Roadmaster Active Suspension
2018 APPLICATION GUIDE
VEHICLE MAKE / MODEL YEAR 2 Wheel Drive 4 Wheel Drive
CHEVROLET / GMC
I T E M #M O D E L R E F #I T E M #M O D E L R E F #
COLORADO / CANYON PICKUP 2004 - 12 4527-T MK4 - XCEFT 4527-T MK4 - XCEFT
COLORADO / CANYON PICKUP 2015 - 18 4617 MK4 - XXCF 4617 MK4 - XXCF
1500, 2500 & 3500 CARGO VAN 1986 - 18 2611-V MK2 - XXVF
1500, 2500 & 3500 PASSENGER VAN 1986 - 06 2611-V MK2 - XXVF
1500, 2500 & 3500 PASSENGER VAN 2007 - 18 2613-M MK2 - XXVM
S-10 / SONOMA PICKUP 1984 - 04 4527-T MK4 - XCEFT 4527-T MK4 - XCEFT
1500 SILVERADO / SIERRA 1973 - 89 4611-T MK4 - XXFT 4611-T MK4 - XXFT
1500 SILVERADO / SIERRA 1990 - 18 4611 MK4 - XXF 4611 MK4 - XXF
2500 & 3500 SILVERADO / SIERRA 1973 - 10 4611 MK4 - XXF 4611 MK4 - XXF
2500 & 3500 SILVERADO / SIERRA 2011 - 18 3611 MK3 - XXF 3611 MK3 - XXF
3500 SILVERADO / SIERRA DUALLY 1973 - 18 SEE "CHEVY/GMC XXX ULTRA-HD" NEXT PAGE
3500 DUALLY CAB & CHASSIS ALL YEARS SEE "CHEVY/GMC XXX ULTRA-HD" NEXT PAGE
1500 SUBURBAN SUV 1984 - 99 4611 MK4 - XXF 4611 MK4 - XXF
2500 SUBURBAN SUV 1984 - 12 4611 MK4 - XXF 4611 MK4 - XXF
TAHOE /YUKON SUV 1995 - 98 4611-T MK4 - XXFT 4611-T MK4 - XXFT
TAHOE /YUKON SUV 1999 ONLY 4614-T MK4 - XXDT 4614-T MK4 - XXDT
DODGE
DAKOTA PICKUP 1992 - 04 4529 MK4 - XEDJ 4514 MK4 - XD
DAKOTA PICKUP 2005 - 11 4514 MK4 - XD 4514 MK4 - XD
D100 / 1500 RAM PICKUP 1973 - 01 4614 MK4 - XXD 4614 MK4 - XXD
1500 RAM PICKUP 2002 - 08 4618-H MK4 - XXDDH 4618-H MK4 - XXDDH
W/ SPECIAL NOTE: ONLY FITS 2 1/2” wide leaf springs
MK3 - XXD2500 / 3500 RAM PICKUP
W/ SPECIAL NOTE:
1973 - 02 3614 MK3 - XXD 3614
CAN'T FIT with an overload spring above the leaf spring pack
2500 / 3500 RAM PICKUP 2003 - 14 3610 MK3 - XXR 3610 MK3 - XXR
W/ SPECIAL NOTES: FITS 3” wide leaf springs with shackles that swing from the TOP DOWN ONLY
CAN’T FIT with an overload spring above the leaf spring pack
2003 - 14 3613-T MK3 - XXGT 3613-T MK3 - XXGT2500 RAM PICKUP
3500 RAM PICKUP 2003 - 18 3613-T MK3 - XXGT 3613-T MK3 - XXGT
W/ SPECIAL NOTES: FITS 3” wide leaf springs with shackles that swing from the BOTTOM UP ONLY
CAN’T FIT with an overload spring above the leaf spring pack
1500 RAM CARGO & PASSENGER VAN 1992 - 97 4612-DV MK4 - XXFFDV
1500 RAM CARGO & PASSENGER VAN 1998 - 04 4611-DV MK4 - XXFDV
2500 & 3500 RAM CARGO & PASSENGER VAN 1992 - 97 4612-DV MK4 - XXFFDV
2500 & 3500 RAM CARGO & PASSENGER VAN 1998 - 04 4611-DV MK4 - XXFDV
SPRINTER VAN - 2500 & 3500 2004 - 06 3620-E MK3 - XXERTE w/ Single Leaf Spring & 70 mm Eye
SPRINTER VAN - 2500 ONLY 2007 - 18 3620 MK3 - XXERT w/ Single Leaf Spring
FORD
2015 - 18 3623-T MK3 - XXEGT
1973 - 12 2516 MK2 - XB 2516 MK2 - XB
E150 & E250 CARGO & PASSENGER VAN 1973 - 07 3612 MK3 - XXFF
E350 CARGO & PASSENGER VAN 1973 - 07 3611 MK3 - XXF
E150, E250 & E350 PASSENGER VAN 2008 - 18 2613-E MK2 - XXFFE
E150, E250 & E350 CARGO VAN 2008 - 18 2612 MK2 - XXFF
EXCURSION SUV 1999 - 05 3621 MK3 - XXEF 3621 MK3 - XXEF
EXPLORER SUV 1991 - 01 3526 MK3 - XEB 3526 MK3 - XEB
EXPLORER “SPORT” SUV (ONLY) 2002 - 05 3526 MK3 - XEB 3526 MK3 - XEB
EXPLORER SPORT TRAC 2000 - 05 3526 MK3 - XEB 3526 MK3 - XEB
F100 / F150 PICKUP 1973 - 02 4612 MK4 - XXFF 4622 MK4 - XXEFF
F150 PICKUP 2003 - 08 3612 MK3 - XXFF 3612 MK3 - XXFF
F150 PICKUP 2009 - 14 3611 MK3 - XXF 3611-Y MK3 - XXY
F150 PICKUP 2015 - 18 3611-B MK3 - XXFB 3611-Y MK3 - XXY
F150 SVT RAPTOR PICKUP 2010 - 14 2691 MK2 - XXSF
F150 SVT RAPTOR PICKUP 2015 - 18 3611 MK3 - XXF
F250, F350 PICKUP
1973 - 10 SEE “FORD - XXX ULTRA-HD” - NEXT PAGE
F250, F350 PICKUP
2011 - 18 3611-S MK3 - XXS 3611-S MK3 - XXS
F250, F350 PICKUP W/OVERLOAD SPRING ABOVE*
2011 - 18 SEE “FORD - XXX ULTRA-HD” - NEXT PAGE
RAS Model Listings continued next page
Page 1 ~Roadmaster Active Suspension Model Listing ~ ISSUE DATE: 03/20/2018
TRANSIT VAN 150, 250* & 350*
RANGER PICKUP
I T E M # M O D E L R E F # I T E M # M O D E L R E F #
NISSAN / TOYOTA
TITAN PICKUP 2004 - 183611 MK3 - XXF 3611 MK3 - XXF
XTERRA XE SUV 1999 - 04 4521-T MK4 - XEFT 4521-T MK4 - XEFT
XTERRA XE SUV 2005 - 184529-XT MK4 - XEDJT 4529-XT MK4 - XEDJT
TACOMA 1986 - 04 4521-ST MK4 - XEFST 4511-T MK4 - XFT
TACOMA 2005 - 184524-SAT MK4 - XEDSAT
with axle above leaf springs 4514-SAT MK4 - XDSAT
with axle below leaf springs
PRE-RUNNER PICKUP 1998 - 184514-SAT MK4 - XDSAT
4514-SAT MK4 - XDSAT
with axle below leaf springs with axle below leaf springs
T-100 PICKUP
TUNDRA PICKUP 2007 - 184618-AT MK4 - XXDDHAT4618-AT MK4 - XXDDHAT
Call toll free:1-800-398-5036
e-mail: sales@activesuspension.com
For product info and video’s visit us on-line @ Activesuspension.com
VEHICLE MAKE / MODEL YEAR 2 Wheel Drive 4 Wheel Drive
Page 2 ~
Roadmaster Active Suspension Model Listing ~ ISSUE DATE: 03/20/2018
IT IS RECOMMENDED NOT TO LOAD ANY VEHICLE BEYOND THE MANUFACTURER'S MAXIMUM GVWR
TUNDRA PICKUP 1999 - 06 4611 MK4 - XXF 4611 MK4 - XXF
**To Place an Order
**If you don't see your vehicle listed
**To check if we have a different spring rating for your application
WHAT SPRING RATING DOES MY KIT USE
X-SPRING
XX-SPRING
XXX-SPRING
*Some Applications can use multiple Spring Ratings*
Spring Rating is listed on MODEL REF #
ex- MK4-XD / MK3-XXS / MK3-XXXSHD
Light Duty Towing/Load
Medium Duty Towing/Load
HEAVY Duty Towing/Load
SPRING SIZE USED FOR Popular Applications
Tacoma*, Ranger, S10, Sonoma, Colorado, Canyon
F150,Chevy/GMC1500, F250*, Tundra, Tocoma*
F250*,F350, Ram3500, Chevy/GMC2500*& 3500
1973 - 18 3611-HD 3611-HD
CHEVY / GMC - XXX ULTRA-HD
2500 & 3500 SERIES PICKUP
1973 - 10 3611-HD MK3 - XXXF-HD 3611-HD MK3 - XXXF-HD
2009 - 10 3611-LHD MK3 - XXXL-HD 3611-LHD MK3 - XXXL-HD
2011 - 18 3611-SHD MK3 - XXXS-HD 3611-SHD MK3 - XXXS-HD
2011 - 18 3611-SLHD MK3 - XXXSL-HD 3611-SLHD MK3 - XXXSL-HD
2011 - 18 3611-SLHD MK3 - XXXSL-HD 3611-SLHD MK3 - XXXSL-HD
DODGE - XXX ULTRA-HD
2500 / 3500 RAM PICKUP 1973 - 02 3614-HD MK3 - XXXD-HD 3614-HD
2003 - 14 3610-HD MK3 - XXXR-HD 3610-HD
MK3 - XXXD-HD
W/ SPECIAL NOTE:
2500 / 3500 RAM PICKUP
W/ SPECIAL NOTE:
FITS 3” wide leaf springs with shackles that swing from the BOTTOPM UP ONLY
CAN’T FIT WITH OVERLOAD SPRING ABOVE THE LEAF SPRING PACK
2003 - 18 3613-THD MK3 - XXXGT-HD 3613-THD MK3 - XXXGT-HD
2500 / 3500 RAM PICKUP
W/ SPECIAL NOTE:
XXX ULTRA HEAVY-DUTY
Kits listed below are to be used on vehicles that carry heavy load.
2500 & 3500 SERIES PICKUP w/Overload Spring
FORD - XXX ULTRA-HD
1973 - 18 3611-CHD
MK3 - XXXF-HD
MK3 - XXXC-HD 3611-CHD
MK3 - XXXF-HD
MK3 - XXXC-HD
2015 - 18 3623-THD 3623-THD
MK3 - XXXEGT-HD
F250, F350 PICKUP
F250, F350 PICKUP
w/Overload Spring
F250, F350 PICKUP
F250, F350 PICKUP
w/Overload Spring
F350 DUALLY PICKUP
w/Overload Spring
TRANSIT VAN 250/350
EXCURSION SUV
1999 - 05 3621-HD
MK3 - XXXEGTHD
MK3 - XXXEF-HD 3621-HD MK3 - XXXEF-HD
MK3 - XXXR-HD
CAN’T FIT WITH OVERLOAD SPRING ABOVE THE LEAF SPRING PACK
CAN’T FIT WITH OVERLOAD SPRING ABOVE THE LEAF SPRING PACK
**Give Us A Call**
The information contained herein is based on current known O.E.M. product changes and therefore renders all previously issued Application Guides null and void.
