Roadway Illumination and

Electrical Supplies

Material Producer List

Traffic Operations Division – Traffic Engineering Section

Material Producer List – Roadway Illumination and

Electrical Supplies

2

January 26, 2018

Table of Contents

Materials Pre-qualified for Illumination and Electrical items 610-687

No additional submittals are required for products that are pre-qualified

Page

Item 610 – Roadway Illumination Assemblies………………………………………………… 4

Item 613 – High Mast Illumination Poles…………………………………………………….…. 17

Item 614 – High Mast Illumination Assemblies…..………………………………………….. 18

Item 618 – Conduit………………………………………………………………………………………. 22

Item 620 – Electrical Conductors………………………………………………………………….. 28

(Includes breakaway connectors)

Item 621 – Tray Cable………………………………………………………………………………….. 33

Item 622 – Duct Cable………………………………………………………………………….……… 35

Item 624 – Ground Boxes………………………………………………………….……………..….. 37

Item 628 – Electrical Services……………………………………………………………….……… 43

Item 685 – Roadside Flashing Beacon Assemblies –

Single Pole Breakaway Connectors ……………………………………………………….......... 47

Item 687 – Pedestal Pole Assemblies ……………………………………….…………….…... 50

Click on any Item above to go directly to that page

For more information about these materials, contact the Traffic Operations Division,

Engineering Operations Branch at (512) 416-3232.

Notice:

All submittal and corresponding documentation becomes public information.

All manufacturers’ products that are listed within this document are pre-qualified.

Manufacturer name change does not change the pre-qualified status of the original

material. TxDOT reserves the right to remove any manufacturer or product from this list, at

any time. Manufacturers interested in being added to the pre-qualified list should contact

Traffic Operations Division.

Material Producer List – Roadway Illumination and

Electrical Supplies

3

January 26, 2018

Item 610 – Roadway Illumination Assemblies

General

Roadway Illumination Poles do not need to be pre-qualified when TxDOT RIP (Roadway

Illumination Pole) standard sheets are included in the plan set.

Construction

Perform work in accordance with the details shown on the plans, and the requirements of

Item 610 and applicable Special Provisions to Item 610.

Fabricate steel roadway illumination poles in accordance with TxDOT standards RIP

(Roadway Illumination Pole). Poles fabricated according to RIP standard sheets require no

shop drawings.

Alternate designs to RIP or the use of aluminum to fabricate poles will require the

submission of shop drawings electronically.

For instructions on the requirements and procedures of shop drawings go to:

http://www.txdot.gov/business/resources/specifications/shop-drawings.html.

Click on “Requirements and Procedures for Optional and Non-Standard Illumination Pole

Designs and Shop Drawings.”

Material Producer List – Roadway Illumination and

Electrical Supplies

4

January 26, 2018

Item 610 – Roadway Illumination Assemblies

General

The following products are pre-qualified for use on the projects where roadway

illumination assemblies are furnished or installed as required by the item descriptive

code. Fixtures are subject to testing. No substitutions of products will be allowed when

pre-qualified products are shown. Where miscellaneous parts, brackets, hardware,

nuts, bolts, washers, or other incidentals are necessary and are not shown as pre-

qualified products, the contractor shall furnish products that meet the requirements of

the plans and specifications.

Item 610 - Roadway Illumination Assemblies – Underpass Fixture

Manufacturer

Brand

Type

Model

Energy Plus Lighting

1465 FM 2673

Canyon Lake, TX 78133

(830) 964-2357

energypluslight.com

UDP

SERIES

♦ Induction Fluorescent

Underpass Fixture

♦ UDP-165-QL-GR

Kenall Lighting

1020 Lakeside Dr.

Gurnee, IL 60031

(800) 453-6255

kenall.com

KENALL

♦ Induction Fluorescent

Underpass Fixture –

Steel Housing

♦ Induction Fluorescent

Underpass Fixture –

Aluminum Housing

♦ Box Beam Bracket to

Mount Fixture

♦ Bridge Deck Bracket

to Mount Fixture

♦ U-Beam Bracket

♦ TS2020-3/3-1-150IND-277V-R-

SSPH-TEXAS

♦ TS2020-*/*-150IND-*Volt-8-SSPH-

TDOT-ALUMINUM

♦ Ask for BB Bracket When Required

– Sold Separately

♦ Ask for BD Bracket When

Required – Sold Separately

♦ Ask for UB Bracket When Required

– Sold Separately

ESCO Lighting

3254 N. Kilborn Ave.

Chicago, IL 60641

(773) 427-7000

escolighting.com

ESCO

♦ Induction Fluorescent

Underpass Fixture

♦ SP2343

Material Producer List – Roadway Illumination and

Electrical Supplies

5

January 26, 2018

Item 610 - Roadway Illumination Assemblies – Underpass Fixture

Manufacturer

Brand

Type

Model

H.E. Williams

831 W. Fairview Ave.

P.O. Box 837

Carthage, MO 64836

(417) 358-4065

hew.com

Infinity

♦ Induction Fluorescent

Underpass Fixture

♦ BB Box Beam

♦ BD Bridge Deck

♦ UB U-Beam

♦ ICERL1-150S-41K-BAT/CG1-GRA-

UNV

♦ ICERL3-150S-41K-BAT/CG1-GRA-

UNV

♦ ICERL5-150S-41K-BAT/CG1-

14DEG-UNV

Eaton (formerly Cooper)

1121 Highway 74 South

Peachtree City, GA 30269

(770) 486-4800

cooperindustries.com

Fail-Safe

♦ Induction Fluorescent

Underpass Fixture

♦ TF28-150ICE-UNV-A1432

Material Producer List – Roadway Illumination and

Electrical Supplies

6

January 26, 2018

Item 610 - Roadway Illumination Assemblies – Luminaire

Manufacturer

Brand

Type

Model

Eaton (formerly Cooper)

1121 Highway 74 South

Peachtree City, GA 30269

(770) 486-4800

cooperindustries.com

Streetworks

♦ 150W HPS- 240/480

Volt

♦ 250W HPS- 120/240

Volt

♦ 250W HPS- 240/480

Volt

♦ 400W HPS- 120/240

Volt

♦ 400W HPS- 240/480

Volt

♦ OVW15SMJ3DD0004

♦ OVW25SMG2DD0001

♦ OVW25SMJ2DD0002

♦ OVW40SMG2DD0005

♦ OVW40SMJ2DD0003

G.E. Lighting Systems, Inc.

3010 Spartanburg Highway

Henderson, NC 28793

(800) 305-1372

gelightingsystems.com

M4RC

♦ 150W HPS- 240/480

Volt

♦ 250W HPS- 120/240

Volt

♦ 250W HPS- 240/480

Volt

♦ 400W HPS- 120/240

Volt

♦ 400W HPS- 240/480

Volt

♦ M4RC15S9M4GMC3312

or GE Manufacture #180055

♦ M4RC25S7M4GSC2311 or GE

Manufacture #168025

♦ M4RC25S9M4GSC2311 or GE

Manufacture #168023

♦ M4RC40S7M4GSC3311 or GE

Manufacture #157785

♦ M4RC40S9M4GSC3311 or GE

Manufacture #158165

Holophane

3825 Columbus Road SW

Granville, OH 43023

(740) 587-4030

FAX (866) 761-9819

holophane.com

Mongoose

♦ 250W HPS- 120 Volt

♦ 250W HPS- 240 Volt

♦ 250W HPS- 480 Volt

♦ 400W HPS- 120Volt

♦ 400W HPS- 240Volt

♦ 400W HPS- 480 Volt

♦ G25RHP12LNRHGBR-TXDOT

♦ G25RHP24LNRHGBR-TXDOT

♦ G25RHP48LNRHGBR-TXDOT

♦ G40RHP12LNRHGBR-TXDOT

♦ G40RHP24LNRHGBR-TXDOT

♦ G40RHP48LNRHGBR-TXDOT

Material Producer List – Roadway Illumination and

Electrical Supplies

7

January 26, 2018

Item 610 - Roadway Illumination Assemblies – LED Luminaire

Manufacturer

Brand

Type

Model

TraStar

860 N. Dorothy Drive #600

Richardson, TX 75081

(972) 480-0888

trastarusa.com

Duralight

♦ 150W EQ LED –

(66W)-120/240 Volt;

LLF=0.86

♦ 150W EQ LED -

(66W)- 480 Volt;

LLF=0.86

♦ 250W EQ LED

(120W)- 120/240 Volt;

LLF=0.86

♦ 250W EQ LED

(120W)- 480 Volt;

LLF=0.86

♦ 400W EQ LED

(185W)- 120/240 Volt;

LLF=0.86

♦ 400W EQ LED

(185W)- 480 Volt;

LLF=0.86

♦ 150W EQ LED (70W)-

120/240 Volt;

LLF=0.86

♦ 150W EQ LED (70W)-

480 Volt; LLF=0.86

♦ 250W EQ LED

(135W)- 120/240 Volt;

LLF=0.86

♦ 250W EQ LED

(135W)- 480 Volt;

LLF=0.86

♦ 400W EQ LED

(205W)- 120/240 Volt;

LLF=0.86

♦ 400W EQ LED

(205W)- 480 Volt;

LLF=0.86

♦ DURA-ST15-4K-120-3-GR-SCLB

♦ DURA-ST15-4K-120-3-GR-SCLB

♦ DURA-ST25-4K-120-2-GR-SCLB

♦ DURA-ST25-4K-480-2-GR-SCLB

♦ DURA-ST40-4K-120-2-GR-SCLB

♦ DURA-ST40-4K-480-2-GR-SCLB

♦ JXM-ST140-3-40K-120-3-GR-

SCLBTX

♦ JXM-STI40-3-40K-480-3-GR-SCLBTX

♦ JXM-ST180-3-40K-120-2-GR-

SCLBTX

♦ JXM-STI80-3-40K-480-2-GR-SCLBTX

♦ JXM-ST180-4-40K-120-2-GR-

SCLBTX

♦ JXM-ST180-4-40K-480-2-GR-

SCLBTX

Material Producer List – Roadway Illumination and

Electrical Supplies

8

January 26, 2018

Item 610 - Roadway Illumination Assemblies – LED Luminaire

Manufacturer

Brand

Type

Model

Eaton (formerly Cooper)

1121 Highway 74 South

Peachtree City, GA 30269

(770) 486-4800

cooperindustries.com

Streetworks

♦ 150W EQ LED (72W)-

120/240 VOLT

LLF=0.86

♦ 150W EQ LED (72W)-

480 VOLT LLF=0.86

♦ 250W EQ LED

(143W)-120/240 VOLT

LLF=0.816

♦ 250W EQ LED

(154W)-480 VOLT

LLF=0.816

♦ 400W EQ LED

(180W)- 120/240 Volt;

LLF=0.81

♦ 400W EQ LED

(180W)- 480 Volt;

LLF=0.81

♦ 150W EQ LED-

120/240 Volt;

LLF=0.86

♦ 150W EQ LED- 480

Volt; LLF=0.86

♦ 250W EQ LED-

120/240 Volt;

LLF=0.86

♦ 250W EQ LED- 480

Volt; LLF=0.86

♦ 400W EQ LED-

120/240 Volt;

LLF=0.86

♦ 400W EQ LED- 480

Volt; LLF=0.86

♦ 400W EQ LED-

120/240 Volt;

LLF=0.85

♦ 400W EQ LED- 480

Volt; LLF=0.85

♦ VERD-A028-D-U-T3-4N7-20K-AP-

TXDOT-D0077

♦ VERD-A028-D-8-T3-4N7-20K-AP-

TXDOT-D0078

♦ VERD-G-A02-D-U-T2-4N7-20K-AP-

TXDOT-D0027

♦ VERD-G-A02-D-8-T2-4N7-20K-AP-

TXDOT-D0028

♦ VERD-M-A03-D-U-T2-4N7-20K-AP-

TXDOT-D0004

♦ VERD-M-A03-D-8-T2-4N7-20K-AP-

TXDOT-D0005

♦ XNV2-AC-02-D-U-3-525-

4N7-AP-TXDOT-D0030

♦ XNV2-AC-02-D-8-3-525-

4N7-AP-TXDOT-D0031

♦ XNV2-AC-02-D-U-2-4N7- AP-TXDOT-

D0028

♦ XNV2-AC-02-D-8-2-4N7- AP-TXDOT-

D0029

♦ NVN-AE-03-D-U-T2R-4N7-AP-TXDOT-

D0102

♦ NVN-AE-03-D-8-T2R-4N7-AP-TXDOT-

D0103

♦ NVN-AF-03-D-U-T2R-4N7-AP-TXDOT-

D0225

♦ NVN-AF-03-D-8-T2R-4N7-AP-TXDOT-

D00226

Material Producer List – Roadway Illumination and

Electrical Supplies

9

January 26, 2018

Item 610 - Roadway Illumination Assemblies – LED Luminaire

Manufacturer

Brand

Type

Model

GreenStar

6900 Alamo Downs Pkwy

Suite 120

San Antonio, TX 78238

greenstarled.com

GreenStar

♦150W EQ LED

(100W)-120/240 Volt;

LLF=0.74

♦150W EQ LED

(100W)-480 Volt;

LLF=0.74

♦250W EQ LED

(170W)-120/240 Volt;

LLF=0.74

♦250W EQ LED

(170W)-480 Volt;

LLF=0.74

♦400W EQ LED

(240W)-120/240 Volt;

LLF=0.74

♦400W EQ LED

(240W)-480 Volt;

LLF=0.74

♦XAVX08431SNXXI

♦XAVH08434SNXXI

♦XAVX12431SNXXI; oldpart #

AV12431SN

♦XAVH12434SNXXI; oldpart #

AV12434SN

♦XAVX20431SNXXI

♦XAVH20434SNXXI

GE Lighting Solutions

3010 Spartanburg Hwy

East Flat Rock, NC 28726

gelightingsystems.com

Evolve

♦150W EQ LED (78W)-

120V; LLF=0.80

♦150W EQ LED (78W)-

240V; LLF=0.80

♦150W EQ LED (78W)-

480V; LLF=0.80

♦250W EQ LED

(130W)-240V;

LLF=0.79

♦250W EQ LED

(130W)-480V;

LLF=0.79

♦400W EQ LED

(285W)-240V;

LLF=0.70

♦400W EQ LED

(285W)-480V;

LLF=0.70

♦ERS11B3D17404GRAY120

♦ERS13B3D17404GRAY120

♦ERS15B3D17404GRAY081

♦ERS20E3E17404GRAY083

♦ERS2HE3E17404GRAY134

♦ERS20H3E11404GRAY135

♦ERS2HH3E11404GRAY136

Material Producer List – Roadway Illumination and

Electrical Supplies

10

January 26, 2018

Item 610 - Roadway Illumination Assemblies – LED Luminaire

Manufacturer

Brand

Type

Model

Philips

Philips Lighting

200 Franklin Square Drive

Somerset, NJ 08873

lightingproducts.philips.com

Lumec

♦250W EQ LED

(120W)-120/240V;

LLF=0.833

♦250W EQ LED

(120W)-480V;

LLF=0.833

♦400W EQ LED

(200W)-120/240V;

LLF=0.833

♦400W EQ LED

(200W)-480V;

LLF=0.833

♦[RFM-004]-108W48LED4K-T-R2M-

[UNIV-009]-DMG-ML-PH9-RCD-SP2-

GY3

♦[RFM-004]-108W48LED4K-T-R2M-

[HVU-002]-DMG-ML-PH9-RCD-SP2-

GY3

♦[RFL-006]-180W80LED4K-T-R2M-

[UNIV-009]-DMG-ML-PH9-RCD-SP2-

GY3

♦[RFL-006]-180W80LED4K-T-R2M-

[HVU-002]-DMG-ML-PH9-RCD-SP2-

GY3

Acuity

Acuity Brands Lighting, Inc.

3825 Columbus Rd.

Granville, OH 43023

acuitybrands.com

American

Electric

♦150W EQ LED (70W)-

120/240V; LLF=0.742

♦150W EQ LED (70W)-

480V; LLF=0.742

♦250W EQ LED

(126W)-120/240V;

LLF=0.815

♦250W EQ LED

(126W)-480V;

LLF=0.815

♦250W EQ LED

(150W)-120/240V;

LLF=0.815

♦250W EQ LED

(150W)-480V;

LLF=0.815

♦400W EQ LED

(209W)-120/240V;

LLF=0.877

♦400W EQ LED

(209W)-480V;

LLF=0.877

♦ATB0 20BLEDE10 MVOLTR3 20 BL

NL SH F2 RFD22058

♦ATB0 20BLEDE10 480 R320 BL NL

SH F2 RFD209795

♦ATB0 30BLEDE13 MVOLTR2 20 BL

NL SH RFD244668

♦ATB0 30BLEDE13 480 R220 BL NL

SH RFD244669

♦ATB0 30BLED15 MVOLTR2 20 BL

NL SH RFD209796

♦ATB0 30BLED15 480 R2 20BL NL

SH RFD220059

♦ATBL D MVOLT R2 4B 20NL SH

RFD209798

♦ATBL D 480 R2 4B 20 NLSH

RFD220060

Material Producer List – Roadway Illumination and

Electrical Supplies

11

January 26, 2018

Item 610 - High Pressure Sodium Lamps

Manufacturer

Brand

Type

Model

Osram Sylvania

100 Endicott Street

Danvers, MA 24210

(978) 777-1900

For Lamps

(800) 544-4828

sylvania.com

Sylvania – Lumalux

Plus®/ECO

♦ 400 Watt Lamp

♦ 250 Watt Lamp

♦ 150 Watt Lamp

♦ 67312 - LU400/PLUS/ECO

♦ 67572 - LU250/PLUS/ECO

♦ 67494 -LU150/55/PLUS/ ECO

Philips Lighting

Company

200 Franklin Square

Dr.

P.O. Box 6800

Somerset, NJ 08875

(800) 555-0050

lighting.philips.com

Philips -

Ceramalux®/ALTO

® Non-Cycling Lamp

♦ 400 Watt Lamp

♦ 250 Watt Lamp

♦ 150 Watt Lamp

♦ 14743-9 – C400S51/ALTO NC HPS

♦ 14742-1 – C250S50/ALTO NC HPS

♦ 14741-3 –

C150S55/ALTO NC HPS

GE Lighting

Nela Park, 1975

Noble Rd.

Cleveland, OH

44112

(216) 266-2121

gelighting.com

GE – EcoluxNC™

♦ 400 Watt Lamp

♦ 250 Watt Lamp

♦ 150 Watt Lamp

♦ 14675 – LU400/ECO/NC

♦ 14674 – LU250/ECO/NC

♦ 40390 – LU150/55/ECO/

NC

Material Producer List – Roadway Illumination and

Electrical Supplies

12

January 26, 2018

Item 610 -

Photoelectric Control - Photocell

Manufacturer

Brand

Type

Model

Tork

1 Grove Street

Mt. Vernon, NY 10550

(914) 664-5042

tork.com

Tork

♦ 120-277 Volt

Photocell

♦ S895

♦ NSI-TORK S895 *

* Tork has recently been bought out

by NSI

American Electric Lighting /

DTL

P.O. Box 3004

Newark, OH 43800

(800) 754-0463

darktolight.com

DTL

♦ 120-277 Volt

Photocell

♦ DUX124 -12A30

Tyco Electronics

8000 Purfoy Rd.

Fuquay-Varina, NC 27526

(919) 557-8459

tycoelectronics.com

Area

Lighting

Research

Tyco

♦ 120-277 Volt

Photocell

♦ ALR-SST-PV-IES-UL

(3E7425-000)

Material Producer List – Roadway Illumination and

Electrical Supplies

13

January 26, 2018

Item 610 - Breakaway Fuse-holders

Manufacturer

Brand

Type

Model

Eaton –Bussmann Series

114 Old State Road

Ellisville,MO 63021 (855)

287-7626

cooperindustries.com

Bussmann

♦ Double-pole

♦ Double-pole

♦ HEX-KW-DRYC – used when no

neutral is required

♦ HEN-KW-DRYC – used when neutral

is present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Littelfuse Inc.

800 E. Northwest Highway

Des Plaines, IL 60016-3096

(847) 824-1188

littelfuse.com

Littelfuse

♦ Double-pole

♦ Double-pole

♦ 0LEXYYCSX – used when no neutral

is required

♦ LEXT0YYSX – used when neutral is

present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Material Producer List – Roadway Illumination and

Electrical Supplies

14

January 26, 2018

Item 610 -

Breakaway Fuse-holders

Manufacturer

Brand

Type

Model

Mersen USA

374 Merrimac Street

Newburyport, MA 01950

(978) 462-6662

ferrazshawmut.com

Ferraz Shawmut is Now

Mersen.

Parent Company name

change only. Brand of

connector is still

Ferraz Shawmut.

Ferraz

Shawmut

♦ Double-pole

♦ Double-pole

♦ FEX-91-91-BA – used when no

neutral is required

♦ FEXN-91-91-BA – used when

neutral is present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Ideal Industries, Inc.

1 Becker Place

Sycamore, IL 60178

(800) 435-0705

idealindustries.com

Ideal-

Buchanan

SLK

♦ Double-pole

♦ Double-pole

♦ 30-S2222D – used when no

neutral is required

♦ 30-S2222P – used when neutral is

present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Material Producer List – Roadway Illumination and

Electrical Supplies

15

January 26, 2018

Item 610 -

Optional and Non-Standard Illumination Pole Designs and Shop Drawings

Manufacturer

Brand

Type

Model

Hapco

26252 Hillman Highway

Abingdon, VA 24210

(800) 368-7171

hapco.com

Hapco

♦ 40 Ft.-Aluminum - T-

Base mounted with (1)

8Ft. Arm Only

♦ Based on Drawing # B15138 and

B15136

Material Producer List – Roadway Illumination and

Electrical Supplies

16

January 26, 2018

Item 610 -

Breakaway Transformer Base

Manufacturer

Brand

Type

Model

Akron Foundry Co.

2728 Wingate Ave.

Akron, OH 44314

(330) 745-3101

akronfoundry.com

Akron

♦ Breakaway

Transformer Base for

Luminaire Poles Less

Than 40 Foot Height

♦ Breakaway

Transformer Base for

Luminaire Poles 40 to

50 Foot Height

♦ TB1-17

♦ TB3-17

Material Producer List – Roadway Illumination and

Electrical Supplies

17

January 26, 2018

Item 613 – High Mast Illumination Poles

General

There are no pre-qualified High Mast Illumination Poles.

Construction

Perform work in accordance with the details shown on the plans, and the requirements

of item 613. Provide components that fit together properly.

(a)

Standard Design.

Fabricate poles in accordance with this Item and the plans.

Alternate designs are not permitted.

(b)

Shop Drawings.

Do not submit shop drawings for high mast illumination poles

fabricated in accordance with this Item and the plans.

Material Producer List – Roadway Illumination and

Electrical Supplies

18

January 26, 2018

Item 614 – High Mast Illumination Assemblies

General

The following products are pre-qualified for use on the projects where high mast

illumination assemblies are furnished or installed as required by the item descriptive

code. Fixtures are subject to testing. No substitutions of products will be allowed when

pre-qualified products are shown. Where miscellaneous parts, brackets, hardware,

nuts, bolts, washers, or other incidentals are necessary and are not shown as pre-

qualified products, the contractor shall furnish products that meet the requirements of

the plans and specifications.

Item 614 -

Luminaire – High Mast

Manufacturer

Brand

Type

Model

Holophane

3825 Columbus Road SW

Granville, OH 43023

(740) 587-6167

FAX (888) 300-5321

holophane.com

High Mast

Cutoff-

HMSC

High Mast

Cutoff-

HMSC

High Mast

Dark Skies-

HMSD

♦ High Mast – Type A

♦ High Mast – Type B

♦ High Mast – Type S

♦ HMSC40RHP48B9- TXDOT 12 TYPE

A

♦ HMSC40RHP48B9- TXDOT 12 TYPE

B

♦ HMAO40RHP48S- TXDOT 12 TYPE

S

*Note model number for A & B

changed from B7 to B9. No other

changes noted.

G.E. Lighting Systems, Inc.

3010 Spartanburg Highway

Henderson, NC 28793

(800) 305-1372

gelightingsystems.com

G.E.

♦ High Mast – Type A

♦ High Mast – Type B

♦ High Mast – Type C

♦ High Mast – Type S

♦ 159189

♦ 159190

♦ 159191

♦ 159193

Eaton (formerly Cooper)

1121 Highway 74 South

Peachtree City, GA 30269

(770) 486-4800

cooperindustries.com

Streetworks

♦ High Mast – Type A

♦ High Mast – Type B

♦ High Mast – Type C

♦ High Mast – Type S

♦ GMA40SM83DD0018

♦ GMA40SM83DD0019

♦ GMA40SM83DD0020

♦ GMA40SM8ARD0017

Material Producer List – Roadway Illumination and

Electrical Supplies

19

January 26, 2018

Item 614 -

High Pressure Sodium Lamps

Manufacturer

Brand

Type

Model

Osram Sylvania

100 Endicott Street

Danvers, MA 24210

(978) 777-1900

For Lamps

(800) 544-4828

sylvania.com

Sylvania - Lumalux

Plus®/ECO

♦ 400 Watt Lamp

♦ 67312 - LU400/PLUS/ECO

Philips Lighting Company

200 Franklin Square Dr.

P.O. Box 6800

Somerset, NJ 08875

(800) 555-0050

lighting.philips.com

Philips -

Ceramalux®/ALTO

® Non-Cycling

Lamp

♦ 400 Watt Lamp

♦ 14743-9 – C400S51/ALTO NC

HPS

GE Lighting

Nela Park, 1975 Noble

Rd.

Cleveland, OH 44112

(216) 266-2121

gelighting.com

GE – EcoluxNG™

♦ 400 Watt Lamp

♦ 14675 – LU400/ECO/NC

Material Producer List – Roadway Illumination and

Electrical Supplies

20

January 26, 2018

Item 614 -

High Mast Kit

Manufacturer

Brand

Type

Model

Mica Corporation

5750 N. Riverside Dr.

Fort Worth, TX 76137

(817) 577-2088

micacorporation.com

Mica

Corporation

♦ High Mast – 125

Foot

♦ High Mast – 150

Foot

♦ High Mast – 175

Foot

♦ HMK-125-PH

♦ HMK-150-PH

♦ HMK -175-PH

Carolina High Mast, Inc.

700 East McLeroy Blvd. –

Suite A

Saginaw, TX 76179

(682) 286-0046

Carolina

High Mast,

Inc.

♦ High Mast – 125

Foot

♦ High Mast – 150

Foot

♦ High Mast – 175

Foot

♦ HMK-125-CHMI

♦ HMK-150-CHMI

♦ HMK -175-CHMI

Rexel

2400 Brockton

San Antonio, TX 78217

(210) 352-1047

rexelusa.com

Rexel

♦ High Mast – 125

Foot

♦ High Mast – 150

Foot

♦ High Mast – 175

Foot

♦ HMK-125-RX

♦ HMK-150-RX

♦ HMK -175-RX

Wildcat Electric Supply, Ltd.

2061 Clovis Barker Road #5.

San Marcos, TX 77666

(512) 396-8900

(866) 301-5200

wildcatelectric.com

Wildcat

♦ High Mast – 125

Foot

♦ High Mast – 150

Foot

♦ High Mast – 175

Foot

♦ HMK-125-WC

♦ HMK-150-WC

♦ HMK -175-WC

Stratus Products

Division of

Structural & Steel Products,

Inc

1320 South University

Suite 701

Fort Worth, TX 76107

(800) 782-5804

stratusprod.com

Stratus

Products

♦ High Mast – 100

Foot

♦ High Mast – 125

Foot

♦ High Mast – 150

Foot

♦ High Mast – 175

Foot

♦ HMK-100-SSPI

♦ HMK-125-SSPI

♦ HMK-150-SSPI

♦ HMK -175-SSPI

Millerbernd Manufacturing

Co.

622 6th Street South

Winsted, MN 55395

(320) 485-2111

FAX (320) 485-2220

millerberndmfg.com

Millerbernd

♦ High Mast – 100

Foot

♦ High Mast – 125

Foot

♦ High Mast – 150

Foot

♦ High Mast – 175

Foot

♦ MMC100KIT

♦ MMC125KIT

♦ MMC150KIT

♦ MMC175KIT

Material Producer List – Roadway Illumination and

Electrical Supplies

21

January 26, 2018

Item 614 - High Mast Ring- Previously Approved Shop Drawings

Manufacturer

Brand

Type

Model

J.W. Hall Enterprises, Inc.

17731 Elizabeth Rd.

Algoa, TX 77511

(281) 337-6311

jwhall.com

♦ High Mast Ring

Drawing # HM 2002-01

Sheets 1 through 6

Drawing # HE 2002

Sheets 7 through 9

Carolina High Mast, Inc.

700 East McLeroy Blvd. –

Suite A

Saginaw, TX 76179

(682) 286-0046

.

♦ High Mast Ring

Drawing # TXDOT-01

Sheets 1 through 5

Drawing # TXDOT-02

Sheets 1 through 4

Drawing # TXDOT-03

Sheets 1 through 4

Drawing # TXDOT-04

Sheets 1 through 3

Traffic Control Devices

4417 Main Street

Pearland, TX 77581

(281) 992-3030

tcd.cc

♦ High Mast Ring

Drawing # E-901

Sheets 1 through 10

Brookfield Fabricating Corp.

Stanbury Industrial Dr.

Brookfield, MO 64628

(660) 258-2214

♦ High Mast Ring

Drawings Dated 4-8-96

Sheets 1 through 4 –

Good Until 9-30-2011

Drawings Approved 8-

29-2011

Sheet 1 Dated 7-1-08

Sheet 2 Dated 8-5-11

Sheet 3 Dated 7-1-08

Sheet 4 Dated 7-1-08

PKM Steel Service

228 E. Avenue A

P.O. Box 1066

Salina, KS 67402-1066

(785) 827-3638

pkmsteel.com

♦ High Mast Ring

Sheet E1 Dated 8-2-05

Sheet 1 Dated 10-12-

05

Sheet 2 Dated 10-12-

05

Sheet 3 Dated 10-12-

05

Material Producer List – Roadway Illumination and

Electrical Supplies

22

January 26, 2018

Item 618 – Conduit

General

The following products have been tested and are pre-qualified for use on projects where

Conduit, Junction Boxes, Expansion Joints and Conduit Fittings are furnished or

installed. Where miscellaneous parts, brackets, hardware, nuts, bolts, washers, or other

incidentals are necessary and are not shown as pre-qualified products, the contractor

shall furnish products that meet the requirements of the plans and specifications. No

substitutions of products will be allowed when pre-qualified products are shown.

Item 618 - Rigid Metallic Conduit – (RMC)

Manufacturer

Brand

Type

Model

Allied Tube & Conduit

16100 S. Lathrop Avenue

Harvey, IL 60426-6021

(800) 882-5543

alliedeg.us

Allied

♦ Galvanized Rigid

Metal Conduit (RMC)

♦ Trade Sizes from 1/2" to 6"

Wheatland

900 Haddon Avenue P.O. Box

600 Collingswood, NJ 08108-

0600 (800) 257-8182

wheatland.com

Wheatland

♦ Galvanized Rigid

Metal Conduit (RMC)

♦ Trade Sizes from 1/2" to 6"

Republic Conduit

7301 Logistics Drive

Louisville, KY 40258

(800) 840-8823

(502) 995-5900

republicconduit.com

Republic

♦ Galvanized Rigid

Metal Conduit (RMC)

♦ Trade Sizes from 1/2" to 6"

Western Tube & Conduit

Corp.

2001 E. Dominguez St. Long

Beach, CA 90801-2720

(310) 537-6300

(800) 310-8823

westerntube.com

Western

Conduit

♦ Galvanized Rigid

Metal Conduit (RMC)

♦ Trade Sizes from 1/2" to 6"

Material Producer List – Roadway Illumination and

Electrical Supplies

23

January 26, 2018

Item 618 - PolyVinyl Chloride Pipe- (PVC)

Manufacturer

Brand

Type

Model

Cantex

P.O. Box 340

Mineral Wells, TX 76068

(940) 325-3344

(800) 433-5623

cantexinc.com

Cantex

♦ PVC

♦ Schedule 40 and 80

♦ Trade Sizes from 1/2" to 6"

Allied Tube & Conduit

16100 S. Lathrop Avenue

Harvey, IL 60426-6021

alliedeg.us

Allied Tube

& Conduit

♦ PVC

♦ Schedule 40 and 80

♦ Trade Sizes from 1/2" to 6"

Prime Conduit Inc.

23240 Chagrin Blvd. Suite

405

Cleveland, OH 44122

(216) 464-3400

(800) 321-1970

primeconduit.com

Prime

Conduit

♦ PVC

♦ Schedule 40 and 80

♦ Trade Sizes from 1/2" to 6"

National Pipe & Plastics, Inc.

3421 Old Vestal Road

Vestal, NY 13850

(800) 836-4350

nationalpipe.com

NPPI PVC

♦ PVC

♦ Schedule 40 and 80

♦ Trade Sizes from 1/2" to 6"

Heritage Plastics Central, Inc.

1202 N. Bowie Drive

Weatherford, TX 76086

(817) 594-8791

heritageplastics.com

Heritage

♦ PVC

♦ Schedule 40 and 80

♦ Trade Sizes from 1/2" to 6"

Rocky Mountain Colby Pipe

Co.

5125-B Race Ct.

Denver, CO 80216

(800) 681-8682

rmcp.com

Rocky

Mountain

Colby

♦ PVC

♦ Schedule 40 and 80

♦ Schedule 40 - Trade Sizes from

1/2" to 6"

♦ Schedule 80 - Trade Sizes from 1

¼" to 6"

Material Producer List – Roadway Illumination and

Electrical Supplies

24

January 26, 2018

Item 618 - PolyVinyl Chloride Pipe- (PVC)

Manufacturer

Brand

Type

Model

OMNI

259 Plauche Street

Harahan, LA 70123

(504) 736-0331

omni-opti.com

OMNI

♦ PVC

♦ Schedule 40 - Trade Sizes from

1/2" to 6"

♦ Schedule 80 - Trade Sizes from 2”

to 6”

American Pipe & Plastics, Inc.

P.O. Box 577

Binghamton, NY 13902

(607) 775-4340

ampipe.com

American

Pipe &

Plastics

♦ PVC

♦ Schedule 40 – Trade Sizes from 1

¼” to 6” in 10’ lengths – All model

#’s start with UL

♦ Schedule 40 – Trade Sizes from 1

¼” to 6” in 20’ lengths – All model

#’s start with UL

JM Eagle

5200 West Century

Boulevard

Los Angeles, CA 90045

(800) 621-4404

jmeagle.com

JM Eagle

♦ PVC

Schedule 40

♦ ½” 0.5 S40 UL

♦ ¾” 0.75 S40 UL

♦ 1” 1 S40 UL

♦ 1 ¼” 1.25 S40 UL

♦ 1 ½” 1.50 S40 UL

♦ 2” 2 S40 UL

♦ 2 ½” 2.5 S40

♦ 3” 3 S40 UL

♦ 3 ½” 3.5 S40

♦ 4” 4 S40 UL

♦ 5” 5 S40 UL

♦ 6” 6 S40 UL

Schedule 80

0.5 S80 UL

0.75 S80 UL

1 S80 UL

1.25 S80 UL

1.50 S80 UL

2 S80 UL

2.5 S80 UL

3 S80 UL

3.5 S80 UL

4 S80 UL

5 S80 UL

6 S80 UL

Material Producer List – Roadway Illumination and

Electrical Supplies

25

January 26, 2018

Item 618 - High-Density Polyethylene Conduit (HDPE)

Manufacturer

Brand

Type

Model

Blue Diamond Industries, LLC

3399 Tates Creek Road

Suite 110

Lexington, KY 40502

(859) 224-0415

bdiky.com

Blue

Diamond

HDPE

♦ HDPE Conduit –

Schedule 40

Color - Black

♦ 1/2" BDI065BK-UL

♦ 3/4" BDI095BK-UL

♦ 1" BDI115BK-UL

♦ 1 ¼” BDI135BK-UL

♦ 1 ½” BDI165BK-UL

♦ 2" BDI215BK-UL

♦ 3" BDI315BK-UL

♦ 4" BDI414BK-UL

Draka Cableteq USA

One Tamaque Blvd.

Schuylkill Haven, PA 17972

(570) 385-4381

drakausa.com

Draka

♦ HDPE Conduit –

Schedule 40

Color - Black

♦ 2" 321659

♦ 3" 321663

Dura∙line

11400 Parkside Dr.

Suite 300

Knoxville, TN. 37934

(865) 218-3460

(800) 847-7661

duraline.com

Formerly A-D Technologies

Name change on MPL Nov.

2013

Dura∙line

♦ HDPE Conduit –

Schedule 40

Color - Black

♦ 1/2" HDP 050 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 3/4" HDP 075 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 1" HDP 100 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 1 ¼” HDP 125 W SCHE40 SW

UVS/UVS N EMPT D X(TXDOT

APPROVED)

♦ 1 ½” HDP 150 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 2” HDP 200 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 3” HDP 300 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 4” HDP 400 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

♦ 6” HDP 600 W SCHE40 SW

UVS/UVS N EMPTD X(TXDOT

APPROVED)

Material Producer List – Roadway Illumination and

Electrical Supplies

26

January 26, 2018

Item 618 -

High-Density Polyethylene Conduit (HDPE)

Manufacturer

Brand

Type

Model

United Poly Systems, LLC

4707 E. Kearney St

Springfield, MO 65803

(417)708-9887

unitedpolysystems.com

United Poly

Systems

♦ HDPE Conduit –

Schedule 40

Color - Black

♦ 1” Schedule 40 -

D100011AORNNNNSTX

♦ 1 1/4” Schedule 40 -

D125011AORNNNNSTX

♦ 1 1/2” Schedule 40 -

D150011AORNNNNSTX

♦ 2” Schedule 40 -

D200011AORNNNNSTX

♦ 2 1/2” Schedule 40 -

D250011AORNNNNSTX

♦ 3” Schedule 40 -

D300011AORNNNNSTX

♦ 4” Schedule 40 -

D400011AORNNNNSTX

♦ 5” Schedule 40 -

D500011AORNNNNSTX

♦ 6” Schedule 40 -

D600011AORNNNNSTX

Material Producer List – Roadway Illumination and

Electrical Supplies

27

January 26, 2018

Item 618 - Precast Polymer Concrete Junction Box for Concrete Traffic Barrier

Manufacturer

Brand

Type

Model

Hubbell

3621 Industrial Park Drive

Lenoir City, TN. 37771

(800) 346-3062

quazite.com

Hubbell

Quazite

♦ Median Barrier Box

♦ Median Barrier Box –

for Concrete Barrier (F-

Shape)

♦ Junction Box w/Cover

OD – 9 X 11 X 7 ¼”

ID – 7 ⅜ X 9⅜ X 6 ½”

♦ PC1012B500/PC1012CA00

♦ PC0516B500/PC0516CA00

♦ PC0608Z503831

Cover Imprinted “Danger High Voltage

–Illumination”

Material Producer List – Roadway Illumination and

Electrical Supplies

28

January 26, 2018

Item 620 – Electrical Conductors

General

The following products are pre-qualified for use on projects where Conductors are

furnished or installed as required by the item descriptive code. Where splicing

materials, insulating materials, GelCaps, fuse holders or other incidentals are necessary

and are not shown as pre-qualified products, the contractor shall furnish products that

meet the requirements of the plans and specifications. No substitutions of products will

be allowed when pre-qualified products are shown.

Item 620 -

Conductors – Type XHHW

Manufacturer

Brand

Type

Model

American Insulated Wire Co.

Bought out by Southwire

Corp.

American

♦ XHHW-2 Or

♦ XHHW

♦ Available in 14 AWG through 750

kcmil

♦ 6 AWG & 8AWG Available in Black

Only

American will continue to be pre-

qualified until stock is depleted.

Encore Wire

1410 Millwood Rd.

McKinney, TX 75069

(800) 962-9473

encorewire.com

Encore

♦ XHHW-2 Or

♦ XHHW

♦ Available in 14 AWG through 1000

kcmil

Service Wire Company

310 Davis Road

Culloden, W. Va. 25510

(800) 624-3572

(713) 674-6666

(800) 231-9473

servicewire.com

Service

Wire

♦ XHHW-2 Or

♦ XHHW

♦ Available in 14 AWG through 750

kcmil

Southwire Corporation

1 Southwire Division

Carrolton, GA 30119

(800) 444-1700

(770) 832-4242

southwire.com

Southwire

♦ XHHW-2 Or

♦ XHHW

♦ Available in 14 AWG through 1000

kcmil

♦ 6 AWG & 8AWG Available in Black

Only

Advanced Digital Cable Inc.

94 Eagle Fork Road

Hayesville, NC 28904

(800) 343-2579

advanceddigitalcable.com

Advanced

Digital

♦ XHHW-2 Or

♦ XHHW

♦ Available in 14 AWG through 1000

kcmil

Material Producer List – Roadway Illumination and

Electrical Supplies

29

January 26, 2018

Item 620 -

Conductors – Type XHHW

Manufacturer

Brand

Type

Model

Draka Cableteq USA

One Tamaque Blvd.

Schuylkill Haven, PA 17972

(570) 385-4381

drakausa.com

Draka

♦ XHHW-2

♦ 8 AWG Black 6200110BK

♦ 8 AWG White 6200110WH

♦ 8 AWG Red 6200110RD

♦ 8 AWG Green 6200110GN

♦ 6 AWG Black 6200359BK

♦ 6 AWG White 6200359WH

♦ 6 AWG Red 6200359RD

♦ 6 AWG Green 6200359GN

♦ 4 AWG Black 6200020BK

♦ 4 AWG White 6200020WH

♦ 4 AWG Red 6200020RD

♦ 4 AWG Green 6200020GN

♦ 2 AWG Black 6200067BK

♦ 2 AWG White 6200067WH

♦ 2 AWG Red 6200067RD

♦ 2 AWG Green 6200067GN

♦ 8 AWG Bare 113-0007-168

♦ 6 AWG Bare 113-0007-146

♦ 4 AWG Bare 113-0007-137

♦ 2 AWG Bare 113-0007-100

Falcon Fine Wire

2401 Discovery Blvd.

Rockwall, TX 75032

(800) 874-7230

(214) 771-3441

falconfinewire.com

Falcon

♦ XHHW-2 Or

♦ XHHW

♦ Available in 14 AWG through 4000

kcmil

Available Jacket Colors:

Black, Red. White, Green

3090194 – ETL Number Will Be

Printed On Jacket

Material Producer List – Roadway Illumination and

Electrical Supplies

30

January 26, 2018

Item 620 - Conductors – Type XHHW

Manufacturer

Brand

Type

Model

Republic Wire Inc.

5525 Union Centre Drive

West Chester, OH 45069

(513) 860-1800

republicwire.com

Republic

Wire Inc.

♦ XHHW-2 Or

♦ XHHW

♦ Available in 8 AWG through 2 AWG

Available Jacket Colors:

Black, Red. White, Green

♦ Available in 1/0 AWG through 750

Kcmil

Available in Black Only

♦ Bare Copper

Soft Drawn Solid and Stranded 8AWG

- 2AWG

Coleman Cable, Inc.

1530 Shields Drive

Waukegan, IL 60085

(800) 325-9355

colemancable.com

CCI

♦ XHHW-2

Available in Black Only

♦ 8 AWG 18080

♦ 6 AWG 18060

♦ 4 AWG 18040

♦ 2 AWG 18020

♦ 1 AWG 18010

♦ 1/0 AWG 18100

♦ 2/0 AWG 18200

♦ 3/0 AWG 18300

♦ 4/0 AWG 18400

♦ 250 MCM 18250

♦ 350 MCM 18350

♦ 400 MCM 18440

♦ 500 MCM 18500

♦ Bare Copper

Solid and Stranded 8 AWG – 4AWG

Stranded 2 AWG – 600 kcmil

Material Producer List – Roadway Illumination and

Electrical Supplies

31

January 26, 2018

Item 620 -

Breakaway Fuse-holders

Manufacturer

Brand

Type

Model

Eaton –Bussmann Series

114 Old State Road

Ellisville, MO 63021

(855) 287-7626

cooperindustries.com

Bussmann

♦ Double-pole

♦ Double-pole

♦ HEX-KW-DRYC – used when no

neutral is required

♦ HEN-KW-DRYC – used when neutral

is present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID sheets are in plan set.

Littelfuse Inc.

800 E. Northwest Highway

Des Plaines, IL 60016-3096

(847) 824-1188

littelfuse.com

Littelfuse

♦ Double-pole

♦ Double-pole

♦ 0LEXYYCSX – used when no neutral

is required

♦ LEXT0YYSX – used when neutral is

present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Material Producer List – Roadway Illumination and

Electrical Supplies

32

January 26, 2018

Item 620 - Breakaway Fuse-holders

Manufacturer

Brand

Type

Model

Mersen USA

374 Merrimac Street

Newburyport, MA 01950

(978) 462-6662

ferrazshawmut.com

Ferraz Shawmut is Now

Mersen.

Parent Company name

change only. Brand of

connector is still

Ferraz Shawmut.

Ferraz

Shawmut

♦ Double-pole

♦ Double-pole

♦ FEX-91-91-BA – used when no

neutral is required

♦ FEXN-91-91-BA – used when

neutral is present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Ideal Industries, Inc.

1 Becker Place

Sycamore, IL 60178

(800) 435-0705

idealindustries.com

Ideal-

Buchanan

SLK

♦ Double-pole

♦ Double-pole

♦ 30-S2222D – used when no

neutral is required

♦ 30-S2222P – used when neutral is

present

Each fuse holder will allow 2

conductors per pole for a total of 4

conductors per unit. Each connection

rated for 16 AWG up to 2 AWG.

These breakaway connectors are to

be used for both breakaway and non-

breakaway poles where a fuse holder

is called for. Installing contractor to

supply 10-ampere time delay fuse.

To

be used when TxDOT Standards RIP

and RID are in the plan set.

Material Producer List – Roadway Illumination and

Electrical Supplies

33

January 26, 2018

Item 621 – Tray Cable

General

The following products are pre-qualified for use on projects where Tray Cable is

furnished or installed as required by the item descriptive code. No substitutions of

products will be allowed when pre-qualified products are shown.

Item 621 -

Tray Cable- XHHW Conductors with Overall PVC Jacket

Manufacturer

Brand

Type

Model

American Insulated Wire Co.

Bought out by Southwire

Corp.

American

♦ Tray Cable – Power

Cable – XLP

XHHW-2 Insulation,

PVC Jacket, Copper

Conductors

♦ Available in 14 AWG through 500

kcmil

American will continue to be pre-

qualified until stock is depleted.

Service Wire Company

310 Davis Road

Culloden, W. Va. 25510

(800) 624-3572

(713) 674-6666

(800) 231-9473

servicewire.com

Service

Wire

♦ Tray Cable – Power

Cable – XLP

XHHW-2 Insulation,

PVC Jacket, Copper

Conductors

♦ Available in 14 AWG through 750

kcmil

Southwire Corporation

1 Southwire Division

Carrolton, GA 30119

(800) 444-1700

(770) 832-4242

southwire.com

Southwire

♦ Tray Cable – Power

Cable – XLP

XHHW-2 Insulation,

PVC Jacket, Copper

Conductors

♦ Available in 14 AWG through 500

kcmil

Advanced Digital Cable Inc.

94 Eagle Fork Road

Hayesville, NC 28904

(800) 343-2579

advanceddigitalcable.com

Advanced

Digital

♦ Tray Cable – Power

Cable – XLP

XHHW Insulation,

PVC Jacket, Copper

Conductors

♦ Available in 12 AWG -3 and 4

conductor

Material Producer List – Roadway Illumination and

Electrical Supplies

34

January 26, 2018

Item 621 -

Tray Cable- XHHW Conductors with Overall PVC Jacket

Manufacturer

Brand

Type

Model

Falcon Fine Wire and Wire

Products, Inc.

2401 Discovery Blvd.

Rockwall, TX 75032

(214) 771-3441

(800) 874-7230

www.falconfinewire.com

Falcon

Fine Wire

♦ Tray Cable – 3

Conductors

♦ Tray Cable – 4

Conductors

♦ 760308XL 8AWG

♦ 760308XL 10AWG

♦ 760308XL 12AWG

♦ 760308XL 14AWG

♦ 760408XL 8AWG

♦ 760410XL 10AWG

♦ 760412XL 12AWG

♦ 760414XL 14AWG

Material Producer List – Roadway Illumination and

Electrical Supplies

35

January 26, 2018

Item 622 – Duct Cable

General

The following products are pre-qualified for use on projects where Duct Cable is

furnished or installed as required by the item descriptive code. Where connectors are

necessary and are not shown as pre-qualified products, the contractor shall furnish

products that meet the requirements of the plans and specifications. No substitutions

of products will be allowed.

Item 622 -

Duct Cable with Type XHHW Conductors

Manufacturer

Brand

Type

Model

Dura∙line

11400 Parkside Dr.

Suite 300

Knoxville, TN. 37934

(865) 218-3460

(800) 847-7661

duraline.com

Formerly A-D Technologies

Name change on MPL Jan.

2014

Dura∙line

♦ Duct Cable – HDPE

with XHHW Conductors

Installed

♦ Size of Duct and Conductors as

Shown In the Plans. Specify Duct and

Conductor Size and Color and

Number of Conductors Needed When

Ordering.

Printing on Outside Wall of Duct as

Per DMS 11060

Also Printed on Outside Wall of Duct

will be “TxDOT” or “TxDOT Approved”

Blue Diamond Industries, LLC

3399 Tates Creek Road

Suite 110

Lexington, KY 40502

(859) 224-0415

bdiky.com

Blue

Diamond

♦ Duct Cable – HDPE

with XHHW Conductors

Installed

♦ Size of Duct and Conductors as

Shown In the Plans. Specify Duct and

Conductor Size and Color and

Number of Conductors Needed When

Ordering.

Printing on Outside Wall of Duct as

Per DMS 11060

Also Printed on Outside Wall of Duct

will be “TxDOT” or “TxDOT Approved”

Draka Cableteq USA

One Tamaque Blvd.

Schuylkill Haven, PA 17972

(800) 233-3190

drakausa.com

Draka

♦ Duct Cable – HDPE

with XHHW Conductors

Installed

♦ Size of Duct and Conductors as

Shown In the Plans. Specify Duct and

Conductor Size and Color and

Number of Conductors Needed When

Ordering.

Printing on Outside Wall of Duct as

Per DMS 11060

Also Printed on Outside Wall of Duct

will be “TxDOT” or “TxDOT Approved”

Material Producer List – Roadway Illumination and

Electrical Supplies

36

January 26, 2018

Item 622 -

Duct Cable with Type XHHW Conductors

Manufacturer

Brand

Type

Model

Southwire Corporation

One Southwire Drive

Carrolton, GA 30119 (770)

832-4242

southwire.com

SIMpull

♦ Duct Cable – HDPE

with XHHW Conductors

Installed

♦ Size of Duct and Conductors as

Shown In the Plans. Specify Duct and

Conductor Size and Color and

Number of Conductors Needed When

Ordering.

Printing on Outside Wall of Duct as

Per DMS 11060

Also Printed on Outside Wall of Duct

will be “TxDOT” or “TxDOT Approved”

Material Producer List – Roadway Illumination and

Electrical Supplies

37

January 26, 2018

Item 624 – Ground Boxes

General

The following products are pre-qualified for use on projects where Ground Boxes are

furnished or installed as required by descriptive code. Products are subject to testing.

No substitutions will be allowed for Types A through E as listed below. For types not

listed below, applicable TxDOT standards and specifications will apply.

Item 624 - Ground Boxes – Precast Polymer Concrete

Manufacturer

Brand

Type

Model

Hubbell

3621 Industrial Park Drive

Lenoir City, TN. 37771

(800) 346-3062

quazite.com

Hubbell

Quazite

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For Type A, B & E

Cover For Type C & D

♦ PG1324B512 / PG1324H506

♦ 2PG1324B512 / PG1324H506

♦ PG1730B512 / PG1730H507

♦ PG1730B517 / PG1730H507

♦ PG1324B514 / PG1324H506

♦ PG1324H5064A (Danger High

Voltage FTM)

♦ PG1324H5064B (Danger High

Voltage Irrigation)

♦ PG1324H5064D(Danger High

Voltage Illumination)

♦ PG1324H5064E (Danger High

Voltage Traffic Signal)

♦ PG1324H5064G (Danger High

Voltage Sign Lighting)

♦ PG1324H506H7 (Danger High

Voltage)

♦ PG1730H5074A (Danger High

Voltage FTM)

♦ PG1730H5074B (Danger High

Voltage Irrigation)

♦ PG1730H5074D (Danger High

Voltage Illumination)

♦ PG1730H5074E (Danger High

Voltage Traffic Signal)

♦ PG1730H5074G (Danger High

Voltage Sign Lighting)

♦ PG1730H507H7 (Danger High

Voltage)

Material Producer List – Roadway Illumination and

Electrical Supplies

38

January 26, 2018

Item 624 -

Ground Boxes – Precast Polymer Concrete

Manufacturer

Brand

Type

Model

Armorcast Products Company

13230 Saticoy St.

North Hollywood, CA. 91605

(818) 982-3600

armorcastprod.com

Armor cast

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For All Boxes

♦ A6001946TAPCX12

♦ A6001946TAPCX24

♦ A6001640TAPCX12

♦ A6001640TAPCX22

♦ A6001946TAPCX18

♦ All Covers Read “Danger High

Voltage.” Additional Logos Added Per

Job Spec.

NewBasis

2626 Kansas Avenue

Riverside, CA. 92507

(909) 787-0600

Toll Free (866) 392-2747

newbasis.com

NewBasis

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For Type A, B & E

Cover For Type C & D

♦ PCB132412G482

♦ (2) PCB132412G482

♦ PCB173012G482

♦ PCB173022G482

♦ PCB132418G482

♦ PCC1324DLA528- DANGER HIGH

VOLTAGE/TRAFFIC SIGNALS

♦ PCC1324DCA528- DANGER HIGH

VOLTAGE/ILLUMINATION

♦ PCC1324DMA528- DANGER HIGH

VOLTAGE/TRAFFIC MANAGEMENT

♦ PCC1324DSA528- DANGER HIGH

VOLTAGE/SIGN ILLUMINATION

♦ PCC1730DLA528- DANGER HIGH

VOLTAGE/TRAFFIC SIGNALS

♦ PCC1730DCA528- DANGER HIGH

VOLTAGE/ILLUMINATION

♦ PCC1730DMA528- DANGER HIGH

VOLTAGE/TRAFFIC MANAGEMENT

♦ PCC1730DSA528- DANGER HIGH

VOLTAGE/SIGN ILLUMINATION

Material Producer List – Roadway Illumination and

Electrical Supplies

39

January 26, 2018

Item 624 - Ground Boxes – Precast Polymer Concrete

Manufacturer

Brand

Type

Model

Synertech Moulded Products

2 Inverness St.

Candiac, Quebec Canada J5R

4WS

Toll Free (888) 868-5214

synertechproducts.com

Synertech

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For Type A, B & E

Cover For Type C & D

♦ S132412HH90

♦ S132424HH90

♦ S173012HH90

♦ S173024HH90

♦ S132418HH90

♦ S1324HBB0A90- DANGER HIGH

VOLTAGE/TRAFFIC SIGNAL

♦ S1324HBB0A91- DANGER HIGH

VOLTAGE/ILLUMINATION

♦ S1324HBB0A92- DANGER HIGH

VOLTAGE/TRAFFIC MANAGEMENT

♦ S1324HBB0A93- DANGER HIGH

VOLTAGE/SIGN ILLUMINATION

♦ S1730HBB0A90- DANGER HIGH

VOLTAGE/TRAFFIC SIGNALS

♦ S1730HBB0A91- DANGER HIGH

VOLTAGE/ILLUMINATION

♦ S1730HBB0A92- DANGER HIGH

VOLTAGE/TRAFFIC MANAGEMENT

♦ S1730HBB0A93- DANGER HIGH

VOLTAGE/SIGN ILLUMINATION

Material Producer List – Roadway Illumination and

Electrical Supplies

40

January 26, 2018

Item 624 -

Ground Boxes – Precast Polymer Concrete

Manufacturer

Brand

Type

Model

Oldcastle Enclosure Solutions

2434 Rubidoux Blvd.

Riverside, CA. 92509

(800) 735-5566

(713) 875-8030

oldcastleprecast.com

Carson Industries, LLC.

is now Oldcastle Enclosure

Solutions 8-29-2013

Model numbers are the same

Oldcastle

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For Type A, B & E

Cover For Type C & D

♦ 13242030

♦ 13242032

♦ 17302061

♦ 17302063

♦ 13242031

♦ 13244159- DANGER HIGH

VOLTAGE/TRAFFIC SIGNALS

♦ 13244156- DANGER HIGH

VOLTAGE/ILLUMINATION

♦ 13244158- DANGER HIGH

VOLTAGE/TRAFFIC MANAGEMENT

♦ 13244157- DANGER HIGH

VOLTAGE

♦ 17304185- DANGER HIGH

VOLTAGE/TRAFFIC SIGNALS

♦ 17304183- DANGER HIGH

VOLTAGE/ILLUMINATION

♦ 17304184- DANGER HIGH

VOLTAGE/TRAFFIC MANAGEMENT

♦ 17304272- DANGER HIGH

VOLTAGE

CDR Systems Corporation

146 South Atlantic Ave.

Ormond Beach, FL. 32176

(386) 615-9510

cdrsystems.com

cdr

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For Type A, B & E

Cover For Type C & D

Cover For All Boxes

♦ SB14-1324-12-0287

♦ SB14-1324-12-0287 - 2 boxes

stacked

♦ SB14-1730-12-0494

♦ SC14-1730-22-0499

♦ SB14-1324-18-0288

♦ SC12-1324-02

♦ SC12-1730-02

♦ All Covers Read “Danger High

Voltage.” Additional Logos Added Per

Job Spec.

Material Producer List – Roadway Illumination and

Electrical Supplies

41

January 26, 2018

Item 624 - Ground Boxes – Precast Polymer Concrete

Manufacturer

Brand

Type

Model

Highline Products, Inc.

131 Hartwell Ave.

Lexington, MA. 02421

(781) 328-3220

highlineproducts.com

Highline

♦ A

♦ B

♦ C

♦ D

♦ E

Cover Logo Information

XX in each model will be

replaced with :

♦ 20

♦ 21

♦ 22

♦ 23

♦ 24

Ordering covers only,

Contact Manufacturer

♦ PHA132412HTD-XX

♦ PHA132424HTD-XX

♦ PHA173012HTD-XX

♦ PHA173024HTD-XX

♦ PHA132418HTD-XX

♦ DANGER HIGH VOLTAGE

♦ DANGER HIGH VOLTAGE/

ILLUMINATION

♦ DANGER HIGH VOLTAGE/ SIGN

ILLUMINATION

♦ DANGER HIGH VOLTAGE/ TRAFFIC

MANAGEMENT

♦ DANGER HIGH VOLTAGE/ TRAFFIC

SIGNALS

Duravault

310 Weathers Dr.

Laredo, TX. 78045

(885) 250-3993

duravault.com

Duravault

♦ A

♦ B

♦ C

♦ D

♦ E

Cover Logo Information

XX in each model will be

replaced with :

Cover For Type A, B & E

Cover For Type C & D

Cover For All Boxes

♦ PC132412STBTXD-XX (122311)

♦ PC132422STBTXD-XX (122322)

♦ PC173012STBTXD-XX (162911)

♦ PC173022STBTXD-XX (162922)

♦ PC132418STBTXD-XX (122317)

♦ PCC1324BTXD-TS/ TRAFFIC

SIGNAL

♦ PCC1324BTXD-IL/ ILLUMINATION

♦ PCC1324BTXD-TM/ TRAFFIC

MANAGEMENT

♦ PCC1324BTXD-SI/ SIGN

ILLUMINATION

♦ PCC1730BTXD-TS/ TRAFFIC

SIGNAL

♦ PCC1730BTXD-IL/ ILLUMINATION

♦ PCC1730BTXD-TM/ TRAFFIC

MANAGEMENT

♦ PCC1730BTXD-SI/ SIGN

ILLUMINATION

All Covers Read “DANGER HIGH

VOLTAGE”

Material Producer List – Roadway Illumination and

Electrical Supplies

42

January 26, 2018

Item 624 -

Ground Boxes – Precast Polymer Concrete

Manufacturer

Brand

Type

Model

Martin Enterprises

19940 Hansen Avenue

Nuevo, CA 92567

(951) 928-8413

martinfrp.com

Martin

♦ A

♦ B

♦ C

♦ D

♦ E

Cover For Type A, B & E

Cover For Type C & D

♦ 1324/12 PC Type A Tier 15 Rated

♦ 1324/24 PC Type B Tier 15 Rated

♦ 1730/18 PC Type C Tier 15 Rated

♦ 1730/24 PC Type D Tier 15 Rated

♦ 1324/18 PC Type E Tier 15 Rated

♦ 1324 Cover Traffic Signal /

DANGER - HIGH VOLTAGE/TRAFFIC

SIGNALS

♦ 1324 Cover Illumination / DANGER

- HIGH VOLTAGE/ILLUMINATION

♦ 1324 Cover Traffic Management /

DANGER - HIGH VOLTAGE/TRAFFIC

MANAGEMENT

♦ 1730 Cover Traffic Signal /

DANGER - HIGH VOLTAGE/TRAFFIC

SIGNALS

♦ 1730 Cover Illumination / DANGER

- HIGH VOLTAGE/ILLUMINATION

♦ 1730 Cover Traffic Management /

DANGER - HIGH VOLTAGE/TRAFFIC

MANAGEMENT

Material Producer List – Roadway Illumination and

Electrical Supplies

43

January 26, 2018

Item 628 – Electrical Services

General

The following products have been tested and are pre-qualified for use on projects where

Electrical Services are furnished or installed. Where miscellaneous parts, brackets,

hardware, nuts, bolts, washers, or other incidentals are necessary and are not shown as

pre-qualified products, the contractor shall furnish products that meet the requirements

of the plans and specifications.

Item 628 -

Electrical Service

Manufacturer

Brand

Type

Model

Electrol Systems

10623 Sentinel Drive

San Antonio, TX 78217

(210) 599-6485

(888) 853-8944

electrolsystems.com

Electrol

♦ A

♦ C

♦ C- Auxiliary Only

♦ D

♦ T- Auxiliary Only

♦ T-All in One

♦ A-Pedestal

♦ D-Pedestal

♦ ELECTROL TYPE A-TXDOT

♦ ELECTROL TYPE C-TXDOT

♦ ELECTROL TYPE C- Auxiliary Only –

TXDOT

♦ ELECTROL TYPE D-TXDOT

♦ ELECTROL TYPE T- Auxiliary Only -

TXDOT

♦ ELECTROL TYPE T- ALL IN ONE

ENCLOSURE –TXDOT

♦ ELECTROL TYPE A-PEDESTAL-TXDOT

♦ ELECTROL TYPE D-PEDESTAL-

TXDOT

WE Manufacturing

5535 Harvey Wilson Drive

Houston , TX 77020

(713) 676-2298

(800) 880-9453

wemanufacturing.com

WE

♦ A

♦ C

♦ C- Auxiliary Only

♦ D

♦ T- Auxiliary Only

♦ T-All in One

♦ A – Pedestal

♦ D-Pedestal

♦ WE TYPE A-TXDOT

♦ WE TYPE C-TXDOT

♦ WE TYPE C- Auxiliary Only –TXDOT

♦ WE TYPE D-TXDOT

♦ WE TYPE T- Auxiliary Only –TXDOT

♦ WE TYPE T- ALL IN ONE ENCLOSURE

–TXDOT

♦ WE TYPE A- PEDESTAL – TXDOT

♦ WE TYPE D-PEDESTAL – TXDOT

Material Producer List – Roadway Illumination and

Electrical Supplies

44

January 26, 2018

Item 628 -

Electrical Service

Manufacturer

Brand

Type

Model

Mica Corporation

P.O. Box 161609

Fort Worth , TX 77020

(817) 847-6121

(817) 577-2088

micacorporation.com

Mica

♦ A

♦ C

♦ D

♦ T- Auxiliary Only

♦ T-All in One

♦ MICA TYPE A-TXDOT

♦ MICA TYPE C-TXDOT

♦ MICA TYPE D-TXDOT

♦ MICA TYPE T- Auxiliary Only –TXDOT

♦ MICA TYPE T- ALL IN ONE

ENCLOSURE –TXDOT

Specialty Control Systems

629 SH 3

League City , TX 77573

(281) 332-0999

specialtycontrol.com

SCS

♦ A

♦ D

♦ T-All in One

♦ D-Pedestal

♦ SCS TYPE A-TXDOT

♦ SCS TYPE D-TXDOT

♦ SCS TYPE T- ALL IN ONE

ENCLOSURE –TXDOT

♦ SCS TYPE D-PEDESTAL-TXDOT

Tesco Controls, Inc.

3434 52nd Ave.

Sacramento , CA 95823

(916) 395-8800

tescocontrols.com

Tesco

♦ A-Pedestal

♦ A-Pedestal

♦ C-Pedestal

♦ D-Pedestal

♦ TESCO TYPE A-PEDESTAL-TXDOT

(120/240)

♦ TESCO TYPE A-1-PEDESTAL-TXDOT

(240/480)

♦ TESCO TYPE C-PEDESTAL-TXDOT

♦ TESCO TYPE D-PEDESTAL-TXDOT

Myers Power Products, Inc.

725 E. Harrison St.

Corona , CA 92879

(951) 520-1900

(866) 696-9377

myerspowerproducts.com

Myers

♦ A-Pedestal

♦ D-Pedestal

♦ D

♦ A

♦ MEUG16 TYPE A-PEDESTAL-TXDOT

♦ MEUG16 TYPE D-PEDESTAL-TXDOT

♦ MYERS TYPE D-TXDOT

♦ MYERS TYPE A-TXDOT

Material Producer List – Roadway Illumination and

Electrical Supplies

45

January 26, 2018

Item 628 - Electrical Service

Manufacturer

Brand

Type

Model

Associated Starters &

Controls

310 Breesport, Ste. D

San Antonio , TX 78216

(210) 798-1334

(888) 798-1334

ASC

♦ A

♦ C

♦ D

♦ T

♦ T-Auxiliary

♦ A - Pedestal

♦ D - Pedestal

♦ ASC TYPE A-TXDOT

♦ ASC TYPE C-TXDOT

♦ ASC TYPE D-TXDOT

♦ ASC TYPE T-TXDOT

♦ ASC TYPE T-AUX-TXDOT

♦ ASC TYPE A-PEDESTAL - TXDOT

♦ ASC TYPE D-PEDESTAL - TXDOT

Milbank Manufacturing Co.

4801 Deramus

Kansas City , MO 64120

(816) 483-5314 (Main

Switch Board)

(660) 463-0800

(Commercial Pedestal)

milbankmfg.com

Milbank

♦ A - Pedestal

♦ A - Pedestal

♦ D - Pedestal

♦ MB TYPE A-PEDESTAL –TXDOT

(120/240)

♦ MB TYPE A-PEDESTAL –TXDOT

(240/480)

♦ MB TYPE D-PEDESTAL –TXDOT

(120/240)

Dynamic Automation &

Controls

10560 Sentinel

San Antonio , TX 78217

(210) 267-2489

(855) 465-6099

dynamic-ac.com

Dynamic

Automation

&

Controls

♦ A

♦ A-Pedestal

♦ D

♦ D-Pedestal

♦ TYPE A-POLE MOUNT

♦ TYPE A-PEDESTAL

♦ TYPE D-POLE MOUNT

♦ TYPE D-PEDESTAL

Material Producer List – Roadway Illumination and

Electrical Supplies

46

January 26, 2018

Item 628 - Photoelectric Control - Photocell

Manufacturer

Brand

Type

Model

Tork

1 Grove Street

Mt. Vernon, NY 10550

(914) 664-5042

tork.com

Tork

♦ 120-277 Volt

Photocell

♦ S895 or

♦ NSI-TORK S895 *

* Tork bought out by NSI

American Electric Lighting /

DTL

P.O. Box 3004

Newark, OH 43800

(800) 754-0463

darktolight.com

DTL

♦ 120-277 Volt

Photocell

♦ DUX124 -12A30

Tyco Electronics

8000 Purfoy Rd.

Fuquay-Varina, NC 27526

(919)557-8459

tycoelectronics.com

Area

Lighting

Research

Tyco

♦ 120-277 Volt

Photocell

♦ ALR-SST-PV-IES-UL

(3E7425-000)

Material Producer List – Roadway Illumination and

Electrical Supplies

47

January 26, 2018

Item 685 – Roadside Flashing Beacon Assemblies

General

The following products are pre-qualified for use on projects where Roadside Flashing

Beacon Assemblies are furnished or installed as required by the item descriptive code.

No substitutions of products will be allowed when pre-qualified products are shown.

Item 685 - Breakaway Holder – Non Fused

Manufacturer

Brand

Type

Model

Mersen USA

374 Merrimac Street

Newburyport, MA 01950

(978) 462-6662

ep-us.mersen.com

Ferraz Shawmut is Now

Mersen.

Parent Company name

change only. Brand of

connector is still

Ferraz Shawmut.

Ferraz

Shawmut

♦ Single Pole

♦ Single Pole

♦ Dummy Fuse (Slug)

♦ FEB-81-81-BA when fused use slug

♦ FEBN-81-81-BA for neutral (non-

fused)

♦ MNL30 - Slug

These breakaway connectors are to

be used

when required by

TxDOT Standards

RFBA

and SPRFBA.

Installing contractor to

supply

dummy fuse-(slug).

Littelfuse Inc.

800 E. Northwest Highway

Des Plaines, IL 60016-3096

(847) 824-1188

littelfuse.com

Littelfuse

♦ Single Pole

♦ Single Pole

♦ Dummy Fuse (Slug)

♦ LEB-JJ-S-WPB1 when fused use slug

♦ LET-JJ-S-WPB1 for neutral (non-

fused)

♦ Not available at this time

These breakaway connectors are to

be used when required by

TxDOT

Standards RFBA and SPRFBA.

Installing contractor to supply dummy

fuse-(slug).

Material Producer List – Roadway Illumination and

Electrical Supplies

48

January 26, 2018

Item 685 -

Breakaway Holder – Non Fused

Manufacturer

Brand

Type

Model

Eaton –Bussmann Series

114 Old State Road

Ellisville, MO 63021

(855) 287-7626

cooperindustries.com

Bussmann

♦ Single Pole

♦ Single Pole

♦ Dummy Fuse (Slug)

♦ HEB-JW-RLC-J when fused use slug

♦ HET-JW-RLC-J for neutral (non-

fused)

♦ NNB - Slug

These breakaway connectors are to

be used when required by

TxDOT

Standards RFBA and SPRFBA.

Installing contractor to supply dummy

fuse-(slug).

Ideal Industries, Inc.

1375 Park Avenue

Sycamore, IL 60178

(800) 435-0705

idealindustries.com

Ideal –

Buchanan

SLK

♦ Single Pole

♦ Single Pole

♦ Dummy Fuse (Slug)

♦ 30-S1212 when fused use slug

♦ 30-S1212N for neutral (non-fused)

♦ Not available at this time

These breakaway connectors are to

be used

when required by

TxDOT Standards

RFBA

and SPRFBA.

Installing contractor to

supply

dummy fuse-(slug).

Material Producer List – Roadway Illumination and

Electrical Supplies

49

January 26, 2018

Item 685 -

Pedestal Pole Base

Manufacturer

Brand

Type

Model

Akron Foundry Company

2728 Wingate Ave.

Akron, OH 44314

(330) 745-3101

akronfoundry.com

Akron

♦ Pedestal Pole Base

♦ Pedestal Pole Base

with Extended Neck

♦ TS-1000

♦ TS-1000-L

Pelco Products, Inc.

320 W. 18th Street

Edmond, OK 73013

(405) 340-3434

pelcoinc.com

Pelco

♦ Pedestal Pole Base

♦ SP-1014 -TX

Component Products, Inc.

521 Morse Avenue

Schaumburg, IL 60193

(800) 807-6537

(847) 301-1000

componentproducts.com

CPI

♦ Pedestal Pole Base

♦ Pedestal Pole Base

with Extended Neck

♦ CPI-BAS-1P (TXDOT)

♦ CPI-BAS-1-PX (TXDOT)

Material Producer List – Roadway Illumination and

Electrical Supplies

50

January 26, 2018

Item 687 – Pedestal Pole Assemblies

General

The following products are pre-qualified for use on projects where Pedestal Pole Bases

are furnished or installed as required by the item descriptive code. Where Pedestal

Poles are necessary and are not shown as pre-qualified products, the contractor shall

furnish products that meet the requirements of the plans and specifications. No

substitutions of products will be allowed when pre-qualified products are shown.

Item 687 - Pedestal Pole Base

Manufacturer

Brand

Type

Model

Akron Foundry Company

2728 Wingate Ave.

Akron, OH 44314

(330) 745-3101

akronfoundry.com

Akron

♦ Pedestal Pole Base

♦ Pedestal Pole Base

with Extended Neck

♦ TS-1000

♦ TS-1000-L

Pelco Products, Inc.

320 W. 18th Street

Edmond, OK 73013

(405) 340-3434

pelcoinc.com

Pelco

♦ Pedestal Pole Base

♦ SP-1014 -TX

Component Products, Inc.

521 Morse Avenue

Schaumburg, IL 60193

(800) 807-6537

(847) 301-1000

componentproducts.com

CPI

♦ Pedestal Pole Base

♦ Pedestal Pole Base

with Extended Neck

♦ CPI-BAS-1P (TXDOT)

♦ CPI-BAS-1-PX (TXDOT)
