1
S.No.
Name of Item/Description
1.(i).
(ii).
(iii).
(iv).
a.
(i).
(ii).
(iii).
b.
(i).
(ii).
(iii).
(iv).
c.
(i).
(ii).
(iii).
d.
e.
f.
g.
h.
i.
‘MSI’ LAMINAR FLOW SYSTEM MODEL LFS-HERT-42: - The basic
elements of our ultra clean Air System is pre-filters, heavy-duty blowers
assembly, HEPA (High Efficiency Particular Air) filters that filters almost all
impurities of size 0.3 micron and larger. Double filtrated Laminar Flow Air
Blows downward through the worktable at a nominal velocity of approx.
90ft/mt. The Laminar flow air meets the specifications of class 100 of U.S.
Federal Standard 209B.
Construction: - Basic material is ¾” wood which is termite and insect proof,
weather resistant, acoustically superior, structurally strong and dimensionally
stable, chosen specially for its sound & vibration damping characteristics. All
joints are routed (not but joints) and bounded with adhesive secured with
screws/nails. Front and side panel exterior are covered with Formica
Lamination of white color or any color of your choice (subject to availability).
Filter sets is carefully formed, installed and checked for leakage Inside of the
structure is nicely filled with fine filler for smooth surface and then nicely
painted in white enamel paint.
Work Table: - Stainless Steel or Mica top as desired.
Side Panels: - Perspex sheet with anodized/wood frame.
Motor & Blower/ Electric System: - Motor blower assembly running smooth
and silently with minimum noise damping acoustically superior paint etc.
Vibration are controlled by mounting anti vibration device so that precision
work can be carried out or Microscope can be used easily within working
surface. Cap.750cufm. Air ejection velocity: 1640ft/sec. +/-20%. The Control
Panel comprising of Main Switch, UV Light switch, Fluorescent light All the
switches are nicely placed with the Indicator bulbs. Main lead approx.3mtr.
Long is provided. Work on 220/230/V AC mains.
Technical Specifications: Work Area: 2’x2’x2’ Horizontal Laminar Flow, No.
of Pre filters: 1no. No. of HEPA filters: 1no. Illumination: 1x20W Fluorescent
tube/CFL light, Heavy Duty Blower: Blower to ensure minimum vibration on
the work table and Housing etc. Plexiglas transparent front door made from
4/5mm thick Plexiglas. Built in stopcocks for gas, air or vacuum lines.
Complete system as above
Working Size 3’x2’x2’
-do- 4’x2’x2’
-do- 6’x2’x2’
Laminar Air Flow (Horizontal) Complete s. s. Body
Working Size 2’x2’x2’
-do- 3’x2’x2’
-do- 4’x2’x2’
VERTICAL VERSION SAME AS ABOVE BUT
Working Size 2’x2’x2’
-do- 3’x2’x2’
-do- 4’x2’x2’
-do- 6’x2’x2’
Laminar Air Flow (Vertical) Complete s. s. Body
Working Size 2’x2’x2
-do- 3’x2’x2’
-do- 4’x2’x2’
Steriflow Portable Laminar Air Flow for field use
Accessories at extra cost:
S. S. Table in place of Mica top.2’ in wooden LAF
-do- 3’
-do- 4’
-do- 6’
Manometer
FREE INSTALLATION & DEMONSTRATION AT SITE WITH 5-YEAR GUARENTEE
AGAINST ANY MANUFACTURING DEFFECT WITHOUT ELECTRICAL PARTS.
2
2
Laminar flow Clean Bench (Self standing Type) 1200mm LCB-1201V
Make: Daihan Labtech.
ISO 14644-1, ISO Class 5 (Class 100) Standard Compliance HEPA filter
removes 99.99% of 0.3um Particles
Easy to Replace Filter From the Back Panel with maintenance free design
and structure
Laminar Air flow and uniform air velocity provide high clean filter air for
high performance
Built-in Lamps and utilities UV and fluorescent lamp, air and gas cock, power
consent are builted as standard
Filter Replacement warning signal by pressure gauge & Controller
display
Built-in Mesh guard for Filter protection
One touch open front panel for easy maintenance
UV Sterilization with on/off working timer
Option: ULPA Filter 99.999% of 0.3um particle removal
Air Leak Proof Cabinet Structure with high clean stainless steel interior work
station and epoxy powder coated steel exterior for long durability
Tempered Safety Glass Sliding Door for maintain high quality cleanliness and
for protection from UV exposure
Low Noise Level and Vibration Free 56~60dB high efficiency sirocco fan
blower
Microprocessor Digital Controller with LCD back light display
Model LCB-1201V
Dimensions Inner 1190 x 550 x 650
(W x D x H mm) Outer 1350 x 800 x 1880
Air Volume 1350m3 /h
Controller 9 stage velocity control, Total using timer,
UV/FL Lamp on/off
HEPA Filter Class 100, purity 0.3um Particle Removal
99.99%
Prefilter 3~30um Particle Removal
Noise Level 56~60dBA
Light UV 20 W x 1 EA, FL 20W x 1EA
Material Interior Stainless Steel 304
Exterior Epoxy Powder Coated Electro Galvanized
Steel
Door Tempered Safety Glass Sliding Door
Utility Device Air Cock, Gas Cock, 220V Consent
Electric Supply 220V, 50Hz
3.
Laminar flow Clean Bench (self Standing Type) 1200mmLCB-1202H
Make: Daihan Labtech.
Model LCB-1202H
Dimensions Inner 1190 x 550 x 650
(W x D x H mm) Outer 1350 x 800 x 1880
Air Volume 1350m3 /h
Controller 9 stage velocity control, Total using timer,
UV/FL Lamp on/off
HEPA Filter Class 100, purity 0.3um Particle Removal
99.99%
Prefilter 3~30um Particle Removal
Noise Level 56~60dBA
Light UV 20 W x 1 EA, FL 20W x 1EA
Material Interior Stainless Steel 304
Exterior Epoxy Powder Coated Electro Galvanized
Steel
Door Tempered Safety Glass Sliding Door
Utility Device Air Cock, Gas Cock, 220V Consent
Electric Supply 220V, 50Hz
3
4.
(i).
(ii).
(iii).
(iv).
a.
b.
‘MSI’ Biological safety Cabinet Biosafety hood level III Biological Safety
Cabinet are designed as per the US federal Standards of class 100 Laminar Air
flow Biological Safety Cabinets. The equipment is provided with the Burn-out
cabinet for the safety of the operator. Its noise level (max.) 62 dB provides
almost noiseless environment to the operator. Environmental air is drawn by a
balanced Centrifugal blower through pre filters retaining more than 75% of
particles larger than 5 microns and is thrown onto work chamber through high
efficiency HEPA filter.
Pre filters: Fabricated out of washable synthetic non woven media. The material
is moisture-fungus-bacteria and frost resistant and are mounted on sturdy frame.
The filters are DOP tested as per standard BS: 283 I and are 90% efficient down
to 5 micron with IPD 5mm WG at rated flow up to 1000 cfm +/- 20%. HEPA
filters: Standard sizes used are made out of micro glass fiber with aluminum foil
separates and mounted in anodized aluminum frame sealed with epoxy and is
provided with rubber gaskets. HEPA filters 99.97% efficiency down to 0.2-0.3
microns are protected by expanded metal sheet mesh or equivalent material.
Filters are DOP tested with IPD less than 18mm WG and FPd less than 40mm
WG at rated flow up to 1000cfm +/- 20% and also tested as per standard US
Fed. Standard -209B
Blower Unit: Assembly consist of suitable motor as per IS 996-1979 working
on 220V AC 50 Hz single phase, dynamically and statistically balanced blowers
make the unit least vibrant with minimum noise (DB) level.
Specifications:
Lighting : SUITABLE FLOURESCENT TUBES
SETS, 20/40 WATT
Sterilization : germicidal UV tube 15/30 watt.
Manometer : Accurately calibrated to assess Static pressure
in HEPA chamber ,made of plexi glass block.
Air Flow : ertical type @ 90 (approx) feet per minute
(FPM)
Gas & Vacuum Lines : Fittings made of brass, duly chrome plated.
Collapsible Sash : Renders unit convertible for use as a
Conventional laminar flow clean air work
Station.
Exhaust System : Protects ambient environment, and avoids
built up, air Borne particles with the help of
special filter.
Optional :
Supplementary Air : Prevents contamination through make up air.
Barrier
Re-Circulatory system : with vertical air re-circulation offering highest
level of cleanliness.
Fumigation Tray : for effective disinfection/decontamination.
Magnehelic Manometer : The Magnehelic Manometer can be replaced
with standar manometer on Instructions.
Exhaust ducting. : PVC Rugged shall be provide extra. Exhaust
system, suitable for 4 ft. dia. virus Burn out
unit (with UV lamp) Exhaust ducting. atextra
cost.
Working Size.
2’x2’x2’
3’x2’x2’
4’x2’x2’
6’x2’x2’
Optional:-
Exhaust ducting per running feet.
Gas Burner for above.
Wooden
60000.00
71000.00
81500.00
103500.00
4
5.
Biohazard Safety Cabinet (Self Standing Type) LCB-1203B -A2
Make: Daihan Labtech.
ISO 14644-1, ISO Class 5 (Class 100) Standards Compliance HEPA filter
removes 99.99% of 0.3um particles
Easy to Replace Filter From the Front Panel with maintenance free design
and structure
Air flow and uniform air velocity provide high clean filter air for high
performance
Built-in Lamps and utilities UV and fluorescent lamp, air and gas cock, power
consent are builted as standard
Easy to replace Filter in front panel
Built- mesh guard for Filter protection
Removable Working Tray easy to clean and disinfection for working
zone
One touch open front panel for easy maintenance
Maximum Door Opening Alarm to protect air flow performance and
safety
UV Sterilization with on/off working timer
Air Leak Proof Cabinet Structure with high clean stainless steel interior work
station and epoxy powder coated steel exterior for long durability
Tempered Safety Glass Sliding Door for maintain high quality cleanliness and
for protection from UV exposure
Low Noise Level and Vibration Free 56~60dB high efficiency sirocco fan
blower
Model LCB-1203B-A2
Dimensions Inner 1190 x 600 x 635
(W x D x H mm) Outer 1350 x 800 x 1880
Air Volume (Approx.) 1350m3 / h
Microprocessor
Digital Controller Air velocity and temperature monitoring,
automatic air velocity control low air
velocity visual & audible alarm, filter
using & change time alarm clock and
timer, auto stop for door excess open
HEPA Filter Class 100, purity 0.3um Particle Removal
99.99%
Air flow velocity Down flow 0.3~0.36m/sec
In flow >0.5m/sec
Noise Level 56~60dBA
Light UV 20W x 1EA, FL 20W x1EA
Material Interior Stainless Steel 304
Exterior Epoxy Powder Coated Electro
Galvanizer Steel
Door Tempered Safety Glass Sliding Door
Utility Device Air Cock, Gas Cock, 220V Consent
Electric Supply 220V 50Hz
a.
Essential Accessories:
Microprocessor Digital Controller with LCD back light display
Air Velocity Control & Alarm System Temperature Monitor at Working Zone
6.
‘MSI’ Fume Hood: Fume Hood made of waterproof laminated Board with
outside laminated with Formica of white or any desired color. Fitted on stand
nicely painted. With door opening with glass window nicely framed. Two side
glass windows for viewing are provided. One Washbasin with Swan neck tap is
provided for water supply. 2no. Fluorescent tube light and one multipurpose 15
amp. Plug socket is also fitted on the inner chamber. Hazardous fumes and odor
is thrown out by a heavy duty exhaust fan/blower of standard make. (1/4 HP
approx) We will provide exhaust line fitting upto the back of the Fume
chamber. (If the fume duct is to be taken high in the sky then ducting charges
extra) (All meson work to your account).
5
(i).
(ii).
(iii).
(iv).
(v).
a.
Working size:
4’x2’x2’
6’x2’x2’
5’x3’x2’
7’x3’x3’
8’x3’x3’
Ducting charges by PVC pipe and canopy on the top.
7.
Fume Hood 155x750x2250 LFH-150CI. Make: Daihan Labtech.
Durable Hazardous Chemical Gas Remove
Wide variety of Material for User Selection
Slide Type Sash Door with Tempered Safety Glass
Powerful Siroco Fan Blower
Model LFH-150 SCI.
Dimensions (W x D x H mm) 1555x750x 2250
Air Volume 1440CMH
Blower (Sirroco Fan) 400W
Material Inner Stainless Steel
Outer Powder Coated Steel and Stainless
Steel Frame
Work Top Synthetic Ceramic Plate
Utility Device Air Cock, Gas Cock, Water Cock,
Cup Sink Drain Explosion Proof
Lamp, Power Ports x 2
Duct Diameter 200mm
Electric Supply 220V, 50Hz
a.
b.
Essential Accessories:
Built-in Utility Device
Ducting charges by PVC pipe and canopy on the top.
8.
(i).
(ii).
(iii).
(iv).
‘MSI’ Inoculation Chamber: Made of Sun mica clad thick wooden board and
plywood at back. Thick non ratting Plexiglas windows provided on two sides
and front folding glass door. Inside sun mica clad. Lower portion is provided
with glove ports and gauntlets on front window. Provided with one fluorescent
tube and one UV tube.
Size. Body of full S.S.
27”x20”x16”.
40”x24”x22”
Size. Body of Wood /Mica laminated
27”x20”x16”.
40”x24”x22”.
9.
(i).
(ii).
(iii).
(iv).
(v).
a.
‘MSI’ Air Curtain: These are a modern device which, when installed on a
door, forms an invisible curtain of continuous air and thus prevents escape of
conditioned air and entry of outside hot, humid, dirty and unwanted polluted air.
The cabinets of Air curtain are made of cold rolled M.S. sheet. The blowers are
made of high quality aluminum sheets, duly balanced both statically as well as
dynamically on computerized digital balancing machines. Designed to provide
uniform air with minimum noise and no vibration. All units are thoroughly
tested at works and meet the highest standards. The motors used are of
continuous rating with sealed ball bearings. High velocity models approx. 10
meters.
Door width 600mm.
do- 900mm.
do- 1200mm.
do- 1500mm.
do- 1800mm.
Hanging charges
6
10.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
Dressing Drum: seamless (One piece) Made of Heavy gauge stainless steel.
Size
6x4
6x6
9x4.5
11x9
14x8
15x12
11.(i).
(ii).
(iii).
a.
b.
c.
‘MSI’ Anaerobic Jar: (McIntosh & fildes Pattern) for the safe growth of
anaerobes through Cold Catalyst. It consists of fitted with two needle valves for
evacuating and filling and a sachet for holding the catalyst but without catalyst.
The jar can be used both with cylinder as well as with Gas packs. Complete
with Petri dish holder and Pressure gauge.
Anaerobic Jar Model LE003-HiAnaerobic system Mark III: : Supplied with
transparent, unbreakable Polycarbonate jar of 3.5 lit cap with sturdy aluminum
lid clamp and sealing ring with built in safety features, pressure valve with
safety valve & 2 way pressure gauge.
Himedia Model LE013: Anaerobic System Mark VI supplied with transparent
unbreakable Polycarbonate jar of 1.5 lit cap with sturdy aluminum lid clamp
and sealing ring with built in safety features, pressure valve and 2 way pressure
gauge.
Accessories.
Gas Packs for Anaerobic culture jars. 'MSI’
Test tube carrier s. s.
Cold Catalyst.
12.(i).
(ii).
(iii).
(iv).
‘MSI’ Autoclave Portable: Fitted with pressure gauge up to 20 psi, the unit has
spring loaded safety valve for pressure adjustment and a dead weight safety
valve. It is hydraulically tested up to 40 PSI an is supplied with electric fittings,
cord and plug to work on220/240 VAC mains supply. Supplied complete with
tripod stand Size 300x300mm. Body made of Aluminum. Deluxe model.
300x375mm
do- but body made of s. s. joint less.300x300
300x375mm
13.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
a.
b.
c.
d.
‘MSI’ Autoclave: Electrically operated Laboratory Autoclave Vertical, double
walled, boiler made of s. s. with s. s. lined lid having fly nut locking system,
Working pressure 5 psi to 15 psi complete with safety valve, water level
indicator, steam release valve, pilot lamp, on/off switch for operation on 220
volt AC mains. Complete with s. s. basket. Outer laminated with s. s. sheet.
Size:
450x250mm
500x300mm
550x350mm
600x450mm
750x550mm
Size: with Automatic Pressure cut off
450x250mm
500x300mm
550x350mm
600x450mm
750x550mm
Optional at Extra cost:
Radial Locking for any of above.
Low Water Cut off device.
Digital Temp Indicator.
Timer with alarm.
7
14.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
a.
b.
c.
d.
Autoclave Vertical High Pressure (Triple Walled): Triple walled with inner
chamber outer wall and jacket made of Stainless Steel Fitted with Stainless
Steel lid and radial type device. The space between steam jacket and outer wall
is fitted with glasswool. Automatic Pressure Control Switch is provided for
controlling the pressure automatically on preset pressure value.
Size Dia x Depth Electric Load Capacity
250mm x 450mm (3KW) 22ltr
300mm x 500mm (4KW) 40ltr
350mm x 550mm (4 KW) 50ltr
400mm x600mm (5KW) 78ltr
450mm x 600mm (6KW) 98ltr
550mm x 750mm (6KW) 152ltr
Optional Accessories.
Arrangement for dry sterilization at the extra cost of.
Automatic low water level cut-off device
Digital Temperature indicator
Timer 0-60min.
15.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
a.
b.
c.
Autoclave Horizontal (Cylinderical): Double Walled Chamber inner made of
thick Stainless Steel, outer made of Heavy Duty Mild Steel duty painted..
Whole unit is mounted on mild Steel Tubular stand duly enamel painted. door is
made of Heavy Mild Steel duly S.S. Lined with Radial Locking System having
Horizontal Mild Steel bars duly chromed tightened on a central screw. Steam
Generator (Boiler) is placed below the main unit, is made of thick Stainless
Steel. Boiler is provided with easily replaceable heating element and is fixed at
the base of M.S. Frame. Provided with steam release cock, Safety Valves etc.
boiler is provided with water level indicator. Workable pressure 20 P.S.I.+ 3
P.S.I. and hydraulically tested up to 40 P.S.I. Suitable to work on 440 V. 3
Phase or 220V Single Phase as per requirement. These Autoclaves are provided
with automatic pressure switch/ Piezostat for controlling pressure at preset
value.
Available in following sizes.
Size (Dia x Depth)
250mm x 450mm
300mm x 500mm
350mm x 550mm
440mm x 600mm
450mm x 600mm
550mm x 750mm
400mm x 1100mm
500mm x 1200mm
Optional Accessories.
These can be provided with circular type thermometer to check the temperature
Timer 0-60min.
Digital Temperature indicator
16.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
a.
b.
c.
Same as above but outer chamber and lid made of Stainless Steel.
Available in following sizes.
Size (Dia x Depth)
250mm x 450mm
300mm x 500mm
350mm x 550mm
440mm x 600mm
450mm x 600mm
550mm x 750mm
400mm x 1100mm
500mm x 1200mm
Optional Accessories.
These can be provided with circular type thermometer to check the temperature
Timer 0-60min.
Digital Temperature indicator
8
17.
(i).
(ii).
(iii).
(iv).
Steam Sterilizer Horizontal High Pressure Cylindrical: This sterilizer is
based on the principal of downward of displacement of air which is most
economical method of obtaining the sterilization.
Triple walled, with rugged and leak proof construction. Inner chamber is made
of thick plate of Stainless Steel 304 quality. Outer chamber is also made of
thick Stainless Steel The steam is lined on the outer side and made of 304
quality Stainless steel with asbestos sheet or glass wool which prevents heat
losses due to radiation and is covered by strong rolled steel sheet duly painted.
Boiler is made from thick stainless steel sheet suitable located under the
sterilizer. High grade flanged type heating elements are placed in from side for
easy replacement etc. Fitted with water gauge made of glass for water level,
safety valve, water inlet and drain. Provided with self locking safety door which
cannot be opened when the chamber is under pressure. The clutch mechanism
automatically disengages the threads of the radial locking system for precluding
and eventuality of accident when the chamber is under pressure. A heat resistant
neoprene rubber gasket is provided for totally safety of the instrument. Provided
with electrically operated PIEZOSTAT, which economics the power
consumption and limits the use of release valve which would frequently blow
steam into the room. It cuts off the power supply to heaters when the set
pressure is achieved and re- energises the heater when pressure falls down.
Two separate valves are provided for evacuating air and steam from inner
chamber and jacket. A steam trap is fitted in the chamber discharge line to
eliminate the condensate automatically. Panel consist of pressure control
switch, main on/off switch, Indicators, relays etc. the sterilizer is provided with
triple safety. First with pressure control switch, Two nos. spring loaded safety
valves, and a dead weight safety valve. A PLUG SCREEN prevents the
discharge line from choking. And it can easily be removed for cleaning. A
power full ejector circulates the air throughout the chamber.
Operating Temperature And Pressure.
121 oC., 1.2 to 2kg./sq. cm.
LOAD: 6.0 TO 12.0 KW
Size (Dia x Depth) Electric Load Capacity
400mm x 600mm (6.0KW) 88ltr.
400mm x 1100mm (9.0KW) 162ltr.
500mm x 900mm (9.0KW) 165ltr.
500m mx 1200mm (9.0KW) 221ltr.
18.
Steam sterilizer Rectangular High Pressure.
Same as cylindrical High Pressure steam sterilizer but in rectangular
shape: Outside made of Heavy Duly rolled steel/ stainless Steel, inside of thick
Stainless Steel, triple walled. Door made of Thick Stainless Steel. Properly
insulated Steam Generator is made of Heavy duly stainless Steel. Pressure
control device is fitted in all electrically operated sterilizer. Provided with
Piezostat” (Pressure control Device). It cut off the power supply to the when the
set pressure is achieved and re-energise the heating elements when pressure
falls below the set point.
Boiler is made from thick stainless steel sheet suitable located under the
sterilizer. High grade flanged type heating elements are placed the from side for
easy replacement etc. fitted with water gauge made of glass for water level,
safety valve, water inlet and drain valves.
Provided with self locking safety door which cannot be opened when the
chamber is under pressure. The clutch mechanism automatically disengages the
threads of the radial locking system for precluding any eventuality of accident
when the chamber is under is pressure. A heat resistant neoprene rubber gasket
is provided for totally safety of the Instrument. Provided with electrically
operated PIEZOSTAT, which economics the power consumption and limits the
use of release valve which would frequently blow steam into the room. It cuts
off power supply to heaters when the set pressure is achieved and re
energises the heater when pressure falls down.
9
(i).
(ii).
(iii).
(iv).
Two separate valves are provided for evacuating air and steam from inner
chamber and jacket. A steam trap is fitted in the chamber discharge line to
eliminate the condensate automatically. Panel consist of pressure control
switch, main on/off switch, Indicators, relays etc. The sterilizer is provided with
triple safety. First with pressure control switch, Two nos. spring loaded safety
valves, and a dead weight safety valve. A PLUG SCREEN prevents the
discharge line from choking. And it can easily be removed for cleaning. A
power full ejector circulates the air throughout the chamber.
Operating Temperature and Pressure.
121 oC., 1.2 to 2kg./sq. cm.
LOAD: 6.0 to 18.0 KW
(W x H x D)(mm) Cap. (Ltr.) S.S. Carriage M.S.Trolly
450 x 450 x 900mm 180 33500.00 19000.00
450 x 600 x 900mm 240 35500.00 23000.00
600 x 600 x 900mm 320 39700.00 28000.00
600 x 600 x 1200mm 430 42800.00 32000.00
S.S. 304
349000.00
378000.00
398000.00
468000.00
19.
Autoclave.LAC-5040S Make: Daihan Labtech.
Fully Automatic Sterilization Process Push just one button to operate from
start to finish
Safe and Convenient Operation Oven temperature, pressure, current over
leakage protection, automatic over pressure release valve ensure user safety (AT
EXTRA COST)
Microprocessor PID Control and Display Dual display for current and set
temperature and time remaining sterilization process signal lamp
Electric Components Room and Steam Line is isolated for Safety
Door Locking Limit Switch (80L/100L MODEL ONLY) can secure the
complete door closing for safety
Model LAC-5040S
Controller Microprocessor manual Set Digital PID Controller
Dimensions Outer 670 x 560 x 950 (W x D x H mm)
Inner 300 x 630
Capacity 45 Lit
Material Exterior Heavy duty Epoxy Resin powder
coated steel EGI Steel
Chamber Stainless Steel 304 (STS 316 L
Option)
Heater 3kW
Temperature Range 110 oC to 135 oC
Set Accuracy +0.1 oC at 121 oC
Display PV & SV Dual Digital Display
Temperature, timer operation cycle
Indication
Sterilization Timer 0-99min
Working Pressure 2.0kg/cm2 at 132 oC
Pressure Guage 0~4kg/cm2
Door Packing Mechanical Swing Door
Safety Over temp. Over pressure and over
current protector, safety release valve
Basket 2EA of stainless steel wire basket
Included
Electric Supply 220V,50Hz
a.
Essential Accessories:
Safe and Convenient Operation Oven temperature, pressure, current over
leakage protection, automatic over pressure release valve.
10
20.
Autoclave.LAC-5060S Make: Daihan Labtech.
Model LAC-5060S
Controller Microprocessor manual Set Digital PID Controller
Dimensions Outer 670 x 560 x 1050 (W
x D x H mm) Inner 350 x 630
Capacity 60 Lit
Material Exterior Heavy duty Epoxy Resin powder
coated steel EGI Steel
Chamber Stainless Steel 304 (STS 316 L
Option)
Heater 3kW
Temperature Range 110 oC to 135 oC
Set Accuracy +0.1 oC at 121 oC
Display PV & SV Dual Digital Display
Temperature, timer operation cycle
Indication
Sterilization Timer 0-99min
Working Pressure 2.0kg/cm2 at 132 oC
Pressure Guage 0~4kg/cm2
Door Packing Mechanical Swing Door
Safety Over temp. Over pressure and over
current protector, safety release valve
Basket 2EA of stainless steel wire basket
Included
Electric Supply 220V,50Hz
a.
Essential Accessories:
Safe and Convenient Operation Oven temperature, pressure, current over
leakage protection, automatic over pressure release valve.
21.
(i).
(ii).
(iii).
(iv).
‘MSI’ BOD BODI-103: BOD Incubator Automatic this is a special type of
incubator designed to meet the requirements for incubation of biochemical
oxygen demand (BOD) on water & sewage. Also recommended for
preservation of vaccines at low temp and study of enzymatic digestion
processes and other tests demanding constant and uniform low temperatures.
The unit is highly suitable for work at temp below as well as above the ambient.
These Incubators are being used as Environmental Study and Growth Chambers
by incorporating Lighting & Humidification Systems. BOD Automatic consists
of a triple walled chamber fitted with cooling and heating systems. Inside walls
are of s. s. sheet and outside MS sheet nicely enamel painted. Mounted on
Caster wheels. Glass wool insulation prevents heat losses. Full view inner glass
door allows inspection of samples without disturbing temperature of chamber.
Special Features of MSI Automatic BOD Incubators are:
Temperature range 5 deg. To 50 deg. C uniform cooling coils
embedded in the walls. Temperature Uniformity at Operating 20 deg.C
is +/-1 deg.
Forced air circulation, ensures uniformity of the temperature.
Sensitive thermostatic temperature control. A safety thermostat cuts
out heaters even on failure of automatic heat control.
Study Refrigeration unit working in conjunction with a low wattage
heater for BOD work.
Selection switches to work either above or below room temperature.
When working above the room temperature, the selective switch by
pass the compressor circuit and energize a high wattage heater.
Size
112 lit ( 4 cu ft.)
170 lit (6 cu ft.)
283 lit (10 cu. ft.)
343 lit (12 cu. ft)
11
a.
b.
c.
d.
e.
f.
Optional Attachment at Extra Cost:
Digital Temp. Indicator cum Controller for above in place of Thermostat.
Light system by fluorescent tube with 0-24 hr. Digital Programmable timer.
Slow speed shaking platform fitted in above.
Humidity Honey well Humidistat with Humidity system.
do- but Digital.
Stabilizer
22.
Low Temperature BOD Incubator Make: Daihan Labtech.
Low Temperature BOD Incubator, 250ltrs. Capacity, programmable PID
Model LBI-250M
Silent Fan Moor: and automatic defrost function achieve excellent temperature
uniformity and quiet operation
10Step Programmable: temperature control and 999 cycle
Option: Light Bank System
Inner Tempered Glass Door: With double silicone packing easy sample view
without door opening
Programmable PID Model LBI-250M
Dimensions Inner 500 x 500x 1000
(W x D x H mm) Outer 660 x 840 x 1755
Capacity 250
Temperature Range 0 oC to 60 oC
Set Accuracy +0.1 oC
Uniformity +0.5 oC at 20 oC
Controller Microprocessor PID Multi-Function
Controller
Display LCD Back PV & SV Display for
Programmable PID Model
Timer 99hr 59min/Continuous
Material Interior Stainless Steel (SUS304)
Exterior Epoxy Powder Coated Steel
Door Inner Tempered Safety Glass
Outer Silicone Packing Magnetic Door
Shelves Adjustable 3 or 5 Shelves
Circulation Fan 14W x 3EA
Compressor 1/3HP
Safety Over & Under Temp. Cut-Off Over
Current Breaker
Electric Supply 220V, 50Hz
a.
Essential Accessories:
Microprocessor PID Control : Provides Precise Temperature control from 0
oC to 60 oC, timer, alarm and auto-tunning
23.
a.
b.
‘MSI’ Hybridization Oven : - These double walled units have outer chamber
of MS sheet duly painted and inner of s. s. temperature range from 5 deg. C
above ambient to 90 deg. C is controlled thought digital PID Temp Indicator
cum controller with an acc of +/- 0.5 deg.C. An air circulation fan is also
provided to ensure temperature uniformity. A carrier to hold bottles (6xsize
60mmx200mm) can be easily placed on the rotor. The carrier rotates at a
variable speed of 2 to 16 r.p.m. Viewing glass window in the door allows
inspection of the specimen inside the chamber. To work on 220/230 V AC
mains.
Carrier to Hold Bottle
Bottle Glass
12
24.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
(xii).
(xiii).
(xiv).
a.
b.
c.
‘MSI’ Hot Air Oven HAO-601: (Memert German type) double walled inside
made of pure s. s. sheet and outside of M.S. finished in durable Powder coated
paint with glass wool insulation between the two walls. Control: ON/OFF
switch, two pilot lamp, temp control by Thermostat with high accuracy,
adjustable shelves with holes, connecting cord and plug. Heating: covered
heaters are placed under ribs and at the bottom and side to get equal and
uniform distribution of heat. Temp. Range 5 deg. Above ambient (room temp)
to 250/300 deg. C Accuracy +/- 1 deg. C Air Transfer: Air regulators with
flaps placed under the side top. With 2 shelves as standard.
Inside Chamber.
300x300x300mm
350x350x350mm
450x450x450mm
600x600x600mm
450x450x600mm
450x600x900mm
600x600x900mm
S.S Outer DELUX MODEL
300x300x300mm
350x350x350mm
450x450x450mm
600x600x600mm
450x450x600mm
450x600x900mm
600x600x900mm
Optional accessories at extra cost.
Air Circulation Fan fitted in any of the above.
Digital Temp. Indicator cum Controller for above in place of Thermostat.
PID Controller
25.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
(xii).
(xiii).
(xiv).
a.
b.
c.
‘MSI’ Incubator: Double walled inside made of pure s. s. sheet and outside of
M.S. finished in durable Powder coated paint with glass wool insulation
between the two walls. Control: ON/OFF switch, two pilot lamp, temp control
by Thermostat with high accuracy, adjustable shelves with holes, connecting
cord and plug. Heating: covered heaters are placed under ribs and at the bottom
and side to get equal and uniform distribution of heat. Temp. Range 5 deg.
Above ambient (room temp) to 80 deg. C Accuracy +/- 1 deg. C Air Transfer:
Air regulators with flaps placed under the side top. With 2 shelves as standard.
Inside Chamber.
300x300x300mm
350x350x350mm
450x450x450mm
600x600x600mm
450x450x600mm
450x600x900mm
600x600x900mm
S.S Outer DELUX MODEL
300x300x300mm
350x350x350mm
450x450x450mm
600x600x600mm
450x450x600mm
450x600x900mm
600x600x900mm
Optional accessories at extra cost.
Air Circulation Fan fitted in any of the above.
Digital Temp. Indicator cum Controller for above in place of Thermostat.
PID Controller for above in place of Thermostat.
13
26.
(i).
(ii).
(iii).
a.
‘MSI’ Water Bath 6/12 Hole: Thermostatic Water bath Double walled. The
bath is constructed double walled inside made of s. s. and outside of M.S. sheet
duly painted with Powder coating paint provided with 25mm Mineral Wool
insulation on five sides. The temperature range of the water bath is+5 deg. C
above room temperature to 100 deg. C with an acc of 0.5deg.C. The temperature
is controlled by a Hydraulic type thermostat room temp to 80 deg. C with max.
temp. 100 deg. C sensitivity of +/- 0.5 deg. C. Heating elements are made of
copper nickel plated tubular type and approximately extend the full length of the
bath. Control panel is provided at the lower portion of the bath consisting of two
neon pilot lights which indicates control cycles as well as the mains heater
switch, Temp control knob. The bath is complete with concentric rings, constant
water level arrangement, ON/Off switch & Plug and cord.
Size Hole
300x250x100mm 6
300x350x100mm 9
355x405x100mm. 12
Digital Temp. Indicator cum Controller for above in place of Thermostat.
27.
(i).
(ii).
(iii).
a.
'MSI’ HIGH PRECISION THERMOSTATIC BATH HPTB-138: The
inner chamber of the bath is made of s. s. and outer casting is fabricated from
M.S. sheet of thick gauge, finished with powder coating having thick glass wool
insulation between the two walls. The finder is of thick gauge glass fixed on the
front panel. The bath itself is located on the upper deck and lower deck provides
switches for thermo-regulator, stirrer, heater, indicator and main lamps. The
apparatus is supplied with thermostatic controller, operate on220/230 v 50
cycles AC.
Sizes Inside chamber
480x240x265mm
425x250x225mm
300x250x225mm
Digital Temp. Indicator cum Controller for above in place of Thermostat.
28.
(i).
(ii).
(iii).
(iv).
a.
b.
c.
‘MSI’ WATER BATH SEROLOGICAL WBSVT-110:- Variable
temperature made of S. S. Sheet double walled with special insulating material,
thick tin coating inside and outside painted beautiful powder coating/stove
enameled. Fitted with sensitive Thermostat to work on +5 deg. c room temp. to
1000 c with an accuracy of +/-10 c pilot lamp, immersion type heater to work on
220 volts AC 50 cycles supply. Complete with three core wire, plug and gabl
type cover without rack.
Size Khan Racks
300x250x175mm 2
300x300x175mm 4
455x300x175mm 6
455x455x175mm 8
Khan Rack for above Stainless Steel
Stirrer with S.S.Stirring Road & Blade
Digital Temp. Indicator cum Controller for above in place of Thermostat.
29.
(i).
(ii).
(iii).
a.
‘MSI’ WATER BATH PARAFIN EMBEDDING WBPE 115:
Thermostatically controlled. Made of heavy gauge S. S. sheet with skirting type
stand finished in cups of 62 mm. dia. with lids and containers are provided to
hold glass vials and not for stocking paraffin with glass cover .Fitted with
Sensitive Thermostat to control 50 c above room temperature to 560 c within
accuracy of +-10c Electrically operated on 220 volts 50 cycles single phase AC
supply.
4 cups& 6 glass vials.
6 cups& 8 glass vials.
12 cups& 12 vials.
Digital Temp. Indicator cum Controller for above in place of Thermostat.
14
30.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
‘MSI’ HEATING MANTLE HM-95: These are made to accommodate
several sizes of round bottom flask in mantle of each size to provided uniform
heating. Bigger sizes of mantles have two or three heating circuits so that upper
circuits could be switched off when small size Flask is heated or when liquid
level drops These multi-sized mantles have heating surface knitted in our
Factory from woven fiber glass cloth with the heating elements covered in fiber
glass sleeve.
They provided a minimum surface temperature of 4500 C working on 230 V,
Singl phase, 50 C single Phases.
Capacity ml. Wattage
50ml 60
100ml 60
250ml 150
500ml 200
1Litre 300
2Litre 450
3Litre 450
5Litre 600
10Litre 2x600
20Litre 3x600
50Litre 6x600
Complete
Mantle Price
1240.00
1240.00
1300.00
1400.00
1675.00
2085.00
2400.00
2700.00
4310.00
6100.00
14200.00
31.
‘MSI’ Water bath Shaker / Metabolic Shaker: It is a double walled unit with
inside made of s. s. sheet and outside of M.S. duly enamel painted. The
Pyramidical lid made of s. s. prevent falling of condensed water droplets on the
specimens. Heating is achieved through an immersion type heater and temp is
controlled by Digital temp Indicator cum controller. The bath has an oscillating
tray riding on ball bearing oscillated through a geared variable speed motor
shaking Erlenmeyer flasks of 100ml cap. Available with heating arrangement
only. Temperature range 5 deg. above ambient to 100 deg. C.
32.
Shaking Water Bath, 22ltrs, LSB-015S Make: Daihan Labtech.
Quiet Shaking Mechanism
Universal Rack Takes Tube and Flask from 50ml up to 2ltr
PID Temperature Control up to 99 oC
Shaker from 20 to 250rpm Digital Speed Control
Three Model with Bath Capacities 20lrt , 30ltr 45ltr
Stainless Steel Bath (SUS304)
Digital PID Controller : Provide +0.1 oC accuracy +0.5 oC uniformity
temperature range from ambient +5 oC to 99 oC touch-sensitive membrane type
control panel
Quiet Shaking Mechanism: Electronically controlled shaking mechanism
provides noiseless reciprocal motion and precise speed control from 20 to
250rpm, perfect for long time use
High Quality Stainless Steel: Corrosion Resistant (SUS304) Bath
Over Temperature Protection: And over current protection capability ensure
user safety
Universal Spring Rack: Accommodates various tube and sized flask from
50ml to 2000ml and tubes racks
Model LSB015S
Dimension Bath 300 x 300 x 240
(W x D x H mm) Overall 534 x 344 x 300
Bath Capacity 20ltr
Heater 1.4kW
Temperature Range Ambient + 5 oC to 99 oC
Accuracy +0.1 oC
Uniformity +0.5 oC
Controller Digital PID Controller
Shaking Speed 20 to 250 stroke/min
Stroke Adjustable 15 to 30mm
15
Display LED 4 Digit Display
Timer 99hr 59min/Continuous
Material Bath Stainless Steel
Case Powder Coated Steel
Rack Stainless Steel Spring Rack
Safety Over Temp. Cut-off, Over Current &
leakage Breaker
Electric Supply 220V, 50Hz
33.
Shaking Water Bath, 30ltrs. LSB-030S Make: Daihan Labtech.
Model LSB030S
Dimension Bath 500 x 300 x 240
(W x D x H mm) Overall 734 x 344 x 300
Bath Capacity 30ltr
Heater 2.1kW
Temperature Range Ambient + 5 oC to 99 oC
Accuracy +0.1 oC
Uniformity +0.5 oC
Controller Digital PID Controller
Shaking Speed 20 to 250 stroke/min
Stroke Adjustable 15 to 30mm
Display LED 4 Digit Display
Timer 99hr 59min/Continuous
Material Bath Stainless Steel
Case Powder Coated Steel
Rack Stainless Steel Spring Rack
Safety Over Temp. Cut-off, Over Current &
leakage Breaker
Electric Supply 220V, 50Hz
34.
‘MSI’ Orbital Cooling Incubator Shaker: It comprises of hermetically sealed
compressor housed Below the incubator to provide temperature below
ambient. Range 5 deg. To 60 deg. +/- 0.5 deg. Acc. Temperature is
controlled by Digital Display Electronic Temperature Controller. Standard
Platform Cap. 16 conical flask of 500ml. chamber cap. 10 cu. Ft. made of s.
s. and outside M. S. nicely painted. Mounted on wheels.
35.
Shaking Incubator, Speed 400rpm and temperature ambient + 5 to
80degree C, LSI-4018A Make: Daihan Labtech.
Model LSI-4018A
Dimensions Bath 545x550x360
(W x D x H mm) Overall 585x850x800
Temperature Range Ambient 5 oC to 80 oC
Set Accuracy + 0.1 oC
Uniformity + 0.5 oC at 25 oC
Shaking Speed 0 to 400rpm
Stroke 20mm Orbital Motion
Controller Digital PID Controller
Display LED 4 Digit Display
Timer 99hr 59min /continuous
Compressor None
Material Interior Stainless Steel (SUS304)
Exterior Epoxy Powder coated
Steel
Safety Over temp Cut-off, Over
Current Breaker
Electric Supply 220V, 50Hz
16
36.
Shaking Incubator. Make: Daihan Labtech.
Shaking Incubator, Speed 300rpm and temperature ambient +5 to
60degreeC, LSI-3016A.
Digital PID Control: Provides precise temperature control from 10 oC to 80 oC
Speed control 0 to 400rpm touch-sensitive membrane type keypad with timer
Safety and Convenience: over temperature control protection, leakage breaker
ensure uer safety
Universal Spring Rack: which can accommodate various sized flasks up to 2L
and tube racks to attach and remove from the shaking plate
Shaking Mechanism: electronically controlled shaking mechanism provides
quiet orbital motion precise speed control and digital display.
Shaking Motion can stop automatically when door is opened.
Model LSI-3016A
Dimensions Bath 545x550x360
(W x D x H mm) Overall 585x850x800
Temperature Range Ambient +5 oC to 60 oC
Set Accuracy + 0.1 oC
Uniformity + 0.5 oC at 25 oC
Shaking Speed 0 to 300rpm
Stroke 20mm Orbital Motion
Controller Digital PID Controller
Display LED 4 Digit Display
Timer 99hr 59min /continuous
Compressor None
Material Interior Stainless Steel (SUS304)
Exterior Epoxy Powder coated
Steel
Safety Over temp Cut-off, Over
Current Breaker
Electric Supply 220V, 50Hz
37.
Refrigerated Shaking Incubator, Speed 300rpm and temperature 7-60
degree C, LSI-3016R Make: Daihan Labtech.
Model LSI-3016R
Dimensions Bath 545x550x360
(W x D x H mm) Overall 585x850x800
Temperature Range 10 oC to 60 oC
Set Accuracy + 0.1 oC
Uniformity + 0.5 oC at 25 oC
Shaking Speed 0 to 300rpm
Stroke 20mm Orbital Motion
Controller Digital PID Controller
Display LED 4 Digit Display
Timer 99hr 59min /continuous
Compressor 1/8HP
Material Interior Stainless Steel (SUS304)
Exterior Epoxy Powder coated
Steel
Safety Over temp Cut-off, Over
Current Breaker
Electric Supply 220V, 50Hz
38.
Refrigerated Shaking Incubator, Speed 400rpm and temperature + 5 to
80degree C, LSI-4018R Make: Daihan Labtech.
Model LSI-4018R
Dimensions Bath 545x550x360
(W x D x H mm) Overall 585x850x800
Temperature Range 10 oC to 80 oC
Set Accuracy + 0.1 oC
Uniformity + 0.5 oC at 25 oC
Shaking Speed 0 to 400rpm
Stroke 20mm Orbital Motion
17
Controller Digital PID Controller
Display LED 4 Digit Display
Timer 99hr 59min /continuous
Compressor 1/8HP
Material Interior Stainless Steel (SUS304)
Exterior Epoxy Powder coated
Steel
Safety Over temp Cut-off, Over
Current Breaker
Electric Supply 220V, 50Hz
a.
Essential Accessories:
Universal Spring Rack: which can accommodate various sized flasks up to 2L
and tube racks to attach and remove from the shaking plate
39.
‘MSI’ Circulatory Water Bath : A highly in demand instrument where water
is required to be circulated to some external source through an FHP pump. Most
useful for circulating water to Abbe Refractometer, Condenser coils &
fermentors etc. etc. Temperature range as per the customer requirements varies
form 0-70 deg.C. Temperature is controlled by digital Temperature Indicator
cum controller of acc. +/- 1 deg.C. Inner chamber made of s. s. and outer
chamber made of M.S. Sheet duly painted. The gap in between the walls is
insulated with high grade Glass Wool insulation. The Refrigeration unit is
housed under the bath Cabinet and the whole unit is mounted on castor wheels
for easy movement. The water is circulated by a heavy duty FHP Pump fitted
inside the cabinet. Separates/witch for pump operation is provided. The
circulating pump helps in external circulation and also keeping the internal
water temperature uniformity in the chamber. Two nozzles one for water inlet
and other for water outlet are provided for easy fitting of the support
instruments in which water is to be circulated. Separate Switch for Cooling unit,
Digital Temperature Indicator cum controller, Switch for Circulating Pump and
Indicator for various operations are all housed in a nicely made Panel. The Lid
is also of double walled insulated with high grade Glass wool. (In short it is a
Chest type Deep freezer). Temperature range 0-70 deg. C. Tank cap. 12-15 lit
water.
40.
Refrigerated Bath Circulator 30 oC to 90 oC13LCB-R13
Make: Daihan Labtech.
Model LCB-R13
Dimensions Bath 250 x 350 x 150
(W x D x H mm) Top 250 x 160
Overall 320 x 440 x 750
Capacity 13 Lit
Temperature Range -3 to 90 oC
Set Accuracy +0.1 oC
Uniformity +0.5 oC
Heater 1kW
Refrigerant 1/4HP
Controller Digital PID Multi-Function Controller
Display LED 40Digit Display
Pump Magnetic Drive Circulation Pump, Max.
Flow 7L/min max. Height 4.3 meters
Material Interior Stainless Steel
Exterior Powder Coated Steel
Safety Over Temp. Cut-Off Over Current and
Leakage Breaker
Electric Supply 220V,50Hz
18
41.
Refrigerated Bath Circulator 30 oC to 90 oC 8LCB-R8
Make: Daihan Labtech.
Microprocessor PID Controller : Provides + 1.0 oC set accuracy + 0.5 oC
uniformity, temperature range from -30 oC to 90 oC
High Quality Stainless Steel: Corrosion resistant (SUS304) bath and insulation
and easy to maintenance with movable casters
Over Temperature Protection : And over cooling , over current Protection
Capability ensure user safety and protect Cooler from damage
Powerful Circulation Pump: with 7L/min and 4.3 meters maximum height
enhance temperature uniformity of the bath, circulation bath inside and outside
of the bath
Model LCB-R08
Dimensions Bath 170 x 320 x 150
(W x D x H mm) Top 170 x 150
Overall 335 x 440 x 645
Capacity 8 Lit
Temperature Range -3 to 90 oC
Set Accuracy +0.1 oC
Uniformity +0.5 oC
Heater 700W
Refrigerant 1/4HP
Controller Digital PID Multi-Function Controller
Display LED 40Digit Display
Pump Magnetic Drive Circulation Pump, Max.
Flow 7L/min max. Height 4.3 meters
Material Interior Stainless Steel
Exterior Powder Coated Steel
Safety Over Temp. Cut-Off Over Current and
Leakage Breaker
Electric Supply 220V,50Hz
42.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
a.
‘MSI’ MUFFEL Furnace MF-65: The casing is made of thick mild steel sheet
reinforced with iron angles, riveting screw joints and welding wherever
necessary and painted in attractive powder coating paint. Heating chamber
consists of rectangular horizontal totally enclosed muffle bracket. Heating
elements are of made of Kanthal or Nichrome wires wound externally on the
muffle and embedded in best quality high temperature embedding cement.
Sufficient insulation lagging is provided all around the embedding muffle.
Maximum temperature upto 1000 Deg. C and working temperature 9000 C
Temperature controlled by Imported English Sunvic Dimmer stat Energy
regulator fitted in front of the furnace with two indicating bulbs, Pyrometer,
,thermocouple lead wires etc. Furnace is suitable for 230 V AC single phase, 50
Hz electric supply.
Muffle Size. Rating KW
9”x4”x4” 1.6
10”x5”x5” 2.0
12”x5”x4” 3.0
12”x6”x4” 3.0
12”x8”x4” 4.0
12”x5”x5” 3.0
12”x6”x6” 3.5
12”x8”x8” 5.0
15”x6”x4” 3.0
14”x7”5” 4.0
15”x7”x7” 4.0
Digital Temp. Indicator cum Controller for above in place of Thermostat.
19
43.
(i).
(ii).
a.
‘MSI’ MUFFEL FURNACE (INDUSTRIAL TYPE) MFI-68:
For temperature 1150 deg. C outer body furnace is made of thick mild steel duly
painted and fitted with angle frame. Inside chamber is of grooved refractory for
supporting the heating elements on four sides and insulated with ceramic wool
to prevent the heat losses. Heating elements are made of Kanthal wire A-1
which has been found to be best suitable for high temperature. Maximum
working temperature of furnace is 10000 C. The Furnace has hinged door faced
with a insulation of Ceramic Wool in place of refractory bricks and closed for
thermo couple, outlet and for thermal fuse, compensating lead wire main leads
suitable for 220/230 volts single phase 50 cycles AC Supply.
Working Chamber. Rating KW
12”x6”x6” 4.5
Working Chamber.
12”x8”x8” 7.5
Digital Temp. Indicator cum Controller for above in place of Thermostat.
44.
(i).
(ii).
(iii).
(iv).
a.
‘MSI’ VACUUM OVEN VO-175: For use in dehydration, moisture
determinate- on and other operations requiring reduced temperature, low pressure
and vacuation of fumes. The oven chamber is made of thick s.s. sheet and
outside mild steel painted with stove enameled. The door clamp makes it
possible to use the vacuum oven as a low pressure oven i.e. for internal pressure
not exceeding 5 lbs /square inch , which facilitates rapid &complete interchange
of gases.With hand screw for tightening, the door clamp bears centrally on the
door at four points on its frame. Seating is simply and quickly accomplished by
light rotation of the door into position and final Adjustment by tightening the
screw clamp. A snap switch and pilot lights are provided on the front of the
temperature regulated compartment. Combined vacuum and pressure gauge is
mounted on the top of the oven together with hand valves. The construction of
the oven and the method of thermoregulation provided uniformity in
temperature distribution within the vacuum chamber, sufficient for all ordinary
laboratory procedures. Thermostatically controlled to work form room
temperature to1100 C on 220 V AC supply.With t removable perforated shelves
inside dimension. Digital temp. ( But w/o Vacuum pump.)
Size
220x200mm
300x250mm
300x300mm
300x450mm
Digital Temp. Indicator cum Controller for above in place of Thermostat.
45.
Vacuum Drying Oven 27ltrs. Digital control Model LVO-2030
Make: Daihan Labtech.
Ideal for Fine Vacuum : Vacuum embedding moisture testing and desiccating
Temperature up to 250 oC and maintain 760mm Hg vacuum
Tempered Safety Glass Window: and 3&4mm Thick stainless steel chamber
and heat resistant silicone packing door
Vacuum & Vent Valve: and safety 3-way valve, slow vacuum relief prevents
powdered sample scattering
Seamless Silicone Packing: Designed and produced with technical structure by
large mode ensure excellent vacuum condition
Digital PID Control: Provides Precision Temperature control, timer, auto-
tunning
Safety and Convenience: Over Temperature and over current protection,
Leakage Breaker ensure user safety
Digital Controller Model LVO-2030
Dimensions Inner 300 x 300 x 300
(W x D x H mm) Outer 730 x 455 x 553
Capacity 27 Lit
Heater 1.5kW
Controller Digital PID Multi-Function
Controller
20
Display LED 4 Digit Display
Timer 99min 59sec /99hr 59min
/99days 23hours /Continuous
Selectable
Temperature Range Ambient +5 to 250 oC
Set Accuracy +0.1 oC
Uniformity +3.0 oC at 120 oC
Vacuum 10~760mm Hg
Material Inner Stainless 3 & 4 mm Thickness
Outer Epoxy powder coated steel
Door Tempered Glass Window with
Silicone Packing
Safety Over Heat Protector Over
Current & Leakage Breaker
Electric Supply 220V, 50Hz
46.
Vacuum Drying Oven 64ltrs. Digital Controller Model LVO-2040
Make: Daihan Labtech.
Digital Controller Model LVO-2040
Dimensions Inner 400 x 400 x 400
(W x D x H mm) Outer 830 x 555 x 660
Capacity 64 Lit
Heater 2.5kW
Controller Digital PID Multi-Function
Controller
Display LED 4 Digit Display
Timer 99min 59sec /99hr 59min
/99days 23hours /Continuous
Selectable
Temperature Range Ambient +5 to 250 oC
Set Accuracy +0.1 oC
Uniformity +3.0 oC at 120 oC
Vacuum 10~760mm Hg
Material Inner Stainless 3 & 4 mm Thickness
Outer Epoxy powder coated steel
Door Tempered Glass Window with
Silicone Packing
Safety Over Heat Protector Over
Current & Leakage Breaker
Electric Supply 220V, 50Hz
47.
‘MSI’ WALK IN INCUBATOR WI-775: Design for vast number of incubation
applications may be set in hall way room or where-ever convenient. Design
feature include enameled steel exterior, Alluminium interior,ventilators, internal
lighting, exhaust fan suitably insulated, 300mm.sq. Inspection window provided.
Complete with panel housing all controls, circulation fan etc.
Inner Chamber Size 2.30x1.1.0x1.1.0 meter
Temp. Range: 50C above ambient to 600 C
Temp. Control: Digital Temp Indicator cum controller
2.3x2.3x2.3meter
48.
‘MSI’ WALK IN HUMIDITY CONTROLLER FOR ABOVE (47): detailed
above but fitted with controlled humidity from ambient to 95%+-3%. At extra
cost in above.
49.
‘MSI’ WALK IN HUMIDITY TEMPERATURE CONTROLLED
INCUBATOR FOR ABOVE (47) : As detailed above but temp. Range 10 degree
c to 50degre c& R.H. ambient to 95%+3%. At extra cost in above.
50.
‘MSI’ CARBON DI OXIDE INCUBATER CDI-850: Al inside chamber size.
71H with x 45 W x 45 D cm ( 6 cu. Ft. approx) automatic Digital electronic
temperature indicator cum controller , full view of inner glass with double wall
insulated with magnetic gasket door. An inlet nozzle at the near of the control
box provides the admission of Co2 or air/Co2 mixtures. Supplied complete
with flow- meter .Temperature range 5 degree C above ambient to 60 degree C
21
above ambient to 60 degree C accuracy +-0.5degree C.
51.
a.
b.
‘MSI’ CARBON DIOXIDE INCUBATER CDI-875: Same as above but
provided with sealed refrigeration unit to bring down temp. Range 5 degree C to
50 degree C with solid state Electronic controller . Accuracy +-5digree C.
ACCESSORIES.
Air Compressor with filter .
Carbon Dioxide Cylinder with rubber pipe &pressure release cock.
52.
(i).
(ii).
(iii).
(iv).
‘MSI’ Seed Dryer. :- Inside made of s. s. and outside of M.S. duly painted
with enamel paint. Air circulating fan with heavy duty blower fitted on the side
of the oven with ON/OFF switch. A ventilation is provided at the top of the
oven. Temperature range from 50 deg. To 250 deg. C thermostatically
controlled. To work on 220/240V single phase AC supply. Digital temp.
Indicator cum controller can be fitted in lue of thermostat at extra cost.
Chamber size. Tray
90x90x60cm 12
90x90x90cm 18
90x120x90cm 24
90x150x90cm 36
53.
(i).
(ii).
(iii).
(iv).
(v).
a.
‘MSI’ Tray Drying Oven: Double walled, mounted on sturdy angle iron
frame. Inner made of thick G.I. Double Sheet duly painted with high
temperature aluminum paint, outer made of heavy duty PCRC duly primer
coated and enamel/Powder coated paint. Insulation between inner and outer
wall is done with 75mm thick glass wool to prevent any heat loss. Provided
with double walled door with a system to prevent its opening. Door is provided
with best quality handle, gasket etc. Provided with brackets to support the
heavily laden trays (made of Alluminium) at different heights. Temp. range is
from ambient to 250oC with an accuracy of +/-3oC or as desired by you and is
controlled by digital temperature indicator cum controller with PT-100 sensor.
Heating is done with ISI mark heating elements made from nichrome heating
wire placed in the sides of the chamber. V belt driven motor operated blower
system in the side of the chamber to maintain the uniformity of the temp.
throughout the chamber. Works on 220V 50 HZ single phase A.C.
Provided with exhaust shaft on the top of the body.
Size Tray Load
2’x2’x3’ 8 Trays 5 KW
3’x2’x3’ 12 Trays 8 KW
3’x2’x5’ 24 Trays 10 KW
3’x3’x6’ 48 Trays 12 KW
4’x3’x8’ 96 Trays 22 KW
Rates of the Bigger Sizes can be provided on request.
Timer 0-24 hrs
54.
‘MSI’ Plant Growth chamber: It has outer wall made of M.S. sheet duly
painted and inner wall made up of heavy gauge s. s. sheet. The gap between
inner and outer wall is filled with high grade glass wool to avoid thermal loss.
Besides outer double walled door, a full view inner glass door allows inspection
of test samples without disturbing the inner chamber conditions. Unit is
supplied with three adjustable perforated shelves. Temp range from 5 deg. To
50 deg. C +/- 1 deg. C is controlled by digital temp indicator cum controller
dual mode so as to set two different temp. for day and night. Exterior
illumination with fluorescent tubes fitted on both sides of the chamber accounts
for artificial day light and the cyclic illumination conditions are regulated
automatically by 0-24 Hr cyclic timer. When tubes are ON temp from 15 deg.
To 50 deg. C can be obtained. Humidity from ambient to 95% +/- 3 % RH is
controlled by a controller at temperature ranging from ambient to 50 deg. C and
the same is achieved by means of injecting steam. Arrangement for increasing
the humidity is provided and not for decreasing.
22
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
Size Capicity
505x830x415mm 6cu. Ft.
570x875x550mm 10 cu. Ft
650x900x550mm 12 cu. Ft
700x900x650mm 15 cu. Ft.
775x900x775mm 20 cu. Ft.
825x1200x825mm 30 cu. Ft. DOUBLE CHAMBER
900x1720x800mm 45 cu. Ft.
55.
(i).
(ii).
a.
DEEP FREEZER (-85°C) (ISO 9001, 14001, OHSAS 18001 Certified)
UPRIGHT ULTRA LOW TEMPERATURE FREEZER TEMP. UPTO -85
C
Standard Features.
- Low Energy Consumption
- 5 Internal compartments/shelves
- Low Noise Level
- 100% HCFC/CFC free
- Porthole for installation of PT100/ Co2 backup
Sub lids, Castors, Lock
- Advanced Battery backup digital display for 72 hours backup
- Visual and acoustic alarm
- Power failure alarm
- Exterior alarm contact for remote monitoring
- High/low temperature alarm
- Probe failure alarm
- Instrument (EPROM) Failure alarm
- Battery backup for alarms and temperature in the event of power
cut
- 3 pin PT100 special designed for ultra low temperature
Net Capacity : 450 Liters
Temp. range at 25C : -40 / -85C ambient (C)
Power Supply : 230 V
Frequency : 50/60 Hz
Insulation : 100mm
PROVIDED WITH CUSTOM DUTY EXEMPTION CERTIFICATE BY
DEPARTMENT.
OR
WITHOUT CUSTOM DUTY EXEMPTION CERTIFICATE.
OPTIONAL.
SUITABLE STABILIZER
56.
4°C FREEZER: ISO 9001 Certified
Twin Temperature Zone-Top & Bottom in FKG 371
External Thermometer
CFC / HCFC free
Built-in fan in FKG 371
Fan-cooled condenser
Internal Fluorescent light
Multi-positional shelf system
Left or right hand door opening
Castors at back of cabinet and adjustable feet at front Lock
MODEL FKG 371
Capacity 381 Liter.
Dimension (H x W x D) 72.8” x 23.4” x 23.4”
Compressor 300 W
Temperature Range 10C to 1C
Energy Consumption 2.9 units/24 hr
Type of Insulation Puff with Cyclopentane
No. of Castors and size (mm) 2 (40.5)
23
a.
OPTIONAL.
SUITABLE STABILIZER
57.
a.
VERTICAL TYPE DEEP FREEZER: (VESTFROAST MAKE)
IMPORTED FROM DENMARK) (ISO 9001 Certified)
TEMP. UPTO -20C
Built in condenser gives low energy consumption.
No Dust Low Noise.
Combination of pull out drawers and fast freeze shelves.
Control panel at the top of cabinet with thermometer or temperature warning
light.
Thermostat
Fast freeze button and lamp.
Mains warning lamp.
Single door.
Digital Temperature display external
External Lock
Model : BFS 345 S
Gross Capacity : 345 Liter.
Net Capacity : 308 liters.
Hours from 18 to 9 : 18 Hrs.
OPTIONAL.
Suitable Stabilizer FOR ABOVE
58.
‘MSI’ Hot Plate: (Temperature Controlled): Round top The Body is made of
M.S. Sheet duly painted with attractive stove enamel paint. The top cast iron
heating plate is round having 20 cm diameter with heating elements of 1.5 K.W.
rating. Temperature is controlled by Energy regulator upto 350 Deg. C.
59.
(i).
(ii).
(iii).
(iv).
a.
b.
c.
‘MSI’ Hot Plate Rectangular: with cast Iron top. For continuous heating upto
350 deg. C. the body is made of specially designed perforated PCRC sheet
painted with attractive stove enamel with insulated elements & Heating
controlled by Energy regulator. To work on 220/230 V AC mains.
Size
10”x12”x6”
10”x16”x6”
12”x18”x6”
18”x24”x6”
Optional at Extra Cost:
Thermostat Fitted in place of energy regulator in any of above.
Digital Temp. Indicator cum Controller for above in place of Thermostat.
S.S. lining on the M.S. top in any of the above.
60.a.
(i).
b..
(i).
(ii).
c.
d.
‘MSI’ Soxhlet Extraction App: Heating Unit for flask of 100ml,150ml,250ml
or 500ml cap without glass parts, with adjustable rod, clamps & boss heads. For
3 tests and individual on/off switch and individual Energy regulator.Hot plate
type
do- but Mantle type.
Heating Unit for flask of 100ml,150ml,250ml or 500ml cap without glass parts,
with adjustable rod, clamps & boss heads. For 6 tests
do- but with 6 Energy regulator H. P. type.
do- but with 6 Energy regulator Mantle type.
Glass parts at extra cost.
Glass part consists of flask, Extractor and condenser. (100/250ml. Flask cap.)
do- flask 500ml cap.
24
61.
(i).
(ii).
(iii).
‘MSI’ Magnetic Stirrer : with Hotplate complete s. s. body with s. s. top
corrosive resistance. With heavy duty Permanent Magnet mounted on a sturdy
variable speed motor for easy operation. Supplied complete with Teflon
paddle and speed regulator & Energy regulator. Best Quality.
Cap. 1or 2 lit.
-do- but 5 lit cap.
-do- Multiple 6 Point
62.
‘MSI’ Vortex Mixer: Useful for stirring centrifugal tubes, test tubes or small
flasks, fitted with a neoprene rubber cup mounted eccentrically on the shaft
against which at its is held the tube with its lower end pressing against the cup.
Mixing action is controlled by varying the angle and pressure of the tube
against the cup. Fitted with speed control arrangement. To work on 220 V AC
mains.
63.
Multi Tube Vortex ‘er: These multi tube is used for mixing multiple conical
and round bottle tubes with variable speed vortexing which provides constant
uniform mixing action it has an LED display of RPM. Time and Pulse Mode.
Pulse Mode can be programmed with on and off times between 1 and 59
seconds in 1 second interval.
This feature enhances vortex action by creating a more vigorous mix.
Specifications:
Speed Range 500 to 3000 RPM
Timer 1 seconds to 99 hrs 59 mins
Orbit 3.6 mm
Maximum weight capacity 4.5 kg
Tray Dimension 18x31cm
64.
(i).
(ii).
(iii).
a.
b.
‘MSI’ Laboratory Stirrers.
Mini Stirrer: fitted with 1/20 HP motor 1200 RPM. Without controller
complete on adjustable stand.
Lab Stirrer: with 1/20 HP Motor 4000RPM with speed regulator
Heavy duty Lab Stirrer: with ¼ HP motor with speed regulator
Optional at extra cost.
Digital RPM meter fitted in any of the above.
Speed Controlled by Heavy duty Variac.
65.
a.
b.
c.
‘MSI’ Emulsifier/Homogenizer : Fitted with FHP motor having speed
regulator and max speed 4000 RPM with Drill Chuck and CP rod fitted with
heavy C.I. base. Motor cap. 1/20 HP.
Spare Homogenizing cup with rod pestle. Cap. 1ml to 5ml.
Do- but cap. 10ml or 20ml.
Do- but cap. 50 or 100 ml
66.
a.
b.
c.
Rotary Mixer.
Provides serial rotation of tubes for extraction diffusion etc.
Mixing action can be set from 5-50 RPM
Timer can be set from 0-99 hrs/ 1-59 min
Rotating bars for tube dia from 10-30 mm.
Plastic coated spring clips
Quick, easy coupling for exchange of rotating bare.
Bar for 50x1.5ml tube
Bar for 20x15ml tube
Bar for 12x50ml tube
25
67.
(i).
(ii).
(iii).
a.
b.
c.
‘MSI’ Rotary Flask Shaker: Designed for continues shaking of solutions in
Erlenmeyer flasks from 50ml to 1lit cap. It is a compact bench type table top
model with platform fitted with rubber discs mounted on ball bearing crank
shafts to give an orbital motion to the flasks, within a diameter of approx 2”.
The motor is coupled by means of V belt with pitch pulley and is mounted on a
heavy and sturdy angle iron frame. Speed is controlled by mechanical speed
controller. To work on 220/230 V Ac mains.
Cap. Of flask.
16 flasks of 250ml.
24 flask of 250ml.
36 flask of 250ml.
OPTIONAL.
Spare Platform for other capacity of flask holding at extra cost
Optional at extra cost:
DC motor drive with continuously variable electronic speed regulator in lieu of
mechanical speed control and AC motor. To work on 220 Volt AC mains.
Digital Speed /RPM indicator fitted in above.
68.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
Orbital Shaker: Orbital Type of Movement 4mm Orbital Movement 2KGS
Permissible Shaking weight 100-800RPM Speed Range Digital Led Speed
Display 99HRS 59MINS Timer Display Operating Model with Bothway
Timer/Continuous Top Plate 22x22cm 5-50 oC Permissible Abmient
Temperature 90% Permanent Relative Moisture.
Spares:
Universal Attachment
Flask Holder Attachment
Dish Attachment
Plastic Lotus Clamp 50ml-100ml
Plastic Lotus Clamp 250ml
Plastic Lotus Clamp 500ml-1000ml
69.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
Orbital Shaker: Orbital Type of Movement 20mm Orbital Movement
7.5KGS Permissible Shaking weight 20-300RPM Speed Range Digital Led
Speed Display 99HRS 59MINS Timer Display Operating Model with Bothway
Timer/Continuous Top Plate 33x33cm 5-50 oC Permissible Abmient
Temperature 90% Permanent Relative Moisture.
Spares:
Universal Attachment
Flask Holder Attachment
Dish Attachment
Plastic Lotus Clamp 50ml-100ml
Plastic Lotus Clamp 250ml
Plastic Lotus Clamp 500ml-1000ml
70.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
Reciprocating Shaker: Reciprocating Type of Movement 20mm
Orbital Movement 7.5KGS Permissible Shaking weight 20-300RPM Speed
Range Digital Led Speed Display 99HRS 59MINS Timer Display
Operating Model with Bothway Timer/Continuous 33x33cm Top Plate
Dimension 5-50 oC Permissible Abmient Temperature 90% Permanent Relative
Moisture.
Spares:
Universal Attachment
Flask Holder Attachment
Dish Attachment
Plastic Lotus Clamp 50ml-100ml
Plastic Lotus Clamp 250ml
Plastic Lotus Clamp 500ml-1000ml
26
71.
(i).
Dancing Shaker:
Three dimensional combination of rocking and orbital motion
Used for staining and destaining gels, blotting techniques and mixing
of lab sample
Non slip platform is continuously adjustable from horizontal to a steep
angle
Low foaming agitation and uniform mixing at slow speed
Speed adjustable from 0-60 RPM
Maximum permissible load is 2 kg.
Spare Dimpled Mat
72.
Test Tube Roller: Test Tube Roller is designed to provide continuous rolling
and rocking motion to the samples at a fixed speed.
The Mixer is designed for uniform mixing of medical laboratory tests of blood,
haematological determinations and other cell suspension samples. In addition it
prevents sedimentation in samples such as dyes, paints, oils and cosmetics etc.
Roller 5ea
Speed 40rpm
Roller Length 32.5cm
73.
(i).
Rocking Shaker: Rocking shaler is used for staining and destaining gels,
hybridization procedures, haematology and blotting techniques.
Rockymax has a variable speed powerful DC motor to provide gentle rocking
motion. All the moving parts are fitted with bearing for quiet trouble free and
smooth operation.
Speed 10-50RPM
Timer 99 hrs 99 mins
Plateform Dimension 30 L X 30 B cm
Maximum Load 10 Kgs
Spare Dimple Mat
74.
a.
b.
c.
Test Tube Rotator.
Provides mixing for diffusion dialyzing, extraction etc.
Rotation can be set from 5-50 RPM
Timer can be set from 0-99 hrs/ 1-59 min
Rotating disks for tube dia 10-30 mm.
Plastic coated spring clips
Angle of Rotation adjustable from horizontal for minimal mixing to
vertical for full end over end mixing
Disk for 24x1.5ml tubes
Disk for 18x15ml tubes
Disk for 12x50ml tubes
75.
a.
b.
c.
‘MSI’ Melting Point apparatus: A metallic heating block heated with superior
quality element. A focusable lens a shadow less lamp, regulator to control the
heat, Unit is housed in a cast metal panel, fitted with neon light, on/off switch
and regulator knob to introduce 3 capillaries.
Thermometer for above 0-360 deg. Extra.
Cooling Plug for above.
Capillary tube for above. Best Indian.
76.
a.
‘MSI’ Colony Counter: Fitted with automatic 4 digit LED display, counting
plate with illuminated standard wolfhugel ruling ensures clearly differentiated
and sharply defined colonies. Each touch of marking pencil in the Petri dish
increments the colony count by ‘1’ and the glowing LED display depicts the
total colony count. Maximum colony Count possible upto 999. Provided with a
manual reset of digital display, ON/Off switch, counting plate, 100mm dia lens,
cord and plug. To work on 220 V AC mains.
ALTERNATE.
Colony counter for manual counting ‘MSI’: Complete with counting plate
100mm dia lens and marking pen.
27
77.
‘MSI’ PRECISION DIGITAL MELTING POINT APPARATUS: - This is
a compact instrument designed for accurate determinations of melting points of
solid samples. The unit consists of a built-in magnetic stirrer, and electronic
controller for adjusting the rate of heating of silicon oil bath, an ON/OFF
switch, a pilot lamp, magnifier, a glare free illuminated background, a high/low
range selector switch and a digital temp indicator with PT -100 sensor. The
outer body is made of 304 grade s. s. The silicon bath consists of a plain
cylindrical container of corning glass having capacity about 200ml. It is fitted
with a special type of oil immersion heater. The rate of heating of the bath can
be precisely adjusted by the controller on the panel. The tips of the capillaries
filled with sample powders can be kept suspended in the oil bath through the
cover. The tips can be clearly observed through the magnifier on the
illuminated background of the bath. The range of the apparatus is from about 2
deg. C above room temperature upto 300 deg. C with readability 1 deg. C. the
apparatus supplied with 175ml silicon oil for use upto 300 deg.C and a box of
capillaries. It can also be sued for determination of boiling points, flow points
and molecular weight by rast’s method with special tubes, not supplied with the
instruments.
78.
a.
‘MSI’ Membrane Sterility Unit: Consists of s. s. holders in manifold of 3 to
hold 47mm dia membrane filters, The tops of the holders are connected to the
outlets of the flushing tube with silicone tubing and glass stop cock. A vacuum
resistant flask or woulfs bottle must be placed between the manifold and
vacuum pump. (Supplied without Woulfs Bottle and Vacuum pump).These
units are used for sterility testing when the membrane filter is to be removed
from the holder of incubation in culture media. A filtration area is 12.5cm. and
has a holding capacity of 250ml Though only vacuum is required for filtration,
some pressure is required for flushing liquids.
Filter Holder s. s. to hold membrane filters of dia 47mm (250ml cap).
79.
‘MSI’ Precision rotary Microtome AO Spencer type: It has a front located
feed indicator with cam drive system setting from 1-50 microns in steps of 1
micron each. The object clamp takes specimen up to 32x27mm on stem of block
holders. The cutting angle is adjustable through 30 deg. Two levers are
provided for releasing knife holder for resetting angle and a third lever releases
the entire assembly for movement on side ways to adjust horizontal distance
from object. Supplied with one knife 120mm long with back and handle in box
3 holders, one honing stone, and one bottle of lubrication oil and dust cover.
80.
‘MSI’ Precision rotary Microtome ERMA type: It incorporates a ball and
flange type object holder for specimen centering. Knife holder with lateral
movement permits use of complete knife edge and has a feed range of
1.25mircon in steps of 1 micron each. Supplied with one knife 120mm long
with back and handle in box 3 holders, one honing stone, one bottle of
lubrication oil and dust cover.
81.
‘MSI’ Base Sledge Microtome: Precision rotary Microtome (Lipshaw
type): It is useful for sectioning of bone tissues, The wheel is counted balanced
with locking device and has automatic feed and release mechanism. A light
cover hinged at back is provided for protection of internal parts from dust. Feed
range 1-50 microns in step of 1 micron each is controlled smoothly by dial
control in the rigid position. For easy positioning of the object to the knife and
for returning the feed to the starting position, the feed crank is located at the left
side of the microtome, and the feed pawl automatically ceases to function when
the feed reaches the extreme forward position.
82.
‘MSI’ Automatic Knife Sharpener: AO Spancer type fitted with geared motor
which ensures an equal level angle by moving the knife to and fro and in the
process reversing the same at regular intervals. A transparent hinged cover is
fitted to top to prevent dust. An adjustable 0-60 min timer is fitted to the unit for
sharpening for a pre set duration. Knife of length up to 185mm can be
sharpened on the unit. Supplied complete with one universal knife holder one
redressing pad, two honing plates and cord and plug.
83.
(i).
Microtome Accessories:
Blade for blade holder.
28
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
Microtome blade Holder Chrome Plated.
L-blocks. 37x25x15mm
Block Holders. Set of 3.
Microtome Razor 120mm. With back and Handle in wooden box
Sharpening Hone 6”x2” superior.
Leather strap.
84.
(i).
(ii).
(iii).
‘MSI’ Slide Warming Table with thermostat
Size
10”x12”
10”x16”
12”x18”
Aluminum
Top
4400.00
6600.00
7900.00
85.
(i).
(ii).
(iii).
a.
‘MSI’ Tissue floating Bath TFWB-118:-This bath is designed to remove the
wrinkles and distortion produced in embedded tissue sections by the slicing
action of the microtome knife. The clinical technicians or pathologists deposit
the sections of the embedded tissue on the surface of the warm water bath where
they quickly soften ,unfold and flatter out , supported by the surface tension
.Each section can then be lifted out o n a microscope slide and set on the board
edge of they bath ,where gentle heat dries them gradually. The black interior of
the bath enables the operator to examine the near transport sections with ease.
The exterior is attractively finished in white backed enamel. Fiberglass between
the walls of the bath provides. Excellent thermal insulation. The bath is fitted
with pilot light on/off switch and thermostat to control from ambient
temperature to 500 with an accuracy of +-10 for operation on 220 volts AC.
Sizes Inside Dia. x Depth x Width of edge
250x115x50
225x75x40
200x50x40
Digital Temp. Indicator cum Controller for above
86.
‘MSI’ IR Moisture Balance IBM-22:- It consist of a 250 Watt IR lamp, a
sensitive torsion balance, and an auto transformer all housed in a compact
cabinet made of solid cast aluminum, having robust design. The infrared
radiation from the lamp is used for heating the sample. The temp. is controlled
by the Auto transformer. The sensitive torsion balance uses magnetic damping
to damp the vibrations of the pan.
The instrument is directly calibrated in percentage of moisture between 0% and
100%. The instrument uses only 5 grams of the material. OTHER CAP.
INSTRUEMNTS LIKE 10GM OR 20 GM CAN ALSO BE SUPPLIED.
The aluminum pans are cheap and are disposable. This helps avoid loss of time
which otherwise would be spent each time to clean the pans after the
experiment is done.
IR Moisture Balance is a very reliable and sturdy instrument for an accurate
determination of the moisture contents of materials which do not undergo
chemical change when exposed to IR radiation. Since drying and weighing of
the samples is done simultaneously, the instrument is especially useful for
substances which quickly reabsorb moisture after drying. Observations can be
taken quickly and the results obtained are accurate. The instrument has been
profitably utilized for a reliable determination of moisture contents of Ag. Soils,
foods, chemicals, plastics, pharmaceuticals, construction soils and other similar
materials.
Sturdy, Light and Portable.
Directly calibrated in Moisture %.
Provision for Controlling Temp.
Samples from 5 gm to 25 gm can be tested. (Please specify at the
time of Order)
Easy to operate and easy to handle.
29
a.
(i).
(ii).
Accuracy 0.2% by direct reading and 0.1% by estimation.
With Infra Red Lamp.
Power 220/230 V AC mains.
ACCESSORIES SUPPLIED WITH THE instrument:
12 no. Disposable al. pan.
Pair of forceps.
Instruction Manual.
SUPPLIED COMPLETE AS ABOVE.
Optional:
Timer with alarm to give a continuous buzz after turning the IR lamp off after
the specified time.
ALTERNATE.
Precisa make Digital Moisture Analyzer Model XM-60
-do- Model XM-120
87.(i).
(ii).
a.
Monocular Microscope: ISI marked Microscope with standard set of Objective
10x,45x & 100x (Oil immersion, spring loaded) properly Para focal, color
coded and high resolution, Eyepiece 10X Wide field eyepiece. All optics are
coated with anti reflection and fungus resistant. Coarse and fine movement with
Mechanical stage and Abbe condenser. Very superior quality.
do- but without Mechanical Stage same as above.
Optional.
Compact Light arrangement with pigmy lamp for above. At extra cost
88.
Olympus student Monocular Microscope Model HSA
89.
Olympus Laboratory Monocular Microscope Model HB.
90.
Olympus Laboratory Monocular Microscope Model GB.
91.
Olympus Research Microscope Model CH 20iBi Binocular.
92.
Olympus Research Microscope Model CH 20iTr. Trinocular.
93.
Olympus Research Microscope Model CX21iBi Binocular.
94.
Olympus Research Microscope Model CX21iTr: Standard set complete, in-
built 6V 20W halogen light illuminator, with Anti-Fungus Plan Achromatic
Objectives 4x, 40x, 40x (spring) & 100x (oil, spring) paired eyepieces wide
field 10x (F.N.20) in thermocole packing, manufactured under license from
Olympus Corporation, Japan
95.
Magnus Inclined Monocular Microscope Model MLM.
96.
Magnus Inclined Binocular Microscope Model MLX-B
97.
Magnus Inclined Trinocular Microscope Model MLX Tr. Trinocular.
98.
Magnus Stereoscopic Binocular Microscope. Model MS-24 or MS-13
99.
Magnus Zoom stereo Binocular Microscope Model MSZ-Bi.
100.
Magnus Zoom Stereo Trinocular Microscope Model MSZ-TR.
101.
Magnus Binocular Research Microscope Model MLXi.
102.
Magnus Trinocular Research Microscope Model MLXi-Tr
103.
Magnus Research Microscope Model ICON (LED)(Binocular Version)
104.
Magnus Research Microscope Model ICON (LED)(Trinocular Version)
105.
Magnus Binocular Microscope Model MLX-B (Freedom)
106.
Magnus Trinocular Microscope Model MLX-Tr (Freedom)
107.
Magnus Binocular Research Microscope Model MLXi (Freedom)
108.
Magnus Trinocular Research Microscope Model MLXi-Tr (Freedom)
109.
Magnus Inclined Monocular Microscope Model MLX-M
110.
Magnus Research Microscope Model ICON with quintuple Nosepiece
(Trinocular Version)
111.
Magnus Monocular Microscope Model MLX-M (LED)
112.
Magnus Binocular Microscope Model MLX-B (LED)
113.
Magnus Trinocular Microscope Model MLX-Tr (LED)
30
114.
Magnus Monocular Microscope Model MLX-M (Freedom )
115.
Magnus Research Microscope Model ICON (LED) with quintuple nose piece
(Trinocular version)
116.
Magnus Research Microscope Model ICON (Freedom) (Binocular Version)
117.
Magnus Research Microscope Model ICON (Freedom) (Trinocular Version)
118.
Magnus Research Microscope Model ICON (Freedom) with quintuple
nosepiece (Trinocular Version)
119.
120.
121.
Magnus MIPS-USB (5 mp) Microscope Image Projection System
122.
Magnus Adapter
123.
Magnus C-Mount Adapter
124.
Optional Filter for Green Excitation
125.
Phase Contrast Objective 40x
126.
Magnus Digital Microphotography System: consitsting of : Olympus
Interchangeable Lens Type Live View Digital Camera (above 12 mega pixels)
along with one zoom lens, rechargeable battery, charger, USB, cable & Magnus
carry bag. Compatible 4GB memory card & Magnus optically corrected
microscope adapter. The price includes the designing & optical alignment cost.
Note: Pressently the camera model E-PL1 is being supplied. In case if it is
discontinued the camera available (of equivalent specifications) at the time of
will be supplied.
127.
Q-Imaging (Model MP3.3-RTV-R-CLR-10-C) Micro Publisher 3.3 RTV,
3.3 mega-pixle CCD Coler- Bayer Mosaic, 10-bit, Real Time Viewing
COOLED CCD CAMERA,
128.
Olympus (Japan) Phase Contrast Attachment for C x 21i consisting of
CX-PH1 Ring slit PH1,
CX-PH2Ring slit PH2,
PLCN10XPH Plan achromat phase contrast Objective 10x/0.25, WD10.6
PLCN10XPH Plan achromat phase contrast Objective 40x/0.65, WD10.6
(Spring )
CT-5 Centering telescope &
43IF550-W45 Interference green contrast filter 45mm dia.
129.
a.
b.
Magnus Stereoscopic Binocular Microscope
Model MS 24 with turret mounted (2x & 4x) in-built objectives
Model MS 13 with turret mounted (1x & 3x) in-built objectives
130.
Olympus Zoom Stereo Binocular Microscope Model .SZ51
131.
Olympus Zoom Stereo Binocular Microscope Model .SZ61
132.
Olympus Zoom Stereo Trinocular Microscope Model .SZ61-TR
133.
Optional Accessories (for SZ51/61 Series)
a.
Auxillary Objective 110LI 1.5X / 2X (for SZ51/51 Series)
b.
Eyepieces (Paired) WHSZ15-H /20X-H (for SZ51/61 Series)
c.
Olympus Transmitted illumination Attachment SZ2-ILA-LSGA
d.
6V15WHAL halogen bulb (with reflector) (for LSGA illuminator)
134.
Olympus Binocular Research Microscope Model. CX31
135.
Olympus Trinocular Research Microscope Model. CX31TR
136(i)
(ii).
Olympus Binocular Research Microscope Model. CX41 without objective
& Condenser.
Plan Achromat Objective 4x,10x,40x,100x(spring,oil)& Brightfield
Condenser ,N.A.1.25,with A.S. vernier Scale.
137(i).
(ii).
Olympus Trinocular Microscope Model. CX41-TR without objective &
Condenser.
Plan Achromat Objective 4x,10x,40x,100x(spring,oil)& Brightfield
Condenser ,N.A.1.25,with A.S. vernier Scale.
138.
Simple Polarizing attachment consisting of polarizer and analyzer
139.
Olympus Upright Phase Contrast Attachment for CX41 Microscope with
Slider Condenser
31
140.
Olympus Upright Phase Contrast Attachment for CX31/41 Microscope
without Phase Contrast/ Dark Field Condenser.
Phase Contrast/ Dark Field Condenser.
141.
Olympus Dual Viewing Attachment Model. CX-DO2 Standard Set
142.
a.
b.
c.
d.
Olympus Binocular Inverted Phase Contrast Microscope Model. CKX31.
CKX31SF2.
CKX31 frame with binocular tube and eyepieces (2pcs), including 30W lamp
socket AR3553,35mm dia. Petri dish holder AD0675, allen wrench GA3720,
tag AD0764, 6V30WHAL (2pcs) and ABX10SA screw
UPLFLN4XPHP.
U plan semi apochromat phase (pre-center) objective 4X/0.13, W.D.17.0
CACHN10XPHP.
Acromat Phase (per-center) objective 10X/0.25, W.D.8.8mm
LCACHN20XPHP.
Long working distance achromat phase contrast (pre-center) objective 20X/0.4,
W.D.3.2
143..
a.
b.
c.
d.
Olympus Binocular Inverted Phase Contrast Microscope Model CKX41
CKX41SF2.
CKX41 frame, including 30W lamp socket AR3553, insert plate AQ1180, allen
wrench GA3720, tag AD0764, 6V30WHAL (2pcs) and AB4X10SA screw
UPLFLN4XPHP.
U plan semi apochromat phase (pre-center) objective 4X/0.13, W.D.17.0
CACHN10XPHP.
Acromat phase (pre-center) objective 10X/0.25, W.D.8.8mm
LCACHN20XPHP.
Long working distance achromat phase contrast (pre-center) objective 20X/0.4,
W.D.3.2
144.
a.
b.
c.
d.
e.
f.
g.
Olympus Trinocular Inverted Phase Contrast Microscope Model
CKX41TR
CKX41SF2.
CKX41frame, including 30W lamp socket AR3553, insert plate AQ1180, allen
wrench GA3720, tag AD0764, 6V30WHAL (2pre-center) and AB4X10SA
screw
U-CTR30-2.
Trinocular tube, FN20, fixed light pass, Bi/Photo: 50/50
UPLFLN4XPH.
U plan semi apochromat phase objective 4X/0.13, W.D.17.0
CPLN10XPH.
Acromat phase (pre-center) objective 10X/0.25,W.D.8.8mm
LCACHN20XPH
Long working distance achromat phase objective 20X/0.4,WD 3.2
LCACHN40XPH.
Long working distance achromat phase objective 40X/0.55,WD2.2
WHB10X.
Wide field eyepiece 10X,FN20
145.
Olympus Multi Headed Microscope (10headed) Model BX51 or equivalent
146.
Olympus Multi Headed Microscope (5headed) Model BX41
147.
Olympus Reflected Light Fluorescence Attachment (B&G Excitation): for
CX41 Microscope
148.
a.
b.
Olympus Fluorite UPLFL Objective for Fluorescence Applications &
Research Applications (for use with BX/CX series of microscope)
Fluorite Objective 40x
Plan Fluorite UPLFLN Objective with 41X magnification
Fluorite Objective100x
Plan Fluorite UPLFLN Objective with 10X magnification
149.
Micro LED- Fluorescence Attachment Blue Excitation (480nm) For Auto-
Immune Tests Applications:
(for use with MLXi / ICON series microscope) Standard consists of:
Micro LED High efficiency illuminator for transmitted light fluorescence
32
(clamps directly on microscope stand allowing also transmitted light brightfield
microscopy), 2 positions filter slider with O-rings & Transport box alongwith
Blue LED cassette with excitation wavelength 480nm, long pass 510nm,
emission filter,
Features:
The use of a high power solid state LED (source from Fraen Corp, ltaly) enables
increased performance replacing conventional mercury arc-lamps.
Light Source Lifetime: Typically 30000 hrs, thus allowing for many yrs. Of
operation & cost savings.
No need of any special alignment procedure
Reduction of maintenance & heat production
No warmup time required for light source.
Allows Transmitted Light Observation without removing the Fluorescence
module.
Battery Pack Option for field operation (Optionally Available at extra cost)
150.
Micro LED- Fluorescence Attachment Royal Blue Excitation (450nm) For
BT Tests Applications
(for use with MLXi / ICON series microscope) Standard set consists of:
151.
Micro LED- Fluorescence Attachment Blue (480nm) & Green (535nm)
Excitation- For Immune Tests Applications
(for use with MLXi / ICON series microscope) Standard set consists of:
152.
Micro LED- Fluorescence Attachment Blue Excitation (480nm) ForAuto-
Immune Applications
(for Existing Olympus CX series microscope users) Standard set consists
of:
153.
Micro LED- Fluorescence Attachment Blue (450nm) &
Green(535nm)Excitation - for Auto-Immune Tests Applications
(for Existing Olympus CX series microscope users) Standard set consists
of:
154.
(i).
(ii).
(iii).
(iv).
Stage Micrometer:
0.01mm best Indian.
do- but Japan.
Ocular Micrometer 10mmx100 Parts Indian
do- but Japan
155.a.
b.
‘MSI’ Inverted Microscope: Inverted Tissue Culture Microscope: Inverted
Binocular Microscope for tissue culture examination having coarse and fine
adjustment, Incident lamp with variable light control arrangement, with ling
working distance objectives and binocular head, complete with following optics
in corrugated box. Objective: 5x, 10x, 20x &40x, Wide filed Eyepiece 10x
(paired).
do- but trinocular version.
156.
Magnus Inverted tissue Culture Trinocular Microscope Model INVI:
For brightfield and phase contrast applications (30o inclined, interpupillary
48mm~75mm) having 6v30w halogen light illuminator, quintuple revolving
nosepiece, coaxial coarse (stroke : 37.7mm per rotation) & fine (stroke : 0.2mm
per rotation) adjustment, plain stage (160x250mm) with glass insert, auxiliary
stage 70x180mm, Condenser LWD 72mm, Long working distance plan infinity
Brightfield Objectives 4x/0.1 (W.D 18mm) & 40x/0.6 (W.D 2.6mm Cover
Glass 1.2mm) And phase Contrast Objectives 10x/0.25 (W.D 10mm) & 20x/0.4
(W.D 5.1mm) with phase annulus plate (10x-20x,40x) & High eyepoint, extra
wide fide eyepiece EW10x (F.N 22) Standard set complete.
Features:
Long working Distance Plan Infinity Optics
Pre-Centered Phase Annulus
Trinocular Port in Standard Unit
Excellent Field Flatness
33
157.
a.
b.
c.
d.
e.
f.
g.
h.
i.
Over Head Projector:
‘MSI’ Overhead Projector A4 size with 2 bulb facility, Imported Fresnel lens
and smooth folding arm and head.
Braun Imported Over head Projectors Paxilux/Vision 250.Libarty
do- Paxilux/Vision 285 model.
do- Paxilux /Vision 285 Deluxe.
Braun/Liberty paxiscope XL (episcope Direct projector)
Mega power visual Presenter MVP-800 auto focusing, resolution 470 TV
lines,22X optical zoom, lens f3.9-85.8mm, f=1.6 -3.2 motorized.
Mega power portable visual presenter MVP-231 Goose neck mechanics, 60x
mechanical zoom by movement of the neck, resolution 470 TV lines, Suitable
for all LCD/DLP projectors, video output, easy to carry around supply with
carrying bag.
do- but with 2x digital zoom, conversion of S video input to
VGA output. Model 230
do- but Model MVP-820.
VAT 14%
158.
LCD Projector: Computer Beamer 2300 Lumens. Imported.
VAT 14%
159.
(i).
‘MSI’ Projection Screen: with Tripod Stand very superior quality spring
action for winding the projection cloth. Nicely painted housing.
--do-- without Tripod Stand
VAT 14%
160.
(i).
(ii).
Slide Projector:
Liberty Braun Nova mat 130AF automatic 35mm slide projector with auto
focus & CABLE REMOTE CONTROL.
Liberty Braun Nova mat E-150 with cordless infrared remote.
a.
b.
c.
d.
e.
f.
g.
h.
i.
Optional at extra cost.
Projection Screen with Tripod Stand very superior quality spring action for
winding the projection cloth. Nicely painted housing.
Motorized Projection Screen Liberty Show Deluxe Motorized Screen (Glass
Beaded Fabric) with cordless Remote Control. 6’x8’
Liberty Show Deluxe Motorized Screen (Matt White Fabric) with cordless
remote control. 6’x8’.
Printer Laser jet 4 in 1 Black & white HP or equivalent.
Printer Laser jet 3 in 1 Black & white HP or equivalent.
Printer Laser jet 4 in 1 Color HP or equivalent.
Ink Jet Pinter for Photo quality print A4 size Photo smart color. HP or
equivalent
Office jet Printer 4 in 1 color printer A4 size. Print, Fax, scan & copy. HP or
equivalent make
Laser torch dual function. Very sturdy.
VAT 14%
161.
.(i).
‘MSI’ TLC kit complete:- Comprising of moveable applicator (spreader) with
built in arrangement )-2mm Perspex base plate 114x23 cm, Aluminium Carrier,
34
(ii).
a.
b.
c.
d.
e.
f.
g.
h.
i.
Perspex spotting temp, plate, developing chamber with lid, five TLC plates
20x20cm, TLC plates 20x5 cm, scriber for marking lines, and chamber with lid
, Rs. 6950.00five TLC plates 20x20cm, two TLC plates 20x5 cm, scriber for
marking lines, and micropipette and glass sprayer with rubber bellow, Complete
with aluminium applicator.
-do- but with brass applicator
Optional at extra cost.
TLC Glass plate 20x20 cm
-do- 20x10 cm
-do- 20x5 cm
TLC Chromatography Tank (Developing chamber with cover for plate size)
20x20 cm
-do- 20x10 cm
-do- 20x5 cm
Desiccators cabinet 30x50x35 cm
Gel Spreader for TLC Plates Made of Brass Nickel plated.
-do- but of aluminum
162. a.
b.
‘MSI’ Paper Chromatography Cabinet: Ascending or Descending, made of
teak of wood and glass construction. It can accommodate two s. s. troughs and 6
glass rods. Size :- 60x30x60 cm for 4 filter paper of 46x57 cm
-do- 80x37x65 for 6 filters
163.
(i).
(ii).
(iii).
(iv).
a.
b.
c.
‘MSI’ Vacuum Pump: Has developed double stage high vacuum pumps add
these are reliable in performance fir laboratory and industrial application. These
are V belt driven having 400 RPM and fitted with best quality electric motor
mounted on CI base plate. Suitable to work on 220 V 1 Ph AC mains.
Cap.
25 lit/min 0.25 HP
50 lit/min 0.25 HP
100 lit/min 0.5 HP
150 lit/min 0.5 HP
Optional at extra cost.
Moisture Trap.
Vacuum Gauge with regulator.
Non Return Valve.
Single stage
10500.00
13500.00
17000.00
20500.00
164.
(i).
(ii).
‘MSI’ Vacuum cum pressure pump (diaphragm type): with suitable motor
pump and creates the vacuum throught a diaphragm.
Cap. 25 lit with ¼ HP motor
Cap. 46 lit with ½ HP motor
165.
a.
b.
Physical Balance: KeRoy make teakwood case and sun mica base very high
All Brass nicely polished parts. Model P-1
Weight box for above Physical 50 gm cap.
-do- 100 gm cap.
166.
a.
b.
ANALYTICAL Balance: KeRoy make teakwood case and sun mica base
precision. All Brass nicely parts. Model K-1
Weight box for above Analytical 50 gm cap.
-do- 100 gm cap.
35
167.(i).
(ii).
Analytical balance single pan: KeRoy. Cap. 200gm acc. 0.1 mgm single pan
balance. Best quality.
-do- Dhona make.
168.(i).
(ii).
(iii).
Balance Portable: Dial Type With top (Kitchen Scale) cap. 1 kg x 5 gm
-do- Cap.2kg x 10gm.
-do- Cap.5kg x25gm.
169.
a.
b.
c.
d.
e.
f.
g.
Haemocytometer: Complete in Box.
Superior makes Counting Chamber & German Pipettes.
Superior makes Counting Chamber & Indian Pipettes.
Superior makes Counting Chamber & China Pipettes.
Rohem standard Counting Chamber & German Pipettes.
-do- but with Indian Pipettes.
Rohem Silverlite Counting Chamber & German Pipettes.
-do- but with Indian Pipettes.
170.(i).
(ii).
(iii).
(iv).
(v).
Haemometer: German Original.
Top Make Indian best Plano Haemometer.
-do- Prismatic Haemometer.
-do- Round type.
Haemoglobinometer ERMA Japan Analogue.
171.(i).
(ii).
Ultrasonic Processor/sonicator: Model EI-125 UP: Power output 125 Watt
average variable form 70 to 100% Probe dia: 5mm/10mm/12mm (Please
speoify), Digital tomer: 0-99 min. Power required 230V AC mains.
-do- same as above but model EI-250UP Power Output :250 Watt
average.
FOR SPECIFICATION ask for PHAMPHLET.
172.
a.
b.
c.
d.
e.
f.
g.
h.
i.
j.
Ultrasonic Flaw Detector: Model EI-751UP. With Normal Probe-2.5
MHz,20mm dia & BNC to BNC cable 2 meter long.
Additional Essential Accessories-
Battery-6V 4.5 AH 2 NO.
Foam Leather Carrying case.
IIW Block (IS-4804-1972)
Step Wedge-1 to 10mm.
Battery Charger.
Optional Accessories:
CD Probe 2 or 4MHz,20mm dia.
Angle Probe 2 or 4 MHz,45 deg. 9x8mm
Membrane Probe 2 or 4 MHz,25mm dia.
DGS scales
Other Special Probes
173.(i).
(ii).
‘MSI’ Distillation assembly s. s Manesty Type:- Wall Mounted complete s. s.
body, electrically operated easily replaceable immersion type heaters. Wall
mounted. Cap. 2 lit/hr
-do- 3 or 4 lit/hr
174.
‘MSI’ Distillation assembly glass: Ultra purification system. All Borosil Glass
Horizontal model cap 4 lit/hr. automatic cut off. EDU Still
36
175.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
‘MSI’ Ultrasonic Cleaners: Standard Models Single Chamber made of s. s.
they are indigenously manufactured to high international specifications and are
backed by over 50 years experience & ready acceptance by professionals from a
wide range of industries for their varied need. Ultrasonic Power at high
frequency-normally 30 KHz (also 23 KHz or 40 KHz) is fed to piezo electric
crystals. The electrical power is converted to mechanical vibrations by these
piezo electric transducers (PZT). The transducers are bounded to the bottom of
the s. s. stand containing cleaning solutions. The mechanical vibrations are
transferred to the liquid through the tank surface. These intense vibrations create
microscopic bubbles known as cavities in the liquids. The cavities thus formed
implode with high pressure forming brushing effect on the surface of the
components to be cleaned. As a result the contamination is removed.
Tank size. Cap. In lit
150x85x65 mm 0.5
150x140x65 mm 1.0
240x140x65 mm 1.8
240x140x150 mm 3.5
250x150x150 mm 6.0
300x200x175 mm 10.5
176.
(i).
(ii).
(iii).
‘MSI’ Drawing Board.
Drawing Board: 45x30cm. Made of seasoned wood & tongue joined
Drawing Board Imperial 23”x36” approx.
Stand for above Drawing Board.
177.(i).
(ii).
First Aid Box: Routine quality lab model.
-do- but big size best quality
178.(i).
(ii).
(iii).
(iv).
(v).
‘MSI’ Crucible tongs: s. s. 6 “
-do- 8”
-do- 10”
-do- 12”
-do- 24”
179.(i).
(ii).
(iii).
(iv).
‘MSI’ Test Tube brush: medium
-do- large
‘MSI’ Bottle brush small
Bottle brush large
180.(i).
(ii).
‘MSI’ Spatula : s. s. 6”
-do- 8”
181.(i).
(ii).
‘MSI’ Forceps, Micro dissecting: s. s. 4” curved serrated
-do- 4” straight
182.
‘MSI’ Needles medium.
183.(i).
(ii).
‘MSI’ Scissors Micro dissecting 4”: curved sharp pointed
-do- 4” straight sharp point
184.
‘MSI’ Slide Blue Star.
185.(i).
(ii).
Aluminium Foil: 9 mtr roll
-do- 1 kg roll
186.
Tissue Paper roll: 2 ply imported paper.
187.
Appron Coat: Cotton white.
188
Cotton: 500 gm pkt.
189.
Glassvials: 5ml with aluminium screw cap. (Sample bottles)
190.
Brown: paper for packing.
191.
Thread: for packing of instruments for autoclaving
192.
Parchment Paper for Osmosis 9cm x 14.5cm.
193.
‘MSI’ Spring Balance: 500gm.
37
194.
‘MSI’ Quartz Prism: 15x15mm
195.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
(xii).
(xiii).
(xiv).
(xv).
‘MSI’ Test Tube Stand :- Made of aluminium sheet.
No. of Holes Dia of Hole mm.
12 12
12 18
12 25
24 12
24 18
24 25
36 12
36 18
36 25
48 12
48 18
48 25
72 12
72 18
72 25
196.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
(xii).
(xiii).
‘MSI’ Enamel Surgical Trays without Cover:
18”x12” (45x30cm)
14”x12” (35x30cm)
12“x10” (30x25cm)
11”x9” (28x22cm)
10”x8” (25x20cm)
8”x6” (20x15cm)
18”x15” (45x38cm)
18”x12” (45x30cm)
15”x12”
19”x24”
22”x26”
32”x22”
32”x42”
197
(i).
(ii).
(iii).
(iv).
‘MSI’ Enamel Surgical Trays with Cover:
12”x10” (30x25cm)
11”x9” (28x22cm)
8”x10” (20x25cm)
8”x6” (20x15cm)
198.
(i).
(ii).
(iii).
(iv).
‘MSI’ Enamel Kidney Trays:
12” Dia 30cm
10” Dia 25cm
8” Dia 20cm
7” Dia 15cm
199.
Cover slips: square 18mm or 22 mm or 24mm
-do- round 18mm,22mm, 24mm
200.(i).
(ii).
Dry & Wet Bulb thermometer: Best Indian make.
-do- Imported ZEAL UK.
201.(i).
(ii).
(iii).
‘MSI’ Wire Gauge: with no. 1 asbestos.
Wire gauge superior with double asbestos
Wire gauge superior with side Frame
202.(i).
(ii).
(iii).
‘MSI’ Tripod Stand: made of heavy cast iron, three balanced screwed legs,
and hammer tone painted. Triangular 10cm x 15cm.
-do- 10cmx20cm
-do- 12cmx20cm
38
203.(i).
(ii).
(iii).
(iv).
‘MSI’ Stop Watch
-do- Digital
Stop Clock Easel metal body.
Stop Watch Imported 1/10 sec. In Metal Body.
204.(i).
(ii).
(iii).
‘MSI’ Quadrants small : Made of metal nicely painted with thread 25cm x
25cm
-do- 50cmx50cm
-do- 100cmx100cm
205.(i).
(ii).
‘MSI’ Stethoscope best Indian Nova phone/Pioneer make.
-do- but superior export quality.
206.
(i).
(ii).
(iii).
(iv).
(v).
‘MSI’ Dessicators: With knobbed lid Borosilicate Neutral Glass with porcelain
perforated Plate.
Size
160 mm
210 mm
240 mm
300 mm
120 mm
Plain
1050.00
1850.00
2800.00
4500.00
800.00
207.
‘MSI’ Sieve shaker.
Rotap Sieve Motorized: this can accommodate sieves of 8” dia and is driven
by ¼ HP Motor. The circular end to end from motion to give by mechanism
which is fully immersed in oil. The taping motion is given by hammer from the
top.
208
‘MSI’ Gyratory Sieve Shaker Motorized: this can accommodate up to 7
sieves of 6” or 8” dia and is Driven by ¼ HP electric motor through reduction
gear. Every part of the sieve is utilized by Contact upward and downward
movement. The whole gear mechanism runs in oil bath. Supplied without test
sieves suitable for operation on 220V AC mains.
209
‘MSI’ Hand operated Sieve Shaker: Can accommodate up to 7 sieves of 8”
dia during the train of Gears operated by a hand wheel. A heavy fly wheel
ensured smooth operation. Supplied Without test sieves and lid receiver
210.
(i).
(ii).
(iii).
‘MSI’ WET SIEVE SHAKER (YODER TYPE) :- This Yoder type motor
driven sieve shaker is for carrying out wet sieve analysis of material. Consists of
a water reservoir and a holder for sieve which can take up to 7 sieve of 8” dia.
The shaker is driven by ¼ HP motor through a belt drive. Suitable to operate on
230 V 50 cycle, single phase AC.
CAP.
FOR 1 SET
FOR 2 SET
FOR 3 SET
WITH G.I.
TANK
29500.00
40500.00
50500.00
39
211.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
(xii).
(xiii).
(xiv).
(xv).
(xvi).
(xvii).
(xviii).
(xix).
(xx).
(xxi).
(xxii).
(xxiii).
(xxiv).
(xxv).
(xxvi).
(xxvii).
(xxviii).
(xxix).
‘MSI’ STANDARD TEST SIEVES: AS PER I.S. 460- 1962
S.S.Mesh framing in Brass 8”
B.S.S. A.S.T.M. I.S.S. MICRONS M.M.
4 5 480 4.75
5 6 340 1812 3.35
6 7 280 2411 2.80
7 8 240 2207 2.36
8 10 200 2057 2.00
10 12 170 1698 1.70
12 14 140 1005 1.40
14 16 120 1200 1.18
16 18 100 1000 1.00
18 20 85 850 0.850
22 2 7 71 0.710
25 30 60 60 0.600
30 3 50 500 0.500
36 40 40 425 0.425
44 45 35 355 0.355
52 50 30 300 0.300
60 60 25 250 0.250
72 70 20 212 0.212
85 80 18 180 0.180
100 100 15 150 0.150
120 120 12 125 0.125
150 140 10 106 0.106
170 170 9 90 0.090
200 200 8 53 0.075
240 230 7 63 0.063
300 270 6 53 0.053
325 300 5 44 0.044
350 325 4 45 0.045
400 380 40 0.040
212.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
(ix).
(x).
(xi).
(xii).
‘MSI’ Electrophoresis app: MSI/GENEI
Vertical Slab Gel Electroporesis Genei make Model 05-01 size 8x7cm
-do- Model 05-02 size 2x (8x7)cm
-do- Model 05-03 size 16x14 cm
-do- Model 05-04 2x (16x14) cm
-do- 16x20 1 gel 106783
-do- 16x20 2 gel 106784
Horizontal.
Submarine Electrophoresis MSI make model 03-01 size 10x7cm
-do- Model 03-02 size 13x13 cm
-do- Model 03-03 size 13x25 cm
-do- Model 03-04 Size 20x20 cm
-do- 30x25 cm 106614
-do- 20x37 cm 106627
213.(i).
(ii).
‘MSI’ Electrophoresis Power supply digital: with 2 meter 0-300 Volts & 0-
100mA continuously variable with short circuit and overload protection. With
manual
Electrophoresis Power Supply Digital range 0-500V, 0-500 mA variable
with timer. CC & CV with manual.
214.
(i).
(ii).
(iii).
(iv).
‘MSI’ Gel rocker for Gel Staining: Culture Aeration, Blotting, Bathing,
Platform Size: 30x30cm, Speed 0-50 RPM, Movement-See-saw, timer 0-60
min (optional)
Gel Rocker single Platform without timer
Gel Rocker single Platform with timer
Gel Rocker double Platform without timer
Gel Rocker double Platform with timer
40
215. (i).
(ii).
(iii).
a.
b.
c.
Digital Gel Documentation system:- Gel documentation System UVI Tech
U.K. Fire Reader Gel documentation System make w/o UV Transilluminator
CCD camera & software. Ideal and compact system for acquiring gel
photographs and can be easily accommodated in any part of the laboratory.
Ideal for documentation, quantification & publication. Upgradable to
Chemilluminosence, versatile and upgradable. Steel and stainless steel
darkroom. Epoxy painted for chemical resistance. Black body imaging grade.
Built in roil out transilluminator. UV timer & security.
CCD Camera-complete Digital Imaging system comprising of CCD camera 16
bit performance with F 1.2 Zoom lens of 8-75mm, 768x562 pixel resolution on
documentation mode
UV Tran illuminator (365 nm) 20x20cm imaging area, multiple image display,
real time read out with full image for image acquisition, Enhancing, archiving
documentation and analysis for MW, I.D. densitometry with photo quality
printer.
OPTIONAL AT EXTRA COST.
HP make Laptop with 15” in built Monitor. CD/DVD drive and inbuilt speaker
etc. 1.3 GHz. Standard configuration with Licensed Window software.
EPILIGHT CONVERTER:White Light Converter
Gel Documentation System College Model.
216.
(i).
(ii).
(iii).
‘MSI’ Micro Centrifuge: (Tinifuge): It is versatile equipment with
applications: for Cell Pelleting, Quick spins for Enzymes, Reaction, Initial Spin
for DNA sequencing Quick Spin for Primer Annealing/Hybridization, Serum
Sampling, Other Short spin rungs. Speed 5000/1000 rpm, fixed speed, rotor FA
6 place x1 ml, Noise: <60 dB, Operating temp 0-40 deg. C.
Speed 6000 rpm
Speed 10000 rpm
Speed 14000 rpm
217.
(i).
(ii).
Micro Centrifuge.
Quiet and reliable
Small foot print
Built in power supply
Digital display of time & RPM
Standard 6 place Rotor for 1.5 ml tubes
Spare 12 place Rotor for 0.5 ml tubes
Spare Rotor for above
6X1.5ml tubes
12x0.5ml tubes
218.
Micro Centrifuge. Spinwin MC-02 is a compact and easy to use. Yet powerful
enough for a wide range of molecular biology separations and quick spins.
Specifications:
Max. RPM 13500RPM
Max. RCF 12225 X g
Max. Capacity 1.5 (2.0ml) x 12 tubes
Adaptor for 0.2 ml and 0.5 ml tubes.
Control Digital Feedback Control with jog Shuttle
Switch (Turn + Push)
Display 99min. 59sec. continuous mode
Cooling Device Air Cooling
Drive System Brushless DC motor, Direct Drive
Acceleration time <-15 sec (for max. speed)
Braking time <-15sec (for max. speed)
Safety System Motor Error Detection, Auto Stop when
opening door
Noise Level <-57dB
Power Consumption 90W
41
219.
a.
‘MSI’ Heating Block /Dry Bath : It is provided with a solid anodized
aluminium combo block (standard) to hold 24 tubes (1.5 ml- 8 tubes, 0.5 ml- 8
tubes, 5 ml-8tubes). It is housed in recessed chamber. The temp. Controller
ensure aluminium block temperature to be within +/- 0.5 deg. C of set value. It
is designed for continuous use and there is no need to unplug. The aluminium
Block can be autoclavable to avoid contamination.
Spare Heating Block 1.5 ml or 2 ml. or 0.5 ml any one.
220.
(i).
(ii).
(iii).
‘MSI’ Lab Model Ice Flaker (Crushed Ice Machine): We offer the Ice
flakers with Guaranteed Production @ 20 deg. C and 15 deg. C water temp. and
DM water. IN out GMP versions we use s. s. 316 bins and outer are of s. s. 304.
& GMP VERSION WE USE S.S. 304 BINS AND OUTER ARE OF MS
POWDER COATED. (Recommended :- DM water or RO Water)
Protection capacity.
40-50kg
70 kg/24 hr.
85 kg/24 hr.
FOR DETAILS AND SPECIFICATIONS SEE THE ATTACHED
SPECIFICATION SHEET
Price non-
GMP version
150000.00
210000.00
245000.00
221.
a.
b.
c.
Two Bed Portable Deionisers
Water Distillation App. Cap 100 lit Exchange India make Model CA-20U with
Conductivity meter.
-do- Model CA-60U with digital conductivity meter
WE ARE THE AUTHORIZED DEALER OF M/S ION EXCHANGE INDIA
LTD. IN YOUR AREA FOR THE ABOVE PRODUCTS.
Installation charges for above any model.
222.
PCR:
(i).
a.
b.
Gradiant Thermo Cycler.
96 well Gradient thermoal Cycler w/o Block unit: Gradient range- 20 deg. C to
70 deg. C, Maximum Gradient-30 deg. C (16 deg. C for 384 well), Max, ramp
rate- 3 deg.C/sec, Block uniformity at 50 deg. C-0.3 deg. C, column uniformity
with 10 deg. Gradient 0.3 deg. C, Temp range 4 deg. To 99 deg. C, Temp set
point precision 0.1 deg.C, Heated lid temperature 100 deg to 115 deg. C.
Connection to PC control program & software upgrades from website.
Block unit for above :- formats --- 0.2 ml cap 96, Gradient block- 0.5, 0.2 ml,
384 (optional), In situ block-yes, User interchangeable- yes.
(ii).
a.
b.
96. Well Thermal Cycler.
96 well Thermal Cycler w/o Block unit : Max. temp rate 2.6 deg. C/sec, Block
uniformity at 50 deg. C-<+/-0.3 deg. D, temperature range -4 deg. To 99 deg. C,
temp. set point precision -0.1 deg. C, Heated lid temp range -100 deg. To 115
deg, C, with connection to PC control program and free software upgrade from
website
Block Unit for above format --- 02ml cap. -96 wells, (Optional -0.5ml, or 384
well), in situ block and user interchangeable.
(iii).
Thermal Cycler with block cap. 0.2ml x 25 well block
(iv).
Thermal Cycler with block cap. 0.5ml x 20 well block
223.
‘MSI’ Blood Cell Counter 6 units (Clay Adam’s type) : Model BCC-10. For
blood cell counting and simple computations including percentage. Each unit
records up to 999 and last totalizes the cells. A bell automatically sounds at
every hundred. Dual knob on both ends facilitating. Supplied in attractive
wooden packing velvet lined with nitrocellulose clear for safe storage when not
in use.
42
224.(i).
(ii).
‘MSI’ Blood Cell Counter 9 units : Model BOC 15: Same as above but
with 8 keys, have Totalizer with dual rest Knobs. Supplied in attractive velvet
lined wooden box with Nitrocellulose clear polish for safe storage when not in
use.
‘MSI’ Electronic differential Blood Cell counter :- Housed in a sleek metal
enclosure it includes a Regulated Power supply housed in a separate enclosure.
It has a 3 digit display with audio beep at every count and visual indication of
last count. An arrangement has been provided for Cancellation of last wrong
count entered. An audio beep is given at every hundred counts. Individual
totals and/or percentage are obtainable at any stage of count. An in built stop
watch and Timer is also provided and normal counting can be done
simultaneously with the timer running. Max count possible is 999 with 8
channels keys. To work on 220/230 v AC supply.
225.
(i).
(ii).
(iii).
‘MSI’ LOBORATORY JACK LJ-65. Box type: Adjustable at any time
within the above range, Maximum Load capacity 25 kg.
Ht. Size All
8” 5”x5” 1700.00
14” 8”x8” 2420.00
17” 10”x10” 2950.00
M.S.
1525.00
2100.00
2700.00
226.(i).
(ii).
a.
MSI’ Tissue Culture Rack : Fabricated out of M.S. 1.5. 1.5x1.25 Inch
Square pipe with powder coated paint fitted with sturdy castor wheel for smooth
shifting movement of the unit. Shelves size 50 x 18 inch are made of M.S.
heavy sheet of 22/20 SWG. Distance between the shelves 14/15 inch each
shelves is been provided with four fluorescent tubes of 4 ft. size. The unit is
workable on 220V AC mains. Heavy duty Electronic Ballast choke. The whole
unit is controlled with Digital Electronic Microprocessor based Programmable
timer for 7 days. Ideal unit performing Culture/Growth work in Laboratory.
Total Size approx: 60”x50”x24” 4 Shelves (5 Tray)
-do- but 5 shelves (6 Tray)
Optional:
Voltage Stabilizer 2 KVA at extra cost. Automatic
227.
Photoperiodic Simulator.
Analogue type switches on/off lights at time set by the user.
Photoperiodic repeat cycle : 24 hrs.
Min on/off period : 30 minutes
Back up auto recharging : NICAD
Powered Output : Directly drives up to 100 tubes lights of 40W
Each
Thermal Safety : 15 A output,
Accuracy : + 1 sec. / day
228.
Digital Photoperiodic Simulator.
Same as above, but with Digital type setting of timer by Thumb Wheel
Switch
229.
Programmable Photoperiodic Simulator.
With accuracy better than + 1 sec./day & facility of programming
230.
Sequential Timer.
for operating two air conditioners of 1.5 tonnes each
Output : Operates two AC’s up to 1.5 tonnes each.
Min. on/off Cycles : 30 Minutes
231.
Biotech Room Temp. Controller.
Temp. range 0.1 oC to 70 oC
Accuracy: : + 1 oC
LED : 13mm with PT-100 SENSOR
Directly output 1.5 ton A.C. & 4.4 KW Heat Convector.
232.
Microprocessor Based Room Temp. Controller.
do- same as above but with programmable temperature controlling of the
43
Room.
233.
Room Temperature Controller Analogue.
Range : 0-50 oC
Accuracy : + 2 oC, for 1.5 tonne AC/4.4 KW Heater
234.
Humidity Controller Analogue.
Control Humidity from Ambient to 90% with imported, Humidstat Switching
unit, etc.
235.
Humidity Controller Digital.
Control Humidity up to 98% with LCD Display with imported RH Sensors and
direct output for humidifier/ dehumidifier of 4KW.
236.
(i).
(ii).
(iii).
(iv).
Willey Grinder (Arthur H. Thomas Type).
The chamber is fitted with a hopper provided with a cover. Three delivery S.S.
sieves brush, L-N Key and plastic receiver are supplied. A removable plexi
glass plate permits observation during operation.
Chamber Size Motor Cap.
40 x 25mm 0.25 H.P.
65 x 25mm 0.25 H.P.
100 x 50mm 0.50 H.P.
200 x 75mm 1.00 H.P.
M. Steel
Chamber
14000.00
16500.00
24000.00
38000.00
237.
(i).
(ii).
(iii).
MSI’ Ball Mill Laboratory Type : Electrically operated having a capacity
from a few gms to 1 kg or 2 kg or 5 kg Fitted with a FHP motor upto 2 kg jar
and with ¼ HP heavy duty motor for 5 k. Jar Maximum speed 80 RPM supplied
with steel balls for mixing and grinding. Operates on 220V Ac mains.
Cap.
1 kg
2 kg
5 kg
All jar.
12000.00
15500.00
26000.00
238.
‘MSI’ Abbe Refractometer: Used for measuring refracting index in the range
1.3 to 1.7 with an accuracy of 0.001 direct on scale and 0.001 by estimation.
Sugar percentage range of 0 to 95% with an accuracy of 1% on scale and 0.1 by
estimation can be measured. Complete with test piece contact liquid and
thermometer in wooden cabinet.
239.
(i).
(ii).
(iii).
(iv).
(v).
(vi).
(vii).
(viii).
MSI’ Hand Refractometer : These instruments are widely used for measuring
the sugar concentration of sugar cane, fruit juice, syrups, jams, confectionery
products and liquids.
Range
0-32%
28-62%
58-92%
B&S 0-50%
-do- 40-85%
Digital Hand Refractometer Model PAL-I ATGO: Japan range 0-53%
Pocket type in nice Case.
-do- range 45-93% PAL-2
-do- 0-93% PAL-3
44
240.
‘MSI’ Bomb Calorimeter: For Determination of Calorific Value of Liquids &
solids. Designed in accordance with the Specifications of the Institute of
Petroleum and the British Standard Institution
Construction: Bomb body machined from corrosion resistant stainless steel
alloy. Each bomb tested at a pressure of 300kg/cm2 for 10 minutes. Colorimeter
vessel & water jacket is made of chromium-planted copper/s. s. Offset stirrer
precludes heat from motor to calorimeter vessel. High mechanical standard.
BOMB CALORIMETER OUTFIT: - Provides a simple and inexpensive
method for determination of heat of combustion organic matter and the calorific
value & sulphur content of solid & liquid fuel. The outfit supplied is complete
for always as per the method recommended by British Standard Institution BS
1016. All parts of the outfit have been finished and tested according to the
specifications laid down by Institute of Petroleum and British Standard
Institution.
BOMB:- The body and lid are machined from corrosion resisting steel;
satisfying the special swinging and bend tests for inter crystalline corrosion and
having food high temperature properties. The interior of the Bomb has been
maintained cylindrical throughout its length. The capacity is approximately
300ml. The metal-to-metal seal between the body and lid is backed by a sealing
ring. The closure ring is made of other corrosion resisting s. s. And hand
tightening of the closure ring is sufficient to ensure perfect gas tight sealing.
The Bomb is provided with a high pressure Schrader value that simplifies the
operation considerably. The value opens and allows filling of Bomb by Oxygen
because of Oxygen pressure from Cylinder. It closes when pressure from
Oxygen Cylinder is cut off.
Two electrodes are incorporated in the lid of the Bomb and in each of these a
saw cut is provided so that the ignition wire can be gripped by the sliding
sleeves fitted on the electrodes.
TESTING OF BOMB:- Each Bomb is tested before its leaves the factory, in
accordance with the requirements of the Institute of Petroleum (IP 12/63T
Appendix 1) and a work certificate is issued with each Bomb. This certificate
gives the results of hydraulic testing under a pressure of 300 atmospheres (4400
psi) maintained for a period of ten minutes without sign of linkage. The
maximum deformation must not exceed the specific limits.
CALORIMETER VESSEL: - The vessel is made of s. s./ copper N. P. It
includes a bomb support that ensures proper positioning of Bomb in the vessel.
WATER JACKET:- The outer container of Jacket is made of s. s. / copper
N.P. both inside and outside. The top of container carries two rods; one carries
the string Unit while the other a clip for holding the thermometer. (In Digital
model this rod is not supplied) An ebonite cover the top. A terminal block is
fitted to the top of the outer container so that connections can be made from the
firing control.
OFF SET STIRRER: The stirring mechanism supplied gives sufficient turbulence for
effective stirring, whilst no heat is imparted to the Calorimeter water. It consists of an
impeller stirrer driven at a constant speed of approximately 800 rpm. The offer
arrangement whereby the motor drives the impeller via a belt precludes any possibility of
heat transference between motor and calorimeter vessel contents.
BOMB FIRING UNIT, VIBRATOR, and TIMER AND ILLUMINATOR
WITH MAGNIFIER: Outfit, for firing a calorimeter bomb AC supply mains
(230 V 50 Hz). It consists of two parts via/ the Electrical Box and Vibrator
Timer Illuminator and Magnifier Unit. The electrical box is provided with
terminals for stirrer unit, Vibrator-timer Illuminator and for the Bomb fuse wire.
(In Digital Model Temperature Indicator is also provided).
The Unit has provision for test of firing wire resistance or open circuit and for
firing. A Green bulb indicates the first condition while red indicates the firing.
CRUCIBLE: Various type of crucibles are available, the standard supplied
with the outfit being an s. s. Crucible of 8ml cap. Which fits in the standard
support ring provided with the outfit?
Complete as above but Digital Thermometer in Place of Back men
Thermometer.
45
(i).
ESSENTIAL ACCESSIRIES AT EXTRA COT:
Oxygen Cylinder with Stage Regulator 10 kg approx
a.
b.
c.
d.
e.
f.
g.
h.
i.
j.
k.
l.
m.
n.
o.
p.
q.
r.
s.
t.
u.
Accessories Supplied with the Instrument:
Bomb and Closure Ring.
Calorimeter Vessel with Bomb jacket.
Water Jacket.
Combined Lid for Calorimeter Vessel and Water jacket.
Stirrer.
Connecting Leads.
Connecting Tube to connect Bomb and Pressure Gauge.
Connecting Tube fine adjustment value to connect Pressure Gauge and Oxygen
Cylinder.
Pressure Gauge on stand.
Spanner for Oxygen tube connection.
Ignition wire (2mtr,).
Cotton Real.
Stand for Bomb lid.
Hook for lifting Bomb.
Stainless Steel Crucible.
Hook for lifting bomb.
Stainless steel crucible.
Gas Release Value.
Valve Key.
Bomb firing unit.
Pellet Press.
a.
b.
c.
d.
e.
f.
g.
h.
ACCESSORIES SUPPLIED AT EXTRA COST:
Ignition Wire Platinum (44 SWG). (Min order 15 gm)
Benzoic Acid of Known Calorific Value
Gelatin Capsules
Nickel Crucible.
Quartz Crucible
Stainless Steel Crucible.
Platinum Crucible (minimum weight 8gm).
Ignition wire-Nichrome.
241.
a.
b.
c.
d.
e.
f.
Cuvette with Teflon lid & Matched Pair Certificate. Opti Glass Made in UK.
Path length 10mm. cap 3.5 ml.
-Do- HELLMA German Make.
-Do- Disposable Cuvette Polystyrene VU Grade pack of 100.
HELMA German make Quartz Curvette path length 10mm cap. 1 ml
Quartz cell rectangular 10m Path length 1.4 semi micro cells.
Glass Cell rectangular 10mm path length 1.4ml semi micro cells.
Glass Cell
2700.00
242.
‘MSI’ Humidifier s. s. body. Cap: 5lit. Based on the rotating dish splash plate
principal. It produce only super fine particles of micron size, which become part
of the atmosphere, thereby reaching every corner of the room, resulting in
uniform humidity. Due to the upward thrust imparted to the micron sized
duration of time. The unit is capable of atomizing upto 3 lit. Of water in an
hour at full evaporation in the driest possible ambient conditions. The unit has
body made of s. s. A single unit is effective for an enclosed space of volume up
to 40 Cu. Meter. The unit is provided with high speed 2800 RPM motor to run
longer period, and the blades are aerodynamically balanced to ensure drop less
fumigation. To work on 220/230V AC mains.
46
a.
b.
Optional accessories:
Control box with humidistat.
Automatic 0-60 minute timer.
243.
a.
‘MSI’ DE-Humidifier: (Fitted with time controlled safety device, in case
humidity controller fails, for safety of the compressor) : Dehumidifiers are
water condensing type, based on Refrigeration Cycle to avoid use of expensive
chemicals required for different type models. The unit is self standing and is
mounted on a study angle iron from, fitted with caster wheels. De humidifier
removes excess moisture from the atmosphere and it is fitted with hermetically
sealed compressor. Heat exchanger and water condensing coils are made of
copper. Water collection tank is provided below the unit to collect condensate
water. Humidity is controlled by automatic Humidistat incorporated in the unit,
upto c30% +/- 3% RH, depending upon the ambient conditions. To achieve very
low humidity, the room should have a independent window type air conditioner
to match with the dehumidifier heat load in the room. Suitable to work on
220/230V Ac supply. Cap. 1.5 ton.
Automatic stabilizer for above.
244.
(i).
(ii).
(iii).
(iv).
a.
Viscometer: Brookfield Viscometer Please mentions the viscosity rang while
ordering. Viscometers from Brookfield Eng. Lab. Inc. USA.
Dial reading Viscometers. Any range LVT/RVT/HAT/HBT
Digital Viscometer DV-E any range, LVDV-E/RVDV- E/HADV-E/HBDV-E
Digital Viscometer DV-I+ range LVDV-I+/RVDV-I+/HADV- I+/HBDV-
I+298000.00 each
Programmable viscometer DV-ii+ Pro. Any range LVD-II+P/
/RVDV-+P// HADV-II+P//HBDV-II+P
DV Loader software supplied with the above free. (d)
Brookfield Viscosity Standard 5,10,50,100,500,1000,5000,12500,30000,
60000,100000 any One (500ml)
245.
(i).
(ii).
(iii).
(iv).
Rheometer Programmable Rheometer DV-111 Ultra.
-do- Model LVDV-IIIU Viscosity 15-6M
-Do- Model RVDV-IIIU Viscosity 100-40M
-do- Model HADV-IIIU Viscosity 200-80M
-Do- Model HBDV-IIIU Viscosity 800-320M
246.
ROTATIONAL VISCOMETER FROM M/S FUNGILAB, SPAIN
MARKETING BY,TOSHNIWAL INSTRUMENTS (AJMER):
(i).
VISCOLEAD ONE L (Range 20-2000000cP)
VISCOLEAD ONE R (Range 100-13000000cP)
VISCOLEAD ONE H (Range 200-106000000cP)
Equivalent to
DVE
(ii).
VISCOLEAD ADV L (Range 20-2000000cP)
VISCOLEAD ADV R (Range 100-13000000cP)
VISCOLEAD ADV H (Range 200106000000cP)
Equivalent to
DV-I Prime
(iii).
VISCOLEAD ADV L with Temp. (Range 20-2000000cP)
VISCOLEAD ADV R with Temp. (Range 100-13000000cP)
VISCOLEAD ADV H with Temp. (Range 200106000000cP)
Equivalent to
DV-I Prime
(iv).
VISCOLEAD PRO L (Range20-2000000cP)
VISCOLEAD PRO R (Range100-40000000cP)
VISCOLEAD PRO H (Range200-106000000cP)
Equivalent to
DV-II Pro
(v).
PREMIUM L (Range 20-2000000cP)
PREMIUM R (Range 100-40000000cP)
PREMIUM H (Range 200106000000cP)
Equivalent to
DV-III Ultra
47
247.
a.
b.
c.
d.
‘MSI’ Seed/Grain Moisture meter Digital:
Model MC:- 7821 for Paddy, rice, corn wheat, automatic calibration, Moisture
range: 8-20% temp range: - 10 deg. To 55 deg. C,
Model MC 7825 G:- moisture range 6-30%, 4 digits/ 10mm LCD display with
color coded LED indicator, Grain code selection as follows :- Wheat/rye, paddy,
rice, semolina, maze/corn, Soya bean’s barley/oats, coffee, cocoa beans, lonseed
lentils, oil seed rape, mustard seed, peas, sorghum/Milo, sunflower & sugar beet
seed, flaz, grass/rye grass, seed/cocksfoot, flous/soft wheat, colure buckwheat,
brassicas/crussels sprout, beans.
Computer Moisture Meter: for Grains & Seeds. Cup TYPE Range : 3-35%
Paddy, Soya Bean, Wheat, Rape Seed, Cotton Seed, Cotton Sead, Millet, Maize,
Barley, Rice, Sunflower seed, Bean Sead Cake, Mung Bean, Peanut PIP
Moisture Meter for Seed/Grain digital Microprocessor: based with direct
reading of Moisture percentage. Suitable for 16 Grains i.e. Rice, Rye Rice,
Wheat, sunflower seed, Soybean, Sorghum, Canola complex, Oats, Rye etc.
Runs on 12V battery with automatic compensation for variable due to
temperature, with carrying case & battery.
248.a.
b.
Digital Wood Moisture Meter: LUTRON Taiwan make range 9% - 30% with
RS 232 serial interface & data hold.
-do- Range 6%-40% (wood), 0% -100% (concrete & non wood
material), 0.2% - 50% (Gypsum) With RS 232 serial interface & data hold.
249.
(i).
(ii).
Seed Counter Digital:
Seed Counter Model 6708 of ‘Indosaw’ make (Economy model) The counted
seeds are here displayed continuously on the numeric LED type display.
Thumbwheel switches are provided for selecting the count size. The machine
automatically stops after counting the set number of seeds. You can start the
new counting by pressing reset key.
Specifications:
LED Display
Easily detachable pan
Counts seed from 1 mm to 15mm
Counts maximum up to 9999 seeds in a batch
Reset arrangement for repeating batches of set size.
Power supply 220V/50H operated.
It is use full in
Germination test (about 400 required)
Taking the test weight (of 10 & 1000 seeds)
Small packing of seed where the seeds required in number
Complete as above
‘MSI’ Seed Counter Digital: total seed to be counted 99999 counting speed 35
to 300 grains/minutes. Maximum size of grain to be counted dia 1 mm to 15
mm, digital alphanumeric display LCD 2 line.
250.
‘MSI’ Seed Size analyzer: Dial Caliper for measuring the length and breadth
of seed
251.
Soil pH meter: Lutron make PH-220S type. Range 0.00-14.00 pH, Automatic
cal for pH & temperature, water proof, spear tip ph electrode ideal for
penetration into soil, meat, cheese etc.
252.
Digital Pedometer Imported:
48
253.a.
b.
c.
d.
‘MSI’ Soil Thermometer:- With BRASS CONE AT BOTTOM, filled in
wooden body, range 100 deg. C or deg. F, 100 mm long brass cone.
-do- in aluminium pipe stick type range e-10 deg. To 100 deg. Alcohol filled.
SOIL. PH & MOISTURE TESTER TAKEMURA JAPAN DM-15.
Digital soil moisture meter Lutron Taiwan make pen type water resistance, 20
cm long probe & range 0-50%.
254.
‘MSI’ Seed analysis Kits : It comprises of Mechanical weighing balance up
to 100 gm, weight box up to 100 gm, enamel plate 9”, sieve – 3.30 mesh,
Magnifying Glass 4”, scoop, measuring cylinder 20 cc, Petri dish, forceps.
These items are packed in a specially designed can vas bag.
255.
‘MSI’ Illuminated Purity Work Board : It is designed for testing physical
purity of seed samples with maximum comfort and efficiency. Also used to
distinguish discolored damaged and chalky grains/seeds. Light below the
rectangular 8”x5” opal glass (plexi glass) makes a handy disphanoscope. Use of
this spot with chaffy grass eliminates all guess works on tests. One convenient
drawer is provided in the front for large seed lots. It is fitted with a magnifying
glass conversing the entire surface of opal glass. Size: 50 x 28x10 cms. (Made
of teak wood for longer life). Draw Cap. : 930 CC approx.
256.
‘MSI’ COD Digestion app: For Determination of Chemical Oxygen demand.
It is a solid state block heated unit with provision for samples to be digested at a
time in 38 mm dia reaction vessels with 20ml sample size to heat at temp 150
deg. C +/- 1 deg. C controlled by Digital Temp. Indicator cum controller. It has
provision for 15 samples and is supplied with 15 no. glass reaction vessels and
15 no air condensers. Fitted with a 2 Hr timer, the sample after being digested
for 2 hr can be analyzed using calorimeter or conventional titration method. To
work on 220 V AC mains.
257.
(i).
(ii).
(iii).
COD MEASUREMENT:
uP COD Vario Measurement Photometer, Digestor AL 125 with 25 measuring
Cuvettes & Std. Accessories
COD Reactor / Digestor AL 125 (with cover)
COD Vario Cuvettes 25 test set 0-150 ppm, 0-1500ppm, 0-15000 ppm (any
one)
258.
(i).
(ii).
(iii).
BOD MEASUREMENT:
BOD Measurement System with 6 sensor & standard accessories : AL606
BOD Incubator (Thermo-Chamber) AL654 (140Ltr. Capacity)
BOD Incubator (Thermo-Chamber) AL654G (140Ltr. Capacity) with Glass
Door
259.
Steamclox Sterilization Indicators: 3M ATI USA Pack.Of 250 no. At 121F
260.
Chemical Sterilization Dry Heat indicator: SADL 251 K 160Dg.. C, 25mm,
1000 label USA
261.
Chemical Sterilization Indicator: Steam Raven USA. Autoclavable tape
18mm x 50 mtr.
262.
Prochem Seam Indicator: Class 5. 250 strips.
263.
Sound level Meter: Digital Lutron Taiwan. Range 30-130 dB, 3 ranges
264.
Sound Level Meter: (Digital) Lutron, Taiwan Range 35-130 dB 3 Ranges
265.
Sound Level Meter: Digital Lutron Taiwan Range 30-130 dB with Carrying
case. 3 Range with over and under range indicator Rs 232 interface, auto range.
266.
Sound Calibrator Lutron Taiwan with sound Pressure level 94 +/- 0.75 dB
267.
UV Light Meter: Luton Taiwan. Long wave or short wave any one range.
49
268.
Hand Tachometer: Digital Non Contact type Imported 5 to 99,999 RPM
269.
Digital LUX:/ Light meter Lutron Taiwan make. 0-50000 LUX
270.
Digital LUX:/ Light Meter Lutron Taiwan make range 0- 1,00,000 LUX with
Data Hold.
271.
Digital LUX:/ Light meter BIG LCD display, 5 digits, 0-4,00,000 LUX (5
range)
272.
Hot wire thermal anemometer: LUTRON Taiwan. Range: - 0.2-20m/s, 07-22
km/hr, 0-50 deg. C & 32F to 122F, also ft/min, mile / hr, knots.
273.
Assmann Physchrometer Hisamatsu: Made in Japan. Big
274.
Digital Portable Leaf Area Meter: Model WDY-500A Range 500 cm2
275.
a.
Portable Leaf Area Meter AM 300.
Truly Field Portable: The ADC AM300 Portable Leaf Area Meter is a
Compact friendly field portable instrument for the accurate non-destructive
measurement of leaf area and associated parameters
The AM300 consists of a high resolution scanner and scan board with integral
data and image storage A multi- position carving handle is provided for ease
of use and increased portability. Measurements of leaves can be made on the
scan board plate or on independent plain surface
The AM300 features the latest in high speed scanner sensor technology
enabling measurements to be made faster and easier than ever. There is no need
to precisely position leaves on the scan surface
Utilising the latest in low power consumption electronics means that over 3000
measurements can be made between recharging the batteries
AM300 Portable Leaf Area Meter with : carrying
bag Battery Charger
Computer interface Instrument manual Power
requirements 110V/60Hz or 240V/50Hz.
Measured Parameters Leaf area, length width, perimeter, Average area
and accumulated area.
Resolution 0.065mm2.
Accuracy Within +/-2%.
Scanning Head LED Light source.
Max. Measurement 100mm (can be used on independent scan board
width for wider leaves).
Display and Storage 64 x240 pixel graphic LCD.
Internal Memory 256 bytes RAM,
Memory Capacity 2000 data sets.
Dimensions 275mm x 250mm x 30mm.
Battery Nickel metal hydride 1.2Ah.
Battery Charger Built in fast charger; can use Supplied Mains.
adapter or 12V car Battery Indicators for charger
status.
Output RS232C with baud rates from 300 To 57600, / xoff
or CTS handshake.
Essential Accessories:
Scan Board and scanner
276.
Digital Thermo anemometer: Lutron Taiwan make with metal vane andRS-
232, Range 0.8-40 m/s, 2.8-2144 km/hr, 0-60 deg. C, or 32 F, combined Backlit
LCD display.
277.
Prismatic Binocular: China make 7x35 or 8x40 or 10 x 50 any one.
50
278.(i).
(ii).
(iii).
(iv).
(v).
Digital Humidity Temp: Meter with K type temp probe range 5% - 95% RH
& -20 to 1000 Deg. C, max/min reading, data hold, C & F combined, Backlit
LCD display.
Stem thermometer (-50 deg. To 150 deg. C or F & resolution 0.1 deg.)
Temperature + Humidity + clock Digital Imported.
Digital Thermo Hygrograph SEKONIC Japan with 6 month re cording ST-50
range -20 to + 80 deg. C RH 0-100%
Precision thermo Hygrograph ISUZU Japan THR 1-2 with graph facility -15
to + 490 deg. c. RH 0-100%
279.
Global Positioning System Garmin. USA Software & PC Cable
Model
(i).
Etrex H
(ii).
Etrex -10
(iii).
Etrex-20
(iv).
Etrex-30
(v).
Etrex Vista H
(vi).
Etrex Vista HCX
(vii).
GPS-72 H
(viii).
GPS MAP-78 S
