PowerTrace

PowerTrace

Technical Information

14.06.13

PowerTrace

■Fast debugger and very fast download

■Upload of full trace within 10 seconds

■Programming support for on-chip and external

flashes

■Hardware breakpoints and trigger (if supported

by the on-chip debugging support)

■Program and data flow trace

■256 or 512 MByte trace memory

■300 MHz effective sample rate with

AUTOFOCUS self calibration

■Statistic functions

■Performance analysis

■Code Coverage

■USB and Ethernet interface included

TRACE32-PowerTrace is a very fast debugger plus a 16

MFrame trace memory in one box. This tool supports all

on-chip debugging standards and in addition all common

trace ports such as NEXUS, ARM-ETM etc.

PowerTrace

TRACE32 - Technical Information 2

PowerTrace Concept

The PowerTrace Module includes all

systems for debugging and traceing.

Controller

❏CPU

■200 MHz PowerPC

■250 Drystone 2.1 MIPS

■64 MByte SDRAM

Interfaces

❏PODBUS Interface to PC,

TRACE32-ICE or TRACE32-

FIRE

❏Direct USB Interface

■12 MBit/sec

❏Direct FastEthernet Interface

■10/100 MBit/sec

Active Debugger

❏Many Ddebuggers available

❏Support of combined operation

■BDM

■JTAG

■OCDS

■ONCE

PowerTrace

TRACE32 - Technical Information 3

❏Software Compatible to In-Circuit

Emulator

■Operation System

■PRACTICE

■ASM Debugger

■HLL Debugger for C,C++, ADA,

PASCAL

■Peripheral Windows

❏High-Speed Download

■Up to 1700 KByte/sec

■Fastest JTAG Debugger world-

wide

❏Variable Debug Clock Speed

■10 kHz...5 MHz

■1/4 CPU Clock

■1/8 CPU Clock

■Variable up to 100 MHz

Trace Analyzer

❏Tra c e Po r t

■Max. 92 Trace Channels for

100 MHz Operation

■Max. 46 Trace Channels for

200 MHz Operation

❏Supported Adapters

❏MICTOR Adaption

■2 Mictor probes (34 channels)

can be used

❏Trace Storage

■256 MByte Trace Storage

■16 MFrames

■Full Dual-ported

■Hardware Search Engine

■640 MByte/sec sample rate

■Time Stamp 12.5 (20) ns Reso-

lution

❏Time Correlation and Tracking

with other TRACE32 Tools

❏Code Coverage

■Hardware Code Coverage

■4 Segments with 2 or 4 MByte

each

❏Data Coverage

■Hardware Data Coverage

■4 Segments with 256 or 512

KByte each

❏Shadow Memory

■4 Segments with 256 or 512

KByte each

❏Breakpoints

■4 Breakpoint Memory with 256

or 512 KBit each

❏Trigger Sequencer

■4 Trigger Events

■4 Trigger Levels

■3 Trigger Counters

❏Trigger Delay

■ 0 .. 300 s

❏External Trigger

■Input from PODBUS

■Output to PODBUS

❏Performance Analyzer

❏Support for EPROM/FLASH

Simulator

■Breakpoints in ROM Area

■8, 16 and 32 Bit EPROM/

FLASH Emulation

PowerTrace

Supported Processors

TRACE32 - Technical Information 4

Supported Processors

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

1004K YES YES YES

24K YES YES YES

24KE YES YES YES

34K YES YES YES

4KC YES YES YES

4KEC YES YES YES

4KM YES YES YES

4KP YES YES YES

4KSD YES YES YES

70F3111 YES YES YES

74K YES YES YES

88FR101 YES YES YES YES

88FR102 YES YES YES YES

88FR111 YES YES YES YES

88FR301 YES YES YES YES

A2F060 YES YES YES YES

A2F200 YES YES YES YES

A2F500 YES YES YES YES

A9500 YES YES YES YES

A9540 YES YES YES YES

AM3505 YES YES YES YES

AM3517 YES YES YES YES

AM3703 YES YES YES YES

AM3715 YES YES YES YES

APM86190 YES YES YES

APM86190B YES YES YES

APM86290 YES YES YES

APM86290B YES YES YES

APM86491 YES YES YES

APM86692 YES YES YES

AR7242 YES YES YES

ARM1020E YES YES YES YES

ARM1022E YES YES YES YES

ARM1026EJ-S YES YES YES YES

ARM1136J-S YES YES YES YES

ARM1136JF-S YES YES YES YES

ARM1156T2-S YES YES YES YES

PowerTrace

Supported Processors

TRACE32 - Technical Information 5

ARM1156T2F-S YES YES YES YES

ARM1176JZ-S YES YES YES YES

ARM1176JZF-S YES YES YES YES

ARM11MPCORE YES YES YES YES

ARM710T YES YES YES YES

ARM710T-AMBA YES YES YES YES YES

ARM720T YES YES YES YES

ARM720T-AMBA YES YES YES YES YES

ARM740T YES YES YES YES

ARM740T-AMBA YES YES YES YES YES

ARM7DI YES YES YES YES

ARM7EJ-S YES YES YES YES

ARM7TDMI YES YES YES YES YES

ARM7TDMI-AMBA YES YES YES YES YES

ARM7TDMI-S YES YES YES YES

ARM915T YES YES YES YES

ARM920T YES YES YES YES

ARM922T YES YES YES YES

ARM926EJ-S YES YES YES YES

ARM940T YES YES YES YES

ARM946E-S YES YES YES YES

ARM966E-S YES YES YES YES

ARM968E-S YES YES YES YES

ARM9E-S YES YES YES YES

ARM9EJ-S YES YES YES YES

ARM9TDMI YES YES YES YES

AT91RM9200 YES YES YES YES

AT91SAM3A4C YES YES YES YES

AT91SAM3A8C YES YES YES YES

AT91SAM3N00A YES YES YES YES

AT91SAM3N00B YES YES YES YES

AT91SAM3N0A YES YES YES YES

AT91SAM3N0B YES YES YES YES

AT91SAM3N0C YES YES YES YES

AT91SAM3N1A YES YES YES YES

AT91SAM3N1B YES YES YES YES

AT91SAM3N1C YES YES YES YES

AT91SAM3N2A YES YES YES YES

AT91SAM3N2B YES YES YES YES

AT91SAM3N2C YES YES YES YES

AT91SAM3N4A YES YES YES YES

AT91SAM3N4B YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 6

AT91SAM3N4C YES YES YES YES

AT91SAM3S16C YES YES YES YES

AT91SAM3S1A YES YES YES YES

AT91SAM3S1B YES YES YES YES

AT91SAM3S1C YES YES YES YES

AT91SAM3S2A YES YES YES YES

AT91SAM3S2B YES YES YES YES

AT91SAM3S2C YES YES YES YES

AT91SAM3S4A YES YES YES YES

AT91SAM3S4B YES YES YES YES

AT91SAM3S4C YES YES YES YES

AT91SAM3S8B YES YES YES YES

AT91SAM3S8C YES YES YES YES

AT91SAM3SD8B YES YES YES YES

AT91SAM3SD8C YES YES YES YES

AT91SAM3U1C YES YES YES YES

AT91SAM3U1E YES YES YES YES

AT91SAM3U2C YES YES YES YES

AT91SAM3U2E YES YES YES YES

AT91SAM3U4C YES YES YES YES

AT91SAM3U4E YES YES YES YES

AT91SAM3X4C YES YES YES YES

AT91SAM3X4E YES YES YES YES

AT91SAM3X8C YES YES YES YES

AT91SAM3X8E YES YES YES YES

AT91SAM9261 YES YES YES YES

AT91SAM9263 YES YES YES YES

ATSAM4E16C YES YES YES YES

ATSAM4E16E YES YES YES YES

ATSAM4E8C YES YES YES YES

ATSAM4E8E YES YES YES YES

ATSAM4LC2A YES YES YES YES

ATSAM4LC2B YES YES YES YES

ATSAM4LC2C YES YES YES YES

ATSAM4LC4A YES YES YES YES

ATSAM4LC4B YES YES YES YES

ATSAM4LC4C YES YES YES YES

ATSAM4LS2A YES YES YES YES

ATSAM4LS2B YES YES YES YES

ATSAM4LS2C YES YES YES YES

ATSAM4LS4B YES YES YES YES

ATSAM4LS4C YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 7

ATSAM4S16A YES YES YES YES

ATSAM4S16B YES YES YES YES

ATSAM4S16C YES YES YES YES

ATSAM4S8A YES YES YES YES

ATSAM4S8B YES YES YES YES

ATSAM4S8C YES YES YES YES

BA22 YES YES YES

C161..167 YES YES YES

C161K YES YES YES YES YES

C161O YES YES YES YES YES

C161S YES YES YES YES YES

C161U YES YES YES YES

C161V YES YES YES YES YES

C165 YES YES YES YES YES

C165H YES YES YES YES

C165UTAH YES YES YES YES

C166CBC YES YES YES YES

C167 YES YES YES YES YES

C167C YES YES YES YES YES

C167CR YES YES YES YES YES

C167CS YES YES YES YES YES

C167CW YES YES YES YES YES

C167SR YES YES YES YES YES

CDC3207G YES YES YES YES

CDC3272G YES YES YES YES

CEVA-X1620 YES YES

CEVA-X1621 YES YES

CEVA-X1622 YES YES

CEVA-X1641 YES YES

CEVA-X1643 YES YES

CEVA-XC323 YES YES

CEVA-XS1100 YES YES

CEVA-XS1102 YES YES

CEVA-XS1141 YES YES

CEVA-XS1200 YES YES

CORTEX-A15 YES YES YES YES

CORTEX-A15MPCORE YES YES YES YES

CORTEX-A5 YES YES YES YES

CORTEX-A5MPCORE YES YES YES YES

CORTEX-A7 YES YES YES YES

CORTEX-A7MPCORE YES YES YES YES

CORTEX-A8 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 8

CORTEX-A9 YES YES YES YES

CORTEX-A9MPCORE YES YES YES YES

CORTEX-M3 YES YES YES YES

CORTEX-M4 YES YES YES YES

CORTEX-R4 YES YES YES YES

CORTEX-R4F YES YES YES YES

CORTEX-R5 YES YES YES YES

CORTEX-R5F YES YES YES YES

CORTEX-R5MPCORE YES YES YES YES

CS7522 YES YES YES YES

CS7542 YES YES YES YES

CY8C5245 YES YES YES YES

CY8C5246 YES YES YES YES

CY8C5247 YES YES YES YES

CY8C5248 YES YES YES YES

CY8C5385 YES YES YES YES

CY8C5386 YES YES YES YES

CY8C5387 YES YES YES YES

CY8C5388 YES YES YES YES

CY8C5485 YES YES YES YES

CY8C5486 YES YES YES YES

CY8C5487 YES YES YES YES

CY8C5488 YES YES YES YES

CY8C5585 YES YES YES YES

CY8C5586 YES YES YES YES

CY8C5587 YES YES YES YES

CY8C5588 YES YES YES YES

CYCLONEVSOC YES YES YES YES

DB5500 YES YES YES YES

DB8500 YES YES YES YES

DB8540 YES YES YES YES

EFM32G200F YES YES YES YES

EFM32G210F YES YES YES YES

EFM32G222F YES YES YES YES

EFM32G230F YES YES YES YES

EFM32G232F YES YES YES YES

EFM32G280F YES YES YES YES

EFM32G290F YES YES YES YES

EFM32G840F YES YES YES YES

EFM32G842F YES YES YES YES

EFM32G880F YES YES YES YES

EFM32G890F YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 9

EFM32GG230F YES YES YES YES

EFM32GG232F YES YES YES YES

EFM32GG280F YES YES YES YES

EFM32GG290F YES YES YES YES

EFM32GG295F YES YES YES YES

EFM32GG330F YES YES YES YES

EFM32GG332F YES YES YES YES

EFM32GG380F YES YES YES YES

EFM32GG390F YES YES YES YES

EFM32GG395F YES YES YES YES

EFM32GG840F YES YES YES YES

EFM32GG842F YES YES YES YES

EFM32GG880F YES YES YES YES

EFM32GG890F YES YES YES YES

EFM32GG895F YES YES YES YES

EFM32GG940F YES YES YES YES

EFM32GG942F YES YES YES YES

EFM32GG980F YES YES YES YES

EFM32GG990F YES YES YES YES

EFM32GG995F YES YES YES YES

EFM32TG108F YES YES YES YES

EFM32TG110F YES YES YES YES

EFM32TG210F YES YES YES YES

EFM32TG222F YES YES YES YES

EFM32TG225F YES YES YES YES

EFM32TG230F YES YES YES YES

EFM32TG232F YES YES YES YES

EFM32TG822F YES YES YES YES

EFM32TG825F YES YES YES YES

EFM32TG840F YES YES YES YES

EFM32TG842F YES YES YES YES

EFM32WG230F YES YES YES YES

EFM32WG232F YES YES YES YES

EFM32WG280F YES YES YES YES

EFM32WG290F YES YES YES YES

EFM32WG295F YES YES YES YES

EFM32WG330F YES YES YES YES

EFM32WG332F YES YES YES YES

EFM32WG380F YES YES YES YES

EFM32WG390F YES YES YES YES

EFM32WG395F YES YES YES YES

EFM32WG840F YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 10

EFM32WG842F YES YES YES YES

EFM32WG880F YES YES YES YES

EFM32WG890F YES YES YES YES

EFM32WG895F YES YES YES YES

EFM32WG940F YES YES YES YES

EFM32WG942F YES YES YES YES

EFM32WG980F YES YES YES YES

EFM32WG990F YES YES YES YES

EFM32WG995F YES YES YES YES

EPXA1 YES YES YES YES

EPXA10 YES YES YES YES

EPXA4 YES YES YES YES

ERTEC200 YES YES YES YES

ERTEC400 YES YES YES YES

EXYNOS4212 YES YES YES YES

EXYNOS4412 YES YES YES YES

EXYNOS5250 YES YES YES YES

IMX280 YES YES YES YES

IMX281 YES YES YES YES

IMX283 YES YES YES YES

IMX285 YES YES YES YES

IMX286 YES YES YES YES

IMX287 YES YES YES YES

IMX502 YES YES YES YES

IMX503 YES YES YES YES

IMX507 YES YES YES YES

IMX508 YES YES YES YES

IMX512 YES YES YES YES

IMX513 YES YES YES YES

IMX514 YES YES YES YES

IMX515 YES YES YES YES

IMX516 YES YES YES YES

IMX534 YES YES YES YES

IMX535 YES YES YES YES

IMX536 YES YES YES YES

IMX537 YES YES YES YES

IMX538 YES YES YES YES

IMX6DUAL YES YES YES YES

IMX6QUAD YES YES YES YES

IMX6SOLO YES YES YES YES

INCA-P YES YES YES YES

INTERAPTIV YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 11

IOP480 YES YES YES

JANUS2 YES YES YES

JANUS200 YES YES YES

JANUS220 YES YES YES

JANUSCC YES YES YES

KRAIT YES YES YES YES

LM3S101 YES YES YES YES

LM3S102 YES YES YES YES

LM3S1110 YES YES YES YES

LM3S1133 YES YES YES YES

LM3S1138 YES YES YES YES

LM3S1150 YES YES YES YES

LM3S1162 YES YES YES YES

LM3S1165 YES YES YES YES

LM3S1332 YES YES YES YES

LM3S1435 YES YES YES YES

LM3S1439 YES YES YES YES

LM3S1512 YES YES YES YES

LM3S1538 YES YES YES YES

LM3S1601 YES YES YES YES

LM3S1607 YES YES YES YES

LM3S1608 YES YES YES YES

LM3S1620 YES YES YES YES

LM3S1621 YES YES YES YES

LM3S1625 YES YES YES YES

LM3S1626 YES YES YES YES

LM3S1627 YES YES YES YES

LM3S1635 YES YES YES YES

LM3S1637 YES YES YES YES

LM3S1651 YES YES YES YES

LM3S1751 YES YES YES YES

LM3S1776 YES YES YES YES

LM3S1811 YES YES YES YES

LM3S1816 YES YES YES YES

LM3S1850 YES YES YES YES

LM3S1911 YES YES YES YES

LM3S1918 YES YES YES YES

LM3S1937 YES YES YES YES

LM3S1958 YES YES YES YES

LM3S1960 YES YES YES YES

LM3S1968 YES YES YES YES

LM3S1B21 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 12

LM3S1J11 YES YES YES YES

LM3S1J16 YES YES YES YES

LM3S1N11 YES YES YES YES

LM3S1N16 YES YES YES YES

LM3S1P51 YES YES YES YES

LM3S1R21 YES YES YES YES

LM3S1R26 YES YES YES YES

LM3S1W16 YES YES YES YES

LM3S1Z16 YES YES YES YES

LM3S2110 YES YES YES YES

LM3S2139 YES YES YES YES

LM3S2276 YES YES YES YES

LM3S2410 YES YES YES YES

LM3S2412 YES YES YES YES

LM3S2432 YES YES YES YES

LM3S2533 YES YES YES YES

LM3S2601 YES YES YES YES

LM3S2608 YES YES YES YES

LM3S2616 YES YES YES YES

LM3S2620 YES YES YES YES

LM3S2637 YES YES YES YES

LM3S2651 YES YES YES YES

LM3S2671 YES YES YES YES

LM3S2678 YES YES YES YES

LM3S2730 YES YES YES YES

LM3S2739 YES YES YES YES

LM3S2776 YES YES YES YES

LM3S2793 YES YES YES YES

LM3S2911 YES YES YES YES

LM3S2918 YES YES YES YES

LM3S2939 YES YES YES YES

LM3S2948 YES YES YES YES

LM3S2950 YES YES YES YES

LM3S2965 YES YES YES YES

LM3S2B93 YES YES YES YES

LM3S300 YES YES YES YES

LM3S301 YES YES YES YES

LM3S308 YES YES YES YES

LM3S310 YES YES YES YES

LM3S315 YES YES YES YES

LM3S316 YES YES YES YES

LM3S317 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 13

LM3S328 YES YES YES YES

LM3S3634 YES YES YES YES

LM3S3651 YES YES YES YES

LM3S3739 YES YES YES YES

LM3S3748 YES YES YES YES

LM3S3749 YES YES YES YES

LM3S3759 YES YES YES YES

LM3S3768 YES YES YES YES

LM3S3826 YES YES YES YES

LM3S3J26 YES YES YES YES

LM3S3N26 YES YES YES YES

LM3S3W26 YES YES YES YES

LM3S3Z26 YES YES YES YES

LM3S5632 YES YES YES YES

LM3S5651 YES YES YES YES

LM3S5652 YES YES YES YES

LM3S5656 YES YES YES YES

LM3S5662 YES YES YES YES

LM3S5732 YES YES YES YES

LM3S5737 YES YES YES YES

LM3S5739 YES YES YES YES

LM3S5747 YES YES YES YES

LM3S5749 YES YES YES YES

LM3S5752 YES YES YES YES

LM3S5757 YES YES YES YES

LM3S5762 YES YES YES YES

LM3S5767 YES YES YES YES

LM3S5768 YES YES YES YES

LM3S5769 YES YES YES YES

LM3S5791 YES YES YES YES

LM3S5951 YES YES YES YES

LM3S5956 YES YES YES YES

LM3S5B91 YES YES YES YES

LM3S5C31 YES YES YES YES

LM3S5K31 YES YES YES YES

LM3S5K36 YES YES YES YES

LM3S5P31 YES YES YES YES

LM3S5P36 YES YES YES YES

LM3S5P51 YES YES YES YES

LM3S5P56 YES YES YES YES

LM3S5R31 YES YES YES YES

LM3S5R36 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 14

LM3S5T36 YES YES YES YES

LM3S5Y36 YES YES YES YES

LM3S600 YES YES YES YES

LM3S601 YES YES YES YES

LM3S608 YES YES YES YES

LM3S610 YES YES YES YES

LM3S6100 YES YES YES YES

LM3S611 YES YES YES YES

LM3S6110 YES YES YES YES

LM3S612 YES YES YES YES

LM3S613 YES YES YES YES

LM3S615 YES YES YES YES

LM3S617 YES YES YES YES

LM3S618 YES YES YES YES

LM3S628 YES YES YES YES

LM3S6420 YES YES YES YES

LM3S6422 YES YES YES YES

LM3S6432 YES YES YES YES

LM3S6537 YES YES YES YES

LM3S6610 YES YES YES YES

LM3S6611 YES YES YES YES

LM3S6618 YES YES YES YES

LM3S6633 YES YES YES YES

LM3S6637 YES YES YES YES

LM3S6730 YES YES YES YES

LM3S6753 YES YES YES YES

LM3S6911 YES YES YES YES

LM3S6918 YES YES YES YES

LM3S6938 YES YES YES YES

LM3S6950 YES YES YES YES

LM3S6952 YES YES YES YES

LM3S6965 YES YES YES YES

LM3S800 YES YES YES YES

LM3S801 YES YES YES YES

LM3S808 YES YES YES YES

LM3S811 YES YES YES YES

LM3S812 YES YES YES YES

LM3S815 YES YES YES YES

LM3S817 YES YES YES YES

LM3S818 YES YES YES YES

LM3S828 YES YES YES YES

LM3S8530 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 15

LM3S8538 YES YES YES YES

LM3S8630 YES YES YES YES

LM3S8730 YES YES YES YES

LM3S8733 YES YES YES YES

LM3S8738 YES YES YES YES

LM3S8930 YES YES YES YES

LM3S8933 YES YES YES YES

LM3S8938 YES YES YES YES

LM3S8962 YES YES YES YES

LM3S8970 YES YES YES YES

LM3S8971 YES YES YES YES

LM3S9781 YES YES YES YES

LM3S9790 YES YES YES YES

LM3S9792 YES YES YES YES

LM3S9997 YES YES YES YES

LM3S9B81 YES YES YES YES

LM3S9B90 YES YES YES YES

LM3S9B92 YES YES YES YES

LM3S9B95 YES YES YES YES

LM3S9B96 YES YES YES YES

LM3S9L97 YES YES YES YES

LM4F110B2QR YES YES YES YES

LM4F110C4QR YES YES YES YES

LM4F110E5QR YES YES YES YES

LM4F110H5QR YES YES YES YES

LM4F111B2QR YES YES YES YES

LM4F111C4QR YES YES YES YES

LM4F111E5QR YES YES YES YES

LM4F111H5QR YES YES YES YES

LM4F112C4QC YES YES YES YES

LM4F112E5QC YES YES YES YES

LM4F112H5QC YES YES YES YES

LM4F112H5QD YES YES YES YES

LM4F120B2QR YES YES YES YES

LM4F120C4QR YES YES YES YES

LM4F120E5QR YES YES YES YES

LM4F120H5QR YES YES YES YES

LM4F121B2QR YES YES YES YES

LM4F121C4QR YES YES YES YES

LM4F121E5QR YES YES YES YES

LM4F121H5QR YES YES YES YES

LM4F122C4QC YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 16

LM4F122E5QC YES YES YES YES

LM4F122H5QC YES YES YES YES

LM4F122H5QD YES YES YES YES

LM4F130C4QR YES YES YES YES

LM4F130E5QR YES YES YES YES

LM4F130H5QR YES YES YES YES

LM4F131C4QR YES YES YES YES

LM4F131E5QR YES YES YES YES

LM4F131H5QR YES YES YES YES

LM4F132C4QC YES YES YES YES

LM4F132E5QC YES YES YES YES

LM4F132H5QC YES YES YES YES

LM4F132H5QD YES YES YES YES

LM4F230E5QR YES YES YES YES

LM4F230H5QR YES YES YES YES

LM4F231E5QR YES YES YES YES

LM4F231H5QR YES YES YES YES

LM4F232E5QC YES YES YES YES

LM4F232H5QC YES YES YES YES

LM4F232H5QD YES YES YES YES

LPC1311 YES YES YES YES

LPC1313 YES YES YES YES

LPC1315 YES YES YES YES

LPC1316 YES YES YES YES

LPC1317 YES YES YES YES

LPC1342 YES YES YES YES

LPC1343 YES YES YES YES

LPC1345 YES YES YES YES

LPC1346 YES YES YES YES

LPC1347 YES YES YES YES

LPC1751 YES YES YES YES

LPC1752 YES YES YES YES

LPC1754 YES YES YES YES

LPC1756 YES YES YES YES

LPC1758 YES YES YES YES

LPC1759 YES YES YES YES

LPC1763 YES YES YES YES

LPC1764 YES YES YES YES

LPC1765 YES YES YES YES

LPC1766 YES YES YES YES

LPC1767 YES YES YES YES

LPC1768 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 17

LPC1769 YES YES YES YES

LPC1770 YES YES YES YES

LPC1772 YES YES YES YES

LPC1774 YES YES YES YES

LPC1776 YES YES YES YES

LPC1777 YES YES YES YES

LPC1778 YES YES YES YES

LPC1780 YES YES YES YES

LPC1781 YES YES YES YES

LPC1785 YES YES YES YES

LPC1786 YES YES YES YES

LPC1787 YES YES YES YES

LPC1788 YES YES YES YES

LPC1810 YES YES YES YES

LPC1820 YES YES YES YES

LPC1830 YES YES YES YES

LPC1850 YES YES YES YES

LPC1853 YES YES YES YES

LPC1857 YES YES YES YES

LPC2101 YES YES YES YES

LPC2102 YES YES YES YES

LPC2103 YES YES YES YES

LPC2104 YES YES YES YES

LPC2105 YES YES YES YES

LPC2106 YES YES YES YES

LPC2109 YES YES YES YES

LPC2112 YES YES YES YES

LPC2114 YES YES YES YES

LPC2119 YES YES YES YES

LPC2124 YES YES YES YES

LPC2129 YES YES YES YES

LPC2131 YES YES YES YES

LPC2131/01 YES YES YES YES

LPC2132 YES YES YES YES

LPC2132/01 YES YES YES YES

LPC2134 YES YES YES YES

LPC2134/01 YES YES YES YES

LPC2136 YES YES YES YES

LPC2136/01 YES YES YES YES

LPC2138 YES YES YES YES

LPC2138/01 YES YES YES YES

LPC2141 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 18

LPC2142 YES YES YES YES

LPC2144 YES YES YES YES

LPC2146 YES YES YES YES

LPC2148 YES YES YES YES

LPC2194 YES YES YES YES

LPC2210 YES YES YES YES

LPC2212 YES YES YES YES

LPC2214 YES YES YES YES

LPC2220 YES YES YES YES

LPC2290 YES YES YES YES

LPC2292 YES YES YES YES

LPC2294 YES YES YES YES

LPC2364 YES YES YES YES

LPC2365 YES YES YES YES

LPC2366 YES YES YES YES

LPC2367 YES YES YES YES

LPC2368 YES YES YES YES

LPC2377 YES YES YES YES

LPC2378 YES YES YES YES

LPC2387 YES YES YES YES

LPC2388 YES YES YES YES

LPC2458 YES YES YES YES

LPC2460 YES YES YES YES

LPC2468 YES YES YES YES

LPC2470 YES YES YES YES

LPC2478 YES YES YES YES

LPC2880 YES YES YES YES

LPC2888 YES YES YES YES

LPC4310FBD144 YES YES YES YES

LPC4310FET100 YES YES YES YES

LPC4320FBD100 YES YES YES YES

LPC4320FBD144 YES YES YES YES

LPC4320FET100 YES YES YES YES

LPC4330FBD144 YES YES YES YES

LPC4330FET100 YES YES YES YES

LPC4330FET180 YES YES YES YES

LPC4330FET256 YES YES YES YES

LPC4333FBD144 YES YES YES YES

LPC4333FET180 YES YES YES YES

LPC4333FET256 YES YES YES YES

LPC4337FBD144 YES YES YES YES

LPC4337FET100 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 19

LPC4337FET180 YES YES YES YES

LPC4337FET256 YES YES YES YES

LPC4350FBD208 YES YES YES YES

LPC4350FET180 YES YES YES YES

LPC4350FET256 YES YES YES YES

LPC4353FET180 YES YES YES YES

LPC4353FET256 YES YES YES YES

LPC4357FBD208 YES YES YES YES

LPC4357FET256 YES YES YES YES

LX4189 YES YES YES

LX4X80 YES YES YES

LX5180 YES YES YES

LX5280 YES YES YES

M14K YES YES YES

M14KC YES YES YES

M1A3P1000 YES YES YES YES

M1A3P1000L YES YES YES YES

M1A3P250 YES YES YES YES

M1A3P400 YES YES YES YES

M1A3P600 YES YES YES YES

M1A3P600L YES YES YES YES

M1A3PE3000L YES YES YES YES

M1AFS1500 YES YES YES YES

M1AFS250 YES YES YES YES

M1AFS600 YES YES YES YES

M1AGL1000 YES YES YES YES

M1AGL250 YES YES YES YES

M1AGL400 YES YES YES YES

M1AGL600 YES YES YES YES

M1AGLE3000 YES YES YES YES

M2S005 YES YES YES YES

M2S010 YES YES YES YES

M2S025 YES YES YES YES

M2S050 YES YES YES YES

M2S080 YES YES YES YES

M2S120 YES YES YES YES

M32176 YES YES

M32180 YES YES

M32192 YES YES

M4K YES YES YES

M7400 YES YES YES YES

MB9AF102N YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 20

MB9AF102R YES YES YES YES

MB9AF104N YES YES YES YES

MB9AF104R YES YES YES YES

MB9AF105NA YES YES YES YES

MB9AF105RA YES YES YES YES

MB9AF111K YES YES YES YES

MB9AF111L YES YES YES YES

MB9AF111M YES YES YES YES

MB9AF111N YES YES YES YES

MB9AF112K YES YES YES YES

MB9AF112M YES YES YES YES

MB9AF112N YES YES YES YES

MB9AF114L YES YES YES YES

MB9AF114M YES YES YES YES

MB9AF114N YES YES YES YES

MB9AF115M YES YES YES YES

MB9AF115N YES YES YES YES

MB9AF116M YES YES YES YES

MB9AF116N YES YES YES YES

MB9AF131L YES YES YES YES

MB9AF131M YES YES YES YES

MB9AF131N YES YES YES YES

MB9AF132K YES YES YES YES

MB9AF132L YES YES YES YES

MB9AF132M YES YES YES YES

MB9AF132N YES YES YES YES

MB9AF141L YES YES YES YES

MB9AF141M YES YES YES YES

MB9AF141N YES YES YES YES

MB9AF142L YES YES YES YES

MB9AF142M YES YES YES YES

MB9AF142N YES YES YES YES

MB9AF144L YES YES YES YES

MB9AF144M YES YES YES YES

MB9AF144N YES YES YES YES

MB9AF311K YES YES YES YES

MB9AF311M YES YES YES YES

MB9AF311N YES YES YES YES

MB9AF312K YES YES YES YES

MB9AF312L YES YES YES YES

MB9AF312M YES YES YES YES

MB9AF312N YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 21

MB9AF314L YES YES YES YES

MB9AF314M YES YES YES YES

MB9AF314N YES YES YES YES

MB9AF315M YES YES YES YES

MB9AF315N YES YES YES YES

MB9AF316M YES YES YES YES

MB9AF316N YES YES YES YES

MB9AF341L YES YES YES YES

MB9AF341M YES YES YES YES

MB9AF341N YES YES YES YES

MB9AF342L YES YES YES YES

MB9AF342M YES YES YES YES

MB9AF342N YES YES YES YES

MB9AF344L YES YES YES YES

MB9AF344M YES YES YES YES

MB9AFA31L YES YES YES YES

MB9AFA31M YES YES YES YES

MB9AFA31N YES YES YES YES

MB9AFA32L YES YES YES YES

MB9AFA32M YES YES YES YES

MB9AFA32N YES YES YES YES

MB9AFA41L YES YES YES YES

MB9AFA41M YES YES YES YES

MB9AFA41N YES YES YES YES

MB9AFA42L YES YES YES YES

MB9AFA42M YES YES YES YES

MB9AFA42N YES YES YES YES

MB9AFA44L YES YES YES YES

MB9AFA44M YES YES YES YES

MB9AFA44N YES YES YES YES

MB9AFB41M YES YES YES YES

MB9AFB41N YES YES YES YES

MB9AFB42L YES YES YES YES

MB9AFB42M YES YES YES YES

MB9AFB42N YES YES YES YES

MB9AFB44L YES YES YES YES

MB9AFB44M YES YES YES YES

MB9AFB44N YES YES YES YES

MB9BF104N YES YES YES YES

MB9BF104R YES YES YES YES

MB9BF105N YES YES YES YES

MB9BF105R YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 22

MB9BF106N YES YES YES YES

MB9BF106R YES YES YES YES

MB9BF112N YES YES YES YES

MB9BF112R YES YES YES YES

MB9BF114N YES YES YES YES

MB9BF114R YES YES YES YES

MB9BF115N YES YES YES YES

MB9BF115R YES YES YES YES

MB9BF116R YES YES YES YES

MB9BF116S YES YES YES YES

MB9BF116T YES YES YES YES

MB9BF117S YES YES YES YES

MB9BF117T YES YES YES YES

MB9BF118S YES YES YES YES

MB9BF118T YES YES YES YES

MB9BF216S YES YES YES YES

MB9BF216T YES YES YES YES

MB9BF217T YES YES YES YES

MB9BF218S YES YES YES YES

MB9BF218T YES YES YES YES

MB9BF304N YES YES YES YES

MB9BF304R YES YES YES YES

MB9BF305N YES YES YES YES

MB9BF305R YES YES YES YES

MB9BF306N YES YES YES YES

MB9BF306R YES YES YES YES

MB9BF312N YES YES YES YES

MB9BF312R YES YES YES YES

MB9BF314N YES YES YES YES

MB9BF314R YES YES YES YES

MB9BF315N YES YES YES YES

MB9BF315R YES YES YES YES

MB9BF316N YES YES YES YES

MB9BF316R YES YES YES YES

MB9BF316S YES YES YES YES

MB9BF316T YES YES YES YES

MB9BF317S YES YES YES YES

MB9BF317T YES YES YES YES

MB9BF318S YES YES YES YES

MB9BF318T YES YES YES YES

MB9BF404N YES YES YES YES

MB9BF404R YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 23

MB9BF405N YES YES YES YES

MB9BF405R YES YES YES YES

MB9BF406N YES YES YES YES

MB9BF406R YES YES YES YES

MB9BF412N YES YES YES YES

MB9BF412R YES YES YES YES

MB9BF414R YES YES YES YES

MB9BF415N YES YES YES YES

MB9BF415R YES YES YES YES

MB9BF416N YES YES YES YES

MB9BF416R YES YES YES YES

MB9BF416S YES YES YES YES

MB9BF416T YES YES YES YES

MB9BF417S YES YES YES YES

MB9BF417T YES YES YES YES

MB9BF418S YES YES YES YES

MB9BF418T YES YES YES YES

MB9BF504N YES YES YES YES

MB9BF504R YES YES YES YES

MB9BF505N YES YES YES YES

MB9BF505R YES YES YES YES

MB9BF506N YES YES YES YES

MB9BF506R YES YES YES YES

MB9BF512N YES YES YES YES

MB9BF512R YES YES YES YES

MB9BF514N YES YES YES YES

MB9BF514R YES YES YES YES

MB9BF515N YES YES YES YES

MB9BF515R YES YES YES YES

MB9BF516N YES YES YES YES

MB9BF516R YES YES YES YES

MB9BF516S YES YES YES YES

MB9BF516T YES YES YES YES

MB9BF517S YES YES YES YES

MB9BF517T YES YES YES YES

MB9BF518S YES YES YES YES

MB9BF518T YES YES YES YES

MB9BF616S YES YES YES YES

MB9BF616T YES YES YES YES

MB9BF617S YES YES YES YES

MB9BF617T YES YES YES YES

MB9BF618T YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 24

MB9DF125 YES YES YES YES

MB9DF126 YES YES YES YES

MB9EF126 YES YES YES YES

MC9328MX1 YES YES YES YES

MC9328MXL YES YES YES YES

MC9328MXS YES YES YES YES

MCF5202 YES YES YES

MCF5203 YES YES YES

MCF5204 YES YES YES

MCF5206 YES YES YES

MCF5206E YES YES YES

MCF5207 YES YES YES

MCF5208 YES YES YES

MCF52100 YES YES YES

MCF5211 YES YES YES

MCF52110 YES YES YES

MCF5212 YES YES YES

MCF5213 YES YES YES

MCF5214 YES YES YES

MCF5216 YES YES YES

MCF52210 YES YES YES

MCF52211 YES YES YES

MCF52212 YES YES YES

MCF52213 YES YES YES

MCF52221 YES YES YES

MCF52223 YES YES YES

MCF52230 YES YES YES

MCF52231 YES YES YES

MCF52232 YES YES YES

MCF52233 YES YES YES

MCF52234 YES YES YES

MCF52235 YES YES YES

MCF52236 YES YES YES

MCF52256 YES YES YES

MCF52258 YES YES YES

MCF52259 YES YES YES

MCF52274 YES YES YES

MCF52277 YES YES YES

MCF5232 YES YES YES

MCF5233 YES YES YES

MCF5234 YES YES YES

MCF5235 YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 25

MCF5249 YES YES YES

MCF5249L YES YES YES

MCF5270 YES YES YES

MCF5271 YES YES YES

MCF5272 YES YES YES

MCF5274 YES YES YES

MCF5274L YES YES YES

MCF5275 YES YES YES

MCF5275L YES YES YES

MCF5280 YES YES YES

MCF5281 YES YES YES

MCF5282 YES YES YES

MCF53010 YES YES YES

MCF53011 YES YES YES

MCF53012 YES YES YES

MCF53013 YES YES YES

MCF53014 YES YES YES

MCF53015 YES YES YES

MCF53016 YES YES YES

MCF53017 YES YES YES

MCF5307 YES YES YES

MCF5307A YES YES YES

MCF5307B YES YES YES

MCF5327 YES YES YES

MCF5328 YES YES YES

MCF5329 YES YES YES

MCF5372 YES YES YES

MCF5372L YES YES YES

MCF5373 YES YES YES

MCF5373L YES YES YES

MCF5407 YES YES YES

MCF54410 YES YES YES

MCF54415 YES YES YES

MCF54416 YES YES YES

MCF54417 YES YES YES

MCF54418 YES YES YES

MCF54450 YES YES YES

MCF54451 YES YES YES

MCF54452 YES YES YES

MCF54453 YES YES YES

MCF54454 YES YES YES

MCF54455 YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 26

MCF5470 YES YES YES

MCF5471 YES YES YES

MCF5472 YES YES YES

MCF5473 YES YES YES

MCF5474 YES YES YES

MCF5475 YES YES YES

MCF5480 YES YES YES

MCF5481 YES YES YES

MCF5482 YES YES YES

MCF5483 YES YES YES

MCF5484 YES YES YES

MCF5485 YES YES YES

MCIMX23 YES YES YES YES

MCIMX25 YES YES YES YES

MCIMX27 YES YES YES YES

MCIMX27L YES YES YES YES

MCIMX31 YES YES YES YES

MCIMX35 YES YES YES YES

MCIMX351 YES YES YES YES

MCIMX353 YES YES YES YES

MCIMX355 YES YES YES YES

MCIMX356 YES YES YES YES

MCIMX357 YES YES YES YES

MCIMX37 YES YES YES YES

MDEB YES YES YES

MDED YES YES YES

MGT560 YES YES YES

MICROBLAZE YES YES YES

MK10DN128VEX5 YES YES YES YES

MK10DN128VFM5 YES YES YES YES

MK10DN128VFT5 YES YES YES YES

MK10DN128VLF5 YES YES YES YES

MK10DN128VLH5 YES YES YES YES

MK10DN128VMP5 YES YES YES YES

MK10DN32VEX5 YES YES YES YES

MK10DN32VFM5 YES YES YES YES

MK10DN32VFT5 YES YES YES YES

MK10DN32VLF5 YES YES YES YES

MK10DN32VLH5 YES YES YES YES

MK10DN32VMP5 YES YES YES YES

MK10DN512VLK10 YES YES YES YES

MK10DN512VLL10 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 27

MK10DN512VLQ10 YES YES YES YES

MK10DN512VMB10 YES YES YES YES

MK10DN512VMC10 YES YES YES YES

MK10DN512VMD10 YES YES YES YES

MK10DN64VEX5 YES YES YES YES

MK10DN64VFM5 YES YES YES YES

MK10DN64VFT5 YES YES YES YES

MK10DN64VLF5 YES YES YES YES

MK10DN64VLH5 YES YES YES YES

MK10DN64VMP5 YES YES YES YES

MK10DX128VEX5 YES YES YES YES

MK10DX128VEX7 YES YES YES YES

MK10DX128VFM5 YES YES YES YES

MK10DX128VFT5 YES YES YES YES

MK10DX128VLF5 YES YES YES YES

MK10DX128VLH5 YES YES YES YES

MK10DX128VLH7 YES YES YES YES

MK10DX128VLK7 YES YES YES YES

MK10DX128VLL7 YES YES YES YES

MK10DX128VLQ10 YES YES YES YES

MK10DX128VMC7 YES YES YES YES

MK10DX128VMD10 YES YES YES YES

MK10DX128VML7 YES YES YES YES

MK10DX128VMP5 YES YES YES YES

MK10DX256VEX7 YES YES YES YES

MK10DX256VLH7 YES YES YES YES

MK10DX256VLK7 YES YES YES YES

MK10DX256VLL7 YES YES YES YES

MK10DX256VLQ10 YES YES YES YES

MK10DX256VMC7 YES YES YES YES

MK10DX256VMD10 YES YES YES YES

MK10DX256VML7 YES YES YES YES

MK10DX32VEX5 YES YES YES YES

MK10DX32VFM5 YES YES YES YES

MK10DX32VFT5 YES YES YES YES

MK10DX32VLF5 YES YES YES YES

MK10DX32VLH5 YES YES YES YES

MK10DX32VMP5 YES YES YES YES

MK10DX64VEX5 YES YES YES YES

MK10DX64VEX7 YES YES YES YES

MK10DX64VFM5 YES YES YES YES

MK10DX64VFT5 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 28

MK10DX64VLF5 YES YES YES YES

MK10DX64VLH5 YES YES YES YES

MK10DX64VLH7 YES YES YES YES

MK10DX64VLK7 YES YES YES YES

MK10DX64VMC7 YES YES YES YES

MK10DX64VMP5 YES YES YES YES

MK10FN1M0VLQ12 YES YES YES YES

MK10FN1M0VMD12 YES YES YES YES

MK10FX512VLQ12 YES YES YES YES

MK10FX512VMD12 YES YES YES YES

MK11DN512VLK5 YES YES YES YES

MK11DN512VMC5 YES YES YES YES

MK11DX128VMC5 YES YES YES YES

MK11DX256VLK5 YES YES YES YES

MK11DX256VMC5 YES YES YES YES

MK12DN512VLH5 YES YES YES YES

MK12DN512VLK5 YES YES YES YES

MK12DN512VMC5 YES YES YES YES

MK12DX128VLF5 YES YES YES YES

MK12DX128VLH5 YES YES YES YES

MK12DX128VLK5 YES YES YES YES

MK12DX128VMC5 YES YES YES YES

MK12DX256VLF5 YES YES YES YES

MK12DX256VLH5 YES YES YES YES

MK12DX256VLK5 YES YES YES YES

MK12DX256VMC5 YES YES YES YES

MK20DN128VEX5 YES YES YES YES

MK20DN128VFM5 YES YES YES YES

MK20DN128VFT5 YES YES YES YES

MK20DN128VLF5 YES YES YES YES

MK20DN128VLH5 YES YES YES YES

MK20DN128VMP5 YES YES YES YES

MK20DN32VEX5 YES YES YES YES

MK20DN32VFM5 YES YES YES YES

MK20DN32VFT5 YES YES YES YES

MK20DN32VLF5 YES YES YES YES

MK20DN32VLH5 YES YES YES YES

MK20DN32VMP5 YES YES YES YES

MK20DN512VLK10 YES YES YES YES

MK20DN512VLL10 YES YES YES YES

MK20DN512VLQ10 YES YES YES YES

MK20DN512VMB10 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 29

MK20DN512VMC10 YES YES YES YES

MK20DN512VMD10 YES YES YES YES

MK20DN512ZCAB10 YES YES YES YES

MK20DN64VEX5 YES YES YES YES

MK20DN64VFM5 YES YES YES YES

MK20DN64VFT5 YES YES YES YES

MK20DN64VLF5 YES YES YES YES

MK20DN64VLH5 YES YES YES YES

MK20DN64VMP5 YES YES YES YES

MK20DX128VEX5 YES YES YES YES

MK20DX128VEX7 YES YES YES YES

MK20DX128VFM5 YES YES YES YES

MK20DX128VFT5 YES YES YES YES

MK20DX128VLF5 YES YES YES YES

MK20DX128VLH5 YES YES YES YES

MK20DX128VLH7 YES YES YES YES

MK20DX128VLK7 YES YES YES YES

MK20DX128VLL7 YES YES YES YES

MK20DX128VLQ10 YES YES YES YES

MK20DX128VMC7 YES YES YES YES

MK20DX128VMD10 YES YES YES YES

MK20DX128VML7 YES YES YES YES

MK20DX128VMP5 YES YES YES YES

MK20DX256VEX7 YES YES YES YES

MK20DX256VLH7 YES YES YES YES

MK20DX256VLK10 YES YES YES YES

MK20DX256VLK7 YES YES YES YES

MK20DX256VLL10 YES YES YES YES

MK20DX256VLL7 YES YES YES YES

MK20DX256VLQ10 YES YES YES YES

MK20DX256VMB10 YES YES YES YES

MK20DX256VMC10 YES YES YES YES

MK20DX256VMC7 YES YES YES YES

MK20DX256VMD10 YES YES YES YES

MK20DX256VML7 YES YES YES YES

MK20DX32VEX5 YES YES YES YES

MK20DX32VFM5 YES YES YES YES

MK20DX32VFT5 YES YES YES YES

MK20DX32VLF5 YES YES YES YES

MK20DX32VLH5 YES YES YES YES

MK20DX32VMP5 YES YES YES YES

MK20DX64VEX5 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 30

MK20DX64VEX7 YES YES YES YES

MK20DX64VFM5 YES YES YES YES

MK20DX64VFT5 YES YES YES YES

MK20DX64VLF5 YES YES YES YES

MK20DX64VLH5 YES YES YES YES

MK20DX64VLH7 YES YES YES YES

MK20DX64VLK7 YES YES YES YES

MK20DX64VMC7 YES YES YES YES

MK20DX64VMP5 YES YES YES YES

MK20FN1M0VLQ12 YES YES YES YES

MK20FN1M0VMD12 YES YES YES YES

MK20FX512VLQ12 YES YES YES YES

MK20FX512VMD12 YES YES YES YES

MK21DN512VMC5 YES YES YES YES

MK21DX128VLK5 YES YES YES YES

MK21DX128VMC5 YES YES YES YES

MK21DX256VLK5 YES YES YES YES

MK21DX256VMC5 YES YES YES YES

MK21FN1M0VMC10 YES YES YES YES

MK21FN1M0VMD10 YES YES YES YES

MK21FX512VMC10 YES YES YES YES

MK21FX512VMD10 YES YES YES YES

MK22DN512VLH5 YES YES YES YES

MK22DN512VLK5 YES YES YES YES

MK22DN512VMC5 YES YES YES YES

MK22DX128VLF5 YES YES YES YES

MK22DX128VLH5 YES YES YES YES

MK22DX128VLK5 YES YES YES YES

MK22DX128VMC5 YES YES YES YES

MK22DX256VLF5 YES YES YES YES

MK22DX256VLH5 YES YES YES YES

MK22DX256VLK5 YES YES YES YES

MK22DX256VMC5 YES YES YES YES

MK22FN1M0VLH10 YES YES YES YES

MK22FN1M0VLK10 YES YES YES YES

MK22FN1M0VLL10 YES YES YES YES

MK22FN1M0VLQ10 YES YES YES YES

MK22FN1M0VMC10 YES YES YES YES

MK30DN512VLK10 YES YES YES YES

MK30DN512VLL10 YES YES YES YES

MK30DN512VLQ10 YES YES YES YES

MK30DN512VMB10 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 31

MK30DN512VMC10 YES YES YES YES

MK30DN512VMD10 YES YES YES YES

MK30DX128VEX7 YES YES YES YES

MK30DX128VLH7 YES YES YES YES

MK30DX128VLK7 YES YES YES YES

MK30DX128VLL7 YES YES YES YES

MK30DX128VLQ10 YES YES YES YES

MK30DX128VMC7 YES YES YES YES

MK30DX128VMD10 YES YES YES YES

MK30DX128VML7 YES YES YES YES

MK30DX256VEX7 YES YES YES YES

MK30DX256VLH7 YES YES YES YES

MK30DX256VLK7 YES YES YES YES

MK30DX256VLL7 YES YES YES YES

MK30DX256VLQ10 YES YES YES YES

MK30DX256VMC7 YES YES YES YES

MK30DX256VMD10 YES YES YES YES

MK30DX256VML7 YES YES YES YES

MK30DX64VEX7 YES YES YES YES

MK30DX64VLH7 YES YES YES YES

MK30DX64VLK7 YES YES YES YES

MK30DX64VMC7 YES YES YES YES

MK40DN512VLK10 YES YES YES YES

MK40DN512VLL10 YES YES YES YES

MK40DN512VLQ10 YES YES YES YES

MK40DN512VMB10 YES YES YES YES

MK40DN512VMC10 YES YES YES YES

MK40DN512VMD10 YES YES YES YES

MK40DX128VEX7 YES YES YES YES

MK40DX128VLH7 YES YES YES YES

MK40DX128VLK7 YES YES YES YES

MK40DX128VLL7 YES YES YES YES

MK40DX128VLQ10 YES YES YES YES

MK40DX128VMC7 YES YES YES YES

MK40DX128VMD10 YES YES YES YES

MK40DX128VML7 YES YES YES YES

MK40DX256VEX7 YES YES YES YES

MK40DX256VLH7 YES YES YES YES

MK40DX256VLK7 YES YES YES YES

MK40DX256VLL7 YES YES YES YES

MK40DX256VLQ10 YES YES YES YES

MK40DX256VMC7 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 32

MK40DX256VMD10 YES YES YES YES

MK40DX256VML7 YES YES YES YES

MK40DX64VEX7 YES YES YES YES

MK40DX64VLH7 YES YES YES YES

MK40DX64VLK7 YES YES YES YES

MK40DX64VMC7 YES YES YES YES

MK50DN512CLL10 YES YES YES YES

MK50DN512CLQ10 YES YES YES YES

MK50DN512CMC10 YES YES YES YES

MK50DN512CMD10 YES YES YES YES

MK50DX128CEX7 YES YES YES YES

MK50DX128CLH7 YES YES YES YES

MK50DX128CLK7 YES YES YES YES

MK50DX128CMB7 YES YES YES YES

MK50DX128CMC7 YES YES YES YES

MK50DX256CLK10 YES YES YES YES

MK50DX256CLK7 YES YES YES YES

MK50DX256CLL10 YES YES YES YES

MK50DX256CLL7 YES YES YES YES

MK50DX256CMC10 YES YES YES YES

MK50DX256CMC7 YES YES YES YES

MK50DX256CMD10 YES YES YES YES

MK50DX256CML7 YES YES YES YES

MK51DN256CLQ10 YES YES YES YES

MK51DN256CMD10 YES YES YES YES

MK51DN512CLL10 YES YES YES YES

MK51DN512CLQ10 YES YES YES YES

MK51DN512CMC10 YES YES YES YES

MK51DN512CMD10 YES YES YES YES

MK51DX128CEX7 YES YES YES YES

MK51DX128CLH7 YES YES YES YES

MK51DX128CLK7 YES YES YES YES

MK51DX128CMC7 YES YES YES YES

MK51DX256CLK10 YES YES YES YES

MK51DX256CLK7 YES YES YES YES

MK51DX256CLL10 YES YES YES YES

MK51DX256CLL7 YES YES YES YES

MK51DX256CMC10 YES YES YES YES

MK51DX256CMC7 YES YES YES YES

MK51DX256CML7 YES YES YES YES

MK52DN512CLQ10 YES YES YES YES

MK52DN512CMD10 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 33

MK53DN512CLQ10 YES YES YES YES

MK53DN512CMD10 YES YES YES YES

MK53DX256CLQ10 YES YES YES YES

MK53DX256CMD10 YES YES YES YES

MK60DN256VLL10 YES YES YES YES

MK60DN256VLQ10 YES YES YES YES

MK60DN256VMC10 YES YES YES YES

MK60DN256VMD10 YES YES YES YES

MK60DN512VLL10 YES YES YES YES

MK60DN512VLQ10 YES YES YES YES

MK60DN512VMC10 YES YES YES YES

MK60DN512VMD10 YES YES YES YES

MK60DN512ZAB10 YES YES YES YES

MK60DN512ZCAB10 YES YES YES YES

MK60DX256VLL10 YES YES YES YES

MK60DX256VLQ10 YES YES YES YES

MK60DX256VMC10 YES YES YES YES

MK60DX256VMD10 YES YES YES YES

MK60FN1M0VLQ12 YES YES YES YES

MK60FN1M0VLQ15 YES YES YES YES

MK60FN1M0VMD12 YES YES YES YES

MK60FN1M0VMD15 YES YES YES YES

MK60FX512VLQ12 YES YES YES YES

MK60FX512VLQ15 YES YES YES YES

MK60FX512VMD12 YES YES YES YES

MK60FX512VMD15 YES YES YES YES

MK61FN1M0VMD12 YES YES YES YES

MK61FN1M0VMD15 YES YES YES YES

MK61FN1M0VMJ12 YES YES YES YES

MK61FN1M0VMJ15 YES YES YES YES

MK61FX512VMD12 YES YES YES YES

MK61FX512VMJ12 YES YES YES YES

MK61FX512VMJ15 YES YES YES YES

MK70FN1M0VMJ12 YES YES YES YES

MK70FN1M0VMJ15 YES YES YES YES

MK70FX512VMJ12 YES YES YES YES

MK70FX512VMJ15 YES YES YES YES

MPC533 YES YES YES

MPC534 YES YES YES

MPC535 YES YES YES

MPC536 YES YES YES

MPC555 YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 34

MPC556 YES YES YES

MPC561 YES YES YES

MPC562 YES YES YES

MPC563 YES YES YES

MPC564 YES YES YES

MPC565 YES YES YES

MPC566 YES YES YES

MPC5744K YES YES YES

MPC5744P YES YES YES

MPC5746M YES YES YES

MPC5748G YES YES YES

MPC5777M YES YES YES

MPC821 YES YES YES YES

MPC823 YES YES YES YES

MPC850 YES YES YES YES

MPC852T YES YES YES

MPC855 YES YES YES YES

MPC859DSL YES YES YES

MPC859T YES YES YES

MPC860 YES YES YES YES

MPC862 YES YES YES YES

MPC866P YES YES YES

MPC866T YES YES YES

MPC870 YES YES YES

MPC875 YES YES YES

MPC880 YES YES YES

MPC885 YES YES YES

MSM6100_3G YES YES YES YES

MSM6250 YES YES YES YES

MSM6300 YES YES YES YES

MSM6500 YES YES YES YES

MSP2015 YES YES YES

MSP2020 YES YES YES

MSP7120 YES YES YES

MSP7140 YES YES YES

MXC91231 YES YES YES YES

MXC91321 YES YES YES YES

MXC91323 YES YES YES YES

MXC91331 YES YES YES YES

NETX100 YES YES YES YES

NETX50 YES YES YES YES

NETX500 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 35

NETX51 YES YES YES YES

NIOS-II YES YES YES

NPE405H YES YES YES

NPE405L YES YES YES

OMAP1510 YES YES YES YES

OMAP1610 YES YES YES YES

OMAP1611 YES YES YES YES

OMAP1612 YES YES YES YES

OMAP1710 YES YES YES YES

OMAP2420 YES YES YES YES

OMAP2430 YES YES YES YES

OMAP2431 YES YES YES YES

OMAP310 YES YES YES YES

OMAP331 YES YES YES YES

OMAP3410 YES YES YES YES

OMAP3420 YES YES YES YES

OMAP3430 YES YES YES YES

OMAP3440 YES YES YES YES

OMAP3503 YES YES YES YES

OMAP3515 YES YES YES YES

OMAP3525 YES YES YES YES

OMAP3530 YES YES YES YES

OMAP3610 YES YES YES YES

OMAP3620 YES YES YES YES

OMAP3630 YES YES YES YES

OMAP3640 YES YES YES YES

OMAP4430 YES YES YES YES

OMAP4460 YES YES YES YES

OMAP4470 YES YES YES YES

OMAP5430 YES YES YES YES

OMAP5432 YES YES YES YES

OMAP5910 YES YES YES YES

OMAP5912 YES YES YES YES

OMAP710 YES YES YES YES

OMAP730 YES YES YES YES

OMAP732 YES YES YES YES

OMAP733 YES YES YES YES

OMAP750 YES YES YES YES

OMAP850 YES YES YES YES

OMAPV1030 YES YES YES YES

OMAPV1035 YES YES YES YES

OMAPV2230 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 36

P2040 YES YES YES

P2041 YES YES YES

P3041 YES YES YES

P4040 YES YES YES

P4080 YES YES YES

P5010 YES YES YES

P5020 YES YES YES

P5040 YES YES YES

PCD80703 YES YES YES YES

PCD80705 YES YES YES YES

PCD80708 YES YES YES YES

PCD80715 YES YES YES YES

PCD80716 YES YES YES YES

PCD80718 YES YES YES YES

PCD80720 YES YES YES YES

PCD80721 YES YES YES YES

PCD80725 YES YES YES YES

PCD80727 YES YES YES YES

PCD80728 YES YES YES YES

PIC32MX YES YES YES

PMB2850_E-GOLD YES YES YES YES

PMB6850_E-GOLD+ YES YES YES YES YES

PMB7850_E-GOLD+ YES YES YES YES

PMB7860 YES YES YES YES

PMB7870 YES YES YES YES

PMB7880 YES YES YES YES

PMB7890 YES YES YES

PMB7900 YES YES YES

PMB8870 YES YES YES YES

PMB8875 YES YES YES YES

PMB8876 YES YES YES YES

PMB8877 YES YES YES YES

PMB8878 YES YES YES YES

PMB8888 YES YES YES YES

PPC401 YES YES YES

PPC403GA YES YES YES

PPC403GB YES YES YES

PPC403GC YES YES YES

PPC403GCX YES YES YES

PPC405 YES YES YES

PPC405Axx YES YES YES

PPC405Bxx YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 37

PPC405CR YES YES YES

PPC405Cxx YES YES YES

PPC405Dxx YES YES YES

PPC405EP YES YES YES

PPC405EX YES YES YES

PPC405Exx YES YES YES

PPC405Fxx YES YES YES

PPC405GP YES YES YES

PPC405GPR YES YES YES

PPC405LP YES YES YES

PPC405PM YES YES YES

PPC440 YES YES YES

PPC440Axx YES YES YES

PPC440EP YES YES YES

PPC440EPX YES YES YES

PPC440GP YES YES YES

PPC440GR YES YES YES

PPC440GRX YES YES YES

PPC440GX YES YES YES

PPC440Gxx YES YES YES

PPC440SP YES YES YES

PPC440SPE YES YES YES

PPC460EX YES YES YES

PPC460GT YES YES YES

PPC460SX YES YES YES

PPC476 YES YES YES

PXB4260 YES YES YES

QSD8250 YES YES YES YES

QSD8650 YES YES YES YES

RC32332 YES YES

RC32333 YES YES

RC32334 YES YES

RC32336 YES YES

RC32351 YES YES

RC32355 YES YES

RC32364 YES YES

RC32365 YES YES

RM48L530-ZWT YES YES YES YES

RM48L540-ZWT YES YES YES YES

RM48L550-ZWT YES YES YES YES

RM48L730-ZWT YES YES YES YES

RM48L740-ZWT YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 38

RM48L750-ZWT YES YES YES YES

RM48L930-ZWT YES YES YES YES

RM48L940-ZWT YES YES YES YES

RM48L950-ZWT YES YES YES YES

RM48L952-ZWT YES YES YES YES

RTL8650 YES YES YES

RX610 YES YES YES

RX621 YES YES YES

RX62N YES YES YES

RX630 YES YES YES

RX631 YES YES YES

RX63N YES YES YES

S3FM02G YES YES YES YES

S5PV310 YES YES YES YES

SC000 YES YES YES YES

SC200 YES YES YES YES

SC210 YES YES YES YES

SC300 YES YES YES YES

SCORPION YES YES YES YES

SDA6000_M2 YES YES YES YES

SH2A-CORE YES YES YES

SH7083 YES YES YES

SH7084 YES YES YES

SH7085 YES YES YES

SH7086 YES YES YES

SH7147 YES YES YES

SH7201 YES YES YES

SH7203 YES YES YES

SH7205 YES YES YES

SH7206 YES YES YES

SH7211 YES YES YES

SH7216 YES YES YES

SH72165 YES YES YES

SH72166 YES YES YES

SH72167 YES YES YES

SH7251 YES YES YES

SH72531 YES YES YES

SH72544 YES YES YES

SH72544R YES YES YES

SH72545 YES YES YES

SH72546 YES YES YES

SH72546R YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 39

SH72567 YES YES YES

SH725xxx YES YES YES

SH7261 YES YES YES

SH7263 YES YES YES

SH7264 YES YES YES

SH7267 YES YES YES

SH7294 YES YES YES

SH7300 YES YES YES

SH7315 YES YES YES

SH73382 YES YES YES

SH7357 YES YES YES

SH74504 YES YES YES

SH7705 YES YES YES

SH7706 YES YES YES

SH7709A YES YES YES

SH7709BE YES YES YES

SH7709LE YES YES YES

SH7709S YES YES YES

SH7710 YES YES YES

SH7712 YES YES YES

SH7720 YES YES YES

SH7721 YES YES YES

SH7722 YES YES YES

SH7723 YES YES YES

SH7727 YES YES YES

SH7729 YES YES YES

SH7751 YES YES YES

SH7751R YES YES YES

SH7760 YES YES YES

SH7761 YES YES YES

SH7763 YES YES YES

SH7764 YES YES YES

SH7770 YES YES YES

SH7780 YES YES YES

SH7781 YES YES YES

SH7785 YES YES YES

SH7786 YES YES YES

SP2704 YES YES YES YES

SP2716 YES YES YES YES

SPC574K70 YES YES YES

SPC574K72 YES YES YES

SPC574K74 YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 40

SPC57EM80 YES YES YES

SPC57HM90 YES YES YES

SPEAR1300 YES YES YES YES

SPEAR1310 YES YES YES YES

SPEAR1340 YES YES YES YES

SPEAR300 YES YES YES YES

SPEAR310 YES YES YES YES

SPEAR320 YES YES YES YES

SPEAR320S YES YES YES YES

SPEAR600 YES YES YES YES

ST10... YES YES YES

ST30F7XXA YES YES YES YES

ST30F7XXC YES YES YES YES

ST30F7XXZ YES YES YES YES

ST40GX1 YES YES YES

ST40NGX1 YES YES YES

ST40RA166 YES YES YES

ST40STB1 YES YES YES

STA2064 YES YES YES YES

STA2065 YES YES YES YES

STA2164 YES YES YES YES

STA2165 YES YES YES YES

STM32F100C4 YES YES YES YES

STM32F100C6 YES YES YES YES

STM32F100C8 YES YES YES YES

STM32F100CB YES YES YES YES

STM32F100R4 YES YES YES YES

STM32F100R6 YES YES YES YES

STM32F100R8 YES YES YES YES

STM32F100RB YES YES YES YES

STM32F100RC YES YES YES YES

STM32F100RD YES YES YES YES

STM32F100RE YES YES YES YES

STM32F100V8 YES YES YES YES

STM32F100VB YES YES YES YES

STM32F100VC YES YES YES YES

STM32F100VD YES YES YES YES

STM32F100VE YES YES YES YES

STM32F100ZC YES YES YES YES

STM32F100ZD YES YES YES YES

STM32F100ZE YES YES YES YES

STM32F101C4 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 41

STM32F101C6 YES YES YES YES

STM32F101C8 YES YES YES YES

STM32F101CB YES YES YES YES

STM32F101R6 YES YES YES YES

STM32F101R8 YES YES YES YES

STM32F101RB YES YES YES YES

STM32F101RC YES YES YES YES

STM32F101RD YES YES YES YES

STM32F101RE YES YES YES YES

STM32F101RF YES YES YES YES

STM32F101RG YES YES YES YES

STM32F101T4 YES YES YES YES

STM32F101T6 YES YES YES YES

STM32F101T8 YES YES YES YES

STM32F101TB YES YES YES YES

STM32F101V8 YES YES YES YES

STM32F101VB YES YES YES YES

STM32F101VC YES YES YES YES

STM32F101VD YES YES YES YES

STM32F101VE YES YES YES YES

STM32F101VF YES YES YES YES

STM32F101VG YES YES YES YES

STM32F101ZC YES YES YES YES

STM32F101ZD YES YES YES YES

STM32F101ZE YES YES YES YES

STM32F101ZF YES YES YES YES

STM32F101ZG YES YES YES YES

STM32F102C4 YES YES YES YES

STM32F102C6 YES YES YES YES

STM32F102C8 YES YES YES YES

STM32F102CB YES YES YES YES

STM32F102R4 YES YES YES YES

STM32F102R6 YES YES YES YES

STM32F102R8 YES YES YES YES

STM32F102RB YES YES YES YES

STM32F103C4 YES YES YES YES

STM32F103C6 YES YES YES YES

STM32F103C8 YES YES YES YES

STM32F103CB YES YES YES YES

STM32F103R4 YES YES YES YES

STM32F103R6 YES YES YES YES

STM32F103R8 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 42

STM32F103RB YES YES YES YES

STM32F103RC YES YES YES YES

STM32F103RD YES YES YES YES

STM32F103RE YES YES YES YES

STM32F103RF YES YES YES YES

STM32F103RG YES YES YES YES

STM32F103T4 YES YES YES YES

STM32F103T6 YES YES YES YES

STM32F103T8 YES YES YES YES

STM32F103TB YES YES YES YES

STM32F103V8 YES YES YES YES

STM32F103VB YES YES YES YES

STM32F103VC YES YES YES YES

STM32F103VD YES YES YES YES

STM32F103VE YES YES YES YES

STM32F103VF YES YES YES YES

STM32F103VG YES YES YES YES

STM32F103ZC YES YES YES YES

STM32F103ZD YES YES YES YES

STM32F103ZE YES YES YES YES

STM32F103ZF YES YES YES YES

STM32F103ZG YES YES YES YES

STM32F105R8 YES YES YES YES

STM32F105RB YES YES YES YES

STM32F105RC YES YES YES YES

STM32F105V8 YES YES YES YES

STM32F105VB YES YES YES YES

STM32F105VC YES YES YES YES

STM32F107RB YES YES YES YES

STM32F107RC YES YES YES YES

STM32F107VB YES YES YES YES

STM32F107VC YES YES YES YES

STM32F205RB YES YES YES YES

STM32F205RC YES YES YES YES

STM32F205RE YES YES YES YES

STM32F205RF YES YES YES YES

STM32F205RG YES YES YES YES

STM32F205VB YES YES YES YES

STM32F205VC YES YES YES YES

STM32F205VE YES YES YES YES

STM32F205VF YES YES YES YES

STM32F205VG YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 43

STM32F205ZC YES YES YES YES

STM32F205ZE YES YES YES YES

STM32F205ZF YES YES YES YES

STM32F205ZG YES YES YES YES

STM32F207IC YES YES YES YES

STM32F207IE YES YES YES YES

STM32F207IF YES YES YES YES

STM32F207IG YES YES YES YES

STM32F207VC YES YES YES YES

STM32F207VE YES YES YES YES

STM32F207VF YES YES YES YES

STM32F207VG YES YES YES YES

STM32F207ZC YES YES YES YES

STM32F207ZE YES YES YES YES

STM32F207ZF YES YES YES YES

STM32F207ZG YES YES YES YES

STM32F215RE YES YES YES YES

STM32F215RG YES YES YES YES

STM32F215VE YES YES YES YES

STM32F215VG YES YES YES YES

STM32F215ZE YES YES YES YES

STM32F215ZG YES YES YES YES

STM32F217IE YES YES YES YES

STM32F217IG YES YES YES YES

STM32F217VE YES YES YES YES

STM32F217VG YES YES YES YES

STM32F217ZE YES YES YES YES

STM32F217ZG YES YES YES YES

STM32F302CB YES YES YES YES

STM32F302CC YES YES YES YES

STM32F302RB YES YES YES YES

STM32F302RC YES YES YES YES

STM32F302VB YES YES YES YES

STM32F302VC YES YES YES YES

STM32F303CB YES YES YES YES

STM32F303CC YES YES YES YES

STM32F303RB YES YES YES YES

STM32F303RC YES YES YES YES

STM32F303VB YES YES YES YES

STM32F303VC YES YES YES YES

STM32F313CC YES YES YES YES

STM32F313RC YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 44

STM32F313VC YES YES YES YES

STM32F372C8 YES YES YES YES

STM32F372CB YES YES YES YES

STM32F372CC YES YES YES YES

STM32F372R8 YES YES YES YES

STM32F372RB YES YES YES YES

STM32F372RC YES YES YES YES

STM32F372V8 YES YES YES YES

STM32F372VB YES YES YES YES

STM32F372VC YES YES YES YES

STM32F373C8 YES YES YES YES

STM32F373CB YES YES YES YES

STM32F373CC YES YES YES YES

STM32F373R8 YES YES YES YES

STM32F373RB YES YES YES YES

STM32F373RC YES YES YES YES

STM32F373V8 YES YES YES YES

STM32F373VB YES YES YES YES

STM32F373VC YES YES YES YES

STM32F383CC YES YES YES YES

STM32F383RC YES YES YES YES

STM32F383VC YES YES YES YES

STM32F405RG YES YES YES YES

STM32F405VG YES YES YES YES

STM32F405ZG YES YES YES YES

STM32F407IE YES YES YES YES

STM32F407IG YES YES YES YES

STM32F407VE YES YES YES YES

STM32F407VG YES YES YES YES

STM32F407ZE YES YES YES YES

STM32F415RG YES YES YES YES

STM32F415VG YES YES YES YES

STM32F415ZG YES YES YES YES

STM32F417IE YES YES YES YES

STM32F417IG YES YES YES YES

STM32F417VE YES YES YES YES

STM32F417VG YES YES YES YES

STM32F417ZE YES YES YES YES

STM32F417ZG YES YES YES YES

STM32L151C6 YES YES YES YES

STM32L151C8 YES YES YES YES

STM32L151CB YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 45

STM32L151QC YES YES YES YES

STM32L151QD YES YES YES YES

STM32L151R6 YES YES YES YES

STM32L151RB YES YES YES YES

STM32L151RC YES YES YES YES

STM32L151RD YES YES YES YES

STM32L151V8 YES YES YES YES

STM32L151VB YES YES YES YES

STM32L151VC YES YES YES YES

STM32L151VD YES YES YES YES

STM32L151ZC YES YES YES YES

STM32L151ZD YES YES YES YES

STM32L152C6 YES YES YES YES

STM32L152C8 YES YES YES YES

STM32L152CB YES YES YES YES

STM32L152QC YES YES YES YES

STM32L152QD YES YES YES YES

STM32L152R6 YES YES YES YES

STM32L152R8 YES YES YES YES

STM32L152RB YES YES YES YES

STM32L152RC YES YES YES YES

STM32L152RD YES YES YES YES

STM32L152V8 YES YES YES YES

STM32L152VB YES YES YES YES

STM32L152VC YES YES YES YES

STM32L152VD YES YES YES YES

STM32L152ZC YES YES YES YES

STM32L152ZD YES YES YES YES

STM32L162QD YES YES YES YES

STM32L162RD YES YES YES YES

STM32L162VD YES YES YES YES

STM32L162ZD YES YES YES YES

STM32W108C8 YES YES YES YES

STM32W108CB YES YES YES YES

STM32W108CC YES YES YES YES

STM32W108CZ YES YES YES YES

STM32W108HB YES YES YES YES

STN8810 YES YES YES YES

STN8815 YES YES YES YES

STN8820 YES YES YES YES

STR720 YES YES YES YES

STR910FAM32 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 46

STR910FAW32 YES YES YES YES

STR910FAZ32 YES YES YES YES

STR911FAM42 YES YES YES YES

STR911FAM44 YES YES YES YES

STR911FAM46 YES YES YES YES

STR911FAM47 YES YES YES YES

STR911FAW42 YES YES YES YES

STR911FAW44 YES YES YES YES

STR911FAW46 YES YES YES YES

STR911FAW47 YES YES YES YES

STR912FAW42 YES YES YES YES

STR912FAW44 YES YES YES YES

STR912FAW46 YES YES YES YES

STR912FAW47 YES YES YES YES

STR912FAZ42 YES YES YES YES

STR912FAZ44 YES YES YES YES

STR912FAZ46 YES YES YES YES

STR912FAZ47 YES YES YES YES

T4160 YES YES YES

T4240 YES YES YES

TC10GP YES YES YES

TC1100 YES YES YES

TC1115 YES YES YES

TC1130 YES YES YES

TC1161 YES YES YES YES

TC1162 YES YES YES YES

TC1163 YES YES YES YES

TC1164 YES YES YES YES

TC1165 YES YES YES YES

TC1166 YES YES YES YES

TC11IA YES YES YES

TC11IB YES YES YES

TC11IC YES YES YES

TC1762 YES YES YES YES

TC1764 YES YES YES YES

TC1765 YES YES YES

TC1766 YES YES YES YES

TC1766ED YES YES YES YES

TC1775 YES YES YES

TC1792 YES YES YES YES

TC1796 YES YES YES YES

TC1796ED YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 47

TC1796L YES YES YES YES

TC1910 YES YES YES

TC1912 YES YES YES

TC1920 YES YES YES

TC264DE YES YES YES

TC265DE YES YES YES

TC275TE YES YES YES

TC277TE YES YES YES

TC2D5TE YES YES YES

TC2D7TE YES YES YES

TEAKLITE-III YES YES

TL3210 YES YES

TMPM330FD YES YES YES YES

TMPM330FW YES YES YES YES

TMPM330FY YES YES YES YES

TMPM332FW YES YES YES YES

TMPM333FW YES YES YES YES

TMPM360F20 YES YES YES YES

TMPM361F10 YES YES YES YES

TMPM362F10 YES YES YES YES

TMPM370FY YES YES YES YES

TMPM372FW YES YES YES YES

TMPM380FWFG YES YES YES YES

TMPM380FYFG YES YES YES YES

TMPM382FSFG YES YES YES YES

TMPM382FYFG YES YES YES YES

TMPM390FW YES YES YES YES

TMPM395FW YES YES YES YES

TMS320DM3725 YES YES YES YES

TMS320DM3730 YES YES YES YES

TMS320TCI6488 YES YES

TMS320VC5470 YES YES YES YES

TMS470MF031 YES YES YES YES

TMS470MF042 YES YES YES YES

TMS470MF066 YES YES YES YES

TMS470MSF541 YES YES YES YES

TMS470MSF542 YES YES YES YES

TMS570LS10106-ZWT YES YES YES YES

TMS570LS10116-ZWT YES YES YES YES

TMS570LS10206-ZWT YES YES YES YES

TMS570LS10216-ZWT YES YES YES YES

TMS570LS1114-ZWT YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 48

TMS570LS1115-ZWT YES YES YES YES

TMS570LS1224-ZWT YES YES YES YES

TMS570LS1225-ZWT YES YES YES YES

TMS570LS1227-ZWT YES YES YES YES

TMS570LS20206-ZWT YES YES YES YES

TMS570LS20216-ZWT YES YES YES YES

TMS570LS2124-ZWT YES YES YES YES

TMS570LS2125-ZWT YES YES YES YES

TMS570LS2134-ZWT YES YES YES YES

TMS570LS2135-ZWT YES YES YES YES

TMS570LS3134-ZWT YES YES YES YES

TMS570LS3135-ZWT YES YES YES YES

TMS570LS3137-ZWT YES YES YES YES

TX4938 YES YES YES

V850E/ME2 YES YES YES

VF11xR YES YES YES YES

VF12xR YES YES YES YES

VF31xR YES YES YES YES

VF32xR YES YES YES YES

VF3xx YES YES YES YES

VF4xx YES YES YES YES

VF51xR YES YES YES YES

VF52xR YES YES YES YES

VF5xx YES YES YES YES

VF6xx YES YES YES YES

VF7xx YES YES YES YES

VR5500A YES YES YES

VR5701 YES YES YES

XC161CJ YES YES YES YES

XC161CS YES YES YES YES

XC164CM YES YES YES YES

XC164CS YES YES YES YES

XC167CI YES YES YES YES

XMC4100 YES YES YES YES

XMC4104 YES YES YES YES

XMC4200 YES YES YES YES

XMC4400 YES YES YES YES

XMC4402 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Supported Processors

TRACE32 - Technical Information 49

XMC4500 YES YES YES YES

XMC4502 YES YES YES YES

XMC4504 YES YES YES YES

XMC4700 YES YES YES YES

ZYNQ7000 YES YES YES YES

CPU

ICE

FIRE

ICD

DEBUG

ICD

MONITOR

ICD

TRACE

POWER

INTEGRATOR

INSTRUCTION

SIMULATOR

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 50

Operation Voltage and Frequeny

Operation Voltage Debugger

Adapter Code OrderNo Voltage Rang e

JTAG Debugger for ST40 (ICD) JTAG-ST40 LA-3710 3.0 .. 3.6 V

JTAG Debugger for CEVA-X (ICD) JTAG-CEVAX LA-3711 3.0 .. 3.6 V

JTAG Debugger License for

CEVA-X Additional

JTAG-CEVAX-

LA-3711A 3.0 .. 3.6 V

JTAG Debugger for ZSP500 DSP

Core (ICD)

JTAG-ZSP500 LA-3712 1.8 .. 3.6 V

JTAG Debugger for ZSP500 DSP

Core Additional

JTAG-

ZSP500-A

LA-3712A 1.8 .. 3.6 V

JTAG Debugger for MSP430 (ICD) JTAG-

MSP430

LA-3713 1.8 .. 3.6 V

JTAG Debugger for RH850 (ICD) JTAG-RH850 LA-3719 0.4 .. 5.2 V

Debugger for MicroBlaze (ICD) JTAG-

MICROBLAZ

LA-3730 1.8 .. 3.6 V

JTAG Debug. License for

MicroBlaze Additonal

JTAG-

MICROBLAZ

E-A

LA-3730A 1.8 .. 3.6 V

OCDS Debugger for XC800 (ICD) OCDS-XC800 LA-3732 2.5 .. 5.2 V

JTAG Debugger for MPC86xx

(ICD)

DEBUG-

MPC86XX

LA-3735 3.0 .. 3.6 V

JTAG Debugger Extension for

MPC86xx

DEBUG-

MPC86XX-X

LA-3735X 3.0 .. 3.6 V

JTAG Debugger for MPC5xxx

Automotive

DEBUG-

MPC5XXX-

AUTO

LA-3736 1.6 .. 5.5 V

JTAG Debugger for TriCore

Automotive

DEBUG-

TRICORE-

AUTO

LA-3737 1.6 .. 5.5 V

Debugger-Bundle MPC5xxx/

TriCore Automotive

DEBUG-MPC-

TC-AUTO

LA-3738 1.6 .. 5.5 V

JTAG Debugger for Cortex-A5x

(ICD)

JTAG-

ARMV8-A

LA-3743 0.4 .. 5.2 V

JTAG Debugger License for

Cortex-A5x Add.

JTAG-

ARMV8-A-A

LA-3743A 0.4 .. 5.2 V

JTAG Debugger Extension for

Cortex-A5x

JTAG-

ARMV8-A-X

LA-3743X 0.4 .. 5.2 V

JTAG Debugger for H8SX (ICD) JTAG-H8SX LA-3745 3.0 .. 5.2 V

JTAG Debugger Extension for

H8SX (ICD)

JTAG-H8SX-X LA-3745X 3.0 .. 5.2 V

BDM Debugger for ColdFire+/V1

(ICD)

BDM-

COLDFIRE-

LA-3746 3.0 .. 5.5 V

BDM Debugger for MCS12Z (ICD) BDM-

MCS12Z

LA-3748 2.7 .. 5.5 V

JTAG Debugger for ARC (ICD) JTAG-ARC LA-3750 0.4 .. 5.2 V

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 51

JTAG Debugger License for ARC

Add.

JTAG-ARC-A LA-3750A 0.4 .. 5.2 V

JTAG Debugger for ARC XDP 60

(ICD)

JTAG-ARC-

XDP

LA-3752 0.4 .. 5.2 V

JTAG Debugger for PWRficient

(ICD)

DEBUG-

PWRFICIENT

LA-3754 1.6 .. 5.0 V

JTAG Debugger for AndesCore

(ICD)

JTAG-ANDES LA-3756 0.4 .. 5.2 V

BDM Debugger for ColdFire HS

(ICD)

BDM-

COLDFIRE-

LA-3757 3.0 .. 5.5 V

JTAG Debugger for Xtensa 14 Pin JTAG-

XTENSA

LA-3760 0.4 .. 5.2 V

JTAG Debugger License for

Xtensa Add.

JTAG-

XTENSA-A

LA-3760A 0.4 .. 5.2 V

JTAG Debugger for Xtensa 20 Pin JTAG-

XTENSA-20

LA-3762 3.0 .. 3.6 V

JTAG Debugger for TeakLite III

(ICD)

JTAG-

TEAKLITE-III

LA-3774 0.4 .. 5.2 V

JTAG Debugger for TeakLite III

Add. (ICD)

JTAG-

TEAKLITE-III-

LA-3774A 0.4 .. 5.2 V

JTAG Debugger Extension for

TEAKLITE-III

JTAG-

TEAKLITE-III-

LA-3774X 0.4 .. 5.2 V

JTAG Debugger for x86 AMD

(ICD)

DEBUG-AMD-

X86

LA-3775 1.6 .. 5.5 V

JTAG Debugger for Intel® Atom™

and x86 (ICD)

DEBUG-

ATO M

LA-3776 1.6 .. 5.5 V

JTAG Debugger for Atom™ and

x86 Add.

DEBUG-

ATO M - A

LA-3776A 1.6 .. 5.5 V

Debugger for 78K0R/RL78 (ICD) DEBUG-

78K0R/RL78

LA-3777 1.6 .. 5.5 V

JTAG Debugger for APS 60 (ICD) JTAG-APS-60 LA-3778 1.6 .. 5.5 V

JTAG Debugger License for APS

Add.

JTAG-APS-A LA-3778A 1.6 .. 5.5 V

JTAG Debugger for AVR32 (ICD) DEBUG-

AVR32

LA-3779 1.6 .. 5.5 V

JTAG Debugger for APS 20 (ICD) JTAG-APS-20 LA-3785 1.6 .. 5.5 V

Debugger for RX Family JTAG-RX LA-3786 3.0 .. 3.6 V

JTAG Debugger for Beyond JTAG-

BEYOND

LA-3793 0.4 .. 5.2 V

JTAG Debugger for QorIQ 64 Bit

(ICD)

DEBUG-

QORIQ64

LA-3794 1.6 .. 5.5 V

JTAG Debugger Extension for

QorIQ 64 Bit

DEBUG-

QORIQ64-X

LA-3794X 1.6 .. 5.5 V

JTAG Debugger for QorIQ 32 Bit

(ICD)

DEBUG-

QORIQ32

LA-3795 1.6 .. 5.5 V

JTAG Debugger Extension for

QorIQ 32 Bit

DEBUG-

QORIQ32-X

LA-3795X 1.6 .. 5.5 V

JTAG Debugger for MPC85XX/

QorIQ e500 (ICD)

DEBUG-PQ3 LA-3796 1.6 .. 5.5 V

JTAG Debugger Extension for

MPC85XX/QorIQ

DEBUG-PQ3-

LA-3796X 1.6 .. 5.5 V

Adapter Code OrderNo Voltage Rang e

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 52

JTAG Debugger for M32R SDI-3

(ICD)

DEBUG-

M32R

LA-7661 0.4 .. 5.2 V

BDM Debugger for 68K (ICD) BDM-68K LA-7710 3.0 .. 5.5 V

BDM Debugger for 68HC16 (ICD) BDM-HC16 LA-7712 4.5 .. 5.5 V

BDM Debugger for 68HC12 (ICD) BDM-HC12 LA-7714 2.7 .. 5.5 V

BDM Debugger for MCS12 (ICD) BDM-MCS12 LA-7717 2.7 .. 5.5 V

JTAG Debugger for MPC74xx

(ICD)

DEBUG-

PPC74XX

LA-7719 1.6 .. 5.5 V

JTAG Debugger Extension for

MPC74xx (ICD)

DEBUG-

PPC74XX-X

LA-7719X 1.6 .. 5.5 V

JTAG Debugger for PPC603/

MPC74x/75x (ICD)

DEBUG-

PPC603

LA-7721 1.6 .. 5.5 V

JTAG Debugger Extension for

PPC603(ICD)

DEBUG-

PPC603-X

LA-7721X 1.6 .. 5.5 V

BDM Debugger for MPC500/800

(ICD)

BDM-

MPC500/800

LA-7722 2.5 .. 5.0 V

JTAG Debugger for PPC400 (ICD) DEBUG-

PPC400

LA-7723 1.6 .. 5.5 V

JTAG Debugger License for

PPC400 Add.

DEBUG-

PPC400-A

LA-7723A 1.6 .. 5.5 V

JTAG Debugger Extension for

PPC400 (ICD)

DEBUG-

PPC400-X

LA-7723X 1.6 .. 5.5 V

JTAG Debugger for MPC82xx/

MPC83xx(ICD)

DEBUG-

MPC8260

LA-7729 1.6 .. 5.5 V

JTAG Debugger Extension for

MPC8260/MPC8240

DEBUG-

MPC8260-X

LA-7729X 1.6 .. 5.5 V

BDM Debugger for MCS08 (ICD) BDM-MCS08 LA-7733 1.8 .. 5.5 V

JTAG Debugger for MPC5200/

MPC512x (ICD)

JTAG-

MPC5200

LA-7734 1.6 .. 5.5 V

JTAG Debugger Extension for

MPC5200/MPC512x

JTAG-

MPC5200-X

LA-7734X 1.6 .. 5.5 V

BDM Debugger for DSP56300

(ICD)

BDM-

DSP56300

LA-7735 4.5 .. 5.5 V

BDM Debugger for MCS12X (ICD) BDM-

MCS12X

LA-7736 2.7 .. 5.5 V

BDM Debugger for DSP56800 and

DSP56800E (ICD)

BDM-

DSP56800

LA-7738 4.5 .. 5.5 V

JTAG Debugger for JANUS (ICD) JTAG-JANUS LA-7739 1.8 .. 3.6 V

JTAG Debugger for ARM9 (ICD) JTAG-ARM9 LA-7742 0.4 .. 5.2 V

JTAG Debugger License for ARM9

Add.

JTAG-ARM9-

LA-7742A 0.4 .. 5.2 V

JTAG Debugger Extension for

ARM9

JTAG-ARM9-

LA-7742X 0.4 .. 5.2 V

JTAG Debugger for ARM10 (ICD) JTAG-ARM10 LA-7744 0.4 .. 5.2 V

JTAG Debugger License for

ARM10 Add.

JTAG-ARM10-

LA-7744A 0.4 .. 5.2 V

JTAG Debugger Extension for

ARM10

JTAG-ARM10-

LA-7744X 0.4 .. 5.2 V

ONCE Debugger for M-CORE

(ICD)

ONCE-

MCORE

LA-7745 2.5 .. 5.5 V

JTAG Debugger for ARM7 20 Pin

Connector (ICD)

JTAG-ARM7-

LA-7746 0.4 .. 5.2 V

JTAG Debugger License for ARM7

Add.

JTAG-ARM7-

LA-7746A 0.4 .. 5.2 V

Adapter Code OrderNo Voltage Rang e

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 53

JTAG Debugger Extension for

ARM7

JTAG-ARM7-

LA-7746X 0.4 .. 5.2 V

Debugger for 196EA (ICD) DEBUG-

196EA

LA-7750 4.5 .. 5.5 V

JTAG Debugger for PPC44x (ICD) DEBUG-

PPC44X

LA-7752 1.6 .. 5.5 V

JTAG Debugger License for

PPC44x Add.

DEBUG-

PPC44X-A

LA-7752A 1.6 .. 5.5 V

JTAG Debugger Extension for

PPC44x (ICD)

DEBUG-

PPC44X-X

LA-7752X 1.6 .. 5.5 V

JTAG Debugger Qorivva

MPC5xxx/SPC5xxx (ICD)

DEBUG-

MPC5500

LA-7753 1.6 .. 5.5 V

JTAG Debugger for MPC5xxx

(ICD) Additional

DEBUG-

MPC5500-A

LA-7753A 1.6 .. 5.5 V

OCDS Debugger for C166CBC

(ICD)

OCDS-

C166CBC

LA-7755 2.5 .. 5.2 V

OCDS Debugger for TriCore (ICD) OCDS-

TRICORE

LA-7756 2.5 .. 5.2 V

OCDS Debugger for TriCore

Additional

OCDS-

TRICORE-A

LA-7756A 2.5 .. 5.2 V

Debugger for SH2/SH3/SH4 H-

UDI-14 Pin (ICD)

JTAG-SH4-14 LA-7758 3.0 .. 3.6 V

OCDS Debugger for XC2000/

C166S V2 (ICD)

OCDS-

C166S-V2

LA-7759 2.5 .. 5.2 V

OCDS Debugger for XC2000/

C166S V2 Additional

OCDS-

C166S-V2-A

LA-7759A 2.5 .. 5.2 V

JTAG Debugger for MIPS32 (ICD) EJTAG-

MIPS32

LA-7760 1.8 .. 3.6 V

EJTAG Debugger License for

MIPS32 Add.

EJTAG-

MIPS32-A

LA-7760A 1.8 .. 3.6 V

JTAG Debugger for MIPS64 (ICD) EJTAG-

MIPS64

LA-7761 1.8 .. 3.6 V

EJTAG Debugger License for

MIPS64 Add.

EJTAG-

MIPS64-A

LA-7761A 1.8 .. 3.6 V

JTAG Debugger for XSCALE (ICD) JTAG-

XSCALE

LA-7762 0.4 .. 5.2 V

JTAG Debugger Extension for

XSCALE (ICD)

JTAG-

XSCALE-X

LA-7762X 0.4 .. 5.2 V

JTAG Debugger for Super10 (ICD) JTAG-

SUPER10

LA-7763 2.5 .. 5.0 V

JTAG Debugger for ARM11 (ICD) JTAG-ARM11 LA-7765 0.4 .. 5.2 V

JTAG Debugger License for

ARM11 Add.

JTAG-ARM11-

LA-7765A 0.4 .. 5.2 V

JTAG Debugger Extension for

ARM11

JTAG-ARM11-

LA-7765X 0.4 .. 5.2 V

JTAG Debugger for H8S (ICD) JTAG-H8S LA-7766 3.0 .. 5.2 V

JTAG Debugger for Teak/TeakLite

JAM 20 (ICD)

JTAG-TEAK-

JAM-20

LA-7774 0.4 .. 5.2 V

JTAG Debug. for Teak/TeakLite

JAM 20 Add.

JTAG-TEAK-

JAM-20-A

LA-7774A 0.4 .. 5.2 V

JTAG Debugger Extension for

TEAK-JAM

JTAG-TEAK-

JAM-X

LA-7774X 0.4 .. 5.2 V

JTAG Debugger for OAK/TeakLite

SEIB (ICD)

JTAG-OAK-

SEIB

LA-7789 1.8 .. 3.6 V

Adapter Code OrderNo Voltage Rang e

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 54

JTAG Debugger for TeakLite/OAK

SEIB (ICD)

JTAG-OAK-

SEIB-A

LA-7789A 1.8 .. 3.6 V

JTAG Debugger Extension for

TeakLite/OAK SEIB

JTAG-OAK-

SEIB-X

LA-7789X 1.8 .. 3.6 V

JTAG Debugger for SH2/SH3/SH4

20 Pin (ICD)

JTAG-SH4-20 LA-7817 3.0 .. 3.6 V

JTAG Debugger License for SH2/

SH3/SH4 Add.

JTAG-SH4-A-

LA-7817A 3.0 .. 3.6 V

JTAG Debugger for TMS320C55X

(ICD)

JTAG-C55X LA-7830 1.8 .. 3.6 V

JTAG Debugger License for

TMS320C55x Add.

JTAG-C55X-A LA-7830A 1.8 .. 3.6 V

JTAG Debugger Extension for

TMSC55X

JTAG-C55X-X LA-7830X 1.8 .. 3.6 V

JTAG Debugger for TMS320C54X

(ICD)

JTAG-C54X LA-7831 1.8 .. 3.6 V

JTAG Debugger License for

TMS320C54X Add.

JTAG-C54X-A LA-7831A 1.8 .. 3.6 V

JTAG Debugger Extension for

TMSC54X

JTAG-C54X-X LA-7831X 1.8 .. 3.6 V

JTAG Debugger for ZSP400 DSP

Core

JTAG-ZSP400 LA-7832 1.8 .. 3.6 V

JTAG Debugger for ZSP400 DSP

Core Additional

JTAG-

ZSP400-A

LA-7832A 1.8 .. 3.6 V

JTAG Debugger for BLACKFIN

(ICD)

JTAG-

BLACKFIN

LA-7833 0.4 .. 5.2 V

JTAG Debugger for StarCore 14

Pin (ICD)

JTAG-

STARCORE-

LA-7834 1.8 .. 3.6 V

N-Wire Debugger for V850 (ICD) JTAG-V850 LA-7835 0.4 .. 5.2 V

JTAG Debugger for MMDSP (ICD) JTAG-MMDSP LA-7836 1.8 .. 3.6 V

JTAG Debugger License for

MMDSP

JTAG-

MMDSP-A

LA-7836A 1.8 .. 3.6 V

Debugger for NIOS-II (ICD) JTAG-NIOS-II LA-7837 1.8 .. 3.6 V

JTAG Debugger for

TMS320C6x00 (ICD)

JTAG-C6X00 LA-7838 1.8 .. 3.6 V

JTAG Debugger License for

TMS320C6xxx Add.

JTAG-C6XXX-

LA-7838A 1.8 .. 3.6 V

N-Wire Debugger for NEC VR-

Series (ICD)

JTAG-VR LA-7842 0.4 .. 5.2 V

JTAG Debugger for Cortex-A/-R

(ARMv7) (ICD)

JTAG-

CORTEX-A/R

LA-7843 0.4 .. 5.2 V

JTAG Debugger License for

Cortex-A/-R Add.

JTAG-

CORTEX-A/

R-A

LA-7843A 0.4 .. 5.2 V

JTAG Debugger Extension for

Cortex-A/-R

JTAG-

CORTEX-A/

R-X

LA-7843X 0.4 .. 5.2 V

JTAG Debugger for Cortex-M

(ICD)

JTAG-

CORTEX_M

LA-7844 0.4 .. 5.2 V

JTAG Debugger License for

Cortex-M Add.

JTAG-

CORTEX_M-

LA-7844A 0.4 .. 5.2 V

Adapter Code OrderNo Voltage Rang e

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 55

Operation Voltage Trace

This list contains information on probes

available for other voltage ranges.

Probes not noted here supply an oper-

ation voltage range from 4.5V to 5.5V.

JTAG Debugger Extension for

Cortex-M

JTAG-

CORTEX_M-

LA-7844X 0.4 .. 5.2 V

JTAG Debugger for StarCore 20

Pin (ICD)

JTAG-

STARCORE-

LA-7845 1.8 .. 3.6 V

JTAG Debugger License for

StarCore 20 Pin Add

JTAG-

STARCORE-

20-A

LA-7845A 1.8 .. 3.6 V

JTAG Debugger for TMS320C28X

(ICD)

JTAG-

TMS320C28X

LA-7847 1.8 .. 3.6 V

JTAG Debugger License for

TMS320C28X Add.

JTAG-

TMS320C28X

-A

LA-7847A 1.8 .. 3.6 V

Adapter Code OrderNo Voltage Rang e

Preprocessor for ColdFire family

PP-

COLDFIRE-

LA-3759 3.0 .. 5.5 V

Preprocessor for ST40 (AUD) PP-ST40 LA-3800 3.0 .. 3.6 V

Preprocessor for NIOS-II Flex

Cable

PP-NIOSII LA-3801 1.5 .. 5.0 V

Preproc. for PPC4XX

AUTOFOCUS II Flex

PP-PPC4XX-

AF-2

LA-3900 1.8 .. 3.3 V

Trace License for PPC4XX

AUTOFOCUS II

PP-PPC4XX-

AF-2-ADD

LA-3900A 1.8 .. 3.3 V

Preproc. for MICROBLAZE

AUTOFOCUS II Flex

PP-

MICROBLAZ

E-AF-2

LA-3901 1.8 .. 3.3 V

Trace License for MicroBlaze

AUTOFOCUS II

PP-

MICROBLA-

AF-2-ADD

LA-3901A 1.8 .. 3.3 V

Preproc. for SHx (AUD)

AUTOFOCUS II FLEX

PP-SHX-AF-2 LA-3902 1.8 .. 3.3 V

Trace License for SH2A, SH4,

SH4A in AF II

PP-SHX-AF-

2-ADD

LA-3902A 1.8 .. 3.3 V

Preproc. for TMS320C64x+

AUTOFOCUS II Flex

PP-C64XP-

AF-2

LA-3903 1.8 .. 3.3 V

Trace License for TMS320C64x+

in AUTOFOCUS II

PP-C64XP-

AF-2-ADD

LA-3903A 1.8 .. 3.3 V

Preproc. for TEAKLITE-III

AUTOFOCUS II Flex

PP-

TEAKLITE3-

AF-2

LA-3904 1.8 .. 3.3 V

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 56

Trace License for TEAKLITE-III

AUTOFOCUS II

PP-

TEAKLITE3-

AF-2-AD

LA-3904A 1.8 .. 3.3 V

Preproc. for RAM Trace Port

AUTOFOCUS II Flex

PP-RTP-AF-2 LA-3905 1.8 .. 3.3 V

Trace License for RAM Trace Port

AUTOFOCUS II

PP-RTP-AF-

2-AD

LA-3905A 1.8 .. 3.3 V

Preproc. for MIPS32

AUTOFOCUS 600 MIPI

PP-MIPS32-

AF-2

LA-3906 1.8 .. 3.3 V

Preproc. for Beyond AUTOFOCUS

II Flex

PP-BEYOND-

AF-2

LA-3908 1.8 .. 3.3 V

Nexus Adapter for Argon+ NEXUS-

ARGON+

LA-7606 2.6 .. 3.3 V

Preprocessor for MPC500/800

Family Data V2

PP-MPC500/

800-V2

LA-7856 2.5 .. 5.0 V

Preprocessor for complete

EGOLD family

PP-

EGOLD+V3

LA-7857 1.8 .. 3.3 V

Preprocessor for MPC500/800

Family (center)

PP-MPC500/

800-C

LA-7871 3.0 .. 3.6 V

Preprocessor for MPC500/800

Family (edge)

PP-MPC500/

800-E

LA-7877 3.0 .. 3.6 V

Preprocessor TriCore OCDS-L2

5V Samtec 60

PP-

TRICORE-5V

LA-7879 3.0 .. 5.5 V

Preprocessor for C166 family PP-C166-

FAMILY

LA-7880 3.0 .. 5.5 V

Preprocessor for EGOLD family PP-EGOLD LA-7881 3.0 .. 5.5 V

Preprocessor for MPC500/800

Family Data

PP-MPC500/

800-D

LA-7883 2.5 .. 5.0 V

Preprocessor for MPC860 and

MPC821 TCON

PP-MPC860-

LA-7884 2.5 .. 5.0 V

Preprocessor for MPC850 and

MPC823-TCON

PP-MPC850-

LA-7885 2.5 .. 5.0 V

Preprocessor for MPC555 TCON PP-MPC555-

LA-7886 2.5 .. 5.0 V

Preprocessor for ARM-ETM 120 PP-ARM-

ETM/120

LA-7889 2.5 .. 3.6 V

Preprocessor for EGOLD+ family PP-EGOLD+ LA-7893 2.2 .. 5.5 V

Preprocessor for MIPS flex cable PP-MIPS LA-7894 0.9 .. 3.3 V

Preprocessor for SH4 and RX

(AUD)

PP-SH3/4 LA-7898 3.0 .. 3.6 V

Preprocessor for MPC880 and

MPC885 TCON

PP-MPC880-

LA-7905 2.5 .. 5.0 V

Converter AMP 40 to Samtec 60 ICD-TC-CON-

40/60

LA-7919 3.0 .. 5.5 V

Preprocessor for ARM-ETM 200

flex cable

PP-ARM-

ETM/200

LA-7921 0.9 .. 3.3 V

Preprocessor for ETM 2-MICTOR

2 flex cables

PP-ARM-

ETM-TWO

LA-7923 2.5 .. 3.6 V

Preprocessor TriCore OCDS-L2

3.3V Samtec 60

PP-

TRICORE-

3.3V

LA-7928 1.8 .. 3.3 V

Preprocessor for PPC4xx family

fast flex

PP-PPC4XX-

LA-7929 0.9 .. 3.6 V

Preprocessor for ST40 8 Bit Data

(AUD)

PP-ST40/8-

BIT-DATA

LA-7934 3.0 .. 3.6 V

Adapter Code OrderNo Voltage Rang e

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 57

Preprocessor for V850-Flex Cable PP-TRACE-

V850

LA-7935 1.8 .. 5.5 V

Preprocessor for VR-Flex PP-TRACE-

LA-7942 1.8 .. 5.5 V

Trace License for QorIQ TRACE-

LICENSE-

QORIQ

LA-7967X 0.9 .. 3.3 V

Trace License Qorivva MPC57xx

and SPC57xx

TRACE-

LICENSE-

MPC57X

LA-7968X 0.9 .. 3.3 V

Trace License for TEAKLITE-III TRACE-

LICENSE-

TEAK3

LA-7969X 0.9 .. 3.3 V

Trace License for ARM (Debug

Cable)

TRACE-

LICENSE-

ARM

LA-7970X 0.9 .. 3.3 V

Trace License for the MIPS32 TRACE-

LICENSE-

MIPS32

LA-7971X 0.9 .. 3.3 V

JTAG Onchip Trace Support for

SH2A

SH2A-OC-

TRACE

LA-7973X 0.9 .. 3.3 V

Trace License for TMS320C55X TRACE-

LICENSE-

C55X

LA-7976X 0.9 .. 3.3 V

Trace License for Ceva-X TRACE-

LICENSE-

CEVAX

LA-7977X 0.9 .. 3.3 V

Trace License for TMS320C6x00 TRACE-

LICENSE-

C6X00

LA-7979X 0.9 .. 3.3 V

Preprocessor for ARM-ETM with

AUTOFOCUS Flex

PP-ARM-

ETM-AF

LA-7991 1.8 .. 3.3 V

Preproc. for ARM-ETM/

AUTOFOCUS II 600 Flex

PP-ARM-

ETM-AF-2

LA-7992 1.8 .. 3.3 V

Trace License for ARM-ETM

AUTOFOCUS II

PP-ARM-

ETM-AF-2-

ADD

LA-7992A 1.8 .. 3.3 V

Preproc. for ARM-ETM/

AUTOFOCUS 600 MIPI

PP-ARM-

ETM-AF-MIPI

LA-7993 1.8 .. 3.3 V

Preproc. for TMS320C55x

AUTOFOCUS II Flex

PP-C55X-AF-

LA-7995 1.8 .. 3.3 V

Trace License for TMS320C55x

AUTOFOCUS II

PP-C55X-AF-

2-ADD

LA-7995A 1.8 .. 3.3 V

Preproc. for Ceva-X AUTOFOCUS

II Flex

PP-CEVA-AF-

LA-7996 1.8 .. 3.3 V

Trace License for Ceva-X

AUTOFOCUS II

PP-CEVA-AF-

2-ADD

LA-7996A 1.8 .. 3.3 V

Preproc. for STARCORE

AUTOFOCUS II Flex

PP-

STARCORE-

AF-2

LA-7999 1.8 .. 3.3 V

Trace License for StarCore

AUTOFOCUS II

PP-

STARCORE-

AF-2-ADD

LA-7999A 1.8 .. 3.3 V

Preprocessor for MPC561/

MPC563 TCON320

PP-MPC561-

LA-9662 2.6 .. 5.5 V

Adapter Code OrderNo Voltage Rang e

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 58

Operation Frequency Trace

The maximum operation frequency of

TRACE32-RISC Trace or PowerTrace

depends on:

❏The max. frequency of the CPU

❏The number of waitstates (bus

trace)

❏The divide factor between trace

clock and core clock

❏The speed of the trace adapter

Module CPU TRACE

LA-3759 MCF5202

LA-3759 MCF5203

LA-3759 MCF5204

LA-3759 MCF5206

LA-3759 MCF5206E

LA-3759 MCF5207

LA-3759 MCF5208

LA-3759 MCF52100

LA-3759 MCF5211

LA-3759 MCF52110

LA-3759 MCF5212

LA-3759 MCF5213

LA-3759 MCF5214

LA-3759 MCF5216

LA-3759 MCF52210

LA-3759 MCF52211

LA-3759 MCF52212

LA-3759 MCF52213

LA-3759 MCF52221

LA-3759 MCF52223

LA-3759 MCF52230

LA-3759 MCF52231

LA-3759 MCF52232

LA-3759 MCF52233

LA-3759 MCF52234

LA-3759 MCF52235

LA-3759 MCF52236

LA-3759 MCF5232

LA-3759 MCF5233

LA-3759 MCF5234

LA-3759 MCF5235

LA-3759 MCF5249

LA-3759 MCF5249L

LA-3759 MCF5270

LA-3759 MCF5271

LA-3759 MCF5272

LA-3759 MCF5274

LA-3759 MCF5274L

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 59

LA-3759 MCF5275

LA-3759 MCF5275L

LA-3759 MCF5280

LA-3759 MCF5281

LA-3759 MCF5282

LA-3759 MCF53010

LA-3759 MCF53011

LA-3759 MCF53012

LA-3759 MCF53013

LA-3759 MCF53014

LA-3759 MCF53015

LA-3759 MCF53016

LA-3759 MCF53017

LA-3759 MCF5307

LA-3759 MCF5307A

LA-3759 MCF5307B

LA-3759 MCF5327

LA-3759 MCF5328

LA-3759 MCF5329

LA-3759 MCF5372

LA-3759 MCF5372L

LA-3759 MCF5373

LA-3759 MCF5373L

LA-3759 MCF5407

LA-3759 MCF54410

LA-3759 MCF54415

LA-3759 MCF54416

LA-3759 MCF54417

LA-3759 MCF54418

LA-3759 MCF54450

LA-3759 MCF54451

LA-3759 MCF54452

LA-3759 MCF54453

LA-3759 MCF54454

LA-3759 MCF54455

LA-3759 MCF5470

LA-3759 MCF5471

LA-3759 MCF5472

LA-3759 MCF5473

LA-3759 MCF5474

LA-3759 MCF5475

LA-3759 MCF5480

LA-3759 MCF5481

LA-3759 MCF5482

LA-3759 MCF5483

LA-3759 MCF5484

LA-3759 MCF5485

LA-3800 ST40GX1 80.0 MHz

LA-3800 ST40NGX1 80.0 MHz

LA-3800 ST40RA166 80.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 60

LA-3801 NIOS-II 150.0 MHz

LA-3900 APM86190 500.0 MHz

LA-3900 APM86190B 500.0 MHz

LA-3900 APM86290 500.0 MHz

LA-3900 APM86290B 500.0 MHz

LA-3900 APM86491 500.0 MHz

LA-3900 APM86692 500.0 MHz

LA-3900 PPC460EX 500.0 MHz

LA-3900 PPC460GT 500.0 MHz

LA-3900 PPC460SX 500.0 MHz

LA-3900 PPC476 500.0 MHz

LA-3902 SH7786 550.0 MHz

LA-3903 TMS320TCI6488 0.3 MHz

LA-3906 1004K

LA-3906 24K

LA-3906 24KE

LA-3906 34K

LA-3906 4KC

LA-3906 4KEC

LA-3906 4KM

LA-3906 4KP

LA-3906 4KSD

LA-3906 74K

LA-3906 AR7242

LA-3906 INTERAPTIV

LA-3906 LX4189 180.0 MHz

LA-3906 LX4X80 180.0 MHz

LA-3906 LX5180 180.0 MHz

LA-3906 LX5280 180.0 MHz

LA-3906 MDEB 180.0 MHz (CPU 720.0 MHz)

LA-3906 MDED 180.0 MHz (CPU 720.0 MHz)

LA-3906 MSP2015 180.0 MHz

LA-3906 MSP2020 180.0 MHz

LA-3906 MSP7120 180.0 MHz

LA-3906 MSP7140 180.0 MHz

LA-3906 RC32332 180.0 MHz

LA-3906 RC32333 180.0 MHz

LA-3906 RC32334 180.0 MHz

LA-3906 RC32336 180.0 MHz

LA-3906 RC32351 180.0 MHz

LA-3906 RC32355 180.0 MHz

LA-3906 RC32364 180.0 MHz

LA-3906 RC32365 180.0 MHz

LA-3906 RTL8650 180.0 MHz

LA-3906 TX4938

LA-3911 MPC5744K

LA-3911 MPC5744P

LA-3911 MPC5746M

LA-3911 MPC5748G

LA-3911 MPC5777M

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 61

LA-3911 SPC574K70

LA-3911 SPC574K72

LA-3911 SPC574K74

LA-3911 SPC57EM80

LA-3911 SPC57HM90

LA-4502 CORTEX-M3 100.0 MHz

LA-4502 CORTEX-M4 100.0 MHz

LA-4502 CY8C5245 100.0 MHz

LA-4502 CY8C5246 100.0 MHz

LA-4502 CY8C5247 100.0 MHz

LA-4502 CY8C5248 100.0 MHz

LA-4502 CY8C5385 100.0 MHz

LA-4502 CY8C5386 100.0 MHz

LA-4502 CY8C5387 100.0 MHz

LA-4502 CY8C5388 100.0 MHz

LA-4502 CY8C5485 100.0 MHz

LA-4502 CY8C5486 100.0 MHz

LA-4502 CY8C5487 100.0 MHz

LA-4502 CY8C5488 100.0 MHz

LA-4502 CY8C5585 100.0 MHz

LA-4502 CY8C5586 100.0 MHz

LA-4502 CY8C5587 100.0 MHz

LA-4502 CY8C5588 100.0 MHz

LA-4502 M1A3P1000 100.0 MHz

LA-4502 M1A3P1000L 100.0 MHz

LA-4502 M1A3P250 100.0 MHz

LA-4502 M1A3P400 100.0 MHz

LA-4502 M1A3P600 100.0 MHz

LA-4502 M1A3P600L 100.0 MHz

LA-4502 M1A3PE3000L 100.0 MHz

LA-4502 M1AFS1500 100.0 MHz

LA-4502 M1AFS250 100.0 MHz

LA-4502 M1AFS600 100.0 MHz

LA-4502 M1AGL1000 100.0 MHz

LA-4502 M1AGL250 100.0 MHz

LA-4502 M1AGL400 100.0 MHz

LA-4502 M1AGL600 100.0 MHz

LA-4502 M1AGLE3000 100.0 MHz

LA-4502 MK10DN128VEX5 100.0 MHz

LA-4502 MK10DN128VFM5 100.0 MHz

LA-4502 MK10DN128VFT5 100.0 MHz

LA-4502 MK10DN128VLF5 100.0 MHz

LA-4502 MK10DN128VLH5 100.0 MHz

LA-4502 MK10DN128VMP5 100.0 MHz

LA-4502 MK10DN32VEX5 100.0 MHz

LA-4502 MK10DN32VFM5 100.0 MHz

LA-4502 MK10DN32VFT5 100.0 MHz

LA-4502 MK10DN32VLF5 100.0 MHz

LA-4502 MK10DN32VLH5 100.0 MHz

LA-4502 MK10DN32VMP5 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 62

LA-4502 MK10DN512VLK10 100.0 MHz

LA-4502 MK10DN512VLL10 100.0 MHz

LA-4502 MK10DN512VLQ10 100.0 MHz

LA-4502 MK10DN512VMB10 100.0 MHz

LA-4502 MK10DN512VMC10 100.0 MHz

LA-4502 MK10DN512VMD10 100.0 MHz

LA-4502 MK10DN64VEX5 100.0 MHz

LA-4502 MK10DN64VFM5 100.0 MHz

LA-4502 MK10DN64VFT5 100.0 MHz

LA-4502 MK10DN64VLF5 100.0 MHz

LA-4502 MK10DN64VLH5 100.0 MHz

LA-4502 MK10DN64VMP5 100.0 MHz

LA-4502 MK10DX128VEX5 100.0 MHz

LA-4502 MK10DX128VEX7 100.0 MHz

LA-4502 MK10DX128VFM5 100.0 MHz

LA-4502 MK10DX128VFT5 100.0 MHz

LA-4502 MK10DX128VLF5 100.0 MHz

LA-4502 MK10DX128VLH5 100.0 MHz

LA-4502 MK10DX128VLH7 100.0 MHz

LA-4502 MK10DX128VLK7 100.0 MHz

LA-4502 MK10DX128VLL7 100.0 MHz

LA-4502 MK10DX128VLQ10 100.0 MHz

LA-4502 MK10DX128VMC7 100.0 MHz

LA-4502 MK10DX128VMD10 100.0 MHz

LA-4502 MK10DX128VML7 100.0 MHz

LA-4502 MK10DX128VMP5 100.0 MHz

LA-4502 MK10DX256VEX7 100.0 MHz

LA-4502 MK10DX256VLH7 100.0 MHz

LA-4502 MK10DX256VLK7 100.0 MHz

LA-4502 MK10DX256VLL7 100.0 MHz

LA-4502 MK10DX256VLQ10 100.0 MHz

LA-4502 MK10DX256VMC7 100.0 MHz

LA-4502 MK10DX256VMD10 100.0 MHz

LA-4502 MK10DX256VML7 100.0 MHz

LA-4502 MK10DX32VEX5 100.0 MHz

LA-4502 MK10DX32VFM5 100.0 MHz

LA-4502 MK10DX32VFT5 100.0 MHz

LA-4502 MK10DX32VLF5 100.0 MHz

LA-4502 MK10DX32VLH5 100.0 MHz

LA-4502 MK10DX32VMP5 100.0 MHz

LA-4502 MK10DX64VEX5 100.0 MHz

LA-4502 MK10DX64VEX7 100.0 MHz

LA-4502 MK10DX64VFM5 100.0 MHz

LA-4502 MK10DX64VFT5 100.0 MHz

LA-4502 MK10DX64VLF5 100.0 MHz

LA-4502 MK10DX64VLH5 100.0 MHz

LA-4502 MK10DX64VLH7 100.0 MHz

LA-4502 MK10DX64VLK7 100.0 MHz

LA-4502 MK10DX64VMC7 100.0 MHz

LA-4502 MK10DX64VMP5 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 63

LA-4502 MK10FN1M0VLQ12 100.0 MHz

LA-4502 MK10FN1M0VMD12 100.0 MHz

LA-4502 MK10FX512VLQ12 100.0 MHz

LA-4502 MK10FX512VMD12 100.0 MHz

LA-4502 MK11DN512VLK5 100.0 MHz

LA-4502 MK11DN512VMC5 100.0 MHz

LA-4502 MK11DX128VMC5 100.0 MHz

LA-4502 MK11DX256VLK5 100.0 MHz

LA-4502 MK11DX256VMC5 100.0 MHz

LA-4502 MK12DN512VLH5 100.0 MHz

LA-4502 MK12DN512VLK5 100.0 MHz

LA-4502 MK12DN512VMC5 100.0 MHz

LA-4502 MK12DX128VLF5 100.0 MHz

LA-4502 MK12DX128VLH5 100.0 MHz

LA-4502 MK12DX128VLK5 100.0 MHz

LA-4502 MK12DX128VMC5 100.0 MHz

LA-4502 MK12DX256VLF5 100.0 MHz

LA-4502 MK12DX256VLH5 100.0 MHz

LA-4502 MK12DX256VLK5 100.0 MHz

LA-4502 MK12DX256VMC5 100.0 MHz

LA-4502 MK20DN128VEX5 100.0 MHz

LA-4502 MK20DN128VFM5 100.0 MHz

LA-4502 MK20DN128VFT5 100.0 MHz

LA-4502 MK20DN128VLF5 100.0 MHz

LA-4502 MK20DN128VLH5 100.0 MHz

LA-4502 MK20DN128VMP5 100.0 MHz

LA-4502 MK20DN32VEX5 100.0 MHz

LA-4502 MK20DN32VFM5 100.0 MHz

LA-4502 MK20DN32VFT5 100.0 MHz

LA-4502 MK20DN32VLF5 100.0 MHz

LA-4502 MK20DN32VLH5 100.0 MHz

LA-4502 MK20DN32VMP5 100.0 MHz

LA-4502 MK20DN512VLK10 100.0 MHz

LA-4502 MK20DN512VLL10 100.0 MHz

LA-4502 MK20DN512VLQ10 100.0 MHz

LA-4502 MK20DN512VMB10 100.0 MHz

LA-4502 MK20DN512VMC10 100.0 MHz

LA-4502 MK20DN512VMD10 100.0 MHz

LA-4502 MK20DN512ZCAB10 100.0 MHz

LA-4502 MK20DN64VEX5 100.0 MHz

LA-4502 MK20DN64VFM5 100.0 MHz

LA-4502 MK20DN64VFT5 100.0 MHz

LA-4502 MK20DN64VLF5 100.0 MHz

LA-4502 MK20DN64VLH5 100.0 MHz

LA-4502 MK20DN64VMP5 100.0 MHz

LA-4502 MK20DX128VEX5 100.0 MHz

LA-4502 MK20DX128VEX7 100.0 MHz

LA-4502 MK20DX128VFM5 100.0 MHz

LA-4502 MK20DX128VFT5 100.0 MHz

LA-4502 MK20DX128VLF5 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 64

LA-4502 MK20DX128VLH5 100.0 MHz

LA-4502 MK20DX128VLH7 100.0 MHz

LA-4502 MK20DX128VLK7 100.0 MHz

LA-4502 MK20DX128VLL7 100.0 MHz

LA-4502 MK20DX128VLQ10 100.0 MHz

LA-4502 MK20DX128VMC7 100.0 MHz

LA-4502 MK20DX128VMD10 100.0 MHz

LA-4502 MK20DX128VML7 100.0 MHz

LA-4502 MK20DX128VMP5 100.0 MHz

LA-4502 MK20DX256VEX7 100.0 MHz

LA-4502 MK20DX256VLH7 100.0 MHz

LA-4502 MK20DX256VLK10 100.0 MHz

LA-4502 MK20DX256VLK7 100.0 MHz

LA-4502 MK20DX256VLL10 100.0 MHz

LA-4502 MK20DX256VLL7 100.0 MHz

LA-4502 MK20DX256VLQ10 100.0 MHz

LA-4502 MK20DX256VMB10 100.0 MHz

LA-4502 MK20DX256VMC10 100.0 MHz

LA-4502 MK20DX256VMC7 100.0 MHz

LA-4502 MK20DX256VMD10 100.0 MHz

LA-4502 MK20DX256VML7 100.0 MHz

LA-4502 MK20DX32VEX5 100.0 MHz

LA-4502 MK20DX32VFM5 100.0 MHz

LA-4502 MK20DX32VFT5 100.0 MHz

LA-4502 MK20DX32VLF5 100.0 MHz

LA-4502 MK20DX32VLH5 100.0 MHz

LA-4502 MK20DX32VMP5 100.0 MHz

LA-4502 MK20DX64VEX5 100.0 MHz

LA-4502 MK20DX64VEX7 100.0 MHz

LA-4502 MK20DX64VFM5 100.0 MHz

LA-4502 MK20DX64VFT5 100.0 MHz

LA-4502 MK20DX64VLF5 100.0 MHz

LA-4502 MK20DX64VLH5 100.0 MHz

LA-4502 MK20DX64VLH7 100.0 MHz

LA-4502 MK20DX64VLK7 100.0 MHz

LA-4502 MK20DX64VMC7 100.0 MHz

LA-4502 MK20DX64VMP5 100.0 MHz

LA-4502 MK20FN1M0VLQ12 100.0 MHz

LA-4502 MK20FN1M0VMD12 100.0 MHz

LA-4502 MK20FX512VLQ12 100.0 MHz

LA-4502 MK20FX512VMD12 100.0 MHz

LA-4502 MK21DN512VMC5 100.0 MHz

LA-4502 MK21DX128VLK5 100.0 MHz

LA-4502 MK21DX128VMC5 100.0 MHz

LA-4502 MK21DX256VLK5 100.0 MHz

LA-4502 MK21DX256VMC5 100.0 MHz

LA-4502 MK21FN1M0VMC10 100.0 MHz

LA-4502 MK21FN1M0VMD10 100.0 MHz

LA-4502 MK21FX512VMC10 100.0 MHz

LA-4502 MK21FX512VMD10 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 65

LA-4502 MK22DN512VLH5 100.0 MHz

LA-4502 MK22DN512VLK5 100.0 MHz

LA-4502 MK22DN512VMC5 100.0 MHz

LA-4502 MK22DX128VLF5 100.0 MHz

LA-4502 MK22DX128VLH5 100.0 MHz

LA-4502 MK22DX128VLK5 100.0 MHz

LA-4502 MK22DX128VMC5 100.0 MHz

LA-4502 MK22DX256VLF5 100.0 MHz

LA-4502 MK22DX256VLH5 100.0 MHz

LA-4502 MK22DX256VLK5 100.0 MHz

LA-4502 MK22DX256VMC5 100.0 MHz

LA-4502 MK22FN1M0VLH10 100.0 MHz

LA-4502 MK22FN1M0VLK10 100.0 MHz

LA-4502 MK22FN1M0VLL10 100.0 MHz

LA-4502 MK22FN1M0VLQ10 100.0 MHz

LA-4502 MK22FN1M0VMC10 100.0 MHz

LA-4502 MK30DN512VLK10 100.0 MHz

LA-4502 MK30DN512VLL10 100.0 MHz

LA-4502 MK30DN512VLQ10 100.0 MHz

LA-4502 MK30DN512VMB10 100.0 MHz

LA-4502 MK30DN512VMC10 100.0 MHz

LA-4502 MK30DN512VMD10 100.0 MHz

LA-4502 MK30DX128VEX7 100.0 MHz

LA-4502 MK30DX128VLH7 100.0 MHz

LA-4502 MK30DX128VLK7 100.0 MHz

LA-4502 MK30DX128VLL7 100.0 MHz

LA-4502 MK30DX128VLQ10 100.0 MHz

LA-4502 MK30DX128VMC7 100.0 MHz

LA-4502 MK30DX128VMD10 100.0 MHz

LA-4502 MK30DX128VML7 100.0 MHz

LA-4502 MK30DX256VEX7 100.0 MHz

LA-4502 MK30DX256VLH7 100.0 MHz

LA-4502 MK30DX256VLK7 100.0 MHz

LA-4502 MK30DX256VLL7 100.0 MHz

LA-4502 MK30DX256VLQ10 100.0 MHz

LA-4502 MK30DX256VMC7 100.0 MHz

LA-4502 MK30DX256VMD10 100.0 MHz

LA-4502 MK30DX256VML7 100.0 MHz

LA-4502 MK30DX64VEX7 100.0 MHz

LA-4502 MK30DX64VLH7 100.0 MHz

LA-4502 MK30DX64VLK7 100.0 MHz

LA-4502 MK30DX64VMC7 100.0 MHz

LA-4502 MK40DN512VLK10 100.0 MHz

LA-4502 MK40DN512VLL10 100.0 MHz

LA-4502 MK40DN512VLQ10 100.0 MHz

LA-4502 MK40DN512VMB10 100.0 MHz

LA-4502 MK40DN512VMC10 100.0 MHz

LA-4502 MK40DN512VMD10 100.0 MHz

LA-4502 MK40DX128VEX7 100.0 MHz

LA-4502 MK40DX128VLH7 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 66

LA-4502 MK40DX128VLK7 100.0 MHz

LA-4502 MK40DX128VLL7 100.0 MHz

LA-4502 MK40DX128VLQ10 100.0 MHz

LA-4502 MK40DX128VMC7 100.0 MHz

LA-4502 MK40DX128VMD10 100.0 MHz

LA-4502 MK40DX128VML7 100.0 MHz

LA-4502 MK40DX256VEX7 100.0 MHz

LA-4502 MK40DX256VLH7 100.0 MHz

LA-4502 MK40DX256VLK7 100.0 MHz

LA-4502 MK40DX256VLL7 100.0 MHz

LA-4502 MK40DX256VLQ10 100.0 MHz

LA-4502 MK40DX256VMC7 100.0 MHz

LA-4502 MK40DX256VMD10 100.0 MHz

LA-4502 MK40DX256VML7 100.0 MHz

LA-4502 MK40DX64VEX7 100.0 MHz

LA-4502 MK40DX64VLH7 100.0 MHz

LA-4502 MK40DX64VLK7 100.0 MHz

LA-4502 MK40DX64VMC7 100.0 MHz

LA-4502 MK50DN512CLL10 100.0 MHz

LA-4502 MK50DN512CLQ10 100.0 MHz

LA-4502 MK50DN512CMC10 100.0 MHz

LA-4502 MK50DN512CMD10 100.0 MHz

LA-4502 MK50DX128CEX7 100.0 MHz

LA-4502 MK50DX128CLH7 100.0 MHz

LA-4502 MK50DX128CLK7 100.0 MHz

LA-4502 MK50DX128CMB7 100.0 MHz

LA-4502 MK50DX128CMC7 100.0 MHz

LA-4502 MK50DX256CLK10 100.0 MHz

LA-4502 MK50DX256CLK7 100.0 MHz

LA-4502 MK50DX256CLL10 100.0 MHz

LA-4502 MK50DX256CLL7 100.0 MHz

LA-4502 MK50DX256CMC10 100.0 MHz

LA-4502 MK50DX256CMC7 100.0 MHz

LA-4502 MK50DX256CMD10 100.0 MHz

LA-4502 MK50DX256CML7 100.0 MHz

LA-4502 MK51DN256CLQ10 100.0 MHz

LA-4502 MK51DN256CMD10 100.0 MHz

LA-4502 MK51DN512CLL10 100.0 MHz

LA-4502 MK51DN512CLQ10 100.0 MHz

LA-4502 MK51DN512CMC10 100.0 MHz

LA-4502 MK51DN512CMD10 100.0 MHz

LA-4502 MK51DX128CEX7 100.0 MHz

LA-4502 MK51DX128CLH7 100.0 MHz

LA-4502 MK51DX128CLK7 100.0 MHz

LA-4502 MK51DX128CMC7 100.0 MHz

LA-4502 MK51DX256CLK10 100.0 MHz

LA-4502 MK51DX256CLK7 100.0 MHz

LA-4502 MK51DX256CLL10 100.0 MHz

LA-4502 MK51DX256CLL7 100.0 MHz

LA-4502 MK51DX256CMC10 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 67

LA-4502 MK51DX256CMC7 100.0 MHz

LA-4502 MK51DX256CML7 100.0 MHz

LA-4502 MK52DN512CLQ10 100.0 MHz

LA-4502 MK52DN512CMD10 100.0 MHz

LA-4502 MK53DN512CLQ10 100.0 MHz

LA-4502 MK53DN512CMD10 100.0 MHz

LA-4502 MK53DX256CLQ10 100.0 MHz

LA-4502 MK53DX256CMD10 100.0 MHz

LA-4502 MK60DN256VLL10 100.0 MHz

LA-4502 MK60DN256VLQ10 100.0 MHz

LA-4502 MK60DN256VMC10 100.0 MHz

LA-4502 MK60DN256VMD10 100.0 MHz

LA-4502 MK60DN512VLL10 100.0 MHz

LA-4502 MK60DN512VLQ10 100.0 MHz

LA-4502 MK60DN512VMC10 100.0 MHz

LA-4502 MK60DN512VMD10 100.0 MHz

LA-4502 MK60DN512ZAB10 100.0 MHz

LA-4502 MK60DN512ZCAB10 100.0 MHz

LA-4502 MK60DX256VLL10 100.0 MHz

LA-4502 MK60DX256VLQ10 100.0 MHz

LA-4502 MK60DX256VMC10 100.0 MHz

LA-4502 MK60DX256VMD10 100.0 MHz

LA-4502 MK60FN1M0VLQ12 100.0 MHz

LA-4502 MK60FN1M0VLQ15 100.0 MHz

LA-4502 MK60FN1M0VMD12 100.0 MHz

LA-4502 MK60FN1M0VMD15 100.0 MHz

LA-4502 MK60FX512VLQ12 100.0 MHz

LA-4502 MK60FX512VLQ15 100.0 MHz

LA-4502 MK60FX512VMD12 100.0 MHz

LA-4502 MK60FX512VMD15 100.0 MHz

LA-4502 MK61FN1M0VMD12 100.0 MHz

LA-4502 MK61FN1M0VMD15 100.0 MHz

LA-4502 MK61FN1M0VMJ12 100.0 MHz

LA-4502 MK61FN1M0VMJ15 100.0 MHz

LA-4502 MK61FX512VMD12 100.0 MHz

LA-4502 MK61FX512VMJ12 100.0 MHz

LA-4502 MK61FX512VMJ15 100.0 MHz

LA-4502 MK70FN1M0VMJ12 100.0 MHz

LA-4502 MK70FN1M0VMJ15 100.0 MHz

LA-4502 MK70FX512VMJ12 100.0 MHz

LA-4502 MK70FX512VMJ15 100.0 MHz

LA-4502 SC000 100.0 MHz

LA-4502 SC300 100.0 MHz

LA-4502 XMC4100 100.0 MHz

LA-4502 XMC4104 100.0 MHz

LA-4502 XMC4200 100.0 MHz

LA-4502 XMC4400 100.0 MHz

LA-4502 XMC4402 100.0 MHz

LA-4502 XMC4500 100.0 MHz

LA-4502 XMC4502 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 68

LA-4502 XMC4504 100.0 MHz

LA-4502 XMC4700 100.0 MHz

LA-4504 M14K

LA-4504 M14KC

LA-4504 M4K

LA-4504 PIC32MX

LA-4506 PMB7890 104.0 MHz

LA-4506 PMB7900 104.0 MHz

LA-7660 M32176

LA-7660 M32180

LA-7660 M32192

LA-7856 MPC561 66.0 MHz

LA-7856 MPC562 66.0 MHz

LA-7856 MPC563 66.0 MHz

LA-7856 MPC564 66.0 MHz

LA-7856 MPC880 66.0 MHz (CPU 120.0 MHz)

LA-7856 MPC885 66.0 MHz (CPU 120.0 MHz)

LA-7857 PMB6850_E-GOLD+ 26.0 MHz

LA-7857 PMB7850_E-GOLD+ 52.0 MHz

LA-7857 PMB7860 52.0 MHz

LA-7857 PMB7870 52.0 MHz

LA-7857 PMB7880 52.0 MHz

LA-7872 IOP480 66.0 MHz

LA-7874 ARM710T-AMBA 50.0 MHz

LA-7874 ARM720T-AMBA 50.0 MHz

LA-7874 ARM740T-AMBA 50.0 MHz

LA-7874 ARM7TDMI 50.0 MHz

LA-7874 ARM7TDMI-AMBA 50.0 MHz

LA-7874 JANUS2 50.0 MHz

LA-7874 JANUS200 50.0 MHz

LA-7874 JANUS220 50.0 MHz

LA-7874 JANUSCC 50.0 MHz

LA-7874 TMS320VC5470 40.0 MHz

LA-7880 C161..167 30.0 MHz

LA-7880 C161U 66.0 MHz

LA-7880 C165 30.0 MHz

LA-7880 C165H 66.0 MHz

LA-7880 C165UTAH 30.0 MHz

LA-7880 C166CBC 30.0 MHz

LA-7880 C167 30.0 MHz

LA-7880 C167C 30.0 MHz

LA-7880 C167CR 30.0 MHz

LA-7880 C167CS 30.0 MHz

LA-7880 C167CW 30.0 MHz

LA-7880 C167SR 30.0 MHz

LA-7880 INCA-P 30.0 MHz

LA-7880 PMB2850_E-GOLD 26.0 MHz

LA-7880 PMB6850_E-GOLD+ 26.0 MHz

LA-7880 SDA6000_M2 66.0 MHz

LA-7880 ST10... 66.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 69

LA-7880 XC161CJ 30.0 MHz

LA-7880 XC161CS 30.0 MHz

LA-7880 XC164CM 30.0 MHz

LA-7880 XC164CS 30.0 MHz

LA-7880 XC167CI 30.0 MHz

LA-7881 PMB2850_E-GOLD 26.0 MHz

LA-7883 MGT560 40.0 MHz

LA-7883 MPC533 40.0 MHz

LA-7883 MPC534 40.0 MHz

LA-7883 MPC535 40.0 MHz

LA-7883 MPC536 40.0 MHz

LA-7883 MPC555 60.0 MHz

LA-7883 MPC556 60.0 MHz

LA-7883 MPC561 40.0 MHz

LA-7883 MPC562 40.0 MHz

LA-7883 MPC563 40.0 MHz

LA-7883 MPC564 40.0 MHz

LA-7883 MPC565 40.0 MHz

LA-7883 MPC566 40.0 MHz

LA-7883 MPC821 40.0 MHz

LA-7883 MPC823 40.0 MHz

LA-7883 MPC850 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC852T 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC855 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC859DSL 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC859T 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC860 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC862 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC866P 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC866T 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC870 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC875 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC880 40.0 MHz (CPU 80.0 MHz)

LA-7883 MPC885 40.0 MHz (CPU 80.0 MHz)

LA-7884 MPC821 50.0 MHz

LA-7884 MPC821 40.0 MHz (CPU 50.0 MHz)

LA-7884 MPC855 50.0 MHz (CPU 80.0 MHz)

LA-7884 MPC860 50.0 MHz (CPU 80.0 MHz)

LA-7884 MPC862 50.0 MHz (CPU 80.0 MHz)

LA-7885 MPC823 50.0 MHz

LA-7885 MPC850 50.0 MHz (CPU 80.0 MHz)

LA-7885 MPC852T 50.0 MHz (CPU 80.0 MHz)

LA-7886 MPC555 60.0 MHz

LA-7886 MPC556 60.0 MHz

LA-7893 PMB6850_E-GOLD+ 26.0 MHz

LA-7897 NPE405H 100.0 MHz

LA-7897 NPE405L 100.0 MHz

LA-7898 RX610 200.0 MHz

LA-7898 RX621 200.0 MHz

LA-7898 RX62N 200.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 70

LA-7898 RX630 200.0 MHz

LA-7898 RX631 200.0 MHz

LA-7898 RX63N 200.0 MHz

LA-7898 SH2A-CORE 50.0 MHz

LA-7898 SH7083 50.0 MHz

LA-7898 SH7084 50.0 MHz

LA-7898 SH7085 50.0 MHz

LA-7898 SH7086 50.0 MHz

LA-7898 SH7147 50.0 MHz

LA-7898 SH7201 50.0 MHz

LA-7898 SH7203 50.0 MHz

LA-7898 SH7205 50.0 MHz

LA-7898 SH7206 50.0 MHz

LA-7898 SH7211 50.0 MHz

LA-7898 SH7216 50.0 MHz

LA-7898 SH72165 50.0 MHz

LA-7898 SH72166 50.0 MHz

LA-7898 SH72167 50.0 MHz

LA-7898 SH7251 50.0 MHz

LA-7898 SH72531 50.0 MHz

LA-7898 SH72544 50.0 MHz

LA-7898 SH72544R 50.0 MHz

LA-7898 SH72545 50.0 MHz

LA-7898 SH72546 50.0 MHz

LA-7898 SH72546R 50.0 MHz

LA-7898 SH72567 50.0 MHz

LA-7898 SH725xxx 50.0 MHz

LA-7898 SH7261 50.0 MHz

LA-7898 SH7263 50.0 MHz

LA-7898 SH7264 50.0 MHz

LA-7898 SH7267 50.0 MHz

LA-7898 SH7294 100.0 MHz

LA-7898 SH7300 100.0 MHz

LA-7898 SH7315 100.0 MHz

LA-7898 SH73382 200.0 MHz

LA-7898 SH7357 200.0 MHz

LA-7898 SH74504 200.0 MHz

LA-7898 SH7705 100.0 MHz

LA-7898 SH7706 100.0 MHz

LA-7898 SH7709A 100.0 MHz

LA-7898 SH7709BE 100.0 MHz

LA-7898 SH7709LE 100.0 MHz

LA-7898 SH7709S 100.0 MHz

LA-7898 SH7710 200.0 MHz

LA-7898 SH7712 200.0 MHz

LA-7898 SH7720 200.0 MHz

LA-7898 SH7721 200.0 MHz

LA-7898 SH7722 200.0 MHz

LA-7898 SH7723 200.0 MHz

LA-7898 SH7727 100.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 71

LA-7898 SH7729 100.0 MHz

LA-7898 SH7751 200.0 MHz

LA-7898 SH7751R 200.0 MHz

LA-7898 SH7760 200.0 MHz

LA-7898 SH7761 200.0 MHz

LA-7898 SH7763 200.0 MHz

LA-7898 SH7764 200.0 MHz

LA-7898 SH7770 200.0 MHz

LA-7898 SH7780 200.0 MHz

LA-7898 SH7781 200.0 MHz

LA-7898 SH7785 200.0 MHz

LA-7898 ST40STB1 80.0 MHz

LA-7905 MPC880 80.0 MHz (CPU 120.0 MHz)

LA-7905 MPC885 80.0 MHz (CPU 120.0 MHz)

LA-7921 ERTEC200 200.0 MHz

LA-7921 ERTEC400 200.0 MHz

LA-7921 LPC2104 200.0 MHz

LA-7921 LPC2105 200.0 MHz

LA-7921 LPC2106 200.0 MHz

LA-7921 LPC2109 200.0 MHz

LA-7921 LPC2112 200.0 MHz

LA-7921 LPC2114 200.0 MHz

LA-7921 LPC2119 200.0 MHz

LA-7921 LPC2124 200.0 MHz

LA-7921 LPC2129 200.0 MHz

LA-7921 LPC2131 200.0 MHz

LA-7921 LPC2131/01 200.0 MHz

LA-7921 LPC2132 200.0 MHz

LA-7921 LPC2132/01 200.0 MHz

LA-7921 LPC2134 200.0 MHz

LA-7921 LPC2134/01 200.0 MHz

LA-7921 LPC2136 200.0 MHz

LA-7921 LPC2136/01 200.0 MHz

LA-7921 LPC2138 200.0 MHz

LA-7921 LPC2138/01 200.0 MHz

LA-7921 LPC2141 200.0 MHz

LA-7921 LPC2142 200.0 MHz

LA-7921 LPC2144 200.0 MHz

LA-7921 LPC2146 200.0 MHz

LA-7921 LPC2148 200.0 MHz

LA-7921 LPC2194 200.0 MHz

LA-7921 LPC2210 200.0 MHz

LA-7921 LPC2212 200.0 MHz

LA-7921 LPC2214 200.0 MHz

LA-7921 LPC2220 200.0 MHz

LA-7921 LPC2290 200.0 MHz

LA-7921 LPC2292 200.0 MHz

LA-7921 LPC2294 200.0 MHz

LA-7921 LPC2364 200.0 MHz

LA-7921 LPC2365 200.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 72

LA-7921 LPC2366 200.0 MHz

LA-7921 LPC2367 200.0 MHz

LA-7921 LPC2368 200.0 MHz

LA-7921 LPC2377 200.0 MHz

LA-7921 LPC2378 200.0 MHz

LA-7921 LPC2387 200.0 MHz

LA-7921 LPC2388 200.0 MHz

LA-7921 LPC2458 200.0 MHz

LA-7921 LPC2460 200.0 MHz

LA-7921 LPC2468 200.0 MHz

LA-7921 LPC2470 200.0 MHz

LA-7921 LPC2478 200.0 MHz

LA-7921 PCD80703 96.0 MHz

LA-7921 PCD80705 96.0 MHz

LA-7921 PCD80708 96.0 MHz

LA-7921 PCD80715 96.0 MHz

LA-7921 PCD80716 96.0 MHz

LA-7921 PCD80718 96.0 MHz

LA-7921 PCD80720 96.0 MHz

LA-7921 PCD80721 96.0 MHz

LA-7921 PCD80725 96.0 MHz

LA-7921 PCD80727 96.0 MHz

LA-7921 PCD80728 96.0 MHz

LA-7921 ST30F7XXA 200.0 MHz

LA-7921 ST30F7XXC 200.0 MHz

LA-7921 ST30F7XXZ 200.0 MHz

LA-7921 STR720 200.0 MHz

LA-7921 STR910FAM32 96.0 MHz

LA-7921 STR910FAW32 96.0 MHz

LA-7921 STR910FAZ32 96.0 MHz

LA-7921 STR911FAM42 96.0 MHz

LA-7921 STR911FAM44 96.0 MHz

LA-7921 STR911FAM46 96.0 MHz

LA-7921 STR911FAM47 96.0 MHz

LA-7921 STR911FAW42 96.0 MHz

LA-7921 STR911FAW44 96.0 MHz

LA-7921 STR911FAW46 96.0 MHz

LA-7921 STR911FAW47 96.0 MHz

LA-7921 STR912FAW42 96.0 MHz

LA-7921 STR912FAW44 96.0 MHz

LA-7921 STR912FAW46 96.0 MHz

LA-7921 STR912FAW47 96.0 MHz

LA-7921 STR912FAZ42 96.0 MHz

LA-7921 STR912FAZ44 96.0 MHz

LA-7921 STR912FAZ46 96.0 MHz

LA-7921 STR912FAZ47 96.0 MHz

LA-7928 PXB4260 130.0 MHz

LA-7928 TC1100 180.0 MHz

LA-7928 TC1115 180.0 MHz

LA-7928 TC1130 180.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 73

LA-7928 TC1163 180.0 MHz

LA-7928 TC1164 180.0 MHz

LA-7928 TC1165 180.0 MHz

LA-7928 TC1166 180.0 MHz

LA-7928 TC11IA 180.0 MHz

LA-7928 TC11IB 180.0 MHz

LA-7928 TC11IC 180.0 MHz

LA-7928 TC1765 180.0 MHz

LA-7928 TC1775 180.0 MHz

LA-7928 TC1910 180.0 MHz

LA-7928 TC1920 180.0 MHz

LA-7929 IOP480 66.0 MHz

LA-7929 NPE405H 180.0 MHz

LA-7929 NPE405L 180.0 MHz

LA-7929 PPC401 80.0 MHz

LA-7929 PPC403GA 33.0 MHz

LA-7929 PPC403GB 33.0 MHz

LA-7929 PPC403GC 33.0 MHz

LA-7929 PPC403GCX 50.0 MHz

LA-7929 PPC405 180.0 MHz (CPU 360.0 MHz)

LA-7929 PPC405Axx

LA-7929 PPC405Bxx

LA-7929 PPC405CR 100.0 MHz (CPU 200.0 MHz)

LA-7929 PPC405CR 133.0 MHz (CPU 266.0 MHz)

LA-7929 PPC405Cxx

LA-7929 PPC405Dxx

LA-7929 PPC405EP 100.0 MHz (CPU 200.0 MHz)

LA-7929 PPC405EP 167.0 MHz (CPU 333.0 MHz)

LA-7929 PPC405EX

LA-7929 PPC405Exx

LA-7929 PPC405Fxx

LA-7929 PPC405GP 100.0 MHz (CPU 200.0 MHz)

LA-7929 PPC405GP 133.0 MHz (CPU 266.0 MHz)

LA-7929 PPC405GPR 100.0 MHz (CPU 200.0 MHz)

LA-7929 PPC405GPR 180.0 MHz (CPU 360.0 MHz)

LA-7929 PPC405LP 180.0 MHz (CPU 360.0 MHz)

LA-7929 PPC405PM 180.0 MHz (CPU 360.0 MHz)

LA-7929 PPC440

LA-7929 PPC440Axx

LA-7929 PPC440EP 180.0 MHz (CPU 720.0 MHz)

LA-7929 PPC440EPX

LA-7929 PPC440GP 125.0 MHz (CPU 500.0 MHz)

LA-7929 PPC440GR

LA-7929 PPC440GRX

LA-7929 PPC440GX 180.0 MHz (CPU 720.0 MHz)

LA-7929 PPC440Gxx

LA-7929 PPC440SP 180.0 MHz (CPU 720.0 MHz)

LA-7929 PPC440SPE

LA-7942 VR5500A 67.0 MHz

LA-7942 VR5701 67.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 74

LA-7992 88FR101 175.0 MHz

LA-7992 88FR102 175.0 MHz

LA-7992 88FR111 175.0 MHz

LA-7992 88FR301 175.0 MHz

LA-7992 AM3505 600.0 MHz

LA-7992 AM3517 600.0 MHz

LA-7992 AM3703 600.0 MHz

LA-7992 AM3715 600.0 MHz

LA-7992 ARM1020E 600.0 MHz

LA-7992 ARM1022E 600.0 MHz

LA-7992 ARM1026EJ-S 600.0 MHz

LA-7992 ARM710T 600.0 MHz

LA-7992 ARM720T 600.0 MHz

LA-7992 ARM740T 600.0 MHz

LA-7992 ARM7DI 600.0 MHz

LA-7992 ARM7EJ-S 600.0 MHz

LA-7992 ARM7TDMI 600.0 MHz

LA-7992 ARM7TDMI-S 600.0 MHz

LA-7992 ARM915T 600.0 MHz

LA-7992 ARM920T 600.0 MHz

LA-7992 ARM922T 600.0 MHz

LA-7992 ARM926EJ-S 600.0 MHz

LA-7992 ARM940T 600.0 MHz

LA-7992 ARM946E-S 600.0 MHz

LA-7992 ARM966E-S 600.0 MHz

LA-7992 ARM968E-S 600.0 MHz

LA-7992 ARM9E-S 600.0 MHz

LA-7992 ARM9EJ-S 600.0 MHz

LA-7992 ARM9TDMI 600.0 MHz

LA-7992 AT91RM9200 600.0 MHz

LA-7992 AT91SAM9261 600.0 MHz

LA-7992 AT91SAM9263 600.0 MHz

LA-7992 CORTEX-A15 600.0 MHz

LA-7992 CORTEX-A15MPCORE 600.0 MHz

LA-7992 CORTEX-A5 600.0 MHz

LA-7992 CORTEX-A5MPCORE 600.0 MHz

LA-7992 CORTEX-A7 600.0 MHz

LA-7992 CORTEX-A7MPCORE 600.0 MHz

LA-7992 CORTEX-A8 600.0 MHz

LA-7992 CORTEX-A9 600.0 MHz

LA-7992 CORTEX-A9MPCORE 600.0 MHz

LA-7992 CORTEX-R4 600.0 MHz

LA-7992 CORTEX-R4F 600.0 MHz

LA-7992 CORTEX-R5 600.0 MHz

LA-7992 CORTEX-R5F 600.0 MHz

LA-7992 CORTEX-R5MPCORE 600.0 MHz

LA-7992 CS7522 600.0 MHz

LA-7992 CS7542 600.0 MHz

LA-7992 CYCLONEVSOC 600.0 MHz

LA-7992 DB5500 600.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 75

LA-7992 DB8500 600.0 MHz

LA-7992 DB8540 600.0 MHz

LA-7992 EPXA1 600.0 MHz

LA-7992 EPXA10 600.0 MHz

LA-7992 EPXA4 600.0 MHz

LA-7992 IMX280 600.0 MHz

LA-7992 IMX281 600.0 MHz

LA-7992 IMX283 600.0 MHz

LA-7992 IMX285 600.0 MHz

LA-7992 IMX286 600.0 MHz

LA-7992 IMX287 600.0 MHz

LA-7992 IMX502 600.0 MHz

LA-7992 IMX503 600.0 MHz

LA-7992 IMX507 600.0 MHz

LA-7992 IMX508 600.0 MHz

LA-7992 IMX512 600.0 MHz

LA-7992 IMX513 600.0 MHz

LA-7992 IMX514 600.0 MHz

LA-7992 IMX515 600.0 MHz

LA-7992 IMX516 600.0 MHz

LA-7992 IMX534 600.0 MHz

LA-7992 IMX535 600.0 MHz

LA-7992 IMX536 600.0 MHz

LA-7992 IMX537 600.0 MHz

LA-7992 IMX538 600.0 MHz

LA-7992 IMX6DUAL 600.0 MHz

LA-7992 IMX6QUAD 600.0 MHz

LA-7992 IMX6SOLO 600.0 MHz

LA-7992 KRAIT 600.0 MHz

LA-7992 MC9328MX1 600.0 MHz

LA-7992 MC9328MXL 600.0 MHz

LA-7992 MC9328MXS 600.0 MHz

LA-7992 MCIMX23 600.0 MHz

LA-7992 MCIMX25 600.0 MHz

LA-7992 MCIMX27 600.0 MHz

LA-7992 MCIMX27L 600.0 MHz

LA-7992 MCIMX31 600.0 MHz

LA-7992 MCIMX35 600.0 MHz

LA-7992 MCIMX351 600.0 MHz

LA-7992 MCIMX353 600.0 MHz

LA-7992 MCIMX355 600.0 MHz

LA-7992 MCIMX356 600.0 MHz

LA-7992 MCIMX357 600.0 MHz

LA-7992 MCIMX37 600.0 MHz

LA-7992 MSM6100_3G 600.0 MHz

LA-7992 MSM6250 600.0 MHz

LA-7992 MSM6300 600.0 MHz

LA-7992 MSM6500 600.0 MHz

LA-7992 MXC91231 400.0 MHz

LA-7992 MXC91321 400.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 76

LA-7992 MXC91323 400.0 MHz

LA-7992 MXC91331 400.0 MHz

LA-7992 NETX100 200.0 MHz

LA-7992 NETX50 200.0 MHz

LA-7992 NETX500 200.0 MHz

LA-7992 NETX51 200.0 MHz

LA-7992 OMAP1510 600.0 MHz

LA-7992 OMAP1610 600.0 MHz

LA-7992 OMAP1611 600.0 MHz

LA-7992 OMAP1612 600.0 MHz

LA-7992 OMAP1710 600.0 MHz

LA-7992 OMAP2420 600.0 MHz

LA-7992 OMAP2430 600.0 MHz

LA-7992 OMAP2431 600.0 MHz

LA-7992 OMAP310 600.0 MHz

LA-7992 OMAP331 600.0 MHz

LA-7992 OMAP3410 600.0 MHz

LA-7992 OMAP3420 600.0 MHz

LA-7992 OMAP3430 600.0 MHz

LA-7992 OMAP3440 600.0 MHz

LA-7992 OMAP3503 600.0 MHz

LA-7992 OMAP3515 600.0 MHz

LA-7992 OMAP3525 600.0 MHz

LA-7992 OMAP3530 600.0 MHz

LA-7992 OMAP3610 600.0 MHz

LA-7992 OMAP3620 600.0 MHz

LA-7992 OMAP3630 600.0 MHz

LA-7992 OMAP3640 600.0 MHz

LA-7992 OMAP4430 600.0 MHz

LA-7992 OMAP4460 600.0 MHz

LA-7992 OMAP4470 600.0 MHz

LA-7992 OMAP5430 600.0 MHz

LA-7992 OMAP5432 600.0 MHz

LA-7992 OMAP5910 600.0 MHz

LA-7992 OMAP5912 600.0 MHz

LA-7992 OMAP710 600.0 MHz

LA-7992 OMAP730 600.0 MHz

LA-7992 OMAP732 600.0 MHz

LA-7992 OMAP733 600.0 MHz

LA-7992 OMAP750 600.0 MHz

LA-7992 OMAP850 600.0 MHz

LA-7992 OMAPV1030 600.0 MHz

LA-7992 OMAPV1035 600.0 MHz

LA-7992 OMAPV2230 600.0 MHz

LA-7992 PMB8870 600.0 MHz

LA-7992 PMB8875 600.0 MHz

LA-7992 PMB8876 600.0 MHz

LA-7992 PMB8877 600.0 MHz

LA-7992 PMB8878 600.0 MHz

LA-7992 PMB8888 600.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 77

LA-7992 QSD8250 600.0 MHz

LA-7992 QSD8650 600.0 MHz

LA-7992 RM48L530-ZWT 600.0 MHz

LA-7992 RM48L540-ZWT 600.0 MHz

LA-7992 RM48L550-ZWT 600.0 MHz

LA-7992 RM48L730-ZWT 600.0 MHz

LA-7992 RM48L740-ZWT 600.0 MHz

LA-7992 RM48L750-ZWT 600.0 MHz

LA-7992 RM48L930-ZWT 600.0 MHz

LA-7992 RM48L940-ZWT 600.0 MHz

LA-7992 RM48L950-ZWT 600.0 MHz

LA-7992 RM48L952-ZWT 600.0 MHz

LA-7992 SC200 600.0 MHz

LA-7992 SC210 600.0 MHz

LA-7992 SCORPION 600.0 MHz

LA-7992 SPEAR1300 600.0 MHz

LA-7992 SPEAR1310 600.0 MHz

LA-7992 SPEAR1340 600.0 MHz

LA-7992 STA2064 600.0 MHz

LA-7992 STA2065 600.0 MHz

LA-7992 STA2164 600.0 MHz

LA-7992 STA2165 600.0 MHz

LA-7992 STN8810 600.0 MHz

LA-7992 STN8815 600.0 MHz

LA-7992 STN8820 600.0 MHz

LA-7992 TMS320DM3725 600.0 MHz

LA-7992 TMS320DM3730 600.0 MHz

LA-7992 TMS570LS10106-ZWT 600.0 MHz

LA-7992 TMS570LS10116-ZWT 600.0 MHz

LA-7992 TMS570LS10206-ZWT 600.0 MHz

LA-7992 TMS570LS10216-ZWT 600.0 MHz

LA-7992 TMS570LS1114-ZWT 600.0 MHz

LA-7992 TMS570LS1115-ZWT 600.0 MHz

LA-7992 TMS570LS1224-ZWT 600.0 MHz

LA-7992 TMS570LS1225-ZWT 600.0 MHz

LA-7992 TMS570LS1227-ZWT 600.0 MHz

LA-7992 TMS570LS20206-ZWT 600.0 MHz

LA-7992 TMS570LS20216-ZWT 600.0 MHz

LA-7992 TMS570LS2124-ZWT 600.0 MHz

LA-7992 TMS570LS2125-ZWT 600.0 MHz

LA-7992 TMS570LS2134-ZWT 600.0 MHz

LA-7992 TMS570LS2135-ZWT 600.0 MHz

LA-7992 TMS570LS3134-ZWT 600.0 MHz

LA-7992 TMS570LS3135-ZWT 600.0 MHz

LA-7992 TMS570LS3137-ZWT 600.0 MHz

LA-7992 VF11xR 600.0 MHz

LA-7992 VF12xR 600.0 MHz

LA-7992 VF31xR 600.0 MHz

LA-7992 VF32xR 600.0 MHz

LA-7992 VF3xx 600.0 MHz

Module CPU TRACE

PowerTrace

Operation Voltage and Frequeny

TRACE32 - Technical Information 78

LA-7992 VF4xx 600.0 MHz

LA-7992 VF51xR 600.0 MHz

LA-7992 VF52xR 600.0 MHz

LA-7992 VF5xx 600.0 MHz

LA-7992 VF6xx 600.0 MHz

LA-7992 VF7xx 600.0 MHz

LA-7992 ZYNQ7000 600.0 MHz

LA-7999 MXC91231 (CPU 300.0 MHz)

LA-7999 MXC91321 (CPU 300.0 MHz)

LA-7999 MXC91323 (CPU 300.0 MHz)

LA-7999 MXC91331 (CPU 300.0 MHz)

LA-9662 MPC561 66.0 MHz

LA-9662 MPC562 66.0 MHz

LA-9662 MPC563 66.0 MHz

LA-9662 MPC564 66.0 MHz

Module CPU TRACE

PowerTrace

Order Information

TRACE32 - Technical Information 79

Order Information

Module Description

Detailed Order Information

OrderNo

Code

Text

LA-7690

POWER-

TRACE-ETH-

512M

PowerTrace Ethernet 512 MB

Universal NEXUS/debug controller

USB 2.0 interface included

Order

No.

Code Text

LA-7690 POWER-TRACE-

ETH-512M

PowerTrace Ethernet 512 MB

Additional Options

LA-7710 BDM-68K BDM Debugger for 68K (ICD)

LA-3757 BDM-COLDFIRE-

BDM Debugger for ColdFire HS (ICD)

LA-3746 BDM-COLDFIRE-

BDM Debugger for ColdFire+/V1 (ICD)

LA-7735 BDM-DSP56300 BDM Debugger for DSP56300 (ICD)

LA-7738 BDM-DSP56800 BDM Debugger for DSP56800 and DSP56800E

(ICD)

LA-7712 BDM-HC16 BDM Debugger for 68HC16 (ICD)

LA-7733 BDM-MCS08 BDM Debugger for MCS08 (ICD)

LA-7717 BDM-MCS12 BDM Debugger for MCS12 (ICD)

LA-7736 BDM-MCS12X BDM Debugger for MCS12X (ICD)

LA-3748 BDM-MCS12Z BDM Debugger for MCS12Z (ICD)

LA-7722 BDM-MPC500/

800

BDM Debugger for MPC500/800 (ICD)

LA-4506 COMBIPROBE-

C166V2

CombiProbe C166V2-Debugger and 4-Bit Trace

LA-7750 DEBUG-196EA Debugger for 196EA (ICD)

LA-3777 DEBUG-78K0R/

RL78

Debugger for 78K0R/RL78 (ICD)

LA-3776 DEBUG-ATOM JTAG Debugger for Intel® Atom™ and x86 (ICD)

LA-3779 DEBUG-AVR32 JTAG Debugger for AVR32 (ICD)

LA-7661 DEBUG-M32R JTAG Debugger for M32R SDI-3 (ICD)

PowerTrace

Order Information

TRACE32 - Technical Information 80

LA-7753 DEBUG-

MPC5500

JTAG Debugger Qorivva MPC5xxx/SPC5xxx (ICD)

LA-3736 DEBUG-

MPC5XXX-

AUTO

JTAG Debugger for MPC5xxx Automotive

LA-7729 DEBUG-

MPC8260

JTAG Debugger for MPC82xx/MPC83xx(ICD)

LA-3735 DEBUG-

MPC86XX

JTAG Debugger for MPC86xx (ICD)

LA-7723 DEBUG-PPC400 JTAG Debugger for PPC400 (ICD)

LA-7752 DEBUG-PPC44X JTAG Debugger for PPC44x (ICD)

LA-7721 DEBUG-PPC603 JTAG Debugger for PPC603/MPC74x/75x (ICD)

LA-7719 DEBUG-

PPC74XX

JTAG Debugger for MPC74xx (ICD)

LA-3796 DEBUG-PQ3 JTAG Debugger for MPC85XX/QorIQ e500 (ICD)

LA-3754 DEBUG-

PWRFICIENT

JTAG Debugger for PWRficient (ICD)

LA-3795 DEBUG-

QORIQ32

JTAG Debugger for QorIQ 32 Bit (ICD)

LA-3794 DEBUG-

QORIQ64

JTAG Debugger for QorIQ 64 Bit (ICD)

LA-3737 DEBUG-

TRICORE-

AUTO

JTAG Debugger for TriCore Automotive

LA-7760 EJTAG-MIPS32 JTAG Debugger for MIPS32 (ICD)

LA-7761 EJTAG-MIPS64 JTAG Debugger for MIPS64 (ICD)

LA-3756 JTAG-ANDES JTAG Debugger for AndesCore (ICD)

LA-3785 JTAG-APS-20 JTAG Debugger for APS 20 (ICD)

LA-3778 JTAG-APS-60 JTAG Debugger for APS 60 (ICD)

LA-3750 JTAG-ARC JTAG Debugger for ARC (ICD)

LA-7744 JTAG-ARM10 JTAG Debugger for ARM10 (ICD)

LA-7765 JTAG-ARM11 JTAG Debugger for ARM11 (ICD)

LA-7746 JTAG-ARM7-20 JTAG Debugger for ARM7 20 Pin Connector (ICD)

LA-7742 JTAG-ARM9 JTAG Debugger for ARM9 (ICD)

LA-3793 JTAG-BEYOND JTAG Debugger for Beyond

LA-7833 JTAG-BLACKFIN JTAG Debugger for BLACKFIN (ICD)

LA-7831 JTAG-C54X JTAG Debugger for TMS320C54X (ICD)

LA-7830 JTAG-C55X JTAG Debugger for TMS320C55X (ICD)

LA-7838 JTAG-C6X00 JTAG Debugger for TMS320C6x00 (ICD)

LA-3711 JTAG-CEVAX JTAG Debugger for CEVA-X (ICD)

LA-7843 JTAG-CORTEX-

A/R

JTAG Debugger for Cortex-A/-R (ARMv7) (ICD)

LA-7844 JTAG-

CORTEX_M

JTAG Debugger for Cortex-M (ICD)

LA-7766 JTAG-H8S JTAG Debugger for H8S (ICD)

LA-3745 JTAG-H8SX JTAG Debugger for H8SX (ICD)

LA-7739 JTAG-JANUS JTAG Debugger for JANUS (ICD)

LA-7848 JTAG-M8051EW-

JTAG Debugger for M8051EW 14 Pins (ICD)

LA-3730 JTAG-

MICROBLAZE

Debugger for MicroBlaze (ICD)

LA-7836 JTAG-MMDSP JTAG Debugger for MMDSP (ICD)

LA-7734 JTAG-MPC5200 JTAG Debugger for MPC5200/MPC512x (ICD)

Order

No.

Code Text

PowerTrace

Order Information

TRACE32 - Technical Information 81

LA-3713 JTAG-MSP430 JTAG Debugger for MSP430 (ICD)

LA-7837 JTAG-NIOS-II Debugger for NIOS-II (ICD)

LA-7789 JTAG-OAK-SEIB JTAG Debugger for OAK/TeakLite SEIB (ICD)

LA-7850 JTAG-R8051XC JTAG Debugger for R8051XC

LA-3719 JTAG-RH850 JTAG Debugger for RH850 (ICD)

LA-3786 JTAG-RX Debugger for RX Family

LA-7758 JTAG-SH4-14 Debugger for SH2/SH3/SH4 H-UDI-14 Pin (ICD)

LA-3710 JTAG-ST40 JTAG Debugger for ST40 (ICD)

LA-7834 JTAG-

STARCORE-14

JTAG Debugger for StarCore 14 Pin (ICD)

LA-7845 JTAG-

STARCORE-20

JTAG Debugger for StarCore 20 Pin (ICD)

LA-7763 JTAG-SUPER10 JTAG Debugger for Super10 (ICD)

LA-7774 JTAG-TEAK-JAM-

JTAG Debugger for Teak/TeakLite JAM 20 (ICD)

LA-3774 JTAG-TEAKLITE-

III

JTAG Debugger for TeakLite III (ICD)

LA-7847 JTAG-

TMS320C28X

JTAG Debugger for TMS320C28X (ICD)

LA-7835 JTAG-V850 N-Wire Debugger for V850 (ICD)

LA-7842 JTAG-VR N-Wire Debugger for NEC VR-Series (ICD)

LA-7762 JTAG-XSCALE JTAG Debugger for XSCALE (ICD)

LA-3760 JTAG-XTENSA JTAG Debugger for Xtensa 14 Pin

LA-7832 JTAG-ZSP400 JTAG Debugger for ZSP400 DSP Core

LA-3712 JTAG-ZSP500 JTAG Debugger for ZSP500 DSP Core (ICD)

LA-7645 NEXUS-AVR32-

NEXUS Debugger/Trace for AVR32 AutoFocus

LA-7620 NEXUS-

MAC71XX

NEXUS Debugger and Trace for MAC71xx/

MAC72xx

LA-7651 NEXUS-MCORE Nexus Adapter for M*Core Device Flex Cable

LA-7630 NEXUS-

MPC5500-AF

NEXUS Debug/Trace for Qorivva MPC5xxx/

SPC5xxx

LA-7791 NEXUS-MPC565-

MICTOR

Nexus Adapter for MPC56x family/Mictor38

LA-7600 NEXUS-

SUPER10-3.3V

Nexus Adapter for Super10 3.3V

LA-7755 OCDS-C166CBC OCDS Debugger for C166CBC (ICD)

LA-7759 OCDS-C166S-V2 OCDS Debugger for XC2000/C166S V2 (ICD)

LA-7756 OCDS-TRICORE OCDS Debugger for TriCore (ICD)

LA-3732 OCDS-XC800 OCDS Debugger for XC800 (ICD)

LA-7745 ONCE-MCORE ONCE Debugger for M-CORE (ICD)

LA-7991 PP-ARM-ETM-AF Preprocessor for ARM-ETM with AUTOFOCUS

Flex

LA-7992 PP-ARM-ETM-

AF-2

Preproc. for ARM-ETM/AUTOFOCUS II 600 Flex

LA-7921 PP-ARM-ETM/

200

Preprocessor for ARM-ETM 200 flex cable

LA-3908 PP-BEYOND-AF-

Preproc. for Beyond AUTOFOCUS II Flex

LA-7880 PP-C166-FAMILY Preprocessor for C166 family

LA-3903 PP-C64XP-AF-2 Preproc. for TMS320C64x+ AUTOFOCUS II Flex

LA-7996 PP-CEVA-AF-2 Preproc. for Ceva-X AUTOFOCUS II Flex

Order

No.

Code Text

PowerTrace

Order Information

TRACE32 - Technical Information 82

LA-3759 PP-COLDFIRE-

Preprocessor for ColdFire family HS

LA-7881 PP-EGOLD Preprocessor for EGOLD family

LA-7893 PP-EGOLD+ Preprocessor for EGOLD+ family

LA-7857 PP-EGOLD+V3 Preprocessor for complete EGOLD family

LA-3901 PP-

MICROBLAZE-

AF-2

Preproc. for MICROBLAZE AUTOFOCUS II Flex

LA-3906 PP-MIPS32-AF-2 Preproc. for MIPS32 AUTOFOCUS 600 MIPI

LA-7883 PP-MPC500/800-

Preprocessor for MPC500/800 Family Data

LA-7856 PP-MPC500/800-

Preprocessor for MPC500/800 Family Data V2

LA-7886 PP-MPC555-TC Preprocessor for MPC555 TCON

LA-9662 PP-MPC561-TC Preprocessor for MPC561/MPC563 TCON320

LA-3911 PP-MPC57XX-

HSTP

Preproc. Qorivva MPC57xx/SPC57XX HSTP HF-

Flex

LA-7885 PP-MPC850-TC Preprocessor for MPC850 and MPC823-TCON

LA-7884 PP-MPC860-TC Preprocessor for MPC860 and MPC821 TCON

LA-7905 PP-MPC880-TC Preprocessor for MPC880 and MPC885 TCON

LA-3801 PP-NIOSII Preprocessor for NIOS-II Flex Cable

LA-3910 PP-PPC-

PPC4XX-HSTP

Preproc. PPC4xx HSTP HF-Flex

LA-7987 PP-PPC-QORIQ-

HSTP

Preproc. QorIQ HSTP HF-Flex

LA-3900 PP-PPC4XX-AF-

Preproc. for PPC4XX AUTOFOCUS II Flex

LA-7929 PP-PPC4XX-F Preprocessor for PPC4xx family fast flex

LA-7898 PP-SH3/4 Preprocessor for SH4 and RX (AUD)

LA-3902 PP-SHX-AF-2 Preproc. for SHx (AUD) AUTOFOCUS II FLEX

LA-3800 PP-ST40 Preprocessor for ST40 (AUD)

LA-7999 PP-STARCORE-

AF-2

Preproc. for STARCORE AUTOFOCUS II Flex

LA-3904 PP-TEAKLITE3-

AF-2

Preproc. for TEAKLITE-III AUTOFOCUS II Flex

LA-7935 PP-TRACE-V850 Preprocessor for V850-Flex Cable

LA-7942 PP-TRACE-VR Preprocessor for VR-Flex

LA-7928 PP-TRICORE-

3.3V

Preprocessor TriCore OCDS-L2 3.3V Samtec 60

LA-3912 PP-TRICORE-

AGBT

Preproc. TriCore AGBT HF-Flex

LA-7971X TRACE-

LICENSE-

MIPS32

Trace License for the MIPS32

LA-7660 TRACE-M32R Debug/Trace Adapter for M32R SDI-3

Order

No.

Code Text

PowerTrace

Contact

TRACE32 - Technical Information 83

Contact

International Representative

Argentina

Anacom Eletronica Ltda.

Mr. Rafael Sorice

Rua Nazareth, 807, Barcelona

BR-09551-200 São Caetano do Sul, SP

Phone: +55 11 3422 4200

FAX: +55 11 3422 4242

EMAIL: rsorice@anacom.com.br

Australia

Embedded Logic Solutions P/L

Mr. Ramzi Kattan

Suite 2, Level 3

144 Marsden Street

Parramatta NSW 2150

Phone: +61 2 9687 1880

FAX: +61 2 9687 1881

EMAIL: sales@emlogic.com.au

Austria

Lauterbach GmbH

Altlaufstr. 40

D-85635 Höhenkirchen-Siegertsbrunn

Phone: +49 8102 9876 0

FAX: +49 8102 9876 999

EMAIL: info@lauterbach.com

Belgium

Tritec Benelux B.V.

Mr. Robbert de Voogt

Stationspark 550

NL-3364 DA Sliedrecht

Phone: +31 184 41 41 31

FAX: +31 184 42 36 11

EMAIL: software@tritec.nl

Brazil

Anacom Eletronica Ltda.

Mr. Rafael Sorice

Rua Nazareth, 807, Barcelona

BR-09551-200 São Caetano do Sul, SP

Phone: +55 11 3422 4200

FAX: +55 11 3422 4242

EMAIL: rsorice@anacom.com.br

Canada

Lauterbach Inc.

Mr. Udo Zoettler

4 Mount Royal Ave.

USA-Marlborough, MA 01752

Phone: +1 508 303 6812

FAX: +1 508 303 6813

EMAIL: info_us@lauterbach.com

China Beijing

Lauterbach Technologies Co., Ltd

Mr. Linglin He

Beijing Office

A3,South Lishi Road, XiCheng District

Beijing 100037, P.R. China

Phone: +86 10 68023502

FAX: +86 10 68023523

EMAIL: linglin.he@lauterbach.com

China Shenzhen

Lauterbach Technologies Co., Ltd

1406/E Xihaimingzhu Building

No.1 Taoyuan Road, Nanshan District

Shenzhen 518052, P.R. China

Phone: +86 755 8621 0671

FAX: +86 755 8621 0675

EMAIL: emily.zhang@lauterbach.com

China Suzhou

Lauterbach Technologies Co., Ltd

Mr. Tom Meyer

Hengyu Square, Rm 709

No. 188, Xing Hai Street

Suzhou, 215021 P.R. of China

Phone: +86 512 6265 8030

FAX: +86 512 6265 8032

EMAIL: info_cn@lauterbach.com

Denmark

Nohau Danmark A/S

Mr. Flemming Jensen

Klausdalsbrovej 493

DK-2730 Herlev

Phone: +45 44 52 16 50

FAX: +45 44 52 26 55

EMAIL: info@nohau.dk

Egypt

Wantech Egypt

Mr. Wagih A. Nawara

5 Shafik Ghalie St., Suite 2

Off Pyramids Road, Giza

Cairo 12111

Phone: +20 100 1251955

FAX: +20 100 1250349

EMAIL: sales@wantechnet.com

Finland

Nohau Solutions Finland

Mr. Leevi Lehtinen

Teknobulevardi 3-5

FI-01531 Vantaa

Phone: +358 40 546 1469

FAX: +358 9 2517 8101

EMAIL: sales@nohau.fi

France

Lauterbach S.A.R.L.

Mr. Jean-Pierre Paradiso

Europarc - Le Hameau B

135 Chemin Des Bassins

F-94035 Créteil Cedex

Phone: +33 1 49 56 20 30

FAX: +33 1 49 56 20 39

EMAIL: info_fr@lauterbach.com

Germany

Lauterbach GmbH

Altlaufstr. 40

D-85635 Höhenkirchen-Siegertsbrunn

Phone: +49 8102 9876 0

FAX: +49 8102 9876 999

EMAIL: info@lauterbach.com

Germany North

Lauterbach GmbH

Mr. Klaus Hommann

Leonhardring 5

D-31319 Sehnde

Phone: +49 5138 6185 0

FAX: +49 5138 6185 3

EMAIL: klaus.hommann@lauterbach.com

Germany South

Lauterbach GmbH

Altlaufstr. 40

D-85635 Höhenkirchen-Siegertsbrunn

Phone: +49 8102 9876 129

FAX: +49 8102 9876 187

EMAIL: sales@lauterbach.com

Greek

Lauterbach GmbH

Altlaufstr. 40

D-85635 Höhenkirchen-Siegertsbrunn

Phone: +49 8102 9876 0

FAX: +49 8102 9876 999

EMAIL: info@lauterbach.com

PowerTrace

Contact

TRACE32 - Technical Information 84

India-Bangalore

Electro Systems Associates Pvt. Ltd.

Mr. G. V. Gurunatham

S-606, World Trade Center

Malleswaram West, No.26/1, Dr. Rajkumar

Road

India - Bangalore 560055

Phone: +91 80 67648888

FAX: +91 80 23475615

EMAIL: Trace32sales@esaindia.com

India-Chennai

Electro Systems Associates Pvt. Ltd.

Mr. D. Kannan

No.109 /59A , Ground Floor

IV Avenue, Ashok Nagar

India - Chennai - 600 083 Tamilnadu

Phone: +91 044-24715750

FAX: ++91 44 24715750

EMAIL: chennai@esaindia.com

India-Delhi

Electro Systems Associates Pvt. Ltd.

Mr. R.K. Bhandari

No. 705, 7th Floor, Laxmi Deep

Shivajinagar

India - Delhi - 110 092

Phone: +91 11-22549351

FAX:

EMAIL: delhi@esaindia.com

India-Hyderabad

Electro Systems Associates Pvt. Ltd.

Mr. C.V.M. Sri Ram Murthy

Shop No. 14, "Global Enclave"

Bhagyanagar Colony, Kukat pally

India - Hyderabad 500 072

Phone: +91 40-23063346

FAX: +91 40-23063346

EMAIL: hyderabad@esaindia.com

India-Pune

Electro Systems Associates Pvt. Ltd.

Mr. R K Bhandari

Shriram Complex,1126/1, Model Colony

Shivajinagar

India - Pune - 411 016

Phone: +91 20 - 30462035 / 25663

FAX: +91 20-25677202

EMAIL: pune@esaindia.com

Ireland

Lauterbach Ltd.

Mr. Barry Lock

11 Basepoint Enterprise Centre

Stroudley Road

Basingstoke, Hants RG24 8UP

Phone: +44-1256-333-690

FAX: +44-1256-336-661

EMAIL: info_uk@lauterbach.com

Israel

Itec Ltd.

Mr. Mauri Gottlieb

P.O.Box 10002

IL-Tel Aviv 61100

Phone: +972 3 6491202

FAX: +972 3 6497661

EMAIL: general@itec.co.il

Italy

Lauterbach Srl

Mr. Maurizio Menegotto

Via Enzo Ferrieri 12

I-20153 Milano

Phone: +39 02 45490282

FAX: +39 02 45490428

EMAIL: info_it@lauterbach.com

Japan

Lauterbach Japan, Ltd.

Mr. Kenji Furukawa

3-8-8 Shinyokohama

Kouhoku-ku

Yokohama-shi, Japan 222-0033

Phone: +81 45 477 4511

FAX: +81 45 477 4519

EMAIL: info@lauterbach.co.jp

Luxemburg

Tritec Benelux B.V.

Mr. Robbert de Voogt

Stationspark 550

NL-3364 DA Sliedrecht

Phone: +31 184 41 41 31

FAX: +31 184 42 36 11

EMAIL: software@tritec.nl

Malaysia

Flash Technology

Mr. Teo Kian Hock

No 61, # 04-15 Kaki Bukit Av 1

Shun Li Industrial Park

SGP-Singapore 417943

Phone: +65 6749 6168

FAX: +65 6749 6138

EMAIL: teokh@flashtech.com.sg

Mexico

Lauterbach Inc.

Mr. Udo Zoettler

4 Mount Royal Ave.

USA-Marlborough, MA 01752

Phone: +1 508 303 6812

FAX: +1 508 303 6813

EMAIL: info_us@lauterbach.com

Netherlands

Tritec Benelux B.V.

Mr. Robbert de Voogt

Stationspark 550

NL-3364 DA Sliedrecht

Phone: +31 184 41 41 31

FAX: +31 184 42 36 11

EMAIL: software@tritec.nl

New Zealand

Embedded Logic Solutions P/L

Mr. Ramzi Kattan

Suite 2, Level 3

144 Marsden Street

Parramatta NSW 2150

Phone: +61 2 9687 1880

FAX: +61 2 9687 1881

EMAIL: sales@emlogic.com.au

Norway

Nohau Solutions AB

Mr. Jörgen Nilsson

Derbyvägen 4

SE-21235 Malmoe

Phone: +46 40 592 206

FAX: +46-40 592 229

EMAIL: sales@nohau.se

Poland

QUANTUM Sp. z o.o.

Mr. Czeslaw Bil

ul. Wystawowa 1

51-618 Wroclaw

Phone: +48 71 362 6356

FAX: +48 71 362 6357

EMAIL: info@quantum.com.pl

Portugal

Captura Electronica,SCCL

Mr. Juan Martinez

c/Duero, 40

E-08031 Barcelona

Phone: +34 93 429 5730

FAX: +34 93 407 0778

EMAIL: info@captura-el.com

Romania

Lauterbach GmbH

Altlaufstr. 40

D-85635 Höhenkirchen-Siegertsbrunn

Phone: +49 8102 9876 0

FAX: +49 8102 9876 999

EMAIL: info@lauterbach.com

Russia

RTSoft

Mr. Alexey Isaev

Nikitinskaya 3

RUS-105037 Moscow

Phone: +7 495 742 6828

FAX: +7 495 742 6829

EMAIL: sales@rtsoft.msk.ru

PowerTrace

Contact

TRACE32 - Technical Information 85

Singapore

Flash Technology

Mr. Teo Kian Hock

No 61, # 04-15 Kaki Bukit Av 1

Shun Li Industrial Park

SGP-Singapore 417943

Phone: +65 6749 6168

FAX: +65 6749 6138

EMAIL: teokh@flashtech.com.sg

South Korea, Pangyo

MDS Technology Co.,Ltd.

Mr. Sangheon Lee

3FL. Hancom Tower

49, Daewangpangyo-ro 644, Bundang-gu

Seongnam-si, Gyeonggi-do, 463-400, ROK

Phone: +82-31-627-3000

FAX: +82-31-627-3100

EMAIL: trace32@mdstec.com

Spain

Captura Electronica,SCCL

Mr. Juan Martinez

c/Duero, 40

E-08031 Barcelona

Phone: +34 93 429 5730

FAX: +34 93 407 0778

EMAIL: info@captura-el.com

Sweden

Nohau Solutions AB

Mr. Jörgen Nilsson

Derbyvägen 4

SE-21235 Malmoe

Phone: +46 40 592 206

FAX: +46 40 592 229

EMAIL: sales@nohau.se

Switzerland

JDT Jberg DatenTechnik

Mr. Andreas Jberg

Zimmereistrasse 2

CH-5734 Reinach AG

Phone: +41 62 7710 886

FAX:

EMAIL: Andreas.Jberg@jdt.ch

Taiwan

Superlink Technology Corp.

Mr. Sulin Huang

3F-8,No.77,Shin-Tai-Wu Rd.Sec1

Taipei Hsien 221, Taiwan, R.O.C.

Phone: +886 2 26983456

FAX: +886 2 26983535

EMAIL: info.stc@superlink.com.tw

Tunesia

Lauterbach Consulting S.A.R.L.

Mr. Khaled Jmal

Phone:

FAX:

EMAIL: info_tn@lauterbach.com

Turkey-1

Tektronik Muh. ve Tic. Ltd.

Mr. Hakan Yavuz

Mahatma Gandhi Cad 68A/2

G.O.Pasa

06700 Ankara

Phone: +90 312 437 3000

FAX: +90 312 437 1616

EMAIL: info@tektronik.com.tr

Turkey-2

G3TEK Embedded Technologies Ltd.

Mr. Celal Aygun

Ilkyerlesim Mah. 445.

Sok. No: 48

06370 Batikent/Ankara

Phone: +90 312 3324769

FAX: +90 312 3324769

EMAIL: info@g3tek.com

Lauterbach Ltd.

Mr. Barry Lock

11 Basepoint Enterprise Centre

Stroudley Rd

Basingstoke, Hants RG24 8UP

Phone: +44 1256 333 690

FAX: +44 1256 336 661

EMAIL: info_uk@lauterbach.com

USA East

Lauterbach Inc.

Mr. Udo Zoettler

4 Mount Royal Ave.

USA-Marlborough, MA 01752

Phone: +1 508 303 6812

FAX: +1 508 303 6813

EMAIL: info_us@lauterbach.com

USA West

Lauterbach Inc.

Mr. Jerry Flake

1111 Main Street, Suite 610

USA-Vancouver, WA. 98660

Phone: +1 503 524 2222

FAX: +1 503 524 2223

EMAIL: jerry.flake@lauterbach.com

PowerTrace

Contact

TRACE32 - Technical Information 86

Additional Information

Lauterbach GmbH

Altlaufstr. 40

D-85649 Hofolding

Tel. ++49 8102 9876-0 FAX -999

info@lauterbach.com

http://www.lauterbach.de

Lauterbach Inc.

4 Mount Royal Ave.

Marlboro MA 01752

Phone (508) 303 6812 FAX (508) 303 6813

info_us@lauterbach.com

http://www.us.lauterbach.com

Lauterbach Ltd.

11 Basepoint Enterprise Ctre Stroudley Road

Basingstoke, Hants RG24 8UP

Phone ++44-1256-333-690 FAX -661

info_uk@lauterbach.com

http:/www.lauterbach.co.uk

Lauterbach S.A.R.L.

135 Chemin Des Bassins

F-94035 Créteil Cedex

Phone ++33-149-562-030

FAX ++33-149-562-039

info_fr@lauterbach.com

http:/www.lauterbach.fr

Lauterbach Japan, Ltd.

3-9-5 Shinyokohama Kouhoku-ku

Yokohama-shi Japan 222-0033

Phone ++81-45-477-4511 FAX -4519

info_j@lauterbach.com

http://www.lauterbach.co.jp

Lauterbach s.r.l.

Via Enzo Ferrieri 12

I-20153 Milano

Phone ++39 02 45490282

FAX ++39 02 45490428

info_it@lauterbach.it

http://www.lauterbach.it

Suzhou Lauterbach Consulting

Co.,Ltd.

Room 1605, Xing Hai International Square

No.200, Xing Hai Street

Suzhou, 215021 PR of China

Phone: 0086-512 6265 8030

FAX: 0086-512 6265 8032

info_cn@lauterbach.cn

http://www.lauterbach.cn

Disclaimer

http://www.lauterbach.com

The information presented is intended to give overview information only.

Changes and technical enhancements or modifications can be made with-

out notice.

PowerTrace Xs1200

Navigation menu

Versions of this User Manual:

Views

Navigation
