Juniper Networks ScreenOS Release
Notes
Release 6.3.0r19
May 2015
Revision 01
Products: Integrated Security Gateway (ISG) 1000, ISG 1000-IDP, ISG 2000, ISG
2000-IDP, Secure Services Gateway (SSG) 5, SSG 20, SSG 140, SSG 300M-series, SSG
500/500M-series, and NetScreen-5000 series (NS 5000–MGT2/SPM2 and NS
5000–MGT3/SPM3).
Contents VersionSummary....................................................9
NewFeaturesandEnhancements......................................9
New Software Features and Enhancements Introduced in 6.3.0 . . . . . . . . . . . 9
Authentication ..............................................10
Antivirus(AV)andWebFiltering................................10
BorderGatewayProtocol(BGP).................................11
CLI ........................................................11
DeviceManagement..........................................11
Dynamic Host Control Protocol (DHCP) . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Internet Protocol Security (IPsec) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Internet Protocol Version 6 (IPv6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
ISG-IDP Diagnostic Improvements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Network Address Translation (NAT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
NetScreen Redundancy Protocol (NSRP) . . . . . . . . . . . . . . . . . . . . . . . . . 16
Other......................................................16
Policies ....................................................18
Routing....................................................20
Security ....................................................21
VirtualPrivateNetwork(VPN)..................................21
ChangestoDefaultBehavior..........................................22
Changes to Default Behavior Introduced in 6.3.0 . . . . . . . . . . . . . . . . . . . . . . 22
Changes to Default Behavior Introduced in 6.3.0r17 . . . . . . . . . . . . . . . . . . . . 23
Changes to Default Behavior Introduced in 6.3.0r13 . . . . . . . . . . . . . . . . . . . . 23
Changes to Default Behavior Introduced in 6.3.0r11 . . . . . . . . . . . . . . . . . . . . . 23
Changes to Default Behavior Introduced in 6.3.0r8 . . . . . . . . . . . . . . . . . . . . . 23
Changes to Default Behavior Introduced in 6.3.0r7 . . . . . . . . . . . . . . . . . . . . . 24
1Copyright © 2015, Juniper Networks, Inc.
Changes to Default Behavior Introduced in 6.3.0r5 . . . . . . . . . . . . . . . . . . . . . 24
Changes to Default Behavior Introduced in 6.3.0r4 . . . . . . . . . . . . . . . . . . . . . 24
Changes to Default Behavior Introduced in 6.3.0r3 . . . . . . . . . . . . . . . . . . . . . 24
Changes to Default Behavior Introduced in 6.3.0r1 . . . . . . . . . . . . . . . . . . . . . 24
Network and Security Manager (NSM) Compatibility . . . . . . . . . . . . . . . . . . . . . . 25
Detector and Attack Objects Update (only for ISG-IDP) . . . . . . . . . . . . . . . . . . . . 25
AddressedIssues...................................................25
Addressed Issues in ScreenOS 6.3.0r19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Admin.....................................................26
Antivirus...................................................26
DNS ......................................................26
WebUI.....................................................26
Others ....................................................26
Routing ....................................................27
Security....................................................27
VPN.......................................................27
Addressed Issues from ScreenOS 6.3.0r18 . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Admin.....................................................28
Antivirus...................................................28
WebUI ....................................................28
Others ....................................................28
Routing....................................................29
Security ...................................................29
VPN ......................................................29
Addressed Issues from ScreenOS 6.3.0r17 . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
CLI .......................................................29
Others ....................................................30
Security ...................................................30
Routing ....................................................31
VPN.......................................................31
WebUI .....................................................31
Addressed Issues from ScreenOS 6.3.0r16 . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Others.....................................................32
Security....................................................32
WebUI.....................................................33
Addressed Issues from ScreenOS 6.3.0r15 . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
CLI........................................................33
Others.....................................................33
Security ...................................................35
VPN ......................................................35
WebUI.....................................................35
Addressed Issues from ScreenOS 6.3.0r14 . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Admin.....................................................36
ALG.......................................................36
Antivirus(AV)...............................................36
Others ....................................................36
Routing ....................................................37
Security....................................................37
VPN.......................................................37
Copyright © 2015, Juniper Networks, Inc.2
ScreenOS 6.3.0 Release Notes
WebUI.....................................................37
Addressed Issues from ScreenOS 6.3.0r13 . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
ALG.......................................................38
Antivirus(AV)...............................................38
Logging....................................................38
Other .....................................................38
Routing....................................................39
Screen ....................................................39
SNMP.....................................................39
VPN ......................................................39
WebUI ....................................................39
Addressed Issues from ScreenOS 6.3.0r12 . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
ALG ......................................................40
Authentication..............................................40
Antivirus (AV) ..............................................40
Logging ...................................................40
Management...............................................40
NSRP .....................................................40
Other .....................................................40
Routing....................................................42
SNMP.....................................................42
VPN ......................................................43
WebUI.....................................................43
Addressed Issues from ScreenOS 6.3.0r11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
ALG.......................................................43
Antivirus(AV)...............................................43
IDP .......................................................43
Management ...............................................43
NAT ......................................................44
NSRP .....................................................44
Other .....................................................44
Routing....................................................45
VoIP ......................................................46
VPN ......................................................46
WebUI ....................................................46
Addressed Issues from ScreenOS 6.3.0r10 . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
ALG.......................................................46
IDP .......................................................46
Management ...............................................46
NSRP .....................................................47
Other .....................................................47
Performance ...............................................48
Routing....................................................48
Security ...................................................48
VOIP......................................................48
VPN ......................................................49
WebUI ....................................................49
3Copyright © 2015, Juniper Networks, Inc.
Addressed Issues from ScreenOS 6.3.0r9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Administration..............................................49
ALG.......................................................49
HA&NSRP................................................49
IDP .......................................................49
Management...............................................50
Other .....................................................50
Performance................................................51
Routing ....................................................51
VOIP ......................................................51
VPN.......................................................51
WebUI .....................................................51
Addressed Issues from ScreenOS 6.3.0r8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Administration ..............................................52
ALG.......................................................52
Antivirus ...................................................52
Authentication..............................................52
CLI........................................................52
DNS ......................................................52
IDP .......................................................52
Management ...............................................53
Other .....................................................53
Routing....................................................54
VPN ......................................................54
WebUI ....................................................54
Addressed Issues from ScreenOS 6.3.0r7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
ALG.......................................................54
Antivirus...................................................54
Authentication..............................................55
CLI .......................................................55
Management ...............................................55
NAT.......................................................55
Other .....................................................55
Routing....................................................56
VoIP ......................................................56
VPN ......................................................56
WebUI.....................................................57
Addressed Issues from ScreenOS 6.3.0r6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Administration..............................................58
Antivirus...................................................58
Authentication..............................................58
CLI .......................................................58
DI ........................................................58
DNS ......................................................58
GPRS .....................................................58
HA&NSRP................................................58
IDP .......................................................59
Management ...............................................59
Other .....................................................59
Copyright © 2015, Juniper Networks, Inc.4
ScreenOS 6.3.0 Release Notes
Routing ...................................................60
Security ...................................................60
VoIP ......................................................60
VPN ......................................................60
WebUI .....................................................61
Addressed Issues from ScreenOS 6.3.0r5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Administration ..............................................61
Antivirus ...................................................61
Authentication ..............................................61
DHCP .....................................................62
DI ........................................................62
HA&NSRP................................................62
IDP .......................................................62
Management ...............................................62
NAT.......................................................62
Other .....................................................62
Routing....................................................63
VoIP ......................................................63
VPN ......................................................63
Addressed Issues from ScreenOS 6.3.0r4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Administration..............................................64
ALG.......................................................64
Antivirus...................................................64
Authentication..............................................64
CLI .......................................................64
DHCP .....................................................64
HA&NSRP................................................64
IDP .......................................................64
Management ...............................................65
Other .....................................................65
Performance ...............................................67
Routing....................................................67
VoIP ......................................................67
VPN ......................................................67
WebUI.....................................................67
Addressed Issues from ScreenOS 6.3.0r3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Administration..............................................68
Antivirus...................................................68
DHCP .....................................................68
GPRS .....................................................68
HAandNSRP..............................................69
IDP .......................................................69
Management...............................................69
NAT.......................................................70
Other .....................................................70
Performance ................................................71
Routing ....................................................71
VoIP.......................................................72
VPN.......................................................72
5Copyright © 2015, Juniper Networks, Inc.
WebUI.....................................................72
Addressed Issues from ScreenOS 6.3.0r2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Administration ..............................................73
Antivirus(AV)...............................................73
Authentication ..............................................73
CommandLineInterface(CLI).................................74
DeepInspection(DI).........................................74
DomainNameSystem(DNS)..................................74
General Packet Radio Service (GPRS) . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
High Availability and NetScreen Redundancy Protocol (HA and
NSRP) .................................................74
Intrusion Detection and Prevention (IDP) . . . . . . . . . . . . . . . . . . . . . . . . . 74
Management ...............................................74
Network Address Translation (NAT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Other......................................................75
Performance ...............................................76
Routing....................................................76
Voice-over-Internet Protocol (VoIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
VirtualPrivateNetwork(VPN).................................76
WebUI .....................................................77
Addressed Issues from ScreenOS 6.3.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Administration ..............................................77
ApplicationLayerGateway(ALG)...............................77
Antivirus(AV)...............................................77
Authentication..............................................78
CommandLineInterface(CLI).................................78
DeepInspection(DI).........................................78
DomainNameSystem(DNS)..................................78
Flow ......................................................78
General Packet Radio Service (GPRS) . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
High Availability and NetScreen Redundancy Protocol (HA and
NSRP).................................................79
Intrusion Detection and Prevention (IDP) . . . . . . . . . . . . . . . . . . . . . . . . . 79
Internet Protocol Version 6 (IPv6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Management...............................................80
Network Address Translation (NAT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Other......................................................81
Performance ...............................................82
Routing....................................................82
Voice-over-Internet Protocol (VoIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
VirtualPrivateNetwork(VPN).................................83
WebUI ....................................................83
KnownIssues......................................................84
KnownIssuesinScreenOS6.3.0r19.................................84
Others ....................................................84
Security ...................................................84
WebUI ....................................................84
Known Issues from ScreenOS 6.3.0r18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Known Issues from ScreenOS 6.3.0r17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Copyright © 2015, Juniper Networks, Inc.6
ScreenOS 6.3.0 Release Notes
Known Issues from ScreenOS 6.3.0r16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Known Issues from ScreenOS 6.3.0r15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Known Issues from ScreenOS 6.3.0r14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Known Issues from ScreenOS 6.3.0r13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Known Issues from ScreenOS 6.3.0r12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Other .....................................................85
Known Issues from ScreenOS 6.3.0r11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
ALG.......................................................85
Management ...............................................85
Other .....................................................85
Routing....................................................86
VPN ......................................................86
Known Issues from ScreenOS 6.3.0r10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
IDP .......................................................86
NSRP .....................................................86
Other .....................................................86
VPN ......................................................87
Known Issues from ScreenOS 6.3.0r9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
DHCP .....................................................87
Management ...............................................87
Other .....................................................87
Performance ...............................................88
VPN ......................................................88
WebUI ....................................................88
Known Issues from ScreenOS 6.3.0r8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
ALG ......................................................88
Management...............................................88
Other .....................................................88
UTM......................................................88
VoIP ......................................................89
VPN ......................................................89
WebUI ....................................................89
Known Issues from ScreenOS 6.3.0r7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Admin.....................................................89
Antivirus...................................................89
Authentication..............................................89
CLI .......................................................89
DNS ......................................................89
IDP .......................................................89
Management...............................................90
Other .....................................................90
Routing ...................................................90
VPN ......................................................90
WebUI .....................................................91
Known Issues from ScreenOS 6.3.0r6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Known Issues from ScreenOS 6.3.0r5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Known Issues from ScreenOS 6.3.0r4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Other......................................................91
VPN.......................................................91
7Copyright © 2015, Juniper Networks, Inc.
Known Issues from ScreenOS 6.3.0r3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Known Issues from ScreenOS 6.3.0r2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Antivirus(AV)...............................................92
DHCP .....................................................92
General Packet Radio Service (GPRS) . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Intrusion Detection and Prevention (IDP) . . . . . . . . . . . . . . . . . . . . . . . . . 92
Management ...............................................92
Network Address Translation (NAT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Other .....................................................92
Performance ...............................................93
Routing....................................................93
VirtualPrivateNetwork(VPN).................................93
KnownIssuesfromScreenOS6.3.0.................................93
Flow ......................................................94
General Packet Radio Service (GPRS) . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Hardware..................................................94
Intrusion Detection and Prevention (IDP) . . . . . . . . . . . . . . . . . . . . . . . . 94
Other .....................................................94
Routing....................................................95
Voice-over-Internet Protocol (VoIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Security ...................................................95
VirtualPrivateNetwork(VPN).................................95
Errata ............................................................95
Concepts & Examples ScreenOS Reference Guide . . . . . . . . . . . . . . . . . . . . . 96
ScreenOS CLI Reference Guide: Command Descriptions . . . . . . . . . . . . . . . 108
ScreenOS Message Log Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
ScreenOSOnlineHelp...........................................110
Hardware Installation and Configuration Guide . . . . . . . . . . . . . . . . . . . . . . . . 111
ScreenOSUpgradeGuide.........................................111
LimitationsandCompatibility.........................................112
Limitations of Features in ScreenOS 6.3.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
DocumentationChanges.............................................115
Getting Help for ScreenOS 6.3.0 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Copyright © 2015, Juniper Networks, Inc.8
ScreenOS 6.3.0 Release Notes
Version Summary
ScreenOS 6.3.0 firmware can be installed on the following products: Secure Services
Gateway (SSG) 5, SSG 20, SSG 140, SSG 320M/350M, SSG 520/520M, SSG 550/550M,
Integrated Services Gateway (ISG) 1000, ISG 1000-IDP, ISG 2000, ISG 2000-IDP, and
NetScreen-5000 series with the NS 5000-MGT2/SPM2 and NS 5000-MGT3/SPM3.
This release incorporates bug fixes from ScreenOS maintenance releases 5.4.0r26 to
6.3.0r18.
NOTE:
•If you are using an SSG 500-series device and an SSG 500M-series device
in a NetScreen Redundancy Protocol (NSRP) environment, all devices
must be running ScreenOS 6.0.0r1 or later.
•NSRP clusters require the use of the same hardware products within a
cluster. Do not mix different product models in NSRP deployments. The
exception to this rule is SSG 500-series and 500M-series devices, which
can be used together in a cluster.
New Features and Enhancements
The following sections describe new features and enhancements available in the
ScreenOS 6.3.0 release.
NOTE: You must register your product at http://support.juniper.net to activate
licensed features such as antivirus (AV), deep inspection (DI), and virtual
systems (vsys) on the device. To register your product, you need the model
and serial numbers of the device. At the support page:
•If you already have an account, enter your user ID and password.
•If you are a new Juniper Networks customer, first create an account, then
enter your ID and password.
After registering your product, confirm that your device has Internet
connectivity. Use the exec license-key update all command to connect the
device to the Juniper Networks server and activate your desired features.
New Software Features and Enhancements Introduced in 6.3.0
The following sections describe the new features introduced in the ScreenOS 6.3.0
release.
9Copyright © 2015, Juniper Networks, Inc.
Version Summary
Authentication
•User Authentication—Beginning with ScreenOS 6.3.0, the Juniper Networks security
device supports authentication redirection for HTTP traffic that is directed to a
nonstandard destination port.
Antivirus (AV) and Web Filtering
•Sophos Anti-Spam to replace Symantec Anti-Spam—Beginning mid-September
2009, Sophos Anti-Spam service will be made available to the ScreenOS-based
products; SSG, and ISG. The Sophos Anti-Spam service will replace the Symantec
Anti-Spam.
There will be no impact to customers running any version of ScreenOS. No configuration
changes are required. The redirection to Sophos servers will be automatic and
transparent to the end-user. The security devices will be pointed to the Sophos servers.
•Antispam—Beginning with ScreenOS 6.2.0, Antispam enhancement inspects the
parameters in the received email header.
•Juniper Full Antivirus Database—Beginning with ScreenOS 6.3.0, Kaspersky Lab
supports only a single antivirus database known as Juniper Full Antivirus Database.
The existing databases such as extended, itw and standard are removed.
•Virus Description and Alert Message—If the data sent in FTP or HTTP Traffic contains
a virus, the security device replaces the data with a warning message or drops the data.
In both cases, a message with a URL link that describes the virus is logged.
For SMTP, IMAP and POP3 Traffic, the security device in addition to the above, changes
the content type to text/plain, replaces the body of the message with a notice and a
URL link that describes the virus, sends it to the appropriate recipient, and notifies the
sender.
•Web Filtering Whitelists and Blacklists Without a License—Web filtering supports
the following features even if the license key is not installed or has expired:
•Define Web-filtering profiles and bind them to policies
•Retrieve category information for HTTP requests
•Define static whitelist and blacklist categories
•Check cache for categories
NOTE: The device does not support checking the cache for categories
if the key is not installed, but it does support this check if the key is
expired.
•Integrated Web Filtering Based on Group Membership—In the previous release, the
URL filter profile was bound to policy. Beginning with ScreenOS 6.3.0 release, the
administrator can bind the profile to user group. The Web Filtering (WF) Manager
extracts the URL from the request and identifies the username and user group
Copyright © 2015, Juniper Networks, Inc.10
ScreenOS 6.3.0 Release Notes
associated with the IP address. If the user belongs to multiple user groups, the WF
Manager binds the profile with the user group that has highest priority. Then, the WF
Manager identifies the category of the URL and permits or blocks the request
accordingly. User groups can be prioritized.
•Increased Number of Web-Filtering Profiles on SSG 500–series—For integrated Web
filtering, the number of customer-defined profiles for SSG 550 and SSG 520 devices
is increased to 300 profiles from 50 (SSG 550) and 25 (SSG 520).
Border Gateway Protocol (BGP)
•Redistributing Routes in BGP—For each virtual router (VR), BGP can support up to
17000 redistributable routes. The increase in redistributable routes in BGP to 17000
applies to the NetScreen-5000 platforms only.
•Display Format of BGP Community Lists—Beginning with ScreenOS 6.3.0, the
configuration file displays the BGP community lists in a new AA NN format, where AA
identifies autonomous system and NN identifies community. This new format is in
compliance with RFC-1997.
CLI
•x-in-ip
set envar x-in-ip
In [ISG-1000 and ISG-2000] devices, Protocol 97 forwards traffic through
CPU and not hardware, causing high CPU. To allow the unknown protocols
like Protocol 97, use the following command: set envar x-in-ip=yes
Use unset command to disable envar.
x-in-ip
Example: The following command allows the unknown protocols like Protocol 97 on
the device:
set envar x-in-ip=yes
reset
Device Management
•Enabling Syslog on Backup Devices—By default, backup devices in an active/passive
NSRP configuration send all syslog messages to the syslog server. This allows an
administrator to effectively monitor backup devices.
•Simple Network Management Protocol Version 3 (SNMPv3)— ScreenOS 6.3.0
supports SNMPv3 framework. System status data can be collected securely from the
device without the data being tampered with and corrupted. The SNMPv3 USM allows
ScreenOS to encrypt the confidential information to prevent the contents from being
exposed on the network. The SNMPv3 VACM provides a configurable access control
model for easy administration.
•Interface Administrative Status—ScreenOS 6.3.0 supports a command for setting
an interface administrative status to the down state. By default, the administrative
11Copyright © 2015, Juniper Networks, Inc.
New Features and Enhancements
status of an interface is set as up. The administrator can disable the administrative
status of an interface with the CLI:
set interface xx disable
•Increased Number of Hosts per SNMP Community—Beginning with the ScreenOS
6.3.0 release, you can configure 64 hosts per SNMP community. In earlier releases of
ScreenOS, this value was limited to no more than 40 hosts per SNMP community.
•Include Device Serial Number in Log Messages—Beginning with the ScreenOS 6.3.0
release, for system logs, the device serial number is used as a unique device identifier
within the logs.
•VLAN1 Interface to Support DHCP and AUTO Configuration—Beginning with the
ScreenOS 6.3.0 release, the VLAN1 interface of a device in transparent mode supports
the DHCP client and AUTO CONFIG features.
•Loading Configuration from USB—When the SSG device initializes, and if the
administrator has configured envar properly, then ScreenOS can check if the USB
device is connected to the port and loads the configuration file usb: auto_config.txt (if
the file is stored in the USB device).
Dynamic Host Control Protocol (DHCP)
•DHCP support—The maximum number of DHCP relay agents supported is enhanced
from 3 to 4.
Internet Protocol Security (IPsec)
•AC VPN Enhancements—ScreenOS 6.3.0 supports dual-hub Auto Connect virtual
private network (AC-VPN) where one hub remains active, passing the traffic from one
spoke to another spoke until a dynamic VPN tunnel is established. The hub with the
highest routing instance priority becomes the active one. The spokes use the VPN
monitoring feature to check the status of the hubs. When the hub acting as a primary
fails, the dynamic tunnel and its associated NHRP routing instance are removed at
both the spokes. Traffic begins to pass through the other hub, which creates a new
dynamic tunnel. If the failed hub comes back, the spokes choose this hub again because
of the priority setting. However, the traffic continues to flow through the newly created
dynamic tunnel until the other fails.
•Support for Multiple Proxy IDs Over Route-Based VPN—ScreenOS 6.3.0 supports
multiple proxy IDs on a route-based VPN. If multiple tunnels exist between peers, the
security device uses proxy IDs to route the traffic through a particular tunnel. For each
proxy ID, a specific tunnel and Phase 2 SA are associated. When traffic matching a
proxy ID arrives, the security device does a proxy-ID check to route that traffic. If multiple
proxy IDs are defined for a route-based VPN, a proxy ID check is always performed,
even if it is disabled. In a hub-and-spoke topology, proxy IDs should be defined for both
hub-to-spoke and spoke-to-spoke configurations.
•DPD Enhancement—ScreenOS 6.3.0 provides a DPD enhancement that allows the
dead peer to failover the tunnel to another VPN group member with the second highest
weight. It uses the DPD reconnect parameter to renegotiate the tunnel with the dead
Copyright © 2015, Juniper Networks, Inc.12
ScreenOS 6.3.0 Release Notes
peer at specific intervals. If the tunnel is successfully renegotiated, the tunnel fails back
to the first member.
•Elliptical Curve Diffie-Hellman Key Arrangement—ScreenOS 6.3.0 supports elliptical
curve Diffie-Hellman (ECDH) groups 19 and 20 for Internet Key Exchange version 1
(IKEv1) key exchange. ECDH uses elliptical curve cryptography to generate public-private
key pair. The module sizes of DH groups 19 and 20 are 256 bits and 384 bits ECDH
prime curves, respectively.
•Support Authentication Header Transport Mode—[ISG 1000/2000, NS 5200/5400
M2/SPM2 , NS 5200/5400 M3/SPM3] ScreenOS 6.3.0 supports authentication header
(AH) transport mode on high-end systems for IPv4 packets only. This feature does not
work if IPv6 is enabled in the system environment.
•IKEv2 Configuration Payload (CP) and Dial-up Support—Support for IKEv2
configuration payload (CP) for dynamic end points and IKEv2 dial-up group user VPN
is available in this release. For details on the implementation, refer to the Concepts &
Examples ScreenOS 6.3.0 Reference Guide.
Internet Protocol Version 6 (IPv6)
•Support OSPFv3 for IPv6 —Beginning ScreenOS 6.3.0, Juniper Networks security
device supports OSPFv3 for IPv6. Most configuration and operational commands
function essentially the same as in OSPFv2.
OSPFv3 does not support the following features:
•NBMA link and neighbor authentication
•Demand Circuit and NSSA
•Multiple instances per link.
OSPFv3 is supported across all platforms. However, advanced mode license is required
to run it on the following devices:
•ISG1000
•ISG1000 with SM
•ISG2000
•ISG2000 with SM
•Command to Inhibit AAAA Requests over IPv4—ScreenOS 6.3.0 provides an option
to enable or disable the Network Address Translation-Port Translation Domain Name
System Application Layer Gateway (NAT-PT DNS ALG) to modify DNS requests
received from the IPv6 domain. Besides translating the addresses for transmitted DNS
requests, the NAT-PT DNS ALG also modifies the DNS request before forwarding it to
another domain that has only IPv4 addresses. By default, this option is disabled.
•IPv6 Prefix and DNS Information Update—ScreenOS 6.3.0 supports dynamic IPv6
prefix and DNS information update from the upstream DHCPv6 server. A CPE router
acting as a DHCPv6 and PPPoE client negotiates IPv6 prefixes and DNS information
for the downstream DHCPv6 server on the other interface of the same CPE router. If
the connection between the CPE router and the upstream DHCPv6 server is
13Copyright © 2015, Juniper Networks, Inc.
New Features and Enhancements
disconnected and then re-established, the CPE router updates the newly learned IPv6
prefix and DNS information dynamically on the downstream DHCPv6 server without
waiting for the delegated prefix to expire.
•SIBR IPv6 Support—Beginning with ScreenOS 6.3.0r13, the Source Interface-Based
Routing (SIBR) feature supports IPv6 SIBR tables. When SIBR is enabled in a virtual
router (VR), the security device performs route lookup in an SIBR routing table. The
configuration of this feature remains the same, except for the fact that the interface
gateway cannot be used as a next-hop if the IPv6 gateway parameter is not specified.
The CLI command is updated as:set vrouter <vr_name> route source in-interface
<interface_name> <IPVX_addr1/mask> interface <interface_name> gateway
<IPVX_addr2>
•Client-to-Site IPv6 VPN Support—Beginning with ScreenOS 6.3.0r13, configuring IPv6
addresses from a server to a client is now supported with IPv6 IP pools. A new command
has been introduced:set ippool [ippool name]<ipv6 address> <ipv6 address>.
ISG-IDP Diagnostic Improvements
•IPv6 Full Support on ISG-IDP—Beginning with ScreenOS 6.3.0, ISG Security Module
provides IPv6 support for the following features: packet capture and packet logs for
IPV6 traffic; configure header match information for IPv6 traffic and ICMPv6 messages;
IPv6 traceroute anomaly; IPv6 log messages in the NSM log viewer.
•ISG-IDP Means to Identify the Secure Module (SM) Used by a Session—Beginning
with ScreenOS 6.3.0, users can identify which SM card and CPU a session is using. It
is possible to filter the session table output with the CLI command get session sm-slot
slot-id sm-cpu cpu-no.
•Command for Displaying CPU Usage on SM—Beginning with ScreenOS 6.3.0, users
can enable the security device to calculate the CPU usage of the ISG Security Module
for the last 60 seconds, last 60 minutes, and last 24 hours by using the
sc_enable_cpu_usage parameter.
•Transfer Core Dump to the Management Module Flash or Compact Flash—Beginning
with ScreenOS 6.3.0, users can transfer the core dump files from the RAM disk of the
ISG Security Module to the flash memory of the management module using the CLI
command set sm-ctx coresave.
•SNMP Trap and Event Log Entries for ISG with IDP—From ScreenOS 6.3.0, ISG Security
Module supports generating log messages and SNMP Traps when CPU usage, memory
usage, and session count per IDP security module exceeds the user-defined threshold.
The device also generates messages when it detects an IDP security module failure.
NOTE: The user-defined threshold value is not stored in NSM. The value
is reset to the default once the system reboots.
•Inspection of Multicast traffic by IDP Security Module—Beginning with ScreenOS
6.3.0, users can enable ISG Security Module to inspect multicast traffic by using the
CLI command set flow multicast idp.
Copyright © 2015, Juniper Networks, Inc.14
ScreenOS 6.3.0 Release Notes
NOTE: For multicast traffic inspection, all outgoing interfaces should belong
to the same zone.
•UAC Integration with Role-Based IDP Policy—From ScreenOS 6.3.0, ISG Security
Module can support role-based IDP policy. Administrators can configure the security
device to inspect traffic using either user roles or source IPs. When user-role-based
IDP inspection is selected, the security device starts checking user-role-based policies
first; if a match is not found, only then the security device searches for IP-based rules.
This feature requires UAC deployment and role information is provided by Infranet
Controller.
Network Address Translation (NAT)
•Enhancement to IKE and ESP Passthrough Traffic—Beginning with ScreenOS 6.3.0,
Network Address Translation (NAT) supports both NAT-Traversal and
Non-NAT-Traversal IKE and IPsec passthrough traffic. The Application Layer Gateway
(ALG) is enabled to support interface NAT and IKE DIP pool NAT.
•Support for More Than 62946 Sessions per IP in a DIP Pool —When the security
device performs NAT-src with a DIP pool containing an IP address range with PAT
enabled, each DIP:DPort pair can only be assigned to one session. Beginning with
ScreenOS 6.3.0, you can enable DIP to support multiple sessions per DIP:DPort. The
DIP pool supports multiple session per DIP:DPort only if two packets have different
destination IP addresses. After configuring the DIP pool scale size, every IP address
contains multiple port pools that consist of all available ports for an IP address. Every
IP can support up to scale-size* 62463 sessions.
The maximum scale size for an interface cannot exceed the DIP scale size value
specified in the vsys profile.
•TCP Session Close Notification—ScreenOS sends a TCP session close notification
ACK message to both the client and the server when a session is being closed.
To enable a policy to send TCP session close notification, complete the following
prerequisites:
•You must enable TCP SYN checking and TCP reset options in both the client and
the server zones.
•You must enable TCP sequence check only for ISG 1000/2000 and NS 5200/5400.
•Creating a Session Cache to Accelerate HTTP Traffic—Beginning with ScreenOS
6.3.0, you can create a session cache for HTTP-based protocols to minimize CPU
utilization and to enhance performance. A session cache is a special structure that
caches all the reusable information of both software and hardware sessions created
by the first connection of an HTTP session bundle.
A session cache supports other traffic but does not ensure performance enhancement.
You cannot create a session cache for the following conditions:
•When the session is synched from another security device.
15Copyright © 2015, Juniper Networks, Inc.
New Features and Enhancements
•When the session is created by an Application Layer Gateway (ALG).
•Importing Traffic to the Correct VSI by Proxy ARP—The administrator can enable
importation of traffic to the correct VSI by setting the proxy ARP entry. Upon adding a
proxy ARP entry on an interface, ScreenOS imports the traffic that is destined to the
IP range using this interface.
You can use the CLI command proxy-arp-entry or WebUI Network > Interface > Edit>
Proxy ARP Entries to set the proxy ARP entry.
•NAT-Dst Port Shift using VIP—Using the port-range VIP entry, a range of ports can be
mapped between Virtual IP and Real Server IP.
NetScreen Redundancy Protocol (NSRP)
•Add More Detail to the Output of get nsrp—The output of the get nsrp vsd-group
command includes a new column; the uptime column for VSD group or myself uptime
column for current security device denotes the duration in the primary or backup state.
Other
•Hot Patch Management—Beginning with ScreenOS 6.3.0, the hot patch enables
injecting the customer service patch into the running image without rebooting the
security device. The hot patch as debug patch provides for easier debugging.
The ScreenOS hot patch management component runs on the security device and
performs the following functions:
•Loads the hot patch file from TFTP to flash memory
•Removes the hot patch file from flash memory
•Maintains the patch finite state machine (FSM)
•Cache Recently Used Route and ARP Entries—Beginning with ScreenOS 6.3.0, Juniper
Networks security device allows the user to cache recently used route and ARP entries
for destination routes by using the set flow route-cache command. This feature does
not work if ECMP is enabled.
•Ability to Add exec and save Commands to Scripting Tool—Beginning with ScreenOS
6.3.0 release, the ScreenOS scripting tool supports the exec and save commands.
These commands are visible in the script context record. The parser identifies these
commands in the script record context and saves them into the script. This
enhancement enables the user to execute commands that facilitate troubleshooting.
•Timeout for Track IP—Beginning with ScreenOS 6.3.0, the user can set the maximum
timeout value for track IP.
•Boot with Default Gateway IP—The new ScreenOS boot loader allows you to define
a default gateway IP, then user can download image from a remote TFTP server.
•Identifying Gigabit Interface—Beginning with ScreenOS 6.3.0, users can identify the
type of gigabit interface using the CLI command get interface interface-name.
Copyright © 2015, Juniper Networks, Inc.16
ScreenOS 6.3.0 Release Notes
•Boot Loader for SSG and Boot ROM Version for ISG or NetScreen–5000 series
Displayed in CLI—Beginning with ScreenOS 6.3.0, you can view the boot loader for an
SSG device and boot ROM version for ISG or NetScreen–5000 device using the get
system command.
Example 1:
ssg20-> get system
BOOT Loader Version: 1.3.2
Example 2:
nsisg2000-> get system
BOOT ROM Version: 1.1.0
•WELF Log Format Enhancement—Beginning with ScreenOS 6.3.0, enhancements
have been made to the event log, traffic log and IDP log formats to follow the WELF
log regulation. If backup for the logs is enabled, logs can be sent to a maximum of four
Webtrends servers. TCP or UDP transport protocol can be used for communication.
IP connections can be manually reset. The following log types must be sent along with
the appropriate heading prefix:
•Configuration log [Config Change]
•URL Filter Detection [URL filtering]
•AntiVirus Detection [AntiVirus]
•Antispam Detection [AntiSpam]
•IPS/DI Detection [IPS/DI]
•Screen Attack [Attack]
•SCTP Protocol Filtering—Beginning with ScreenOS 6.3.0, the existing Stream Control
Transmission Protocol (SCTP) stateful firewall supports protocol filtering. You can
configure the security device to permit or deny traffic based on the SCTP Payload
Protocol and M3UA Service Indicator. The Payload Protocol identifies the type of data
being carried out by the SCTP data chunk, the M3UA Service Indicator identifies the
type of data being carried out by the M3UA data message. Based on the Payload
Protocol, you can create an SCTP profile and bind it to a policy.
NOTE: ScreenOS supports SCTP protocol filtering on NetScreen-5000
and ISG series devices only.
•Converting join-group igmp Commands to exec join-group—Beginning with ScreenOS
6.3.0, the exec join-group and exec leave-group commands replace the set igmp
join-group and unset igmp join-group commands. The exec join-group command replaces
the set join-group command. The exec leave-group command replaces the unset
join-group command. There is no impact on the functionality of the commands. The
set and unset commands are deprecated.
•Boot Loader for SSG-140—A new boot loader version Loadssg140v326.d has been
released for SSG-140 platform. For more information, see the JTAC knowledge base
number KB 23407 located at http://kb.juniper.net/KB23407
17Copyright © 2015, Juniper Networks, Inc.
New Features and Enhancements
Policies
•Policy Installation Enhancement —Beginning with ScreenOS 6.3.0, the policy
installation process has been enhanced.
The new process provides the following advantages:
•Avoids frequent policy re-installation caused by dynamic DNS address changes.
•Eliminates traffic drops while installing the policy.
•Allows the user to configure the hold-interval option of policy installation using the
following CLI command:
set policy install hold-interval seconds
The default value is 5 seconds. The minimum is 0 and the maximum is 10. This
command specifies the maximum time interval between when policy configuration
occurs and actual policy installation begins. When the user creates a new policy or
modifies an existing policy, the policy installation is delayed by up to the value of
hold-interval value specified. This allows the system to more efficiently process the
session table by handling several updates at once or by reducing the thrashing caused
by extremely rapid updates.
unset policy install hold-interval
The unset command resets the default value of hold-interval.
Example: To configure hold-interval option to 2 seconds:
set policy install hold-interval 2
•DSCP Marking for Self-Initiated Traffic—Beginning in ScreenOS 6.3.0r12, you can
configure IKE packets with DSCP values for self-initiated packets. During IKE module
process negotiation, the configured IKE packets marked with the values can be used.
To mark the IKE packets with the specified value, enable the service using the command
set ip service ike dscp <dscp-value>.
•DSCP Marking Based on Policy Configuration—In ScreenOS 6.3.0r12, when a session
matches a policy with DSCP enabled, the bidirectional traffic performs the DSCP
marking.
The DSCP feature is now enhanced to prevent DSCP re-marking packets that already
have a DSCP value. This feature enables a DSCP group to have more than one DSCP
value for a packet.
The DSCP marking for each packet is checked to determine whether the DSCP value
belongs to a DSCP group before the packet does the DSCP marking. If the DSCP value
does not belong to a DSCP group, the device retains the packet's DSCP value.
Low-End Platforms—For CPU-based platforms, all packets in the first path or fast
path are checked for DSCP value and DSCP marking based on policy configuration.
The configuration is effective in all conditions irrespective of whether the first packet
matches the policy configuration or not.
High-End Platforms—For high-end platforms, the DSCP marking for fast path is
processed by the ASIC according to the session installed by the first path. Only the first
Copyright © 2015, Juniper Networks, Inc.18
ScreenOS 6.3.0 Release Notes
path is checked for the DSCP value to determine the DSCP marking based on policy
configuration.
If the first packet arrives with an existing DSCP value and if the DSCP value does not
belong to the DSCP group in the policy configuration, then the session will not perform
DSCP marking for that packet. Subsequent packets in the session will also not have
the DSCP marking done even if the DSCP value matches the DSCP group in the policy
configuration.
NOTE: If the policy has been configured as no-hw-sess in high-end
platforms, then the implementation is same as in low-end platforms, as
all the packets are processed by the CPU.
The DSCP group is used to classify traffic within the device and to classify a number
of DCSP values having the same behavior as the configured DSCP group. The DSCP
group allows you :
•To create a DSCP group and to define the DSCP group type. The maximum number
of DSCP groups allowed per VSYS is 64. The DSCP group types are:
•Include—Specifies adding or including the DSCP values to the configured DSCP
group . By default, the DSCP value for a group is zero.
set dscp-group name <group name> include
•Exclude—Specifies to removing or excluding the DSCP values from the configured
DSCP group. By default, the group contains 64 DSCP values.
set dscp-group name <group name> exclude
•To configure a DSCP value for a policy. If a DSCP value is not configured for any
policy, then you can insert a DSCP value into a DSCP group, or you can delete a DSCP
value from a DSCP group.
set dscp-group <group name> dscp-value <low number>-<high number>
•To display the DSCP group information.
get dscp-group <group name>
•To bind a DSCP group to a policy for low-end platforms:
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic dscp enable <value> group-dscp <group name>
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic dscp enable group-dscp <group name>
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic dscp enable value <value> group-dscp <group name>
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic dscp enable group-dscp <group name>
•To bind a DSCP group to a policy for high-end platforms:
19Copyright © 2015, Juniper Networks, Inc.
New Features and Enhancements
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic priority <value> dscp value <value> group-dscp <group
name>
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic dscp value <value> group-dscp <group name>
Set policy from <zone_name> to <zone_name> <src_addr_name> <dst_addr_name>
<service name> <action> traffic priority <value> group-dscp <group name>
Routing
•IRDP Support for All Platforms—Beginning with ScreenOS 6.3.0 release, ICMP Router
Discover Protocol (IRDP) support is available on all platforms; however, IRDP support
is available only on an Ethernet interface with an IP address.
•DSCP Marking for Self-Initiated Traffic—The administrator can configure the DSCP
value for traffic initiated by the security device. The DSCP value can be configured for
11 services: BGP, OSPF, RIP, RIPNG, TELNET, SSH, WEB, TFTP, SNMP, SYSLOG, and
WEBTRENDS. You can use both the CLI and the WebUI to configure DSCP marking.
•QoS Classification Based on Incoming Markings—In ScreenOS 6.3.0, traffic-shaping
policies are enhanced to support quality of service (QoS) based on the IP precedence
and Differentiated Services code point (DSCP) marking of incoming packets. The QoS
classification feature for incoming traffic works only if the traffic-shaping mode is set
to Auto or On.
•Adding Routes to BGP—In ScreenOS 6.3.0r11, the Border Gateway Protocol (BGP)
conditional advertisement feature supports route advertisement using different address
family checks. By default, a BGP advertises the best routes in its routing table to its
peers. You can use the BGP conditional advertisement feature by using the check option
in set vr <virtual-router-name> protocol bgp command to configure conditional
advertisement of BGP routes to a peer or a peer group in a different address family.
BGP conditional advertisement is supported in IPv4 and IPv6 address families.
•To configure and to advertise one IPv4 network route to peer and check the
reachability of one IPv4 subnet or IPv6 subnet:
set vr vr-1 protocol bgp ipv4 network <ipv4_addr/mask>
check<ipv4_addr/mask|pv6_add /prefix_length>
•To configure and to advertise one IPv6 network route to peer and check the
reachability of one IPv4 subnet or IPv6 subnet:
set vr vr-1 protocol bgp ipv6 network <ipv6_addr/prefix_length >
check<ipv6_addr/prefix_length | ipv4_addr/mask>
The conditional advertisement feature has been enhanced to include the following
new configuration option and parameters to check the subnet of different address
family:
•ipv4_addr/mask — The IP address and subnet mask of the network. The subnet mask
value indicates which bits of the address are significant. The mask does not have to
be the same as the subnet mask used in the network. For example, 10.0.0.0/8 is a
Copyright © 2015, Juniper Networks, Inc.20
ScreenOS 6.3.0 Release Notes
valid network to be advertised by BGP. When the check option is used,
ip4_addr1/mask1 can be a MIP address range.
•ipv6_addr/prefix_length — The IP address and prefix length of the network. The
address is specified in hexadecimal format, using 16-bit values between colons. The
prefix length is a decimal value that indicates how many of the high-order contiguous
bits of the address comprise the prefix (the network portion of the address).
•check— Directs the device to check network reachability before advertising BGP
peers.
Security
•Denial of Service Attack Defenses—ScreenOS 6.3.0 supports the feature of strict
TCP-SYN-check wherein a strict syn check is applied to all the packets in a TCP
three-way-handshake before the three-way handshake completes. Users can enable
this feature by using the set flow tcp-syn-check strict command.
•Verification of IP address in ASIC Whitelist—Beginning with ScreenOS 6.3.0, users
can verify if a specific IP-address is in the ASIC whitelist by using the get asic ppu
whitelist ip-address command.
•Support for SecureID Server Cluster—RSA supports a primary server and up to 10
replica servers to process authentication requests. At least one of primary or slave
servers must be configured with static IP. RSA SecureID Server Cluster supports the
name locking, load balancing, and failover functions.
Virtual Private Network (VPN)
•Enhancement to VPN support in VSYS— The system can only support up to 16K static
VPN tunnels in a VSYS. An enhancement was made to enlarge per-VSYS static tunnel
capacity to the system max (25K) by preempting VPN group tunnels via environment
variable "no-vpn-grp=yes".
•Automatically Configuring a Local IPv6 Address for an IPv6 IKE Gateway— In
ScreenOS 6.3.0r11, you can automatically configure a local address for IPv6 IKE gateway.
In order to configure an IPv6 IPsec tunnel, you must define the local IPv6 address in
the IKE tunnel configuration. When you are configuring large number of devices, defining
a local IPv6 address can be difficult. This enhancement enables you to automatically
configure a local IPv6 address through DHCPv6 or IPv6 Stateless Address Auto
Configuration (SLAAC) into the IKE tunnel configuration.
To automatically configure a local address for an IPv6 IKE gateway, set the IPv6 address
0::0 as the local address in the following command:
•For IKEv1
set ike gateway <name> address <peer-ipv6-addr> aggressive outgoing-interface
<out-if-name>local-address 0::0 preshare <secret> sec-level standard
21Copyright © 2015, Juniper Networks, Inc.
New Features and Enhancements
Changes to Default Behavior
This section lists changes to default behavior in ScreenOS 6.3.0 from earlier ScreenOS
firmware releases.
Changes to Default Behavior Introduced in 6.3.0
•BGP Configuration — After you upgrade from ScreenOS 6.1 to ScreenOS 6.3, only the
connected route will be displayed in the routing table. However, the BGP route export
will fail, because the firewall is not configured to the connected routes.
To force the route export:
set vrouter "trust-vr"
set protocol bgp <protocol>
[...]
set ipv4 network <ip address> no-check
[...]
•New Image Key — ScreenOS firmware versions are now signed with a new image key.
Before you can upgrade any ScreenOS image, that has a date of August 13, 2014, or
later, you will need to either install the new image key or delete the previous image
key.
NOTE: As on August 13, 2014, the previous versions of ScreenOS firmwares
that were signed with the old image key are removed from the Juniper
Networks software download site and reposted after signing with the new
image key.
For more information, see the JTAC knowledge base numbers TSB16495
and TSB16496 located at https://kb.juniper.net/TSB16495 and
https://kb.juniper.net/TSB16496 respectively.
Copyright © 2015, Juniper Networks, Inc.22
ScreenOS 6.3.0 Release Notes
Changes to Default Behavior Introduced in 6.3.0r17
•SNMP Configuration — An “ipaddr has been configured in v1/v2 mode." error was
displayed when an SNMPv3 was being configured after SNMPv2 was configured. An
“ipaddr has been configured in v3 mode." error was displayed when an SNMPv2 was
being configured after SNMPv3 was configured.
Changes to Default Behavior Introduced in 6.3.0r13
•NSRP Configuration—The backup interface status (ifOperStatus) displays the state
as testing when the physical interface status is UP and as down when the physical
interface status is DOWN in an NSRP passive cluster member.
Changes to Default Behavior Introduced in 6.3.0r11
•Public Key Infrastructure— A new command is introduced to support manual certificate
renewal process by using the same distinguished name without modifying the
configuration but by updating the existing certificate in use by removing it.
set pki x509 manual-renew
To work on this feature, perform the following:
•Generate a key-pair: If the key-pair with the DN is supported in PKI-store, then add
a pad to PKI-store using CN=NSMANAULRENEW command to generate a new
key-pair. As a result, there are two key-pairs in PKI-store.
•Generate a PKI request: If there is a pad CN=NSMANAULRENEW already available
in the DN for the key-pair, then remove the pad to generate PKI request. This is to
ensure that the new certificate will have the same DN as the old certificate.
•Load the certificate: The new certificate with the same DN replaces the old certificate.
•Recording event log messages in the right VSYS — In a multiple VSYS configuration
on the firewall, an event that occurred in a specific custom VSYS-A was incorrectly
recorded as an event log message in the root VSYS or in a different custom VSYS-B.
This behavior is corrected and fixed. As per the behavior change we now log the event
log messages under the right VSYS specified for and will avoid logging incorrect event
log messages in different VSYS.
Changes to Default Behavior Introduced in 6.3.0r8
•IGMP packets compatibility —A command was introduced to permit IGMP packets
with TTL greater than one and to provide compatibility with other interoperability
devices:
set interface <interface name>protocol igmp no-check-ttl
•Firewall can block packets with a Routing header—Firewall has the ability to block
packets with a routing header type 0. To avoid blocking all the routing headers, the
firewall supports the routing header type filters using the following command:
set service < name>protocol routing-ext-hdr type<value>
23Copyright © 2015, Juniper Networks, Inc.
Changes to Default Behavior
Changes to Default Behavior Introduced in 6.3.0r7
•HMAC SHA-256 RFC 4868 compliance—The previous implementation of HMAC
SHA-256, incorrectly truncated the message digest at 96 bits. It now uses 128 bits, in
accordance with RFC 4868.
Changes to Default Behavior Introduced in 6.3.0r5
•IPv6 packet extension header—To filter or deny the extension header with user-defined
service, define the src-port and dst-port as wildcard 0-65535.
Changes to Default Behavior Introduced in 6.3.0r4
•NSRP Configuration—NSRP configuration is out of synchronization due to set tftp
source-interface <interface name> command.
Changes to Default Behavior Introduced in 6.3.0r3
•Increase in the capacity of number of service objects and address groups—For ISG
Series, the capacity of number of service objects and address groups is increased to
4096. For NS 5000, only the capacity of number of service objects is increased to
4096.
•Maximum timeout value of ipsec-nat alg—The maximum value of ipsec-nat alg timeout
has been changed from 180 to 3600 seconds.
•VPN tunnel capacity for advanced license key—On SSG550, the VPN tunnel capacity
has been changed from 1000 to 2048 for advanced license key.
•Unexpected Low VPN Throughput—When VPN monitor is configured for VPNs on
NetScreen-5200 or NetScreen-5400, the device can define sub-optimal ASIC mapping
for processing VPN traffic in the hardware which causes unexpected low VPN
throughput. A new command set flow ipsec-distr-asic is introduced to include the
enhancement that VPN encryption will be distributed into different chips based on the
tunnel's SA index per round robin. By default, it is disabled. This is applicable for
NetScreen-5000 series only. For NetScreen-5000 series with VPN on IPv6 environment,
enabling this command is not recommended as it would yield less than optimal
performance.
Changes to Default Behavior Introduced in 6.3.0r1
•The set igmp join-group and unset igmp join-group commands for the interface are
deprecated. If you execute the set/unset igmp join-group commands, the following
warning appears:
WARNING: This command is a deprecated command and cannot be saved to
configuration. Please use the following new preferred syntax:
exec igmp interface if_name join-group group_addr [{ include | exclude| to_include
|to_exclude} sources_ip ]
•The CLI command set interface interface nameproxy-arp-entry ip_min ip_max takes
precedence over the existing set arp nat-dst command. This means that when the
Copyright © 2015, Juniper Networks, Inc.24
ScreenOS 6.3.0 Release Notes
proxy ARP entry is defined and matched, then the system does not respond to the ARP
request via the physical interface.
Because the set interface interface nameproxy-arp-entry ip_min ip_max command allows
the customer to have better control of the device, the command set arp nat-dst is not
recommended.
•The SNMP changes might affect the management software as follows:
•Logical interfaces are added to the interface table.
•Several new SNMP traps are introduced in the ScreenOS 6.3.0. For details on the
new SNMP traps, see the change history of published ScreenOS 6.3.0 MIB
NS-TRAPS.mib.
You can consider modifications as required.
Network and Security Manager (NSM) Compatibility
This section provides information about updates required to complementary Juniper
Networks products to ensure their compatibility with ScreenOS 6.3.0.
Support for ScreenOS 6.3.0 has been introduced with NSM 2009.1r1. Navigate to the
Support webpage for more information: http://www.juniper.net/support.
Detector and Attack Objects Update (only for ISG-IDP)
The Detector Engine shipped with this ScreenOS version is 3.5.140842. For more
information on the availability of new releases, see the Detector Engine Release Notes
at http://www.juniper.net/techpubs/software/management/idp/de/.
After you have performed the ScreenOS firmware upgrade, you must update to the latest
IDP Detector Engine and Attack Object database:
1. Download the latest detector and attack database to the NSM GUI server. From NSM,
select Tools > View/Update NSM attack database, and complete the wizard steps.
2. Push the detector update to the ISG-IDP devices. From NSM, select Devices > IDP
Detector Engine > Load IDP Detector Engine, and complete the wizard steps.
3. Push a policy update to the ISG-IDP devices. From NSM, select Devices > Configuration
> Update Device Config, and complete the wizard steps.
Addressed Issues
The following operational issues from ScreenOS 6.2, 6.1, 6.0, and 5.4 release branches
were resolved in this release:
25Copyright © 2015, Juniper Networks, Inc.
Network and Security Manager (NSM) Compatibility
Addressed Issues in ScreenOS 6.3.0r19
Admin
•952483 - The firewall did not allow the configuration of schedule and notify-conn-close
parameters within the same policy.
Antivirus
•955656 - An antispam feature blocked e-mails from a few domains because the SMTP
parser transformed the dot (.) in the domain address to the IP address 0.0.0.0, which
was considered an invalid parameter.
DNS
•970550 - An exception dump occurred because of the improper DNS handling of an
address book entry.
•1036414 - The performance of DNS requests decreased after upgrading from ScreenOS
6.2 to ScreenOS 6.3.
WebUI
•946406 - An exception dump occurred when a policy was either added or edited
through WebUI, because of a comma included in the address book.
•981226 - WebUI exceeded the permissible limit of the UDP flood threshold
configurations.
Others
•959898 - An exception dump occurred when the DI database was updated.
•962983 - An exception dump occurred because of the invalid pointers on packets that
traveled through a tunnel.
•986860 - An exception dump occurred because of memory loss in the SNMP module.
•1003865 - Memory was overwritten in the IDP Security Module because of a race
condition.
•1004818 - SNMPv3 failed to function when a string entry in the local-engine id field
was longer than 27 characters.
•1005074 - The MSRPC connection failed when no new cookies were left for allocation
to establish a new MSRPC connection.
•1011948 - Unable to specify MGT zone for SNMPv3 src interface.
•1012257 - An exception dump occurred when memory availability was zero as a result
of memory leakage.
•1014009 - A temperature alarm failed to be triggered when the threshold temperature
was set lower than the system temperature.
Copyright © 2015, Juniper Networks, Inc.26
ScreenOS 6.3.0 Release Notes
•1016586 - An exception dump occurred when a VSYS was deleted.
•1031677 - An exception dump occurred because of the corrupted link list in the SCTP
ALG module.
Routing
•950554 - Routes flapped intermittently when OSPF transitioned from type 7 to type
5 LSA.
•994030 - The firewall created duplicate OSPF route entries in the routing table with
the next hop as 0.0.0.0.
Security
•959847 - The firewall displayed the "packet too big" error for IPv6 packets when the
interface MTU was set to 1500.
•968746 - The firewall blocked traffic from a chassis with a 16-port Ethernet card when
one of the ports was enabled.
•1004221 - The backup firewall with dual stack IPv4/v6 experienced packet loss when
IPv6 was enabled.
•1008315 - Global tcp-mss did not function as expected when the firewall started a
syn-proxy defense.
•1017672 - The firewall failed to reverse-translate the port number in the SIP payload
when DIP/interface NAT was used.
•1023661 - The firewall dropped fragmented packets in the ASIC.
•1033963 - SSLv3 was manually disabled because of a vulnerability in the protocol to
POODLE attacks.
•1039268 - The firewall displayed the "Address: Duplicate entry" error for an unknown
reason when an address was configured.
VPN
•977062 - The "shared to fair" and "fair to shared" transitions for CPU limit were forcibly
written in logs in the root VSYS.
•1007969 - The maximum number of supported proposals for IKE negotiation increased
from 10 to 15.
27Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Addressed Issues from ScreenOS 6.3.0r18
Admin
•979649 - Administrative SSH sessions remained on the device even after the session
timed out.
Antivirus
•960784 - When AV was enabled, some YouTube videos could not be played.
WebUI
•912330 - When the user attempted to view the interface bandwidth table, the WebUI
displayed a blank page with a small square box in the upper left corner.
•927619 - In the WebUI, configuration information about the SNMP host could not be
located.
•971932 - The DSCP value could not be updated when the corresponding policy was
created via WebUI.
•975830 - When the user attempted to modify an interface that had been configured
with the WebUI, the CLI displayed the following syslog message:
Interface ethernet3/15.1 being used as syslog src-interface. Please unset it first.
Others
•733966 - An exception dump occurred when the SCCP ALG was processing SCCP
traffic.
•812829 - SSG Series devices rebooted and created a core file when an attack database
was manually updated.
•847275 - [ISG/NS5000] An exception dump occurred in ASIC platforms because of
a double session free condition, which caused a session list corruption.
•933472 - SIP 200 OK packets were dropped when the SIP ALG tried to multicast SDP
packets.
•956617 - An exception dump occurred when the device was reading the physical
registers of the interface.
•954715 - A few SNMP traps in the NS-TRAPS.mib file were missing.
•968621 - A few TCP packets were dropped in a GRE tunnel when the packet IP length
was odd.
•975993 - SNMP was only able to query the primary power supply in an SSG500.
•978458 - Even when no debugs were enabled, the get db st command displayed the
following error message:
Inherit policy from parent in backward case.
Copyright © 2015, Juniper Networks, Inc.28
ScreenOS 6.3.0 Release Notes
•978819 - An SNMP walk operation failed to display BGP peers in a custom virtual
router.
•979058 - An exception dump occurred because data traffic arrived on a PIM when a
neighbor was being deleted.
•980787 - The alarm LED did not change to red when the device reached the
low-memory threshold.
•985306 - An exception dump occurred while a policy was being changed in NSM,
because of an incorrect dump operation that was performed during a session rematch.
•994095 - While performing NAT with session cache enabled, DIP ports were not
released even when no DIP sessions were available.
•1004065 - When the content length field was greater than 65,535 in an RTSP payload,
the RTSP ALG modified the field value incorrectly.
•1006677 - An exception dump occurred during IKE negotiation when IKE proposals
used either group 19 or group 20.
Routing
•960773 - The BGP neighboring node flapped when the path attribute length was not
set in the BGP route update.
Security
•937739 - [SSG140] The traffic initiated from the firewall failed to pass to another
device because of a "wait for arp rsp" string in the debug flow.
•939364 - An exception dump occurred because a local-packet-double-free issue was
caused by heavy traffic.
•938185 - The enforcer failed to automatically reconnect to the Infranet Controller
when the active/backup cluster failed twice.
•988559 - The firewall retransmitted packet-capture files and closed sessions with
the reason given as “other”.
•999772 - ScreenOS was potentially vulnerable to a CVE-2014-0076 ECDSA nonce
disclosure using a side-channel attack.
VPN
•958251 - The IKEv2 VPN traffic failed after a rekey, when NAT-T was involved.
Addressed Issues from ScreenOS 6.3.0r17
CLI
•954276 - IPv6 self logs were not generated for the unicast IPv6 traffic with the set
firewall log-self exclude multicast command enabled.
•955531 - The get route ip command displayed an incorrect virtual router when Inter-VR
routing was configured.
29Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Others
•686132 - VIP destinations were identified as being down because of the short socket
queue length.
•835847 - An exception dump occurred while processing the IPsec ACVPN traffic.
•847112 - An exception dump occurred because of the corrupted build_task_socket_list
that was triggered by an incorrect behavior of IPv6 socket check.
•890657 - The MGT zone option was unavailable for the SNMPv3 scr-interface.
•915944 - IKE heartbeats in combination with IKEv2 were not supported, because, while
ScreenOS used IKEv2 for IPsec VPN in combination with an IKE heartbeat, the CHILD_SA
renegotiated every IKE heartbeat threshold.
•916471 - Traffic that required any ALG RM resources was dropped because the RM
resources with inactive sessions were also allocated to the SQL ALG.
•920454 - SCCP did not function correctly when it was configured with a MIP.
•929794 - The SCP transfer to back up a configuration file from a device to the server
was terminated occasionally because the device began sending the TCP FIN packet
even before the host received the complete file.
•930754 - An exception dump occurred when a session was created by HA and no
interface was found.
•931973 - [ISG-IDP] IDP core dump occurred during a policy push because of a race
condition with AI.
•933084 - An exception dump occurred while accessing an invalid packet header
argument other than 5-tuple fields.
•935973 - The SCTP ALG incorrectly dropped SCTP packets in chunk bundle cases
when chunk lengths of COOKIE_ECHO and INIT_ACK were different.
•937391 - An exception dump occurred because of a NULL pointer in nsp_tunnel when
a policy was deleted.
•947948 - An exception dump occurred because a session was reused before the
fragment was freed in fcb.
•965947 - After upgrading from ScreenOS 6.3.0r12 to ScreenOS 6.3r13 or later versions,
high CPU usage occurred because of the SNMP functionality.
Security
•942614 - A problem with parsing pair policies for policy-based VPNs resulted in high
CPU usage causing the firewall to reboot.
•929892 - Few TCP sessions processed by antivirus remained in the close_wait state
after processing an ACK, which led to the antivirus session becoming full.
•982141 - An exception dump occurred in multiple firewall clusters that were managed
via SSL, because of a malformed heartbeat packet.
Copyright © 2015, Juniper Networks, Inc.30
ScreenOS 6.3.0 Release Notes
Routing
•939242 - An Invalid route remained in the route cache after an active route was
recovered.
•968466 - Track IP objects with a default timeout interval of 1 timed out even before
the reply was received.
VPN
•930506 - The VPN under IKEv2 through dialup (serial 0/0 in a V.92 interface) did not
come up after it went down (did not renegotiate).
WebUI
•911395 - In the WebUI, the scr-interface option was unavailable for SNMPv3.
•915316 - Unable to delete policies from the WebUI because the browser displayed
error 404, Page Not Found.
•928960 - The VIP policy was removed automatically from the WebUI after modifying
the VIP address because the change in VIP corrupted the address tree.
•953826 - In ScreenOS 6.2.0r18 and ScreenOS 6.3.0r16, the WebUI displayed an error,
Cannot display the configuration under Configuration >Update >Config.
•956274 - Unable to delete the track IP function from the WebUI because the browser
displayed error 404, Page Not Found.
•956282 - Unable to delete the external group from the WebUI because the browser
displayed error 404, Page Not Found.
•956288 - Unable to delete a VSD group from the WebUI because the browser displayed
error 404, Page Not Found.
•956291 - Unable to delete the NSRP track IP function from the WebUI because the
browser displayed error 404, Page Not Found.
•956312 - Unable to delete address lists from the WebUI because the browser displayed
error 404, Page Not Found.
•956314 - Unable to delete the SUN-RPC service from the WebUI because the browser
displayed error 404, Page Not Found.
•956317 - Unable to delete address groups from the WebUI because the browser
displayed error 404, Page Not Found.
•956320 - Unable to delete the MS-RPC service from the WebUI because the browser
displayed error 404, Page Not Found.
31Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Addressed Issues from ScreenOS 6.3.0r16
Others
•769049 - An exception dump occurred when antispam and antivirus processes used
too much system memory.
•819171 - A brute force attack was triggered n+1 times its configured value.
•888573 - [SSG5/SSG20] V.92 serial interface failed to reconnect when the call was
terminated improperly.
•892843 - The default router would be automatically deleted from the IPv6 routing
table because the IPv6 routing table was not refreshed when the RA was received.
•897651 - IKE congestion displayed an error while calculating ike_nego_activity_count,
because of an incorrect behavior that was set when the commit-bit was enabled.
•898323 - The device printed data buffer information logs on the console when it
received a UDP packet larger than 4000 bytes.
•901137 - If IPv6 was enabled, the RADIUS auth IPv4 server address could fail because
of the server’s inability to create a RADIUS socket.
•901422 - VSD Group 0 was created when the VSD group configuration exceeded the
valid ID threshold.
•907339 - The MIP settings on the dialer interface did not appear in the system output
for the get config commands on the console. Although these settings did appear in the
WebUI output and in the get interface dialer mip command console output, after the
firewall was rebooted these MIP settings disappeared.
•908829 - The MSRPC traffic failed because the ALG did not parse some authentication
fields.
•918217 - While renewing its SCEP certificate, the primary device failed to update and
remained in the pending state.
•919797 - The device under test (DUT) crashed when it was rebooted because it
attempted to re-enter an unprotected resource.
•929757 - Event log messages regarding the mode change were not displayed in the
Root VSYS when the cpu-limit/vsys-profile feature triggered a shared-to-fair mode
transition due to a high CPU incident.
Security
•861671 - The firewall rebooted automatically when changes were made to the policy
through the WebUI.
•879680 - The firewall crashed when it attempted to assign memory because of a bug
in the web task logic.
•882566 - The firewall failed when the Multicast PIM module referred to a null pointer.
•884567 - The firewall dropped UDP packets because the PPUs froze when the firewall
attempted to process fragmented traffic.
Copyright © 2015, Juniper Networks, Inc.32
ScreenOS 6.3.0 Release Notes
•892915 - The user had to restart syslog by using apply & reset connections from WebUI
because SSG140 with syslog enabled over TCP, periodically failed to send syslog
messages.
•893808 - The firewall accepted the subnet ID as the IP address of the interface.
WebUI
•776323 - TACACS+ in transparent mode could not be configured through the WebUI.
•877558 - The WebUI did not display complete data for the default option All Routers
in the Policy List drop-down when the user navigated through Network >Routing >
PBR >Policy.
•904619 - In the WebUI, the VLAN zone could not be blocked when the user navigated
through Network >Zones >Edit.
Addressed Issues from ScreenOS 6.3.0r15
CLI
•664162 - Track IP configured through the CLI did not always reflect the correct
configuration when displayed in the WebUI.
•688061 - While saving a configuration using the get config >tftp command, g-arp was
automatically added to the config file.
•789133 - In the CLI configuration, the trap versions were displayed only when SNMP
was configured with networks that used the /32 subnets.
Others
•841084 - The firewall in NSRP failed when a subinterface was removed.
•694835 - The device experienced an exception dump when running multicast traffic
with PIM, because of a null pointer.
•734260 - IPv6 packets were dropped incorrectly because of sequence number checking.
•743657 - A large number of configured PBR policies took a long time to be built, which
resulted in a watchdog timeout. This caused the device to perform a core dump.
•746210 - NSM does not allow you to set a VSI interface with a value greater than 7.
•770815 - Under certain conditions, the device rebooted unexpectedly during an SSH
connection to the Infranet Controller.
•807561 - Irrespective of the status of the link, an SNMP walk performed to check
ipv6IfOperStatus on backup devices returned the interface status as UP.
•812703 - Traffic forwarding through GRE over a route-based IPsec tunnel failed when
traffic shaping was enabled.
•819292 - ISDN failed, because the protocol packet response was very slow.
•836499 - Adding an incorrect subnet mask IP address to a multi-cell policy resulted
in deletion of other addresses in the multi-cell policy.
33Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•840476 - Some Real Time Objects (RTOs) were not synchronized between primary
and backup devices while performing a major ScreenOS upgrade.
•850527 - Occasionally, a new NSRP master was not connected to the Infranet
Controller after an NSRP failover. The Get infranet controller command displayed the
status as Closed.
•853577 - The device performed a core dump and rebooted because of a MIP on the
loopback interface.
•857406 - The MSRPC traffic failed because the port values were not compared while
an rpc_map_search was performed.
•859608 - The SNMP traps were not triggered when the source IP-based session limit
was reached.
•862597 - While setting the source address and the destination address as negate in
the intra-zone policy, the intrazone policy did not match with the configured policy,
and it defaulted to a global policy.
•865894 - Unable to delete L2TP users, even though the L2TP tunnels were inactive,
because of an incorrect count of active L2TP users.
•867748 - Unable to manage secondary firewall through the backup manage-ip
interface.
•869155 - When the mgt.1 interface was created, it was accidentally added to a VSD
group. This caused a change in the MAC address of the mgt interface.
•869675 - The device encountered an exception error when the WSF module took too
long to process a large, corrupted packet.
•869698 - Issuing the save config to tftp a.b.c.d filename.txt command, enabled flow
vector profiling.
•872130 - Return packets dropped while they were being forwarded from one node to
another.
•872593 - Traffic logs were not generated for TCP port 1503.
•874372 - The device experienced an exception dump when an SSH process referenced
a null pointer.
•875123 - Some applications, like FTP, failed because of an incorrect TCP ACK sequence
number when in an NAT environment.
•876229 - A read error in a real-time clock (RTC) chip caused the device to reboot.
•878809 - A multicast session got stuck because of a time sync.
•879511 - The device experienced an exception dump when a user with read or write
privileges had their access changed to root privileges.
•880797 - FTP-Get service was unable to restrict FTP upload through the APPEND
command.
Copyright © 2015, Juniper Networks, Inc.34
ScreenOS 6.3.0 Release Notes
•884643 - When the ICMP-ANY service was set to never time out, ICMP sessions were
not closed even after the ICMP-Reply was received.
•896357 - An exception dump occurred because of a memory corruption in the SIP Via
list.
Security
•722000 - [ISG] IDP Security Modules in an NSRP cluster were not shown in the WebUI.
VPN
•750452 - A policy-based VPN session lost its tunnel information because of a route
change. As a result, the packet was forwarded incorrectly to an interface (instead of
to a tunnel).
•804902 - VPN packets with sequence numbers greater than 0xffffff00 created frq1
duplication, resulting in a MAC flood.
•843507 - EAP authentication information was not cleared when clearing IKEv2 SA,
causing an exception dump.
•845065 - A VPN could get reset when using SHA-2 because of a mismatch between
software and hardware sequence numbers.
•863127 - OSPFv3 got stuck in the EX_START state in a route-based VPN tunnel that
was using unnumbered tunnel interfaces.
WebUI
•678784 - The WebUI stopped responding while dialer interfaces were being configured.
•704897 - When a static mroute was configured from the WebUI, the OIF was not
displayed if one of the interfaces was in a custom VR and the other was in a default
VR.
•812494 - SurfControl integrated Web filtering was configurable even for unlicensed
versions through the WebUI.
•849169 - The device experienced an exception dump when it tried a lookup for group
addresses through the WebUI, where the group address zone ID referenced a null
pointer.
35Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Addressed Issues from ScreenOS 6.3.0r14
Admin
•803487 - ScreenOS failed when the auth table was large and the exec infranet controller
check-sessions command took longer than 30 seconds.
ALG
•818193 - Occasionally, the SIP call timer timed out SIP messages earlier than expected.
•832693 - When a client initiated a session with the NFS server, the dummy port (created
previously when the NFS server was used as an NFS client) does not allow the NFS
control session to be processed by the SUNRPC ALG. This resulted in the blockage of
the subsequent data sessions.
•834945 - Harmless RPC traces were printed on the console.
•840673 - The SIP call dropped after 45 minutes because the session expire header
was not updated when the re-invite was sent.
Antivirus (AV)
•842538 - AV scan performance was slow when trying to relay an HTTP 302 message
if the connection mode is not a keep-alive.
Others
•817379 - The SSG Series devices failed to handle the NSM packets that contained an
0xffff TCP checksum.
•822847 - The system experienced a memory leak when the pass-through traffic
required authentication.
•831747 - Device encountered an exception error when pinging a multicast group address
due to a NULL pointer being incorrectly referenced.
•833083 - The southern hemisphere DST setting, which begins in October and ends in
April, automatically got disabled at the end of October. This resulted in the incorrect
time being displayed.
•835602 - The PKI information synchronized with the backup information even though
the rto-mirror for PKI was disabled.
•839155 - Packets were matched incorrectly by debug flow filter when either src/dst
ip or src/dst port were the same.
•842055 - NSRP flaps and packet drops were encountered due to a dead lock between
SLU engine and PPU, this further resulted in ASIC to reinit.
•853718 - A packet drop occurred as a result of an incorrect TCP sequence calculation.
Copyright © 2015, Juniper Networks, Inc.36
ScreenOS 6.3.0 Release Notes
Routing
•828964 - The learned OSPF routes were lost when the remote peer router-id was
changed; and the peer box failed to obtain the correct network LSA.
Security
•818620 - The command unset ike gateway <gateway> xauth accounting server <server>
cannot be synchronized, especially after one of the devices were rebooted.
•828168 - The NSRP backup firewall failed and then rebooted repeatedly.
VPN
•800584 - The firewall failed to verify ECDSA signature.
•823285 - The policy based VPN tore down after NSRP failover, with remote peer
reporting antireplay errors.
•830423 - After enabling IPv6, the IPsec VPN traffic was dropped.
WebUI
•833871 - Updating DI from WebUI on backup did not get synchronized to the primary
device.
•833873 - The modified OSPF neighbor list value was not updated properly.
•842738 - The DNS server could not be modified when the device was in transparent
mode.
•701694 - The root administrator lost read/write privileges while modifying the
administrator password.
37Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Addressed Issues from ScreenOS 6.3.0r13
ALG
•796066—The SIP data session no longer uses in the same route as the control session.
The data session now uses the route specified in the routing table.
Antivirus (AV)
•803148—Websites occasionally fail to open when the AV is enabled and the syn-ack
packet has window size of 0.
Logging
•804620—Redirection of logs to an external website might stop, and, although more
than 10 percent of free space is available, the following message appears: There is less
than 10% space available in current active file.
Other
•585488—The firewall core was dumped and rebooted when the tftp get tech > tftp
command was used.
•587570—The multicast outgoing interface (OIF) was calculated incorrectly.
•681596—Firewall or pass through traffic intermitted when high-end platforms reported
increase in CPU5 drop counters.
•730059—The firewall rebooted unexpectedly when net-pak contains the wrong flag.
•730138—The console output displayed a slot_num(1) or chip_num(2) error.
•742169—The firewall rebooted spontaneously because of a duplicate session issue.
•745496—The server had a large TCP window, causing the Notify-conn-close to fail.
•751579— VLAN traffic on ASIC-based platforms in Layer-2 Transparent Mode was
dropped when the VSYS bound to the VLAN group was deleted and the same VLAN
group was referenced in another VSYS.
•754606—SYN flood protection was triggered even though the attack threshold was
not reached.
•771666—When IPv6 and BGP were both enabled, it caused the firewall to core dump.
•771827—The device rebooted with a crash dump in the IKMPD task due to a memory
leak.
•771959—The Infranet controller connection was disconnected on the firewall as a
result of missing Keep Alive messages in a scenario with a large number of policy
configurations on the firewall.
•775604—In an NSRP cluster, dhcp server auto did not work.
•775844—On SSG 520M and SSG 550M devices, the fan status occasionally appeared
as down.
Copyright © 2015, Juniper Networks, Inc.38
ScreenOS 6.3.0 Release Notes
•777402—PPTP occasionally failed because of a route lookup failure in the cross-VR
design of the child GRE session.
•788853—The firewall performed a core dump and rebooted because of a wrong
parameter logic being used while generating logs.
•789358—On PIM interfaces, setting the set int <phy link-down> command did not keep
the interface down even after a reboot.
•796098—When mirroring was configured on NS 2000 or ISG Series devices (including
IDP-enabled devices), a TCP three-way handshake failed on the device during SYN
proxy processing.
•811257—The NSRP backup device did not undergo a "never" timeout synchronization
at session creation.
•814516—The SSG Series device did not start the PPPoE connection after NSRP failover.
Routing
•768724—In some instances, BGP routes failed to be advertised because of a broken
SPF list.
•783986—When compatibility with RFC-1583 was set for OSPF and a network change
occurred the device had to run several calculations for SPF.
Screen
•790842—The firewall performed a core dump and rebooted when the set zone trust
screen ip-spoofing include-default-route command was executed.
SNMP
•782678—The device might send multiple traps for a single event, causing duplicate
entries.
•785140—SNMP traps are not generated for a few Screen options.
•807264—In ScreenOS 6.3, when the SNMP listen port was configured, the change did
not get updated and the default port value of 161 was retained.
VPN
•780465—The Ctrl+C option did not interrupt the output of the CLI through get
commands.
•783720—After NSRP failover, the remote IPSec gateway might drop AH packets
because of anti-replay protection.
WebUI
•781483—In the WeUI, several NHTB event-log pages are blank. Event logs do not
display the correct number of entries per page.
39Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•793235—In the WebUI, the Network > Interface Edit > OSPF page neighbor list from
the Neighbor List drop down and then click drop-down menu and click Apply. However,
the neighbor list drop-down menu setting is not updated after the Apply function, and
the list does not appear on the device, which continues to display "None."
Addressed Issues from ScreenOS 6.3.0r12
ALG
•678300—Failed to translate IP on SET-PARAMETER within RTSP by ALG causes the
video streaming to stop intermittently.
•736470—H.323 ALG was unable to handle cross vsys H.323 traffic.
•752103—RTSP SET_PARAMETER is not address translated.
•771008—Communication failed when H232 ALG may change h245 address in the
payload.
•778810—Policy change caused h323 alg hit a null pointer and device failed.
Authentication
•778720—Firewall stopped authenticating against RADIUS server.
Antivirus (AV)
•753601—Sometimes websites failed to open with AV enabled, if the server does not
send the FIN ,after sending HTTP body.
Logging
•740584—When a sub-interface is created and cancelled an event message "MTU for
interface has been changed to 1500." is displayed.
Management
•726174—Firewall might add additional padding to a reply packet.
•737433—The ifIndex value is not the same in standard MIB and NetScreen enterprise
MIB while executing SNMP query for interfaces.
NSRP
•705438—In asymmetric routing condition, if a session is not prepared and synchronized
correctly might result in unexpected packet drop.
Other
•523647—The "set envar" command used to address the ESP sequence number is not
retained permanently after the process of Asic re-init and reboot of the firewall.
•590160—Device might crash when route id is a larger number and the NSRP route
sync is enabled.
Copyright © 2015, Juniper Networks, Inc.40
ScreenOS 6.3.0 Release Notes
•689721—The Random Number Generation for SPI does not work.
•710595—When the "Pending Drop Notify" counter fills up the Infranet Controller process
on the firewall and does not release regularly, results in Drop queue full message and
no Drop notify messages to be forwarded to Infranet Controller.
•719600—Device hanged due to ASIC when IDP tried to process IPv6 ESP traffic resulting
in split bran situation.
•721101—Device might reboot unexpectedly when the firewall received invalid HA
messages.
•725966—Firewall experiences core dump after HA fail over due to IKE-v2 parameter
sync problem between the primary and the backup devices.
•726468—The PKI process might send an incorrectly formatted message to the SSH
process, resulting in a core dump.
•727126—Firewall spontaneously reboots when FTP server tries to initiate data
connection before client sends "RETR" command.
•728097—On interface configuration, firewall is accepting network number (1.1.1.0/24)
as an IP address.
•728480—Asymmetric traffic failed when IPv6 was enabled.
•731534—Firewall was spontaneously rebooting due to memory overwrite.
•731582—Debug flow drop, shows the packet information for the dropped packets.
•732793—Device might crash when you modify an existing policy.
•735268—Sometimes device may reboot with core dump due to a logical error in the
code.
•736122—In IKEv2 VPN, device may reboot with crash dump on receiving illegal or
malformed IKEv2 packet.
•739175—Illegal memory access causes spontaneous reboot of the firewall.
•740513—When SIP ALG fragments the packet, the first fragment is of small-sized
which may not include the mandatory SIP headers.
•743309—Multicast traffic can cause firewall to coredump.
•743842—Brute-force attack pop3 detection failed under certain conditions.
•744684—Sometimes, after OS upgrade, the firewall starts rebooting continuously in
loop condition, due to a memory overwrite issue. This is because of smaller buffer size
of fat table in flash.
•744785—When you send traffic to an IP address that is part of the loopback interface
subnet, there is an infinite loop and this might cause high CPU.
•745791—In layer2 mode, if a switching loop sending a packet originating from the
firewall back to itself on a different interface, then the interface adds the vlan-1 Mac
address to the interface Mac table. An additional check is added to prevent the firewall
from adding its own VLAN.
41Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•746646—[ns5000 and ISG] ARP entries in Hardware and Software may mismatch
due to inconsistent ARP update mechanism.
•750929—Device might crash when you delete the interface used by NTP module.
•752246—SCTP natted traffic might stop working when you set the envar x-in-ip.
•756682—Internet Explorer 9 pop-up credentials does not appear with SSG firewall
Authentication.
•768558—Sometimes cross ASIC traffic gets dropped due to incorrect logical check in
the code.
•769297—System failure occurred during malloc memory leak failure.
•769737—When the card is plugged in on slot 5 the information of the card cannot be
seen in datafile.
•771104—ICMP unreachable traffic does not undergo NAT operation in transparent
mode.
•773293—Harmless unnecessary debug message has been removed from the console
output.
•777142—When performing snoop offset filter on VPN tunnel traffic firewall may crash.
•777170—After IPV6 was enabled there was high CPU on backup of NSRP firewall.
•778730—SIP ALG caused a system failure during a list erase function.
•779261—HA resync caused device with large configuration in NSRP failure.
•781343—In a VSD-less cluster, the device will now check to make sure the ingress and
egress interfaces match the session. If they do not match, then the device clears the
existing session and creates a new session with the correct interfaces.
•781815—The new policy installation process was modified to be more compatible with
NSM.
•797994—When the firewall is configured for ALG with loopback interface the firewall
may core dump and reboot.
Routing
•730018—BGP IPv6 prefix was not advertised after reboot.
•733528—In IGMP proxy, when an admin clears multicast-route (mroute) by executing
the CLI clear vr vr-name mroute command, it cannot rebuild the mroute even after the
new igmp v3 report packet arrives.
•734361—BGP neighbor parameter rejection command is deleted after BGP instance
flap or upon reconnect.
SNMP
•737747—While using standard MIB2, indexes or mapping between Indexes of the OID
'ipAdEntIfIndex' and the OID 'ifDescr.x' are incorrect and as a result SNMP poll sends
an incorrect result.
Copyright © 2015, Juniper Networks, Inc.42
ScreenOS 6.3.0 Release Notes
•738116—SNMP Authentication Failure Trap is generated when a GET-REQUEST with
different SNMP version is received.
VPN
•705374—IKEv2 failed in rekey after failover to backup.
•731964— L2TP IKEv2 VPN might not come up if multiple IKEv1 & IKEv2 VPNs are
configured.
•749931—Phase 2 rekey failed on IPSec with NAT-Traversal.
•770471—In WebUI, removing the configuration related to proxy-id was not possible.
•780247—Proxy ID mismatch between SA and policy was due to an endian issue.
WebUI
•751661—In PPPoA Interfaces WebUI the connect and disconnect buttons did not work.
•777559—In WebUI, event log was not showing the correct number of lines.
•773466—In WebUI, special characters in the route map name were discarded when
using the "Add Seq No" link. This resulted in the creation of a new route map rather
than a new sequence number on the existing route map.
Addressed Issues from ScreenOS 6.3.0r11
ALG
•710227—SIP ALG was modified to ensure that all SIP data fragments have their call
data modified according to any NAT parameters.
Antivirus (AV)
•690029—when AV was enabled downloading a large file (if the content-length of
HTTP request was too large) failed with ASP error.
IDP
•695082—IDP module on the ISG platform used to hang when executing the command
"get sm status".
Management
•671719—NSM was unable to update policy to device because sme_bulkcli was stuck.
•687217—Firewall failed when you run fprofile.
•696588—If SCP file transfer was used regularly then there was a high memory on
firewall.
•703695—Unable to add MIP configuration to a multi-cell policy through WebUI.
43Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
NAT
•611751—MIP for GRE over IPsec did not work, if the MIP was not in the same IP subnet
as the tunnel interface.
•700690—Sometimes the Extended IP x.x.x.x or its range collides with IP y.y.y.y or its
range when configuring an ext DIP on unnumbered tunnel interface.
NSRP
•703949—The expired tunnel sessions were not removed properly in a backup device.
Other
•551755—"IPv6 neighbor gateway [IP6] is reachable" was logged incorrectly when it
is unreachable.
•582089—Pass through IPv6 IPSEC sessions are interrupted due to incorrect session
timeouts set on ALG created child sessions.
•592160—After HA failover, the tunnel route pointing to the VPN stayed inactive for a
long time by causing traffic loss on the new master.
•599686—FTP ALG did not work correctly when receiving unexpected ack from server,
after the EPASV request from client.
•661016—when ACVPN was configured the device experienced a memory leak.
•662330—Asic classifier bug caused IGMP Query messages to trigger Source Route IP
alert on ISG's.
•662930—Traffic through the IPSEC tunnel destined to one of the interfaces sometimes
failed, because of reply packets getting sourced from tunnel interface IP.
•675550—When upgrading through tftp, the device might reboot with core dump.
•686087—Unable to bind an unnumbered tunnel interface within a VSYS if the VSYS
name contains parenthesis.
•686165—If the IP of egress interface changed then existing sessions might not get
updated with the new IP.
•688228—When layer 2 broadcast packet was received, it was incorrectly interpreted
as Winnuke attack.
•690786—Unable to change the maximum number of sessions with envar command
on ISG2000 box with advanced license and less than 2GB memory.
•691510—ASIC stopped forwarding traffic due to an issue with PPU-F.
•692085—Firewall was rebooted and core dumped due to multicast packets accessing
the null pointer for a PIM neighbor.
•692124—NHRP feature resulted in a memory leak condition.
•692497—When "set envar x-in-ip=yes" on ISG1000, get error "x-in-ip not supported".
Copyright © 2015, Juniper Networks, Inc.44
ScreenOS 6.3.0 Release Notes
•694306—FW experienced high task CPU momentarily at polling times due to snmp
task on 6.3. code.
•699131—ISDN primary number and alternative number length fields changed from 15
to 16.
•699200—Due to URL filter and DNS the firewall caused core dump and rebooted the
system.
•700331—Firewall was rebooted and core dumped after adding VSD-Group.
•700352—DNS server cache snooping remote information disclosure is detected.
•700481—With SNMP and more than 8 VSD groups configured, the device might cause
core dump and rebooted during SNMP polling.
•701519—Pass through VPN traffic breaks source session limit set on zone screening.
•701968—Session are not updated with the new VPN with better route and packet
dropped.
•703689—When DST was enabled and the system was rebooted, the SNMPv3 engine
time was set to a higher value than the specified value in the RFC.
•708406—Firewall rebooted and core dumped due to accessing the invalid memory
area.
•709646—Under a certain condition, Serial interface accepted traffic whereas Ethernet
interface did not accept traffic.
•718372—When a session was taken out of hardware and if the firewall received a FIN
then the firewall did not close the session.
•721988—There was a memory Leak in Anti-SPAM feature of UTM.
•722208—SSG device stopped passing traffic in all directions due to an error in read
logic on the interfaces.
•723404—During external vulnerability scan, a spontaneous reboot due to a null pointer
occurred.
•724145—During device reset, the custom NSM management port resets from 7900 to
a default port of 7800.
•727177—Pass through IPsec sessions are not removed in NSRP VSD-less cluster.
Routing
•686224—BGP neighbor flapped at irregular intervals.
•718144—During route failover some sessions are not getting cleared.
•728946—BGP router cannot be established between two loopback interfaces belonging
to different Virtual routers on the same device.
45Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
VoIP
•705648—SIP ALG was unable to parse the multipart or mixed MIME type in SIP INVITE
packet, when it had values within quotes, but spaces in between words.
VPN
•592488—Connection to VPN failed when the external IP changes on the NAT device
that resides in-between VPN end points.
•703677—In redundant VPN configuration, OSPF did not come up during VPN failback
from secondary to primary.
WebUI
•676776—WebUI was unable to display vrouter name, if the length was more than 15
characters.
•687935—In WebUI, the policy search feature was unable to display the selected service
if it belonged to multi-cell service.
•688016—WebUI was unable to display NHTB table entries if the list of NHTB entries
was more than 582.
•717325—Monitor Zone and Monitor Interface configuration was not available in WebUI.
Addressed Issues from ScreenOS 6.3.0r10
ALG
•604887—With SIP ALG enabled, the device might sometimes send TCP packets with
window size zero which might stall the SIP session.
•679138—RM resources are released incorrectly that subsequently causes RTSP traffic
to drop.
IDP
•697323—Sometimes the security module stops forwarding the traffic due to a memory
leak in IDP engine.
Management
•578449—Firewall was unable to connect to NSM using the first connect.
•665355—NSM supports "unset nsrp config sync vpn-non-vsi" command.
•674637—The firewall crashes sometimes when a long URL was described in custom
category of sc-cpa.
•675913—SNMPwalk was not including logical interfaces in the output list for IFDESCR
and IFNAME OIDs.
Copyright © 2015, Juniper Networks, Inc.46
ScreenOS 6.3.0 Release Notes
NSRP
•568133—IPv6 RA messages are processed on VSD 0 interfaces and are not processed
on VSI interfaces which are part of VSD 1 and VSD 2.
•574244—Even after no preempt option was enabled, sometimes the device rebooted
as master.
•666641—Data link was unavailable when there is only one link in HA zone connected
to 16 port uPIM.
•672901—After failback due to preempt, the new master (with preempt) sometimes
lost connection to IC4500 (Infranet Controller).
Other
•578204—Firewall forwarded duplicate log information to NSM due to an error in the
session byte count.
•599808—Ability to log UDP floods on ASIC based systems was added.
•600543—With NSM enabled, the device management was very slow and the device
was resetting frequently.
•601364—Interface physical link was brought up after reboot even after it was down.
•610108—IPv6 Auto-Discovered route was inactive when IPv6 over PPPoE is connected.
•660288—In non-HA mode, IPv6 multicast packet was dropped by the interface when
ipv6 config is disabled. Do not consider VSI.
•660950—In NSRP Active or Active environment, PPTP might get disconnected
unexpectedly.
•662392—Duplicate MAC addresses are returned in reports for the mac-tables of SSG
bgroup interfaces.
•662589—Firewall experienced core dump and rebooted the system when accessing
the Dlog process.
•662930—Traffic through the IPSEC tunnel destined to one of the interfaces sometimes
fails, because of reply packets getting sourced from tunnel interface IP.
•664485—Policy might not compile exactly, when "negate" was used.
•665008—TCP connection was not established for MSRCP traffic in certain conditions,
due to an endian issue.
•666370—Incorrect destination port was displayed 20480(0x5000) in the event log
for the web management connection when the system configuration is saved through
web-UI.
•668859—In SNMPv3 configuration, there was no option to specify the source interface.
•673295—The command "set chassis audible-alarm all" was modified on the SSG
platform to remove the "battery" option as the SSG platform does not support this
option.
47Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•674245—"Packet Too Big" message from ICMPv6 was dropped due to no session.
•674736—GTP IDreq packets are incorrectly dropped by sanity check due to unknown
IE.
•675296—In L2 mode, the vsdless session must have time sync mechanism.
•676289—The device crashes while running certain commands through SSH or telnet.
•676354—SSG140 dlog queue fullness causes session leak and results in traffic drop
with message "packet dropped, the dlog queue is full".
•676984—Authentication in NSRP from an Infranet Controller can sometimes lead to
duplicate authentication entry and might cause crash dump and reboot unexpectedly.
•677467—Open SSH 5.8 client with pty-req greater than 256 bytes fails with "PTY
allocation request failed" error.
•680365—Firewall crashes and reboots when AV was enabled.
•681955—Syn-cookie might not get triggered sometimes for the traffic that traverses
custom L2 zones.
•683501—The MSS option and length are incorrectly built when using SYN proxy.
•685029—For IPv4 traffic with IP Protocol 58, traffic log displayed ICMPv6 in the service
field.
•687205—"Config datafile" for NSM might not include routes from shared DMZ VR (for
vsys) to other vrouters.
•687653—Sometimes tftp fails due to save config (from device).
•688938—In a multiple VSYS environment, event Log messages on the Syslog server
was showing a wrong VSYS as the origin of the message, as the message belongs to
a different VSYS.
Performance
•607132—Traffic might be affected by flow control mechanism on the interface.
Routing
•683325—OSPF neighbor ship gets affected in loading while the OSPF messages
fragment size was bigger than 1668 bytes.
Security
•677385—Transparent or L2 mode firewalls sends a SYN+ACK response packet to
client with an all-zero MAC address.
VOIP
•662790—SIP registration packet was larger than the allowed registration packet size
for Avaya 9600 series phone.
Copyright © 2015, Juniper Networks, Inc.48
ScreenOS 6.3.0 Release Notes
•664502—H323 messages are still flooding in ISG2000 even after disabling h323
app-screen message-flood.
VPN
•591501—After reboot, the configuration pertaining to IKEv2 for EAP authentication
was not preserved if the definition of the IKEv2 gateway name contained spaces.
•604229—IPv6 with IKEv2 VPN tunnel might not sometimes come up between the
Motorola router and Juniper SSG device because of certain implementations.
•673075—IKE DPD messages are generated from the NSRP backup device even after
the NSRP failover occurs.
WebUI
•610921—WebUI has limitations on ipv6 client-duid length.
•671222—The WebUI login might not accept a username of 31 or greater characters
even though the username was valid through CLI.
•678280—Unable to modify WEB filter custom message on ScreenOS firewall through
NSM GUI for integrated SurfControl CPA.
•685269—The "activate" command fails while saving the BGP neighbor through WebUI.
Addressed Issues from ScreenOS 6.3.0r9
Administration
•580929—Unable to add zone to proxy-id when zone name has a space.
•604785—While creating VSYS with VR in the same line an incorrect and mandatory
VR id number syntax is required as an optional field.
ALG
•539589—Return NIS packets might be dropped on the firewall due to non-existence
of ALG pinhole. This is specifically with design where NIS server resorts to DNS lookup
when host is not found in NIS database.
HA & NSRP
•609184—HA LED status was incorrect when unset VSD-group id was configured as
0.
IDP
•662378—After restarting the security module the policies are not compiled and loaded
in to the IDP module.
•670888—IDP module core dumps when the security module is restarted.
49Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Management
•556535—PBR configuration was lost after the firewall was rebooted.
•575680—SNMP walk on 10-gig interfaces shows incorrect interface speed.
•607350—Unable to retrieve the chassis slot information with SNMP walk.
Other
•544795—"Unset http skipmime mime-list" command appears during config.
•558343—Memory utilization of "sys pool" increases as some of the memory allocated
in SMTP parser are not freed when the SMTP sessions are released.
•561641—Packet loss under heavy traffic with NS5400 and 2XGE cards.
•574264—Sometimes legitimate source IP address might be detected as an antispam
blacklist IP address during high number of SMTP traffic.
•578457—SCP was not working on Ubuntu 10.10.
•581190—The device failed when memory was allocated.
•584827—The backup firewall might not get all IPSec SA synchronized from system
restart due to large number of VPN connections on NSRP setup.
•585139—Sometimes device might reboot unexpectedly when certain TCP-based SIP
traffic passed through the firewall.
•585768—SSH connections drop after 45 seconds of inactivity.
•587433—Sometimes after OS upgrade, the firewall might not start up because of
certain condition in flash writing mechanism.
•587809—Negotiation event log was not generated when IKE phase one was initiated.
•593583—The device failed while processing SMTP traffic for Antispam.
•595094—In IPv6 environment, device might encounter HIGH flow CPU as IPv6 policy
search algorithm might consume most of the FLOW CPU time.
•596169—SSG device running PPPoe core dumps when there was no DNS option
defined in PPP control packet.
•596585—If IPv6 was not enabled on incoming interface, the multicast link local packet
such as NA was not considered as a to-self packet, and the device forwarded these
packets.
•598630—Event log displays "route is invalid" even though there are no route changes.
•598836—ASIC resets when FTP service is configured with a never timeout.
•599609—The "in packet" and "in ucast" counter increased, though the physical
interface was down.
•601092—Device name is missing in the syslog message forwarded from the firewall.
•601173—Shared memory corruption caused by CPU enqueuing caused incorrect packets
to free buffer queue.
Copyright © 2015, Juniper Networks, Inc.50
ScreenOS 6.3.0 Release Notes
•602147—"set arp" command was not supported in Transparent mode.
•604069—When Antispam or Antivirus was enabled, under certain conditions during
TCP establishment, the TCP traffic did not flow properly.
•606118—Internal duplicate policy log entries caused the send mail task on the firewall
to loop that subsequently caused high CPU usage.
•610023—[SSG300/500]Byte count for log-self shows wrong value.
•610123—ASIC stopped forwarding traffic due to shared memory corruption problem.
•610271—While logging multicast traffic, the policy based traffic log was incorrect.
•612248—During high traffic, frequently pressing Crtl+C on console caused wrong output
in the event log and subsequently the device failed.
•613108—After deleting a policy, the "traffic logs" for that policy was not removed and
are not cleared manually.
•614521—Policy scheduler cannot cover one minute between 23:59 and 00:00.
•660958—[SSG550/SSG320] IPv6 log self shows wrong source and destination port
numbers.
•661003—[SSG500/SSG300] destination ports are shown different in the self log
saved from WEBUI.
Performance
•598073—FPGA performance limitation dropped HTTP packets and caused latency
during performance testing.
Routing
•577347—After double NSRP failover, the routes redistributed into OSPF failed.
•588275—Unable to clean up the RIP routes learnt from demand circuit in a VR.
VOIP
•537064—Corrected the tunnel policy search logic, after opening a pinhole in the firewall
because sometimes the tunnel policy search failed.
VPN
•590496—Firewall does not respond to notification message when phase 2 proposals
mismatch in IkeV2.
WebUI
•562438—In WebUI, the "dialup user group" for IKEv2 was disabled and cannot be
configured.
•596093—Java Script WebUI display error was corrected in Internet Explorer 9.
51Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•614616—The 6 to 4 tunnel end point IP address from WebUI will be rolled out by clicking
Ok button.
Addressed Issues from ScreenOS 6.3.0r8
Administration
•580933— High task CPU triggered flow CPU utilization alarm.
ALG
•586961— Application with large MSRPC payload did not work with ALG enabled.
Antivirus
•529357— Management traffic was dropped by the firewall when the antivirus database
was getting updated.
Authentication
•587578— 802.1x authentication is not supported on a bgroup interface.
CLI
•574045— A command was introduced to permit IGMP packets with TTL greater than
one and to provide compatibility with other interoperability devices.
DNS
•580838— Fragmented DNS packets failed to pass through device if Jumbo frame
support was enabled.
IDP
•546621— IDP AVT timeout parameters caused high task CPU. This problem was seen
more in NSRP cluster.
•560339— ISG IDP signature did not detect the Telnet attack pattern when configured
in the policy.
•530282— sme_image caused high task CPU and NSM failed to update ISG-IDP.
Copyright © 2015, Juniper Networks, Inc.52
ScreenOS 6.3.0 Release Notes
Management
•428710— Deleting the source interface bound to NSM module resulted in trace errors
or crash dump causing the device to reboot unexpectedly.
Other
•487640— Hardware counters did not work on NS-5000-2XGE-G4 [2 x 10GigE Secure
Port Module (SPM)].
•539351— MS-RPC sessions failed because of a cold start sync failure caused by RPC
process.
•554007— The device sometimes failed because of a particular type of packet.
•554716— Memory leak was triggered in system memory pool upon SSH login to SSG.
•555070— SCTP traffic failed when it was moved to ASIC using the command set envar
x-in-ip=yes.
•561219— Firewall experienced high CPU while receiving ICMP ECHO request with fixed
sequential ID.
•563425— Firewall failed sometimes when there was a communication error, such as
duplex mismatch with the Infranet Controller.
•563494— Syslog messages contained the character 'T' between date and time that
caused parsing errors.
•568377— ASIC goes into non-responsive state with IPSEC-DSCP marking enabled.
•570868— The firewall rebooted unexpectedly because of an unexceptional read error
in an incorrect packet buffer.
•572707— Firewall failed because of a malfunction while running SPF in the OSPF task.
•576128— The security module information with error "sm_get_cmd transmit timeout"
could not be obtained because of memory leak on SM.
•580534— Auth table entries for the Infranet-auth policies was not maintained correctly
for the VPN tunnel sessions.
•585314— SCP to the firewall failed from an UNIX machine and displayed the error
"unknown file '--ns_sys_config."
•590147— Members of aggregate interface set as down were up after reboot.
53Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Routing
•554973— PBR was unable to route traffic using tunnel interface when it was in the up
state.
VPN
•550440— With IKEv2, firewall had responded to the create_child_sa message from
peer successfully but showed VPN status as inactive.
•573906— Firewall uses old xauth-ip for p2sa rekey though the xauth-ip has changed.
This resulted in repeatedly requesting the user for Xauth authentication.
•579094— IKEv2 with AES encryption in proposal failed because of incorrect attributes.
•579899— In transparent mode, the traffic destined to vlan1 through policy based VPN
could not reply back to the same tunnel. Eventually management traffic such as ping
did not work.
•581469— When IKEv2 was executed, clients located behind some NAT devices were
disconnected.
WebUI
•578196— Hardware version displayed 0(0) on the WebUI.
•582678— Creating admin user with special characters resulted in creating an invalid
user.
•585834— While domain name had resolved many different IP addresses, Policy
Elements Addresses character were sometimes shown as garbled.
Addressed Issues from ScreenOS 6.3.0r7
ALG
•524042—SIP ALG was unable to handle the RTP data session properly in a DIP/VIP
environment.
Antivirus
•503330—Firewall was unable to process packets with the error, "Cannot allocate
memory logged with AV dropped due to scan-engine error code 10".
•514358—High memory utilization in the AV engine resulted in error, "Cannot allocate
36880 bytes of memory".
•519926—Firewall rebooted unexpectedly because of an error when processing packet
in the AV engine.
•548601—When ASP received out-of-seq TCP packets, it did not send back ACK until
all packets were received in sequence.
•559335—File download stopped intermittently when AV was enabled because of an
error in the TCP proxy connection.
Copyright © 2015, Juniper Networks, Inc.54
ScreenOS 6.3.0 Release Notes
Authentication
•448478—RSA SecureID authentication stopped working after few hours of operation.
•557646—WebAuth failed to provide the correct login page to the client for connecting
through a VPN tunnel.
CLI
•559694—When concurrent session was large, there was intermittent high task CPU
for a second, when an interface was added or removed.
•568937—The tunnel interface description command was not displayed in the "get
configuration" output, and the configuration was lost after the firewall was rebooted.
Management
•548025—NHRP configuration was not supported in the config data file when managing
through NSM.
•552547—When there were primary and secondary NSM servers configured with source
interface, the device did not try to connect to the primary, and tried connecting only to
the secondary NSM server.
•569631—The admin name and password could not be changed or edited using NSM.
NAT
•533403—While translating from IPv6 to IPv4, NAT-PT process on the firewall was
adding additional fragment header without doing fragmentation, which caused the
packets to drop.
Other
•522601—Firewall failed while processing the packet for Ichat ALG.
•524318—The null zone was renamed to an unknown name in the VSYS environment
when renaming the VSYS.
•547040—ASIC dropped multicast packet when the last hop PIM router with SPT
disabled packet was received.
•548257—Traffic stopped passing due to session allocation failure in certain condition.
•548464—Sometimes the tcp traffic was delayed by 1ms, when the tcp traffic passed
through the 10G IO card.
•552417—Incorrect calculation of string length caused the device to reboot unexpectedly.
•552804—Firewall failed during SPF calculation in OSPF V3.
•555254—Implemented the support for UDP based fragment on data session when
the session was part of the ALG like SIP protocol.
•558859—Firewall experienced a high memory usage and memory leak in the SSL and
certificate modules.
55Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•558980—Firewall failed when executing get route ip command in a multicast
environment.
•562919—Firewall failed when the command was executed and redirected to tftp get
igmp group > tftp x.x.x.x get_igmp.log from ethernet2/1.1:1.
•564557—Firewall incorrectly handled the POP3 RSET command.
•567152—Firewall stopped passing traffic on the bgroup interface with two interfaces
in the bgroup which were connected to the same switch and when one of the members
interface state changed to down.
•567976—Firewall failed when collecting the debug data for a split-brain condition due
to an ASIC problem.
•568304—Firewall failed when the DNS refresh occurred and the policies were updated,
which also updates the proxy ID for the policy-based VPN.
•569540—Incorrect time stamp was displayed in the event log message during the last
month of DST, when the DST was enabled.
•569979—Firewall failed to download a file from Adobe website when the
reassembly-for-alg was enabled in the zone with DI.
•570432—Incorrect log with IPv4 address was generated while editing an IPv6 address
book entry.
•570628—Debug messages were displayed in the buffer even when no debugs were
running on the firewall.
•570710—Firewall did not allow MIP IPs of the same range to be configured in different
VSYS.
•570948—Firewall failed when it received a last fragment packet size of 64 bytes.
•582278—Firewall dropped the pass through PIM multicast traffic due to an error in a
policy lookup process.
•584381—Firewall failed due to an unexceptional error while processing the traffic.
Routing
•564997—Firewall sent invalid triggered RIP updates on the interface which was not
configured to send the update.
VoIP
•539819—An H.323 IP phone registration failed because a packet that matched a session
on the ASIC was forwarded to an incorrect session queue.
VPN
•548117—In IKEv2, firewall did not send the IDi and IDr messages with payload
information to the peer when the Phase 2 VPN failed with a proposal mismatch.
•572352—VPN tunnels failed with proxy-id mismatch error after upgrading from
ScreenOS release 6.0r4 to ScreenOS release 6.3r5.
Copyright © 2015, Juniper Networks, Inc.56
ScreenOS 6.3.0 Release Notes
WebUI
•519824—A device failed when a reject message was configured for integrated surf
control using WebUI containing more than 500 double byte characters.
•538758—During deletion of VPN modecfg profile, "Unknown keyword" error was
displayed due to the missing quotes when the profile was created in WebUI.
•552566—With HTTP redirect enabled, the device failed to redirect to HTTPs while
accessing IPv6 address using WebUI.
•567094—Sometimes the firewall policy with multiple address/service objects change
to a single object, if the "too many counting policies" error was encountered when the
policy was configured using WebUI.
•573637—WebUI did not display all the list of interfaces when there was a long list of
interfaces with sub interfaces.
57Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Addressed Issues from ScreenOS 6.3.0r6
Administration
•536897—Under certain circumstances, the message command rejected due to writing
config conflict was printed on the telnet, ssh or console of the device.
Antivirus
•535728—While scanning the FTP session, the APP session was aborted because the
device ran out of packets with code 0 resulting in low memory. Delete unused license
to free memory space.
Authentication
•536931—Cross-vsys authentication did not bind to the correct session in both vsys
which resulted in a session that was created in the ingress vsys but not in the egress
vsys. This resulted in denial of traffic.
CLI
•541186—The set log exclude-id command did not work for some of the event-types.
DI
•538459—Memory leak in sys memory pool occurred when generating an alarm for
some signatures.
DNS
•531507—The status of Domain Name Server (DNS) entry in the address book was
incorrect.
GPRS
•544157—GTP events produced multiple log entries.
HA & NSRP
•524021—NSRP backup session installation error occurred because of route look up
failure that caused packet drop after failover.
•529696—Under certain circumstances, with the HA link probe configured, the device
sometimes rebooted unexpectedly when the status of the HA link changed.
•538250—Communication through the master node sometimes failed when exchanging
the backup device through NSM doing the RMA procedure.
Copyright © 2015, Juniper Networks, Inc.58
ScreenOS 6.3.0 Release Notes
IDP
•536048—Repeated pushing of AppSig Db to security modules from NSM in the absence
of IDP policy caused memory leak on the security modules leading to update failures
on NSM.
Management
•544149—[SSG350]Status of I/O fan 2 was reported incorrect through SNMP on
SSG350.
•551538—Sometimes, the set envar config=flash command did not load the existing
configuration file upon reboot.
Other
•453396—Under certain conditions the L2TP packets timed out, and the tunnel was
not deactivated and removed properly, which caused new packets to use an existing
tunnel and was black holed.
•499157—High-end platforms reported high task CPU utilization if there were huge
number of phase 2 SAs configured.
•504136—The firewall sometimes resets when SIP packets with invalid header were
received.
•504566—The device sometimes rebooted unexpectedly if a tunnel session was treated
as a normal session.
•524232—RTSP ALG erroneously treated two different packets as a pair of translated
packet and then dropped the packet.
•526243—The device rebooted unexpectedly due to CPU deadlock.
•527319—[SSG20]No link was present for Copper SFP running JXM-1SFP-S module.
•530924—PPP negotiations sometimes failed because of failure in adding a host route.
•535171—Firewall failed when it received an IPv6 packet for an IPv4 session cache entry
during the sanity check process.
•535584—Firewall was not able to learn the new MAC address in the IPV6 environment
when the upstream device NIC card or MAC address was changed.
•537316—The device rebooted unexpectedly during DNS refresh.
•538370—External authentication server support was added for FIPS mode.
•538766—The device rebooted unexpectedly due to IPv6 address double free issue.
•539010—Firewall failed when the policy pointer was NULL because of wrong packet
tag between ASIC and CPU.
•540038—Sometimes, in NSRP Active/Active mode, asymmetric traffic was dropped.
•541647—The error message "FTP, FTP-Get and FTP-Put should not be put in the same
group" was displayed when adding FTP service to a multi-cell policy.
59Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•547117—Packets were dropped by anti-spoofing screening option on the backup NSRP
firewall.
•547750—[IPv6] UDP checksum was zero.
•547943—[NS5000] The increasing CPU4 drop counters affected the MGT3 platform
only.
•548054—ISG and NS5000 platforms dropped pass-through ESP fragmented packets
with total size around 1700 bytes.
•548294—When the set flow reverse-route clear always command was configured, the
packet did not get arp resolved and was queued twice.
•548449—Firewall displayed a Trace dump when get config command was run with
OSPFv3 and IPv6 enabled.
•549614—Firewall failed when details for a peer gateway in a manual VPN configuration
were accessed.
•549816—Under certain circumstances, the firewall core dumped and rebooted
unexpectedly.
•558643—With FIPS enabled, device failed to boot after upgrading to 6.3r5.
Routing
•441711—RIPv2 failed to advertise routes to the neighbors after few hours of operation
in a hub-and-spoke VPN setup.
•533910—RIP updates with more than 825 routes were dropped.
•535615—OSPF neighbor on the VPN tunnel went down when the OSPF neighbor
session was incorrectly formed on the loopback interface rather than the tunnel
interface.
•543671—BGP peering failed when force-reconnect option was enabled under certain
configuration conditions.
•544754—Inter-area route was not removed from routing table even though an intra-area
route was learnt and existed in the OSPF database.
Security
•540983—SYN packet sent to the server by the firewall after triggering the SYN-proxy
had an incorrect checksum.
VoIP
•530047—SIP ALG was unable to handle the SIP calls that needed cross vsys policy
search.
VPN
•508798—Firewall utilized very high memory when VPN was configured.
Copyright © 2015, Juniper Networks, Inc.60
ScreenOS 6.3.0 Release Notes
•533635—Route-based VPN failover did not work because of an error in the route look
up process.
WebUI
•534271—Predefined service timeout could not be edited using the WebUI.
•535613—In the WebUI, adding a VIP using a service name with an ampersand (&)
resulted in "400 Bad Request" error.
•535995—Unable to add profile name or user-group name with a blank space in WebUI
when configuring URL filtering.
•536474—Replacing the NSRP configuration using the WebUI including certain specific
CLI sometimes caused unexpected behavior after reset.
•546601—Adding track IP in a vsys using WebUI resulted in error.
Addressed Issues from ScreenOS 6.3.0r5
The following operational issues were resolved in this release:
Administration
•509654—[SSG 140] TX/RX LED remained ON even after the set interface ethernet0/X
phy link-down command was executed.
•511835—The configuration sometimes got deleted while configuring the administration
setting for custom L2-zone.
Antivirus
•523759—The firewall rebooted with "Exception Dump" when AV was enabled on the
policy.
Authentication
•511019—802.1X authentication failed after PC hibernation.
•528252—The firewall sent multiple WebAuth requests to the user when a single HTTP
request was split into multiple packets.
61Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
DHCP
•510653—Unable to configure DHCP option string with a length greater than 128 bytes.
DI
•528641—Under certain conditions, after DI attack signature update, the configured
"action" in attack policies became incorrect.
HA & NSRP
•509803—Software sessions on backup firewall did not ageout properly because of
its inability to synchronize time with its master unit.
•519838—Both firewalls in NSRP cluster sometimes became master.
IDP
•522728—Under certain conditions, the traffic dropped because the inline-tap mode
was changed to inline mode.
Management
•505106—Under certain conditions, the policies were marked as "invalid" because of
NSM policy push operation.
•520991—After reboot, the unset http skipmime mime-list command was added to the
configuration.
•522075—TCP sweep and UDP sweep screen options could not be configured using
NSM because these options were missing in the ScreenOS config datafile.
•522349—Signatures with 30 or more characters were truncated when passed through
the syslog output.
•524380—The ifOperStatus reports wrong value in the NSRP passive cluster member.
•526797—When DNS response was fragmented, the reason for session close in the
traffic log became ageout.
•529788—NSM view statistics sometimes caused the device to reboot unexpectedly
with dump.
NAT
•512224—MIP translation between IPv6 addresses failed to translate.
Other
•478573—[SSG300] The device sent corrupted IP packets on reboot.
•483101—The Elliptical Curve Diffie-Hellman (ECDH) IKE implementation populated
both group type and description in the Payload, and caused interoperability issue with
third party VPN devices.
Copyright © 2015, Juniper Networks, Inc.62
ScreenOS 6.3.0 Release Notes
•503307—Application-Specific Integrated Circuit (ASIC) hung and stopped passing
traffic due to incorrect session pointer.
•513394—A problem with the generation of counter statistics caused the firewall to
reboot unexpectedly.
•519557—Firewall sometimes dropped packets in transparent mode if syn-flood was
enabled.
•526215—"Policy:Not Found" error was displayed when the user tried to add a new
policy with "before id" and "DSCP enable value" keywords together.
•529690—ESP pass-through traffic did not consider custom service timeout when the
custom ESP service was part of a service group.
•529736—The policy scheduling options "Recurring" and "Once" did not work together.
•532937—The firewall incorrectly allowed the user to configure an IPv6 MIP and then
DIP with the same address.
•500993—Issue with RSH when the application reused source port while closing control
connection. The data traffic still existed.
•533822—When using SQL redirect, the ALG did not open the pinhole correctly.
Routing
•528011—In specific circumstances, BGP did not send updates on routes that were
unreachable.
•528417—Redistributed default IPv6 route in OSPFv3 was not advertised after an hour
of redistribution.
VoIP
•529845—With SIP ALG enabled, the firewall sometimes experienced high CPU.
VPN
•469089—The VPN monitor did not function for a manual key VPN because a proxy id
check was added on the packet sanity check, which was not required for a manual key
VPN.
•506464—Under certain conditions, the device sometimes rebooted unexpectedly
because of RSA authentication.
Addressed Issues from ScreenOS 6.3.0r4
The following operational issues were resolved in this release:
63Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Administration
•467398—Local root user sometimes lost root privilege when the remote admin used
the same user name.
•496029—While managing the firewall using SSH Secure Shell v.3.2.9, firewall reported
"Potential replay attack detected on SSH connection initiated from x.x.x.x."
•501075—The VeriSign CA certificate had expired and was invalid. It could be removed
from the system as the system already contained a valid VeriSign CA certificate. The
valid certificate could be seen with get pki x list cert command.
•504196—SSH management sometimes disconnected abruptly when large output
commands were executed.
•508319—The device sometimes rebooted unexpectedly when the memory got
overwritten by the EAP task.
ALG
•498113—In certain conditions, with RTSP ALG enabled, the RTSP traffic failed through
the firewall.
•498869—Fragmented MSRPC packets were supported in the ALG.
Antivirus
•498121—In certain scenarios, with AV enabled, the HTTP slows down due to TCP
retransmission.
Authentication
•503196—The source interface option for authentication (auth) did not work when
LDAP was configured as the AUTH server.
CLI
•484141—System rebooted unexpectedly when get sip transactions command was
executed.
DHCP
•495244—DHCP custom option 43 was sent with an invalid length.
HA & NSRP
•515159—The backup device used virtual MAC for ip tracking in a PPPoE environment
using interface redundancy.
IDP
•507318—IDP Engine failed on security module and created core file.
Copyright © 2015, Juniper Networks, Inc.64
ScreenOS 6.3.0 Release Notes
•513071—With application identification enabled, invalid pointers had created an issue.
Management
•491132—ICMP packets to the management interface experienced delay at regular
intervals.
•494629—SNMP trap was not sent to indicate that the CPU utilization had returned to
normal level.
•501026—The exec policy verify command did not work for the group service.
•502845—The firewall rebooted unexpectedly when the L2TP policy was removed
through NSM.
•503139—Under certain conditions, during an SNMP walk, the firewall sometimes
rebooted unexpectedly.
Other
•419637—Many drop notification messages between IC and IE caused instability in the
SSH connection between them.
•471425—The event log displayed interface flapping messages within the same second
on the firewall, but the other end of the connection did not record interface flapping
messages within the same second on the firewall.
•485192—The GRE packets of PPTP session were dropped sometimes if PPTP server
CALLID was set to 0.
•488614—The set zone <zone name> tcp-rst command did not work for SSH on high-end
platforms.
•491466—SQL connections failed sometimes when the SQL ALG was enabled.
•492796—[NS5000] Under certain conditions, only software sessions were created
when there was no destination MAC address entry of the packet in the MAC learning
table. As a result, subsequent packets were flooded and the CPU utilization was high.
•494276—A URL blocked by Websense sometimes did not display the corresponding
blocked message in the browser in an asymmetric routing environment.
•494617—ScreenOS devices managed by NSM version 2009 or above sometimes
encountered memory leak issue.
•494946—[SSG 300] The alarm LED did not turn red when large ICMP packets were
detected.
•495554—Firewall rebooted unexpectedly when the policies changed and read at the
same time.
•498529—The SNMP get query for BGP related OID sometimes provided an incorrect
output.
•498562—IPv6 did not work on PPPoE ADSL interface.
•499421—With edipi enabled, XAUTH user cannot inherit the IP information from old
XAUTH session when rekeying new SA leading to memory leak.
65Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•500495—With antispam enabled, e-mail with attachments greater than 3 to 4 MB
sometimes dropped due to out of memory error.
•500843—Output of SNMP walk sometimes displayed incorrect interface for ARP table
entries.
•501256—The Translated Dest column was empty when the traffic logs were saved
using WebUI.
•501343—Even though there was no incoming traffic, alarm traffic for policy increased,
because the self traffic was denied by the deny policy.
•502419—Traffic shaping statistics were not displayed on the NSRP VSI interfaces on
the firewall.
•504084—The track IP failed sometimes when the interface was inactive.
•505456—Event log displayed "system temperature severely high" message even when
the temperature of the device was appropriate and the hardware was in good condition.
•505554—Traffic log for large PING over MTU size was displayed as close-ageout
instead of close-resp.
•506473—Radius server was not reachable when the source interface was not the
Virtual Security Interface (VSI).
•506543—Parsing a folder with the name "quit" abruptly closed the FTP session.
•509166—SSG5 wireless device was not able to locate the best channel under certain
conditions.
•510473—Typo in infranet enforcer mode test command resulted in syntax error after
reboot.
•511026—The implementation of IKEv2 DoS attack prevention was incorrect.
•511812—When a BGP neighbor was configured and an outgoing route map was applied,
the firewall did not apply the local preference correctly as specified in the policy terms.
•512752—In certain conditions, failure of the infranet controller connection caused high
CPU condition on the device.
•515064—In certain conditions, it was possible to define a custom service object for
protocol 0.
•520662—Under certain conditions, the get alg pptp xlat command sometimes caused
the device to reboot unexpectedly.
Copyright © 2015, Juniper Networks, Inc.66
ScreenOS 6.3.0 Release Notes
Performance
•494910—[SSG 140] In certain circumstances, when there was heavy traffic through
the interface, all the traffic passing through the interface e0/9 was blocked.
Routing
•501996—In case of multiple virtual routers (VRs), sometimes, deleting a multicast
route from one VR might not update information in the other VR causing the device to
reboot unexpectedly.
•504708—With NSRP sync route enabled, the redistribution of routes from BGP to
OSPF was delayed.
•505962—The RIP packets were constructed twice with the same RTE, but with different
metrics.
•501953—The redistributed default route did not get advertised in the OSPFv3.
VoIP
•511469—Limitation on the maximum h245 channel number was 10. This limitation
caused problem with certain VoIP applications.
•517439—URI of SIP message was modified incorrectly when NAT with SIP ALG was
used.
VPN
•441805—The ikmpd task caused periodic high task CPU peaks.
•500203—ASIC based firewall sometimes stopped passing traffic when ESP packets
with invalid SA value were received.
•502729—VPN failed to come up when the outgoing interface was a loopback interface.
•503323—After deleting a VSYS, the system log erroneously displayed error messages
related to deleting a tunnel zone, and SSH PKI key associated with that VSYS.
•504014—In some scenarios, VPN policy with MIP failed to translate Proxy ID.
•505065—VPN policy with domain name was not updating the right proxy-id after
reboot.
•508886—NetScreen Remote Client for dial up VPN did not failover to redundant
gateway when track-ip failed.
WebUI
•496267—The tunnel interface erroneously appeared inactive in the WebUI and ready
in the CLI when the VPN monitor was disabled.
•496418—WebUI configured as a web bookmark did not open in a new window on an
SA Series page.
67Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•502098—Sometimes, the device rebooted unexpectedly when the VPN name was
changed.
•504696—Potential unauthorized disclosure vulnerability was found, when the private
address of the firewall was sometimes disclosed.
•506282—Whitelist URL was blocked by URL filtering because the code did not identify
the port number (non 80) in the hostname header.
•507172—Sometimes, the firewall rebooted unexpectedly when WebUI was accessed.
•513085—In the WebUI, under certain conditions, MIP configuration for IPv6 address
was not available.
•515172—Alarm events for DI detection were missing in an exported report from the
WebUI.
Addressed Issues from ScreenOS 6.3.0r3
The following operational issues were resolved in this release:
Administration
•417686—Socket leak might occur when Internet Explorer (IE) with HTTPS was used
for WebAuth management.
•472816—Sometimes the clear socket <socket id> command could not clear the tcp
socket when it was in a certain state.
•480480—Under certain conditions, memory leak in the event log module caused high
memory utilization.
•481730—The get system command displayed the hardware version as 0000(0)-(00)
on SSG300 and SSG500 devices.
•493627—Under certain conditions, device might reboot unexpectedly when RPC
(MS-RPC or SUN-RPC) traffic passes through the device and show rpc map command
was executed.
Antivirus
•478469—In transparent mode, VLAN tag was removed from the HTTP traffic after AV
scanning.
DHCP
•484087—The destination IP was incorrectly set to 0.0.0.0 when DHCP relay agent
received a DHCP ACK in response to a DHCP INFORM.
GPRS
•448582—GTP inspection dropped the SGSN Context Response message if the Next
Extension Header type was 0xC2 (Suspend Response).
•449284—In certain conditions, the firewall failed to allocate GSN, and hence caused
the GTP traffic to drop.
Copyright © 2015, Juniper Networks, Inc.68
ScreenOS 6.3.0 Release Notes
•456358—The common flags GTP Information Element was not removed when set
remove-r6 command was configured.
•457093—For a new GTP tunnel, CreatePdpRequests from an SGSN were dropped if
the response was not received before a certain time period.
•472199—When R6 IE removal was enabled, GTP CreatePdpRequest packets got
corrupted when both the MS-Time zone information element and a private extension
were present.
•485578—The GTP remove-r6 feature removed the mandatory RAI IE from SGSN
Context Request and Identification Request messages.
•485911—Support had been added for removing Information Element '184 - Bearer
Control Mode' using the GTP remove-R6 feature.
•486613—When GTP traffic dropped, the bad system status message appeared in the
log.
HA and NSRP
•472083—When NSRP track-ip monitoring was configured within vsys, configdata file
had incorrect track-ip information.
IDP
•467521—[ISG-IDP] In certain conditions, processing of RPC packets caused memory
allocation problem which eventually caused the security module to hang.
•485928—[ISG-IDP] The IDP engine resets due to application identification.
•493618—[ISG-IDP] IDP engine core dumps frequently due to DFA cache memory
corruption.
Management
•455186—Firewall running OSPF rebooted unexpectedly after a delta configuration
through NSM was performed.
•456690—The traffic log did not display IPv6 addresses correctly.
•459999—The set flow vpn-tcp-mss command was not available for configuring in
NSM.
•466692—The SNMP IPv6 IfIndex value was reported as incorrect from the firewall.
•468514—Traffic log was not generated for a source or destination port equal to 1503.
•468659—E-mail notifications for logs from the firewall were not formatted correctly.
•470754—[NetScreen-5000] The redundant interface reported overflow errors when
it was not initialized correctly after a system restart.
•471298—UDP MSRPC EnDPort mapper (MS-RPC-EPM) traffic incorrectly displayed
the traffic log as MSRPC ENDPOINT MAPPER (TCP).
69Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•485725—Firewall socket issue caused higher task CPU than expected which caused
the management through web and SSL to fail.
•485946, 470729—Event log message displayed <username> turn off debug switch
for all when admin exited the CLI.
•485958—Source interface of secondary NSM server was incorrectly removed from
the configuration.
•491026—SNMP walk for certain MIBs did not return any value.
NAT
•450989—Unable to access MIP configured on loopback group from different zones
on the firewall.
•480667—The firewall allocated vsys limit for configuring MIPs to a shared interface
in root-vsys instead of global limit.
Other
•463515—MAC entries in the bgroup mac-table were not cleared after an interface went
down.
•465718—Under certain conditions, the device might reboot unexpectedly when a
Dial-Up user tried to connect.
•466619—The set license-key auto-update command rolled back to unset after a device
reboot.
•472178—The set zone trust screen udp-sweep threshold command enabled the
tcp-sweep option.
•472433—Packet might be corrupted due to ASIC buffer problem.
•472690, 264366—ICMP flood screening option incorrectly dropped packet and
generated alarm even when the packet rate was lower than the configured threshold.
•477561—The guaranteed bandwidth parameter was incorrectly allocated in traffic
shaping.
•479300—In some scenarios, non-impacting messages such as “TR installing ready
reverse wing” were logged to the debug buffer.
•479752—Under certain conditions, the device might reboot unexpectedly when running
get config datafile command.
•480179—When the SC-CPA server was inaccessible, the device displayed UF-MGR:
Internal error: Failed to allocate uf_record event.
•481096—Enabling the set log audit-loss-mitigation feature caused the device to halt
traffic after the log buffer was filled.
•481805—The bandwidth settings configured on the gigabit subinterfaces were not
loaded after reboot.
•484133—With unknown protocol protection disabled, traffic with protocol number
greater than 137 was dropped erroneously.
Copyright © 2015, Juniper Networks, Inc.70
ScreenOS 6.3.0 Release Notes
•484169—Firewall might reboot unexpectedly if GBIC card was not properly initialized
during boot up.
•484839—In some scenarios, firewall might restart unexpectedly if get alg pptp xlate
command was executed.
•485332—PIM register message was dropped when the inner packets were fragments.
•486445—The device might reboot unexpectedly due to its access to a NULL pointer.
•486896—Event log timestamp was changed because of NTP update.
•489167—The session was torn down while changing multi-cell policy if RPC was one
of the service cell.
•489205—In IPv6, the MTU was not changed according to an ICMP6 "Packet Too Big"
error message.
•490158—[Netscreen-5000] In some scenarios, the firewall stopped forwarding traffic
and was also not accessible through in-band access.
•490176—An upgrade for SSG140 running a dual boot image using SCP (secure copy)
required the device to reboot twice.
•491531—TCP session might be broken when failover occurs from one tunnel to the
other due to wrong TCP Window Scaling Factor in hardware session.
•492544, 491555—In certain situations, TCP-based SIP traffic in the environment could
cause the firewall to reboot unexpectedly.
•498306—[SSG 300/500] Under certain conditions the firewall would reboot
unexpectedly when UAC was configured.
Performance
•413433—[SSG-500] Internal sanity check caused higher CPU than expected resulting
in intermittent packet drops.
•478205—When large amount of WebAuth transaction takes place at a time, some
HTTP SYN packets might drop during TCP 3-way handshake without returning SYN
and ACK packets.
•491967—Policy search was slow with complex and larger number of policy
configurations causing high CPU utilization.
Routing
•466158—Capability negotiation error between BGP peers caused BGP to stay in idle
state.
•473625—Under certain conditions, multicast traffic did not match the longest matching
multicast group policy.
•474158, 446155—Change in RPF source route or change in route towards the RP was
not reflected properly to the multicast routing table.
•480470—BGP anti-flap processing was removed from the backup NSRP node.
71Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•482372—In some scenarios, IBGP did not send updates to some of the BGP peers.
•483854—OSPF neighbor relationship was lost on active primary connection when the
backup link flapped.
•485608—Firewall failure dump was caused by the BGP route updates.
•490020—In specific circumstances OSPF converged incorrectly.
VoIP
•458341—SIP ALG did not handle the SIP calls that used multi-part message as
expected.
•484227—SIP MIME and Multipart messages were modified on the firewall that caused
the SIP packets to drop.
VPN
•472618—NS-Remote IPsec phase one negotiation failed when IKE ID was changed.
•475831—Quotation marks (" ") were removed from configuration when the set vpn
vpn_name bind zone "zone_name" command was used.
•479107—The VPN proposals ordered through WebUI of the firewall was ambiguous
and could lead to unintended selection of the proposal between the VPN peers.
•480642—User could not pair a VPN policy when multiple MIPs were used as destination.
•480691—The VPN tunnel down message (for example, VPN <vpn-name> from
<IP-address> is down) was not generated in the event log when the NSRP backup
device became the master.
•482399—AC-VPN failed to connect from one Spoke to another Spoke VPN site in the
NAT-T scenario.
•486043—Firewall might reboot unexpectedly when IKE/CLI and flow module accessed
the NHTB table at the same time.
•486608—The set vpn <vpn> dscp-mark <dscp> command for manual VPN failed to
set the DSCP marking for outgoing ESP packets.
•489859—In some scenarios, when the firewall was reset, the tunnel interface status
remained down even when the security association (SA) was up.
•494667—Incorrect proxy-id with VPN Policy having MIP and overlapping source and
destination address.
WebUI
•291948—When the device had many event log entries, refreshing the main WebUI
page or the report page using Report > System Log > Event action caused high CPU
utilization.
•450974—Enabling or disabling the Java or ActiveX component also unsets IP Spoofing.
Copyright © 2015, Juniper Networks, Inc.72
ScreenOS 6.3.0 Release Notes
•474665—In vsys, for IKE gateway configuration, option to select shared root interface
was not available in the outgoing interface drop box in the WebUI.
•479160—Unable to save AutoIKE configuration for VPN phase 2 in the WebUI when
Proxy ID was enabled and vpn group was selected.
•479440—“unknown keyword ipv6” error was displayed when using VPN wizard for
vpn setup with IPv6 disabled on the firewall.
•480387—“The value of time-out cannot be greater than interval” was displayed for
certain interval values greater than the threshold values when creating Track IP entry
using the WebUI.
•493414—In the WebUI, when the user clicked Go or New button to open a policies
menu, the device rebooted unexpectedly.
•495940—WebUI incorrectly displayed the tunnel interface status as inactive.
Addressed Issues from ScreenOS 6.3.0r2
The following operational issues were resolved in this release:
Administration
•445491—When displaying BGP route advertised without specifying a neighbor address,
the error bgp neighbor 0.0.0.0 doesn't exist is displayed.
•456101—[ISG, NetScreen 5000] The port mirror command displayed erroneous Failed
command - set mirror port source ethernet4/1 destination ethernet1/1 message on console
bootup, even though the command existed in the configuration file and was working.
Antivirus (AV)
•458125—In transparent mode, with the UTM enabled, when preparing a child session
in the ALG traffic, the VLAN tag information was lost.
Authentication
•416043—The device did not clear the existing System Information Block (SIB) when
the associated radio caused the wireless authentication failure.
•471517—Protocol version check caused the RSA SecureID authentication failure.
73Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Command Line Interface (CLI)
•462860—[SSG 140/300/500, ISG 1000/2000, NetScreen 5GT] After a reboot, the
unset admin hw-reset command was not saved.
Deep Inspection (DI)
•454303—When a DI policy was enabled, and the ip-action was "notify", the packet
that matched the DI group specified in the policy got dropped.
Domain Name System (DNS)
•458316—A device might reset if a vsys that contains address book objects with DNS
names was deleted.
•471892—DNS queries did not work when device was configured to use itself as DNS
server (when DNS proxy is enabled on an interface).
General Packet Radio Service (GPRS)
•437975—With GTP inspection enabled, at times, the GTP Echo Response might drop
and the log displays the bad state message.
High Availability and NetScreen Redundancy Protocol (HA and NSRP)
•448011—Under certain conditions, WSF was not being updated in hardware session.
•449011—[SSG 140, SSG 300, SSG 500] When Active/Passive NSRP in L2 mode is
configured, some traffic might stop for a few minutes just after failover under a specific
condition.
•449858—Non-VSI PPTP session was not functioning as expected in NSRP
Active/Passive scenario.
•454981—[SSG 300M] When NSRP failover occurred, the red LED alarm was triggered.
•461079—[NetScreen 5000] The backup firewall would prematurely remove the
sessions on the master in a VSD-less NSRP cluster and cross-ASIC traffics.
•463752—In NSRP Active/Active mode, if tcp syn-check was enabled, the user could
not update the session after the three-way TCP handshake was complete.
Intrusion Detection and Prevention (IDP)
•431797—Packets were dropped when the TCP Error Reassembler Packet Memory
Exhausted signature was enabled.
Management
•455868—[SSG Devices] Number of tasks has been increased on SSG devices to allow
management to the device.
•473110—Format of IPv6 addresses were being sent incorrectly to NSM log viewer.
Copyright © 2015, Juniper Networks, Inc.74
ScreenOS 6.3.0 Release Notes
Network Address Translation (NAT)
•455943—When the PPTP service and GRE service timeout are configured to never,
the PPTP xlate fills up unless the PPTP connection is shutdown.
Other
•302382—In certain conditions, the firewall might reset if a session incorrectly references
a MAC address without route information.
•387173—Traffic was blocked intermittently because of an error in handling non-IDP
traffic as IDP sessions.
•432190—[NetScreen 5000 M3] VLAN retag did not work properly with 10 Gig interfaces.
•437660—Firewall reboots due to MGCP traffic.
•448252—[SSG 300] In transparent mode, the NMAP scan caused packet going across
the firewall to drop.
•449239—SQL ALG did not function as expected when client request came into the
SQL server's MIP address.
•451051—[ISG] Internal memory corruption caused ISG devices to stop creating new
sessions and hence impacted traffic.
•455183—Few packets might be dropped due to ASIC reinit.
•455373—The device resets when some SQL ALG registers access an odd address.
•455405—ALG for FTP, RSTP, GTP, SQL, SIP, and RSH was corrupting the control
packet which in turn was causing problems with the data packet.
•459357—WebAuth redirect from firewall contains a corrupted target URL when a proxy
was used and the HTTP-request was split into two packets. The first packet includes
the GET line and the second packet includes the HOST line.
•460233—With DST enabled, the e-mail notification time from ScreenOS was an hour
ahead of the actual time.
•461492—When SQL IPMP failover was performed, subsequent traffic did not pass
through the firewall.
•462783—Under certain conditions, sessions with timeout of 0 or 1 were never aged
out of the firewall.
•463422—New TCP did not pass through the firewall in Transparent mode if there was
no matching MAC table entry.
•465223—The get gbe id 1 CLI command causes the device to reset.
•468821—Double quotation mark (" ") was not accepted in the middle of a comment
or description for the definition of an address, route or group policy objects.
•473279—The debug nsm nsp-debug command might result in system reset.
75Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Performance
•455350—MTU was set to 1500 when a tunnel interface causing performance issues
was added to the interface.
Routing
•433987—Memory leak because of large OSPF LSA might reset the device.
•435956—Firewall removed some RP-set when it received BSR messages with a tag
zero.
•436444—Device might reset if IGMP v3 source specific report was sent.
•448691—BGP routes can get stuck in route table if two neighbors send the same prefix
route and routes change frequently.
•449723—Firewall might reboot because of incorrect scheduling of SPF algorithm for
the OSPF protocol.
•459513—Unable to set IPv6 static route to null interface.
Voice-over-Internet Protocol (VoIP)
•422611—Power Cycling H.323 IP Phone resulted in NAT pport leak.
•442077—H.323 calls failed when it exceeded 10 OLC channels.
•442660—Incorrect format of INVITE messages resulted in random failure of VoIP calls
using SIP.
•472554—[SSG 140] Maximum number of NAT cookies has been increased to 512.
Virtual Private Network (VPN)
•442719—Unable to configure a C Class Broadcast IP address for the IKE Gateway
address.
•448720—Unable to remove User Group that was previously bound to a VPN, even
after that VPN has been removed.
•452080—The TCP 3-way handshake failed because of an error in the setup of IPsec
VPN.
•455520—Tunnel interface was not created when route based VPN configuration was
pushed from the NSM.
•459053—A logically down interface might still respond to VPN monitor packets sent
by a VPN peer device, and hence not allowing the VPN state to go down.
•459239—Xauth information was erroneously removed when initial-notify was received.
•474622—[IKEv2] Tunnel IP address did not get released when Dial-Up IKE v2 SA was
terminated.
•474923—[IKEv2] Rekey is unsuccessful when using Dial-Up VPN.
Copyright © 2015, Juniper Networks, Inc.76
ScreenOS 6.3.0 Release Notes
WebUI
•455462—Using the WebUI, when an aggregate BGP route was added, a new option
summary-only was added that was not specified in the WebUI.
•459894—Unable to remove the address book object "DMZ Any" after it was configured.
•463137—IRDP cannot be enabled on interface e0/0 using the WebUI.
•465697—In certain conditions, the WebUI management causes the system to reset
because of incorrect parameter value.
•468211—In the WebUI, the IPv6 route entry did not accept uppercase characters for
an IPv6 address.
•469439—VPN monitor configuration might rollback to default after editing vpn entry
from the WebUI.
Addressed Issues from ScreenOS 6.3.0
The following operational issues were resolved in this release:
Administration
•309759—Reloading configurations while the device is experiencing heavy traffic might
cause the device to fail.
•388700—It is currently possible to configure a VIP from a subnet other than the
unnumbered tunnel interface IP. However, this is not a supported configuration; admins
should not be allowed to configure a VIP from a subnet other than the unnumbered
tunnel interface IP.
•414839—The policy logs in syslog did not show the correct data sent or received for
FTP.
•416873—After a reboot, some event log entries were not recorded in the syslog file,
when the syslog was configured using UDP.
•429883—The MSS-based sockets were changed on the new accepted socket.
•432014—The authorized user with read and write privileges is able to issue the set
admin password command because of which some user privileges are lost.
Application Layer Gateway (ALG)
•446420—The Microsoft windows management interface (WMI) control service fails
in some scenario.
Antivirus (AV)
•299960—Using the new Kaspersky Labs antivirus scan engine, the antivirus database
takes a relatively long time (1 to 5 minutes) to load from a flash disk to system memory.
While the database is loading, CPU usage might go extremely high and device
performance might drop.
77Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•388885—The extended antivirus (AV) pattern file was too large for the flash memory
devices that support this function. However, the standard antivirus pattern file worked
as expected. ISG 1000/2000 and NetScreen 5000-series devices do not support the
extended AV pattern file setting.
Authentication
•429374—Re-authentication for dot1x was not handled correctly.
Command Line Interface (CLI)
•435979—[SSG 500] The output of the get chassis command does not include PIM
name.
•392417—The set tag <number> command under vsys was not configured correctly.
Deep Inspection (DI)
•410393—When updating offline from the Local Server, the automatic DI signature
update fails.
•426280—The attack db rollback command did not work on some platforms. For the
other platforms, the result of the command was logged as either successful or failed
in event log.
Domain Name System (DNS)
•439044—If syslog server is referenced using DNS hostname, syslog messages are still
sent to the original IP address even after the IP address of the hostname is changed.
Flow
•235781—Using transparent mode, under high traffic conditions, sometimes a small
number of sessions cannot be cleared. The sessions appear to be "time 0" but continue
to remain in the session table. Running set sat session-clean clears these sessions from
the table after one round of session cleaning.
•239631—If you configure the initial session timeout below the valid range (20–300
seconds), the system interprets these values as minutes instead of seconds.
General Packet Radio Service (GPRS)
•422979—When GTP inspection was enabled, ICMP Destination Unreachable packets
of the GTP session were dropped.
•426075—When GTP inspection was enabled, occasionally a DeletePdpResponse or
EchoResponse dropped and the message non-existent gsn appeared in the log.
Copyright © 2015, Juniper Networks, Inc.78
ScreenOS 6.3.0 Release Notes
High Availability and NetScreen Redundancy Protocol (HA and NSRP)
•235303—Delay in the peripheral devices updating the forwarding table when a failover
occurs in an NSRP cluster in transparent mode. When the devices have no gratuitous
ARP mechanism as in NAT or Route mode, peripheral devices update the forwarding
table only when the active physical interface is restarted. The update happens after
five seconds by default.
•236275—In transparent mode, if the VSD group is not bound to a VLAN group, the
security device incorrectly reports the VSD as being in Active-Passive mode.
•236634—In an Active-Passive configuration, if the active security device handles a
large number of FTP connections, the CPU utilization of the backup device remains
high even when the rate of the FTP connections per second on the backup is low.
•253467—If a device's SIP traffic is very heavy in an NSRP deployment, although the
master box works well, there are delays when resources on the backup box are removed.
Operational impact on the cluster is minimal, and the backup box recovers
automatically.
•303714—For NSRP cluster deployments, when upgrading from ScreenOS 5.4 (or any
earlier release), the following ALGs do not sync correctly until both devices in the pair
are upgraded: SIP, SCCP, MGCP, RTSP, SQL, PPTP, P2P, AppleiChat, and H.323.
•422747—In the Active/Active mode, FIN packet in the NSRP data path is not processed
correctly when SYN-CHECK is enabled.
•424242—When performing an NSRP failover, the route pointed to a different tunnel
interface. However, the synchronized session continued to point to the old SA tunnel.
•437661—The RIP and OSPF MD5 authentication results in the NSRP configuration are
not in synchronization.
•438794—Backup NSRP firewall lost synchronized OSPF routes.
Intrusion Detection and Prevention (IDP)
•305128—If only a destination port (dst-port) is specified in IDP flow filter, the filter
does not capture traffic in both directions.
•305295—If an IDP rule is configured with the attack value NONE, then diffserv does
not work. Also, when the IDP rule attack value is NONE, if a TCP packet that matches
the drop packet action passes through the device, IDP is unable to escalate the response
and drop the connection.
•410393—When updating offline from the Local Server, the automatic DI signature
update fails.
•426280—The attack db rollback command did not work on some platforms. For the
other platforms, the result of the command was logged as either successful or failed
in event log.
79Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Internet Protocol Version 6 (IPv6)
•227934—SSG platforms incorrectly process the ICMPv6 error packet that they receive
in response to a non-first fragment packet that exceeds the outgoing interface MTU.
•236085—In transparent mode, you cannot manage a zone that is on a vsys using the
zone nsrp manage CLI command, because it is a global setting based on vlan1 interface.
In root mode, you can manage only the related vsys.
•236087—On SSG 320/350 devices, a 4-byte PVE tag is used to identify which interface
the packet came from, limiting the maximum supported packet length to 1514 bytes.
•236549—When deployed in transparent mode, some high-end platforms such as ISG
1000-IDP do not support more than 20 reassembled segments. If you try to ping another
device with data that requires more than 20 reassembled segments (for example,
30,000 bytes), the ping request fails.
•239285—ScreenOS does not verify the IP address that you enter when you configure
the security device.
•239598—On some high-end platforms, after you have enabled IPv6, the CLI incorrectly
allows you to enable parameters such as DSCP marking, IDP, and NSRP Data
Forwarding that are not supported in IPv6 mode.
•267239—When modifying an IPv6 or a wildcard policy through the WebUI, all existing
sessions for the policy are removed. However, existing sessions are not removed if you
only modify some minor features—such as session-limit or alarm-without-drop—of
an ordinary IPv4 policy through the WebUI.
Management
•218168—The incorrect range in integrated URL filtering SC-CPA cache is causing NSM
validation error.
•272925—When the console timeout is set to 0, telnet client applications have no way
to determine when a session has timed out. If the telnet client has not sent data for a
significant length of time and the session should timeout, the TCP socket for the telnet
session might not be correctly released.
•292490—NSM update fails when configuring IKEv2 soft lifetime buffer.
•438684—The set flow mac-cache-mgt command is not working for the management
of the backup firewall using the master firewall.
Copyright © 2015, Juniper Networks, Inc.80
ScreenOS 6.3.0 Release Notes
Network Address Translation (NAT)
•403509—DIP leaks when a loopback interface for cross-Vsys is used simultaneously
with a loopback group in the destination vsys for outgoing DIP NAT.
Other
•255774—The debug command unset console dbuf might make the box unstable,
especially under heavy traffic. Administrators are advised to use care when running
this command.
•258931—Due to a memory limitation, NS 5000 devices are currently unable to support
500 vsys when an advanced license key—such as for virtual router or Layer 2
Active-Active support—is part of the deployment.
•263480—When a small second packet follows a jumbo frame (more than 8500 bytes)
on 10G card within a minute, then it might be dropped.
•263512—ScreenOS 6.1.0 includes a new SSHv2 secondary login banner feature.
However, unless the feature is enabled, if the secondary banner is displayed before a
login prompt on a console or via a Telnet connection, no positive acknowledgment to
the secondary banner is required (applicable to console, Telnet, SSHv1, and SSHv2
connections).
•263585—In certain situations, Network Address Translation (NAT) traffic using H.323
ALG resets the device.
•266022—Because the NS 5400 supports 2 million sessions by default in 6.1 (and
6.0.0r2 and later), you must ensure that the device has a minimum of 450MB of free
memory when upgrading from 5.4 or 6.0.0r1 to 6.1.0 or 6.0.0r2. One million sessions
require approximately 340MB of memory.
•274425—The drop of to-self IKE packets is not logged when no IKE is configured.
•312046—On some devices, an attempt to negotiate the maximum transmission unit
(MTU) using the ICMP "packet too big" packet might fail. Failure to negotiate the MTU
might, for example, cause an FTP session failure. The failure is caused in part because
the ICMP packet is sent only once.
•387143—The alarm LED is cleared automatically without issuing the clear led alarm
command.
•391304—The duration of time reported by policy traffic logs is shorter than the actual
time duration.
•393301—During Web authentication, when an ACK packet was received, the firewall
erroneously sent a FIN packet to end the session.
•413775—[ISG] The set sat sess-close [0|1] command did not function as expected.
•416573—When the debug command was run, the redundant debug information was
removed.
•419564—The ppp multi link bundle supports only two BRI channels.
81Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
•427094—Occasionally, the connection between the Catalyst switch and the Copper
Gigabit interface with manual duplex setting is down.
•427467—[SSG 140] The device reboots unexpectedly because of ARP traffic across
bgroup interfaces.
•428914—[ISG, NetScreen-5000] When Websense was enabled, access to certain
websites dropped due to application error.
•429239—When the remote authentication server was primary, the authentication
failback option did not function as expected.
•431675—The defragmentation limit is changed to support up to 65535 bytes of IP
packet.
•431762—During an upgrade to Release 6.1.0r5, MGCP-related messages might appear
on the console.
•431944—In transparent mode, MPLS pass-through traffic is dropped.
•433456—The original source and destination address are missing from the log to USB
flash.
•435348—[SSG 5/20, SSG 140, SSG 500] The firewall could reset due to an exception
before the boot up process. The device shows the exception dump.
•439759—When an access list that is tied to an RP configuration for multicast is not
set, the firewall might reboot.
•440546—The antivirus scanning process might get stuck the SMTP sessions, if the
client is using SMTP DSN (Delivery Status Notification) and the recipient's e-mail
address contains word QUIT.
•441723—Firewall does not send TCP RST for traffic matched by IPv6 REJECT policies.
Performance
•297405—Inter-Vsys traffic are dropped if it do not pass through an ALG or ICMP.
Routing
•258978—For the SSG 320M/350M, the supported maximum number of Border Gateway
Protocol (BGP) redistributed routes is 4096. However, if a large number of routes are
added with an automated script, it is possible to exceed the supported limit. Routes
entered or redistributed manually should not be able to exceed 4096.
•398277—OSPF adjacencies were lost due to an FPGA error.
•416966—When a route was displayed by get route command some of the flags were
not freed, and the firewall rebooted. The route was frequently added and deleted by
changing dynamic routing.
•430932—Secondary VPN Tunnel configured with point to multi-point OSPF stopped
in ExStart.
•440113—IPv6 Neighbor solicitation messages from the source “::” are dropped by IP
Spoofing.
Copyright © 2015, Juniper Networks, Inc.82
ScreenOS 6.3.0 Release Notes
Voice-over-Internet Protocol (VoIP)
•310928, 314481—In NAT mode, the security device might stop responding under heavy
Media Gateway Control Protocol (MGCP) traffic.
•421768—When the H.323 ALG was enabled, the H.323 RAS admissionConfirm packets
were dropped.
Virtual Private Network (VPN)
•395216—The fragmented packets of cross-chip ASIC VPN traffic were dropped.
•395312—When Baltimore Unitrust CA was used, the PKI negotiation using the SCEP
failed.
•430028—The device reboots when auto renewal of the same SCEP key was performed.
•433028—The device reboots on its own when SCEP auto-renewal of the same key is
performed.
WebUI
•393022—ECDSA signature authentication is missing from the authentication methods
list in the IKE phase 1-proposal editing WebUI page.
83Copyright © 2015, Juniper Networks, Inc.
Addressed Issues
Known Issues
The following are known deficiencies in features at the time of this release. Whenever
possible, a workaround is suggested following the problem description, preceded by
W/A.
Known Issues in ScreenOS 6.3.0r19
Others
•956460 - Fragmented ESP traffic intermittently fails to defragment.
Security
•1012329 - ISG-IDP inline tap mode drops traffic.
WebUI
•955167 - Unable to create a global policy when the destination was set as MIP.
•964680 - The Proxy ID fails to get updated when the corresponding address object
is changed via the WebUI.
W/A - Manually clear IPsec Proxy ID references before editing address objects.
Known Issues from ScreenOS 6.3.0r18
None
Known Issues from ScreenOS 6.3.0r17
None
Known Issues from ScreenOS 6.3.0r16
None
Known Issues from ScreenOS 6.3.0r15
None
Known Issues from ScreenOS 6.3.0r14
None
Known Issues from ScreenOS 6.3.0r13
None
Copyright © 2015, Juniper Networks, Inc.84
ScreenOS 6.3.0 Release Notes
Known Issues from ScreenOS 6.3.0r12
Other
•782888—OSPF routes synced on backup firewall are inactive after you perform unset
or set protocol ospf enable command.
Known Issues from ScreenOS 6.3.0r11
ALG
•740513—When SIP ALG fragments the packet, the first fragment is of small-sized
which may not include the mandatory SIP headers.
Management
•726174—Firewall might add additional padding to a reply packet.
•737747—While using standard MIB2, indexes or mapping between Indexes of the OID
'ipAdEntIfIndex' and the OID 'ifDescr.x' are incorrect and as a result SNMP poll sends
an incorrect result.
Other
•725966—Firewall experiences core dump after HA fail over due to IKE-v2 parameter
sync problem between the primary and the backup devices.
•726468—The PKI process might send an incorrectly formatted message to the SSH
process, resulting in a core dump.
•727126—Firewall spontaneously reboots when FTP server tries to initiate data
connection before client sends RETR command.
•728097—On interface configuration, firewall is accepting network number (1.1.1.0/24)
as an IP address.
•731582—Debug flow drop, shows the packet information for the dropped packets.
•733528—In IGMP proxy, when an admin clears multicast-route (mroute) by executing
the CLI clear vr vr-name mroute command, it cannot rebuild the mroute even after the
new igmp v3 report packet is arrived.
•739175—Illegal memory access causes spontaneous reboot of the firewall.
•743309—Multicast traffic can cause firewall to coredump.
•744684—Sometimes, after OS upgrade, the firewall starts rebooting continuously in
loop condition, due to a memory overwrite issue. This is because of smaller buffer size
of fat table in flash.
85Copyright © 2015, Juniper Networks, Inc.
Known Issues
Routing
•734361—BGP neighbor parameter rejection command is deleted after BGP instance
flap or upon reconnect.
VPN
•740149—VPN tunnel might fail to come up with AES192/256 in IKEV2, when one VPN
peer is using 6.3r10 release and the other VPN peer is using 6.3r9 release or a below
release.
Known Issues from ScreenOS 6.3.0r10
IDP
•695082—IDP Module on the ISG platform hangs when executing the command "get
sm status" .
NSRP
•703949—The expired tunnel sessions were not removed properly in a backup device.
Other
•582089—Pass through IPv6 IPSEC sessions are interrupted due to incorrect session
timeouts set on ALG created child sessions.
•611751—MIP for GRE over IPsec does not work, if the MIP is not in the same IP subnet
as the tunnel interface.
•675550—When upgrading through tftp,the device might reboot with coredump.
•690786—Unable to change the maximum number of sessions with envar command
on ISG2000 box with advanced license and less than 2GB memory.
•694306—FW might experience high task CPU momentarity at polling times due to
snmp task on 6.3. code.
•701519—Pass through VPN traffic breaks source session limit set on zone screening.
•701968—Session are not updated with the new VPN with better route and packet
dropped.
•703949—The expired tunnel sessions were not removed properly in a backup device.
Copyright © 2015, Juniper Networks, Inc.86
ScreenOS 6.3.0 Release Notes
VPN
•592488—Connection to VPN fails when the external IP changes on the NAT device
that resides in-between VPN end points.
Known Issues from ScreenOS 6.3.0r9
DHCP
•658763—The maximum number of DHCP relay agents supported is increased from 3
to 4.
Management
•578449—Firewall was unable to connect to NSM using the first connect.
Other
•601364—Interface physical link is brought up after reboot even after it is down.
•610108—IPv6 Auto-Discovered route is inactive when IPv6 over PPPoE was connected.
•662930—Traffic through the IPSEC tunnel destined to one of the interfaces sometimes
fails, because of reply packets getting sourced from tunnel interface IP.
•664485—Policy might not compile exactly, when "negate" is used.
•666370—Incorrect destination port is displayed 20480(0x5000) in the event log for
the web management connection when the system configuration is saved through
web-UI.
•673295—The command "set chassis audible-alarm all" was modified on the SSG
platform to remove the "battery" option as the SSG platform does not support this
option.
87Copyright © 2015, Juniper Networks, Inc.
Known Issues
Performance
•607132—Traffic might be affected by flow control.
VPN
•591501—After reboot, the configuration pertaining to IKEv2 for EAP authentication
was not preserved if the definition of the IKEv2 gateway name contained spaces.
WebUI
•665076—The maximum number of DHCP relay agents supported for WebUI/NSM is
increased from 3 to 4.
Known Issues from ScreenOS 6.3.0r8
ALG
•537064— Corrected the tunnel policy search logic, after opening a pinhole in the firewall
because sometimes the tunnel policy search might fail.
Management
•610023— [SSG300/500]Byte count for log-self shows wrong value.
Other
•558343— Memory utilization of "sys pool" increases as some of the memory allocated
in SMTP parser are not freed when the SMTP sessions are released.
•587433— Sometimes after OS upgrade, the firewall might not start up because of a
certain condition in flash writing mechanism.
•596585— If IPv6 is not enabled on incoming interface, the multicast link local packet
such as NA will not be considered as a to-self packet, and the device will forward these
packets.
•599609— The "in packet" and "in ucast" counter keeps increasing, though the physical
interface is down.
UTM
•574264— Sometimes legitimate source IP address might be detected as an antispam
blacklist IP address during high number of SMTP traffic.
•604069— When Antispam or Antivirus is enabled, under certain conditions during TCP
establishment, the TCP traffic might not flow properly.
Copyright © 2015, Juniper Networks, Inc.88
ScreenOS 6.3.0 Release Notes
VoIP
•585139— Sometimes device might reboot unexpectedly when certain TCP-based SIP
traffic passes through the firewall.
VPN
•587809— Negotiation event log is not generated when IKE phase one is initiated.
WebUI
•562438— In WebUI, the "dialup user group" for IKEv2 is disabled and cannot be
configured.
•596093— Java Script WebUI display error is corrected in Internet Explorer 9.
Known Issues from ScreenOS 6.3.0r7
Admin
•580933—High task CPU triggers flow CPU utilization alarm.
Antivirus
•529357—Firewall drops management traffic while the antivirus database was getting
updated.
Authentication
•587578—802.1x authentication is not supported on a bgroup interface.
CLI
•574045—A new command is introduced to permit IGMP packets with TTL greater than
one and provide compatibility with other interoperability devices.
DNS
•580838—If Jumbo frame support is enabled, fragmented DNS packets fail to pass
through device.
IDP
•530282—sme_image and NSM fails to update ISG-IDP and causes high task CPU.
•546621—IDP AVT timeout parameters causes high task CPU. This problem is seen
more in NSRP cluster.
89Copyright © 2015, Juniper Networks, Inc.
Known Issues
Management
•428710—Deleting the interface which is being bound to NSM module as source interface
might cause trace errors or crash dump causing the device to reboot.
Other
•487640—Hardware counters are not working on NS-5000-2XGE-G4 [2 x 10GigE
Secure Port Module (SPM)].
•539351—MS-RPC sessions fail due to a cold start sync failure caused by RPC process.
•554007—Sometimes, the device might fail due to a particular type of packet.
•563494—Syslog messages contain 'T' character between date and time causing
parsing errors.
•568377—ASIC might go into hung state with IPSEC-DSCP marking enabled.
•570868—Firewall reboots due to unexceptional read error in a wrong packet buffer.
•572707—Firewall fails due to a malfunction while running SPF in the OSPF task.
•576128—Cannot get security module information with error "sm_get_cmd transmit
timeout" because of memory leak on SM.
•585314—SCP to the firewall fails from an UNIX machine with error "unknown file --
ns_sys_config."
•590147—Members of aggregate interface become physically up after reboot even
though they are set for physically down.
Routing
•554973—PBR is unable to route traffic using tunnel interface when it is in an up state.
•561446—OSPF neighbor flaps due to a problem with the OSPF update task on a system
level device.
VPN
•479677—Each VSYS can only use up to 16K tunnels.
•550440—With IKEv2, NetScreen firewall responds to create_child_sa message from
peer with success but shows VPN status as inactive.
•579094—IKEv2 with AES encryption in proposal fails due to incorrect attributes.
•581469—While running IKEv2, clients located behind some NAT devices might get
disconnected.
Copyright © 2015, Juniper Networks, Inc.90
ScreenOS 6.3.0 Release Notes
WebUI
•585834—While domain name resolves many different IP addresses, Policy Elements
Addresses character might show as garbled.
Known Issues from ScreenOS 6.3.0r6
The known issues listed in this section are specific to ScreenOS 6.3.0r6. For the known
issues identified for previous ScreenOS releases, see the Release Notes for the specific
release.
None.
Known Issues from ScreenOS 6.3.0r5
The known issues listed in this section are specific to ScreenOS 6.3.0r5. For the known
issues identified for previous ScreenOS releases, see the Release Notes for the specific
release.
None.
Known Issues from ScreenOS 6.3.0r4
The known issues listed in this section are specific to ScreenOS 6.3.0r4. For the known
issues identified for previous ScreenOS releases, see the Release Notes for the specific
release.
Other
•442729—Traffic might stop on an interface when the system chip fails.
•518253—[SSG Series] Mapped IP (MIP) of the firewall does not respond to ARP query
with source IP of 0.0.0.0.
VPN
•506464—Under certain conditions, the device might reboot unexpectedly related to
RSA authentication.
Known Issues from ScreenOS 6.3.0r3
The known issues listed in this section are specific to ScreenOS 6.3.0r3. For the known
issues identified for previous ScreenOS releases, see the Release Notes for the specific
release.
None.
Known Issues from ScreenOS 6.3.0r2
The known issues listed in this section are specific to ScreenOS 6.3.0r2. For the known
issues identified for previous ScreenOS releases, see the Release Notes for the specific
release.
91Copyright © 2015, Juniper Networks, Inc.
Known Issues
Antivirus (AV)
•478469—In transparent mode, VLAN tag is removed from the HTTP traffic after AV
scanning.
DHCP
•484087—The destination IP is incorrectly set to 0.0.0.0 when DHCP relay agent receives
a DHCP ACK in response to a DHCP INFORM.
General Packet Radio Service (GPRS)
•448582—GTP inspection drops the SGSN Context Response message if the Next
Extension Header type is 0xC2 (Suspend Response).
•456358—The Common Flags GTP Information Element is not removed when set
remove-r6 command is configured.
•457093—For a new GTP tunnel, if a CreatePdpRequest does not receive any response,
then the already used TEIDs cannot be reused for a certain time period. This can result
in the dropping of CreatePdpRequests from an SGSN that reuses these TEIDs before
a certain time period.
•472199—When R6 IE removal is enabled, GTP CreatePdpRequest packets get corrupted
if they contain both the MS-Timezone information element and a private extension.
•485578—The GTP remove-r6 feature removes the mandatory RAI IE from SGSN
Context Request and Identification Request messages.
•486613—When GTP traffic drops, the bad system status message appears in the log.
Intrusion Detection and Prevention (IDP)
•485928—[ISG-IDP] The IDP engine resets due to application identification.
Management
•466692—Certain IPv6 Index value is reported as incorrect.
Network Address Translation (NAT)
•480667—The firewall allocates only 2000 MIPs to an interface even when all the user
ids configure MIP in one shared interface.
Other
•468514—Traffic log is not generated for a source or destination port equal to 1503.
•471298—UDP MSRPC EnDPort mapper (MS-RPC-EPM) traffic incorrectly displays its
traffic log as MSRPC ENDPOINT MAPPER (TCP).
•472433—Packet might be corrupted due to ASIC buffer problem.
•472690—At times, ICMP flood might generate false alarm.
Copyright © 2015, Juniper Networks, Inc.92
ScreenOS 6.3.0 Release Notes
•481096—Enabling set log audit-loss-mitigation feature causes device to halt traffic
after log buffer is filled.
•481805—After reboot, bandwidth settings configured on gigabit subinterfaces are not
loaded.
•484133—With unknown protocol protection disabled, traffic with protocol number
greater than 137 is erroneously dropped.
•484839—Firewall might fail if get alg pptp xlate command is executed.
Performance
•478205—When large amount of WebAuth transaction happens at a time, some HTTP
SYN packets might be dropped during TCP 3-way handshake without returning SYN
and ACK packets.
Routing
•480470—BGP anti-flap processing is removed from the backup NSRP node.
Virtual Private Network (VPN)
•472606—False replay protection alarm occurs when the sequence number is updated
incorrectly due to race condition between the rekey process and the update from ASIC.
•472618—NS-Remote IPsec phase one negotiation might fail if IKE ID is changed.
•475831—Quotation marks (" ") are removed from the configuration when using the
set vpn vpn_name bind zone "zone_name" command.
•480642—User cannot pair a VPN policy when multiple MIPs are used as destination.
•480691—The VPN tunnel down message (for example, VPN <vpn-name> from
<IP-address> is down) is not generated in the event log when the NSRP backup device
becomes the master.
•489859—After the firewall is reset, the tunnel interface is down, even though the
security association (SA) is up.
Known Issues from ScreenOS 6.3.0
The following are known deficiencies in features at the time of this release. Whenever
possible, a workaround is suggested following the problem description, preceded by
W/A.
The known issues listed in this section are specific to ScreenOS 6.3.0r1. For the known
issues identified for previous ScreenOS releases, see the Release Notes for the specific
release.
93Copyright © 2015, Juniper Networks, Inc.
Known Issues
Flow
•456996—The syn-cookie does not function for IPv6 SYN packet with fragment header.
This packet type is generated when IPV4 translates to IPV6 and the DF bit is not set
in original V4 packet.
This does not impact the IPv4 only deployment in any way. The syn-cookie feature can
be used in IPv4 deployment. For IPv6 deployment, syn-proxy option can be used.
General Packet Radio Service (GPRS)
•440783—[ISG] The CPU does the GTP packet check only for the first GTP-DROP
UserGtPdu and drops it correctly.
Hardware
•440062—On executing the set interface X/X phy link-down command on the
JXU-1SFP-S card, the interface link status is erroneous. This is because the TX of fiber
transceiver cannot be disabled on the JXU-1SFP-S card.
Intrusion Detection and Prevention (IDP)
•313252—On the ISG series device, when the Security Module is functioning in the TAP
mode, then ScreenOS only transfers the first fragment of packets to Security Module.
•436544—The Security Module of the ISG series cannot detect certain DNS compound
attack. This is because of the detector functionality.
Other
•416822— If you execute the CLI command save many times, there is no FBTL available
to extend the flash life. Because this conflict with the FAT cluster allocation process,
it leads to logic flash block leakage. This will be fixed in the subsequent ScreenOS
release.
•453156— ScreenOS crashes when the USB device mount fails. This occurs due to
continued and repetitive execution of the get file command.
•454916— On a Jupiter chip, when clearing the ARP table several times with heavy VPN
encryption traffic poured out, all of the VPN encrypted packets are sent to CPU for l2
entry reinstall. This causes a buffer leak.
W/A—Reinitialize the ASIC. This can take up to three minutes.
Copyright © 2015, Juniper Networks, Inc.94
ScreenOS 6.3.0 Release Notes
Routing
•430289—On certain Virtual Routers, after configuring the interface rp candidate
(interface xx mgroup-list yy;) if you configure the Virtual Router access-list (yy) in a
range such as 231.6.0.1/32 to 231.6.0.100/32; then some groups cannot create (s,g) on
untrust vrouter and some other groups cannot forward.
Voice-over-Internet Protocol (VoIP)
Security
•431084—Support for UDP and ICMP flood is not available on the aggregate interface.
Virtual Private Network (VPN)
•423941—When configuring overlapped proxy ids for route-based VPN, the IKEv2
negotiation might fail. The issue can be resolved if traffic selector narrowing is supported
by IKEv2.
W/A—The issue can be resolved if traffic selector narrowing is supported by IKEv2.
Errata
This section lists outstanding issues with the documentation.
95Copyright © 2015, Juniper Networks, Inc.
Errata
Concepts & Examples ScreenOS Reference Guide
•Configuring a DHCP Server section in the ScreenOS 6.1.0, Concepts & Examples ScreenOS
Reference Guide: Vol 2, Fundamentals has the following incorrect information.
WebUI
> Addresses > New: Enter the following, then click OK:
Reserved: (select)
IP Address: 172.16.10.11
Ethernet Address: 1234 abcd 5678
CLI
DHCP Server
set interface ethernet0/1 dhcp server option domainname dynamic.com
set interface ethernet0/1 dhcp server option lease 0
set interface ethernet0/1 dhcp server option dns1 172.16.10.240
set interface ethernet0/1 dhcp server option dns2 172.16.10.241
set interface ethernet0/1 dhcp server option smtp 172.16.10.25
set interface ethernet0/1 dhcp server option pop3 172.16.10.110
set interface ethernet0/1 dhcp server ip 172.16.10.10 to 172.16.10.19
set interface ethernet0/1 dhcp server ip 172.16.10.120 to 172.16.10.129
set interface ethernet0/1 dhcp server ip 172.16.10.210 to 172.16.10.219
set interface ethernet0/1 dhcp server ip 172.16.10.11 mac 1234abcd5678
set interface ethernet0/1 dhcp server ip 172.16.10.112 mac abcd1234efgh
set interface ethernet0/1 dhcp server service
save
To successfully configure the example, make the following corrections to the above
WebUI and CLI:
Do not perform the following in the WebUI:
> Addresses > New: Enter the following, then click OK:
Reserved: (select)
IP Address: 172.16.10.11
Ethernet Address: 1234 abcd 5678
Remove the command set interface ethernet0/1 dhcp server ip 172.16.10.11 mac
1234abcd5678 from the CLI.
•ScreenOS releases prior to 6.2.0 support VLAN retagging option only on
NetScreen-5200 and NetScreen-5400 devices. VLAN retagging is not supported on
Copyright © 2015, Juniper Networks, Inc.96
ScreenOS 6.3.0 Release Notes
ISG and SSG series. This limitation is not included in the release 6.0.0 Concepts and
Examples ScreenOS Reference Guide.
•The following note is incorrect in the NetScreen Redundancy Protocol chapter of the
ScreenOS 6.2.0 and 6.3.0 Concepts & Examples ScreenOS Reference Guide:
NOTE: ScreenOS does not support NSRP IPv6 related RTO synchronization.
This example explains only about the configuration synchronization.
Synchronization of IPv6 RTO is supported from ScreenOS 6.2.0 onwards.
•The following information is missing in the Dialup Virtual Private Networks chapter in
the Concepts & Examples ScreenOS Reference Guide:
When creating a VPN policy with address group and service group, the proxy ID is
0.0.0.0/0.0.0.0/0/0. While creating a second VPN policy with different address group
and service group using the same VPN tunnel, the following error message appears:
The new policy id <#> has identical IKE id as that of policy id <#>.. vpn invalid or not exist.
To resolve this error, create a new VPN tunnel using a different IKE gateway with
different dialup user and IKE ID. The new VPN tunnel creates a new VPN ID. Create the
second policy with a different address group and a service group using the new VPN
tunnel. Therefore, the proxy ID check refers to the new tunnel.
•In the Configuring an Active/Active NSRP Cluster section in the Concepts & Examples
ScreenOS Reference Guide, the figure displays the following incorrect title and labeling:
1. The title of the figure reads Active/Passive NSRP Configuration.
2. The label to the left of the figure reads the following:
a. On device A the Manage IP is 10.1.1.21 and is on the redundant2 Interface.
b. On device B the Manage IP is 10.1.1.22 and is on the redundant2 interface.
The correct information is as follows:
1. The title of the figure should read Active/Active NSRP configuration.
2. The label to the left of the figure should read the following information:
a. On device A, the manage IP is 10.1.1.1 and is on the redundant2 Interface.
b. On device B, the manage IP is 10.1.1.2 and is on the redundant2 Interface.
•The following information is missing in the Reconnaissance Deterrence and Advanced
Virtual Private Network Features chapters in the Concepts & Examples ScreenOS
Reference Guide:
•The set flow tcp-syn-bit-check command checks the SYN bit but does not refresh
the session. The set flow tcp-syn-bit-check command enables the PPU to perform
the SYN check and sends the packet to the CPU for session creation.
•The set flow tcp-syn-check command does a SYN check and refreshes session after
a three-way-handshake refresh.
97Copyright © 2015, Juniper Networks, Inc.
Errata
•The set flow tcp-syn-check-in-tunnel command enables SYN Check for tunnel traffic.
The set flow tcp-syn-check-in-tunnel command causes the PPU to check the SYN
bit. If you disable this command, all SYN packets, tunnel and non-tunnel will be sent
to the CPU for processing.
•The threshold is set only for the average CPU. As the management traffic uses the
average CPU for threshold, there is no recommended value to prioritize.
•The following Addressed Issue is not documented in the ScreenOS 6.0.0r5 release
notes:
258534—VRRP transitions within ScreenOS were not reported in the event logs.
•The following global scan-mgr command is not supported for the ScreenOS 6.x release:
set av scan-mgr queue-size
•The following information is not available in the H.323 Application Layer Gateway
chapter of the Concepts & Examples ScreenOS Reference Guide: A single policy with
policy-based NAT (DIP ID 2) fails due to the twin-pair port limitations on the DIP pool.
The policy segments the traffic so that they do not have more than 512 phones (the
DIP limitation) on each DIP pool.
•The following information is not available in the Digital Subscriber Line chapter of the
Concepts & Examples ScreenOS Reference Guide. The adsl1/0 interface acts as a PPPoE
client. Ethernet 0/2 and ethernet 0/1 act as the DHCP server. On successful PPPoE of
adsl1/0, the DHCP parameters that also contain the DNS information are applied to
the DHCP server. Although the DNS option is automatically updated by PPPoE server,
the user must select the Automatic Update of DHCP Server’s DNS Parameters option.
•The following information in the VLAN-Based Traffic Classification chapter of the 6.2.0
and 6.3.0 Concepts & Examples ScreenOS Reference Guide: example currently contains
the following incorrect information:
VLAN Group Name: v10
Start: 10
End: 10
Network > VLAN > Group > Edit (for group v10)
Interface Name: (select) ethernet2/1
set vlan group name v10
set vlan group v10 10 10
set vlan port eth2/1 group v10 zone v1-trust
set vlan port eth2/2 group v10 zone v1-untrust
set policy from v1-trust to v1-untrust any any any permit
set vlan retag name secure_vlan 10 20
set vlan retag name secure_vlan 10 20 untag
set vlan port eth2/1 retag secure_vlan
Copyright © 2015, Juniper Networks, Inc.98
ScreenOS 6.3.0 Release Notes
To configure the examples, make the following corrections to the CLI commands as
follows:
VLAN Group Name: v20
Start: 20
End: 20
Network > VLAN > Group > Edit (for group v20)
Interface Name: (select) ethernet2/2
set vlan group name v20
set vlan group v20 20 20
set vlan port eth2/1 group v20 zone v1-trust
set vlan port eth2/2 group v20 zone v1-untrust
set policy from v1-trust to v1-untrust any any any permit
set vlan retag name secure_vlan 10 20
set vlan retag name secure_vlan 10 20 untag
set vlan port eth2/2 retag secure_vlan
•In the Transport mode IPsec VPN section of the Site-to-Site Virtual Private Networks
chapter ScreenOS 6.3.0, Concepts & Examples ScreenOS Reference Guide the Figure
234: Transport Mode IPsec VPN incorrectly states the Gateway 2 values as "lo3:
4.4.4.4/32 and lo4: 4.4.4.5/32" which must be corrected to "lo1: 6.6.6.6/32 and lo2:
6.6.6.7" and the following information is missing in Gateway - 1 and Gateway - 2
Configurations. To successfully configure the example, make the following corrections
to the configurations:
Gateway-1 Configuration:
1. IKE Configuration on host-1 and host-2
set ike gateway gateway1 address 1.1.1.1 aggressive outgoing-interface loopback.1
preshare test1 sec-level standard
set ike gateway gateway2 address 1.1.1.10 aggressive outgoing-interface loopback.2
preshare test1 sec-level standard
2. VPN Configuration on host-1 and host-2
set vpn v1 gateway gateway1 transport sec-level standard
set vpn v2 gateway gateway2 transport sec-level standard
3. Proxy configuration for v1 and v2
set vpn "v1" proxy-id local-ip 4.4.4.4/32 remote-ip 6.6.6.6/32 "ANY"
set vpn "v2" proxy-id local-ip 4.4.4.5/32 remote-ip 4.4.4.7/32 "ANY"
4. MIP Configuration
set interface loopback.1 mip 3.3.3.3 host 6.6.6.6
set interface loopback.2 mip 3.3.3.4 host 6.6.6.7
5. IKE Configuration for GW-2
99Copyright © 2015, Juniper Networks, Inc.
Errata
set ike gateway s1 address 6.6.6.6 aggressive outgoing-interface loopback.3 preshare
test1 sec-level standard
set ike gateway s2 address 6.6.6.7 aggressive outgoing-interface loopback.4
preshare test1 sec-level standard
6. VPN Configuration for s1 and s2
set vpn v3 gateway s1 transport sec-level standard
set vpn v4 gateway s2 transport sec-level standard
7. DIP Configuration
set interface eth2 ext ip 4.4.4.4 255.255.255.255 dip 10 4.4.4.4 4.4.4.4
set interface eth2 ext ip 4.4.4.5 255.255.255.255 dip 11 4.4.4.5 4.4.4.5
8. Policy Setup
Outgoing policy
set policy id 3 from trust to untrust "1.1.1.1" "3.3.3.3" any nat src dip-id 10 tunnel vpn
v3
set policy id 4 from trust to untrust "1.1.1.10" "3.3.3.4" any nat src dip-id 11 tunnel vpn
v4
Incoming policy
set policy id 1 from trust to untrust "1.1.1.1" "(MIP)3.3.3.3" any tunnel vpn v1
set policy id 2 from trust to untrust "1.1.1.10" "(MIP)3.3.3.4" any tunnel vpn v2
NOTE: Users need to configure the outgoing policy before configuirng
the incoming policy. This is because we do policy search twice, the first
one is to check the incoming packet, and the second one is to find
another VPN (the outgoing VPN) through which we send the packet.
9. Flow check
set flow ply-chk-self-out-tunnel
Gateway-2 Configuration:
1. IKE and VPN Configuration to Server-PC
set ike gateway gateway1 address 5.0.0.1 aggressive outgoing-interface lo.3 preshare
test sec-level standard
set ike gateway gateway2 address 5.0.0.2 aggressive outgoing-interface lo.4 preshare
test sec-level standard
2. VPN Configuration on server-1 and server-2
set vpn v3 gateway gateway1 transport sec-level standard
set vpn v4 gateway gateway2 transport sec-level standard
3. Proxy configuration for v3 and v4
set vpn "v3" proxy-id local-ip 3.3.3.3/32 remote-ip 1.1.1.1/32 "ANY"
set vpn "v4" proxy-id local-ip 3.3.3.4/32 remote-ip 1.1.1.10/32 "ANY"
4. Reversed MIP (Traffic Is from Untrust to Trust)
Copyright © 2015, Juniper Networks, Inc.100
ScreenOS 6.3.0 Release Notes
set interface lo.3 mip 7.7.7.7 host 4.4.4.4
set interface lo.4 mip 7.7.7.8 host 4.4.4.5
5. IKE and VPN configuration to GW-1 (Client-PC)
set ike gateway h1 address 4.4.4.4 aggressive outgoing-interface lo.1 preshare test
sec-level standard
set ike gateway h2 address 4.4.4.5 aggressive outgoing-interface lo.2 preshare test
sec-level standard
6. VPN Configuration on host-1 and host-2
set vpn v1 gateway h1 transport sec-level standard
set vpn v2 gateway h2 transport sec-level standard
7. MIP
set interface lo.1 mip 6.6.6.6 host 5.0.0.1
set interface lo.2 mip 6.6.6.7 host 5.0.0.2
8. Policy Setup Outgoing policy
Outgoing policy
set policy id 7 from untrust to trust "4.4.4.4" "6.6.6.6" any tunnel vpn v3
set policy id 8 from untrust to trust "4.4.4.5" "6.6.6.7" any tunnel vpn v4
Incoming policy
set policy id 5 from untrust to trust "4.4.4.4" "(MIP)6.6.6.6" any tunnel vpn v1
set policy id 6 from untrust to trust "4.4.4.5" "(MIP)6.6.6.7" any tunnel vpn v2
9. Flow check
set flow ply-chk-self-out-tunnel
•The Supported RADIUS Enhancements for Auth and XAuth Users section in the Concepts
& Examples ScreenOS Reference Guide,Fail-Over page displays the following incorrect
information:
If authentication via a backup server is successful, and the revert interval has elapsed,
the device sends subsequent authentication requests to the backup server.
The correct information is as follows:
If authentication via a backup server is successful, and the revert interval has not
elapsed, the device sends subsequent authentication requests to the backup server
•The following note is incorrect in Authentication Servers chapter of the ScreenOS 6.2.0
and 6.3.0 Concepts & Examples ScreenOS Reference Guide:
NOTE: This feature applies to RADIUS and LDAP servers only.
The correct note is as follows:
NOTE: This feature applies to RADIUS, LDAP, and TACACS servers only.
101Copyright © 2015, Juniper Networks, Inc.
Errata
•The following note is incorrect and has to be deleted in Mapped and Virtual Addresses
chapter of the ScreenOS 6.2.0 and 6.3.0 Concepts & Examples ScreenOS Reference
Guide:
NOTE: You can only set a VIP on an interface in the Untrust zone.
•The following command is incorrect in Authentication Servers chapter of the ScreenOS
6.2.0 and 6.3.0 Concepts & Examples ScreenOS Reference Guide:
set admin auth timeout 0
The correct command is as follows:
set admin auth web timeout 0
•The following information in the Denial of Service Attack Defenses chapter in the
ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide Teardrop Attack
section is correct when the firewall expects 548 (Including IP header) but contains
528 (excluding IP header).
When the sum of the offset and size of one fragmented packet differ from that of the
next fragmented packet, the packets overlap, and the server attempting to reassemble
the packet can crash, especially if it is running an older operating system that has this
vulnerability. After you enable the Teardrop Attack SCREEN option, and when the
device detects this discrepancy in a fragmented packet. The packets are dropped.
•The following information is updated in Denial of Service Attack Defenses Chapter in
the Concepts & Examples ScreenOS Reference Guide:
In the Attack threshold, Alarm Threshold, Source Threshold, and Destination Threshold
sections the statement same destination address and port number must be updated
as same destination address and ingress interface port (physical port or logical port
like sub interface) in all the occurrences.
The following is the list of updated thresholds:
•Attack Threshold—Attack threshold is triggered based on same destination IP plus
same Ingress Interface Port (physical port or logical port like sub interface) per sec
required to activate the SYN proxying mechanism.
NOTE: Threshold is not triggered based on Transport Layer ports (TCP
ports or UDP ports).
For example, if Attack threshold is 20, so if there are 20 PPS to same destination IP
and on same Ingress interface, then the ATTACK threshold will be triggered. However,
if there are 20 PPS to the same destination, but distributed among multiple incoming
interfaces, then ATTACK threshold will not be triggered.
•Alarm Threshold—The value you set for an alarm threshold triggers an alarm when
the number of proxied, half-completed connection requests to the same destination
address and ingress interface port (physical port or logical port like sub interface)
per second exceeds that value. For example, if you set the SYN attack threshold at
Copyright © 2015, Juniper Networks, Inc.102
ScreenOS 6.3.0 Release Notes
2000 SYN segments per second and the alarm at 1000, then a total of 3001 SYN
segments to the same destination address and ingress interface port (physical port
or logical port like sub interface) per second is required to trigger an alarm entry in
the log.
For each SYN segment to the same destination address and ingress interface port
(physical port or logical port like sub interface) in excess of the alarm threshold, the
attack detection module generates a message. At the end of the second, the logging
module compresses all similar messages into a single log entry that indicates how
many SYN segments to the same destination address and ingress interface port
(physical port or logical port like sub interface) arrived after exceeding the alarm
threshold. If the attack persists beyond the first second, the event log enters an alarm
every second until the attack stops.
•Source Threshold—This option allows you to specify the number of SYN segments
received per second from a single source IP address—regardless of the destination
address and ingress interface port (physical port or logical port like sub
interface)—before the security device begins dropping connection requests from
that source.
Tracking a SYN flood by source address uses different detection parameters from
tracking a SYN flood by destination address and ingress interface port (physical port
or logical port like sub interface). When you set a SYN attack threshold and a source
threshold, you put both the basic SYN flood protection mechanism and the
source-based SYN flood tracking mechanism in effect.
•Destination Threshold—This option allows you to specify the number of SYN
segments received per second for a single destination IP address before the security
device begins dropping connection requests to that destination. If a protected host
can be reached through multiple ingress interfaces, you might want to set a threshold
based on destination IP address only—regardless of ingress interface
Tracking a SYN flood by destination address uses different detection parameters
from tracking a SYN flood(Attack Threshold) where destination address plus ingress
interface port (physical port or logical port like sub interface) is used. Consider the
following case where SYN Flood Attack threshold is 20, and Interface 1 as well as
Interface 2 are the ingress interfaces to reach the same server. An attacker sends 19
PPS to Interface 1 and 19 PPS to Interface 2; neither set of packets (where a set is
defined as having the same destination address and same ingress interface) activates
the SYN proxying mechanism. The basic SYN flood attack mechanism (ATTACK
Threshold) tracks destination address and ingress interface (physical or logical like
sub interface), and neither set exceeds the attack threshold of 20 pps. However, if
the destination threshold is 20 pps, the device treats traffic with same destination
address to both the ingress interfaces as members of a single set and rejects the
21st packet—on Ingress Interface 1 or Ingress interface 2 to that destination.
•In Setting a Service Timeout section of Concepts & Examples ScreenOS Reference
Guide, the behavior of timeout value function is as follows:
•For 5.3.0r2 and earlier releases, when a policy is configured with multiple services or
groups and if the matched service has an overlapped service timeout then the option
is to select the last service timeout configured.
103Copyright © 2015, Juniper Networks, Inc.
Errata
•From 5.3.0r3 and later releases, when a policy is configured with multiple services
or groups and if the matched service has an overlapped service timeout then the
option is to select the first matching service in the policy in alphabetical order.
For more information see the JTAC Knowledge base number KB11970 located at
http://kb.juniper.net/KB11970 .
•The following information in Service Timeout Configuration and Lookup section in the
Building Blocks for Policies chapter is incorrect:
Services with multiple rule entries share the same timeout value. If multiple services
share the same protocol and destination port range, all services share the last timeout
value configured.
The correct information is as follows:
Services with multiple rule entries share the same timeout value. When we set multiple
services in a policy, and if these services share the same protocol and destination port
range, then the service entries are arranged in alphabetical order. The first service
timeout value is selected when processing the timeout lookup.
•The following information in Configuring Active/Active NSRP in Transparent Mode
chapter is incorrect:
2. Cluster and VSD Groups for Device B
set interface ethernet2/7 zone ha
set interface ethernet2/7 zone ha
set interface ethernet2/8 zone ha
set nsrp cluster id 7
unset nsrp vsd id 0
set nsrp vsd id 7 priority 100
set nsrp vsd id 7 preempt
set nsrp vsd id 7 priority 50
set nsrp vsd id 7 preempt
set nsrp rto-mirror sync
The correct information is mentioned as follows:
2. Cluster and VSD Groups for Device B
set interface ethernet2/7 zone ha
set interface ethernet2/8 zone ha
set nsrp cluster id 7
unset nsrp vsd id 0
set nsrp vsd id 5 priority 100
set nsrp vsd id 5 preempt
Copyright © 2015, Juniper Networks, Inc.104
ScreenOS 6.3.0 Release Notes
set nsrp vsd id 7 priority 50
set nsrp vsd id 7 preempt
set nsrp rto-mirror sync
•The following information is missing from the Route-cache section of the “Routing”
chapter in the Concepts & Examples ScreenOS Reference Guide for ScreenOS release
6.3.0:
NOTE: We do not recommend that route-cache be enabled in dynamic
routing and route flap scenarios.
•In ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide, Policy-Based
Routing chapter, Configuring an Extended Access List section is updated with WebUI
procedure for the creation of access list 20.
•In ScreenOS 6.2.0 and 6.3.0 Concepts & Examples ScreenOS Reference Guide, Deep
Inspection chapter, Brute Force Attack Objects section, table 11 incorrectly lists the
protocols supported to prevent against brute force attack. The protocols that are
supported against the brute force attack depend on the protocol anomaly attack object
that is included in the DI signature database. The latest DI signature database protocols
supported are FTP, POP, IMAP, and HTTP.
•In ScreenOS 6.0.0, 6.1.0, and 6.3.0 Concepts & Examples ScreenOS Reference Guide:
Part 6, Voice-over-Internet Protocol, in the SIP Headers section, the Requesting Messages
with NAT table contains the following incorrect information:
•For the Outbound Request (from private to public) message type, the action for the
Route field is Replace ALG address with local address.
The correct action for Route is Replace local address with ALG address.
•For the Outbound Request (from private to public) message, the action for the Call-ID
field is Replace ALG address with local address.
The correct action for Call-ID is None.
•For the Outbound Response (from public to private) message type, the action for
the Call-ID field is Replace ALG address with local address.
The correct action for Call-ID is None.
•In ScreenOS 6.0.0, 6.1.0, and 6.3.0 Concepts & Examples ScreenOS Reference Guide:
Part 6, Voice-over-Internet Protocol, in the SIP NAT Scenario section, the value for Call-ID
should not change between the internal and external networks in the SIP NAT Scenario
1and SIP NAT Scenario 2 figures.
•In ScreenOS 6.0.0, 6.1.0, and 6.3.0 Concepts & Examples ScreenOS Reference Guide:
Part 6, Voice-over-Internet Protocol, in the SIP Headers section, the following sample
SIP request message field is not supported, because ScreenOS does not perform NAT
for the Call-ID header in the SIP ALG:
Call-ID: a12abcde@10.150.20.3
105Copyright © 2015, Juniper Networks, Inc.
Errata
•In the ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide: Part 4 Attack
Detection and Defense Mechanisms, in the AV Resource Allotment section, the following
note is incorrectly documented for the WebUI:
NOTE: You must use the CLI to configure this option.
The correct information is:
Security > Antivirus > Global: In the AV Scanner Global Settings, change the Maximum
AV Resources Allowed per AV Client value (70% by default), and then click Apply.
•In the ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide: Part 4 Attack
Detection and Defense Mechanisms, in the Fail-Mode Behavior section, the following
information is incorrectly documented for the WebUI:
Security> Antivirus> Global: Select Fail ModeTraffic Permit to permit unexamined
traffic, or clear it to block unexamined traffic, then click Apply.
The correct information is:
Security > Antivirus > Global: In the AV Scanner Global Settings, select Permit, which
appears next to When Unable to Scan, to permit unexamined traffic, or select Block
All Traffic to block unexamined traffic, and then click Apply.
•In the ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide: Part 5 VPNs,
in the WebUI (Tokyo) section of the Site-to-Site Virtual Private Networks chapter, the
following information is incorrectly documented for the VPN WebUI:
VPNs > AutoKey Advanced > Gateway > New: Enter the following, then click OK:
Gateway Name: To_Paris
Security Level: Custom
RemoteGateway Type:
Static IP Address: (select), IP Address/Hostname: 2.2.2.2
Preshared Key
Preshared Key: h1p8A24nG5
Outgoing Interface: ethernet3
> Advanced: Enter the following advanced settings, then click Return to return to the
basic Gateway configuration page:
Security Level: Custom
Phase 1 Proposal (for Custom Security Level): pre-g2-3des-sha
Mode (Initiator): Main (ID Protection)
The correct information is:
VPNs > AutoKey Advanced > Gateway > New: Enter the following, then click OK:
Gateway Name: To_Paris
Copyright © 2015, Juniper Networks, Inc.106
ScreenOS 6.3.0 Release Notes
RemoteGateway Type:
Static IP Address: (select), IP Address/Hostname: 2.2.2.2
> Advanced: Enter the following advanced settings, then click Return to return to the
basic Gateway configuration page:
Preshared Key
Preshared Key: h1p8A24nG5
Outgoing Interface: ethernet3
Security Level: Custom
Phase 1 Proposal (for Custom Security Level): pre-g2-3des-sha
Mode (Initiator): Main (ID Protection)
•In ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide: Volume 4, Attack
Detection and Defense Mechanisms, in the Attack Object Database Server section, the
reference to URL https://services.netscreen.com/restricted/sigupdates is incorrect.
The correct URL is: https://services.netscreen.com/restricted/signupdates.
•In ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide: Volume 4, Attack
Detection and Defense Mechanisms, in the SYN Flood section, the SYN Flood Protection
Parameters table contains the following incorrect information for Source Threshold:
If the device tracks 25 SYN packets from the same source IP address, beginning with
the 26th packet, it rejects all further SYN packets from that source for the remainder
of that second and the next second as well.
The correct action for Route is:
If the device tracks 25 SYN packets from the same source IP address, beginning with
the 26th packet, it rejects all further SYN packets from that source for the remainder
of that second.
•In the ScreenOS 6.3.0 Concepts & Examples ScreenOS Reference Guide: Part 4, Attack
Detection and Defense Mechanisms, "Reconnaissance Deterrence” chapter, “Port
Scanning” section, Figure 99: Port Scan displays the following incorrect destination
port address information:
Dst addr:port
1.2.2.5:21
1.2.2.160:23
1.2.2.84:53
1.2.2.211:80
1.2.2.10:111
1.2.2.20:113
1.2.2.21:123
1.2.2.240:129
1.2.2.17:137
1.2.2.123:138
1.2.2.6139
107Copyright © 2015, Juniper Networks, Inc.
Errata
The correct destination port address information is as follows:
Dst addr:port
1.2.2.5:21
1.2.2.5:23
1.2.2.5:53
1.2.2.5:80
1.2.2.5:111
1.2.2.5:113
1.2.2.5:123
1.2.2.5:129
1.2.2.5:137
1.2.2.5:138
1.2.2.5:139
ScreenOS CLI Reference Guide: Command Descriptions
•In the ScreenOS 6.3 CLI Reference Guide for IPv4, “pppoa” chapter, “Keywords and
Variables” section, under “ppp,” the following information is incorrect:
•lcp-echo-retries the number of unacknowledged LCP Echo requests before connection
is terminated. The valid range is 1–30. The default is 10.
•lcp-echo-timeout the time that elapses between transmission of two LCP Echo
requests. The valid range is 1–1000 seconds. The default is 180 seconds.
The correct information is:
•lcp-echo-retries – The number of unacknowledged LCP Echo requests before
connection is terminated. The valid range is 1–30 echo requests. The default value
is 8 echo requests. When the PPPoE profile is configured from the WebUI, the default
value is 10 echo requests.
•lcp-echo-timeout – The time that elapses between transmission of two LCP Echo
requests. The valid range is 1–1000 seconds. The default value is 60 seconds. When
the PPPoE profile is configured from the WebUI, the default value is 180 seconds.
•In the ScreenOS 6.3 CLI Reference Guides for IPv4 and IPv6, “snmpv3” chapter,
“Keywords and Variables” section, under “engine-id,” the following information is
incorrect:
The length of the engine-id is 8 to 32 characters.
The correct information is:
The length of the engine-id varies from 8 to 27 characters.
•The set flow log-dropped-packet and unset flow log-dropped-packet commands are
not documented in the 6.3.0 ScreenOS IPv4 CLI Reference Guide: Command Descriptions.
You can access the description of these commands from the 6.3.0 ScreenOS IPv6 CLI
Reference Guide: Command Descriptions.
•In the ping chapter of the 6.2.0 and 6.3.0 ScreenOS IPv4 CLI Reference Guide: Command
Descriptions, the following feature is not supported, because ScreenOS does not
perform ping from MIP:
Copyright © 2015, Juniper Networks, Inc.108
ScreenOS 6.3.0 Release Notes
ping 192.168.11.2 from mip 10.1.1.3
•The following information in the ntp Through RIPng chapter of the 6.2.0 and 6.3.0
ScreenOS IPv6 CLI Reference Guide: Command Descriptions is incorrect and redundant:
av
set policy { … } av name_str
set av name_str
unset policy { pol_num |idpol_num }avname_str
unset av name_str
Sends HTTP or SMTP traffic to which the policy applies to the specified
antivirus (AV) scanner, which examines the data for viruses. If it finds a virus,
the AV scanner quarantines the infected data for further study and returns
the SMTP or HTTP file—without the infected data—to the security device,
which then forwards the file to the intended recipient
av name_str
Example: The following command instructs the security device to forward SMTP traffic
originating from the remote mail server r-mail in the Untrust zone and destined for the
local mail server mail1 in the DMZ zone to an AV scanner named av1:
set policy id 1 from untrust to dmz r-mail1 mail1 smtp permit av av1
ScreenOS 6.2.0 and ScreenOS 6.3.0 IPv6 policies do not support av.
•The following command available in the rm Through zone chapter in the ScreenOS IPv6
CLI Reference Guide: Command Descriptions does not support IPv6:
add-default-route
•In ScreenOS CLI Reference Guide: IPv6 Command Descriptions, ntp Through RIPng
chapter exec policy verify command information is provided though the command is
not supported on IPv6.
ScreenOS Message Log Reference Guide
•The following information is missing in the ScreenOS Message Log Reference Guide:
•TCP Sweep Protection
Alert (00442)
Message TCP sweep! From <src-ip> to zone <zone-name>, proto TCP (int
<interface-name>). Occurred <none>times.
Meaning The security device has detected an excessive number of IP attempts to
establish a connection at the specified interface from the specified source IP address.
Action No recommended action.
•UDP Sweep Protection
Alert (00443)
Message UDP sweep! From <src-ip> to zone <zone-name>, proto UDP (int
<interface-name>). Occurred <none>times.
109Copyright © 2015, Juniper Networks, Inc.
Errata
Meaning The security device has detected an excessive number of IP attempts to
establish a connection at the specified interface from the specified source IP address.
Action No recommended action.
•ICMP Ping ID Zero Protection
Critical (00441)
Message ICMP ping id=0! From <src-ip> to <dst-ip>, proto 1 (zone <zone-name>,
int <interface-name>). Occurred <none>times.
Meaning The security device received either an Echo Request or an Echo Reply packet
with the Identifier set to Zero.
Action Verify the screen option to allow the required packets.
•TCP Packet without Flag Protection
Critical (00413)
Message No TCP flag! From <src-ip>:<src-port>to <dst-ip>:<dst-port>, proto TCP
(zone <zone-name>, int <interface-name>). Occurred <none>times.
Meaning The security device received in the TCP packet with no flags set in TCP
segment header.
Action No recommended action.
ScreenOS Online Help
•In the ScreenOS 6.3.0 online Help, on the Administrator Configuration page, in Step 3
under the To Modify the Username and Password of an Existing Administrator section,
the following note is incomplete:
Note: Passwords must be 1 to 31 characters in length.
The complete note is:
Note: Passwords can contain up to 31 characters and must use only standard ASCII
symbols.
•In the ScreenOS 6.3.0 online Help, on the Default Certificate Validation Settings page,
under Check Method of the To Define Default Settings section, the following information
is incorrect:
OSPF: Select this option to have the security device use only OSPF to check the
certificate status.
The correct information is:
OCSP: Select this option to have the security device use only OCSP to check the
certificate status.
•The following note is incorrect in the SCREEN Options page in the ScreenOS 6.3.0
Online Help:
Copyright © 2015, Juniper Networks, Inc.110
ScreenOS 6.3.0 Release Notes
NOTE: The following options are available for physical interfaces only:
SYN Attack, ICMP Flood, UDP Flood, and Port Scan Attack.
The correct information is:
NOTE: The SYN Attack, ICMP Flood, UDP Flood, and Port Scan Attack
options are defined in the zone level. For high-end platforms, the ICMP or
UDP flood attack option defined at the sub-interface level is applied only
to physical interface and not to the sub-interface level. Only the SYN
flood/Port Scan attack option is applied to the sub-interface level.
•In ScreenOS 6.3.0 Online Help, the reference to URL
https://services.netscreen.com/restricted/sigupdates is incorrect on the Deep Inspection
Signature Pack Update page.
The correct URL is: https://services.netscreen.com/restricted/signupdates.
Hardware Installation and Configuration Guide
•In the installation and configuration guides for devices, “Hardware Overview“ chapter,
“Device Status LEDs“ section, Table 2: Device Status LED Descriptions, the following
information is incorrect:
ALARM - Amber - On steadily - HA status changed or redundant group member not
found.
The correct information is:
ALARM - Amber - On steadily - HA peer device status changed or redundant group
member not found.
•In the installation and configuration guides for SSG 140, SSG 300M Series and SSG
500M Series devices, Table 2: Device Status LED Descriptions, the following information
is incorrect:
ALARM - Amber - On steadily - Low memory (less than 10% remaining) and high CPU
utilization (more than 90% in use).
The correct information is:
ALARM - Red - On steadily - Either the memory or CPU usage reached alarm threshold.
ScreenOS Upgrade Guide
•The following note has to be added in the ScreenOS Upgrade Procedures chapter in
the Figure 1: Firmware Upgrade Path
NOTE: For the SSG 500 device, it is strongly recommend to update the
upgrade path with the boot loader 6.0 before proceeding to the ScreenOS
latest version.
111Copyright © 2015, Juniper Networks, Inc.
Errata
•The following note has to be added in the ScreenOS Upgrade Procedures chapter
Upgrading Security Devices in an NSRP Active/Passive Configuration section in the From
CLI heading after point e.
NOTE: If the command save soft from tftp ip_addr screenos_filename to
flash is executed while the device is still NSRP Master, then an NSRP failover
would be automatically performed when executing this command.
•In the ScreenOS Upgrade Procedures chapter, in Table 1: Upgrade Paths to ScreenOS
6.3.0, the upgrade recommendation (boot-loader filename) for SSG520, SSG550,
SSG520M, and SSG550M is incorrect.
The correct upgrade recommendation (boot-loader filename) for SSG520, SSG550,
SSG520M, and SSG550M is Loadssg500v107.
Limitations and Compatibility
This section describes limitations and compatibility issues with the current release.
Limitations of Features in ScreenOS 6.3.0
This section describes the limitations of some features in the ScreenOS 6.3.0 release.
They apply to all platforms unless otherwise noted.
NOTE: Transceiver Compatibility—Juniper Networks strongly recommends
that only Juniper–provided transceivers be used on interface modules.
Different transceiver types (long-range, short-range, copper and so on) can
be used together on multi-port SFP interface modules as long as they are
Juniper-provided transceivers.
Juniper Networks cannot guarantee that the interface module will operate
correctly if third-party transceivers are used.
Please contact Juniper Networks for the correct transceiver part number for
your device.
•Admin login sessions not cleared automatically—If the admin timeout value is set to
zero using the set console time 0 command, any accidental network disconnection
(For example, a cable is unplugged or the client is not closed normally) leaves the
associated sessions open and leave an active entry in the admin table. The entries are
not cleared until the device is reset. [281310].
•Telnet client not available from a Virtual System (Vsys)—The new telnet client from
the CLI interface enhancement is not available at the Vsys level. [307763]
•Fast Ethernet port trunking on ISG 1000/2000 requires consecutively numbered
ports—Fast Ethernet port trunking on ISG 1000 and ISG 2000 devices has a limitation.
If an aggregate interface has more than two ports defined, the ports must be numbered
consecutively without interruption when they are added to the interface.
Copyright © 2015, Juniper Networks, Inc.112
ScreenOS 6.3.0 Release Notes
For example, ethernet2/2, ethernet2/1, and ethernet2/3 ports can be configured even
in the order given because they are numbered consecutively. If ports ethernet2/1,
ethernet2/2, and ethernet2/4 are configured, however, then sessions on this interface
experience load balancing issues. This second example is not a supported or
recommended configuration.
•Use of DIPs and SCTP multi-homing—There are several Stream Control Transmission
Protocol (SCTP) limitations when the ScreenOS devices uses DIPs.
•When SCTP multi-homing is used with DIPs, there is source port translation error
that results in erroneous source port translation and ultimately dropped traffic.
•When DIPs are used in an SCTP multi-homing deployment, sessions cannot be
immediately cleared when a shutdown message is received. Sessions are freed after
a timeout.
•When SCTP multi-homing is employed on a device using DIPs, not all sessions are
synched by devices in an NSRP cluster.
•When DIPs are used with SCTP multi-homing, SCTP heartbeat traffic is dropped by
the device, thus the SCTP heartbeat function is not supported.
•ScreenOS 6.3.0 does not support SCTP multi-homing when DIPs are used by the
ScreenOS device. [285236, 285672, 285722, 285988]
•8G2-G4 card throughput stability—Running repetitive maximum throughput tests at
certain small frame sizes, can cause a variance of up to about 14% difference in
throughput between two test cycles. The behavior is restricted to the 8 port G4 card.
This does not jeopardize customer traffic in any way.
•NetScreen 5000 series throughput stability—For NetScreen–5000 8G2-G4, a
hardware limitation might result in degraded throughput stability. This limitation is
also present in ScreenOS 6.0.0 and 6.1.0. [287811]
•TCP and UDP sweep screen attack monitoring—The TCP and UDP sweep screen
check is insufficiently accurate. Under extended testing, the TCP and UDP sweep screen
sometimes reports benign traffic or below-threshold attacks as valid sweep attacks.
[293313]
•Virtual MAC Address duplication—Because ScreenOS derives VMACs based on
information taken from cluster ID, interface ID, and VSD, it is not permitted to use the
same clusters and VSDs on the same broadcast domain. If cluster IDs and VSDs are
duplicated on a broadcast domain, it might result in the same VMAC being assigned
to more than one interface or device. [300933]
•PIM Power and Thermal Requirements—If you install either 8-port or 16-port uPIMs
in your SSG 140, SSG 500-series, or SSG 500M-series device, you must observe the
power and thermal guidelines. Please refer to the PIM and Mini-PIM Installation and
Configuration Guide for the power and thermal guidelines for all supported platforms,
available at:
http://www.juniper.net/techpubs/hardware/pim_guide/pim_guide.pdf .
113Copyright © 2015, Juniper Networks, Inc.
Limitations and Compatibility
WARNING: Exceeding the power or heat capacity of your device might
cause the device to overheat, resulting in equipment damage and network
outage.
•NSRP—NSRP is not supported on WAN interfaces. Devices with WAN interfaces can
use NSRP, but the WAN ports do not automatically failover as the Ethernet ports do.
•Flood Screens—On ISG 1000, ISG 2000, NetScreen-5000 Series devices, the UDP
and ICMP flood screens apply to the physical interface and therefore require that the
zone be bound to a physical interface. The following limitations apply:
•When zones are bound to a sub-interface, the ICMP and UDP flood screens are not
enforced unless the zone is also bound to a physical interface.
•When ICMP and UDP flood screen options are configured for different zones and on
the same physical interface, the flood threshold is applied based on the last
configured zone threshold.
•When ICMP and UDP flood screen options are applied to a zone tied to multiple
physical interfaces, the entire threshold value is applied to each of the physical
interfaces.
•For reference, the High Availability (HA) zone does not allow any screen features to
be configured.
•UDP and ICMP Flood Screening—ScreenOS 6.3.0 does not support UDP and ICMP
flood screening for aggregate interfaces in ISG and NetScreen 5000 series. [428057]
•Configuration file downloads through WebUI without authentication—Using the
WebUI, the firewall downloads the configuration file without authentication. For more
information, see the JTAC knowledge base number KB 12943 located at
http://kb.juniper.net.
•Call unhold fails—According to RFC 3261, a calling party shall use a=sendonly to hold
a call and a=sendrecv to unhold it. The observed behavior of the SIP phone used in our
testing is that it does not include the a=sendrecv command when it tries to unhold a
call. This lack causes the SIP server to return a "500 internal error" response because
it is unable to determine the state of the transaction. This problem is a telephony
system issue that cannot be resolved by ALG. Hence, there is no work around for this
issue available through a firewall. [300723].
•Maximum number of OSPF Redistributed Routes—For the SSG 320M/350M , the
supported maximum number of Open Shortest Path First (OSPF) redistributed routes
is 4096, but it might be possible to exceed the maximum. OSPF redistributed routes
are handled in two parts: route task and OSPF task. The route task adds redistributed
routes to OSPF continuously during one CPU time slice. The redistributed routes counter
are not, however, updated until the OSPF task is processed by the CPU, so more routes
might be added in OSPF when the routes are added using an automated script. Routes
entered or redistributed manually should not be able to exceed 4096. [258979]
•ISG and NetScreen 5000 series Multicast Hardware Support—Multicast sessions
can be handled by the ASIC only if there is a single output interface per virtual router.
Copyright © 2015, Juniper Networks, Inc.114
ScreenOS 6.3.0 Release Notes
The mcast group address can be pushed to ASIC so frames are forwarded in hardware.
To use this feature run the set/unset flow multicast install-hw-session command.
[309007, 427260]
•HA pair on ISG2000 devices—Currently ScreenOS does not support redundant or
aggregate interfaces in an active-active HA pair on ISG2000 devices. Packets received
on the backup device cannot pass through the cluster in an active-active ISG2000
pair.
•ASIC Hardware Support—ICMP-flood and UDP-flood detections are done by ASIC on
high-end platforms such as ISGs and NS-5000. There is no detection method to let
the ASIC know if the alarm-without-drop is configured. Therefore, the ASIC drops the
attack packets. On SSG series, the flow CPU detects and determines if the
alarm-without-drop is configured or not and takes appropriate actions.
•Policies—Policy Verification exec policy verify command is not supported for IPv6
policies. It is only supported for IPv4 policies.
•ICSA —ScreenOS captures raw IP packets of types 0, 6, 17, 43, 44, and 60 to the packet
log when the set flow log-dropped-packet and set firewall log-illegal-packet commands
are configured. The packet log may be accessed through the command get log packet.
However, the packet log is available only on the device. It may not be transmitted to
an external syslog server.
•Client-to-Site IPv6 VPN Support—IPv6 IP pools are supported in the IKEv1 protocol,
but they are not supported in the L2TP, PPP, and IKEv2 protocols.
Documentation Changes
•Starting with the ScreenOS 6.3.0 documentation, the content presentation of the
following guides is standardized to align with Juniper Technical Publications Standards:
•Concepts & Examples ScreenOS 6.3.0 Reference Guide
•ScreenOS 6.3.0 IPv4 CLI Reference Guide
•ScreenOS 6.3.0 IPv6 CLI Reference Guide
•Upgrade Guide
Because of the alignment, the content presentation of ScreenOS 6.3.0 documentation
differs from that of ScreenOS 6.2.0 and earlier documentation
Getting Help for ScreenOS 6.3.0 Software
For further assistance with Juniper Networks products, visit:
www.juniper.net/customers/support .
Juniper Networks occasionally provides maintenance releases (updates and upgrades)
for ScreenOS firmware. To have access to these releases, you must register your security
device with Juniper Networks.
Copyright © 2014, Juniper Networks, Inc. All rights reserved.
115Copyright © 2015, Juniper Networks, Inc.
Documentation Changes
Juniper Networks, the Juniper Networks logo, NetScreen, and ScreenOS are registered
trademarks of Juniper Networks, Inc. in the United States and other countries. All other
trademarks, service marks, registered trademarks, or registered service marks in this
document are the property of Juniper Networks or their respective owners. All
specifications are subject to change without notice. Juniper Networks assumes no
responsibility for any inaccuracies in this document or for any obligation to update
information in this document. Juniper Networks reserves the right to change, modify,
transfer, or otherwise revise this publication without notice.
Copyright © 2015, Juniper Networks, Inc.116
ScreenOS 6.3.0 Release Notes

Navigation menu
