MR MIDI System Exclusive Specification

Document Version 1.53/2.11-A

Written by: Jeff R. Dec

Documentation Management: Bill Whipple

Thanks to: Robby Berman, Michael Chen

Copyright © 1997

ENSONIQ Corp

155 Great Valley Parkway

Box 3035

Malvern, PA 19355-0735

USA

World Wide Web(http://www.ensoniq.com)

Printed in U.S.A.

All Rights Reserved

Your Authorized ENSONIQ Dealer is your primary source for service and suppo

This manual is copyrighted and all rights are reserved by ENSONIQ Corp. Thi

Although every effort has been made to ensure the accuracy of the text and

TABLE OF CONTENTS:

1.0 Introduction and Overview

1.1 Data Type Definitions

1.2 4 to 5 Bulk SysEx Data Encoding

1.3 Data Block Size

1.4 Checksum Calculation

1.5 Reserved/Not Defined Data

1.6 MR-Rack and MR-61/76 Model ID Code

1.7 Error Messages

2.0 Universal System Exclusive Messages

2.1 Universal System Exclusive Device Inquiry Message

2.2 Universal System Exclusive Device Identity Reply Message

2.3 Universal System Exclusive General MIDI ON Message

2.4 Universal System Exclusive General MIDI OFF Message

2.5 Universal MIDI Bulk Tuning Dump Reply Message

2.6 Universal MIDI Single Note Tuning Change Message

3.0 Ensoniq MR Specific System Exclusive Messages

3.1 Single Item Transmit Request

3.1.1 System Parameter Transmit Request

3.1.2 Single Sound Program Transmit Request

3.1.3 Single Performance Transmit Request

3.1.4 Single Drum Kit Program Transmit Request

3.2 Parameter Change Request

3.2.1 Sound Program Parameter Change Request

3.2.2 Performance Parameter Change Request

3.2.3 Drum Kit Program Parameter Change Request

3.3 Waveform Information Request

3.4 Initialize RAM Request

3.5 Transmit Display/LED Request

mrsysex.txt 10/10/2011 8:17 PM

Page 1 of 161

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

3.6 Receive Display/LED Request

4.0 Global System Parameter Structure

4.1 Single Sound Program Dump Data Format

4.2 Transmit Display/LED Dump Data Format

4.3 Receive Display/LED Dump Data Format

5.0 Sound Program Parameters Structure

5.1 Sound Program Insert Effect Structure

6.0 Layer Parameter Structure

6.1 Pitch Parameters

6.2 Filter Parameters

6.3 Waveform Parameters

6.4 Amplitude Parameters

6.5 Envelope 1 Parameters

6.6 Envelope 2 Parameters

6.7 Envelope 3 Parameters

6.8 LFO Parameters

7.0 Drum Kit Program Parameters

8.0 Performance Parameters

8.1 Part 1 Performance Parameters

8.2 Part 2 thru 16 Performance Parameters

8.3 Performance Effects Parameters

8.4 Performance PerfEditKit Drum Kit Program Parameters

Appendix 1 - MR Internal Waveform List

Appendix 2 - EXP1 World Expansion Board Waveform List

Appendix 3 - EXP2 Drum Expansion Board Waveform List

Appendix 4 - EXP3 Urban Dance Project Expansion Board Waveform List

Appendix 5 - Insert Effect Parameters

Appendix 6 - Breakdown of an Example Single Sound Program SysEx Dump

1.0 Introduction and Overview

This document describes the MIDI System Exclusive (SysEx) communication pro

1.1 Data Type Definitions

The following internal data types are used within the MR:

Unsigned Long Word

Positive Integer (4-bytes) ranging from 0 to 4294967295

Long Word

Two’s Complement Signed Integer (4-bytes) ranging f

Unsigned Short Word Positive Integer (2-bytes) ranging from 0 to 65535

Short Word

Two’s Complement Signed Integer (2-bytes) ranging from -32768 to +32767

Unsigned Byte Positive Integer ranging from 0 to 255

Byte

Two’s Complement Signed Integer ranging from -128 to +127

ASCII Character Positive Integer (1-byte) ranging from 0 to 127

Unless otherwise specified, all data types are in Motorola big-endian byte order.

1.2 4 to 5 Bulk SysEx Data Encoding

Where specified, the MR will encode/interpret a consecutive group of 4-bytes:

Byte #0 b31b30b29b28b27b26b25b24

Byte #1 b23b22b21b20b19b18b17b16

Byte #2 b15b14b13b12b11b10b09b08

mrsysex.txt 10/10/2011 8:17 PM

Page 2 of 161

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

Byte #3 b07b06b05b04b03b02b01b00

as the following 5 consecutive SysEx bytes:

Byte #0 0 b06b05b04b03b02b01b00

Byte #1 0 b13b12b11b10b09b08b07

Byte #2 0 b20b19b18b17b16b15b14

Byte #3 0 b27b26b25b24b23b22b21

Byte #4 0 0 0 0 b31b30b29b28

In the event that less than 4 bytes need to be encoded, the remaining bytes

1.3 Data Block Size

The Data Block Size parameter, which is found in certain Ensoniq specific S

1.4 Checksum Calculation

Unless otherwise specified, checksum values are to be calculated by perform

1.5 Reserved/Not Defined Data

Any data that is denoted as Reserved or Not Defined should NEVER be modifie

1.6 MR-Rack and MR-61/76 Model ID Code

The Model ID Code for the MR-Rack is defined as the value 00h, while the MR

1.7 Error Messages

The following SysEx error message will be generated in response to an impro

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

7F Error Reply

01 Bad Message Error Code

F7 End of System Exclusive

2.0 Universal System Exclusive Messages

The following Universal Real-Time and Non-Real-Time System Exclusive messag

2.1 Universal System Exclusive Device Inquiry Message

The MR supports the MIDI Device Inquiry message which allows instruments an

mrsysex.txt 10/10/2011 8:17 PM

Page 3 of 161

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

F0 System Exclusive Status Byte

7E Non Real Time Message Code

nn Device ID Number (0 to 127)

or

7F All Channel Broadcast Code

06 General Information Message Code

01 Identity Request Message Code

F7 End of System Exclusive

2.2 Universal System Exclusive Device Identity Reply Message

The following Identity Reply message contains information about the MR, and

F0 System Exclusive Status Byte

7E Non Real Time Message Code

nn Device ID Number (0 to 127)

06 General Information Message Code

02 Identity Reply Message Code

0F Ensoniq Manufacturer's Code

09 MR Product Family ID Code (LSByte)

00 MR Product Family ID Code (MSByte)

mm MR Family Member ID Code (LSByte)

00 MR Family Member ID Code (MSByte)

rr Software Revision Information

00 Reserved

ii Major Version Number (Integer Portion)

nn Minor Version Number (Decimal Fraction Portion)

F7 End of System Exclusive

2.3 Universal System Exclusive General MIDI ON Message

The following message will cause the MR-Rack to select the General MIDI per

F0 System Exclusive Status Byte

7E Non Real Time Message Code

nn Device ID Number (0 to 127)

or

7F All Channel Broadcast Code

09 General MIDI Message Code

01 General MIDI "ON" Message Code

F7 End of System Exclusive

2.4 Universal System Exclusive General MIDI OFF Message

Upon the reception of this message, the MR will conclude General MIDI opera

mrsysex.txt 10/10/2011 8:17 PM

Page 4 of 161

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

F0 System Exclusive Status Byte

7E Non Real Time Message Code

nn Device ID Number (0 to 127)

or

7F All Channel Broadcast Code

09 General MIDI Message Code

02 General MIDI "OFF" Message Code

F7 End of System Exclusive

2.5 Universal MIDI Bulk Tuning Dump Reply Message

As a recent addition to the MIDI Specification and the Ensoniq product line

F0 System Exclusive Status Byte

7E Non Real Time Message Code

nn Device ID Number (0 to 127)

or

7F All Channel Broadcast Code

08 MIDI Tuning Standard Message Code

01 Bulk Dump Reply Message Code

tt Tuning Program Number (0 to 127)

(This is currently ignored by the MR)

[aa] x 16 Tuning Program Name - 16 ASCII Characters

(This is currently ignored by the MR)

xx Semitone Frequency Data for MIDI Key #0

yy MSB Fraction of Semitone Data for MIDI Key #0

zz LSB Fraction of Semitone Data for MIDI Key #0

Repeat [xx,yy,zz] 127 More Times For MIDI Keys #1 to 127

cc Checksum = XOR of

7E (Non Real Time Message Code)

08 (MIDI Tuning Standard Message Code)

01 (Bulk Dump Reply Message Code)

tt (Tuning Program Number)

All 128 sets of [xx,yy,zz]

F7 End of System Exclusive

2.6 Universal MIDI Single Note Tuning Change Message

This message allows real-time, performance oriented adjustments to be made

In addition, the MR’s response to this message has been extended to allow a

F0 System Exclusive Status Byte

7F Real Time Message Code

mrsysex.txt 10/10/2011 8:17 PM

Page 5 of 161

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

nn Device ID Number (0 to 127)

or

7F All Channel Broadcast Code

08 MIDI Tuning Standard Message Code

02 Note Change Message Code

tt Tuning Program Number (0 to 127)

(This is currently ignored by the MR)

cc Number of Note Changes

kk MIDI Key Number (0 to 127)

xx Semitone Frequency Data for MIDI Key kk

yy MSB Fraction of Semitone Data for MIDI Key kk

zz LSB Fraction of Semitone Data for MIDI Key kk

Repeat [kk,xx,yy,zz] to Equal Number of Note Changes Minus One

F7 End of System Exclusive

3.0 Ensoniq MR Specific System Exclusive Messages

This section describes the entire set of Ensoniq specific SysEx messages th

3.1 Single Item Transmit Request

This multi-context command will initiate a dump of a single Sound Program,

3.1.1 System Parameter Transmit Request

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

03 Transmit Request Command

00 System Parameter Dump Request

00 Reserved

00 Reserved

F7 End of System Exclusive

The MR will respond to this command with the following SysEx message string:

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

mrsysex.txt 10/10/2011 8:17 PM

Page 6 of 161

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

43 Transmit Request Reply Command

00 System Parameter Dump Request

00 Reserved

00 Reserved

bb Data Block Size - 0 b06b05b04b03b02b01b00

bb Data Block Size - 0 b13b12b11b10b09b08b07

bb Data Block Size - 0 b20b19b18b17b16b15b14

bb Data Block Size - 0 b27b26b25b24b23b22b21

0b Data Block Size - 0 0 0 0 b31b30b29b28

Start of Data Block

[Section 4.0 Data Structure] ( 4-to-5 Bulk SysEx Data Encoded

End of Data Block

kk 14-Bit Checksum - LSByte

kk 14-Bit Checksum - MSByte

F7 End of System Exclusive

3.1.2 Single Sound Program Transmit Request

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

03 Transmit Request Command

01 Single Sound Program Dump Request

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

F7 End of System Exclusive

The MR will respond to this command with the following SysEx message string:

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

mrsysex.txt 10/10/2011 8:17 PM

Page 7 of 161

386

387

388

389

390

391

392

393

394

395

396

397

398

399

400

401

402

403

404

405

406

407

408

409

410

411

412

413

414

415

416

417

418

419

420

421

422

423

424

425

426

427

428

429

430

431

432

433

434

435

436

437

438

439

440

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

43 Transmit Request Reply Command

01 Single Sound Program Dump Request

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

bb Data Block Size - 0 b06b05b04b03b02b01b00

bb Data Block Size - 0 b13b12b11b10b09b08b07

bb Data Block Size - 0 b20b19b18b17b16b15b14

bb Data Block Size - 0 b27b26b25b24b23b22b21

0b Data Block Size - 0 0 0 0 b31b30b29b28

Start of Data Block

[Section 4.1 Data Structure] ( 4-to-5 Bulk SysEx Data Encoded

End of Data Block

kk 14-Bit Checksum - LSByte

kk 14-Bit Checksum - MSByte

F7 End of System Exclusive

3.1.3 Single Performance Transmit Request

The MR-61/76 does not allow for Performance dumps because the sequencer has

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

nn Device ID Number (0 to 127)

03 Transmit Request Command

02 Single Performance Dump Request

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

F7 End of System Exclusive

The MR-Rack will respond to this command with the following SysEx message string:

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

nn Device ID Number (0 to 127)

43 Transmit Request Reply Command

02 Single Performance Dump Request

mrsysex.txt 10/10/2011 8:17 PM

Page 8 of 161

441

442

443

444

445

446

447

448

449

450

451

452

453

454

455

456

457

458

459

460

461

462

463

464

465

466

467

468

469

470

471

472

473

474

475

476

477

478

479

480

481

482

483

484

485

486

487

488

489

490

491

492

493

494

495

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

bb Data Block Size - 0 b06b05b04b03b02b01b00

bb Data Block Size - 0 b13b12b11b10b09b08b07

bb Data Block Size - 0 b20b19b18b17b16b15b14

bb Data Block Size - 0 b27b26b25b24b23b22b21

0b Data Block Size - 0 0 0 0 b31b30b29b28

Start of Data Block

[Section 8 Data Structure] ( 4-to-5 Bulk SysEx Data Encoded

End of Data Block

kk 14-Bit Checksum - LSByte

kk 14-Bit Checksum - MSByte

F7 End of System Exclusive

3.1.4 Single Drum Kit Program Transmit Request

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

03 Transmit Request Command

03 Single Drum Kit Program Dump Request

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

F7 End of System Exclusive

The MR will respond to this command with the following SysEx message string:

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

43 Transmit Request Reply Command

03 Single Drum Kit Program Dump Request

mrsysex.txt 10/10/2011 8:17 PM

Page 9 of 161

496

497

498

499

500

501

502

503

504

505

506

507

508

509

510

511

512

513

514

515

516

517

518

519

520

521

522

523

524

525

526

527

528

529

530

531

532

533

534

535

536

537

538

539

540

541

542

543

544

545

546

547

548

549

550

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

bb Data Block Size - 0 b06b05b04b03b02b01b00

bb Data Block Size - 0 b13b12b11b10b09b08b07

bb Data Block Size - 0 b20b19b18b17b16b15b14

bb Data Block Size - 0 b27b26b25b24b23b22b21

0b Data Block Size - 0 0 0 0 b31b30b29b28

Start of Data Block

[Section 7 Data Structure] ( 4-to-5 Bulk SysEx Data Encoded )

End of Data Block

kk 14-Bit Checksum - LSByte

kk 14-Bit Checksum - MSByte

F7 End of System Exclusive

3.2 Parameter Change Request

This multi-context command will allow for a consecutive group of one to fou

3.2.1 Sound Program Parameter Change Request

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

05 Parameter Change Request Command

01 Sound Program Parameter

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

01 Program Parameter (See Section 5.0)

or

02 Layer Parameter (See Section 6)

yy Layer Number minus 1 (LSByte)

zz Layer Number minus 1 (MSByte)

bb Parameter Offset - 0 b06b05b04b03b02b01b00

bb Parameter Offset - 0 b13b12b11b10b09b08b07

bb Parameter Offset - 0 b20b19b18b17b16b15b14

bb Parameter Offset - 0 b27b26b25b24b23b22b21

0b Parameter Offset - 0 0 0 0 b31b30b29b28

mrsysex.txt 10/10/2011 8:17 PM

Page 10 of 161

551

552

553

554

555

556

557

558

559

560

561

562

563

564

565

566

567

568

569

570

571

572

573

574

575

576

577

578

579

580

581

582

583

584

585

586

587

588

589

590

591

592

593

594

595

596

597

598

599

600

601

602

603

604

605

0b Parameter Byte Size (1 to 4)

00

00

00

00

bb Parameter Value - 0 b06b05b04b03b02b01b00

bb Parameter Value - 0 b13b12b11b10b09b08b07

bb Parameter Value - 0 b20b19b18b17b16b15b14

bb Parameter Value - 0 b27b26b25b24b23b22b21

0b Parameter Value - 0 0 0 0 b31b30b29b28

F7 End of System Exclusive

3.2.2 Performance Parameter Change Request

The MR-61/76 does not allow for Performance parameter changes because the s

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

nn Device ID Number (0 to 127)

05 Parameter Change Request Command

02 Performance Parameter (See Section 8)

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

00 Reserved

00 Reserved

00 Reserved

bb Parameter Offset - 0 b06b05b04b03b02b01b00

bb Parameter Offset - 0 b13b12b11b10b09b08b07

bb Parameter Offset - 0 b20b19b18b17b16b15b14

bb Parameter Offset - 0 b27b26b25b24b23b22b21

bb Parameter Offset - 0 0 0 0 b31b30b29b28

0b Parameter Byte Size (1 to 4)

00

00

00

00

bb Parameter Value - 0 b06b05b04b03b02b01b00

bb Parameter Value - 0 b13b12b11b10b09b08b07

bb Parameter Value - 0 b20b19b18b17b16b15b14

bb Parameter Value - 0 b27b26b25b24b23b22b21

bb Parameter Value - 0 0 0 0 b31b30b29b28

F7 End of System Exclusive

mrsysex.txt 10/10/2011 8:17 PM

Page 11 of 161

606

607

608

609

610

611

612

613

614

615

616

617

618

619

620

621

622

623

624

625

626

627

628

629

630

631

632

633

634

635

636

637

638

639

640

641

642

643

644

645

646

647

648

649

650

651

652

653

654

655

656

657

658

659

660

3.2.3 Drum Kit Program Parameter Change Request

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

05 Parameter Change Request Command

03 Drum Kit Program Parameter (See Section 7)

pp Program Number (0 to 127)

bb Bank Number (0 to 127)

00 Reserved

00 Reserved

00 Reserved

bb Parameter Offset - 0 b06b05b04b03b02b01b00

bb Parameter Offset - 0 b13b12b11b10b09b08b07

bb Parameter Offset - 0 b20b19b18b17b16b15b14

bb Parameter Offset - 0 b27b26b25b24b23b22b21

bb Parameter Offset - 0 0 0 0 b31b30b29b28

0b Parameter Byte Size (1 to 4)

00

00

00

00

bb Parameter Value - 0 b06b05b04b03b02b01b00

bb Parameter Value - 0 b13b12b11b10b09b08b07

bb Parameter Value - 0 b20b19b18b17b16b15b14

bb Parameter Value - 0 b27b26b25b24b23b22b21

bb Parameter Value - 0 0 0 0 b31b30b29b28

F7 End of System Exclusive

3.3 Waveform Information Request

The following command string will request a dump of all the waveform names,

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

mrsysex.txt 10/10/2011 8:17 PM

Page 12 of 161

661

662

663

664

665

666

667

668

669

670

671

672

673

674

675

676

677

678

679

680

681

682

683

684

685

686

687

688

689

690

691

692

693

694

695

696

697

698

699

700

701

702

703

704

705

706

707

708

709

710

711

712

713

714

715

06 Waveform Information Request Message

00 Query Expansion Board Slot #1

or

01 Query Expansion Board Slot #2

or

02 Query Expansion Board Slot #3

F7 End of System Exclusive

The MR will respond to a properly formatted command with the following SysEx message:

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

46 Waveform Information Reply Message

00 Query Expansion Board Slot #1

or

01 Query Expansion Board Slot #2

or

02 Query Expansion Board Slot #3

bb

Number of Waveform Information Blocks - 0 b06b05b04b03b02b01b00

bb

Number of Waveform Information Blocks - 0 b13b12b11b10b09b08b07

bb

Number of Waveform Information Blocks - 0 b20b19b18b17b16b15b14

bb

Number of Waveform Information Blocks - 0 b27b26b25b24b23b22b21

0b

Number of Waveform Information Blocks - 0 0 0 0 b31b30b29b28

Start of Waveform Information Block #1

4-to-5 Bulk SysEx Data Encoded:

[Waveform Number (MSByte)]

[Waveform Number (LSByte)]

[Waveform Checksum (LSByte)]

[Waveform Checksum (MSByte)]

Waveform Name ( NULL Terminated ASCII String )

End of Waveform Information Block #1

The Waveform Information Block Is Repeated For The Remaining Waveforms

F7 End of System Exclusive

3.4 Initialize RAM Request

mrsysex.txt 10/10/2011 8:17 PM

Page 13 of 161

716

717

718

719

720

721

722

723

724

725

726

727

728

729

730

731

732

733

734

735

736

737

738

739

740

741

742

743

744

745

746

747

748

749

750

751

752

753

754

755

756

757

758

759

760

761

762

763

764

765

766

767

768

769

770

The function of this command is to erase, or nullify, a range of RAM Sound

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

07 Initialize RAM Request

01 Sound Program RAM

pp Starting Program Number (0 to 127)

bb Bank Number (0 to 127)

cc Number of Programs to Clear - LSByte

cc Number of Programs to Clear - MSByte

F7 End of System Exclusive

Note:

If the Starting Program Number added to the Number of Programs to Clear exceeds 127,

the MR will wrap around to Program #0, and continue within the SAME bank, after erasing

Program #127.

3.5 Transmit Display/LED Request

The following command string will request a dump of the current LCD screen

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

09 Transmit Display/LED Request Message

F7 End of System Exclusive

The MR will send the following SysEx message in response to the previous command:

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

mrsysex.txt 10/10/2011 8:17 PM

Page 14 of 161

771

772

773

774

775

776

777

778

779

780

781

782

783

784

785

786

787

788

789

790

791

792

793

794

795

796

797

798

799

800

801

802

803

804

805

806

807

808

809

810

811

812

813

814

815

816

817

818

819

820

821

822

823

824

825

nn Device ID Number (0 to 127)

49 Transmit Display/LED Reply Message

[Section 4.2 Data Structure]

F7 End of System Exclusive

3.6 Receive Display/LED Request

This command will temporarily display a user specified ASCII text string on

F0 System Exclusive Status Byte

0F Ensoniq Manufacturer Code

09 MR Family ID Code

00 MR-Rack Model ID Code

or

01/02 MR-61/76 Model ID Code

nn Device ID Number (0 to 127)

0A Receive Display/LED Request Message

[Section 4.3 Data Structure]

F7 End of System Exclusive

4.0 Global System Parameter Structure

The following is the Global System Parameter Structure for the MR-Rack:

Offset Parameter Name Range/Values

00-03h Global System Parameter Size

0000001Ch, Fixed Unsigned Long Word

04-07h Global System Parameter Tag 'GBL1' In ASCII

08h System Pitch Bend Down Range See Table 5.3

09h System Pitch Bend Up Range See Table 5.2

0Ah System Fine Tune Offset See Table 4.1

0Bh System Pitch Table See Table 5.1

0C-0Dh System Tempo

25 to 250, Unsigned Short Word

0Eh System Tempo Clock Source 00h = Internal

01h = MIDI

0Fh Audition Mode See Table 4.2

10h Wake-Up Mode 00h = Last Page

01h = Last Sound

02h = General MIDI

03h = Demo

11h Write Protect 00h = OFF

01h = Prompt

12h System Stak MIDI Channel 0 to 15

13h System CTRL1 Source See Table 4.3

14h System CTRL2 Source See Table 4.3

15h System CTRL3 Source See Table 4.3

16h System CTRL4 Source See Table 4.3

mrsysex.txt 10/10/2011 8:17 PM

Page 15 of 161

826

827

828

829

830

831

832

833

834

835

836

837

838

839

840

841

842

843

844

845

846

847

848

849

850

851

852

853

854

855

856

857

858

859

860

861

862

863

864

865

866

867

868

869

870

871

872

873

874

875

876

877

878

879

880

17h System MIDI Enables 01h = All Notes Off Recv

Bitwise Definitions

02h = System Exclusive Recv

04h = Bank & Prog Change Recv

08h = Part Parameter Reset

10h = Perf Prog Change Recv

20h = Auto Select FX Bus

80h = Not Defined

18h System Exclusive Device ID Number 0 to 127

19h Stak Coherence 00h = OFF

01h = ON

1Ah System Pitch Bend Mode 00h = As Programmed

01h = Normal

02h = Held

1Bh Aux To Main Outs 00h = Never

01h = Always

02h = Auto

The following is the Global System Parameter Structure for the MR-61/76:

Offset Parameter Name Range/Values

00-03h Global System Parameter Size

00000028h, Fixed Unsigned Long Word

04-07h Global System Parameter Tag 'GBL1' In ASCII

08h System Pitch Bend Down Range See Table 5.3

09h System Pitch Bend Up Range See Table 5.2

0Ah System Fine Tune Offset See Table 4.1

0Bh System Pitch Table See Table 5.1

0C-0Dh Reserved

0Eh System Tempo Clock Source 00h = Internal

01h = MIDI

0F-10h Reserved

11h Write Protect 00h = OFF

01h = Prompt

12h Base MIDI Channel 0 to 15

13h System CTRL1 Source See Table 4.3

14h System CTRL2 Source See Table 4.3

15h System CTRL3 Source See Table 4.3

16h System CTRL4 Source See Table 4.3

17h System MIDI Enables 01h = All Notes Off Recv

Bitwise Definitions 02h = Not Defined

04h = Bank & Prog Change Recv

08h = Track Parameter Reset

10h = Not Defined

20h = Auto Select FX Bus

80h = Not Defined

18h System Exclusive Device ID Number 0 to 127

19h Reserved

1Ah System Pitch Bend Mode 00h = As Programmed

01h = Normal

02h = Held

1Bh Aux To Main Outs 00h = Never

01h = Always

02h = Auto

1Ch Touch Curve 00h = Table-1

01h = Table-2

mrsysex.txt 10/10/2011 8:17 PM

Page 16 of 161

881

882

883

884

885

886

887

888

889

890

891

892

893

894

895

896

897

898

899

900

901

902

903

904

905

906

907

908

909

910

911

912

913

914

915

916

917

918

919

920

921

922

923

924

925

926

927

928

929

930

931

932

933

934

935

02h = Table-3

03h = Table-4

04h = Fixed 64

05h = Fixed 127

1Dh Pressure Threshold 00h = Soft

01h = Medium

02h = Firm

03h = Hard

1Eh Foot Switch 1 Left Mode See Table 4.4

1Fh Foot Switch 1 Right Mode See Table 4.4

20h Foot Switch 2 Left Mode See Table 4.4

21h Foot Switch 2 Right Mode See Table 4.4

22h CV Pedal Mode 00h = Foot Controller #004

01h = Volume #007

02h = SysCTRL1

03h = SysCTRL2

04h = SysCTRL3

05h = SysCTRL4

23-24h Reserved

25h Transmit MIDI Clocks 00h = OFF

01h = ON

26h FX Out Enables 01h = Insert FX Out

Bitwise Definitions 02h = Global Chorus Out

04h = Global Reverb Out

08h = Dry FX Bus Out

10h = Not Defined

20h = Not Defined

40h = Not Defined

80h = Not Defined

27h Rewind Sound 00h = OFF

01h = ON

4.1 Single Sound Program Dump Data Format

Offset Parameter Name Range/Values

00-03h Sound Program Size Unsigned Long Word

04-07h Sound Program Tag 'PRG1' In ASCII

08-0Bh Offset Table Size 00000018h

0C-0Fh Offset Table Tag 'OFTT' In ASCII

The following parameter is used to specify the starting offset value of the

10-13h Effects Offset

00000000h ( No Insert Effect

00000140h ( 01 Layer Defined

000001F4h ( 02 Layers Defined

000002A8h ( 03 Layers Defined

0000035Ch ( 04 Layers Defined

00000410h ( 05 Layers Defined

000004C4h ( 06 Layers Defined

00000578h ( 07 Layers Defined

0000062Ch ( 08 Layers Defined

000006E0h ( 09 Layers Defined

mrsysex.txt 10/10/2011 8:17 PM

Page 17 of 161

936

937

938

939

940

941

942

943

944

945

946

947

948

949

950

951

952

953

954

955

956

957

958

959

960

961

962

963

964

965

966

967

968

969

970

971

972

973

974

975

976

977

978

979

980

981

982

983

984

985

986

987

988

989

990

00000794h ( 10 Layers Defined

00000848h ( 11 Layers Defined

000008FCh ( 12 Layers Defined

000009B0h ( 13 Layers Defined

00000A64h ( 14 Layers Defined

00000B18h ( 15 Layers Defined

00000BCCh ( 16 Layers Defined

14-17h Program Parameters Offset 00000020h

18-1Bh Layer Offset Table Offset 00000044h

1C-1Fh Reserved 00000000h

20-43h Sound Program Parameters Structure See Section 5.0

The Layer Offset Table is used to store the starting offset value for each

44-47h Layer Offset Table Size 00000048h

48-4Bh Layer Offset Table Tag 'OFST' In ASCII

4C-4Fh Layer #01 Offset 0000008Ch

50-53h Layer #02 Offset 00000140h or 00000000h

54-57h Layer #03 Offset 000001F4h or 00000000h

58-5Bh Layer #04 Offset 000002A8h or 00000000h

5C-5Fh Layer #05 Offset 0000035Ch or 00000000h

60-63h Layer #06 Offset 00000410h or 00000000h

64-67h Layer #07 Offset 000004C4h or 00000000h

68-6Bh Layer #08 Offset 00000578h or 00000000h

6C-6Fh Layer #09 Offset 0000062Ch or 00000000h

70-73h Layer #10 Offset 000006E0h or 00000000h

74-77h Layer #11 Offset 00000794h or 00000000h

78-7Bh Layer #12 Offset 00000848h or 00000000h

7C-7Fh Layer #13 Offset 000008FCh or 00000000h

80-83h Layer #14 Offset 000009B0h or 00000000h

84-87h Layer #15 Offset 00000A64h or 00000000h

88-8Bh Layer #16 Offset 00000B18h or 00000000h

Because the MR dynamically allocates memory for a given Sound Program based

08C-13Fh Layer #01 Parameter Structure See Section 6

140-1F3h Layer #02 Parameter Structure See Section 6

1F4-2A7h Layer #03 Parameter Structure See Section 6

2A8-35Bh Layer #04 Parameter Structure See Section 6

35C-40Fh Layer #05 Parameter Structure See Section 6

410-4C3h Layer #06 Parameter Structure See Section 6

4C4-577h Layer #07 Parameter Structure See Section 6

578-62Bh Layer #08 Parameter Structure See Section 6

62C-6DFh Layer #09 Parameter Structure See Section 6

6E0-793h Layer #10 Parameter Structure See Section 6

794-847h Layer #11 Parameter Structure See Section 6

848-8FBh Layer #12 Parameter Structure See Section 6

8FC-9AFh Layer #13 Parameter Structure See Section 6

9B0-A63h Layer #14 Parameter Structure See Section 6

A64-B17h Layer #15 Parameter Structure See Section 6

B18-BCBh Layer #16 Parameter Structure See Section 6

The Sound Program Insert Effect Structure, as outlined in Section 5.1, will

mrsysex.txt 10/10/2011 8:17 PM

Page 18 of 161

991

992

993

994

995

996

997

998

999

1000

1001

1002

1003

1004

1005

1006

1007

1008

1009

1010

1011

1012

1013

1014

1015

1016

1017

1018

1019

1020

1021

1022

1023

1024

1025

1026

1027

1028

1029

1030

1031

1032

1033

1034

1035

1036

1037

1038

1039

1040

1041

1042

1043

1044

1045

140-1A9h Sound Program Insert Effect Structure ( 01 Layer Defined

1F4-25Dh Sound Program Insert Effect Structure ( 02 Layers Defined

2A8-311h Sound Program Insert Effect Structure ( 03 Layers Defined

35C-3C5h Sound Program Insert Effect Structure ( 04 Layers Defined

410-479h Sound Program Insert Effect Structure ( 05 Layers Defined

4C4-52Dh Sound Program Insert Effect Structure ( 06 Layers Defined

578-5E1h Sound Program Insert Effect Structure ( 07 Layers Defined

62C-695h Sound Program Insert Effect Structure ( 08 Layers Defined

6E0-749h Sound Program Insert Effect Structure ( 09 Layers Defined

794-7FDh Sound Program Insert Effect Structure ( 10 Layers Defined

848-8B1h Sound Program Insert Effect Structure ( 11 Layers Defined

8FC-965h Sound Program Insert Effect Structure ( 12 Layers Defined

9B0-A19h Sound Program Insert Effect Structure ( 13 Layers Defined

A64-ACDh Sound Program Insert Effect Structure ( 14 Layers Defined

B18-B81h Sound Program Insert Effect Structure ( 15 Layers Defined

BCC-C35h Sound Program Insert Effect Structure ( 16 Layers Defined

4.2 Transmit Display/LED Dump Data Format

The following is the Transmit Display/LED Dump data format for the MR-Rack:

Offset Parameter Name Range/Values

00-13h LCD Display - Line #1 - Page #0 ASCII Text String

14-27h LCD Display - Line #2 - Page #0 ASCII Text String

28-3Bh LCD Display - Line #1 - Page #1 ASCII Text String

3C-4Fh LCD Display - Line #2 - Page #1 ASCII Text String

50h Performance Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

51h System Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

52h Effects Bypass LED Status 00h = OFF

01h = ON

02h = Flashing

53h Effects Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

54h Sound Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

55h Parameter Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

56h Mute Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

57h Reserved

The following is the Transmit Display/LED Dump data format for the MR-61/76:

Offset Parameter Name Range/Values

mrsysex.txt 10/10/2011 8:17 PM

Page 19 of 161

1046

1047

1048

1049

1050

1051

1052

1053

1054

1055

1056

1057

1058

1059

1060

1061

1062

1063

1064

1065

1066

1067

1068

1069

1070

1071

1072

1073

1074

1075

1076

1077

1078

1079

1080

1081

1082

1083

1084

1085

1086

1087

1088

1089

1090

1091

1092

1093

1094

1095

1096

1097

1098

1099

1100

00-13h LCD Display - Line #1 - Page #0 ASCII Text String

14-27h LCD Display - Line #2 - Page #0 ASCII Text String

28-3Bh LCD Display - Line #1 - Page #1 ASCII Text String

3C-4Fh LCD Display - Line #2 - Page #1 ASCII Text String

50h Sequencer Track 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

51h Sequencer Track 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

52h Sequencer Track 3 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

53h Sequencer Track 4 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

54h Sequencer Track 5 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

55h Sequencer Track 6 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

56h Sequencer Track 7 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

57h Sequencer Track 8 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

58h Sequencer Track 9 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

59h Sequencer Rhythm 00h = OFF

Pushbutton (Right) LED Status 01h = ON

02h = Flashing

5Ah Sequencer Track 11 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5Bh Sequencer Track 12 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5Ch Sequencer Track 13 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5Dh Sequencer Track 14 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5Eh Sequencer Track 15 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5Fh Sequencer Track 16 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

mrsysex.txt 10/10/2011 8:17 PM

Page 20 of 161

1101

1102

1103

1104

1105

1106

1107

1108

1109

1110

1111

1112

1113

1114

1115

1116

1117

1118

1119

1120

1121

1122

1123

1124

1125

1126

1127

1128

1129

1130

1131

1132

1133

1134

1135

1136

1137

1138

1139

1140

1141

1142

1143

1144

1145

1146

1147

1148

1149

1150

1151

1152

1153

1154

1155

60h Song Editor Intro 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

61h Song Editor Verse 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

62h Song Editor Chorus 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

63h Song Editor Verse 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

64h Song Editor Chorus 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

65h Song Editor Bridge 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

66h Song Editor Solo 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

67h Song Editor Ending 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

68h Song Editor Select Song 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

69h Song Editor Bank 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Ah Song Editor Bank 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Bh Song Editor Bank 3 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Ch Song Editor Song Playlist 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Dh Song Editor From Region 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Eh Song Editor To Region 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Fh Song Editor Loop 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

70h Song Editor Record Mode 00h = OFF

Replace LED Status 01h = ON

02h = Flashing

71h Song Editor Record Mode 00h = OFF

Add LED Status 01h = ON

02h = Flashing

72h Song Editor Record Mode 00h = OFF

mrsysex.txt 10/10/2011 8:17 PM

Page 21 of 161

1156

1157

1158

1159

1160

1161

1162

1163

1164

1165

1166

1167

1168

1169

1170

1171

1172

1173

1174

1175

1176

1177

1178

1179

1180

1181

1182

1183

1184

1185

1186

1187

1188

1189

1190

1191

1192

1193

1194

1195

1196

1197

1198

1199

1200

1201

1202

1203

1204

1205

1206

1207

1208

1209

1210

Step LED Status 01h = ON

02h = Flashing

73h Song Editor Record Mode 00h = OFF

Track Mix LED Status 01h = ON

02h = Flashing

74h Song Editor Record Mode 00h = OFF

Final Mix LED Status 01h = ON

02h = Flashing

75-77h Reserved

78h Sequencer Play 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

79h Sequencer Record 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

7Ah Sequencer Rhythm 00h = OFF

Pushbutton (Left) LED Status 01h = ON

02h = Flashing

7B-7Fh Reserved

80h FX/Mixdown Mute 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

81h FX/Mixdown Solo 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

82-87h Reserved

88h Drum Machine Select Rhythm 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

89h Drum Machine Start/Stop 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

8Ah Drum Machine Fill/Variation 00h = OFF

Pushbutton (Left) LED Status 01h = ON

02h = Flashing

8Bh Drum Machine Fill/Variation 00h = OFF

Pushbutton (Right) LED Status 01h = ON

02h = Flashing

8C-8Fh Reserved

90h Sound Finder Select Sound 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

91h Sound Finder Transpose 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

92h Sound Finder Split 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

93h Sound Finder Layer 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

94-97h Reserved

98h Idea Pad Recall Idea 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

mrsysex.txt 10/10/2011 8:17 PM

Page 22 of 161

1211

1212

1213

1214

1215

1216

1217

1218

1219

1220

1221

1222

1223

1224

1225

1226

1227

1228

1229

1230

1231

1232

1233

1234

1235

1236

1237

1238

1239

1240

1241

1242

1243

1244

1245

1246

1247

1248

1249

1250

1251

1252

1253

1254

1255

1256

1257

1258

1259

1260

1261

1262

1263

1264

1265

99h Idea Pad Start/Stop 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

9A-9Fh Reserved

A0h Enter/Yes Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

A1h Exit/No Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

A2h Disk/Global Save 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

A3-CFh Reserved

4.3 Receive Display/LED Dump Data Format

The following is the Receive Display/LED Dump data format for the MR-Rack:

Offset Parameter Name Range/Values

00-13h LCD Display - Line #1 ASCII Text String

14h Carriage Return ASCII Character 0Dh

15h Line Feed ASCII Character 0Ah

16-29h LCD Display - Line #2 ASCII Text String

2Ah NULL ASCII Character 00h

2Bh Performance Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

2Ch System Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

2Dh Effects Bypass LED Status 00h = OFF

01h = ON

02h = Flashing

2Eh Effects Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

2Fh Sound Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

30h Parameter Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

31h Mute Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

32h Reserved

The following is the Receive Display/LED Dump data format for the MR-61/76:

Offset Parameter Name Range/Values

mrsysex.txt 10/10/2011 8:17 PM

Page 23 of 161

1266

1267

1268

1269

1270

1271

1272

1273

1274

1275

1276

1277

1278

1279

1280

1281

1282

1283

1284

1285

1286

1287

1288

1289

1290

1291

1292

1293

1294

1295

1296

1297

1298

1299

1300

1301

1302

1303

1304

1305

1306

1307

1308

1309

1310

1311

1312

1313

1314

1315

1316

1317

1318

1319

1320

00-13h LCD Display - Line #1 ASCII Text String

14h Carriage Return ASCII Character 0Dh

15h Line Feed ASCII Character 0Ah

16-29h LCD Display - Line #2 ASCII Text String

2Ah NULL ASCII Character 00h

2Bh Sequencer Track 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

2Ch Sequencer Track 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

2Dh Sequencer Track 3 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

2Eh Sequencer Track 4 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

2Fh Sequencer Track 5 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

30h Sequencer Track 6 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

31h Sequencer Track 7 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

32h Sequencer Track 8 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

33h Sequencer Track 9 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

34h Sequencer Rhythm 00h = OFF

Pushbutton (Right) LED Status 01h = ON

02h = Flashing

35h Sequencer Track 11 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

36h Sequencer Track 12 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

37h Sequencer Track 13 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

38h Sequencer Track 14 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

39h Sequencer Track 15 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

3Ah Sequencer Track 16 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

mrsysex.txt 10/10/2011 8:17 PM

Page 24 of 161

1321

1322

1323

1324

1325

1326

1327

1328

1329

1330

1331

1332

1333

1334

1335

1336

1337

1338

1339

1340

1341

1342

1343

1344

1345

1346

1347

1348

1349

1350

1351

1352

1353

1354

1355

1356

1357

1358

1359

1360

1361

1362

1363

1364

1365

1366

1367

1368

1369

1370

1371

1372

1373

1374

1375

3Bh Song Editor Intro 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

3Ch Song Editor Verse 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

3Dh Song Editor Chorus 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

3Eh Song Editor Verse 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

3Fh Song Editor Chorus 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

40h Song Editor Bridge 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

41h Song Editor Solo 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

42h Song Editor Ending 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

43h Song Editor Select Song 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

44h Song Editor Bank 1 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

45h Song Editor Bank 2 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

46h Song Editor Bank 3 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

47h Song Editor Song Playlist 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

48h Song Editor From Region 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

49h Song Editor To Region 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

4Ah Song Editor Loop 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

4Bh Song Editor Record Mode 00h = OFF

Replace LED Status 01h = ON

02h = Flashing

4Ch Song Editor Record Mode 00h = OFF

Add LED Status 01h = ON

02h = Flashing

4Dh Song Editor Record Mode 00h = OFF

mrsysex.txt 10/10/2011 8:17 PM

Page 25 of 161

1376

1377

1378

1379

1380

1381

1382

1383

1384

1385

1386

1387

1388

1389

1390

1391

1392

1393

1394

1395

1396

1397

1398

1399

1400

1401

1402

1403

1404

1405

1406

1407

1408

1409

1410

1411

1412

1413

1414

1415

1416

1417

1418

1419

1420

1421

1422

1423

1424

1425

1426

1427

1428

1429

1430

Step LED Status 01h = ON

02h = Flashing

4Eh Song Editor Record Mode 00h = OFF

Track Mix LED Status 01h = ON

02h = Flashing

4Fh Song Editor Record Mode 00h = OFF

Final Mix LED Status 01h = ON

02h = Flashing

50-52h Reserved

53h Sequencer Play 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

54h Sequencer Record 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

55h Sequencer Rhythm 00h = OFF

Pushbutton (Left) LED Status 01h = ON

02h = Flashing

56-5Ah Reserved

5Bh FX/Mixdown Mute 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5Ch FX/Mixdown Solo 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

5D-62h Reserved

63h Drum Machine Select Rhythm 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

64h Drum Machine Start/Stop 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

65h Drum Machine Fill/Variation 00h = OFF

Pushbutton (Left) LED Status 01h = ON

02h = Flashing

66h Drum Machine Fill/Variation 00h = OFF

Pushbutton (Right) LED Status 01h = ON

02h = Flashing

67-6Ah Reserved

6Bh Sound Finder Select Sound 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Ch Sound Finder Transpose 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Dh Sound Finder Split 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6Eh Sound Finder Layer 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

6F-72h Reserved

73h Idea Pad Recall Idea 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

mrsysex.txt 10/10/2011 8:17 PM

Page 26 of 161

1431

1432

1433

1434

1435

1436

1437

1438

1439

1440

1441

1442

1443

1444

1445

1446

1447

1448

1449

1450

1451

1452

1453

1454

1455

1456

1457

1458

1459

1460

1461

1462

1463

1464

1465

1466

1467

1468

1469

1470

1471

1472

1473

1474

1475

1476

1477

1478

1479

1480

1481

1482

1483

1484

1485

74h Idea Pad Start/Stop 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

75-7Ah Reserved

7Bh Enter/Yes Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

7Ch Exit/No Pushbutton LED Status 00h = OFF

01h = ON

02h = Flashing

7Dh Disk/Global Save 00h = OFF

Pushbutton LED Status 01h = ON

02h = Flashing

7E-AAh Reserved

Table 4.1 - Fine Tune Offset Values

80h = -50 Cents

82h = -49 Cents

84h = -48 Cents

87h = -47 Cents

89h = -46 Cents

8Ch = -45 Cents

8Fh = -44 Cents

91h = -43 Cents

94h = -42 Cents

96h = -41 Cents

99h = -40 Cents

9Bh = -39 Cents

9Eh = -38 Cents

A0h = -37 Cents

A3h = -36 Cents

A6h = -35 Cents

A8h = -34 Cents

ABh = -33 Cents

ADh = -32 Cents

B0h = -31 Cents

B2h = -30 Cents

B5h = -29 Cents

B8h = -28 Cents

BAh = -27 Cents

BDh = -26 Cents

BFh = -25 Cents

C2h = -24 Cents

C4h = -23 Cents

C7h = -22 Cents

C9h = -21 Cents

CCh = -20 Cents

CFh = -19 Cents

D1h = -18 Cents

D4h = -17 Cents

D6h = -16 Cents

D9h = -15 Cents

DBh = -14 Cents

DEh = -13 Cents

mrsysex.txt 10/10/2011 8:17 PM

Page 27 of 161

1486

1487

1488

1489

1490

1491

1492

1493

1494

1495

1496

1497

1498

1499

1500

1501

1502

1503

1504

1505

1506

1507

1508

1509

1510

1511

1512

1513

1514

1515

1516

1517

1518

1519

1520

1521

1522

1523

1524

1525

1526

1527

1528

1529

1530

1531

1532

1533

1534

1535

1536

1537

1538

1539

1540

E0h = -12 Cents

E3h = -11 Cents

E6h = -10 Cents

E8h = -09 Cents

EBh = -08 Cents

EDh = -07 Cents

F0h = -06 Cents

F2h = -05 Cents

F5h = -04 Cents

F8h = -03 Cents

FAh = -02 Cents

FDh = -01 Cents

00h = 00 Cents

03h = +01 Cents

06h = +02 Cents

08h = +03 Cents

0Bh = +04 Cents

0Eh = +05 Cents

10h = +06 Cents

13h = +07 Cents

15h = +08 Cents

18h = +09 Cents

1Ah = +10 Cents

1Dh = +11 Cents

20h = +12 Cents

22h = +13 Cents

25h = +14 Cents

27h = +15 Cents

2Ah = +16 Cents

2Ch = +17 Cents

2Fh = +18 Cents

31h = +19 Cents

34h = +20 Cents

37h = +21 Cents

39h = +22 Cents

3Ch = +23 Cents

3Eh = +24 Cents

41h = +25 Cents

43h = +26 Cents

46h = +27 Cents

48h = +28 Cents

4Bh = +29 Cents

4Eh = +30 Cents

50h = +31 Cents

53h = +32 Cents

55h = +33 Cents

58h = +34 Cents

5Ah = +35 Cents

5Dh = +36 Cents

60h = +37 Cents

62h = +38 Cents

65h = +39 Cents

67h = +40 Cents

6Ah = +41 Cents

6Ch = +42 Cents

mrsysex.txt 10/10/2011 8:17 PM

Page 28 of 161

1541

1542

1543

1544

1545

1546

1547

1548

1549

1550

1551

1552

1553

1554

1555

1556

1557

1558

1559

1560

1561

1562

1563

1564

1565

1566

1567

1568

1569

1570

1571

1572

1573

1574

1575

1576

1577

1578

1579

1580

1581

1582

1583

1584

1585

1586

1587

1588

1589

1590

1591

1592

1593

1594

1595

6Fh = +43 Cents

71h = +44 Cents

74h = +45 Cents

77h = +46 Cents

79h = +47 Cents

7Ch = +48 Cents

7Eh = +49 Cents

Table 4.2 - Audition Modes

00h = Sound Type

01h = A Octaves

02h = A# Octaves

03h = B Octaves

04h = C Octaves

05h = C# Octaves

06h = D Octaves

07h = D# Octaves

08h = E Octaves

09h = F Octaves

0Ah = F# Octaves

0Bh = G Octaves

0Ch = G# Octaves

0Dh = A maj Chord

0Eh = A# maj Chord

0Fh = B maj Chord

10h = C maj Chord

11h = C# maj Chord

12h = D maj Chord

13h = D# maj Chord

14h = E maj Chord

15h = F maj Chord

16h = F# maj Chord

17h = G maj Chord

18h = G# maj Chord

19h = A maj Arpeg

1Ah = A# maj Arpeg

1Bh = B maj Arpeg

1Ch = C maj Arpeg

1Dh = C# maj Arpeg

1Eh = D maj Arpeg

1Fh = D# maj Arpeg

20h = E maj Arpeg

21h = F maj Arpeg

22h = F# maj Arpeg

23h = G maj Arpeg

24h = G# maj Arpeg

25h = All OFF Only

Table 4.3 - System Controller Sources

00h = Bank Select

01h = Mod Wheel

02h = Breath

03h = MIDI Controller #3

mrsysex.txt 10/10/2011 8:17 PM

Page 29 of 161

1596

1597

1598

1599

1600

1601

1602

1603

1604

1605

1606

1607

1608

1609

1610

1611

1612

1613

1614

1615

1616

1617

1618

1619

1620

1621

1622

1623

1624

1625

1626

1627

1628

1629

1630

1631

1632

1633

1634

1635

1636

1637

1638

1639

1640

1641

1642

1643

1644

1645

1646

1647

1648

1649

1650

04h = Foot Controller

05h = Glide Time

06h = Data Entry

07h = Volume

08h = Balance

09h = MIDI Controller #9

0Ah = Pan

0Bh = Expression

0Ch = FX Control 1

0Dh = FX Control 2

0Eh = MIDI Controller #14

0Fh = MIDI Controller #15

10h = General Purpose 1

11h = General Purpose 2

12h = General Purpose 3

13h = General Purpose 4

14h = MIDI Controller #20

15h = MIDI Controller #21

16h = MIDI Controller #22

17h = MIDI Controller #23

18h = MIDI Controller #24

19h = MIDI Controller #25

1Ah = MIDI Controller #26

1Bh = MIDI Controller #27

1Ch = MIDI Controller #28

1Dh = MIDI Controller #29

1Eh = MIDI Controller #30

1Fh = MIDI Controller #31

20h = Bank Select

21h = Mod Wheel

22h = Breath

23h = MIDI Controller #35

24h = Foot Controller

25h = Glide Time

26h = Data Entry

27h = Volume

28h = Balance

29h = MIDI Controller #41

2Ah = Pan

2Bh = Expression

2Ch = FX Control 1

2Dh = FX Control 2

2Eh = MIDI Controller #46

2Fh = MIDI Controller #47

30h = General Purpose 1

31h = General Purpose 2

32h = General Purpose 3

33h = General Purpose 4

34h = MIDI Controller #52

35h = MIDI Controller #53

36h = MIDI Controller #54

37h = MIDI Controller #55

38h = MIDI Controller #56

39h = MIDI Controller #57

3Ah = MIDI Controller #58

mrsysex.txt 10/10/2011 8:17 PM

Page 30 of 161

1651

1652

1653

1654

1655

1656

1657

1658

1659

1660

1661

1662

1663

1664

1665

1666

1667

1668

1669

1670

1671

1672

1673

1674

1675

1676

1677

1678

1679

1680

1681

1682

1683

1684

1685

1686

1687

1688

1689

1690

1691

1692

1693

1694

1695

1696

1697

1698

1699

1700

1701

1702

1703

1704

1705

3Bh = MIDI Controller #59

3Ch = MIDI Controller #60

3Dh = MIDI Controller #61

3Eh = MIDI Controller #62

3Fh = MIDI Controller #63

40h = Sustain

41h = Portamento ON/OFF

42h = Sostenuto

43h = Soft Pedal

44h = Legato Foot Switch

45h = Hold 2

46h = Patch Select

47h = Timbre

48h = Release

49h = Attack

4Ah = Brightness

4Bh = Sound Controller 6

4Ch = Sound Controller 7

4Dh = Sound Controller 8

4Eh = Sound Controller 9

4Fh = Sound Controller 10

50h = General Purpose 5

51h = General Purpose 6

52h = General Purpose 7

53h = General Purpose 8

54h = Portamento

55h = MIDI Controller #85

56h = MIDI Controller #86

57h = MIDI Controller #87

58h = MIDI Controller #88

59h = MIDI Controller #89

5Ah = MIDI Controller #90

5Bh = FX Depth 1

5Ch = FX Depth 2

5Dh = FX Depth 3

5Eh = FX Depth 4

5Fh = FX Depth 5

60h = Data Increment

61h = Data Decrement

62h = Non-Reg Parameter LSB

63h = Non-Reg Parameter MSB

64h = Reg Parameter LSB

65h = Reg Parameter MSB

66h = MIDI Controller #102

67h = MIDI Controller #103

68h = MIDI Controller #104

69h = MIDI Controller #105

6Ah = MIDI Controller #106

6Bh = MIDI Controller #107

6Ch = MIDI Controller #108

6Dh = MIDI Controller #109

6Eh = MIDI Controller #110

6Fh = MIDI Controller #111

70h = MIDI Controller #112

71h = MIDI Controller #113

mrsysex.txt 10/10/2011 8:17 PM

Page 31 of 161

1706

1707

1708

1709

1710

1711

1712

1713

1714

1715

1716

1717

1718

1719

1720

1721

1722

1723

1724

1725

1726

1727

1728

1729

1730

1731

1732

1733

1734

1735

1736

1737

1738

1739

1740

1741

1742

1743

1744

1745

1746

1747

1748

1749

1750

1751

1752

1753

1754

1755

1756

1757

1758

1759

1760

72h = MIDI Controller #114

73h = MIDI Controller #115

74h = MIDI Controller #116

75h = MIDI Controller #117

76h = MIDI Controller #118

77h = MIDI Controller #119

Table 4.4 - Foot Switch Modes

00h = Unused

01h = Sustain

02h = Sostenuto

03h = SysCTRL1

04h = SysCTRL2

05h = SysCTRL3

06h = SysCTRL4

07h = Up Button

08h = Down Button

09h = Split

0Ah = Layer

0Bh = Transpose

0Ch = Recall Idea

0Dh = IP Start

0Eh = DM Fill Var1

0Fh = DM Fill Var2

10h = DM Fill Var3

11h = DM Fill Var4

12h = DM Fill Var5

13h = DM Fill Var6

14h = DM Fill Var7

15h = DM Fill Var8

16h = Fill/Var

17h = DM Start

18h = Play/Stop

19h = PlayTop/Stop

1Ah = RecPlay/Stop

1Bh = Record

1Ch = Stop

1Dh = Rewind

1Eh = FastForward

1Fh = Mute

20h = Solo

21h = Region From

22h = Region To

23h = Step Advance

5.0 Sound Program Parameters Structure

Offset Parameter Name Range/Values

00-03h Sound Program Parameters Size Unsigned Long Word

04-07h Sound Program Parameters Tag 'PGP1' In ASCII

08-17h Sound Program Name ASCII Text String

18h Pitch Table See Table 5.1

19h Pitch Bend Up Range See Table 5.2

mrsysex.txt 10/10/2011 8:17 PM

Page 32 of 161

1761

1762

1763

1764

1765

1766

1767

1768

1769

1770

1771

1772

1773

1774

1775

1776

1777

1778

1779

1780

1781

1782

1783

1784

1785

1786

1787

1788

1789

1790

1791

1792

1793

1794

1795

1796

1797

1798

1799

1800

1801

1802

1803

1804

1805

1806

1807

1808

1809

1810

1811

1812

1813

1814

1815

1Ah Pitch Bend Down Range See Table 5.3

1B-1Ch Reserved

1Dh Program FX Bus 00h = Default

01h = Chorus

02h = Light Reverb

03h = Medium Reverb

04h = Wet Reverb

05h = Dry

1E-1Fh Reserved

20h GM Alias See Table 5.5

21h Program Enables

01h = Held Pitch Bend

Bitwise Definitions 02h = Not Defined

04h = Not Defined

08h = Not Defined

10h = Not Defined

20h = Not Defined

40h = Not Defined

80h = Not Defined

22h Re-Strike Limit 00h = Default

01h = 01 Voice /Layer

02h = 02 Voices/Layer

03h = 03 Voices/Layer

04h = 04 Voices/Layer

05h = 05 Voices/Layer

06h = 06 Voices/Layer

07h = 07 Voices/Layer

08h = 08 Voices/Layer

09h = 09 Voices/Layer

0Ah = 10 Voices/Layer

0Bh = 11 Voices/Layer

0Ch = 12 Voices/Layer

0Dh = 13 Voices/Layer

0Eh = 14 Voices/Layer

0Fh = 15 Voices/Layer

10h = 16 Voices/Layer

23h Sound Finder Catagory See Table 5.4

5.1 Sound Program Insert Effect Structure

Offset Parameter Name Range/Values

00-03h Insert Effect Structure Size Long Word

04-07h Insert Effect Structure Tag 'IFX1' in ASCII

08h Insert Mod Source See Table 8.7

09h Insert Mod Destination Parameter See Appendix 5

0A-0Bh Insert Mod Source Minimum Value Source

Parameter Dependent

0C-0Dh Insert Mod Source Maximum Value Source

Parameter Dependent

0E-0Fh Insert Mod Destination Destination

Parameter Minimum Value

Parameter Dependent

10-11h Insert Mod Destination Destination

Parameter Maximum Value

Parameter Dependent

12h Insert Chorus Mix 0 to 127

13h Insert Reverb Amount 0 to 127

14h Insert Input Mix 0 to 127

15h Insert Effect Parameter Count

Algorithm Dependent,

mrsysex.txt 10/10/2011 8:17 PM

Page 33 of 161

1816

1817

1818

1819

1820

1821

1822

1823

1824

1825

1826

1827

1828

1829

1830

1831

1832

1833

1834

1835

1836

1837

1838

1839

1840

1841

1842

1843

1844

1845

1846

1847

1848

1849

1850

1851

1852

1853

1854

1855

1856

1857

1858

1859

1860

1861

1862

1863

1864

1865

1866

1867

1868

1869

1870

See Appendix 5

16-17h FX1 Algorithm Family ID

Algorithm Dependent, See Table 8.8

18-19h FX1 Algorithm Member ID

Algorithm Dependent, See Table 8.8

1A-29h FX1 Algorithm Name ASCII Text String

2A-69h FX1 Parameters (Insert) See Appendix 5

2A-2Bh FX1 Parameter #00

Algorithm Dependent

2C-2Dh FX1 Parameter #01

Algorithm Dependent

2E-2Fh FX1 Parameter #02

Algorithm Dependent

30-31h FX1 Parameter #03

Algorithm Dependent

32-33h FX1 Parameter #04

Algorithm Dependent

34-35h FX1 Parameter #05

Algorithm Dependent

36-37h FX1 Parameter #06

Algorithm Dependent

38-39h FX1 Parameter #07

Algorithm Dependent

3A-3Bh FX1 Parameter #08

Algorithm Dependent

3C-3Dh FX1 Parameter #09

Algorithm Dependent

3E-3Fh FX1 Parameter #10

Algorithm Dependent

40-41h FX1 Parameter #11

Algorithm Dependent

42-43h FX1 Parameter #12

Algorithm Dependent

44-45h FX1 Parameter #13

Algorithm Dependent

46-47h FX1 Parameter #14

Algorithm Dependent

48-49h FX1 Parameter #15

Algorithm Dependent

4A-4Bh FX1 Parameter #16

Algorithm Dependent

4C-4Dh FX1 Parameter #17

Algorithm Dependent

4E-4Fh FX1 Parameter #18

Algorithm Dependent

50-51h FX1 Parameter #19

Algorithm Dependent

52-53h FX1 Parameter #20

Algorithm Dependent

54-55h FX1 Parameter #21

Algorithm Dependent

56-57h FX1 Parameter #22

Algorithm Dependent

58-59h FX1 Parameter #23

Algorithm Dependent

5A-5Bh FX1 Parameter #24

Algorithm Dependent

5C-5Dh FX1 Parameter #25

Algorithm Dependent

5E-5Fh FX1 Parameter #26

Algorithm Dependent

60-61h FX1 Parameter #27

Algorithm Dependent

62-63h FX1 Parameter #28

Algorithm Dependent

64-65h FX1 Parameter #29

Algorithm Dependent

66-67h FX1 Parameter #30

Algorithm Dependent

68-69h FX1 Parameter #31

Algorithm Dependent

Table 5.1 - Pitch Table

00h = EqualTemper

01h = Pythagrn-C

02h = Just Int-C

03h = Meantone-C

04h = Wrkmeistr-C

05h = Vallotti-C

06h = Grk-Diatonc

07h = Grk-Chromat

08h = Grk-Enharm

09h = Turkish-A

0Ah = Arabic-1

0Bh = Arabic-2

0Ch = Arabic-3

0Dh = Arabic-4

mrsysex.txt 10/10/2011 8:17 PM

Page 34 of 161

1871

1872

1873

1874

1875

1876

1877

1878

1879

1880

1881

1882

1883

1884

1885

1886

1887

1888

1889

1890

1891

1892

1893

1894

1895

1896

1897

1898

1899

1900

1901

1902

1903

1904

1905

1906

1907

1908

1909

1910

1911

1912

1913

1914

1915

1916

1917

1918

1919

1920

1921

1922

1923

1924

1925

0Eh = Java-Pelog1

0Fh = Java-Pelog2

10h = Java-Pelog3

11h = Java-Slndro

12h = Java-Combi

13h = Indian-Raga

14h = Tibetan

15h = Chinese-1

16h = Chinese-2

17h = Thailand

18h = 24-Tone-Equ

19h = 19-Tone-Equ

1Ah = 31-Tone-Equ

1Bh = 53-Tone-Equ

1Ch = Harmonic

1Dh = CarlosAlpha

1Eh = CarlosBeta

1Fh = CarlosGamma

20h = Partch-43

21h = Reverse

22h = Bagpipe

23h = ShonaMbira1

24h = ShonaMbira2

25h = SuperJust

26h = 88CET

27h = Pierce

28h = WS1

29h = WS2

2Ah = WS3

2Bh = Stretch

2Ch = RandomDetune

2Dh = RAM

Table 5.2 - Pitch Bend Up Range

F4h = 12 Down

F5h = 11 Down

F6h = 10 Down

F7h = 09 Down

F8h = 08 Down

F9h = 07 Down

FAh = 06 Down

FBh = 05 Down

FCh = 04 Down

FDh = 03 Down

FEh = 02 Down

FFh = 01 Down

00h = OFF

01h = 01 Up

02h = 02 Up

03h = 03 Up

04h = 04 Up

05h = 05 Up

06h = 06 Up

07h = 07 Up

mrsysex.txt 10/10/2011 8:17 PM

Page 35 of 161

1926

1927

1928

1929

1930

1931

1932

1933

1934

1935

1936

1937

1938

1939

1940

1941

1942

1943

1944

1945

1946

1947

1948

1949

1950

1951

1952

1953

1954

1955

1956

1957

1958

1959

1960

1961

1962

1963

1964

1965

1966

1967

1968

1969

1970

1971

1972

1973

1974

1975

1976

1977

1978

1979

1980

08h = 08 Up

09h = 09 Up

0Ah = 10 Up

0Bh = 11 Up

0Ch = 12 Up

Table 5.3 - Pitch Bend Down Range

F4h = 12 Up

F5h = 11 Up

F6h = 10 Up

F7h = 09 Up

F8h = 08 Up

F9h = 07 Up

FAh = 06 Up

FBh = 05 Up

FCh = 04 Up

FDh = 03 Up

FEh = 02 Up

FFh = 01 Up

00h = OFF

01h = 01 Down

02h = 02 Down

03h = 03 Down

04h = 04 Down

05h = 05 Down

06h = 06 Down

07h = 07 Down

08h = 08 Down

09h = 09 Down

0Ah = 10 Down

0Bh = 11 Down

0Ch = 12 Down

Table 5.4 - Sound Finder Category

00h = PIANO-A

01h = PNOLYR-A

02h = PIANO-E

03h = PNOLYR-E

04h = ORGAN-A

05h = ORGAN-E

06h = ORGANLYR

07h = KEYS

08h = SYN-LEAD

09h = SYN-PAD

0Ah = SYN-COMP

0Bh = SYN-VINT

0Ch = SYNOTHER

0Dh = GUITAR-A

0Eh = GUITAR-E

0Fh = PLUCKED

10h = STRGSOLO

11h = STRGSECT

12h = BRASSOLO

mrsysex.txt 10/10/2011 8:17 PM

Page 36 of 161

1981

1982

1983

1984

1985

1986

1987

1988

1989

1990

1991

1992

1993

1994

1995

1996

1997

1998

1999

2000

2001

2002

2003

2004

2005

2006

2007

2008

2009

2010

2011

2012

2013

2014

2015

2016

2017

2018

2019

2020

2021

2022

2023

2024

2025

2026

2027

2028

2029

2030

2031

2032

2033

2034

2035

13h = SAX-SOLO

14h = BRASSECT

15h = WINDREED

16h = ORCHSTRA

17h = VOCALS

18h = BASS

19h = BASS-SYN

1Ah = DRUM-KIT

1Bh = DRMKITGM

1Ch = PERC-KIT

1Dh = PERCSOLO

1Eh = MALLET

1Fh = BELL

20h = HITS

21h = LOOPGRUV

22h = SOUND-FX

23h = LAYERS

24h = SPLITS

25h = *UTILITY

26h = *CUSTOM

Table 5.5 - GM Alias

00h = Grand Piano

01h = Bright Piano

02h = Electric Grand

03h = Honky Tonk Piano

04h = Electric Piano 1

05h = Electric Piano 2

06h = Harpsichord

07h = Clavinet

08h = Celesta

09h = Glockenspiel

0Ah = Music Box

0Bh = Vibraphone

0Ch = Marimba

0Dh = Xylophone

0Eh = Tubular Bell

0Fh = Dulcimer

10h = Drawbar Organ

11h = Perc Organ

12h = Rock Organ

13h = Church Organ

14h = Reed Organ

15h = Accordian

16h = Harmonica

17h = Bandoneon

18h = Nylon Guitar

19h = Steel Guitar

1Ah = Jazz Guitar

1Bh = Clean Guitar

1Ch = Muted Guitar

1Dh = Overdriven Guitar

1Eh = Distorted Guitar

1Fh = Guitar Harmonics

mrsysex.txt 10/10/2011 8:17 PM

Page 37 of 161

2036

2037

2038

2039

2040

2041

2042

2043

2044

2045

2046

2047

2048

2049

2050

2051

2052

2053

2054

2055

2056

2057

2058

2059

2060

2061

2062

2063

2064

2065

2066

2067

2068

2069

2070

2071

2072

2073

2074

2075

2076

2077

2078

2079

2080

2081

2082

2083

2084

2085

2086

2087

2088

2089

2090

20h = Acoustic Bass

21h = Fingered Bass

22h = Picked Bass

23h = Fretless Bass

24h = Slap Bass 1

25h = Slap Bass 2

26h = Synth Bass 1

27h = Synth Bass 2

28h = Violin

29h = Viola

2Ah = Cello

2Bh = Contra Bass

2Ch = Tremolo Strings

2Dh = Pizzicato

2Eh = Harp

2Fh = Tympani

30h = Strings

31h = Slow Strings

32h = Synth String 1

33h = Synth String 2

34h = Choir Ahhs

35h = Voice Ohhs

36h = Synth Voice

37h = Orchestra Hit

38h = Trumpet

39h = Trombone

3Ah = Tuba

3Bh = Mute Trumpet

3Ch = French Horn

3Dh = Brass

3Eh = Synth Brass 1

3Fh = Synth Brass 2

40h = Soprano Sax

41h = Alto Sax

42h = Tenor Sax

43h = Baritone Sax

44h = Oboe

45h = English Horn

46h = Bassoon

47h = Clarinet

48h = Piccolo

49h = Flute

4Ah = Recorder

4Bh = Pan Flute

4Ch = Bottle Blow

4Dh = Shakuhachi

4Eh = Whistle

4Fh = Ocarina

50h = Square Wave

51h = Saw Wave

52h = Synth Calliope

53h = Chiffer Lead

54h = Charang

55h = Solo Vox

56h = 5th Saw Wave

mrsysex.txt 10/10/2011 8:17 PM

Page 38 of 161

2091

2092

2093

2094

2095

2096

2097

2098

2099

2100

2101

2102

2103

2104

2105

2106

2107

2108

2109

2110

2111

2112

2113

2114

2115

2116

2117

2118

2119

2120

2121

2122

2123

2124

2125

2126

2127

2128

2129

2130

2131

2132

2133

2134

2135

2136

2137

2138

2139

2140

2141

2142

2143

2144

2145

57h = Bass & Lead

58h = New Age Pad

59h = Warm Pad

5Ah = Poly Synth

5Bh = Space Voice

5Ch = Bowed Glass

5Dh = Metal Pad

5Eh = Halo Pad

5Fh = Sweep Pad

60h = Ice Rain

61h = Soundtrack

62h = Crystal

63h = Atmosphere

64h = Brightness

65h = Goblin

66h = Echo Drops

67h = Star Theme

68h = Sitar

69h = Banjo

6Ah = Shamisen

6Bh = Koto

6Ch = Kalimba

6Dh = Badpipes

6Eh = Fiddle

6Fh = Shanai

70h = Tinkle Bell

71h = Agogo

72h = Steel Drum

73h = Wood Block

74h = Taiko

75h = Melodic Tom

76h = Synth Drum

77h = Reverse Cymbal

78h = Guitar Fret Noise

79h = Breath Noise

7Ah = Seashore

7Bh = Birdsong

7Ch = Telephone

7Dh = Helicopter

7Eh = Applause

7Fh = Gunshot

6.0 Layer Parameter Structure

Offset Parameter Name Range/Values

00-03h Layer Parameter Struture Size

000000B4h, Fixed Long Word

04-07h Layer Tag 'LYR1' In ASCII

08-09h Use Layer Number 0 to 15

0Ah Layer Control

00h = Layer Disabled

01h = Layer Enabled

02h = Mute Layer

03h = Solo Layer

0Bh Trigger Control See Table 6.5

0Ch Controller High Threshold 0 to 127

mrsysex.txt 10/10/2011 8:17 PM

Page 39 of 161

2146

2147

2148

2149

2150

2151

2152

2153

2154

2155

2156

2157

2158

2159

2160

2161

2162

2163

2164

2165

2166

2167

2168

2169

2170

2171

2172

2173

2174

2175

2176

2177

2178

2179

2180

2181

2182

2183

2184

2185

2186

2187

2188

2189

2190

2191

2192

2193

2194

2195

2196

2197

2198

2199

2200

0Dh Controller Low Threshold 0 to 127

0Eh Trigger Mode

80h = Key Up (Note-OFF)

90h = Key Down (Note-ON)

0Fh High Keyboard Key Threshold

21 to 108 (Keyboard Keys A0 to C8)

10h Low Keyboard Key Threshold

21 to 108 (Keyboard Keys A0 to C8)

11h High Note-On Velocity 0 to 127

12h Low Note-On Velocity 0 to 127

13-14h Layer Delay

0 to 9999, Unsigned Short Word

15h Volume (dB) -72 to +14

16h Pan -64 to +63

17h Semi Tune -64 to +63

18h Fine Tune -128 to +127

19h Voice Mode 00h = Poly

01h = Mono

1Ah Glide Mode 00h = OFF

01h = ON

1Bh Glide Time 0 to 127

1Ch Key Group 0 (OFF), 1 to 16

1D-1Fh Reserved

20-2Fh Layer Name ASCII Text String

6.1 Pitch Parameters

Offset Parameter Name Range/Values

30h ENV1 Mod Amount -127 to +127

31h LFO Mod Amount 0 to 127

32h Key Track See Table 6.4

33h Pitch Mod Source See Table 6.1

34h Pitch Mod Amount -127 to +127

35h Pitch Mod Range 0 to 64

36h Reserved

6.2 Filter Parameters

Offset Parameter Name Range/Values

37h Filter Mode 00h = 2LP/2HP

01h = 3LP/1HP

02h = 2LP/2LP

03h = 3LP/1LP

38h Filter 1+2 Link 00h = OFF

01h = ON

39h Filter 1 Cutoff 0 to 127

3Ah Reserved

3Bh Filter 1 ENV2 Mod Amount 0 to 127

3Ch Filter 1 Cutoff Mod Source See Table 6.1

3Dh Filter 1 Cutoff Mod Amount -127 to +127

3Eh Filter 1 Cutoff Keyboard Tracking See Table 6.4

3Fh Filter 1 Cutoff Keyboard 0 to 129

Tracking Breakpoint

(Keyboard Keys C-1 to A9)

40-41h Reserved

42h Filter 2 Cutoff 0 to 127

43h Reserved

44h Filter 2 ENV2 Mod Amount 0 to 127

mrsysex.txt 10/10/2011 8:17 PM

Page 40 of 161

2201

2202

2203

2204

2205

2206

2207

2208

2209

2210

2211

2212

2213

2214

2215

2216

2217

2218

2219

2220

2221

2222

2223

2224

2225

2226

2227

2228

2229

2230

2231

2232

2233

2234

2235

2236

2237

2238

2239

2240

2241

2242

2243

2244

2245

2246

2247

2248

2249

2250

2251

2252

2253

2254

2255

45h Filter 2 Cutoff Mod Source See Table 6.1

46h Filter 2 Cutoff Mod Amount -127 to +127

47h Filter 2 Cutoff Keyboard Tracking See Table 6.4

48h Filter 2 Cutoff Keyboard 0 to 129

Tracking Breakpoint

(Keyboard Keys C-1 to A9)

49-4Ah Reserved

6.3 Waveform Parameters

Offset Parameter Name Range/Values

4Bh Reserved

4Ch Waveform Number (MSByte)

See Appendices 1 to 4

4Dh Waveform Number (LSByte)

See Appendices 1 to 4

4Eh Waveform Checksum (LSByte)

See Appendices 1 to 4

4Fh Waveform Checksum (MSByte)

See Appendices 1 to 4

50h Waveform Playback Direction 00h = Forward

01h = Backward

51h Waveform Shift Amount -64 to +63

52h Waveform Shift Mode 00h = OFF

01h = Shift All

02h = Stretch

03h = Pick One

04h = Shift Vel

53h Waveform Start Index 0 to 127

54h Waveform Mod Source See Table 6.1

55h Waveform Mod Amount -127 to +127

56-57h Reserved

6.4 Amplitude Parameters

Offset Parameter Name Range/Values

58h Amplitude Mod Source See Table 6.1

59h Amplitude Mod Amount -127 to +127

5Ah Panning Mod Source See Table 6.1

5Bh Panning Mod Amount -127 to +127

5Ch Rolloff Slope (dB/Octave) 0 to 127

5Dh Rolloff Key Number 0 to 129

(Keyboard Keys C-1 to A9)

5Eh Rolloff Mode 00h = OFF

01h = Below

02h = Above

5F-60h Reserved

61h Noise Rate 0 to 127

62-64h Reserved

65h MIDI Enables 01h = Pitch Bend

Bitwise Definitions 02h = Sustain

04h = Not Defined

08h = Not Defined

10h = Not Defined

20h = Not Defined

40h = Not Defined

80h = Not Defined

66h Reserved

mrsysex.txt 10/10/2011 8:17 PM

Page 41 of 161

2256

2257

2258

2259

2260

2261

2262

2263

2264

2265

2266

2267

2268

2269

2270

2271

2272

2273

2274

2275

2276

2277

2278

2279

2280

2281

2282

2283

2284

2285

2286

2287

2288

2289

2290

2291

2292

2293

2294

2295

2296

2297

2298

2299

2300

2301

2302

2303

2304

2305

2306

2307

2308

2309

2310

67h Noise Sync See Table 6.2

6.5 Envelope 1 Parameters

Offset Parameter Name Range/Values

68-6Bh Envelope Tag 'ENV1' In ASCII

6Ch Release Mod Amount -127 to +127

6Dh Attack Time 0 to 99

6Eh Attack Peak Level 0 to 127

6Fh Decay 1 Time 0 to 99

70h Decay 1 Break Level 0 to 127

71h Decay 2 Time 0 to 99

72h Decay 2 Break Level 0 to 127

73h Decay 3 Time 0 to 99

74h Sustain Level 0 to 127

75h Release Time 0 to 99

76h Level Velocity 0 to 99

77h Attack Velocity 0 to 99

78h Key Scale 0 to 99

79h Envelope Mode 00h = Normal

01h = Finish

02h = Repeat

7Ah Velocity Curve See Table 6.3

7Bh Reserved

6.6 Envelope 2 Parameters

Offset Parameter Name Range/Values

7C-7Fh Envelope Tag 'ENV1' In ASCII

80h Release Mod Amount -127 to +127

81h Attack Time 0 to 99

82h Attack Peak Level 0 to 127

83h Decay 1 Time 0 to 99

84h Decay 1 Break Level 0 to 127

85h Decay 2 Time 0 to 99

86h Decay 2 Break Level 0 to 127

87h Decay 3 Time 0 to 99

88h Sustain Level 0 to 127

89h Release Time 0 to 99

8Ah Level Velocity 0 to 99

8Bh Attack Velocity 0 to 99

8Ch Key Scale 0 to 99

8Dh Envelope Mode 00h = Normal

01h = Finish

02h = Repeat

8Eh Velocity Curve See Table 6.3

8Fh Reserved

6.7 Envelope 3 Parameters

Offset Parameter Name Range/Values

90-93h Envelope Tag 'ENV1' In ASCII

mrsysex.txt 10/10/2011 8:17 PM

Page 42 of 161

2311

2312

2313

2314

2315

2316

2317

2318

2319

2320

2321

2322

2323

2324

2325

2326

2327

2328

2329

2330

2331

2332

2333

2334

2335

2336

2337

2338

2339

2340

2341

2342

2343

2344

2345

2346

2347

2348

2349

2350

2351

2352

2353

2354

2355

2356

2357

2358

2359

2360

2361

2362

2363

2364

2365

94h Release Mod Amount -127 to +127

95h Attack Time 0 to 99

96h Attack Peak Level 0 to 127

97h Decay 1 Time 0 to 99

98h Decay 1 Break Level 0 to 127

99h Decay 2 Time 0 to 99

9Ah Decay 2 Break Level 0 to 127

9Bh Decay 3 Time 0 to 99

9Ch Sustain Level 0 to 127

9Dh Release Time 0 to 99

9Eh Level Velocity 0 to 99

9Fh Attack Velocity 0 to 99

A0h Key Scale 0 to 99

A1h Envelope Mode 00h = Normal

01h = Finish

02h = Repeat

A2h Velocity Curve See Table 6.3

A3h Reserved

6.8 LFO Parameters

Offset Parameter Name Range/Values

A4-A7h LFO Tag 'LFO1' In ASCII

A8h LFO Waveshape 00h = Triangle

01h = Sine + Tri

02h = Sine

03h = Positive Tri

04h = Positive Sine

05h = Sawtooth

06h = Square

A9h LFO Depth 0 to 127

AAh LFO Rate 0 to 99

ABh LFO Delay Time 0 to 99

ACh LFO Phase 0 to 127

ADh LFO Depth Mod Source See Table 6.1

AEh LFO Depth Mod Amount -127 to +127

AFh LFO Rate Mod Source See Table 6.1

B0h LFO Rate Mod Amount -127 to +127

B1h LFO Retrigger 00h = OFF

01h = ON

B2h LFO Timebase See Table 6.2

B3h Reserved

Table 6.1 - Modulation Sources

00h = OFF

01h = Full Amount

02h = LFO

03h = Stepped

04h = Smooth

05h = ENV1

06h = ENV2

07h = ENV3

08h = Velocity

mrsysex.txt 10/10/2011 8:17 PM

Page 43 of 161

2366

2367

2368

2369

2370

2371

2372

2373

2374

2375

2376

2377

2378

2379

2380

2381

2382

2383

2384

2385

2386

2387

2388

2389

2390

2391

2392

2393

2394

2395

2396

2397

2398

2399

2400

2401

2402

2403

2404

2405

2406

2407

2408

2409

2410

2411

2412

2413

2414

2415

2416

2417

2418

2419

2420

09h = Vel+Press

0Ah = MIDIKey

0Bh = Keyboard

0Ch = Pressure

0Dh = Pitch Wheel

0Eh = Mod Wheel

0Fh = Whl+Press

10h = Ft Pedal

11h = Sustain

12h = Sostento

13h = SysCTRL1

14h = SysCTRL2

15h = SysCTRL3

16h = SysCTRL4

Table 6.2 - Time Divisions

00h = Normal

01h = Whole Note

02h = Whole Triplet

03h = Half Note

04h = Half Triplet

05h = Quarter Note

06h = Quarter Triplet

07h = Eighth Note

08h = Eighth Triplet

09h = Sixteenth Note

0Ah = Sixteenth Triplet

0Bh = 32nd Note

Table 6.3 - Response Curves

00h = Quick Rise

01h = Convex 1

02h = Convex 2

03h = Convex 3

04h = Linear

05h = Concave 1

06h = Concave 2

07h = Concave 3

08h = Concave 4

09h = Late Rise

Table 6.4 - Keyboard Tracking

F0h = -2

F1h = -15/8

F2h = -7/4

F3h = -13/8

F4h = -3/2

F5h = -11/8

F6h = -5/4

F7h = -9/8

F8h = -1

F9h = -7/8

mrsysex.txt 10/10/2011 8:17 PM

Page 44 of 161

2421

2422

2423

2424

2425

2426

2427

2428

2429

2430

2431

2432

2433

2434

2435

2436

2437

2438

2439

2440

2441

2442

2443

2444

2445

2446

2447

2448

2449

2450

2451

2452

2453

2454

2455

2456

2457

2458

2459

2460

2461

2462

2463

2464

2465

2466

2467

2468

2469

2470

2471

2472

2473

2474

2475

FAh = -3/4

FBh = -5/8

FCh = -1/2

FDh = -3/8

FEh = -1/4

FFh = -1/8

00h = OFF

01h = +1/8

02h = +1/4

03h = +3/8

04h = +1/2

05h = +5/8

06h = +3/4

07h = +7/8

08h = +1

09h = +9/8

0Ah = +5/4

0Bh = +11/8

0Ch = +3/2

0Dh = +13/8

0Eh = +7/4

0Fh = +15/8

10h = +2

11h = Pitch Table (Valid ONLY For Pitch Key Track Parameter)

Table 6.5 - Trigger Control Sources

00h = OFF (Unused)

01h = Mod Wheel

02h = Breath

03h = MIDI Controller

04h = Foot Controller

05h = Glide Time

06h = Data Entry

07h = Volume

08h = Balance

09h = MIDI Controller

0Ah = Pan

0Bh = Expression

0Ch = FX Control 1

0Dh = FX Control 2

0Eh = MIDI Controller

0Fh = MIDI Controller

10h = General Purpose 1

11h = General Purpose 2

12h = General Purpose 3

13h = General Purpose 4

14h = MIDI Controller

15h = MIDI Controller

16h = MIDI Controller

17h = MIDI Controller

18h = MIDI Controller

19h = MIDI Controller

1Ah = MIDI Controller

1Bh = MIDI Controller

mrsysex.txt 10/10/2011 8:17 PM

Page 45 of 161

2476

2477

2478

2479

2480

2481

2482

2483

2484

2485

2486

2487

2488

2489

2490

2491

2492

2493

2494

2495

2496

2497

2498

2499

2500

2501

2502

2503

2504

2505

2506

2507

2508

2509

2510

2511

2512

2513

2514

2515

2516

2517

2518

2519

2520

2521

2522

2523

2524

2525

2526

2527

2528

2529

2530

1Ch = MIDI Controller

1Dh = MIDI Controller

1Eh = MIDI Controller

1Fh = MIDI Controller

20h = Bank Select

21h = Mod Wheel

22h = Breath

23h = MIDI Controller

24h = Foot Controller

25h = Glide Time

26h = Data Entry

27h = Volume

28h = Balance

29h = MIDI Controller

2Ah = Pan

2Bh = Expression

2Ch = FX Control 1

2Dh = FX Control 2

2Eh = MIDI Controller

2Fh = MIDI Controller

30h = General Purpose 1

31h = General Purpose 2

32h = General Purpose 3

33h = General Purpose 4

34h = MIDI Controller

35h = MIDI Controller

36h = MIDI Controller

37h = MIDI Controller

38h = MIDI Controller

39h = MIDI Controller

3Ah = MIDI Controller

3Bh = MIDI Controller

3Ch = MIDI Controller

3Dh = MIDI Controller

3Eh = MIDI Controller

3Fh = MIDI Controller

40h = Sustain

41h = Portamento ON/OFF

42h = Sostenuto

43h = Soft Pedal

44h = Legato Foot Switch

45h = Hold 2

46h = Patch Select

47h = Timbre

48h = Release

49h = Attack

4Ah = Brightness

4Bh = Sound Controller 6

4Ch = Sound Controller 7

4Dh = Sound Controller 8

4Eh = Sound Controller 9

4Fh = Sound Controller 10

50h = General Purpose 5

51h = General Purpose 6

52h = General Purpose 7

mrsysex.txt 10/10/2011 8:17 PM

Page 46 of 161

2531

2532

2533

2534

2535

2536

2537

2538

2539

2540

2541

2542

2543

2544

2545

2546

2547

2548

2549

2550

2551

2552

2553

2554

2555

2556

2557

2558

2559

2560

2561

2562

2563

2564

2565

2566

2567

2568

2569

2570

2571

2572

2573

2574

2575

2576

2577

2578

2579

2580

2581

2582

2583

2584

2585

53h = General Purpose 8

54h = Portamento

55h = MIDI Controller

56h = MIDI Controller

57h = MIDI Controller

58h = MIDI Controller

59h = MIDI Controller

5Ah = MIDI Controller

5Bh = FX Depth 1

5Ch = FX Depth 2

5Dh = FX Depth 3

5Eh = FX Depth 4

5Fh = FX Depth 5

60h = Data Increment

61h = Data Decrement

62h = Non-Reg Parameter LSB

63h = Non-Reg Parameter MSB

64h = Reg Parameter LSB

65h = Reg Parameter MSB

66h = MIDI Controller

67h = MIDI Controller

68h = MIDI Controller

69h = MIDI Controller

6Ah = MIDI Controller

6Bh = MIDI Controller

6Ch = MIDI Controller

6Dh = MIDI Controller

6Eh = MIDI Controller

6Fh = MIDI Controller

70h = MIDI Controller

71h = MIDI Controller

72h = MIDI Controller

73h = MIDI Controller

74h = MIDI Controller

75h = MIDI Controller

76h = MIDI Controller

77h = MIDI Controller

78h = System CTRL 1

79h = System CTRL 2

7Ah = System CTRL 3

7Bh = System CTRL 4

7.0 Drum Kit Program Parameters

Offset Parameter Name Range/Values

00-03h Drum Kit Program Size

0000019Ch, Fixed Long Word

04-07h Drum Kit Program Tag 'DRM1' In ASCII

08-17h Drum Kit Program Name ASCII Text String

18h Drum Kit Catagory 26h (*CUSTOM)

19h Drum Kit Base Note 23h (Drum Key B1)

1Ah Number of Drum Keys 40h

1Bh Drum Key Definition Size 06h

1C-21h Drum Key B1 Definition

mrsysex.txt 10/10/2011 8:17 PM

Page 47 of 161

2586

2587

2588

2589

2590

2591

2592

2593

2594

2595

2596

2597

2598

2599

2600

2601

2602

2603

2604

2605

2606

2607

2608

2609

2610

2611

2612

2613

2614

2615

2616

2617

2618

2619

2620

2621

2622

2623

2624

2625

2626

2627

2628

2629

2630

2631

2632

2633

2634

2635

2636

2637

2638

2639

2640

1Ch Drum Key B1 Bank 0 to 127

1Dh Drum Key B1 Program 0 to 127

1Eh Drum Key B1 Pan -64 to +63

1Fh Drum Key B1 Volume -50 to +14

20h Drum Key B1 Tuning Shift -64 to +63

21h Drum Key B1 FX Bus 00h = Insert

01h = Chorus

02h = Light Reverb

03h = Medium Reverb

04h = Wet Reverb

05h = Dry

022-19Bh Drum Keys C2 thru D7

See Drum Key B1 Definition

8.0 Performance Parameters

Offset Parameter Name Range/Values

00-03h Performance Size

00000576h, Long Word

04-07h Performance Tag 'PRF1' In ASCII

08-17h Performance Name ASCII Text String

18h Reserved

19h Insert Control Part 0 (OFF), 1 to 16

1A-2Bh Reserved

8.1 Part 1 Performance Parameters

Offset Parameter Name Range/Values

2Ch Part 1 MIDI Channel 0 to 15

2Dh Part 1 Bank Number 0 to 127

2Eh Part 1 Program Number 0 to 127

2Fh Reserved

30h Part 1 Volume 0 to 127

31h Part 1 Pan

See Table 8.6

32h Part 1 MIDI Enables

01h = Program Change Rcv

Bitwise Definitions

02h = Bank Select Rcv

04h = Data Entry Rcv

08h = Pitch Bend Rcv

10h = Mod Wheel Rcv

20h = Foot Pedal Rcv

40h = Volume Rcv

80h = Pan Rcv

33h Part 1 MIDI Enables

01h = Expression Rcv

Bitwise Defintions 02h = Sustain Rcv

04h = SysCTRL1 Rcv

08h = SysCTRL2 Rcv

10h = SysCTRL3 Rcv

20h = SysCTRL4 Rcv

40h = Volume Invert

80h = Not Defined

34h Part 1 Semitone Shift1 See Table 8.6

35h Part 1 Fine Tuning1 -128 to +127

36h Reserved

37h Part 1 LFO Rate1 See Table 8.6

mrsysex.txt 10/10/2011 8:17 PM

Page 48 of 161

2641

2642

2643

2644

2645

2646

2647

2648

2649

2650

2651

2652

2653

2654

2655

2656

2657

2658

2659

2660

2661

2662

2663

2664

2665

2666

2667

2668

2669

2670

2671

2672

2673

2674

2675

2676

2677

2678

2679

2680

2681

2682

2683

2684

2685

2686

2687

2688

2689

2690

2691

2692

2693

2694

2695

38h Part 1 LFO Depth1 See Table 8.6

39h Part 1 LFO Delay1 See Table 8.6

3Ah Part 1 Octave Shift1 3Eh = -2 Octaves

3Fh = -1 Octaves

40h = 0 Octaves

41h = +1 Octaves

42h = +2 Octaves

3Bh Part 1 Filter Cutoff1 See Table 8.6

3Ch Reserved

3Dh Part 1 Amplitude Envelope See Table 8.6

Attack Time1

3Eh Part 1 Amplitude Envelope See Table 8.6

Decay Time1

3Fh Part 1 Amplitude Envelope See Table 8.6

Release Time1

40h Part 1 Filter Envelope See Table 8.6

Attack Time1

41h Part 1 Filter Envelope See Table 8.6

Decay Time1

42h Part 1 Filter Envelope See Table 8.6

Release Time1

43h Part 1 Amplitude & Filter See Table 8.6

Velocity Sensitivity1

44h Part 1 Pitch Table1 See Table 8.1

45h Part 1 Pitch Bend Up Range1 See Table 8.3

46h Part 1 Pitch Bend Down Range1 See Table 8.4

47h Part 1 Delay Offset1 See Table 8.5

48h Part 1 LFO & Noise Sync1 See Table 8.2

49h Part 1 Keyboard Range Low Note 21 to 108

(Keyboard Keys A0 to C8)

4Ah Part 1 Keyboard Range High Note 21 to 108

(Keyboard Keys A0 to C8)

4Bh Part 1 Velocity Range Low Limit 0 to 127

4Ch Part 1 Velocity Range High Limit 0 to 127

4Dh Part 1 Pressure Mode FFh = OFF

00h = Auto

01h = Channel

02h = Key

4Eh Part 1 Glide Mode1 00h = Program

01h = OFF

02h = ON

4Fh Part 1 Glide Time1 See Table 8.6

50h Part 1 FX Bus1 00h = Insert

01h = Chorus

02h = Light Reverb

04h = Wet Reverb

05h = Dry

51h Part 1 Expression 0 to 127

52h Part 1 Velocity Mode

0 (Normal), 1 to 127

53h Part 1 Enable 00h = OFF

01h = ON

02h = Mute

03h = Solo

54-55h Reserved

mrsysex.txt 10/10/2011 8:17 PM

Page 49 of 161

2696

2697

2698

2699

2700

2701

2702

2703

2704

2705

2706

2707

2708

2709

2710

2711

2712

2713

2714

2715

2716

2717

2718

2719

2720

2721

2722

2723

2724

2725

2726

2727

2728

2729

2730

2731

2732

2733

2734

2735

2736

2737

2738

2739

2740

2741

2742

2743

2744

2745

2746

2747

2748

2749

2750

(1)

These Performance Parameters should be considered RESERVED when a D

8.2 Part 2 thru 16 Performance Parameters

Offset Parameter Name Range/Values

056-07Fh Part 02 Performance Parameters Refer to Part 1

080-0A9h Part 03 Performance Parameters Refer to Part 1

0AA-0D3h Part 04 Performance Parameters Refer to Part 1

0D4-0FDh Part 05 Performance Parameters Refer to Part 1

0FE-127h Part 06 Performance Parameters Refer to Part 1

128-151h Part 07 Performance Parameters Refer to Part 1

152-17Bh Part 08 Performance Parameters Refer to Part 1

17C-1A5h Part 09 Performance Parameters Refer to Part 1

1A6-1CFh Part 10 Performance Parameters Refer to Part 1

1D0-1F9h Part 11 Performance Parameters Refer to Part 1

1FA-223h Part 12 Performance Parameters Refer to Part 1

224-24Dh Part 13 Performance Parameters Refer to Part 1

24E-277h Part 14 Performance Parameters Refer to Part 1

278-2A1h Part 15 Performance Parameters Refer to Part 1

2A2-2CBh Part 16 Performance Parameters Refer to Part 1

8.3 Performance Effects Parameters

Offset Parameter Name Range/Values

2CC-2CFh UMTE Tag 'EFX1' In ASCII

2D0h Insert Mod Source See Table 8.7

2D1h Insert Mod Destination Parameter See Appendix 5

2D2-2D3h Insert Mod Source Minimum Value Source

Parameter Dependent

2D4-2D5h Insert Mod Source Maximum Value Source

Parameter Dependent

2D6-2D7h Insert Mod Destination

Destination Parameter

Parameter Minimum Value Dependent

2D8-2D9h Insert Mod Destination

Destination Parameter

Parameter Maximum Value Dependent

2DA-2DDh FX0 Offset (Shell)

0000001Eh, Fixed Short Word

2DE-2E1h FX1 Offset (Insert)

00000072h, Fixed Short Word

2E2-2E5h FX2 Offset (Global Chorus)

000000C6h, Fixed Short Word

2E6-2E9h FX3 Offset (Global Reverb)

000000EAh, Fixed Short Word

2EA-2EBh FX0 Algorithm Family ID

001Ah, See Table 8.8

2EC-2EDh FX0 Algorithm Member ID

0000h, See Table 8.8

2EE-2FDh FX0 Name ASCII Text String

2FE-33Dh FX0 Parameters (Shell)

2FE-2FFh Insert Output Assignment 0000h = Main

0001h = Aux

300-301h Chorus Output Assignment 0000h = Main

0001h = Aux

302-303h Reverb Output Assignment 0000h = Main

0001h = Aux

304-305h Dry Bus Output Assignment 0000h = Main

0001h = Aux

306-307h Insert Chorus Mix 0 to 127

308-309h Chorus Input Mix 0 to 127

mrsysex.txt 10/10/2011 8:17 PM

Page 50 of 161

2751

2752

2753

2754

2755

2756

2757

2758

2759

2760

2761

2762

2763

2764

2765

2766

2767

2768

2769

2770

2771

2772

2773

2774

2775

2776

2777

2778

2779

2780

2781

2782

2783

2784

2785

2786

2787

2788

2789

2790

2791

2792

2793

2794

2795

2796

2797

2798

2799

2800

2801

2802

2803

2804

2805

30A-30Bh Insert Reverb Amount 0 to 127

30C-30Dh Chorus Reverb Amount 0 to 127

30E-30Fh Light Reverb Send 0 to 63

310-311h Medium Reverb Send 32 to 95

312-313h Wet Reverb Send 64 to 127

314-315h Reserved FX0 Parameter

316-317h Reserved FX0 Parameter

318-319h Insert Input Mix 0 to 127

31A-31Bh Reserved FX0 Parameter

31C-31Dh Reserved FX0 Parameter

31E-31Fh Reserved FX0 Parameter

320-321h Reserved FX0 Parameter

322-323h Reserved FX0 Parameter

324-325h Reserved FX0 Parameter

326-327h Reserved FX0 Parameter

328-329h Reserved FX0 Parameter

32A-32Bh Reserved FX0 Parameter

32C-32Dh Reserved FX0 Parameter

32E-32Fh Reserved FX0 Parameter

330-331h Reserved FX0 Parameter

332-333h Reverb Return Level 0 to 127

334-335h Reserved FX0 Parameter

336-337h Reserved FX0 Parameter

338-339h Reserved FX0 Parameter

33A-33Bh Reserved FX0 Parameter

33C-33Dh Reserved FX0 Parameter

33E-33Fh FX1 Algorithm Family ID See Table 8.8

340-341h FX1 Algorithm Member ID See Table 8.8

342-351h FX1 Name ASCII Text String

352-391h FX1 Parameters (Insert) See Appendix 5

352-353h FX1 Parameter #00

Algorithm Dependent

354-355h FX1 Parameter #01

Algorithm Dependent

356-357h FX1 Parameter #02

Algorithm Dependent

358-359h FX1 Parameter #03

Algorithm Dependent

35A-35Bh FX1 Parameter #04

Algorithm Dependent

35C-35Dh FX1 Parameter #05

Algorithm Dependent

35E-35Fh FX1 Parameter #06

Algorithm Dependent

360-361h FX1 Parameter #07

Algorithm Dependent

362-363h FX1 Parameter #08

Algorithm Dependent

364-365h FX1 Parameter #09

Algorithm Dependent

366-367h FX1 Parameter #10

Algorithm Dependent

368-369h FX1 Parameter #11

Algorithm Dependent

36A-36Bh FX1 Parameter #12

Algorithm Dependent

36C-36Dh FX1 Parameter #13

Algorithm Dependent

36E-36Fh FX1 Parameter #14

Algorithm Dependent

370-371h FX1 Parameter #15

Algorithm Dependent

372-373h FX1 Parameter #16

Algorithm Dependent

374-375h FX1 Parameter #17

Algorithm Dependent

376-377h FX1 Parameter #18

Algorithm Dependent

378-379h FX1 Parameter #19

Algorithm Dependent

37A-37Bh FX1 Parameter #20

Algorithm Dependent

37C-37Dh FX1 Parameter #21

Algorithm Dependent

37E-37Fh FX1 Parameter #22

Algorithm Dependent

380-381h FX1 Parameter #23

Algorithm Dependent

mrsysex.txt 10/10/2011 8:17 PM

Page 51 of 161

2806

2807

2808

2809

2810

2811

2812

2813

2814

2815

2816

2817

2818

2819

2820

2821

2822

2823

2824

2825

2826

2827

2828

2829

2830

2831

2832

2833

2834

2835

2836

2837

2838

2839

2840

2841

2842

2843

2844

2845

2846

2847

2848

2849

2850

2851

2852

2853

2854

2855

2856

2857

2858

2859

2860

382-383h FX1 Parameter #24

Algorithm Dependent

384-385h FX1 Parameter #25

Algorithm Dependent

386-387h FX1 Parameter #26

Algorithm Dependent

388-389h FX1 Parameter #27

Algorithm Dependent

38A-38Bh FX1 Parameter #28

Algorithm Dependent

38C-38Dh FX1 Parameter #29

Algorithm Dependent

38E-38Fh FX1 Parameter #30

Algorithm Dependent

390-391h FX1 Parameter #31

Algorithm Dependent

392-393h FX2 Algorithm Family ID

0004h, See Table 8.8

394-395h FX2 Algorithm Member ID

0000h, See Table 8.8

396-3A5h FX2 Name ASCII Text String

3A6-3B5h FX2 Parameters (Global Chorus)

3A6-3A7h Chorus LFO Rate 0 to 116

3A8-3A9h Chorus Depth 0 to 250

3AA-3ABh Chorus Center 0 to 500

3AC-3ADh Chorus Spread 0 to 10

3AE-3AFh Chorus Phase 0 to 1

3B0-3B1h Reserved FX2 Parameter

3B2-3B3h Reserved FX2 Parameter

3B4-3B5h Reserved FX2 Parameter

3B6-3B7h FX3 Algorithm Family ID

0001h, See Table 8.8

3B8-3B9h FX3 Algorithm Member ID

0000h, See Table 8.8

3BA-3C9h FX3 Name ASCII Text String

3CA-3D9h FX3 Parameters (Global Reverb)

3CA-3CBh Reverb Decay 0 to 100

3CC-3CDh Reverb HF Damping 0 to 127

3CE-3CFh Reverb HF Bandwidth 0 to 127

3D0-3D1h Reverb Diffusion 1 0 to 100

3D2-3D3h Reverb Diffusion 2 0 to 100

3D4-3D5h Reverb Definition 0 to 100

3D6-3D7h Reserved FX3 Parameter

3D8-3D9h Reserved FX3 Parameter

8.4 Performance PerfEditKit Drum Kit Program Parameters

Offset Parameter Name Range/Values

3DA-3DDh Drum Kit Program Size

0000019Ch, Fixed Long Word

3DE-3E1h Drum Kit Program Tag 'DRM1' In ASCII

3E2-3F1h Drum Kit Program Name ASCII Text String

3F2h Drum Kit Catagory 26h (*CUSTOM)

3F3h Drum Kit Base Note 23h (Drum Key B1)

3F4h Number of Drum Keys 40h

3F5h Drum Key Definition Size 06h

3F6-3FBh Drum Key B1 Definition

3F6h Drum Key B1 Bank 0 to 127

3F7h Drum Key B1 Program 0 to 127

3F8h Drum Key B1 Pan -64 to +63

3F9h Drum Key B1 Volume -50 to +14

3FAh Drum Key B1 Tuning Shift -64 to +63

3FBh Drum Key B1 FX Bus 00h = Insert

mrsysex.txt 10/10/2011 8:17 PM

Page 52 of 161

2861

2862

2863

2864

2865

2866

2867

2868

2869

2870

2871

2872

2873

2874

2875

2876

2877

2878

2879

2880

2881

2882

2883

2884

2885

2886

2887

2888

2889

2890

2891

2892

2893

2894

2895

2896

2897

2898

2899

2900

2901

2902

2903

2904

2905

2906

2907

2908

2909

2910

2911

2912

2913

2914

2915

01h = Chorus

02h = Light Reverb

03h = Medium Reverb

04h = Wet Reverb

05h = Dry

3FC-575h Drum Keys C2 thru D7

See Drum Key B1 Definition

Table 8.1 - Pitch Table

00h = Program

01h = System

02h = EqualTemper

03h = Pythagrn-C

04h = Just Int-C

05h = Meantone-C

06h = Wrkmeistr-C

07h = Vallotti-C

08h = Grk-Diatonc

09h = Grk-Chromat

0Ah = Grk-Enharm

0Bh = Turkish-A

0Ch = Arabic-1

0Dh = Arabic-2

0Eh = Arabic-3

0Fh = Arabic-4

10h = Java-Pelog1

11h = Java-Pelog2

12h = Java-Pelog3

13h = Java-Slndro

14h = Java-Combi

15h = Indian-Raga

16h = Tibetan

17h = Chinese-1

18h = Chinese-2

19h = Thailand

1Ah = 24-Tone-Equ

1Bh = 19-Tone-Equ

1Ch = 31-Tone-Equ

1Dh = 53-Tone-Equ

1Eh = Harmonic

1Fh = CarlosAlpha

20h = CarlosBeta

21h = CarlosGamma

22h = Partch-43

23h = Reverse

24h = Bagpipe

25h = ShonaMbira1

26h = ShonaMbira2

27h = SuperJust

28h = 88CET

29h = Pierce

2Ah = WS1

2Bh = WS2

2Ch = WS3

mrsysex.txt 10/10/2011 8:17 PM

Page 53 of 161

2916

2917

2918

2919

2920

2921

2922

2923

2924

2925

2926

2927

2928

2929

2930

2931

2932

2933

2934

2935

2936

2937

2938

2939

2940

2941

2942

2943

2944

2945

2946

2947

2948

2949

2950

2951

2952

2953

2954

2955

2956

2957

2958

2959

2960

2961

2962

2963

2964

2965

2966

2967

2968

2969

2970

2Dh = Stretch

2Eh = RandomDetune

2Fh = RAM

Table 8.2 - LFO/Noise Sync Sources

00h = Program

01h = Normal

02h = Whole Note

03h = Whole Triplet

04h = Half Note

05h = Half Triplet

06h = Quarter Note

07h = Quarter Triplet

08h = Eighth Note

09h = Eighth Triplet

0Ah = Sixteenth Note

0Bh = Sixteenth Triplet

0Ch = 32nd Note

Table 8.3 - Pitch Bend Up Range

F4h = 12 Down

F5h = 11 Down

F6h = 10 Down

F7h = 09 Down

F8h = 08 Down

F9h = 07 Down

FAh = 06 Down

FBh = 05 Down

FCh = 04 Down

FDh = 03 Down

FEh = 02 Down

FFh = 01 Down

00h = Program

01h = System

02h = OFF

03h = 01 Up

04h = 02 Up

05h = 03 Up

06h = 04 Up

07h = 05 Up

08h = 06 Up

09h = 07 Up

0Ah = 08 Up

0Bh = 09 Up

0Ch = 10 Up

0Dh = 11 Up

0Eh = 12 Up

Table 8.4 - Pitch Bend Down Range

F4h = 12 Up

F5h = 11 Up

F6h = 10 Up

mrsysex.txt 10/10/2011 8:17 PM

Page 54 of 161

2971

2972

2973

2974

2975

2976

2977

2978

2979

2980

2981

2982

2983

2984

2985

2986

2987

2988

2989

2990

2991

2992

2993

2994

2995

2996

2997

2998

2999

3000

3001

3002

3003

3004

3005

3006

3007

3008

3009

3010

3011

3012

3013

3014

3015

3016

3017

3018

3019

3020

3021

3022

3023

3024

3025

F7h = 09 Up

F8h = 08 Up

F9h = 07 Up

FAh = 06 Up

FBh = 05 Up

FCh = 04 Up

FDh = 03 Up

FEh = 02 Up

FFh = 01 Up

00h = Program

01h = System

02h = OFF

03h = 01 Down

04h = 02 Down

05h = 03 Down

06h = 04 Down

07h = 05 Down

08h = 06 Down

09h = 07 Down

0Ah = 08 Down

0Bh = 09 Down

0Ch = 10 Down

0Dh = 11 Down

0Eh = 12 Down

Table 8.5 - Part Delay Offsets

00h = +0ms

01h = +1ms

02h = +2ms

03h = +3ms

04h = +4ms

05h = +5ms

06h = +6ms

07h = +7ms

08h = +8ms

09h = +9ms

0Ah = +10ms

0Bh = +11ms

0Ch = +12ms

0Dh = +13ms

0Eh = +14ms

0Fh = +15ms

10h = +16ms

11h = +17ms

12h = +18ms

13h = +19ms

14h = +20ms

15h = +21ms

16h = +22ms

17h = +23ms

18h = +24ms

19h = +25ms

1Ah = +26ms

1Bh = +27ms

mrsysex.txt 10/10/2011 8:17 PM

Page 55 of 161

3026

3027

3028

3029

3030

3031

3032

3033

3034

3035

3036

3037

3038

3039

3040

3041

3042

3043

3044

3045

3046

3047

3048

3049

3050

3051

3052

3053

3054

3055

3056

3057

3058

3059

3060

3061

3062

3063

3064

3065

3066

3067

3068

3069

3070

3071

3072

3073

3074

3075

3076

3077

3078

3079

3080

1Ch = +28ms

1Dh = +29ms

1Eh = +30ms

1Fh = +31ms

20h = +32ms

21h = +33ms

22h = +34ms

23h = +35ms

24h = +36ms

25h = +37ms

26h = +38ms

27h = +39ms

28h = +40ms

29h = +41ms

2Ah = +42ms

2Bh = +43ms

2Ch = +44ms

2Dh = +45ms

2Eh = +46ms

2Fh = +47ms

30h = +48ms

31h = +49ms

32h = +50ms

33h = +55ms

34h = +60ms

35h = +65ms

36h = +70ms

37h = +75ms

38h = +80ms

39h = +85ms

3Ah = +90ms

3Bh = +95ms

3Ch = +100ms

3Dh = +105ms

3Eh = +110ms

3Fh = +115ms

40h = +120ms

41h = +125ms

42h = +130ms

43h = +135ms

44h = +140ms

45h = +145ms

46h = +150ms

47h = +155ms

48h = +160ms

49h = +165ms

4Ah = +170ms

4Bh = +175ms

4Ch = +180ms

4Dh = +185ms

4Eh = +190ms

4Fh = +195ms

50h = +200ms

51h = +205ms

52h = +210ms

mrsysex.txt 10/10/2011 8:17 PM

Page 56 of 161

3081

3082

3083

3084

3085

3086

3087

3088

3089

3090

3091

3092

3093

3094

3095

3096

3097

3098

3099

3100

3101

3102

3103

3104

3105

3106

3107

3108

3109

3110

3111

3112

3113

3114

3115

3116

3117

3118

3119

3120

3121

3122

3123

3124

3125

3126

3127

3128

3129

3130

3131

3132

3133

3134

3135

53h = +215ms

54h = +220ms

55h = +225ms

56h = +230ms

57h = +235ms

58h = +240ms

59h = +245ms

5Ah = +250ms

5Bh = +255ms

5Ch = +260ms

5Dh = +265ms

5Eh = +270ms

5Fh = +275ms

60h = +280ms

61h = +285ms

62h = +290ms

63h = +295ms

64h = +300ms

65h = +325ms

66h = +350ms

67h = +375ms

68h = +400ms

69h = +425ms

6Ah = +450ms

6Bh = +475ms

6Ch = +500ms

6Dh = +550ms

6Eh = +600ms

6Fh = +650ms

70h = +700ms

71h = +750ms

72h = +800ms

73h = +850ms

74h = +900ms

75h = +1000ms

76h = +1100ms

77h = +1200ms

78h = +1300ms

79h = +1400ms

7Ah = +1500ms

7Bh = +1600ms

7Ch = +1700ms

7Dh = +1800ms

7Eh = +1900ms

7Fh = +2000ms

Table 8.6 - Parameter Offset Values

00h = -64

01h = -63

02h = -62

03h = -61

04h = -60

05h = -59

06h = -58

mrsysex.txt 10/10/2011 8:17 PM

Page 57 of 161

3136

3137

3138

3139

3140

3141

3142

3143

3144

3145

3146

3147

3148

3149

3150

3151

3152

3153

3154

3155

3156

3157

3158

3159

3160

3161

3162

3163

3164

3165

3166

3167

3168

3169

3170

3171

3172

3173

3174

3175

3176

3177

3178

3179

3180

3181

3182

3183

3184

3185

3186

3187

3188

3189

3190

07h = -57

08h = -56

09h = -55

0Ah = -54

0Bh = -53

0Ch = -52

0Dh = -51

0Eh = -50

0Fh = -49

10h = -48

11h = -47

12h = -46

13h = -45

14h = -44

15h = -43

16h = -42

17h = -41

18h = -40

19h = -39

1Ah = -38

1Bh = -37

1Ch = -36

1Dh = -35

1Eh = -34

1Fh = -33

20h = -32

21h = -31

22h = -30

23h = -29

24h = -28

25h = -27

26h = -26

27h = -25

28h = -24

29h = -23

2Ah = -22

2Bh = -21

2Ch = -20

2Dh = -19

2Eh = -18

2Fh = -17

30h = -16

31h = -15

32h = -14

33h = -13

34h = -12

35h = -11

36h = -10

37h = -09

38h = -08

39h = -07

3Ah = -06

3Bh = -05

3Ch = -04

3Dh = -03

mrsysex.txt 10/10/2011 8:17 PM

Page 58 of 161

3191

3192

3193

3194

3195

3196

3197

3198

3199

3200

3201

3202

3203

3204

3205

3206

3207

3208

3209

3210

3211

3212

3213

3214

3215

3216

3217

3218

3219

3220

3221

3222

3223

3224

3225

3226

3227

3228

3229

3230

3231

3232

3233

3234

3235

3236

3237

3238

3239

3240

3241

3242

3243

3244

3245

3Eh = -02

3Fh = -01

40h = 00

41h = +01

42h = +02

43h = +03

44h = +04

45h = +05

46h = +06

47h = +07

48h = +08

49h = +09

4Ah = +10

4Bh = +11

4Ch = +12

4Dh = +13

4Eh = +14

4Fh = +15

50h = +16

51h = +17

52h = +18

53h = +19

54h = +20

55h = +21

56h = +22

57h = +23

58h = +24

59h = +25

5Ah = +26

5Bh = +27

5Ch = +28

5Dh = +29

5Eh = +30

5Fh = +31

60h = +32

61h = +33

62h = +34

63h = +35

64h = +36

65h = +37

66h = +38

67h = +39

68h = +40

69h = +41

6Ah = +42

6Bh = +43

6Ch = +44

6Dh = +45

6Eh = +46

6Fh = +47

70h = +48

71h = +49

72h = +50

73h = +51

74h = +52

mrsysex.txt 10/10/2011 8:17 PM

Page 59 of 161

3246

3247

3248

3249

3250

3251

3252

3253

3254

3255

3256

3257

3258

3259

3260

3261

3262

3263

3264

3265

3266

3267

3268

3269

3270

3271

3272

3273

3274

3275

3276

3277

3278

3279

3280

3281

3282

3283

3284

3285

3286

3287

3288

3289

3290

3291

3292

3293

3294

3295

3296

3297

3298

3299

3300

75h = +53

76h = +54

77h = +55

78h = +56

79h = +57

7Ah = +58

7Bh = +59

7Ch = +60

7Dh = +61

7Eh = +62

7Fh = +63

Table 8.7 - Insert FX Modulation Sources

00h = OFF

01h = Full Mod Amount

02h = Velocity

03h = Vel+Pressure

04h = +Pos MIDI Key #

05h = -Neg MIDI Key #

06h = Pressure

07h = Pitchwheel

08h = Mod Wheel

09h = Whl+Pressure

0Ah = Foot Pedal

0Bh = Sustain

0Ch = Sostenuto

0Dh = SysCTRL1

0Eh = SysCTRL2

0Fh = SysCTRL3

10h = SYSCTRL4

Table 8.8 - FX Algorithm Family/Member Assignments

Algorithm Name Family ID Member ID

Global Reverb 0001h 0000h

Global Chorus 0004h 0000h

Shell Mixer 001Ah 0000h

01 Parametric EQ 0012h 0005h

02 Hall Reverb 0001h 0002h

03 Large Room 0001h 0004h

04 Small Room 0001h 0005h

05 Large Plate 0001h 0006h

06 Small Plate 0001h 0007h

07 NonLinReverb1 0001h 0008h

08 NonLinReverb2 0001h 0009h

09 Gated Reverb 0001h 000Ah

10 Stereo Chorus 0004h 0001h

11 8-VoiceChorus 0004h 0002h

12 REV(Chorus 001Eh 000Ch

13 Rev(Flanger 001Eh 000Dh

14 REV(Phaser 001Eh 000Eh

15 Chorus(REV 001Eh 0004h

16 Flanger(REV 001Eh 0005h

mrsysex.txt 10/10/2011 8:17 PM

Page 60 of 161

3301

3302

3303

3304

3305

3306

3307

3308

3309

3310

3311

3312

3313

3314

3315

3316

3317

3318

3319

3320

3321

3322

3323

3324

3325

3326

3327

3328

3329

3330

3331

3332

3333

3334

3335

3336

3337

3338

3339

3340

3341

3342

3343

3344

3345

3346

3347

3348

3349

3350

3351

3352

3353

3354

3355

17 Phaser(REV 001Eh 0006h

18 EQ(REV 001Eh 0008h

19 Spinner(Rev 001Eh 0007h

20 DDL(Chorus 001Eh 0000h

21 DDL(Flanger 001Eh 0002h

22 DDL(Phaser 001Eh 0003h

23 DDL(EQ 001Eh 0001h

24 Multi-Tap DDL 0003h 0000h

25 Dist(Chorus 001Eh 0009h

26 Dist(Flanger 001Eh 000Ah

27 Dist(Phaser 001Eh 000Bh

28 Dist(AutoWah 000Eh 0000h

29 ResVCF(DDL 0013h 0004h

30 Dist(VCF(DDL 0013h 0001h

31 Pitch Detuner 0016h 0000h

32 Chatter Box 0013h 0002h

33 Formant Morph 0013h 0003h

34 RotarySpeaker 0010h 0000h

35 Tunable Spkr 000Fh 0000h

36 Guitar Amp 0011h 0003h

37 Dist(DDL(Trem 0011h 0001h

38 Comp(Dist(DDL 0011h 0002h

39 EQ(Comp(Gate 000Ah 0002h

40 EQ(Chorus(DDL 0011h 0000h

Appendix 1 - MR Internal Waveform List

Waveform Class = Keyboard

NUMBER CHECKSUM WAVENAME

0000h 0D8Ch GRAND PIANO

0000h 6BE6h GRAND MED HI

0000h 394Ah GRAND MED LO

0000h 2C2Ch GRAND SOFT

0154h 1B8Fh PIANO THUD

0154h 0543h PNO HAMMER UP

0001h 33CAh PNO HARP NOIS

00EDh 197Dh TINE EPNO A

00EDh F931h TINE EPNO B

0002h D332h TINE EPNO C

0002h 69DFh TINE EPNO D

0002h 12ABh TINE EPNO E

0002h 030Eh TINE EPNO F

0003h 313Ch DIGI PIANO

00EEh 097Ah DIGI PNO SOFT

00EEh 37C9h FM EPNO A

0003h 0069h FM EPNO B

0003h 1DDAh FM EPNO C

0003h AED1h FM EPNO D

00EFh 411Bh WURLIE HIVEL

00E9h 2564h WURLIE LOVEL

0004h 85C6h HARPSICHORD

0005h 1BD1h CLAVINET

0005h 2D19h FM CLAV

mrsysex.txt 10/10/2011 8:17 PM

Page 61 of 161

3356

3357

3358

3359

3360

3361

3362

3363

3364

3365

3366

3367

3368

3369

3370

3371

3372

3373

3374

3375

3376

3377

3378

3379

3380

3381

3382

3383

3384

3385

3386

3387

3388

3389

3390

3391

3392

3393

3394

3395

3396

3397

3398

3399

3400

3401

3402

3403

3404

3405

3406

3407

3408

3409

3410

0006h 2160h CELESTE

000Ch 38B2h ORG-775305004

000Ch DC38h ORG-845351402

000Ch 2A58h ORG-875434578

000Ch 01B3h ORG-875645332

000Ch 12E0h ORG-888000000

000Ch 14DFh ORG-888808008

000Ch 1C14h ORG-888856444

000Ch 1AEBh ORG-888880880

000Ch 3508h ORGAN WAVE 1

000Ch 055Fh ORGAN WAVE 2

000Dh 51A1h PERC ORGAN 1

000Dh 1D38h PERC ORGAN 2

000Eh 32B8h ROTARY ORGAN

00F1h 4E71h SYNKEY WAVE

000Fh 03ABh CHURCH ORGAN

00ECh 20A5h PIPE ORGAN

0010h 3843h REED ORGAN

00F1h 0ACCh CLINK

0166h 6C44h ORG KEYCLICK

0164h D740h MOOG LEAD

0046h 095Bh PAD SYNTH

Waveform Class = String Sound

NUMBER CHECKSUM WAVENAME

0013h E05Eh NYLON GUITAR

0013h AFC3h NYLON GTR SOFT

0014h EE14h STEEL GUITAR

0014h 49C1h STEEL GTR SOFT

003Eh 3195h FRET NOISE

0016h 2A12h EL GUITAR 1

0016h 0557h EL GTR 1 SOFT

0016h 857Eh EL GUITAR 2

0018h 009Fh DIST GUITAR

0018h 10B6h DIST GTR LOOP

0019h 8002h FEEDBACK HARM

0019h FBA6h GTR HARMONIC

0015h 5817h JAZZ GUITAR

0017h 504Fh MUTE GUITAR

0017h 6620h MUTE GTR SOFT

0020h 34ECh CELLO

001Fh 3A29h VIOLIN

0024h 0E48h STRING SECTION

0024h 2345h STRING SECT B

0024h 198Ah STRING SECT C

00CFh 4937h PIZZ STRINGS

003Bh 1F12h BANJO

0022h 2239h HARP

00E5h 2B6Dh GOTO

003Ch 17C2h SHAMISEN

003Ah 291Eh SITAR

Waveform Class = Brass+Horns

mrsysex.txt 10/10/2011 8:17 PM

Page 62 of 161

3411

3412

3413

3414

3415

3416

3417

3418

3419

3420

3421

3422

3423

3424

3425

3426

3427

3428

3429

3430

3431

3432

3433

3434

3435

3436

3437

3438

3439

3440

3441

3442

3443

3444

3445

3446

3447

3448

3449

3450

3451

3452

3453

3454

3455

3456

3457

3458

3459

3460

3461

3462

3463

3464

3465

NUMBER CHECKSUM WAVENAME

002Ah C259h TRUMPET

002Ch 100Ch MUTE TRUMPET

00BBh F608h FLUGELHORN

00B6h CC0Eh SOLO FR HORN

002Bh 844Eh TROMBONE

002Dh 1D65h POP BRASS SEC

00BFh 1E04h FR HORN SECT

002Eh 34BAh SYNTH BRASS

Waveform Class = Wind+Reeds

NUMBER CHECKSUM WAVENAME

0030h 59AAh TENOR SAX

0072h A785h ALTO SAX

002Fh 1770h SOPRANO SAX

0137h 3FC0h SAX AIR

0077h 4D8Ah CHIFF

0037h 27E7h CHIFFLUTE

0034h 3DE1h FLUTE

0039h 0AC4h OCARINA

0036h 1646h PAN FLUTE

0031h 287Ch OBOE

00F5h BA1Ch ENGLISH HORN

00F8h EF32h BASSOON

0033h 230Dh CLARINET

0011h 995Bh ACCORDION 1

0011h 3665h ACCORDION 2

0012h E376h HARMONICA

00FEh 2B8Fh CONCH SHELL

0035h 2A0Ah RECORDER

Waveform Class = Vocal Sound

NUMBER CHECKSUM WAVENAME

0107h 41D1h VOCAL AAHS

0106h 60CAh VOCAL OOHS

0106h 95C6h BREATHY OOH

010Eh 0142h SYNTH VOX AAH

0112h 3593h VOCAL AIR

0112h 259Ch DOO ATTACK

0110h B006h ONE

0110h 90D7h TWO

0110h 02E7h THREE

0110h 5360h FOUR

Waveform Class = Bass Sound

NUMBER CHECKSUM WAVENAME

001Ah A632h STANDUP BASS

mrsysex.txt 10/10/2011 8:17 PM

Page 63 of 161

3466

3467

3468

3469

3470

3471

3472

3473

3474

3475

3476

3477

3478

3479

3480

3481

3482

3483

3484

3485

3486

3487

3488

3489

3490

3491

3492

3493

3494

3495

3496

3497

3498

3499

3500

3501

3502

3503

3504

3505

3506

3507

3508

3509

3510

3511

3512

3513

3514

3515

3516

3517

3518

3519

3520

001Ah 6116h STANDUP BS 2

001Ah 38BBh STANDUP BS 3

001Ch 4112h FRETLESS BASS

001Bh 0FD1h FINGER BASS 1

001Bh A030h FINGER BASS 2

001Bh 8867h FINGER BASS 3

006Fh 1BA4h PICK BASS 1

006Fh 503Eh PICK BASS 2

0114h 4643h MUTED BASS

001Dh FC7Bh SLAP BASS 1

001Dh D19Ah SLAP BASS 2

0113h 00E2h BASS POP NOIS

0117h 9B73h BS HARMONICS

0113h 3CA2h EL BASS TAP

0115h ECACh ANALOG BS 1

0115h 6A67h ANALOG BS 2

0115h F96Bh ANALOG BS 3

0070h B6D4h FM BASS 1

0070h 05AFh FM BASS 2

001Ah 4E7Ah GUITARRON

0116h 7020h TUBE BASS

Waveform Class = Drum Sound

NUMBER CHECKSUM WAVENAME

0049h 4D52h ACOUSTC KICK

013Fh B870h BIG KICK

0139h 679Bh BOOM KICK

0049h 4A1Ah BRIGHT KICK

0139h 186Ah DANCE KICK

004Ah CE38h DEEP KICK A

004Ah D020h DEEP KICK B

004Ah D021h DEEP KICK C

00A0h 50DEh ELEC KICK

0139h 29CDh FAT KICK

009Fh 429Eh GATED KICK

00B0h 719Ch JAZZ KICK

013Ch 647Fh LOOP KICK

0139h 1DB6h MUFF KICK

00A0h F7E4h PROCESSD KICK

0049h A1E6h PUNCHY KICK

013Ch A3A1h RAP KICK

0049h 435Bh REAL KICK

009Fh 21B0h RESO KICK

0049h D1E5h ROCK KICK A

0049h D325h ROCK KICK B

00A6h FD53h ROOM KICK 1A

00A6h FF1Bh ROOM KICK 1B

00A6h FF1Ch ROOM KICK 1C

0049h FCE6h ROOM KICK 2A

0049h FEA7h ROOM KICK 2B

0049h FEA8h ROOM KICK 2C

00A2h F8CCh SYNTH KICK 1

0141h 036Bh SYNTH KICK 2

mrsysex.txt 10/10/2011 8:17 PM

Page 64 of 161

3521

3522

3523

3524

3525

3526

3527

3528

3529

3530

3531

3532

3533

3534

3535

3536

3537

3538

3539

3540

3541

3542

3543

3544

3545

3546

3547

3548

3549

3550

3551

3552

3553

3554

3555

3556

3557

3558

3559

3560

3561

3562

3563

3564

3565

3566

3567

3568

3569

3570

3571

3572

3573

3574

3575

004Ah D907h TIGHT KICK

004Ch 1E38h BIG SNARE A

004Ch 1FF7h BIG SNARE B

004Ch 1FF8h BIG SNARE C

006Dh EBD2h COM/GATE SNR

00AEh 5737h CONCERT SNARE

013Eh E22Bh CRACK SNARE

013Ah 2C0Ah DANCE SNARE

004Ch 1415h DARK SNR 1 A

004Ch 156Eh DARK SNR 1 B

004Ch 11F4h DARK SNR 2 A

004Ch 1339h DARK SNR 2 B

004Ch D6ABh DRY SNR 1 A

004Ch D889h DRY SNR 1 B

004Ch D88Ah DRY SNR 1 C

004Ch 2E6Ah DRY SNR 2 A

004Ch 303Ah DRY SNR 2 B

004Ch 303Bh DRY SNR 2 C

004Ch 942Fh DYN SNR 1 A

004Ch 95AFh DYN SNR 1 B

004Ch 6C32h DYN SNR 2 A

004Ch 6DB6h DYN SNR 2 B

004Ch 173Bh DYN SNR 3 A

004Ch 18B4h DYN SNR 3 B

00A1h 15F6h ELEC SNARE

004Ch 6506h FAT SNARE A

004Ch 66DFh FAT SNARE B

006Dh 2477h GATED POP SNR

004Ch 06FFh GM SNARE 1

013Bh 2E8Ch HIPHOP SNARE

004Ch 00F2h LIVE SNR 1 A

004Ch 02C9h LIVE SNR 1 B

004Ch A13Ch LIVE SNR 2 A

004Ch A30Dh LIVE SNR 2 B

004Ch 8474h LIVE SNR 3 A

004Ch 863Eh LIVE SNR 3 B

0078h DCF3h POP SNARE

013Bh 06C6h RAP SNARE

004Ch 28C8h REAL SNARE

004Ch 91B8h RING SNARE A

004Ch 9311h RING SNARE B

004Ch 9312h RING SNARE C

004Ch 9313h RING SNARE D

013Eh 300Fh RIMSHOT

004Ch 04FBh ROCK SNARE

00A4h 2CE7h SYNTH SNARE

00A4h 7E42h TECHNO SNARE

0140h 1F08h SNARE ROLL

004Bh 1BA0h SIDESTICK 1

004Bh 32CBh SIDESTICK 2

004Bh 9A40h SIDESTICK 3A

004Bh 9C13h SIDESTICK 3B

009Ah A264h STICK CLICK

00AAh 2FB6h BRUSH HIT

00ABh 1F1Ah BRUSH SLAP

mrsysex.txt 10/10/2011 8:17 PM

Page 65 of 161

3576

3577

3578

3579

3580

3581

3582

3583

3584

3585

3586

3587

3588

3589

3590

3591

3592

3593

3594

3595

3596

3597

3598

3599

3600

3601

3602

3603

3604

3605

3606

3607

3608

3609

3610

3611

3612

3613

3614

3615

3616

3617

3618

3619

3620

3621

3622

3623

3624

3625

3626

3627

3628

3629

3630

00ACh 3BE3h BRUSH SWISH

00ACh 15E7h BRUSH SWISH2

00ACh 574Fh BRUSH SWISH3

00ACh 5761h BRUSH SWISH4

00AAh 18C5h BRUSH TAP

00B1h 1701h BRUSH TOM

004Eh 0782h DRY TOM

004Eh 9881h DRY TOM HI

004Eh D6B7h LIVE TOM 2 A

004Eh D87Dh LIVE TOM 2 B

004Eh D87Eh LIVE TOM 2 C

004Eh 27F9h PURE TOM A

004Eh 28E2h PURE TOM B

004Eh 0AB1h BIG TOM 1 A

004Eh 28E3h PURE TOM C

004Eh 0C6Fh BIG TOM 1 B

004Eh 0C70h BIG TOM 1 C

004Eh 0C71h BIG TOM 1 D

009Eh 94DFh BIG TOM 2 A

009Eh 96A7h BIG TOM 2 B

009Eh 96A8h BIG TOM 2 C

009Eh 96A9h BIG TOM 2 D

009Eh 68F5h BIG TOM 3 A

009Eh 6AD5h BIG TOM 3 B

009Eh 6AD6h BIG TOM 3 C

009Eh 6AD7h BIG TOM 3 D

009Eh 12BDh ROOM TOM

004Eh 1CD0h LIVE TOM 1 A

004Eh 1E95h LIVE TOM 1 B

004Eh 1E96h LIVE TOM 1 C

009Eh 1F12h ROCK TOM 1 A

009Eh 20EAh ROCK TOM 1 B

009Eh 20EBh ROCK TOM 1 C

009Eh 0348h ROCK TOM 2 A

009Eh 0521h ROCK TOM 2 B

009Eh 0522h ROCK TOM 2 C

006Eh 24FBh SYNTH DRUM

00A3h 9AA2h SYNTH RIM

Waveform Class = Cymbals

NUMBER CHECKSUM WAVENAME

004Fh F13Fh CLOSED HAT 1

004Fh 1C11h CLOSED HAT 2

004Fh ED63h CLOSED HAT 3

004Fh 3D1Ch 15"HAT TIGHT

00A5h F47Eh SYN CLOSEHAT

00A5h 30D4h SYN CL HAT 2

004Fh 087Ch RAP HAT 1

004Fh 04AEh RAP HAT 2

00A5h F683h TECHNO HAT 1

00A6h 5BAFh TECHNO HAT 2

00A5h 9B4Ch TECHNO HAT 4

00A5h 4331h TECHNO HAT 3

mrsysex.txt 10/10/2011 8:17 PM

Page 66 of 161

3631

3632

3633

3634

3635

3636

3637

3638

3639

3640

3641

3642

3643

3644

3645

3646

3647

3648

3649

3650

3651

3652

3653

3654

3655

3656

3657

3658

3659

3660

3661

3662

3663

3664

3665

3666

3667

3668

3669

3670

3671

3672

3673

3674

3675

3676

3677

3678

3679

3680

3681

3682

3683

3684

3685

0051h 0255h OPEN HAT

0051h 6B28h 15"HAT OPEN

0051h CBA5h 15"HAT LOOSE

00A6h 12F4h SYN OPEN HAT

00A6h 74EAh SYN OP HAT 2

0050h 1CA5h PEDAL HAT

0050h 679Ah 15"HAT FOOT

0052h 0C1Ch CRASH CYMBAL

015Bh 30A7h CYM LOOP

0053h E845h RIDE CYMBAL

0053h 5F3Dh THIN RIDE A

0053h 604Ah THIN RIDE B

0055h EE5Ch RIDE BELL

0054h E143h CHINA CRASH

0053h A6BFh SYNTH CYMBAL

Waveform Class = Percussion

NUMBER CHECKSUM WAVENAME

005Eh 2D80h AGOGO

0059h B0ABh BONGO

005Fh 26EBh CABASA

005Fh 79ADh EQ CABASA 1

005Fh 6CA9h EQ CABASA 2

006Bh 26E8h CASTANETS

0063h 13E1h CLAVE

009Bh 0598h CLICK

005Ch 49C3h CONGA HEEL

005Bh F4BEh CONGA HIGH

005Ch 1D9Ah CONGA LOW

005Ah 1AF0h CONGA MUTE

0057h 414Ch COWBELL

0057h 24A9h COWBELL STICK

0065h B2CCh CUICA

011Bh 42A7h FINGER SNAPS

0062h 407Ah GUIRO

011Eh 1AC0h HANDCLAPS

0158h 1069h JAWHARP

0060h 20B3h MARACAS

0060h 6E75h THIN MARACA

006Ah D449h SHAKER

006Ah 507Dh SHEKERE DN

006Ah D546h SHEKERE UP

0096h 1C89h SLEIGHBELL

0158h 41B5h SPOONS

006Ch 3C21h TAIKO

0056h 31D9h TAMBOURINE

0056h 17A6h TAMBO DOWN

0056h 144Fh TAMBO UP

005Dh 227Fh TIMBALI

0127h A67Fh TIMBALI RIM

0066h F4B6h TRIANGLE

0058h 19E5h VIBRASLAP

0061h 28EFh WHISTLE

mrsysex.txt 10/10/2011 8:17 PM

Page 67 of 161

3686

3687

3688

3689

3690

3691

3692

3693

3694

3695

3696

3697

3698

3699

3700

3701

3702

3703

3704

3705

3706

3707

3708

3709

3710

3711

3712

3713

3714

3715

3716

3717

3718

3719

3720

3721

3722

3723

3724

3725

3726

3727

3728

3729

3730

3731

3732

3733

3734

3735

3736

3737

3738

3739

3740

0064h 262Fh WOODBLOCK

004Dh 1EB9h SYN CLAPS

00A7h B6BAh SYN COWBELL

00A8h 0B40h SYN MARACAS

00A9h A849h SYNTH CLAVE

0098h 22A8h SYNTH KISS

012Ah 3488h WIND CHIME

0160h 2065h CACTUS LOOP

0160h 1EECh NUT RATTLE LP

0121h 3D54h RAINSTICK

Waveform Class = Tuned Percussion

NUMBER CHECKSUM WAVENAME

0008h 266Bh VIBRAPHONE

0009h 310Eh MARIMBA

000Ah 045Dh XYLOPHONE

015Eh 14E2h LOG DRUM

0073h 1A1Bh KALIMBA

003Dh 2D3Fh STEEL DRUM

0144h 19B9h DOORBELL

0145h 219Dh GAMELAN BELL

0007h 3493h GLOCKENSPIEL

015Fh 2F53h HANDBELLS

015Ch 0B2Ah SM TUNED GONG

000Bh 267Ah TUBULAR

0023h B913h TYMPANI

0143h 45C3h DANCE HIT

0143h 1773h ORCH HIT

Waveform Class = Sound Effect

NUMBER CHECKSUM WAVENAME

0042h 2E6Fh APPLAUSE

003Fh 4581h BIRD SONG

0075h 3BEDh GUNSHOT

0041h 025Ch HELICOPTER

0040h 1F9Fh TELEPHONE

0068h 85C2h WIND CHIMES

0156h BCEDh SURFACE NOISE

0156h 0C45h TAPE LOOP

Waveform Class = Waveform

NUMBER CHECKSUM WAVENAME

014Eh 6018h TEST SINE 44.

0043h FC25h SAWTOOTH

0045h 52EFh SINE WAVE

0044h CF15h SQUARE WAVE

0134h 06CFh TRIANGLE WAVE

012Dh A2FDh ANALOG WV 1

012Dh 22BBh ANALOG WV 2

mrsysex.txt 10/10/2011 8:17 PM

Page 68 of 161

3741

3742

3743

3744

3745

3746

3747

3748

3749

3750

3751

3752

3753

3754

3755

3756

3757

3758

3759

3760

3761

3762

3763

3764

3765

3766

3767

3768

3769

3770

3771

3772

3773

3774

3775

3776

3777

3778

3779

3780

3781

3782

3783

3784

3785

3786

3787

3788

3789

3790

3791

3792

3793

3794

3795

012Dh 3B13h ANALOG WV 3

012Dh 28EBh ANALOG WV 4

012Dh 2595h ANALOG WV 5

012Dh 3202h ANALOG WV 6

012Dh DC0Fh ANALOG WV 7

012Dh D633h ANALOG WV 8

0131h 2F9Dh DIGITAL WV 1

0131h 1B76h DIGITAL WV 2

0130h EE67h BELL WAVE 1

0130h 1826h BELL WAVE 2

0130h 391Ah BELL WAVE 3

0130h 3048h BELL WAVE 4

0130h DE49h BELL WAVE 5

0130h C3FDh BELL WAVE 6

0130h AB47h BELL WAVE 7

0130h 95D7h BIG BELL WF

0130h 21A2h SYNTH BELL

0135h 6C7Bh VOCAL WF 1

0135h 6134h VOCAL WF 2

0135h 5775h VOCAL WF 3

0135h 65E2h VOCAL WF 4

0135h 68BFh VOCAL WF 5

0135h CD2Fh VOCAL WF 6

0032h BA92h DOUBLE REED

0074h C06Eh REED WF

0074h 3EF0h SINGLE REED

0146h 1E7Fh PIANO BS WF

0146h 1E1Dh PIANO WF

0162h 0D6Eh E-BASS WF 1

0162h CD69h E-BASS WF 2

Waveform Class = Inharmonic

NUMBER CHECKSUM WAVENAME

0047h 1D5Eh NOISE

0076h 2BCAh SPECTRUM

0147h 20C6h AIR LOOP

0148h 32D0h BIG BELL

0048h AA7Eh CRYSTAL

0076h 2056h TEXTURE

Waveform Class = Transwave

NUMBER CHECKSUM WAVENAME

014Ch 27AAh AAH OOH XW

0166h 03C5h ANA BS XWAVE

016Ah 3D81h ANA VOX-X

016Ah 3241h ANALOG PAD X

014Ah 9F6Eh BELL XWAVE 1

014Ah 61C8h BELL XWAVE 2

014Ah 9C2Ch BELL XWAVE 3

014Ah 0BC3h BELL XWAVE 4

016Ah E909h DRAWBAR XW

mrsysex.txt 10/10/2011 8:17 PM

Page 69 of 161

3796

3797

3798

3799

3800

3801

3802

3803

3804

3805

3806

3807

3808

3809

3810

3811

3812

3813

3814

3815

3816

3817

3818

3819

3820

3821

3822

3823

3824

3825

3826

3827

3828

3829

3830

3831

3832

3833

3834

3835

3836

3837

3838

3839

3840

3841

3842

3843

3844

3845

3846

3847

3848

3849

3850

016Ah D55Eh MELLOW SWEEP

014Ah FC92h MULTI BELL

016Ah 31C7h ORGAN XWAVE

014Dh 8F30h OSC SYNC XW 1

014Dh 8B5Bh OSC SYNC XW 2

014Bh 54F7h PHASE SYNC

016Ah D517h PULSE X

0166h 3E56h RAP BS XWAVE

014Bh BFC7h RESONANCE

0166h EADAh REZ BS XWAVE

014Bh F286h REZ SWEEP

014Bh CE32h REZO-X 4

014Bh 74B9h REZO-X 3

014Bh 61A5h REZO-X 2

014Bh D42Dh REZO-X 1

0167h F911h SCRATCH WAVE

016Ah A97Bh SOFT ANALOG

0166h ED2Bh TECHNO BASS

014Bh B382h TINE XWAVE

014Ch 9052h TRANSWAVE AA

014Ch F35Dh TRANSWAVE AH

014Ch 6E0Ah TRANSWAVE EE

014Ch 0B5Fh TRANSWAVE OO

014Bh EA17h TRANSWAVE Z

016Ah F231h TRI SWEEP

0167h E9F9h WAKKA WAKKA

The following is a list of additional internal waveforms found only in the MR-61/76:

Waveform Class = Vocal Sound

NUMBER CHECKSUM WAVENAME

0110h b006h ONE

0110h 90d7h TWO

0110h 02e7h THREE

0110h 5360h FOUR

Waveform Class = Drum Sound

NUMBER CHECKSUM WAVENAME

004ah ce38h DEEP KICK A

004ah d020h DEEP KICK B

004ah d021h DEEP KICK C

0049h d1e5h ROCK KICK A

0049h d325h ROCK KICK B

0049h fce6h ROOM KICK 2A

0049h fea7h ROOM KICK 2B

0049h fea8h ROOM KICK 2C

004ch 1e38h BIG SNARE A

004ch 1ff7h BIG SNARE B

004ch 1ff8h BIG SNARE C

004ch 1415h DARK SNR 1 A

004ch 156eh DARK SNR 1 B

mrsysex.txt 10/10/2011 8:17 PM

Page 70 of 161

3851

3852

3853

3854

3855

3856

3857

3858

3859

3860

3861

3862

3863

3864

3865

3866

3867

3868

3869

3870

3871

3872

3873

3874

3875

3876

3877

3878

3879

3880

3881

3882

3883

3884

3885

3886

3887

3888

3889

3890

3891

3892

3893

3894

3895

3896

3897

3898

3899

3900

3901

3902

3903

3904

3905

004ch 11f4h DARK SNR 2 A

004ch 1339h DARK SNR 2 B

004ch d6abh DRY SNR 1 A

004ch d889h DRY SNR 1 B

004ch d88ah DRY SNR 1 C

004ch 2e6ah DRY SNR 2 A

004ch 303ah DRY SNR 2 B

004ch 303bh DRY SNR 2 C

004ch 942fh DYN SNR 1 A

004ch 95afh DYN SNR 1 B

004ch 6c32h DYN SNR 2 A

004ch 6db6h DYN SNR 2 B

004ch 173bh DYN SNR 3 A

004ch 18b4h DYN SNR 3 B

004ch 6506h FAT SNARE A

004ch 66dfh FAT SNARE B

004ch 00f2h LIVE SNR 1 A

004ch 02c9h LIVE SNR 1 B

004ch a13ch LIVE SNR 2 A

004ch a30dh LIVE SNR 2 B

004ch 8474h LIVE SNR 3 A

004ch 863eh LIVE SNR 3 B

004ch 91b8h RING SNARE A

004ch 9311h RING SNARE B

004ch 9312h RING SNARE C

004ch 9313h RING SNARE D

00a4h 7e42h TECHNO SNARE

004bh 9a40h SIDESTICK 3A

004bh 9c13h SIDESTICK 3B

00ach 15e7h BRUSH SWISH2

00ach 574fh BRUSH SWISH3

00ach 5761h BRUSH SWISH4

004eh 9881h DRY TOM HI

004eh d6b7h LIVE TOM 2 A

004eh d87dh LIVE TOM 2 B

004eh d87eh LIVE TOM 2 C

004eh 27f9h PURE TOM A

004eh 28e2h PURE TOM B

004eh 0ab1h BIG TOM 1 A

004eh 28e3h PURE TOM C

004eh 0c6fh BIG TOM 1 B

004eh 0c70h BIG TOM 1 C

004eh 0c71h BIG TOM 1 D

009eh 94dfh BIG TOM 2 A

009eh 96a7h BIG TOM 2 B

009eh 96a8h BIG TOM 2 C

009eh 96a9h BIG TOM 2 D

009eh 68f5h BIG TOM 3 A

009eh 6ad5h BIG TOM 3 B

009eh 6ad6h BIG TOM 3 C

009eh 6ad7h BIG TOM 3 D

004eh 1cd0h LIVE TOM 1 A

004eh 1e95h LIVE TOM 1 B

004eh 1e96h LIVE TOM 1 C

009eh 1f12h ROCK TOM 1 A

mrsysex.txt 10/10/2011 8:17 PM

Page 71 of 161

3906

3907

3908

3909

3910

3911

3912

3913

3914

3915

3916

3917

3918

3919

3920

3921

3922

3923

3924

3925

3926

3927

3928

3929

3930

3931

3932

3933

3934

3935

3936

3937

3938

3939

3940

3941

3942

3943

3944

3945

3946

3947

3948

3949

3950

3951

3952

3953

3954

3955

3956

3957

3958

3959

3960

009eh 20eah ROCK TOM 1 B

009eh 20ebh ROCK TOM 1 C

009eh 0348h ROCK TOM 2 A

009eh 0521h ROCK TOM 2 B

009eh 0522h ROCK TOM 2 C

Waveform Class = Cymbals

NUMBER CHECKSUM WAVENAME

004fh 3d1ch 15"HAT TIGHT

00a5h 30d4h SYN CL HAT 2

00a5h f683h TECHNO HAT 1

00a6h 5bafh TECHNO HAT 2

00a5h 9b4ch TECHNO HAT 4

00a5h 4331h TECHNO HAT 3

0051h 6b28h 15"HAT OPEN

0051h cba5h 15"HAT LOOSE

00a6h 74eah SYN OP HAT 2

0050h 679ah 15"HAT FOOT

015bh 30a7h CYM LOOP

00a6h fd53h ROOM KICK 1A

0053h 5f3dh THIN RIDE A

00a6h ff1bh ROOM KICK 1B

00a6h ff1ch ROOM KICK 1C

0053h 604ah THIN RIDE B

0053h a6bfh SYNTH CYMBAL

Waveform Class = Percussion

NUMBER CHECKSUM WAVENAME

005fh 79adh EQ CABASA 1

005fh 6ca9h EQ CABASA 2

005ch 49c3h CONGA HEEL

0060h 6e75h THIN MARACA

006ah 507dh SHEKERE DN

006ah d546h SHEKERE UP

0056h 17a6h TAMBO DOWN

0056h 144fh TAMBO UP

0127h a67fh TIMBALI RIM

Waveform Class = Sound Effect

NUMBER CHECKSUM WAVENAME

0156h 0c45h TAPE LOOP

Appendix 2 - EXP1 World Expansion Board Waveform List

Waveform Class = String Sound

NUMBER CHECKSUM WAVENAME

00e7h 3795h BANDOLIN

mrsysex.txt 10/10/2011 8:17 PM

Page 72 of 161

3961

3962

3963

3964

3965

3966

3967

3968

3969

3970

3971

3972

3973

3974

3975

3976

3977

3978

3979

3980

3981

3982

3983

3984

3985

3986

3987

3988

3989

3990

3991

3992

3993

3994

3995

3996

3997

3998

3999

4000

4001

4002

4003

4004

4005

4006

4007

4008

4009

4010

4011

4012

4013

4014

4015

00e7h 37bbh BANDOLIN LP

0176h 417eh BANHU

003bh 0984h BANJO 2

0175h 227bh BERIMBAU LP

0175h fc7ah BERIMBAU WAH

0175h 3e1eh BERIMBAU WF

00e4h 5ad2h BIWA 2

00e4h 5b01h BIWA 2 SOFT

017dh 0402h BOWED PSALTRY

017dh 4337h BOWED PSALTWF

0177h 44d6h CHARANGO

0177h 456fh CHARANGO SFT

0014h 9be9h DOBRO

00e6h b3efh DULCIMER LP

0176h b942h ERHU

003bh dd3fh FRTLS B BANJO

0176h b600h GAOHU

0176h e143h GAYAGUM

0176h 9e1dh GOPECHAN

0176h 6758h GOPECHAN STRM

0176h 2578h GU QIN

0176h 2628h GU QIN SOFT

00e6h b34eh H DULCIMER

0176h c4b7h HAEGUM

0176h f829h HYUNGUM HARD

0176h 841ah HYUNGUM SOFT

0176h b6c1h JINGHU

0171h ed5ch JURDA SAZ

0171h ee0ch JURDA SAZ FST

00e6h 5bafh KANTELE

00e6h 5c56h KANTELE LP

0153h faffh KOTO 2

0153h fb48h KOTO 2 SOFT

0177h bde2h MOUTH BOW

0175h 618dh MVET

0171h ea15h OUD

0171h ceb4h OUD FRT NZ 1

0171h 05fdh OUD FRT NZ 2

0171h 49a3h OUD FRT NZ 3

0171h ea58h OUD SOFT

0176h 2cfbh PIPA

0176h 2da0h PIPA SOFT

017dh 9da7h REBAB

0176h 01c4h RUAN

0176h afb2h SANXION

0176h aff8h SANXION SOFT

0176h 526ah SANXION TREMS

0171h ae81h SAROD

0171h 0ccfh SAZ DRONE

0171h 0d0eh SAZ DRONE LP

0175h df08h SENEGALESE

003ch bc75h SHAMISEN 2

003ch bd19h SHAMISEN 2SFT

003ah f3b4h SITAR 2

003ah f551h SITAR 2 LP

mrsysex.txt 10/10/2011 8:17 PM

Page 73 of 161

4016

4017

4018

4019

4020

4021

4022

4023

4024

4025

4026

4027

4028

4029

4030

4031

4032

4033

4034

4035

4036

4037

4038

4039

4040

4041

4042

4043

4044

4045

4046

4047

4048

4049

4050

4051

4052

4053

4054

4055

4056

4057

4058

4059

4060

4061

4062

4063

4064

4065

4066

4067

4068

4069

4070

003ah f3c2h SITAR 2 SOFT

003ah 2ae5h SITAR 3

003ah 2b56h SITAR 3 LP

003ah a1b7h SITAR CHIKARI

0176h 3d05h TAISHO KOTO

0174h b627h TAMBOURA 1

0174h f59fh TAMBOURA 2

0173h 8f10h UKELELE

0173h 8f50h UKELELE SOFT

0079h 745fh VIHUELA STRM

0176h a41bh YANGKEUM

0176h 2d3ah YUET CHIN

0176h 2dfch YUET CHIN SFT

0176h 13b4h ZHENG LOOP

0176h c796h ZHENG STR LP

0176h c6ddh ZHENG STRUM

0176h 5e2fh ZHONGHU

Waveform Class = Brass+Horns

NUMBER CHECKSUM WAVENAME

0100h ba5dh NABAL

Waveform Class = Wind+Reeds

NUMBER CHECKSUM WAVENAME

0011h 4dbch BANDO KEYCLIK

0011h b93dh BANDONEON FST

0011h b8dah BANDONEON LP

0011h b8c5h BANDONEON MED

0011h b8bbh BANDONEON SLO

0179h 1627h CHI BEND

0179h 5e8eh CHI LOOP

0179h 2960h CHOK

017bh a0fah CONCH SHELL

017bh ddd6h CONCH TRUMP 1

0185h bd39h CRUMHORN

0185h 8b75h DBL FLUTE DRN

0039h a247h DBL OCARINADR

0039h f4d3h DBLE OCARINA

0179h 3c48h DI

0172h 6deah DIDJE RHYTHM1

0172h 23b0h DIDJE RHYTHM2

0172h 57f0h DIDJE RHYTHM3

0179h 5c41h HICHIRIKI

0039h a761h HUN

0185h 2c46h HYANG PIRI

0179h 68b3h KAGURABUE

0185h 83beh KHAEN

017ah ff98h MOXENIO PHRS1

017ah 0cf6h MOXENIO PHRS2

017ah 0d67h MOXENIO PHRS3

017bh 34c3h NAGAK

mrsysex.txt 10/10/2011 8:17 PM

Page 74 of 161

4071

4072

4073

4074

4075

4076

4077

4078

4079

4080

4081

4082

4083

4084

4085

4086

4087

4088

4089

4090

4091

4092

4093

4094

4095

4096

4097

4098

4099

4100

4101

4102

4103

4104

4105

4106

4107

4108

4109

4110

4111

4112

4113

4114

4115

4116

4117

4118

4119

4120

4121

4122

4123

4124

4125

0178h 4dc3h NOSE FLUTE

017ah 624ch PINCUYO PHRS

017ah 8adeh QUENA 1

017ah fedah QUENA 2

0035h bb5dh RECORDER 2

0179h 876ch RYUTEKI

0179h dba2h SAENG HWANG

0038h 901eh SHAK ORNAMNT1

0038h 9085h SHAK ORNAMNT2

0038h 3310h SHAKUHACHI 2

0038h 8134h SHAKUHACHI CH

0185h bd96h SHAWM

0185h dfb1h SHO

0185h 8bcdh SHUAN GUAN

017ah 7714h SIKUS

017ah 8ebbh SIKUS CHIFF

017ah 77c9h SIKUS LP

0179h b8bbh SO

0179h d537h SOGEUM

0185h 4304h SUONA

0179h a6bdh TAEGUM

0185h fbb7h TAEPYUNGSO

0185h fc4eh TAEPYUNGSOFST

0185h 9837h TANG PIRI

0185h 98ceh TANG PIRI FST

0179h f456h TANSO

017ah 5a18h TINAMU FLUTE

0011h f0f8h UILEANN PIPES

Waveform Class = Vocal Sound

NUMBER CHECKSUM WAVENAME

0182h a033h AHA 1

0182h a0ceh AHA 2

0182h 25a1h ARAH MIO

0182h 8b51h GO !!

0182h 3e8ch HA !!

0182h 9978h IJOWA

0111h 42cbh KOREAN VOX 1

0111h 44bch KOREAN VOX 2

0111h 44bdh KOREAN VOX 3

0182h 39edh MONKS

0182h 9c13h NATIVE VOX 1

0182h dd6dh OH 1

0182h d1ffh OH 2

0182h 0588h OH 3

0182h a395h SALSA VOX 1

0182h a409h SALSA VOX 2

0182h a40ah SALSA VOX 3

0182h a40bh SALSA VOX 4

0182h b304h SALSA VOX 5

0182h 907dh SHOUT

0182h 7849h SO

0182h 08e6h WELLE WELLE

mrsysex.txt 10/10/2011 8:17 PM

Page 75 of 161

4126

4127

4128

4129

4130

4131

4132

4133

4134

4135

4136

4137

4138

4139

4140

4141

4142

4143

4144

4145

4146

4147

4148

4149

4150

4151

4152

4153

4154

4155

4156

4157

4158

4159

4160

4161

4162

4163

4164

4165

4166

4167

4168

4169

4170

4171

4172

4173

4174

4175

4176

4177

4178

4179

4180

0111h ec7fh YO !!

Waveform Class = Drum Sound

NUMBER CHECKSUM WAVENAME

016eh 3e67h ADONDO DOWN

016eh ff1dh ADONDO OPEN

016eh 414dh ADONDO UP

016fh 681ah AM INDIAN DRM

016eh 4af0h BATA HIT

016eh 2627h BATA MUTE

016eh 4947h BATA SLAP

016eh a5a7h BATA TAP

016eh 5617h BLEKEDE 1

016eh 625dh BLEKEDE 2

016fh 5206h BODRHAN

016fh 7c45h BOMBO HIT

016fh a463h BOMBO RIMSHOT

016Dh 46ech BUK HIT

016fh 0d24h CAJA

016fh 0b01h CAJON FLAM

016fh f633h CAJON HIT 1

016fh 0ac9h CAJON HIT 2

016fh 94e9h CAJON MUTE 1

016fh 0c75h CAJON MUTE 2

016fh 22cch CAJON SLAP 1

016fh a2a8h CAJON SLAP 3

016Dh 131fh CHALGO

016Dh 05c4h CHANGO HIT 1

016Dh 37aeh CHANGO HIT2

016Dh 78d2h CHANGO RIMSHT

016Dh 6eb5h CHANGO TAPROL

016Dh 1bcch CHINGO

016Dh bf6dh CHWAGO

016eh 9282h CLAY DRUM HT1

016eh a342h CLAY DRUM HT2

016eh 1de5h CLAY DRUM MT

016eh 8306h CLAY DRUM SP1

016eh 113dh CLAY DRUM SP2

016eh bef6h CLAY DRUM TAP

0181h 5381h DJEMBE FLAM

0181h 0e02h DJEMBE HEEL

0181h f325h DJEMBE MUTE

0181h 3a46h DJEMBE OPEN 1

0181h c980h DJEMBE OPEN 2

0181h 7397h DJEMBE SLAP

0181h 40b8h DJEMBE TAP

016eh fd96h DJUN DJUN

017Eh 77f5h DUMBEK F ROLL

017Eh 788fh DUMBEK F SNG

017Eh 3f9fh DUMBEK MUTE

017Eh 6426h DUMBEK OPEN

017Eh 4c53h DUmBEK SLAP

017Eh 1c9ah DUMBEK SWISH1

mrsysex.txt 10/10/2011 8:17 PM

Page 76 of 161

4181

4182

4183

4184

4185

4186

4187

4188

4189

4190

4191

4192

4193

4194

4195

4196

4197

4198

4199

4200

4201

4202

4203

4204

4205

4206

4207

4208

4209

4210

4211

4212

4213

4214

4215

4216

4217

4218

4219

4220

4221

4222

4223

4224

4225

4226

4227

4228

4229

4230

4231

4232

4233

4234

4235

017Eh 0cf0h DUMBEK SWISH2

017Eh 8973h DUMBEK TAP 1

017Eh b463h DUMBEK TAP 2

016fh 4e6dh FRAME DRUM 1

016Dh 9aeeh GU 1

016Dh ffd9h GU 2

016Dh 1524h GU 3

016Dh fd09h GU 3

016Dh cafbh GU 4

016Dh 22d9h HIRADAIKO HIT

016Dh 71ach HIRADAIKO RIM

016Dh fefch KO TZUMI HIT

016Dh 613dh KO TZUMI SLP

016Dh 0446h KYOBANGO

016eh 0b82h MADAHL DRUM

016Dh 3450h NOGO

016eh a869h RIQ HIT

016eh 3c90h RIQ SHAKE

016eh 8da7h RIQ SLAP

016eh 60f1h RIQ TAP

016eh 0325h SAKARA HIT

016eh b62dh SAKARA MUTE

016Dh f3c9h SHIME DAIKO

016fh 11a5h SM INDIAN TOM

016eh 0f29h TAMBORIM HIT

016eh 7ee5h TAMBORIM TAP1

016eh b539h TAMBORIM TAP2

016Dh eb40h TSURI HIT

016Dh 429bh TSURI RIM 1

016Dh 79d8h TSURI RIM 2

017Fh 3f5eh UDU HARD HIT

017Fh cbe5h UDU LO HIT 1

017Fh 6f28h UDU LO HIT 2

017Fh 4139h UDU MIX

017Fh 6723h UDU POP HIT

017Fh f215h UDU SLAP 1

017Fh 39c0h UDU SLAP 2

017Fh e8feh UDU SLAP 3

017Fh 8a3eh UDU SOFT HT 1

017Fh c888h UDU SOFT HT 2

017Fh 324ch UDU SOFT HT 3

017Fh e469h UDU TAP

016Dh 252ah UNGO HIT

016Dh eac3h YUNNGO

Waveform Class = Cymbals

NUMBER CHECKSUM WAVENAME

0159h 22d1h CHA 1

0159h 3b9dh CHA 1 MUTE

0159h c721h CHA 1 MUTE

0159h a456h CHABARA

015ah 1427h CHAU GONG

015ah c107h JING 1

mrsysex.txt 10/10/2011 8:17 PM

Page 77 of 161

4236

4237

4238

4239

4240

4241

4242

4243

4244

4245

4246

4247

4248

4249

4250

4251

4252

4253

4254

4255

4256

4257

4258

4259

4260

4261

4262

4263

4264

4265

4266

4267

4268

4269

4270

4271

4272

4273

4274

4275

4276

4277

4278

4279

4280

4281

4282

4283

4284

4285

4286

4287

4288

4289

4290

0159h 66d5h JING 2

0159h 1381h KOENKARI HT1

0159h 12e3h KOENKARI HT2

015ah 3f04h LUO 1 HARD

015ah 3f7eh LUO 1 LOOP

015ah cf1dh LUO 1 SOFT

015ah 31a0h LUO 4

015ah 1f97h LUO 4 SOFT

0159h 1f2bh PENG ZHONG

015ah 44afh WADORA HT

015ah 1cebh WADORA RIM

015ah e4bdh WOHAN GONG

Waveform Class = Percussion

NUMBER CHECKSUM WAVENAME

0063h 1b86h AFRICAN CLAVE

0160h cee4h AFRICAN LOOP

006ah 0e3ah AFUCHE

0160h 0bafh AFUCHE LOOP

005eh 3487h AGOGO 2

0170h 1265h BAN GU ROLL

0157h 1d95h BLACK BLACKS

0061h 02d1h BOBBY WHISTLE

0157h 1d4ah BONES 1

0059h 6270h BONGO HI FLAM

0059h f526h BONGO HI HIT1

0059h e449h BONGO HI HIT2

0059h 6541h BONGO HI HIT3

0059h 86c8h BONGO HI ROLL

0119h fb7dh BONGO LO SLP

0119h afa8h BONGO LO TP 2

0119h 9e7ch BONGO LOW HIT

0119h 9581h BONGO LOW SGL

0119h f9cch BONGO LOW TP1

0119h 5870h BONGO LOW TP3

0119h f46dh BONGO LOWMUTE

0119h 9550h BONGO LOWROLL

0059h 876ah BONGOHI SINGL

0157h b79eh CAJON SLAP 2

006bh 22f9h CASTANET ROLL

006bh 234bh CASTANETS 2

006bh 97f5h CASTANETS 3

006ah f47ah CHAJCHAS 1

006ah 197dh CHAJCHAS 2

0160h 1877h CHAJCHAS LOOP

0170h 4c6ah CHAUN LING

0170h de1ch CHUK HIT

0157h 34d3h CLICK STICK 1

0157h 3380h CLICK STICK 2

0160h c97bh CLICK STIK LP

0160h 0a49h COCO RATL LP

005ch 49c1h CONGA HEEL

005ch d30eh CONGA HIT

mrsysex.txt 10/10/2011 8:17 PM

Page 78 of 161

4291

4292

4293

4294

4295

4296

4297

4298

4299

4300

4301

4302

4303

4304

4305

4306

4307

4308

4309

4310

4311

4312

4313

4314

4315

4316

4317

4318

4319

4320

4321

4322

4323

4324

4325

4326

4327

4328

4329

4330

4331

4332

4333

4334

4335

4336

4337

4338

4339

4340

4341

4342

4343

4344

4345

005ch 5e97h CONGA SLAP

005ch f932h CONGA TAP

0057h 8517h COWBELL 2 MT

0057h 5458h COWBELL 2 OPN

0057h b352h COWBELL 2 STK

0057h 1feah COWBELL 3

0158h 21d6h CRICKET 1

0158h 2537h CRICKET 2

0158h c0b7h CRICKET 3

0065h 279bh CUICA 2

0065h 6f1ah CUICA 3

0065h e81ah CUICA 4

0157h a7e4h DEWCLAW RATTL

0157h 2d93h DODOMPO

0160h cd71h FESTEJO LP

0161h 2b56h GANKOQUI

0061h 1839h GRIO

0157h d27dh GU 5

0062h 3339h GUIRO MIX

0170h 1154h HYSHIGI

0158h 312dh JAW HARP DOWN

0158h 734bh JAW HARP UP

0158h 99b8h JAW HARP WF 1

0158h 9087h JAW HARP WF 2

0158h 8a86h JAW HRP BOING

0170h 2e05h KASHISHI

0170h 2b5ah KAUI BAN 1

0170h 31a6h KAUI BAN 2

0170h 26cfh KAUI BAN 3

0160h 2b8ch KAYAMBA LOOP

006ah 3b6ch KSENG KSENG

006ah 7066h LG SHEKERE TP

006ah 2bf4h LG SHEKERESHK

0126h 2de7h MOKUGYO

0170h 3788h MOKUSHO 1

0170h 7b63h MOKUSHO 2

0126h 1f22h MUYU

0170h 13cah NAN BANG ROLL

0170h 1451h NAN BANG SGL

0160h df86h NATIVE BELLS

0161h ffbbh NDJUKA STICK

0121h 21b1h NUT CLUSTER

0121h 1cd4h NUT RATTLE

0160h d9a7h NUT SHAKER LP

0170h 23bfh O STRUCK

0160h e157h OKEDO LOOP

006ah 42f1h PENZUNAS

0158h 2bc2h PERC MIX 1

0158h 1c35h PERC MIX 2

0157h d9ech PUILI STICKS

0157h 065dh QUIJADA HIT

0157h 4f91h QUIJADA SCP 1

0157h 6100h QUIJADA SCP 2

0157h eac3h QUIJADA SCP 3

005bh 6035h QUINTO HIT

mrsysex.txt 10/10/2011 8:17 PM

Page 79 of 161

4346

4347

4348

4349

4350

4351

4352

4353

4354

4355

4356

4357

4358

4359

4360

4361

4362

4363

4364

4365

4366

4367

4368

4369

4370

4371

4372

4373

4374

4375

4376

4377

4378

4379

4380

4381

4382

4383

4384

4385

4386

4387

4388

4389

4390

4391

4392

4393

4394

4395

4396

4397

4398

4399

4400

005bh 9c4fh QUINTO SLAP

005bh c159h QUINTO TAP

006ah 28f8h RAINSTICK 2

0157h 2e33h RATTLE

005ch 9f82h SACHA TUM HT1

005bh 48eeh SACHA TUM HT2

005ah 4d97h SACHA TUM MT1

005ah bfb2h SACHA TUM MT2

005ah d44ah SACHA TUM MT3

011eh ce7fh SALSA CLAP

0061h 895ch SAMBA WHISTLE

0121h 1f2fh SANZA RATL LP

0121h 1ef4h SANZA RATTLE

0170h 280ah SASSARU FAST

0170h 2196h SASSARU SLOW

0160h 3b32h SHAKER LOOP

006ah 0a01h SHAKESTICK 1

006ah 23bfh SHAKESTICK 2

0157h 2d6bh SISTRUM

006ah 388bh SM SHEKERE TP

006ah fb1bh SM SHEKERESHK

0158h 13d1h STICKS 1

0158h d492h STICKS 2

0157h b5b1h STOMP STICK

0122h c336h TABLA BEND UP

0122h 563ah TABLA HIT 1

0122h 2ddch TABLA HIT 2

0122h c3c7h TABLA MIX

0122h 41f6h TABLA MUTE 1

0122h 3180h TABLA MUTE 2

0122h dd01h TABLA MUTE 3

0122h 9e1eh TABLA OPEN 1

0122h 6379h TABLA OPEN 2

0122h 8d03h TABLA POP HIT

0124h 121bh TABLA S ROLL

0122h 496dh TABLA SLAP 1

0122h b3a5h TABLA SLAP 2

0122h 3ba9h TABLA SOFTHT1

005dh 4289h TIMBALE RIM 2

005dh 3c7dh TIMBALE RIM 3

0127h 1018h TIMBALE RIM 4

0127h 6739h TIMBALE RIM 5

005dh 6d9ch TIMBALE SHELL

005dh d3f6h TIMBALEHI HIT

0127h b6d9h TIMBALELO HIT

005ch 657dh TUMBA HIT

005ch 03bbh TUMBA MT 1

005ch eaf7h TUMBA MT 2

005ch 4fd9h TUMBA SLAP

0170h 31bah YOTSU 1 SGL

0170h 3003h YOTSUDAKE 1

0170h 162dh YOTSUDAKE 2

Waveform Class = Tuned Percussion

mrsysex.txt 10/10/2011 8:17 PM

Page 80 of 161

4401

4402

4403

4404

4405

4406

4407

4408

4409

4410

4411

4412

4413

4414

4415

4416

4417

4418

4419

4420

4421

4422

4423

4424

4425

4426

4427

4428

4429

4430

4431

4432

4433

4434

4435

4436

4437

4438

4439

4440

4441

4442

4443

4444

4445

4446

4447

4448

4449

4450

4451

4452

4453

4454

4455

NUMBER CHECKSUM WAVENAME

016bh 1709h ANGKLUNG

000ah 6a52h BALAPHONE 1

000ah 3af6h BALAPHONE 2

000ah 982eh BALAPHONE 3

016bh 041eh BIAN QING

016bh c3a8h BIAN ZHONG

016bh 0f99h BUDDHIST BELL

016bh 0842h KABUKI BEL LP

0073h 05eah KALIMBA 2

0073h 061dh KALIMBA 2 SFT

016bh 2398h KENONG

015dh 2ba2h LOG DRUM 2

015dh 1e9eh LOG DRUM 3

015dh 8bc6h LOG DRUM 4

015dh bc99h LOG DRUM 5

016bh 800fh MISSION BELL1

016bh 7dbeh MISSION BELL2

016bh 9355h ORUGORU

016bh 6478h PAN HYANG

0183h 2fc2h PYON GYONG

016bh f5e3h PYON JONG

016bh 8c4dh SG BOWL LP

016bh 8c0ah SINGINGBOWLHT

016bh 4bf4h SINGINGBOWLSG

003dh 4a48h STEEL DR2 SFT

003dh 499fh STEEL DRUM 2

016bh faf4h TUK JONG

016bh e914h UNLA

016bh 44dbh UNLA WF

016bh 095ch XING

Waveform Class = Inharmonic

NUMBER CHECKSUM WAVENAME

0147h f5aeh BREATHING

0184h 1753h BULLROARER 1

0184h 2f92h BULLROARER 2

0147h d1ceh CHOK AIR LP

Appendix 3 - EXP2 Drum Expansion Board Waveform List

Waveform Class = Vocal Sound

NUMBER CHECKSUM WAVENAME

0110h b006h ONE

0110h 90d7h TWO

0110h 02e7h THREE

0110h 5360h FOUR

Waveform Class = Drum Sound

mrsysex.txt 10/10/2011 8:17 PM

Page 81 of 161

4456

4457

4458

4459

4460

4461

4462

4463

4464

4465

4466

4467

4468

4469

4470

4471

4472

4473

4474

4475

4476

4477

4478

4479

4480

4481

4482

4483

4484

4485

4486

4487

4488

4489

4490

4491

4492

4493

4494

4495

4496

4497

4498

4499

4500

4501

4502

4503

4504

4505

4506

4507

4508

4509

4510

NUMBER CHECKSUM WAVENAME

004ah ce38h DEEP KICK A

004ah d020h DEEP KICK B

004ah d021h DEEP KICK C

0049h d1e5h ROCK KICK A

0049h d325h ROCK KICK B

0049h fce6h ROOM KICK 2A

0049h fea7h ROOM KICK 2B

0049h fea8h ROOM KICK 2C

004ch 1e38h BIG SNARE A

004ch 1ff7h BIG SNARE B

004ch 1ff8h BIG SNARE C

004ch 1415h DARK SNR 1 A

004ch 156eh DARK SNR 1 B

004ch 11f4h DARK SNR 2 A

004ch 1339h DARK SNR 2 B

004ch d6abh DRY SNR 1 A

004ch d889h DRY SNR 1 B

004ch d88ah DRY SNR 1 C

004ch 2e6ah DRY SNR 2 A

004ch 303ah DRY SNR 2 B

004ch 303bh DRY SNR 2 C

004ch 942fh DYN SNR 1 A

004ch 95afh DYN SNR 1 B

004ch 6c32h DYN SNR 2 A

004ch 6db6h DYN SNR 2 B

004ch 173bh DYN SNR 3 A

004ch 18b4h DYN SNR 3 B

004ch 6506h FAT SNARE A

004ch 66dfh FAT SNARE B

004ch 00f2h LIVE SNR 1 A

004ch 02c9h LIVE SNR 1 B

004ch a13ch LIVE SNR 2 A

004ch a30dh LIVE SNR 2 B

004ch 8474h LIVE SNR 3 A

004ch 863eh LIVE SNR 3 B

004ch 91b8h RING SNARE A

004ch 9311h RING SNARE B

004ch 9312h RING SNARE C

004ch 9313h RING SNARE D

00a4h 7e42h TECHNO SNARE

004bh 9a40h SIDESTICK 3A

004bh 9c13h SIDESTICK 3B

00ach 15e7h BRUSH SWISH2

00ach 574fh BRUSH SWISH3

00ach 5761h BRUSH SWISH4

004eh 9881h DRY TOM HI

004eh d6b7h LIVE TOM 2 A

004eh d87dh LIVE TOM 2 B

004eh d87eh LIVE TOM 2 C

004eh 27f9h PURE TOM A

004eh 28e2h PURE TOM B

004eh 0ab1h BIG TOM 1 A

004eh 28e3h PURE TOM C

mrsysex.txt 10/10/2011 8:17 PM

Page 82 of 161

4511

4512

4513

4514

4515

4516

4517

4518

4519

4520

4521

4522

4523

4524

4525

4526

4527

4528

4529

4530

4531

4532

4533

4534

4535

4536

4537

4538

4539

4540

4541

4542

4543

4544

4545

4546

4547

4548

4549

4550

4551

4552

4553

4554

4555

4556

4557

4558

4559

4560

4561

4562

4563

4564

4565

004eh 0c6fh BIG TOM 1 B

004eh 0c70h BIG TOM 1 C

004eh 0c71h BIG TOM 1 D

009eh 94dfh BIG TOM 2 A

009eh 96a7h BIG TOM 2 B

009eh 96a8h BIG TOM 2 C

009eh 96a9h BIG TOM 2 D

009eh 68f5h BIG TOM 3 A

009eh 6ad5h BIG TOM 3 B

009eh 6ad6h BIG TOM 3 C

009eh 6ad7h BIG TOM 3 D

004eh 1cd0h LIVE TOM 1 A

004eh 1e95h LIVE TOM 1 B

004eh 1e96h LIVE TOM 1 C

009eh 1f12h ROCK TOM 1 A

009eh 20eah ROCK TOM 1 B

009eh 20ebh ROCK TOM 1 C

009eh 0348h ROCK TOM 2 A

009eh 0521h ROCK TOM 2 B

009eh 0522h ROCK TOM 2 C

Waveform Class = Cymbals

NUMBER CHECKSUM WAVENAME

004fh 3d1ch 15"HAT TIGHT

00a5h 30d4h SYN CL HAT 2

00a5h f683h TECHNO HAT 1

00a6h 5bafh TECHNO HAT 2

00a5h 9b4ch TECHNO HAT 4

00a5h 4331h TECHNO HAT 3

0051h 6b28h 15"HAT OPEN

0051h cba5h 15"HAT LOOSE

00a6h 74eah SYN OP HAT 2

0050h 679ah 15"HAT FOOT

015bh 30a7h CYM LOOP

00a6h fd53h ROOM KICK 1A

0053h 5f3dh THIN RIDE A

00a6h ff1bh ROOM KICK 1B

00a6h ff1ch ROOM KICK 1C

0053h 604ah THIN RIDE B

0053h a6bfh SYNTH CYMBAL

Waveform Class = Percussion

NUMBER CHECKSUM WAVENAME

005fh 79adh EQ CABASA 1

005fh 6ca9h EQ CABASA 2

005ch 49c3h CONGA HEEL

0060h 6e75h THIN MARACA

006ah 507dh SHEKERE DN

006ah d546h SHEKERE UP

0056h 17a6h TAMBO DOWN

0056h 144fh TAMBO UP

mrsysex.txt 10/10/2011 8:17 PM

Page 83 of 161

4566

4567

4568

4569

4570

4571

4572

4573

4574

4575

4576

4577

4578

4579

4580

4581

4582

4583

4584

4585

4586

4587

4588

4589

4590

4591

4592

4593

4594

4595

4596

4597

4598

4599

4600

4601

4602

4603

4604

4605

4606

4607

4608

4609

4610

4611

4612

4613

4614

4615

4616

4617

4618

4619

4620

0127h a67fh TIMBALI RIM

Waveform Class = Sound Effect

NUMBER CHECKSUM WAVENAME

0156h 0c45h TAPE LOOP

Appendix 4 - EXP3 Urban Dance Project Expansion Board Waveform List

Waveform Class = Keyboard

NUMBER CHECKSUM WAVENAME

0000h abech DANCE PIANO

000dh 63dch PERC PLUS ORG

000dh 234ch PERQABEE

000dh 83b6h USED ORGAN

Waveform Class = String Sound

NUMBER CHECKSUM WAVENAME

0025h ef81h ANALOG STRING

0024h 760ah LO FI STRINGS

0025h c851h 16 OSC.STRING

0025h c8f9h SYN STRING LP

0024h 1518h STRING CHORD

0024h cdb4h SECTION FALL

0024h 4fceh SECTION LICK

0024h ce3fh SECTION RUN

0016h 5cd7h FUNK GTR MAP1

0016h 1eeah FUNK GTR MAP2

0016h 5626h FUNK GTR MAP3

0016h 85c9h FUNK GTR MAP4

0016h f9edh FUNKGT SLIDES

Waveform Class = Brass+Horns

NUMBER CHECKSUM WAVENAME

0188h 132eh BRASS HIT 01

0188h f174h BRASS HIT 02

0188h 9a3bh BRASS HIT 03

0188h 4bddh BRASS HIT 04

0188h c416h BRASS HIT 05

0188h 0d07h BRASS HIT 06

0188h fddbh BRASS HIT 07

0188h 02a7h BRASS HIT 08

0188h 4132h BRASS HIT 09

0188h ea4eh BRASS HIT 10

0188h 120dh BRASS HIT 11

0188h c589h BRASS HIT 12

0188h 4e01h DISS HORN HIT

0188h d20bh HORN HIT

mrsysex.txt 10/10/2011 8:17 PM

Page 84 of 161

4621

4622

4623

4624

4625

4626

4627

4628

4629

4630

4631

4632

4633

4634

4635

4636

4637

4638

4639

4640

4641

4642

4643

4644

4645

4646

4647

4648

4649

4650

4651

4652

4653

4654

4655

4656

4657

4658

4659

4660

4661

4662

4663

4664

4665

4666

4667

4668

4669

4670

4671

4672

4673

4674

4675

0188h f604h HORN RIFF

0188h 05f7h TRUMPET HIT 1

0188h 9862h TRUMPET HIT 2

0189h 148ch SQUEALS MAP 1

0189h 7cb7h SQUEALS MAP 2

0189h a53ch SQUEALS MAP 3

0188h 6318h TRUMPET HIT 3

0189h b5cfh TRUMPETSQUEAL

Waveform Class = Wind+Reeds

NUMBER CHECKSUM WAVENAME

00f2h 6f51h FLUTE LOOP

00f2h 43d2h FLUTE MAP 1

00f2h a292h FLUTE MAP 2

Waveform Class = Vocal Sound

NUMBER CHECKSUM WAVENAME

0111h 96ddh VOCAL MAP 01

0111h 3ff7h VOCAL MAP 02

0111h b802h VOCAL MAP 03

0111h d60dh VOCAL MAP 04

0111h c047h VOCAL MAP 05

0111h eeaah VOCAL MAP 06

0111h 1a8bh VOCAL MAP 07

0111h e2dbh VOCAL MAP 08

0111h cd4ah VOCAL MAP 09

0111h 100ah VOCAL MAP 10

0111h ff73h VOCAL MAP 11

0111h c678h VOCAL MAP 12

0111h cb7bh VOCAL MAP 13

0111h f429h VOCAL MAP 14

Waveform Class = Bass Sound

NUMBER CHECKSUM WAVENAME

001ah 1359h AC. BASS 2

001ah 63a0h AC. BASS 3

001ch ec22h JAZZ BASS

001ah 640ah AC BS FRET NZ

0115h 15f2h CLICK BASS

0115h cf85h DEEP BASS

0115h 7965h DOPE BASS 1

0115h b03ah GLO SINE BASS

0115h b8fch DANCE BASS 1

0115h ea81h DANCE BASS 2

0115h b99ah DANCE BASS 3

0070h b3cbh ESQ 1 BASS 2

0115h 672dh GEN X BASS

0115h 1be7h JAMM BASS

0115h 3bb4h JUP BASS SOFT

mrsysex.txt 10/10/2011 8:17 PM

Page 85 of 161

4676

4677

4678

4679

4680

4681

4682

4683

4684

4685

4686

4687

4688

4689

4690

4691

4692

4693

4694

4695

4696

4697

4698

4699

4700

4701

4702

4703

4704

4705

4706

4707

4708

4709

4710

4711

4712

4713

4714

4715

4716

4717

4718

4719

4720

4721

4722

4723

4724

4725

4726

4727

4728

4729

4730

0115h 29d1h JUP BASS MED

0115h 22beh JUP BASS HARD

0115h 51dch MMM BASS

0115h 5865h SAWZ BASS

0115h c628h SPACE BASS 1

0115h 63e5h SPACE BASS 2

0115h 7abbh THICK BASS

Waveform Class = Drum Sound

NUMBER CHECKSUM WAVENAME

0139h aa69h DA POWER KICK

0139h 489eh KICKS MAP 01

0139h b853h KICKS MAP 02

0139h dde6h KICKS MAP 03

0139h 5ebbh KICKS MAP 04

0139h 8bfbh KICKS MAP 05

0139h 787bh KICKS MAP 06

0139h cfe0h KICKS MAP 07

0139h 3f54h KICKS MAP 08

0139h 8533h KICKS MAP 09

0139h b4c6h KICKS MAP 10

0139h 832bh KICKS MAP 11

0139h 00cah KICKS MAP 12

0139h 3c1eh KICKS MAP 13

0139h 6c48h KICKS MAP 14

0139h d7bdh KICKS MAP 16

0139h b1b4h KICKS MAP 17

0139h e611h KICKS MAP 18

0139h 987dh KICKS MAP 19

0139h ebebh KICKS MAP 20

0139h 18deh KICKS MAP 21

0139h 3c8fh KICKS MAP 22

0139h f2ech KICKS MAP 23

0139h c73eh KICKS MAP 24

0139h d2f7h KICKS MAP 25

0139h 57bfh KICKS MAP 26

0139h cf53h KICKS MAP 27

013Ah 8423h SNARE MAP 01

013Ah 491fh SNARE MAP 02

013Ah bc01h SNARE MAP 03

013Ah 6f98h SNARE MAP 04

013Ah 3e5fh SNARE MAP 05

013Ah 32f5h SNARE MAP 06

013Ah 8defh SNARE MAP 07

013Ah 3a9ch SNARE MAP 08

013Ah 2888h SNARE MAP 09

013Ah 243eh SNARE MAP 10

013Ah 2234h SNARE MAP 11

013Ah 1a99h SNARE MAP 12

013Ah 3eb4h SNARE MAP 13

013Ah 09f2h SNARE MAP 14

013Ah 842dh SNARE MAP 15

013Ah 4e84h SNARE MAP 16

mrsysex.txt 10/10/2011 8:17 PM

Page 86 of 161

4731

4732

4733

4734

4735

4736

4737

4738

4739

4740

4741

4742

4743

4744

4745

4746

4747

4748

4749

4750

4751

4752

4753

4754

4755

4756

4757

4758

4759

4760

4761

4762

4763

4764

4765

4766

4767

4768

4769

4770

4771

4772

4773

4774

4775

4776

4777

4778

4779

4780

4781

4782

4783

4784

4785

013Ah 7805h SNARE MAP 17

013Ah 203dh SNARE MAP 18

013Ah 0218h SNARE MAP 19

013Ah d9d6h SNARE MAP 20

013Ah 3ab9h SNARE MAP 21

013Ah 7314h SNARE MAP 22

013Ah 0fbeh SNARE MAP 23

013Ah ccfah SNARE MAP 24

013Ah 03fah SNARE MAP 25

013Ah 3843h SNARE ROLL 2

004Eh 347ah TOMS MAP 1

004Eh ce94h TOMS MAP 2

Waveform Class = Cymbals

NUMBER CHECKSUM WAVENAME

004Fh dba0h CLOZD HAT MP1

004Fh 2e6eh CLOZD HAT MP2

004Fh f9b5h CLOZD HAT MP3

004Fh 6fd2h CLOZD HAT MP4

004Fh c0a1h CLOZD HAT MP5

004Fh 9bf7h CLOZD HAT MP6

004Fh d63ch CLOZD HAT MP7

004Fh f91ch CLOZD HAT MP8

0051h f6afh OPEN HAT MP01

0051h 23adh OPEN HAT MP02

0051h c59bh OPEN HAT MP03

0051h a752h OPEN HAT MP04

0051h a41ah OPEN HAT MP05

0051h 6f9bh OPEN HAT MP06

0051h e033h OPEN HAT MP07

0051h 476fh OPEN HAT MP08

0051h d875h OPEN HAT MP09

0051h ef01h OPEN HAT MP10

0051h 13a9h ELEC.HAT MAP

0053h 666ch DANCE RIDE 1

0053h 6abah DANCE RIDE 2

0053h bccbh DANCE RIDE 3

0053h d6dch DANCE RIDE 4

0053h ed2ch DANCE RIDE 5

0053h 2c8eh CZ SYN RIDE

0053h 9b94h 808 RIDE CYM

0052h 7728h DANCE CRASH 1

0052h 50adh DANCE CRASH 2

0052h 70f2h DANCE CRASH 3

0052h 0784h DANCE CRASH 4

0052h 4200h DANCE CRASH 5

Waveform Class = Percussion

NUMBER CHECKSUM WAVENAME

0160h c408h 01-DOPE 77

0160h 5f95h 02-DOPE 82

mrsysex.txt 10/10/2011 8:17 PM

Page 87 of 161

4786

4787

4788

4789

4790

4791

4792

4793

4794

4795

4796

4797

4798

4799

4800

4801

4802

4803

4804

4805

4806

4807

4808

4809

4810

4811

4812

4813

4814

4815

4816

4817

4818

4819

4820

4821

4822

4823

4824

4825

4826

4827

4828

4829

4830

4831

4832

4833

4834

4835

4836

4837

4838

4839

4840

0160h fbc4h 03-DOPE 85

0160h c8fbh 04-DA BOMB 86

0160h 7240h 05-DOPE 89

0160h 0d94h 06-BRKBEAT 90

0160h 1d86h 07-HIP HOP 90

0160h 1635h 08-DOPE 92

0160h 6724h 09-DOPE 95

0160h b0dch 10-RATRAP 105

0160h 6c22h 11-CONGA 108

0160h 5ac3h 12-DOPE 123

0160h c61eh 13-TECHNO 124

0160h e623h 14-HIPHOP 124

0160h e273h 15-HIPHOP 124

0160h 8764h 16-TECHNO 130

0160h 48dfh 17-TECHNO 130

0160h a3afh 18-TECHNO 132

0160h 59e0h 19-TECHNO 134

0160h d417h 20-TECHNO 134

0160h 4e11h 21-TECHNO 134

0160h fde2h 22-TECHNO 136

0160h 2230h 23-TECHNO 138

0160h 7f54h 24-TECHNO 138

0160h 9b37h 25-HOUSE 140

0160h d1ech 26-HOUSE 140

0160h 409dh 27-TECHNO 140

0160h 8e1bh 28-TECHNO 140

0160h 4457h 30-BELLZ 142

0160h cfa8h 31-TRANCE 146

0160h 7125h 32-ACID 150

0160h 0c02h 34-ACID 154

0160h 4b78h 35-RAVE 170

0160h dac8h 36-RAVE 170

0160h de63h BOOM BIP MAP

0160h b365h BRKBEAT MAP

011Eh 8502h CLAP CLAP

011Eh c67eh CLAP MAP 1

011Eh 01f7h CLAP MAP 2

011Eh 8427h CLAP MAP 3

011Eh 4f06h CLAP MAP 4

011Eh 7702h CLAP MAP 5

0160h 2dedh DOPE JAZZ MAP

0160h ff6ah DUMMDRUM MAP

011Bh 68b3h FINGERSNAP MP

0158h bf8ch FREAKOUT PERC

0160h 75b5h FUNK OUT MAP

0160h 4750h HARDCORE MAP

0160h 1addh HEAVY MAP

0160h 2849h IT HERTZ MAP

0160h 2ae7h KIK IT MAP

0160h 6cedh OL SKOOL MAP

0160h 255ah RAT RAP MAP

0056h 8e1ah TAMBO MAP 1

0056h e852h TAMBO MAP 2

0160h ca4dh THE RIOT MAP

0160h 6dc2h WAK PAK MAP

mrsysex.txt 10/10/2011 8:17 PM

Page 88 of 161

4841

4842

4843

4844

4845

4846

4847

4848

4849

4850

4851

4852

4853

4854

4855

4856

4857

4858

4859

4860

4861

4862

4863

4864

4865

4866

4867

4868

4869

4870

4871

4872

4873

4874

4875

4876

4877

4878

4879

4880

4881

4882

4883

4884

4885

4886

4887

4888

4889

4890

4891

4892

4893

4894

4895

0056h a68ch BAD TAMBO

0160h c8b2h JAZZ RIDE LP

0066h f8ech DANCE TRIANGL

0160h f711h CLOZD HAT LP

Waveform Class = Tuned Percussion

NUMBER CHECKSUM WAVENAME

0143h d1a2h 1970'S HIT

0143h 6e14h BUZZ BASS

0143h 37ddh CHORD VOX

0187h ac69h CHORDS HMM

0187h f09ah DIRTY HIT

0143h 9117h ESQ 1 BASS 1

0187h a66ah EURO HIT 1

0187h 0a27h EURO HIT 2

0187h f231h EURO HIT 3

0143h f103h GIT STAB

0143h c92ch HIT ME HARD

0187h 7f91h HIT STAB

0143h da55h HOP HIT

0143h fbfch HOUSE NATION

0143h 7b92h HOUSE STAB

0143h e6deh OLD CLASSIC

0187h 941fh ORGAN HIT

0187h 60d8h RAVE ORG HIT

0143h 7bf0h RECORD STOP

0143h d672h SMACK HIT

0143h e0dah SNAP SYNTH

0143h 96a8h STAB HIT 1

0143h 4321h STAB HIT 2

0143h d30fh TECHNO CHORD

0143h 2115h VOX HIT

Waveform Class = Sound Effect

NUMBER CHECKSUM WAVENAME

0082h 6489h BEEP MAP 1

0082h c0afh BEEP MAP 2

0156h 6a5eh BLAST

0156h d04ah CABLE'S OUT

0156h fe17h FAST FWD TAPE

0094h 1aaah LAZER ZAP 3

0156h 61f4h METAL HIT

0156h 1e6ah NEEDLE UP

0156h ded4h POP+CLICK MAP

0156h db3fh RECKIT BAD

0156h d8aeh RECORD NOISE

0156h 4087h REWIND TAPE

0094h 353dh REZ ZAPS

018Ah f915h SCRATCH MAP 1

018Ah 2c20h SCRATCH MAP 2

0156h ebe0h SHORT WAVE 1

mrsysex.txt 10/10/2011 8:17 PM

Page 89 of 161

4896

4897

4898

4899

4900

4901

4902

4903

4904

4905

4906

4907

4908

4909

4910

4911

4912

4913

4914

4915

4916

4917

4918

4919

4920

4921

4922

4923

4924

4925

4926

4927

4928

4929

4930

4931

4932

4933

4934

4935

4936

4937

4938

4939

4940

4941

4942

4943

4944

4945

4946

4947

4948

4949

4950

0156h e80ch SHORT WAVE 2

0156h ce8bh SPACE LAND

0156h a344h SPACE MAN

0156h db1dh SPACE SYNTH 1

0156h fa66h SPACE SYNTH 2

0156h 5068h SPACE SYNTH 3

0156h cd98h SPACE SYNTH 4

0156h 1a3ah STATIC CLING

0094h 7d94h SUPER ZAP

0156h ccd1h WRONG NUMBER

0094h e197h ZAP 1A

0094h 14e4h ZAP 1B

0094h 5d27h ZAP 2A

0094h 1754h ZAP 2B

Waveform Class = Waveform

NUMBER CHECKSUM WAVENAME

012Dh c33bh JOE'S LEAD

012Dh 66d2h OBEE REZ

012Dh 23ebh PW LEAD SYN

012Dh 2852h PW MOOG SYN

0131h 6fdeh RASPY SYNTH

012Dh b3f3h RES SAW 1

012Dh 3b17h RES SAW 2

012Dh 9fdeh RES SAW 3

012Dh 5c65h RES SAW 4

0043h 88dch REZZ HIT

012Dh d529h SOLITUDE

Waveform Class = Inharmonic

NUMBER CHECKSUM WAVENAME

0047h c87fh 8-BIT FUNK

0149h d67ch DIRTY BELL LP

0047h c2fch DRONE

0047h 286eh GRANULAR

0047h ef8bh INDUSTRIAL

0076h 2982h INHARMONIC 1

0076h 0e88h INHARMONIC 2

0076h 0469h INHARMONIC 3

0148h 7126h OLD RACKBELL

0047h 723bh REZ NOIZ MAP

Waveform Class = Transwave

NUMBER CHECKSUM WAVENAME

014Dh 64bbh BASS REZ 2

014Dh 04c9h BLUE TRANCE

016Ah d02dh BRAINIAC

014Ah 630bh CHIME-X

016Ah 3614h CLAVINEX

mrsysex.txt 10/10/2011 8:17 PM

Page 90 of 161

4951

4952

4953

4954

4955

4956

4957

4958

4959

4960

4961

4962

4963

4964

4965

4966

4967

4968

4969

4970

4971

4972

4973

4974

4975

4976

4977

4978

4979

4980

4981

4982

4983

4984

4985

4986

4987

4988

4989

4990

4991

4992

4993

4994

4995

4996

4997

4998

4999

5000

5001

5002

5003

5004

5005

014Dh 2076h CLIX-POPS

014Dh c32dh COLOR WHEEL

014Dh 7d12h CYBORG

016Ah 3ec4h ELVIS

014Bh ca04h FAT SQUAREZ

014Dh 7ebeh FRANKENWAVE

016Ah ee7ah GET EVEN

014Dh 88e4h GREEN TRANCE

014Dh 17ach HARMONIX

014Ch 5611h HEY

014Dh b153h HIHAT-X

016Ah fc1dh JOLT

014Dh 828fh LIGHT YEARS

014Ah 0646h LONG GONG 1

014Ah 9620h LONG GONG 2

016Ah dd09h MERCURY BASS

014Ah 0a5eh MIRROR-X

014Dh 3c5eh OPERETTA

014Dh 7e0ah ORANGE TRANCE

016Ah dbb0h OVERTONES

016Ah 2bd5h POLYMOD SWEEP

014Dh 4b59h PULSEWAVEMOD

014Bh 8403h QUITE ODD

014Dh 0a97h RAT BREATH X

014Dh 32feh RED TRANCE

014Bh 085dh REZ LOOPS-2

014Bh 087ah REZ POP ATAKS

016Ah fc66h REZ SQUARE

014Bh 2ab0h ROBOT SWEEP

014Dh 27b2h SAMPLE & HOLD

014Bh dc69h SAW REZ SWEEP

016Ah 0c3ah SKY ROCKETS

014Ah dfcah SPARKLERS

016Ah e719h STEP UP

0168h 97d5h STEPS

014Bh 3a32h STEPS REZ

014Ch 4c58h SYLLABLES

014Dh cf75h SYNKING

016Ah 1c23h TABLE-4-2

014Ch 340ah THANK YOU

0166h b021h TRAN-REZ BASS

014Bh 2aceh TRANS BLIPS

014Bh 7a3fh TRANS BOY

014Dh 9799h TRANS E.PIANO

016Ah f8ach TRANS-FRED

016Ah e0a6h TRANS-GRESSOR

0168h ba8eh TRANZGRUV 01

016Ah 3304h TRANZGRUV 02

0168h 2905h TRANZGRUV 03

014Dh caa8h TRANZGRUV 04

014Dh aa28h TRANZGRUV 05

014Dh 4d66h TRANZGRUV 06

0168h 1aceh TRANZGRUV 07

0168h 6c81h TRANZGRUV 08

0168h 23e9h TRANZGRUV 09

mrsysex.txt 10/10/2011 8:17 PM

Page 91 of 161

5006

5007

5008

5009

5010

5011

5012

5013

5014

5015

5016

5017

5018

5019

5020

5021

5022

5023

5024

5025

5026

5027

5028

5029

5030

5031

5032

5033

5034

5035

5036

5037

5038

5039

5040

5041

5042

5043

5044

5045

5046

5047

5048

5049

5050

5051

5052

5053

5054

5055

5056

5057

5058

5059

5060

0168h 3c52h TRANZGRUV 10

014Ah e2b3h TUBULAR-X

016Ah 6b3ah U B RANDOM

014Ch fa6ch VODER-X

014Ch 5524h VOWELS

014Dh 3bbbh VOX SYN SWEEP

014Dh f972h YELLOW TRANCE

014Ch 1f74h YODEL X

Appendix 5 - Insert Effect Parameters

Insert Effect 1: Parametric EQ

Total parameters: 12 (12 visible, 0 hidden)

Visible 0 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 1 (2) Ofs 4

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 2 (3) Ofs 6

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 3 (6) Ofs 12

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 4 (7) Ofs 14

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 5 (8) Ofs 16

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 6 (9) Ofs 18

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 7 (10) Ofs 20

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 8 (11) Ofs 22

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (4) Ofs 8

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (5) Ofs 10

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Insert Effect 2: Hall Reverb

Total parameters: 21 (21 visible, 0 hidden)

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

LF Decay Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 Ofs 4

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 3 Ofs 6

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 4 Ofs 8

Primary Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 5 Ofs 10

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 7 Ofs 14

Definition Min 0 (0 ) Max 100 (100 )

Visible 8 Ofs 16

Detune Rate Min 0 (0.00Hz ) Max 154 (1.54Hz )

Visible 9 Ofs 18

Detune Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 10 Ofs 20

PreDelay Min 0 (0ms ) Max 36 (36ms )

Visible 11 Ofs 22

ER 1 Time Min 0 (0ms ) Max 112 (112ms )

Visible 12 Ofs 24

ER 1 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 13 Ofs 26

ER 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 14 Ofs 28

ER 2 Time Min 0 (0ms ) Max 112 (112ms )

Visible 15 Ofs 30

ER 2 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 16 Ofs 32

ER 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 17 Ofs 34

Position 1 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 18 Ofs 36

Position 2 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 19 Ofs 38

Position 3 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 Ofs 40

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 3: Large Room

Total parameters: 21 (21 visible, 0 hidden)

mrsysex.txt 10/10/2011 8:17 PM

Page 92 of 161

5061

5062

5063

5064

5065

5066

5067

5068

5069

5070

5071

5072

5073

5074

5075

5076

5077

5078

5079

5080

5081

5082

5083

5084

5085

5086

5087

5088

5089

5090

5091

5092

5093

5094

5095

5096

5097

5098

5099

5100

5101

5102

5103

5104

5105

5106

5107

5108

5109

5110

5111

5112

5113

5114

5115

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

LF Decay Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 Ofs 4

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 3 Ofs 6

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 4 Ofs 8

Primary Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 5 Ofs 10

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 7 Ofs 14

Definition Min 0 (0 ) Max 100 (100 )

Visible 8 Ofs 16

Detune Rate Min 0 (0.00Hz ) Max 154 (1.54Hz )

Visible 9 Ofs 18

Detune Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 10 Ofs 20

PreDelay Min 0 (0ms ) Max 36 (36ms )

Visible 11 Ofs 22

ER 1 Time Min 0 (0ms ) Max 112 (112ms )

Visible 12 Ofs 24

ER 1 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 13 Ofs 26

ER 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 14 Ofs 28

ER 2 Time Min 0 (0ms ) Max 112 (112ms )

Visible 15 Ofs 30

ER 2 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 16 Ofs 32

ER 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 17 Ofs 34

Position 1 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 18 Ofs 36

Position 2 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 19 Ofs 38

Position 3 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 Ofs 40

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 4: Small Room

Total parameters: 21 (21 visible, 0 hidden)

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

LF Decay Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 Ofs 4

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 3 Ofs 6

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 4 Ofs 8

Primary Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 5 Ofs 10

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 7 Ofs 14

Definition Min 0 (0 ) Max 100 (100 )

Visible 8 Ofs 16

Detune Rate Min 0 (0.00Hz ) Max 154 (1.54Hz )

Visible 9 Ofs 18

Detune Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 10 Ofs 20

PreDelay Min 0 (0ms ) Max 36 (36ms )

Visible 11 Ofs 22

ER 1 Time Min 0 (0ms ) Max 112 (112ms )

Visible 12 Ofs 24

ER 1 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 13 Ofs 26

ER 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 14 Ofs 28

ER 2 Time Min 0 (0ms ) Max 112 (112ms )

Visible 15 Ofs 30

ER 2 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 16 Ofs 32

ER 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 17 Ofs 34

Position 1 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 18 Ofs 36

Position 2 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 19 Ofs 38

Position 3 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 Ofs 40

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 5: Large Plate

Total parameters: 12 (12 visible, 0 hidden)

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 2 Ofs 4

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 3 Ofs 6

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 4 Ofs 8

Diffusion 2 Min 0 (0 ) Max 100 (100 )

mrsysex.txt 10/10/2011 8:17 PM

Page 93 of 161

5116

5117

5118

5119

5120

5121

5122

5123

5124

5125

5126

5127

5128

5129

5130

5131

5132

5133

5134

5135

5136

5137

5138

5139

5140

5141

5142

5143

5144

5145

5146

5147

5148

5149

5150

5151

5152

5153

5154

5155

5156

5157

5158

5159

5160

5161

5162

5163

5164

5165

5166

5167

5168

5169

5170

Visible 5 Ofs 10

Definition Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

PreDelay Min 0 (0ms ) Max 36 (36ms )

Visible 7 Ofs 14

ER 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

ER 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 9 Ofs 18

ER 3 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 10 Ofs 20

ER 4 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 11 Ofs 22

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 6: Small Plate

Total parameters: 12 (12 visible, 0 hidden)

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 2 Ofs 4

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 3 Ofs 6

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 4 Ofs 8

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 5 Ofs 10

Definition Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

PreDelay Min 0 (0ms ) Max 36 (36ms )

Visible 7 Ofs 14

ER 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

ER 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 9 Ofs 18

ER 3 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 10 Ofs 20

ER 4 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 11 Ofs 22

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 7: NonLinReverb1

Total parameters: 21 (21 visible, 0 hidden)

Visible 0 Ofs 0

Env 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 1 Ofs 2

Env 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 Ofs 4

Env 3 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 3 Ofs 6

Env 4 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 4 Ofs 8

Env 5 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 5 Ofs 10

Env 6 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 6 Ofs 12

Env 7 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 7 Ofs 14

Env 8 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

Env 9 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 9 Ofs 18

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 10 Ofs 20

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 11 Ofs 22

Primary Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 12 Ofs 24

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 13 Ofs 26

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 14 Ofs 28

Density 1 Min 0 (0 ) Max 100 (100 )

Visible 15 Ofs 30

Density 2 Min 0 (0 ) Max 100 (100 )

Visible 16 Ofs 32

ER 1 Time Min 0 (0ms ) Max 112 (112ms )

Visible 17 Ofs 34

ER 1 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 18 Ofs 36

ER 2 Time Min 0 (0ms ) Max 112 (112ms )

Visible 19 Ofs 38

ER 2 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 Ofs 40

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 8: NonLinReverb2

Total parameters: 21 (21 visible, 0 hidden)

Visible 0 Ofs 0

Env 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 1 Ofs 2

Env 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 Ofs 4

Env 3 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

mrsysex.txt 10/10/2011 8:17 PM

Page 94 of 161

5171

5172

5173

5174

5175

5176

5177

5178

5179

5180

5181

5182

5183

5184

5185

5186

5187

5188

5189

5190

5191

5192

5193

5194

5195

5196

5197

5198

5199

5200

5201

5202

5203

5204

5205

5206

5207

5208

5209

5210

5211

5212

5213

5214

5215

5216

5217

5218

5219

5220

5221

5222

5223

5224

5225

Visible 3 Ofs 6

Env 4 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 4 Ofs 8

Env 5 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 5 Ofs 10

Env 6 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 6 Ofs 12

Env 7 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 7 Ofs 14

Env 8 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

Env 9 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 9 Ofs 18

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 10 Ofs 20

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 11 Ofs 22

Primary Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 12 Ofs 24

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 13 Ofs 26

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 14 Ofs 28

Density 1 Min 0 (0 ) Max 100 (100 )

Visible 15 Ofs 30

Density 2 Min 0 (0 ) Max 100 (100 )

Visible 16 Ofs 32

ER 1 Time Min 0 (0ms ) Max 112 (112ms )

Visible 17 Ofs 34

ER 1 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 18 Ofs 36

ER 2 Time Min 0 (0ms ) Max 112 (112ms )

Visible 19 Ofs 38

ER 2 Send Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 Ofs 40

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 9: Gated Reverb

Total parameters: 18 (17 visible, 1 hidden)

Visible 0 (6) Ofs 12

Gate Thresh Min 0 (-96.0dB ) Max 96 (0.0dB ) See Table 9

Visible 1 (7) Ofs 14

Gate Hysteresis Min 0 (0dB ) Max 48 (48dB )

Visible 2 (8) Ofs 16

Gate Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 3 (9) Ofs 18

Gate Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 4 (10) Ofs 20

Gate Hold Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 5 (0) Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 6 (1) Ofs 2

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 7 (3) Ofs 6

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 8 (4) Ofs 8

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 9 (5) Ofs 10

Definition Min 0 (0 ) Max 100 (100 )

Visible 10 (11) Ofs 22

Slap Time Min 0 (0ms ) Max 108 (108ms )

Visible 11 (12) Ofs 24

Slap Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 12 (13) Ofs 26

ER 1 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 13 (14) Ofs 28

ER 2 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 14 (15) Ofs 30

ER 3 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 15 (16) Ofs 32

ER 4 Level Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 16 (17) Ofs 34

Output Bal Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Hidden 17 (17) Ofs 34

Output Bal Min 0 (Full <L ) Max 127 (Full <L ) See Table 8

Insert Effect 10: Stereo Chorus

Total parameters: 5 (5 visible, 0 hidden)

Visible 0 Ofs 0

LFO Rate Min 0 (0.0Hz ) Max 105 (20.0Hz ) See Table 12

Visible 1 Ofs 2

Chorus Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 2 Ofs 4

ChorusCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 3 Ofs 6

Spread Min 0 (L<---->R) Max 10 (R<---->L) See Table 13

Visible 4 Ofs 8

Chorus Phase Min 0 (0deg ) Max 1 (-180deg ) See Table 14

Insert Effect 11: 8-Voice Chorus

Total parameters: 14 (13 visible, 1 hidden)

Visible 0 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 1 (2) Ofs 4

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

mrsysex.txt 10/10/2011 8:17 PM

Page 95 of 161

5226

5227

5228

5229

5230

5231

5232

5233

5234

5235

5236

5237

5238

5239

5240

5241

5242

5243

5244

5245

5246

5247

5248

5249

5250

5251

5252

5253

5254

5255

5256

5257

5258

5259

5260

5261

5262

5263

5264

5265

5266

5267

5268

5269

5270

5271

5272

5273

5274

5275

5276

5277

5278

5279

5280

Visible 2 (3) Ofs 6

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 3 (4) Ofs 8

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 4 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 5 (13) Ofs 26

Dry Blend Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 6 (11) Ofs 22

HPF Cutoff Min 0 (10Hz ) Max 109 (10.9kHz ) See Table 2

Visible 7 (5) Ofs 10

LFO Rate Min 0 (0.0Hz ) Max 70 (7.0Hz )

Visible 8 (6) Ofs 12

Chorus Depth Min 0 (0.0ms ) Max 3000 (300.0ms )

Visible 9 (7) Ofs 14

ChorusCenter Min 0 (0.0ms ) Max 3000 (300.0ms )

Visible 10 (12) Ofs 24

Center Offset Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 11 (9) Ofs 18

Chorus Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 12 (10) Ofs 20

Chorus Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Hidden 13 (13) Ofs 26

Dry Blend Min 0 (Full Dry) Max 127 (Full Dry) See Table 15

Insert Effect 12: Rev(Chorus

Total parameters: 13 (13 visible, 0 hidden)

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 2 Ofs 4

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 3 Ofs 6

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 4 Ofs 8

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 5 Ofs 10

Definition Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

Chorus Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 7 Ofs 14

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 8 Ofs 16

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 9 Ofs 18

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 10 Ofs 20

Chorus Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 11 Ofs 22

Chorus Center Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 12 Ofs 24

System Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Insert Effect 13: Rev(Flanger

Total parameters: 15 (15 visible, 0 hidden)

Visible 0 Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 Ofs 2

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 2 Ofs 4

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 3 Ofs 6

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 4 Ofs 8

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 5 Ofs 10

Definition Min 0 (0 ) Max 100 (100 )

Visible 6 Ofs 12

FlangerMix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 7 Ofs 14

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 8 Ofs 16

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 9 Ofs 18

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 10 Ofs 20

Flanger Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 11 Ofs 22

FlangerCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 12 Ofs 24

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 13 Ofs 26

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 14 Ofs 28

System Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Insert Effect 14: Rev(Phaser

Total parameters: 14 (13 visible, 1 hidden)

Visible 0 (0) Ofs 0

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 1 (1) Ofs 2

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 2 (2) Ofs 4

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

mrsysex.txt 10/10/2011 8:17 PM

Page 96 of 161

5281

5282

5283

5284

5285

5286

5287

5288

5289

5290

5291

5292

5293

5294

5295

5296

5297

5298

5299

5300

5301

5302

5303

5304

5305

5306

5307

5308

5309

5310

5311

5312

5313

5314

5315

5316

5317

5318

5319

5320

5321

5322

5323

5324

5325

5326

5327

5328

5329

5330

5331

5332

5333

5334

5335

Visible 3 (3) Ofs 6

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 4 (4) Ofs 8

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 5 (5) Ofs 10

Definition Min 0 (0 ) Max 100 (100 )

Visible 6 (6) Ofs 12

Phaser Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 7 (7) Ofs 14

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 8 (8) Ofs 16

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 9 (10) Ofs 20

Phaser Depth Min 0 (0 ) Max 100 (100 )

Visible 10 (11) Ofs 22

Phaser Center Min 0 (0 ) Max 100 (100 )

Visible 11 (12) Ofs 24

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 12 (13) Ofs 26

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Hidden 13 (13) Ofs 26

Feedback Min 0 (-99% ) Max 127 (-99% ) See Table 4

Insert Effect 15: Chorus(Rev

Total parameters: 12 (12 visible, 0 hidden)

Visible 0 Ofs 0

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 1 Ofs 2

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 2 Ofs 4

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 3 Ofs 6

Chorus Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 4 Ofs 8

Chorus Center Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 5 Ofs 10

Rev Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 6 Ofs 12

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 7 Ofs 14

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 8 Ofs 16

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 9 Ofs 18

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 10 Ofs 20

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 11 Ofs 22

Definition Min 0 (0 ) Max 100 (100 )

Insert Effect 16: Flanger(Rev

Total parameters: 14 (14 visible, 0 hidden)

Visible 0 Ofs 0

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 1 Ofs 2

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 2 Ofs 4

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 3 Ofs 6

Flanger Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 4 Ofs 8

FlangerCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 5 Ofs 10

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 6 Ofs 12

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 7 Ofs 14

Rev Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 8 Ofs 16

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 9 Ofs 18

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 10 Ofs 20

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 11 Ofs 22

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 12 Ofs 24

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 13 Ofs 26

Definition Min 0 (0 ) Max 100 (100 )

Insert Effect 17: Phaser(Rev

Total parameters: 14 (13 visible, 1 hidden)

Visible 0 (0) Ofs 0

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 1 (1) Ofs 2

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 2 (3) Ofs 6

Phaser Depth Min 0 (0 ) Max 100 (100 )

Visible 3 (4) Ofs 8

Phaser Center Min 0 (0 ) Max 100 (100 )

Visible 4 (5) Ofs 10

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 5 (6) Ofs 12

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

mrsysex.txt 10/10/2011 8:17 PM

Page 97 of 161

5336

5337

5338

5339

5340

5341

5342

5343

5344

5345

5346

5347

5348

5349

5350

5351

5352

5353

5354

5355

5356

5357

5358

5359

5360

5361

5362

5363

5364

5365

5366

5367

5368

5369

5370

5371

5372

5373

5374

5375

5376

5377

5378

5379

5380

5381

5382

5383

5384

5385

5386

5387

5388

5389

5390

Visible 6 (7) Ofs 14

Rev Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 7 (8) Ofs 16

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 8 (9) Ofs 18

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 9 (10) Ofs 20

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 10 (11) Ofs 22

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 11 (12) Ofs 24

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 12 (13) Ofs 26

Definition Min 0 (0 ) Max 100 (100 )

Hidden 13 (13) Ofs 26

Definition Min 0 (0 ) Max 100 (0 )

Insert Effect 18: EQ(Reverb

Total parameters: 16 (16 visible, 0 hidden)

Visible 0 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 1 (2) Ofs 4

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 2 (3) Ofs 6

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 3 (6) Ofs 12

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 4 (7) Ofs 14

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 5 (8) Ofs 16

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 6 (4) Ofs 8

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 7 (5) Ofs 10

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 8 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (9) Ofs 18

Rev Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 10 (10) Ofs 20

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 11 (11) Ofs 22

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 12 (12) Ofs 24

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 13 (13) Ofs 26

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 14 (14) Ofs 28

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 15 (15) Ofs 30

Definition Min 0 (0 ) Max 100 (100 )

Insert Effect 19: Spinner(Rev

Total parameters: 16 (16 visible, 0 hidden)

Visible 0 Ofs 0

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 1 Ofs 2

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 2 Ofs 4

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 3 Ofs 6

DDL Mod Depth Min 0 (0.0ms ) Max 20 (2.0ms )

Visible 4 Ofs 8

DDL ModCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 5 Ofs 10

Level Mod Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 6 Ofs 12

L-to-R Mod Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 7 Ofs 14

F-to-B Mod Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 8 Ofs 16

Cancellation Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 9 Ofs 18

Rev Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 10 Ofs 20

Decay Min 0 (0.0sec ) Max 100 (10.0sec ) See Table 3

Visible 11 Ofs 22

HF Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 12 Ofs 24

HF Bandwidth Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 6

Visible 13 Ofs 26

Diffusion 1 Min 0 (0 ) Max 100 (100 )

Visible 14 Ofs 28

Diffusion 2 Min 0 (0 ) Max 100 (100 )

Visible 15 Ofs 30

Definition Min 0 (0 ) Max 100 (100 )

Insert Effect 20: DDL(Chorus

Total parameters: 22 (22 visible, 0 hidden)

Visible 0 Ofs 0

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 1 Ofs 2

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 2 Ofs 4

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

mrsysex.txt 10/10/2011 8:17 PM

Page 98 of 161

5391

5392

5393

5394

5395

5396

5397

5398

5399

5400

5401

5402

5403

5404

5405

5406

5407

5408

5409

5410

5411

5412

5413

5414

5415

5416

5417

5418

5419

5420

5421

5422

5423

5424

5425

5426

5427

5428

5429

5430

5431

5432

5433

5434

5435

5436

5437

5438

5439

5440

5441

5442

5443

5444

5445

Visible 3 Ofs 6

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 4 Ofs 8

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 5 Ofs 10

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 6 Ofs 12

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 7 Ofs 14

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 9 Ofs 18

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 10 Ofs 20

Dly3 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 11 Ofs 22

Dly3 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 12 Ofs 24

Dly3 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 13 Ofs 26

Dly4 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 14 Ofs 28

Dly4 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 15 Ofs 30

Dly4 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 16 Ofs 32

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 17 Ofs 34

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 18 Ofs 36

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 19 Ofs 38

Chorus Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 20 Ofs 40

ChorusCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 21 Ofs 42

Spread Min 0 (L<---->R) Max 10 (R<---->L) See Table 13

Insert Effect 21: DDL(Flanger

Total parameters: 23 (23 visible, 0 hidden)

Visible 0 Ofs 0

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 1 Ofs 2

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 2 Ofs 4

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 3 Ofs 6

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 4 Ofs 8

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 5 Ofs 10

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 6 Ofs 12

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 7 Ofs 14

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 9 Ofs 18

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 10 Ofs 20

Dly3 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 11 Ofs 22

Dly3 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 12 Ofs 24

Dly3 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 13 Ofs 26

Dly4 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 14 Ofs 28

Dly4 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 15 Ofs 30

Dly4 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 16 Ofs 32

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 17 Ofs 34

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 18 Ofs 36

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 19 Ofs 38

Flanger Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 20 Ofs 40

FlangerCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 21 Ofs 42

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 22 Ofs 44

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Insert Effect 22: DDL(Phaser

Total parameters: 23 (22 visible, 1 hidden)

Visible 0 (0) Ofs 0

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 1 (1) Ofs 2

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 2 (2) Ofs 4

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 3 (3) Ofs 6

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 4 (4) Ofs 8

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

mrsysex.txt 10/10/2011 8:17 PM

Page 99 of 161

5446

5447

5448

5449

5450

5451

5452

5453

5454

5455

5456

5457

5458

5459

5460

5461

5462

5463

5464

5465

5466

5467

5468

5469

5470

5471

5472

5473

5474

5475

5476

5477

5478

5479

5480

5481

5482

5483

5484

5485

5486

5487

5488

5489

5490

5491

5492

5493

5494

5495

5496

5497

5498

5499

5500

Visible 5 (5) Ofs 10

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 6 (6) Ofs 12

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 7 (7) Ofs 14

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 (8) Ofs 16

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 9 (9) Ofs 18

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 10 (10) Ofs 20

Dly3 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 11 (11) Ofs 22

Dly3 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 12 (12) Ofs 24

Dly3 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 13 (13) Ofs 26

Dly4 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 14 (14) Ofs 28

Dly4 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 15 (15) Ofs 30

Dly4 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 16 (16) Ofs 32

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 17 (17) Ofs 34

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 18 (19) Ofs 38

Phaser Depth Min 0 (0 ) Max 100 (100 )

Visible 19 (20) Ofs 40

Phaser Center Min 0 (0 ) Max 100 (100 )

Visible 20 (21) Ofs 42

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 21 (22) Ofs 44

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Hidden 22 (22) Ofs 44

Feedback Min 0 (-99% ) Max 127 (-99% ) See Table 4

Insert Effect 23: DDL(EQ

Total parameters: 25 (25 visible, 0 hidden)

Visible 0 (0) Ofs 0

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 1 (1) Ofs 2

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 2 (2) Ofs 4

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 3 (3) Ofs 6

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 4 (4) Ofs 8

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 5 (5) Ofs 10

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 6 (6) Ofs 12

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 7 (7) Ofs 14

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 (8) Ofs 16

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 9 (9) Ofs 18

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 10 (10) Ofs 20

Dly3 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 11 (11) Ofs 22

Dly3 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 12 (12) Ofs 24

Dly3 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 13 (13) Ofs 26

Dly4 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 14 (14) Ofs 28

Dly4 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 15 (15) Ofs 30

Dly4 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 16 (16) Ofs 32

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 17 (18) Ofs 36

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 18 (19) Ofs 38

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 19 (22) Ofs 44

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 20 (23) Ofs 46

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 21 (24) Ofs 48

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 22 (20) Ofs 40

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 23 (21) Ofs 42

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 24 (17) Ofs 34

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Insert Effect 24: Multi-Tap DDL

Total parameters: 23 (23 visible, 0 hidden)

Visible 0 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 1 (2) Ofs 4

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 2 (3) Ofs 6

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 3 (4) Ofs 8

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

mrsysex.txt 10/10/2011 8:17 PM

Page 100 of 161

5501

5502

5503

5504

5505

5506

5507

5508

5509

5510

5511

5512

5513

5514

5515

5516

5517

5518

5519

5520

5521

5522

5523

5524

5525

5526

5527

5528

5529

5530

5531

5532

5533

5534

5535

5536

5537

5538

5539

5540

5541

5542

5543

5544

5545

5546

5547

5548

5549

5550

5551

5552

5553

5554

5555

Visible 4 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 5 (5) Ofs 10

Diffusion 1 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 6 (6) Ofs 12

Diffus Time 1 Min 0 (0ms ) Max 62 (62ms )

Visible 7 (7) Ofs 14

Diffusion 2 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 (8) Ofs 16

Diffus Time 2 Min 0 (0ms ) Max 62 (62ms )

Visible 9 (9) Ofs 18

Diffusion 3 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 10 (10) Ofs 20

Diffus Time 3 Min 0 (0ms ) Max 62 (62ms )

Visible 11 (11) Ofs 22

Diffusion 4 Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 12 (12) Ofs 24

Diffus Time 4 Min 0 (0ms ) Max 62 (62ms )

Visible 13 (13) Ofs 26

Dly Interval Min 0 (Uniform ) Max 5 (Random ) See Table 19

Visible 14 (14) Ofs 28

MaxDlyTime Min 0 (1/1 Sys ) Max 511 (500ms )

Visible 15 (15) Ofs 30

Dly Smoothing Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 16 (16) Ofs 32

Feedback Tap Min 1 (1 ) Max 9 (9 )

Visible 17 (17) Ofs 34

Dly Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 18 (18) Ofs 36

Dly Damping Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 19 (19) Ofs 38

Dly Levels Min 0 (Uniform ) Max 5 (Random ) See Table 19

Visible 20 (20) Ofs 40

Dly Max Level Min 0 (0 ) Max 100 (100 )

Visible 21 (21) Ofs 42

Dly Pan Min 0 (Centered) Max 6 (Random ) See Table 20

Visible 22 (22) Ofs 44

Dly Spread Min 0 (0 ) Max 100 (100 )

Insert Effect 25: Dist(Chorus

Total parameters: 26 (26 visible, 0 hidden)

Visible 0 (2) Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 1 (5) Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 3 (6) Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 4 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 5 (3) Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 6 (4) Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (7) Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 (8) Ofs 16

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (10) Ofs 20

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (11) Ofs 22

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (14) Ofs 28

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 12 (15) Ofs 30

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 13 (16) Ofs 32

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 14 (17) Ofs 34

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 15 (18) Ofs 36

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 16 (19) Ofs 38

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 17 (12) Ofs 24

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 18 (13) Ofs 26

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 19 (9) Ofs 18

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 20 (20) Ofs 40

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 21 (21) Ofs 42

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 22 (22) Ofs 44

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 23 (23) Ofs 46

Chorus Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 24 (24) Ofs 48

ChorusCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 25 (25) Ofs 50

Spread Min 0 (L<---->R) Max 10 (R<---->L) See Table 13

Insert Effect 26: Dist(Flanger

Total parameters: 27 (27 visible, 0 hidden)

Visible 0 (2) Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 1 (5) Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

mrsysex.txt 10/10/2011 8:17 PM

Page 101 of 161

5556

5557

5558

5559

5560

5561

5562

5563

5564

5565

5566

5567

5568

5569

5570

5571

5572

5573

5574

5575

5576

5577

5578

5579

5580

5581

5582

5583

5584

5585

5586

5587

5588

5589

5590

5591

5592

5593

5594

5595

5596

5597

5598

5599

5600

5601

5602

5603

5604

5605

5606

5607

5608

5609

5610

Visible 2 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 3 (6) Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 4 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 5 (3) Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 6 (4) Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (7) Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 (8) Ofs 16

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (10) Ofs 20

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (11) Ofs 22

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (14) Ofs 28

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 12 (15) Ofs 30

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 13 (16) Ofs 32

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 14 (17) Ofs 34

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 15 (18) Ofs 36

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 16 (19) Ofs 38

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 17 (12) Ofs 24

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 18 (13) Ofs 26

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 19 (9) Ofs 18

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 20 (20) Ofs 40

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 21 (21) Ofs 42

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 22 (22) Ofs 44

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 23 (23) Ofs 46

Flanger Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 24 (24) Ofs 48

FlangerCenter Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 25 (25) Ofs 50

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 26 (26) Ofs 52

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Insert Effect 27: Dist(Phaser

Total parameters: 27 (26 visible, 1 hidden)

Visible 0 (2) Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 1 (5) Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 3 (6) Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 4 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 5 (3) Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 6 (4) Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (7) Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 (8) Ofs 16

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (10) Ofs 20

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (11) Ofs 22

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (14) Ofs 28

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 12 (15) Ofs 30

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 13 (16) Ofs 32

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 14 (17) Ofs 34

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 15 (18) Ofs 36

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 16 (19) Ofs 38

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 17 (12) Ofs 24

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 18 (13) Ofs 26

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 19 (9) Ofs 18

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 20 (20) Ofs 40

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 21 (21) Ofs 42

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 22 (23) Ofs 46

Phaser Depth Min 0 (0 ) Max 100 (100 )

Visible 23 (24) Ofs 48

Phaser Center Min 0 (0 ) Max 100 (100 )

Visible 24 (25) Ofs 50

Notch Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 25 (26) Ofs 52

Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

mrsysex.txt 10/10/2011 8:17 PM

Page 102 of 161

5611

5612

5613

5614

5615

5616

5617

5618

5619

5620

5621

5622

5623

5624

5625

5626

5627

5628

5629

5630

5631

5632

5633

5634

5635

5636

5637

5638

5639

5640

5641

5642

5643

5644

5645

5646

5647

5648

5649

5650

5651

5652

5653

5654

5655

5656

5657

5658

5659

5660

5661

5662

5663

5664

5665

Hidden 26 (26) Ofs 52

Feedback Min 0 (-99% ) Max 127 (-99% ) See Table 4

Insert Effect 28: Dist(AutoWah

Total parameters: 13 (13 visible, 0 hidden)

Visible 0 (4) Ofs 8

Pre HPF Fc Min 0 (10Hz ) Max 60 (1.50kHz ) See Table 2

Visible 1 (5) Ofs 10

Pre VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 2 (6) Ofs 12

Pre VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 3 (7) Ofs 14

PreVCF EnvAmt Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 4 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 5 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 6 (12) Ofs 24

Distortion Min 0 (On ) Max 1 (Off ) See Table 23

Visible 7 (9) Ofs 18

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 8 (10) Ofs 20

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 9 (11) Ofs 22

PostVCF EnvAmt Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 10 (2) Ofs 4

VCF Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 11 (3) Ofs 6

VCF Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 12 (8) Ofs 16

Post HPF Fc Min 0 (10Hz ) Max 60 (1.50kHz ) See Table 2

Insert Effect 29: ResVCF(DDL

Total parameters: 19 (19 visible, 0 hidden)

Visible 0 Ofs 0

VCF Input Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 1 Ofs 2

VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 2 Ofs 4

VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 3 Ofs 6

ADSR Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 4 Ofs 8

ADSR Decay Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 5 Ofs 10

ADSR Sustain Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 6 Ofs 12

ADSR Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 7 Ofs 14

ADSR Env Amt Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 8 Ofs 16

ADSR TrigMode Min 0 (Single ) Max 1 (Multi ) See Table 24

Visible 9 Ofs 18

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 10 Ofs 20

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 11 Ofs 22

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 12 Ofs 24

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 13 Ofs 26

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 14 Ofs 28

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 15 Ofs 30

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 16 Ofs 32

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 17 Ofs 34

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 18 Ofs 36

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 30: Dist(VCF(DDL

Total parameters: 31 (31 visible, 0 hidden)

Visible 0 (2) Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 1 (5) Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 3 (6) Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 4 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 5 (3) Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 6 (4) Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (7) Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 (9) Ofs 18

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 9 (10) Ofs 20

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

mrsysex.txt 10/10/2011 8:17 PM

Page 103 of 161

5666

5667

5668

5669

5670

5671

5672

5673

5674

5675

5676

5677

5678

5679

5680

5681

5682

5683

5684

5685

5686

5687

5688

5689

5690

5691

5692

5693

5694

5695

5696

5697

5698

5699

5700

5701

5702

5703

5704

5705

5706

5707

5708

5709

5710

5711

5712

5713

5714

5715

5716

5717

5718

5719

5720

Visible 10 (11) Ofs 22

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (8) Ofs 16

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 12 (12) Ofs 24

VCF Input Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 13 (13) Ofs 26

VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 14 (14) Ofs 28

VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 15 (15) Ofs 30

ADSR Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 16 (16) Ofs 32

ADSR Decay Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 17 (17) Ofs 34

ADSR Sustain Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 18 (18) Ofs 36

ADSR Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 19 (19) Ofs 38

ADSR Env Amt Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 (30) Ofs 60

ADSR TrigMode Min 0 (Single ) Max 1 (Multi ) See Table 24

Visible 21 (20) Ofs 40

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 22 (21) Ofs 42

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 23 (22) Ofs 44

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 24 (23) Ofs 46

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 25 (24) Ofs 48

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 26 (25) Ofs 50

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 27 (26) Ofs 52

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 28 (27) Ofs 54

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 29 (28) Ofs 56

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 30 (29) Ofs 58

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 31: Pitch Detuner

Total parameters: 16 (16 visible, 0 hidden)

Visible 0 Ofs 0

Voice1 Semi Min 0 (-24 semi) Max 48 (+24 semi) See Table 25

Visible 1 Ofs 2

Voice1 Fine Min 0 (-100cent) Max 200 (+100cent) See Table 26

Visible 2 Ofs 4

Voice1 Level Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 3 Ofs 6

Voice1 Regen Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 4 Ofs 8

Voice1 Width Min 1 (1ms ) Max 185 (185ms )

Visible 5 Ofs 10

Voice1 Mod Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 6 Ofs 12

Voice2 Semi Min 0 (-24 semi) Max 48 (+24 semi) See Table 25

Visible 7 Ofs 14

Voice2 Fine Min 0 (-100cent) Max 200 (+100cent) See Table 26

Visible 8 Ofs 16

Voice2 Level Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 9 Ofs 18

Voice2 Regen Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 10 Ofs 20

Voice2 Width Min 1 (1ms ) Max 185 (185ms )

Visible 11 Ofs 22

Voice2 Mod Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 12 Ofs 24

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 13 Ofs 26

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 14 Ofs 28

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 15 Ofs 30

Regen Time Min 0 (1/1 Sys ) Max 196 (185ms )

Insert Effect 32: Chatter Box

Total parameters: 20 (20 visible, 0 hidden)

Visible 0 Ofs 0

VCF Input Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 1 Ofs 2

VCF Dry Amt Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 2 Ofs 4

Shape 1 Min 0 ('A' ) Max 29 ('Z' ) See Table 27

Visible 3 Ofs 6

Shape 2 Min 0 ('A' ) Max 29 ('Z' ) See Table 27

Visible 4 Ofs 8

Shape 3 Min 0 ('A' ) Max 29 ('Z' ) See Table 27

Visible 5 Ofs 10

Shape 4 Min 0 ('A' ) Max 29 ('Z' ) See Table 27

Visible 6 Ofs 12

FormantWarp Min 12 (-12 semi) Max 36 (+12 semi) See Table 25

Visible 7 Ofs 14

AutoPan Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 8 Ofs 16

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 9 Ofs 18

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

mrsysex.txt 10/10/2011 8:17 PM

Page 104 of 161

5721

5722

5723

5724

5725

5726

5727

5728

5729

5730

5731

5732

5733

5734

5735

5736

5737

5738

5739

5740

5741

5742

5743

5744

5745

5746

5747

5748

5749

5750

5751

5752

5753

5754

5755

5756

5757

5758

5759

5760

5761

5762

5763

5764

5765

5766

5767

5768

5769

5770

5771

5772

5773

5774

5775

Visible 10 Ofs 20

LFO 2 Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 11 Ofs 22

LFO 2 Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 12 Ofs 24

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 13 Ofs 26

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 14 Ofs 28

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 15 Ofs 30

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 16 Ofs 32

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 17 Ofs 34

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 18 Ofs 36

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 19 Ofs 38

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Insert Effect 33: Formant Morph

Total parameters: 25 (25 visible, 0 hidden)

Visible 0 Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 1 Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 2 Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 3 Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 4 Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 5 Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 6 Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 7 Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 Ofs 16

VCF Input Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 9 Ofs 18

VCF Dry Amt Min 0 (Off ) Max 100 (0.0dB ) See Table 1

Visible 10 Ofs 20

Shape 1 Min 0 ('A' ) Max 29 ('Z' ) See Table 27

Visible 11 Ofs 22

Shape 2 Min 0 ('A' ) Max 29 ('Z' ) See Table 27

Visible 12 Ofs 24

FormantWarp Min 12 (-12 semi) Max 36 (+12 semi) See Table 25

Visible 13 Ofs 26

AutoPan Depth Min 0 (0% ) Max 100 (100% ) See Table 7

Visible 14 Ofs 28

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 15 Ofs 30

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 16 Ofs 32

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 17 Ofs 34

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 18 Ofs 36

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 19 Ofs 38

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 Ofs 40

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 21 Ofs 42

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 22 Ofs 44

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 23 Ofs 46

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 24 Ofs 48

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Insert Effect 34: Rotary Speaker

Total parameters: 32 (32 visible, 0 hidden)

Visible 0 (2) Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 1 (5) Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 3 (6) Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 4 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 5 (3) Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 6 (4) Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (7) Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 (9) Ofs 18

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 9 (10) Ofs 20

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 10 (11) Ofs 22

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (8) Ofs 16

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

mrsysex.txt 10/10/2011 8:17 PM

Page 105 of 161

5776

5777

5778

5779

5780

5781

5782

5783

5784

5785

5786

5787

5788

5789

5790

5791

5792

5793

5794

5795

5796

5797

5798

5799

5800

5801

5802

5803

5804

5805

5806

5807

5808

5809

5810

5811

5812

5813

5814

5815

5816

5817

5818

5819

5820

5821

5822

5823

5824

5825

5826

5827

5828

5829

5830

Visible 12 (14) Ofs 28

Speed Min 0 (Slow ) Max 1 (Fast ) See Table 28

Visible 13 (15) Ofs 30

Spread Min 0 (Stereo ) Max 1 (Mono ) See Table 29

Visible 14 (12) Ofs 24

Crossover Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 15 (13) Ofs 26

Lo Hi Bal Min 0 (Full <Lo) Max 127 (Full >Hi) See Table 30

Visible 16 (30) Ofs 60

Rotor Mix Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 17 (16) Ofs 32

Hi Inertia Min 0 (100ms ) Max 30 (10.0s ) See Table 31

Visible 18 (17) Ofs 34

Hi Slow Min 0 (0.0Hz ) Max 50 (10.0Hz ) See Table 32

Visible 19 (18) Ofs 36

Hi Fast Min 0 (0.0Hz ) Max 50 (10.0Hz ) See Table 32

Visible 20 (19) Ofs 38

Hi FM Min Min 0 (0 ) Max 100 (100 )

Visible 21 (20) Ofs 40

Hi FM Max Min 0 (0 ) Max 100 (100 )

Visible 22 (21) Ofs 42

Hi AM Min Min 0 (0 ) Max 100 (100 )

Visible 23 (22) Ofs 44

Hi AM Max Min 0 (0 ) Max 100 (100 )

Visible 24 (23) Ofs 46

Lo Inertia Min 0 (100ms ) Max 30 (10.0s ) See Table 31

Visible 25 (24) Ofs 48

Lo Slow Min 0 (0.0Hz ) Max 50 (10.0Hz ) See Table 32

Visible 26 (25) Ofs 50

Lo Fast Min 0 (0.0Hz ) Max 50 (10.0Hz ) See Table 32

Visible 27 (26) Ofs 52

Lo FM Min Min 0 (0 ) Max 100 (100 )

Visible 28 (27) Ofs 54

Lo FM Max Min 0 (0 ) Max 100 (100 )

Visible 29 (28) Ofs 56

Lo AM Min Min 0 (0 ) Max 100 (100 )

Visible 30 (29) Ofs 58

Lo AM Max Min 0 (0 ) Max 100 (100 )

Visible 31 (31) Ofs 62

Speed Control Min 0 (Normal ) Max 1 (Toggle ) See Table 33

Insert Effect 35: Tunable Spkr

Total parameters: 14 (14 visible, 0 hidden)

Visible 0 (2) Ofs 4

Pre HP Fc Min 0 (10Hz ) Max 60 (1.50kHz ) See Table 2

Visible 1 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 2 (5) Ofs 10

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 3 (6) Ofs 12

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 4 (7) Ofs 14

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 5 (8) Ofs 16

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 6 (9) Ofs 18

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (10) Ofs 20

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 8 (11) Ofs 22

Mid 3 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 9 (12) Ofs 24

Mid 3 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 10 (13) Ofs 26

Mid 3 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 12 (4) Ofs 8

HPF Cutoff Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 13 (3) Ofs 6

LPF Cutoff Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Insert Effect 36: Guitar Amp

Total parameters: 31 (31 visible, 0 hidden)

Visible 0 (4) Ofs 8

Pre HP Fc Min 0 (10Hz ) Max 60 (1.50kHz ) See Table 2

Visible 1 (7) Ofs 14

Pre EQ Trim Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 2 (8) Ofs 16

Pre EQ Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 3 (9) Ofs 18

Pre EQ Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 4 (10) Ofs 20

Pre EQ Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 5 (0) Ofs 0

Preamp Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 6 (1) Ofs 2

Master Level Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 7 (6) Ofs 12

Tube Bias Min 0 (0 ) Max 100 (100 )

Visible 8 (2) Ofs 4

Bias Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 9 (3) Ofs 6

Bias Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 10 (5) Ofs 10

Post HP Fc Min 0 (10Hz ) Max 60 (1.50kHz ) See Table 2

Visible 11 (12) Ofs 24

Amp BassGain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 12 (14) Ofs 28

Amp Mid1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

mrsysex.txt 10/10/2011 8:17 PM

Page 106 of 161

5831

5832

5833

5834

5835

5836

5837

5838

5839

5840

5841

5842

5843

5844

5845

5846

5847

5848

5849

5850

5851

5852

5853

5854

5855

5856

5857

5858

5859

5860

5861

5862

5863

5864

5865

5866

5867

5868

5869

5870

5871

5872

5873

5874

5875

5876

5877

5878

5879

5880

5881

5882

5883

5884

5885

Visible 13 (15) Ofs 30

Amp Mid1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 14 (16) Ofs 32

Amp Mid1Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 15 (17) Ofs 34

Amp Mid2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 16 (18) Ofs 36

Amp Mid2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 17 (19) Ofs 38

Amp Mid2Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 18 (13) Ofs 26

Amp TrebGain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 19 (11) Ofs 22

PostEQ Level Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 20 (20) Ofs 40

Speaker LPF Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 21 (21) Ofs 42

Gate Thresh Min 0 (-96.0dB ) Max 96 (0.0dB ) See Table 9

Visible 22 (22) Ofs 44

Gate Hysteresis Min 0 (0dB ) Max 48 (48dB )

Visible 23 (23) Ofs 46

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 24 (24) Ofs 48

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 25 (25) Ofs 50

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 26 (26) Ofs 52

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 27 (27) Ofs 54

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 28 (28) Ofs 56

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 29 (29) Ofs 58

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 30 (30) Ofs 60

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 37: Dist(DDL(Trem

Total parameters: 31 (31 visible, 0 hidden)

Visible 0 (2) Ofs 4

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 1 (5) Ofs 10

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 2 (0) Ofs 0

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 3 (6) Ofs 12

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 4 (1) Ofs 2

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 5 (3) Ofs 6

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 6 (4) Ofs 8

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 7 (7) Ofs 14

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 8 (9) Ofs 18

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (11) Ofs 22

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (12) Ofs 24

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 11 (13) Ofs 26

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 12 (14) Ofs 28

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 13 (15) Ofs 30

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 14 (16) Ofs 32

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 15 (10) Ofs 20

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 16 (8) Ofs 16

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 17 (17) Ofs 34

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 18 (18) Ofs 36

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 19 (19) Ofs 38

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 20 (20) Ofs 40

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 21 (21) Ofs 42

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 22 (22) Ofs 44

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 23 (23) Ofs 46

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 24 (24) Ofs 48

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 25 (25) Ofs 50

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 26 (26) Ofs 52

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 27 (27) Ofs 54

LFO Rate Min 0 (1/1 Sys ) Max 116 (20.0Hz ) See Table 17

Visible 28 (28) Ofs 56

LFO Shape Min 0 (Triangle) Max 7 (4-Step ) See Table 18

Visible 29 (29) Ofs 58

LFO Phase Min 0 (-180deg ) Max 180 (+180deg ) See Table 16

Visible 30 (30) Ofs 60

LFO Depth Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Insert Effect 38: Comp(Dist(DDL

mrsysex.txt 10/10/2011 8:17 PM

Page 107 of 161

5886

5887

5888

5889

5890

5891

5892

5893

5894

5895

5896

5897

5898

5899

5900

5901

5902

5903

5904

5905

5906

5907

5908

5909

5910

5911

5912

5913

5914

5915

5916

5917

5918

5919

5920

5921

5922

5923

5924

5925

5926

5927

5928

5929

5930

5931

5932

5933

5934

5935

5936

5937

5938

5939

5940

Total parameters: 32 (32 visible, 0 hidden)

Visible 0 (0) Ofs 0

Comp Ratio Min 0 (1.0:1 ) Max 34 (INF:1 ) See Table 34

Visible 1 (1) Ofs 2

Comp Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 2 (2) Ofs 4

Comp Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 3 (3) Ofs 6

Comp Thresh Min 0 (-96.0dB ) Max 96 (0.0dB ) See Table 9

Visible 4 (4) Ofs 8

Comp Output Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 5 (5) Ofs 10

Gate Thresh Min 0 (-96.0dB ) Max 96 (0.0dB ) See Table 9

Visible 6 (6) Ofs 12

Gate Hysteresis Min 0 (0dB ) Max 48 (48dB )

Visible 7 (9) Ofs 18

Dist LPF Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 8 (12) Ofs 24

Dist Offset Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 9 (7) Ofs 14

Dist Gain Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 10 (13) Ofs 26

Dist Curve Min 0 (Soft ) Max 4 (Buzz ) See Table 21

Visible 11 (8) Ofs 16

Dist Volume Min 0 (Off ) Max 100 (0dB ) See Table 22

Visible 12 (10) Ofs 20

Post VCF Fc Min 0 (10Hz ) Max 94 (7.10kHz ) See Table 2

Visible 13 (11) Ofs 22

Post VCF Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 14 (14) Ofs 28

Dist Dry Lev Min 0 (Off ) Max 100 (0.0dB ) See Table 11

Visible 15 (16) Ofs 32

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 16 (18) Ofs 36

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 17 (19) Ofs 38

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 18 (20) Ofs 40

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 19 (21) Ofs 42

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 20 (22) Ofs 44

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 21 (23) Ofs 46

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 22 (17) Ofs 34

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 23 (15) Ofs 30

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 24 (24) Ofs 48

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 25 (25) Ofs 50

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 26 (26) Ofs 52

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 27 (27) Ofs 54

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 28 (28) Ofs 56

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 29 (29) Ofs 58

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 30 (30) Ofs 60

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 31 (31) Ofs 62

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Insert Effect 39: EQ(Comp(Gate

Total parameters: 23 (23 visible, 0 hidden)

Visible 0 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 1 (2) Ofs 4

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 2 (3) Ofs 6

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 3 (6) Ofs 12

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 4 (7) Ofs 14

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 5 (8) Ofs 16

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 6 (9) Ofs 18

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 7 (10) Ofs 20

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 8 (11) Ofs 22

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (4) Ofs 8

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (5) Ofs 10

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 12 (12) Ofs 24

Comp PreDelay Min 0 (0ms ) Max 100 (100ms )

Visible 13 (13) Ofs 26

Comp Ratio Min 0 (1.0:1 ) Max 34 (INF:1 ) See Table 34

Visible 14 (14) Ofs 28

Comp Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 15 (15) Ofs 30

Comp Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 16 (16) Ofs 32

Comp Thresh Min 0 (-96.0dB ) Max 96 (0.0dB ) See Table 9

mrsysex.txt 10/10/2011 8:17 PM

Page 108 of 161

5941

5942

5943

5944

5945

5946

5947

5948

5949

5950

5951

5952

5953

5954

5955

5956

5957

5958

5959

5960

5961

5962

5963

5964

5965

5966

5967

5968

5969

5970

5971

5972

5973

5974

5975

5976

5977

5978

5979

5980

5981

5982

5983

5984

5985

5986

5987

5988

5989

5990

5991

5992

5993

5994

5995

Visible 17 (17) Ofs 34

Comp Output Min 0 (Off ) Max 148 (+48dB ) See Table 1

Visible 18 (21) Ofs 42

Gate Thresh Min 0 (-96.0dB ) Max 96 (0.0dB ) See Table 9

Visible 19 (22) Ofs 44

Gate Hysteresis Min 0 (0dB ) Max 48 (48dB )

Visible 20 (18) Ofs 36

Gate Attack Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 21 (19) Ofs 38

Gate Release Min 0 (50us ) Max 58 (10.0s ) See Table 10

Visible 22 (20) Ofs 40

Gate Hold Min 0 (50us ) Max 58 (10.0s ) See Table 10

Insert Effect 40: EQ(Chorus(DDL

Total parameters: 32 (32 visible, 0 hidden)

Visible 0 (0) Ofs 0

EQ Input Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 1 (2) Ofs 4

LoShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 2 (3) Ofs 6

LoShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 3 (6) Ofs 12

Mid 1 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 4 (7) Ofs 14

Mid 1 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 5 (8) Ofs 16

Mid 1 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 6 (9) Ofs 18

Mid 2 Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 7 (10) Ofs 20

Mid 2 Q Min 10 (1.0 ) Max 400 (40.0 )

Visible 8 (11) Ofs 22

Mid 2 Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 9 (4) Ofs 8

HiShelf Fc Min 0 (10Hz ) Max 121 (20.0kHz ) See Table 2

Visible 10 (5) Ofs 10

HiShelf Gain Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 11 (1) Ofs 2

EQ Output Min 0 (Off ) Max 124 (+24dB ) See Table 1

Visible 12 (31) Ofs 62

Dry Blend Min 0 (Full Dry) Max 127 (Full Wet) See Table 15

Visible 13 (12) Ofs 24

LFO Rate Min 0 (0.0Hz ) Max 105 (20.0Hz ) See Table 12

Visible 14 (13) Ofs 26

Chorus Depth Min 0 (0.0ms ) Max 250 (25.0ms )

Visible 15 (14) Ofs 28

Chorus Center Min 0 (0.0ms ) Max 500 (50.0ms )

Visible 16 (15) Ofs 30

Dly1 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 17 (16) Ofs 32

Dly1 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 18 (17) Ofs 34

Dly1 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 19 (18) Ofs 36

Dly1 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 20 (19) Ofs 38

Dly1 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 21 (20) Ofs 40

Dly2 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 22 (21) Ofs 42

Dly2 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 23 (22) Ofs 44

Dly2 Feedback Min 0 (-99% ) Max 127 (+99% ) See Table 4

Visible 24 (23) Ofs 46

Dly2 Damping Min 0 (100Hz ) Max 127 (21.2kHz ) See Table 5

Visible 25 (24) Ofs 48

Dly2 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 26 (25) Ofs 50

Dly3 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 27 (26) Ofs 52

Dly3 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 28 (27) Ofs 54

Dly3 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Visible 29 (28) Ofs 56

Dly4 Time Min 0 (1/1 Sys ) Max 641 (630ms )

Visible 30 (29) Ofs 58

Dly4 Level Min 0 (Off ) Max 124 (+12.0dB ) See Table 11

Visible 31 (30) Ofs 60

Dly4 Pan Min 0 (Full <L ) Max 127 (Full >R ) See Table 8

Display Table #1

00h = OFF

01h = -49.5dB

02h = -49.0dB

03h = -48.5dB

04h = -48.0dB

05h = -47.5dB

06h = -47.0dB

07h = -46.5dB

08h = -46.0dB

09h = -45.5dB

mrsysex.txt 10/10/2011 8:17 PM

Page 109 of 161

5996

5997

5998

5999

6000

6001

6002

6003

6004

6005

6006

6007

6008

6009

6010

6011

6012

6013

6014

6015

6016

6017

6018

6019

6020

6021

6022

6023

6024

6025

6026

6027

6028

6029

6030

6031

6032

6033

6034

6035

6036

6037

6038

6039

6040

6041

6042

6043

6044

6045

6046

6047

6048

6049

6050

0Ah = -45.0dB

0Bh = -44.5dB

0Ch = -44.0dB

0Dh = -43.5dB

0Eh = -43.0dB

0Fh = -42.5dB

10h = -42.0dB

11h = -41.5dB

12h = -41.0dB

13h = -40.5dB

14h = -40.0dB

15h = -39.5dB

16h = -39.0dB

17h = -38.5dB

18h = -38.0dB

19h = -37.5dB

1Ah = -37.0dB

1Bh = -36.5dB

1Ch = -36.0dB

1Dh = -35.5dB

1Eh = -35.0dB

1Fh = -34.5dB

20h = -34.0dB

21h = -33.5dB

22h = -33.0dB

23h = -32.5dB

24h = -32.0dB

25h = -31.5dB

26h = -31.0dB

27h = -30.5dB

28h = -30.0dB

29h = -29.5dB

2Ah = -29.0dB

2Bh = -28.5dB

2Ch = -28.0dB

2Dh = -27.5dB

2Eh = -27.0dB

2Fh = -26.5dB

30h = -26.0dB

31h = -25.5dB

32h = -25.0dB

33h = -24.5dB

34h = -24.0dB

35h = -23.5dB

36h = -23.0dB

37h = -22.5dB

38h = -22.0dB

39h = -21.5dB

3Ah = -21.0dB

3Bh = -20.5dB

3Ch = -20.0dB

3Dh = -19.5dB

3Eh = -19.0dB

3Fh = -18.5dB

40h = -18.0dB

mrsysex.txt 10/10/2011 8:17 PM

Page 110 of 161

6051

6052

6053

6054

6055

6056

6057

6058

6059

6060

6061

6062

6063

6064

6065

6066

6067

6068

6069

6070

6071

6072

6073

6074

6075

6076

6077

6078

6079

6080

6081

6082

6083

6084

6085

6086

6087

6088

6089

6090

6091

6092

6093

6094

6095

6096

6097

6098

6099

6100

6101

6102

6103

6104

6105

41h = -17.5dB

42h = -17.0dB

43h = -16.5dB

44h = -16.0dB

45h = -15.5dB

46h = -15.0dB

47h = -14.5dB

48h = -14.0dB

49h = -13.5dB

4Ah = -13.0dB

4Bh = -12.5dB

4Ch = -12.0dB

4Dh = -11.5dB

4Eh = -11.0dB

4Fh = -10.5dB

50h = -10.0dB

51h = -09.5dB

52h = -09.0dB

53h = -08.5dB

54h = -08.0dB

55h = -07.5dB

56h = -07.0dB

57h = -06.5dB

58h = -06.0dB

59h = -05.5dB

5Ah = -05.0dB

5Bh = -04.5dB

5Ch = -04.0dB

5Dh = -03.5dB

5Eh = -03.0dB

5Fh = -02.5dB

60h = -02.0dB

61h = -01.5dB

62h = -01.0dB

63h = -00.5dB

64h = 00.0dB

65h = +01.0dB

66h = +02.0dB

67h = +03.0dB

68h = +04.0dB

69h = +05.0dB

6Ah = +06.0dB

6Bh = +07.0dB

6Ch = +08.0dB

6Dh = +09.0dB

6Eh = +10.0dB

6Fh = +11.0dB

70h = +12.0dB

71h = +13.0dB

72h = +14.0dB

73h = +15.0dB

74h = +16.0dB

75h = +17.0dB

76h = +18.0dB

77h = +19.0dB

mrsysex.txt 10/10/2011 8:17 PM

Page 111 of 161

6106

6107

6108

6109

6110

6111

6112

6113

6114

6115

6116

6117

6118

6119

6120

6121

6122

6123

6124

6125

6126

6127

6128

6129

6130

6131

6132

6133

6134

6135

6136

6137

6138

6139

6140

6141

6142

6143

6144

6145

6146

6147

6148

6149

6150

6151

6152

6153

6154

6155

6156

6157

6158

6159

6160

78h = +20.0dB

79h = +21.0dB

7Ah = +22.0dB

7Bh = +23.0dB

7Ch = +24.0dB

7Dh = +25.0dB

7Eh = +26.0dB

7Fh = +27.0dB

80h = +28.0dB

81h = +29.0dB

82h = +30.0dB

83h = +31.0dB

84h = +32.0dB

85h = +33.0dB

86h = +34.0dB

87h = +35.0dB

88h = +36.0dB

89h = +37.0dB

8Ah = +38.0dB

8Bh = +39.0dB

8Ch = +40.0dB

8Dh = +41.0dB

8Eh = +42.0dB

8Fh = +43.0dB

90h = +44.0dB

91h = +45.0dB

92h = +46.0dB

93h = +47.0dB

94h = +48.0dB

Display Table #2

00h = 10Hz

01h = 11Hz

02h = 12Hz

03h = 14Hz

04h = 16Hz

05h = 18Hz

06h = 20Hz

07h = 22Hz

08h = 25Hz

09h = 28Hz

0Ah = 32Hz

0Bh = 35Hz

0Ch = 40Hz

0Dh = 45Hz

0Eh = 50Hz

0Fh = 56Hz

10h = 63Hz

11h = 71Hz

12h = 80Hz

13h = 90Hz

14h = 100Hz

15h = 112Hz

16h = 125Hz

mrsysex.txt 10/10/2011 8:17 PM

Page 112 of 161

6161

6162

6163

6164

6165

6166

6167

6168

6169

6170

6171

6172

6173

6174

6175

6176

6177

6178

6179

6180

6181

6182

6183

6184

6185

6186

6187

6188

6189

6190

6191

6192

6193

6194

6195

6196

6197

6198

6199

6200

6201

6202

6203

6204

6205

6206

6207

6208

6209

6210

6211

6212

6213

6214

6215

17h = 140Hz

18h = 160Hz

19h = 180Hz

1Ah = 200Hz

1Bh = 224Hz

1Ch = 250Hz

1Dh = 280Hz

1Eh = 315Hz

1Fh = 355Hz

20h = 400Hz

21h = 425Hz

22h = 450Hz

23h = 475Hz

24h = 500Hz

25h = 530Hz

26h = 560Hz

27h = 600Hz

28h = 630Hz

29h = 650Hz

2Ah = 670Hz

2Bh = 710Hz

2Ch = 750Hz

2Dh = 800Hz

2Eh = 825Hz

2Fh = 850Hz

30h = 875Hz

31h = 900Hz

32h = 925Hz

33h = 950Hz

34h = 980Hz

35h = 1.00kHz

36h = 1.06kHz

37h = 1.12kHz

38h = 1.18kHz

39h = 1.25kHz

3Ah = 1.32kHz

3Bh = 1.40kHz

3Ch = 1.50kHz

3Dh = 1.60kHz

3Eh = 1.70kHz

3Fh = 1.80kHz

40h = 1.90kHz

41h = 2.00kHz

42h = 2.12kHz

43h = 2.24kHz

44h = 2.36kHz

45h = 2.50kHz

46h = 2.65kHz

47h = 2.80kHz

48h = 3.00kHz

49h = 3.15kHz

4Ah = 3.35kHz

4Bh = 3.55kHz

4Ch = 3.75kHz

4Dh = 4.00kHz

mrsysex.txt 10/10/2011 8:17 PM

Page 113 of 161

6216

6217

6218

6219

6220

6221

6222

6223

6224

6225

6226

6227

6228

6229

6230

6231

6232

6233

6234

6235

6236

6237

6238

6239

6240

6241

6242

6243

6244

6245

6246

6247

6248

6249

6250

6251

6252

6253

6254

6255

6256

6257

6258

6259

6260

6261

6262

6263

6264

6265

6266

6267

6268

6269

6270

4Eh = 4.12kHz

4Fh = 4.25kHz

50h = 4.50kHz

51h = 4.75kHz

52h = 5.00kHz

53h = 5.15kHz

54h = 5.30kHz

55h = 5.45kHz

56h = 5.60kHz

57h = 5.75kHz

58h = 6.00kHz

59h = 6.15kHz

5Ah = 6.30kHz

5Bh = 6.50kHz

5Ch = 6.70kHz

5Dh = 6.90kHz

5Eh = 7.10kHz

5Fh = 7.30kHz

60h = 7.50kHz

61h = 7.75kHz

62h = 8.00kHz

63h = 8.25kHz

64h = 8.50kHz

65h = 8.75kHz

66h = 9.00kHz

67h = 9.25kHz

68h = 9.50kHz

69h = 9.80kHz

6Ah = 10.0kHz

6Bh = 10.3kHz

6Ch = 10.6kHz

6Dh = 10.9kHz

6Eh = 11.2kHz

6Fh = 11.8kHz

70h = 12.2kHz

71h = 12.6kHz

72h = 13.2kHz

73h = 14.0kHz

74h = 15.0kHz

75h = 16.0kHz

76h = 17.0kHz

77h = 18.0kHz

78h = 19.0kHz

79h = 20.0kHz

Display Table #3

00h = 0.0sec

01h = 0.1sec

02h = 0.2sec

03h = 0.3sec

04h = 0.4sec

05h = 0.5sec

06h = 0.6sec

07h = 0.7sec

mrsysex.txt 10/10/2011 8:17 PM

Page 114 of 161

6271

6272

6273

6274

6275

6276

6277

6278

6279

6280

6281

6282

6283

6284

6285

6286

6287

6288

6289

6290

6291

6292

6293

6294

6295

6296

6297

6298

6299

6300

6301

6302

6303

6304

6305

6306

6307

6308

6309

6310

6311

6312

6313

6314

6315

6316

6317

6318

6319

6320

6321

6322

6323

6324

6325

08h = 0.8sec

09h = 0.9sec

0Ah = 1.0sec

0Bh = 1.1sec

0Ch = 1.2sec

0Dh = 1.3sec

0Eh = 1.4sec

0Fh = 1.5sec

10h = 1.6sec

11h = 1.7sec

12h = 1.8sec

13h = 1.9sec

14h = 2.0sec

15h = 2.1sec

16h = 2.2sec

17h = 2.3sec

18h = 2.4sec

19h = 2.5sec

1Ah = 2.6sec

1Bh = 2.7sec

1Ch = 2.8sec

1Dh = 2.9sec

1Eh = 3.0sec

1Fh = 3.1sec

20h = 3.2sec

21h = 3.3sec

22h = 3.4sec

23h = 3.5sec

24h = 3.6sec

25h = 3.7sec

26h = 3.8sec

27h = 3.9sec

28h = 4.0sec

29h = 4.1sec

2Ah = 4.2sec

2Bh = 4.3sec

2Ch = 4.4sec

2Dh = 4.5sec

2Eh = 4.6sec

2Fh = 4.7sec

30h = 4.8sec

31h = 4.9sec

32h = 5.0sec

33h = 5.1sec

34h = 5.2sec

35h = 5.3sec

36h = 5.4sec

37h = 5.5sec

38h = 5.6sec

39h = 5.7sec

3Ah = 5.8sec

3Bh = 5.9sec

3Ch = 6.0sec

3Dh = 6.1sec

3Eh = 6.2sec

mrsysex.txt 10/10/2011 8:17 PM

Page 115 of 161

6326

6327

6328

6329

6330

6331

6332

6333

6334

6335

6336

6337

6338

6339

6340

6341

6342

6343

6344

6345

6346

6347

6348

6349

6350

6351

6352

6353

6354

6355

6356

6357

6358

6359

6360

6361

6362

6363

6364

6365

6366

6367

6368

6369

6370

6371

6372

6373

6374

6375

6376

6377

6378

6379

6380

3Fh = 6.3sec

40h = 6.4sec

41h = 6.5sec

42h = 6.6sec

43h = 6.7sec

44h = 6.8sec

45h = 6.9sec

46h = 7.0sec

47h = 7.1sec

48h = 7.2sec

49h = 7.3sec

4Ah = 7.4sec

4Bh = 7.5sec

4Ch = 7.6sec

4Dh = 7.7sec

4Eh = 7.8sec

4Fh = 7.9sec

50h = 8.0sec

51h = 8.1sec

52h = 8.2sec

53h = 8.3sec

54h = 8.4sec

55h = 8.5sec

56h = 8.6sec

57h = 8.7sec

58h = 8.8sec

59h = 8.9sec

5Ah = 9.0sec

5Bh = 9.1sec

5Ch = 9.2sec

5Dh = 9.3sec

5Eh = 9.4sec

5Fh = 9.5sec

60h = 9.6sec

61h = 9.7sec

62h = 9.8sec

63h = 9.9sec

64h = 10.0sec

Display Table #4

00h = -99%

01h = -98%

02h = -97%

03h = -96%

04h = -95%

05h = -94%

06h = -93%

07h = -92%

08h = -91%

09h = -90%

0Ah = -88%

0Bh = -86%

0Ch = -84%

0Dh = -82%

mrsysex.txt 10/10/2011 8:17 PM

Page 116 of 161

6381

6382

6383

6384

6385

6386

6387

6388

6389

6390

6391

6392

6393

6394

6395

6396

6397

6398

6399

6400

6401

6402

6403

6404

6405

6406

6407

6408

6409

6410

6411

6412

6413

6414

6415

6416

6417

6418

6419

6420

6421

6422

6423

6424

6425

6426

6427

6428

6429

6430

6431

6432

6433

6434

6435

0Eh = -80%

0Fh = -78%

10h = -76%

11h = -74%

12h = -72%

13h = -70%

14h = -68%

15h = -66%

16h = -64%

17h = -62%

18h = -60%

19h = -58%

1Ah = -56%

1Bh = -54%

1Ch = -52%

1Dh = -50%

1Eh = -48%

1Fh = -46%

20h = -44%

21h = -42%

22h = -40%

23h = -38%

24h = -36%

25h = -34%

26h = -32%

27h = -30%

28h = -28%

29h = -26%

2Ah = -24%

2Bh = -22%

2Ch = -20%

2Dh = -19%

2Eh = -18%

2Fh = -17%

30h = -16%

31h = -15%

32h = -14%

33h = -13%

34h = -12%

35h = -11%

36h = -10%

37h = -09%

38h = -08%

39h = -07%

3Ah = -06%

3Bh = -05%

3Ch = -04%

3Dh = -03%

3Eh = -02%

3Fh = -01%

40h = 00%

41h = +01%

42h = +02%

43h = +03%

44h = +04%

mrsysex.txt 10/10/2011 8:17 PM

Page 117 of 161

6436

6437

6438

6439

6440

6441

6442

6443

6444

6445

6446

6447

6448

6449

6450

6451

6452

6453

6454

6455

6456

6457

6458

6459

6460

6461

6462

6463

6464

6465

6466

6467

6468

6469

6470

6471

6472

6473

6474

6475

6476

6477

6478

6479

6480

6481

6482

6483

6484

6485

6486

6487

6488

6489

6490

45h = +05%

46h = +06%

47h = +07%

48h = +08%

49h = +09%

4Ah = +10%

4Bh = +11%

4Ch = +12%

4Dh = +13%

4Eh = +14%

4Fh = +15%

50h = +16%

51h = +17%

52h = +18%

53h = +19%

54h = +20%

55h = +22%

56h = +24%

57h = +26%

58h = +28%

59h = +30%

5Ah = +32%

5Bh = +34%

5Ch = +36%

5Dh = +38%

5Eh = +40%

5Fh = +42%

60h = +44%

61h = +46%

62h = +48%

63h = +50%

64h = +52%

65h = +54%

66h = +56%

67h = +58%

68h = +60%

69h = +62%

6Ah = +64%

6Bh = +66%

6Ch = +68%

6Dh = +70%

6Eh = +72%

6Fh = +74%

70h = +76%

71h = +78%

72h = +80%

73h = +82%

74h = +84%

75h = +86%

76h = +88%

77h = +90%

78h = +92%

79h = +93%

7Ah = +94%

7Bh = +95%

mrsysex.txt 10/10/2011 8:17 PM

Page 118 of 161

6491

6492

6493

6494

6495

6496

6497

6498

6499

6500

6501

6502

6503

6504

6505

6506

6507

6508

6509

6510

6511

6512

6513

6514

6515

6516

6517

6518

6519

6520

6521

6522

6523

6524

6525

6526

6527

6528

6529

6530

6531

6532

6533

6534

6535

6536

6537

6538

6539

6540

6541

6542

6543

6544

6545

7Ch = +96%

7Dh = +97%

7Eh = +98%

7Fh = +99%

Display Table #5

00h = 100Hz

01h = 200Hz

02h = 300Hz

03h = 400Hz

04h = 500Hz

05h = 600Hz

06h = 700Hz

07h = 800Hz

08h = 900Hz

09h = 1.0kHz

0Ah = 1.1kHz

0Bh = 1.2kHz

0Ch = 1.3kHz

0Dh = 1.4kHz

0Eh = 1.5kHz

0Fh = 1.6kHz

10h = 1.7kHz

11h = 1.8kHz

12h = 1.9kHz

13h = 2.0kHz

14h = 2.1kHz

15h = 2.2kHz

16h = 2.3kHz

17h = 2.4kHz

18h = 2.5kHz

19h = 2.6kHz

1Ah = 2.7kHz

1Bh = 2.8kHz

1Ch = 2.9kHz

1Dh = 3.0kHz

1Eh = 3.1kHz

1Fh = 3.2kHz

20h = 3.3kHz

21h = 3.4kHz

22h = 3.5kHz

23h = 3.6kHz

24h = 3.7kHz

25h = 3.8kHz

26h = 3.9kHz

27h = 4.0kHz

28h = 4.1kHz

29h = 4.2kHz

2Ah = 4.3kHz

2Bh = 4.4kHz

2Ch = 4.6kHz

2Dh = 4.8kHz

2Eh = 5.0kHz

2Fh = 5.2kHz

mrsysex.txt 10/10/2011 8:17 PM

Page 119 of 161

6546

6547

6548

6549

6550

6551

6552

6553

6554

6555

6556

6557

6558

6559

6560

6561

6562

6563

6564

6565

6566

6567

6568

6569

6570

6571

6572

6573

6574

6575

6576

6577

6578

6579

6580

6581

6582

6583

6584

6585

6586

6587

6588

6589

6590

6591

6592

6593

6594

6595

6596

6597

6598

6599

6600

30h = 5.4kHz

31h = 5.6kHz

32h = 5.8kHz

33h = 6.0kHz

34h = 6.2kHz

35h = 6.4kHz

36h = 6.6kHz

37h = 6.8kHz

38h = 7.0kHz

39h = 7.2kHz

3Ah = 7.4kHz

3Bh = 7.6kHz

3Ch = 7.8kHz

3Dh = 8.0kHz

3Eh = 8.2kHz

3Fh = 8.4kHz

40h = 8.6kHz

41h = 8.8kHz

42h = 9.0kHz

43h = 9.2kHz

44h = 9.4kHz

45h = 9.6kHz

46h = 9.8kHz

47h = 10.0kHz

48h = 10.2kHz

49h = 10.4kHz

4Ah = 10.6kHz

4Bh = 10.8kHz

4Ch = 11.0kHz

4Dh = 11.2kHz

4Eh = 11.4kHz

4Fh = 11.6kHz

50h = 11.8kHz

51h = 12.0kHz

52h = 12.2kHz

53h = 12.4kHz

54h = 12.6kHz

55h = 12.8kHz

56h = 13.0kHz

57h = 13.2kHz

58h = 13.4kHz

59h = 13.6kHz

5Ah = 13.8kHz

5Bh = 14.0kHz

5Ch = 14.2kHz

5Dh = 14.4kHz

5Eh = 14.6kHz

5Fh = 14.8kHz

60h = 15.0kHz

61h = 15.2kHz

62h = 15.4kHz

63h = 15.6kHz

64h = 15.8kHz

65h = 16.0kHz

66h = 16.2kHz

mrsysex.txt 10/10/2011 8:17 PM

Page 120 of 161

6601

6602

6603

6604

6605

6606

6607

6608

6609

6610

6611

6612

6613

6614

6615

6616

6617

6618

6619

6620

6621

6622

6623

6624

6625

6626

6627

6628

6629

6630

6631

6632

6633

6634

6635

6636

6637

6638

6639

6640

6641

6642

6643

6644

6645

6646

6647

6648

6649

6650

6651

6652

6653

6654

6655

67h = 16.4kHz

68h = 16.6kHz

69h = 16.8kHz

6Ah = 17.0kHz

6Bh = 17.2kHz

6Ch = 17.4kHz

6Dh = 17.6kHz

6Eh = 17.8kHz

6Fh = 18.0kHz

70h = 18.2kHz

71h = 18.4kHz

72h = 18.6kHz

73h = 18.8kHz

74h = 19.0kHz

75h = 19.2kHz

76h = 19.4kHz

77h = 19.6kHz

78h = 19.8kHz

79h = 20.0kHz

7Ah = 20.2kHz

7Bh = 20.4kHz

7Ch = 20.6kHz

7Dh = 20.8kHz

7Eh = 21.0kHz

7Fh = 21.2kHz

Display Table #6

00h = 100Hz

01h = 200Hz

02h = 300Hz

03h = 400Hz

04h = 500Hz

05h = 600Hz

06h = 700Hz

07h = 800Hz

08h = 900Hz

09h = 1.0kHz

0Ah = 1.1kHz

0Bh = 1.2kHz

0Ch = 1.3kHz

0Dh = 1.4kHz

0Eh = 1.5kHz

0Fh = 1.6kHz

10h = 1.7kHz

11h = 1.8kHz

12h = 1.9kHz

13h = 2.0kHz

14h = 2.1kHz

15h = 2.2kHz

16h = 2.3kHz

17h = 2.4kHz

18h = 2.5kHz

19h = 2.6kHz

1Ah = 2.7kHz

mrsysex.txt 10/10/2011 8:17 PM

Page 121 of 161

6656

6657

6658

6659

6660

6661

6662

6663

6664

6665

6666

6667

6668

6669

6670

6671

6672

6673

6674

6675

6676

6677

6678

6679

6680

6681

6682

6683

6684

6685

6686

6687

6688

6689

6690

6691

6692

6693

6694

6695

6696

6697

6698

6699

6700

6701

6702

6703

6704

6705

6706

6707

6708

6709

6710

1Bh = 2.8kHz

1Ch = 2.9kHz

1Dh = 3.0kHz

1Eh = 3.1kHz

1Fh = 3.2kHz

20h = 3.3kHz

21h = 3.4kHz

22h = 3.5kHz

23h = 3.6kHz

24h = 3.7kHz

25h = 3.8kHz

26h = 3.9kHz

27h = 4.0kHz

28h = 4.1kHz

29h = 4.2kHz

2Ah = 4.3kHz

2Bh = 4.4kHz

2Ch = 4.6kHz

2Dh = 4.8kHz

2Eh = 5.0kHz

2Fh = 5.2kHz

30h = 5.4kHz

31h = 5.6kHz

32h = 5.8kHz

33h = 6.0kHz

34h = 6.2kHz

35h = 6.4kHz

36h = 6.6kHz

37h = 6.8kHz

38h = 7.0kHz

39h = 7.2kHz

3Ah = 7.4kHz

3Bh = 7.6kHz

3Ch = 7.8kHz

3Dh = 8.0kHz

3Eh = 8.2kHz

3Fh = 8.4kHz

40h = 8.6kHz

41h = 8.8kHz

42h = 9.0kHz

43h = 9.2kHz

44h = 9.4kHz

45h = 9.6kHz

46h = 9.8kHz

47h = 10.0kHz

48h = 10.2kHz

49h = 10.4kHz

4Ah = 10.6kHz

4Bh = 10.8kHz

4Ch = 11.0kHz

4Dh = 11.2kHz

4Eh = 11.4kHz

4Fh = 11.6kHz

50h = 11.8kHz

51h = 12.0kHz

mrsysex.txt 10/10/2011 8:17 PM

Page 122 of 161

6711

6712

6713

6714

6715

6716

6717

6718

6719

6720

6721

6722

6723

6724

6725

6726

6727

6728

6729

6730

6731

6732

6733

6734

6735

6736

6737

6738

6739

6740

6741

6742

6743

6744

6745

6746

6747

6748

6749

6750

6751

6752

6753

6754

6755

6756

6757

6758

6759

6760

6761

6762

6763

6764

6765

52h = 12.2kHz

53h = 12.4kHz

54h = 12.6kHz

55h = 12.8kHz

56h = 13.0kHz

57h = 13.2kHz

58h = 13.4kHz

59h = 13.6kHz

5Ah = 13.8kHz

5Bh = 14.0kHz

5Ch = 14.2kHz

5Dh = 14.4kHz

5Eh = 14.6kHz

5Fh = 14.8kHz

60h = 15.0kHz

61h = 15.2kHz

62h = 15.4kHz

63h = 15.6kHz

64h = 15.8kHz

65h = 16.0kHz

66h = 16.2kHz

67h = 16.4kHz

68h = 16.6kHz

69h = 16.8kHz

6Ah = 17.0kHz

6Bh = 17.2kHz

6Ch = 17.4kHz

6Dh = 17.6kHz

6Eh = 17.8kHz

6Fh = 18.0kHz

70h = 18.2kHz

71h = 18.4kHz

72h = 18.6kHz

73h = 18.8kHz

74h = 19.0kHz

75h = 19.2kHz

76h = 19.4kHz

77h = 19.6kHz

78h = 19.8kHz

79h = 20.0kHz

7Ah = 20.2kHz

7Bh = 20.4kHz

7Ch = 20.6kHz

7Dh = 20.8kHz

7Eh = 21.0kHz

7Fh = 21.2kHz

Display Table #7

00h = 00%

01h = 01%

02h = 02%

03h = 03%

04h = 04%

05h = 05%

mrsysex.txt 10/10/2011 8:17 PM

Page 123 of 161

6766

6767

6768

6769

6770

6771

6772

6773

6774

6775

6776

6777

6778

6779

6780

6781

6782

6783

6784

6785

6786

6787

6788

6789

6790

6791

6792

6793

6794

6795

6796

6797

6798

6799

6800

6801

6802

6803

6804

6805

6806

6807

6808

6809

6810

6811

6812

6813

6814

6815

6816

6817

6818

6819

6820

06h = 06%

07h = 07%

08h = 08%

09h = 09%

0Ah = 10%

0Bh = 11%

0Ch = 12%

0Dh = 13%

0Eh = 14%

0Fh = 15%

10h = 16%

11h = 17%

12h = 18%

13h = 19%

14h = 20%

15h = 21%

16h = 22%

17h = 23%

18h = 24%

19h = 25%

1Ah = 26%

1Bh = 27%

1Ch = 28%

1Dh = 29%

1Eh = 30%

1Fh = 31%

20h = 32%

21h = 33%

22h = 34%

23h = 35%

24h = 36%

25h = 37%

26h = 38%

27h = 39%

28h = 40%

29h = 41%

2Ah = 42%

2Bh = 43%

2Ch = 44%

2Dh = 45%

2Eh = 46%

2Fh = 47%

30h = 48%

31h = 49%

32h = 50%

33h = 51%

34h = 52%

35h = 53%

36h = 54%

37h = 55%

38h = 56%

39h = 57%

3Ah = 58%

3Bh = 59%

3Ch = 60%

mrsysex.txt 10/10/2011 8:17 PM

Page 124 of 161

6821

6822

6823

6824

6825

6826

6827

6828

6829

6830

6831

6832

6833

6834

6835

6836

6837

6838

6839

6840

6841

6842

6843

6844

6845

6846

6847

6848

6849

6850

6851

6852

6853

6854

6855

6856

6857

6858

6859

6860

6861

6862

6863

6864

6865

6866

6867

6868

6869

6870

6871

6872

6873

6874

6875

3Dh = 61%

3Eh = 62%

3Fh = 63%

40h = 64%

41h = 65%

42h = 66%

43h = 67%

44h = 68%

45h = 69%

46h = 70%

47h = 71%

48h = 72%

49h = 73%

4Ah = 74%

4Bh = 75%

4Ch = 76%

4Dh = 77%

4Eh = 78%

4Fh = 79%

50h = 80%

51h = 81%

52h = 82%

53h = 83%

54h = 84%

55h = 85%

56h = 86%

57h = 87%

58h = 88%

59h = 89%

5Ah = 90%

5Bh = 91%

5Ch = 92%

5Dh = 93%

5Eh = 94%

5Fh = 95%

60h = 96%

61h = 97%

62h = 98%

63h = 99%

64h = 100%

Display Table #8

00h = Full Left

01h = 99% Left

02h = 98% Left

03h = 96% Left

04h = 94% Left

05h = 92% Left

06h = 90% Left

07h = 88% Left

08h = 86% Left

09h = 84% Left

0Ah = 82% Left

0Bh = 80% Left

mrsysex.txt 10/10/2011 8:17 PM

Page 125 of 161

6876

6877

6878

6879

6880

6881

6882

6883

6884

6885

6886

6887

6888

6889

6890

6891

6892

6893

6894

6895

6896

6897

6898

6899

6900

6901

6902

6903

6904

6905

6906

6907

6908

6909

6910

6911

6912

6913

6914

6915

6916

6917

6918

6919

6920

6921

6922

6923

6924

6925

6926

6927

6928

6929

6930

0Ch = 78% Left

0Dh = 76% Left

0Eh = 74% Left

0Fh = 72% Left

10h = 70% Left

11h = 68% Left

12h = 66% Left

13h = 64% Left

14h = 62% Left

15h = 60% Left

16h = 58% Left

17h = 56% Left

18h = 54% Left

19h = 52% Left

1Ah = 50% Left

1Bh = 48% Left

1Ch = 46% Left

1Dh = 44% Left

1Eh = 42% Left

1Fh = 40% Left

20h = 38% Left

21h = 36% Left

22h = 34% Left

23h = 32% Left

24h = 30% Left

25h = 28% Left

26h = 26% Left

27h = 25% Left

28h = 24% Left

29h = 23% Left

2Ah = 22% Left

2Bh = 21% Left

2Ch = 20% Left

2Dh = 29% Left

2Eh = 18% Left

2Fh = 17% Left

30h = 16% Left

31h = 15% Left

32h = 14% Left

33h = 13% Left

34h = 12% Left

35h = 11% Left

36h = 10% Left

37h = 09% Left

38h = 08% Left

39h = 07% Left

3Ah = 06% Left

3Bh = 05% Left

3Ch = 04% Left

3Dh = 03% Left

3Eh = 02% Left

3Fh = 01% Left

40h = Center

41h = 01% Right

42h = 02% Right

mrsysex.txt 10/10/2011 8:17 PM

Page 126 of 161

6931

6932

6933

6934

6935

6936

6937

6938

6939

6940

6941

6942

6943

6944

6945

6946

6947

6948

6949

6950

6951

6952

6953

6954

6955

6956

6957

6958

6959

6960

6961

6962

6963

6964

6965

6966

6967

6968

6969

6970

6971

6972

6973

6974

6975

6976

6977

6978

6979

6980

6981

6982

6983

6984

6985

43h = 03% Right

44h = 04% Right

45h = 05% Right

46h = 06% Right

47h = 07% Right

48h = 08% Right

49h = 09% Right

4Ah = 10% Right

4Bh = 11% Right

4Ch = 12% Right

4Dh = 13% Right

4Eh = 14% Right

4Fh = 15% Right

50h = 16% Right

51h = 17% Right

52h = 18% Right

53h = 19% Right

54h = 20% Right

55h = 21% Right

56h = 22% Right

57h = 23% Right

58h = 24% Right

59h = 25% Right

5Ah = 26% Right

5Bh = 28% Right

5Ch = 30% Right

5Dh = 32% Right

5Eh = 34% Right

5Fh = 36% Right

60h = 38% Right

61h = 40% Right

62h = 42% Right

63h = 44% Right

64h = 46% Right

65h = 48% Right

66h = 50% Right

67h = 52% Right

68h = 54% Right

69h = 56% Right

6Ah = 58% Right

6Bh = 60% Right

6Ch = 62% Right

6Dh = 64% Right

6Eh = 66% Right

6Fh = 68% Right

70h = 70% Right

71h = 72% Right

72h = 74% Right

73h = 76% Right

74h = 78% Right

75h = 80% Right

76h = 82% Right

77h = 84% Right

78h = 86% Right

79h = 88% Right

mrsysex.txt 10/10/2011 8:17 PM

Page 127 of 161

6986

6987

6988

6989

6990

6991

6992

6993

6994

6995

6996

6997

6998

6999

7000

7001

7002

7003

7004

7005

7006

7007

7008

7009

7010

7011

7012

7013

7014

7015

7016

7017

7018

7019

7020

7021

7022

7023

7024

7025

7026

7027

7028

7029

7030

7031

7032

7033

7034

7035

7036

7037

7038

7039

7040

7Ah = 90% Right

7Bh = 92% Right

7Ch = 94% Right

7Dh = 96% Right

7Eh = 98% Right

7Fh = Full Right

Display Table #9

00h = -96.0dB

01h = -95.0dB

02h = -94.0dB

03h = -93.0dB

04h = -92.0dB

05h = -91.0dB

06h = -90.0dB

07h = -89.0dB

08h = -88.0dB

09h = -87.0dB

0Ah = -86.0dB

0Bh = -85.0dB

0Ch = -84.0dB

0Dh = -83.0dB

0Eh = -82.0dB

0Fh = -81.0dB

10h = -80.0dB

11h = -79.0dB

12h = -78.0dB

13h = -77.0dB

14h = -76.0dB

15h = -75.0dB

16h = -74.0dB

17h = -73.0dB

18h = -72.0dB

19h = -71.0dB

1Ah = -70.0dB

1Bh = -69.0dB

1Ch = -68.0dB

1Dh = -67.0dB

1Eh = -66.0dB

1Fh = -65.0dB

20h = -64.0dB

21h = -63.0dB

22h = -62.0dB

23h = -61.0dB

24h = -60.0dB

25h = -59.0dB

26h = -58.0dB

27h = -57.0dB

28h = -56.0dB

29h = -55.0dB

2Ah = -54.0dB

2Bh = -53.0dB

2Ch = -52.0dB

2Dh = -51.0dB

mrsysex.txt 10/10/2011 8:17 PM

Page 128 of 161

7041

7042

7043

7044

7045

7046

7047

7048

7049

7050

7051

7052

7053

7054

7055

7056

7057

7058

7059

7060

7061

7062

7063

7064

7065

7066

7067

7068

7069

7070

7071

7072

7073

7074

7075

7076

7077

7078

7079

7080

7081

7082

7083

7084

7085

7086

7087

7088

7089

7090

7091

7092

7093

7094

7095

2Eh = -50.0dB

2Fh = -49.0dB

30h = -48.0dB

31h = -47.0dB

32h = -46.0dB

33h = -45.0dB

34h = -44.0dB

35h = -43.0dB

36h = -42.0dB

37h = -41.0dB

38h = -40.0dB

39h = -39.0dB

3Ah = -38.0dB

3Bh = -37.0dB

3Ch = -36.0dB

3Dh = -35.0dB

3Eh = -34.0dB

3Fh = -33.0dB

40h = -32.0dB

41h = -31.0dB

42h = -30.0dB

43h = -29.0dB

44h = -28.0dB

45h = -27.0dB

46h = -26.0dB

47h = -25.0dB

48h = -24.0dB

49h = -23.0dB

4Ah = -22.0dB

4Bh = -21.0dB

4Ch = -20.0dB

4Dh = -19.0dB

4Eh = -18.0dB

4Fh = -17.0dB

50h = -16.0dB

51h = -15.0dB

52h = -14.0dB

53h = -13.0dB

54h = -12.0dB

55h = -11.0dB

56h = -10.0dB

57h = -09.0dB

58h = -08.0dB

59h = -07.0dB

5Ah = -06.0dB

5Bh = -05.0dB

5Ch = -04.0dB

5Dh = -03.0dB

5Eh = -02.0dB

5Fh = -01.0dB

60h = 00.0dB

Display Table #10

00h = 50us

mrsysex.txt 10/10/2011 8:17 PM

Page 129 of 161

7096

7097

7098

7099

7100

7101

7102

7103

7104

7105

7106

7107

7108

7109

7110

7111

7112

7113

7114

7115

7116

7117

7118

7119

7120

7121

7122

7123

7124

7125

7126

7127

7128

7129

7130

7131

7132

7133

7134

7135

7136

7137

7138

7139

7140

7141

7142

7143

7144

7145

7146

7147

7148

7149

7150

01h = 100us

02h = 200us

03h = 400us

04h = 800us

05h = 1ms

06h = 2ms

07h = 3ms

08h = 4ms

09h = 5ms

0Ah = 6ms

0Bh = 7ms

0Ch = 8ms

0Dh = 9ms

0Eh = 10ms

0Fh = 11ms

10h = 12ms

11h = 13ms

12h = 14ms

13h = 15ms

14h = 20ms

15h = 30ms

16h = 40ms

17h = 50ms

18h = 60ms

19h = 70ms

1Ah = 80ms

1Bh = 90ms

1Ch = 100ms

1Dh = 200ms

1Eh = 300ms

1Fh = 400ms

20h = 500ms

21h = 600ms

22h = 700ms

23h = 800ms

24h = 900ms

25h = 1.0s

26h = 1.1s

27h = 1.2s

28h = 1.3s

29h = 1.4s

2Ah = 1.5s

2Bh = 1.6s

2Ch = 1.7s

2Dh = 1.8s

2Eh = 1.9s

2Fh = 2.0s

30h = 2.5s

31h = 3.0s

32h = 3.5s

33h = 4.0s

34h = 4.5s

35h = 5.0s

36h = 6.0s

37h = 7.0s

mrsysex.txt 10/10/2011 8:17 PM

Page 130 of 161

7151

7152

7153

7154

7155

7156

7157

7158

7159

7160

7161

7162

7163

7164

7165

7166

7167

7168

7169

7170

7171

7172

7173

7174

7175

7176

7177

7178

7179

7180

7181

7182

7183

7184

7185

7186

7187

7188

7189

7190

7191

7192

7193

7194

7195

7196

7197

7198

7199

7200

7201

7202

7203

7204

7205

38h = 8.0s

39h = 9.0s

3Ah = 10.0s

Display Table #11

00h = OFF

01h = -49.5dB

02h = -49.0dB

03h = -48.5dB

04h = -48.0dB

05h = -47.5dB

06h = -47.0dB

07h = -46.5dB

08h = -46.0dB

09h = -45.5dB

0Ah = -45.0dB

0Bh = -44.5dB

0Ch = -44.0dB

0Dh = -43.5dB

0Eh = -43.0dB

0Fh = -42.5dB

10h = -42.0dB

11h = -41.5dB

12h = -41.0dB

13h = -40.5dB

14h = -40.0dB

15h = -39.5dB

16h = -39.0dB

17h = -38.5dB

18h = -38.0dB

19h = -37.5dB

1Ah = -37.0dB

1Bh = -36.5dB

1Ch = -36.0dB

1Dh = -35.5dB

1Eh = -35.0dB

1Fh = -34.5dB

20h = -34.0dB

21h = -33.5dB

22h = -33.0dB

23h = -32.5dB

24h = -32.0dB

25h = -31.5dB

26h = -31.0dB

27h = -30.5dB

28h = -30.0dB

29h = -29.5dB

2Ah = -29.0dB

2Bh = -28.5dB

2Ch = -28.0dB

2Dh = -27.5dB

2Eh = -27.0dB

2Fh = -26.5dB

30h = -26.0dB

mrsysex.txt 10/10/2011 8:17 PM

Page 131 of 161

7206

7207

7208

7209

7210

7211

7212

7213

7214

7215

7216

7217

7218

7219

7220

7221

7222

7223

7224

7225

7226

7227

7228

7229

7230

7231

7232

7233

7234

7235

7236

7237

7238

7239

7240

7241

7242

7243

7244

7245

7246

7247

7248

7249

7250

7251

7252

7253

7254

7255

7256

7257

7258

7259

7260

31h = -25.5dB

32h = -25.0dB

33h = -24.5dB

34h = -24.0dB

35h = -23.5dB

36h = -23.0dB

37h = -22.5dB

38h = -22.0dB

39h = -21.5dB

3Ah = -21.0dB

3Bh = -20.5dB

3Ch = -20.0dB

3Dh = -19.5dB

3Eh = -19.0dB

3Fh = -18.5dB

40h = -18.0dB

41h = -17.5dB

42h = -17.0dB

43h = -16.5dB

44h = -16.0dB

45h = -15.5dB

46h = -15.0dB

47h = -14.5dB

48h = -14.0dB

49h = -13.5dB

4Ah = -13.0dB

4Bh = -12.5dB

4Ch = -12.0dB

4Dh = -11.5dB

4Eh = -11.0dB

4Fh = -10.5dB

50h = -10.0dB

51h = -09.5dB

52h = -09.0dB

53h = -08.5dB

54h = -08.0dB

55h = -07.5dB

56h = -07.0dB

57h = -06.5dB

58h = -06.0dB

59h = -05.5dB

5Ah = -05.0dB

5Bh = -04.5dB

5Ch = -04.0dB

5Dh = -03.5dB

5Eh = -03.0dB

5Fh = -02.5dB

60h = -02.0dB

61h = -01.5dB

62h = -01.0dB

63h = -00.5dB

64h = 00.0dB

65h = +00.5dB

66h = +01.0dB

67h = +01.5dB

mrsysex.txt 10/10/2011 8:17 PM

Page 132 of 161

7261

7262

7263

7264

7265

7266

7267

7268

7269

7270

7271

7272

7273

7274

7275

7276

7277

7278

7279

7280

7281

7282

7283

7284

7285

7286

7287

7288

7289

7290

7291

7292

7293

7294

7295

7296

7297

7298

7299

7300

7301

7302

7303

7304

7305

7306

7307

7308

7309

7310

7311

7312

7313

7314

7315

68h = +02.0dB

69h = +02.5dB

6Ah = +03.0dB

6Bh = +03.5dB

6Ch = +04.0dB

6Dh = +04.5dB

6Eh = +05.0dB

6Fh = +05.5dB

70h = +06.0dB

71h = +06.5dB

72h = +07.0dB

73h = +07.5dB

74h = +08.0dB

75h = +08.5dB

76h = +09.0dB

77h = +09.5dB

78h = +10.0dB

79h = +10.5dB

7Ah = +11.0dB

7Bh = +11.5dB

7Ch = +12.0dB

7Dh = +12.5dB

7Eh = +13.0dB

7Fh = +13.5dB

Display Table #12

00h = 0.0Hz

01h = 0.1Hz

02h = 0.2Hz

03h = 0.3Hz

04h = 0.4Hz

05h = 0.5Hz

06h = 0.6Hz

07h = 0.7Hz

08h = 0.8Hz

09h = 0.9Hz

0Ah = 1.0Hz

0Bh = 1.1Hz

0Ch = 1.2Hz

0Dh = 1.3Hz

0Eh = 1.4Hz

0Fh = 1.5Hz

10h = 1.6Hz

11h = 1.7Hz

12h = 1.8Hz

13h = 1.9Hz

14h = 2.0Hz

15h = 2.1Hz

16h = 2.2Hz

17h = 2.3Hz

18h = 2.4Hz

19h = 2.5Hz

1Ah = 2.6Hz

1Bh = 2.7Hz

mrsysex.txt 10/10/2011 8:17 PM

Page 133 of 161

7316

7317

7318

7319

7320

7321

7322

7323

7324

7325

7326

7327

7328

7329

7330

7331

7332

7333

7334

7335

7336

7337

7338

7339

7340

7341

7342

7343

7344

7345

7346

7347

7348

7349

7350

7351

7352

7353

7354

7355

7356

7357

7358

7359

7360

7361

7362

7363

7364

7365

7366

7367

7368

7369

7370

1Ch = 2.8Hz

1Dh = 2.9Hz

1Eh = 3.0Hz

1Fh = 3.1Hz

20h = 3.2Hz

21h = 3.3Hz

22h = 3.4Hz

23h = 3.5Hz

24h = 3.6Hz

25h = 3.7Hz

26h = 3.8Hz

27h = 3.9Hz

28h = 4.0Hz

29h = 4.1Hz

2Ah = 4.2Hz

2Bh = 4.3Hz

2Ch = 4.4Hz

2Dh = 4.5Hz

2Eh = 4.6Hz

2Fh = 4.7Hz

30h = 4.8Hz

31h = 4.9Hz

32h = 5.0Hz

33h = 5.1Hz

34h = 5.2Hz

35h = 5.3Hz

36h = 5.4Hz

37h = 5.5Hz

38h = 5.6Hz

39h = 5.7Hz

3Ah = 5.8Hz

3Bh = 5.9Hz

3Ch = 6.0Hz

3Dh = 6.1Hz

3Eh = 6.2Hz

3Fh = 6.3Hz

40h = 6.4Hz

41h = 6.5Hz

42h = 6.6Hz

43h = 6.7Hz

44h = 6.8Hz

45h = 6.9Hz

46h = 7.0Hz

47h = 7.1Hz

48h = 7.2Hz

49h = 7.3Hz

4Ah = 7.4Hz

4Bh = 7.5Hz

4Ch = 7.6Hz

4Dh = 7.7Hz

4Eh = 7.8Hz

4Fh = 7.9Hz

50h = 8.0Hz

51h = 8.1Hz

52h = 8.2Hz

mrsysex.txt 10/10/2011 8:17 PM

Page 134 of 161

7371

7372

7373

7374

7375

7376

7377

7378

7379

7380

7381

7382

7383

7384

7385

7386

7387

7388

7389

7390

7391

7392

7393

7394

7395

7396

7397

7398

7399

7400

7401

7402

7403

7404

7405

7406

7407

7408

7409

7410

7411

7412

7413

7414

7415

7416

7417

7418

7419

7420

7421

7422

7423

7424

7425

53h = 8.3Hz

54h = 8.4Hz

55h = 8.5Hz

56h = 8.6Hz

57h = 8.7Hz

58h = 8.8Hz

59h = 8.9Hz

5Ah = 9.0Hz

5Bh = 9.1Hz

5Ch = 9.2Hz

5Dh = 9.3Hz

5Eh = 9.4Hz

5Fh = 9.5Hz

60h = 9.6Hz

61h = 9.7Hz

62h = 9.8Hz

63h = 9.9Hz

64h = 10.0Hz

65h = 12.0Hz

66h = 14.0Hz

67h = 16.0Hz

68h = 18.0Hz

69h = 20.0Hz

Display Table #13

00h = L----|----R

01h = -L---|---R-

02h = --L--|--R--

03h = ---L-|-R---

04h = ----L|R----

05h = -----M-----

06h = ----R|L----

07h = ---R-|-L---

08h = --R--|--L--

09h = -R---|---L-

0Ah = R----|----L

Display Table #14

00h = 0deg

01h = -180deg

Display Table #15

00h = Full Dry

01h = 00.5% Wet

02h = 01.0% Wet

03h = 01.5% Wet

04h = 02.0% Wet

05h = 02.8% Wet

06h = 03.6% Wet

07h = 04.4% Wet

08h = 05.2% Wet

09h = 06.0% Wet

mrsysex.txt 10/10/2011 8:17 PM

Page 135 of 161

7426

7427

7428

7429

7430

7431

7432

7433

7434

7435

7436

7437

7438

7439

7440

7441

7442

7443

7444

7445

7446

7447

7448

7449

7450

7451

7452

7453

7454

7455

7456

7457

7458

7459

7460

7461

7462

7463

7464

7465

7466

7467

7468

7469

7470

7471

7472

7473

7474

7475

7476

7477

7478

7479

7480

0Ah = 06.8% Wet

0Bh = 07.6% Wet

0Ch = 08.4% Wet

0Dh = 09.2% Wet

0Eh = 10.0% Wet

0Fh = 10.8% Wet

10h = 11.6% Wet

11h = 12.4% Wet

12h = 13.2% Wet

13h = 14.0% Wet

14h = 14.8% Wet

15h = 15.6% Wet

16h = 16.4% Wet

17h = 17.2% Wet

18h = 18.0% Wet

19h = 18.8% Wet

1Ah = 19.6% Wet

1Bh = 20.4% Wet

1Ch = 21.2% Wet

1Dh = 22.0% Wet

1Eh = 22.8% Wet

1Fh = 23.6% Wet

20h = 24.4% Wet

21h = 25.2% Wet

22h = 26.0% Wet

23h = 26.8% Wet

24h = 27.6% Wet

25h = 28.4% Wet

26h = 29.2% Wet

27h = 30.0% Wet

28h = 30.8% Wet

29h = 31.6% Wet

2Ah = 32.4% Wet

2Bh = 33.2% Wet

2Ch = 34.0% Wet

2Dh = 34.8% Wet

2Eh = 35.6% Wet

2Fh = 36.4% Wet

30h = 37.2% Wet

31h = 38.0% Wet

32h = 38.8% Wet

33h = 39.6% Wet

34h = 40.4% Wet

35h = 41.2% Wet

36h = 42.0% Wet

37h = 42.8% Wet

38h = 43.6% Wet

39h = 44.4% Wet

3Ah = 45.2% Wet

3Bh = 46.0% Wet

3Ch = 46.8% Wet

3Dh = 47.6% Wet

3Eh = 48.4% Wet

3Fh = 49.2% Wet

40h = 50.0% Wet

mrsysex.txt 10/10/2011 8:17 PM

Page 136 of 161

7481

7482

7483

7484

7485

7486

7487

7488

7489

7490

7491

7492

7493

7494

7495

7496

7497

7498

7499

7500

7501

7502

7503

7504

7505

7506

7507

7508

7509

7510

7511

7512

7513

7514

7515

7516

7517

7518

7519

7520

7521

7522

7523

7524

7525

7526

7527

7528

7529

7530

7531

7532

7533

7534

7535

41h = 50.8% Wet

42h = 51.6% Wet

43h = 52.4% Wet

44h = 53.2% Wet

45h = 54.0% Wet

46h = 54.8% Wet

47h = 55.6% Wet

48h = 56.4% Wet

49h = 57.2% Wet

4Ah = 58.0% Wet

4Bh = 58.8% Wet

4Ch = 59.6% Wet

4Dh = 60.4% Wet

4Eh = 61.2% Wet

4Fh = 62.0% Wet

50h = 62.8% Wet

51h = 63.6% Wet

52h = 64.4% Wet

53h = 65.2% Wet

54h = 66.0% Wet

55h = 66.8% Wet

56h = 67.6% Wet

57h = 68.4% Wet

58h = 69.2% Wet

59h = 70.0% Wet

5Ah = 70.8% Wet

5Bh = 71.6% Wet

5Ch = 72.4% Wet

5Dh = 73.2% Wet

5Eh = 74.0% Wet

5Fh = 74.8% Wet

60h = 75.6% Wet

61h = 76.4% Wet

62h = 77.2% Wet

63h = 78.0% Wet

64h = 78.8% Wet

65h = 79.6% Wet

66h = 80.4% Wet

67h = 81.2% Wet

68h = 82.0% Wet

69h = 82.8% Wet

6Ah = 83.6% Wet

6Bh = 84.4% Wet

6Ch = 85.2% Wet

6Dh = 86.0% Wet

6Eh = 86.8% Wet

6Fh = 87.6% Wet

70h = 88.4% Wet

71h = 89.2% Wet

72h = 90.0% Wet

73h = 90.8% Wet

74h = 91.6% Wet

75h = 92.4% Wet

76h = 93.2% Wet

77h = 94.0% Wet

mrsysex.txt 10/10/2011 8:17 PM

Page 137 of 161

7536

7537

7538

7539

7540

7541

7542

7543

7544

7545

7546

7547

7548

7549

7550

7551

7552

7553

7554

7555

7556

7557

7558

7559

7560

7561

7562

7563

7564

7565

7566

7567

7568

7569

7570

7571

7572

7573

7574

7575

7576

7577

7578

7579

7580

7581

7582

7583

7584

7585

7586

7587

7588

7589

7590

78h = 94.8% Wet

79h = 95.6% Wet

7Ah = 96.4% Wet

7Bh = 97.2% Wet

7Ch = 98.0% Wet

7Dh = 98.8% Wet

7Eh = 99.6% Wet

7Fh = Full Wet

Display Table #16

00h = -180deg

01h = -178deg

02h = -176deg

03h = -174deg

04h = -172deg

05h = -170deg

06h = -168deg

07h = -166deg

08h = -164deg

09h = -162deg

0Ah = -160deg

0Bh = -158deg

0Ch = -156deg

0Dh = -154deg

0Eh = -152deg

0Fh = -150deg

10h = -148deg

11h = -146deg

12h = -144deg

13h = -142deg

14h = -140deg

15h = -138deg

16h = -136deg

17h = -134deg

18h = -132deg

19h = -130deg

1Ah = -128deg

1Bh = -126deg

1Ch = -124deg

1Dh = -122deg

1Eh = -120deg

1Fh = -118deg

20h = -116deg

21h = -114deg

22h = -112deg

23h = -110deg

24h = -108deg

25h = -106deg

26h = -104deg

27h = -102deg

28h = -100deg

29h = -98deg

2Ah = -96deg

2Bh = -94deg

mrsysex.txt 10/10/2011 8:17 PM

Page 138 of 161

7591

7592

7593

7594

7595

7596

7597

7598

7599

7600

7601

7602

7603

7604

7605

7606

7607

7608

7609

7610

7611

7612

7613

7614

7615

7616

7617

7618

7619

7620

7621

7622

7623

7624

7625

7626

7627

7628

7629

7630

7631

7632

7633

7634

7635

7636

7637

7638

7639

7640

7641

7642

7643

7644

7645

2Ch = -92deg

2Dh = -90deg

2Eh = -88deg

2Fh = -86deg

30h = -84deg

31h = -82deg

32h = -80deg

33h = -78deg

34h = -76deg

35h = -74deg

36h = -72deg

37h = -70deg

38h = -68deg

39h = -66deg

3Ah = -64deg

3Bh = -62deg

3Ch = -60deg

3Dh = -58deg

3Eh = -56deg

3Fh = -54deg

40h = -52deg

41h = -50deg

42h = -48deg

43h = -46deg

44h = -44deg

45h = -42deg

46h = -40deg

47h = -38deg

48h = -36deg

49h = -34deg

4Ah = -32deg

4Bh = -30deg

4Ch = -28deg

4Dh = -26deg

4Eh = -24deg

4Fh = -22deg

50h = -20deg

51h = -18deg

52h = -16deg

53h = -14deg

54h = -12deg

55h = -10deg

56h = -08deg

57h = -06deg

58h = -04deg

59h = -02deg

5Ah = 00deg

5Bh = +02deg

5Ch = +04deg

5Dh = +06deg

5Eh = +08deg

5Fh = +10deg

60h = +12deg

61h = +14deg

62h = +16deg

mrsysex.txt 10/10/2011 8:17 PM

Page 139 of 161

7646

7647

7648

7649

7650

7651

7652

7653

7654

7655

7656

7657

7658

7659

7660

7661

7662

7663

7664

7665

7666

7667

7668

7669

7670

7671

7672

7673

7674

7675

7676

7677

7678

7679

7680

7681

7682

7683

7684

7685

7686

7687

7688

7689

7690

7691

7692

7693

7694

7695

7696

7697

7698

7699

7700

63h = +18deg

64h = +20deg

65h = +22deg

66h = +24deg

67h = +26deg

68h = +28deg

69h = +30deg

6Ah = +32deg

6Bh = +34deg

6Ch = +36deg

6Dh = +38deg

6Eh = +40deg

6Fh = +42deg

70h = +44deg

71h = +46deg

72h = +48deg

73h = +50deg

74h = +52deg

75h = +54deg

76h = +56deg

77h = +58deg

78h = +60deg

79h = +62deg

7Ah = +64deg

7Bh = +66deg

7Ch = +68deg

7Dh = +70deg

7Eh = +72deg

7Fh = +74deg

80h = +76deg

81h = +78deg

82h = +80deg

83h = +82deg

84h = +84deg

85h = +86deg

86h = +88deg

87h = +90deg

88h = +92deg

89h = +94deg

8Ah = +96deg

8Bh = +98deg

8Ch = +100deg

8Dh = +102deg

8Eh = +104deg

8Fh = +106deg

90h = +108deg

91h = +110deg

92h = +112deg

93h = +114deg

94h = +116deg

95h = +118deg

96h = +120deg

97h = +122deg

98h = +124deg

99h = +126deg

mrsysex.txt 10/10/2011 8:17 PM

Page 140 of 161

7701

7702

7703

7704

7705

7706

7707

7708

7709

7710

7711

7712

7713

7714

7715

7716

7717

7718

7719

7720

7721

7722

7723

7724

7725

7726

7727

7728

7729

7730

7731

7732

7733

7734

7735

7736

7737

7738

7739

7740

7741

7742

7743

7744

7745

7746

7747

7748

7749

7750

7751

7752

7753

7754

7755

9Ah = +128deg

9Bh = +130deg

9Ch = +132deg

9Dh = +134deg

9Eh = +136deg

9Fh = +138deg

A0h = +140deg

A1h = +142deg

A2h = +144deg

A3h = +146deg

A4h = +148deg

A5h = +150deg

A6h = +152deg

A7h = +154deg

A8h = +156deg

A9h = +158deg

AAh = +160deg

ABh = +162deg

ACh = +164deg

ADh = +166deg

AEh = +168deg

AFh = +170deg

B0h = +172deg

B1h = +174deg

B2h = +176deg

B3h = +178deg

B4h = +180deg

Display Table #17

00h = 1/1 Sys

01h = 1/1T Sys

02h = 1/2 Sys

03h = 1/2T Sys

04h = 1/4 Sys

05h = 1/4T Sys

06h = 1/8 Sys

07h = 1/8T Sys

08h = 1/16 Sys

09h = 1/16T Sys

0Ah = 1/32 Sys

0Bh = 0.0Hz

0Ch = 0.1Hz

0Dh = 0.2Hz

0Eh = 0.3Hz

0Fh = 0.4Hz

10h = 0.5Hz

11h = 0.6Hz

12h = 0.7Hz

13h = 0.8Hz

14h = 0.9Hz

15h = 1.0Hz

16h = 1.1Hz

17h = 1.2Hz

18h = 1.3Hz

mrsysex.txt 10/10/2011 8:17 PM

Page 141 of 161

7756

7757

7758

7759

7760

7761

7762

7763

7764

7765

7766

7767

7768

7769

7770

7771

7772

7773

7774

7775

7776

7777

7778

7779

7780

7781

7782

7783

7784

7785

7786

7787

7788

7789

7790

7791

7792

7793

7794

7795

7796

7797

7798

7799

7800

7801

7802

7803

7804

7805

7806

7807

7808

7809

7810

19h = 1.4Hz

1Ah = 1.5Hz

1Bh = 1.6Hz

1Ch = 1.7Hz

1Dh = 1.8Hz

1Eh = 1.9Hz

1Fh = 2.0Hz

20h = 2.1Hz

21h = 2.2Hz

22h = 2.3Hz

23h = 2.4Hz

24h = 2.5Hz

25h = 2.6Hz

26h = 2.7Hz

27h = 2.8Hz

28h = 2.9Hz

29h = 3.0Hz

2Ah = 3.1Hz

2Bh = 3.2Hz

2Ch = 3.3Hz

2Dh = 3.4Hz

2Eh = 3.5Hz

2Fh = 3.6Hz

30h = 3.7Hz

31h = 3.8Hz

32h = 3.9Hz

33h = 4.0Hz

34h = 4.1Hz

35h = 4.2Hz

36h = 4.3Hz

37h = 4.4Hz

38h = 4.5Hz

39h = 4.6Hz

3Ah = 4.7Hz

3Bh = 4.8Hz

3Ch = 4.9Hz

3Dh = 5.0Hz

3Eh = 5.1Hz

3Fh = 5.2Hz

40h = 5.3Hz

41h = 5.4Hz

42h = 5.5Hz

43h = 5.6Hz

44h = 5.7Hz

45h = 5.8Hz

46h = 5.9Hz

47h = 6.0Hz

48h = 6.1Hz

49h = 6.2Hz

4Ah = 6.3Hz

4Bh = 6.4Hz

4Ch = 6.5Hz

4Dh = 6.6Hz

4Eh = 6.7Hz

4Fh = 6.8Hz

mrsysex.txt 10/10/2011 8:17 PM

Page 142 of 161

7811

7812

7813

7814

7815

7816

7817

7818

7819

7820

7821

7822

7823

7824

7825

7826

7827

7828

7829

7830

7831

7832

7833

7834

7835

7836

7837

7838

7839

7840

7841

7842

7843

7844

7845

7846

7847

7848

7849

7850

7851

7852

7853

7854

7855

7856

7857

7858

7859

7860

7861

7862

7863

7864

7865

50h = 6.9Hz

51h = 7.0Hz

52h = 7.1Hz

53h = 7.2Hz

54h = 7.3Hz

55h = 7.4Hz

56h = 7.5Hz

57h = 7.6Hz

58h = 7.7Hz

59h = 7.8Hz

5Ah = 7.9Hz

5Bh = 8.0Hz

5Ch = 8.1Hz

5Dh = 8.2Hz

5Eh = 8.3Hz

5Fh = 8.4Hz

60h = 8.5Hz

61h = 8.6Hz

62h = 8.7Hz

63h = 8.8Hz

64h = 8.9Hz

65h = 9.0Hz

66h = 9.1Hz

67h = 9.2Hz

68h = 9.3Hz

69h = 9.4Hz

6Ah = 9.5Hz

6Bh = 9.6Hz

6Ch = 9.7Hz

6Dh = 9.8Hz

6Eh = 9.9Hz

6Fh = 10.0Hz

70h = 12.0Hz

71h = 14.0Hz

72h = 16.0Hz

73h = 18.0Hz

74h = 20.0Hz

Display Table #18

00h = Triangle

01h = Sine

02h = Sawtooth

03h = Square

04h = Asymm

05h = 16-Step

06h = 8-Step

07h = 4-Step

Display Table #19

00h = Uniform

01h = Linear+

02h = Linear-

03h = Exponential+

mrsysex.txt 10/10/2011 8:17 PM

Page 143 of 161

7866

7867

7868

7869

7870

7871

7872

7873

7874

7875

7876

7877

7878

7879

7880

7881

7882

7883

7884

7885

7886

7887

7888

7889

7890

7891

7892

7893

7894

7895

7896

7897

7898

7899

7900

7901

7902

7903

7904

7905

7906

7907

7908

7909

7910

7911

7912

7913

7914

7915

7916

7917

7918

7919

7920

04h = Exponential-

05h = Random

Display Table #20

00h = Centered

01h = Alternating

02h = L->R

03h = R->L

04h = Center->Out

05h = Out->Center

06h = Random

Display Table #21

00h = Soft

01h = Medium 1

02h = Medium 2

03h = Hard

04h = Buzz

Display Table #22

00h = OFF

01h = -99dB

02h = -98dB

03h = -97dB

04h = -96dB

05h = -95dB

06h = -94dB

07h = -93dB

08h = -92dB

09h = -91dB

0Ah = -90dB

0Bh = -89dB

0Ch = -88dB

0Dh = -87dB

0Eh = -86dB

0Fh = -85dB

10h = -84dB

11h = -83dB

12h = -82dB

13h = -81dB

14h = -80dB

15h = -79dB

16h = -78dB

17h = -77dB

18h = -76dB

19h = -75dB

1Ah = -74dB

1Bh = -73dB

1Ch = -72dB

1Dh = -71dB

1Eh = -70dB

1Fh = -69dB

mrsysex.txt 10/10/2011 8:17 PM

Page 144 of 161

7921

7922

7923

7924

7925

7926

7927

7928

7929

7930

7931

7932

7933

7934

7935

7936

7937

7938

7939

7940

7941

7942

7943

7944

7945

7946

7947

7948

7949

7950

7951

7952

7953

7954

7955

7956

7957

7958

7959

7960

7961

7962

7963

7964

7965

7966

7967

7968

7969

7970

7971

7972

7973

7974

7975

20h = -68dB

21h = -67dB

22h = -66dB

23h = -65dB

24h = -64dB

25h = -63dB

26h = -62dB

27h = -61dB

28h = -60dB

29h = -59dB

2Ah = -58dB

2Bh = -57dB

2Ch = -56dB

2Dh = -55dB

2Eh = -54dB

2Fh = -53dB

30h = -52dB

31h = -51dB

32h = -50dB

33h = -49dB

34h = -48dB

35h = -47dB

36h = -46dB

37h = -45dB

38h = -44dB

39h = -43dB

3Ah = -42dB

3Bh = -41dB

3Ch = -40dB

3Dh = -39dB

3Eh = -38dB

3Fh = -37dB

40h = -36dB

41h = -35dB

42h = -34dB

43h = -33dB

44h = -32dB

45h = -31dB

46h = -30dB

47h = -29dB

48h = -28dB

49h = -27dB

4Ah = -26dB

4Bh = -25dB

4Ch = -24dB

4Dh = -23dB

4Eh = -22dB

4Fh = -21dB

50h = -20dB

51h = -19dB

52h = -18dB

53h = -17dB

54h = -16dB

55h = -15dB

56h = -14dB

mrsysex.txt 10/10/2011 8:17 PM

Page 145 of 161

7976

7977

7978

7979

7980

7981

7982

7983

7984

7985

7986

7987

7988

7989

7990

7991

7992

7993

7994

7995

7996

7997

7998

7999

8000

8001

8002

8003

8004

8005

8006

8007

8008

8009

8010

8011

8012

8013

8014

8015

8016

8017

8018

8019

8020

8021

8022

8023

8024

8025

8026

8027

8028

8029

8030

57h = -13dB

58h = -12dB

59h = -11dB

5Ah = -10dB

5Bh = -09dB

5Ch = -08dB

5Dh = -07dB

5Eh = -06dB

5Fh = -05dB

60h = -04dB

61h = -03dB

62h = -02dB

63h = -01dB

64h = 00dB

Display Table #23

00h = ON

01h = OFF

Display Table #24

00h = Single

01h = Multi

Display Table #25

00h = -24 Semi

01h = -23 Semi

02h = -22 Semi

03h = -21 Semi

04h = -20 Semi

05h = -19 Semi

06h = -18 Semi

07h = -17 Semi

08h = -16 Semi

09h = -15 Semi

0Ah = -14 Semi

0Bh = -13 Semi

0Ch = -12 Semi

0Dh = -11 Semi

0Eh = -10 Semi

0Fh = -09 Semi

10h = -08 Semi

11h = -07 Semi

12h = -06 Semi

13h = -05 Semi

14h = -04 Semi

15h = -03 Semi

16h = -02 Semi

17h = -01 Semi

18h = 00 Semi

19h = +01 Semi

1Ah = +02 Semi

1Bh = +03 Semi

mrsysex.txt 10/10/2011 8:17 PM

Page 146 of 161

8031

8032

8033

8034

8035

8036

8037

8038

8039

8040

8041

8042

8043

8044

8045

8046

8047

8048

8049

8050

8051

8052

8053

8054

8055

8056

8057

8058

8059

8060

8061

8062

8063

8064

8065

8066

8067

8068

8069

8070

8071

8072

8073

8074

8075

8076

8077

8078

8079

8080

8081

8082

8083

8084

8085

1Ch = +04 Semi

1Dh = +05 Semi

1Eh = +06 Semi

1Fh = +07 Semi

20h = +08 Semi

21h = +09 Semi

22h = +10 Semi

23h = +11 Semi

24h = +12 Semi

25h = +13 Semi

26h = +14 Semi

27h = +15 Semi

28h = +16 Semi

29h = +17 Semi

2Ah = +18 Semi

2Bh = +19 Semi

2Ch = +20 Semi

2Dh = +21 Semi

2Eh = +22 Semi

2Fh = +23 Semi

30h = +24 Semi

Display Table #26

00h = -100Cent

01h = -99 Cent

02h = -98 Cent

03h = -97 Cent

04h = -96 Cent

05h = -95 Cent

06h = -94 Cent

07h = -93 Cent

08h = -92 Cent

09h = -91 Cent

0Ah = -90 Cent

0Bh = -89 Cent

0Ch = -88 Cent

0Dh = -87 Cent

0Eh = -86 Cent

0Fh = -85 Cent

10h = -84 Cent

11h = -83 Cent

12h = -82 Cent

13h = -81 Cent

14h = -80 Cent

15h = -79 Cent

16h = -78 Cent

17h = -77 Cent

18h = -76 Cent

19h = -75 Cent

1Ah = -74 Cent

1Bh = -73 Cent

1Ch = -72 Cent

1Dh = -71 Cent

1Eh = -70 Cent

mrsysex.txt 10/10/2011 8:17 PM

Page 147 of 161

8086

8087

8088

8089

8090

8091

8092

8093

8094

8095

8096

8097

8098

8099

8100

8101

8102

8103

8104

8105

8106

8107

8108

8109

8110

8111

8112

8113

8114

8115

8116

8117

8118

8119

8120

8121

8122

8123

8124

8125

8126

8127

8128

8129

8130

8131

8132

8133

8134

8135

8136

8137

8138

8139

8140

1Fh = -69 Cent

20h = -68 Cent

21h = -67 Cent

22h = -66 Cent

23h = -65 Cent

24h = -64 Cent

25h = -63 Cent

26h = -62 Cent

27h = -61 Cent

28h = -60 Cent

29h = -59 Cent

2Ah = -58 Cent

2Bh = -57 Cent

2Ch = -56 Cent

2Dh = -55 Cent

2Eh = -54 Cent

2Fh = -53 Cent

30h = -52 Cent

31h = -51 Cent

32h = -50 Cent

33h = -49 Cent

34h = -48 Cent

35h = -47 Cent

36h = -46 Cent

37h = -45 Cent

38h = -44 Cent

39h = -43 Cent

3Ah = -42 Cent

3Bh = -41 Cent

3Ch = -40 Cent

3Dh = -39 Cent

3Eh = -38 Cent

3Fh = -37 Cent

40h = -36 Cent

41h = -35 Cent

42h = -34 Cent

43h = -33 Cent

44h = -32 Cent

45h = -31 Cent

46h = -30 Cent

47h = -29 Cent

48h = -28 Cent

49h = -27 Cent

4Ah = -26 Cent

4Bh = -25 Cent

4Ch = -24 Cent

4Dh = -23 Cent

4Eh = -22 Cent

4Fh = -21 Cent

50h = -20 Cent

51h = -19 Cent

52h = -18 Cent

53h = -17 Cent

54h = -16 Cent

55h = -15 Cent

mrsysex.txt 10/10/2011 8:17 PM

Page 148 of 161

8141

8142

8143

8144

8145

8146

8147

8148

8149

8150

8151

8152

8153

8154

8155

8156

8157

8158

8159

8160

8161

8162

8163

8164

8165

8166

8167

8168

8169

8170

8171

8172

8173

8174

8175

8176

8177

8178

8179

8180

8181

8182

8183

8184

8185

8186

8187

8188

8189

8190

8191

8192

8193

8194

8195

56h = -14 Cent

57h = -13 Cent

58h = -12 Cent

59h = -11 Cent

5Ah = -10 Cent

5Bh = -09 Cent

5Ch = -08 Cent

5Dh = -07 Cent

5Eh = -06 Cent

5Fh = -05 Cent

60h = -04 Cent

61h = -03 Cent

62h = -02 Cent

63h = -01 Cent

64h = 00 Cent

65h = +01 Cent

66h = +02 Cent

67h = +03 Cent

68h = +04 Cent

69h = +05 Cent

6Ah = +06 Cent

6Bh = +07 Cent

6Ch = +08 Cent

6Dh = +09 Cent

6Eh = +10 Cent

6Fh = +11 Cent

70h = +12 Cent

71h = +13 Cent

72h = +14 Cent

73h = +15 Cent

74h = +16 Cent

75h = +17 Cent

76h = +18 Cent

77h = +19 Cent

78h = +20 Cent

79h = +21 Cent

7Ah = +22 Cent

7Bh = +23 Cent

7Ch = +24 Cent

7Dh = +25 Cent

7Eh = +26 Cent

7Fh = +27 Cent

80h = +28 Cent

81h = +29 Cent

82h = +30 Cent

83h = +31 Cent

84h = +32 Cent

85h = +33 Cent

86h = +34 Cent

87h = +35 Cent

88h = +36 Cent

89h = +37 Cent

8Ah = +38 Cent

8Bh = +39 Cent

8Ch = +40 Cent

mrsysex.txt 10/10/2011 8:17 PM

Page 149 of 161

8196

8197

8198

8199

8200

8201

8202

8203

8204

8205

8206

8207

8208

8209

8210

8211

8212

8213

8214

8215

8216

8217

8218

8219

8220

8221

8222

8223

8224

8225

8226

8227

8228

8229

8230

8231

8232

8233

8234

8235

8236

8237

8238

8239

8240

8241

8242

8243

8244

8245

8246

8247

8248

8249

8250

8Dh = +41 Cent

8Eh = +42 Cent

8Fh = +43 Cent

90h = +44 Cent

91h = +45 Cent

92h = +46 Cent

93h = +47 Cent

94h = +48 Cent

95h = +49 Cent

96h = +50 Cent

97h = +51 Cent

98h = +52 Cent

99h = +53 Cent

9Ah = +54 Cent

9Bh = +55 Cent

9Ch = +56 Cent

9Dh = +57 Cent

9Eh = +58 Cent

9Fh = +59 Cent

A0h = +60 Cent

A1h = +61 Cent

A2h = +62 Cent

A3h = +63 Cent

A4h = +64 Cent

A5h = +65 Cent

A6h = +66 Cent

A7h = +67 Cent

A8h = +68 Cent

A9h = +69 Cent

AAh = +70 Cent

ABh = +71 Cent

ACh = +72 Cent

ADh = +73 Cent

AEh = +74 Cent

AFh = +75 Cent

B0h = +76 Cent

B1h = +77 Cent

B2h = +78 Cent

B3h = +79 Cent

B4h = +80 Cent

B5h = +81 Cent

B6h = +82 Cent

B7h = +83 Cent

B8h = +84 Cent

B9h = +85 Cent

BAh = +86 Cent

BBh = +87 Cent

BCh = +88 Cent

BDh = +89 Cent

BEh = +90 Cent

BFh = +91 Cent

C0h = +92 Cent

C1h = +93 Cent

C2h = +94 Cent

C3h = +95 Cent

mrsysex.txt 10/10/2011 8:17 PM

Page 150 of 161

8251

8252

8253

8254

8255

8256

8257

8258

8259

8260

8261

8262

8263

8264

8265

8266

8267

8268

8269

8270

8271

8272

8273

8274

8275

8276

8277

8278

8279

8280

8281

8282

8283

8284

8285

8286

8287

8288

8289

8290

8291

8292

8293

8294

8295

8296

8297

8298

8299

8300

8301

8302

8303

8304

8305

C4h = +96 Cent

C5h = +97 Cent

C6h = +98 Cent

C7h = +99 Cent

C8h = +100Cent

Display Table #27

00h = 'A'

01h = 'E'

02h = 'I'

03h = 'O'

04h = 'U'

05h = 'AA'

06h = 'AE'

07h = 'AH'

08h = 'AO'

09h = 'EH'

0Ah = 'ER'

0Bh = 'IH'

0Ch = 'IY'

0Dh = 'UH'

0Eh = 'UW'

0Fh = 'B'

10h = 'D'

11h = 'F'

12h = 'G'

13h = 'J'

14h = 'K'

15h = 'L'

16h = 'M'

17h = 'N'

18h = 'P'

19h = 'R'

1Ah = 'S'

1Bh = 'T'

1Ch = 'V'

1Dh = 'Z'

Display Table #28

00h = Slow

01h = Fast

Display Table #29

00h = Stereo

01h = Mono

Display Table #30

00h = Full <Lo

01h = 99% <Lo

02h = 98% <Lo

03h = 96% <Lo

mrsysex.txt 10/10/2011 8:17 PM

Page 151 of 161

8306

8307

8308

8309

8310

8311

8312

8313

8314

8315

8316

8317

8318

8319

8320

8321

8322

8323

8324

8325

8326

8327

8328

8329

8330

8331

8332

8333

8334

8335

8336

8337

8338

8339

8340

8341

8342

8343

8344

8345

8346

8347

8348

8349

8350

8351

8352

8353

8354

8355

8356

8357

8358

8359

8360

04h = 94% <Lo

05h = 92% <Lo

06h = 90% <Lo

07h = 88% <Lo

08h = 86% <Lo

09h = 84% <Lo

0Ah = 82% <Lo

0Bh = 80% <Lo

0Ch = 78% <Lo

0Dh = 76% <Lo

0Eh = 74% <Lo

0Fh = 72% <Lo

10h = 70% <Lo

11h = 68% <Lo

12h = 66% <Lo

13h = 64% <Lo

14h = 62% <Lo

15h = 60% <Lo

16h = 58% <Lo

17h = 56% <Lo

18h = 54% <Lo

19h = 52% <Lo

1Ah = 50% <Lo

1Bh = 48% <Lo

1Ch = 46% <Lo

1Dh = 44% <Lo

1Eh = 42% <Lo

1Fh = 40% <Lo

20h = 38% <Lo

21h = 36% <Lo

22h = 34% <Lo

23h = 32% <Lo

24h = 30% <Lo

25h = 28% <Lo

26h = 26% <Lo

27h = 25% <Lo

28h = 24% <Lo

29h = 23% <Lo

2Ah = 22% <Lo

2Bh = 21% <Lo

2Ch = 20% <Lo

2Dh = 19% <Lo

2Eh = 18% <Lo

2Fh = 17% <Lo

30h = 16% <Lo

31h = 15% <Lo

32h = 14% <Lo

33h = 13% <Lo

34h = 12% <Lo

35h = 11% <Lo

36h = 10% <Lo

37h = 09% <Lo

38h = 08% <Lo

39h = 07% <Lo

3Ah = 06% <Lo

mrsysex.txt 10/10/2011 8:17 PM

Page 152 of 161

8361

8362

8363

8364

8365

8366

8367

8368

8369

8370

8371

8372

8373

8374

8375

8376

8377

8378

8379

8380

8381

8382

8383

8384

8385

8386

8387

8388

8389

8390

8391

8392

8393

8394

8395

8396

8397

8398

8399

8400

8401

8402

8403

8404

8405

8406

8407

8408

8409

8410

8411

8412

8413

8414

8415

3Bh = 05% <Lo

3Ch = 04% <Lo

3Dh = 03% <Lo

3Eh = 02% <Lo

3Fh = 01% <Lo

40h = Lo-Hi

41h = 01% >Hi

42h = 02% >Hi

43h = 03% >Hi

44h = 04% >Hi

45h = 05% >Hi

46h = 06% >Hi

47h = 07% >Hi

48h = 08% >Hi

49h = 09% >Hi

4Ah = 10% >Hi

4Bh = 11% >Hi

4Ch = 12% >Hi

4Dh = 13% >Hi

4Eh = 14% >Hi

4Fh = 15% >Hi

50h = 16% >Hi

51h = 17% >Hi

52h = 18% >Hi

53h = 19% >Hi

54h = 20% >Hi

55h = 21% >Hi

56h = 22% >Hi

57h = 23% >Hi

58h = 24% >Hi

59h = 25% >Hi

5Ah = 26% >Hi

5Bh = 28% >Hi

5Ch = 30% >Hi

5Dh = 32% >Hi

5Eh = 34% >Hi

5Fh = 36% >Hi

60h = 38% >Hi

61h = 40% >Hi

62h = 42% >Hi

63h = 44% >Hi

64h = 46% >Hi

65h = 48% >Hi

66h = 50% >Hi

67h = 52% >Hi

68h = 54% >Hi

69h = 56% >Hi

6Ah = 58% >Hi

6Bh = 60% >Hi

6Ch = 62% >Hi

6Dh = 64% >Hi

6Eh = 66% >Hi

6Fh = 68% >Hi

70h = 70% >Hi

71h = 72% >Hi

mrsysex.txt 10/10/2011 8:17 PM

Page 153 of 161

8416

8417

8418

8419

8420

8421

8422

8423

8424

8425

8426

8427

8428

8429

8430

8431

8432

8433

8434

8435

8436

8437

8438

8439

8440

8441

8442

8443

8444

8445

8446

8447

8448

8449

8450

8451

8452

8453

8454

8455

8456

8457

8458

8459

8460

8461

8462

8463

8464

8465

8466

8467

8468

8469

8470

72h = 74% >Hi

73h = 76% >Hi

74h = 78% >Hi

75h = 80% >Hi

76h = 82% >Hi

77h = 84% >Hi

78h = 86% >Hi

79h = 88% >Hi

7Ah = 90% >Hi

7Bh = 92% >Hi

7Ch = 94% >Hi

7Dh = 96% >Hi

7Eh = 98% >Hi

7Fh = Full >Hi

Display Table #31

00h = 100ms

01h = 200ms

02h = 300ms

03h = 400ms

04h = 500ms

05h = 600ms

06h = 700ms

07h = 800ms

08h = 900ms

09h = 1.0s

0Ah = 1.1s

0Bh = 1.2s

0Ch = 1.3s

0Dh = 1.4s

0Eh = 1.5s

0Fh = 1.6s

10h = 1.7s

11h = 1.8s

12h = 1.9s

13h = 2.0s

14h = 2.5s

15h = 3.0s

16h = 3.5s

17h = 4.0s

18h = 4.5s

19h = 5.0s

1Ah = 6.0s

1Bh = 7.0s

1Ch = 8.0s

1Dh = 9.0s

1Eh = 10.0s

Display Table #32

00h = 0.0Hz

01h = 0.2Hz

02h = 0.4Hz

03h = 0.6Hz

mrsysex.txt 10/10/2011 8:17 PM

Page 154 of 161

8471

8472

8473

8474

8475

8476

8477

8478

8479

8480

8481

8482

8483

8484

8485

8486

8487

8488

8489

8490

8491

8492

8493

8494

8495

8496

8497

8498

8499

8500

8501

8502

8503

8504

8505

8506

8507

8508

8509

8510

8511

8512

8513

8514

8515

8516

8517

8518

8519

8520

8521

8522

8523

8524

8525

04h = 0.8Hz

05h = 1.0Hz

06h = 1.2Hz

07h = 1.4Hz

08h = 1.6Hz

09h = 1.8Hz

0Ah = 2.0Hz

0Bh = 2.2Hz

0Ch = 2.4Hz

0Dh = 2.6Hz

0Eh = 2.8Hz

0Fh = 3.0Hz

10h = 3.2Hz

11h = 3.4Hz

12h = 3.6Hz

13h = 3.8Hz

14h = 4.0Hz

15h = 4.2Hz

16h = 4.4Hz

17h = 4.6Hz

18h = 4.8Hz

19h = 5.0Hz

1Ah = 5.2Hz

1Bh = 5.4Hz

1Ch = 5.6Hz

1Dh = 5.8Hz

1Eh = 6.0Hz

1Fh = 6.2Hz

20h = 6.4Hz

21h = 6.6Hz

22h = 6.8Hz

23h = 7.0Hz

24h = 7.2Hz

25h = 7.4Hz

26h = 7.6Hz

27h = 7.8Hz

28h = 8.0Hz

29h = 8.2Hz

2Ah = 8.4Hz

2Bh = 8.6Hz

2Ch = 8.8Hz

2Dh = 9.0Hz

2Eh = 9.2Hz

2Fh = 9.4Hz

30h = 9.6Hz

31h = 9.8Hz

32h = 10.0Hz

Display Table #33

00h = Normal

01h = Toggle

Display Table #34

mrsysex.txt 10/10/2011 8:17 PM

Page 155 of 161

8526

8527

8528

8529

8530

8531

8532

8533

8534

8535

8536

8537

8538

8539

8540

8541

8542

8543

8544

8545

8546

8547

8548

8549

8550

8551

8552

8553

8554

8555

8556

8557

8558

8559

8560

8561

8562

8563

8564

8565

8566

8567

8568

8569

8570

8571

8572

8573

8574

8575

8576

8577

8578

8579

8580

00h = 1.0:1

01h = 1.1:1

02h = 1.2:1

03h = 1.3:1

04h = 1.4:1

05h = 1.5:1

06h = 1.6:1

07h = 1.7:1

08h = 1.8:1

09h = 1.9:1

0Ah = 2.0:1

0Bh = 2.1:1

0Ch = 2.2:1

0Dh = 2.3:1

0Eh = 2.4:1

0Fh = 2.5:1

10h = 2.6:1

11h = 2.7:1

12h = 2.8:1

13h = 2.9:1

14h = 3.0:1

15h = 4.0:1

16h = 5.0:1

17h = 6.0:1

18h = 7.0:1

19h = 8.0:1

1Ah = 9.0:1

1Bh = 10:1

1Ch = 15:1

1Dh = 20:1

1Eh = 25:1

1Fh = 30:1

20h = 35:1

21h = 40:1

22h = INF:1

Appendix 6 - Breakdown of an Example Single Sound Program SysEx Dump

The following Single Sound Program Transmit Request message (See Section 3.1.2):

SysEx Data Bytes Internal Data Bytes Description

F0

System Exclusive Status Byte

0F

Ensoniq Manufacturer Code

09 MR Family ID Code

00

MR-Rack Model ID Code

00

Device ID Number = 0

03

Transmit Request Command

01

Single Sound Program Dump Request

7F

Program Number = 127

01 Bank Number = 1

F7

End of System Exclusive

will elicit the following response from the MR assuming that the factory pa

mrsysex.txt 10/10/2011 8:17 PM

Page 156 of 161

8581

8582

8583

8584

8585

8586

8587

8588

8589

8590

8591

8592

8593

8594

8595

8596

8597

8598

8599

8600

8601

8602

8603

8604

8605

8606

8607

8608

8609

8610

8611

8612

8613

8614

8615

8616

8617

8618

8619

8620

8621

8622

8623

8624

8625

8626

8627

8628

8629

8630

8631

8632

8633

8634

8635

SysEx Data Bytes Internal Data Bytes Description

F0

System Exclusive Status Byte

0F

Ensoniq Manufacturer Code

09 MR Family ID Code

00

MR-Rack Model ID Code

00 Device ID = 0

43

Transmit Request Reply Command

01

Single Sound Program Dump Request

7F

Program Number = 127

01 Bank Number = 1

2A 03 00 00 00 00 00 01 AA Data Block Size

2A 03 00 00 00 00 00 01 AA Sound Program Size

31 0E 49 02 05 50 52 47 31 'PRG1' in ASCII

18 00 00 00 00 00 00 00 18

Size of Table Of Contents

54 26 19 7A 04 4F 46 54 54 'OFTT' in ASCII

40 02 00 00 00 00 00 01 40 Effects Offset

20 00 00 00 00 00 00 00 20

Program Parameters Offset

44 00 00 00 00 00 00 00 44

Layer Offset Table Offset

00 00 00 00 00 00 00 00 00 Reserved

24 00 00 00 00 00 00 00 24

Sound Program Parameters Structure Size

31 20 1D 02 05 50 47 50 31 'PGP1' in ASCII

73 72 11 7B 04 4F 64 79 73 'Odys' in ASCII

4C 72 15 1B 07 73 65 79 4C 'seyL' in ASCII

00 48 05 2B 06 65 61 64 00 'ead ' in ASCII

00 00 00 00 00 00 00 00 00 ' ' in ASCII

00 04 08 00 00 00

Pitch Table = Equal Temper

02

Pitch Bend Up Range = 2 Up

02

Pitch Bend Down Range = 2 Down

00 Reserved

00 00 0C 00 00 00 Reserved

03

FX Bus = Medium Reverb

00 00 Reserved

08 00 00 38 05 57

GM Alias = Bass & Lead

00

Program Enables: Held Pitch Bend = OFF

00

Restrike Limit = Default

08

Sound Finder Catagory = Syn-Lead

48 00 00 00 00 00 00 00 48

Layer Offset Table Size

54 26 19 7A 04 4F 46 53 54 'OFST' in ASCII

0C 01 00 00 00 00 00 00 8C Layer #01 Offset

00 00 00 00 00 00 00 00 00 Layer #02 Offset

00 00 00 00 00 00 00 00 00 Layer #03 Offset

00 00 00 00 00 00 00 00 00 Layer #04 Offset

00 00 00 00 00 00 00 00 00 Layer #05 Offset

00 00 00 00 00 00 00 00 00 Layer #06 Offset

00 00 00 00 00 00 00 00 00 Layer #07 Offset

00 00 00 00 00 00 00 00 00 Layer #08 Offset

00 00 00 00 00 00 00 00 00 Layer #09 Offset

00 00 00 00 00 00 00 00 00 Layer #10 Offset

00 00 00 00 00 00 00 00 00 Layer #11 Offset

00 00 00 00 00 00 00 00 00 Layer #12 Offset

00 00 00 00 00 00 00 00 00 Layer #13 Offset

00 00 00 00 00 00 00 00 00 Layer #14 Offset

00 00 00 00 00 00 00 00 00 Layer #15 Offset

00 00 00 00 00 00 00 00 00 Layer #16 Offset

mrsysex.txt 10/10/2011 8:17 PM

Page 157 of 161

8636

8637

8638

8639

8640

8641

8642

8643

8644

8645

8646

8647

8648

8649

8650

8651

8652

8653

8654

8655

8656

8657

8658

8659

8660

8661

8662

8663

8664

8665

8666

8667

8668

8669

8670

8671

8672

8673

8674

8675

8676

8677

8678

8679

8680

8681

8682

8683

8684

8685

8686

8687

8688

8689

8690

34 01 00 00 00 00 00 00 B4

Layer #1 Parameter Structure Size

31 24 65 62 04 4C 59 52 31 'LYR1' in ASCII

00 02 00 00 00 00 00

Use Layer Number = 1

01

Layer Control = Enabled

00

Trigger Control = OFF

6C 20 02 78 07 7F

Controller High Threshold = 127

00

Controller Low Threshold = 0

90

Trigger Mode = Key Down

6C

High Keyboard Key Threshold = 108

00 00 7C 2B 01 15

Low Keyboard Key Threshold = 21

7F

High Note-On Velocity = 127

00

Low Note-On Velocity = 0

00

Layer Delay MSB = 00h

00 00 14 00 00 00

Layer Delay LSB = 00h

05 Volume = 5

00 Pan = 0

00 SemiTune = 0

03 00 04 00 00 00 Fine Tune = 0

01 Voice Mode = Mono

00 Glide Mode = OFF

03 Glide Time = 3

00 00 00 00 00 00 Key Group = OFF

00 00 00 Reserved

74 52 39 4B 04 49 6E 69 74 'Init' in ASCII

65 72 05 63 04 4C 61 79 65 'Laye' in ASCII

00 40 00 11 07 72 20 20 00 'r ' in ASCII

00 00 00 00 00 00 00 00 00 ' ' in ASCII

00 22 28 00 00 00

ENV1 Mod Amount = 0

0A

LFO Mod Amount = 10

11

Key Track = Pitch Table

00

Pitch Mod Source = OFF

01 00 00 00 00 00

Pitch Mod Amount = 0

00

Pitch Mod Range = 0

00 Reserved

01

Filter Mode = 3LP/1HP

42 00 14 00 00 00

Filter 1+2 Link = OFF

05

Filter 1 Cutoff = 5

00 Reserved

42

Filter 1 ENV2 Mod Amount = 66

3C 00 54 7B 00 0F

Filter 1 Cutoff Mod Source = Wheel+Pressure

75

Filter 1 Cutoff Mod Amount = 117

00

Filter 1 Cutoff Keyboard Tracking = OFF

3C

Filter 1 Cutoff Key

00 14 00 00 00 00 00 Reserved

0A

Filter 2 Cutoff = 10

00 Reserved

00 2E 3D 00 04 40

Filter 2 ENV2 Mod Amount = 64

0F

Filter 2 Cutoff Mod Source = Wheel+Pressure

57

Filter 2 Cutoff Mod Amount = 87

00

Filter 2 Cutoff Keyboard Tracking = OFF

00 00 00 60 03 3C

Filter 2 Cutoff Key

00 00 00 Reserved

7C 4B 0C 02 00 00

Waveform Number (MSB)

43

Waveform Number (LSB)

25

Waveform Checksum (LSB)

mrsysex.txt 10/10/2011 8:17 PM

Page 158 of 161

8691

8692

8693

8694

8695

8696

8697

8698

8699

8700

8701

8702

8703

8704

8705

8706

8707

8708

8709

8710

8711

8712

8713

8714

8715

8716

8717

8718

8719

8720

8721

8722

8723

8724

8725

8726

8727

8728

8729

8730

8731

8732

8733

8734

8735

8736

8737

8738

8739

8740

8741

8742

8743

8744

8745

FC

Waveform Checksum (MSB)

00 00 00 00 00 00

Playback Direction = Forward

00 Shift Amount = 0

00 Shift Mode = OFF

00 Start Index = 0

00 00 00 00 00 00

Waveform Mod Source = OFF

00

Waveform Mod Amount = 0

00 00 Reserved

00 00 00 00 00 00

Amplitude Mod Source = OFF

00

Amplitude Mod Amount = 0

00

Panning Mod Source = OFF

00

Panning Mod Amount = 0

00 00 70 01 00 00 Rolloff Slope = 0

3C

Rolloff Key Number = 60

00 Rolloff Mode = OFF

00 Reserved

00 00 00 02 00 00 Reserved

40 Noise Rate = 64

00 00 Reserved

00 00 7C 07 00 00 Reserved

FF MIDI Enables:

Pitch Bend = ON

Sustain = ON

00 Reserved

00

Noise Sync = Normal

31 2C 39 2A 04 45 4E 56 31 'ENV1' in ASCII

00 7E 01 00 00 00

Release Mod Amount = 0

00 Attack Time = 0

7F

Attack Peak Level = 127

00 Decay 1 Time = 0

00 7E 01 78 07 7F

Decay 1 Break Level = 127

00 Decay 2 Time = 0

7F

Decay 2 Break Level = 127

00 Decay 3 Time = 0

00 32 50 78 07 7F

Sustain Level = 127

14 Release Time = 20

19

Level Velocity = 25

00

Attack Velocity = 0

00 08 00 00 00 00 Key Scale = 0

00

Envelope Mode = Normal

04

Velocity Curve = Linear

00 Reserved

31 2C 39 2A 04 45 4E 56 31 'ENV1' in ASCII

07 7E 0D 00 00 00

Release Mod Amount = 0

03 Attack Time = 3

7F

Attack Peak Level = 127

07 Decay 1 Time = 7

4F 5A 41 29 06 65

Decay 1 Break Level = 101

30 Decay 2 Time = 48

6D

Decay 2 Break Level = 109

4F Decay 3 Time = 79

00 00 50 78 07 7F

Sustain Level = 127

14 Release Time = 20

00 Level Velocity = 0

00

Attack Velocity = 0

mrsysex.txt 10/10/2011 8:17 PM

Page 159 of 161

8746

8747

8748

8749

8750

8751

8752

8753

8754

8755

8756

8757

8758

8759

8760

8761

8762

8763

8764

8765

8766

8767

8768

8769

8770

8771

8772

8773

8774

8775

8776

8777

8778

8779

8780

8781

8782

8783

8784

8785

8786

8787

8788

8789

8790

8791

8792

8793

8794

8795

8796

8797

8798

8799

8800

00 08 00 00 00 00 Key Scale = 0

00

Envelope Mode = Normal

04

Velocity Curve = Linear

00 Reserved

31 2C 39 2A 04 45 4E 56 31 'ENV1' in ASCII

00 7E 01 00 00 00

Release Mod Amount = 0

00 Attack Time = 0

7F

Attack Peak Level = 127

00 Decay 1 Time = 0

4F 6A 19 19 07 73

Decay 1 Break Level = 115

26 Decay 2 Time = 38

75

Decay 2 Break Level = 117

4F Decay 3 Time = 79

00 00 50 78 07 7F

Sustain Level = 127

14 Release Time = 20

00 Level Velocity = 0

00

Attack Velocity = 0

00 08 00 00 00 00 Key Scale = 0

00

Envelope Mode = Normal

04

Velocity Curve = Linear

00 Reserved

31 1E 19 62 04 4C 46 4F 31 'LFO1' in ASCII

1C 02 01 00 00 00

Waveshape = Triangle

00 LFO Depth = 0

41 LFO Rate = 65

1C LFO Delay = 28

0F 7E 39 00 00 00 LFO Phase = 0

0E

LFO Depth Mod Source = Mod Wheel

7F

LFO Depth Mod Amount = 127

0F

LFO Rate Mod Source = Wheel+Pressure

00 00 00 38 0F F7

LFO Rate Mod Amount = -9

00

LFO Retrigger = OFF

00

LFO Timebase = Normal

00 Reserved

46 00 00 00 00 00 00 00 46

Insert Effect Structure Size

31 30 19 4A 04 49 46 58 31 'IFX1' in ASCII

00 00 00 00 00 00

Insert Mod Source = OFF

00

Insert Mod Dest = EQ Input

00 00

Mod Source Min = 0

00 00 7C 03 00 00 7F

Mod Source Max = 127

00 00 Mod Dest Min = OFF

00 00 70 03 00 00 7C

Mod Dest Max = +24dB

00

Chorus Mix = Full Dry

00 Reverb Send = 0

04 00 38 78 07 7F

Insert Mix = Full Wet

0E

Parameter Count = 14

00 04

Algorithm Family = 4

2D 70 08 00 00 00 02

Algorithm Member = 2

38 2D '8-' in ASCII

63 52 3D 33 05 56 6F 69 63 'Voic' in ASCII

6F 50 0D 2A 06 65 43 68 6F 'eCho' in ASCII

00 66 55 13 07 72 75 73 00 'rus ' in ASCII

64 00 00 00 00 00 00 ' ' in ASCII

00 64 EQ Input = 0.0db

56 00 00 03 00 00 60 EQ Output = -2.0dB

mrsysex.txt 10/10/2011 8:17 PM

Page 160 of 161

8801

8802

8803

8804

8805

8806

8807

8808

8809

8810

8811

8812

8813

8814

8815

8816

8817

8818

8819

8820

8821

8822

8823

8824

8825

8826

8827

8828

8829

8830

8831

8832

8833

8834

8835

8836

00 56 Mid 1 Fc = 5.60kHz

6D 00 28 00 00 00 0A Mid 1 Q = 1.0

00 6D Mid 1 Gain = +9db

28 00 30 00 00 00 0C LFO Rate = 1.2Hz

00 28

Chorus Depth = 4.0ms

00 00 38 00 00 00 0E

Chorus Center = 1.4ms

00 00 Unused FX Parm #08

40 00 1C 04 00 00 87

Chorus Phase = +90deg

00 40

Chorus Feedback = 0%

64 00 00 00 00 00 00 HPF Cutoff = 10Hz

00 64

Center Offset = 100%

00 00 04 02 00 00 41

Dry Blend = 50.8% Wet

00 00 Unused FX Parm #14

00 00 00 00 00 00 00 Unused FX Parm #15

00 00 Unused FX Parm #16

00 00 00 00 00 00 00 Unused FX Parm #17

00 00 Unused FX Parm #18

00 00 00 00 00 00 00 Unused FX Parm #19

00 00 Unused FX Parm #20

00 00 00 00 00 00 00 Unused FX Parm #21

00 00 Unused FX Parm #22

00 00 00 00 00 00 00 Unused FX Parm #23

00 00 Unused FX Parm #24

00 00 00 00 00 00 00 Unused FX Parm #25

00 00 Unused FX Parm #26

00 00 00 00 00 00 00 Unused FX Parm #27

00 00 Unused FX Parm #28

00 00 00 00 00 00 00 Unused FX Parm #29

00 00 Unused FX Parm #30

00 00 00 00 00 00 00 Unused FX Parm #31

00 00

4-to-5 Format Zero Padding

59 4D n/a Checksum = 4D59h

F7 n/a

End of System Exclusive

Part # 9311007101 Model # MM-132

mrsysex.txt 10/10/2011 8:17 PM

Page 161 of 161
