RADS User Manual

Remko Scharroo

Version 4.3.0

30 May 2018

Laboratory for Satellite Altimetry

NOAA•NESDIS•STAR

NOAA

)

))

This document was typeset with L

EX 2ε.

The layout was designed by Remko Scharroo c

1993–2015

Contents

1 Introduction 1

2 RADS software installation 3

2.1 Prerequisites....................................... 3

2.2 Downloadthesourcecode............................... 3

2.2.1 Download the bundle from GitHub . . . . . . . . . . . . . . . . . . . . . 4

2.2.2 Software synchronisation with git ...................... 4

2.3 Softwareconﬁguration................................. 4

2.4 Softwarecompilation.................................. 5

2.5 Installation........................................ 6

3 RADS data mirroring 7

4 RADS data management 9

4.1 Preparations before using the data base . . . . . . . . . . . . . . . . . . . . . . . 9

4.2 Commonfunctionalities ................................ 9

4.3 RADS4conﬁgurationﬁle................................ 10

4.3.1 Tags in the conﬁguration ﬁle . . . . . . . . . . . . . . . . . . . . . . . . . 10

4.3.2 Tags within a var-block............................. 11

4.3.3 The data-tag................................... 12

4.3.4 Tags for mission deﬁnitions . . . . . . . . . . . . . . . . . . . . . . . . . . 13

5 RADS utilities 15

5.1 Commandlineinterface ................................ 15

5.1.1 Shortoptions .................................. 16

5.1.2 Longoptions .................................. 17

5.2 Commonoptions .................................... 17

5.2.1 Common data selectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5.2.2 Backward compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

iii

iv Contents

5.2.3 Other common options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.3 Orderoftheoptions .................................. 20

5.4 rads2asc4......................................... 21

5.4.1 Syntax ...................................... 21

5.4.2 Commonoptions................................ 22

5.4.3 Program speciﬁc options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.4.4 Example..................................... 23

5.5 rads2grd4 ........................................ 25

5.5.1 Syntax ...................................... 25

5.5.2 Commonoptions................................ 26

5.5.3 Program speciﬁc options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5.5.4 Examples .................................... 27

5.6 rads2nc.......................................... 28

5.6.1 Syntax ...................................... 29

5.6.2 Commonoptions................................ 29

5.6.3 Program speciﬁc options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5.6.4 Example..................................... 30

5.7 radscolin4 ........................................ 31

5.7.1 Syntax ...................................... 32

5.7.2 Commonoptions................................ 33

5.7.3 Program speciﬁc options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5.7.4 Examples .................................... 34

6 RADS library 36

6.1 Modulerads....................................... 36

6.1.1 rads........................................ 36

6.1.2 radsinit ..................................... 38

6.1.3 radsend..................................... 39

6.1.4 radsgetvar................................... 40

6.1.5 radsstat ..................................... 40

6.1.6 radsinitsatstruct ............................... 41

6.1.7 radsinitpassstruct .............................. 41

6.1.8 radssetoptions................................. 41

6.1.9 radsopenpass ................................. 42

6.1.10 radsclosepass ................................. 42

6.1.11 radsreadxml.................................. 43

Contents v

6.1.12 radssetalias .................................. 43

6.1.13 radssetlimits.................................. 44

6.1.14 radssetregion ................................. 44

6.1.15 radssetformat ................................. 45

6.1.16 rads predict equator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Bibliography 47

Index 48

Chapter 1

Introduction

This document describes the layout and use of the Radar Altimeter Database System (RADS),

Version 4. RADS was ﬁrst developed at Delft University of Technology’s Department of

Aerospace Engineering, and remains a joint development with NOAA Laboratory for Satellite

Altimetry and EUMETSAT.

The Radar Altimeter Database System is composed of three elements:

A few hundred gigabytes of altimeter data ﬁles from missions stretching from Geosat to

whatever altimeter data was made available in the last few days;

A set of software tools (object library and executables);

Conﬁguration ﬁles.

So apart from the actual altimeter data, RADS provides a suite of applications and subroutines

that simplify the reading, editing, handling and analysing of data from numerous radar al-

timeters. Although the actual content and layout of the underlying data products do not have

to be identical for all altimeters, the user interface is. Also, the data base is easily expandable

with additional data and/or additional corrections without impact to the user interface, or to

the software in general. In fact, only in very few cases the core software will need to be ad-

justed and recompiled, in even fewer cases adjustments to the actual tools will be required.

Most changes can be covered by changes in the conﬁguration ﬁle.

The data base consists of netCDF ﬁles, one for each satellite pass (half a revolution starting

and ending close to the poles). Ascending passes have odd numbers, descending passes even

numbers. The pass numbering increases consecutively within a repeat cycle.

In case of exact repeat missions the satellite returns to the same ground track every repeat

cycle. For Jason-2, for example, this is after 254 passes, when the pass number starts over at

1. Which pass is number 1 is based on the longitude of the equator crossing (ascending node).

Thus all passes with the same pass number are collinear.

For non-repeat missions or those with very long repeat cycles (like CryoSat-2 or the Jason-1

Extended Mission), we created ”sub-cycles” of a manageable length. There too passes with the

same pass number are nearly collinear. Note that the length of the ”sub-cycle” may change for

cycle to cycle in a kind of dance-step manner.

Each netCDF data ﬁle contains the actual (binary) data as well as the meta data that describe

the contents (data type, units, creation history, etc.) The naming convention for the ﬁles is

SSpPPPPcCCC.nc, where SS is an abbreviation for the satellite (altimeter), PPPP is the pass

2 Introduction

number, CCC is the cycle number, and nc is the extension, a standard convention for netCDF

data ﬁles.

The data ﬁles are grouped in one directory for each cycle, named cCCC. These cycle directories

are then grouped into one directory for each mission phase, which are ﬁnally part of one

directory per satellite. For example, the data ﬁle for pass 801 of cycle 150 in ERS-1’s tandem

mission is $RADSDATAROOT/e1/g/c150/e1p0801c150.nc, where $RADSDATAROOT is the root

directory of the RADS data base.

To read and manipulate the data, you can use standard netCDF tools, like ncdump (that comes

with the netCDF package), GMT (Generic Mapping Tools), nco (NetCDF Operators). But more

suitable is the use of the RADS subroutine library and programs. The library is the basis for all

data utilities provided with RADS and can also be used to create other programs to the user’s

convenience. For a description on each of the subroutines in the library and on how to create

your own program see Appendix 6. In addition, a number of handy utilities are provided to

do some of the most essential jobs (Chapter 5).

Whether you are using the routines, or the provided utilities, you will have to know how the

data handling system of RADS works. It is not essential that you understand the intrinsics of

the data ﬁles, but it is highly recommended that you familiarise yourself with the way the data

can be manipulated, selected and edited on the ﬂy by the RADS routines. Basically, the RADS

routines can take a lot of work out of your hands, provided you have read Chapter 4.

Before going into the details of RADS, the software and the data have to be installed on your

computer. Chapter 2 guides you through the process of software installation, and Chapter 3

tells you how to keep the database up to date.

Chapter 2

RADS software installation

In order to work efﬁciently with the RADS data base you are required to install the software

(subroutine library, utilities, scripts, and conﬁguration ﬁles). This we will tackle in this Chap-

ter. Once you are done with that at least part of the data base needs to be copied onto your

hard disk (or another mounted device), which will be described in the next Chapter.

2.1 Prerequisites

In order to install and run the RADS software you need a few things installed on your system:

A unix platform (for example Linux or Mac OS X).

The make command.

A Fortran 90 compiler. RADS is known to compile with gfortran,f90,f95,xlf90,xlf95,ifort.

The netCDF library (version 4) and module ﬁle compiled with the Fortran 90 interface. Of

course, netCDF comes with its own dependencies (like HDF5 and szip). Please ﬁgure out

where to ﬁnd the netCDF module ﬁle netcdf.mod and the netCDF C library libnetcdf and

Fortran library libnetcdff before you continue.

Optionally, the git program.

For downloading and synchronising the data base, the rsync program.

2.2 Download the source code

The source code can be downloaded as a bundle (zip or tarball) from GitHub or can be syn-

chronised directly with the github server with the git program. The two methods are described

below in Sections 2.2.1 and 2.2.2.

You can put the source code anywhere you like. We will later conﬁgure where things will be

installed. After downloading the software, continue with the conﬁguration, compilation, and

installation steps in Sections 2.3 through 2.5.

It is recommended to regularly check for updates of the RADS source code and recompile if

necessary.

4 RADS software installation

2.2.1 Download the bundle from GitHub

To download the latest bundle of the source code, simply go to https://github.com/remkos/rads/

releases/latest. There you will ﬁnd the latest release notes, and links for the downloading of

the bundle, either as a zip ﬁle, or as a compressed tarball.

You can extract the software in place, or anywhere you want by running:

$ tar -xvzf rads-v4.3.0.tar.gz

$ unzip rads-v4.3.0.zip

This will create a directory called rads-v4.3.0.

2.2.2 Software synchronisation with git

The version control system git helps to administrate software development projects on dis-

tributed systems (or at least by distributed users), avoiding problems of accidentally wiping

out each other’s changes. Also, it is a very practical tool for distributing trees of software to

others, who then can make their own changes without running the risk of accidentally over-

writing them when a new update is provided. The git command can merge those changes, and

alerts you of that happening.

You need to have at least the executable git installed on your system to connect to the GitHub

repository. This program comes installed by default on Mac OS X and most Linux and Unix

systems.

First you need to ’clone’ the code from the GitHub server onto your machine:

$ git clone https://github.com/remkos/rads

This downloads all the code and puts it into a directory called rads. This needs to be done

only once.

Later on you can bring the source on your machine up to date by going into the rads directory

and executing:

$ git pull -t origin master

although it is much simpler to just use:

$ make update

2.3 Software conﬁguration

Now we are going to determine where the software executables, library, and data are going to

be stored. For this we run the conﬁgure in the source directory (rads-v4.3.0 if you down-

loaded the tarball, or rads if you used git). The program conﬁgure will allow you to specify

where you want things installed and also determines which Fortran compiler you have and

what special options are needed for your platform.

By default, conﬁgure will install everything under the directory were it resides itself. It will

create directories:

2.4 Software compilation 5

bin for the executables (both binaries and scripts)

include for the Fortran 90 module ﬁles to be used with the RADS library

lib for the RADS library

share for the system independent data: the satellite data and conﬁguration ﬁles. This one

particularly, you might want to put somewhere else, on a dedicated disk, for example.

Normally, you would need to tell conﬁgure only where you want to install the aforemen-

tioned directories. The rest, like where to ﬁnd your Fortran compiler and the netCDF library,

are things that conﬁgure should be able to ﬁgure out by itself, using the nf-conﬁg script, for

example. Therefore, you will only have to specify the root directory for the installation (pre-

ﬁx) and likely the place where you want the RADS altimeter data to reside or where they are

already residing (datadir). Run, for example:

$ configure --prefix=/usr/local --datadir=/rads/data

The ﬁrst argument to conﬁgure speciﬁes that the bin,include and lib directory are to be put

under /usr/local. The second argument speciﬁes the directory for the data and conﬁguration

ﬁle (which could be on a server for more systems to use). Still a directory share is created

under /usr/local to contain the manuals.

If, for whatever reason, conﬁgure cannot ﬁnd a Fortran compiler or the netCDF libraries on

its own, you need to specify the location of the Fortran compiler and the netCDF library and

include ﬁles. Here is an example:

$ configure FC=/sw/bin/gfortran \

--with-netcdf-inc=/sw/lib/netcdf-gfortran/include \

--with-netcdf-lib=/sw/lib:/sw/lib/netcdf-gfortran/lib \

--prefix=/usr/local --datadir=/rads/data

The ﬁrst argument to conﬁgure speciﬁes the location of the fortran compiler, while the second

identiﬁes the directory where we can ﬁnd netcdf.mod. The third argument speciﬁes the two

directories that contain the netCDF C library (libnetcdf) and netCDF Fortran library (libnetcdff),

separated by a colon. If these two are merged, or in one directory, you can just use one direc-

tory name.

The conﬁgure program also tests if your Fortran compiler is ready for Fortran 90 and can

compile with the netCDF library. If you have problems, you may need to review the options

you gave to conﬁgure, and make sure that conﬁgure picked the same compiler that was used

to compile the netCDF library. Finding the nf-conﬁg command on your system may be pivotal.

Run configure --help to get more info.

2.4 Software compilation

Now that your system is conﬁgured, it should be easy to compile the software. Just run in the

source directory (where you also ran conﬁgure):

$ make

It will compile and link the programs in the subdirectory src, but not those in devel. The latter

are only provided to you to get a feel of how the RADS altimeter database was created. You

will not be able to compile or link those programs, as essential routines have been left out.

6 RADS software installation

If you have problems compiling, you may need to tweak one of the makeﬁles, conﬁg.mk.

Please let us know about it, so that we can change the conﬁgure program accordingly. You can

do this at the issue tracker on the RADS GitHub page: https://github.com/remkos/rads/issues.

2.5 Installation

To install the software, conﬁguration ﬁle, and manuals in the places discussed in Section 2.3,

run the following command in the directory where conﬁgure resides:

$ make install

Now you can continue with the mirroring of the data ﬁles.

Chapter 3

RADS data mirroring

RADS now exceeds 400 GBytes of data. It virtually impossible to copy all of it in one go,

or copy all of it every time that updates have been made. To facilitate the updating, it is

recommended to use the rsync program. This program will determine by itself which ﬁles are

updated and will update only those. In fact, it will transfer only those parts of the ﬁles that are

actually changed. This provides a signiﬁcant speed beneﬁt when, for example, an extra data

ﬁeld is added.

You need to have at least the executable rsync installed on your system to use rsync. In case

of Linux machines, simply install the rsync package available on most distributions. The pro-

gram rsync comes standard with Mac OS X, or can be obtained from http://rsync.samba.org.

The rsync command will download the data from the rsync server at the Delft University of

Technology in The Netherlands. This server is setup such that it will allow you to access only

the RADS data and software. It will not allow you to log in to the server as a common user.

Thus, setting up ssh key pairs is not possible.

Let us start, for example, to synchronise the Jason-2 data. The subdirectory for the Jason-2

data is j2 (See Table 3.1 for all 2-character abbreviations of the altimeter missions). To get all

the Jason-2 data, you will type the following commands (still assuming you have your data in

/rads/data):

$ cd /rads/data

$ rsync -avz --del radsuser@rads.tudelft.nl::rads/data/j2 .

At the beginning rsync will ask you to enter the password for radsuser. It will have been

provided to you when you registered as a user.

Apart from the satellite speciﬁc directories, there is a directory that contains conﬁguration

ﬁles, that help RADS to read the data ﬁles. These ﬁles are also installed in the same place,

when installing the software, but you can download them from the rsync server as well. Be

sure to keep these ﬁles up to date.

$ cd /rads/data

$ rsync -avz --del radsuser@rads.tudelft.nl::rads/data/conf .

If you are patient, and want to get all of the data at once, you can perform the following

commands:

$ cd /rads

$ rsync -avz --del radsuser@rads.tudelft.nl::rads/data .

8 RADS data mirroring

Altimeter Abbr. Nr Alternatives References

GEOS 3 g3 1 ge3 geos-3 geos3 (not included in RADS)

Seasat ss 2 sea seasat-a (not included in RADS)

Geosat gs 3 geo geosat

ERS-1 e1 4 er1 ers-1 ers1 [Francis, 1990; Francis et al., 1991]

TOPEX tx 5 top topex [Fu et al., 1994]

Poseidon pn 6 pos poseidon

ERS-2 e2 7 er2 ers-2 ers2 [Francis et al., 1995]

GFO g1 8 gfo gfo-1 gfo1

Jason-1 j1 9 ja1 jason-1 jason1 [M´enard et al., 2003]

Envisat n1 10 en1 envisat

Jason-2 j2 11 ja2 jason-2 jason2 [Lambin et al., 2010]

CryoSat-2 c2 12 cs2 cryosat-2 cryosat2 [Wingham et al., 2006]

SARAL sa 13 sa srl saral altika

Jason-3 j3 14 ja3 jason-3 jason3 (limited access in RADS)

HY-2A 2a 15 h2a hy-2a hy2a (not included in RADS)

Sentinel-3A 3a 16 s3a sentinel-3a sentinel3a sntnl-3a (in RADS summer 2016)

Sentinel-3B 3b 17 s3b sentinel-3b sentinel3b sntnl-3b (to be launched end 2017)

Table 3.1 Abbreviation and numbers used for the various altimeter missions.

If, for whatever reason, the mirroring is interrupted, you can simply start it again, and it will

continue where it left off. If you have a recent version of the rsync program, we recommend

that you use the option --del instead of --delete, as it speeds up the process signiﬁcantly.

There is one more directory that may be of interest, but is not essential. The /rads/tables

directory contains a number of lists: lists of the time intervals of passes and cycles, and lists of

the data available for each satellite.

To mirror these directories use rsync:

$ cd /rads

$ rsync -avz --del radsuser@rads.tudelft.nl::rads/tables .

If you need to use rsync regularly to synchronise the RADS data base and you do not want to

enter the password every time, you can set up the environment variable RSYNC_PASSWORD by

one of the following methods (depending on the shell):

export RSYNC_PASSWORD=radspasswd # under sh or bash

setenv RSYNC_PASSWORD radspasswd # under csh or tcsh

If you are using the bash or sh shell, you can do it all in one line, for example:

RSYNC_PASSWORD=radspasswd \

rsync -avz --del radsuser@rads.tudelft.nl::rads/data .

Obviously, the password is not simply radspasswd.

Chapter 4

RADS data management

This Chapter describes the basic functionalities of the data management system of RADS.

These functionalities are part of the RADS utilities as well as the RADS subroutine library

on which the utilities are based.

4.1 Preparations before using the data base

The use of RADS starts with the deﬁnition of the environment variable RADSDATAROOT, such

that it points to the root of the RADS data base. For example (for bash users):

$ export RADSDATAROOT=/rads/data

If you already speciﬁed this directory in the conﬁgure step, then you do not have to set the

RADSDATAROOT directory.

It is also practical to include /usr/local/bin (or where ever you installed the binaries) in your

executable search path, so that existing executables can be used. However, this is not essential,

just practical.

4.2 Common functionalities

A subroutine library is created to facilitate the data reading, conversion to SI units, editing and

the construction of sea level anomalies. Based on these routines, several programs (utilities)

are created to list or manipulate the contents of the data base. Since these programs share the

same routines, much of their functionalities are the same, as well as their user interface. In

addition, a number of developer tools are available to create the data base. These programs

will be of less concern to the users, and are not yet explained in this manual. Their code is only

provided for reference, and are not intended to be compiled on your system.

Common to all RADS utilities is the internal data selection, editing, and the ability to construct

the sea level anomaly (or any other ﬁelds) on the ﬂy. The construction of the sea level anomaly

includes a number of arithmetic expressions (adding and subtracting), plus applying a num-

ber of selection criteria that can ﬂag the sea level anomaly as invalid. Both the ability to do

arithmetic (even beyond mere adding and subtracting) and editing are built into the software

library, so that they can be shared by the various RADS utilities.

Even when writing their own program, the user does not have to generate code to construct a

sea level anomaly or to do editing. At the same time that the sea level anomaly is constructed,

10 RADS data management

the data is edited based on system-wide, user, or local preferences. These preferences can be

speciﬁed at several levels, either in XML conﬁguration ﬁles, or by command line options. The

order in which these preferences are processed is the following:

System-wide general preferences, found in $RADSDATAROOT/conf/rads.xml.

General user preferences, found in a ﬁle ˜/.rads/rads.xml, if available.

General local preferences, found in a ﬁle rads.xml in the current working directory.

Preference ﬁles indicated by the -X or --xml option on the command line.

Other command line arguments, such as -L or --limits.

So the command line arguments overrule the local preferences and which overrule the user

preferences and eventually the system-wide preferences.

The XML conﬁguration ﬁle is “human readable” and is described in the next section.

4.3 RADS4 conﬁguration ﬁle

The RADS4 conﬁguration ﬁle rads.xml controls:

Information about the various altimeter missions, such as repeat period, number of passes

per cycle, etc.

Information about all the variables available for each mission, including editing criteria,

format for writing to ascii, and the complete information needed to store the variable upon

creation of the database.

Optionally, description of variables that can be created on the ﬂy from other variables.

The conﬁguration ﬁle is a structured XML ﬁle, comprised of a number items and blocks, of the

following shape:

<block>

</block>

As usual in an XML ﬁle, <tag> starts an item with name tag and </tag> ends it. Any content

in between is the value, or are the values associated with this tag. Generally, the line can be

broken by carriage returns and leading spaces are ignored.

4.3.1 Tags in the conﬁguration ﬁle

The various names of the tags used in the conﬁguration ﬁle are described below.

if is followed by a condition such as sat="j1 j2", which means that the contents of the block

following this <if> applies only to the missions j1 and j2. The selection can be negated

by starting it with an exclamation point, i.e. sat="!j1 j2" means that the following block

applies to all missions except j1 and j2.

elseif,else can follow an if-block. For example:

... for j1 and j2 ...

4.3 RADS4 conﬁguration ﬁle 11

</if>

... for e1 and e2 ...

</elseif>

<else>

... all other missions ...

</else>

global attributes speciﬁes the global attributes that are always to be written to the output

ﬁle, line by line. The ﬁrst word on each line is the name of the global attribute, the rest is

its value.

satellites speciﬁes, line by line, the 2- and 3-character abbreviations for the altimeter mis-

sions. The rest of each line is used to specify alternative names which can be searched for

substrings.

var identiﬁes a block of tags that describe a single variable. The tag needs to include an op-

tion such as name="alt_gdre" to specify the variable name, and optionally (for example)

field=425 which specify the ﬁeld numbers used in RADS3. A condition like sat="j1 j2"

can also be added as an option in this tag.

alias speciﬁes an alias (i.e. an alternative name) for a previously speciﬁed variable. The tag

should at least include an option such as name="alt" to specify the name of the alias,

and optionally the ﬁeld number used in RADS3 (e.g. field=4). Again, a condition like

sat="j1" can be added. If more than one value is given, then it means that the alias

will point to the ﬁrst variable, unless it is not available, then it points to the second. For

example:

means that if one uses the variable alt for Jason-2, then the variable alt_gdre is processed.

If determining this variable was unsuccessful, then alt_gdrd is used instead.

4.3.2 Tags within a var-block

The following tags can only occur within a var-block (with one exception, see below):

long name speciﬁes the description of the variable, as well as the long_name attribute to be

written to the netCDF data ﬁles.

standard name,source,comment specify the standard_name,source, and comment at-

tributes to be written to the netCDF data ﬁles.

units speciﬁes the units of the variable as used in any output, as well as the units attribute

in the netCDF data ﬁles.

ﬂag values speciﬁes the meanings of a ﬂag, counting up from 0. For example yes no means

that 0 is to be interpreted as ”yes”, 1 as ”no”.

ﬂag mask speciﬁes the meanings of a ﬂag word made up of bits. For example

left front up means that when the LSB is raised ”left” is true, and the next bits indi-

cate if ”front” and ”up” are true.

limits speciﬁes the range of ”good” values. Any value less than the lower limit or greater than

the upper limit result in the variable to be set to NaN. In case the variable is a ﬂag mask,

then the ﬁrst value indicates the mask of bits that should not be set, the second value the

bits that should be set, otherwise the result will yield NaN.

12 RADS data management

plot range speciﬁes a suggested range for plotting the variable. It is not used for any process-

ing, except for the radsvar program.

parameters is used for the RADS4 database creation and has no impact on any user pro-

grams.

data speciﬁes the variable name as used in the input RADS netCDF data ﬁles (normally the

same as the variable name), but could also be used to specify a mathematical statement

that derives the variable from others, or to interpolate values from a grid. More about this

in Section 4.3.3.

quality ﬂag indicates which variables are checked to determine the quality of the current vari-

able. If any of the speciﬁed variables lead to NaN (not-a-number), the corresponding value

of the current variable is set to NaN as well.

dimension is the dimension of the variable. Default is 1-dimensional. Some variables can be

2-dimensional.

format is the Fortran format speciﬁcation for ASCII output of the variable.

compress speciﬁes the data type (i.e., int1,int2,int4,real, or dble) and optional

scale_factor and add_offset to be used in the output netCDF ﬁles. This applies only

the output ﬁles. Input netCDF ﬁles may be different.

Because you may want to overrule just one line in a var-block, one can stick the option

var="varname" in the above tags. For example,

</var>

is equivalent to

4.3.3 The data-tag

The data-tag can be used in a variety of ways, depending on the text (value) between the

<data> and </data> strings, or the optional source=source option.

netcdf: The simplest form, explained above, is that the value indicates the name of the

netCDF variable in the RADS data ﬁles. For example: <data>alt_gdre</data>. RADS

automatically assumes this type of input if only one value is given. Alternatively use

<data source="nc"> or <data source="netcdf">.

It is also possible to read global or variable attributes, which will then be as-

signed to the variable for all of the given pass. For example, if such attributes

exist, range_ku:add_offset (the attribute add_offset of the variable range_ku) or

:range_bias_ku (the global attribute range_bias_ku) could be used to retrieve a pos-

sible bias added to the Ku-band range.

math: If more than one value is given (i.e. it contains at least one space), then it will be recog-

nised as a mathematical statement, in ”Reverse Polish” notation. A number of mathemat-

ical operators are available, as described in Table 4.1. This can be very practical to deter-

mine on the ﬂy the difference between two variables, or a combination of many (such as the

sea level anomaly). For example <data>wet_tropo_rad wet_tropo_ecmwf SUB</data>

computes the difference between the radiometer wet tropospheric correction and the

4.3 RADS4 conﬁguration ﬁle 13

ECWMF wet tropospheric corrections by subtracting the latter from the former. To exercise

this mathematical machinery, one can also use <data source="math">.

grid: RADS can interpolate in 2-D netCDF grids on the ﬂy. This is practical if you have a static

model to be interpolated at a certain location (longitude and latitude, or any other two

variables). Depending on the argument of the source= option, one can select to do bilinear

interpolation ("grid" or "grid_l"), cubic spline interpolation ("grid_c" or "grid_s"), or

nearest neighbour selection ("grid_q" or "grid_n"). Without any of these options, a ﬁle

name ending on ”.nc” will automatically be recognised as needing linear interpolation. In

addition one can specify the variables to be used as x- and y-coordinated in the interpola-

tion. Default is x="lon" y="lat". Example for interpolating an SSB model:

<data source="grid" x="wind_speed_alt" y="swh">my_ssb_model.nc</data>

constant: To assign a single constant value use, for example,

<data source="constant">0</data>.

branch: An additional option allows you to read a variable from a different directory branch.

For example, if you have an additional set of data stored in the directory c2.mydata next to

the normal c2 branch, then you can add the option branch=".mydata" which will indicate

that this extension is used to the 2-character mission abbreviation to ﬁnd ﬁles containing

the current variable within the var block. Currently up to 5 branches (including the stan-

dard one) can be used.

4.3.4 Tags for mission deﬁnitions

A number of tags are employed to give general information about the various altimeter mis-

sions. You ﬁnd them at the end of the global conﬁguration ﬁle rads.xml. These tags are:

satellite Name of the satellite (maximum 8 characters).

satid Satellite ID used in the crossover program radsxogen.

dt1hz Time step of 1-Hz data.

inclination Orbital inclination in degrees.

frequency Altimeter frequency or frequencies.

xover params Parameters used in radsxogen.

phase A block of tags that apply to a given mission phase.

mission Name of the mission phase.

cycles First and last cycle number in this mission phase.

repeat Length of the repeat cycle (not subcycle) in days and passes (half revolutions) in this

mission phase.

ref pass Date (and time) of a reference equator crossing, longitude of this equator crossing,

cycle number (not subcycle number), pass number in this mission phase phase, and ab-

solute orbit number. If the absolute orbit number is not given, 1 is assumed. This line

provides the reference for the cycle and pass numbering.

start time Start data (and time) of the mission phase.

In the above, date (and time) epochs can be written as yyyy-mm-ddThh:mm:ss, where the part

from ’T’ onward can be omitted in whole or in part.

14 RADS data management

Operator Description

xySUBa a=x-y

xyADDa a=x+y

xyMULa a=x*y

PI a a = pi

E a a = exp(1)

x POP remove last item from stack

x NEG a a = −x

x ABS a a = |x|

x INV a a = 1/x

x SQRT a a = sqrt(x)

x SQR a a = x*x

x EXP a a = exp(x)

x LOG a a = ln(x)

x LOG10 a a = log10(x)

x SIN a a = sin(x)

x COS a a = cos(x)

x TAN a a = tan(x)

x SIND a a = sin(x) [x in degrees]

x COSD a a = cos(x) [x in degrees]

x TAND a a = tan(x) [x in degrees]

x SINH a a = sinh(x)

x COSH a a = cosh(x)

x TANH a a = tanh(x)

x ASIN a a = arcsin(x)

x ACOS a a = arccos(x)

x ATAN a a = arctan(x)

x ASIND a a = arcsin(x) [a in degrees]

x ACOSD a a = arccos(x) [a in degrees]

x ATAND a a = arctan(x) [a in degrees]

x ASINH a a = arcsinh(x)

x ACOSH a a = arccosh(x)

x ATANH a a = arctanh(x)

x ISNAN a a = 1 if x is NaN; a = 0 otherwise

x ISAN a a = 0 if x is NaN; a = 1 otherwise

x RINT a a is nearest integer to x

x NINT a a is nearest integer to x

x CEIL a a is nearest integer greater or equal to x

x CEILING a a is nearest integer greater or equal to x

x FLOOR a a is nearest integer less or equal to x

x D2R a convert x from degrees to radian

x R2D a convert x from radian to degrees

x YMDHMS a convert seconds of 1985 to format YYYYMMDDHHMMSS

x SUM a a(i) = x(1) + ... + x(i) while skipping all NaN

x DIF a a(i) = x(i)-x(i-1); a(1) = NaN

x DUP a b duplicate the last item on the stack

xyDIVa a=x/y

x y POW a a = xy

x y FMOD a a = x modulo y

x y MIN a a = the lesser of x and y

x y MAX a a = the greater of x and y

x y ATAN2 a a = arctan(x) taking into account the quadrant as determined by y

x y HYPOT a a = sqrt(x*x+y*y)

x y R2 a a = x*x + y*y

x y EQ a a = 1 if x == y; a = 0 otherwise

x y NE a a = 0 if x == y; a = 1 otherwise

xyLTa a=1ifx<y; a = 0 otherwise

xyLEa a=1ifx≤y; a = 0 otherwise

xyGTa a=1ifx>y; a = 0 otherwise

xyGEa a=1ifx≥y; a = 0 otherwise

x y NAN a a = NaN if x == y; a = x otherwise

x y AND a a = y if x is NaN; a = x otherwise

x y OR a a = NaN if y is NaN; a = x otherwise

x y IAND a a = bitwise AND of x and y

x y IOR a a = bitwise OR of x and y

x y BTEST a a = 1 if bit y of x is set; a = 0 otherwise

x y AVG a a = 0.5*(x+y) [when x or y is NaN a returns the other value]

x y DXDY a a(i) = (x(i+1)-x(i-1))/(y(i+1)-y(i-1)); a(1) = a(n) = NaN

x y EXCH a b exchange the last two items on the stack (NaNs have no inﬂuence)

x y z INRANGE a a = 1 if x is between y and z; a = 0 otherwise (also in case of any NaN)

x y z BOXCAR a a = ﬁlter x along monotonic dimension y with boxcar of length z (NaNs are skipped)

x y z GAUSS a a = ﬁlter x along monotonic dimension y with Gauss function with sigma z (NaNs are skipped)

Table 4.1 Math operators that can be used in the data-tag. Left of the operator (in uppercase) are

the input value(s); on the right of the operator the output value(s).

Chapter 5

RADS utilities

5.1 Command line interface

The RADS4 commands share a very similar layout of the arguments that can be used on the

command line. The common features of the command line interface, are explained in this

Section. In later Sections we will explain the syntax and use of each of the RADS4 commands.

To learn the syntax of any of the RADS4 commands, simply use the argument --help after the

command name. Let us start off with an excerpt of the help of the radsstat4 program obtained

when typing:

$ radsstat4 --help

radsstat4 (4.3.0): Print RADS statistics per cycle, pass or day(s)

Usage: radsstat4 [required_arguments] [rads_dataselectors] [rads_options] [program_options]

Required argument is:

-S, --sat SAT[/PHASE] Specify satellite [and phase] (e.g. e1/g, tx)

Optional [rads_dataselectors] are:

-C, --cycle C0[,C1[,DC]] Specify first and last cycle and modulo

-L, --limits VAR=MIN,MAX Specify edit data range for variable VAR

Common [rads_options] are:

-v, --verbose Increase verbosity level

Program specific [program_options] are:

-l, --minmax Output min and max in addition to mean and stddev

-o, --output [OUTNAME] Create netCDF output instead of ASCII (default output

filename is "radsstat.nc")

The command line for every RADS4 program consists of a few of the following components:

program name always starts the command line.

required arguments need to be part of the command line for proper operation; in the above

example it speciﬁes the satellite mission.

data selectors are options (in the Unix parlance those parts that start with one or two hyphens)

that select the RADS data of interest.

RADS options are options that are common to most programs.

program options are options can be placed on the command line to provide certain optional

functionalities speciﬁc to the program.

In this sense, RADS is very much in-line with most Unix commands. RADS also supports both

16 RADS utilities

so-called short options and long options, which each can have required or optional arguments.

This you will also ﬁnd in many other Unix commands, particularly those of the GNU ﬂavour.

In general the order of the arguments is irrelevant, though there are some exceptions that will

be explained per program.

5.1.1 Short options

Short options start with a single hyphen and are followed by a single lower case or upper

case letter. In RADS a distinction is made between lower case and upper case options in that

the upper case options have a common meaning and syntax between most RADS programs

whereas lower case options are speciﬁc per program; this is done to harmonise the meanings

across programs and help the user to easier remember and recognise the distinctive scope of

the options.

Short options can have arguments (values attached to them), which can either be required or

optional. So there are three posibilities:

no argument: The option ﬂag just switches something on or off, for example -l in radsstat4

adds the printing of minima and maxima to the output. In some cases, like -v, the option

can be repeated to increase the verbosity level one step each time.

Short options without argument can be combined behind a single hyphen. Thus each of

the following are equivalent:

-v -l -v

-l -vv

-lvv

-vlv

required argument: The option ﬂag assigns some value. For example, -S j2 selects the satellite

altimeter mission j2.

The option ﬂag and the value can be separated by whitespace (one or more spaces or tabs),

but they can also be pasted together. In addition, the option ﬂag can be preceded by short

options without argument under the same hyphen. So again, the following combinations

all mean the same thing:

-v -S j2

-v -Sj2

-vS j2

-vSj2

In this document, for clarity, we leave a single space between the option and the argument.

optional argument: The option ﬂag assigns some value, or switches something on with a de-

fault value. In the above example for radsstat4, the option -o can be used with or without

an argument, as identiﬁed by the argument [outname] between square brackets. As the

help explains, when -o is omitted, the output is in ASCII format, when -o is used without

argument, then a netCDF ﬁle radsstat.nc is created, and when used with an argument (e.g.

-o myﬁle.nc) then a netCDF ﬁle with that name is created.

Note that the use of these types of options can be tricky, as any value that does not start

with a hyphen that follows can be perceived as an argument of this option, which can lead

to some unintended consequences. To avoid this problem, the option list can be ended with

--. All remaining material will then be seen as verbatim arguments (for example input ﬁle

names), even when they start with a hyphen.

5.2 Common options 17

5.1.2 Long options

To make it a bit less hard to understand (or to remember) some of the options, quite often

an alternative ”long option”, starting with two hyphens is provided. As can be seen in the

radsstat4 help, the short option -v can also be written as --verbose. But any shorter version of

the long option, as long at it is unique, can be used. So --verb is allowed as well.

Just like short options, long options can have no argument, a required argument, or an optional

argument. But long options cannot be combined into one, while short options can.

There are a few alternative ways of combining a long option with its required or optional

argument.

One can always use whitespace (spaces or tabs) to separate the long option from its argu-

ment.

If the argument contains an equal sign (’=’) then one can also use a colon to separate the

long option and its argument.

If the argument does not contain an equal sign, then an equal sign can be used to separate

the long option and the argument.

For example, either of the following syntaxes can be used:

--cycle 10,20 --limits sla=-1,1

--cycle=10/20 --limits:sla=-1/1

--cyc 10-20 --lim sla=-1,1

--cyc=10,20 --lim:sla=-1,1

5.2 Common options

As indicated above, the RADS4 commands have a lot of options in common. Most of these use

short options in upper case. Long options are always lower case.

5.2.1 Common data selectors

Below, in alphabetical order, are the command line options used to select data from the RADS

database.

-A VAR1=VAR2 --alias VAR1=VAR2

Assign VAR1 as an alias of VAR2. This means that when VAR1 is requested, VAR2 will be

used. For example --alias wet tropo=wet tropo ecmwf makes wet tropo (which is used in

the construction of the sea level anomaly sla) an alias of wet tropo ecmwf. Hence the model

wet tropospheric correction, and not the radiometer wet tropospheric correction will then

be used to determine sea level.

-C C0[,C1[,DC]] --cycle C0[,C1[,DC]]

Select data from cycle C0 to cycle C1. If the latter is omitted, only data from cycle C0 is se-

lected. Adding DC will run through the cycles with a step of DC, skipping the intermediate

ones. The arguments C0,C1 and DC can be separated by commas, slashes, or the minus

sign. So -C 1/3 selects cycles 1 through 3. If omitted, data from all cycles (throughout all

mission phases) are selected.

18 RADS utilities

-F VAR=FMT --fmt VAR=FMT --format VAR=FMT

For variable VAR use the Fortran format FMT in ASCII output. E.g., -F sla=f8.4. This can

also be achieved with the ctagformat tag in a RADS4 conﬁguration ﬁle.

-L VAR=MIN,MAX --limits VAR=MIN,MAX

Specify the valid range for the selection of a variable. Outside this range the variable will

be set to NaN. This is an alternative to using the limits tag in a RADS4 conﬁguration ﬁle.

--lat LAT0,LAT1

Select data in the latitude range from LAT0 to LAT1 in degrees. This is equivalent to using

--limits lat=LAT0,LAT1. The south to north range has to be speciﬁed on the interval from

–90◦to 90◦. Examples:

--lat -40,-20 Select data between 40◦S and 20◦S

--lat 0,90 Selects entire northern hemisphere

When omitted, the default range speciﬁed in the RADS4 conﬁguration ﬁle is used. By

default, this is –90◦to +90◦.

--lon LON0,LON1

Select data in the longitude range from LON0 to LON1 in degrees. This is the same as

--limits lon=LON0,LON1. Note that the output longitudes are inﬂuenced by the selection

the interval, be it in the range from –180◦to 180◦or from 0◦to 360◦. Examples:

--lon -40,-20 Select data between 40◦W and 20◦W

--lon 320,340 Same, but output will have only positive longitudes

When omitted, the default range speciﬁed in the RADS4 conﬁguration ﬁle is used, which

is normally –180◦to 180◦.

-P P0[,P1[,DP]] --pass P0[,P1[,DP]]

Select data from pass P0 to pass P1 (out of each selected cycle). If the latter is omitted,

only data from pass P0 is selected. Adding DP will run through the passes with a step of

DP, skipping the intermediate ones. The arguments P0,P1 and DP can be separated by

commas, slashes, or the minus sign. So -P 1-100 selects passes 1 through 100. If omitted,

data from all passes in each of the select cycles is selected.

In addition, one can use -P a (or --pass asc) to select only ascending passes, whereas -P d

(or --pass des) is used to select only descending passes.

-Q VAR=FLAG --quality-ﬂag VAR=FLAG

Check the variable FLAG when validating the variable VAR. This means that in any event

that the variable FLAG is set to NaN (is out of bounds), then VAR is also set to NaN as well.

This is identical to using the quality ﬂag tag in a RADS4 conﬁguration ﬁle.

-R LON0,LON1,LAT0,LAT1 --region LON0,LON1,LAT0,LAT1

Select data within the longitude range from LON0 to LON1 and the latitude range of LAT0

to LAT1, both in degrees. This is equivalent to using both the --lon and --lat options.

-R LON0,LAT0,RADIUS --region LON0,LAT0,RADIUS

Select data within a circular region with a spherical radius RADIUS degrees, around the

point LON0,LAT0 (in degrees).

-S SAT[/PHASE] --sat SAT[/PHASE]

Select data from a given satellite SAT. Many variants of the satellite name can be used.

Either the 2-character code, the 3-character code, or a substring of the satellite name listed

in Table 3.1.

5.2 Common options 19

This is a required option and needs to be given for all RADS4 programs. Optionally, one

can also indicate the mission phase PHASE, separated from the satellite by a slash. (For

backwards compatibility with RADS3 also a colon can be used, but this is discouraged).

--sla SLA0,SLA1

Specify the range of for sea level anomaly in meters (if requested). This is the same as

--limits sla=SLA0,SLA1.

--time T0,T1 --ymd T0,T1 --doy T0,T1 --sec T0,T1

Select data only in the time interval from T0 to T1. RADS4 is generally quite efﬁcient in

ﬁguring out the time format when using the generic --time, but best is to use instead --ymd

with time in the format [YY]YYMMDD[HHMMSS],--doy for [YY]YYDDD (year and day

of year), or --sec for time in seconds from 1 Jan 1985. Decimal points to indicate fractional

days or seconds are also allowed.

The following examples all select data between 1 January 1999, 12:00 UTC and 31 Decem-

ber 2001, 00:00 UTC:

--ymd 990101.5,20011231 Note that the century can be omitted

--doy 99001.5,2001365 when using --ymd or --doy.

--mjd 51179.5,52274.0 With --mjd or --doy, use only fractions of day,

--ymd 990101120000,011231 but with --ymd one can also use ”HHMMSS”.

--sec 441806400,536371200 The old-fashioned seconds since 1985 are still there as well.

One will notice that the data selection is very fast. RADS4 will not go through all the data

sets to get the right data, but will use its ”knowledge” of the repeat cycles and passes to

quickly select the appropriate cycles and passes and scan only those.

-V VAR1,... --var VAR1,...

Select one or more variables from the RADS database. Any number of variables can be

selected in one go by adding their names to the list, separated by commas or slashes. Also

the old RADS3 numerical ﬁeld numbers for the variables can be used!

-X XMLFILE --xml XMLFILE

Load the conﬁguration ﬁle XMLFILE in addition to the default conﬁguration ﬁles

($RADSDATAROOT/conf/rads.xml, and—if available—$HOME/.rads/rads.xml and rads.

xml in the current working directory).

-Z VAR=TYPE[,SCALE[,OFFSET]] --compress VAR=TYPE[,SCALE[,OFFSET]]

Specify how the variable VAR is to be stored in a netCDF output ﬁle. TYPE is one of: int1,

int2, int4, real, dble. SCALE and OFFSET are optional with a default of 1 and 0. This is

identical to using the compress tag in a RADS4 conﬁguration ﬁle. One can also use --cmp.

In all lists, shown as separated by commas above, one can also use slashes, as is done in the

GMT program syntax.

5.2.2 Backward compatibility

For backward compatibility with RADS3 a number of options are still allowed, even though

their use is deprecated.

-h H0,H1

Specify the range from SLA (in meters). This has been replaced by --sla H0,H1.

--opt J

Use ﬁeld number Jwhen ﬁeld J/100 is requested. This is now achieved with

--alias VAR1=VAR2.

20 RADS utilities

--opt I=J

Make ﬁeld number I(in the range 1 to 99) and alias of ﬁeld number J(in the range 101-

9999). This is now achieved with --alias VAR1=VAR2.

--sel VAR1,...

Select variables to be read. Same as --var VAR1,..., except that using --sel signals some

additional backward compatible options.

In addition, again to support backward compatibility with RADS3, the user can omit the dou-

ble hyphen in front of the RADS3 data selectors like sel=,sat=,cycle=,pass=, etc. But it is

highly recommended to use the new options instead.

5.2.3 Other common options

Additional common options in RADS4 are:

--args FILENAME

Get any of the command line arguments from a ﬁle named FILENAME with one option per

line.

--debug LEVEL

Set debug/verbosity level to LEVEL.

--help

Print the syntax of the command and all its arguments.

--log FILENAME

Write statistics and other log information to ﬁle FILENAME (default is standard output).

-q --quiet

Suppress warning messages (but keeps fatal error messages).

-v --verbose

Increase the verbosity level (warnings and debugging). This option can be used numerous

times, increasing verbosity by one level each time.

--version

Print the program version only.

Terminates all command line options; all following command-line arguments are consid-

ered non-option arguments, even if they begin with a hyphen.

5.3 Order of the options

When processing the data of a single satellite the order of the command line options is irrele-

vant, with the exception that options that appear later (further to the right) on the command

line overrule any similar options that appear earlier. For example -q -v will produce verbose

output, as -v overrules the earlier -q.

Yet, there is a more complicated order in which the command line options are processed by

the RADS library:

1. Process some input/output options: --args,--debug,--help,--log,-q,--quiet,-v,--verbose,

--version.

2. Process the satellite mission selector -S or --sat.

5.4 rads2asc4 21

3. Process possible additional XML ﬁles indicated by the -X or --xml options.

4. Process any alias deﬁnitions speciﬁed by the -A or --alias options.

5. Process miscellaneous common options not mentioned elsewhere in this list.

6. Process the variable selection deﬁned by the -V or --var options.

7. Process program-speciﬁc options.

Each of these groups of options are processed left to right. This order is common to all RADS

programs discussed later in this Chapter, as they all use the RADS library to scan the command

line.

When processing multiple satellites at the time (for example when creating dual-satellite

crossovers with radsxogen), it matters whether you put common options before or after mis-

sion selector (-S or --sat). The order then determines whether the option is unique to a single

mission, or applies to all. The rule is as follows:

Common options ahead of the ﬁrst mission selector apply to all missions.

Common options after the ﬁrst mission selector apply to the last mission selector to the

right of the option.

Program-speciﬁc options can be put anywhere.

This means, for example:

$radsxogen [common options]-S e1 [e1 options]-S e2 [e2 options]

5.4 rads2asc4

The program rads2asc4 lists a selection of the RADS4 data base in one ASCII ﬁle or in several

pass-by-pass ASCII ﬁles. These ﬁles contain a header per pass with a description of the data

content followed by one record for each measurement that passes the selection criteria. The

records are built up of columns, separated by white space, listing various data ﬁelds. Which

data ﬁelds are listed (and in which order they are listed) is determined by the command line

argument -V or --var.

In the output, the data that has not passed the editing criteria will be represented by ”NaN”

(Not-a-Number). If the sea level anomaly ﬁeld suffers that fate, the record will not be listed in

the output ﬁle, unless the -r option is used (or -r 0 or -r none).

If the argument -o OUTNAME or --output OUTNAME is used, the output will go into one

ﬁle (named OUTNAME). Otherwise, pass ﬁles are created with the names SSpPPPPcCCC.asc,

similar to what is described in Chapter 1.

This program can be called as rads2asc, or as rads2asc4 to avoid conﬂicts with an already

installed RADS3.

For more details, see the description of the command line options in the next Sections.

5.4.1 Syntax

rads2asc4 (4.3.0): Select RADS altimeter data and output to ASCII

Usage: rads2asc4 [required_arguments] [rads_dataselectors] [rads_options] [program_options]

Required argument is:

22 RADS utilities

-S, --sat SAT[/PHASE] Specify satellite [and phase] (e.g. e1/g, tx)

Optional [rads_dataselectors] are:

-A, --alias VAR1=VAR2 Use variable VAR2 when VAR1 is requested

-C, --cycle C0[,C1[,DC]] Specify first and last cycle and modulo

-F, --fmt, --format VAR=FMT

Specify Fortran format used to print VAR (for ASCII output only)

-L, --limits VAR=MIN,MAX Specify edit data range for variable VAR

--lon LON0,LON1 Specify longitude boundaries (deg)

--lat LAT0,LAT1 Specify latitude boundaries (deg)

-P, --pass P0[,P1[,DP]] Specify first and last pass and modulo; alternatively use -Pa

(--pass asc) or -Pd (--pass des) to restrict selection to

ascending or descending passes only

-Q, --quality-flag VAR=FLAG

Check variable FLAG when validating variable VAR

-R, --region LON0,LON1,LAT0,LAT1

Specify rectangular region (deg)

-R, --region LON0,LAT0,RADIUS

Specify circular region (deg)

--sla SLA0,SLA1 Specify range for SLA (m)

--time T0,T1 Specify time selection (optionally use --ymd, --doy,

or --sec for [YY]YYMMDD[HHMMSS], [YY]YYDDD, or SEC85)

-V, --var VAR1,... Select variables to be read

-X, --xml XMLFILE Load configuration file XMLFILE in addition to the defaults

-Z, --cmp, --compress VAR=TYPE[,SCALE[,OFFSET]]

Specify binary output format for variable VAR (netCDF only); TYPE

is one of: int1, int2, int4, real, dble; SCALE and OFFSET are

optional (def: 1,0)

Still working for backward compatibility with RADS3 are options:

--h H0,H1 Specify range for SLA (m) (now --sla H0,H1)

--opt J Use field number J when J/100 requested (now -A VAR1=VAR2)

--opt I=J Make field I (range 1-99) and alias for field J (now -A VAR1=VAR2)

--sel VAR1,... Select variables to read

Common [rads_options] are:

--args FILENAME Get all command line arguments from FILENAME (1 argument per line)

--debug LEVEL Set debug/verbosity level

--help Print this syntax massage

--log FILENAME Send statistics to FILENAME (default is standard output)

-q, --quiet Suppress warning messages (but keeps fatal error messages)

-v, --verbose Increase verbosity level

--version Print version info only

-- Terminates all options; all following command-line arguments are

considered non-option arguments, even if they begin with a hyphen

Program specific [program_options] are:

-r, --reject-on-nan VAR Reject records if variable VAR on -V specifier is NaN

-r NR Reject records if data item number NR on -V specifier is NaN

-r 0, -r none, -r Do not reject records with NaN values

-r n, -r any Reject records if any value is NaN

Note: If no -r option is given -r sla is assumed

-f Do not start with time,lat,lon in output (only with --sel)

-s, --stat a|c|p Include statistics for all data (a), per cycle (c), or per pass (p)

--step N Step through records with stride N (default = 1)

--list FILENAME Specify file name in which to write list of output files

--maxrec NREC Specify maximum number of output records (default = unlimited)

-o, --output OUTNAME Specify name of a single output file or - for standard output or

(when ending in /) directory name for pass files; by default pass

files are created in the current directory

5.4.2 Common options

For a full explanation of the command line options that are common to most RADS4 programs,

see Section 5.2.

5.4.3 Program speciﬁc options

The command line options that are speciﬁc to rads2asc4 are listed here.

-r VAR --reject-on-nan VAR

Do not output records when the value of variable VAR, given as an argument to the -V

5.4 rads2asc4 23

or --VAR option, is set to NaN. By default records for which the sea level anomaly (if

requested) is set to NaN are rejected.

-r NR --reject-on-nan NR

For backward compatibility with RADS3, this will eliminate records when the value of

item number NR on the -V option is NaN.

-r 0 -r none -r

When either of these is used, no records are eliminated and all NaN values are kept.

-r n -r any

Indicates that a line should not be printed when a value in any of the data columns is NaN.

-f This only counts when using --sel instead of --var, in order to be backward compatible with

RADS3. When using--sel normally time, latitude and longitude are automatically added

as output columns. With -f those columns are not automatically added, i.e., you will have

to add them to the list of variables.

-s c|p

Include statistics per cycle (c) or pass (p). Those will by included in the output with lines

starting with ’# min :’, ’# max :’, ’# mean:’, and ’# std :’ followed by the cycle num-

ber, the number of valid passes in the cycle (c) or the pass number itself (p), the number

of valid records in that cycle (c) or pass (p), and then the statistics (minimum, maximum,

mean, and standard deviation) of each column.

--step N

Print only one out of Nrecords.

--list FILENAME

Specify the name of a ﬁle to which to write a list of the created output ﬁles.

--maxrec NREC

Specify the maximum number of output records. The default is unlimited.

-o OUTNAME --output OUTNAME

By default (without this option) ﬁles are created per pass with a name similar to the ones

in the data base, i.e., SSpPPPPcCCC.asc, where SS is the satellite abbreviation, PPPP is the

pass number, and CCC is the cycle number. This option will send the output to a single

named ﬁle, or to standard output when using -o -. Alternatively, when OUTNAME ends

in a slash, then it indicates the directory in which to store the pass ﬁles SSpPPPPcCCC.asc.

5.4.4 Example

Assuming a default conﬁguration, we issue the following command:

$ rads2asc4 -S e2 -C 0 -P 901,1000,2 -R -8,42,28,48 \

-V time_ymdhms,lat,lon,sla,swh,wind_speed -o rads2asc4.asc -v

The program will print to standard output information on which passes are available and

have valid data points in the requested area (Mediterranean Sea), how many records were

read and how many remained in the particular area, how many records were rejected based

on the selection criteria on the corrections, and ﬁnally some statistics on the columns that were

requested.

*******************************************************************************

Data selection for satellite ERS-2 phase a

x = pass has no data in period and area

24 RADS utilities

- = pass file does not exist

o = pass file has no valid data

# = pass file has valid data

Cycle Pass ....+....1....+....2....+....3....+....4....+....5....+....6....+....7....+....8....+....9....+....0

0 901 ------o##------------##------------##------------#

######################################################################################################################################

# Editing statistics for ERS-2 (e2)

# Created: 2018-05-30 09:34:09 UTC: rads2asc4 -S e2 -C 0 -P 901,1000,2 -V time_ymdhms,lat,lon,sla,swh,wind_speed -R -8,42,28,48 -o rads2asc4.out -v

# PASSES QUERIED 50

# REJECTED SELECTED LOWER UPPER STEP

# Cycle number limits 0 50 0 0 1

# Pass number limits 0 50 901 1000 2

# Time limits 0 50 NaN NaN

# Equator longitude limits (asc) 42 8 -3.440 57.004

# Equator longitude limits (des) 0 0 -23.004 37.440

# PASSES AND MEASUREMENTS READ 8 11517

# REJECTED SELECTED LOWER UPPER MIN MAX MEAN STDDEV

# time [seconds since 1985-01-01 00:00:00 0 11517 NaN NaN 950512/1843 950515/1932 950513/2310 91577.

# latitude [degrees_north] 10533 984 28.000 48.000 30.185 47.955 39.453 4.546

# longitude [degrees_east] 5435 6082 -8.000 42.000 -7.996 41.989 17.967 13.990

# MEASUREMENTS IN REQUESTED PERIOD AND REGION 851

# REJECTED SELECTED LOWER UPPER MIN MAX MEAN STDDEV

# sea level anomaly [m] 293 558 -3.000 3.000 -0.262 0.118 -0.083 0.078

# REAPER/COMBI orbital altitude [m] 0 851 NaN NaN 787721.981 791023.401 789246.395 846.239

# Ku-band range corrected for instr. effec 0 851 750000.000 850000.000 787647.826 791005.014 789215.301 843.813

# ECMWF dry tropospheric correction [m] 0 851 -2.400 -2.100 -2.331 -2.266 -2.305 0.016

# radiometer wet tropospheric correction [ 11 840 -0.600 0.000 -0.598 -0.031 -0.129 0.072

# NIC09 ionospheric correction [m] 0 851 -0.400 0.040 -0.025 -0.018 -0.022 0.002

# MOG2D dynamic atmospheric correction (ER 0 851 -1.000 1.000 -0.143 0.234 0.011 0.068

# solid earth tide [m] 0 851 -1.000 1.000 -0.108 0.084 -0.010 0.051

# FES2014b ocean tide [m] 0 851 -5.000 5.000 -1.590 0.764 -0.057 0.428

# FES2014a load tide [m] 0 851 -0.500 0.500 -0.018 0.044 0.010 0.011

# pole tide [m] 0 851 -0.100 0.100 -0.010 0.003 -0.004 0.004

# BM3 sea state bias [m] 6 845 -1.000 1.000 -0.857 0.473 -0.091 0.084

# DTU15 mean sea surface height [m] 0 851 NaN NaN 3.573 53.228 32.760 12.704

# Ku-band significant wave height [m] 16 835 0.000 8.000 0.000 7.960 1.487 1.046

# Ku-band backscatter coefficient [dB] 8 843 6.000 27.000 6.460 26.410 11.768 2.151

# altimeter wind speed [m/s] 2 849 -1.000 30.000 0.000 24.944 5.775 3.435

# std dev of Ku-band range [m] 66 785 0.000 0.400 0.022 0.398 0.146 0.051

# number of valid Ku-band measurements [1] 64 787 16.500 20.500 17.000 20.000 19.944 0.341

# flag word [count] 286 565 65512.000 0.000 0.000 0.000 0.000 0.000

# std dev of Ku-band significant wave heig 63 788 0.000 2.100 0.290 2.100 0.924 0.277

# off-nadir angle squared from waveform (s 0 851 -0.050 0.050 0.000 0.000 0.000 0.000

# reference frame offset [m] 0 851 NaN NaN 0.062 0.062 0.062 0.000

######################################################################################################################################

The resulting ASCII output ﬁle rads2asc4.asc will look like this:

# RADS_ASC

# Created: 2018-05-30 09:34:09 UTC: rads2asc4 -S e2 -C 0 -P 901,1000,2 -V time_ymdhms,lat,lon,sla,swh,wind_speed -R -8,42,28,48 -o rads2asc4.out -v

# Satellite = ERS-2

# Phase = a

# Cycle = 000

# Pass = 0915

# Equ_time = 326925796.651424 (1995-05-12 20:43:16.651424)

# Equ_lon = 26.724487

# Original = OPR V6 (0603) data of 1997-175T18:26:46 (ver.1)

# Col 1 = time [yymmddhhmmss]

# Col 2 = latitude [degrees_north]

# Col 3 = longitude [degrees_east]

# Col 4 = sea level anomaly [m]

# Col 5 = Ku-band significant wave height [m]

# Col 6 = altimeter wind speed [m/s]

950512205154.226807 30.661485 19.480321 -0.0916 0.120 1.737

950512205155.207275 30.719321 19.464490 -0.0562 0.000 1.815

950512205156.187500 30.777142 19.448650 -0.1665 0.330 1.616

950512205157.167969 30.834975 19.432791 -0.1600 0.560 1.858

............ lines removed ..............................

950515192036.179321 43.127032 39.342061 0.0097 1.260 4.894

950515192037.159790 43.184400 39.321693 0.0279 1.140 4.576

5.5 rads2grd4 25

950515192038.140259 43.241765 39.301295 0.0488 0.930 5.521

950515192039.120483 43.299112 39.280871 0.0415 0.870 5.821

5.5 rads2grd4

The program rads2grd4 is a quick-and-dirty gridding program for RADS data. No smoothing

or interpolation is performed. The data are simply collected in cells of predeﬁned size, after

which the mean and standard deviation in each cell is computed.

The boundaries of the grid are speciﬁed by the limits set in the RADS4 conﬁguration ﬁles, or

by the appropriate common command line arguments --limits, loptlat, or --lon. The cell size is

determined by the option --res. Alternatively, the options --x and --y can be used to set both

the range and interval along both coordinate axis of the grid. The use of grid-node oriented

or cell oriented boundaries is controlled by the --c option. The required minimum number of

measurements per cell can be speciﬁed with the --min option. Cells with a number of points

less than the required number will not be part of the output.

The grid program not only grids sea level anomaly in longitude-latitude space, but any data

ﬁeld in any other space speciﬁed by the -V (or --var) option. For example, a non-parametric

sea state bias model can be created by gridding the sea level anomalies in wind-wave space,

in which case -wind speed,swh,sla is used.

Multiple variables can be gridded simultaneously on the same space. When gridding several

variables at once, only records (measurements) for which every variable is valid (not NaN)

will be included in the gridding process.

There are two ways to produce output:

ASCII: Without the -o or --output option the program will write to standard output a ﬁle with

an ASCII header explaining the content, followed by one record for each grid cell with a

valid solution. Those records contain the x- and y-coordinate of the centre of the cell, and a

pair of mean and standard deviation for each z-variable. The right-most column contains

the number of points in the cell. This output can be used directly in GMT’s xyz2grd.

netCDF: With the -o or --output option a netCDF grid ﬁle is produced. This contains a grid

for the mean and standard deviation of each variable as well as a grid with the number of

points.

The output is a list of ASCII records per cell: xand yof the centre of the cell, mean of z,

standard deviation of z, number of points. Cells with a number of points less than the required

number are not listed. This output can be used directly in GMT.

This program can be called as rads2grd, or as rads2grd4 to avoid conﬂicts with an already

installed RADS3.

5.5.1 Syntax

rads2grd4 (4.3.0): Quickly grid RADS data to xyz or netCDF grid

Usage: rads2grd4 [required_arguments] [rads_dataselectors] [rads_options] [program_options]

Required argument is:

-S, --sat SAT[/PHASE] Specify satellite [and phase] (e.g. e1/g, tx)

Optional [rads_dataselectors] are:

-A, --alias VAR1=VAR2 Use variable VAR2 when VAR1 is requested

-C, --cycle C0[,C1[,DC]] Specify first and last cycle and modulo

26 RADS utilities

-F, --fmt, --format VAR=FMT

Specify Fortran format used to print VAR (for ASCII output only)

-L, --limits VAR=MIN,MAX Specify edit data range for variable VAR

--lon LON0,LON1 Specify longitude boundaries (deg)

--lat LAT0,LAT1 Specify latitude boundaries (deg)

-P, --pass P0[,P1[,DP]] Specify first and last pass and modulo; alternatively use -Pa

(--pass asc) or -Pd (--pass des) to restrict selection to

ascending or descending passes only

-Q, --quality-flag VAR=FLAG

Check variable FLAG when validating variable VAR

-R, --region LON0,LON1,LAT0,LAT1

Specify rectangular region (deg)

-R, --region LON0,LAT0,RADIUS

Specify circular region (deg)

--sla SLA0,SLA1 Specify range for SLA (m)

--time T0,T1 Specify time selection (optionally use --ymd, --doy,

or --sec for [YY]YYMMDD[HHMMSS], [YY]YYDDD, or SEC85)

-V, --var VAR1,... Select variables to be read

-X, --xml XMLFILE Load configuration file XMLFILE in addition to the defaults

-Z, --cmp, --compress VAR=TYPE[,SCALE[,OFFSET]]

Specify binary output format for variable VAR (netCDF only); TYPE

is one of: int1, int2, int4, real, dble; SCALE and OFFSET are

optional (def: 1,0)

Still working for backward compatibility with RADS3 are options:

--h H0,H1 Specify range for SLA (m) (now --sla H0,H1)

--opt J Use field number J when J/100 requested (now -A VAR1=VAR2)

--opt I=J Make field I (range 1-99) and alias for field J (now -A VAR1=VAR2)

--sel VAR1,... Select variables to read

Common [rads_options] are:

--args FILENAME Get all command line arguments from FILENAME (1 argument per line)

--debug LEVEL Set debug/verbosity level

--help Print this syntax massage

--log FILENAME Send statistics to FILENAME (default is standard output)

-q, --quiet Suppress warning messages (but keeps fatal error messages)

-v, --verbose Increase verbosity level

--version Print version info only

-- Terminates all options; all following command-line arguments are

considered non-option arguments, even if they begin with a hyphen

Program specific [program_options] are:

-V, --var X,Y,Z[,...] Variables for x, y and z (default: lon,lat,sla); multiple z’s may be specified

--x X0,X1[,DX] Set x-range and interval (default: as set by default limits and --res)

--y Y0,Y1[,DY] Set y-range and interval (default: as set by default limits and --res)

--res DX[,DY] Set resolution in x and y (default: 1)

--min MINNR Minimum number of points per grid cell (default: 2)

-o, --output, --grd GRIDNAME

Create netCDF grid (suppresses ASCII)

--line-format FORMAT Format to be used for ASCII output (default is determined by variables)

-c Boundaries are cell oriented

-c[x|y] Only [x|y]-boundaries are cell oriented

5.5.2 Common options

For a full explanation of the command line options that are common to most RADS4 programs,

see Section 5.2. Note that the -V and --var options have a slightly different meaning in this

program (see below) than in most others.

5.5.3 Program speciﬁc options

The command line options that are speciﬁc to rads2grd4 are listed here.

-V X,Y,Z[,...] --var X,Y,Z[,...]

Specify the variables for the ordinates Xand Y, and the variable to be gridded (Z). One can

specify one or more variables for Z; each will be part of the output.

--x X0,X1[,DX]

5.5 rads2grd4 27

Set the x-range and optional interval. The default range is determined by the limits set in

the RADS4 conﬁguration ﬁle. The interval can also be set with the --res option.

--x X0,X1[,DX]

Set the y-range and optional interval. The default range is determined by the limits set in

the RADS4 conﬁguration ﬁle. The interval can also be set with the --res option.

--res DX[,DY]

Set the resolution of the x- and y-coordinate. If only one number is given the same number

is used for both coordinates. The default resolution is 1×1.

--min MINNR

Specify the minimum number of points in the grid cell. The default is 2.

-o GRIDNAME --output GRIDNAME

Create a netCDF ﬁle with the name GRIDNAME containing the output grids. This sup-

presses the ASCII output. For backward compatibility with RADS3, one can also use --grd.

--line-format FORMAT

Format to be used for ASCII output. The default is determined by the speciﬁc Fortran

formats for each variable speciﬁed in the RADS4 conﬁguration ﬁle.

-c [x|y] Determines that the boundaries of the x-y space are cell-oriented, instead of grid-

oriented. When using -c x this applies only to the x-coordinate, when using -c y it applies

only to the y-coordinate. When using -c without argument, it applies to both coordinates.

5.5.4 Examples

Assuming a default conﬁguration, we issue the following command:

$ rads2grd4 -S e2 -C 0 -P 901,1000,2 -R -8,42,28,48 -V wind_speed,swh,sla -c

This command creates the following results to print to standard output:

# Grid of RADS variables

# Created: 2018-05-30 09:34:09 UTC: rads2grd4 -S e2 -C 0 -P 901,1000,2 -V wind_speed,swh,sla -c

# Satellite : e2/a

# Cycles : 0 - 0

# Passes : 901 - 1000

# Output columns per grid cell:

# ( 1) altimeter wind speed [m/s]

# ( 2) Ku-band significant wave height [m]

# ( 3- 4) mean and stddev of sea level anomaly [m]

# ( 5) nr of measurements

0.500 0.500 -0.0194 0.1099 463

1.500 0.500 -0.0404 0.1090 766

2.500 0.500 -0.0513 0.1100 938

3.500 0.500 -0.0472 0.0966 925

............ lines removed ..............................

15.500 7.500 -0.0270 0.1109 24

16.500 7.500 -0.0302 0.0917 47

17.500 7.500 0.0035 0.0817 73

18.500 7.500 -0.0320 0.0778 42

When we want to create a netCDF ﬁle as output, we use the -o option:

$ rads2grd4 -S e2 -C 0 -P 901,1000,2 -R -8,42,28,48 -V wind_speed,swh,sla -c \\

-o rads2grd4.nc

To list its contents, use the ncdump command. The result will look like the following:

netcdf rads2grd4-o {

dimensions:

28 RADS utilities

wind_speed = 31 ;

swh = 8 ;

variables:

double wind_speed(wind_speed) ;

wind_speed:long_name = "altimeter wind speed" ;

wind_speed:units = "m/s" ;

wind_speed:standard_name = "wind_speed" ;

wind_speed:axis = "X" ;

wind_speed:valid_min = -0.5 ;

wind_speed:valid_max = 29.5 ;

wind_speed:grid_step = 1. ;

double swh(swh) ;

swh:long_name = "Ku-band significant wave height" ;

swh:units = "m" ;

swh:standard_name = "sea_surface_wave_significant_height" ;

swh:axis = "Y" ;

swh:valid_min = 0.5 ;

swh:valid_max = 7.5 ;

swh:grid_step = 1. ;

float sla_mean(swh, wind_speed) ;

sla_mean:long_name = "mean of sea level anomaly" ;

sla_mean:units = "m" ;

sla_mean:_FillValue = NaNf ;

float sla_stddev(swh, wind_speed) ;

sla_stddev:long_name = "std dev of sea level anomaly" ;

sla_stddev:units = "m" ;

sla_stddev:_FillValue = NaNf ;

int nr(swh, wind_speed) ;

nr:long_name = "number of points per cell" ;

// global attributes:

:Conventions = "CF-1.7" ;

:title = "rads2grd4-o.out" ;

:history = "2018-05-30 09:34:10 UTC: rads2grd4 -S e2 -C 0 -P 901,1000,2 -V wind_speed,swh,sla -c -o rads2grd4-o.out" ;

:node_offset = 1 ;

data:

wind_speed = -0.5, 0.5, 1.5, 2.5, 3.5, 4.5, 5.5, 6.5, 7.5, 8.5, 9.5, 10.5,

11.5, 12.5, 13.5, 14.5, 15.5, 16.5, 17.5, 18.5, 19.5, 20.5, 21.5, 22.5,

23.5, 24.5, 25.5, 26.5, 27.5, 28.5, 29.5 ;

............ lines removed ..............................

0, 0, 0, 0, 0, 0, 4, 9, 4, 24, 22, 16, 22, 53, 75, 112, 75, 143, 100, 38,

0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,

0, 0, 0, 0, 0, 0, 0, 0, 0, 4, 1, 2, 9, 17, 20, 28, 24, 47, 73, 42, 1, 0, 0,

0, 0, 0, 0, 0, 0, 0, 0 ;

}

5.6 rads2nc

The RADS4 program rads2nc works similar to rads2asc4 (Section 5.4). Instead of writing out-

put to one or more ASCII ﬁles, it creates one or more netCDF ﬁles. This signiﬁcantly reduces

the output size, and can be convenient for reading into third-party programs.

By default, rads2nc will create pass-by-pass netCDF ﬁles, named SSpPPPPcCCC.nc, with only

the information of the netCDF variables given on the command line using the -V or --var

options. The variables are edited given the selection criteria in the RADS4 conﬁgurations ﬁles

or elsewhere on the command line. Values regarded ’invalid’ will be set to the _FillValue in

the netCDF ﬁles (or NaN in case of ﬂoating numbers). They will show up as an underscore (_)

in the output of ncdump.

The output can also be captured in a single netCDF ﬁle or in a different directory than the

current working directory. See the description of the option -o or --output below.

For more details, see the description of the command line options in the next Sections.

5.6 rads2nc 29

5.6.1 Syntax

rads2nc (4.3.0): Select RADS altimeter data and output to netCDF

Usage: rads2nc [required_arguments] [rads_dataselectors] [rads_options] [program_options]

Required argument is:

-S, --sat SAT[/PHASE] Specify satellite [and phase] (e.g. e1/g, tx)

Optional [rads_dataselectors] are:

-A, --alias VAR1=VAR2 Use variable VAR2 when VAR1 is requested

-C, --cycle C0[,C1[,DC]] Specify first and last cycle and modulo

-F, --fmt, --format VAR=FMT

Specify Fortran format used to print VAR (for ASCII output only)

-L, --limits VAR=MIN,MAX Specify edit data range for variable VAR

--lon LON0,LON1 Specify longitude boundaries (deg)

--lat LAT0,LAT1 Specify latitude boundaries (deg)

-P, --pass P0[,P1[,DP]] Specify first and last pass and modulo; alternatively use -Pa

(--pass asc) or -Pd (--pass des) to restrict selection to

ascending or descending passes only

-Q, --quality-flag VAR=FLAG

Check variable FLAG when validating variable VAR

-R, --region LON0,LON1,LAT0,LAT1

Specify rectangular region (deg)

-R, --region LON0,LAT0,RADIUS

Specify circular region (deg)

--sla SLA0,SLA1 Specify range for SLA (m)

--time T0,T1 Specify time selection (optionally use --ymd, --doy,

or --sec for [YY]YYMMDD[HHMMSS], [YY]YYDDD, or SEC85)

-V, --var VAR1,... Select variables to be read

-X, --xml XMLFILE Load configuration file XMLFILE in addition to the defaults

-Z, --cmp, --compress VAR=TYPE[,SCALE[,OFFSET]]

Specify binary output format for variable VAR (netCDF only); TYPE

is one of: int1, int2, int4, real, dble; SCALE and OFFSET are

optional (def: 1,0)

Still working for backward compatibility with RADS3 are options:

--h H0,H1 Specify range for SLA (m) (now --sla H0,H1)

--opt J Use field number J when J/100 requested (now -A VAR1=VAR2)

--opt I=J Make field I (range 1-99) and alias for field J (now -A VAR1=VAR2)

--sel VAR1,... Select variables to read

Common [rads_options] are:

--args FILENAME Get all command line arguments from FILENAME (1 argument per line)

--debug LEVEL Set debug/verbosity level

--help Print this syntax massage

--log FILENAME Send statistics to FILENAME (default is standard output)

-q, --quiet Suppress warning messages (but keeps fatal error messages)

-v, --verbose Increase verbosity level

--version Print version info only

-- Terminates all options; all following command-line arguments are

considered non-option arguments, even if they begin with a hyphen

Program specific [program_options] are:

-r, --reject-on-nan VAR Reject records if variable VAR on -V specifier is NaN

-r NR Reject records if data item number NR on -V specifier is NaN

-r 0, -r none, -r Do not reject records with NaN values

-r n, -r any Reject records if any value is NaN

Note: If no -r option is given -r sla is assumed

--step N Step through records with stride n (default: 1)

--maxrec NREC Specify maximum number of output records (default: unlimited)

-o, --output OUTNAME Specify name of a single output file or (when ending in /) directory

name for pass files; default is pass files in current directory

5.6.2 Common options

For a full explanation of the command line options that are common to most RADS4 programs,

see Section 5.2.

30 RADS utilities

5.6.3 Program speciﬁc options

The command line options that are speciﬁc to rads2nc are listed here. Notice that they have

some in common with rads2asc4 (Section 5.4).

-r VAR --reject-on-nan VAR

Do not output records when the value of variable VAR, given as an argument to the -V

or --VAR option, is set to NaN. By default records for which the sea level anomaly (if

requested) is set to NaN are rejected.

-r NR --reject-on-nan NR

For backward compatibility with RADS3, this will eliminate records when the value of

item number NR on the -V option is NaN.

-r 0 -r none -r

When either of these is used, no records are eliminated and all NaN values are kept.

-r n -r any

Indicates that a line should not be printed when any of the selected variables is NaN.

--step N

Print only one out of Nrecords.

--maxrec NREC

Specify the maximum number of output records. The default is unlimited.

-o OUTNAME --output OUTNAME

By default (without this option) ﬁles are created per pass with a name similar to the ones

in the data base, i.e., SSpPPPPcCCC.asc, where SS is the satellite abbreviation, PPPP is the

pass number, and CCC is the cycle number. This option will send the output to a single

named ﬁle. Alternatively, when OUTNAME ends in a slash, then it indicates the directory

in which to store the pass ﬁles SSpPPPPcCCC.nc.

5.6.4 Example

Assuming a default conﬁguration, we issue the following command:

$ rads2nc -S e2 -C 0 -P 901,1000,2 -R -8,42,28,48 \

-V time,lat,lon,sla,swh,wind_speed -o rads2nc.nc -v

Just as rads2asc4 the program rads2nc will now print to standard output information on

which passes are available and have valid data points in the requested area (Mediterranean

Sea), how many records were read and how many remained in the particular area, how many

records were rejected based on the selection criteria on the corrections, and ﬁnally some statis-

tics on the columns that were requested. At the same time a netCDF ﬁle rads2nc.nc will be

created. To list its contents, use the ncdump command. The result will look like the following:

netcdf rads2nc {

dimensions:

time = UNLIMITED ; // (558 currently)

variables:

double time(time) ;

time:long_name = "time" ;

time:standard_name = "time" ;

time:units = "seconds since 1985-01-01 00:00:00 UTC" ;

time:field = 101s ;

time:comment = "UTC time of measurement. Attribute leap_second gives time of leap second if any occurs during the data set" ;

int lat(time) ;

lat:_FillValue = 2147483647 ;

lat:long_name = "latitude" ;

lat:standard_name = "latitude" ;

5.7 radscolin4 31

lat:units = "degrees_north" ;

lat:scale_factor = 1.e-06 ;

lat:field = 201s ;

lat:comment = "Positive latitude is North latitude, negative latitude is South latitude" ;

int lon(time) ;

lon:_FillValue = 2147483647 ;

lon:long_name = "longitude" ;

lon:standard_name = "longitude" ;

lon:units = "degrees_east" ;

lon:scale_factor = 1.e-06 ;

lon:field = 301s ;

lon:comment = "East longitude relative to Greenwich meridian" ;

short sla(time) ;

sla:_FillValue = 32767s ;

sla:long_name = "sea level anomaly" ;

sla:standard_name = "sea_surface_height_above_sea_level" ;

sla:units = "m" ;

sla:quality_flag = "swh sig0 range_rms range_numval flags swh_rms attitude" ;

sla:scale_factor = 0.0001 ;

sla:coordinates = "lon lat" ;

sla:field = 0s ;

sla:comment = "Sea level determined from satellite altitude - range - all altimetric corrections" ;

short swh(time) ;

swh:_FillValue = 32767s ;

swh:long_name = "Ku-band significant wave height" ;

swh:standard_name = "sea_surface_wave_significant_height" ;

swh:units = "m" ;

swh:scale_factor = 0.001 ;

swh:coordinates = "lon lat" ;

swh:field = 17s ;

short wind_speed(time) ;

wind_speed:_FillValue = 32767s ;

wind_speed:long_name = "altimeter wind speed" ;

wind_speed:standard_name = "wind_speed" ;

wind_speed:source = "altimeter" ;

wind_speed:units = "m/s" ;

wind_speed:scale_factor = 0.01 ;

wind_speed:coordinates = "lon lat" ;

wind_speed:field = 19s ;

// global attributes:

:Conventions = "CF-1.7" ;

:title = "RADS 4 pass file" ;

:institution = "EUMETSAT / NOAA / TU Delft" ;

:source = "radar altimeter" ;

:references = "RADS Data Manual, Version 4.2 or later" ;

:featureType = "trajectory" ;

:ellipsoid = "TOPEX" ;

:ellipsoid_axis = 6378136.3 ;

:ellipsoid_flattening = 0.00335281317789691 ;

:filename = "rads2nc.out" ;

:mission_name = "ERS-2" ;

:mission_phase = "a" ;

:log01 = "2018-05-30 | rads2nc -S e2 -C 0 -P 901,1000,2 -V time,lat,lon,sla,swh,wind_speed -R -8,42,28,48 -o rads2nc.out -v: RAW data from" ;

:history = "2018-05-30 09:34:09 : rads2nc -S e2 -C 0 -P 901,1000,2 -V time,lat,lon,sla,swh,wind_speed -R -8,42,28,48 -o rads2nc.out -v" ;

data:

time = 326926314.226853, 326926315.207322, 326926316.187547,

326926317.168015, 326926318.148484, 326926319.128953, 326926320.109178,

............ lines removed ..............................

1129, 1169, 1147, 1155, 1158, 1180, 1162, 1133, 1133, 1066, 1043, 1028,

987, 957, 546, 555, 526, 529, 564, 565, 574, 611, 615, 634, 618, 644,

634, 614, 595, 605, 595, 624, 621, 604, 611, 634, 637, 633, 610, 643,

647, 624, 585, 579, 558, 489, 458, 552, 582 ;

}

5.7 radscolin4

The program radscolin4 creates collinear tracks (in a rather straightforward way). No smooth-

ing or interpolation is performed. The data are “gridded” based on their time with respect to

the equator passages. The measurements are simply collected in bins of predeﬁned length. By

default this is the 1-Hz sampling rate of the speciﬁc mission), but it can be altered with the --dt

32 RADS utilities

option. Then the data falling in those bins for each speciﬁed pass are output in a way similar

to rads2asc4 (Section 5.4) or rads2nc (Section 5.6). No averaging or differencing is performed.

This program can also be used to compute differences between two different altimeter mis-

sions (with --diff,--diff-no-coord, or --diff1), as long as they are collinear. Some variance to the

strict collinearity is allowed when using the -f or --force option. See Section 5.3 for more info

on using the command line when multiple missions are involved.

The program will output only those bins in which valid sea level anomalies can be found for

all speciﬁed repeat cycles, unless the -r option is used. This behaviour of -r is signiﬁcantly

different from rads2asc4 and rads2nc. See the syntax description below.

The output is one record for each bin, containing the variables selected by the -V or --var

option, for each of the speciﬁed cycles. The output can be either ASCII (the default) or netCDF

(with the -o or --output) option. In the case of ASCII, normally only the passes with some valid

data are output. Using the option -k or --keep keeps all passes, irrespectively.

This program can be called as radscolin, or as rads2colin4 to avoid conﬂicts with an already

installed RADS3.

5.7.1 Syntax

radscolin4 (4.3.0): Make collinear data sets from RADS

Usage: radscolin4 [required_arguments] [rads_dataselectors] [rads_options] [program_options]

Required argument is:

-S, --sat SAT[/PHASE] Specify satellite [and phase] (e.g. e1/g, tx)

Optional [rads_dataselectors] are:

-A, --alias VAR1=VAR2 Use variable VAR2 when VAR1 is requested

-C, --cycle C0[,C1[,DC]] Specify first and last cycle and modulo

-F, --fmt, --format VAR=FMT

Specify Fortran format used to print VAR (for ASCII output only)

-L, --limits VAR=MIN,MAX Specify edit data range for variable VAR

--lon LON0,LON1 Specify longitude boundaries (deg)

--lat LAT0,LAT1 Specify latitude boundaries (deg)

-P, --pass P0[,P1[,DP]] Specify first and last pass and modulo; alternatively use -Pa

(--pass asc) or -Pd (--pass des) to restrict selection to

ascending or descending passes only

-Q, --quality-flag VAR=FLAG

Check variable FLAG when validating variable VAR

-R, --region LON0,LON1,LAT0,LAT1

Specify rectangular region (deg)

-R, --region LON0,LAT0,RADIUS

Specify circular region (deg)

--sla SLA0,SLA1 Specify range for SLA (m)

--time T0,T1 Specify time selection (optionally use --ymd, --doy,

or --sec for [YY]YYMMDD[HHMMSS], [YY]YYDDD, or SEC85)

-V, --var VAR1,... Select variables to be read

-X, --xml XMLFILE Load configuration file XMLFILE in addition to the defaults

-Z, --cmp, --compress VAR=TYPE[,SCALE[,OFFSET]]

Specify binary output format for variable VAR (netCDF only); TYPE

is one of: int1, int2, int4, real, dble; SCALE and OFFSET are

optional (def: 1,0)

Still working for backward compatibility with RADS3 are options:

--h H0,H1 Specify range for SLA (m) (now --sla H0,H1)

--opt J Use field number J when J/100 requested (now -A VAR1=VAR2)

--opt I=J Make field I (range 1-99) and alias for field J (now -A VAR1=VAR2)

--sel VAR1,... Select variables to read

Common [rads_options] are:

--args FILENAME Get all command line arguments from FILENAME (1 argument per line)

--debug LEVEL Set debug/verbosity level

--help Print this syntax massage

--log FILENAME Send statistics to FILENAME (default is standard output)

-q, --quiet Suppress warning messages (but keeps fatal error messages)

-v, --verbose Increase verbosity level

--version Print version info only

5.7 radscolin4 33

-- Terminates all options; all following command-line arguments are

considered non-option arguments, even if they begin with a hyphen

Program specific [program_options] are:

--dt DT Set minimum bin size in seconds (default is determined by satellite)

--step N Write out only one out of N bins along track

-r, --reject-on-nan VAR Base rejection criteria (below) on VAR; default is ’sla’ or 1st on -V

-r NR Reject stacked data when fewer than NR tracks with valid values

-r 0, -r none, -r Keep all stacked data points, even NaN

-r n, -r any Reject stacked data when data on any track is NaN (default)

Note: If no -r option is given, -r any is assumed

-k, --keep Keep all passes, even those that do not have data in the selected area

-a, --mean Output mean in addition to pass data

-s, --stddev Output standard deviation in addition to pass data

-l, --minmax Output minimum and maximum in addition to pass data

-d, --no-pass Do not output pass data

-t, --no-track Do not print along-track data (ascii output only)

-c, --cumul Output cumulative statistics (ascii output only) (implies --keep)

--diff Compute difference between first and second half of selected passes

(implies --keep)

--diff-no-coord Same as --diff, but excluding coordinates from computing difference

--diff1 Same as --diff-no-coord, writing one cycle at a time, chronologically

(cannot be combined with -o, -a, -s, or -l)

-f, --force Force comparison, even when missions are not considered collinear

-o, --output [FILENAME] Create netCDF output by pass (default is ascii output to stdout).

Optionally specify FILENAME including "#", to be replaced by the pass

number. Default is "radscolin_p#.nc"

5.7.2 Common options

For a full explanation of the command line options that are common to most RADS4 programs,

see Section 5.2.

5.7.3 Program speciﬁc options

The command line options that are speciﬁc to radscolin4 are listed here. Notice that the -r

option is somewhat different than that of rads2asc4 (Section 5.4) and rads2nc (Section 5.6).

--dt DT Set the minimum bin size in seconds. The default is the maximum 1-Hz sampling

rate of the missions selected.

--step NWrite out only one out of N bins along track.

-r VAR --reject-on-nan VAR

Base the count of “valid passes” on variable whether VAR is not NaN. By default radscolin4

looks for the validity of the variable sla, if used in the list of variables on the -V option. If

sla is not used, the ﬁrst variable is checked for validity.

-r NR

Reject stacked data when there are fewer than NR tracks with valid values. Which variable

is used to determine “valid” is explained above.

-r 0 -r none -r

When either of these is used, keep the stacked data in the output, even when they are NaN.

-r n -r any

Reject stacked data when data on any track is NaN. This is the default behaviour.

-k --keep

Keep all the passes in the output, even those that do not have any valid data in the selected

area. By default, passes without any valid values are removed from the output.

-a --mean

Output the mean value in each stacked bin in addition to the values in each collinear pass.

34 RADS utilities

-s --stddev

Output the standard deviation in each stacked bin in addition to the values in each collinear

pass.

-l --minmax

Output the minimum and maximum in each stacked bin in addition to the values in each

collinear pass.

-d --no-pass

Do not output the values in each individual collinear pass.

-t --no-track

Do not print the along-track data (applies to ASCII output only).

-c --cumul

Print cumulative statistics (applies to ASCII output only).

--diff

Compute the difference between the ﬁrst and the second half of the selected passes. This

is practical when computing the difference between two missions. It implies --keep.

--diff-no-coord

This is the same as --diff, except that the coordinates (time, latitude and longitude) are not

differenced, instead the ﬁrst value is produced.

--diff1

This is the same as --diff-no-coord, except that in ascii printouts passes are printed chrono-

logically, one cycle at a time, instead of the usual multiple columns for passes. This cannot

be used in combination with statistics options (-a,-s, or -l)

-f --force

Force collinear track comparison, even when missions are not strictly considered collinear.

-o [FILENAME] --output [FILENAME]

Create netCDF output ﬁles per pass. The default is ASCII output to standard output. Op-

tionally specify a FILENAME including the hash character (’#’), which will be replaced by

the pass number. The default netCDF output ﬁle name is radscolin_p#.nc.

5.7.4 Examples

Assuming a default conﬁguration, we issue the following command:

$ radscolin -S e2 -C 0,2 -P 915,1000,2 -R -8,42,28,48 -V lat,sla,swh

This command creates to following results to print to standard output:

# RADS collinear track file

# Created: 2018-05-30 09:34:09 UTC: radscolin4 -S e2 -C 0,2 -P 915,1000,2 -R -8,42,28,48 -V lat,sla,swh

# Pass = 0915

# Satellite = e2 e2 e2

# Cycles = 000 001 002

# Column ranges for each variable:

# 1 - 3 : latitude [degrees_north]

# 4 - 6 : sea level anomaly [m]

# 7 - 9 : Ku-band significant wave height [m]

# 10 : number of measurements

# 11 : record number

30.661485 30.649574 30.691639 -0.0916 -0.0201 -0.0127 0.120 0.640 0.840 3 528

30.719321 30.707412 30.749460 -0.0562 -0.0840 -0.0171 0.000 0.880 0.760 3 529

30.777142 30.765233 30.807295 -0.1665 -0.0813 -0.0544 0.330 0.760 0.890 3 530

30.834975 30.823067 30.865128 -0.1600 -0.0550 -0.0619 0.560 0.560 0.960 3 531

5.7 radscolin4 35

............ lines removed ..............................

43.299112 43.263665 43.286058 0.0415 0.0760 -0.0004 0.870 0.520 0.410 3 747

# 42.368730 42.333236 42.355645 -0.0130 0.0414 -0.0176 1.022 0.362 0.840 0 999 # avg

# 0.572197 0.572222 0.572209 0.0494 0.0385 0.0713 0.264 0.192 0.505 0 999 # std

# 33 33 33 33 33 33 33 33 33 0 999 # nr

To illustrate the impact of the -r option, we also present here the result of the following com-

mand:

$ radscolin -S e2 -C 0,2 -P 915,1000,2 -R -8,42,28,48 -V lat,sla,swh -r

# RADS collinear track file

# Created: 2018-05-30 09:34:10 UTC: radscolin4 -S e2 -C 0,2 -P 915,1000,2 -R -8,42,28,48 -V lat,sla,swh -r

# Pass = 0915

# Satellite = e2 e2 e2

# Cycles = 000 001 002

# Column ranges for each variable:

# 1 - 3 : latitude [degrees_north]

# 4 - 6 : sea level anomaly [m]

# 7 - 9 : Ku-band significant wave height [m]

# 10 : number of measurements

# 11 : record number

30.185412 NaN 30.215553 NaN NaN NaN 3.740 NaN 6.140 2 520

NaN 30.418223 30.459773 NaN NaN NaN NaN NaN 1.680 2 524

30.487462 30.476067 30.518135 NaN NaN NaN 0.770 0.480 0.960 3 525

30.545822 30.533894 30.575961 NaN NaN NaN 0.700 0.770 1.060 3 526

............ lines removed ..............................

NaN 47.161520 NaN NaN NaN NaN NaN 0.250 NaN 1 815

# 42.323495 42.345405 42.355645 -0.0143 0.0431 -0.0176 1.026 0.368 0.840 0 999 # avg

# 0.588227 0.588225 0.572209 0.0487 0.0381 0.0713 0.271 0.198 0.505 0 999 # std

# 35 35 33 35 35 33 35 35 33 0 999 # nr

Chapter 6

RADS library

6.1 Module rads

6.1.1 rads

SUMMARY:

RADS main module

SYNOPSIS:

module rads

use typesizes

use rads_grid, only: grid

!*Parameters

! Dimensions

integer(fourbyteint), parameter :: rads_var_chunk = 100, rads_varl = 40, &

rads_naml = 160, rads_cmdl = 320, rads_strl = 1600, rads_hstl = 3200, &

rads_cyclistl = 50, rads_optl = 50, rads_max_branches = 5

! RADS4 data types

integer(fourbyteint), parameter :: rads_type_other = 0, rads_type_sla = 1, &

rads_type_flagmasks = 2, rads_type_flagvalues = 3, rads_type_time = 11, &

rads_type_lat = 12, rads_type_lon = 13, rads_type_dim = 14

! RADS4 data sources

integer(fourbyteint), parameter :: rads_src_none = 0, rads_src_nc_var = 10, &

rads_src_nc_att = 11, rads_src_math = 20, rads_src_grid_lininter = 30, &

rads_src_grid_splinter = 31, rads_src_grid_query = 32, &

rads_src_constant = 40, rads_src_flags = 50, rads_src_tpj = 60

! RADS4 warnings

integer(fourbyteint), parameter :: rads_warn_nc_file = -3

! RADS4 errors

integer(fourbyteint), parameter :: rads_noerr = 0, &

rads_err_nc_file = 1, rads_err_nc_parse = 2, rads_err_nc_close = 3, rads_err_memory = 4, &

rads_err_var = 5, rads_err_source = 6, rads_err_nc_var = 7, rads_err_nc_get = 8, &

rads_err_xml_parse = 9, rads_err_xml_file = 10, rads_err_alias = 11, rads_err_math = 12, &

rads_err_cycle = 13, rads_err_nc_create = 14, rads_err_nc_put = 15

! Additional RADS4 helpers

character(len=1), parameter :: rads_linefeed = char(10), rads_tab = char(9), rads_noedit = ’_’

! RADS3 errors or incompatibilities

integer(fourbyteint), parameter :: rads_err_incompat = 101, rads_err_noinit = 102

integer(twobyteint), parameter :: rads_nofield = -1

! Math constants

real(eightbytereal), parameter :: pi = 3.1415926535897932d0, rad = pi/180d0

! I/O parameters

integer, parameter :: stderr = 0, stdin = 5, stdout = 6

!*Variables

! I/O variables

integer(fourbyteint), save :: rads_verbose = 0 ! Verbosity level

integer(fourbyteint), save :: rads_log_unit = stdout ! Unit number for statistics logging

!*RADS4 variable structures

type :: rads_varinfo ! Information on variable used by RADS

6.1 Module rads 37

character(len=rads_varl) :: name ! Short name of variable used by RADS

character(len=rads_naml) :: long_name ! Long name (description) of variable

character(len=rads_naml) :: standard_name ! Optional CF ’standard’ name (’’ if none)

character(len=rads_naml) :: source ! Optional data source (’’ if none)

character(len=rads_naml) :: parameters ! Optional link to model parameters (’’ if none)

character(len=rads_strl) :: dataname ! Name associated with data (e.g. netCDF var name)

character(len=rads_cmdl) :: flag_meanings ! Optional meaning of flag values (’’ if none)

character(len=rads_cmdl) :: quality_flag ! Quality flag(s) associated with var (’’ if none)

character(len=rads_cmdl) :: comment ! Optional comment (’’ if none)

character(len=rads_varl) :: units ! Optional units of variable (’’ if none)

character(len=rads_varl) :: format ! Fortran format for output

character(len=rads_varl) :: gridx, gridy ! RADS variable names of the grid x and y coords

type(grid), pointer :: grid ! Pointer to grid (if data source is grid)

real(eightbytereal) :: default ! Optional default value (Inf if not set)

real(eightbytereal) :: limits(2) ! Lower and upper limit for editing

real(eightbytereal) :: plot_range(2) ! Suggested range for plotting

real(eightbytereal) :: add_offset, scale_factor ! Offset and scale factor in case of netCDF

real(eightbytereal) :: xmin, xmax, mean, sum2 ! Minimum, maximum, mean, sum squared deviation

logical :: boz_format ! Format starts with B, O or Z.

integer(fourbyteint) :: ndims ! Number of dimensions of variable

integer(fourbyteint) :: brid ! Branch ID (default 1)

integer(fourbyteint) :: nctype, varid ! netCDF data type (nf90_int, etc.) and var ID

integer(fourbyteint) :: datatype ! Type of data (one of rads_type_*)

integer(fourbyteint) :: datasrc ! Retrieval source (one of rads_src_*)

integer(fourbyteint) :: cycle, pass ! Last processed cycle and pass

integer(fourbyteint) :: selected, rejected ! Number of selected or rejected measurements

endtype

type :: rads_var ! Information on variable or alias

character(len=rads_varl), pointer :: name ! Pointer to short name of variable (or alias)

character(len=rads_naml), pointer :: long_name ! Pointer to long name (description) of variable

type(rads_varinfo), pointer :: info, inf1, inf2 ! Links to structs of type(rads_varinfo)

logical(twobyteint) :: noedit ! .true. if editing is suspended

integer(twobyteint) :: field(2) ! RADS3 field numbers (rads_nofield = none)

endtype

type :: rads_cyclist ! List of cycles

integer(fourbyteint) :: n, i ! Number of elements in list, additional value

integer(fourbyteint) :: list(rads_cyclistl) ! List of values

endtype

type :: rads_phase ! Information about altimeter mission phase

character(len=rads_varl) :: name, mission ! Name (1-letter), and mission description

integer(fourbyteint) :: cycles(2), passes ! Cycle range and maximum number of passes

real(eightbytereal) :: start_time, end_time ! Start time and end time of this phase

real(eightbytereal) :: ref_time, ref_lon ! Time and lon of equator crossing of "ref. pass"

integer(fourbyteint) :: ref_cycle, ref_pass ! Cycle and pass number of "reference pass"

integer(fourbyteint) :: ref_orbit ! Absolute orbit nr of "reference pass" (at eq.)

real(eightbytereal) :: pass_seconds ! Length of pass in seconds

real(eightbytereal) :: repeat_days ! Length of repeat period in days

real(eightbytereal) :: repeat_shift ! Eastward shift of track pattern for near repeats

integer(fourbyteint) :: repeat_nodal ! Length of repeat period in nodal days

integer(fourbyteint) :: repeat_passes ! Number of passes per repeat period

type(rads_cyclist), pointer :: subcycles ! Subcycle definition (if requested)

endtype

type :: rads_sat ! Information on altimeter mission

character(len=rads_naml) :: userroot ! Root directory of current user (i.e. $HOME)

character(len=rads_naml) :: dataroot ! Root directory of RADS data (i.e. $RADSDATAROOT)

character(len=rads_varl) :: branch(rads_max_branches) ! Name of optional branches

character(len=rads_varl) :: spec ! Temporary holding space for satellite specs

character(len=rads_cmdl) :: command ! Command line

character(len=rads_naml), pointer :: glob_att(:) ! Global attributes

character(len=8) :: satellite ! Satellite name

real(eightbytereal) :: dt1hz ! "1 Hz" sampling interval

real(eightbytereal) :: frequency(2) ! Frequency (GHz) of primary and secondary channel

real(eightbytereal) :: inclination ! Satellite inclination (deg)

real(eightbytereal) :: eqlonlim(0:1,2) ! Equator lon limits for asc. and desc. passes

real(eightbytereal) :: centroid(3) ! Lon, lat, distance (in rad) selection criteria

real(eightbytereal) :: xover_params(2) ! Crossover parameters used in radsxoconv

integer(fourbyteint) :: cycles(3),passes(3) ! Cycle and pass limits and steps

integer(fourbyteint) :: error ! Error code (positive = fatal, negative = warning)

integer(fourbyteint) :: pass_stat(7) ! Stats of rejection at start of rads_open_pass

integer(fourbyteint) :: total_read, total_inside ! Total nr of measurements read and inside region

integer(fourbyteint) :: nvar, nsel ! Nr of available and selected vars and aliases

logical :: n_hz_output ! Produce multi-Hz output

character(len=2) :: sat ! 2-Letter satellite abbreviation

integer(twobyteint) :: satid ! Numerical satellite identifier

38 RADS library

type(rads_cyclist), pointer :: excl_cycles ! Excluded cycles (if requested)

type(rads_var), pointer :: var(:) ! List of available variables and aliases

type(rads_var), pointer :: sel(:) ! List of selected variables and aliases

type(rads_var), pointer :: time, lat, lon ! Pointers to time, lat, lon variables

type(rads_phase), pointer :: phases(:) ! Definitions of all mission phases

type(rads_phase), pointer :: phase ! Pointer to current phase

endtype

type :: rads_file ! Information on RADS data file

integer(fourbyteint) :: ncid ! NetCDF ID of pass file

character(len=rads_cmdl) :: name ! Name of the netCDF pass file

endtype

type :: rads_pass ! Pass structure

character(len=rads_strl) :: original ! Name of the original (GDR) pass file(s)

character(len=rads_hstl), pointer :: history ! File creation history

real(eightbytereal) :: equator_time, equator_lon ! Equator time and longitude

real(eightbytereal) :: start_time, end_time ! Start and end time of pass

real(eightbytereal), pointer :: tll(:,:) ! Time, lat, lon matrix

integer(twobyteint), pointer :: flags(:) ! Array of engineering flags

logical :: rw ! NetCDF file opened for read/write

integer(fourbyteint) :: cycle, pass ! Cycle and pass number

integer(fourbyteint) :: nlogs ! Number of RADS3 log entries

integer(fourbyteint) :: ndata ! Number of data points (1-Hz)

integer(fourbyteint) :: n_hz, n_wvf ! Size second/third dimension (0=none)

integer(fourbyteint) :: first_meas, last_meas ! Index of first and last point in region

integer(fourbyteint) :: time_dims ! Dimensions of time/lat/lon stored

integer(fourbyteint) :: trkid ! Numerical track identifiers

type (rads_file) :: fileinfo(rads_max_branches) ! File information for pass files

type (rads_sat), pointer :: S ! Pointer to satellite/mission structure

type (rads_pass), pointer :: next ! Pointer to next pass in linked list

endtype

type :: rads_option ! Information on command line options

character(len=rads_varl) :: opt ! Option (without the - or --)

character(len=rads_cmdl) :: arg ! Option argument

integer :: id ! Identifier in form 10*nsat + i

endtype

! These command line options can be accessed by RADS programs

type(rads_option), allocatable, target, save :: &

rads_opt(:) ! List of command line options

integer(fourbyteint), save :: rads_nopt = 0 ! Number of command line options saved

PURPOSE:

This module provides the main functionalities for the RADS4 software.

To use any of the following subroutines and functions, add the following

line in your Fortran 90 (or later) code:

use rads

See LICENSE.TXT file for copying and redistribution conditions.

This program is free software: you can redistribute it and/or modify

it under the terms of the GNU Lesser General Public License as

published by the Free Software Foundation, either version 3 of the

License, or (at your option) any later version.

This program is distributed in the hope that it will be useful,

but WITHOUT ANY WARRANTY; without even the implied warranty of

MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the

GNU Lesser General Public License for more details.

6.1.2 rads init

SUMMARY:

Initialize RADS4

SYNTAX:

6.1 Module rads 39

subroutine rads_init (S, sat, xml)

type(rads_sat), intent(inout) :: S <or> S(:)

character(len=*), intent(in), optional :: sat <or> sat(:)

character(len=*), intent(in), optional :: xml(:)

PURPOSE:

This routine initializes the <S> struct with the information pertaining

to given satellite/mission phase <sat>, which is to be formed as ’e1’,

or ’e1g’, or ’e1/g’. If no phase is specified, all mission phases will be

queried.

The <S> and <sat> arguments can either a single element or an array. In the

latter case, one <S> struct will be initialized for each <sat>.

To parse command line options after this, use rads_parse_cmd.

Only if the <sat> argument is omitted, then the routine will parse

the command line for arguments in the form:

--sat=<sat> --cycle=<lo>,<hi>,<step> --pass=<lo>,<hi>,<step>

--lim:<var>=<lo>,<hi> --lat=<lo>,<hi> --lon=<lo>,<hi> --alias:<var>=<var>

--opt:<value>=<value> --opt=<value>,... --fmt:<var>=<value>

or their equivalents without the = or : separators after the long name,

or their equivalents without the initial --, or the short options -S, -C,

-P, -L, -F

The routine will read the satellite/mission specific setup XML files and

store all the information in the stuct <S>. The XML files polled are:

$RADSDATAROOT/conf/rads.xml

˜/.rads/rads.xml

rads.xml

<xml> (from the optional array of file names)

If more than one -S option is given, then all further options following

this argument until the next -S option, plus all options prior to the

first -S option will pertain to this mission.

Execution will be halted when the dimension of <S> is insufficient to

store information of multiple missions, or when required XML files are

missing.

The verbosity level can be controlled by setting rads_verbose before

calling this routine (default = 0). The output unit for log info can

be controlled by setting rads_log_unit up front (default = stdout).

ARGUMENTS:

S : Satellite/mission dependent structure

sat : (optional) Satellite/mission abbreviation

xml : (optional) Array of names of additional XML files to be loaded

6.1.3 rads end

SUMMARY:

End RADS4

SYNTAX:

subroutine rads_end (S)

type(rads_sat), intent(inout) :: S <or> S(:)

PURPOSE:

This routine ends RADS by freeing up all <S> space and other allocated

global arrays.

ARGUMENT:

S : Satellite/mission dependent struct or array of structs

40 RADS library

6.1.4 rads get var

SUMMARY:

Read variable (data) from RADS4 file

SYNTAX:

recursive subroutine rads_get_var (S, P, var, data, noedit)

type(rads_sat), intent(inout) :: S

type(rads_pass), intent(inout) :: P

character(len=*) :: var

<or> integer(fourbyteint) :: var

<or> type(rads_var), intent(in) :: var

real(eightbytereal), intent(out) :: data(:)

logical, intent(in), optional :: noedit

PURPOSE:

This routine loads the data from a single variable <var> into the

buffer <data>. This command must be preceeded by <rads_open_pass>.

The variable <var> can be addressed as a variable name, a RADS3-type

field number or a varlist item.

The array <data> must be at the correct size to contain the entire

pass of data, i.e., it must have the dimension P%ndata.

If no data are available and no default value and no secondary aliases

then NaN is returned in the array <data>.

ARGUMENTS:

S : Satellite/mission dependent structure

P : Pass dependent structure

var : (string) Name of the variable to be read.

If <var> ends with % editing is skipped.

(integer) Field number.

(type(rads_var)) Variable struct (e.g. S%sel(i))

data : Data returned by this routine

noedit : (optional) Set to .true. to skip editing on limits and/or

quality flags; set to .false. to allow editing (default)

ERROR CODE:

S%error : rads_noerr, rads_err_var, rads_err_memory, rads_err_source

6.1.5 rads stat

SUMMARY:

Print the RADS statistics for a given satellite

SYNTAX:

subroutine rads_stat (S)

type(rads_sat), intent(in) :: S <or> S(:)

integer(fourbyteint), intent(in), optional :: unit

PURPOSE:

This routine prints out the statistics of all variables that were

processed per mission (indicated by scalar or array <S>), to the output

on unit <rads_log_unit>.

ARGUMENTS:

S : Satellite/mission dependent structure

6.1 Module rads 41

6.1.6 rads init sat struct

SUMMARY:

Initialize empty rads_sat struct

SYNOPSIS:

subroutine rads_init_sat_struct (S)

type(rads_sat), intent(inout) :: S

PURPOSE:

This routine initializes the <S> struct with the bare minimum.

It is later updated in rads_init_sat_0d.

ARGUMENTS:

S : Satellite/mission dependent structure

6.1.7 rads init pass struct

SUMMARY:

Initialize empty rads_pass struct

SYNOPSIS:

subroutine rads_init_pass_struct (S, P)

type(rads_sat), target, intent(in) :: S

type(rads_pass), intent(inout) :: P

PURPOSE:

This routine initializes the struct with the bare minimum.

This is only really necessary prior to calling rads_create_pass.

ARGUMENTS:

S : Satellite/mission dependent structure

P : Pass dependent structure

6.1.8 rads set options

SUMMARY:

Specify the list of command specific options

SYNPOSIS

PURPOSE:

Add the command specific options to the list of common RADS options.

The argument <optlist> needs to have the same format as in the routine

<getopt> in the <rads_misc> module. The short options will be placed

before the common ones, the long options will be placed after them.

ARGUMENT:

optlist : (optional) list of command specific short and long options

42 RADS library

6.1.9 rads open pass

SUMMARY:

Open RADS pass file

SYNOPSIS:

subroutine rads_open_pass (S, P, cycle, pass, rw)

use netcdf

use rads_netcdf

use rads_time

use rads_misc

use rads_geo

type(rads_sat), intent(inout) :: S

type(rads_pass), intent(inout) :: P

integer(fourbyteint), intent(in) :: cycle, pass

logical, intent(in), optional :: rw

PURPOSE:

This routine opens a netCDF file for access to the RADS machinery.

However, prior to opening the file, three tests are performed to speed

up data selection:

(1) All passes outside the preset cycle and pass limits are rejected.

(2) Based on the time of the reference pass, the length of the repeat

cycle and the number of passes per cycle, a rough estimate is

made of the temporal extent of the pass. If this is outside the

selected time window, then the pass is rejected.

(3) Based on the equator longitude and the pass number of the reference

pass, the length of the repeat cycle and the number of passes in

the repeat cycle, an estimate is made of the equator longitude of

the current pass. If this is outside the limits set in S%eqlonlim

then the pass is rejected.

If the pass is rejected based on the above critetia or when no netCDF

file exists, S%error returns the warning value rads_warn_nc_file.

If the file cannot be read properly, rads_err_nc_parse is returned.

Also, in both cases, P%ndata will be set to zero.

By default the file is opened for reading only. Specify perm=nf90_write to

open for reading and writing.

The file opened with this routine should be closed by using rads_close_pass.

ARGUMENTS:

S : Satellite/mission dependent structure

P : Pass structure

cycle : Cycle number

pass : Pass number

rw : (optional) Set read/write permission (def: read only)

ERROR CODE:

S%error : rads_noerr, rads_warn_nc_file, rads_err_nc_parse

6.1.10 rads close pass

SUMMARY:

Close RADS pass file

SYNOPSIS:

subroutine rads_close_pass (S, P, keep)

use netcdf

use rads_netcdf

type(rads_sat), intent(inout) :: S

type(rads_pass), intent(inout) :: P

logical, intent(in), optional :: keep

6.1 Module rads 43

PURPOSE:

This routine closes a netCDF file previously opened by rads_open_pass.

The routine will reset the ncid element of the structure to

indicate that the passfile is closed.

If <keep> is set to .true., then the history, flags, time, lat, and lon

elements the structure are kept. I.e., they are not deallocated

but only their links are removed. Otherwise, they are deallocated along

with the log entries.

A second call to rads_close_pass without the keep argment can subsequently

deallocate the time, lat and lon elements of the structure.

ARGUMENTS:

S : Satellite/mission dependent structure

P : Pass structure

keep : Keep the P%tll matrix (destroy by default)

ERROR CODE:

S%error : rads_noerr, rads_err_nc_close

6.1.11 rads read xml

SUMMARY:

Read RADS4 XML file

SYNOPSIS:

subroutine rads_read_xml (S, filename)

use netcdf

use xmlparse

use rads_time

use rads_misc

type(rads_sat), intent(inout) :: S

character(len=*), intent(in) :: filename

PURPOSE:

This routine parses a RADS4 XML file and fills the <S> struct with

information pertaining to the given satellite and all variable info

encountered in that file.

The execution terminates on any error, and also on any warning if

fatal = .true.

ARGUMENTS:

S : Satellite/mission dependent structure

filename : XML file name

fatal : If .true., then all warnings are fatal.

ERROR CODE:

S%error : rads_noerr, rads_err_xml_parse, rads_err_xml_file

6.1.12 rads set alias

SUMMARY:

Set alias to an already defined variable

SYNOPSIS:

subroutine rads_set_alias (S, alias, varname, field)

44 RADS library

use rads_misc

type(rads_sat), intent(inout) :: S

character(len=*), intent(in) :: alias, varname

integer(twobyteint), intent(in), optional :: field(2)

PURPOSE:

This routine defines an alias to an existing variable, or up to three

variables. When more than one variable is given as target, they will

be addressed one after the other.

If alias is already defined as an alias or variable, it will be overruled.

The alias will need to point to an already existing variable or alias.

Up to three variables can be specified, separated by spaces or commas.

ARGUMENTS:

S : Satellite/mission dependent structure

alias : New alias for (an) existing variable(s)

varname : Existing variable name(s)

field : (optional) new field numbers to associate with alias

ERROR CODE:

S%error : rads_noerr, rads_err_alias, rads_err_var

6.1.13 rads set limits

SUMMARY:

Set limits on given variable

SYNOPSIS:

subroutine rads_set_limits (S, varname, lo, hi, string, iostat)

use rads_misc

type(rads_sat), intent(inout) :: S

character(len=*), intent(in) :: varname

real(eightbytereal), intent(in), optional :: lo, hi

character(len=*), intent(in), optional :: string

integer(fourbyteint), intent(out), optional :: iostat

PURPOSE:

This routine set the lower and upper limits for a given variable in

RADS.

The limits can either be set by giving the lower and upper limits

as double floats <lo> and <hi> or as a character string <string> which

contains the two numbers separated by whitespace, a comma or a slash.

In case only one number is given, only the lower or higher bound

(following the separator) is set, the other value is left unchanged.

ARGUMENTS:

S : Satellite/mission dependent structure

varname : Variable name

lo, hi : Lower and upper limit

string : String of up to two values, with separating whitespace

or comma or slash.

iostat : (optional) iostat code from reading string

ERROR CODE:

S%error : rads_noerr, rads_err_var

6.1.14 rads set region

SUMMARY:

6.1 Module rads 45

Set latitude/longitude limits or distance to point

SYNOPSIS:

subroutine rads_set_region (S, string)

use rads_misc

type(rads_sat), intent(inout) :: S

character(len=*), intent(in) :: string

PURPOSE:

This routine set the region for data selection (after the -R option).

The region can either be specified as a box by four values "W/E/S/N",

or as a circular region by three values "E/N/radius". Separators

can be commas, slashes, or whitespace.

In case of a circular region, longitude and latitude limits are set

accordingly for a rectangular box surrounding the circle. However, when

reading pass data, the distance to the centroid is used as well to

edit out data.

ARGUMENTS:

S : Satellite/mission dependent structure

string : String of three or four values with separating whitespace.

For rectangular region: W/E/S/N.

For circular region: E/N/radius (radius in degrees).

ERROR CODE:

S%error : rads_noerr, rads_err_var

6.1.15 rads set format

SUMMARY:

Set print format for ASCII output of given variable

SYNOPSIS:

subroutine rads_set_format (S, varname, format)

type(rads_sat), intent(inout) :: S

character(len=*), intent(in) :: varname, format

PURPOSE:

This routine set the FORTRAN format specifier of output of a given

variable in RADS.

ARGUMENTS:

S : Satellite/mission dependent structure

varname : Variable name

format : FORTRAN format specifier (e.g. ’f10.3’)

ERROR CODE:

S%error : rads_noerr, rads_err_var

6.1.16 rads predict equator

SUMMARY:

Predict equator crossing time and longitude

46 RADS library

SYNOPSIS:

subroutine rads_predict_equator (S, P, cycle, pass)

type(rads_sat), intent(in) :: S

type(rads_pass), intent(inout) :: P

integer(fourbyteint), intent(in) :: cycle, pass

PURPOSE:

This routine estimates the equator time and longitude, as well

as the start and end time of a given <cycle> and <pass>.

The routine works for exact repeat orbits as well as drifting

orbits.

The estimated variables (equator_time, equator_lon, start_time, end_time)

are returned in the pass struct .

ARGUMENTS:

S : Satellite/mission dependent structure

P : Pass structure

cycle : Cycle number

pass : Pass number

Bibliography

Francis, C. R. (1990), The ERS-1 radar altimeter, paper presented at the 2nd ERS-1 PI meeting,

Noordwijk,The Netherlands.

Francis, C. R., et al. (1995), The ERS-2 spacecraft and its payload, ESA Bulletin,83, 13–31.

Francis, C. R., et al. (1991), The ERS-1 spacecraft and its payload, ESA Bulletin,65, 26–48.

Fu, L.-L., E. J. Christensen, C. A. Yamarone, M. Lefebvre, Y. M´

enard, M. Dorrer, and P. Escudier

(1994), TOPEX mission overview, J. Geophys. Res.,99(C12), 24,369–24,382.

Lambin, J., et al. (2010), The OSTM/Jason-2 mission, Mar. Geod.,33(S1), 4–25, doi:10.1080/

01490419.2010.491030.

M´

enard, Y., L.-L. Fu, P. Escudier, B. J. Haines, G. Kunstmann, F. Parisot, J. Perbos, P. Vincent,

and S. D. Desai (2003), The Jason-1 mission, J. Mar. Geod.,Jason-1.

Wingham, D. J., et al. (2006), CryoSat: A mission to determine the ﬂuctuations in Earth’s land

and marine ice ﬁelds, Adv. Space Res.,37(4), 841–871, doi:10.1016/j.asr.2005.07.027.

Index

conﬁguration

alias, 11

comment, 11

compress, 12, 19

cycles, 13

data, iii, 12, 14

dimension, 12

dt1hz, 13

else, 10

elseif, 10

flag_mask, 11

flag_values, 11

format, 12

frequency, 13

global_attributes, 11

if, 10

inclination, 13

limits, 11, 18

long_name, 11

mission, 13

parameters, 12

phase, 13

plot_range, 12

quality_flag, 12, 18

ref_pass, 13

repeat, 13

satellite, 13

satellites, 11

satid, 13

source, 11

standard_name, 11

start_time, 13

units, 11

var, iii, 11–13

xover_params, 13

directories

/rads/data, 7

/usr/local, 5

/usr/local/bin, 9

bin, 5

devel, 5

include, 5

lib, 5

share, 5

src, 5

ﬁles

$HOME/.rads/rads.xml, 19

$RADSDATAROOT/conf/rads.xml, 19

conﬁg.mk, 6

libnetcdf, 3, 5

libnetcdff, 3, 5

netcdf.mod, 3, 5

OUTNAME, 21

rads.xml, 10, 13, 19

rads2asc4.asc, 24

rads2nc.nc, 30

radsstat.nc, 16

functions

rads close pass, 42

rads end, 39

rads get var, 40

rads init, 38

rads open pass, 42

rads predict equator, 45

rads read xml, 43

rads set alias, 43

rads set format, 45

rads set limits, 44

rads set options, 41

rads set region, 44

rads stat, 40

Generics

rads init pass struct, 41

rads init sat struct, 41

modules

rads, 36

Index 49

options, long

--, 16, 20

--VAR, 23, 30

--alias, 17, 19–21

--args, 20

--cmp, 19

--compress, 19

--cumul, 34

--cycle, 17

--debug, 20

--diff, 32, 34

--diff-no-coord, 32, 34

--diff1, 32, 34

--doy, 19

--dt, 31, 33

--fmt, 18

--force, 32, 34

--format, 18

--grd, 27

--help, 15, 20

--keep, 32–34

--lat, 18

--limits, 18, 19, 25

--line-format, 27

--list, 23

--log, 20

--lon, 18, 25

--maxrec, 23, 30

--mean, 33

--min, 25, 27

--minmax, 34

--mjd, 19

--no-pass, 34

--no-track, 34

--opt, 19, 20

--output, 21, 23, 25, 27, 28, 30, 32, 34

--pass, 18

--quality-ﬂag, 18

--quiet, 20

--region, 18

--reject-on-nan, 22, 23, 30, 33

--res, 25, 27

--sat, 18, 20, 21

--sec, 19

--sel, 20, 23

--sla, 19

--stddev, 34

--step, 23, 30, 33

--time, 19

--var, 19–21, 23, 25, 26, 28, 32

--verbose, 17, 20

--version, 20

--x, 25–27

--xml, 19, 21

--y, 25

--ymd, 19

options, short

--c, 25

-A, 17, 21

-C, 17

-F, 18

-L, 18

-P, 18

-Q, 18

-R, 18

-S, 16, 18, 20, 21

-V, 19, 21–23, 25, 26, 28, 30, 32, 33

-X, 19, 21

-Z, 19

-a, 33, 34

-c, 27, 34

-d, 34

-f, 23, 32, 34

-h, 19

-k, 32, 33

-l, 16, 34

-o, 16, 21, 23, 25, 27, 28, 30, 32, 34

-q, 20

-r, 21–23, 30, 32, 33, 35

-s, 23, 34

-t, 34

-v, 16, 17, 20

-wind speed,swh,sla, 25

programs

bash, 8

conﬁgure, 4–6, 9

f90, 3

f95, 3

gfortran, 3

git, iii, 3, 4

GitHub, 3

github, 3

GMT, 2, 19

ifort, 3

make, 3

ncdump, 27, 28, 30

nco, 2

nf-conﬁg, 5

rads2asc, 21

rads2asc4, 21, 22, 28, 30, 32, 33

50 Index

rads2colin4, 32

rads2grd, 25

rads2grd4, 25, 26

rads2nc, 28, 30, 32, 33

radscolin, 32

radscolin4, 31, 33

radsstat4, 15–17

radsvar, 12

radsxogen, 13, 21

rsync, 3, 7, 8

sh, 8

ssh, 7

xlf90, 3

xlf95, 3

xyz2grd, 25

variables

sla, 17, 33

wet tropo, 17

wet tropo ecmwf, 17

Rads4 User Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
