SuperLoader™ 3A
With LTO-3 A-Series Drive
FEATURES AND BENEFITS
Made for Professional Video – Designed
specifically for storing and sharing rich
media assets
Complete “Pro Video” feature set
including:
• File system on each 400GB cartridge:
Makes media application-independent,
transportable, exchangeable
• Network-attached media and drive
sharing: Available to any workstation
on the network over Gigabit Ethernet
• MXF-aware technology: Restores sub-
clips by timecode to save time and
increase productivity
Content on LTO Ultrium 3 cartridges can
be shared between different applications
and devices making it an ideal exchange
medium.
When combined with available asset
management applications, creates a
complete backup, archive and restore
solution for video professionals
Provides Quantum’s proven reliability
and expert support for the highest
security and reliability for video archiving
AUTOMATION
UP TO 6.4TB CAPACITY
UP TO 68MB/s TRANSFER RATE
2U RACKMOUNTABLE FORM FACTOR
www.quantum.com
The SuperLoader 3A incorporates Quantum’s revolutionary
technology developed specifically as a storage solution for
professional video environments with file-based workflows.
By leveraging standard video industry formats and proven
IT industry standard tapes and drives, Quantum is expanding
its line of digital storage solutions. The Quantum
SuperLoader 3A accommodates 1 or 2 magazines, each
holding 8 data cartridges for a total of 16 cartridges, all
housed within a two rack-unit enclosure. Individual tape
cartridges can be loaded or removed from the convenient
front “mail” slot, or complete magazines can be removed
for loading, unloading or shelf-storage in convenient
3.2TB modules.
The SuperLoader 3A includes a gigabit Ethernet interface
and a built-in FTP server, so it can be network attached
and visible to every workstation. The SuperLoader 3A
storage system is also “MXF-aware” which enables direct
access to metadata and allows subclip access to content
by timecode. Each tape has its own file system and
directory and can be freely moved between SuperLoaders,
stand-alone drives and even video facilities. With this
standard file system and MXF-aware file support, this
ProVideo technology delivers a new level of transparent
cross-platform and cross-application storage solution.
SuperLoader 3A
For contact and product information,
visit quantum.com or call 800-677-6268
Backup. Recovery. Archive. It’s What We Do.
©2007 Quantum Corporation. All rights reserved. Quantum, the Quantum logo, and all other
logos are registered trademarks of Quantum Corporation or of their respective owners. DS00356 July 2007
About Quantum
Quantum Corp. (NYSE:QTM) is the leading global storage company
specializing in backup, recovery and archive. Combining focused
expertise, customer-driven innovation, and platform independence,
Quantum provides a comprehensive range of disk, tape, media and
software solutions supported by a world-class sales and service
organization. As a long-standing and trusted partner, the company
works closely with a broad network of resellers, OEMs and other
suppliers to meet customers' evolving data protection needs.
PERFORMANCE
Sustained Transfer Rate
Native: 68MB/sec
Formatted Capacity
Native: 400GB
Interfaces: Gigabit Ethernet
IP SERVICES
FTP server – with MXF service extensions
FTP Java client with partial restore support
HTTP Server – Cross platform configuration, status, and FTP client SNMP monitoring
(DLTSage™)
MXF SERVICES
Metadata
- File directory & basic MXF metadata available within <18 seconds of cartridge load
- Display basic metadata in FTP client and Windows Explorer™ properties
- Retrieve full MXF header
Partial restore of essence:(Generates new MXF file)
Supported Essence Types: Mpeg 2 "I" Frame, Mpeg 4 proxy, D10
(IMX 30-40-50 Mb/s), DvCam DVCPro 25/50,
DVC Pro HD, 720P/50 and 720P/60
Operational Patterns: OP1A, OP-Atom
Descriptive Metadata Scheme: 1 DMS1
RELIABILITY
MCBF: 400,000
Cartridge Capacity: 8 or 16 cartridges
COMPATIBILITY
Operating Systems: Windows Desktops, Windows Server,
UNIX, Linux, Mac OSX
Software/Hardware: Go to www.quantum.com for the most up to
date tested solutions
MANAGEMENT REQUIREMENTS
Integrated Web-based Management standard on all SuperLoader 3A products
Power Requirements: 90 to 256 VAC
On-board Remote
Management Tools: 10/100baseT Ethernet
Available Operations: Review System Status, Remote Diagnostics, Browse
System Logs, Configuration, Firmware Upgrades, Drive
Operations, Remote Management, Check Inventory,
System Upgrades
OPERATIONS
Cartridge Loader: Single front loader slot (mail slot) and bulk cartridge
loading in removeable active magazines.
Barcode Reader: Standard
ENVIRONMENTAL LIMITS
Temperature Range (Dry Bulb):
Operating: +10ºC to +35ºC
Non-Operating: - 40ºC to +65ºC
Temperature Variation
Operating: 10ºC per hour
Non-Operating: 20ºC per hour
Humidity
Operating: 20% to 80% non-condensing
Non-Operating: 10% to 90% non-condensing
Gradient: 10% per hour without condensation
Temperature Range (Wet Bulb):
Operating: 26ºC max
Non-Operating: 29ºC max
Altitude
Operating: -500 to 10,000 feet (-153 m to 3048 m)
Non-Operating: -500 to 40,000 feet (-153 m to 12192 m)
AGENCY APPROVALS
Safety: U.S. (UL 1950) Canada (CSA 22.2 No. 950) Europe
(EN60950/IEC 950) EMI/RFI ECC Directive 89336 CD
BS6527 (UK) EN 55022 (EU) EN 55024 (EU) CFR 47,
1995 FCC Rules Part 15 Class A (MDOC) IEC-003
Canada V-3/97.04 VCCI Class A (Japan) AS/NZS 3548
Australia/New Zealand (C-tick Mark) CNS 13438 BSMI
Class A Taiwan
Agency Markings: CD, VCCI, UL, FCC, CSA
TAPE SPECIFICATIONS
Cartridge Dimensions: 4.1” x 4.1” x 1.0”
Archive Storage: 30 years
Durability: 5000 load/unload cycles
Recording Format: LTO Ultrium 3
TECHNICAL SPECIFICATIONS
PHYSICAL SPECIFICATIONS
Width (in/cm) 16.7 inches (8.66cm)
Height (in/cm) 3.41 inches (42.42cm)
Length (in/cm) 27.5 inches (69.85cm)
Weight (lbs/kg) 31 lbs for typical configuration (14.06cm)
Model Numbers and Descriptions
EC-L2DAG-YF SuperLoader 3A with LTO-3 drives, 2 Magazines, with Barcode Reader, ERS Compliant
