Busy Developers' Guide to HSSF

Features

by Glen Stampoultzis, Yegor Kozlov

1. Busy Developers' Guide to Features

Want to use HSSF read and write spreadsheets in a hurry? This guide is for you. If you're

after more in-depth coverage of the HSSF user-API please consult the HOWTO guide as it

contains actual descriptions of how to use this stuff.

1.1. Index of Features

•How to create a new workbook

•How to create a sheet

•How to create cells

•How to create date cells

•Working with different types of cells

•Iterate over rows and cells

•Text Extraction

•Aligning cells

•Working with borders

•Fills and color

•Merging cells

•Working with fonts

•Custom colors

•Reading and writing

•Use newlines in cells.

•Create user defined data formats

•Fit Sheet to One Page

•Set print area for a sheet

•Set page numbers on the footer of a sheet

•Shift rows

•Set a sheet as selected

•Set the zoom magnification for a sheet

•Create split and freeze panes

•Repeating rows and columns

•Headers and Footers

•Drawing Shapes

•Styling Shapes

•Shapes and Graphics2d

•Outlining

•Images

•Named Ranges and Named Cells

•How to set cell comments

•How to adjust column width to fit the contents

•Hyperlinks

1.2. Features

1.2.1. New Workbook

HSSFWorkbook wb = new HSSFWorkbook();

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.2. New Sheet

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet1 = wb.createSheet("new sheet");

HSSFSheet sheet2 = wb.createSheet("second sheet");

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.3. Creating Cells

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

// Create a row and put some cells in it. Rows are 0 based.

HSSFRow row = sheet.createRow((short)0);

// Create a cell and put a value in it.

HSSFCell cell = row.createCell((short)0);

cell.setCellValue(1);

// Or do it on one line.

row.createCell((short)1).setCellValue(1.2);

Busy Developers' Guide to HSSF Features

Page 2

row.createCell((short)2).setCellValue("This is a string");

row.createCell((short)3).setCellValue(true);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.4. Creating Date Cells

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

// Create a row and put some cells in it. Rows are 0 based.

HSSFRow row = sheet.createRow((short)0);

// Create a cell and put a date value in it. The first cell is not styled

// as a date.

HSSFCell cell = row.createCell((short)0);

cell.setCellValue(new Date());

// we style the second cell as a date (and time). It is important to

// create a new cell style from the workbook otherwise you can end up

// modifying the built in style and effecting not only this cell but other cells.

HSSFCellStyle cellStyle = wb.createCellStyle();

cellStyle.setDataFormat(HSSFDataFormat.getBuiltinFormat("m/d/yy h:mm"));

cell = row.createCell((short)1);

cell.setCellValue(new Date());

cell.setCellStyle(cellStyle);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.5. Working with different types of cells

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

HSSFRow row = sheet.createRow((short)2);

row.createCell((short) 0).setCellValue(1.1);

row.createCell((short) 1).setCellValue(new Date());

row.createCell((short) 2).setCellValue("a string");

row.createCell((short) 3).setCellValue(true);

row.createCell((short) 4).setCellType(HSSFCell.CELL_TYPE_ERROR);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

Busy Developers' Guide to HSSF Features

1.2.6. Demonstrates various alignment options

public static void main(String[] args)

throws IOException

{HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

HSSFRow row = sheet.createRow((short) 2);

createCell(wb, row, (short) 0, HSSFCellStyle.ALIGN_CENTER);

createCell(wb, row, (short) 1, HSSFCellStyle.ALIGN_CENTER_SELECTION);

createCell(wb, row, (short) 2, HSSFCellStyle.ALIGN_FILL);

createCell(wb, row, (short) 3, HSSFCellStyle.ALIGN_GENERAL);

createCell(wb, row, (short) 4, HSSFCellStyle.ALIGN_JUSTIFY);

createCell(wb, row, (short) 5, HSSFCellStyle.ALIGN_LEFT);

createCell(wb, row, (short) 6, HSSFCellStyle.ALIGN_RIGHT);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

}

/**

* Creates a cell and aligns it a certain way.

* @param wb the workbook

* @param row the row to create the cell in

* @param column the column number to create the cell in

* @param align the alignment for the cell.

private static void createCell(HSSFWorkbook wb, HSSFRow row, short column, short align)

{HSSFCell cell = row.createCell(column);

cell.setCellValue("Align It");

HSSFCellStyle cellStyle = wb.createCellStyle();

cellStyle.setAlignment(align);

cell.setCellStyle(cellStyle);

}

1.2.7. Working with borders

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

// Create a row and put some cells in it. Rows are 0 based.

HSSFRow row = sheet.createRow((short) 1);

// Create a cell and put a value in it.

Busy Developers' Guide to HSSF Features

Page 4

HSSFCell cell = row.createCell((short) 1);

cell.setCellValue(4);

// Style the cell with borders all around.

HSSFCellStyle style = wb.createCellStyle();

style.setBorderBottom(HSSFCellStyle.BORDER_THIN);

style.setBottomBorderColor(HSSFColor.BLACK.index);

style.setBorderLeft(HSSFCellStyle.BORDER_THIN);

style.setLeftBorderColor(HSSFColor.GREEN.index);

style.setBorderRight(HSSFCellStyle.BORDER_THIN);

style.setRightBorderColor(HSSFColor.BLUE.index);

style.setBorderTop(HSSFCellStyle.BORDER_MEDIUM_DASHED);

style.setTopBorderColor(HSSFColor.BLACK.index);

cell.setCellStyle(style);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.8. Iterate over rows and cells

Sometimes, you'd like to just iterate over all the rows in a sheet, or all the cells in a row. This

is possible with a simple for loop.

Luckily, this is very easy. HSSFRow defines a CellIterator inner class to handle iterating

over the cells (get one with a call to row.cellIterator()), and HSSFSheet provides a

rowIterator() method to give an iterator over all the rows.

(Unfortunately, due to the broken and backwards-incompatible way that Java 5 foreach loops

were implemented, it isn't possible to use them on a codebase that supports Java 1.4, as POI

does)

HSSFSheet sheet = wb.getSheetAt(0);

for (Iterator rit = sheet.rowIterator(); rit.hasNext(); ) {

HSSFRow row = (HSSFRow)rit.next();

for (Iterator cit = row.cellIterator(); cit.hasNext(); ) {

HSSFCell cell = (HSSFCell)cit.next();

// Do something here

}

HSSFSheet sheet = wb.getSheetAt(0);

for (Iterator<HSSFRow> rit = (Iterator<HSSFRow>)sheet.rowIterator(); rit.hasNext(); ) {

HSSFRow row = rit.next();

for (Iterator<HSSFCell> cit = (Iterator<HSSFCell>)row.cellIterator(); cit.hasNext(); ) {

HSSFCell cell = cit.next();

// Do something here

}

Busy Developers' Guide to HSSF Features

}

1.2.9. Iterate over rows and cells using Java 1.5 foreach loops - OOXML Branch Only

Sometimes, you'd like to just iterate over all the rows in a sheet, or all the cells in a row. If

you are using Java 5 or later, then this is especially handy, as it'll allow the new foreach loop

support to work.

Luckily, this is very easy. Both HSSFSheet and HSSFRow implement java.lang.Iterable to

allow foreach loops. For HSSFRow this allows access to the CellIterator inner class to

handle iterating over the cells, and for HSSFSheet gives the rowIterator() to iterator over all

the rows.

HSSFSheet sheet = wb.getSheetAt(0);

for (HSSFRow row : sheet.rowIterator()) {

for (HSSFCell cell : row.cellIterator()) {

// Do something here

}

Note:

This only works on the OOXML branch of POI

1.2.10. Text Extraction

For most text extraction requirements, the standard ExcelExtractor class should provide all

you need.

InputStream inp = new FileInputStream("workbook.xls");

HSSFWorkbook wb = new HSSFWorkbook(new POIFSFileSystem(inp));

ExcelExtractor extractor = new ExcelExtractor(wb);

extractor.setFormulasNotResults(true);

extractor.setIncludeSheetNames(false);

String text = extractor.getText();

For very fancy text extraction, XLS to CSV etc, take a look at

/src/scratchpad/examples/src/org/apache/poi/hssf/eventusermodel/examples/XLS2CSVmra.java

1.2.11. Fills and colors

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

Busy Developers' Guide to HSSF Features

Page 6

// Create a row and put some cells in it. Rows are 0 based.

HSSFRow row = sheet.createRow((short) 1);

// Aqua background

HSSFCellStyle style = wb.createCellStyle();

style.setFillBackgroundColor(HSSFColor.AQUA.index);

style.setFillPattern(HSSFCellStyle.BIG_SPOTS);

HSSFCell cell = row.createCell((short) 1);

cell.setCellValue("X");

cell.setCellStyle(style);

// Orange "foreground", foreground being the fill foreground not the font color.

style = wb.createCellStyle();

style.setFillForegroundColor(HSSFColor.ORANGE.index);

style.setFillPattern(HSSFCellStyle.SOLID_FOREGROUND);

cell = row.createCell((short) 2);

cell.setCellValue("X");

cell.setCellStyle(style);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.12. Merging cells

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

HSSFRow row = sheet.createRow((short) 1);

HSSFCell cell = row.createCell((short) 1);

cell.setCellValue("This is a test of merging");

sheet.addMergedRegion(new Region(1,(short)1,1,(short)2));

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.13. Working with fonts

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

// Create a row and put some cells in it. Rows are 0 based.

HSSFRow row = sheet.createRow((short) 1);

// Create a new font and alter it.

Busy Developers' Guide to HSSF Features

HSSFFont font = wb.createFont();

font.setFontHeightInPoints((short)24);

font.setFontName("Courier New");

font.setItalic(true);

font.setStrikeout(true);

// Fonts are set into a style so create a new one to use.

HSSFCellStyle style = wb.createCellStyle();

style.setFont(font);

// Create a cell and put a value in it.

HSSFCell cell = row.createCell((short) 1);

cell.setCellValue("This is a test of fonts");

cell.setCellStyle(style);

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

Note, the maximum number of unique fonts in a workbook is limited to 32767 ( the

maximum positive short). You should re-use fonts in your apllications instead of creating a

font for each cell. Examples:

Wrong:

for (int i = 0; i < 10000; i++) {

HSSFRow row = sheet.createRow(i);

HSSFCell cell = row.createCell((short) 0);

HSSFCellStyle style = workbook.createCellStyle();

HSSFFont font = workbook.createFont();

font.setBoldweight(HSSFFont.BOLDWEIGHT_BOLD);

style.setFont(font);

cell.setCellStyle(style);

}

Correct:

HSSFCellStyle style = workbook.createCellStyle();

HSSFFont font = workbook.createFont();

font.setBoldweight(HSSFFont.BOLDWEIGHT_BOLD);

style.setFont(font);

for (int i = 0; i < 10000; i++) {

HSSFRow row = sheet.createRow(i);

HSSFCell cell = row.createCell((short) 0);

cell.setCellStyle(style);

}

1.2.14. Custom colors

Busy Developers' Guide to HSSF Features

Page 8

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet();

HSSFRow row = sheet.createRow((short) 0);

HSSFCell cell = row.createCell((short) 0);

cell.setCellValue("Default Palette");

//apply some colors from the standard palette,

// as in the previous examples.

//we'll use red text on a lime background

HSSFCellStyle style = wb.createCellStyle();

style.setFillForegroundColor(HSSFColor.LIME.index);

style.setFillPattern(HSSFCellStyle.SOLID_FOREGROUND);

HSSFFont font = wb.createFont();

font.setColor(HSSFColor.RED.index);

style.setFont(font);

cell.setCellStyle(style);

//save with the default palette

FileOutputStream out = new FileOutputStream("default_palette.xls");

wb.write(out);

out.close();

//now, let's replace RED and LIME in the palette

// with a more attractive combination

// (lovingly borrowed from freebsd.org)

cell.setCellValue("Modified Palette");

//creating a custom palette for the workbook

HSSFPalette palette = wb.getCustomPalette();

//replacing the standard red with freebsd.org red

palette.setColorAtIndex(HSSFColor.RED.index,

(byte) 153, //RGB red (0-255)

(byte) 0, //RGB green

(byte) 0 //RGB blue

);

//replacing lime with freebsd.org gold

palette.setColorAtIndex(HSSFColor.LIME.index, (byte) 255, (byte) 204, (byte) 102);

//save with the modified palette

// note that wherever we have previously used RED or LIME, the

// new colors magically appear

out = new FileOutputStream("modified_palette.xls");

wb.write(out);

out.close();

1.2.15. Reading and Rewriting Workbooks

Busy Developers' Guide to HSSF Features

POIFSFileSystem fs =

new POIFSFileSystem(new FileInputStream("workbook.xls"));

HSSFWorkbook wb = new HSSFWorkbook(fs);

HSSFSheet sheet = wb.getSheetAt(0);

HSSFRow row = sheet.getRow(2);

HSSFCell cell = row.getCell((short)3);

if (cell == null)

cell = row.createCell((short)3);

cell.setCellType(HSSFCell.CELL_TYPE_STRING);

cell.setCellValue("a test");

// Write the output to a file

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.16. Using newlines in cells

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet s = wb.createSheet();

HSSFRow r = null;

HSSFCell c = null;

HSSFCellStyle cs = wb.createCellStyle();

HSSFFont f = wb.createFont();

HSSFFont f2 = wb.createFont();

cs = wb.createCellStyle();

cs.setFont( f2 );

//Word Wrap MUST be turned on

cs.setWrapText( true );

r = s.createRow( (short) 2 );

r.setHeight( (short) 0x349 );

c = r.createCell( (short) 2 );

c.setCellType( HSSFCell.CELL_TYPE_STRING );

c.setCellValue( "Use \n with word wrap on to create a new line" );

c.setCellStyle( cs );

s.setColumnWidth( (short) 2, (short) ( ( 50 * 8 ) / ( (double) 1 / 20 ) ) );

FileOutputStream fileOut = new FileOutputStream( "workbook.xls" );

wb.write( fileOut );

fileOut.close();

1.2.17. Data Formats

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("format sheet");

HSSFCellStyle style;

HSSFDataFormat format = wb.createDataFormat();

Busy Developers' Guide to HSSF Features

Page 10

HSSFRow row;

HSSFCell cell;

short rowNum = 0;

short colNum = 0;

row = sheet.createRow(rowNum++);

cell = row.createCell(colNum);

cell.setCellValue(11111.25);

style = wb.createCellStyle();

style.setDataFormat(format.getFormat("0.0"));

cell.setCellStyle(style);

row = sheet.createRow(rowNum++);

cell = row.createCell(colNum);

cell.setCellValue(11111.25);

style = wb.createCellStyle();

style.setDataFormat(format.getFormat("#,##0.0000"));

cell.setCellStyle(style);

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.18. Fit Sheet to One Page

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("format sheet");

HSSFPrintSetup ps = sheet.getPrintSetup();

sheet.setAutobreaks(true);

ps.setFitHeight((short)1);

ps.setFitWidth((short)1);

// Create various cells and rows for spreadsheet.

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.19. Set Print Area

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("Sheet1");

wb.setPrintArea(0, "$A$1:$C$2");

//sets the print area for the first sheet

//Alternatively:

//wb.setPrintArea(0, 0, 1, 0, 0) is equivalent to using the name reference (See the JavaDocs for more details)

Busy Developers' Guide to HSSF Features

// Create various cells and rows for spreadsheet.

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.20. Set Page Numbers on Footer

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("format sheet");

HSSFFooter footer = sheet.getFooter()

footer.setRight( "Page " + HSSFFooter.page() + " of " + HSSFFooter.numPages() );

// Create various cells and rows for spreadsheet.

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.21. Using the Convenience Functions

The convenience functions live in contrib and provide utility features such as setting borders

around merged regions and changing style attributes without explicitly creating new styles.

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet1 = wb.createSheet( "new sheet" );

// Create a merged region

HSSFRow row = sheet1.createRow( (short) 1 );

HSSFRow row2 = sheet1.createRow( (short) 2 );

HSSFCell cell = row.createCell( (short) 1 );

cell.setCellValue( "This is a test of merging" );

Region region = new Region( 1, (short) 1, 4, (short) 4 );

sheet1.addMergedRegion( region );

// Set the border and border colors.

final short borderMediumDashed = HSSFCellStyle.BORDER_MEDIUM_DASHED;

HSSFRegionUtil.setBorderBottom( borderMediumDashed,

region, sheet1, wb );

HSSFRegionUtil.setBorderTop( borderMediumDashed,

region, sheet1, wb );

HSSFRegionUtil.setBorderLeft( borderMediumDashed,

region, sheet1, wb );

HSSFRegionUtil.setBorderRight( borderMediumDashed,

region, sheet1, wb );

Busy Developers' Guide to HSSF Features

Page 12

HSSFRegionUtil.setBottomBorderColor(HSSFColor.AQUA.index, region, sheet1, wb);

HSSFRegionUtil.setTopBorderColor(HSSFColor.AQUA.index, region, sheet1, wb);

HSSFRegionUtil.setLeftBorderColor(HSSFColor.AQUA.index, region, sheet1, wb);

HSSFRegionUtil.setRightBorderColor(HSSFColor.AQUA.index, region, sheet1, wb);

// Shows some usages of HSSFCellUtil

HSSFCellStyle style = wb.createCellStyle();

style.setIndention((short)4);

HSSFCellUtil.createCell(row, 8, "This is the value of the cell", style);

HSSFCell cell2 = HSSFCellUtil.createCell( row2, 8, "This is the value of the cell");

HSSFCellUtil.setAlignment(cell2, wb, HSSFCellStyle.ALIGN_CENTER);

// Write out the workbook

FileOutputStream fileOut = new FileOutputStream( "workbook.xls" );

wb.write( fileOut );

fileOut.close();

1.2.22. Shift rows up or down on a sheet

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("row sheet");

// Create various cells and rows for spreadsheet.

// Shift rows 6 - 11 on the spreadsheet to the top (rows 0 - 5)

sheet.shiftRows(5, 10, -5);

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.23. Set a sheet as selected

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("row sheet");

sheet.setSelected(true);

// Create various cells and rows for spreadsheet.

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.24. Set the zoom magnification

The zoom is expressed as a fraction. For example to express a zoom of 75% use 3 for the

numerator and 4 for the denominator.

Busy Developers' Guide to HSSF Features

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet1 = wb.createSheet("new sheet");

sheet1.setZoom(3,4); // 75 percent magnification

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.25. Splits and freeze panes

There are two types of panes you can create; freeze panes and split panes.

A freeze pane is split by columns and rows. You create a freeze pane using the following

mechanism:

sheet1.createFreezePane( 3, 2, 3, 2 );

The first two parameters are the columns and rows you wish to split by. The second two

parameters indicate the cells that are visible in the bottom right quadrant.

Split pains appear differently. The split area is divided into four separate work area's. The

split occurs at the pixel level and the user is able to adjust the split by dragging it to a new

position.

Split panes are created with the following call:

sheet2.createSplitPane( 2000, 2000, 0, 0, HSSFSheet.PANE_LOWER_LEFT );

The first parameter is the x position of the split. This is in 1/20th of a point. A point in this

case seems to equate to a pixel. The second parameter is the y position of the split. Again in

1/20th of a point.

The last parameter indicates which pane currently has the focus. This will be one of

HSSFSheet.PANE_LOWER_LEFT, PANE_LOWER_RIGHT, PANE_UPPER_RIGHT or

PANE_UPPER_LEFT.

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet1 = wb.createSheet("new sheet");

HSSFSheet sheet2 = wb.createSheet("second sheet");

HSSFSheet sheet3 = wb.createSheet("third sheet");

HSSFSheet sheet4 = wb.createSheet("fourth sheet");

// Freeze just one row

sheet1.createFreezePane( 0, 1, 0, 1 );

// Freeze just one column

sheet2.createFreezePane( 1, 0, 1, 0 );

// Freeze the columns and rows (forget about scrolling position of the lower right quadrant).

sheet3.createFreezePane( 2, 2 );

// Create a split with the lower left side being the active quadrant

Busy Developers' Guide to HSSF Features

Page 14

sheet4.createSplitPane( 2000, 2000, 0, 0, HSSFSheet.PANE_LOWER_LEFT );

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.26. Repeating rows and columns

It's possible to set up repeating rows and columns in your printouts by using the

setRepeatingRowsAndColumns() function in the HSSFWorkbook class.

This function Contains 5 parameters. The first parameter is the index to the sheet (0 = first

sheet). The second and third parameters specify the range for the columns to repreat. To stop

the columns from repeating pass in -1 as the start and end column. The fourth and fifth

parameters specify the range for the rows to repeat. To stop the columns from repeating pass

in -1 as the start and end rows.

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet1 = wb.createSheet("new sheet");

HSSFSheet sheet2 = wb.createSheet("second sheet");

// Set the columns to repeat from column 0 to 2 on the first sheet

wb.setRepeatingRowsAndColumns(0,0,2,-1,-1);

// Set the the repeating rows and columns on the second sheet.

wb.setRepeatingRowsAndColumns(1,4,5,1,2);

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

1.2.27. Headers and Footers

Example is for headers but applies directly to footers.

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("new sheet");

HSSFHeader header = sheet.getHeader();

header.setCenter("Center Header");

header.setLeft("Left Header");

header.setRight(HSSFHeader.font("Stencil-Normal", "Italic") +

HSSFHeader.fontSize((short) 16) + "Right w/ Stencil-Normal Italic font and size 16");

FileOutputStream fileOut = new FileOutputStream("workbook.xls");

wb.write(fileOut);

fileOut.close();

Busy Developers' Guide to HSSF Features

1.2.28. Drawing Shapes

POI supports drawing shapes using the Microsoft Office drawing tools. Shapes on a sheet are

organized in a hiearchy of groups and and shapes. The top-most shape is the patriarch. This is

not visisble on the sheet at all. To start drawing you need to call createPatriarch on

the HSSFSheet class. This has the effect erasing any other shape information stored in that

sheet. By default POI will leave shape records alone in the sheet unless you make a call to

this method.

To create a shape you have to go through the following steps:

1. Create the patriarch.

2. Create an anchor to position the shape on the sheet.

3. Ask the patriarch to create the shape.

4. Set the shape type (line, oval, rectangle etc...)

5. Set any other style details converning the shape. (eg: line thickness, etc...)

HSSFPatriarch patriarch = sheet.createDrawingPatriarch();

a = new HSSFClientAnchor( 0, 0, 1023, 255, (short) 1, 0, (short) 1, 0 );

HSSFSimpleShape shape1 = patriarch.createSimpleShape(a1);

shape1.setShapeType(HSSFSimpleShape.OBJECT_TYPE_LINE);

Text boxes are created using a different call:

HSSFTextbox textbox1 = patriarch.createTextbox(

new HSSFClientAnchor(0,0,0,0,(short)1,1,(short)2,2));

textbox1.setString(new HSSFRichTextString("This is a test") );

It's possible to use different fonts to style parts of the text in the textbox. Here's how:

HSSFFont font = wb.createFont();

font.setItalic(true);

font.setUnderline(HSSFFont.U_DOUBLE);

HSSFRichTextString string = new HSSFRichTextString("Woo!!!");

string.applyFont(2,5,font);

textbox.setString(string );

Just as can be done manually using Excel, it is possible to group shapes together. This is

done by calling createGroup() and then creating the shapes using those groups.

It's also possible to create groups within groups.

Note:

Any group you create should contain at least two other shapes or subgroups.

Busy Developers' Guide to HSSF Features

Page 16

Here's how to create a shape group:

// Create a shape group.

HSSFShapeGroup group = patriarch.createGroup(

new HSSFClientAnchor(0,0,900,200,(short)2,2,(short)2,2));

// Create a couple of lines in the group.

HSSFSimpleShape shape1 = group.createShape(new HSSFChildAnchor(3,3,500,500));

shape1.setShapeType(HSSFSimpleShape.OBJECT_TYPE_LINE);

( (HSSFChildAnchor) shape1.getAnchor() ).setAnchor((short)3,3,500,500);

HSSFSimpleShape shape2 = group.createShape(new HSSFChildAnchor((short)1,200,400,600));

shape2.setShapeType(HSSFSimpleShape.OBJECT_TYPE_LINE);

If you're being observant you'll noticed that the shapes that are added to the group use a new

type of anchor: the HSSFChildAnchor. What happens is that the created group has it's

own coordinate space for shapes that are placed into it. POI defaults this to (0,0,1023,255)

but you are able to change it as desired. Here's how:

myGroup.setCoordinates(10,10,20,20); // top-left, bottom-right

If you create a group within a group it's also going to have it's own coordinate space.

1.2.29. Styling Shapes

By default shapes can look a little plain. It's possible to apply different styles to the shapes

however. The sorts of things that can currently be done are:

•Change the fill color.

•Make a shape with no fill color.

•Change the thickness of the lines.

•Change the style of the lines. Eg: dashed, dotted.

•Change the line color.

Here's an examples of how this is done:

HSSFSimpleShape s = patriarch.createSimpleShape(a);

s.setShapeType(HSSFSimpleShape.OBJECT_TYPE_OVAL);

s.setLineStyleColor(10,10,10);

s.setFillColor(90,10,200);

s.setLineWidth(HSSFShape.LINEWIDTH_ONE_PT * 3);

s.setLineStyle(HSSFShape.LINESTYLE_DOTSYS);

1.2.30. Shapes and Graphics2d

While the native POI shape drawing commands are the recommended way to draw shapes in

Busy Developers' Guide to HSSF Features

a shape it's sometimes desirable to use a standard API for compatibility with external

libraries. With this in mind we created some wrappers for Graphics and Graphics2d.

Note:

It's important to not however before continuing that Graphics2d is a poor match to the capabilities of the Microsoft Office

drawing commands. The older Graphics class offers a closer match but is still a square peg in a round hole.

All Graphics commands are issued into an HSSFShapeGroup. Here's how it's done:

a = new HSSFClientAnchor( 0, 0, 1023, 255, (short) 1, 0, (short) 1, 0 );

group = patriarch.createGroup( a );

group.setCoordinates( 0, 0, 80 * 4 , 12 * 23 );

float verticalPointsPerPixel = a.getAnchorHeightInPoints(sheet) / (float)Math.abs(group.getY2() - group.getY1());

g = new EscherGraphics( group, wb, Color.black, verticalPointsPerPixel );

g2d = new EscherGraphics2d( g );

drawChemicalStructure( g2d );

The first thing we do is create the group and set it's coordinates to match what we plan to

draw. Next we calculate a reasonable fontSizeMultipler then create the EscherGraphics

object. Since what we really want is a Graphics2d object we create an EscherGraphics2d

object and pass in the graphics object we created. Finally we call a routine that draws into the

EscherGraphics2d object.

The vertical points per pixel deserves some more explanation. One of the difficulties in

converting Graphics calls into escher drawing calls is that Excel does not have the concept of

absolute pixel positions. It measures it's cell widths in 'characters' and the cell heights in

points. Unfortunately it's not defined exactly what type of character it's measuring.

Presumably this is due to the fact that the Excel will be using different fonts on different

platforms or even within the same platform.

Because of this constraint we've had to implement the concept of a verticalPointsPerPixel.

This the amount the font should be scaled by when you issue commands such as

drawString(). To calculate this value use the follow formula:

multipler = groupHeightInPoints / heightOfGroup

The height of the group is calculated fairly simply by calculating the difference between the

y coordinates of the bounding box of the shape. The height of the group can be calculated by

using a convenience called HSSFClientAnchor.getAnchorHeightInPoints().

Many of the functions supported by the graphics classes are not complete. Here's some of the

functions that are known to work.

•fillRect()

Busy Developers' Guide to HSSF Features

Page 18

•fillOval()

•drawString()

•drawOval()

•drawLine()

•clearRect()

Functions that are not supported will return and log a message using the POI logging

infrastructure (disabled by default).

1.2.31. Outlining

Outlines are great for grouping sections of information together and can be added easily to

columns and rows using the POI API. Here's how:

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet1 = wb.createSheet("new sheet");

sheet1.groupRow( 5, 14 );

sheet1.groupRow( 7, 14 );

sheet1.groupRow( 16, 19 );

sheet1.groupColumn( (short)4, (short)7 );

sheet1.groupColumn( (short)9, (short)12 );

sheet1.groupColumn( (short)10, (short)11 );

FileOutputStream fileOut = new FileOutputStream(filename);

wb.write(fileOut);

fileOut.close();

To collapse (or expand) an outline use the following calls:

sheet1.setRowGroupCollapsed( 7, true );

sheet1.setColumnGroupCollapsed( (short)4, true );

The row/column you choose should contain an already created group. It can be anywhere

within the group.

2. Images

Images are part of the drawing support. To add an image just call createPicture() on

the drawing patriarch. At the time of writing the following types are supported:

•PNG

•JPG

•DIB

It should be noted that any existing drawings may be erased once you add a image to a sheet.

Busy Developers' Guide to HSSF Features

// Create the drawing patriarch. This is the top level container for

// all shapes. This will clear out any existing shapes for that sheet.

HSSFPatriarch patriarch = sheet5.createDrawingPatriarch();

HSSFClientAnchor anchor;

anchor = new HSSFClientAnchor(0,0,0,255,(short)2,2,(short)4,7);

anchor.setAnchorType( 2 );

patriarch.createPicture(anchor, loadPicture( "src/resources/logos/logoKarmokar4.png", wb ));

Creating an image and setting its anchor to the actual width and height:

HSSFPatriarch patriarch = sheet5.createDrawingPatriarch();

HSSFPicture picture = patriarch.createPicture(new HSSFClientAnchor(), loadPicture( "src/resources/logos/logoKarmokar4.png", wb ));

picture.resize();

HSSFPatriarch patriarch = sheet5.createDrawingPatriarch();

HSSFPicture picture = patriarch.createPicture(new HSSFClientAnchor(), loadPicture( "src/resources/logos/logoKarmokar4.png", wb ));

HSSFClientAnchor preferredSize = picture.getPreferredSize();

picture.setAnchor(preferredSize);

Note:

HSSFPicture.resize() works only for JPEG and PNG. Other formats are not yet supported.

Reading images from a workbook:

HSSFWorkbook wb;

List lst = wb.getAllPictures();

for (Iterator it = lst.iterator(); it.hasNext(); ) {

HSSFPictureData pict = (HSSFPictureData)it.next();

String ext = pict.suggestFileExtension();

byte[] data = pict.getData();

if (ext.equals("jpeg")){

FileOutputStream out = new FileOutputStream("pict.jpg");

out.write(data);

out.close();

}

3. Named Ranges and Named Cells

Named Range is a way to refer to a group of cells by a name. Named Cell is a degenerate

Busy Developers' Guide to HSSF Features

Page 20

case of Named Range in that the 'group of cells' contains exactly one cell. You can create as

well as refer to cells in a workbook by their named range. When working with Named

Ranges, the classes: org.apache.poi.hssf.util.CellReference and &

org.apache.poi.hssf.util.AreaReference are used.

Creating Named Range / Named Cell

// setup code

String sname = "TestSheet", cname = "TestName", cvalue = "TestVal";

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet(sname);

sheet.createRow(0).createCell((short) 0).setCellValue(cvalue);

// 1. create named range for a single cell using areareference

HSSFName namedCell = wb.createName();

namedCell.setNameName(cname);

String reference = sname+"!A1:A1"; // area reference

namedCell.setReference(reference);

// 2. create named range for a single cell using cellreference

HSSFName namedCell = wb.createName();

namedCell.setNameName(cname);

String reference = sname+"!A1"; // cell reference

namedCell.setReference(reference);

// 3. create named range for an area using AreaReference

HSSFName namedCell = wb.createName();

namedCell.setNameName(cname);

String reference = sname+"!A1:C5"; // area reference

namedCell.setReference(reference);

Reading from Named Range / Named Cell

// setup code

String cname = "TestName";

HSSFWorkbook wb = getMyWorkbook(); // retrieve workbook

// retrieve the named range

int namedCellIdx = wb.getNameIndex(cellName);

HSSFName aNamedCell = wb.getNameAt(namedCellIdx);

// retrieve the cell at the named range and test its contents

AreaReference aref = new AreaReference(aNamedCell.getReference());

CellReference[] crefs = aref.getAllReferencedCells();

for (int i=0; i<crefs.length; i++) {

HSSFSheet s = wb.getSheet(crefs[i].getSheetName());

HSSFRow r = sheet.getRow(crefs[i].getRow());

HSSFCell c = r.getCell(crefs[i].getCol());

// extract the cell contents based on cell type etc.

}

Busy Developers' Guide to HSSF Features

Reading from non-contiguous Named Ranges

// Setup code

String cname = "TestName";

HSSFWorkbook wb = getMyWorkbook(); // retrieve workbook

// Retrieve the named range

// Will be something like "$C$10,$D$12:$D$14";

int namedCellIdx = wb.getNameIndex(cellName);

HSSFName aNamedCell = wb.getNameAt(namedCellIdx);

// Retrieve the cell at the named range and test its contents

// Will get back one AreaReference for C10, and

// another for D12 to D14

AreaReference[] arefs = AreaReference.generateContiguous(aNamedCell.getReference());

for (int i=0; i<arefs.length; i++) {

// Only get the corners of the Area

// (use arefs[i].getAllReferencedCells() to get all cells)

CellReference[] crefs = arefs[i].getCells();

for (int j=0; j<crefs.length; j++) {

// Check it turns into real stuff

HSSFSheet s = wb.getSheet(crefs[j].getSheetName());

HSSFRow r = s.getRow(crefs[j].getRow());

HSSFCell c = r.getCell(crefs[j].getCol());

// Do something with this corner cell

}

Note, when a cell is deleted, Excel does not delete the attached named range. As result,

workbook can contain named ranges that point to cells that no longer exist. You should check

the validity of a reference before constructing AreaReference

if(hssfName.isDeleted()){

//named range points to a deleted cell.

} else {

AreaReference ref = new AreaReference(hssfName.getReference());

}

4. Cell Comments

In Excel a comment is a kind of a text shape, so inserting a comment is very similar to

placing a text box in a worksheet:

HSSFWorkbook wb = new HSSFWorkbook();

HSSFSheet sheet = wb.createSheet("Cell comments in POI HSSF");

// Create the drawing patriarch. This is the top level container for all shapes including cell comments.

HSSFPatriarch patr = sheet.createDrawingPatriarch();

Busy Developers' Guide to HSSF Features

Page 22

//create a cell in row 3

HSSFCell cell1 = sheet.createRow(3).createCell((short)1);

cell1.setCellValue(new HSSFRichTextString("Hello, World"));

//anchor defines size and position of the comment in worksheet

HSSFComment comment1 = patr.createComment(new HSSFClientAnchor(0, 0, 0, 0, (short)4, 2, (short) 6, 5));

// set text in the comment

comment1.setString(new HSSFRichTextString("We can set comments in POI"));

//set comment author.

//you can see it in the status bar when moving mouse over the commented cell

comment1.setAuthor("Apache Software Foundation");

// The first way to assign comment to a cell is via HSSFCell.setCellComment method

cell1.setCellComment(comment1);

//create another cell in row 6

HSSFCell cell2 = sheet.createRow(6).createCell((short)1);

cell2.setCellValue(36.6);

HSSFComment comment2 = patr.createComment(new HSSFClientAnchor(0, 0, 0, 0, (short)4, 8, (short) 6, 11));

//modify background color of the comment

comment2.setFillColor(204, 236, 255);

HSSFRichTextString string = new HSSFRichTextString("Normal body temperature");

//apply custom font to the text in the comment

HSSFFont font = wb.createFont();

font.setFontName("Arial");

font.setFontHeightInPoints((short)10);

font.setBoldweight(HSSFFont.BOLDWEIGHT_BOLD);

font.setColor(HSSFColor.RED.index);

string.applyFont(font);

comment2.setString(string);

//by default comments are hidden. This one is always visible.

comment2.setVisible(true);

comment2.setAuthor("Bill Gates");

/**

* The second way to assign comment to a cell is to implicitly specify its row and column.

* Note, it is possible to set row and column of a non-existing cell.

* It works, the commnet is visible.

comment2.setRow(6);

comment2.setColumn((short)1);

FileOutputStream out = new FileOutputStream("poi_comment.xls");

wb.write(out);

out.close();

Busy Developers' Guide to HSSF Features

Reading cell comments

HSSFCell cell = sheet.get(3).getColumn((short)1);

HSSFComment comment = cell.getCellComment();

if (comment != null) {

HSSFRichTextString str = comment.getString();

String author = comment.getAuthor();

}

// alternatively you can retrieve cell comments by (row, column)

comment = sheet.getCellComment(3, 1);

5. Adjust column width to fit the contents

HSSFSheet sheet = workbook.getSheetAt(0);

sheet.autoSizeColumn((short)0); //adjust width of the first column

sheet.autoSizeColumn((short)1); //adjust width of the second column

Note:

To calculate column width HSSFSheet.autoSizeColumn uses Java2D classes that throw exception if graphical environment is

not available. In case if graphical environment is not available, you must tell Java that you are running in headless mode and

set the following system property: java.awt.headless=true (either via -Djava.awt.headless=true startup

parameter or via System.setProperty("java.awt.headless", "true")).

6. How to read hyperlinks

HSSFSheet sheet = workbook.getSheetAt(0);

HSSFCell cell = sheet.getRow(0).getCell((short)0);

HSSFHyperlink link = cell.getHyperlink();

if(link != null){

System.out.println(link.getAddress());

}

7. How to create hyperlinks

HSSFWorkbook wb = new HSSFWorkbook();

//cell style for hyperlinks

//by default hypelrinks are blue and underlined

HSSFCellStyle hlink_style = wb.createCellStyle();

HSSFFont hlink_font = wb.createFont();

hlink_font.setUnderline(HSSFFont.U_SINGLE);

hlink_font.setColor(HSSFColor.BLUE.index);

hlink_style.setFont(hlink_font);

Busy Developers' Guide to HSSF Features

Page 24

HSSFCell cell;

HSSFSheet sheet = wb.createSheet("Hyperlinks");

//URL

cell = sheet.createRow(0).createCell((short)0);

cell.setCellValue("URL Link");

HSSFHyperlink link = new HSSFHyperlink(HSSFHyperlink.LINK_URL);

link.setAddress("http://poi.apache.org/");

cell.setHyperlink(link);

cell.setCellStyle(hlink_style);

//link to a file in the current directory

cell = sheet.createRow(1).createCell((short)0);

cell.setCellValue("File Link");

link = new HSSFHyperlink(HSSFHyperlink.LINK_FILE);

link.setAddress("link1.xls");

cell.setHyperlink(link);

cell.setCellStyle(hlink_style);

//e-mail link

cell = sheet.createRow(2).createCell((short)0);

cell.setCellValue("Email Link");

link = new HSSFHyperlink(HSSFHyperlink.LINK_EMAIL);

//note, if subject contains white spaces, make sure they are url-encoded

link.setAddress("mailto:poi@apache.org?subject=Hyperlinks");

cell.setHyperlink(link);

cell.setCellStyle(hlink_style);

//link to a place in this workbook

//create a target sheet and cell

HSSFSheet sheet2 = wb.createSheet("Target Sheet");

sheet2.createRow(0).createCell((short)0).setCellValue("Target Cell");

cell = sheet.createRow(3).createCell((short)0);

cell.setCellValue("Worksheet Link");

link = new HSSFHyperlink(HSSFHyperlink.LINK_DOCUMENT);

link.setAddress("'Target Sheet'!A1");

cell.setHyperlink(link);

cell.setCellStyle(hlink_style);

FileOutputStream out = new FileOutputStream("hssf-links.xls");

wb.write(out);

out.close();

Busy Developers' Guide to HSSF Features

Quick Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
