Administrator Guide

Administrator Guide

Administrator Guide: Open Build Service

by Karsten Keil

Publication Date: 01/02/2019

SUSE LLC

10 Canal Park Drive

Suite 200

Cambridge MA 02141

USA

https://www.suse.com/documentation

Permission is granted to copy, distribute and/or modify this document under the terms of the GNU Free

Documentation License, Version 1.2 or (at your option) version 1.3; with the Invariant Section being this

Free Documentation License”.

For SUSE trademarks, see http://www.suse.com/company/legal/ . All other third-party trademarks are the

property of their respective owners. Trademark symbols (®, ™ etc.) denote trademarks of SUSE and its

aliates. Asterisks (*) denote third-party trademarks.

All information found in this book has been compiled with utmost attention to detail. However, this does

not guarantee complete accuracy. Neither SUSE LLC, its aliates, the authors nor the translators shall be

held liable for possible errors or the consequences thereof.

Contents

About this Guide vi

1 Installation and Conﬁguration 1

1.1 Planning 1

Resource Planning 1

1.2 Simple Installation 2

Back-end Installation 2• Front-end Installation 6• Online

Conﬁguration 9

1.3 Worker Farm 12

1.4 Distributed Setup 13

1.5 Monitoring 16

Endpoint Checks 16 • Common Checks 17 • Other Checks 18

2 File System Overview 20

2.1 Conﬁguration Files 20

Front-end Conﬁguration 20 • Back-end Conﬁguration 29

2.2 Log Files 50

Front-end 50 • Back-end 50

2.3 /srv/obs Tree 51

build Directory 51 •cloudupload Directory 52 •db

Directory 52 •diffcache Directory 52 •events

Directory 52 •info Directory 53 •jobs Directory 53 •log

Directory 53 •projects Directory 53 •remotecache

Directory 53 •repos Directory 53 •repos_sync

Directory 53 •run Directory 54 •sources Directory 54 •trees

Directory 54 •upload Directory 54 •workers Directory 54

iii Administrator Guide

2.4 Metadata 55

OBS Revision Control 55 • Project Metadata 56 • Package

Metadata 58 • Attribute Metadata 58 • Job Files 59

3 Administration 61

3.1 Tools 61

obs_admin 61 •osc 64

3.2 Managing Build Targets 67

Interconnect 67 • Importing Distributions 68

3.3 Source Services 71

Using Services for Validation 72 • Dierent Modes When Using

Services 72 • Storage of Source Service Deﬁnitions 73 • Dropping a

Source Service Again 74

3.4 Dispatch Priorities 74

The /build/_dispatchprios API Call 75 •dispatch_adjust Array 76

3.5 Publisher Hooks 77

Conﬁguring Publisher Hooks 77 • Example Publisher Scripts 79

3.6 Unpublisher Hooks 80

Conﬁguring Unpublisher Hooks 81 • Example Unpublisher Scripts 82

3.7 Managing Users and Groups 84

User and Group Roles 84 • Standalone User and Group

Database 84 • Proxy Mode 85 • LDAP/Active

Directory 86 • Authentication Methods 92

3.8 Message Bus for Event Notiﬁcations 94

RabbitMQ 94

3.9 Backup 100

3.10 Spider Identiﬁcation 100

4 Troubleshooting 102

4.1 General Hints 102

4.2 Debugging Front-end Problems 103

iv Administrator Guide

A GNU Licenses 104

A.1 GNU General Public License 104

A.2 GNU Free Documentation License 106

vAdministrator Guide

About this Guide

This guide is part of the Open Build Service documentation. These books are considered to

contain only reviewed content, establishing the reference documentation of OBS.

This guide does not focus on a specic OBS version. It is also not a replacement of the

documentation inside of the openSUSE Wiki (https://en.opensuse.org/Portal:Build_Service) .

However, content from the wiki may be included in these books in a consolidated form.

1Available Documentation

The following documentation is available for OBS:

Administrator Guide

This guide oers information about the initial setup and maintenance for running Open

Build Service instances.

Article “Beginnerʼs Guide”

This guide describes basic workows for working with packages on Open Build Service.

This includes checking out a package from an upstream project, creating patches,

branching a repository, and more.

Book “Best Practice Guide”

This guide oers step-by-step instructions for the most common features of the Open Build

Service and the openSUSE Build Service.

Book “Reference Guide”

This guide covers ideas and motivations, concepts and processes of the Open Build Service

and also covers administration topics.

Book “User Guide”

This guide is intended for users and developers who want to dig deeper into Open Build

Service. It contains information on backgrounds, setting up your computer for working

with OBS, and usage scenarios.

vi Available Documentation

2Feedback

Several feedback channels are available:

Bugs and Enhancement Requests

Help for openSUSE is provided by the community. Refer to https://en.opensuse.org/

Portal:Support for more information.

Bug Reports

To report bugs for Open Build Service, go to https://bugzilla.opensuse.org/ , log in, and

click New.

Mail

For feedback on the documentation of this product, you can also send a mail to doc-

team@suse.com . Make sure to include the document title, the product version and the

publication date of the documentation. To report errors or suggest enhancements, provide

a concise description of the problem and refer to the respective section number and page

(or URL).

3Documentation Conventions

The following notices and typographical conventions are used in this documentation:

/etc/passwd : directory names and le names

PLACEHOLDER : replace PLACEHOLDER with the actual value

PATH : the environment variable PATH

ls , --help : commands, options, and parameters

user : users or groups

package name : name of a package

Alt

–

: a key to press or a key combination; keys are shown in uppercase as on

a keyboard

File, File Save As: menu items, buttons

Dancing Penguins (Chapter Penguins, ↑Another Manual): This is a reference to a chapter in

another manual.

vii Feedback

Commands that must be run with root privileges. Often you can also prex these

commands with the sudo command to run them as non-privileged user.

root # command

geeko > sudo command

Commands that can be run by non-privileged users.

geeko > command

Notices

Warning: Warning Notice

Vital information you must be aware of before proceeding. Warns you about security

issues, potential loss of data, damage to hardware, or physical hazards.

Important: Important Notice

Important information you should be aware of before proceeding.

Note: Note Notice

Additional information, for example about dierences in software versions.

Tip: Tip Notice

Helpful information, like a guideline or a piece of practical advice.

4Contributing to the Documentation

The OBS documentation is written by the community. And you can help too!

Especially as an advanced user or an administrator of OBS, there will be many topics where

you can pitch in even if your English is not the most polished. Conversely, if you are not very

experienced with OBS but your English is good: We rely on community editors to improve the

language.

viii Contributing to the Documentation

This guide is written in DocBook XML which can be converted to HTML or PDF documentation.

To clone the source of this guide, use Git:

git clone https://github.com/openSUSE/obs-docu.git

To learn how to validate and generate the OBS documentation, see the le README .

To submit changes, use GitHub pull requests:

1. Fork your own copy of the repository.

2. Commit your changes into the forked repository.

3. Create a pull request. This can be done at https://github.com/openSUSE/obs-docu .

It is even possible to host instance-specic content in the ocial Git repository, but it

needs to be tagged correctly. For example, parts of this documentation are tagged as <para

os="opensuse"> . In this case, the paragraph will only become visible when creating the

openSUSE version of a guide.

ix Contributing to the Documentation

1Installation and Conﬁguration

1.1 Planning

For testing an own OBS instance and for small setups like only packaging some scripts from

your administrators into RPMS and creating proper installation sources from them, the ready

to use obs-server appliance images are the easiest way. You can download them from http://

openbuildservice.org/download/ .

To use the OBS for your Linux software development with many packages, projects and users,

consider setting up an own installation. Depending on the number of users, projects, and

architectures, you can split up the back-end (called partitioning) and have separate hosts for

the front-end and the database.

But for most installations it is still OK to run everything but workers one host with enough

resources.

For exibility and if you want some kind of high availability it is recommended to use

virtualization for the dierent components.

1.1.1 Resource Planning

Normally for a small to middle installation a setup with everything except workers on one host

is sucient. You should have separate /srv volume for the back-end data, XFS as le system

is best choice.

For each scheduler architecture you should add 4 GB RAM and one CPU core. For each build

distribution you should add at least 50GB disk space per architecture.

A medium instance with about 50 users can easily run on a machine with 16GB RAM 4 cores

and 1 TB storage. The storage of course depend on the size of your projects and how often you

have new versions.

For bigger installations you can use separate networks for back-end communication, workers

and front-end.

1Planning

The reference installation on build.opensuse.org with lot of users, distributions runs on a

partitioned setup with:

a mysql cluster as database

api-server: 16GB RAM 4 cores 50GB disk

separate binary back-ends (scheduler, dispatcher, reposerver, publisher, warden)

source server 11 GB RAM, 4 cores, 3 TB disk (RAM used mainly for caching)

main back-end: 62 GB RAM (oversized), 16TB disk

lot of workers (see - https://build.opensuse.org/monitor )

For build time and performance the count and performance of available worker hosts more

important as the remaining parts.

1.2 Simple Installation

Simple installation means, all OBS services running on the same machine.

Important

It is very important that you read the README.SETUP le coming with your OBS version

and follow the instructions there, because here maybe changes to this version.

Before you start the installation of the OBS, you should make sure that your hosts have the

correct fully qualied hostname and DNS is working and can resolve all names.

1.2.1 Back-end Installation

The back-end hosts all sources and built packages. It also schedules the jobs. You need to install

the "obs-server" package for this. You need to check the /usr/lib/obs/server/BSCong.pm le,

but the defaults should be good enough for the simple case.

You can control the dierent back-end components via systemctl. Basically you can enable/

disable the service during booting the system and start/stop/restart it in a running system. For

more information, have a look at the systemctl man page (https://www.freedesktop.org/software/

systemd/man/systemctl.html#Commands) . For example, to restart the repository server use

2Simple Installation

systemctl restart obsrepserver.service

TABLE1.1:SERVICE NAMES

Component Service Name Remarks

Source Server obssrcserver.service

Repository Server obsrepserver.service

Source Services obsservice.service

Download obsdodup.service since 2.7

Delta Storage obsdeltastore.service since 2.7

Scheduler obsscheduler.service

Dispatcher obsdispatcher.service

Publisher obspublisher.service

Signer obssigner.service

Warden obswarden.service

Cloud upload

worker

obsclouduploadworker.service Only needed

for cloud

upload feature

Cloud upload

server

obsclouduploadserve.service Only needed

for cloud

upload feature

The sequence in the table reects the start sequence, you need to enable the services with

systemctl start <name>

rst and then you can start them:

systemctl start obssrcserver.service

systemctl start obsrepserver.service

systemctl start obsservice.service

3Back-end Installation

systemctl start obsdodup.service

systemctl start obsdeltastore.service

systemctl start obsscheduler.service

systemctl start obsdispatcher.service

systemctl start obspublisher.service

systemctl start obssigner.service

systemctl start obswarden.service

systemctl start obsclouduploadworker.service

systemctl start obsclouduploadserver.service

Warning

The commands start services which are accessible from the outside. Do not do this on a

system connected to an untrusted network or make sure to block the ports with a rewall.

1.2.1.1 Cloud Upload Setup

In order to setup the Cloud Upload feature you will need to congure the tools required per each

cloud provider. Right now we only support the AWS Amazon Cloud (https://aws.amazon.com )

and Microsoft Azure (https://portal.azure.com ) as providers.

1.2.1.1.1 Server setup

Before you can start uploading images to the Amazon Web Services (AWS) you have to:

1. Install the obs-cloud-uploader package

zypper in obs-cloud-uploader

2. Start the cloud upload services

rcobsclouduploadworker start

rcobsclouduploadserver start

At last you have to register the cloud uploader service in /usr/lib/obs/server/BSCong.pm, eg.

by adding following line:

our $clouduploadserver = "http://$hostname:5452";

Read more about conguring the backend in Section1.4, “Distributed Setup”.

4Back-end Installation

Warning

Ensure that the system time of your cloud uploader instance is correct. AWS is relying

on the timestamps of the requests it receives. Having an incorrect system time will cause

cloud uploads to fail.

1.2.1.1.2 AWS Amazon Cloud

1.2.1.1.2.1 Authentication Workﬂow

We are going to use the role based authentication provided by Amazon to enable the OBS

instance to upload images to other user's accounts.

The users will obtain an external ID (automatically created and unique) and the OBS account

ID to create an Identity and Access Management (IAM) role. After the user created the role, he

needs to provide the Amazon Resource Name (ARN) of the role to OBS. OBS will use this ARN

to obtain temporary credentials, therefore an uploader account is necessary which we need to

congure (see AWS authentication credentials setup). OBS will use the ARN to obtain temporary

credentials for the users account to upload the appliance. The ARN and the external ID are not

considered as a secret.

The whole workow is described in the AWS documentation (https://docs.aws.amazon.com/IAM/

latest/UserGuide/id_roles_create_for-user_externalid.html) .

1.2.1.1.2.2 Credentials Setup

For uploading images to AWS, OBS is using the AWS CLI (https://aws.amazon.com/cli) tool.

Before you can start uploading your images, you have to enter the AWS credentials to the

/etc/obs/cloudupload/.aws/credentials conguration le. These credentials will then be

used by OBS to retrieve the temporary credentials from the ARN provided by users. More

information about IAM role base authorization can be found in the Amazon documentation

(https://docs.aws.amazon.com/IAM/latest/UserGuide/id_roles_create_for-user_externalid.html) ).

5Back-end Installation

1.2.1.1.3 Microsoft Azure

1.2.1.1.3.1 Authentication Workﬂow

The authentication is done via Microsoft's Active Directory. The user has to create a new

application and needs to provide those two credentials to OBS:

1. Application ID

The Application ID is a unique ID that represents an Active Directory Application.

2. Application Key

The Application Key can be generated for every application and is the password.

OBS communicates with the REST API of Microsoft Azure to authenticate and upload images.

1.2.1.1.3.2 Conﬁguration

The Application ID and the Application Key will be stored encrypted in the database. As for

that, it's required to generate an SSL secret and public key that has to be stored on the server

where the obs-cloud-uploader package has been installed.

To generate that SSL certicate, execute the following commands:

cd /etc/obs/cloudupload

openssl genrsa -out secret.pem

openssl rsa -in secret.pem -out _pubkey -outform PEM -pubout

1.2.1.1.3.3 Credentials setup

It's important that the public key is named _pubkey and the secret key is named secret.pem

and are kept in /etc/obs/cloudupload.

1.2.2 Front-end Installation

You need to install the "obs-api" package for this and a MySQL server.

6Front-end Installation

1.2.2.1 MySQL Setup

Make sure that the mysql server is started on every system reboot (use "insserv mysql" for

permanent start). You should run mysql_secure_installation and follow the instructions.

Create the empty production databases:

# mysql -u root -p

mysql> create database api_production;

mysql> quit

Use a separate MySQL user (for example, obs ) for the OBS access:

# mysql -u root -p

mysql> create user 'obs'@'%' identified by 'TopSecretPassword';

mysql> create user 'obs'@'localhost' identified by 'TopSecretPassword';

mysql> GRANT all privileges ON api_production.*

TO 'obs'@'%', 'obs'@'localhost';

mysql> FLUSH PRIVILEGES;

mysql> quit

Congure your MySQL user and password in the "production" section of the api cong: /srv/

www/obs/api/cong/database.yml

Example:

# MySQL (default setup). Versions 4.1 and 5.0 are recommended.

# Get the fast C bindings:

# gem install mysql

# (on OS X: gem install mysql -- --include=/usr/local/lib)

# And be sure to use new-style password hashing:

# http://dev.mysql.com/doc/refman/5.0/en/old-client.html

production:

adapter: mysql2

database: api_production

username: obs

password: TopSecretPassword

encoding: utf8

timeout: 15

pool: 30

Now populate the database

cd /srv/www/obs/api/

7Front-end Installation

sudo RAILS_ENV="production" rake db:setup

sudo RAILS_ENV="production" rake writeconfiguration

sudo chown -R wwwrun.www log tmp

Now you are done with the database setup.

1.2.2.2 Apache Setup

Now we need to congure the Web server. By default, you can reach the familiar web user

interface and also api both on port 443 speaking https. Repositories can be accessed via http

on port 82 (once some packages are built). An overview page about your OBS instance can be

found behind 'http://localhost'.

The obs-api package comes with an Apache vhost le, which does not need to get modied

when you stay with these defaults: /etc/apache2/vhosts.d/obs.conf

Install the required packages via

zypper in obs-api apache2 apache2-mod_xforward rubygem-passenger-apache2 memcached

Add the following Apache modules in /etc/sysconfig/apache2 :

APACHE_MODULES="... passenger rewrite proxy proxy_http xforward headers socache_shmcb"

Enable SSL in /etc/syscong/apache2 via

APACHE_SERVER_FLAGS="SSL"

For production systems you should order ocial SSL certicates. For testing follow the

instructions to create a self signed SSL certicate:

mkdir /srv/obs/certs

openssl genrsa -out /srv/obs/certs/server.key 1024

openssl req -new -key /srv/obs/certs/server.key \

-out /srv/obs/certs/server.csr

openssl x509 -req -days 365 -in /srv/obs/certs/server.csr \

-signkey /srv/obs/certs/server.key -out /srv/obs/certs/server.crt

cat /srv/obs/certs/server.key /srv/obs/certs/server.crt \

> /srv/obs/certs/server.pem

To allow the usage of https API in Web UI code you need to trust your certicate as well:

cp /srv/obs/certs/server.pem /etc/ssl/certs/

8Front-end Installation

c_rehash /etc/ssl/certs/

1.2.2.3 API Conﬁguration

Check and edit /srv/www/obs/api/cong/options.yml

If you change the hostnames/ips of the api, you need to adjust frontend_host accordingly. If

you want to use LDAP, you need to change the LDAP settings as well. Look at the Section3.7,

“Managing Users and Groups” for details. You will nd examples and more details in the Section2.1,

“Conﬁguration Files”.

It is recommended to enable

use_xforward: true

as well here.

Afterwards you can start the OBS web api and make it permanent via

systemctl enable apache2

systemctl start apache2

systemctl enable obsapidelayed.service

systemctl start obsapidelayed.service

systemctl enable memcached.service

systemctl start memcached.service

Now you have you own empty instance running and you can do some online conguration steps.

1.2.3 Online Conﬁguration

To customize the OBS instance you may need to congure some settings via the OBS API and

Web user interface.

First you should change the password of the Admin account, for this you need rst login as user

Admin in the Web UI with the default password "opensuse". Click on the Admin link (right top

of the page), here you can change the password.

After changing the Admin password, set up osc to use the Admin account for more changes.

Here an example:

osc -c ~/.obsadmin_osc.rc -A https://api.testobs.org

Follow the instructions on the terminal.

9Online Conﬁguration

Warning

The password is stored in clear text in this le by default, so you need to give this le

restrictive access rights, only read/write access for your user should be allowed. osc

allows to store the password in other ways (in keyrings for example), refer to the osc

documentation for this.

Now you can check out the main conguration of the OBS:

osc -c ~/.obsadmin_osc.rc api /configuration >/tmp/obs.config

cat /tmp/obs.config

<title>Open Build Service</title>

The <a href="http://openbuildservice.org"> Open Build Service (OBS)</a>

is an open and complete distribution development platform that provides a

transparent

infrastructure for development of Linux distributions, used by openSUSE, MeeGo

and other distributions.

Supporting also Fedora, Debian, Ubuntu, RedHat and other Linux distributions.

The OBS is developed under the umbrella of the <a href="http://

www.opensuse.org">openSUSE project<

/a>. Please find further informations on the <

a href="http://wiki.opensuse.org/openSUSE:Build_Service">openSUSE Project wiki

pages</a>.

The Open Build Service developer team is greeting you. In case you use your OBS

productive

in your facility, please do us a favor and add yourself at <

a href="http://wiki.opensuse.org/openSUSE:Build_Service_installations">

this wiki page</a>. Have fun and fast build times!

</description>

<name>private</name>

<download_on_demand>on</download_on_demand>

<enforce_project_keys>off</enforce_project_keys>

<registration>allow</registration>

<default_access_disabled>off</default_access_disabled>

<allow_user_to_create_home_project>on</allow_user_to_create_home_project>

10 Online Conﬁguration

<disallow_group_creation>off</disallow_group_creation>

<change_password>on</change_password>

<hide_private_options>off</hide_private_options>

<cleanup_empty_projects>on</cleanup_empty_projects>

<disable_publish_for_branches>on</disable_publish_for_branches>

<admin_email>unconfigured@openbuildservice.org</admin_email>

<unlisted_projects_filter>^home:.+</unlisted_projects_filter>

<unlisted_projects_filter_description>home projects</

unlisted_projects_filter_description>

</schedulers>

</configuration>

Important

unlisted_projects_lter only admit Regular Expression (see RLIKE specications of

MySQL/MariaDB for more information) and unlisted_projects_lter_description is part

of the link shown in the project list for ltering

You should edit this le according to your preferences, then sent it back to the server:

osc -c ~/.obsadmin_osc.rc api /configuration -T /tmp/obs.config

If you want to use an interconnect to another OBS instance to reuse the build targets you can

do this as Admin via the Web UI or create a project with a remoteurl tag (see Section2.4.2,

“Project Metadata”)

<title>openSUSE.org Project</title>

This project refers to projects hosted on the Build Service

[...]

Use openSUSE.org:openSUSE:12.3 for example to build against the

openSUSE:12.3 project as specified on the opensuse.org Build Service.

</description>

<remoteurl>https://api.opensuse.org/public</remoteurl>

</project>

11 Online Conﬁguration

You can create the project using a le with the above content with osc like this:

osc -c ~/.obsadmin_osc.rc meta prj openSUSE.org -F /tmp/openSUSE.org.meta

You also can import binary distribution, see Section3.2.2, “Importing Distributions” for this.

The OBS has a list of available distributions used for build. This list is displayed to user, if they

are adding repositories to their projects. This list can be managed via the API path /distributions

osc -c ~/.obsadmin_osc.rc api /distributions > /tmp/distributions.xml

Example distributions.xml le:

<repository>standard</repository>

<icon url="https://static.opensuse.org/distributions/logos/suse-SLE-12-8.png"

width="8" height="8"/>

<icon url="https://static.opensuse.org/distributions/logos/suse-SLE-12-16.png"

width="16" height="16"/>

</distribution>

</distributions>

You can add your own distributions here and update the list on the server:

osc -c ~/.obsadmin_osc.rc api /distributions -T /tmp/distributions.xml

1.3 Worker Farm

To not burden your OBS back-end daemons with the unpredictable load package builds can

produce (think someone builds a monstrous package like LibreOce) you should not run OBS

workers on the same host as the rest of the back-end daemons.

12 Worker Farm

Important

You back-end need to be congured to use the correct hostnames for the repo and source

server and the ports need to be reachable by the workers. Also, the IP addresses of the

workers need to be allowed to connect the services. (look at the /usr/lib/obs/server/

BSCong.pm::ipaccess array).

You can deploy workers quite simply using the worker appliance. Or install a minimum system

plus the obs-worker package on the hardware.

Edit the /etc/syscong/obs-server le, at least OBS_SRC_SERVER, OBS_REPO_SERVERS and

OBS_WORKER_INSTANCES need to be set. More details in the Section2.1, “Conﬁguration Files”.

start the worker:

systemctl enable obsworker

systemctl start obsworker

1.4 Distributed Setup

All OBS back-end daemons can also be started on individual machines in your network. Also,

the front-end Web server and the MySQL server can run on dierent machines. Especially for

large scale OBS installations this is the recommended setup.

A setup with partitioning is very similar to the steps of the simple setup. Here we are only

mention the dierences to the simple setup.

Note

You need to make sure that the dierent machines can communicate via the network, it

is very recommended to use a separate network for this to isolate it from the public part.

On all back-end hosts you need to install the obs-server package. On the front-end host you need

to install the obs-api package.

Important

Only one source server instance can be exist on a single OBS installation.

13 Distributed Setup

The binary back-end can be split on project level, this is called partitioning.

On one partition following services needs to be congured and run:

1. repserver

2. schedulers

3. dispatcher

4. warden

5. publisher

You do not need to share any directories on File System level between the partitions.

Here some example for partitioning:

1. A main partition for everything not in the others (host mainbackend)

2. A home partition for all home projects of the users (host homebackend)

3. A release partition for released software projects (host releasebackend)

The conguration is done in the back-end cong le /usr/lib/obs/server/BSCong.pm. Most

parts of the le can be shared between the back-ends.

Here the important parts of the mainbackend of out testobs.org installation:

[...]

my $hostname = Net::Domain::hostfqdn() || 'localhost';

# IP corresponding to hostname (only used for $ipaccess); fallback to localhost since

inet_aton may fail to resolve at shutdown.

my $ip = quotemeta inet_ntoa(inet_aton($hostname) || inet_aton("localhost"));

my $frontend = 'api.testobs.org'; # FQDN of the Web UI/API server if it's not $hostname

# If defined, restrict access to the backend servers (bs_repserver, bs_srcserver,

bs_service)

our $ipaccess = {

'127\..*' => 'rw', # only the localhost can write to the backend

"^$ip" => 'rw', # Permit IP of FQDN

"10.20.1.100" => 'rw', # Permit IP of srcsrv.testobs.org

"10.20.1.101" => 'rw', # Permit IP of mainbackend.testobs.org

"10.20.1.102" => 'rw', # Permit IP of homebackend.testobs.org

"10.20.1.103" => 'rw', # Permit IP of releasebackend.testobs.org

'10.20.2.*' => 'worker', # build results can be delivered from any client in the

network

};

14 Distributed Setup

# IP of the Web UI/API Server (only used for $ipaccess)

if ($frontend) {

my $frontendip = quotemeta inet_ntoa(inet_aton($frontend) || inet_aton("localhost"));

$ipaccess->{$frontendip} = 'rw' ; # in dotted.quad format

}

# also change the SLP reg files in /etc/slp.reg.d/ when you touch hostname or port

our $srcserver = "http://srcsrv.testobs.org:5352";

our $reposerver = "http://mainbackend.testobs.org:5252";

our $serviceserver = "http://service.testobs.org:5152";

# Needed if you want to use the cloud upload feature

our $clouduploadserver = "http://$hostname:5452";

our @reposervers = ("

http://mainbackend.testobs.org:5252,

http://homebackend.testobs.org:5252,

http://releasebackend.testobs.org:5252

");

# you can use different ports for worker connections

our $workersrcserver = "http://w-srcsrv.testobs.org:5353";

our $workerreposerver = "http://w-mainbackend.testobs.org:5253";

[...]

our $partition = 'main';

# this defines how the projects are split. All home: projects are hosted

# on an own server in this example. Order is important.

our $partitioning = [

'home:' => 'home',

'release' => 'release'

'.*' => 'main',

];

our $partitionservers = {

'home' => 'http://homebackend.testobs.org:5252',

'release' => 'http://releasebackend.testobs.org:5252',

'main' => 'http://mainbackend.testobs.org:5252',

};

[...]

On the other partition server you need to change "our $reposerver", "our $workerreposerver"

and "our $partition".

On all partition servers you need to start:

systemctl start obsrepserver.service

15 Distributed Setup

systemctl start obsscheduler.service

systemctl start obsdispatcher.service

systemctl start obspublisher.service

systemctl start obswarden.service

On the worker machines you should set of repo servers in the OBS_REPO_SERVERS variable.

You can also dene workers with a subset of the repo servers to prioritize partitions.

1.5 Monitoring

In this chapter you will nd some general monitoring instructions for the Open Build Service. All

examples are based on Nagios plugins, but the information provided should be easily adaptable

for other monitoring solutions.

1.5.1 Endpoint Checks

1.5.1.1 HTTP Checks: Checking Whether the HTTP Server Responds

This check will output a critical if the HTTP server with ip address 172.19.19.19 (-I

172.19.19.19) listening on port 80 (-p 80) does not answer and output a warning if the HTTP

return code is not 200. The server name that will be used is server (-H server) which is important

if dierent virtual hosts are listening on the same port.

check_http -H server -I 172.19.19.19 -p 80 -u http://server

The same check, but this time it will check a ssl enabled HTTP server.

check_http -S -H server -I 172.19.19.19 -p 443 -u https://server

It is also possible to check the presence of a certain string in the HTTP response. In this case it

will check for the string Source Service Server.

check_http -s "Source Service Server" -S -H server -I 172.19.19.19 -p 5152

Open Build Service HTTP endpoints that should be checked:

1. Web Interface / API: port 443

2. Repository Server: port 82

16 Monitoring

3. Package Repository Server: port 5252

4. Source Repository Server: port 5352

5. Source Service Server: port 5152

6. Cloud Upload Server: port 5452

1.5.2 Common Checks

This is a list of common checks that should be run on each individual server.

1.5.2.1 Disk Space: Checking Available Disk Space

This check will output a warning if less than 10 percent disk space is available (-w 10) and

output a critical if less than 5 percent disk space are available (-c 5). It will check all le systems

except le systems with type none (-x none).

check_disk -w 10 -c 5 -x none

1.5.2.2 Memory Usage: Checking Available Memory

This check will output a warning if less than 10 percent memory is available (-w 10) and output

a critical if less than 5 percent memory is available (-c 5). OS caches will be counted as free

memory (-C) and it will check the available memory (-f). check_mem.pl is not a standard Nagios

plugin and can be downloaded at https://exchange.nagios.org/ .

check_mem.pl -f -C -w 10 -c 5

1.5.2.3 NTP: Checking Date and Time

This check will compare the local time with the time provided by the NTP server pool.ntp.org

(-H pool.ntp.org). It will output a warning if the time diers by 0.5 seconds (-w 0.5) and output

a critical if the time diers by 1 seconds (-c 1).

check_ntp_time -H pool.ntp.org -w 0.5 -c 1

17 Common Checks

1.5.2.4 Ping: Checking That the Server Is Alive

This plugin checks if the server responds to a ping request and it will output a warning if the

respond time exceeds 200ms or 30 percent package loss (-w 200.0,30%) and output a critical if

the respond time exceeds 500ms or 60 percent package loss.

check_icmp -H server -w 200.0,30% -c 500.0,60%

1.5.2.5 Load: Checking the Load on the Server

This check will output a warning if the load value exceeded 7.0 in the last minute, 6.0 in the

last 5 minutes or 5.0 in the last 15 minutes (-w 7.0,6.0,5.0). It will output a critical if the load

value exceeded 12.0 in the last minute, 8.0 in the last 5 minutes or 6.0 in the last 15 minutes

(-c 12.0,8.0,6.0).

check_load -w 7.0,6.0,5.0 -c 12.0,8.0,6.0

1.5.2.6 Disk Health: Checking the Health of Local Hard Disks

This check is only relevant on physical systems with local storage attached to it. It will check the

disk status utilizing the S.M.A.R.T interface and it will output a critical if any of the S.M.A.R.T

values exceeds critical limits. check_smartmon is not a standard Nagios plugin and can be

downloaded at https://exchange.nagios.org/ .

check_smartmon --drive /dev/sda --drive /dev/sdb

1.5.3 Other Checks

1.5.3.1 MySQL: Checking That the MySQL Database Is Responding

This check will check that the MySQL database server is running and that the database

api_production is available.

check_mysql -H localhost -u nagios -p xxxxxx -d api_production

18 Other Checks

MySQL Databases to check:

1. api_production

2. mysql

1.5.3.2 Backup Status: Checking That a Valid Backup Is Available

It is always advisable to check that the last backup run was successful and a recent backup is

available. The check itself depends on the Backup solution that is used.

19 Other Checks

2File System Overview

2.1 Conﬁguration Files

2.1.1 Front-end Conﬁguration

The front-end is congured with 4 les:

/srv/www/obs/api/cong/database.yml

/srv/www/obs/api/cong/options.yml

/srv/www/obs/api/cong/feature.yml

/etc/apache2/vhosts.d/obs.conf

2.1.1.1 database.yml

This le has the information needed to access the database. It contain credentials for the database

access and should be only readable by root and the group running the Web server (www).

The le has settings for the production, development and test ruby environment, for production

systems only the production section is important.

Example production section

production:

adapter: mysql2

database: api_production

username: obsapiuser

password: topsecret

encoding: utf8

timeout: 15

pool: 30

TABLE2.1:DATABASE CONFIGURATION KEYWORDS

keyword Description Remarks

adapter Database driver only mysql databases are supported

database Database name do not change !

20 Conﬁguration Files

keyword Description Remarks

username mysql user name database user, not a system user

password password for this user clear text

encoding codetable

timeout wait time in milliseconds

pool number of open connections

per thread

socket path to the mysql socket same host only

host IP address or hostname of the

mysql server

for remote servers

port port number of the mysql

server

for remote servers

2.1.1.2 options.yml

The conguration le /srv/www/obs/api/cong/options.yml is the default conguration le

for the Open Build Service Web UI and API. It contains conguration parameters for example

for back-end connections and connection to the API. Important are the congurations for source

and front-end hosts. The conguration for LDAP authentication is also located in this le.

Conguration options can be set per Rails environment (https://guides.rubyonrails.org/

conﬁguring.html#rails-environment-settings) or as generic conguration option dened in

default.

Note

We've updated the format of the options.yml after the release of OBS 2.9. Old conguration

les can be converted via

(cd /srv/www/obs/api/; rake migrate_options_yml)

21 Front-end Conﬁguration

Note

More and more congurations will be moved to the database and do not longer exist in

this le. The database conguration can be accessed via the API /conguration path.

TABLE2.2:options.yml CONFIGURATION ITEMS

Cong item Description Values default Remarks

use_xforward Use mod_xforward

module

true false Apache only, should

be true

use_nginx_redirect Use X-Accel-Redirect /

internal_redirect

Nginx only

min_votes_for_rating Minimum votes for a

rating

integer 3

response_schema_validationSet to true to verify

XML responses

comply to the schema

true false test/debug option

source_host back-end source

server host

localhost

source_port back-end source

server port

integer 5352

source_protocol back-end source

server protocol

http , https

front end_host Front-end host localhost

frontend_port Front-end port integer 443

frontend_protocol Front-end protocol http https

22 Front-end Conﬁguration

Cong item Description Values default Remarks

external_frontend_host External Front-end

host

if your users access

the hosts through a

proxy or dierent

name

external_frontend_port External Front-end

port

integer 443

external_frontend_protocol External Front-end

protocol

http https

extended_backend_log Extended back-end

log

true false test/debug option

proxy_auth_mode: turn proxy mode on/

o

:off :on see LDAP section

proxy_auth_test_user Test user coolguy test/debug option

proxy_auth_test_email Email of Test user coolguy@

example.com

test/debug option

global_write_through if set to false, the API

will only fake writes

to back-end

true false test/debug option

auto_cleanup_after_days not longer used 30 moved to /

conguration API

errbit_api_key API key of the

application

test/debug option

errbit_host installation of

errbit.com a Ruby

error catcher

test/debug option

23 Front-end Conﬁguration

Cong item Description Values default Remarks

errbit_api_key API key of the

application

test/debug option

ldap_mode: OBS LDAP mode on/

o

:off :on see LDAP section

Example options.yml

# This file contains the default configuration of the Open Build Service

# API.

default: &default

# Make use of mod_xforward module in apache

use_xforward: true

# Make use of X-Accel-Redirect for Nginx.

# http://kovyrin.net/2010/07/24/nginx-fu-x-accel-redirect-remote

#use_nginx_redirect: /internal_redirect

# Minimum count of rating votes a project/package needs to # be taken in

# account

# for global statistics:

min_votes_for_rating: 3

# Set to true to verify XML reponses comply to the schema

response_schema_validation: false

# backend source server

source_host: localhost

source_port: 5352

#source_protocol: https

# api access to this instance

frontend_host: localhost

frontend_port: 443

frontend_protocol: https

# if your users access the hosts through a proxy (or just a different name,

# use this to

# overwrite the settings for users)

#external_frontend_host: api.opensuse.org

#external_frontend_port: 443

#external_frontend_protocol: https

24 Front-end Conﬁguration

extended_backend_log: true

# proxy_auth_mode can be :off, :on or :simulate

proxy_auth_mode: :off

# ATTENTION: If proxy_auth_mode'is :on, the frontend takes the user

# name that is coming as headervalue X-username as a

# valid user does no further authentication. So take care...

proxy_auth_test_user: coolguy

proxy_auth_test_email: coolguy@example.com

# set this to enable auto cleanup requests after the given days

auto_cleanup_after_days: 30

#schema_location

#version

# if set to false, the API will only fake writes to backend (useful in

# testing)

# global_write_through: true

# see

# http://colszowka.heroku.com/2011/02/22/setting-up-your-custom-hoptoad-notifier-

endpoint-for-free-using-errbit-on-heroku

#errbit_api_key: api_key_of_your_app

#errbit_host: installation.of.errbit.com

production:

<<: *default

test:

<<: *default

source_host: backend

memcached_host: cache

development:

<<: *default

source_host: backend

memcached_host: cache

25 Front-end Conﬁguration

2.1.1.3 feature.yml

The conguration le /srv/www/obs/api/cong/feature.yml contains the default conguration

about features that can be enabled or disabled in Open Build Service.

TABLE2.3:feature.yml CONFIGURATION ITEMS

Cong item Description Values default Remarks

image_templates enable/disable image

template feature

true false see Reference Guide

for more information

kiwi_image_editor enable/disable Kiwi

Image Editor

true false

cloud_upload enable/disable Cloud

Upload setup

true false

Example feature.yml

production:

features: &default

image_templates: true

kiwi_image_editor: false

cloud_upload: false

development:

features:

<<: *default

kiwi_image_editor: true

cloud_upload: true

test:

features:

<<: *default

kiwi_image_editor: true

cloud_upload: true

2.1.1.4 Apache Virtual Host obs.conf

The Apache conguration depends on the Apache version and which extra options are used, so

use the documentation of the Apache version you are using.

26 Front-end Conﬁguration

Here, as an example, the standard conguration used by the appliance: Apache vhost example

Listen 82

# May needed on old distributions or after an update from them.

#Listen 443

# Passenger defaults

PassengerSpawnMethod "smart"

PassengerMaxPoolSize 20

#RailsEnv "development"

# allow long request urls and being part of headers

LimitRequestLine 20000

LimitRequestFieldsize 20000

# Just the overview page

# just give an overview about this OBS instance via static web page

DocumentRoot "/srv/www/obs/overview"

Options Indexes

Require all granted

</Directory>

</VirtualHost>

# Build Results

# The resulting repositories

DocumentRoot "/srv/obs/repos"

Options Indexes FollowSymLinks

Require all granted

</Directory>

</VirtualHost>

# OBS WEB UI & API

ServerName api

# General setup for the virtual host

DocumentRoot "/srv/www/obs/api/public"

ErrorLog /srv/www/obs/api/log/apache_error.log

TransferLog /srv/www/obs/api/log/apache_access.log

27 Front-end Conﬁguration

PassengerMinInstances 2

PassengerPreStart https://api

SSLEngine on

# SSL protocols

# Supporting TLS only is adequate nowadays

SSLProtocol all -SSLv2 -SSLv3

# SSL Cipher Suite:

# List the ciphers that the client is permitted to negotiate.

# We disable weak ciphers by default.

# See the mod_ssl documentation or "openssl ciphers -v" for a

# complete list.

SSLCipherSuite ALL:!aNULL:!eNULL:!SSLv2:!LOW:!EXP:!MD5:@STRENGTH

SSLCertificateFile /srv/obs/certs/server.crt

SSLCertificateKeyFile /srv/obs/certs/server.key

AllowOverride all

Options -MultiViews

# This requires mod_xforward loaded in apache

# Enable the usage via options.yml

# This will decrease the load due to long running requests a lot (unloading

from rails stack)

XForward on

Require all granted

</Directory>

SetEnvIf User-Agent ".*MSIE [1-5].*" \

nokeepalive ssl-unclean-shutdown \

downgrade-1.0 force-response-1.0

CustomLog /var/log/apache2/ssl_request_log ssl_combined

# from http://guides.rubyonrails.org/asset_pipeline.html

Header unset ETag

FileETag None

# RFC says only cache for 1 year

ExpiresActive On

ExpiresDefault "access plus 1 year"

28 Front-end Conﬁguration

</LocationMatch>

SetEnvIf User-Agent ".*MSIE [1-5].*" \

nokeepalive ssl-unclean-shutdown \

downgrade-1.0 force-response-1.0

## Older firefox versions needs this, otherwise it wont cache anything over SSL.

Header append Cache-Control "public"

</VirtualHost>

2.1.2 Back-end Conﬁguration

The Back-end is congured with 2 les:

/etc/syscong/obs-server - a shell script used for workers and the OBS start scripts

/usr/lib/obs/server/BSCong.pm - a perl script dening some global variables

2.1.2.1 /etc/sysconfig/obs-server

This script is used to set up the basic paths and the worker. the most important settings are the

OBS_SRC_SERVER and OBS_REPO_SERVERS and the OBS_WORKER_INSTANCES.

TABLE2.4:obs-server VARIABLES

Variable Description Values default Remarks

OBS_BACKENDCODE_DIR Path to the back-

end scripts

/usr/lib/obs/

server/

OBS_RUN_DIR communication

directory base

/srv/obs/run

OBS_LOG_DIR logging directory /srv/obs/log

OBS_BASE_DIR base directory /srv/obs

OBS_API_AUTOSETUP Automatically

setup API and Web

yes no appliance only,

will overwrite

cong les

29 Back-end Conﬁguration

Variable Description Values default Remarks

OBS_SRC_SERVER source server host localhost:5352 only one

OBS_REPO_SERVERS repository server

host

localhost:5252 maybe a list

OBS_WORKER_INSTANCES number of build

instances

integer 0

OBS_WORKER_INSTANCE

_NAMES

names of the

workers

space-separated

list

OBS_WORKER_DIRECTORY worker base

directory

/srv/obs

$bsuser OS user running the

back-end

obsrun

$bsgroup OS group running the

back-end

obsrun

$bsquotale Package quota for

projects

optional

$sched_asyncmode Use asynchronous

scheduler

Avoid issues with

remote projects on

slow networks

$sched_startupmode Cold start mode 0 1 2

$disable_data_sync fdatasync may cause data

corruption

$rundir back-end

communication

$bsdir/run

$logdir log directory $bsdir/log

$nosharedtrees Shared trees

0=shared 1=not

shared 2=not shared

with fallback

0 1 2optional for non-ACL

systems, should be

set for access control

42 Back-end Conﬁguration

Variable Description Values default Remarks

$packtrack enable binary release

tracking

[]

$limit_projects limit visibility of

projects for some

architectures

optional

$relsync_pool allow separation

of releasenumber

syncing per

architecture

$stageserver stage server rsync URI

$stageserver_sync Extra stage sync

server

rsync URI

$sign Path to sign script

$sign_project call sign with --

project <project>

0 1

$keyle Global sign key

$localarch Local architecture for

product building

$buildlog_maxsize worker max buildlog

size

'500 * 1000000' in bytes

$buildlog_maxidle Time with no

changes in the

buildlog will kill the

job

'8 * 3600' in sec

$xenstore_maxsize xenstore size '20 * 1000000' current XEN has no

xenstore anymore

43 Back-end Conﬁguration

Variable Description Values default Remarks

$gettimeout Max timeout for get '1 * 3600' in sec

$workerhostcheck check script for

worker

$powerhosts Worker with more

resources

obsolete use

constraints

$powerpkgs packages which need

workers with more

resources

obsolete use

constraints

$norootexceptions List of packages need

to build as root

$old_style_services Use old style source

service handling

0 1

$partition Current partition see Section1.4,

“Distributed Setup”

$partitioning Partition project

mapping

see Section1.4,

“Distributed Setup”

$partitionservers Partition server

mapping

see Section1.4,

“Distributed Setup”

$dispatch_adjust Adjust dispatch

priority

see Section3.4.2,

“dispatch_adjust

Array”

$publishedhook_use

_regex

Use regular

expressions in

publish hook map

0 1 see Section3.5,

“Publisher Hooks”

$publishedhook Publish hook map see Section3.5,

“Publisher Hooks”

44 Back-end Conﬁguration

Variable Description Values default Remarks

$unpublishedhook_use

_regex

Use regular

expressions in

unpublish hook map

0 1 see Section3.6,

“Unpublisher Hooks”

$unpublishedhook Unpublish hook map see Section3.6,

“Unpublisher Hooks”

Example BSCong.pm

# This program is free software; you can redistribute it and/or modify

# it under the terms of the GNU General Public License version 2 as

# published by the Free Software Foundation.

# This program is distributed in the hope that it will be useful,

# but WITHOUT ANY WARRANTY; without even the implied warranty of

# MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the

# GNU General Public License for more details.

# You should have received a copy of the GNU General Public License

# along with this program (see the file COPYING); if not, write to the

# Free Software Foundation, Inc.,

# 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA

################################################################

# Open Build Service Configuration

package BSConfig;

use Net::Domain;

use Socket;

my $hostname = Net::Domain::hostfqdn() || 'localhost';

# IP corresponding to hostname (only used for $ipaccess); fallback to localhost since

inet_aton may fail to resolve at shutdown.

my $ip = quotemeta inet_ntoa(inet_aton($hostname) || inet_aton("localhost"));

my $frontend = undef; # FQDN of the Web UI/API server if it's not $hostname

45 Back-end Conﬁguration

# If defined, restrict access to the backend servers (bs_repserver, bs_srcserver,

bs_service)

our $ipaccess = {

'127\..*' => 'rw', # only the localhost can write to the backend

"^$ip" => 'rw', # Permit IP of FQDN

'.*' => 'worker', # build results can be delivered from any client in the network

};

# IP of the Web UI/API Server (only used for $ipaccess)

if ($frontend) {

my $frontendip = quotemeta inet_ntoa(inet_aton($frontend) || inet_aton("localhost"));

$ipaccess->{$frontendip} = 'rw' ; # in dotted.quad format

}

# Also change the SLP reg files in /etc/slp.reg.d/ when you touch hostname or port

our $srcserver = "http://$hostname:5352";

our $reposerver = "http://$hostname:5252";

our $serviceserver = "http://$hostname:5152";

# you can use different ports for worker connections

#our $workersrcserver = "http://$hostname:5353";

#our $workerreposerver = "http://$hostname:5253";

our $servicedir = "/usr/lib/obs/service/";

#our $servicetempdir = "/var/temp/";

#our $serviceroot = "/opt/obs/MyServiceSystem";

# Maximum number of concurrent jobs for source service

#our $service_maxchild = 20;

our $gpg_standard_key = "/srv/obs/obs-default-gpg.asc";

# optional notification service:

#our $hermesserver = "http://$hostname/hermes";

#our $hermesnamespace = "OBS";

# Notification Plugin, multiple plugins supported, separated by space

#our $notification_plugin = "notify_hermes notify_rabbitmq";

# For the workers only, it is possible to define multiple repository servers here.

# But only one source server is possible yet.

our @reposervers = ("http://$hostname:5252");

# Package defaults

our $bsdir = '/srv/obs';

our $bsuser = 'obsrun';

our $bsgroup = 'obsrun';

46 Back-end Conﬁguration

#our $bsquotafile = '/srv/obs/quota.xml';

# Use asynchronus scheduler. This avoids hanging schedulers on remote projects,

# when the network is slow or broken. This will become the default in future

# our $sched_asyncmode = 1;

# Define how the scheduler does a cold start. The default (0) is to request the

# data for all packages, (1) means that only the non-remote packages are fetched,

# (2) means that all of the package data fetches get delayed.

# our $sched_startupmode = 0;

# Disable fdatasync calls, increases the speed, but may lead to data

# corruption on system crash when the filesystem does not guarantees

# data write before rename.

# It is esp. required on XFS filesystem.

# It is safe to be disabled on ext4 and btrfs filesystems.

#our $disable_data_sync = 1;

# Package rc script / backend communication + log files

our $rundir = "$bsdir/run";

our $logdir = "$bsdir/log";

# optional for non-acl systems, should be set for access control

# 0: trees are shared between projects (built-in default)

# 1: trees are not shared (only usable for new installations)

# 2: new trees are not shared, in case of a missing tree the shared

# location is also tried (package default)

our $nosharedtrees = 2;

# enable binary release tracking by default for release projects

our $packtrack = [];

# optional: limit visibility of projects for some architectures

#our $limit_projects = {

# "ppc" => [ "openSUSE:Factory", "FATE" ],

# "ppc64" => [ "openSUSE:Factory", "FATE" ],

#};

# optional: allow seperation of releasnumber syncing per architecture

# one counter pool for all ppc architectures, one for i586/x86_64,

# arm archs are separated and one for the rest in this example

our $relsync_pool = {

"local" => "local",

"i586" => "i586",

"x86_64" => "i586",

"ppc" => "ppc",

"ppc64" => "ppc",

47 Back-end Conﬁguration

"ppc64le" => "ppc",

"mips" => "mips",

"mips64" => "mips",

"mipsel" => "mipsel",

"mips64el" => "mipsel",

"aarch64" => "arm",

"aarch64_ilp32" => "arm",

"armv4l" => "arm",

"armv5l" => "arm",

"armv6l" => "arm",

"armv6hl" => "arm",

"armv7l" => "arm",

"armv7hl" => "arm",

"armv5el" => "armv5el", # they do not exist

"armv6el" => "armv6el",

"armv7el" => "armv7el",

"armv8el" => "armv8el",

"sparcv9" => "sparcv9",

"sparc64" => "sparcv9",

};

#No extra stage server sync

#our $stageserver = 'rsync://127.0.0.1/put-repos-main';

#our $stageserver_sync = 'rsync://127.0.0.1/trigger-repos-sync';

#No package signing server

our $sign = "/usr/bin/sign";

#Extend sign call with project name as argument "--project $NAME"

#our $sign_project = 1;

#Global sign key

our $keyfile = "/srv/obs/obs-default-gpg.asc";

# Use a special local arch for product building

# our $localarch = "x86_64";

# config options for the bs_worker

#our buildlog_maxsize = 500 * 1000000;

#our buildlog_maxidle = 8 * 3600;

#our xenstore_maxsize = 20 * 1000000;

#our gettimeout = 1 * 3600;

# run a script to check if the worker is good enough for the job

#our workerhostcheck = 'my_check_script';

# Allow to build as root, exceptions per package

# the keys are actually anchored regexes

48 Back-end Conﬁguration

# our $norootexceptions = { "my_project/my_package" => 1, "openSUSE:Factory.*/

installation-images" => 1 };

# Use old style source service handling

# our $old_style_services = 1;

###

# Optional support to split the binary backend. This can be used on large servers

# to separate projects for better scalability.

# There is still just one source server, but there can be multiple servers which

# run each repserver, schedulers, dispatcher, warden and publisher

# This repo service is the 'home' server for all home:* projects. This and the

# $reposerver setting must be different on the binary backend servers.

# our $partition = 'home';

# this defines how the projects are split. All home: projects are hosted

# on an own server in this example. Order is important.

# our $partitioning = [ 'home:' => 'home',

# '.*' => 'main',

# ];

# our $partitionservers = { 'home' => 'http://home-backend-server:5252',

# 'main' => 'http://main-backend-server:5252',

# };

# Publish hooks

our $publishedhook_use_regex = 1;

our $publishedhook = {

"Product\/SLES12" => "/usr/local/bin/script2run_sles12",

"Product\/SLES11.*" => "/usr/local/bin/script2run_sles11",

};

# host specific configs

my $hostconfig = __FILE__;

$hostconfig =~ s/[^\/]*$/bsconfig.$hostname/;

if (-r $hostconfig) {

print STDERR "reading $hostconfig...\n";

require $hostconfig;

}

49 Back-end Conﬁguration

2.2 Log Files

2.2.1 Front-end

The front-end log les are found under /srv/www/obs/api/log.

The following front-end log les exist:

apache_access.log - apache requests

apache_error.log - errors from apache

backend_access.log - API → backend requests

clockworkd.clock.output → timer event log

delayed_job.log → delayed job log

production.log→ main ruby log

production.searchd.log - search daemon log

production.searchd.query.log - search request logs

2.2.2 Back-end

The back-end log les are found by default under /srv/obs/log/.

The following back-end log les exist:

dispatcher.log - dispatcher log

dodup.log - download on demand log (since 2.7)

publisher.log - publisher log

rep_server.log - repo server log

scheduler_<arch>.log - scheduler log for each architecture

signer.log - sign service log

50 Log Files

src_server.log - source server log

src_service.log - source service daemon log

warden.log - warden log

clouduploadserver.log - cloud upload server log

clouduploadworker.log - cloud upload worker log

The following log les for the upload jobs exist inside the /srv/obs/cloudupload directory (also

linked in /bs/cloudupload):

<job_id>.log - log les for undone upload jobs

done/<job_id>.log - log les for already nished upload jobs

2.3 /srv/obs Tree

The default back-end data directory is located under /srv/obs/. Here are a bunch of

subdirectories used for communication between the dierent server, to store data, status

information and logs. Here is one le conguration.xml in the top directory, which stores the

global OBS conguration for the back-end. You should not modify this le directly, but use

the API /conguration interface instead, since this information needs to kept in sync with the

front-end.

2.3.1 build Directory

In this subdirectory managed by the repo server daemon, all repository data, metadata and build

results are stored in a hierarchical tree.

Example build directory tree of a binary imported distribution (OpenSUSE:13.2) and a small

test project with 3 packages:

├── openSUSE:13.2

│ └── standard

│ ├── i586

│ │ └── :full

│ └── x86_64

│ └── :full

51 /srv/obs Tree

├── Test1

│ └── os13.2

│ ├── i586

│ │ ├── :full

│ │ ├── :logfiles.fail

│ │ ├── :logfiles.success

│ │ ├── :meta

│ │ ├── :repo

│ │ ├── rsync

│ │ ├── srtp

│ │ └── wget

│ └── x86_64

│ ├── :full

│ ├── :logfiles.fail

│ ├── :logfiles.success

│ ├── :meta

│ ├── :repo

│ ├── rsync

│ ├── srtp

│ └── wget

2.3.2 cloudupload Directory

Info for cloud upload jobs is stored here, it has a subdir named done for storing the already

nished jobs.

2.3.3 db Directory

Back-end database root directory use by the source server, repo server scheduler and publisher.

Nobody should touch this.

2.3.4 diffcache Directory

Cache for source server compare operations.

2.3.5 events Directory

Communication between services.

52 cloudupload Directory

2.3.6 info Directory

Scheduler information managed by the scheduler and used by the repo server.

2.3.7 jobs Directory

The build jobs are stored in the /srv/obs/jobs directory. They are organized bybuild architecture:

jobs

├── armv7l

├── i586

├── load

└── x86_64

└── Release:Stable::SLE-12_GA::CI-demo-36db80552b735e193dced13f058f866f

The jobs/load le contains statistical data about the build jobs.

2.3.8 log Directory

Contains the log les of the back-end daemons.

2.3.9 projects Directory

Contains the project hierarchy and metadata under revision control.

2.3.10 remotecache Directory

Cache for remote repository information.

2.3.11 repos Directory

Directory managed by the publisher to collect build results, also used by the repo server and

scheduler to nd build results.

2.3.12 repos_sync Directory

Directory with les pointing to the project root directories, helper for publisher rsync.

53 info Directory

2.3.13 run Directory

State and lock information for the back-end daemons

2.3.14 sources Directory

All package sources under revision control in one directory per package, managed by the source

server. Package sources are by default deduplicated across all projects, as long a source le has

the same MD5 sum, it is only stored once. A pseudo '_project' package exist in the directory

containing the project metadata revisions. ':service' and ':upload' are temporary directories used

by the source server.

Example sources directory structure:

sources/

├── CI-demo

[...]

├── srtp

├── test1

├── _project

├── :service

└── :upload

2.3.15 trees Directory

Revision control data for project and packages, managed by the source server.

2.3.16 upload Directory

Temporary directory for uploading les for other back-end components.

2.3.17 workers Directory

Worker information

54 run Directory

2.4 Metadata

2.4.1 OBS Revision Control

This section gives a short generic overview how the revision information are stored in the OBS

back-end for packages and projects. The OBS back-end stores all les in a light weight content

based hierarchical tree. Each le is hashed (with MD5) and stored with the hash as part of

the lename under the /srv/obs/tree or /srv/obs/sources directories. The revision information is

stored in separate les by the Source Server in the /srv/obs/projects directory.

2.4.1.1 OBS revision control ﬁles

The revision information is stored in simple CSV like le format with a bar (|) as delimiter

between the 8 columns. The les do have the extension .rev for package/project revision data

and .mref for meta revision data. The hash then points to a <hash>-MD5SUMS le in the /srv/

obs/tree/ directories which have the le list with MD5 hashes of this revision. The hashes in this

le list are pointing to the source les in the /srv/obs/sources tree.

An example revision le:

1|1|56cdd3adb778089d1fcc49b92bb93e5b|0.9|1464005086|user4|initial version|

2|2|fe7aa1ade5c9d005de738c234c90bc90|0.9|1464005304|user4|fix spec file|

3|1|72c7986e694f45ab1a62779e64e92a8f|1.0|1464005339|user4|new version|

4|2|699e9931e6f167d78e65bbe5853f592f|1.0|1464006221|user4|add patch file|

5|1|0cfc3a2297f38d2aa9d8d0e98fc22a38|1.1|1464007797|user4|new version|

TABLE2.6:THE 8 COLUMNS

Column Content XML tag may empty

1 revision number ref no

2version revision

number vref yes

3 hash srcmd5 no

4 version version yes

5 time stamp time no

55 Metadata

Column Content XML tag may empty

6 user user no

7 commit message comment yes

8 request id requestid yes

Depending on the target (package, project or metadata) used, elds can be empty or have special

values, for example, unknown for the version.

Example MD5SUMS le

/srv/obs # cat trees/Test1/package1/56cdd3adb778089d1fcc49b92bb93e5b-MD5SUMS

0a17daaa913df9e50ee65e83a1898363 package1.spec

1f810b3521242a98333b7bbf6b2b7ef7 test1.sh

2.4.1.2 OBS Revision API

The revision info can be retrieved via API calls for the specic package, for example, using /

source/<project>/<package>/_history .

Specic revisions of les can be retrieved with the optional "rev=N" parameter, for example, /

source/<project>/<package>/<le>?rev=N.

On PUT and POST methods for les the optional "comment=some+comment" can be used to

set a commit message.

2.4.2 Project Metadata

Project metadata are XML les containing the meta project information, such as title,

description, related user and groups with roles, build settings, repository settings, publish

settings, debug settings and more.

TABLE2.7:PROJECT META XML

XML tag Attributes Content

project name project name

title Short description

56 Project Metadata

XML tag Attributes Content

description Developer information

person userid login name

person role role (maintainer, bugowner, …)

group groupid group name

group role role (maintainer, bugowner, …)

devel An optional devel project

build optional build ags

publish optional publish ags

useforbuild optional useforbuild ags

debuginfo optional debuginfo ags

binarydownload optional binarydownload ags

repository name name of the repository for build results

repository path project name of the source project for remaining

build requires

repository path repository name of repository in the source project

repository arch architecture name

remoteurl path to a remote OBS API for interconnect

Example project metadata:

<title>Test project 11</title>

<description>Project for demo</description>

57 Project Metadata

</repository>

</project>

2.4.3 Package Metadata

XML le about package meta information, like Title, description, related user and groups with

roles, build settings, publish settings, debug settings and more. Most XML tags are the same as

for projects.

Example package metadata:

<title>A test package for learning</title>

<description>An example test package for learning.

</description>

<build>

</build>

</publish>

</debuginfo>

</package>

2.4.4 Attribute Metadata

Attributes can be used to add special information to packages. Attributes can be used to trigger

special actions.

Example attribute data:

</attribute>

58 Package Metadata

</attribute>

</attributes>

2.4.5 Job Files

Jobs are stored by the scheduler in the /srv/obs/jobs directory and contain the build

setup information for the package, for example, a reference to the exact source version, build

dependencies, build repository information, timestamps.

Sample job le:

<buildinfo project="Release:Stable" repository="SLE-12_GA" package="CI-demo"

srcserver="http://obs.b1-systems.de:5352"

reposerver="http://obs.b1-systems.de:5252">

<job>Release:Stable::SLE-12_GA::

CI-demo-36db80552b735e193dced13f058f866f</job>

<disturl>obs://b1-systems.de/Release:Stable/SLE-12_GA/

36db80552b735e193dced13f058f866f-CI-demo</disturl>

<reason>new build</reason>

<prjconfconstraint>linux:version:min 3.0.0</prjconfconstraint>

59 Job Files

[...]

<path project="Release:Stable" repository="SLE-12_GA"

server="http://obs.b1-systems.de:5252" />

<path project="SUSE:SLE-12:GA" repository="standard"

server="http://obs.b1-systems.de:5252" />

</buildinfo>

60 Job Files

3Administration

3.1 Tools

3.1.1 obs_admin

obs_admin is a command-line tool used on the back-end server(s) to manage running services,

submit maintenance tasks, and debug problems. It should be only used by experienced admins.

It has built-in help which you can display with obs_admin --help.

Options to control the running services:

Job Controlling

===============

--shutdown-scheduler <architecture>

Stops the scheduler nicely with dumping out its current state

for fast startup.

--check-project <project> <architecture>

--check-project <project> <repository> <architecture>

--check-all-projects <architecture>

Check status of a project and its repositories again

--deep-check-project <project> <architecture>

--deep-check-project <project> <repository> <architecture>

Check status of a project and its repositories again

This deep check also includes the sources, in case of lost events.

--check-package <project> <package> <architecture>

Check status of a package in all repositories

--publish-repository <project> <repository>

Creates an event for the publisher. The scheduler is NOT scanning for new packages.

The publisher may skip the event, if nothing has changed.

Use --republish-repository when you want to enforce a publish.

--unpublish-repository <project> <repository>

Removes the prepared :repo collection and let the publisher remove the result. This

is also updating the search database.

WARNING: this works also for locked projects!

61 Tools

--prefer-publish-event <name>

prefers a publish event to be next. <name> is the file name inside of the publish

event directory.

--republish-repository <project> <repository>

enforce to publish a repository

--rebuild-full-tree <project> <repository> <arch>

rebuild the content of :full/ directory

--clone-repository <source project> <source repository> <destination repository>

--clone-repository <source project> <source repository> <destination project>

Clone an existing repo into another existing repository.

Usefull for creating snapshots.

--rescan-repository <project> <repository> <architecture>

Asks the scheduler to scan a repository for new packages and add

them to the cache file.

--force-check-project <project> <repository> <architecture>

Enforces the check of an repository, even when it is currently blocked due to amount

calculating time.

--create-patchinfo-from-updateinfo

creates a patchinfo submission based on an updateinfo information.

Options for maintenance are:

Maintenance Tasks

=================

Note: the --update-*-db calls are usually only needed when corrupt data has been created,

for

example after a file system corruption.

--update-source-db [<project>]

Update the index for all source files.

--update-request-db

Updates the index for all requests.

--remove-old-sources <days> <y> (--debug)

WARNING: this is an experimental feature atm. It may trash your data, but you have

anyway

a backup, right?

remove sources older than <x> days, but keep <y> number of revisions

62 obs_admin

--debug for debug output

Options for debugging:

Debug Options

=============

--dump-cache <project> <repository> <architecture>

Dumps out the content of a binary cache file.

This shows all the content of a repository, including all provides

and requires.

--dump-state <architecture>

--dump-project-from-state <project> <arch>

dump the state of a project.

--dump-relsync <file>

To dump content of :relsync files.

--set-relsync <file> <key> <value>

Modify key content in a a :relsync file.

--check-meta-xml <project>

--check-meta-xml <project> <package>

Is parsing a project or package xml file and puts out error messages, in case of

errors.

--check-product-xml <file>

Is parsing a product xml file and puts out error messages, in case of errors.

It does expand all xi:include references and validates the result.

--check-product-group-xml <file>

Is parsing a group xml file from a product definition and puts out error messages, in

case of errors.

--check-kiwi-xml <file>

--check-kiwi-xml <project> <package>

Is parsing a KIWI xml file and puts out error messages, in case of errors.

--check-constraints <file>

--check-constraints <project> <package>

Validates a _constraints file

--check-pattern-xml <file>

Is parsing a pattern xml file and puts out error messages, in case of errors.

--check-request-xml <file>

63 obs_admin

Is parsing a request xml file and puts out error messages, in case of errors.

--parse-build-desc <file> [<arch> [<buildconfigfile>]]

Parse a spec, dsc or KIWI file with the Build script parser.

--show-scheduler-architectures

Show all architectures which are configured in configuration.xml to be supported by

this instance.

--show-delta-file <file>

Show all instructions of a OBS delta file

--show-delta-store <file>

Show delta store statistics

3.1.2 osc

The osc command-line client is mainly used by developers and packagers. But for some tasks,

admin people also need this tool. It too has builtin help: use osc --help. The tool needs to be

congured rst to know the OBS API URL and your user details.

To congure the osc tool the rst time you need to call it with

osc -A <URL to the OBS API>

For example:

osc -A https://api.testobs.org

Follow the instructions on the terminal.

Warning

The password is stored in clear text in the .oscrc le by default, so you need to give

this le restrictive access rights, only read/write access for your user should be allowed.

osc allows to store the password in other ways (in keyrings for example) and may use

dierent methods for authentication like Kerberos see Section3.7.5.2, “Kerberos”

For the admins the most important osc subcommands are:

meta - to create or update projects or package data

API - to read and write online conguration data

64 osc

3.1.2.1 osc meta Subcommand

meta: Show meta information, or edit it

Show or edit build service metadata of type <prj|pkg|prjconf|user|pattern>.

This command displays metadata on buildservice objects like projects,

packages, or users. The type of metadata is specified by the word after

"meta", like e.g. "meta prj".

prj denotes metadata of a buildservice project.

prjconf denotes the (build) configuration of a project.

pkg denotes metadata of a buildservice package.

user denotes the metadata of a user.

pattern denotes installation patterns defined for a project.

To list patterns, use 'osc meta pattern PRJ'. An additional argument

will be the pattern file to view or edit.

With the --edit switch, the metadata can be edited. Per default, osc

opens the program specified by the environmental variable EDITOR with a

temporary file. Alternatively, content to be saved can be supplied via

the --file switch. If the argument is '-', input is taken from stdin:

osc meta prjconf home:user | sed ... | osc meta prjconf home:user -F -

For meta prj and prjconf updates optional commit messages can be applied

with --message.

When trying to edit a non-existing resource, it is created implicitly.

Examples:

osc meta prj PRJ

osc meta pkg PRJ PKG

osc meta pkg PRJ PKG -e

Usage:

osc meta <prj|prjconf> [-r|--revision REV] ARGS...

osc meta <prj|pkg|prjconf|user|pattern> ARGS...

ARGS...

ARGS...

osc meta pattern --delete PRJ PATTERN

osc meta attribute PRJ [PKG [SUBPACKAGE]] [--attribute ATTRIBUTE]

[--create|--delete|--set [value_list]]

Options:

65 osc

-h, --help show this help message and exit

--delete delete a pattern or attribute

-s ATTRIBUTE_VALUES, --set=ATTRIBUTE_VALUES

set attribute values

-R, --remove-linking-repositories

Try to remove also all repositories building against

remove ones.

-c, --create create attribute without values

-e, --edit edit metadata

-m TEXT, --message=TEXT

specify log message TEXT. For prj and prjconf meta

only

-r REV, --revision=REV

checkout given revision instead of head revision.

For

prj and prjconf meta only

-F FILE, --file=FILE

read metadata from FILE, instead of opening an

editor.

'-' denotes standard input.

-f, --force force the save operation, allows one to ignores some

errors like depending repositories. For prj meta

only.

--attribute-project

include project values, if missing in packages

--attribute-defaults

include defined attribute defaults

-a ATTRIBUTE, --attribute=ATTRIBUTE

affect only a given attribute

3.1.2.2 osc api Subcommand

api: Issue an arbitrary request to the API

Useful for testing.

URL can be specified either partially (only the path component), or fully

with URL scheme and hostname ('http://...').

Note the global -A and -H options (see osc help).

Examples:

osc api /source/home:user

osc api -X PUT -T /etc/fstab source/home:user/test5/myfstab

osc api -e /configuration

66 osc

Usage:

osc api URL

Options:

-h, --help show this help message and exit

-a NAME STRING, --add-header=NAME STRING

add the specified header to the request

-T FILE, -f FILE, --file=FILE

specify filename to upload, uses PUT mode by default

-d STRING, --data=STRING

specify string data for e.g. POST

-e, --edit GET, edit and PUT the location

-X HTTP_METHOD, -m HTTP_METHOD, --method=HTTP_METHOD

specify HTTP method to use (GET|PUT|DELETE|POST)

The online API documentation is available at https://build.opensuse.org/apidocs

Some examples for admin stu:

# Read the global configuration file

osc api /configuration

# Update the global configuration

osc api /configuration -T /tmp/configuration.xml

# Read the distributions list

osc api /distributions

# Udate the distributions list

osc api /distributions -T /tmp/distributions.xml

# retrieve statistics

osc api /statistics/latest_added

3.2 Managing Build Targets

3.2.1 Interconnect

Using another Open Build Service as source for build targets is the easiest way to start. The

advantage is, that you save local resources and you do not need to build everything from scratch.

The disadvantage is that you depend on the remote instance, if it has a downtime your instance

cannot do any builds for these targets, if the remote admins decide to remove some targets you

cannot use them anymore.

67 Managing Build Targets

The easiest way to interconnect with some of the public OBS instances is to use the Web UI. You

need to log in with an administrator account of your instance to do this. On the start page of an

administrator account you will nd a Conguration link. On the Conguration page you nd

an Interconnect tab on the top, use this and select the public side you want.

If you want to connect to a not listed instance, you can simple create a remote project using

the osc meta prj command. A remote project diers from a local project as it has a remoteurl

tag (see Section2.4.2, “Project Metadata”).

Example:

<title>openSUSE.org Project Link</title>

This project refers to projects hosted on the openSUSE Build Service

</description>

<remoteurl>https://api.opensuse.org/public</remoteurl>

</project>

Sending this via osc to the server:

osc meta prj -m "add openSUSE.org remote" -F /tmp/openSUSE.org.prj

3.2.2 Importing Distributions

With local hosted distributions packages you are independent from other parties. On sides

with no or bad internet connections, this is the only way to go. You do not need to build the

distribution packages on your instance, you can use binary packages for this. Here are dierent

ways to get a local build repository:

1. mirror a distribution from another OBS instance

2. mirror a binary distribution from a public mirror and import the binaries

3. use already existing local install repositories (for example, from an SMT instance)

4. use the install media to import the binaries

These tasks need to be run on the obs back-end. In a partition setup you need to run it on the

partition which would the owner for the project.

68 Importing Distributions

3.2.2.1 Mirroring from a Remote OBS Instance

Mirroring a project from a remote OBS instance can be done with the obs_mirror_project

script which is supplied with the obs sources and via the obs-utils package. You can get

the latest version from GitHub: https://raw.githubusercontent.com/openSUSE/open-build-service/

master/dist/obs_mirror_project .

The usage:

____________________________________________________________________________________

Usage: obs_mirror_project.rb -p PROJECT -r REPOSITORY

[-a ARCHITECTURE] [-d DESTINATION] [-A APIURL] [-t] [-v]

Example: (mirror openSUSE 13.1 as base distro)

obs_mirror_project -p openSUSE:13.1 -r standard -a i586,x86_64

____________________________________________________________________________________

Options help:

-p, --proj PROJECT Project Name: eg. openSUSE:13.1,Ubuntu:14.04,etc.

-r, --repo REPOSITORY Repository Name: eg. standard,qemu,etc.

-a, --arch Architecture Architecture Name: eg. i586,x86_64,etc.

-d, --dest DESTINATION Destination Path: eg. /obs

Default: PWD (current working directory)

-A, --api APIURL OSC API URL :Default: https://api.opensuse.org

-t, --trialrun Trial run: not executing actions

-v, --verbose Verbose

-h, --help Display this screen

3.2.2.2 Importing Binary Packages

This is the same procedure for all local sources. If you have a local copy of a distribution, you

can either use symbolic links to the binary packages or copy them in a directory on the back-end

repo server under the /srv/obs/build directory. You should follow the common name schema

for build repository here. As rst step you should create an empty project for the distribution,

you can use the Web UI or the osc command-line tool. Then you add a repository with the

name standard and the build architectures you want. Here an example project meta le:

<title>openSUSE 13.2 build repositories</title>

<description>openSUSE 13.2 build repositories</description>

<build>

</build>

69 Importing Distributions

</publish>

</repository>

</project>

After you have created the project with these settings, the /srv/obs/build directory should have

a tree for SUSE:13.2:

/srv/obs/

├── build

│ └── SUSE:13.2

│ └── standard

│ ├── i586

│ │ ├── :bininfo

│ │ └── :schedulerstate

│ └── x86_64

│ ├── :bininfo

│ └── :schedulerstate

Warning

All the directories under /srv/obs/build have to be owned by the obsrun user and group.

The obsrun user need write access to them. If not the scheduler process will crash

on your instance.

You need to import the project conguration as well, you can get them for example from the

openSUSE Build Service.

osc -A https://api.opensuse.org meta prjconf openSUSE:13.2 >/tmp/13.2.prjconf

osc meta prjconf -m 'Original version from openSUSE' SUSE:13.2 -F /tmp/13.2.prjconf

Now you need to create the directory ':full' for the binary sources under each architecture, this

should be owned by obsrun too.

testobs:/srv/www/obs/api # mkdir /srv/obs/build/SUSE\:13.2/standard/i586/:full

testobs:/srv/www/obs/api # mkdir /srv/obs/build/SUSE\:13.2/standard/x86_64/:full

testobs:/srv/www/obs/api # chown obsrun:obsrun \

/srv/obs/build/SUSE\:13.2/standard/i586/:full

testobs:/srv/www/obs/api # chown obsrun:obsrun \

/srv/obs/build/SUSE\:13.2/standard/x86_64/:full

70 Importing Distributions

Now you can copy (or link) all binary packages for the architecture in the :full directory. You

need the architecture specic package and the noarch packages as well.

Important

If you import packages for enterprise distributions like SLES12 you also need the packages

from the SDK. Maybe you need packages from add-on products as well, depending what

software you want build.

Finally you should trigger a rescan for the project on the back-end server using obs_admin:

testobs # obs_admin --rescan-repository SUSE:13.2 standard i586

testobs # obs_admin --rescan-repository SUSE:13.2 standard x86_64

This reads all packages and creates the dependency tree.

3.3 Source Services

Source Services are tools to validate, generate or modify sources in a trustable way. They are

designed as smallest possible tools and can be combined following the powerful idea of the

classic UNIX design.

Design goals of source services were:

server side generated les must be easy to identify and must not be modiable by the

user. This way other users can trust them to be generated in the documented way without

modications.

generated les must never create merge conicts

generated les must be a separate commit to the user change

services must be runnable at any time without user commit

services must be runnable on server and client side in the same way

services must be designed in a safe way. A source checkout and service run must never

harm the system of a user.

services shall be designed in a way to avoid unnecessary commits. This means there shall

be no time-dependent changes. In case the package already contains the same le, the

newly generated le must be dropped.

71 Source Services

local services can be added and used by everybody.

server side services must be installed by the admin of the OBS server.

services can be dened per package or project wide.

3.3.1 Using Services for Validation

Source Services may be used to validate sources. This can happen per package, which is useful

when the packager wants to validate that downloaded sources are really from the original

maintainer. Or validation can happen for an entire project to apply general policies. These

services cannot get skipped in any package

Validation can happen by validating les (for example using the verify_file or

source_validator service. These services just fail in the error case which leads to the build

state "broken". Or validation can happen by redoing a certain action and store the result as new

le as download_files is doing. In this case the newly generated le will be used instead of

the committed one during build.

3.3.2 Dierent Modes When Using Services

Each service can be used in a special mode dening when it should run and how to use the

result. This can be done per package or globally for an entire project.

3.3.2.1 Default Mode

The default mode of a service is to always run after each commit on the server side and locally

before every local build.

3.3.2.2 trylocal Mode

The trylocal mode is running the service locally when using current osc versions. The result gets

committed as standard les and not named with _service: prex. Additionally the service runs

on the server by default, but usually the service should detect that the result is the same and

skip the generated les. In case they dier for any reason (because the webui or API was used

for example) they be generated and added on the server.

72 Using Services for Validation

3.3.2.3 localonly Mode

The localonly mode is running the service locally when using current osc versions. The result gets

committed as standard les and not named with _service: prex. The service is never running

on the server side. It is also not possible to trigger it manually.

3.3.2.4 serveronly Mode

The serviceonly mode is running the service on the server only. This can be useful, when the

service is not available or can not work on developer workstations.

3.3.2.5 buildtime Mode

The service is running inside of the build job, for local and server side builds. A side eect is

that the service package is becoming a build dependency and must be available. Every user can

provide and use a service this way in their projects. The generated sources are not part of the

source repository, but part of the generated source packages. Network access is not be available

when the workers are running in a secure mode.

3.3.2.6 disabled Mode

The disabled mode is neither running the service locally or on the server side. It can be used to

temporarily disable the service but keeping the denition as part of the service denition. Or

it can be used to dene the way how to generate the sources and doing so by manually calling

osc service disabledrun The result will get committed as standard les again.

3.3.3 Storage of Source Service Deﬁnitions

The called services are always dened in a _service le. It is either part of the package sources

or used project-wide when stored inside the _project package.

The _service le contains a list of services which get called in this order. Each service may dene

a list of parameters and a mode. The project wide services get called after the per package

dened services. The _service le is an xml le like this example:

73 Storage of Source Service Deﬁnitions

<param name="file">krabber-1.0.tar.gz</param>

<param

name="checksum">7f535a96a834b31ba2201a90c4d365990785dead92be02d4cf846713be938b78</param>

</service>

</services>

This example downloads the les via download_les service via the given URLs from the spec le.

When using osc this le gets committed as part of the commit. Afterwards the krabber-1.0.tar.gz

le will always be compared with the sha256 checksum. And last but not least there is the

update_source service mentioned, which is usually not executed. Except when osc service

disabledrun is called, which will try to upgrade the package to a newer source version available

online.

3.3.4 Dropping a Source Service Again

Sometimes it is useful to continue working on generated les manually. In this situation the

_service le needs to be dropped, but all generated les need to be committed as standard les.

The OBS provides the "mergeservice" command for this. It can also be used via osc by calling

osc service merge .

3.4 Dispatch Priorities

The dispatcher takes a job from the scheduler and assign it to a free worker. It tries to

share the available build time fair between all the project repositories with pending jobs. To

achieve this the dispatcher calculates a load per project repository of the used build time

(similar to the system load in Unix operating systems). The dispatcher assigned jobs to build

clients from the repository with the lowest load (thereby increasing the its load). It is possible

to tweak this mechanism via dispatching priorities assigned to the repositories via the /

build/_dispatchpriosAPI call or via the dispatch_adjust array in the BSCong.pmSection2.1.2.2,

“BSConﬁg.pm” conguration le.

74 Dropping a Source Service Again

3.4.1 The /build/_dispatchprios API Call

The /build/_dispatchprios API call allows an Admin to set a priority for dened projects and

repositories using the HTML put method. With the HTML get method the current XML priority

le can be read.

<prio project="ProjectName" repository="RepoName" arch="Architecture" adjust="Number" /

</dispatchprios>

The attributes project, repository and arch are all optional, if for example arch and repository are

missing the entry is used for all repositories and architectures for the given project. It is not

supported to use regular expressions for the names. The adjust value is taken as logarithmic scale

factor to the current load of the repositories during the compare. Projects without any entry get

a default priority of 0, higher values cause the matching projects to get more build time.

Example dispatchprios XML le

</dispatchprios>

TABLE3.1:ROUNDED SCALE FACTORS RESULTING FROM A PRIORITY

priority scale factor  priority scale factor

-50 100000 3 0.5

-30 1000 5 0.3

-20 100 7 0.2

-15 30 10 0.1

-10 10 15 0.03

-7 5 20 0.01

-5 3 30 0.001

-3 2 40 0.0001

75 The /build/_dispatchprios API Call

priority scale factor  priority scale factor

0 1 50 0.00001

3.4.2 dispatch_adjust Array

With the dispatch_adjust array in the BSCong.pm le the dispatch priorities of project

repositories based on regular expressions for the project, repository name and maybe

architecture. Each match will add or subtract a value to the priority of the repository. The default

priority is 0, higher values cause the matching projects to get more build time.

Each entry in the dispatch_adjust array has the format

'regex string' => priority adjustment

The full name of a build repository looks like

Project:Subproject/Repository/Architecture

Examples:

Devel:Science/SLES-11/i586

home:king:test/Leap42/x86_64

If a repository matches a string the adjustment is added to the current value. The nal value is

the sum of the adjustments of all matched entries. This sum is the same logarithmic scale factor

as described in the previous section.

Example dispatch_adjust denition in the BSCong.pm

our $dispatch_adjust = [

'Devel:' => 7,

'HotFix:' => +20,

'.+:test.*' => -10,

'home:' => -3,

'home:king' => +30,

'.+/SLE12-SP2' => -40,

];

The above example could have the following background: All Devel projects should get some

higher priority so the developer jobs getting more build time. The projects under HotFix are

very important xes for customers and so they should get a worker as soon as possible. All

projects with test in the name get some penalty, also home projects are getting only about half

76 dispatch_adjust Array

of the build time as a normal project, with the exception of the home project from king, the

user account of the boss. The SLES12-SP2 repository is not in real use yet, but if here is nothing

else to do build for it as well.

Important

The dispatcher calculates the values form the 'dispatch_adjust' array rst, if the same

project and repository also has an entry in the dispatchprios XML le, the XML le entry

will overwrite the calculated priority. The best practice is to only use one of the methods.

3.5 Publisher Hooks

The job of the publisher service is to publish the built packages and/or images by creating

repositories that are made available through a web server.

It can be congured to use custom scripts to copy the build results to dierent servers or do

anything with them that comes to mind. These scripts are called publisher hooks.

3.5.1 Conﬁguring Publisher Hooks

Hooks are congured via the conguration le /usr/lib/obs/server/BSCong.pm, where one script

per project is linked to the repository that should be run if the project/repository combination

is published. It is possible to use regular expressions here.

The script is called by the user obsrun with the following parameters:

1. information about the project and its repository (for example, training/SLE11-SP1 )

2. path to published repository (for example, /srv/obs/repos/training/SLE11-SP1 )

3. changed packages (for example, x86 64/test.rpm x86 64/utils.rpm )

The hooks are congured by adding a hash reference named $publishedhook to the BSCong.pm

conguration le. The key contains the project, and the value references the accompanying

script. If the value is written as an array reference it is possible to call the hook with self-dened

parameters.

77 Publisher Hooks

The publisher will add the 3 listed parameters at the end, after the self-dened parameters (in

/usr/lib/obs/server/BSConfig.pm ):

our $publishedhook = {

"Product/SLES12" => "/usr/local/bin/script2run_sles12",

"Product/SLES11-SP3" => "/usr/local/bin/script2run_sles11",

"Product/SLES11-SP4" => "/usr/local/bin/script2run_sles11",

};

Regular expressions or substrings can be used to dene a script for more than one repository

in one project. The use of regular expressions has to be activated by dening $publishedhook

use regex = 1; as follows (in /usr/lib/obs/server/BSConfig.pm ):

our $publishedhook_use_regex = 1;

our $publishedhook = {

"Product\/SLES12" => "/usr/local/bin/script2run_sles12",

"Product\/SLES11.*" => "/usr/local/bin/script2run_sles11",

};

With self dened parameters:

our $publishedhook_use_regex = 1;

our $publishedhook = {

"Product\/SLES11.*" => ["/usr/local/bin/script2run", "sles11", "/srv/www/

public_mirror"],

};

The conguration is read by the publisher at startup only, so it has to be restarted after

conguration changes have been made. The hook script’s output is not logged by the publisher

and should be written to a log le by the script itself. In case of a broken script,this is logged in

the publisher’s log le (/srv/obs/log/publisher.log by default):

Mon Mar 7 14:34:17 2016 publishing Product/SLES12

fetched 0 patterns

running createrepo

calling published hook /usr/local/bin/script2run_sles12

/usr/local/bin/script2run_sles12 failed: 65280

syncing database (6 ops)

Interactive scripts are not working and will fail immediately.

If you need to do a lot of work in the hook script and do not want to block the publisher all the

time, you should consider using a separate daemon that does all the work and just gets triggered

by the congured hook script.

78 Conﬁguring Publisher Hooks

The scripts are called without a timeout.

3.5.2 Example Publisher Scripts

3.5.2.1 Simple Publisher Hook

The following example script ignores the packages that have changed and copies all RPMs from

the repository directory to a target directory:

#!/bin/bash

OBSHOME="/srv/obs"

SRC_REPO_DIR="$OBSHOME/repos"

LOGFILE="$OBSHOME/log/reposync.log"

$DST_REPO_DIR="/srv/repo-mirror"

# Global substitution! To handle strings like Foo:Bar:testing - two

#+double-colons!

PRJ_PATH=${1//:/:\/}

PATH_TO_REPO=$2

rsync -a --log-file=$LOGFILE $PATH_TO_REPO/ $DST_REPO_DIR/$PRJ_PATH/

For testing purposes, it can be invoked as follows:

$ sudo -u obsrun /usr/local/bin/publish-hook.sh Product/SLES11-SP1 \

/srv/obs/repos/Product/SLE11-SP1

3.5.2.2 Advanced Publisher Hook

The following example script reads the destination path from a parameter that is congured

with the hook script:

#!/bin/bash

LOGFILE="/srv/obs/log/reposync.log"

DST_REPO_DIR=$1

# Global substion! To handle strings like Foo:Bar:testing - two

#+double-colons!

PRJ_PATH=${2//:/:\/}

PATH_TO_REPO=$3

mkdir -p $DST_REPO_DIR/$PRJ_PATH

rsync -a --log-file=$LOGFILE $PATH_TO_REPO/ $DST_REPO_DIR/$PRJ_PATH/

79 Example Publisher Scripts

For testing purposes, it can be invoked as follows:

$ sudo -u obsrun /usr/local/bin/publish-hook.sh \

/srv/www/public_mirror/Product/SLES11-SP1 \

/srv/obs/repos/Product/SLE11SP1

The following example script only copies packages that have changed, but does not delete

packages that have been removed:

#!/bin/bash

DST_REPO_DIR=$1

PRJ_PATH=${2//:/:\/}

PATH_TO_REPO=$3

shift 3

mkdir -p $DST_REPO_DIR/$PRJ_PATH

while [ $# -gt 0 ]

dir=(${1//\// })

if [ ! -d "$DST_REPO_DIR/$PRJ_PATH/$dir" ]; then

mkdir -p $DST_REPO_DIR/$PRJ_PATH/$dir

cp $PATH_TO_REPO/$1 $DST_REPO_DIR/$PRJ_PATH/$1

shift

done

createrepo $DST_REPO_DIR/$PRJ_PATH/.

For testing purposes, it can be invoked as follows:

$ sudo -o obsrun /usr/local/bin/publish-hook.sh /srv/www/public_mirror \

Product/SLES11-SP1 /srv/obs/repos/Product/SLE11-SP1 \

src/icinga-1.13.3-1.3.src.rpm x86_64/icinga-1.13.3-1.3.x86_64.rpm \

x86_64/icinga-devel-1.13.3-1.3.x86_64.rpm

3.6 Unpublisher Hooks

The job of the publisher service is to publish the built packages and/or images by creating

repositories that are made available through a web server.

The OBS Publisher can be congured to use custom scripts to be called whenever already

published packages get removed. These scripts are called unpublisher hooks. Unpublisher

hooks are run before the publisher hooks.

80 Unpublisher Hooks

3.6.1 Conﬁguring Unpublisher Hooks

Hooks are congured via the conguration le /usr/lib/obs/server/BSCong.pm, where one script

per project is linked to the repository that should be run if the project/repository combination

is removed. It is possible to use regular expressions here.

The script is called by the user obsrun with the following parameters:

1. information about the project and its repository (for example, training/SLE11-SP1)

2. repository path (for example, /srv/obs/repos/training/SLE11-SP1 )

3. removed packages (for example, x86 64/test.rpm x86 64/utils.rpm )

The hooks are congured by adding a hash reference named $unpublishedhook to the BSCong.pm

conguration le. The key contains the project and the value references the accompanying

script. If the value is written as an array reference, it is possible to call the hook with custom

parameters.

The publisher adds the three listed parameters at the end, directly after the custom parameters

(in /usr/lib/obs/server/BSConfig.pm ):

our $unpublishedhook = {

"Product/SLES12" => "/usr/local/bin/script2run_sles12",

"Product/SLES11-SP3" => "/usr/local/bin/script2run_sles11",

"Product/SLES11-SP4" => "/usr/local/bin/script2run_sles11",

};

Regular expressions or substrings can be used to dene a script for more than one repository in

one project. The use of regular expressions needs to be activated by dening $unpublishedhook

use regex = 1; (in /usr/lib/obs/server/BSConfig.pm ):

our $unpublishedhook_use_regex = 1;

our $unpublishedhook = {

"Product\/SLES12" => "/usr/local/bin/script2run_sles12",

"Product\/SLES11.*" => "/usr/local/bin/script2run_sles11",

};

With custom parameters:

our $unpublishedhook_use_regex = 1;

our $unpublishedhook = {

"Product\/SLES11.*" => [

"/usr/local/bin/script2run", "sles11", "/srv/www/public_mirror"

};

81 Conﬁguring Unpublisher Hooks

The conguration is read by the publisher at startup only, so it has to be restarted after

conguration changes have been made. The hook script’s output is not logged by the publisher

and should be written to a log le by the script itself. In case of a broken script, this is logged

in the publisher’s log le (/srv/obs/log/publisher.log by default):

Mon Mar 7 14:34:17 2016 publishing Product/SLES12

fetched 0 patterns

running createrepo

calling unpublished hook /usr/local/bin/script2run_sles12

/usr/local/bin/script2run_sles12 failed: 65280

syncing database (6 ops)

Interactive scripts are not working and will fail immediately.

If you need to do a lot of work in the hook script and do not want to block the publisher all

the time, consider using a separate daemon that does all the work and just gets triggered by

the congured hook script.

The scripts are called without a timeout.

Note

Reminder: If unpublish hooks and publish hooks are dened, the unpublish hook runs before

the publish hook.

3.6.2 Example Unpublisher Scripts

3.6.2.1 Simple Unpublisher Hook

The following example script deletes all packages from the target directory that have been

removed from the repository.

#!/bin/bash

OBSHOME="/srv/obs"

LOGFILE="$OBSHOME/log/reposync.log"

DST_REPO_DIR="/srv/repo-mirror"

# Global substitution! To handle strings like Foo:Bar:testing - two

#+double-colons!

PRJ_PATH=${1//:/:\/}

PATH_TO_REPO=$2

shift 2

82 Example Unpublisher Scripts

while [ $# -gt 0 ]

rm -v $DST_REPO_DIR/$PRJ_PATH/$1 >>$LOGFILE 2>&1

shift

done

For testing purposes, it can be invoked as follows:

$ sudo -u obsrun /usr/local/bin/unpublish-hook.sh \

Product/SLES11-SP1 \

/srv/obs/repos/Product/SLE11-SP1 \

src/icinga-1.13.3-1.3.src.rpm \

x86_64/icinga-1.13.3-1.3.x86_64.rpm \

x86_64/icinga-devel-1.13.3-1.3.x86_64.rpm

3.6.2.2 Advanced Unpublisher Hook

The following example script reads the destination path from a parameter that is congured

via the hook script:

#!/bin/bash

OBSHOME="/srv/obs"

LOGFILE="$OBSHOME/log/reposync.log"

DST_REPO_DIR=$1

# Global substitution! To handle strings like Foo:Bar:testing - two

#+double-colons!

PRJ_PATH=${1//:/:\/}

PATH_TO_REPO=$2

shift 3

while [ $# -gt 0 ]

rm -v $DST_REPO_DIR/$PRJ_PATH/$1 >>$LOGFILE 2>&1

shift

done

For testing purposes, it can be invoked as follows:

$ sudo -u obsrun /usr/local/bin/unpublish-hook.sh \

/srv/www/public_mirror/Product/SLES11-SP1 \

/srv/obs/repos/Product/SLE11SP1 \

src/icinga-1.13.3-1.3.src.rpm \

x86_64/icinga-1.13.3-1.3.x86_64.rpm \

x86_64/icinga-devel-1.13.3-1.3.x86_64.rpm

83 Example Unpublisher Scripts

3.7 Managing Users and Groups

The OBS has an integrated user and group management with a role based access rights model.

In every OBS instance, at least one user need to exist and have the global Admin role assigned.

Groups can be dened by the Admin and instead of adding a list of users to a project/package

role user can be added to a group and the group will be added to a project or package role.

3.7.1 User and Group Roles

The OBS role model has one global role: Admin, which can be granted to users. An OBS admin

has access to all projects and packages via the API interface and the web user interface. Some

menus in the Web UI do not allow changes by an Admin (for example, the Repository menu)

as long the Admin is not a Maintainer for the project as well. But the same change can be done

via editing the metadata directly. The other roles are specic to projects and packages and can

be assigned to a user or a group.

TABLE3.2:ROLES IN OBS

Role Description Remarks

Maintainer Read and write access to projects or

packages

Bugowner Read access to projects or packages should be unique per package

Reader Read access to sources

Downloader Read access to the binaries

Reviewer Default reviewer for a package or

project

3.7.2 Standalone User and Group Database

OBS provides its own user database which can also store a password. The authentication to

the API happens via HTTP BASIC AUTH. See the API documentation to nd out how to create,

modify or delete user data. Also a call for changing the password exists.

84 Managing Users and Groups

Users can be added by the maintainer or if registration is allowed via the registration menu

on the Web UI. It can be congured that a conrmation is needed after registration before the

user may login.

3.7.3 Proxy Mode

The proxy mode can be used for specially secured instances, where the OBS web server shall not

get connected to the network directly. There are authentication proxy products out there which

do the authentication and send the user name via an HTTP header to OBS. Originally, this was

developed for IChain - a legacy single login authentication method from Novell. This also has

the advantage that the user password never reaches OBS.

The proxy mode can also be used for LDAP or Active Directory, but only for authentication.

Important

With enabled proxy mode the OBS trust the username in the http header. Since this was

veried by the Web server and the Web server only forward requests for a veried and

authenticated session, this is safe, as long you make sure that the direct web/API interface

of the OBS is not reachable from the outside.

With the proxy mode the user still need to be registered in the OBS and all OBS roles and user

properties are managed inside the OBS.

3.7.3.1 OBS Proxy Mode Conﬁguration

Currently the LDAP conguration is in the options.yml le.

TABLE3.3:OPTIONS FOR PROXY MODE CONFIGURATION

Cong item Description Values

default

Remarks

proxy_auth_mode turn proxy mode on/

o

:off :on need to be :o if

ldap_mode: is :on

85 Proxy Mode

3.7.4 LDAP/Active Directory

Note

The LDAP support was considered experimental and not ocially supported. It is ocially

supported since 2.8.3 release.

Using LDAP or Active Directory as source for user and optional group information in

environments which already have such a server has the advantage for the admin people that

the user related information only need to be maintained in one place. In the following sections

we are writing LDAP, but this includes Microsoft's Active Directory as well. Only in parts where

dierences exists Active Directory (AD) will be explicit mentioned.

In this mode the OBS contact the LDAP server directly from the OBS API, if the user was found

and provides the correct password the user is added transparently to the OBS user database.

The password or password hash is not stored in the OBS database. Because the user database

password eld is mandatory, a random hash is stored instead. The LDAP interface allows to

restrict the access to users which are in a special LDAP group. Optional also groups can be

discovered from the LDAP server. This can be also ltered.

Before anybody can add a user to a package or project with a role, the user need to had logged

in at least one time, since the check for available users is local only. If the LDAP group mode

is enabled, LDAP groups are also added transparently, if an existing group on the LDAP server

is added to a project or package.

On bigger installations this mode can result in many search requests to the LDAP server and slow

down access to projects and packages, because on every role check an LDAP search operation

will contact the LDAP server. As alternative method group mirroring was implemented. This

allows that the internal OBS group database is updated with the group membership information

during the user authentication. All role test are made local against the OBS database and do not

need additional LDAPoperations.

Note

The local user group membership in :mirror mode is updated as follows: When the

user logins, the user memberOf attributes are parsed and compared with the global OBS

grouplist, if a group matches, the user is added, if they are no longer a group member,

they are removed. since this maybe a costly operation, depending on the group counts,

this is only done on a full login. After a full login the user status is cashed for 2 minutes, if

86 LDAP/Active Directory

the user do a login during this time, nothing will be checked or updated. Here is a second

mechanism to update user membership: If somebody adds a new Group in the OBS, the

member attributes of the group are parsed and all current users which are in the local

database become members.

3.7.4.1 OBS LDAP Conﬁguration

Currently the main OBS LDAP conguration is in the le options.yml . Beside the settings in

that le, the openLDAP conguration le is also evaluated by the Ruby LDAP implementation.

This conguration le is usually located at /etc/openldap/ldap.conf . You can set here

additional TLS/SSL directives like TLS_CACERT , TLS_CACERTDIR and TLS_REQCERT . For more

information refer to the openLDAP man page ( man ldap.conf ).

Note

When LDAP mode is activated, users can only log in via LDAP. This also includes existing

admin accounts. To make a LDAP user an admin, use a rake task which can be run on the

OBS instance. For example, to make user tux , use:

cd /srv/www/obs/api

bundle exec rake user:give_admin_rights tux RAILS_ENV=production

TABLE3.4:LDAP CONFIGURATION OPTIONS

Cong item Description Values

default

Remarks

ldap_mode OBS LDAP mode on/

o

:off :on

ldap_servers List of LDAP servers colon-separated list

ldap_max_attempts tries to ping LDAP

server

int 15

ldap_search_timeout timeout of an LDAP

int 0…N 50 wait for ever

87 LDAP/Active Directory

Cong item Description Values

default

Remarks

ldap_user_memberof_attr User attribute for

Group membership

memberOf case sensitive

ldap_group_member_attr Group attribute for

members

member

ldap_ssl use ldaps port and

protocol

:off :on

ldap_start_tls usr Start TLS on LDAP

protocol

:o :on

ldap_port LDAP portnumbers if not set 389 for

LDAP, 636 for LDAPS

ldap_referrals Windows 2003 AD

requires

:off :on

ldap_search_base company’s LDAP

search base for the

users who will use OBS

none

ldap_search_attr user ID attribute sAMAccountName

uid

sAMAccountName for

AD, uid for openldap

ldap_name_attr Full user name cn

ldap_mail_attr Attribute for users

mail

ldap_search_user Bind user for LDAP

for example,

cn=ldapbind,

ou=system,

dc=mycompany,

dc=com

88 LDAP/Active Directory

Cong item Description Values

default

Remarks

ldap_search_auth Password for the

ldap_search_user

ldap_user_lter Search lter for OBS

users

for example, a group

membership, empty all

users allowed

ldap_authenticate How user how the

credentials are veried

:ldap :local only use :ldap

ldap_auth_mech Used auth mech :md5

:cleartext

only if local

ldap_auth_attr Used auth attribute

for :local

userPassword do not use

ldap_group_support Import OBS groups

from LDAP

:off

:on :mirror

see text

ldap_group_search_base company’s LDAP

search base for groups

ldap_group_title_attr Attribute of the group

name

ldap_group_objectclass_attr Object class for group Group

ldap_obs_admin_group Group name for OBS

Admins

if set, members of that

group become OBS

admin role

Example LDAP section of the options.yml le:

[...]

##################

# LDAP options

##################

89 LDAP/Active Directory

ldap_mode: :on

# LDAP Servers separated by ':'.

# OVERRIDE with your company's ldap servers. Servers are picked randomly for

# each connection to distribute load.

ldap_servers: ldap1.mycompany.com:ldap2.mycompany.com

# Max number of times to attempt to contact the LDAP servers

ldap_max_attempts: 15

# timeout of an ldap search requests to avoid infinitely lookups (in seconds, 0 no

timeout)

ldap_search_timeout: 5

# The attribute the user member of is stored in (case sensitive !)

ldap_user_memberof_attr: memberOf

# Perform the group_user search with the member attribute of group entry or memberof

attribute of user entry

# It depends on your ldap define

# The attribute the group member is stored in

ldap_group_member_attr: member

# If you're using ldap_authenticate=:ldap then you should ensure that

# ldaps is used to transfer the credentials over SSL or use the StartTLS extension

ldap_ssl: :on

# Use StartTLS extension of LDAP

ldap_start_tls: :off

# LDAP port defaults to 636 for ldaps and 389 for ldap and ldap with StartTLS

#ldap_port:

# Authentication with Windows 2003 AD requires

ldap_referrals: :off

# OVERRIDE with your company's ldap search base for the users who will use OBS

ldap_search_base: ou=developmentt,dc=mycompany,dc=com

# Account name attribute (sAMAccountName for Active Directory, uid for openLDAP)

ldap_search_attr: sAMAccountName

# The attribute the users name is stored in

ldap_name_attr: cn

# The attribute the users email is stored in

ldap_mail_attr: mail

# Credentials to use to search ldap for the username

ldap_search_user: "cn=ldapbind,ou=system,dc=mycompany,dc=com"

ldap_search_auth: "top secret"

# By default any LDAP user can be used to authenticate to the OBS

90 LDAP/Active Directory

# In some deployments this may be too broad and certain criteria should

# be met; eg group membership

# To allow only users in a specific group uncomment this line:

ldap_user_filter: (memberof=cn=obsusers,ou=groups,dc=mycompany,dc=com)

# Note this is joined to the normal selection like so:

# (&(#{dap_search_attr}=#{login})#{ldap_user_filter})

# giving an ldap search of:

# (&(sAMAccountName=#{login})(memberof=CN=group,OU=Groups,DC=Domain Component))

# Also note that openLDAP must be configured to use the memberOf overlay

# ldap_authenticate says how the credentials are verified:

# :ldap = attempt to bind to ldap as user using supplied credentials

# :local = compare the credentials supplied with those in

# LDAP using #{ldap_auth_attr} & #{ldap_auth_mech}

# if :local is used then ldap_auth_mech can be

# :md5

# :cleartext

ldap_authenticate: :ldap

ldap_auth_mech: :md5

# This is a string

ldap_auth_attr: userPassword

# Whether to search group info from ldap, it does not take effect it is not set

# Please also set below ldap_group_* configs correctly to ensure the operation works

properly

# Possible values:

# :off disabled

# :on enabled; every group member operation ask the LDAP server

# :mirror enabled; group membership is mirrored and updated on user login

ldap_group_support: :mirror

# OVERRIDE with your company's ldap search base for groups

ldap_group_search_base: ou=obsgroups,dc=mycompany,dc=com

# The attribute the group name is stored in

ldap_group_title_attr: cn

# The value of the group objectclass attribute

# group for Active Directory, groupOfNames in openLDAP

ldap_group_objectclass_attr: group

# The LDAP group for obs admins

# if this group is set and a user belongs to this group they get the global admin role

91 LDAP/Active Directory

ldap_obs_admin_group: obsadmins

3.7.5 Authentication Methods

3.7.5.1 LDAP Methods

The LDAP mode has 2 methods to check authorization:

1. LDAP bind method. With the provided credentials, an LDAP bind request is tried.

2. Local method. The provided credentials checked locally against the content of the

userPassword attribute.

Important

The local method should be not used, since the userPassword attribute in most LDAP

installations will not be available until you are bind with a privilege user.

3.7.5.2 Kerberos

In OBS you can use single sign on via Kerberos tickets.

OBS Kerberos conguration resides in the options.yml le.

TABLE3.5:KERBEROS CONFIGURATION OPTIONS

Cong item Description Example

kerberos_keytab Kerberos key table: le where long-

term keys for one or more principals

are stored

"/etc/krb5.keytab"

kerberos_service_principal Kerberos OBS principal: OBS unique

identity to which Kerberos can

assign tickets

"HTTP/

hostname.example.com@EXAMPLE.COM"

kerberos_realm Kerberos realm: authentication

administrative domain

"EXAMPLE.COM"

92 Authentication Methods

Example Kerberos section of the options.yml le:

[...]

##################

# Kerberos options

##################

kerberos_mode: true

kerberos_keytab: "/etc/krb5.keytab"

kerberos_service_principal: "HTTP/hostname.example.com@EXAMPLE.COM"

kerberos_realm: "EXAMPLE.COM"

[...]

Note

Once Kerberos is enabled, only users with logins that match users known to Kerberos will

be able to authenticate to OBS. It is recommended to give admin rights to a matching

user before enabling Kerberos mode.

3.7.5.3 OBS Token Authorization

OBS 2.5 provides a mechanism to create tokens for specic operations. This can be used to allow

certain operations in the name of a user to others. This is esp. useful when integrating external

infrastructure. The create token should be kept secret by default, but it can also be revoked at

any time if it became obsolete or leaked.

3.7.5.3.1 Managing Tokens of a User

Tokens belong always to a user. A list of active tokens can received via

osc token

osc token --delete <TOKEN>

93 Authentication Methods

3.7.5.3.2 Executing a Source Service

A token can be used to execute a source service. The source service has to be setup for the

package rst, check the source service chapter for this. A typical example is to update sources

of a package from git. A source service for that can be setup with

osc add git://....

A token can be registered as generic token, means allowing to execute all source services in OBS

if the user has permissions. You can create such a token and execute the operation with

osc token --create

osc token --trigger <TOKEN> <PROJECT> <PACKAGE>

osc api -X POST /trigger/runservice?token=<TOKEN>&project=<PROJECT>&package=<PACKAGE>

You can also limit the token to a specic package. The advantage is that the operation is limited

to that package, so less bad things can happen when the token leaks. Also you do not need to

specify the package on execution time. Create and execute it with

osc token --create <PROJECT> <PACKAGE>

osc token --trigger <TOKEN>

osc api -X POST /trigger/runservice?token=<TOKEN>

3.8 Message Bus for Event Notiﬁcations

The OBS has an integrated notication subsystem for sending events that are happening in our

app through a message bus. We have chosen RabbitMQ (https://www.rabbitmq.com/) as our

message bus server technology based on the AMQP (https://www.amqp.org/) protocol.

3.8.1 RabbitMQ

RabbitMQ claims to be "the most popular open source message broker". Meaning that it can deliver

asynchronous messages in many dierent exchange ways (one to one, broadcasting, based on

topics). It also includes a exible routing system based on queues.

94 Message Bus for Event Notiﬁcations

RabbitMQ is lightweight and easy to deploy on premises and in the cloud. It supports multiple

messaging protocols too. And can be deployed in distributed and federated congurations to

meet high-scale, high-availability requirements.

3.8.1.1 Conﬁguration

Currently the RabbitMQ conguration is in the le options.yml . All those options there start

with the prex amqp. These conguration items match with some of the calls we do using the

Bunny (http://rubybunny.info/) gem.

TABLE3.6:RABBITMQ CONFIGURATION OPTIONS

Cong item Description Values

default

Remarks

amqp_namespace Namespace for the

queues of this instance

'opensuse.obs'Is a prex for the

queue names

amqp_options Connection

conguration

See this guide (http://

rubybunny.info/articles/

connecting.html) to

know which are the

parameters allowed.

amqp_options[host] Server host A valid hostname

amqp_options[port] Server port 5672

amqp_options[user] User account

amqp_options[pass] Account password

amqp_options[vhost] Virtual host

amqp_exchange_name Name for the exchange

95 RabbitMQ

Cong item Description Values

default

Remarks

amqp_exchange_options Exchange

conguration

See this guide (http://

rubybunny.info/articles/

exchanges.html)

to know more about

exchanges.

amqp_exchange_options[type]Type of comunication

for the exchange

direct

amqp_exchange_options[auto_delete]If set, the exchange

is deleted when all

queues have nished

using it

false

amqp_exchange_options[arguments]More conguration for

plugins / extensions

amqp_queue_options Queues conguration See this guide (http://

rubybunny.info/articles/

queues.html) to

know more about

queues.

amqp_queue_options[durable]Should this queue be

durable?

false

amqp_queue_options[auto_delete]Should this queue

be automatically

deleted when the last

consumer disconnects?

false

amqp_queue_options[exclusive]Should this queue

be exclusive (only

can be used by this

false

96 RabbitMQ

Cong item Description Values

default

Remarks

connection, removed

when the connection is

closed)?

amqp_queue_options[arguments]Additional optional

arguments (typically

used by RabbitMQ

extensions and

plugins)

Example of the RabbitMQ section of the options.yml le:

[...]

# RabbitMQ based message bus

# Prefix of the message bus rooting key

amqp_namespace: 'opensuse.obs'

# Connection options -> http://rubybunny.info/articles/connecting.html

amqp_options:

host: rabbit.example.com

port: 5672

user: guest

pass: guest

vhost: /vhost

# Exchange options -> http://rubybunny.info/articles/exchanges.html

amqp_exchange_name: pubsub

amqp_exchange_options:

type: topic

auto_delete: false

arguments:

persistent: true

passive: true

# Queue options -> http://rubybunny.info/articles/queues.html

amqp_queue_options:

durable: false

97 RabbitMQ

auto-delete: false

exclusive: false

arguments:

extension_1: blah

TABLE3.7:LIST OF EVENT MESSAGES / QUEUES FOR THE MESSAGE BUS

Queue Name Description Payload

__prex__.package.build_success A package build has succeeded :repository, :arch, :release, :readytime, :srcmd5, :rev, :reason, :bcnt, :verifymd5, :hostarch, :starttime, :endtime, :workerid, :versrel, :previouslyfailed

__prex__.package.build_fail A package build has failed :repository, :arch, :release, :readytime, :srcmd5, :rev, :reason, :bcnt, :verifymd5, :hostarch, :starttime, :endtime, :workerid, :versrel, :previouslyfailed, :faillog

__prex__.package.build_unchanged A package build has succeeded

with unchanged result

:repository, :arch, :release, :readytime, :srcmd5, :rev, :reason, :bcnt, :verifymd5, :hostarch, :starttime, :endtime, :workerid, :versrel, :previouslyfailed

__prex__.package.create A new package was created :project, :package, :sender

__prex__.package.update The package metada was

updated

:project, :package, :sender

__prex__.package.delete A package was deleted :project, :package, :sender, :comment

__prex__.package.undelete A package was undeleted :project, :package, :sender, :comment

__prex__.package.branch A package was branched :project, :package, :sender, :targetproject, :targetpackage, :user

__prex__.package.commit A package has committed

changes

:project, :package, :sender, :comment, :user, :les, :rev, :requestid

__prex__.package.upload Sources of a package were

uploaded

:project, :package, :sender, :comment, :lename, :requestid, :target, :user

__prex__.package.service_success Source service succeeded for a

package

:comment, :project, :package, :sender, :rev, :user, :requestid

__prex__.package.service_fail Source service failed for a

package

:comment, :error, :project, :package, :sender, :rev, :user, :requestid

__prex__.package.version_change A package has changed its

version

:project, :package, :sender, :comment, :requestid, :les, :rev, :newversion, :user, :oldversion

98 RabbitMQ

Queue Name Description Payload

__prex__.package.comment A new comment for the

package was created

:project, :package, :sender, :commenters, :commenter, :comment_body, :comment_title

__prex__.project.create A new project was created :project, :sender

__prex__.project.update_project_conf The project conguration was

updated

:project, :sender, :les, :comment

__prex__.project.update A project was updated :project, :sender

__prex__.project.delete A project was deleted :project, :comment, :requestid, :sender

__prex__.project.undelete A project was undeleted :project, :comment, :sender

__prex__.project.comment A new comment for the project

was created

:project, :commenters, :commenter, :comment_body, :comment_title

__prex__.repo.packtrack Binary was published in the

repository

:project, :repo, :payload

__prex__.repo.publish_state Publish State of Repository has

changed

:project, :repo, :state

__prex__.repo.published A repository was published :project, :repo

__prex__.request.create A request was created :author, :comment, :description, :number, :actions, :state, :when, :who, :di

(local projects)

__prex__.request.change A request was changed (admin

only)

:author, :comment, :description, :number, :actions, :state, :when, :who

__prex__.request.delete A request was deleted :author, :comment, :description, :number, :actions, :state, :when, :who

__prex__.request.state_change The state of a request was

changed

:author, :comment, :description, :number, :actions, :state, :when, :who, :oldstate

__prex__.request.review_wanted A request requires a review :author, :comment, :description, :number, :actions, :state, :when, :who, :reviewers, :by_user, :by_group, :by_project, :by_package, :di

(local projects)

99 RabbitMQ

Queue Name Description Payload

__prex__.request.comment A new comment for the request

was created

:author, :comment, :description, :number, :actions, :state, :when, :who, :commenters, :commenter, :comment_body, :comment_title, :request_number

3.9 Backup

3.10 Spider Identiﬁcation

OBS is hiding specic parts/pages of the application from search crawlers (duckduckgo, google

etc.), mostly for performance reasons. Which user-agent strings are identied as crawlers

congured in the le /srv/www/obs/api/config/crawler-user-agents.json .

To update that list, you must run the command bundle exec rake

voight_kampf:import_user_agents in the root directory of your OBS instance. This

downloads the current crawler list of user agents as a JSON le into the config/ directory of

the Rails application.

If you want to extend or edit this list, switch to the config/ directory and open the crawler-

user-agents.json le with the editor of your choice. The content can look like this:

[

{

"pattern": "Googlebot\\/",

"url": "http://www.google.com/bot.html"

{

"pattern": "Googlebot-Mobile"

{

"pattern": "Googlebot-Image"

[...]

]

To add a new bot to this list, a pattern must be dened. This is required to identify a bot. Almost

all bots have their own user agent that they are sending to a Web server to identify them. For

example, the user agent of the Googlebot looks like this:

Mozilla/5.0 (compatible; Googlebot/2.1; +http://www.google.com/bot.html)

100 Backup

To choose the pattern for the new bot, compare the user agent of the bot you want to identify

with others and look for a part that is unique (like in the Googlebot example, the part:

Googlebot).

Let's assume we want to add the bot Geekobot to the list of bots and the user agent looks like this:

Mozilla/5.0 (compatible; Geekobot/2.1; +https://www.opensuse.org)

Our unique part would be Geekobot. So we add a new entry to the list of bots:

[

{

"pattern": "Googlebot\\/",

"url": "http://www.google.com/bot.html"

{

"pattern": "Googlebot-Mobile"

{

"pattern": "Googlebot-Image"

[...]

{

"pattern": "Geekobot"

}

]

Note

You can also use regular expressions in the pattern element.

Save the le and restart the Rails application and the bot Geekobot should be identied properly.

101 Spider Identiﬁcation

4Troubleshooting

Here are two major classes of problems regarding the Open Build Service:

1. Normal package build errors

2. Bugs, resource shortage or cong issues caused issues

The rst category are errors like missing dependent packages in the build environment, errors

during compiling or linking, errors in the build description and so on. Most of them should not

happen if the packager does test the build locally before committing it to the OBS. This type of

problems is not covered by this chapter.

4.1 General Hints

If you detect unexpected behavior of the open build service, you should follow some rules to

locate the problem:

1. Consult the log les, for the back-end look at /srv/obs/log for the back-end log les and /

srv/www/obs/api/log for the front-end log les. See the Log les Section2.2, “Log Files” for

more details.

2. Consult the normal OS system logs and the kernel log (dmesg) if here are reported system

or HW problems.

3. Check if all services are running on the back-end and front-end. See the OBS Architecture

in reference book for details.

4. Try to nd an easy way to reproduce the problem.

5. To check whether this issue was already reported, see https://github.com/openSUSE/open-

build-service .

6. Use search machines (Google) to nd out if others did also run into this problem. If you

are lucky, you will nd a x or workaround as well.

7. If you create a new bug report, include all information to reproduce the problem and the

complete error message/error log if here are any.

102 General Hints

4.2 Debugging Front-end Problems

If you get unexpected results from submitting commands with the osc tool, you can use the

debug feature of the tools to nd more information about what happened.

osc debug options

--debugger jump into the debugger before executing anything

--post-mortem jump into the debugger in case of errors

-t, --traceback print call trace in case of errors

-H, --http-debug debug HTTP traffic (filters some headers)

--http-full-debug debug HTTP traffic (filters no headers)

-d, --debug print info useful for debugging

The --debugger and --post-mortem are only suitable for osc developers. If you get an error

message from osc, the -t, --traceback can give the developer some more information about the

problem. The -H, --http-debug and --http-full-debug options are useful to see the raw answers

of OBS API, often this gives a hint what maybe wrong. If you report a problem regarding the osc

tool, it may help to include the osc output with additional *--http-debug --traceback options.

Warning

With --http-full-debug all http headers are included, this may include user data and

authentication stu so review and replace such data with XXXXXXXX or so before you

post it on the internet.

103 Debugging Front-end Problems

AGNU Licenses

This appendix contains the GNU General

Public License version 2 and the GNU Free

Documentation License version 1.2.

GNU General Public License

Version 2, June 1991

MA 02111-1307, USA

Everyone is permitted to copy and distribute verbatim copies of this license document, but

changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it.

By contrast, the GNU General Public License is intended to guarantee your freedom to share

and change free software--to make sure the software is free for all its users. This General Public

License applies to most of the Free Software Foundation’s software and to any other program

whose authors commit to using it. (Some other Free Software Foundation software is covered

by the GNU Library General Public License instead.) You can apply it to your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public

Licenses are designed to make sure that you have the freedom to distribute copies of free

software (and charge for this service if you wish), that you receive source code or can get it

if you want it, that you can change the software or use pieces of it in new free programs; and

that you know you can do these things.

To protect your rights, we need to make restrictions that forbid anyone to deny you these rights

or to ask you to surrender the rights. These restrictions translate to certain responsibilities for

you if you distribute copies of the software, or if you modify it.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must

give the recipients all the rights that you have. You must make sure that they, too, receive or

can get the source code. And you must show them these terms so they know their rights.

We protect your rights with two steps: (1) copyright the software, and (2) oer you this license

which gives you legal permission to copy, distribute and/or modify the software.

Also, for each author’s protection and ours, we want to make certain that everyone

understands that there is no warranty for this free software. If the software is modied by

someone else and passed on, we want its recipients to know that what they have is not the

original, so that any problems introduced by others will not reect on the original authors’

reputations.

Finally, any free program is threatened constantly by software patents. We wish to avoid the

danger that redistributors of a free program will individually obtain patent licenses, in eect

making the program proprietary. To prevent this, we have made it clear that any patent must

be licensed for everyone’s free use or not licensed at all.

The precise terms and conditions for copying, distribution and modication follow.

GNU GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR

COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by

the copyright holder saying it may be distributed under the terms of this General Public

License. The “Program”, below, refers to any such program or work, and a “work based on the

Program” means either the Program or any derivative work under copyright law: that is to say,

a work containing the Program or a portion of it, either verbatim or with modications and/

or translated into another language. (Hereinafter, translation is included without limitation

in the term “modication”.) Each licensee is addressed as “you”.

Activities other than copying, distribution and modication are not covered by this License;

they are outside its scope. The act of running the Program is not restricted, and the output

from the Program is covered only if its contents constitute a work based on the Program

(independent of having been made by running the Program). Whether that is true depends

on what the Program does.

1. You may copy and distribute verbatim copies of the Program’s source code as you receive

it, in any medium, provided that you conspicuously and appropriately publish on each copy

an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that

refer to this License and to the absence of any warranty; and give any other recipients of the

Program a copy of this License along with the Program.

You may charge a fee for the physical act of transferring a copy, and you may at your option

oer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming

a work based on the Program, and copy and distribute such modications or work under the

terms of Section 1 above, provided that you also meet all of these conditions:

a). You must cause the modied les to carry prominent notices stating that you changed

the les and the date of any change.

b). You must cause any work that you distribute or publish, that in whole or in part contains

or is derived from the Program or any part thereof, to be licensed as a whole at no charge to

all third parties under the terms of this License.

c). If the modied program normally reads commands interactively when run, you must

cause it, when started running for such interactive use in the most ordinary way, to print

or display an announcement including an appropriate copyright notice and a notice that

there is no warranty (or else, saying that you provide a warranty) and that users may

redistribute the program under these conditions, and telling the user how to view a copy of

this License. (Exception: if the Program itself is interactive but does not normally print such an

announcement, your work based on the Program is not required to print an announcement.)

These requirements apply to the modied work as a whole. If identiable sections of that

work are not derived from the Program, and can be reasonably considered independent and

separate works in themselves, then this License, and its terms, do not apply to those sections

when you distribute them as separate works. But when you distribute the same sections as

part of a whole which is a work based on the Program, the distribution of the whole must be

on the terms of this License, whose permissions for other licensees extend to the entire whole,

and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written

entirely by you; rather, the intent is to exercise the right to control the distribution of

derivative or collective works based on the Program.

In addition, mere aggregation of another work not based on the Program with the Program

(or with a work based on the Program) on a volume of a storage or distribution medium does

not bring the other work under the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in

object code or executable form under the terms of Sections 1 and 2 above provided that you

also do one of the following:

104

a). Accompany it with the complete corresponding machine-readable source code, which

must be distributed under the terms of Sections 1 and 2 above on a medium customarily used

for software interchange; or,

b). Accompany it with a written oer, valid for at least three years, to give any third party,

for a charge no more than your cost of physically performing source distribution, a complete

machine-readable copy of the corresponding source code, to be distributed under the terms

of Sections 1 and 2 above on a medium customarily used for software interchange; or,

c). Accompany it with the information you received as to the oer to distribute corresponding

source code. (This alternative is allowed only for noncommercial distribution and only if you

received the program in object code or executable form with such an oer, in accord with

Subsection b above.)

The source code for a work means the preferred form of the work for making modications

to it. For an executable work, complete source code means all the source code for all modules

it contains, plus any associated interface denition les, plus the scripts used to control

compilation and installation of the executable. However, as a special exception, the source

code distributed need not include anything that is normally distributed (in either source or

binary form) with the major components (compiler, kernel, and so on) of the operating system

on which the executable runs, unless that component itself accompanies the executable.

If distribution of executable or object code is made by oering access to copy from a designated

place, then oering equivalent access to copy the source code from the same place counts

as distribution of the source code, even though third parties are not compelled to copy the

source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly

provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute

the Program is void, and will automatically terminate your rights under this License. However,

parties who have received copies, or rights, from you under this License will not have their

licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing

else grants you permission to modify or distribute the Program or its derivative works. These

actions are prohibited by law if you do not accept this License. Therefore, by modifying or

distributing the Program (or any work based on the Program), you indicate your acceptance

of this License to do so, and all its terms and conditions for copying, distributing or modifying

the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient

automatically receives a license from the original licensor to copy, distribute or modify the

Program subject to these terms and conditions. You may not impose any further restrictions

on the recipients’ exercise of the rights granted herein. You are not responsible for enforcing

compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for

any other reason (not limited to patent issues), conditions are imposed on you (whether by

court order, agreement or otherwise) that contradict the conditions of this License, they do

not excuse you from the conditions of this License. If you cannot distribute so as to satisfy

simultaneously your obligations under this License and any other pertinent obligations, then

as a consequence you may not distribute the Program at all. For example, if a patent license

would not permit royalty-free redistribution of the Program by all those who receive copies

directly or indirectly through you, then the only way you could satisfy both it and this License

would be to refrain entirely from distribution of the Program.

If any portion of this section is held invalid or unenforceable under any particular

circumstance, the balance of the section is intended to apply and the section as a whole is

intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property

right claims or to contest validity of any such claims; this section has the sole purpose of

protecting the integrity of the free software distribution system, which is implemented by

public license practices. Many people have made generous contributions to the wide range of

software distributed through that system in reliance on consistent application of that system;

it is up to the author/donor to decide if he or she is willing to distribute software through any

other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of

the rest of this License.

8. If the distribution and/or use of the Program is restricted in certain countries either by

patents or by copyrighted interfaces, the original copyright holder who places the Program

under this License may add an explicit geographical distribution limitation excluding those

countries, so that distribution is permitted only in or among countries not thus excluded. In

such case, this License incorporates the limitation as if written in the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General

Public License from time to time. Such new versions will be similar in spirit to the present

version, but may dier in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Program species a version

number of this License which applies to it and “any later version”, you have the option of

following the terms and conditions either of that version or of any later version published

by the Free Software Foundation. If the Program does not specify a version number of this

License, you may choose any version ever published by the Free Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose

distribution conditions are dierent, write to the author to ask for permission. For software

which is copyrighted by the Free Software Foundation, write to the Free Software Foundation;

we sometimes make exceptions for this. Our decision will be guided by the two goals of

preserving the free status of all derivatives of our free software and of promoting the sharing

and reuse of software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY

FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT

WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER

PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

105

EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS

TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE

PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING,

REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN

WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY

AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU

FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING

BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR

LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO

OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public,

the best way to achieve this is to make it free software which everyone can redistribute and

change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start

of each source le to most eectively convey the exclusion of warranty; and each le should

have at least the “copyright” line and a pointer to where the full notice is found.

one line to give the program’s name and

an idea of what it does.

This program is free software; you can

redistribute it and/or

modify it under the terms of the GNU

General Public License

as published by the Free Software

Foundation; either version 2

of the License, or (at your option) any

later version.

This program is distributed in the hope

that it will be useful,

but WITHOUT ANY WARRANTY; without even

the implied warranty of

MERCHANTABILITY or FITNESS FOR A

PARTICULAR PURPOSE. See the

GNU General Public License for more

details.

You should have received a copy of the

GNU General Public License

along with this program; if not, write

to the Free Software

Foundation, Inc., 59 Temple Place -

Suite 330, Boston, MA 02111-1307, USA.

Also add information on how to contact you by electronic and paper mail.

If the program is interactive, make it output a short notice like this when it starts in an

interactive mode:

Gnomovision version 69, Copyright (C)

year name of author

Gnomovision comes with ABSOLUTELY NO

WARRANTY; for details

type `show w’. This is free software,

and you are welcome

to redistribute it under certain

conditions; type `show c’

for details.

The hypothetical commands `show w’ and `show c’ should show the appropriate parts of the

General Public License. Of course, the commands you use may be called something other than

`show w’ and `show c’; they could even be mouse-clicks or menu items--whatever suits your

program.

You should also get your employer (if you work as a programmer) or your school, if any, to

sign a “copyright disclaimer” for the program, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all

interest in the program `Gnomovision’

(which makes passes at compilers)

written

by James Hacker.

signature of Ty Coon, 1 April 1989

Ty Coon, President of Vice

This General Public License does not permit incorporating your program into proprietary

programs. If your program is a subroutine library, you may consider it more useful to permit

linking proprietary applications with the library. If this is what you want to do, use the GNU

Lesser General Public License (http://www.fsf.org/licenses/lgpl.html) instead of this License.

GNU Free Documentation License

Version 1.2, November 2002

Boston, MA 02111-1307 USA

Everyone is permitted to copy and distribute verbatim copies of this license document, but

changing it is not allowed.

106

PREAMBLE

The purpose of this License is to make a manual, textbook, or other functional and useful

document “free” in the sense of freedom: to assure everyone the eective freedom to copy

and redistribute it, with or without modifying it, either commercially or noncommercially.

Secondarily, this License preserves for the author and publisher a way to get credit for their

work, while not being considered responsible for modications made by others.

This License is a kind of “copyleft”, which means that derivative works of the document must

themselves be free in the same sense. It complements the GNU General Public License, which

is a copyleft license designed for free software.

We have designed this License in order to use it for manuals for free software, because free

software needs free documentation: a free program should come with manuals providing the

same freedoms that the software does. But this License is not limited to software manuals; it

can be used for any textual work, regardless of subject matter or whether it is published as a

printed book. We recommend this License principally for works whose purpose is instruction

or reference.

APPLICABILITY AND DEFINITIONS

This License applies to any manual or other work, in any medium, that contains a notice placed

by the copyright holder saying it can be distributed under the terms of this License. Such a

notice grants a world-wide, royalty-free license, unlimited in duration, to use that work under

the conditions stated herein. The “Document”, below, refers to any such manual or work. Any

member of the public is a licensee, and is addressed as “you”. You accept the license if you

copy, modify or distribute the work in a way requiring permission under copyright law.

A “Modied Version” of the Document means any work containing the Document or a portion

of it, either copied verbatim, or with modications and/or translated into another language.

A “Secondary Section” is a named appendix or a front-matter section of the Document that

deals exclusively with the relationship of the publishers or authors of the Document to the

Document’s overall subject (or to related matters) and contains nothing that could fall directly

within that overall subject. (Thus, if the Document is in part a textbook of mathematics, a

Secondary Section may not explain any mathematics.) The relationship could be a matter

of historical connection with the subject or with related matters, or of legal, commercial,

philosophical, ethical or political position regarding them.

The “Invariant Sections” are certain Secondary Sections whose titles are designated, as being

those of Invariant Sections, in the notice that says that the Document is released under this

License. If a section does not t the above denition of Secondary then it is not allowed to be

designated as Invariant. The Document may contain zero Invariant Sections. If the Document

does not identify any Invariant Sections then there are none.

The “Cover Texts” are certain short passages of text that are listed, as Front-Cover Texts or

Back-Cover Texts, in the notice that says that the Document is released under this License. A

Front-Cover Text may be at most 5 words, and a Back-Cover Text may be at most 25 words.

A “Transparent” copy of the Document means a machine-readable copy, represented in a

format whose specication is available to the general public, that is suitable for revising

the document straightforwardly with generic text editors or (for images composed of pixels)

generic paint programs or (for drawings) some widely available drawing editor, and that

is suitable for input to text formatters or for automatic translation to a variety of formats

suitable for input to text formatters. A copy made in an otherwise Transparent le format

whose markup, or absence of markup, has been arranged to thwart or discourage subsequent

modication by readers is not Transparent. An image format is not Transparent if used for

any substantial amount of text. A copy that is not “Transparent” is called “Opaque”.

Examples of suitable formats for Transparent copies include plain ASCII without markup,

Texinfo input format, LaTeX input format, SGML or XML using a publicly available DTD,

and standard-conforming simple HTML, PostScript or PDF designed for human modication.

Examples of transparent image formats include PNG, XCF and JPG. Opaque formats include

proprietary formats that can be read and edited only by proprietary word processors, SGML or

XML for which the DTD and/or processing tools are not generally available, and the machine-

generated HTML, PostScript or PDF produced by some word processors for output purposes

only.

The “Title Page” means, for a printed book, the title page itself, plus such following pages

as are needed to hold, legibly, the material this License requires to appear in the title page.

For works in formats which do not have any title page as such, “Title Page” means the text

near the most prominent appearance of the work’s title, preceding the beginning of the body

of the text.

A section “Entitled XYZ” means a named subunit of the Document whose title either

is precisely XYZ or contains XYZ in parentheses following text that translates XYZ in

another language. (Here XYZ stands for a specic section name mentioned below, such as

“Acknowledgements”, “Dedications”, “Endorsements”, or “History”.) To “Preserve the Title”

of such a section when you modify the Document means that it remains a section “Entitled

XYZ” according to this denition.

The Document may include Warranty Disclaimers next to the notice which states that this

License applies to the Document. These Warranty Disclaimers are considered to be included

by reference in this License, but only as regards disclaiming warranties: any other implication

that these Warranty Disclaimers may have is void and has no eect on the meaning of this

License.

VERBATIM COPYING

You may copy and distribute the Document in any medium, either commercially or

noncommercially, provided that this License, the copyright notices, and the license notice

saying this License applies to the Document are reproduced in all copies, and that you add

no other conditions whatsoever to those of this License. You may not use technical measures

to obstruct or control the reading or further copying of the copies you make or distribute.

However, you may accept compensation in exchange for copies. If you distribute a large

enough number of copies you must also follow the conditions in section 3.

You may also lend copies, under the same conditions stated above, and you may publicly

display copies.

COPYING IN QUANTITY

If you publish printed copies (or copies in media that commonly have printed covers) of the

Document, numbering more than 100, and the Document’s license notice requires Cover Texts,

you must enclose the copies in covers that carry, clearly and legibly, all these Cover Texts:

Front-Cover Texts on the front cover, and Back-Cover Texts on the back cover. Both covers

must also clearly and legibly identify you as the publisher of these copies. The front cover

must present the full title with all words of the title equally prominent and visible. You may

add other material on the covers in addition. Copying with changes limited to the covers, as

long as they preserve the title of the Document and satisfy these conditions, can be treated

as verbatim copying in other respects.

If the required texts for either cover are too voluminous to t legibly, you should put the

rst ones listed (as many as t reasonably) on the actual cover, and continue the rest onto

adjacent pages.

If you publish or distribute Opaque copies of the Document numbering more than 100, you

must either include a machine-readable Transparent copy along with each Opaque copy,

or state in or with each Opaque copy a computer-network location from which the general

network-using public has access to download using public-standard network protocols a

complete Transparent copy of the Document, free of added material. If you use the latter

option, you must take reasonably prudent steps, when you begin distribution of Opaque copies

in quantity, to ensure that this Transparent copy will remain thus accessible at the stated

location until at least one year after the last time you distribute an Opaque copy (directly or

through your agents or retailers) of that edition to the public.

It is requested, but not required, that you contact the authors of the Document well before

redistributing any large number of copies, to give them a chance to provide you with an

updated version of the Document.

MODIFICATIONS

You may copy and distribute a Modied Version of the Document under the conditions of

sections 2 and 3 above, provided that you release the Modied Version under precisely this

License, with the Modied Version lling the role of the Document, thus licensing distribution

and modication of the Modied Version to whoever possesses a copy of it. In addition, you

must do these things in the Modied Version:

A. Use in the Title Page (and on the covers, if any) a title distinct from that of the Document,

and from those of previous versions (which should, if there were any, be listed in the History

section of the Document). You may use the same title as a previous version if the original

publisher of that version gives permission.

B. List on the Title Page, as authors, one or more persons or entities responsible for authorship

of the modications in the Modied Version, together with at least ve of the principal authors

of the Document (all of its principal authors, if it has fewer than ve), unless they release

you from this requirement.

107

C. State on the Title page the name of the publisher of the Modied Version, as the publisher.

D. Preserve all the copyright notices of the Document.

E. Add an appropriate copyright notice for your modications adjacent to the other copyright

notices.

F. Include, immediately after the copyright notices, a license notice giving the public

permission to use the Modied Version under the terms of this License, in the form shown

in the Addendum below.

G. Preserve in that license notice the full lists of Invariant Sections and required Cover Texts

given in the Document’s license notice.

H. Include an unaltered copy of this License.

I. Preserve the section Entitled “History”, Preserve its Title, and add to it an item stating at

least the title, year, new authors, and publisher of the Modied Version as given on the Title

Page. If there is no section Entitled “History” in the Document, create one stating the title,

year, authors, and publisher of the Document as given on its Title Page, then add an item

describing the Modied Version as stated in the previous sentence.

J. Preserve the network location, if any, given in the Document for public access to a

Transparent copy of the Document, and likewise the network locations given in the Document

for previous versions it was based on. These may be placed in the “History” section. You may

omit a network location for a work that was published at least four years before the Document

itself, or if the original publisher of the version it refers to gives permission.

K. For any section Entitled “Acknowledgements” or “Dedications”, Preserve the Title of the

section, and preserve in the section all the substance and tone of each of the contributor

acknowledgements and/or dedications given therein.

L. Preserve all the Invariant Sections of the Document, unaltered in their text and in their

titles. Section numbers or the equivalent are not considered part of the section titles.

M. Delete any section Entitled “Endorsements”. Such a section may not be included in the

Modied Version.

N. Do not retitle any existing section to be Entitled “Endorsements” or to conict in title

with any Invariant Section.

O. Preserve any Warranty Disclaimers.

If the Modied Version includes new front-matter sections or appendices that qualify as

Secondary Sections and contain no material copied from the Document, you may at your

option designate some or all of these sections as invariant. To do this, add their titles to the

list of Invariant Sections in the Modied Version’s license notice. These titles must be distinct

from any other section titles.

You may add a section Entitled “Endorsements”, provided it contains nothing but

endorsements of your Modied Version by various parties--for example, statements of peer

review or that the text has been approved by an organization as the authoritative denition

of a standard.

You may add a passage of up to ve words as a Front-Cover Text, and a passage of up to 25

words as a Back-Cover Text, to the end of the list of Cover Texts in the Modied Version. Only

one passage of Front-Cover Text and one of Back-Cover Text may be added by (or through

arrangements made by) any one entity. If the Document already includes a cover text for the

same cover, previously added by you or by arrangement made by the same entity you are

acting on behalf of, you may not add another; but you may replace the old one, on explicit

permission from the previous publisher that added the old one.

The author(s) and publisher(s) of the Document do not by this License give permission to use

their names for publicity for or to assert or imply endorsement of any Modied Version.

COMBINING DOCUMENTS

You may combine the Document with other documents released under this License, under

the terms dened in section 4 above for modied versions, provided that you include in the

combination all of the Invariant Sections of all of the original documents, unmodied, and

list them all as Invariant Sections of your combined work in its license notice, and that you

preserve all their Warranty Disclaimers.

The combined work need only contain one copy of this License, and multiple identical

Invariant Sections may be replaced with a single copy. If there are multiple Invariant Sections

with the same name but dierent contents, make the title of each such section unique by

adding at the end of it, in parentheses, the name of the original author or publisher of that

section if known, or else a unique number. Make the same adjustment to the section titles in

the list of Invariant Sections in the license notice of the combined work.

In the combination, you must combine any sections Entitled “History” in the various original

documents, forming one section Entitled “History”; likewise combine any sections Entitled

“Acknowledgements”, and any sections Entitled “Dedications”. You must delete all sections

Entitled “Endorsements”.

COLLECTIONS OF DOCUMENTS

You may make a collection consisting of the Document and other documents released under

this License, and replace the individual copies of this License in the various documents with a

single copy that is included in the collection, provided that you follow the rules of this License

for verbatim copying of each of the documents in all other respects.

You may extract a single document from such a collection, and distribute it individually under

this License, provided you insert a copy of this License into the extracted document, and follow

this License in all other respects regarding verbatim copying of that document.

AGGREGATION WITH INDEPENDENT WORKS

A compilation of the Document or its derivatives with other separate and independent

documents or works, in or on a volume of a storage or distribution medium, is called an

“aggregate” if the copyright resulting from the compilation is not used to limit the legal rights

of the compilation’s users beyond what the individual works permit. When the Document is

included in an aggregate, this License does not apply to the other works in the aggregate

which are not themselves derivative works of the Document.

If the Cover Text requirement of section 3 is applicable to these copies of the Document, then

if the Document is less than one half of the entire aggregate, the Document’s Cover Texts

may be placed on covers that bracket the Document within the aggregate, or the electronic

equivalent of covers if the Document is in electronic form. Otherwise they must appear on

printed covers that bracket the whole aggregate.

TRANSLATION

Translation is considered a kind of modication, so you may distribute translations of the

Document under the terms of section 4. Replacing Invariant Sections with translations requires

special permission from their copyright holders, but you may include translations of some

or all Invariant Sections in addition to the original versions of these Invariant Sections. You

may include a translation of this License, and all the license notices in the Document, and

any Warranty Disclaimers, provided that you also include the original English version of this

License and the original versions of those notices and disclaimers. In case of a disagreement

between the translation and the original version of this License or a notice or disclaimer, the

original version will prevail.

If a section in the Document is Entitled “Acknowledgements”, “Dedications”, or “History”,

the requirement (section 4) to Preserve its Title (section 1) will typically require changing

the actual title.

108

TERMINATION

You may not copy, modify, sublicense, or distribute the Document except as expressly

provided for under this License. Any other attempt to copy, modify, sublicense or distribute the

Document is void, and will automatically terminate your rights under this License. However,

parties who have received copies, or rights, from you under this License will not have their

licenses terminated so long as such parties remain in full compliance.

FUTURE REVISIONS OF THIS LICENSE

The Free Software Foundation may publish new, revised versions of the GNU Free

Documentation License from time to time. Such new versions will be similar in spirit to the

present version, but may dier in detail to address new problems or concerns. See http://

www.gnu.org/copyleft/.

Each version of the License is given a distinguishing version number. If the Document species

that a particular numbered version of this License “or any later version” applies to it, you

have the option of following the terms and conditions either of that specied version or of

any later version that has been published (not as a draft) by the Free Software Foundation. If

the Document does not specify a version number of this License, you may choose any version

ever published (not as a draft) by the Free Software Foundation.

ADDENDUM: How to use this License for your documents

To use this License in a document you have written, include a copy of the License in the

document and put the following copyright and license notices just after the title page:

Permission is granted to copy,

distribute and/or modify this document

under the terms of the GNU Free

Documentation License, Version 1.2

or any later version published by the

Free Software Foundation;

with no Invariant Sections, no Front-

Cover Texts, and no Back-Cover Texts.

A copy of the license is included in

the section entitled “GNU

Free Documentation License”.

If you have Invariant Sections, Front-Cover Texts and Back-Cover Texts, replace the

“with...Texts.” line with this:

with the Invariant Sections being LIST

THEIR TITLES, with the

Front-Cover Texts being LIST, and with

the Back-Cover Texts being LIST.

If you have Invariant Sections without Cover Texts, or some other combination of the three,

merge those two alternatives to suit the situation.

If your document contains nontrivial examples of program code, we recommend releasing

these examples in parallel under your choice of free software license, such as the GNU General

Public License, to permit their use in free software.

109

Administrator Guide Obs Admin

Navigation menu

Versions of this User Manual:

Views

Navigation
