Page 1 (15)

Front page

Customer Care / Training & Vendor Development/ Content Creation Team

Confidential - Copyright © 2007 NOKIA Only for training and service purposes

Version: 1.0 19.10.2007 N82/ RM-313

RM-314

Board version: 2EY_31a

Service Schematics

RM-313/RM-314

IMPORTANT:

This document is intended for use by authorized NOKIA service centers only.

Introduction

“Service Schematics” was created with focus on customer care.

The purpose of this document is to provide further technical repair information for

NOKIA mobile phones on Level 3/4 service activities.

It contains additional information such as e.g. “Component finder”.

The “Signal overview” page gives a good and fast overview about the most

important signals and voltages on board.

Saving process time and improving the repair quality is the aim of this document.

It is to be used additionally to the service manual and other training

or service information such as Service Bulletins.

All measurements were made using following equipment:

Nokia repair SW : Phoenix version 2007.20.9.28808

Oscilloscope : Fluke PM 3380A/B

Spectrum Analyzer : Advantest R3162 with an analog probe

RF-Generator / GSM Tester : Rhode & Schwarz CMU 200

Multimeter : Fluke 73 Series II

While every endeavour has been made to ensure the accuracy of this document, some

errors may exist. If the reader finds any errors, NOKIA shall be notified in writing.

Copyright © NOKIA

This material, including documentation and any related computer programs is protected

by copyright, controlled by NOKIA. All rights are reserved. Copying, including reproducing,

modifying, storing, adapting or translating any or all of this material requires the prior

written consent of NOKIA. This material also contains companyconfidential information,

which may not be disclosed to others without the prior written consent of NOKIA.

Table of Content

1

2

3

4

5

6

7

8

9

AV connector

Front page

Camera, HWA

Menelaus, microSD

AVilma, Betty

Rapido, Memories, GPS

10

UI PWB

Display, Backlight, UI connector

WLAN, Bluetooth

OMAP

11

RF part RM-313

12

RF part RM-314

13

Signal overview

Please send E-Mail to: TrainingAndVendor.Development@nokia.com

14

Component finder RM-313

15

Component finder RM-314

HS_EAR_R

XEarL

HS_GND

MIC2P

FM Radio Production Test Pads

XEarR

HS_MIC

PLUG_DET

HS_EAR_L

AV CONNECTOR

AVPaEn

MIC2N

AVPlugDet

AVECICtrl

AVVideoCtrl

From OPA361 in APE. C2018 is for N2001

XEarRC

XEarLC

GND

2

C20341u0

VIO

J2034

E2004

1

14V/50V

R2008

18p

C2008

7

GND

L2002 220R/100MHz

C2030

1u0

J2033

GND

C20331u0

C2015

C2005

10n

2n7

R2007

14V/50V

R2005

15R

R2004

1

15R

E2001

1u0

C2036

C2032

GND

GND

1u0

600R/100MHz

L2004

C2031

2u2

GND

X2001

1

2

3

4

5

6

68nH

L2003

2

GND

C2004

2n7

RIGHTINM

D1

HPRIGHT

SCL D2

D3

SDA

D4

_SD

B1

B2 CPVSS

B3 LEFTINP

LEFTINM

B4

C1

VDD

C2

GNDRIGHTINP

C3

C4

TPA6130A2YZHR

N2000

CPN

A1

A2 CPP

A3

GND

VDD A4

HPLEFT

0R

R2012

E2006

1

27p

C2003

1

J2032

E2005

C2018

1u0

3

C2037

1u0

GND

C2002

27p

E2003

1

1u0

220R/100MHz

L2006

5

1

C2035

E2002

1

3

4

R2010

100k

VOUT

GND

GND

10k

0

VIO

14V/50V

R2009

7

GND

R2002

6

C2009

18p

J2030

GND

GND

L2001 220R/100MHz

C2014

10n

D3

D2= VOUT

GNDB2,C2=

IN1A1 A2

VIO

IN2A3

B1 NO1

B3 NO2

C1COM1

C3COM2

D1 NC1

NC2

1

TS5A26542

N2001

L2005 600R/100MHz

C2013

10n

GND

VOUT

GNDGND

GND

10k

R2006

FCI_CMT(3:0)

TVOUT_CONN_APE

FM_ANT

VBAT

0

XAUDIO(7:0)

AUDIOCTRL(5:0)

USB_ACI(7:0)

Rapido

OMAP

AVilma

GPS

BTHFM
