LOREX QLR460 Series SPEC SHEET S10120 Product Specifications

User Manual:

Open the PDF directly: View PDF .
Page Count: 2

QLR460 PC SURVEILLANCE DIGITAL VIDEO RECORDER

PC SURVEILLANCE, H.264, INTERNET REMOTE

VIEWING DIGITAL VIDEO RECORDER

•CONNECT easily: Lorex Easy Connect Internet Setup

Wizard will get you connected in 3 simple steps.

•SEE everything: View up to 4 cameras on your computer.

Easy to use software allows you to control and configure

multiple cameras.

•RECORD what happens: Directly to your computer’s

hard drive. Triplex operation allows you to view, record

and playback simultaneously. Advanced H.264 video

compression maximizes recording time.

•PROTECT what matters: Connect anytime, from anywhere

in the world using the internet remote monitoring software.

Be alerted by motion events sent to you via email.

Utilize your computer as a cost effective surveillance

system for business and home.

PC SURVEILLANCE, H.264, INTERNET REMOTE VIEWING

DIGITAL VIDEO RECORDER

HOME & BUSINESS SECURITY

4 Channel Quad View

www.lorextechnology.com

CONNECT. PROTECT.

Microsoft Windows™, XP, Vista, 7 are trademarks of Microsoft Corporation. Other trademarks are the property of

Lorex Technology Inc. We reserve the right to change models, configurations or specifications without notice or

liability. Product may not be exactly as shown.

PC SURVEILLANCE, H.264, INTERNET REMOTE VIEWING

DIGITAL VIDEO RECORDER

• Intel Pentium 4, 3.0Ghz and above

• 1GB of RAM

• 250GB SATA hard drive

• 64MB or greater video card capable of 1024 x 768 resolution with 32 bit

color resolution

• Windows™ Vista XP, 7 (32 & 64 bit versions)

• 300 Watt power supply

• Optical Drive

• Broadband connection required for remote management

Minimum System Requirements Product Information:

Models: QLR460: Universal Retail Sleeve

UPC: 7-78597-00460-1

Weight: 0.2 lbs /90 grams

Package

Dimensions:

10.2 x 2.1” x 11.2” /

259mm x 53mm x 284mm (W x H x D)

Package Cube: 0.004 CBM / 0.143 ft

Includes: 4 port PCI Card and Mounting Screws,

2-Channel Audio Cable, QSG, Instruction

Manual, Software CD

©2010 Lorex Technology Inc.

As our product is subject to continuous improvement, Lorex Technology &

subsidiaries reserve the right to modify product design, specifications & prices

without notice and without incurring any obligation. E&OE

2-06232010

Lorex Technology Inc.

3700 Koppers Street

Baltimore, Maryland 21227, USA.

250 Royal Crest Court, Markham,

Ontario L3R 3S1, Canada.

Video Input: 4 ch (BNC), NTSC/PAL

Display Speed: 30fps (4ch)

Split Screen: 1, 4

Recording Speed: 30fps (4ch) @ 320 x 240

Recording Resolution: 320 x 240 / 720 x 240

Recording Modes: Motion Detection, Schedule,

Continuous

Playback Display: 1, 4

Search Modes: Date, Time, Channel, Event

Network Speed: Real-Time

Remote View: Client software or Web Browser

Dynamic IP Support: Lorex DDNS

Supported O/S: Windows, XP, Vista, 7 (32 bit)

Specifications: Dimensions:

4.7in/

120mm x H

4.5in/

115mm x W

0.7in/

20mm x D

Digital Video Recorder:

• Digital Recording of live video to PC’s hard drive

• Can also record on an external hard drive (not included)

• Internet Remote Monitoring

• H.264 video compression maximizes recording time

• View up to four locations simultaneously

• PC compatible with Windows™ XP, Vista and 7

• Viewing options: Quad / Full Screen / Sequencing

• Easy search and playback of digitally recorded video

• Password security protection

• Free Lorex DDNS (Dynamic Domain Name System) service

keeps you connected from anywhere at all times

• Exclusive LOREX Easy Connect Internet Set-up Wizard

• Email alerts notify you when events occur
