SCH-R270
MOBILE PHONE
User Manual
Please read this manual before operating your
phone and keep it for future reference.
SCH-R270_UM_English_FE01_CH_051512_F2
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone
System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the
rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain
with SAMSUNG and its suppliers.
Open Source Software
Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser
General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered
under the open source licenses, please visit:
http://opensource.samsung.com
.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING
THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS
OR BENEFITS.
SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS,
OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY.
Samsung Telecommunications America (STA), LLC
Headquarters:
1301 E. Lookout Drive
Richardson, TX 75082
Customer Care Center:
1000 Klein Rd.
Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
Internet Address:
http://www.samsung.com
©2012 Samsung Telecommunications America, LLC. Samsung is a registered trademark of Samsung Electronics Co., Ltd.
Do you have questions about your Samsung Mobile Device?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsung.com/us/support
Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications,
Inc., or its affiliates in the United States and/or other countries.
ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are
registered trademarks and are wholly owned by the Bluetooth SIG.
microSD™, microSD™HC, and the microSD logo are Trademarks of the SD Card Association.
easy
edgeSM is a service mark of United States Cellular Corporation.
Openwave® is a registered Trademark of Openwave, Inc.
Google, the Google logo, Android, the Android logo, Gmail, Google Mail, Google Maps, Google Music, Google Play, Google Talk,
Google Play, Picasa, YouTube and other marks are trademarks of Google Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
Swype™ and the Swype logos are trademarks of Swype, Inc.
1
Table of Contents
Section 1: Getting Started .......................... 4
Understanding this User Manual . . . . . . . . . . . . 4
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Charging the Battery . . . . . . . . . . . . . . . . . . . . 7
Activating Your Phone . . . . . . . . . . . . . . . . . . . 8
Section 2: Understanding Your Phone ..... 11
Features of Your Phone . . . . . . . . . . . . . . . . . 11
Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Closed View of Your Phone . . . . . . . . . . . . . . . 13
Open View (Front) of Your Phone . . . . . . . . . . 14
Command Keys . . . . . . . . . . . . . . . . . . . . . . . 15
Navigation Key Shortcuts . . . . . . . . . . . . . . . . 17
Understanding the Display Screen . . . . . . . . . 18
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . 19
Section 3: Call Functions ......................... 21
Making and Answering a Call . . . . . . . . . . . . . 21
In-Call Options . . . . . . . . . . . . . . . . . . . . . . . . 24
Voice Commands . . . . . . . . . . . . . . . . . . . . . . 24
Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Accessing Calls . . . . . . . . . . . . . . . . . . . . . . . 28
Section 4: Entering Text ............................35
Changing the Text Entry Mode . . . . . . . . . . . . 35
Using T9 Word Mode . . . . . . . . . . . . . . . . . . . 35
Using Abc Mode . . . . . . . . . . . . . . . . . . . . . . . 36
Entering Numbers . . . . . . . . . . . . . . . . . . . . . 36
Entering Symbols . . . . . . . . . . . . . . . . . . . . . . 37
Entering Emoticons . . . . . . . . . . . . . . . . . . . . 37
Section 5: Understanding Your Contacts .38
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Finding a Contacts Entry . . . . . . . . . . . . . . . . . 38
Adding a New Contacts Entry . . . . . . . . . . . . . 40
Saving a Number After a Call . . . . . . . . . . . . . 40
Editing a Contacts Entry . . . . . . . . . . . . . . . . . 41
Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Contacts Groups . . . . . . . . . . . . . . . . . . . . . . . 43
Memory Info . . . . . . . . . . . . . . . . . . . . . . . . . . 45
2
Section 6: Messaging ................................46
Types of Messages . . . . . . . . . . . . . . . . . . . . .46
Creating and Sending Text Messages . . . . . . . 46
Creating and Sending Picture Messages . . . . . 47
Receiving Messages . . . . . . . . . . . . . . . . . . . .49
Message Boxes . . . . . . . . . . . . . . . . . . . . . . . .50
CMAS Messages . . . . . . . . . . . . . . . . . . . . . . .54
Erase Messages . . . . . . . . . . . . . . . . . . . . . . .55
Message Settings . . . . . . . . . . . . . . . . . . . . . .56
Section 7: Multimedia ...............................59
Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
My Images . . . . . . . . . . . . . . . . . . . . . . . . . . .61
My Ringtones . . . . . . . . . . . . . . . . . . . . . . . . .62
Music Player . . . . . . . . . . . . . . . . . . . . . . . . . .63
Section 8: Web ..........................................67
Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
easyedge . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Launching an Application . . . . . . . . . . . . . . . . 68
Finding and Downloading Applications . . . . . . 68
Tone Room . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Section 9: Tools ........................................70
Tools Menu . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Voice Service . . . . . . . . . . . . . . . . . . . . . . . . . .72
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Memo Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . .74
World Time . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Stop Watch . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Tip Calculator . . . . . . . . . . . . . . . . . . . . . . . . .78
USB Mass Storage . . . . . . . . . . . . . . . . . . . . . .78
Section 10: Changing Your Settings ........79
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Display Settings . . . . . . . . . . . . . . . . . . . . . . . .79
Sound Settings . . . . . . . . . . . . . . . . . . . . . . . .82
Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . .83
Phone Settings . . . . . . . . . . . . . . . . . . . . . . . .85
Phone Info . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Memory Info . . . . . . . . . . . . . . . . . . . . . . . . . .92
3
Section 11: Health and Safety Information 94
Exposure to Radio Frequency (RF) Signals . . . 94
Specific Absorption Rate (SAR) Certification
Information . . . . . . . . . . . . . . . . . . . . . . . . . 98
FCC Part 15 Information to User . . . . . . . . . . . 99
Commercial Mobile Alerting System (CMAS) . 100
Smart Practices While Driving . . . . . . . . . . . 100
Battery Use and Safety . . . . . . . . . . . . . . . . . 101
Samsung Mobile Products and Recycling . . . 103
UL Certified Travel Charger . . . . . . . . . . . . . 104
Display / Touch-Screen . . . . . . . . . . . . . . . . 104
GPS & AGPS . . . . . . . . . . . . . . . . . . . . . . . . . 105
Emergency Calls . . . . . . . . . . . . . . . . . . . . . 106
Care and Maintenance . . . . . . . . . . . . . . . . . 106
Responsible Listening . . . . . . . . . . . . . . . . . 107
Operating Environment . . . . . . . . . . . . . . . . 109
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices . . . . . . . 111
Restricting Children's Access to
Your Mobile Device . . . . . . . . . . . . . . . . . . 112
FCC Notice and Cautions . . . . . . . . . . . . . . . 112
Other Important Safety Information . . . . . . . 113
Section 12: Warranty Information ..........115
Standard Limited Warranty . . . . . . . . . . . . . . 115
End User License Agreement for Software . . 119
Index .........................................................124
4
Section 1: Getting Started
This section explains how to start using your SCH-R270 by
activating your service, setting up your Voicemail, or getting an
understanding of how this manual is put together.
Understanding this User Manual
The chapters of this guide generally follow the same order as the
menus and sub-menus in your phone. A robust index for quick
reference to most features begins on page 124.
Also included is important safety information that you should
know before using your phone. Most of this information is near
the back of the guide, beginning on page 94.
Notes and Tips
Throughout this guide there is text that is set apart from the rest.
These are intended to point out important information, quick
methods for activating features, to define terms, and more. The
definitions for these methods are as follows:
Notes
: Explain alternative options within the current feature, menu, or
sub-menu.
Tips
: Provide quick or innovative methods for performing functions
related to the subject at hand.
Important
: Points out important information about the current feature
that could affect performance, or even damage your phone.
Text Conventions
This manual provides condensed information about how to use
your phone. To make this possible, the following terms and icon
display in place of repeatedly-used procedural steps:
highlight
Use the Navigation key ( ) to move a
highlighting effect onto a menu item or screen
item of interest.
select
After “highlighting” a menu item or screen item,
press to launch, access, or save a
highlighted menu item or screen field of interest.
Used in place of “select” in long “drill down”
procedure steps.
Example:
Select
Settings
Call Settings
Call
Answer
.
Getting Started 5
Battery
Your phone is powered by a rechargeable, standard Li-Ion
battery. A travel charger is included with the phone, for charging
the battery.
Note:
The battery comes partially charged. You must fully charge
the battery before using your phone for the first time. A fully
discharged battery requires up to 4 hours of charge time.
After the first charge, you can use the phone while charging.
Warning!
Use only Samsung-approved charging devices and
batteries. Samsung accessories are designed to
maximize battery life. Using other accessories may
invalidate your warranty and may cause damage.
Removing the battery cover
Pull up using the slot provided (1), while lifting the cover
off the phone (2).
6
Installing the battery cover
Align the cover and press it firmly into place, being sure it
snaps into place at the corners.
Installing the Battery
Note:
Your phone comes packaged with a partially charged
rechargeable standard Li-Ion battery and travel adapter.
Important!
You must fully charge the battery the first time you use
your phone, otherwise you could damage the battery.
1. Remove the battery cover. For more information, refer to
“Removing the battery cover” on page 5.
2. Insert battery into the phone housing, aligning the gold
contacts on the battery with the gold contacts in the
phone. Push down on the bottom of the battery down.
3. Install the battery cover.
Getting Started 7
Removing the Battery
1. Press and hold to turn off the phone (if on).
2. Remove the battery cover. For more information, refer to
“Removing the battery cover” on page 5.
3. Lift the bottom of the battery up (1) and away (2) from the
phone.
Charging the Battery
Your phone is powered by a rechargeable standard Li-Ion battery.
Only use Samsung-approved charging devices and batteries.
Samsung accessories are designed to maximize battery life. Use
of other accessories may invalidate your warranty and may cause
damage.
1. Insert the larger end of the USB Data Cable into the
Charging Head.
2. Plug the charging head into a standard AC power outlet.
3. Insert the smaller end of the USB Data Cable into the
charger/accessory connector on the lower right side of
your phone.
Incorrect
Charging Head
8
4. When charging is complete, unplug the charging head
from the power outlet and remove the USB cable from the
phone.
Important!
For connection to an electrical supply not located in
North America, you must use an adaptor of the proper
configuration for the power outlet. Use of the wrong
adapter could damage your phone and void your
warranty.
Low Battery Indicator
The battery indicator ( ) in the upper-right corner of the
display indicates power level. Monitor the battery strength and
ensure your battery is adequately charged.
Five bars ( ) indicate a full charge.
An empty battery icon ( ) indicates a near empty battery.
A blinking empty battery icon ( ) and a tone sounding
indicate you have two to three minutes before the battery is too
low to operate the phone.
If you continue to use your phone without charging the battery,
the phone will shut down.
Activating Your Phone
Contact your Wireless Carrier and follow their instructions for
obtaining service, if necessary. We suggest that you read this
guide to fully understand the services your phone supports.
Turning Your Phone On
1. If closed, open your phone, as shown.
Incorrect
Correct
Getting Started 9
2. Press . The display lights.
Note:
As with any other radio-transmitting device, do not touch the
antenna while using your phone because this may affect call
quality or cause the phone to operate at a higher than
necessary power level.
The phone begins searching for a network signal.
Once the phone finds a signal, the time, date, and day at the top of
the screen.
you are now ready to place and receive calls.
Note:
If you are outside of your carrier’s coverage or roaming area,
the Roaming icon ( )displays at the top of the phone’s
screen. If you cannot place or receive calls, try later when
service is available, or at another location.
Turning Your Phone Off
1. If closed, open your phone.
2. Press and hold for two or more seconds. The
phone powers off.
Note:
If the phone is on and you press for less than one
second, the phone does not power off. This prevents your
phone from accidental shut-down.
Setting Up and Listening to Voicemail
Voicemail allows callers to leave voice messages, which are
retrievable anytime.
Note:
Once your Voicemail account is set up, you can use the
Voicemail folder (under the Message menu) to view details
of voice messages in your Voicemail box.
To dial Voicemail:
1. In standby mode, press and hold or dial your own
mobile number.
2. Follow the prompts in the new user tutorial to setup your
mail box.
10
To listen to Voicemail
In standby mode, press and hold or dial your own
mobile number to dial Voicemail. After connecting, you
hear your voice greeting and are prompted to enter your
password.
Understanding Your Phone 11
Section 2: Understanding Your Phone
This section outlines some key features of your phone. It also
describes the screen format and the icons that display when the
phone is in use.
Features of Your Phone
Domestic and international voice and text messaging service
(available on participating networks).
High speed data (CDMA 2000 1x Technology)
Bluetooth
®
Wireless Technology, v2.1 Enhanced Data Rate (see Note)
Global Positioning System (GPS) Technology
Personal Information Management Tools
Text (SMS) and Picture (MMS) Messaging
Music Player (requires an optional Memory Card)
Memory Card Slot (MicroSD
and microSD
HC up to 32 GB)
E-mail Messaging
Built-in 1.3 Megapixel Digital Camera
Voice Dial
Note:
The SCH-R270 supports the wireless Headset, Handsfree,
Object Push, File Transfer, Dial-up Networking, and Phone
Book Access profiles for Bluetooth® wireless technology.
The SCH-R270 does not support Bluetooth OBEX profiles. For
more information, refer to “Bluetooth” on page 70.
12
Side View
Features
1.
Volume Key
: Allows you adjust the ring volume in standby
mode, adjust the voice volume during a call, or mute the
ringer during an incoming call.
2.
Power/Accessory Connector
: Used to connect an optional
headset (for hands free operation), or optional TTY device,
charging accessories, or optional accessory cables to your
phone.
3.
Camera Key
: Launches the Camera feature of your phone
and takes photos.
4.
3.5 MM Headset Jack
: Plug in a 3.5 millimeter headset jack
to hear music, calls, and more.
5.
Strap Attachment
: Attach an optional strap (not included).
1
2
3
4
5
Understanding Your Phone 13
Closed View of Your Phone
Feature
1.
Camera Lens
: The lens of your built-in camera.
2.
Sub LCD screen
: Displays Status icons, time, and date
without opening the phone.
1
2
14
Open View (Front) of Your Phone
Features
1.
Earpiece
: Allows you to listen to callers.
2.
Main Display
: Indicates the status of your phone, including
status icons, message indicators, signal strength and
more.
3.
Navigation Key
: In Menu mode, lets you scroll through the
phone menu options. In Standby mode, lets you access
preset functions and one user-defined function.
4.
Left Soft Key
: Used to navigate through menus and
applications and to select the choice indicated at the
bottom left corner of the Main LCD.
5.
SEND Key
: Lets you place or receive a call. In standby
mode, press once to access the recent calls log.
6.
Voicemail Key:
Lets you speed dial your Voicemail account
to review your voice messages.
7.
Special Function Key
: When in a text entry field press and
hold to toggle between text entry modes. Also when dialing
an international number, press and hold to add a “+”.
8.
Voice Recognition Key
: Press and hold to launch voice
recognition system. Pressed while entering text in T9
mode, T9 displays an alternative word suggestion. For
details see “Using T9 Word Mode” on page 35.
1
3
4
5
7
13
12
11
10
8
2
14
6
9
Understanding Your Phone 15
9.
Microphone
: Lets the other caller hear you when you are
speaking.
10.
Vibrate Mode Key
: Press and hold to activate vibration
mode.
11.
CLR Key
: Deletes characters from the display when you are
in text entry mode. Press this key to return to the previous
menu or screen when navigating features on your phone.
12.
END Key
: Ends a call. If you press and hold the END key, the
power goes On or Off. When you receive an incoming call,
press to send the call to voicemail.
13.
Right Soft Key
: Used to navigate through menus and
applications and to select the choice indicated at the
bottom right corner of the Main Display.
14.
OK Key
: Press when navigating through a menu to accept
the highlighted choice.
Command Keys
Key Type/Mode Function
Left soft/Standby mode
Edit mode
Launches the Messages menu.
Edits a contact entry.
Right soft/Contact
Options mode
Back
Launches the Contacts Find
screen.
Displays a pop-up.
Goes back one menu level.
16
Function Keys
The Function keys launch menus, accept selections, answer
calls, dial calls, and perform other functions from Standby mode,
or in various other modes.
The following table depicts each key and the action it performs:
Key From Action
Standby mode
In a menu
Camera mode
Edit mode
Launches the Main Menu.
Accepts the highlighted
selection.
Takes a photo or creates a Picture
message.
Edits a Draft message.
Standby mode
Dialing mode
During a call
Answers calls.
Short press displays a list of
recent calls to and from the
phone.
Press twice to call the most
recent number.
Enter a number that you want and
call.
Dials a call.
Picks up a waiting call. Press
twice to switch back to the other
call.
Any mode
During a call
From any menu
Turns the phone On or Off.
Press once to disconnect the call.
Returns to Standby mode, or
cancels last input.
Text input mode
Menu mode
Deletes a character.
Press and hold to erase the entire
sentence.
Briefly press to go back one
menu level.
Key From Action
Understanding Your Phone 17
Navigation Key Shortcuts
In standby mode, press a navigation key to launch the key’s
corresponding application.
Tip:
To customize the
My Images
shortcut key press
Menu
(),
then select
Settings
Phone Settings
Shortcut Key
.
Camera Key
Use the
Camera Key
( ) for Camera functions:
In standby mode, press and hold to launch the camera.
While in Camera mode, press to take a photo.
Vibration Mode Key
Use the
Vibrate Mode Key
to control Vibrate Only mode:
In standby mode
, press and hold to set your phone to Vibrate Only
mode.
In standby mode
, press and hold to return to the previous sound
profile.
Voice Commands Key
Use the Voice Commands Key
to launch and use Voice
Commands.
Volume Key
Use the
Volume
Key
( ) to adjust volume:
In standby mode:
- Press to set Master Volume.
- Press and hold down to activate Sounds Off.
During calls:
- Press to adjust voice volume.
Press down to mute the ringtone of an incoming call.
Navigation key
Browse menus, submenus, or
lists.
Each directional key acts as
shortcut to launch applications.
Key From Action
Voice Commands
Calls
Calendar
easy
edgeSM
18
Note:
You can also enter Camera mode in standby mode by
pressing
Menu
()
Multimedia
Camera
.
Speakerphone
Use the Speakerphone function to enable or disable the
speakerphone. This lets you conduct a call handsfree, and/or lets
you share a call with others.
To enter Speakerphone Mode
During a call, press
SPK
()
Yes
soft key to activate
the speakerphone.
Caution!
While in Speakerphone mode, hold your phone away
from your ear. (For more information, refer to
“Responsible Listening” on page 107.)
To exit Speakerphone Mode
During a call, press
SPK
()
Yes
soft key to deactivate the
speakerphone.
Voicemail Key
Use the
Voicemail Key
( ) to set up and check Voicemail.
In standby mode, press and hold the
Voicemail Key
()
to call
Voicemail.
Understanding the Display Screen
1. The top line of the
phone’s display
contains icons
that indicate
network status,
battery power,
signal strength,
connection type,
and more.
2. The Main Clock
displays the day,
date, and time.
3. The bottom line of the screen displays current soft key
functions.
The sample screen displays that pressing the Left soft key
Messages
launches the Messages menu, pressing
displays the Main Menu, and pressing the Right (
Contacts
)
soft key displays the Contacts
Find
screen.
1
2
3
Understanding Your Phone 19
Display Screen Icons
Your SCH-R270 phone lists definitions of the icons that display on
the top line of the screen.
To access the Icon Glossary:
In standby mode, press
Menu
() Settings
Phone Info
Icon Glossary
. The icons list displays.
Menu Navigation
Access the menus and sub menus in your phone using the
navigation key ( ), the left or right soft keys ( or ),
or use a shortcut.
1. In standby mode, press
Menu
( ).
2. Use the navigation key to browse through the menus.
3. To enter the menu or sub menu that displays on the
screen, press .
4. Press the soft key to return to the previous menu.
Navigate Using a Shortcut
You can also access menus and sub menus using menu
numbers. After pressing Menu ( ), press the menu number
to go directly to the menu or sub menu of your choice. Before you
can navigate using a shortcut, you must know the menu or
sub-menu number to access.
1. In standby mode, press
Menu
( ).
2. Press the number of the menu, sub menu, and other
information for the feature to access.
Example:
Press
Menu
( ), then press , . This
takes you to the
Multimedia
menu (Menu 8), and then to
the
Camera
(sub menu 1).
Navigate Using Quick Search
Use the
Quick Search
feature to find a menu or menu item by
pressing the number keys that correspond to the first few letters
of menu or menu item name. (For more information, refer to
“Quick Search” on page 90.)
20
Dialogue Boxes
Dialogue boxes prompt for action, inform you of status, or warn
of situations such as low battery. Dialogue boxes and their
definitions are outlined below.
Choice
Example:
“Save Message?”
Reconfirm
Example:
“Erase All Messages?”
Performing
Example:
“Sending..” “Connecting..”
Completed
Example:
“Message Saved”
Information
Example:
“New Message”
Error
Example:
“System Error!”
Warning
Example:
“Low Battery,” “Memory Full!”
Call Functions 21
Section 3: Call Functions
This section explains how to make and answer calls. This section
also includes the features and functionality associated with
making or answering calls.
Making and Answering a Call
Making a Call
With the phone on, enter the number to call using the
keypad and press .
Answering a Call
Press to answer an incoming call.
Adjusting the Call Volume
In standby mode, repeatedly press the
Volume
key ( )
down until the Call Volume Level desired displays on the screen.
The Volume key is on the left side of phone.
Dialing Emergency Numbers
It is import that you DO NOT depend on this phone as a primary
method of calling 911 or for any other essential or emergency
communications.
Because of various transmission methods, network parameters,
and user settings necessary to complete a call from your wireless
phone, a connection cannot always be guaranteed. Therefore,
emergency calling may not be available on all wireless networks
at all times.
To place an emergency call:
1. Turn on the phone and dial 911 using the keypad.
2. Press to place the call.
You can specify other numbers as emergency numbers using the
Emergency # settings. (For more information, refer to
“Emergency #” on page 87.)
Important!
Emergency number 911 is preset into your phone. You
can dial this number almost any time, even when the
phone is locked or restricted.
If you call 911 an audible tone plays and an Emergency
prompt displays on the screen for the duration of the
call.
22
Dialing International Numbers
Call Another Country
Manual Method
1. In standby mode, enter
011
(the three-digit exit code for
the United States).
2. Enter the country code.
3. Enter the number to call, then press .
Note:
Puerto Rico and Canada are on the North American dialing
plan. Making calls to Puerto Rico and Canada is similar to
making calls within the United States, no unique country
codes are necessary.
Call Another Country
Shortcut Method
1. In standby mode, press and hold until a plus sign (
+
)
displays on the screen.
Note:
When you press , your phone automatically replaces
this
+
with 011, the three-digit exit code for the United
States.
2. Enter the country code for the country that you are calling.
3. Enter the number to call, then press .
Manual Pause Calling
When you call automated systems (like banking services), you
are often required to enter a password or account number.
Instead of manually entering the numbers each time, you can
store the numbers in your Contacts along with special characters
called pauses.
2-Sec Pause
: A two-second pause stops the calling sequence for two
seconds then automatically sends the remaining digits.
Wait
: A hard pause stops the calling sequence until you
press .
To manually call a number with pause(s) without storing it to your
Contacts:
1. Enter the number to call.
2. Press the Options soft key.
3. Highlight the desired pause option and press to enter
the pause into your number sequence:
2-Sec Pause
: a two-second pause.
Wait
: a hard pause (awaits input from you).
Note:
If you select
2-Sec Pause
,
P
displays on the screen. If you
select
Wait
,
W
displays on the screen.
4. Press to the number.
Call Functions 23
Pause Dial from Contacts
If you voice dial a contact that contains (two-second) T pause(s)
simply wait for the pauses to pass and the dialing to complete.
If you voice dial a contact that contains (hard) P pause(s), wait for the
appropriate prompt(s) from the number you are calling (credit card
number, bank account number, or other) and enter the appropriate
response(s).
1. If you stored the number using 2-second pause(s), simply
find the Contacts entry, highlight the number, and press
. (For more information, refer to “Finding a
Contacts Entry” on page 38.)
2. If you stored the number using Wait(s), find and dial the
number from Contacts and wait for the appropriate prompt
from the dialed number.
3. Press to resume dialing the number.
Making a Call using Speed Dial
You can store phone numbers and contact names in your phone’s
Contacts list. Speed Dialing lets you quickly and easily dial any
contact in your Contacts list by using that contact’s location
number in the list. You can assign and change location (speed
dial) numbers for your contacts. (See “Assigning a Speed Dial
Location” on page 43.)
One-Touch Dialing
Speed Dial numbers 2 through 9 are special One-Touch dialing
numbers. You can call the phone numbers stored in your phone’s
Contacts list and assigned Speed Dial numbers 2 through 9 by
pressing and holding a single key.
Example:
For Speed Dial number 3, press and hold until the
name and number display and the number dials.
Two-Touch Dialing
Memory locations 10 through 99 are special Two-Touch dialing
locations.
Example:
For location number 13, briefly press , then press
and hold until the name and number displays and
the number dials.
Three-Touch Dialing
Memory locations 100 through 999 are special Three-Touch
dialing locations.
Example:
For location number 113, briefly press , briefly
press again, then press and hold until the
name and number displays and the number dials.
24
Pause Dialing From a Contacts Entry
To speed dial a contact that contains (two-second) P pause(s) wait for
the pauses and dialing to complete.
To speed dial a contact that contains (hard) W pause(s), wait for the
prompt(s) from the number you called (credit card number, bank
account number, or other) then enter your digits.
Making a Call from Quick Search Dialing
Use the
Quick Search
feature to dial any number stored in your
Contacts list by pressing the number keys that correspond to the
first few letters of a Contact name. (For more information, refer to
“Quick Search” on page 90.)
Dialing a Contact using Quick Search
To find and dial a Contact, do the following:
1. In standby mode, press the number keys that correspond
to the first few letters of the Contact name.
2. Press the Up navigation key. The
Find
screen displays the
desired Contact name, as shown.
3. If needed, use the Up and Down navigation keys to
highlight the Contact you wish to call.
4. Press to call the highlighted Contact.
In-Call Options
You can access numerous menus and features while in a call.
1. While in a call, press the Options soft key.
The following menu items display:
•Speaker On
/
Off
: Enables/disables Speakerphone mode during this
call.
• Message
: The
Messages
menu displays on the screen.
•Contacts
: The Contacts
Find
screen displays on the screen.
Recent Calls
: The
All
Calls
Log screen displays on the screen.
Send DTMF
: Send your phone number as DTMF tones.
Voice Privacy
: Select
Standard
or
Enhanced
voice privacy.
•Location
: Lets you change your phone’s Location setting.
Voice Commands
Voice Commands is advanced speech recognition software that
recognizes your spoken commands to dial phone numbers,
create messages, and launch phone features such as Contacts,
Calendar and My Music.
The system prompts you to say a command. When the system is
listening, speak clearly and say the command. If you are
frequently prompted to repeat a command, go to the Settings
menu to train the system to your voice.
Call Functions 25
Note:
At each step, Voice Commands displays a list of available
commands.
If Voice Commands does not recognize your command, it
prompts for confirmation.
In standby mode, press and hold to launch Voice
Commands.
The following is a list of functions that you can perform
with Voice Commands:
Call <Name or #>
: Say the name or number of the person to call,
or say voicemail or last number.
Send <MSG Type>
: Select a message type: Text or Picture.
Go To <Menu>
: Say the application name or menu item to open.
•Check <Item>
: View details about your phone’s status.
•Contacts <Name>
: Searches and displays a contact by name to
call. Ex: say “Contacts Aaron”.
•Redial
: Redials the last phone number called.
•Help
: Displays helpful information about the Nuance Voice Service.
Call <Name or #>
Place a call by speaking a contact name or telephone number.
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Call
”, followed by:
“<
A Contact Name
>”, to call the default telephone number
for a contact. Or, say “Call”, followed by the type of number, Mobile,
Home, Work, or Pager.
“<
Telephone Number
>” to dial phone number.
Voicemail
” to access voicemail.
Last Number
” to dial the number for the most recent call record.
3. Follow the prompts to confirm your selection and place the
call.
Send <MSG Type>
Create a new message by speaking the type of message and the
recipient(s).
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Send
<
Text, or Picture
>
Message to
<
contact name
>
”.
26
The new message opens, with the To: field populated with
your selection(s). Continue creating the message.
Go To <Menu>
Access a menu item by speaking the menu’s name.
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Go to
”, followed by the name of a menu item, for
example, “Calls”, “Messages”, “Contacts”,
“Tools”, “Multimedia”, “Settings“, “Phone Settings”,
“Sound Settings” or other item. The item opens.
Check <Item>
Access device information by speaking the command.
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Check
”, followed by a command:
• Status
: Displays status details about the phone such as levels for
the battery, data signal, missed calls, and more.
•Voicemail
: Opens the Voicemail screen.
•Messages
: Lists the status of all the message types including: New
Voicemail, New TXT Messages, and New Picture Messages.
Missed calls
: Displays missed calls.
•Time
: Displays the current time and date.
Signal Strength
: Displays and announces the current signal
strength level.
Battery Level
: Displays and announces the current battery level.
•Volume
: Displays the Master Volume status.
•My Number
: Displays the phone number assigned to this phone.
Contacts <Name>
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Contacts
”, followed by a command:
•Call
: Followed by the contact name, dials the contact.
•Create New
: Displays the NEW CONTACT screen so you can create
a new contact.
•Modify
: Say the name of the contact to modify. Displays the contact
information to modify.
•Erase
: Say the name of the contact to erase.
Call Functions 27
Redial
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Redial
”. The
CALLING
screen appears in the display
showing the Contact and/or number being redialed.
Help
1. In standby mode, press and hold .
The audio prompt “
Please say a command
” sounds and the
Voice Commands display.
2. Say “
Help
”. The
HELP
screen appears showing text that
explains how to use Voice Comands.
Voice Commands Settings
Configure the Voice Commands feature of your phone.
1. In standby mode, press
Menu
() Tools
Voice SVC Voice Settings.
2. Select a setting for customization:
•Confirm Choices
: When voice recognition is not confident it has
recognized a name or number correctly, a list of up to three choices
displays.
• Sensitivity
: Controls how voice recognition determines when a
spoken word is a match. If you frequently experience the messages
“Please repeat...” or “No Match Found,” adjust the sensitivity.
Adapt Voice
: Adapts to your voice so your commands are
understood in your tone and voice pattern.
•Prompts
: Allows you to configure the Mode, Audio Playback, and
Timeout values.
Key Setting
: Select the method for launching Voice Commands.
Choose
Voice Key Only
to launch with the Voice Commands key.
Choose
Voice Key/Ear Mic
to launch with the Voice Commands key,
OR with headset controls when you attach an optional headset.
• About
: View information about Voice Commands.
28
About Voice Commands
This option causes the About Nuance screen to display the
version and build information about the Voice Command
software.
1. At the Voice SVC sub-menu, select Voice Settings
About.
The About Nuance screen displays the version level of the
Nuance software installed on your phone.
Roaming
Roaming lets you use your SCH-R270 when you travel outside of
your Wireless Carrier’s coverage area. The Roaming icon ( )
displays in the top line of the screen when Roaming is active, and
extra charges may apply when making or receiving calls.
Note:
Some features may be unavailable while roaming. Roaming
consumes additional power from the battery and requires
frequent recharging. Contact Cricket for more information.
How Roaming Works
The Roaming option lets you set preferences for roaming out of
your home network. The following options are available:
Home Only
: The phone is available for normal operation only in the
designated coverage area.
Automatic
: To acquire service the Wireless Carrier’s Preferred
Roaming List (PRL) for networks is used. If no preferred networks are
found, the phone automatically uses the first digital system
discovered.
Note:
For more information, refer to “System Select” on page 89.
Accessing Calls
The Calls menu retains information about Outgoing, Incoming,
and Missed calls. You can also view times for your last call and
the time totals for all calls.
In standby mode, press
Menu
() Calls . The
following Calls logs and options display:
Outgoing Calls
Incoming Calls
•Missed Calls
All Calls
Call Timer
Data Counter
FPO
Call Functions 29
Outgoing Calls
Your phone retains information about the last 90 outgoing calls
and stores them in the Outgoing calls log. You can review the
Outgoing calls log for the time and date of a call, as well as other
information.
Tip:
In standby mode, press to view your most recent calls.
1. In standby mode, press
Menu
() Calls
Outgoing Calls
. A list of outgoing calls displays.
2. Highlight a call, then press
OPEN
to view the name of the
called party (if in the Contacts list), the number dialed, the
time and date the call was placed, and the duration of the
call (in minutes and seconds).
3. From the highlighted call, press the Options soft key.
4. Select one of the following options:
•Save
: Save the number to your Contacts.
• Details
: (Calls from Contacts Only): Displays the entry for the calling
Contact.
•Erase
: Erase the selected call from your Outgoing call log.
•Lock/Unlock
: Locks the call to prevent deletion or allows deletion
of the call record.
•Erase All
: Erase all calls from your Outgoing call log.
•View Timer
: Displays the number of calls and/or the total time
spent on the Last Call, Outgoing Calls, Incoming Calls, Roaming
Calls, All Calls, Last Reset, and Lifetime Calls.
5. Press the Msg soft key to launch the
Send Message
menu.
6. Select one of the following options:
Text Message
: Lets you send a text message to the selected
number called.
Picture Message
: Lets you send a picture message to the
selected number called.
Incoming Calls
Your phone retains information about the last 90 Incoming calls
and stores them in the Incoming call log. You can review the
Incoming call log for the time and date of the call, as well as
other information.
1. In standby mode, press
Menu
Calls
Incoming
Calls
. A list of incoming calls displays.
2. Highlight a call, then press
OPEN
to view the Name of the
caller (if in the Contacts list), the originating number, the
time and date the call was received, and the duration of
the call (in minutes and seconds).
3. Press the Options soft key.
FPO
FPO
30
4. Select one of the following options:
Save
: Save the number to your Contacts.
• Details
: (Calls from Contacts Only): Displays the entry for the calling
Contact.
Erase
: Erase the selected call from your Incoming calls log.
Lock
/Unlock
: Locks the call to prevent deletion or allows deletion
of the call record.
Erase All
: Erase all calls from your Incoming calls log.
View Timer
: Displays the number of calls and/or the total time
spent on the Last Call, Outgoing Calls, Incoming Calls, Roaming
Calls, All Calls, Last Reset, and Lifetime Calls.
5. Press the Msgs soft key.
6. Select one of the following options:
Text Message
: Send a text message to the selected calling
number.
Picture Message
: Send a picture message to the selected calling
number.
Missed Calls
Your phone retains information about the last 90 missed calls
(unretrieved calls) and stores them in the Missed call log. You can
review the Missed call log for the time and date of the call, as
well as other information.
1. In standby mode, press
Menu
() Calls
Missed Calls
. A list of missed calls displays.
2. Highlight a call, then press
OPEN
to view the Name of the
caller (if in the Contacts list), the originating number, and
the time and date the call was received.
3. Press the Options soft key and select an option:
Save
: Save the number to your Contacts.
• Details
: (Calls from Contacts Only): Displays the entry for the calling
Contact.
Erase
: Erase the selected call from your Missed call log.
Lock/Unlock
: Locks the call to prevent deletion or allows deletion
of the call record.
Erase All
: Erase all calls from your Missed call log.
View Timer
: Displays the number of calls and/or the total time
spent on the Last Call, Outgoing Calls, Incoming Calls, Roaming
Calls, All Calls, Last Reset, and Lifetime Calls.
4. Press the Msgs soft key.
FPO
Call Functions 31
5. Select one of the following options:
Text Message
: Lets you send a text message to the selected
called number.
Picture Message
: Lets you send a picture message to the
selected called number.
All Calls
You can review all of the calls log entries (outgoing, incoming,
and missed calls) for the time and date of a call, as well as other
information.
1. In standby mode, press
Menu
() Calls
All Calls
. A list of all logged calls displays.
2. Highlight a call, then press
OPEN
to view further
information about the call.
3. Press the Options soft key and select one of the following
options:
Save
: Save the number to your Contacts.
• Details
: (Calls from Contacts Only): Displays the entry for the calling
Contact.
Erase
: Erase the selected call from your Calls log.
Lock/Unlock
: Locks the call to prevent deletion or allows deletion
of the call record.
Erase All
: Erase all calls from your Calls log.
View Timer
: Displays the number of calls and/or the total time
spent on the Last Call, Outgoing Calls, Incoming Calls, Roaming
Calls, All Calls, Last Reset, and Lifetime Calls.
4. Press the Msg soft key.
5. Select one of the following options:
Text Message
: Lets you send a text message to the selected
calling/called number.
Picture Message
: Lets you send a picture message to the
selected calling/called number.
Call Timer
View the duration of your last call, total calls, and calls made
during the life cycle of you phone using the Call Timer feature.
View the duration of your last call, total calls, and calls made
during the life cycle of you phone using the Call Timer feature.
Note:
Call Timer is not for billing purposes.
1. In standby mode, press
Menu
() Calls .
2. Select
Call Timer
and press . The following display:
Last Call
: View the duration of your last call.
Outgoing Calls
: View the duration of the total outgoing calls made
on your phone since the last erasure.
FPO
FPO
32
Incoming Calls
: View the duration of the total incoming calls
received on your phone since the last erasure.
Roaming Calls
: View the total calls duration on your phone while
roaming since the last erasure.
All Calls
: View the duration of the total call, incoming, outgoing,
and data calls made on your phone since the last erasure.
Last Reset
: View the time and date all timers were last reset.
Lifetime Calls
: View the duration of all calls since your phone was
activated.
3. Highlight the desired counter and press the Reset soft key
to reset a selected counter (except Last Reset and Lifetime
Calls).
– or –
Press the Reset All soft key to reset all counters except
Lifetime Calls.
4. Press to exit the Call Timer list.
Data Counter
1. In standby mode, press
Menu
() Calls .
2. Select
Data Counter
and press . The following
options display:
Transmit
: View the total amount of data transmitted by your phone
since the last reset.
Received
: View the total amount of data received by your phone
since the last reset.
Total
: View the total amount of data sent or received by your phone
since the last reset.
Last Reset
: View the time and date all timers were last reset.
Lifetime Data Counter
: View the total amount of data sent or
received by your phone since activation (Lifetime Data Counter
cannot be reset).
3. Highlight the desired counter and press the Reset soft key
to reset the counter (except Last Reset and Lifetime Data
Counter).
4. Press the Reset All soft key to reset all counters except
Lifetime Data Counter.
5. Press to exit the
Data Counter
list.
FPO
Call Functions 33
Making a Call Using Calls
1. In standby mode, press
Menu
() Calls
and
locate a call from
Outgoing Calls
,
Incoming Calls
,
Missed
Calls
,
All Calls
,
Call Timer
, and
Data Counter
.
– or –
In standby mode, press and use the
Left
or
Right
Navigation key to view call categories.
2. Highlight a call record, then press .
Creating or Updating Contacts Using Calls
1. In standby mode, press
Menu
() Calls and
locate a call record from
Outgoing Calls
,
Incoming Calls
,
Missed Calls
, or
All Calls
.
– or –
In standby mode, press and use the
Left
or
Right
Navigation key to view the call categories.
2. Highlight a call record, then press
Options
Save
Create New
or
Update Existing
and press .
3. Enter the contact information and press
Save
.
Deleting Call Records
1. In standby mode, press
Menu
() Calls and
locate a call record from
Outgoing Calls
,
Incoming Calls
,
Missed Calls
, or
All Calls
.
– or –
In standby mode, press and use the
Left
or
Right
Navigation key to view call categories.
2. Highlight a call record and press
Options
Erase
.
3. Press
Yes
at the “
Erase entry?
” prompt to erase the record.
Deleting All Call Records
1. In standby mode, press
Menu
() Calls and
Locate a call record from
Outgoing Calls
,
Incoming Calls
,
Missed Calls
, or
All Calls
.
– or –
In standby mode, press and use the
Left
or
Right
Navigation key to view the call categories.
2. Highlight a call record and press
Options
Erase All
.
3. Press
Yes
at the “
Erase all entries?
” prompt.
FPO
FPO
FPO
FPO
34
Viewing the Data Counter
1. In standby mode, press
Menu
() Calls .
2. Select
Data Counter
and press . The data counter
information displays.
3. Highlight a data counter category and press
Reset
to clear
the counter.
– or –
Press
Reset All
to clear all the data counters.
FPO
Entering Text 35
Section 4: Entering Text
This section outlines how to select the desired text entry mode
when entering characters using the phone keypad. This section
also describes how to use the T9 predictive text entry system to
reduce the number of key strokes needed to enter text.
Changing the Text Entry Mode
Text messages are made up of alphabetical characters, numbers,
and symbols. You can use the following text entry modes to
simplify text entry:
T9 Word
: Press each phone key only once to enter the letter of the
word that you are spelling. T9 WORD mode letter options are:
T9 word
: Enter all lower case letters
T9 Word
: Enter initial capital letters
T9 WORD
: Enter all upper case letters
ABC
: Enter letters by repeatedly pressing each phone key until the
desired character (as shown on the key) displays on the screen. ABC
mode letter options are:
abc
: Enter all lower case letters
Abc
: Enter initial capital letters
ABC
: Enter all upper case letters
123
:
Enter numbers by pressing the corresponding keys on the phone
keypad.
Symbols
: Using the phone keypad, enter a symbol into your message
by pressing the number above the symbol in the Symbols pop-up
window.
Emoticons
:
Use emoticons to enter smiley symbols into a text
field.
Add T9 Word
: Add English predictive text terms to your T9 dictionary.
The current text entry mode is indicated as the left soft key
option.To change the text entry mode while composing a text
message:
Repeatedly press and hold to toggle between text
entry modes,
Abc
,
123
, and
T9Word
.
Or, do the following:
Press the Left soft key highlight a text entry mode
press .
Using T9
Word Mode
T9® Word recognizes commonly used words for the numeric
sequence of key presses and inserts the word into your message.
T9 Word is much faster than the traditional method of text entry
(Abc) and requires only one key press per letter of the word that
you are spelling.
36
1. While composing a text message, press the Left soft key,
then select
T9Word
.
2. For practice, enter the word “
Samsung
” by pressing each
of the following keys once:
T9 Word recognizes that the most commonly used word for
the numeric sequence entered is “Samsung.”
If more than one word shares the same numeric sequence,
T9 Word displays the most commonly used words. Press
the Navigation key Up or Down to display other words, if
available.
Tip:
Press to enter a space. Press to enter a period.
These key functions apply to both T9 Word and Abc modes.
Using Abc Mode
1. While composing a text message, press the Left soft key,
then select
abc
,
Abc or ABC
.
2. In Abc mode, continue pressing a key until the letter you
want displays.
Example:
Press once for “
G
” and twice for “
H
”.
3. Pause briefly and the character inserts into your message.
4. Press to enter a space or press . to enter a
period.
Entering Numbers
Enter numbers into a text message while in 123 mode.
1. While composing a text message, press the Left soft key,
then select
123
.
2. Enter numbers while in 123 mode by pressing the key
labeled with the corresponding number to insert into your
message.
SAMSUNG
Entering Text 37
Entering Symbols
Use Symbols mode to enter common symbols into a text field,
such as “@” or “%”.
1. While composing a text message, press the Left soft key,
then select
Symbols
. The first of three symbol screens
displays on the screen.
2. Use the
Prev
and
Next
soft keys to page through the other
symbols.
3. Press the key that corresponds with the symbol
to enter.
Example:
Press for an exclamation point (
!
).
Entering Emoticons
Use Emoticons mode to enter smiley symbols into a text field.
1. While composing a text message, press the Left soft key,
then select
Emoticons
.
2. Use the
Prev
and
Next
soft keys to page through the other
symbols, if desired.
3. Press the key that corresponds with the emoticon
to enter.
38
Section 5: Understanding Your Contacts
This section details how you can manage your daily contacts by
storing their names and numbers in your Contacts list. You can
have your Contacts entries sorted by name.
Contacts
Up to 500 entries are stored in Contacts. Each entry can have up
to five associated phone numbers and one e-mail address. You
can enter a phone number with up to 32 digits, including
2-Sec
or
Wait
pauses (see “Manual Pause Calling” on page 22 for more
information). Associated names can contain up to 32 character.
You can assign the Speed Dial numbers of your choice for each
entry. You can also mark your Contacts list as Restricted to
prevent unauthorized viewing. (For more information, refer to
“Restriction” on page 89.)
Tip:
Speed Dial
One-Touch Dialing
,
Two-Touch Dialing
, and
Three-
Touch Dialing
allow you to call numbers stored in Contacts
faster. (For more information, refer to “Speed Dial” on
page 43.)
1. In standby mode, press
Menu
()
Contacts
.
2. Select one of the following options:
•Find
: Find a Contacts entry by name.
Add New Entry
: Add a number or e-mail address to your Contacts.
Speed Dial
: Assign a Contacts entry to a Speed Dial number. (For
more information, refer to
“Speed Dial”
on page 43.)
•Group
: Review, send messages to, add Contacts to, or rename four
out of your five groups. (For more information, refer to
“Contacts
Groups”
on page 43.)
•Memory Info
: Display used and available memory for Contacts
entries.
Finding a Contacts Entry
Shortcut Key Method
If you have stored a name entry in Contacts, Find allows you to
find it quickly by entering the first few letters of a Contact’s
name.
1. In standby mode, press the
Contacts
soft key.
The
Find
screen displays on the screen with the
Go To
field
highlighted, followed by the first few names in your
Contacts list.
Understanding Your Contacts 39
2. Enter the first few characters of a name as entered in
Contacts. For example, if you saved the name as “Amy
Smith”, begin the search by pressing (for “A”).
As you enter letters, the names of the closest matches
display.
3. When the desired entry displays on the screen, use the Up/
Down navigation keys to highlight the entry.
Press to dial the number associated with the name.
Press the
Edit
soft key to add or change information for this entry.
Press
View
( ) to display information about the entry.
Press the
Options
soft key. Select one of the following options:
New Contact
:
Add a new entry to Contacts.
Erase
:
Erase the name and associated information.
Send Txt Msg
:
Create and send a text message to the selected
Contact.
Send Pic Msg
:
Create and send a picture message to the selected
Contact.
Call
:
Dial the number associated with the name.
Send Name Card Via Bluetooth
:
Send selected Contacts to another
Bluetooth device.
Voice Method
If you have stored a name entry in Contacts, use the Voice
Method to find it quickly by speaking commands to dial phone
numbers, search and display a contact by name, or redial the last
phone number called.
For more information, refer to “Voice Commands” on page 24.
1. In standby mode, press and hold to launch Voice
Commands.
2. Say:
Call <Name or #>
and say the name or number of the person to
call, or say voicemail or last number.
•Contacts <Name>
to search and displays a contact by name to
call. Ex: say “Contacts Aaron”.
•Redial
to redial the last phone number called.
Quick Search Method
For information on enabling Quick Search, see “Quick Search” on
page 90.
1. In standby mode and with Quick Search enabled, press the
first few numeric keys that correspond to the letters of the
Contact’s name.
40
Example:
To search for “Aaron” you would enter
.
2. Press the Up navigation key. A list of Contact names that
begin with letters corresponding to the number keys you
pressed displays on the screen.
3. Highlight the searched for Contact.
Press to call the Contact.
Press
to view the Contact.
Adding a New Contacts Entry
You can use either of two methods to add an entirely new entry to
Contacts.
Dial Method
1. Using the keypad, enter the number you wish to add to
your Contacts.
2. Press the
Save
soft key.
3. Select one of the following options:
•Create New
: Lets you create a new Contacts entry.
Update Existing
: Lets you add the number you entered to an
existing Contacts entry.
4. Select
Create New
.
5. Select the number type that matches your new entry and
press .
6. Use the keypad to enter a name to associate with the
Contacts entry.
7. Press
Save
( ) to save the entry.
Menu Method
1. In standby mode, press
Menu
()
Contacts
Add New Entry
.
2. Enter the name of the new contact.
3. Press
Save
( ) to save the new entry.
Saving a Number After a Call
Once you finish a call, you can store the caller’s number to your
Contacts list.
Note:
If the call was incoming and Caller ID information was
unavailable, then the
Save
option is also unavailable.
1. Press to end your call. The call time, length of call,
phone number, and name of the party (if available)
displays.
2. Press
Save
. The Save screen displays the following
options:
•Create New
: Lets you create a new Contacts entry.
Understanding Your Contacts 41
Update Existing
: Updates information in an existing contact entry.
3. Select the desired option, then refer to the desired
procedure in this section.
Editing a Contacts Entry
1. In standby mode, press
Menu
()
Contacts
Find
.
2. Highlight the contact to change and press
Edit
().
3. Highlight the information to edit and press to delete
all the information, then enter the new information.
4. Press
Options
( ) to display the following:
Set Speed Dial
/
Remove speed dial
:
Assign/remove a speed dial
number. (For more information, refer to
“Speed Dial”
on page 43.)
Set as default
:
Enter a number to automatically dial for this contact or
speed dialing.
Wait
:
A hard pause (waits for input from you).
2-Sec Pause
:
A 2-second pause after which dialing resumes. (For
more information, refer to
“Add Pauses to Contacts Numbers”
on page 41.)
Select the desired option.
5. Press
SAVE
() w
hen you are finished changing the
Contacts entry.
Add Pauses to Contacts Numbers
Calls to automated systems such as banking services often
require a password or account number. Instead of manually
entering these numbers, you can store them in a Contacts entry
with the phone number and with special characters called
pauses, up to a maximum of 32 digits.
42
For more information, refer to “Pause Dial from Contacts” on
page 23.
2-Sec Pause:
Stops the calling sequence for two seconds, then sends
the remaining digits.
Wait:
Stops the calling sequence until the phone receives further
input.
Note:
You can enter multiple 2-Sec Pauses to extend the length of
a pause. For example, two consecutive 2-Sec Pauses cause
a total pause time of four seconds. Keep in mind that pauses
count as digits towards the 32-digit maximum.
To add pauses to a Contacts entry number, do the following:
1. Find the Contacts entry associated with the number you
want to include one or more pauses. (For more
information, refer to “Finding a Contacts Entry” on
page 38.)
2. Select and edit the desired number. (For more information,
refer to “Editing a Contacts Entry” on page 41.)
3. Press
Options
.
4. Select a pause option to add to the number sequence.
2-Sec Pause
: A 2-second pause after which dialing resumes.
•Wait
: A hard pause (waits for input).
5. Press to store the number to Contacts when you are
finished entering information.
Assigning a Ringtone to a Contacts Entry
When you assign a ringtone to a Contacts entry, the phone plays
the ringtone that you assigned to the entry when you receive a
call from that Contact instead of the ringtone currently assigned
to Voice Calls.
1. Find the Contacts entry you want to edit. (For more
information, refer to “Finding a Contacts Entry” on
page 38.)
2. Highlight the desired Contact, then press the
Edit
soft key.
The
Edit Contact
screen displays on the screen.
3. Highlight the
Ringtone
field, then press the
Set
soft key.
4. Highlight a Ringtone and press .
5. Press to save your changes.
Deleting a Contacts Entry
1. Find the Contacts entry you want to delete. (For more
information, refer to “Finding a Contacts Entry” on
page 38.)
2. Highlight the desired entry, press the
Options
soft key, then
select
Erase
. The phone prompts you to confirm the
erasure.
Understanding Your Contacts 43
3. To confirm erasure of the selected Contact, press the
Yes
soft key. To retain the Contact, press the
No
soft key.
Speed Dial
Speed Dials are 1-, 2- or 3-digit shortcuts you assign to contacts,
to allow you to quickly call the contact.
For more information on creating and removing Speed Dial
numbers, see “Making a Call using Speed Dial” on page 23.
Note:
Some Speed Dials are reserved by default, and cannot be
assigned: Speed Dial 1 is reserved for Voicemail. Speed Dial
211 is reserved for information about health and human
services, 311 for non-emergency municipal services; 411
for directory assistance; 611 for customer service access;
and 911 for emergencies.
Assigning a Speed Dial Location
To assign a Speed Call number to a new Contacts entry number,
do the following:
1. In standby mode, press
Menu
()
Contacts
Speed Dial
.
2. Highlight an unassigned speed dial location, or enter the
speed dial digits into the
Go To
field, then press
Set
.
3. At the
Set Speed Dial
screen, highlight a contact, or enter
the first few characters into the
Go To
field.
4. At the
Set speed dial to contact?
prompt, press
Yes
and
press
OK
.
Removing a Speed Dial Location
1. In standby mode, press
Menu
()
Contacts
Speed Dial
.
2. Highlight an unassigned speed dial location, or enter the
speed dial digits into the
Go To
field, then press
Set
.
3. Press
Remove
.
4. Press
Yes
at the
Remove speed dial?
prompt.
Speed dial removed
” displays.
Contacts Groups
Contact Groups let you easily send messages to multiple,
selected Contacts. You can also use Groups to find Contact
entries and to add/remove Contacts names in a Group or to
create or rename a Group.
Viewing Groups
1. In standby mode, press
Menu
()
Contacts
Group
.
2. Available groups display. These groups are available by
default:
No Groups
•Business
44
• Colleague
• Family
• Friends
3. Highlight a group, then press
VIEW
to display a list of group
members.
Add a New Group
1. In standby mode, press
Menu
()
Contacts
Group
.
2. Press
New
, enter a name for the group, then press
Save
.
Add Contacts Entry to a Group
Using Group Add Option
The Add option lets you add one or more existing Contacts to a
Group.
1. Highlight an existing group and view it.
2. Press
Options
Add
, and press
Mark
next to each contact
to add to this group, then press
Done
.
3. Press the
Options
soft key.
4. Select one of the following options:
Send Txt Msg
: Send a text message to the selected Group.
Send Pic Msg
: Send a picture message to the selected Group.
Remove Contacts Entry from a Group
1. In standby mode, press
Menu
()
Contacts
Group
.
2. Highlight the Group (other than No Group) from which you
want to remove a Contact, then press
VIEW
( ).
A list of the Contacts assigned to the selected Group
displays on the screen.
3. Highlight the Contact to remove and press
Erase
.
4. Press
Yes
at the
Erase contact from group?
prompt.
Rename a Group
The Rename option lets you change the name any of the Groups,
except No Group.
1. In standby mode, press
Menu
()
Contacts
Group
.
2. Highlight the Group name other than No Group to rename,
then press
Options
Rename
.
3. Enter changes to the group name using the keypad. (For
more information, refer to “Entering Text” on page 35.)
4. Press
Save
( ) to confirm the name change.
5. Once you complete entering the new Group name, press
SAVE
( ). “
Group Renamed
” displays on the screen
followed by the
Group List
and the new Group.
Understanding Your Contacts 45
Erase a Group
The
Erase
option deletes a Group and allows you to reassign the
Contacts.
1. In standby mode, press
Menu
()
Contacts
Group
.
2. Highlight the Group to delete, press the
Options
soft key,
then select
Erase
.
3. Press
Yes
to confirm group erasure.
Memory Info
The
Memory Info
menu option lets you view the amount of
memory used to store Contacts entries, as well as the memory
remaining.
In standby mode, press
Menu
()
Contacts
Memory Info
.
The
Memory Info Contacts
screen displays the
Total
amount
of memory in your phone, the amount of memory
Used
to
store Contacts entries, and the remaining (
Free
) memory.
46
Section 6: Messaging
This section explains how to send or receive different types of
messages. This section also describes the features and
functionality associated with messaging.
Types of Messages
Your phone is able to send and receive Text messages to
compatible phones and devices. You can enter text messages up
to 160 characters in length.
Note:
Available memory is shared between all messages. You can
store up to 100 messages. However, the exact number is
dependent upon message length.
Creating and Sending Text Messages
1. In standby mode, press
Messages
Send Message
Text Message
. The
Create Txt Msg
screen displays the
To:
list.
– or –
Menu
() Messages Send Message
Text Message.
2. Enter the phone number or e-mail address of the recipient,
or press the
Add
soft key and select Contacts, Groups, or
Recent Calls to select a recipient or group, then press
.
3. Enter the text content of your message.
4. Press the
Options
soft key to select one of the following
options:
Edit Send To
: Edit the recipient’s number or e-mail address.
Add Quick Text
: Insert pre-composed text in your message.
Save As Draft
: Save the message to your Draft folder.
Priority Level
: Choose
High
or
Normal
.
Validity Period
: Enter the Date and time when this message is no
longer valid.
Deferred Delivery
: Set the date and time to deliver this message.
Delivery Ack
: Choose
On
or
Off
: Requests confirmation when your
message is received.
Messaging 47
Add To Contacts
: Save the recipient’s number or e-mail address as
a Contacts list entry.
Cancel Message
: Cancel the message, with the option to save it in
the Drafts folder.
5. Press
Send
( ) once you are finished entering your
message.
Creating and Sending Picture Messages
You can send picture messages to recipients with compatible
phones or devices. You can even accompany a Picture message
with a voice memo or preloaded sound.
Tip:
You can send a Picture message to up to ten recipients. Enter
each recipient’s address or phone number in a separate
Send
to
field of the Picture message composer.
1. In standby mode, press
Messages
Send Message
Picture Message
.
– or –
Menu
() Messages Send Message
Picture Message.
2. Enter the phone number or e-mail address of the recipient,
or press the
Add
soft key and select Contacts, Groups,
Recent Calls, or OnlineAlbum to select a recipient or group,
then press .
3. Press the Navigation key right to add
CC
or
BCC
recipients.
4. Enter a subject for the Picture message in the
Subject
field.
5. Press the Navigation key down to highlight the
Text
field,
then enter the message text.
6. Press the Navigation key down until the
field
highlights, then press
.
7. Highlight a picture and press to add the highlighted
picture to your message.
Tip:
Press the
View
soft key to expand the highlighted picture to full-
screen size.
– or –
Press
Camera
to take a picture, then center the subject in
the viewfinder and press
Take
to take the picture.
Press
Send
( ) to add the picture to the message.
48
8. Highlight the Sound field, press
Sound
and select a sound
file, then press
OK
.
9. Press Options to select one of these options:
•Preview
: View the picture as the recipient sees it.
Add Quick Text
: Insert pre-composed text in your message.
Save As Draft
: Save the message to your Draft folder.
Priority Level
: Choose
High
,
Normal
or
Low
.
•Validity Period
: Enter the
Date
and
Time
when this message is not
longer valid.
Deferred Delivery
: Set the date and time to deliver this message.
Delivery Ack
: Requests confirmation when your message is
received. Choose
On
or
Off
Cancel Message
: Cancel the message, with the option to save it in
the Drafts folder.
Remove Pic
: Remove the picture from your message.
Remove Sound
: Remove the sound file from your message.
Add slide
: Add a slide to the message.
Add To Contacts
: Save the recipient’s number or e-mail address as
a Contacts list entry.
10. Press
Send
to send the message.
Creating and Sending Picture Messages from
Camera Mode
1. In standby mode, press and hold the
Camera
key ( ) to display the viewfinder.
2. Center the subject in the viewfinder, then press
Take
( ) to take a picture.
3. Press
Send
( ) to save the picture and create a
picture message.
4. Enter the phone number or e-mail address of the recipient,
or press the
Add
soft key and select Contacts, Groups,
Recent Calls, or OnlineAlbum to select a recipient or group,
then press .
5. Press the Navigation key right to add
CC
or
BCC
recipients.
6. Enter a subject for the Picture message in the
Subject
field.
7. Press the Navigation key down to highlight the
Text
field,
then enter the message text.
8. Press the Navigation key down to highlight the Sound
field, if you wish to insert a sound into your Picture
message.
Press
Sound
and select a sound file, then press
OK
.
Messaging 49
9. Press Options to select one of these options:
•Preview
: View the picture as the recipient sees it.
Add Quick Text
: Insert pre-composed text in your message.
•Save As Draft
: Save the message to your Draft folder.
Priority Level
: Choose
High
,
Normal
or
Low
.
Validity Period
: Enter the
Date
and
Time
when this message is not
longer valid.
Deferred Delivery
: Set the date and time to deliver this message.
Delivery Ack
: Requests confirmation when your message is
received. Choose
On
or
Off
Cancel Message
: Cancel the message, with the option to save it in
the Drafts folder.
Remove Pic
: Remove the picture from your message.
Remove Sound
: Remove the sound file from your message.
Add slide
: Add a slide to the message.
Add To Contacts
: Save the recipient’s number or e-mail address as
a Contacts list entry.
10. Press
Send
to send the message.
Receiving Messages
When you receive a message, you can choose to:
View Now
: Open the message for viewing.
View Later
: Dismiss the alert, and save the message in the Messages
folders.
Viewing a Text Message
1. After you select the
View Now
option, the new text
message displays.
2. If you chose view later and opened the Inbox, press
Options and select one of the following:
•Reply
: Replies to the sender.
•Reply With Copy
: Compose and send a reply message to the
originator of the received message and include a copy of the
original message.
•Forward
: Send a copy of this message to another recipient.
•Lock
/
Unlock
: Block/permit erasure of the highlighted message.
Add To Contacts
: Save the senders number to your Contacts.
Erase Inbox
: Erases all the messages in the Inbox.
Message Info
: Displays message delivery status, addressee, size,
and more.
3. If you selected View Now, while viewing your message
press the
Options
soft key and select one of these options:
50
View Last Message
: Displays the last message sent from this
number.
Add To Contacts
: Save the sender’s number to your Contacts.
Note:
For more information on received message options, see
“Inbox” on page 50.
Viewing a Picture Message
1. After you select the
View Now
option, “
Connecting
displays on the screen followed by “
Receiving Message
and a progress bar indicates the message is downloading
to the phone.
2. After the Picture message downloads, an alert sounds, and
the new Picture message displays. If the message includes
a sound file, the phone begins playing it.
3. While viewing your message press the
Options
soft key.
4. Select one of the following options:
•Play Again
: Play the sound file included in the picture message
again.
•Forward
: Send a copy of this message to another recipient.
•Save Pic
: Save the picture included in this message to the My
Images folder.
Save Sound
: Save the sound file included in this message to the
My Sounds folder.
•Lock
/
Unlock
: Block/permit erasure of the highlighted message.
Add To Contacts
: Save the sender’s number to your Contacts.
•Message Info
: Displays message delivery status, addressee, size,
and more.
•Extract
: Calls the sender of the received message.
Message Boxes
Your phone stores messages in any one of five message boxes.
The subsections that follow describe each message box in detail.
Inbox
Received messages of all types (except Voicemail and
Emergency Alerts) are stored in the Inbox.
Messaging 51
1. In standby mode, press
Messages
then select
Inbox
. A
list of incoming messages displays.
– or –
Menu
() Messages Inbox.
2. Select the message to view. The contents of the
highlighted message display.
3. While viewing your message press the
Options
soft key.
Options depend on the type of message. For more
information see “Viewing a Text Message” on page 49 or
see “Viewing a Picture Message” on page 50.
Managing Inbox Messages
1. In standby mode, press
Messages
, then select
Inbox
. A
list of incoming messages displays on the screen.
– or –
Menu
() Messages Inbox.
2. Highlight a message in the list.
3. Press
Erase
to remove the highlighted message from the
Inbox.
4. Press the
Options
soft key to view options. For more
information see “Viewing a Text Message” on page 49 or
see “Viewing a Picture Message” on page 50.
Outbox
Your phone stores messages in the Outbox until they send and
then clears them from the Outbox. There are actions to take if the
messsage for some reason fails.
Review Messages in the Outbox
1. In standby mode, press
Messages
, then select
Outbox
.
Your list of sent messages display.
– or –
Menu
() Messages Outbox.
2. Press
OPEN
( ) to view the message then press:
•Erase
to erase this message.
• RESEND
( ) to resend this message.
3. While viewing your message, press the
Options
soft key.
The options differ depending on the type of message.
4. Manage your messages by selecting one of the following:
•Forward
: Forwards the message to another contact.
• Resend
: Resends the message to the same recipient.
•Lock
/
Unlock
: Locks to protect from deletion or Unlocks to allow
deletion of the message.
Add To Contacts
: Save the recipient’s number to your Contacts.
•Erase Outbox
: Erases all the messages in the Outbox.
52
•Message Info
: Displays message delivery status, addressee, size,
and more.
Messages and Lock Mode
Your phone can still receive messages while in Lock Mode. The
Sender, time and date of the message display, but you cannot
access the message until you enter the lock code.
Drafts Box
Messages in the Draft Box are those that have been composed
but never sent. You can return to the Draft Box at any time to
view, edit, or send a draft message.
Create a Draft Message
1. In standby mode, press
Messages
Send Message
Text Message
or
Picture Message
.
The
Create Txt
or
Picture Msg
screen displays.
– or –
Menu
() Messages
Send Message
Text Message or Picture Message.
2. If you selected
Text Message
in Step 1, perform steps 2 – 4
(see “Creating and Sending Text Messages” on page 46.)
3. If you selected
Picture Message
in Step 1, perform steps
2 – 9 (see “Creating and Sending Picture Messages” on
page 47).
4. Press
Options
Save As Draft
. The message saves to the
Drafts folder.
View and Edit Draft Text Messages
1. In standby mode, press
Messages
, then select
Drafts
.
A list of any saved draft messages displays.
– or –
Menu
() Messages
Drafts
.
2. Highlight a draft message to view or edit, then press
Edit
().
3. Use the Down Navigation key to highlight the field to edit
and enter the new information.
4. Press
Options
to select one of these options:
Edit Send To
: Change, add, or remove recipients from this
message.
Add Quick Text
: Insert pre-composed text into your message text.
Save As Draft
: Save the message to your Drafts box.
Priority Level
: Choose
High
or
Normal
.
Validity Period
: Enter the
Date
and
Time
when this message is
not longer valid.
Deferred Delivery
: Set the date and time to deliver this message.
Delivery Ack
: Choose
On
or
Off
: Requests confirmation when your
message is received.
Messaging 53
Add To Contacts
: Save the recipient’s number or e-mail address to
your Contacts.
Cancel Message
: Cancel the message, with the option to save it in
the Drafts folder.
5. Press
Send
( ) to send the message.
View and Edit Draft Picture Messages
1. In standby mode, press
Messages
, then select
Drafts
.
A list of draft messages displays.
– or –
Menu
() Messages
Drafts
.
2. Highlight a picture message view or edit, then press
Edit
().
3. Enter the phone number or e-mail address of the recipient,
or press the
Add
soft key and select Contacts, Groups,
Recent Calls, or OnlineAlbum to select a recipient or group,
then press .
4. Press the Navigation key right to add
CC
or
BCC
recipients.
5. Use the Down Navigation key to highlight the field to edit
and enter the new information.
6. Press
Options
and select one of the following:
•Preview
: Displays a preview of the draft message.
Add Quick Text
: Insert pre-composed text into your message text.
•Save As Draft
: Save the message to your Drafts box.
Priority Level
: Choose
High
or
Normal
, or
Low
.
Validity Period
: Enter the
Date
and
Time
when this message is
not longer valid.
•Deferred Delivery
: Set the date and time to deliver this message.
Delivery Ack
: Choose
On
or
Off
: Requests confirmation when your
message is received.
Cancel Message
: Cancel the message, with the option to save it in
the Drafts folder.
Remove Pic
: Remove the picture from this message.
Remove Sound
: Remove the selected sound from this message.
Add Slide
: Add a blank slide to this message.
Add To Contacts
: Save the recipient’s number or e-mail address to
your Contacts.
Managing Draft Messages
1. In standby mode, press
Messages
, then select
Drafts
.
A list of any draft messages that you’ve composed displays
on the screen.
– or –
Menu
() Messages
Drafts
.
2. Highlight a message and press the
Erase
soft key to
remove the highlighted message from the Drafts box.
54
3. Press the
Yes
soft key to erase this draft message.
– or –
Press the
No
soft key to keep this draft message in the
Drafts box.
4. Press
Edit
to edit the draft message fields or content.
5. Press the
Options
soft key and select one of the following:
•Send
: Send the highlighted message to the original recipient, if the
recipient’s number and/or e-mail address is included with the draft
message.
•Lock
/
Unlock
: Block/permit erasure of the highlighted message.
Add To Contacts
: Save the recipient’s number and/or e-mail
address to your Contacts.
•Save Quick Text
: Save the message text as Quick Text for insertion
into other messages.
•Erase Drafts
: Delete all unlocked draft messages.
CMAS Messages
This device is designed to receive wireless emergency alerts
from the Commercial Mobile Alerting System ("CMAS"; which
may also be known as the Personal Localized Alerting Network
("PLAN")). If your wireless provider has chosen to participate in
CMAS/PLAN, alerts are available while in the provider's coverage
area. If you travel outside your provider's coverage area, wireless
emergency alerts may not be available.
For more information, please contact US Cellular Customer
Service.
Emergency Alerts allows customers to receive geographically
targeted messages. Alert messages are provided by the US
Department of Homeland Security and will alert customers of
imminent threats to their safety within their area. There is no
charge for receiving an Emergency Alert message.
There are three types of Emergency Alerts:
Alerts issued by the President
Alerts involving extreme or severe threats to safety of life and property
AMBER Alerts (missing child alert)
Viewing CMAS Messages
1. In standby mode, press
Messages
, then select
CMAS
.
2. Highlight a message and press
View
to read the
message.
Messaging 55
Disabling CMAS Messages
Customers may choose not to receive Imminent Threat and
AMBER Alerts. Alerts issued by the President can not be disabled.
To disable Imminent Threat Alerts (Extreme and Severe) and
AMBER Alerts, follow these instructions:
1. In standby mode, press
Messages
, then select
Msg
Settings
CMAS Alerts
Receive Alerts
.
2. Highlight the alert to disable and press
Unmark
to
disable the alert.
3. Press
Done
to save the settings.
Voicemail
New messages in your voice mailbox are indicated by the
voicemail icon ( ) and are logged in the Voicemail box of the
Messages menu. Open the Voicemail box to view the Callback #
(if available), Urgency, and other details of the Voicemail
message.
Listen to Voicemail
Voicemail messages are listed in this box. Highlight the name or
number and press OK to listen to the voicemail message.
1. In standby mode, press
Messages
, then select
Voicemail
. The
Voicemail
screen displays the number of
new voicemail messages received and the date and time
the latest message was received.
2. Highlight a message and press or to call
your voice mailbox and listen to the message.
Tip:
You can also press and hold to dial your voice mailbox.
3. If “
No messages
” displays if there are no new voicemail
messages.
Erase Messages
Using Erase Messages, you can erase all of the messages in
each of your boxes from one convenient location.
Note:
This function erases all messages in a selected box. To
delete a single message, open the box from the
Messages
menu, highlight a message, open the message if you want,
then press
Erase
to delete it.
1. In standby mode, press
Messages
, then select
Erase
Messages
.
2. Select one of the following options:
• Inbox
: Deletes all unlocked messages stored in the Inbox.
• Outbox
: Deletes all unlocked messages stored in the Outbox.
• Drafts
: Deletes all unlocked messages stored in the Drafts box.
56
•CMAS
: Deletes all CMAS/Emergency messages stored in the
CMAS box.
All Messages
: Deletes all unlocked messages stored in all of the
message boxes, except Voicemail.
3. Select the messages category to delete and press .
You are prompted to confirm the erasure of all messages in
the selected box.
4. Press the
Yes
soft key to deletes all messages in this box.
– or –
5. Press
No
to cancel deletion.
Message Settings
Use the
Msg Settings
sub-menus to define general settings and
text message settings.
General Message Settings
1. In standby mode, press
Messages
, then press
Msg
Settings
General
.
2. Select one of the following options:
•Auto Save
: Choose whether your messages are saved
automatically when you exit them. Selections are:
On
,
Off
, or
Prompt
.
Auto Erase
: Choose whether to erase the oldest read message
automatically without prompting.
•Quick Text
: Edit your pre-composed messages to insert into a new
message.
Voicemail #
: Edit or view your Voicemail number.
Entry Mode
: Choose the default method for entering text into
messages. Selections are:
T9 word
,
T9Word
,
T9WORD
,
abc
,
Abc
,
ABC
, or
123
.
Callback #
: Choose whether to include a callback phone number
with your outgoing messages. Enter the number to include.
• Signature
: Choose whether to include a text signature in outgoing
message text, and enter the signature text.
• Reminder
: Select whether and how often you hear a reminder tone
or vibration when you receive a message. Selections are:
Once
,
Every 2 Minutes
,
Every 15 Minutes
, or
Off
.
Entering and Editing Quick Text
1. In standby mode, press
Messages
, then select
Msg
Settings
General
Quick Text
. The
Quick Text
sub-menu
displays on the screen.
2.
Press
New
to create a new Quick Text.
Messaging 57
Tip:
You can also create new Quick Text by viewing an Outbox
message or highlighting a Drafts message and using the
Save
Quick Text
option in the
Options
menu. (For more information,
refer to “Review Messages in the Outbox” on page 51.)
3. Enter/change the text content of your Quick Text and press
. The Quick Text menu displays with the new Quick
Text highlighted.
Edit Quick Text:
1. Highlight a Quick Text to change, then press
Edit
().
Note:
You cannot change or erase pre-loaded Quick Texts.
2. Enter/change the Quick Text content.
Erase Quick Text:
1. Highlight a Quick Text to erase, then press
Erase
. A prompt
displays for confirmation of the erasure.
2. Press
Yes
to erase the highlighted Quick Text.
– or –
3. Press
No
to cancel.
Text Message Settings
In standby mode, press
Messages
, then select
Msg
Settings
Text Message
. Select one of the following
options:
•Auto View
: Choose whether your messages are automatically
viewed or prompted to view them. Selections are:
On
, or
Off
.
• Signature
: Choose whether to include a text signature in outgoing
message text, and enter the signature text.
•Auto Scroll
: Choose whether your messages automatically scroll
while viewing. Selections are:
On
, and
Off
.
Message View
: Choose whether your message displays normally,
or as a Chat message. Selections are:
Chat
, or
Normal
.
Picture Message Settings
In standby mode, press
Messages
, then select
Msg
Settings
Picture Message
. Select one of the following
options:
Auto Receive
: With Auto Receive
On
, Picture messages
automatically download and display as they are received. With Auto
Receive
Off
, you are prompted to download Picture messages.
• Signature
: Determine if you want a signature attached to the
Picture message. None does not attach a signature; otherwise,
select Custom and create a custom signature to attach.
58
Emergency Alerts Settings
In standby mode, press
Messages
, then select
Msg
Settings
CMAS Alerts
. Select one of the following
options:
Receive Alerts
: Select the types of emergency alerts to receive.
Selections are:
Extreme Alert
,
Severe Alert
, or
AMBER Alert
. All
are selected as a default.
Alert Reminder
: Select the amount of time to issue an Alert
reminder until you view the message. Selections are:
Once
,
Every
2 Minutes
,
Every 15 MInutes
, or
Off
.
•Alert Vibrate
: Choose whether the phone vibrates the phone when
an alert is received. Selections are:
On
, or
Off
.
Alert Tone
: Choose whether the phone plays a tone when an alert
is received. Selections are:
On
, or
Off
.
Multimedia 59
Section 7: Multimedia
This section outlines your phone’s multimedia functions and key
features associated with multimedia.
Multimedia
In standby mode, press
Menu
()
Multimedia
. The following sub-menus display:
•Camera
: Lets you launch and set up your phone’s camera
•My Images
: Lets you choose the pictures that display on the
phone’s screen or in picture messages.
My Ringtones
: Lets you assign ringtones for Ringtone (calls),
Contact ID, and Alert Tone.
•Music Player
: Launches the Music player so you can listen to
songs.
Tip:
To launch the Multimedia menu using a voice command: Press
and hold until the phone prompts, “
Say a command.
Say “
Go to Multimedia
” into the microphone.
Camera
Use your SCH-R270 to take full color digital pictures, display
them on your phone’s vivid color display, and instantly share
them with family and friends. It’s fun, and as easy to use as a
traditional point-and-click camera. This section explains how you
can:
Take pictures with your phone’s built-in digital camera.
Send your pictures to others in Picture messages.
Set the options associated with the camera that help you take crisp,
clear pictures.
Taking Pictures
Taking pictures with the built-in camera is as simple as launching
the camera, choosing a subject, pointing the lens (located on the
front of your phone’s flip, near the hinge), and pressing a button.
1. In standby mode, press and hold the
Camera
key ( )
until the view finder displays.
– or –
Press
Menu
( ), then select
Multimedia
Camera
.
60
2. Using the display as a viewfinder, point the camera lens at
your subject then press
Take
( ) or press the
Camera
key
.
3. Press the
Save
soft key or press the
Camera key
to save the picture to memory.
– or –
Press the
Cancel
soft key or the
Clear
key to erase
the photo.
Tip:
You can change a number of the camera’s settings to suit
particular uses for your pictures. See “Camera Options” on
page 60 for more information.
Camera Options
The Camera Options let you adjust default camera settings to suit
available lighting, the subject of the photo, or the purpose of the
photo, for the current camera session. When you exit the camera,
Shot Type and Self Timer revert to their default values, other
options or settings are maintained.
To access Camera Options, do the following:
1. In camera mode, press Options. The Camera Options
menu displays the following:
Shot Type
: Takes a Single Shot, Series Shot, Mosaic
Shot, or Frame Shot (adds a frame to the photo).
Resolution
: Changes the clarity (in pixels) and size
(in bytes) of pictures. Resolutions: 960x1280,
480x640, or 240x320.
Night Shot
: When set to
On
, takes pictures in low
light conditions.
Self Timer
: Delays taking a picture from 2, 5, or 10
seconds.
Quality
: Selects how much to compress this photo.
Selections are: SuperFine, Fine, or Normal.
White Balance
: Adjusts picture quality according to
available light. Selections are: Auto, Sunny,
Cloudy, Tungsten, and Florescent.
Color Effect
: Changes the color look of pictures.
Choose from six available settings: Normal,
Black&White, Sepia, Negative, Green, and Aqua.
Multimedia 61
My Images
My Images lets you manage the picture that display on the
phone’s screen while in standby mode (Wallpaper) and as picture
IDs for your contacts.
1. In standby mode, press
Menu
()
Multimedia
My Images
. A matrix of thumbnail
images of your pictures displays on the screen.
2. Highlight a picture, then press
View
to expand the
highlighted picture to fill the screen.
3. Press the
Options
soft key and press to select the
desired option:
•Send
: Lets you send the selected image to a specified recipient in a
Picture message or Via Bluetooth.
Online Album
: Send a copy of the highlighted picture to your
Album on US Cellular’s server (using a Picture message).
•Set As
: Lets you assign the selected picture as the
Main
Wallpaper
, as the
Picture ID
for a Contact, or as the
Front
Wallpaper
.
•Erase
: Erases one or more selected pictures.
•Move
: Moves images from your phone to your optional memory
card, or vice versa.
•Copy
: Copies images from your phone to your optional memory
card, or vice versa.
•Rename
: Renames the picture.
•Lock
/
Unlock
: Allows or prevents picture deletion.
•Slide Show
: Displays images in a slide show format.
•Image Info
: Displays information about the picture, such as the
Name
, creation
Date
and
Time
,
Resolution
, and the data
Size
.
4. Press to return to the previous menu.
5. Press to return to standby mode.
Settings
: Set the memory path, Auto save, Icon
display, Shutter sound and Reset settings.
Memory
: Saves photos to the Phone or Card.
Auto Save
: Set to On to automatically save
pictures to the Gallery.
Icon Display
: Displays icon in the view finder.
Choose from Display All, Guidelines, or No Icons
Shutter Sound
: Choose a sound to play when the
photo is taken. Choose from Off, Shutter, OK, or
Ding Dong.
Reset Settings
: Returns the camera to its default
settings.
62
My Ringtones
My Ringtones assigns ringtones (preloaded and downloaded) as
a Ringtone, Contact ID, or as an Alert Tone.
1. In standby mode, press
Menu
()
Multimedia
My Ringtones
to display a list of
ringtones on the screen.
2. Highlight a ringtone and press:
to
Play
the ringtone.
•Set As
soft key to assign the highlighted ringtone. Press to
select the highlighted option.
Ringtone
: Lets you assign the selected ringtone to incoming voice
calls.
Contact ID
: Lets you assign the selected ringtone as the distinctive
ringer for a Contact.
Alert Tone
: Lets you assign the selected ringtone to
All Msg
,
Text Msg
,
Picture Msg
, or
Voicemail Msg
.
3. When using a downloaded ringtone, press the Options soft
key to display:
Erase
: Erases the selected file.
Rename
: Lets you rename the selected file.
Ringtone Info
: Displays information about the selected file, such
as the file name, the file type, and the data size.
Send Via Bluetooth
: Shares a selected ringtone to another
Bluetooth enabled device.
Send Pic Msg
: Attaches the selected ringtone and sends it as a
picture message.
4. Press to return to the previous menu.
5. Press to return to standby mode.
Record New Voice Memo
You can use your phone to record voice memos for later
playback. You can also record the caller on the other end of the
line during a phone conversation.
Note:
The maximum length for a single voice memo is 60 seconds.
Record a Voice Memo
1. In standby mode, press
Menu
()
Multimedia
My Ringtones Record New.
2. Press ( ), then start recording the sound. As it is
recording the phone displays a countdown timer that
displays the seconds remaining for the recording.
Press the
Pause
soft key to pause the memo.
Select
Resume
to continue recording when a memo is paused.
3. Press when finished recording. The new recording
automatically saves.
Multimedia 63
Review Voice Memos
If you’ve saved any voice memos, you can listen to them
anytime.
1. In standby mode, press
Menu
()
Multimedia
My Ringtones. A list of sound files
displays.
2. Use the navigation keys to highlight the voice memo
to play.
3. Press one of the following:
•Play
to play the voice memo.
Press
to stop the memo.
Erase a Voice Memo
1. In standby mode, press
Menu
()
Multimedia
My Ringtones. A list of sound files
displays.
2. Use the Navigation keys to highlight the voice memo
to erase.
3. Press Options
Erase
.
4. Press
Yes
at the “Erase Ringtone?” prompt to erase the
selected ringtone or press No to cancel.
Music Player
Music Player lets you play MP3 and unprotected AAC, AAC+,
WMA music files, loaded onto an optional microSD™ or
microSDHC™ Memory Card using a personal computer.
In standby mode, press
Menu
()
Multimedia
Music Player.
Launching the Music Library Menu
1. In standby mode, press
Menu
()
Multimedia
Music Player.
2. Touch
Library
.
3. Select the desired option and press
OPEN
().
•Now Playing
: Music Player mode only: Indicates number of music
files currently playing. Select this option (or press ) to
return to the Music Player screen.
•All
: Lists all music files on the Memory Card.
•Artists
: Lists artist names for music files on the Memory Card.
•Albums
: Lists Albums by name that reside on the Memory Card.
•Genres
: List all the songs of a particular type on the Memory Card.
Recently Added
: Lists all the recently added songs.
• Playlists
: Lists any playlists you have saved and lets you create,
save, and manage playlists.
64
4. Highlight a music file (except Now Playing), then:
Press
Play
to play the highlighted music file.
Press
Mark
to mark a song to play, erase, or add to a playlist.
Press
Options
and select one of the following:
Mark all
: Marks all the songs displayed to play, erase, or add to a
playlist.
Erase
: Erases the marked songs.
Add to Playlist
: Adds a marked music file to an existing playlist.
Song Info
: Lists the Title, Artist, Album, Genre, File Name, Encoding
Format, Bitrate, File size, and Date.
Downloading Music Files from the PC
You can transfer music from your PC onto a memory card
inserted into your phone.
1. Install a microSD™ or microSDHC™ Memory Card into
your phone.
2. Power on the phone.
3. Connect the USB end of the USB Data Cable to the
power-accessory connector on your phone.
4. Set the PC Connection setting to
USB Mass Storage
. For
more information, refer to “PC Connection” on page 91.
5. Connect the USB end of the USB Data Cable to a matching
connector on your personal computer. A new “
Removable
Disk
” window opens on your computer screen.
6. Select the Open folder to view files options. A new
Windows Explorer window opens on your computer
screen.
7. Drag or download music (MP3) files into the “
My_Music
folder.
Tip:
You can also insert the Memory Card into a compatible card
reader. Card readers vary, so follow the installation
instructions included with your card reader and personal
computer.
Multimedia 65
Playing Music
1. In standby mode, press
Menu
()
Multimedia
Music Player.
2. Select the desired option and press
OPEN
().
3. Highlight a music file and press
Play
.
Music Player Controls
•Volume Key
Press Up to increase volume, or Down to decrease the volume while
playing music.
Navigation Key
Press
to pause/resume playing a music file.
Press the
Up
Navigation key to display the Now Playing screen and a
list of the selected songs.
Press the
Down
Navigation key to stop playing a song.
Press the
Left
Navigation key to go backward to the previous song in
the list.
Press the
Right
Navigation key to advance to the next song in the list.
•Library
: Returns to the Library screen.
• Options
: Displays the following options:
Go to Home Screen
: Displays the Home screen with music playing in
the background.
Play Mode
: Select Normal, Shuffle, Repeat One, or Repeat All.
Add to Playlist
: Add the playing song to the current playlist.
Remove From List
: Removes the playing song from the current
playlist.
Visual Supplements
: Use the Left and Right Navigation keys to select
a view. Selections are: Simple View, Equalizer, Lyrics, or Album Art.
Memory Usage
: Displays the Used, Free, and available Card Memory.
Song Info
: Lists the Title, Artist, Album, Genre, File Name, Encoding
Format, Bitrate, File size, and Date.
Creating a Playlist
1. In standby mode, press
Menu
()
Multimedia
Music Player.
2. Press
Library
Playlists
and press
OPEN
().
3. Press
Add
and using the keypad, enter a name for the new
playlist.
4. Press to accept the name for the playlist.
5. Press
Mark
( ) next to each song to include in this
playlist then press
Done
.
66
6. The new playlist displays on the Playlists screen with the
newly marked songs added.
Removing Songs from a Playlist
1. In standby mode, press
Menu
()
Multimedia
Music Player.
2. Press
Library
Playlists
and press
OPEN
().
3. Highlight the Playlist that contains the music to remove
and press
View
().
4. Press
Mark
( ) next to each song to remove from this
playlist then press
Options
Remove
. The selected songs
are removed from the playlist.
Renaming a Playlist
1. In standby mode, press
Menu
()
Multimedia
Music Player.
2. Press
Library
Playlists
and press
OPEN
().
3. Highlight the playlist to rename and press
Options
Rename Playlist
.
4. Press to backspace and erase the current playlist
name, then enter a new playlist name using the keypad.
5. Press to save.
Erasing a Playlist
1. In standby mode, press
Menu
()
Multimedia
Music Player.
2. Press
Library
Playlists
and press
OPEN
().
3. Highlight the playlist to erase and press
Options
Erase
Playlist
.
Web 67
Section 8: Web
Browser
This section helps you with the basic use of your data services
including downloading multimedia applications and games,
ringtones, and navigating the Web with your phone.
In standby mode, press
Menu
()
Browser
.
Important!
Data charges may apply depending on your data plan.
Pressing
Yes
accepts these charges. For more
information call your U.S. Cellular service
representative.
easyedge
easy
edgeSM, allows you to download multimedia, applications,
games, and check news and sports.
Note: easy
edgeSM from U.S. Cellular is only available on approved
phones and requires an
easy
edgeSM data plan.
Visit www.uscellular.com/easyedge or call U.S. Cellular
customer service (by dialing 611 on your phone) and ask
about
easy
edgeSM.
In standby mode, press
Menu
()
easyedge
.
The
easy
edgeSM screen displays several icons:
1.
easyedge
: view the
easy
edgeSM catalog, Search
easy
edgeSM, or read helpful information about
downloads.
2.
City ID
: Displays the city and state of an incoming call.
3.
PAC-MAN by Namco
: Play the PAC-MAN game.
7
12345
6
10
8 9
68
Launching an Application
1. In standby mode, press
Menu
()
easyedge
.
The
easy
edgeSM screen displays.
2. Highlight the application you wish to run, then
press .
Finding and Downloading Applications
1. In standby mode, press
Menu
()
easyedge
.
The
easy
edgeSM screen displays.
2. Highlight the Easyedge icon and press .
3. Select Catalog or Search to locate, purchase (when
required), and download an application, ringtone, or other
multimedia files.
Tone Room
Tone Room Deluxe enables you to access the latest and hottest
content from your favorite artists for ringtones and ringback
tones from your phone or the Web. This easy to use service
features a music catalog with tens of thousands of titles for you
to discover. Personalize your experience and express yourself by
subscribing to Tone Room Deluxe and using ringback tones to
customize music for your friends and family to hear when they
call you.
4.
AccuWeather.com P remiun v4.0
: View weather for any
selected city.
5.
Daily Perks
: Allows you to view exclusive content and
money-saving offers on your mobile phone for FREE.
6.
Social Scene
: Offers Facebook, Twitter, Email and all the
latest news from the web on your phone. View feeds and
photos, upload pictures, receive notifications of new
messages and more.
7.
Do Not Disturb
: Allows you to block specific phone
numbers, NonContacts, Private numbers, or calls from
9am-5pm.
8.
Tone Room Deluxe
: Offers Ringback tones in several
categories. You can search for ringtone, or manage
ringtones and other account information.
9.
Settings
: Configure
easy
edgeSM settings and
applications.
10.
Help
: Displays information about how to buy
applications, charges, demos, removing applications,
and other configuration information.
Web 69
Tone Room Deluxe allows you to buy a la carte ringtones or a
subscription which provides access to the Tone Room Deluxe
ringback service along with new credits that you can use each
month to download ringtones or acquire ringback tones. You can
purchse additional content once you exhaust your monthly
credits.
In standby mode, press
Menu
()
Tone Room
.
The
Tone Room
screen displays.
70
Section 9: Tools
This section explains how to use your phone’s digital assistant
functionality to schedule events, set reminders, perform
calculations, and more.
Tools Menu
Tools is a suite of Personal Information Manager (PIM)
applications such as a Calendar, and Memo Pad that run on your
phone. You can use your phone to schedule events, set
reminders, perform calculations, and more with the functions
provided by this useful feature.
1. In standby mode, press
Menu
() Tools .
2. Select from the following:
•Bluetooth
: Accesses Bluetooth functions.
Voice SVC
: Accesses voice recognition functions.
•Calendar
: Views the current, past, or future month in a monthly
calendar layout.
Memo Pad
: Store and review useful information.
Alarm Clock
: Set an alarm to go off once, or daily, at a specified
time.
World Time
: Views the current time of day or night in another part
of the world.
Calculator
: Lets you perform calculations, including addition,
subtraction, multiplication, and division.
Stop Watch
: Lets you view the amount of time.
Converter
: Lets you convert currencies (according to the latest
rates) and weights, measures, and temperatures from one system
or increment to another.
Tip Calculator
: Lets you quickly calculate service gratuities with a
minimum of key presses.
USB Mass Storage
: Connect to your PC to transfer files, music and
more.
Bluetooth
Bluetooth is a short-range wireless communications technology
capable of exchanging information over a distance of about 30
feet without requiring a physical connection.
Unlike infrared, you don't need to line up the devices to beam
information with Bluetooth. If the devices are within a range of
one another, you can exchange information between them, even
if they are located in different rooms.
The
Bluetooth
wireless technology settings menu provides the
ability to view and change the device name, display the visibility,
and set the security for the device.
Tools 71
Turn Bluetooth On/Off
When your phone’s Bluetooth function is turned on, you can use
the Bluetooth features available. When the Bluetooth function is
turned off, you cannot send or receive information through
Bluetooth.
To save battery life or in situations where Bluetooth use is
prohibited, such as airline traveling, you can turn off the
Bluetooth wireless technology function.
(For more information, refer to “Bluetooth Settings” on page 72.)
Add New Device
To search for available Bluetooth devices:
1. In standby mode, press
Menu
() Tools
Bluetooth Registered List.
2. At the prompt, turn on Bluetooth.
3. Place the other Bluetooth device in discoverable mode and
press . For more information, refer to the device
user manual. The phone searches for Bluetooth devices
and displays a list of devices on the screen.
4. Highlight the device you want to pair with your phone and
press
Pair
( ). Secure devices require a passkekey or
PIN.
5. If necessary, enter the passkey or PIN information and
press . the selected device.
Note:
If you are pairing with another handset, both devices prompt
you to enter a PIN. To pair the two handsets, enter the same
PIN on both devices.
6. The Bluetooth function pairs with the selected device, then
prompts you to confirm that you want to connect with the
device now.
Press
Yes
to connect with the device.
Press
No
to connect with the device at a later time.
Registered List
Registered List
provides a list of Bluetooth wireless technology
devices previously connected to your handset.
In standby mode, press
Menu
() Tools
Bluetooth Registered List. The
Bluetooth
screen
displays a list of devices previously connected to your
device or available for pairing.
Connecting to a Bluetooth Device
From the Registered List,
Select the desired device.
Note:
If you are unable to pair with the device a pop-up displays.
Press Yes to retry.
72
Bluetooth Settings
1. In standby mode, press
Menu
() Tools
Bluetooth Bluetooth Settings.
2. Select one of the following options:
• Enable
/
Disable
: Turns Bluetooth on or off.
Discovery Mode
: Lets other devices “see” (access) your device.
Select
On
for other devices to see your device, or
Off
for no visibility.
Device Name
: Displays the handset name. You may change this
name. Enter text changes and press to save them.
Supported Profiles
: Lists and explains the Bluetooth profiles
supported by your phone.
Device Info
: Displays the Bluetooth Type, Status, and Address of
your phone.
Voice Service
Voice Commands by Nuance is state-of-the-art voice recognition
software for your mobile phone that lets you dial numbers,
lookup contact information, and open applications using your
voice.
For more information, refer to “Voice Commands” on page 24.
Calendar
Calendar lets you view the current, past, or future month in a
monthly calendar layout. While viewing the calendar, the current
date highlights and days with scheduled events are surrounded
by a box.
Add a New Event
1. In standby mode, press
Menu
() Tools
Calendar.
A calendar displays the current date highlighted. The
month and year also display.
2. Highlight the date of the new event and press Add. The
New Event screen displays.
3. Enter the following event details:
Appointment Name
: Enter the name of the event.
Start Date
: Enter the start date for the event.
•Start Time
: Enter the start time. Press the Directional Key to set am
or pm.
End Date
: Enter the end date for the event.
End Time
: Enter the end time. Press the Directional Keys to set am
or pm.
• Recurrence
: Press the Directional Key to set the frequency of the
event.
Tools 73
•Alert
: Press the Directional Key to choose an alert tone.
• Reminder
: Press the Directional Key to set a reminder of the event.
•Alert time
: Press the Directional Key to set an alert to sound before
the event.
4. Press
Save
( ) to store the event in your calendar.
View an event
1. In standby mode, press
Menu
() Tools
Calendar.
A calendar displays with the current date highlighted. The
month and year also display.
2. Use the following keys to navigate your calendar and
highlight a desired date.
Use the Left/Right navigation keys to move from one day to another.
Use the Up/Down navigation keys to move from one week to
another.
Press the Left Navigation key to view previous months or the Right
Navigation key to view future months.
3. Press the Options soft key while viewing the calendar to
access the following options:
Go To Date
: Displays the specified date.
Go To Today
: Displays today’s date.
Weekly
: Displays a a one-week view of calendar events by date and
time.
Erase Old
: Erases past events.
Erase All
: Erases all events.
4. Pressing
View
to view the highlighted date and
event. A list of scheduled events for the selected day
displays.
5. Select the desired event and press
View
.
Information for the selected event displays.
Memo Pad
You can create a notes and store them in Memo Pad. You can’t
prioritize or set an alert for stored notes. Return to Memo Pad
anytime you wish to review and edit your notes.
Add a Memo
1. In standby mode, press
Menu
() Tools
Memo Pad. A list of your stored memos displays. If this is
your first time in Memo Pad, “No memos” displays.
2. Press Add to add a new memo.
3. Enter memo text using the keypad.
4. Press to save the memo.
74
View, Edit, and Erase Memos
1. In standby mode, press
Menu
() Tools
Memo Pad. A list of your stored memos displays.
2. Highlight the memo to view and press View ().
3. Press Edit to edit the memo and enter changes using the
keypad.
4. Press Options Erase to erase this memo. You are
prompted to verify the erasure.
5.
Press
Yes
to erase the memo.
– or –
Press
No
to cancel.
Alarm Clock
Set your alarm clock to sound daily at a specified time. Once set,
the alarm clock is easy to change or turn off completely.
Note:
The alarm doesn’t function when the phone is turned off. If
the time for an alarm that was set for Once has elapsed and
the phone is off, the alarm occurs at the same time on the
following day.
In standby mode, press
Menu
() Tools
Alarm Clock.
Adding a New Alarm
1. In standby mode, press
Menu
() Tools
Alarm Clock.
2. Press the
Add
soft key to add an alarm. The Set Alarm1
screen displays.
3. Highlight the
Alarm
field and use the
Left
or
Right
Navigation keys to turn the alarm On.
4. Select the
Time
field and enter the time for the alarm, then
use the
Left
or
Right
Navigation keys to set AM or PM.
5. Highlight the
Frequency
field and select the frequency for
this alarm Selections are:
Daily
,
Mon.-Fri
.,
Weekends
, or
Once
.
6. Highlight the
Ringer
field and Use the
Left
or
Right
Navigation keys to select an alert type for this alarm.
Options are:
Tone
,
Vibrate
, or
Light Only
.
7. Press
Save
( ) when finished. The alarm is set and
the alarm icon ( ) displays at the top of the screen.
Tools 75
When an Alarm Sounds
An animated alarm clock displays with the options Snooze or
Dismiss, and an alert sounds when the specified time for the
alarm arrives.
To silence the alarm, use the Navigation key to select
Dismiss and press .
Note:
If you pressed
Snooze
, the alarm sounds every 5 minutes
until you press
Dismiss
.
Turn Off an Alarm
Turning off an Alarm stops it from sounding when the set time is
reached while retaining the Alarm settings for your reuse.
1. In standby mode, press
Menu
() Tools
Alarm Clock.
2. Highlight an alarm and press the
Options
soft key and
select
Off
. The highlighted Alarm is turned off, but the
alarm settings are retained for later reuse.
Alarm Options
Using Alarm Options you can create a new alarm, enable or
diable an existing alarm, or erase an alarm.
1. In standby mode, press
Menu
() Tools
Alarm Clock.
2. Press
Options
, select one of the following, then
press :
•On
/
Off
:Enables or disables the highlighted Alarm, using current
settings.
Add new alarm
: Select to add a new alarm.
•Erase this alarm
: Select to erase the highlighted alarm.
•Erase All
: Select to erase more than one alarm.
World Time
World Time displays the time of day or night in another part of the
world. You can view time in 24 different time zones.
1. In standby mode, press
Menu
() Tools
World Time. A world map displays.
2. Press the
Left
or
Right
Navigation key to locate and display
a particular time zone.
– or –
Press the
Options
soft key and select
Go to City
, then use
the Up or Down Navigation key to select a city.
76
3. Press
DST On
to activate Daylight Saving Time for the
selected time zone.
4. Press
Options
Set as Home Zone
to set the selected time
zone as your current location or time zone. You are
prompted to confirm the Home Zone change.
5.
Press
to keep the displayed time zone as a second,
default time zone.
6. Press to discard the displayed time zone and close
the World Time screen.
Calculator
You can perform calculations, including addition, subtraction,
multiplication, and division using your phone.
1. In standby mode, press
Menu
() Tools
Calculator. The Calculator displays.
2. Enter the first number in your calculation using the keypad
(up to nine digits).
Press to enter a decimal point. (Calculator only accepts 5
digits after a decimal point.)
Press the
Pound
( ) keyto change the sign for a number to a
negative.
3. Use the Navigation keys to set the type of calculation to
perform. Selections are:
Up
navigation key: [
x
] Multiplication
Down
navigation key: [
÷
] Division
Left
navigation key: [
-
] Subtraction
Right
navigation key: [
+
] Addition
OK
key: [
=
] Equals/Total
4. Press Operator for nested operations [such as (1.81 +
9.34) / 5.22] and to calculate powers (such as 32). Select
one of the following options:
(
: Beginning of nested operation
)
: Ending of nested operation
Power
: Raise the current number to the power of the next entry.
5. Use the keypad to enter the next number in the calculation.
6. Repeat steps 3 and 4 as needed.
7. Press to perform the calculation and view the
result.
8. Press to clear your last operation or number entry.
9. Press Clear to clear all of your entries.
Tools 77
Stop Watch
You can use this menu to set a stop watch.
1. In standby mode, press
Menu
() Tools
Stop Watch.
2. Press to
Start
/
Stop
stopwatch count.
3. Press the Record soft key to record splits.
4. Press the Reset soft key to erase all stop watch (lap)
recorded times.
Converter
Convert values you enter into selected units.
1. In standby mode, press
Menu
() Tools
Converter.
2. Use the Navigation Keys to highlight a conversion type,
then press :
• Currency
• Length
• Weight
•Volume
•Area
• Temperature
3. Use the
Left
and
Right
Navigation Keys to select the unit to
convert From.
4. Highlight the
From
quantity field. Use the keypad to enter
the quantity you want converted in the From quantity field.
5. Highlight the
To
unit field. Use the Left and Right navigation
keys to select the units to convert From and To. The
converted quantity displays in the To quantity field.
Tip:
Press to include a decimal point.
78
Tip Calculator
Tip Calculator automatically calculates the following amounts:
Gratuity (tip)
Individual payment (for groups)
Calculations are based on the total amount of the check, a
selected percentage, and the number of people paying.
1. In standby mode, press
Menu
() Tools
Tip Calculator
. The Tip Calculator screen displays with the
Bill field highlighted.
2. Use the keypad to enter the total amount of the bill.
Note:
Press to include a decimal point.
3. Highlight the
Tip
field and use the keypad to change the tip
percentage (the default percentage is 20%).
4. Highlight the
# Paying
field and use the keypad to change
the number of persons paying.
5. The amount of the Tip, the bill Total, and the amount each
person should pay display in the bottom portion of the
screen.
USB Mass Storage
Use the USB Mass Storage option to download files from your
computer to your phone.
1. Install a microSD™ or microSDHC™ Memory Card into
your phone.
2. Power on the phone.
3. Connect the small (micro USB) end of the USB Data Cable
to the power-accessory connector on your phone.
4. In standby mode, press
Menu
() Tools
USB Mass Storage
. You are prompted to “
Connect To PC
”.
5. Connect the USB end of the USB Data Cable to a matching
connector on your personal computer. The
AutoPlay
menu
opens on your computer screen.
6. Select the
Open folder to view files
option. A new Windows
Explorer window opens on your computer screen listing
the contents of your phone’s Memory Card.
7. Drag or download files into the correct folders.
Changing Your Settings 79
Section 10: Changing Your Settings
This section explains how to customize your phone’s settings to
suit your needs and preferences.
Settings
In standby mode, press
Menu
() Settings .
Location
This function identifies your location to the network using the
Global Positioning System (GPS). You can set this function for
continuous operation or to operate only in the event that you
dial 911.
Note:
Contact U.S. Cellular to determine whether, when, or where
location-based services are available.
1. In standby mode, press
Menu
() Settings
Location.
2. Select the desired Location setting and press .
Location On
: GPS location is on whenever you make or receive a
call, wherever the feature is available.
911 Only
: GPS location is on only when you dial 911.
Display Settings
This section shows you how to change your phone’s menu
appearance, display brightness and contrast, and display content
to better meet your needs.
1. In standby mode, press
Menu
() Settings
Display Settings.
2. Select one of the following options:
Wallpaper
Choose the images to display in the background of the phone’s
front and main screens while the phone is closed or open and in
standby mode.
1. In standby mode, press
Menu
() Settings
Display Settings Wallpaper.
2. Select the Display wallpaper to change:
•Main Display
Front Display
3. Select the image type to use. Several images display.
•My Images
: Lets you select a photo you’ve taken or an image that
you’ve downloaded from the Internet as a wallpaper image.
80
•Preset Images
: Lets you select an image that came preloaded with
your phone as a wallpaper image.
4. Select an image and press .
Clock Format
Clock Format lets you choose the format your phone uses to
present the current time in the phone’s front and main displays
while the phone is closed or in standby mode.
1. In standby mode, press
Menu
() Settings
Display Settings Clock Format.
2. Select the desired clock format and press .
•Main Clock
Digital
Analog
Samsung
Off
•Front Clock
Samsung
Digital
Analog
Theme
Lets you select the color theme used to display menu screens
and popup menus and messages. You can choose from a variety
of themes.
1. In standby mode, press
Menu
() Settings
Display Settings Theme.
2. Select one of the following options then press to
save the theme.
Samsung
• Celestial
Dialing Font Size
Lets you select the size of your dialing font.
1. In standby mode, press
Menu
() Settings
Display Settings Font Size.
2. Highlight one of the following options then press .
Normal
Large
Changing Your Settings 81
Banner
Create your own personalized greeting that displays while your
phone is in standby mode.
1. In standby mode, press
Menu
() Settings
Display Settings Banner.
2. Press and hold to erase the existing banner text
and enter new text for this banner (Up to 18 characters).
3. Press to save the new banner.
Backlight
You can set the backlight for your display or keypad to remain on
for a specified period of time or remain on as long as the folder is
open.
Note:
Prolonged backlight use drains your battery faster.
1. In standby mode, press
Menu
() Settings
Display Settings Backlight.
2. Select one of the following sub menus:
Main Display
: Sets the time the internal display backlight remains
on after a period of inactivity. Optional settings are:
10 seconds
,
15 seconds
,
30 seconds
,
Always On
, and
Always Off
.
Keypad
: Sets the amount of time the keypad backlight remains on
after a period of inactivity. Optional settings are:
10 seconds
,
15 seconds
,
30 seconds
,
Always On
, and
Always Off
.
•Charging
: Sets the brightness of the backlight when the device is
charging. Settings are:
10 seconds
,
15 seconds
,
30 seconds
,
Always On
, and
Always Off
.
Brightness
: Sets the brightness of the backlight. Press the
Left
or
Right
Navigation keys to lower or raise the brightness level.
Front Contrast
Front Contrast lets you choose the display contrast to suit
yourself.
1. In standby mode, press
Menu
() Settings
Display Settings
Front Contrast
.
2. Use the
Left
or
Right
navigation keys to sample any of the
51 display contrast settings from
-50
to
+50
. The screen
displays the effects of each new setting.
Press
to save the new setting.
Press
t
o discard the new setting and return to the
Display
menu.
82
Sound Settings
This section shows you how to customize your phone’s audio
properties, such as ringers, keypad tones, alerts, shut down
sounds, and more.
In standby mode, press
Menu
() Settings
Sound Settings. The
Sound Settings
menu displays.
Master Volume
Use the
Volume
sub-menu to set the default volume for incoming
calls and messages.
1. In standby mode, press
Menu
() Settings
Sound Settings Master Volume.
2. Use the
Left
or
Right
Navigation keys or the Volume key to
change the volume level (Silence All,
Vibrate
, Low, Low/
Medium, Medium, Medium/High, High).
3. Press
Vib. on
to add
with vibrate
to the Master Volume
setting.
Example:
With Master Volume set to
Low
, pressing
Vib. on
changes
the Master Volume setting to
Low with vibrate
.
Tip:
Press
Play
to preview the selected ringtone or alert tone while
adjusting the volume setting.
4. Press
SET
( ) to save the settings.
Ringer Type
You can assign ring tones for calls, alarms, and other alerts in the
Ringer Type
sub menu.
1. In standby mode, press
Menu
() Settings
Sound Settings Ringer Type. The following Ringer
Types display:
Voice Calls
Messages
Text Message
Picture Message
Voicemail
Note:
Your phone includes preloaded ringtones and sounds. You
can download additional ringtones and sounds using
easy
edgeSM.
Record your own sounds by accessing
My Ringtones
through
the
Multimedia
menu. Select
Menu
Multimedia
My
Ringtones
Record New
. (For more information, refer to
“Record New Voice Memo” on page 62.)
2. Select the desired option. A list of ringtones or sounds
displays.
Changing Your Settings 83
3. Use the Navigation key to scroll through the ringtones and
sounds for the preferred ringer.
4. Press
Play
to play a sample of the selected ringtone.
5. Press to set this ringtone.
Alerts
You can set your phone to sound an alert whenever you enter or
leave your service area, connect or disconnect a call, as well as
other options.
1. In standby mode, press
Menu
() Settings
Sound Settings Alerts.
2. Select the desired option and press
On
(activate) or
Off
(deactivate):
Minute Beep
: Sound an alert ten seconds before each elapsed
minute of a call.
Roam/SVC Alert
: Sound an alert when you leave your home
service area while on a call.
Call Connect
: Sound an alert when you connect a call.
Power On
: Play melodies when you turn your phone on.
Voice Privacy Alert
: Sounds an alert when Voice Privacy is
enabled.
Key Tone
Key Tone allows you to adjust the volume level and length of the
tone that the keypad generates each time you press a key.
1. In standby mode, press
Menu
() Settings
Sound Settings Key Tone.
2. Select one of the following options:
Tone Level
Tone Length
Setting the Tone Level
1. Use the Volume key or Navigation key to set the keypad
Tone Level.
2. Press to save the selected tone level.
Setting the Tone Length
Select Short or Long and press to save the
selection.
Call Settings
The Call Settings options let you select how your phone handles
voice and data calls.
In standby mode, press
Menu
() Settings
Call Settings. The Call Settings sub-menu displays.
84
Call Answer
You can select a specific answer mode when you receive an
incoming call.
1. In standby mode, press
Menu
() Settings
Call Settings Call Answer.
2. Select the method from the Call Answer sub-menu to use
for answering calls:
•Any Key
: Press any key except the , , or the Right
or Left soft key to answer an incoming call.
Send Key
: Press to answer an incoming call.
Flip Open
: Open the flip to answer an incoming call.
Tip:
You can set your phone to answer calls automatically, without
any input from you. (For more information, refer to “Auto
Answer” on page 84.)
Auto Answer
Auto Answer enables your phone to automatically answer calls
after a period of time that you specify.
1. In standby mode, press
Menu
() Settings
Call Settings Auto Answer.
2. Select one of the following options:
Off
: Disables automatic answering of calls
After 1 Second
: Phone automatically answers calls after 1 second
After 3 Seconds
: Phone automatically answers calls after 3
seconds
After 5 Seconds
: Phone automatically answers calls after 5
seconds
Auto Retry
Auto Retry automatically re-dials a number if the connection fails.
Depending upon your location, the number of times your phone
automatically dials the number may vary.
1. In standby mode, press
Menu
() Settings
Call Settings Auto Retry.
2. Select one of the following options from the Auto Retry
sub-menu:
Off
: Disables automatic redialing of numbers
Every 10 Seconds
: Phone automatically redials a number every
10 seconds
Every 30 Seconds
: Phone automatically redials a number every
30 seconds
Every 60 Seconds
: Phone automatically redials a number every
60 seconds
Changing Your Settings 85
TTY Mode
Your phone is fully TTY compatible. TTY equipment is connected
to your phone through the headset connector on the right side of
the phone. TTY Mode must be enabled before you can use your
phone with a TTY device.
1. In standby mode, press
Menu
() Settings
Call Settings TTY Mode. You are prompted to confirm
you want to change the current TTY Mode setting.
2. Press the
Yes
soft key to access the TTY Mode options.
– or –
Press the
No
soft key to cancel.
3. If you press the Yes soft key, select the desired TTY Mode
setting:
TTY Full
: Enables TTY mode and disables microphone and
earpiece
TTY + Talk (VCO)
: Enables TTY mode and microphone
TTY + Hear
(HCO)
: Enables TTY mode and earpiece
TTY Off
: Disables TTY mode
Note:
The
TTY
icon ( ) displays at the top of the screen when
the phone is in standby mode.
Voice Privacy
When Voice Privacy is enabled (that is, set to Enhanced), it turns
on advanced voice encryption.
1. In standby mode, press
Menu
() Settings
Call Settings Voice Privacy.
2. Select a Voice Privacy setting:
Standard
: Voice privacy is disabled.
Enhanced
: Voice privacy is enabled.
International Dialing
1. In standby mode, press
Menu
() Settings
Call Settings
International Dialing
.
2. Select and international dialing code and press
Phone Settings
The Phone Settings options let you tailor your phones basic
operations. To access the Phone Settings sub-menu, do the
following:
In standby mode, press
Menu
() Settings
Phone Settings. The Phone Settings sub-menu displays.
86
Airplane Mode
When set to On, Airplane Mode disables all radio functions of
your phone. This prevents you from receiving or making calls
(except emergency calls), but allows you to use other features
(such as the camera and the Tools) safely in sensitive
environments, such as on board an aircraft.
1. In standby mode, press
Menu
() Settings
Phone Settings Airplane Mode.
2. Select the desired Airplane Mode setting. :
On
: Disables the radio transmitter and receiver in your phone
Off
: Enables the radio transmitter and receiver in your phone
Language
The language option on your phone can change the language of
voice prompts, menus, and key-input.
1. In standby mode, press
Menu
() Settings
Phone Settings Language.
2. Select your language preference:
English
Español
Security
Use the Security sub-menu to lock your phone, set up emergency
numbers, enable or disable voice privacy, set restrictions, and
other security options.
1. In standby mode, press
Menu
() Settings
Phone Settings
Security
. The “
Enter Code
” prompt
displays.
2. Enter the four-digit lock code using the keypad.
Note:
The default lock code is the last four digits of your mobile
phone number.
The “
Enter Code
” prompt disappears and the
Security
menu displays.
Lock Phone
Locking the phone limits all outgoing calls except calls to 911
emergency and the three user-programmable emergency
numbers. You can lock the phone manually during use, or set the
phone to lock automatically when it is turned on. With the phone
in lock mode, you can answer incoming calls, but you must
unlock the phone to place outgoing calls (except to emergency
and secret numbers).
1. At the Security sub-menu, select Lock Phone.
Changing Your Settings 87
2. Select a Device Lock Mode option:
Lock
: Locks the phone immediately. (The phone stays locked until
you enter the lock code.)
Unlock
: Unlocks the phone.
On Power up
: The phone locks automatically the next time your
phone is powered on. (The phone stays locked until you enter the
lock code.)
Change Lock
The default lock code for your phone is generally the last four
digits of your phone number. It is advisable to change the default
lock code to a secret code for security purposes.
1. At the Security sub-menu, select Change Lock. you are
prompted to enter the new lock code.
2. Enter the new lock code. You are prompted to re-enter the
new lock code for verification.
3. Enter the new lock code again. Your changes are stored.
Note:
Your phone does not allow you to view the lock code for
obvious security reasons. If you change the lock code, be
sure to write down or memorize the new code.
Emergency #
Your phone provides the option of storing three emergency
numbers (up to 32 digits long). You can dial an emergency
number any time, even when your phone is locked or restricted.
This useful feature controls outgoing calls from your phone.
Emergency number 911 is hard-coded into your phone. You can
dial this number any time, even when the phone is locked or
restricted. If you call 911 an audible tone is heard and an
Emergency prompt displays on the screen for the duration of the
call.
Important!
Because of various transmission methods, network
parameters, and user settings necessary to complete a
call from your wireless phone, a connection cannot
always be guaranteed. Therefore, emergency calling
may not be available on all wireless networks at all
times.
DO NOT depend on this phone as a primary method of
calling 911 or for any other essential or emergency
communications.
Remember to always turn your phone on and check for adequate
signal strength before placing a call.
88
To store emergency numbers:
1. At the Security sub-menu, select Emergency #.
2. Select from the three emergency number entries.
3. Enter an emergency number (up to 32 digits in length).
4. Press to save the number that you entered.
Call emergency numbers in lock mode:
1. In standby mode, enter the emergency number.
2. Press to place the call.
Emergency Ringback
When calling 911, this feature allows 911 to call you back when
the phone has be disconnected.
1. At the Security sub-menu, select Emergency Ringback.
2. Highlight
On
or
Off
and press .
Resetting the Phone
Reset Phone returns all setup options to their factory default.
1. At the Security sub-menu, select Reset Phone. You are
prompted to confirm that you want to restore your phone’s
default settings (except for the Contacts and Voice Dial).
2. Press the
Yes
soft key to restore default settings.
– or –
Press the
No
soft key to
retain your current settings.
Erase All Entries
Erase All Entries erases all information from your Contacts list.
Note:
To completely remove any personal information stored on
your device, see “Precautions for Transfer and Disposal” on
page 119.
1. At the Security sub-menu, select Erase All Entries. you
are prompted to enter the lock code again.
2. Enter the four-digit lock code using the keypad.
Note:
The default lock code is the last four digits of your mobile
phone number.
The “Erase All Entries?” prompt displays.
3. Press the
Yes
soft key to erase all Contacts list entries.
– or –
Press the
No
soft key to cancel
.
Changing Your Settings 89
Restriction
Restriction lets you limit the use of your phone to make outgoing
calls and/or to receive incoming calls to any numbers, to no
numbers, or to calls from/to your Contacts.
1. At the Security sub-menu, select Restriction.
2. Highlight the desired Restriction and press .
• Calls
: Restrict/allow incoming or outgoing calls.
•SMS Messages
: Restrict/allow incoming or outgoing text
messages.
MMS Message
: Restrict/allow incoming or outgoing multimedia
messages.
•Data
: Allow All data call or Allow none data calls.
Factory Data Reset
Factory Data Reset erases all of your Contacts, messages, and
apps from your phone and resets your phone’s settings to their
factory default values.
1. At the Security sub-menu, select Factory Data Reset. You
are prompted to verify that you want to erase all of your
data from your phone and reset its settings to factory
default values.
2. Press
Yes
to erase your data and reset your phone’s
settings to factory defaults.
NAM Selection
The Network menu allows you to select NAM (Number
Assignment Module) settings for your phone. You can store two
NAM settings, which are essentially telephone numbers, for your
phone.
1. In standby mode, press
Menu
() Settings
Phone Settings NAM Selection.
2. Select the desired NAM option. The phone powers itself off
and back on.
NAM1
: Your service contract has one phone line.
NAM2
:
Your service contract has two phone lines.
System Select
The System Select menu allows you to select the roaming
setting for your phone.
1. In standby mode, press
Menu
() Settings
Phone Settings System Select.
2. Select the desired roaming option:
Home Only
:Your phone is available for normal operation only
within your designated coverage area.
Automatic
:The Preferred Roaming List (PRL) is used to acquire
service. If no preferred systems are found, any digital system is
acquired.
90
Set Time
Use the Set Time option to set the current date and time.
Note:
In digital service mode, the
Set Time
feature is disabled. The
network adjusts time and date automatically.
1. In standby mode, press
Menu
() Settings
Phone Settings Set Time.
2. Select one of the following options:
Set Date
Set Time
Speed Dial
Speed Dials are 1-, 2- or 3-digit shortcuts you assign to contacts,
to allow you to quickly call the contact.
1. In standby mode, press
Menu
() Settings
Phone Settings Speed Dial.
2. Highlight
On
to enable the Speed Dial feature or highlight
Off
to disable.
3. Press .
For more information, refer to
“Speed Dial on
page 43.
Quick Search
Quick Search
is an easy way to locate Contacts.
1. In standby mode, press
Menu
() Settings
Phone Settings Quick Search.
2. Highlight
On
to enable the Quick Search feature or
highlight
Off
to disable.
3. Press
.
Changing Your Settings 91
Shortcut Key
Shortcut Key lets you set which feature, function, or application
launches when you press the Up navigation key while in standby
mode.
1. In standby mode, press
Menu
() Settings
Phone Settings Shortcut Key.
2. Use the Directional Key to highlight
Up Key
,
Right
Key
, or
Left
Key
and press .
3. Highlight an item, and press .
PC Connection
1. In standby mode, press
Menu
() Settings
Phone Settings PC Connection.
2. Select one of the following options and press .
USB Mass Storage
: Transfer files, music and more to the phone as
a storage device.
• Bluetooth
: Paris with another Bluetooth device to share files.
No Connection
: Not connected as a mass storage or Bluetooth
device.
Phone Info
The Phone Info options display the phone’s hardware and
software versions, definitions of the icons that display at the top
of the phones screen, and the assigned phone number for this
device.
In standby mode, press
Menu
() Settings
Phone Info.
Phone Number
This option causes the Phone Number screen to display as well
as your ten-digit, US Cellular phone number.
In standby mode, press
Menu
() Settings
Phone Info Phone Number. The phone number
assigned by U.S. Cellular displays.
Icon Glossary
This option displays a list of icons (by name) used on this phone.
1. In standby mode, press
Menu
() Settings
Phone Info Icon Glossary. Displays a list of the icons
that display on the top line of the screen.
2. Use the Up and Down navigation keys or the Volume key to
scroll through the icons list.
92
Version
You can view both the software and hardware version of your
phone using this feature. This feature is helpful if you need to
contact Customer Service.
In standby mode, press
Menu
() Settings
Phone Info Version.
Your phone’s software (S/W), preferred roaming list (PRL),
browser (WEB),
easy
edgeSM (easyedge), and hardware-
related information (H/W, MEID, and pESN) displays.
Software Update
1. In standby mode, press
Menu
() Settings
Phone Info Software Update.
2. Select one of these options and press :
Check for Update
: Checks for the latest software version and if
available downloads it to the handset.
• Status
: Displays the phone’s software verison, Status, Code, Date,
and Time.
Operating System
In standby mode, press
Menu
() Settings
Phone Info Operating System. The brew mp™
operating system version displays.
Memory Info
Memory Info options let you review your phone’s available
memory and help you manage your files stored there.
To access the Memory Info options:
1. In standby mode, press
Menu
() Settings
Memory Info.
2. Select one of the following options and press :
•Save Options
: Select Images or Ringtone and select the location to
save those files.
Phone Memory
: Select Memory Usage, My Images, or My
Ringtones.
Memory Usage
: Displays the Total Used, and Available memory. Also
displays the amount of memory used for My Images, My Ringtones,
Applications, and Pic Msg.
My Images
: Displays a list of images downloaded or stored to Erase,
Move, or Copy.
My Ringtones
: Displays a list of ringtones downloaded or stored.
•Card Memory
: Displays the following:
Memory Usage
: Displays the memory used as Total Used, Available,
My Images, and My Music.
My Images
: Displays a list of downloaded images with the amount of
memory used for each image.
Changing Your Settings 93
My Music
: Displays a list of downloaded music files with the amount of
memory used for each image.
Format Card
: Formats the memory card and erases all data. Press
Yes
to continue or
No
to cancel.
94
Section 11: Health and Safety Information
This section outlines the safety precautions associated with using
your phone. The terms “mobile device” or “cell phone” are used
in this section to refer to your phone.
Read this information before
using your mobile device
.
Exposure to Radio Frequency (RF) Signals
The U.S. Food and Drug Administration (FDA) has published
information for consumers relating to Radio Frequency (RF)
exposure from wireless phones. The FDA publication includes the
following information:
Do cell phones pose a health hazard?
Many people are concerned that cell phone radiation will cause
cancer or other serious health hazards. The weight of scientific
evidence has not linked cell phones with any health problems.
Cell phones emit low levels of Radio Frequency (RF) energy. Over
the past 15 years, scientists have conducted hundreds of studies
looking at the biological effects of the radio frequency energy
emitted by cell phones. While some researchers have reported
biological changes associated with RF energy, these studies have
failed to be replicated. The majority of studies published have
failed to show an association between exposure to radio
frequency from a cell phone and health problems.
The low levels of RF cell phones emit while in use are in the
microwave frequency range. They also emit RF at substantially
reduced time intervals when in the stand-by mode. Whereas high
levels of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating effects
causes no known adverse health effects.
The biological effects of radio frequency energy should not be
confused with the effects from other types of electromagnetic
energy.
Very high levels of electromagnetic energy, such as is found in
X-rays and gamma rays, can ionize biological tissues. Ionization
is a process where electrons are stripped away from their normal
locations in atoms and molecules. It can permanently damage
biological tissues including DNA, the genetic material.
The energy levels associated with radio frequency energy,
including both radio waves and microwaves, are not great
enough to cause ionization of atoms and molecules. Therefore,
RF energy is a type of non-ionizing radiation. Other types of
non-ionizing radiation include visible light, infrared radiation
(heat), and other forms of electromagnetic radiation with
relatively low frequencies.
Health and Safety Information 95
While RF energy does not ionize particles, large amounts can
increase body temperatures and cause tissue damage. Two
areas of the body, the eyes and the testes, are particularly
vulnerable to RF heating because there is relatively little blood
flow in them to carry away excess heat.
Research Results to Date: Is there a connection between RF
and certain health problems?
The results of most studies conducted to date say no. In addition,
attempts to replicate and confirm the few studies that have
shown a connection have failed.
The scientific community at large therefore believes that the
weight of scientific evidence does not show an association
between exposure to Radio Frequency (RF) from cell phones and
adverse health outcomes. Still the scientific community has
supported additional research to address gaps in knowledge.
Some of these studies are described below.
Interphone Study
Interphone is a large international study designed to determine
whether cell phones increase the risk of head and neck cancer. A
report published in the International Journal of Epidemiology
(June, 2010) compared cell phone usage for more than 5,000
people with brain tumors (glioma and meningioma) and a similar
number of healthy controls.
Results of this study did NOT show that cell phones caused brain
cancer. In this study, most people had no increased risk of brain
cancer from using cell phones. For people with the heaviest use
of cell phones (an average of more than ½ hour per day, every
day, for over 10 years) the study suggested a slight increase in
brain cancer. However, the authors determined that biases and
errors prevented any conclusions being drawn from this data.
Additional information about Interphone can be found at
http://www.iarc.fr/en/media-centre/pr/2010/pdfs/pr200_E.pdf.
Interphone is the largest cell phone study to date, but it did not
answer all questions about cell phone safety. Additional research
is being conducted around the world, and the FDA continues to
monitor developments in this field.
International Cohort Study on Mobile Phone Users (COSMOS)
The COSMOS study aims to conduct long-term health monitoring
of a large group of people to determine if there are any health
issues linked to long-term exposure to radio frequency energy
from cell phone use. The COSMOS study will follow
approximately 300,000 adult cell phone users in Europe for 20 to
30 years. Additional information about the COSMOS study can be
found at
http://www.ukcosmos.org/index.html
.
96
Risk of Brain Cancer from Exposure to Radio Frequency Fields
in Childhood and Adolescence (MOBI-KIDS)
MOBI-KIDS is an international study investigating the relationship
between exposure to radio frequency energy from
communication technologies including cell phones and brain
cancer in young people. This is an international multi-center
study involving 14 European and non-European countries.
Additional information about MOBI-KIDS can be found at
http://www.creal.cat/programes-recerca/en_projectes-creal/
view.php?ID=39.
Surveillance, Epidemiology, and End Results (SEER) Program
of the National Cancer Institute
The National Cancer Institute (NCI) actively follows cancer
statistics in the United States to detect any change in rates of
new cases for brain cancer. If cell phones play a role in risk for
brain cancer, rates should go up, because heavy cell phone use
has been common for quite some time in the U.S. Between 1987
and 2005, the overall age-adjusted incidence of brain cancer did
not increase. Additional information about SEER can be found at
http://seer.cancer.gov/
.
Cell Phone Industry Actions
Although the existing scientific data do not justify FDA regulatory
actions, the FDA has urged the cell phone industry to take a
number of steps, including the following:
Support-needed research on possible biological effects of RF for
the type of signal emitted by cell phones;
Design cell phones in a way that minimizes any RF exposure to the
user; and
Cooperate in providing users of cell phones with the current
information on cell phone use and human health concerns.
The FDA also is working with voluntary standard-setting bodies
such as the Institute of Electrical and Electronics Engineers
(IEEE), the International Commission on Non-Ionizing Radiation
Protection (ICNIRP), and others to assure that safety standards
continue to adequately protect the public.
Reducing Exposure: Hands-Free Kits and Other
Accessories
Steps to Reduce Exposure to Radio Frequency Energy
If there is a risk from being exposed to radio frequency energy
(RF) from cell phones - and at this point we do not know that
there is - it is probably very small. But, if you are concerned
about avoiding even potential risks, you can take a few simple
steps to minimize your RF exposure.
Reduce the amount of time spent using your cell phone;
Use speaker mode or a headset to place more distance between your
head and the cell phone.
Health and Safety Information 97
Hands-Free Kits
Hands-free kits may include audio or Bluetooth® headsets and
various types of body-worn accessories such as belt-clips and
holsters. Combinations of these can be used to reduce RF energy
absorption from cell phones.
Headsets can substantially reduce exposure because the phone
is held away from the head in the user's hand or in approved
body-worn accessories. Cell phones marketed in the U.S. are
required to meet RF exposure compliance requirements when
used against the head and against the body.
Because there are no known risks from exposure to RF emissions
from cell phones, there is no reason to believe that hands-free
kits reduce risks. Hands-free kits can be used for convenience
and comfort. They are also required by law in many states if you
want to use your phone while driving.
Cell Phone Accessories that Claim to Shield the Head from RF
Radiation
Because there are no known risks from exposure to RF emissions
from cell phones, there is no reason to believe that accessories
which claim to shield the head from those emissions reduce
risks. Some products that claim to shield the user from RF
absorption use special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do not work as
advertised. Unlike “hands-free” kits, these so-called “shields”
may interfere with proper operation of the phone. The phone may
be forced to boost its power to compensate, leading to an
increase in RF absorption.
Children and Cell Phones
The scientific evidence does not show a danger to any users of
cell phones from RF exposure, including children and teenagers.
The steps adults can take to reduce RF exposure apply to
children and teenagers as well.
Reduce the amount of time spent on the cell phone;
Use speaker mode or a headset to place more distance between the
head and the cell phone.
Some groups sponsored by other national governments have
advised that children be discouraged from using cell phones at
all. For example, The Stewart Report from the United Kingdom
made such a recommendation in December 2000. In this report,
a group of independent experts noted that no evidence exists that
using a cell phone causes brain tumors or other ill effects. Their
recommendation to limit cell phone use by children was strictly
precautionary; it was not based on scientific evidence that any
health hazard exists.
98
Additional information on the safety of RF exposures from various
sources can be obtained from the following organizations
(updated 10/1/2010):
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/.
Environmental Protection Agency (EPA):
http://www.epa.gov/radtown/wireless-tech.html.
Occupational Safety and Health Administration (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/.
(Note: This web address is case sensitive.)
National Institute for Occupational Safety and Health (NIOSH):
http://www.cdc.gov/niosh/.
World Health Organization (WHO):
http://www.who.int/peh-emf/en/.
International Commission on Non-Ionizing Radiation Protection:
http://www.icnirp.de.
Health Protection Agency:
http://www.hpa.org.uk/Topics/Radiation/.
US Food and Drug Administration:
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm.
Specific Absorption Rate (SAR) Certification
Information
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the exposure limits for
Radio Frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government.
These FCC RF exposure limits are derived from the
recommendations of two expert organizations: the National
Council on Radiation Protection and Measurement (NCRP) and
the Institute of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by scientific and
engineering experts drawn from industry, government, and
academia after extensive reviews of the scientific literature
related to the biological effects of RF energy.
The RF exposure limit set by the FCC for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR is a measure of the rate of
absorption of RF energy by the human body expressed in units of
watts per kilogram (W/kg). The FCC requires wireless phones to
comply with a safety limit of 1.6 watts per kilogram (1.6 W/kg).
The FCC SAR limit incorporates a substantial margin of safety to
give additional protection to the public and to account for any
variations in measurements.
Health and Safety Information 99
SAR tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands. Although the
SAR is determined at the highest certified power level, the actual
SAR level of the phone while operating can be well below the
maximum reported value. This is because the phone is designed
to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output of the
phone.
Before a new model phone is available for sale to the public, it
must be tested and certified to the FCC that it does not exceed
the SAR limit established by the FCC. Tests for each model phone
are performed in positions and locations (e.g. at the ear and worn
on the body) as required by the FCC. For body-worn operation,
this phone has been tested and meets FCC RF exposure
guidelines when used with an accessory that contains no metal
and that positions the mobile device a minimum of 1.5 cm from
the body.
Use of other accessories may not ensure compliance with FCC RF
exposure guidelines. The FCC has granted an Equipment
Authorization for this mobile phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines.
The maximum SAR values for this model phone as reported to
the FCC are:
Head
: 0.57 W/kg.
Body-worn
: 0.63 W/kg.
SAR information on this and other model phones can be
accessed online on the FCC's website through
http://
transition.fcc.gov/oet/rfsafety/sar.html
. To find information that
pertains to a particular model phone, this site uses the phone
FCC ID number which is usually printed somewhere on the case
of the phone. Sometimes it may be necessary to remove the
battery pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions on the
website and it should provide values for typical or maximum SAR
for a particular phone. Additional SAR information can also be
obtained at
http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-cellular-
telephones
.
FCC Part 15 Information to User
Pursuant to part 15.21 of the FCC Rules, you are cautioned that
changes or modifications not expressly approved by Samsung
could void your authority to operate the device.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
100
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Commercial Mobile Alerting System (CMAS)
This device is designed to receive wireless emergency alerts
from the Commercial Mobile Alerting System ("CMAS"; which
may also be known as the Personal Localized Alerting Network
("PLAN")). If your wireless provider has chosen to participate in
CMAS/PLAN, alerts are available while in the provider's coverage
area. If you travel outside your provider's coverage area, wireless
emergency alerts may not be available. For more information,
please contact your wireless provider.
Smart Practices While Driving
On the Road - Off the Phone
The primary responsibility of every driver is the safe operation of
his or her vehicle.
Responsible drivers understand that no secondary task should be
performed while driving whether it be eating, drinking, talking to
passengers, or talking on a mobile phone - unless the driver has
assessed the driving conditions and is confident that the
secondary task will not interfere with their primary responsibility.
Do not engage in any activity while driving a moving vehicle which
may cause you to take your eyes off the road or become so
absorbed in the activity that your ability to concentrate on the act
of driving becomes impaired
. Samsung is committed to promoting
responsible driving and giving drivers the tools they need to
understand and address distractions.
Check the laws and regulations on the use of mobile devices and
their accessories in the areas where you drive. Always obey them.
The use of these devices may be prohibited or restricted in certain
areas. For example, only hands-free use may be permitted in
certain areas.
Health and Safety Information 101
Before answering calls, consider your circumstances. Let the call
go to voicemail when driving conditions require. Remember,
driving comes first, not the call!
If you consider a call necessary and appropriate, follow these
tips:
Use a hands-free device;
Secure your phone within easy reach;
Place calls when you are not moving;
Plan calls when your car will be stationary;
Do not engage in stressful or emotional conversations;
Let the person with whom you are speaking know that you are driving
and will suspend the call if necessary;
Do not take notes or look up phone numbers while driving;
Notice regarding legal restrictions on mounting this device in an
automobile:
Laws in some states may prohibit mounting this device on or
near the windshield of an automobile. In other states, the law
may permit mounting this device only in specific locations in the
automobile. Be sure to consult the state and local laws or
ordinances where you drive before mounting this device in an
automobile. Failure to comply with these restrictions could result
in fines, penalties, or other damages.
Never mount this device in a manner that will obstruct the
driver's clear view of the street and traffic.
Never use wireless data services such as text messaging, Web
browsing, or e-mail while operating a vehicle.
Never watch videos, such as a movie or clip, or play video games
while operating a vehicle.
For more information, go to
http://www.ctia.org
.
Battery Use and Safety
Important! Handle and store batteries properly to avoid injury or
damage
. Most battery issues arise from improper
handling of batteries and, particularly, from the
continued use of damaged batteries.
Do not disassemble, crush, puncture, shred, or otherwise attempt
to change the form of your battery
. Do not put a high degree of
pressure on the battery. This can cause leakage or an internal
short-circuit, resulting in overheating.
102
Do not let the phone or battery come in contact with liquids.
Liquids can get into the phone's circuits, leading to corrosion. Even
when the phone appears to be dry and appears to operate normally,
the circuitry could slowly corrode and pose a safety hazard. If the
phone and/or battery get wet, have them checked by your service
provider or contact Samsung, even if they appear to be working
properly.
Do not place your battery in or near a heat source
. Excessive
heating can damage the phone or the battery and could cause the
phone or the battery to explode. Do not dry a wet or damp battery with
an appliance or heat source such as a microwave oven, hair dryer,
iron, or radiator. Avoid leaving your phone in your car in high
temperatures.
Do not dispose of the phone or the battery in a fire
. The phone or
the battery may explode when overheated.
Do not handle a damaged or leaking battery
. Do not let leaking
battery fluid come in contact with your eyes, skin or clothing. For safe
disposal options, contact your nearest Samsung-authorized service
center.
Avoid dropping the cell phone
. Dropping the phone or the battery,
especially on a hard surface, can potentially cause damage to the
phone and battery. If you suspect damage to the phone or battery,
take it to a service center for inspection.
Never use any charger or battery that is damaged in any way
.
Do not allow the battery to touch metal objects
. Accidental
short-circuiting can occur when a metallic object (coin, key, jewelry,
clip, or pen) causes a direct connection between the + and - terminals
of the battery (metal strips on the battery), for example when you
carry a spare battery in a pocket or bag. Short-circuiting the terminals
may damage the battery or the object causing the short-circuiting.
Important!
Use only Samsung-approved batteries, and recharge
your battery only with Samsung-approved chargers
which are specifically designed for your phone.
WARNING!
Use of a non-Samsung-approved battery or charger may present a
risk of fire, explosion, leakage, or other hazard
. Samsung's
warranty does not cover damage to the phone caused by
non-Samsung-approved batteries and/or chargers.
Do not use incompatible cell phone batteries and chargers
. Some
websites and second-hand dealers not associated with reputable
manufacturers and carriers, might be selling incompatible or even
counterfeit batteries and chargers. Consumers should purchase
manufacturer or carrier-recommended products and accessories. If
unsure about whether a replacement battery or charger is compatible,
contact the manufacturer of the battery or charger.
Health and Safety Information 103
Misuse or use of incompatible phones, batteries, and charging
devices could result in damage to the equipment and a possible
risk of fire, explosion, or leakage, leading to serious injuries,
damages to your phone, or other serious hazard
.
Samsung Mobile Products and Recycling
Samsung cares for the environment and encourages its
customers to recycle Samsung mobile devices and genuine
Samsung accessories.
Proper disposal of your mobile device and its battery is not only
important for safety, it benefits the environment. Batteries must
be recycled or disposed of properly.
Recycling programs for your mobile device, batteries, and
accessories may not be available in your area.
We've made it easy for you to recycle your old Samsung mobile
device by working with respected take-back companies in every
state in the country.
Drop It Off
You can drop off your Samsung-branded mobile device and
batteries for recycling at one of our numerous Samsung
Recycling Direct (SM) locations. A list of these locations may
be found at:
http://pages.samsung.com/us/recyclingdirect/
usactivities_environment_samsungrecyclingdirect_locations.jsp
.
Samsung-branded devices and batteries will be accepted at
these locations for no fee.
Consumers may also recycle their used mobile device or
batteries at many retail or carrier-provided locations where
mobile devices and batteries are sold. Additional information
regarding specific locations may be found at:
http://www.epa.gov/epawaste/partnerships/plugin/cellphone/
index.htm
or at
http://www.call2recycle.org/
.
Mail It In
The Samsung Mobile Take-Back Program will provide
Samsung customers with a free recycling mailing label. Just
go to
http://www.samsung.com/us/aboutsamsung/citizenship/
usactivities_environment_samsungrecyclingdirect.html?INT=STA_r
ecyle_your_phone_page
and follow the instructions to print out
a free pre-paid postage label and then send your old mobile
device or battery to the address listed, via U.S. Mail, for
recycling.
Dispose of unwanted electronics through an approved
recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect
Or call, (877) 278-0799.
104
Follow local regulations regarding disposal of mobile devices
and batteries
Dispose of your mobile device and batteries in accordance with
local regulations. In some areas, the disposal of these items in
household or business trash may be prohibited. Help us protect
the environment - recycle!
Warning!
Never dispose of batteries in a fire because they may
explode.
UL Certified Travel Charger
The Travel Charger for this phone has met applicable UL safety
requirements. Please adhere to the following safety instructions
per UL guidelines:
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY
LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN NORTH
AMERICA, USE AN ATTACHMENT PLUG ADAPTOR OF
THE PROPER CONFIGURATION FOR THE POWER
OUTLET.
THIS POWER UNIT IS INTENDED TO BE CORRECTLY
ORIENTED IN A VERTICAL OR HORIZONTAL OR FLOOR
MOUNT POSITION.
Display / Touch-Screen
Please note the following information when using your mobile
device:
WARNING REGARDING DISPLAY
The display on your mobile device is made of glass or
acrylic and could break if your mobile device is dropped or
if it receives significant impact. Do not use if screen is
broken or cracked as this could cause injury to you.
WARRANTY DISCLAIMER: PROPER USE OF A TOUCH-SCREEN
MOBILE DEVICE
If your mobile device has a touch-screen display, please
note that a touch-screen responds best to a light touch
from the pad of your finger or a non-metallic stylus. Using
excessive force or a metallic object when pressing on the
touch-screen may damage the tempered glass surface
and void the warranty. For more information, please refer
to the “Standard Limited Warranty”.
Health and Safety Information 105
GPS & AGPS
Certain Samsung mobile devices can use a Global Positioning
System (GPS) signal for location-based applications. A GPS uses
satellites controlled by the U.S. Government that are subject to
changes implemented in accordance with the Department of
Defense policy and the 2008 Federal Radio navigation Plan (FRP).
Changes may affect the performance of location-based
technology on your mobile device.
Certain Samsung mobile devices can also use an Assisted Global
Positioning System (AGPS), which obtains information from the
cellular network to improve GPS performance. AGPS uses your
wireless service provider's network and therefore airtime, data
charges, and/or additional charges may apply in accordance with
your service plan. Contact your wireless service provider for
details.
Your Location
Location-based information includes information that can be
used to determine the approximate location of a mobile device.
Mobile devices which are connected to a wireless network
transmit location-based information. Additionally, if you use
applications that require location-based information (e.g. driving
directions), such applications transmit location-based
information. The location-based information may be shared with
third-parties, including your wireless service provider,
applications providers, Samsung, and other third-parties
providing services.
Use of AGPS in Emergency Calls
When you make an emergency call, the cellular network may
activate AGPS technology in your mobile device to tell the
emergency responders your approximate location.
AGPS has limitations and
might not work in your area
. Therefore:
Always tell the emergency responder your location to the best of your
ability; and
Remain on the mobile device for as long as the emergency responder
instructs you.
Navigation
Maps, directions, and other navigation-data, including data
relating to your current location, may contain inaccurate or
incomplete data, and circumstances can and do change over
time. In some areas, complete information may not be available.
Therefore,
you should always visually confirm that the
navigational instructions are consistent with what you see before
following them. All users should pay attention to road conditions,
closures, traffic, and all other factors that may impact safe driving
or walking. Always obey posted road signs
.
106
Emergency Calls
This mobile device, like any wireless mobile device, operates
using radio signals, wireless and landline networks, as well as
user-programmed functions, which cannot guarantee connection
in all conditions, areas, or circumstances.
Therefore, you should never rely solely on any wireless mobile
device for essential communications (medical emergencies, for
example). Before traveling in remote or underdeveloped areas,
plan an alternate method of contacting emergency services
personnel. Remember, to make or receive any calls, the mobile
device must be switched on and in a service area with adequate
signal strength.
Emergency calls may not be possible on all wireless mobile
device networks or when certain network services and/or mobile
device features are in use. Check with local service providers.
To make an emergency call:
1. If the mobile device is not on, switch it on.
2. Key in the emergency number for your present location (for
example, 911 or other official emergency number).
Emergency numbers vary by location.
3. Press the “Send” key.
If certain features are in use (call blocking, for example), you may
first need to deactivate those features before you can make an
emergency call. Consult your User Manual and your local cellular
service provider. When making an emergency call, remember to
give all the necessary information as accurately as possible.
Remember that your mobile device may be the only means of
communication at the scene of an accident; do not cut off the call
until given permission to do so.
Care and Maintenance
Your mobile device is a product of superior design and
craftsmanship and should be treated with care. The suggestions
below will help you fulfill any warranty obligations and allow you
to enjoy this product for many years:
Keep your Samsung Mobile Device away from:
Liquids of any kind
Keep the mobile device dry. Precipitation, humidity, and
liquids contain minerals that will corrode electronic circuits. If
the mobile device does get wet, do not accelerate drying with
the use of an oven, microwave, or dryer, because this may
damage the mobile device and could cause a fire or
explosion.
Do not use the mobile device with a wet hand. Doing so may
cause an electric shock to you or damage to the mobile
device.
Health and Safety Information 107
Extreme heat or cold
Avoid temperatures below 0°C / 32°F or above 45°C / 113°F.
Microwaves
Do not try to dry your mobile device in a microwave oven.
Doing so may cause a fire or explosion.
Dust and dirt
Do not expose your mobile device to dust, dirt, or sand.
Cleaning solutions
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the mobile device. Wipe it with a soft
cloth slightly dampened in a mild soap-and-water solution.
Shock or vibration
Do not drop, knock, or shake the mobile device. Rough
handling can break internal circuit boards.
Paint
Do not paint the mobile device. Paint can clog the device’s
moving parts or ventilation openings and prevent proper
operation.
Responsible Listening
Caution! Avoid potential hearing loss
.
Damage to hearing occurs when a person is exposed to loud
sounds over time. The risk of hearing loss increases as sound is
played louder and for longer durations. Prolonged exposure to
loud sounds (including music) is the most common cause of
preventable hearing loss. Some scientific research suggests that
using portable audio devices, such as portable music players and
cell phones, at high volume settings for long durations may lead
to permanent noise-induced hearing loss.
This includes the use of headphones (including headsets,
earbuds, and Bluetooth® or other wireless devices). Exposure to
very loud sound has also been associated in some studies with
tinnitus (a ringing in the ear), hypersensitivity to sound, and
distorted hearing. Individual susceptibility to noise-induced
hearing loss and potential hearing problem varies. Additionally,
the amount of sound produced by a portable audio device varies
depending on the nature of the sound, the device settings, and
the headphones that are used. As a result, there is no single
volume setting that is appropriate for everyone or for every
combination of sound, settings, and equipment.
You should follow some common sense recommendations when
using any portable audio device:
Always turn the volume down before plugging the earphones into an
audio source.
108
Set the volume in a quiet environment and select the lowest volume at
which you can hear adequately.
Be aware that you can adapt to higher volume settings over time, not
realizing that the higher volume may be harmful to your hearing.
When using headphones, turn the volume down if you cannot hear the
people speaking near you or if the person sitting next to you can hear
what you are listening to.
Do not turn the volume up to block out noisy surroundings. If you
choose to listen to your portable device in a noisy environment, use
noise-cancelling headphones to block out background environmental
noise. By blocking background environment noise, noise cancelling
headphones should allow you to hear the music at lower volumes than
when using earbuds.
Limit the amount of time you listen. As the volume increases, less
time is required before you hearing could be affected.
Avoid using headphones after exposure to extremely loud noises, such
as rock concerts, that might cause temporary hearing loss. Temporary
hearing loss might cause unsafe volumes to sound normal.
Do not listen at any volume that causes you discomfort. If you
experience ringing in your ears, hear muffled speech, or experience
any temporary hearing difficulty after listening to your portable audio
device, discontinue use and consult your doctor.
You can obtain additional information on this subject from the
following sources:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: (800) 222-2336
Email: info@audiology.org
Internet:
http://www.audiology.org/Pages/default.aspx
National Institute on Deafness and Other
Communication Disorders
National Institutes of Health
31 Center Drive, MSC 2320
Bethesda, MD 20892-2320
Email: nidcdinfo@nih.gov
Internet:
http://www.nidcd.nih.gov/
Health and Safety Information 109
Operating Environment
Remember to follow any special regulations in force in any area,
and always switch your mobile device off whenever it is
forbidden to use it, or when it may cause interference or danger.
When connecting the mobile device or any accessory to another
device, read its user's guide for detailed safety instructions. Do
not connect incompatible products.
Using Your Mobile Device Near Other Electronic Devices
Most modern electronic equipment is shielded from Radio
Frequency (RF) signals. However, certain electronic equipment
may not be shielded against the RF signals from your wireless
mobile device. Consult the manufacturer to discuss alternatives.
Implantable Medical Devices
A minimum separation of six (6) inches should be maintained
between a handheld wireless mobile device and an implantable
medical device, such as a pacemaker or implantable cardioverter
defibrillator, to avoid potential interference with the device.
Persons who have such devices:
Should ALWAYS keep the mobile device more than six (6) inches from
their implantable medical device when the mobile device is turned ON;
Should not carry the mobile device in a breast pocket;
Should use the ear opposite the implantable medical device to
minimize the potential for interference;
Should turn the mobile device OFF immediately if there is any reason
to suspect that interference is taking place;
Should read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using
your wireless mobile device with an implantable medical device,
consult your health care provider.
National Institute for Occupational Safety and
Health (NIOSH)
395 E Street, S.W., Suite 9200
Patriots Plaza Building
Washington, DC 20201
Voice: 1-800-35-NIOSH (1-800-356-4674)
1-800-CDC-INFO (1-800-232-4636)
Outside the U.S. 513-533-8328
Email: cdcinfo@cdc.gov
Internet:
http://www.cdc.gov/niosh/topics/noise/
default.html
1-888-232-6348 TTY
110
For more information see:
http://www.fcc.gov/oet/rfsafety/rf-
faqs.html#
.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information. Switch your mobile
device off in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with the
manufacturer or its representative regarding your vehicle before
using your mobile device in a motor vehicle. You should also
consult the manufacturer of any equipment that has been added
to your vehicle.
Posted Facilities
Switch your mobile device off in any facility where posted notices
require you to do so.
Potentially Explosive Environments
Switch your mobile device off when in any area with a potentially
explosive atmosphere and obey all signs and instructions. Sparks
in such areas could cause an explosion or fire resulting in bodily
injury or even death. Users are advised to switch the mobile
device off while at a refueling point (service station).
Users are reminded of the need to observe restrictions on the use
of radio equipment in fuel depots (fuel storage and distribution
areas), chemical plants, or where blasting operations are in
progress. Areas with a potentially explosive atmosphere are
often, but not always, clearly marked. They include below deck
on boats, chemical transfer or storage facilities, vehicles using
liquefied petroleum gas (such as propane or butane), areas
where the air contains chemicals or particles, such as grain,
dust, or metal powders, and any other area where you would
normally be advised to turn off your vehicle engine.
When your Device is Wet
Do not turn on your device if it is wet. If your device is already on,
turn it off and remove the battery immediately (if the device will
not turn off or you cannot remove the battery, leave it as-is).
Then, dry the device with a towel and take it to a service center.
Health and Safety Information 111
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices
The U.S. Federal Communications Commission (FCC) has
established requirements for digital wireless mobile devices to be
compatible with hearing aids and other assistive hearing devices.
When individuals employing some assistive hearing devices
(hearing aids and cochlear implants) use wireless mobile
devices, they may detect a buzzing, humming, or whining noise.
Some hearing devices are more immune than others to this
interference noise, and mobile devices also vary in the amount of
interference they generate.
The wireless telephone industry has developed a rating system
for wireless mobile devices to assist hearing device users find
mobile devices that may be compatible with their hearing
devices. Not all mobile devices have been rated. Mobile devices
that are rated have the rating on their box or a label located on
the box.
The ratings are not guarantees. Results will vary depending on
the user's hearing device and hearing loss. If your hearing device
happens to be vulnerable to interference, you may not be able to
use a rated mobile device successfully. Trying out the mobile
device with your hearing device is the best way to evaluate it for
your personal needs.
M-Ratings
: Wireless mobile devices rated M3 or M4 meet FCC
requirements and are likely to generate less interference to
hearing devices than mobile devices that are not labeled. M4 is
the better/higher of the two ratings. M-ratings refer to enabling
acoustic coupling with hearing aids that do not operate in telecoil
mode.
T-Ratings
: Mobile devices rated T3 or T4 meet FCC requirements
and are likely to generate less interference to hearing devices
than mobile devices that are not labeled. T4 is the better/higher
of the two ratings. T-ratings refer to enabling inductive coupling
with hearing aids operating in telecoil mode.
Hearing devices may also be rated. Your hearing aid
manufacturer or hearing health professional may help you find
this rating. Higher ratings mean that the hearing device is
relatively immune to interference noise.
Under the current industry standard, American National
Standards Institute (ANSI) C63.19, the hearing aid and wireless
mobile device rating values are added together to indicate how
usable they are together. For example, if a hearing aid meets the
M2 level rating and the wireless mobile device meets the M3
level rating, the sum of the two values equals M5.
112
Under the standard, this should provide the hearing aid user with
normal use while using the hearing aid with the particular
wireless mobile device. A sum of 6 or more would indicate
excellent performance.
However, these are not guarantees that all users will be satisfied.
T ratings work similarly.
The HAC rating and measurement procedure are described in the
American National Standards Institute (ANSI) C63.19 standard.
Restricting Children's Access to Your Mobile
Device
Your mobile device is not a toy. Do not allow children to play with
it because they could hurt themselves and others, damage the
mobile device, or make calls that increase your mobile device
bill.
Keep the mobile device and all its parts and accessories out of
the reach of small children.
FCC Notice and Cautions
FCC Notice
The mobile device may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can require you
to stop using the mobile device if such interference cannot be
eliminated. Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact the
National Fire Protection Association.
Cautions
Any changes or modifications to your mobile device not expressly
approved in this document could void your warranty for this
equipment and void your authority to operate this equipment.
Only use approved batteries, antennas, and chargers. The use of
M3 + M2 = 5
T3 + T2 = 5
Health and Safety Information 113
any unauthorized accessories may be dangerous and void the
mobile device warranty if said accessories cause damage or a
defect to the mobile device.
Although your mobile device is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending, or sitting on it.
Other Important Safety Information
Only qualified personnel should service the mobile device or install the
mobile device in a vehicle. Faulty installation or service may be
dangerous and may invalidate any warranty applicable to the device.
Ensure that any mobile devices or related equipment installed in your
vehicle are securely mounted.
Check regularly that all wireless mobile device equipment in your
vehicle is mounted and operating properly.
When using a headset in dry environments, static electricity can build
up in the headset and cause a small quick static electrical shock. To
minimize the risk of electrostatic discharge from the headset avoid
using the headset in extremely dry environments or touch a grounded
unpainted metal object to discharge static electricity before inserting
the headset.
Do not store or carry flammable liquids, gases, or explosive materials
in the same compartment as the mobile device, its parts, or
accessories.
For vehicles equipped with an air bag, remember that an air bag
inflates with great force. Do not place objects, including installed or
portable wireless equipment near or in the area over the air bag or in
the air bag deployment area. If wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
Switch your mobile device off before boarding an aircraft. The use of
wireless mobile devices in aircraft is illegal and may be dangerous to
the aircraft's operation. Check with appropriate authorities before
using any function of a mobile device while on an aircraft.
Failure to observe these instructions may lead to the suspension or
denial of cell phone services to the offender, or legal action, or both.
While using your device, leave some lights on in the room and do not
hold the screen too close to your eyes.
Seizures or blackouts can occur when you are exposed to flashing
lights while watching videos or playing games for extended periods. If
you feel any discomfort, stop using the device immediately.
114
Reduce risk of repetitive motion injuries. When you repetitively
perform actions, such as pressing keys, drawing characters on a
touch screen with your fingers, or playing games, you may experience
occasional discomfort in your hands, neck, shoulders, or other parts of
your body. When using your device for extended periods, hold the
device with a relaxed grip, press the keys lightly, and take frequent
breaks. If you continue to have discomfort during or after such use,
stop use and see a physician.
If your device has a camera flash or light, do not use the flash or light
close to the eyes of people or pets. [122011]
Warranty Information 115
Section 12: Warranty Information
Standard Limited Warranty
What is covered and for how long?
SAMSUNG TELECOMMUNICATIONS AMERICA, LLC (“SAMSUNG”)
warrants that SAMSUNG’s handsets and accessories (“Products”)
are free from defects in material and workmanship under normal
use and service for the period commencing upon the date of
purchase by the first consumer purchaser and continuing for the
following specified period of time after that date:
What is not covered?
This Limited Warranty is conditioned upon proper use of the
Product.
This Limited Warranty does not cover: (a) defects or damage
resulting from accident, misuse, abnormal use, abnormal
conditions, improper storage, exposure to liquid, moisture,
dampness, sand or dirt, neglect, or unusual physical, electrical or
electromechanical stress; (b) scratches, dents and cosmetic
damage, unless caused by SAMSUNG; (c) defects or damage
resulting from excessive force or use of a metallic object when
pressing on a touch screen; (d) equipment that has the serial
number or the enhancement data code removed, defaced,
damaged, altered or made illegible; (e) ordinary wear and tear;
(f) defects or damage resulting from the use of Product in
conjunction or connection with accessories, products, or
ancillary/peripheral equipment not furnished or approved by
SAMSUNG; (g) defects or damage resulting from improper
testing, operation, maintenance, installation, service, or
adjustment not furnished or approved by SAMSUNG; (h) defects
or damage resulting from external causes such as collision with
an object, fire, flooding, dirt, windstorm, lightning, earthquake,
exposure to weather conditions, theft, blown fuse, or improper
use of any electrical source; (i) defects or damage resulting from
cellular signal reception or transmission, or viruses or other
software problems introduced into the Product; or (j) Product
used or purchased outside the United States. This Limited
Warranty covers batteries only if battery capacity falls below 80%
of rated capacity or the battery leaks, and this Limited Warranty
does not cover any battery if (i) the battery has been charged by
a battery charger not specified or approved by SAMSUNG for
Phone 1 Year
Batteries 1 Year
Case/Pouch/Holster 90 Days
Other Phone Accessories 1 Year
116
charging the battery; (ii) any of the seals on the battery are
broken or show evidence of tampering; or (iii) the battery has
been used in equipment other than the SAMSUNG phone for
which it is specified.
What are SAMSUNG’s obligations?
During the applicable warranty period, provided the Product is
returned in accordance with the terms of this Limited Warranty,
SAMSUNG will repair or replace the Product, at SAMSUNG’s sole
option, without charge. SAMSUNG may, at SAMSUNG’s sole
option, use rebuilt, reconditioned, or new parts or components
when repairing any Product, or may replace the Product with a
rebuilt, reconditioned or new Product.
Repaired/replaced cases, pouches and holsters will be warranted
for a period of ninety (90) days. All other repaired/replaced
Products will be warranted for a period equal to the remainder of
the original Limited Warranty on the original Product or for ninety
(90) days, whichever is longer. All replaced Products, parts,
components, boards and equipment shall become the property of
SAMSUNG. Except to any extent expressly allowed by applicable
law, transfer or assignment of this Limited Warranty is prohibited.
What must you do to obtain warranty service?
To obtain service under this Limited Warranty, you must return
the Product to an authorized phone service facility in an adequate
container for shipping, accompanied by the sales receipt or
comparable proof of sale showing the original date of purchase,
the serial number of the Product and the seller’s name and
address.
To obtain assistance on where to deliver the Product, please call
SAMSUNG Customer Care at 1-888-987-4357. If SAMSUNG
determines that any Product is not covered by this Limited
Warranty, you must pay all parts, shipping, and labor charges for
the repair or return of such Product.
You should keep a separate backup copy of any contents of the
Product before delivering the Product to SAMSUNG for warranty
service, as some or all of the contents may be deleted or
reformatted during the course of warranty service.
What are the limits on SAMSUNG’s liability?
THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF
SAMSUNG’S RESPONSIBILITIES, AND THE EXCLUSIVE REMEDY
REGARDING THE PRODUCTS.
ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION,
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY. IN NO EVENT SHALL SAMSUNG BE
LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT OR FOR, WITHOUT LIMITATION, COMMERCIAL
LOSS OF ANY SORT; LOSS OF USE, TIME, DATA, REPUTATION,
OPPORTUNITY, GOODWILL, PROFITS OR SAVINGS;
Warranty Information 117
INCONVENIENCE; INCIDENTAL, SPECIAL, CONSEQUENTIAL OR
PUNITIVE DAMAGES; OR DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THE PRODUCT. SOME STATES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, OR THE DISCLAIMER OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS AND DISCLAIMERS MAY NOT APPLY TO YOU.
SAMSUNG MAKES NO WARRANTIES OR REPRESENTATIONS,
EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO THE
QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE OR
SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR EQUIPMENT
USED IN CONJUNCTION WITH THE PRODUCT, OR THE ABILITY TO
INTEGRATE ANY SUCH SOFTWARE OR EQUIPMENT WITH THE
PRODUCT, WHETHER SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT IS INCLUDED WITH THE PRODUCT DISTRIBUTED BY
SAMSUNG OR OTHERWISE. RESPONSIBILITY FOR THE QUALITY,
CAPABILITIES, OPERATIONS, PERFORMANCE AND SUITABILITY OF
ANY SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS
SOLELY WITH THE USER AND THE DIRECT VENDOR, OWNER OR
SUPPLIER OF SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT.
Nothing in the Product instructions or information shall be
construed to create an express warranty of any kind with respect
to the Products. No agent, employee, dealer, representative or
reseller is authorized to modify or extend this Limited Warranty or
to make binding representations or claims, whether in
advertising, presentations or otherwise, on behalf of SAMSUNG
regarding the Products or this Limited Warranty.
This Limited Warranty gives you specific legal rights, and you
may also have other rights that vary from state to state.
What is the procedure for resolving disputes?
ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY FROM THIS
LIMITED WARRANTY OR THE SALE, CONDITION OR
PERFORMANCE OF THE PRODUCTS SHALL BE RESOLVED
EXCLUSIVELY THROUGH FINAL AND BINDING ARBITRATION, AND
NOT BY A COURT OR JURY.
Any such dispute shall not be combined or consolidated with a
dispute involving any other person’s or entity’s Product or claim,
and specifically, without limitation of the foregoing, shall not
under any circumstances proceed as part of a class action. The
arbitration shall be conducted before a single arbitrator, whose
award may not exceed, in form or amount, the relief allowed by
the applicable law. The arbitration shall be conducted according
to the American Arbitration Association (AAA) Commercial
Arbitration Rules applicable to consumer disputes. This
arbitration provision is entered pursuant to the Federal Arbitration
Act. The laws of the State of Texas, without reference to its
choice of laws principles, shall govern the interpretation of the
Limited Warranty and all disputes that are subject to this
118
arbitration provision. The arbitrator shall decide all issues of
interpretation and application of this arbitration provision and the
Limited Warranty.
For any arbitration in which your total damage claims, exclusive
of attorney fees and expert witness fees, are $5,000.00 or less
(“Small Claim”), the arbitrator may, if you prevail, award your
reasonable attorney fees, expert witness fees and costs as part
of any award, but may not grant SAMSUNG its attorney fees,
expert witness fees or costs unless it is determined that the claim
was brought in bad faith. In a Small Claim case, you shall be
required to pay no more than half of the total administrative,
facility and arbitrator fees, or $50.00 of such fees, whichever is
less, and SAMSUNG shall pay the remainder of such fees.
Administrative, facility and arbitrator fees for arbitrations in
which your total damage claims, exclusive of attorney fees and
expert witness fees, exceed $5,000.00 (“Large Claim”) shall be
determined according to AAA rules. In a Large Claim case, the
arbitrator may grant to the prevailing party, or apportion among
the parties, reasonable attorney fees, expert witness fees and
costs. Judgment may be entered on the arbitrator’s award in any
court of competent jurisdiction.
This arbitration provision also applies to claims against
SAMSUNG’s employees, representatives and affiliates if any such
claim arises from the Product’s sale, condition or performance.
You may opt out of this dispute resolution procedure by providing
notice to SAMSUNG no later than 30 calendar days from the date of
the first consumer purchaser’s purchase of the Product. To opt out,
you must send notice by e-mail to optout@sta.samsung.com, with
the subject line: “Arbitration Opt Out.” You must include in the opt
out e-mail (a) your name and address; (b) the date on which the
Product was purchased; (c) the Product model name or model
number; and (d) the IMEI or MEID or Serial Number, as applicable, if
you have it (the IMEI or MEID or Serial Number can be found (i) on
the Product box; (ii) on the Product information screen, which can
be found under “Settings;” (iii) on a label on the back of the
Product beneath the battery, if the battery is removable; and (iv) on
the outside of the Product if the battery is not removable).
Alternatively, you may opt out by calling 1-888-987-4357 no later
than 30 calendar days from the date of the first consumer
purchaser’s purchase of the Product and providing the same
information. These are the only two forms of notice that will be
effective to opt out of this dispute resolution procedure. Opting out
of this dispute resolution procedure will not affect the coverage of
the Limited Warranty in any way, and you will continue to enjoy the
benefits of the Limited Warranty.
Severability
If any portion of this Limited Warranty is held to be illegal or
unenforceable, such partial illegality or unenforceability shall not
affect the enforceability of the remainder of the Limited Warranty.
Warranty Information 119
Precautions for Transfer and Disposal
If data stored on this device is deleted or reformatted using the
standard methods, the data only appears to be removed on a
superficial level, and it may be possible for someone to retrieve
and reuse the data by means of special software.
To avoid unintended information leaks and other problems of this
sort, it is recommended that the device be returned to Samsung’s
Customer Care Center for an Extended File System (EFS) Clear
which will eliminate all user memory and return all settings to
default settings. Please contact the
Samsung Customer Care
Center
for details.
Important!
Please provide warranty information (proof of
purchase) to Samsung’s Customer Care Center in order
to provide this service at no charge. If the warranty has
expired on the device, charges may apply.
Samsung Telecommunications America, LLC
1301 E. Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2012 Samsung Telecommunications America, LLC. All rights
reserved.
No reproduction in whole or in part allowed without prior written
approval. Specifications and availability subject to change
without notice. [111611]
End User License Agreement for Software
IMPORTANT. READ CAREFULLY: This End User License Agreement
(“EULA”) is a legal agreement between you (either an individual
or a single entity) and Samsung Electronics Co., Ltd. for software
owned by Samsung Electronics Co., Ltd. and its affiliated
companies and its third party suppliers and licensors that
accompanies this EULA, which includes computer software and
may include associated media, printed materials, “online” or
electronic documentation (“Software”).
BY CLICKING THE “I ACCEPT” BUTTON (OR IF YOU BYPASS OR
OTHERWISE DISABLE THE “I ACCEPT”, AND STILL INSTALL,
COPY, DOWNLOAD, ACCESS OR OTHERWISE USE THE
SOFTWARE), YOU AGREE TO BE BOUND BY THE TERMS OF THIS
EULA. IF YOU DO NOT ACCEPT THE TERMS IN THIS EULA, YOU
MUST CLICK THE “DECLINE” BUTTON, AND DISCONTINUE USE
OF THE SOFTWARE.
1. GRANT OF LICENSE. Samsung grants you the following rights
provided that you comply with all terms and conditions of this
EULA: You may install, use, access, display and run one copy of
the Software on the local hard disk(s) or other permanent storage
media of one computer and use the Software on a single
computer or a mobile device at a time, and you may not make
120
the Software available over a network where it could be used by
multiple computers at the same time. You may make one copy of
the Software in machine-readable form for backup purposes
only; provided that the backup copy must include all copyright or
other proprietary notices contained on the original.
2. RESERVATION OF RIGHTS AND OWNERSHIP. Samsung reserves
all rights not expressly granted to you in this EULA. The Software
is protected by copyright and other intellectual property laws and
treaties. Samsung or its suppliers own the title, copyright and
other intellectual property rights in the Software. The Software is
licensed, not sold.
3. LIMITATIONS ON END USER RIGHTS. You may not reverse
engineer, decompile, disassemble, or otherwise attempt to
discover the source code or algorithms of, the Software (except
and only to the extent that such activity is expressly permitted by
applicable law not withstanding this limitation), or modify, or
disable any features of, the Software, or create derivative works
based on the Software. You may not rent, lease, lend, sublicense
or provide commercial hosting services with the Software.
4. CONSENT TO USE OF DATA. You agree that Samsung and its
affiliates may collect and use technical information gathered as
part of the product support services related to the Software
provided to you, if any, related to the Software. Samsung may
use this information solely to improve its products or to provide
customized services or technologies to you and will not disclose
this information in a form that personally identifies you.
5. UPGRADES. This EULA applies to updates, supplements and
add-on components (if any) of the Software that Samsung may
provide to you or make available to you after the date you obtain
your initial copy of the Software, unless we provide other terms
along with such upgrade. To use Software identified as an
upgrade, you must first be licensed for the Software identified by
Samsung as eligible for the upgrade. After upgrading, you may
no longer use the Software that formed the basis for your
upgrade eligibility.
6. SOFTWARE TRANSFER. You may not transfer this EULA or the
rights to the Software granted herein to any third party unless it
is in connection with the sale of the mobile device which the
Software accompanied. In such event, the transfer must include
all of the Software (including all component parts, the media and
printed materials, any upgrades, this EULA) and you may not
retain any copies of the Software. The transfer may not be an
indirect transfer, such as a consignment. Prior to the transfer, the
end user receiving the Software must agree to all the EULA
terms.
7. EXPORT RESTRICTIONS. You acknowledge that the Software is
subject to export restrictions of various countries. You agree to
comply with all applicable international and national laws that
Warranty Information 121
apply to the Software, including the U.S. Export Administration
Regulations, as well as end user, end use, and destination
restrictions issued by U.S. and other governments.
8. TERMINATION. This EULA is effective until terminated. Your
rights under this License will terminate automatically without
notice from Samsung if you fail to comply with any of the terms
and conditions of this EULA. Upon termination of this EULA, you
must cease all use of the Software and destroy all copies, full or
partial, of the Software.
9. THIRD-PARTY APPLICATIONS. Certain third-party applications
may be included with, or downloaded to this mobile device.
SAMSUNG makes no representations whatsoever about any of
these applications. Since SAMSUNG has no control over such
applications, Purchaser acknowledges and agrees that
SAMSUNG is not responsible for the availability of such
applications and is not responsible or liable for any content,
advertising, products, services, or other materials on or available
from such applications. Purchaser expressly acknowledges and
agrees that use of third-party applications is at Purchaser’s sole
risk and that the entire risk of unsatisfactory quality,
performance, accuracy and effort is with Purchaser. It is up to
Purchaser to take precautions to ensure that whatever Purchaser
selects to use is free of such items as viruses, worms, Trojan
horses, and other items of a destructive nature. References on
this mobile device to any names, marks, products, or services of
any third-parties are provided solely as a convenience to
Purchaser, and do not constitute or imply an endorsement,
sponsorship, or recommendation of, or affiliation with the
third-party or its products and services. Purchaser agrees that
SAMSUNG shall not be responsible or liable, directly or indirectly,
for any damage or loss caused or alleged to caused by, or in
connection with, use of or reliance on any such third-party
content, products, or services available on or through any such
application. Purchaser acknowledges and agrees that your use of
any third-party application is governed by such third-party
application provider’s Terms of Use, License Agreement, Privacy
Policy, or other such agreement and that any information or
personal data you provide, whether knowingly or unknowingly, to
such third-party application provider, will be subject to such
third-party application provider’s privacy policy, if such a policy
exists. SAMSUNG DISCLAIMS ANY RESPONSIBILITY FOR ANY
DISCLOSURE OF INFORMATION OR ANY OTHER PRACTICES OF
ANY THIRD-PARTY APPLICATION PROVIDER.
10. Disclaimer of Warranty Regarding Third-Party Applications.
SAMSUNG DOES NOT WARRANT OR MAKE ANY
REPRESENTATIONS REGARDING THE AVAILABILITY, USE,
TIMELINESS, SECURITY, VALIDITY, ACCURACY, OR RELIABILITY OF,
OR THE RESULTS OF THE USE OF, OR OTHERWISE RESPECTING,
THE CONTENT OF ANY THIRD-PARTY APPLICATION WHETHER
SUCH THIRD-PARTY APPLICATION IS INCLUDED WITH THE
122
PRODUCT DISTRIBUTED BY SAMSUNG, IS DOWNLOADED, OR
OTHERWISE OBTAINED. USE OF ANY THIRD-PARTY APPLICATION
IS DONE AT PURCHASER’S OWN DISCRETION AND RISK AND
PURCHASER IS SOLELY RESPONSIBLE FOR ANY DAMAGE TO
YOUR MOBILE DEVICE OR LOSS OF DATA THAT RESULTS FROM
THE DOWNLOADING OR USE OF SUCH THIRD-PARTY
APPLICATIONS. SAMSUNG EXPRESSLY DISCLAIMS ANY
WARRANTY REGARDING WHETHER PURCHASER’S PERSONAL
INFORMATION IS CAPTURED BY ANY THIRD-PARTY APPLICATION
PROVIDER OR THE USE TO WHICH SUCH PERSONAL
INFORMATION MAY BE PUT BY SUCH THIRD-PARTY APPLICATION
PROVIDER. ANY THIRD-PARTY APPLICATIONS PROVIDED WITH
THIS MOBILE DEVICE ARE PROVIDED “AS IS” AND ON AN “AS
AVAILABLE” BASIS, WITHOUT WARRANTIES OF ANY KIND FROM
SAMSUNG, EITHER EXPRESS OR IMPLIED. TO THE FULLEST
EXTENT POSSIBLE PURSUANT TO APPLICABLE LAW, SAMSUNG
DISCLAIMS ALL WARRANTIES EXPRESS, IMPLIED, OR
STATUTORY, INCLUDING, BUT NOT LIMITED TO, IMPLIED
WARRANTIES OF MERCHANTABILITY, SATISFACTORY QUALITY OR
WORKMANLIKE EFFORT, FITNESS FOR A PARTICULAR PURPOSE,
RELIABILITY OR AVAILABILITY, ACCURACY, LACK OF VIRUSES,
QUIET ENJOYMENT, NON-INFRINGEMENT OF THIRD PARTY
RIGHTS OR OTHER VIOLATION OF RIGHTS. SAMSUNG DOES NOT
WARRANT AGAINST INTERFERENCE WITH YOUR ENJOYMENT OF
THE THIRD-PARTY APPLICATION, THAT THE FUNCTIONS
CONTAINED IN THE THIRD-PARTY APPLICATION WILL MEET
PURCHASER’S REQUIREMENTS, THAT THE OPERATION OF THE
THIRD-PARTY APPLICATION WILL BE UNINTERRUPTED OR
ERROR-FREE, OR THAT DEFECTS IN THE THIRD-PARTY
APPLICATION WILL BE CORRECTED. PURCHASER ASSUMES THE
ENTIRE COST OF ALL NECESSARY SERVICING, REPAIR, OR
CORRECTION. SOME JURISDICTIONS DO NOT ALLOW
EXCLUSIONS OR LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS
MAY NOT APPLY TO YOU. NO ADVICE OR INFORMATION,
WHETHER ORAL OR WRITTEN, OBTAINED BY PURCHASER FROM
SAMSUNG SHALL BE DEEMED TO ALTER THIS DISCLAIMER OF
WARRANTY REGARDING THIRD-PARTY APPLICATIONS, OR TO
CREATE ANY WARRANTY.
11. Limitation of Liability. SAMSUNG WILL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND ARISING OUT OF OR RELATING TO
THE USE OR THE INABILITY TO USE ANY THIRD-PARTY
APPLICATION, ITS CONTENT OR FUNCTIONALITY, INCLUDING BUT
NOT LIMITED TO DAMAGES CAUSED BY OR RELATED TO
ERRORS, OMISSIONS, INTERRUPTIONS, DEFECTS, DELAY IN
OPERATION OR TRANSMISSION, COMPUTER VIRUS, FAILURE TO
CONNECT, NETWORK CHARGES, AND ALL OTHER DIRECT,
INDIRECT, SPECIAL, INCIDENTAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES EVEN IF SAMSUNG HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME
Warranty Information 123
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. NOT
WITHSTANDING THE FOREGOING, SAMSUNG’S TOTAL LIABILITY
TO PURCHASER FOR ALL LOSSES, DAMAGES, CAUSES OF
ACTION, INCLUDING BUT NOT LIMITED TO THOSE BASED ON
CONTRACT, TORT, OR OTHERWISE, ARISING OUT OF
PURCHASER’S USE OF THIRD-PARTY APPLICATIONS ON THIS
MOBILE DEVICE, OR ANY OTHER PROVISION OF THIS EULA,
SHALL NOT EXCEED THE AMOUNT PURCHASER PAID
SPECIFICALLY FOR ANY SUCH THIRD-PARTY APPLICATION THAT
WAS INCLUDED WITH THIS MOBILE DEVICE. THE FOREGOING
LIMITATIONS, EXCLUSIONS, AND DISCLAIMERS (INCLUDING
SECTIONS 9, 10, AND 11) SHALL APPLY TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY
FAILS ITS ESSENTIAL PURPOSE.
12. U.S. Government End Users Restricted Rights. The Software
is licensed only with "restricted rights" and as "commercial
items" consisting of "commercial software" and "commercial
software documentation" with only those rights as are granted to
all other end users pursuant to the terms and conditions herein.
All Software and Products provided to the United States
Government pursuant to solicitations issued on or after
December 1, 1995 is provided with the commercial rights and
restrictions described elsewhere herein. All Software and
Products provided to the United States Government pursuant to
solicitations issued prior to December 1, 1995 are provided with
RESTRICTED RIGHTS as provided for in FAR, 48 CFR 52.227-14
(JUNE 1987) or DFAR, 48 CFR 252.227-7013 (OCT 1988), as
applicable.
13. APPLICABLE LAW. This EULA is governed by the laws of
TEXAS, without regard to conflicts of laws principles. This EULA
shall not be governed by the UN Convention on Contracts for the
International Sale of Goods, the application of which is expressly
excluded. If a dispute, controversy or difference is not amicably
settled, it shall be finally resolved by arbitration in Seoul, Korea in
accordance with the Arbitration Rules of the Korean Commercial
Arbitration Board. The award of arbitration shall be final and
binding upon the parties.
14. ENTIRE AGREEMENT; SEVERABILITY. This EULA is the entire
agreement between you and Samsung relating to the Software
and supersedes all prior or contemporaneous oral or written
communications, proposals and representations with respect to
the Software or any other subject matter covered by this EULA. If
any provision of this EULA is held to be void, invalid,
unenforceable or illegal, the other provisions shall continue in full
force and effect.
124
Index
Numerics
2-Sec Pause 42
A
Activating Your Phone 8
Adding Contacts
Dial Method 40
Menu Method 40
Adjust
key beep 83
Alerts 83
B
Battery
Charging 7
Installing 6
Low Battery Indicator 8
Removing 7
Battery Use & Safety 101
C
Call Functions
Adjusting the Call Volume 21
Making a Call — Number Entry
Dialing 21
Making a Call — Speed Dialing 23
Call Settings 83
Auto Answer 84
Auto Retry 84
Call Answer 84
TTY Mode 85
Voice Privacy 85
Camera Mode 17
Care and Maintenance 106
Charging the Battery 7
Children and Cell Phones 97
Clock Format 80
CMAS
messages 54
Commercial Mobile Alerting System
(CMAS) 100
Contacts
Adding 40
Adding Speed Dial Numbers 43
Contacts Groups 43
Deleting 42
Editing 41
Finding 38
Memory Info 45
Contacts Groups
Add Contacts 44
Erase 45
Rename 44
Create a Draft Message 52
Create and Send Text Messages 46
D
Dialing Font Size 80
Display / Touch-Screen 104
Display Setting
Dialing Font 80
125
Display Settings
Backlight 81
Banner 81
Clock Format 80
Dialing Font Size 80
Front Contrast 81
Theme 80
Wallpaper 79
Do cell phones pose a health hazard?
94
E
Editing Contacts
Add Pauses 41
Assigning a Ringtone 42
Emergency Alerts Messages
Settings 58
Emergency Calls 21, 106
Exposure to Radio Frequency (RF)
Signals 94
F
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices 111
FCC Notice and Cautions 112
Finding Contacts
Shortcut Key Method 38
Voice Method 39
G
GPS & AGPS 105
H
Health and Safety Information 94
I
Icon Glossary 91
In-Call Options 24
Installing the Battery 6
International Calls 22
L
Language Setting 86
M
Memo Pad
Add a Memo 73
Review, Edit, and Erase Memos
74
Menu, In-Call Options 24
Messages
CMAS 54
Create a Draft Message 52
Create and Send 46
Message Boxes 50
Receive 49
Settings 56
Types 46
Mode
Camera 17
Music Library
launching the menu 63
Music Player 63
controls 65
playing music 65
126
N
Navigation Key Shortcuts 17
O
Operating Environment 109
Other Important Safety Information
113
P
Personal Localized Alerting Network
(PLAN) 100
Personal Organizer
Alarm Clock 74
Calculator 76
Calendar 72
Memo Pad 73
World Time 75
Phone
Command Keys 15
Display Screen 18
Display Screen Icons 19
Features 11
View, Open, Front 14
View,Closed 13
Phone Info 91
Icon Glossary 91
Phone Number 91
software update 92
Version 92
Phone Number 91
Phone Settings
Airplane Mode 86
Language 86
Security 86
Shortcut Key 91
Picture Messages
Send in Camera Mode 47
Settings 57
Playing Music
from Music Player 65
R
Receive Text Messages 49
Record Memos 62
Reducing Exposure
Hands-Free Kits and Other
Accessories 96
Removing the Battery 7
Responsible Listening 107
Restricting Children's Access to Your
Mobile device 112
Ringer Types, Assigning 82
Roaming 28
S
Samsung Mobile Products and Recy-
cling 103
Security Settings 86
Change Lock 87
Emergency # 87
Lock Phone 86
Resetting Your Phone 88
Restriction 89
Send Text Messages 46
Set Time 90
Settings
Call Settings 83
Camera Options 60
Display Settings 79
Phone Settings 85
Security Settings 86
Sound Settings 82
127
Settings, Picture Messages 57
Setup
Location 79
Shortcut to menus 19
Smart Practices While Driving 100
Software update 92
Sound Settings
Alerts 83
Key Tone 83
Ringer Type 82
Volume 82
Specific Absorption Rate (SAR) Certi-
fication Information 98
Speed Dial 23
Speed Dialing
One-Touch Dialing 23
Three Touch Dialing 23
Two-Touch Dialing 23
Standard Limited Warranty 115
T
Taking Pictures 59
Text
Entering Emoticons 37
Entering Numbers 36
Entering Symbols 37
Using Abc Mode 36
Using T9® Word Mode 35
Text Messages
Settings 57
Time, Set 90
Tools
Tools Menu 70
TTY Mode 85
Turning Your Phone
Off 9
On 8
U
UL Certified Travel Charger 104
Understanding this User Manual 4
V
Version 92
Voice Memo
Record Memos 62
Review Memos 63
Voice Messages
About Voice Commands 28
Voice Service 72
Voicemail
Listen 10
Setup 9
W
Wallpaper 79
Warranty Information 115
Y
Your Phone
Turning Off 9
Turning On 8

Navigation menu
