1 Main Page
2 Hierarchical Index
- 2.1 Class Hierarchy
3 Class Index
- 3.1 Class List
4 Class Documentation

Time of Day

Generated by Doxygen 1.8.8

Thu Dec 18 2014 13:50:07

Contents

1 Main Page 1

1.1 About ................................................. 1

1.2 Getting Started ............................................ 3

1.3 Day & Night Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.4 Weather Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.5 Time Zone & Location Coordinates .................................. 4

1.6 Ambient Light & Reﬂections ...................................... 4

1.7 Rendering Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.8 Performance Remarks ........................................ 5

1.9 Rendering Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.10 Custom Shaders ............................................ 6

1.11 Networking .............................................. 6

1.12 Parameter Import & Export ...................................... 6

1.13 Example Scripts ............................................ 6

1.14 Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.15 Contact Information .......................................... 8

1.16 Literature ............................................... 8

1.17 Changelog ............................................... 8

2 Hierarchical Index 15

2.1 Class Hierarchy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3 Class Index 17

3.1 Class List ............................................... 17

4 Class Documentation 19

4.1 TOD_AmbientParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.2 TOD_Animation Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.2.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.3 TOD_AtmosphereParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.3.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

iv CONTENTS

4.4 TOD_Camera Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.4.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.5 TOD_CloudParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.5.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.6 TOD_Components Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.6.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.7 TOD_CycleParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.7.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.8 TOD_DayParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.8.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.9 TOD_FogParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.9.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.10 TOD_LightParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.10.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.11 TOD_MoonParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.11.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.12 TOD_NightParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.12.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.13 TOD_Parameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.13.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.14 TOD_PostEffectsBase Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.14.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.15 TOD_Rays Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.15.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.16 TOD_ReﬂectionParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.16.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.17 TOD_Resources Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.17.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.18 TOD_Sky Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.18.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.18.2 Member Function Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.18.2.1 FakeHDR2LDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.18.2.2 FakeHDR2LDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.18.2.3 FakeHDR2LDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.18.2.4 FakeHDR2LDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.18.2.5 LoadParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.18.2.6 OrbitalToLocal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.18.2.7 OrbitalToUnity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.18.2.8 RenderToCubemap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4.18.2.9 RenderToSphericalHarmonics . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

CONTENTS v

4.18.2.10 SampleAtmosphere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.18.2.11 SampleEquatorColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.18.2.12 SampleFogColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.18.2.13 SampleSkyColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.18.2.14 UpdateReﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.19 TOD_StarParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.19.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.20 TOD_SunParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.20.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.21 TOD_Time Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.21.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4.21.2 Member Function Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4.21.2.1 AddHours . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4.21.2.2 AddSeconds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4.21.2.3 ApplyTimeCurve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4.22 TOD_Weather Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4.22.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.23 TOD_WorldParameters Class Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.23.1 Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

Chapter 1

Main Page

1.1 About

Time of Day is a package to render realistic dynamic sky domes with day and night cycle, clouds, cloud shadows,

weather types and physically based atmospheric scattering.

Sky:

• Physically based sky shading

• Rayleigh & Mie scattering

• Highly customizable

• Dynamic weather manager

• Sun and moon god rays (Unity Pro)

Lighting:

• Full PBR & HDR support

• Realtime Unity 5 ambient light

• Realtime Unity 5 reﬂections

Clouds:

2 Main Page

• Dynamic wind speed & direction

• Conﬁgurable shape, color & scale

• Correctly projected cloud shadows

Time & Location:

• Dynamic day & night cycle

• Adjustable time progression curve

• Full longitude, latitude & time zone support

• Full Gregorian calendar support

• Rotating night sky

• Realistic sun position

• Realistic moon position and phase

Performance & Requirements:

• Extremely optimized shaders & scripts

• Zero dynamic memory allocations

• Supports shader model 2.0

• Supports all platforms

• Supports linear & gamma color space

• Supports forward & deferred rendering

• Supports HDR & LDR rendering

• Supports virtual reality hardware

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

1.2 Getting Started 3

[Forum Thread |Web Player |Documentation ]

You can expect a thoroughly documented, well-written and highly optimized code base.

All equations used in the shaders and scripts include references to the scientiﬁc papers they are based on.

1.2 Getting Started

1. Add the sky dome to your scene:

• Drag the prefab "Time of Day/Prefabs/Sky Dome" into your scene

• Tweak the parameters until you are satisﬁed with the result

2. Move the sky dome to the camera position in every frame:

• Select your camera and add the Time of Day camera script (Component ->Time of Day ->Camera

Main Script)

• Tag this camera game object as "MainCamera"

3. Render god rays on the main camera:

• Select your camera and add the Time of Day god ray script (Component ->Time of Day ->Camera

God Rays)

• Tweak the parameters until you are satisﬁed with the result

REMARK: The camera script moves the sky dome directly before clipping the scene, guaranteeing that all other

position updates have been processed. You should not move the sky dome in "LateUpdate" because this can cause

minor differences in the sky dome position between frames when moving the camera.

1.3 Day & Night Cycle

The sky dome prefab has a script TOD_Time attached to it that manages the dynamic day & night cycle. Enabling

and disabling this script enables and disables the automatic cycle.

The following parameters are being set by the script:

• TOD_Sky.Cycle.Hour

• TOD_Sky.Cycle.Day

• TOD_Sky.Cycle.Month

• TOD_Sky.Cycle.Year

The script TOD_Time offers a time curve property that can be modiﬁed via the Unity inspector to speed up or slow

down certain parts of the day-night cycle. The X axis of the graph denotes the current internal time, which always

progresses linearly. The Y axis of the graph denotes the time that is being set in the sky dome and is therefore

visible to the player. That means the higher the inclination of the curve the faster this certain part of the day passes

by.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4 Main Page

1.4 Weather Manager

The script TOD_Weather can be used to automatically set various parameters of TOD_Sky according to weather

presets.

The following parameters are being set by the script:

• TOD_Sky.Atmosphere.Fogginess

• TOD_Sky.Clouds.Density

• TOD_Sky.Clouds.Sharpness

• TOD_Sky.Clouds.Brightness

1.5 Time Zone & Location Coordinates

The TOD_Sky.World and TOD_Sky.Cycle parameter sections allow for conﬁguration of the sky dome to represent

the exact sun and moon movement of any location on the planet depending on Gregorian date, UTC/GMT time zone

and geographic coordinates. This also allows to recreate eclipses just as they would occur in real life. It is important

to manually set the correct time zone offset (TOD_Sky.World.UTC) that ﬁts the longitude and latitude parameters in

order to use local time instead of UTC.

All of those parameters are completely optional - if the sky dome should be used in a generic fantasy world they

can simply be ignored and left at their default values.

1.6 Ambient Light & Reﬂections

Unity 5 introduced new ways to approximate ambient light and reﬂections. For a primer on the new features, watch

the Unite 2014 talk.

Time of Day offers full support for Unity 5 image-based ambient light and reﬂections. It can update both the per-

scene ambient light and a realtime reﬂection probe at runtime. Ambient light can be disabled (i.e. not managed by

Time of Day), a solid color, a gradient or spherical harmonics. Reﬂections can be disabled (i.e. not managed by

Time of Day) or a cubemap. Both ambient light and reﬂections contain approximations of the atmosphere in the top

half and lerp to the conﬁgured ambient light color towards the bottom half. This means the ambient light color set

on the Time of Day prefab can be looked at as the ground color of the scene in those cases.

Time of Day also allows you to include some or all layers of your scene in the reﬂection probe bake process. This is

to be used with care since updating a reﬂection probe with various reﬂected objects is an expensive operation. For

most scenes it should be ﬁne to only render the sky dome to the realtime reﬂection probe by using "Skybox" clear

ﬂags and a "Nothing" culling mask.

1.7 Rendering Quality

There are various different quality levels for both the sky dome and the cloud shader. Those quality settings can be

conﬁgured both dynamically at runtime and directly in the Unity editor window using two inspector enums.

TOD_CloudQuality:

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

1.8 Performance Remarks 5

• Bumped offers complex cloud shading with dynamic density and cloud normal mapping

• Density offers simpliﬁed cloud shading with dynamic density but without normal mapping

• Fastest offers extremely simpliﬁed cloud shading with simpliﬁed cloud shape calculations

TOD_MeshQuality:

• High tessellation sky dome (2562 verts) and moon (574 verts)

• Medium tessellation sky dome (642 verts) and moon (294 verts)

• Low tessellation sky dome (162 verts) and moon (148 verts)

For the best visual quality it is recommended to use Time of Day with the following Unity Pro setup:

• Linear color space

• HDR enabled on the main camera

• The following image effects on the main camera (in that order)

1. "Image Effects ->Bloom and Glow ->Bloom" or "SE Natural Bloom & Dirty Lens" from the Asset Store

2. "Image Effects ->Color Adjustments ->Tonemapping"

3. "Image Effects ->Color Adjustments ->Color Correction" or "Amplify Color" from the Asset Store

1.8 Performance Remarks

• The size of a web player with just the sky dome is only around 200KB as most equations are evaluated

dynamically

• All scripts and shaders are highly optimized and will not have a signiﬁcant FPS impact on desktop computers

• Older mobile devices should switch to the cloud and dome quality settings that offer suitable performance

• Cloud shadows utilize a Unity projector and require another draw call for all objects they are projected on

• Reducing the texture resolution in the cloud texture import settings can increase performance on mobile

• Realtime reﬂections that include objects other than the sky dome can be expensive and should be used with

care

1.9 Rendering Order

All components of the sky dome are being rendered after the opaque but before the transparent meshes of your

scene.That means that only areas of the sky dome that are not being occluded by any other geometry have to be

rendered.

The rendering order of the sky dome components is the following:

• Transparent-490 Space Dome (if not manually disabled)

• Transparent-480 Sun Plane (if on screen)

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

6 Main Page

• Transparent-470 Moon Mesh (if on screen)

• Transparent-460 Atmosphere (if not manually disabled)

• Transparent-455 Clear Alpha (if god rays are enabled)

• Transparent-450 Cloud Layer (if not manually disabled)

This leads to 3-6 draw calls to render the complete sky dome, depending on the scene setup.

1.10 Custom Shaders

The TOD_Sky script sets some global shader parameters that can be used in your custom shaders. For a complete

list see the TOD_Base.cginc ﬁle. Any of those variables can be used in any shader by simply deﬁning uniform

variables with the same name, which will then automatically be set to the most recent values every frame. It is also

possible to simply include TOD_Base.cginc to get access to all variables.

In addition to those base variables there is also TOD_Scattering.cginc, which offers functions to easily evaluate the

scattering equations in custom shaders. The method ﬂoat4 ScatteringColor(ﬂoat3 dir) is the easiest to use since it

automatically takes care of all the required calculations. It is recommended to call this function in a vertex shader

and interpolate the color to the fragment or surface shader, but it can also be used in image effects to implement

things like global fog.

1.11 Networking

• To network the date, synchronize the property TOD_Sky.Cycle.Ticks of type long

• To network the cloud movement, synchronize the property TOD_Sky.Components.Animation.CloudUV of type

Vector4

1.12 Parameter Import & Export

It is possible to export custom presets via the "Export" button in the TOD_Sky inspector panel and import them on

a different prefab or even in a different project via the "Import" button. Exported parameters can also be loaded at

runtime by using the appropriate API calls.

1.13 Example Scripts

The package comes with various example scripts to demonstrate sky dome integration.

• AudioAtDay / AudioAtNight / AudioAtWeather: Fade audio sources in and out according to a time of day or a

speciﬁc weather type

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

1.14 Frequently Asked Questions 7

• ParticleAtDay / ParticleAtNight / ParticleAtWeather: Fade particle systems in and out according to a time of

day or a speciﬁc weather type

• RenderAtDay / RenderAtNight / RenderAtWeather: Enable or disable renderer components according to a

time of day or a speciﬁc weather type

• LightAtDay / LightAtNight / LightAtWeather: Fade light intensities in and out according to a time of day or a

speciﬁc weather type

• DeviceTime: Automatically set the time of day to the device time on scene start

• LoadSkyFromFile: Load exported sky dome parameters at runtime from a TextAsset that can be assigned via

drag & drop

1.14 Frequently Asked Questions

Q: How can I get a TOD_Sky reference in my custom scripts?

•TOD_Sky.Instance keeps a static reference to the most recent sky dome that has been instantiated

•TOD_Sky.Instances keeps a static list of referenes to all sky domes that have been instantiated

Q: How can I use the sky dome with virtual reality devices like the Oculus Rift?

• Add the TOD_Camera script to one of the cameras (preferably the one that’s being rendered ﬁrst)

• The sky will render correctly without artifacts

Q: How can I render a cubemap or custom skybox at night?

• Select the shader "Time of Day/Space (Cube)" on the space material

• Assign your cubemap to the material

Q: How can I align the sky dome geographic directions with those of my scene?

• Rotate the sky dome around the y-axis such that the sun rises in the east of your scene

Q: How can I ﬁx Z-ﬁghting and sorting issues with the cloud shadows?

• Adjust the values for "Offset" directly in the shader code of the cloud shadow shaders

REMARK: Offset values have to be constants and can therefore only be adjusted directly in the shader code.

Suitable values depend on the depth buffer resolution of the targeted platform and hardware. While the default

values work in most scenarios, some scenes might require some further tweaking.

Q: How can I disable some part of the sky dome?

• Disable any child game object to keep that speciﬁc part of the sky dome from rendering

• You can also disable any script on the parent game object individually to disable that speciﬁc functionality

REMARK: Always disable entire child objects instead of their individual components like mesh renderers. The

enabled states of components are being be modiﬁed by the sky dome scripts, which will otherwise override your

changes.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

8 Main Page

1.15 Contact Information

If you have any questions that cannot be answered using the FAQ or documentation feel free to contact me:

• In the ofﬁcial forum thread of the package

• Via personal message on the Unity community forums

• Via Twitter

• Via my website

REMARK: I should always be able to reply within two work days. If I have not replied after several days, please try

using a different method to contact me as there might be an issue with the one you chose. If I am not available for

multiple days I will always try to announce this beforehand in the ofﬁcal forum thread.

1.16 Literature

The following literature has been used to implement physically correct atmospheric scattering:

1. Preetham, Shirley, Smits

2. Schafhitzel, Falk, Ertl

3. Bruneton, Neyret

4. Riley, Ebert, Kraus, Tessendorf, Hansen

5. Hoffman, Preetham

6. Nishita, Sirai, Tadamura, Nakamae

7. Nielsen, Christensen

These papers are being referenced in the code in the following way:

See [N] page P equation (E)

Where the letters are being replaced according to this:

• N: Paper #

• P: Page #

• E: Equation # (if available)

1.17 Changelog

VERSION 2.3.4

-------------

- Fixed moon position being vastly off

- Fixed space texture tiling to infinity towards the horizon (could cause issues when rotating)

- Tweaked horizon line for low haziness values

- Tweaked the default prefab parameters

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

1.17 Changelog 9

- Disabled headless mode detection in-editor

- Simplified and optimized TOD_Time calculations

- Changed rendering order of sun and moon to support eclipses

- Made inspector adjustments to the cycle properties correctly progress day, month and year

- Made moon phase get calculated directly from the sun position

- Removed Moon.Phase inspector variable (no longer required)

- Removed Progress*fields from TOD_Time (no longer required)

- Removed Moon (Flat) shader (adjusting Moon.Contrast now has the same effect)

VERSION 2.3.3

-------------

- Added TOD_Sky.LoadParameters(...) to load exported parameters at runtime

- Added LoadSkyFromFile example script

- Added skybox material that is assigned to the render settings skybox for dynamic GI

- Added TOD_Sky.Moon.HaloSize to increase or decrease the size of the moon halo

- Added TOD_Sky.Reflection.ClearFlags to specify which clear flags to use for the reflection cubemap

- Added TOD_Sky.Reflection.CullingMask to specify which layers to include in the reflection cubemap

- Added warning to TOD_Camera if skybox clear flags are used (redundant with a sky dome)

- Made parameter export and import remember the most recently specified path

- Made the reflection cubemap less bright in the bottom hemisphere

- Made light source color fall off to black before switching positions

- Changed reflection baking to use a native Unity 5 realtime reflection probe (better quality)

- Changed TOD_Sky.RenderToSphericalHarmonics(...) and TOD_Sky.RenderToCubemap(...) APIs

- Renamed TOD_Components.*Shader to TOD_Components.*Material

- Removed TOD_Sky.Fog.UpdateInterval (it’s fast enough to update every frame anyhow)

- Removed TOD_Sky.Fog/Ambient/Reflection.Directional (now part of fog mode, unused for the others)

- Removed some parameters that are unused on Unity 3 and Unity 4 if running those versions

VERSION 2.3.2

-------------

- Fixed that the sky dome would go into headless mode (i.e. black) on mobile

- Fixed an error in Unity 5 Beta 14 (this means Beta 13 is no longer supported)

- Made sky fogginess correctly affect the light intensity

- Optimized coloring calculations

- Renamed TOD_AmbientType.Flat to TOD_AmbientType.Color

- Renamed TOD_AmbientType.Trilight to TOD_AmbientType.Gradient

- Renamed TOD_Sky.RenderToSH3(...) to TOD_Sky.RenderToSphericalHarmonics(...)

VERSION 2.3.1

-------------

- Fixed errors if sky dome renderers or mesh filters were deleted (i.e. when running on a server)

- Fixed that ScatteringColor(...) in TOD_Scattering.cginc would add some stuff to its alpha value

- Fixed issues if the main camera of a scene changes after scene load

- Added TOD_Sky.World.Horizon to specify whether or not to adjust the horizon to zero level

- Added TOD_Sky.UpdateFog(), TOD_Sky.UpdateAmbient() and TOD_Sky.UpdateReflection() to API

- Added headless mode detection to skip some rendering calculations when running on a server

- Made TOD_Sky.SampleAtmosphere(...) only include the moon halo if directLight is true

- Made the moon halo always fade out when the moon is below the horizon

- Made TOD_Sky.Cycle.DateTime have DateTimeKind.Utc instead of DateTimeKind.Unspecified

- Made the fog color values clamp between 0 and 1 to avoid super bright glowing directional fog

- Changed TOD_AdditiveColor and TOD_MoonHaloColor in TOD_Base.cginc to float3 (alpha is unused)

- Removed TOD_Components.CameraTransform as it is no longer required

VERSION 2.3.0

-------------

- Fixed atmosphere banding towards nighttime by adding dithering from a lookup texture

- Fixed that SetupQualitySettings() would allocate 0.6kb of memory every frame

- Added TOD_Animation.RandomInitialCloudUV to randomize the clouds at startup

- Added optional shader "Moon (Flat)" for a flatter moon shading

- Added TOD_Sky.World.ZeroLevel to set the zero / water level of a scene

- Added TOD_Camera.DomePosOffset to specify a sky dome position offset relative to the camera

- Added TOD_Sky.Initialized to check whether or not the sky dome has been initialized

- Made RenderSettings.ambientLight get set in every ambient mode (for legacy shaders)

- Made fog, ambient and reflection really get updated every single frame if their update interval is 0

- Made sun and moon meshes fade out exactly at the horizon line

- Made the color of the sky dome beneath the horizon line fade to a darker tone towards the bottom

- Made the atmosphere shader additive (greatly improves moon / atmosphere blend)

- Made the night texture fade to black at daytime (due to the new additive atmosphere)

- Made the moon phase always be rotated towards the direction of the orbital path of the moon

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

10 Main Page

- Made the sun texture converge towards a circle for very high sun mesh brightnesses

- Moved more enums to the global namespace and added the TOD_ prefix

- Moved Cycle.Longitude, Cycle.Latitude and Cycle.UTC to the World parameter category

- Changed the returned alpha value of TOD_Sky.SampleAtmosphere(...) to one

- Changed the returned alpha value of ScatteringColor(...) in TOD_Scattering.cginc to one

- Renamed TOD_Sky+Variables to TOD_Sky+API (now contains all API methods and properties)

- Renamed TOD_Sky+Quality to TOD_Sky+Settings (now sets all project and scene settings)

- Renamed TOD_SunShafts to TOD_Rays (now handles god rays of both sun and moon)

- Renamed TOD_Sky.SunShaftColor to TOD_Sky.RayColor

- Renamed TOD_Sky.Light.ShaftColoring to TOD_Sky.Light.RayColoring

- Renamed TOD_Sky.Sun.ShaftColor to TOD_Sky.Sun.RayColor and added TOD_Sky.Moon.RayColor

- Removed TOD_Sky.World.HorizonOffset and TOD_Sky.World.ViewerHeight (now covered by ZeroLevel)

- Removed TOD_AmbientType.Hemisphere since it was removed from Unity 5 (use trilight instead)

- Removed clampAlpha parameter from TOD_Sky.SampleAtmosphere(...)

- Replaced TOD_Sky.Ambient.Exposure with Day.AmbientMultiplier and Night.AmbientMultiplier

- Replaced TOD_Sky.Reflection.Exposure with Day.ReflectionMultiplier and Night.ReflectionMultiplier

VERSION 2.2.0

-------------

- Fixed a moon shader compilation error in Unity 5 on Windows

- Added support for Unity 5 ambient light modes (tricolor, hemisphere, spherical harmonics)

- Added support for Unity 5 realtime reflections (sky cubemap)

- Added TOD_Sky.Stars.Position to specify whether or not to move the stars with the earth rotation

- Added TOD_Sky.SampleAtmosphere(...) overload that ignores direct light

- Added TOD_Sky.RenderToCubemap(...) with various overloads

- Added TOD_Sky.RenderToSH3(...) with various overloads

- Added TOD_Sky.SampleFogColor(), TOD_Sky.SampleSkyColor() and TOD_Sky.SampleEquatorColor()

- Added optional shader to project cubemaps onto the space object

- Removed TOD_Sky.FogColor (access RenderSettings.fogColor instead)

- Removed TOD_Sky.Stars.Density (directly adjust the texture instead)

- Moved all fog parameters to TOD_Sky.Fog

- Moved all ambient light parameters to TOD_Sky.Ambient

- Moved all reflection parameters to TOD_Sky.Reflection

- Made audio example scripts set the volume in OnEnable()

VERSION 2.1.1

-------------

- Fixed various issues in gamma color space

- Fixed time not properly incrementing in some cases if TOD_Time.ProgressDate was checked

- Fixed some inconsistencies with the light and cloud color calculations, leading to better results overall

- Fixed cloud shadow shape calculation being off for the lowest quality setting

- Fixed cloud UV world space adjustments being off for rotated sky domes

- Rescaled TOD_Sky.Light.CloudColoring (custom prefabs have to be readjusted accordingly)

- Rescaled TOD_Sky.Night.CloudMultiplier (custom prefabs have to be readjusted accordingly)

- Added TOD_Sky.Day.CloudColor and TOD_Sky.Night.CloudColor

- Added TOD_Sky.Instance and TOD_Sky.Instances to easily get the most recent sky or all skies in the scene

- Added TOD_Animation.WorldSpaceCloudUV

- Added overloads of T() and ScatteringColor() that take distance into account to TOD_Scattering.cginc

- Removed TOD_Base.cginc include from TOD_Scattering.cginc (now has to be included in the shader file)

- Brought the sun shaft image effect up to date

- Changed the code indentation policy (indent with tabs, align with spaces)

- Prepared more parts of the codebase for Unity 5

VERSION 2.1.0

-------------

- Added XML export and import of the prefab parameters

- Added TOD_Scattering.cginc that contains functions to sample the scattering color

- Added TOD_Base.cginc that contains shader parameters and common transformations

- Added TOD_World2Sky and TOD_Sky2World shader matrices

- Added TOD_Sky.Stars.Brightness parameter to make stars get affected by bloom image effects

- Added TOD_Sky.LocalMoonDirection, TOD_Sky.LocalSunDirection and TOD_Sky.LocalLightDirection

- Added TOD_Sky.Sun.MeshBrightness and TOD_Sky.Moon.MeshBrightness

- Added TOD_Sky.Sun.MeshContrast and TOD_Sky.Moon.MeshContrast

- Added TOD_Sky.Clouds.Glow to adjust the light source glow applied to the clouds

- Added TOD_Sky.Atmosphere.FakeHDR to adjust the fake HDR mapping that is applied at dusk and dawn

- Added TOD_Time.TimeCurve to specify a time progression curve for the day night cycle

- Added two new cloud textures (the old ones can be deleted if unused)

- Removed two unnecessary calls to InverseTransformDirection from TOD_Sky.SampleAtmosphere

- Improved space texture to better work with the new brightness parameter

- Improved visual quality of the atmosphere when using HDR

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

1.17 Changelog 11

- Improved cloud layer rendering

- Made TOD_Sky.Cycle.DateTime accurate to one millisecond rather than one second

- Made camera scripts automatically search for the sky dome if no reference is set in the inspector

- Moved all moon parameters to TOD_Sky.Moon.X (was TOD_Sky.Night.MoonX and TOD_Sky.Cycle.MoonX)

- Moved all sun parameters to TOD_Sky.Sun.X (was TOD_Sky.Day.SunX)

VERSION 2.0.9

-------------

- Fixed time not getting incremented properly

- Fixed inaccuracies when progressing time and moon phase with extremely high frame rates

- Fixed inaccuracies when progressing time and moon phase with extremely fast time scales

VERSION 2.0.8

-------------

- Fixed that sun and moon could visibly pop in and out if scaled extremely huge

- Fixed that the date would not get fully incremented for extremely fast time scales

- Fixed that the sun shafts could go through clouds

- Tweaked the TOD_Sky.IsDay and TOD_Sky.IsNight thresholds

- Replaced TOD_Time.UpdateInterval with TOD_Sky.Light.UpdateInterval (now only affects the light source)

- Prepared parts of the codebase for Unity 5 (specifically the new transform behaviour)

VERSION 2.0.7

-------------

- Fixed an issue where the ambient light color would never fully lerp to the night value

VERSION 2.0.6

-------------

- Replaced Day/Night.AmbientIntensity with Day/Night.AmbientColor to offer more customization options

- Added Light.AmbientColoring to adjust ambient light coloring at dusk and dawn

- Added example scripts to enable / disable lights in the scene at day / night / weather

- Added inspector variable to adjust the time update interval in TOD_Time

- Added option to use the real-life moon position rather than the fake "opposite to sun" moon position

- Made all components of TOD_Sky initialize before Start() so that they are accessible from other scripts

- Disabled the automatic light source shadow type adjustment so that the user can manually set it

VERSION 2.0.5

-------------

- Changed cloud scale parameters from float to 2D vectors to define different scales in x and y direction

- Fixed TOD_Camera always causing the scene to be edited if enabled

- Fixed cloud inconsistencies between linear and gamma color space

- Fixed moon halo disappearing in gamma color space and made the color alpha affect its visibility

- Fixed an issue where the demo mouse look script could overwrite previously imported Standard Assets

- Fixed possible sun and moon gimbal lock that could cause them to spin towards zenith

- Fixed sun shafts being too faint in some setups

- Improved overall lighting calculations

- Improved moon visuals

- Made the sky dome play nice with "depth only" clear flags

- Made the cloud coloring still darken the clouds even for very low values

- Made Components.Animation.CloudUV modulo with the cloud scale to avoid unnecessarily large values

- Added inspector variables to adjust sun shaft base color and sun shaft coloring

- Added the property Cycle.Ticks to get the time information as a long for easy network synchronization

- Added the property Cycle.DateTime to get the time information as a System.DateTime

- Added an inspector variable to set a minimum value for the light source height

VERSION 2.0.4

-------------

- Added a property for the atmosphere renderer component to TOD_Components

- Added properties for all child mesh filter components to TOD_Components

- Changed the quality settings to be adjustable at runtime via public enum inspector variables

- Merged the three prefabs into a single prefab as separate quality prefabs are no longer required

- Fixed the materials always showing up in version control

- Fixed the sky dome always causing the scene to be modified and the editor always asking to save on close

- Fixed the customized sky dome inspector not always looking like the default inspector

- Improved the performance of all cloud shaders by reducing interpolations from frag to vert

- Improved the visuals of all cloud shaders and streamlined their style

- Increased the default cloud texture import resolution to 1024x1024

- Added a white noise texture for future use

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

12 Main Page

VERSION 2.0.3

-------------

- Fixed all issues with DX11 rendering in order to fully support DX11 from this point on

VERSION 2.0.2

-------------

- Fixed an issue where the image effect shaders could overwrite previously imported Standard Assets

VERSION 2.0.1

-------------

- Changed date and time organization to represent the valid Gregorian calendar

- Addressed issues with the Unity sun shaft image effect by providing a modified image effect

- Fixed clouds not correctly handling the planetary atmosphere curvature

- Fixed clouds not offsetting according to the world position of the sky dome

- Fixed cloud glow passing through even the thickest of clouds

- Fixed cloud shadow projection

- Fixed Light.Falloff not affecting the toggle point of the light position between sun and moon

- Automatically disable the corresponding shadows if Day/Night/Clouds.ShadowStrength is set to 0

- Removed Clouds.ShadowProjector toggle as it is no longer required

- Tweaked the old moon halo to not require an additional draw call and added it back in

- Made the sky dome position in world space add an offset to the cloud UV coordinates

- Added Light.Coloring to adjust the light coloring separate from the sky coloring

- Rescaled some parameters for easier use and tweaked their default values

VERSION 2.0.0

-------------

- Moved all documentation to Doxygen

- Renamed the folder "Sky Assets" to "Assets"

- Made the color space be detected automatically by default

- Reworked the sun texture and shader

- Allow light source intensities greater than one

- Reworked the way ambient light is being calculated

- Reworked the way light affects the atmosphere and clouds

- Improved all scattering calculations, especially the integral approximation

- Automatically disable space the game object at night

- Added a public method to sample the sky dome color in any viewing direction

- Added a fog bias parameter to lerp between zenith and horizon color

- Adjusted the atmosphere alpha calculation

- Added a parameter to easily adjust the scattering color

- Added shader parameters for the moon texture color and contrast

- Adjusted the render queue positions

- Removed the moon halo material as it is no longer required

- Added the physical scattering model to the night sky

- Greatly improved the weather system

- Added fog and contrast parameters to the atmosphere

- Restructured the parameter classes to be more intuitive to use

- Moved all component references into a separate class

- Made the sky presets be applied via editor script rather than separate prefabs

- Improved cloud shading and performance across the board

- Removed the cloud shading parameter

- Added cloud glow from the sun and moon

- Added sky and cloud tone multipliers to sun and moon

- Added viewer height and horizon offset parameters

- Slightly improved overall performance

- Replaced ambient intensity with two parameters for sun and moon

- Replaced the two directional lights with a single one that automatically follows either sun or moon

VERSION 1.7.3

-------------

- Added two parameters "StarTiling" and "StarDensity" to the "Night" section

- Added "Offset -1, -1" to the cloud shadow shaders to avoid Z-fighting on some platforms

- Tweaked the cloud shader for more consistent results in linear and gamma color space

- Tweaked the moon texture to be a lot brighter by default, especially on mobile

- Tweaked the automatically calculated fog color to be similar to the horizon color

- Removed the property "Brightness" from the moon shader as it is no longer needed

VERSION 1.7.2

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

1.17 Changelog 13

-------------

- Fixed the ambient light calculation being too dark, even with high ambient light parameter values

- Added the properties "SunZenith" and "MoonZenith" to access sun and moon zenith angles in degrees

- Added a paramter "Halo" to adjust the moon halo intensity and made its color be derived from the light

- Changed several parameters to be clamped between 0 and 1

- Changed the name of the property "OrbitRadius" to "Radius"

- Tweaked the moon phase calculation of both moon mesh and moon halo

- Tweaked several default parameter values of the prefabs

VERSION 1.7.1

-------------

- Changed the default cardinal direction axes of the sky dome (x axis is now west/east, z axis south/north)

- Removed the property "ZenithFactor" as it is no longer being used

- Moved all child object references into a separate toggleable section called "Children"

- Tweaked the default parameters of the prefabs (brightness, haziness, cloud color, moon light intensity)

- Tweaked the calculations of the moon light color, ambient light at night and cloud tone at night

- Tweaked the default sun and moon base color based on good real life approximations

- Tweaked the moon halo

- Renamed the parameter "ShadowAlpha" in "Clouds" to "ShadowStrength"

- Added the parameter "ShadowStrength" for the sun and moon lights

VERSION 1.7.0

-------------

- Fixed an issue where the sun could incorrectly travel around the north,

even though the location is in the northern hemisphere (Thanks Gregg!)

- Fixed an issue that led to the brightest parts of the sky dome being slightly too dark

- Fixed the automatically calculated fog color not being exactly the same as the horizon

- Added a name prefix to all components to prevent name collisions with other packages

- Added cloud shadows (can be disabled)

- Added UTC time zone support

- Added a parameter to configure the color of the light reflected by the moon

- Added parameters for wind direction in degrees and wind speed in knots

- Added an option to automatically adjust the ambient light color (disabled by default)

- Added a parameter to adjust the sun’s light color

- Added a plane with an additive shader at the sun’s position to always render a circular sun

- Added dynamic cloud shape adjustments to the "Low" prefab (cloud weather types will now also work)

- Added shading calculations to the "Low" and "Medium" prefabs

- Improved the performance of "Low" prefab by reducing the vertex count

- Improved the performance of "Low" prefab by removing the moon halo for that prefab by default

- Improved the cloud shading of the "High" prefab

- Improved the visual quality of the weather presets

- Improved the calculation of the sun’s position

- Changed the automatic fog color adjustment to be disabled by default

- Changed the moon halo to adjust according to the moon phase

- Changed the name of the parameter from "Color" to "AdditiveColor" for both day and night

- Changed the cloud animation to support network synchronization

- Changed the default tiling of the stars texture to 1 (was 3)

- Changed the moon vertex count in all presets to scale with the device performance

- Removed the parameter "CloudColor" from "NightParameters" as it is now derived from the moon light color

VERSION 1.6.1

-------------

- Fixed an issue related to HDR rendering

VERSION 1.6.0

-------------

- Improved the visuals and functionality of the weather system

(most METAR codes should now be possible to achieve visually)

- Improved performance of the moon halo shader

- Added official support for HDR rendering

- Replaced the sun mesh with implicit sun scattering in the atmosphere layer

to reduce dome vertex count, draw calls and pixel overdraw

- Added an additional quality level (now Low/Medium/High instead of Desktop/Mobile)

- Added sky dome presets from various locations around the globe for easier use

- Tweaked the wavelength constants a little to allow for a wider range of sun coloring adjustments

VERSION 1.5.1

-------------

- Fixed an issue causing a missing sun material in the mobile prefab

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

14 Main Page

VERSION 1.5.0

-------------

- Enabled mip mapping of the stars texture by default to avoid flickering

- Added support for using custom skyboxes at night (see readme for details)

- Greatly improved the parametrization of the sun color influence at sunrise and sunset

- Added internal pointers to commonly used components for faster access

- Split the sun and moon parameters into their own property classes

- Adjusted the cloud shading calculation to keep it from darkening some clouds too much

- Adjusted the color wavelengths to produce a more realistic blue color of the sky by default

- Made the moon phase influence the intensity of the sunlight reflected by the moon

- Replaced the lens flares with custom halo shaders that are correctly being occluded by clouds

- Enabled the new halo effects on mobile

- Moved all shaders into a "Time of Day" category

- Added a basic weather manager with three weather types

VERSION 1.4.0

-------------

- Added "Fog { Mode Off }" to the shaders to properly ignore fog

- Added the parameter "Night Cloud Color" to render clouds at night

- Added the parameter "Night Haze Color" to render some haze at night

- Added the parameter "Night Color" to add some color to the night sky

- Renamed the parameter "Haze" to "Haziness"

- Renamed the parameter "Sky Tone" to "Brightness"

- Renamed the properties "Day" and "Night" to "IsDay" and "IsNight"

- Restructured all sky parameters into groups

- Improved the sun lens flare texture

- Improved the stars texture

- Fixed a rendering artifact at the horizon for low haziness values

- Made the scattering calculation in gamma space look identical to linear space

VERSION 1.3.0

-------------

- Greatly improved performance on mobile devices

- Greatly improved sunset and sunrise visual quality

- Added a parameter to control how strongly the sun color affects the sky color

- Added realistic sun and moon lens flare effects

- Added two additional cloud noise textures

- Improved handling of latitude and longitude

- Made the sky dome render correctly independent of its rotation

VERSION 1.2.0

-------------

- Fixed some bugs regarding linear vs. gamma space rendering

- Fixed some issues with the horizon fadeout

- Adjusted sun and moon size

- Optimized sun and fog color calculation

- Greatly improved visual quality of the cloud system

- Added parameter to control cloud tone, allowing for dark clouds

- Added improved stars texture at night

- Added parameter to control the sun color falloff speed

VERSION 1.1.0

-------------

- First public release on the Asset Store

VERSION 1.0.0

-------------

- First private release for internal use

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

Chapter 2

Hierarchical Index

2.1 Class Hierarchy

This inheritance list is sorted roughly, but not completely, alphabetically:

MonoBehaviour

TOD_Animation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TOD_Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

TOD_Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

TOD_PostEffectsBase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

TOD_Rays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

TOD_Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

TOD_Sky . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

TOD_Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

TOD_Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

TOD_AmbientParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TOD_AtmosphereParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

TOD_CloudParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

TOD_CycleParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

TOD_DayParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

TOD_FogParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

TOD_LightParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

TOD_MoonParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

TOD_NightParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

TOD_Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

TOD_ReﬂectionParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

TOD_StarParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

TOD_SunParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

TOD_WorldParameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

16 Hierarchical Index

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

Chapter 3

Class Index

3.1 Class List

Here are the classes, structs, unions and interfaces with brief descriptions:

TOD_AmbientParameters

Parameters of the ambient mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TOD_Animation

Cloud animation class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TOD_AtmosphereParameters

Parameters of the atmosphere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

TOD_Camera

Camera class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

TOD_CloudParameters

Parameters of the clouds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

TOD_Components

Component manager class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

TOD_CycleParameters

Parameters of the day and night cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

TOD_DayParameters

Parameters that are unique to the day . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

TOD_FogParameters

Parameters of the fog mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

TOD_LightParameters

Parameters of the light source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

TOD_MoonParameters

Parameters that are unique to the moon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

TOD_NightParameters

Parameters that are unique to the night . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

TOD_Parameters

All parameters of the sky dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

TOD_PostEffectsBase

Post effects base class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

TOD_Rays

God ray class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

TOD_ReﬂectionParameters

Parameters of the reﬂection mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

TOD_Resources

Material and mesh wrapper class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

TOD_Sky

Main sky dome management class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

TOD_StarParameters

Parameters of the stars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

18 Class Index

TOD_SunParameters

Parameters that are unique to the sun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

TOD_Time

Time iteration class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

TOD_Weather

Weather management class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

TOD_WorldParameters

Parameters of the world . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

Chapter 4

Class Documentation

4.1 TOD_AmbientParameters Class Reference

Parameters of the ambient mode.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• TOD_AmbientType Mode = TOD_AmbientType.Color

Ambient light mode.

• ﬂoat UpdateInterval = 1.0f

Refresh interval of the ambient light probe in seconds.

4.1.1 Detailed Description

Parameters of the ambient mode.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.2 TOD_Animation Class Reference

Cloud animation class.

Public Attributes

• ﬂoat WindDegrees = 0.0f

Wind direction in degrees. = 0 for wind blowing in northern direction. = 90 for wind blowing in eastern direction. = 180

for wind blowing in southern direction. = 270 for wind blowing in western direction.

• ﬂoat WindSpeed = 3.0f

Speed of the wind that is acting upon the clouds.

20 Class Documentation

• bool WorldSpaceCloudUV = true

Whether or not to adjust the cloud coordinates when the sky dome moves.

• bool RandomInitialCloudUV = true

Whether or not the clouds should be randomized at startup.

Properties

• Vector4 CloudUV [get, set]

Current cloud UV coordinates. Can be synchronized between multiple game clients to guarantee identical cloud

positions.

• Vector4 OffsetUV [get]

Current offset UV coordinates. Is being calculated from the sky dome world position.

4.2.1 Detailed Description

Cloud animation class.

Component of the sky dome parent game object.

The documentation for this class was generated from the following ﬁle:

• TOD_Animation.cs

4.3 TOD_AtmosphereParameters Class Reference

Parameters of the atmosphere.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• Color ScatteringColor = Color.white

Artistic value to shift the scattering color of the atmosphere. Can be used to easily simulate alien worlds.

• ﬂoat RayleighMultiplier = 1.0f

[0, ∞] Intensity of the atmospheric Rayleigh scattering. Generally speaking this resembles the static scattering.

• ﬂoat MieMultiplier = 1.0f

[0, ∞] Intensity of the atmospheric Mie scattering. Generally speaking this resembles the angular scattering.

• ﬂoat Brightness = 1.0f

[0, ∞] Brightness of the atmosphere. This is being applied as a simple multiplier to the output color.

• ﬂoat Contrast = 1.0f

[0, ∞] Contrast of the atmosphere. This is being applied as a power of the output color.

• ﬂoat Directionality = 0.65f

[0, 1] Directionality factor that determines the size and sharpness of the glow around the light source.

• ﬂoat Haziness = 0.5f

[0, 1] Intensity of the haziness of the sky at the horizon.

• ﬂoat Fogginess = 0.0f

[0, 1] Density of the fog covering the sky. This does not affect the RenderSettings fog that is being applied to other

objects in the scene.

• ﬂoat FakeHDR = 0.5f

[0, 1] Amount of fake HDR at sunset.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.4 TOD_Camera Class Reference 21

4.3.1 Detailed Description

Parameters of the atmosphere.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.4 TOD_Camera Class Reference

Camera class.

Public Member Functions

• void DoDomeScaleToFarClip ()

• void DoDomePosToCamera ()

Public Attributes

•TOD_Sky sky

Sky dome reference inspector variable. Will automatically be searched in the scene if not set in the inspector.

• bool DomePosToCamera = true

Automatically move the sky dome to the camera position in OnPreCull().

• Vector3 DomePosOffset = Vector3.zero

The sky dome position offset relative to the camera.

• bool DomeScaleToFarClip = true

Automatically scale the sky dome to the camera far clip plane in OnPreCull().

• ﬂoat DomeScaleFactor = 0.95f

The sky dome scale factor relative to the camera far clip plane.

4.4.1 Detailed Description

Camera class.

Component of the main camera of the scene to move and scale the sky dome.

The documentation for this class was generated from the following ﬁle:

• TOD_Camera.cs

4.5 TOD_CloudParameters Class Reference

Parameters of the clouds.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

22 Class Documentation

Public Attributes

• ﬂoat Density = 1.0f

[0, ∞] Density multiplier of the clouds.

= 0 no clouds.

>0 thicker clouds that are less transparent.

• ﬂoat Sharpness = 3.0f

[0, ∞] Sharpness multiplier of the clouds.

= 0 one giant cloud.

>0 several smaller clouds.

• ﬂoat Brightness = 2.0f

[0, ∞] Brightness multiplier of the clouds.

= 0 black clouds.

>0 brighter clouds.

• ﬂoat Glow = 1.0f

[0, ∞] Glow multiplier of the clouds.

• ﬂoat ShadowStrength = 0.0f

[0, 1] Opacity of the cloud shadows.

• Vector2 Scale1 = new Vector2(3, 3)

[1, ∞] Scale of the ﬁrst clouds.

• Vector2 Scale2 = new Vector2(7, 7)

[1, ∞] Scale of the second clouds.

4.5.1 Detailed Description

Parameters of the clouds.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.6 TOD_Components Class Reference

Component manager class.

Public Member Functions

• void Initialize ()

Initializes all component references.

Public Attributes

• GameObject Sun = null

Sun child game object reference.

• GameObject Moon = null

Moon child game object reference.

• GameObject Atmosphere = null

Atmosphere child game object reference.

• GameObject Clear = null

Clear child game object reference.

• GameObject Clouds = null

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.6 TOD_Components Class Reference 23

Clouds child game object reference.

• GameObject Space = null

Space child game object reference.

• GameObject Light = null

Light child game object reference.

• GameObject Projector = null

Projector child game object reference.

• Transform DomeTransform

Transform component of the sky dome game object.

• Transform SunTransform

Transform component of the sun game object.

• Transform MoonTransform

Transform component of the moon game object.

• Transform LightTransform

Transform component of the light source game object.

• Transform SpaceTransform

Transform component of the space game object.

• Renderer SpaceRenderer

Renderer component of the space game object.

• Renderer AtmosphereRenderer

Renderer component of the atmosphere game object.

• Renderer ClearRenderer

Renderer component of the clear game object.

• Renderer CloudRenderer

Renderer component of the cloud game object.

• Renderer SunRenderer

Renderer component of the sun game object.

• Renderer MoonRenderer

Renderer component of the moon game object.

• MeshFilter SpaceMeshFilter

MeshFilter component of the space game object.

• MeshFilter AtmosphereMeshFilter

MeshFilter component of the atmosphere game object.

• MeshFilter ClearMeshFilter

MeshFilter component of the clear game object.

• MeshFilter CloudMeshFilter

MeshFilter component of the cloud game object.

• MeshFilter SunMeshFilter

MeshFilter component of the sun game object.

• MeshFilter MoonMeshFilter

MeshFilter component of the moon game object.

• Material SpaceMaterial

Main material of the space game object.

• Material AtmosphereMaterial

Main material of the atmosphere game object.

• Material ClearMaterial

Main material of the clear game object.

• Material CloudMaterial

Main material of the cloud game object.

• Material SunMaterial

Main material of the sun game object.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

24 Class Documentation

• Material MoonMaterial

Main material of the moon game object.

• Material ShadowMaterial

Main material of the projector game object.

•Light LightSource

Light component of the light source game object.

•Projector ShadowProjector

Projector component of the shadow projector game object.

•TOD_Sky Sky

Sky component of the sky dome game object.

•TOD_Animation Animation

Animation component of the sky dome game object.

•TOD_Time Time

Time component of the sky dome game object.

•TOD_Weather Weather

Weather component of the sky dome game object.

•TOD_Resources Resources

Resource container component of the sky dome game object.

•TOD_Rays Rays

God ray component of the camera game object if available.

4.6.1 Detailed Description

Component manager class.

Component of the main camera of the scene.

The documentation for this class was generated from the following ﬁle:

• TOD_Components.cs

4.7 TOD_CycleParameters Class Reference

Parameters of the day and night cycle.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• ﬂoat Hour = 12

[0, 24] Time of the day in hours.

= 0 at the start of the day.

= 12 at noon.

= 24 at the end of the day.

• int Day = 15

[1, 28-31] Current day of the month.

• int Month = 6

[1, 12] Current month of the year.

• int Year = 2000

[1, 9999] Current year.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.8 TOD_DayParameters Class Reference 25

Properties

• System.DateTime DateTime [get, set]

All time information as a System.DateTime instance.

• long Ticks [get, set]

All time information as a single long. Value corresponds to the System.DateTime.Ticks property.

4.7.1 Detailed Description

Parameters of the day and night cycle.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.8 TOD_DayParameters Class Reference

Parameters that are unique to the day.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• Color AdditiveColor = new Color32(0, 0, 0, 255)

Artistic value for an additive color at day.

• Color AmbientColor = new Color32(20, 25, 30, 255)

Color of the ambient light at day.

• Color CloudColor = new Color32(255, 255, 255, 255)

Color of the clouds at night.

• ﬂoat SkyMultiplier = 1.0f

[0, 1] Sky opacity multiplier at day.

• ﬂoat CloudMultiplier = 1.0f

[0, 1] Cloud tone multiplier at day.

• ﬂoat AmbientMultiplier = 1.0f

[0, ∞] Brightness of ambient light at day.

• ﬂoat ReﬂectionMultiplier = 1.0f

[0, ∞] Brightness of reﬂected light at day.

4.8.1 Detailed Description

Parameters that are unique to the day.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

26 Class Documentation

4.9 TOD_FogParameters Class Reference

Parameters of the fog mode.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• TOD_FogType Mode = TOD_FogType.Color

Fog color mode.

• ﬂoat HeightBias = 0.1f

[0, 1] Fog color sampling height.

= 0 fog is atmosphere color at horizon.

= 1 fog is atmosphere color at zenith.

4.9.1 Detailed Description

Parameters of the fog mode.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.10 TOD_LightParameters Class Reference

Parameters of the light source.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• ﬂoat UpdateInterval = 0.0f

Light source position update interval in seconds. Zero means every frame.

• ﬂoat MinimumHeight = 0.0f

[0, 1] Controls how low the light source is allowed to go.

= -1 light source can go as low as it wants.

= 0 light source will never go below the horizon.

= +1 light source will never leave zenith.

• ﬂoat Falloff = 0.75f

[0, 1] Controls how fast the sun color falls off. This is especially visible during sunset and sunrise.

• ﬂoat Coloring = 0.75f

[0, 1] Controls how strongly the light color is being affected by sunset and sunrise.

• ﬂoat SkyColoring = 0.5f

[0, 1] Controls how strongly the sun color affects the atmosphere color. This is especially visible during sunset and

sunrise.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.11 TOD_MoonParameters Class Reference 27

• ﬂoat CloudColoring = 0.75f

[0, 1] Controls how strongly the sun color affects the cloud color. This is especially visible during sunset and sunrise.

• ﬂoat RayColoring = 0.75f

[0, 1] Controls how strongly the god ray color is being affected by sunset and sunrise.

• ﬂoat AmbientColoring = 0.5f

[0, 1] Controls how strongly the ambient color is being affected by sunset and sunrise.

4.10.1 Detailed Description

Parameters of the light source.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.11 TOD_MoonParameters Class Reference

Parameters that are unique to the moon.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• Color LightColor = new Color32(181, 204, 255, 255)

Color of the light emitted by the moon.

• Color MeshColor = new Color32(255, 233, 200, 255)

Color of the moon material.

• Color RayColor = new Color32(81, 104, 155, 50)

Color of the god rays cast by the moon.

• Color HaloColor = new Color32(15, 20, 30, 25)

Color of the moon halo.

• ﬂoat HaloSize = 0.1f

[0, ∞] Size of the moon halo.

• ﬂoat MeshSize = 1.0f

[0, ∞] Size of the moon mesh in degrees.

• ﬂoat MeshBrightness = 1.0f

[0, ∞] Brightness of the moon mesh.

• ﬂoat MeshContrast = 1.0f

[0, ∞] Contrast of the moon mesh.

• ﬂoat LightIntensity = 0.1f

[0, ∞] Intensity of the moon light source.

• ﬂoat ShadowStrength = 1.0f

[0, 1] Opacity of the object shadows dropped by the moon light source.

• TOD_MoonPositionType Position = TOD_MoonPositionType.Realistic

Type of the moon position calculation.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

28 Class Documentation

4.11.1 Detailed Description

Parameters that are unique to the moon.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.12 TOD_NightParameters Class Reference

Parameters that are unique to the night.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• Color AdditiveColor = new Color32(0, 0, 0, 255)

Artistic value for an additive color at night.

• Color AmbientColor = new Color32(0, 0, 0, 255)

Color of the ambient light at night.

• Color CloudColor = new Color32(47, 73, 137, 255)

Color of the clouds at night.

• ﬂoat SkyMultiplier = 0.01f

[0, 1] Sky opacity multiplier at night.

• ﬂoat CloudMultiplier = 0.01f

[0, 1] Cloud tone multiplier at night.

• ﬂoat AmbientMultiplier = 1.0f

[0, ∞] Brightness of ambient light at night.

• ﬂoat ReﬂectionMultiplier = 1.0f

[0, ∞] Brightness of reﬂected light at night.

4.12.1 Detailed Description

Parameters that are unique to the night.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.13 TOD_Parameters Class Reference

All parameters of the sky dome.

Public Member Functions

•TOD_Parameters (TOD_Sky sky)

• void ToSky (TOD_Sky sky)

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.14 TOD_PostEffectsBase Class Reference 29

Public Attributes

•TOD_CycleParameters Cycle

•TOD_WorldParameters World

•TOD_AtmosphereParameters Atmosphere

•TOD_DayParameters Day

•TOD_NightParameters Night

•TOD_SunParameters Sun

•TOD_MoonParameters Moon

•TOD_LightParameters Light

•TOD_StarParameters Stars

•TOD_CloudParameters Clouds

•TOD_FogParameters Fog

•TOD_AmbientParameters Ambient

•TOD_ReﬂectionParameters Reﬂection

4.13.1 Detailed Description

All parameters of the sky dome.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.14 TOD_PostEffectsBase Class Reference

Post effects base class.

Public Attributes

•TOD_Sky sky = null

Sky dome reference inspector variable. Will automatically be searched in the scene if not set in the inspector.

4.14.1 Detailed Description

Post effects base class.

Based on PostEffectsBase from the default Unity image effects. Extended for image effects that depend on a

TOD_Sky reference.

The documentation for this class was generated from the following ﬁle:

• TOD_PostEffectsBase.cs

4.15 TOD_Rays Class Reference

God ray class.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

30 Class Documentation

Public Types

• enum ResolutionType {Low,Normal,High }

Resolutions for the god rays. High is full, Normal is half and Low is quarter the screen resolution.

• enum BlendModeType {Screen,Add }

Methods to blend the god rays with the image.

Public Attributes

•ResolutionType Resolution = ResolutionType.Normal

Inspector variable to deﬁne the god ray rendering resolution.

•BlendModeType BlendMode = BlendModeType.Screen

Inspector variable to deﬁne the god ray rendering blend mode.

• int BlurIterations = 2

Inspector variable to deﬁne the number of blur iterations to be performaed.

• ﬂoat BlurRadius = 2

Inspector variable to deﬁne the radius to blur ﬁlter applied to the god rays.

• ﬂoat Intensity = 1

Inspector variable to deﬁne the intensity of the god rays.

• ﬂoat MaxRadius = 0.5f

Inspector variable to deﬁne the maximum radius of the god rays.

• bool UseDepthTexture = true

Inspector variable to deﬁne whether or not to use the depth buffer. If enabled, requires the target platform to allow the

camera to create a depth texture. Unity always creates this depth texture if deferred lighting is enabled. Otherwise

this script will enable it for the camera it is attached to. If disabled, requires all shaders writing to the depth buffer to

also write to the frame buffer alpha channel. Only the frame buffer alpha channel will then be used to check for ray

blockers in the image effect. However, a lot of the built-in Unity shaders do not write correct alpha values for legacy

reasons. It is unknown when this will be ﬁxed, which is why it is recommended to use a depth texture in most cases.

• Shader GodRayShader = null

Inspector variable pointing to the god ray rendering shader.

• Shader ScreenClearShader = null

Inspector variable pointing to the clear rendering shader.

4.15.1 Detailed Description

God ray class.

Component of the main camera of the scene to render god rays. Based on the sun shafts from the default Unity

image effects. Extended to get the god ray color from TOD_Sky and properly handle transparent meshes like

clouds.

The documentation for this class was generated from the following ﬁle:

• TOD_Rays.cs

4.16 TOD_ReﬂectionParameters Class Reference

Parameters of the reﬂection mode.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.17 TOD_Resources Class Reference 31

Public Attributes

• TOD_ReﬂectionType Mode = TOD_ReﬂectionType.None

Reﬂection cubemap mode.

• ReﬂectionProbeClearFlags ClearFlags = ReﬂectionProbeClearFlags.Skybox

Clear ﬂags to use for the reﬂection.

• LayerMask CullingMask = 0

Layers to include in the reﬂection.

• ﬂoat UpdateInterval = 1.0f

Refresh interval of the reﬂection cubemap in seconds.

4.16.1 Detailed Description

Parameters of the reﬂection mode.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.17 TOD_Resources Class Reference

Material and mesh wrapper class.

Public Attributes

• Mesh Quad

• Mesh SphereHigh

• Mesh SphereMedium

• Mesh SphereLow

• Mesh IcosphereHigh

• Mesh IcosphereMedium

• Mesh IcosphereLow

• Mesh HalfIcosphereHigh

• Mesh HalfIcosphereMedium

• Mesh HalfIcosphereLow

• Material CloudMaterialBumped

• Material CloudMaterialDensity

• Material CloudMaterialFastest

• Material ShadowMaterialBumped

• Material ShadowMaterialDensity

• Material ShadowMaterialFastest

• Material SpaceMaterial

• Material AtmosphereMaterial

• Material SunMaterial

• Material MoonMaterial

• Material ClearMaterial

• Material SkyboxMaterial

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

32 Class Documentation

4.17.1 Detailed Description

Material and mesh wrapper class.

Component of the sky dome parent game object.

The documentation for this class was generated from the following ﬁle:

• TOD_Resources.cs

4.18 TOD_Sky Class Reference

Main sky dome management class.

Public Member Functions

• Vector3 OrbitalToUnity (ﬂoat radius, ﬂoat theta, ﬂoat phi)

Convert spherical coordinates to cartesian coordinates.

• Vector3 OrbitalToLocal (ﬂoat theta, ﬂoat phi)

Convert spherical coordinates to cartesian coordinates.

• Color SampleAtmosphere (Vector3 direction, bool directLight=true)

Sample atmosphere colors from the sky dome.

• SphericalHarmonicsL2 RenderToSphericalHarmonics (ﬂoat exposure=1)

Render the sky dome to 3rd order spherical harmonics.

• void RenderToCubemap (ﬂoat exposure=1, bool async=true, RenderTexture targetTexture=null)

Render the sky dome to a cubemap render texture.

• Color SampleFogColor (bool directLight=true)

Calculate the fog color.

• Color SampleSkyColor (ﬂoat exposure=1)

Calculate the sky color.

• Color SampleEquatorColor (ﬂoat exposure=1)

Calculate the equator color.

• void UpdateFog ()

Update the RenderSettings fog color according to TOD_FogParameters.

• void UpdateAmbient ()

Update the RenderSettings ambient light according to TOD_AmbientParameters.

• void UpdateReﬂection (bool async=true)

Update the RenderSettings reﬂection probe according to TOD_ReﬂectionParameters.

• Color FakeHDR2LDR (Color color)

Apply fake HDR to LDR conversion.

• Color FakeHDR2LDR (Color color, ﬂoat factor)

Apply fake HDR to LDR conversion.

• Vector3 FakeHDR2LDR (Vector3 vector)

Apply fake HDR to LDR conversion.

• Vector3 FakeHDR2LDR (Vector3 vector, ﬂoat factor)

Apply fake HDR to LDR conversion.

• void LoadParameters (string xml)

Load parameters at runtime.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.18 TOD_Sky Class Reference 33

Public Attributes

• TOD_ColorSpaceDetection UnityColorSpace = TOD_ColorSpaceDetection.Auto

Inspector variable to adjust the color space.

• TOD_CloudQualityType CloudQuality = TOD_CloudQualityType.Bumped

Inspector variable to adjust the cloud quality.

• TOD_MeshQualityType MeshQuality = TOD_MeshQualityType.High

Inspector variable to adjust the mesh quality.

•TOD_CycleParameters Cycle

Inspector variable containing parameters of the day and night cycle.

•TOD_WorldParameters World

Inspector variable containing parameters of the world.

•TOD_AtmosphereParameters Atmosphere

Inspector variable containing parameters of the atmosphere.

•TOD_DayParameters Day

Inspector variable containing parameters of the day.

•TOD_NightParameters Night

Inspector variable containing parameters of the night.

•TOD_SunParameters Sun

Inspector variable containing parameters of the sun.

•TOD_MoonParameters Moon

Inspector variable containing parameters of the moon.

•TOD_LightParameters Light

Inspector variable containing parameters of the light source.

•TOD_StarParameters Stars

Inspector variable containing parameters of the stars.

•TOD_CloudParameters Clouds

Inspector variable containing parameters of the cloud layers.

•TOD_FogParameters Fog

Inspector variable containing parameters of the fog.

•TOD_AmbientParameters Ambient

Inspector variable containing parameters of the ambient light.

•TOD_ReﬂectionParameters Reﬂection

Inspector variable containing parameters of the reﬂection cubemap.

Properties

• static List<TOD_Sky >Instances [get]

All currently active sky dome instances.

• static TOD_Sky Instance [get]

The most recently created sky dome instance.

• bool Initialized [get]

Whether or not the sky dome was successfully initialized.

• bool Headless [get]

Whether or not the sky dome is running in headless mode.

•TOD_Components Components [get]

Containins references to all components.

• bool IsDay [get]

Boolean to check if it is day.

• bool IsNight [get]

Boolean to check if it is night.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

34 Class Documentation

• ﬂoat Diameter [get]

Diameter of the sky dome.

• ﬂoat Radius [get]

Radius of the sky dome.

• ﬂoat Level [get]

Height level of the sky dome.

• ﬂoat Gamma [get]

Gamma value that is being used in the shaders.

• ﬂoat OneOverGamma [get]

Inverse of the gamma value (1 / Gamma) that is being used in the shaders.

• ﬂoat LerpValue [get]

Falls off the darker the sunlight gets. Can for example be used to lerp between day and night values in shaders.

= +1 at day

= 0 at night.

• ﬂoat SunZenith [get]

Sun zenith angle in degrees.

= 0 if the sun is exactly at zenith.

= 180 if the sun is exactly below the ground.

• ﬂoat MoonZenith [get]

Moon zenith angle in degrees.

= 0 if the moon is exactly at zenith.

= 180 if the moon is exactly below the ground.

• ﬂoat HorizonAngle [get]

Horizon angle in degrees.

= 90 if the horizon is exactly in the middle of the sky dome.

= 180 if the horizon is exactly at the bottom of the sky dome.

• ﬂoat HorizonOffset [get]

Relative horizon offset.

= 0 if the horizon is exactly in the middle of the sky dome.

= 1 if the horizon is exactly at the bottom of the sky dome.

• ﬂoat HorizonLevel [get]

Absolute horizon height level in world space.

• ﬂoat LightZenith [get]

Currently active light source zenith angle in degrees.

= 0 if the currently active light source (sun or moon) is exactly at zenith.

= 90 if the currently active light source (sun or moon) is exactly at the horizon.

• ﬂoat LightIntensity [get]

Current light intensity.

• Vector3 MoonDirection [get]

Moon direction vector in world space.

• Vector3 SunDirection [get]

Sun direction vector in world space.

• Vector3 LightDirection [get]

Current directional light vector in world space. Lerps between TOD_Sky.SunDirection and TOD_Sky.MoonDirection

at dusk and dawn.

• Vector3 LocalMoonDirection [get]

Moon direction vector in sky dome object space.

• Vector3 LocalSunDirection [get]

Sun direction vector in sky dome object space.

• Vector3 LocalLightDirection [get]

Current directional light vector in sky dome object space. Lerps between TOD_Sky.LocalSunDirection and TOD_←-

Sky.LocalMoonDirection at dusk and dawn.

• Color LightColor [get]

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.18 TOD_Sky Class Reference 35

Current light color. Returns the color of TOD_Sky.Components.LightSource.

• Color RayColor [get]

Current ray color.

• Color SunColor [get]

Current sun color.

• Color MoonColor [get]

Current moon color.

• Color MoonHaloColor [get]

Current moon halo color.

• Color CloudColor [get]

Current cloud color.

• Color AdditiveColor [get]

Current additive color.

• Color AmbientColor [get]

Current ambient color.

• ReﬂectionProbe Probe [get]

Current reﬂection probe.

4.18.1 Detailed Description

Main sky dome management class.

Component of the sky dome parent game object.

4.18.2 Member Function Documentation

4.18.2.1 Color TOD_Sky.FakeHDR2LDR ( Color color )[inline]

Apply fake HDR to LDR conversion.

Parameters

color The HDR color.

Returns

The LDR color.

4.18.2.2 Color TOD_Sky.FakeHDR2LDR ( Color color, ﬂoat factor )[inline]

Apply fake HDR to LDR conversion.

Parameters

color The HDR color.

factor The amount of fake HDR to apply.

Returns

The LDR color.

4.18.2.3 Vector3 TOD_Sky.FakeHDR2LDR ( Vector3 vector )[inline]

Apply fake HDR to LDR conversion.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

36 Class Documentation

Parameters

vector The HDR vector.

Returns

The LDR vector.

4.18.2.4 Vector3 TOD_Sky.FakeHDR2LDR ( Vector3 vector, ﬂoat factor )[inline]

Apply fake HDR to LDR conversion.

Parameters

vector The HDR vector.

factor The amount of fake HDR to apply.

Returns

The LDR vector.

4.18.2.5 void TOD_Sky.LoadParameters ( string xml )[inline]

Load parameters at runtime.

Parameters

xml The parameters to load, serialized to XML.

4.18.2.6 Vector3 TOD_Sky.OrbitalToLocal ( ﬂoat theta, ﬂoat phi )[inline]

Convert spherical coordinates to cartesian coordinates.

Parameters

theta Spherical coordinates theta.

phi Spherical coordinates phi.

Returns

Unity position in local space.

4.18.2.7 Vector3 TOD_Sky.OrbitalToUnity ( ﬂoat radius, ﬂoat theta, ﬂoat phi )[inline]

Convert spherical coordinates to cartesian coordinates.

Parameters

radius Spherical coordinates radius.

theta Spherical coordinates theta.

phi Spherical coordinates phi.

Returns

Unity position in world space.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.18 TOD_Sky Class Reference 37

4.18.2.8 void TOD_Sky.RenderToCubemap ( ﬂoat exposure = 1,bool async = true,RenderTexture targetTexture = null )

[inline]

Render the sky dome to a cubemap render texture.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

38 Class Documentation

Parameters

exposure Camera exposure, determines brightness.

async Whether the render should be done over several frames.

targetTexture Target RenderTexture in which rendering should be done.

4.18.2.9 SphericalHarmonicsL2 TOD_Sky.RenderToSphericalHarmonics ( ﬂoat exposure = 1)[inline]

Render the sky dome to 3rd order spherical harmonics.

Parameters

exposure Camera exposure, determines brightness.

4.18.2.10 Color TOD_Sky.SampleAtmosphere ( Vector3 direction, bool directLight = true )[inline]

Sample atmosphere colors from the sky dome.

Parameters

direction View direction in world space.

directLight Whether or not to include direct light.

Returns

Color of the atmosphere in the speciﬁed direction.

4.18.2.11 Color TOD_Sky.SampleEquatorColor ( ﬂoat exposure = 1)[inline]

Calculate the equator color.

Parameters

exposure Camera exposure, determines brightness.

4.18.2.12 Color TOD_Sky.SampleFogColor ( bool directLight = true )[inline]

Calculate the fog color.

Parameters

directLight Whether or not to include direct light.

4.18.2.13 Color TOD_Sky.SampleSkyColor ( ﬂoat exposure = 1)[inline]

Calculate the sky color.

Parameters

exposure Camera exposure, determines brightness.

4.18.2.14 void TOD_Sky.UpdateReﬂection ( bool async = true )[inline]

Update the RenderSettings reﬂection probe according to TOD_ReﬂectionParameters.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.19 TOD_StarParameters Class Reference 39

Parameters

async Whether the render should be done over several frames.

The documentation for this class was generated from the following ﬁles:

• TOD_Sky+API.cs

• TOD_Sky+Settings.cs

• TOD_Sky.cs

• TOD_Sky+Unity.cs

4.19 TOD_StarParameters Class Reference

Parameters of the stars.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• ﬂoat Tiling = 6.0f

[0, ∞] Texture tiling of the stars texture. Determines how often the texture is tiled accross the sky and therefore the

size of the stars.

• ﬂoat Brightness = 3.0f

[0, ∞] Brightness of the stars.

• TOD_StarsPositionType Position = TOD_StarsPositionType.Rotating

Type of the stars position calculation.

4.19.1 Detailed Description

Parameters of the stars.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.20 TOD_SunParameters Class Reference

Parameters that are unique to the sun.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

40 Class Documentation

Public Attributes

• Color LightColor = new Color32(255, 243, 234, 255)

Color of the light emitted by the sun.

• Color MeshColor = new Color32(255, 160, 25, 255)

Color of the sun material.

• Color RayColor = new Color32(255, 243, 234, 255)

Color of the god rays cast by the sun.

• ﬂoat MeshSize = 1.0f

[0, ∞] Size of the sun mesh in degrees.

• ﬂoat MeshBrightness = 1.0f

[0, ∞] Brightness of the sun mesh.

• ﬂoat MeshContrast = 1.0f

[0, ∞] Contrast of the sun mesh.

• ﬂoat LightIntensity = 1.0f

[0, ∞] Intensity of the sun light source.

• ﬂoat ShadowStrength = 1.0f

[0, 1] Opacity of the object shadows dropped by the sun light source.

4.20.1 Detailed Description

Parameters that are unique to the sun.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

4.21 TOD_Time Class Reference

Time iteration class.

Public Member Functions

• ﬂoat ApplyTimeCurve (ﬂoat deltaTime)

Apply the time curve to a time span.

• void AddHours (ﬂoat hours, bool adjust=true)

Add hours and fractions of hours to the current time.

• void AddSeconds (ﬂoat seconds, bool adjust=true)

Add seconds and fractions of seconds to the current time.

Public Attributes

• ﬂoat DayLengthInMinutes = 30

Day length inspector variable. Length of one day in minutes.

• bool UseTimeCurve = false

Adjust the time progress according to the time curve.

• AnimationCurve TimeCurve = AnimationCurve.Linear(0, 0, 24, 24)

Time of day progression curve. Can be used to make days longer and nights shorter.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

4.22 TOD_Weather Class Reference 41

4.21.1 Detailed Description

Time iteration class.

Component of the sky dome parent game object.

4.21.2 Member Function Documentation

4.21.2.1 void TOD_Time.AddHours ( ﬂoat hours, bool adjust = true )[inline]

Add hours and fractions of hours to the current time.

Parameters

hours The hours to add.

adjust Whether or not to apply the time curve.

4.21.2.2 void TOD_Time.AddSeconds ( ﬂoat seconds, bool adjust = true )[inline]

Add seconds and fractions of seconds to the current time.

Parameters

seconds The seconds to add.

adjust Whether or not to apply the time curve.

4.21.2.3 ﬂoat TOD_Time.ApplyTimeCurve ( ﬂoat deltaTime )[inline]

Apply the time curve to a time span.

Parameters

deltaTime The time span to adjust.

Returns

The adjusted time span.

The documentation for this class was generated from the following ﬁle:

• TOD_Time.cs

4.22 TOD_Weather Class Reference

Weather management class.

Public Attributes

• ﬂoat FadeTime = 10f

Fade time inspector variable. Time to fade from one weather type to the other.

• TOD_CloudType Clouds = TOD_CloudType.Custom

Currently selected cloud type.

• TOD_WeatherType Weather = TOD_WeatherType.Custom

Currently selected weather type.

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

42 Class Documentation

4.22.1 Detailed Description

Weather management class.

Component of the sky dome parent game object.

The documentation for this class was generated from the following ﬁle:

• TOD_Weather.cs

4.23 TOD_WorldParameters Class Reference

Parameters of the world.

Public Member Functions

• void CheckRange ()

Assures that all parameters are within a reasonable range.

Public Attributes

• ﬂoat ZeroLevel = 0

The zero / water level of the scene in world space. The horizon offset is automatically adjusted whenever the sky

dome is above this level.

• ﬂoat Latitude = 0

[-90, 90] Latitude of your position in degrees.

= -90 at the south pole.

= 0 at the equator.

= 90 at the north pole.

• ﬂoat Longitude = 0

[-180, 180] Longitude of your position in degrees.

= -180 at 180 degrees in the west of Greenwich, England.

= 0 at Greenwich, England.

= 180 at 180 degrees in the east of Greenwich, England.

• ﬂoat UTC = 0

UTC/GMT time zone of the current location.

= 0 for Greenwich, England.

• TOD_HorizonType Horizon = TOD_HorizonType.Static

Type of the horizon offset.

4.23.1 Detailed Description

Parameters of the world.

The documentation for this class was generated from the following ﬁle:

• TOD_Parameters.cs

Generated on Thu Dec 18 2014 13:50:07 for Time of Day by Doxygen

Pdf Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
