2 per clip.

UC-6 Low Float Clips

(Galvanized or Stainless

Steel).

259394

105

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 2 per clip.

UC-6 Low Float Clips

(Galvanized or Stainless

Steel).

301677

135

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Required

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 2 per clip w/

optional nylon washer.

UC-6 Super Clips

(Galvanized or Stainless

Steel).

259406

51 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Firestone UNA-CLAD UC-6 Steel Panel Uplift Ratings (Cont.)

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

135

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone ISO 95+ GL, .5”-.1”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 2 per clip w/

optional nylon washer.

UC-6 Super Clips

(Galvanized or Stainless

Steel).

301678

Firestone UNA-CLAD UC-6 Steel Panel Uplift Ratings

No Deck

Uplift Deck Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

150

None

Required

Bay insulation (varying types), 3”-6” thickness, or

glass fiber batts & blankets (unfaced), 2”-6” thickness.

UNA

CLAD #12 Purlin Drilling

–

36” oc, 18”

row spacing, 2 per clip. UC-6 Low Float

Clips (Galvanized or Stainless Steel).

259061

Firestone UNA-CLAD UC-6 Steel Panel Uplift Ratings

New Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

Steel, 22

16 gauge,

33 ksi

tional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, Firestone

HailGard, 1.5”-4” 4’x8’ boards. 16 All-Purpose

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Super Clips (Galvanized or

Stainless Steel).

259360

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” thickness. 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLA

D #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Low Float Clips (Galvanized

or Stainless Steel).

259361

105

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, Firestone

HailGard, 1.5”-4” 4’x8’ boards. 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Low Float Clips (Galvanized

or Stainless Steel).

259358

105

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, 16 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, ISOGARD HD Composite, or

Resista, 1.5”-12”, 4’x8’ boards.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Low Float Clips (Galvanized

or Stainless Steel).

341936

105

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, Firestone

HailGard, 1.5”-4” 4’x8’ boards. 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Low Float Clips (Galvanized

or Stainless Steel).

301664

52 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Firestone UNA-CLAD UC-6 Steel Panel Uplift Ratings (Cont.)

New Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

105

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” thickness. 24 HD HailGard

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Low Float Clips (Galvanized

or Stainless Steel).

301669

120

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” thickness. 16 All-Purpose

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Super Clips (Galvanized or

Stainless Steel).

259362

120

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” thickness. 16 All-Purpose

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip. UC-6

Super Clips (Galvanized or

Stainless Steel).

301671

135

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Required

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip w/

optional nylon washers. UC-

6 Super Clips (Galvanized or

Stainless Steel).

259359

135

Steel, 22

18 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

Yes

UNA

CLAD #10 (Stainless or

E-Coated) – 12” oc, 18” row

spacing, 2 per clip w/

optional nylon washers. UC-

6 Super Clips (Galvanized or

Stainless Steel).

301666

Firestone UNA-CLAD UC-14 Steel Panel Uplift Ratings

Existing Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2” thickness, 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-.5”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 1” min length

and 1.5” max length.

259408

Steel, 22

gauge Min.,

36 ksi.

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, .5”-.5”, 4’x8’ boards, ISOGARD

HD, .5”-.5”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 1” min length

and 1.5” max length.

301688

Firestone UNA-CLAD UC-14 Steel Panel Uplift Ratings

New Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

Steel, 22

16 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

APA Rated OSB, 7/16”-1/2” thickness, Firestone

HailGard, 1.5”-4” thickness. 24 HD HailGard Fasteners

per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 1” min length

and 1.5” max length.

30165

Steel, 22

16 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Optional:

Separator Sheet – Firestone CLAD-GARD SA.

Required:

Firestone HailGard, 1.5”-4” thickness. 24 HD HailGard

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 1” min length

and 1.5” max length.

301660

53 | P a g e

D e c e m b e r 1 5 , 2 0 1 6

Firestone UNA-CLAD UC-14 Steel Panel Uplift Ratings (Cont.)

New Roof

Uplift Deck Vapor

Retarder

Separator Sheet, Substrate and Attachment Bearing

Plate

Fastener RoofNav

Assembly

Number

Steel, 22

16 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Required

APA Rated OSB, 7/16”-1/2” thickness, 24 HD HailGard

Fasteners per 4’x8’ board.

Optional:

Firestone ISO 95+ GL, 1”-12”, 4’x8’ boards, ISOGARD

HD, .5”-1”, DensDeck or Prime ¼” Min.

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 1” min length

and 1.5” max length.

259354

Steel, 22

16 gauge,

33 ksi

Optional:

Polyethylene

(6mil)

Required

Firestone HailGard, 1.5”-4” thickness. 24 HD HailGard

Fasteners per 4’x8’ board.

UNA

CLAD #10 (Stainless

or E-Coated) – 12” oc, 18”

row spacing, 1” min length

and 1.5” max length.

25935

1.11 Concentrated Load Testing

Testing is per FM 4471, Section 5.4 Foot Traffic Resistance, which uses a 200# load concentrated on a 3” x 3” square

area at mid span with joists on 5 foot centers.

Table 1.11 Concentrated Load Testing

Panel Panel description

Maximum

Deflection

Permanent

Deflection Damage

UC-3 Nominal 20” wide, 24 ga. Steel with 1.5” rib; 180˚ seam 0.1875” None No failure

UC-4 Nominal 17-3/4” wide, 24 ga. Steel with 1.5” Snap rib 0.125” None No failure

UC-14 Nominal 18” wide, 24 ga. Steel with 1.75” rib; Snap Lock 0.0625” None No failure

UC-6 Nominal 18” wide, 24 ga. Steel with 1.5” rib; 180˚ seam 0.0625” None No failure

Metal Code Approval Guide Updated 12152016

Navigation menu

Versions of this User Manual:

Views

Navigation
