clear ip access-list counters through crl-cache
none
•clear ip access-list counters, page 4
•clear ip access-template, page 5
•clear ip admission cache, page 7
•clear ip audit configuration, page 8
•clear ip audit statistics, page 9
•clear ip auth-proxy cache, page 10
•clear ip auth-proxy watch-list, page 11
•clear ip inspect ha, page 13
•clear ip inspect session, page 14
•clear ip ips configuration, page 16
•clear ip ips statistics, page 17
•clear ip sdee, page 19
•clear ip trigger-authentication, page 20
•clear ip urlfilter cache, page 21
•clear ipv6 access-list, page 23
•clear ipv6 inspect, page 25
•clear ipv6 snooping counters, page 26
•clear kerberos creds, page 27
•clear ldap server, page 28
•clear logging ip access-list cache, page 29
•clear parameter-map type protocol-info, page 30
•clear policy-firewall, page 31
•clear policy-firewall stats global, page 33
Cisco IOS Security Command Reference: Commands A to C
1
•clear policy-firewall stats vrf, page 34
•clear policy-firewall stats vrf global, page 35
•clear policy-firewall stats zone, page 36
•clear port-security, page 37
•clear radius, page 39
•clear radius local-server, page 40
•clear webvpn nbns, page 42
•clear webvpn session, page 43
•clear webvpn stats, page 44
•clear xsm, page 46
•clear zone-pair, page 48
•clid, page 49
•client, page 51
•client authentication list, page 53
•client configuration address, page 55
•client configuration group, page 57
•client inside, page 58
•client pki authorization list, page 59
•client recovery-check interval, page 61
•client connect, page 62
•client rekey encryption, page 64
•client rekey hash, page 66
•client transform-sets, page 68
•commands (view), page 70
•configuration url, page 75
•configuration version, page 77
•config-exchange, page 79
•config-mode set, page 80
•connect, page 81
•content-length, page 83
•content-scan out, page 85
•content-scan whitelisting, page 87
•content-type-verification, page 89
Cisco IOS Security Command Reference: Commands A to C
2
clear ip access-list counters through crl-cache none
•control, page 93
•copy (consent-parameter-map), page 95
•copy idconf, page 97
•copy ips-sdf, page 99
•consent email, page 102
•crl, page 104
•crl (cs-server), page 107
•crl query, page 110
•crl best-effort, page 112
•crl optional, page 114
•crl-cache delete-after, page 116
•crl-cache none, page 118
Cisco IOS Security Command Reference: Commands A to C
3
clear ip access-list counters through crl-cache none
clear ip access-list counters
To clear IP access list counters, use the clear ip access-list counters command in privileged EXEC mode.
clear ip access-list counters [access-list-number|access-list-name]
Syntax Description (Optional) Number or name of the IP access list for
which to clear the counters. If no name or number is
specified, all IP access list counters are cleared.
access-list-number |access-list-name
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.11.0
Usage Guidelines The counter counts the number of packets that match each permit or deny statement in an access list. You
might clear the counters if you want to start at zero to get a more recent count of the packets that are matching
an access list. The show ip access-lists command displays the counters as a number of matches.
Examples The following example clears the counter for access list 150:
Router# clear ip access-list counters 150
Related Commands DescriptionCommand
Displays the contents of IP access lists.show ip access list
Cisco IOS Security Command Reference: Commands A to C
4
clear ip access-list counters through crl-cache none
clear ip access-list counters
clear ip access-template
To clear statistical information on the access template, use the clear ip access-template command in privileged
EXEC mode.
clear ip access-template {access-list-number|name}dynamic-name {source-address source-wildcard-bit|
any|host {hostname|source-address}} {destination-address dest-wildcard-bit| any|host {hostname|
destination-address}}
Syntax Description Access list number. Range is from 100 to 199 for an
IP extended access list and from 2000 to 2699 for an
expanded-range IP extended access list.
access-list-number
Name of an IP access list.
•The name cannot contain a space or quotation
mark, and must begin with an alphabetic
character to avoid ambiguity with numbered
access lists.
name
Name of a dynamic access list.
dynamic-name
Source address in a dynamic access list.
•All other attributes are inherited from the
original access-list entry.
source-address
Source wildcard bits.
source-wildcard-bit
Specifies any source host name.any
Specifies a specific source host.host
Name of the host.
hostname
Destination address in a dynamic access list.
•All other attributes are inherited from the
original access-list entry.
destination-address
Destination wildcard bits.
dest-wildcard-bit
Command Modes Privileged EXEC (#)
Cisco IOS Security Command Reference: Commands A to C
5
clear ip access-list counters through crl-cache none
clear ip access-template
Command History ModificationRelease
Support for this command was introduced on the Supervisor Engine 720.12.2(14)SX
Support for this command on the Supervisor Engine 2 was extended to Cisco
IOS Release 12.2(17d)SXB.
12.2(17d)SXB
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command was modified in a release earlier than Cisco IOS Release
15.0(1)M. The any,host hostname, and timeout minutes keywords and
arguments were added.
15.0(1)M
Examples This example shows how to clear statistical information on the access list:
Router#
clear ip access-template 201 list1 any 172.0.2.1 172.0.2.2
Related Commands DescriptionCommand
Displays configuration information about the NetFlow
hardware.
show mls netflow
Cisco IOS Security Command Reference: Commands A to C
6
clear ip access-list counters through crl-cache none
clear ip access-template
clear ip admission cache
To clear IP admission cache entries from the router, use the clear ip admission cachecommand in privileged
EXEC mode.
clear ip admission cache {*|host ip address}
Syntax Description Clears all IP admission cache entries and associated
dynamic access lists.
*
Clears all IP admission cache entries and associated
dynamic access lists for the specified host.
host ip address
Command Modes Privileged EXEC #
Command History ModificationRelease
This command was introduced.12.3(8)T
This command was integrated into Cisco IOS Release 12.2(33)SXI.12.2(33)SXI
Usage Guidelines Use this command to clear entries from the admission control cache before they time out.
Examples The following example shows that all admission entries are to be deleted:
Router# clear ip admission cache *
The following example shows that the authentication proxy entry for the host with the IP address 192.168.4.5
is to be deleted:
Router# clear ip admission cache 192.168.4.5
Related Commands DescriptionCommand
Displays the admission control entries or the running
admission control configuration.
show ip admission cache
Cisco IOS Security Command Reference: Commands A to C
7
clear ip access-list counters through crl-cache none
clear ip admission cache
clear ip audit configuration
To disable Cisco IOS Firewall IDS, remove all intrusion detection configuration entries, and release dynamic
resources, use the clear ip audit configuration command in EXEC mode.
clear ip audit configuration
Syntax Description This command has no arguments or keywords.
Command Modes EXEC
Command History ModificationRelease
This command was introduced.12.0(5)T
This command is no longer supported in Cisco IOS Mainline or
Technology-based (T) releases. It may continue to appear in 12.2S-family
releases.
12.2(13)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support in
a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines Use the clear ip audit configuration EXEC command to disable Cisco IOS Firewall IDS, remove all intrusion
detection configuration entries, and release dynamic resources.
Examples The following example clears the existing IP audit configuration:
clear ip audit configuration
Cisco IOS Security Command Reference: Commands A to C
8
clear ip access-list counters through crl-cache none
clear ip audit configuration
clear ip audit statistics
To reset statistics on packets analyzed and alarms sent, use the clear ip audit statistics command in EXEC
mode.
clear ip audit statistics
Syntax Description This command has no arguments or keywords.
Command Modes EXEC
Command History ModificationRelease
This command was introduced.12.0(5)T
This command is no longer supported in Cisco IOS Mainline or
Technology-based (T) releases. It may continue to appear in Cisco IOS
12.2S-family releases.
12.2(13)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support in
a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines Use the clear ip audit statistics EXEC command to reset statistics on packets analyzed and alarms sent.
Examples The following example clears all IP audit statistics:
clear ip audit statistics
Cisco IOS Security Command Reference: Commands A to C
9
clear ip access-list counters through crl-cache none
clear ip audit statistics
clear ip auth-proxy cache
To clear authentication proxy entries from the router, use the clear ip auth-proxy cache command in EXEC
mode.
clear ip auth-proxy cache {*|host-ip-address}
Syntax Description Clears all authentication proxy entries, including user
profiles and dynamic access lists.
*
Clears the authentication proxy entry, including user
profiles and dynamic access lists, for the specified
host.
host-ip-address
Command Modes EXEC
Command History ModificationRelease
This command was introduced.12.0(5)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines Use this command to clear entries from the translation table before they time out.
Examples The following example deletes all authentication proxy entries:
clear ip auth-proxy cache *
The following example deletes the authentication proxy entry for the host with IP address 192.168.4.5:
clear ip auth-proxy cache 192.168.4.5
Related Commands DescriptionCommand
Displays the authentication proxy entries or the
running authentication proxy configuration.
show ip auth-proxy
Cisco IOS Security Command Reference: Commands A to C
10
clear ip access-list counters through crl-cache none
clear ip auth-proxy cache
clear ip auth-proxy watch-list
To delete a single watch-list entry or all watch-list entries in Privileged EXEC configuration command mode,
use the clear ip auth-proxy watch-list command.
clear ip auth-proxy watch-list {ip-addr| *}
Syntax Description IP address to be deleted from the watch list.
ip-addr
All watch-list entries from the watch list.*
Command Default This command has no default settings.
Command Modes Privileged EXEC.
Command History ModificationRelease
Support for this command on the Supervisor Engine 2 was extended to Release
12.2(17d)SXB.
12.2(17d)SXB
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines This command is supported on the systems that are configured with a Supervisor Engine 2 Supervisor Engine
2 only.
If you see entries in the watch list that you suspect are not valid, you can enter the clear ip auth-proxy
watch-list command to clear them manually instead of waiting for the watch list to expire.
Examples This example shows how to delete a single watch-list entry:
Router# clear
ip auth-proxy watch-list 10.0.0.2
Router#
This example shows how to delete all watch-list entries:
Router# clear
ip auth-proxy watch-list *
Router#
Cisco IOS Security Command Reference: Commands A to C
11
clear ip access-list counters through crl-cache none
clear ip auth-proxy watch-list
Related Commands DescriptionCommand
Limits the number of login attempts at a firewall
interface and QoS filtering and enter the ARP ACL
configuration submode.
ip auth-proxy max-login-attempts
Enables and configures an authentication proxy watch
list.
ip auth-proxy watch-list
Displays the information about the authentication
proxy watch list.
show ip auth-proxy watch-list
Cisco IOS Security Command Reference: Commands A to C
12
clear ip access-list counters through crl-cache none
clear ip auth-proxy watch-list
clear ip inspect ha
To delete the Firewall stateful failover sessions information from a router’s memory, use the clear ip inspect
hacommand in privileged EXEC mode.
clear ip inspect ha [sessions all| statistics]
Syntax Description (Optional) Clears all the firewall HA sessions.sessions all
(Optional) Clears the HA statistics on the device.statistics
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.4(6)T
Usage Guidelines If the clear ip inspect ha sessions allcommand is used on the standby device, the standby HA sessions are
cleared. This initiates re-synchronization of all HA sessions from the active device to the standby device.
Examples The following example shows all sessions being deleted:
Router# clear ip inspect ha sessions all
The following example shows statitics being deledted.
Router# clear ip inspect ha statistics
Cisco IOS Security Command Reference: Commands A to C
13
clear ip access-list counters through crl-cache none
clear ip inspect ha
clear ip inspect session
To delete Context-Based Access Control (CBAC) configuration and session information from a router’s
memory, use the clear ip inspect sessioncommand in privileged EXEC mode.
clear ip inspect session session-address
Syntax Description Deletes a specific session; the format is 0-FFFFFFFF.
session-address
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.4(4)T
Usage Guidelines Sessions consist of control channels and data channels.
Use the clear ip inspect session command to delete a control channel or a data channel. If you specify a
control channel session, then data channel sessions may also be deleted, depending on the application protocols
being used. If you specify a data channel session, then only that specific session is deleted.
If you attempt to delete a session and the clear ip inspect session command is not supported for the specified
protocol, then an error message is generated.
If you want to delete a specific session, use the show ip inspect session command to display all session
addresses.
The clear ip inspect session command is recommended for advanced users only because it may disrupt
network operations if traffic is still flowing through the session.
Note
Examples The following example displays the current session addresses:
Router# show ip inspect session
Established Sessions
Session 25A3318 (10.0.0.1:20)=>(10.1.0.1:46068) ftp-data SIS_OPEN
Session 25A6E1C (10.1.0.1:46065)=>(10.0.0.1:21) ftp SIS_OPEN
The following example shows a specific session being deleted:
Router# clear ip inspect session 25A6E1C
Cisco IOS Security Command Reference: Commands A to C
14
clear ip access-list counters through crl-cache none
clear ip inspect session
Related Commands DescriptionCommand
Displays CBAC configuration and session
information.
show ip inspect
Cisco IOS Security Command Reference: Commands A to C
15
clear ip access-list counters through crl-cache none
clear ip inspect session
clear ip ips configuration
To disable Cisco IOS Firewall Intrusion Prevention System (IPS), remove all intrusion detection configuration
entries, and release dynamic resources, use the clear ip ips configuration command in EXEC mode.
clear ip ips configuration
Syntax Description This command has no arguments or keywords.
Command Modes EXEC
Command History ModificationRelease
This command was introduced.12.0(5)T
The command name was changed from the clear ip audit configuration
command to the clear ip ips configuration command.
12.3(8)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support in
a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Examples The following example clears the existing IPS configuration:
clear ip ips configuration
Cisco IOS Security Command Reference: Commands A to C
16
clear ip access-list counters through crl-cache none
clear ip ips configuration
clear ip ips statistics
To reset statistics on packets analyzed and alarms sent, use the clear ip ips statistics command in privileged
EXEC mode.
clear ip ips statistics [vrf vrf-name]
Syntax Description (Optional) Resets statistics on packets analyzed and
alarms sent per VRF.
vrf
User specific VRF.
vrf-name
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.12.0(5)T
The command name was changed from the clear ip audit statistics command
to the clear ip ips statistics command.
12.3(8)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
The vrf keyword and argument were added.
12.4(20)T
Examples The following example clears all Intrusion Protection System (IPS) statistics:
clear ip ips statistics
Examples The following example displays the output of the clear ip ips statistics vrf vrf-namecommand:
Router# clear ip ips statistics vrf VRF_600
Router# show ip ips statistics vrf VRF_600
Signature statistics [process switch:fast switch]
signature 5170:1 packets checked: [0:2]
Interfaces configured for ips 3
Session creations since subsystem startup or last reset 0
Current session counts (estab/half-open/terminating) [0:0:0]
Maxever session counts (estab/half-open/terminating) [0:0:0]
Last session created 00:02:34
Cisco IOS Security Command Reference: Commands A to C
17
clear ip access-list counters through crl-cache none
clear ip ips statistics
Last statistic reset never
TCP reassembly statistics
received 8 packets out-of-order; dropped 0
peak memory usage 12 KB; current usage: 0 KB
peak queue length 6
Cisco IOS Security Command Reference: Commands A to C
18
clear ip access-list counters through crl-cache none
clear ip ips statistics
clear ip sdee
To clear Security Device Event Exchange (SDEE) events or subscriptions, use the clear ip sdee command in
privileged EXEC mode.
clear ip sdee {events| subscriptions}
Syntax Description Clears SDEE events from the event buffer.events
Clears SDEE subscriptions.subscriptions
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.3(8)T
Usage Guidelines Because subscriptions are properly closed by the Cisco IOS Intrusion Prevention System (IPS) client, this
command is typically used only to help with error recovery.
Examples The following example shows how to clear all open SDEE subscriptions on the router:
Router# clear ip sdee subscriptions
Related Commands DescriptionCommand
Specifies the method of event notification.ip ips notify
Sets the maximum number of SDEE events that can
be stored in the event buffer.
ip sdee events
Sets the maximum number of SDEE subscriptions
that can be open simultaneously.
ip sdee subscriptions
Cisco IOS Security Command Reference: Commands A to C
19
clear ip access-list counters through crl-cache none
clear ip sdee
clear ip trigger-authentication
To clear the list of remote hosts for which automated double authentication has been attempted, use the clear
ip trigger-authentication command in privileged EXEC mode.
clear ip trigger-authentication
Syntax Description This command has no arguments or keywords.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.11.3 T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines Use this command when troubleshooting automated double authentication. This command clears the entries
in the list of remote hosts displayed by the show ip trigger-authentication command.
Examples The following example clears the remote host table:
Router# show ip trigger-authentication
Trigger-authentication Host Table:
Remote Host Time Stamp
172.21.127.114 2940514234
Router# clear ip trigger-authentication
Router# show ip trigger-authentication
Related Commands DescriptionCommand
Displays the list of remote hosts for which automated
double authentication has been attempted.
show ip trigger-authentication
Cisco IOS Security Command Reference: Commands A to C
20
clear ip access-list counters through crl-cache none
clear ip trigger-authentication
clear ip urlfilter cache
To clear the cache table, use the clear ip urlfilter cache command in user EXEC mode.
clear ip urlfilter cache {ip-address| all} [vrf vrf-name]
Syntax Description Clears the cache table of a specified server IP address.
ip-address
Clears the cache table completely.all
(Optional) Clears the cache table only for the specified
Virtual Routing and Forwarding (VRF) interface.
vrf vrf-name
Command Modes User EXEC (>)
Command History ModificationRelease
This command was introduced.12.2(11)YU
This command was integrated into Cisco IOS Release 12.2(15)T.12.2(15)T
The vrf vrf-namekeyword/argument pair was added.
12.3(14)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set,
platform, and platform hardware.
12.2SX
Usage Guidelines The cache table consists of the most recently requested IP addresses and the respective authorization status
for each IP address.
Examples The following example shows how to clear the cache table of IP address 172.18.139.21:
clear ip urlfilter cache 172.18.139.21
The following example shows how to clear the cache table of all IP addresses:
clear ip urlfilter cache all
The following example shows how to clear the cache table of all IP addresses in the vrf named bank.
clear ip urlfilter cache all vrf bank
Cisco IOS Security Command Reference: Commands A to C
21
clear ip access-list counters through crl-cache none
clear ip urlfilter cache
Related Commands DescriptionCommand
Configures cache parameters.ip urlfilter cache
Displays the destination IP addresses that are cached
into the cache table.
show ip urlfilter cache
Cisco IOS Security Command Reference: Commands A to C
22
clear ip access-list counters through crl-cache none
clear ip urlfilter cache
clear ipv6 access-list
To reset the IPv6 access list match counters, use the clear ipv6 access-listcommand in privileged EXEC
mode.
clear ipv6 access-list [access-list-name ]
Syntax Description (Optional) Name of the IPv6 access list for which to
clear the match counters. Names cannot contain a
space or quotation mark, or begin with a numeric.
access-list-name
Command Default No reset is initiated.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.0(23)S
This command was integrated into Cisco IOS Release 12.2(13)T.12.2(13)T
This command was integrated into Cisco IOS Release 12.2(14)S.12.2(14)S
This command was integrated into Cisco IOS Release 12.2(28)SB.12.2(28)SB
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command was integrated into Cisco IOS Release 12.2(33)SXH.12.2(33)SXH
This command was introduced on Cisco ASR 1000 Series Routers.Cisco IOS XE Release 2.1
This command was modified. Information about IPv4 and IPv6 hardware
statistics is displayed.
12.2(50)SY
Usage Guidelines The clear ipv6 access-listcommand is similar to the clear ip access-list counterscommand, except that it is
IPv6-specific.
The clear ipv6 access-listcommand used without the access-list-nameargument resets the match counters for
all IPv6 access lists configured on the router.
This command resets the IPv6 global ACL hardware counters.
Cisco IOS Security Command Reference: Commands A to C
23
clear ip access-list counters through crl-cache none
clear ipv6 access-list
Examples The following example resets the match counters for the IPv6 access list named marketing:
Router# clear ipv6 access-list marketing
Related Commands DescriptionCommand
Enables the collection of hardware statistics.hardware statistics
Defines an IPv6 access list and enters IPv6 access list
configuration mode.
ipv6 access-list
Displays the contents of all current IPv6 access lists.show ipv6 access-list
Cisco IOS Security Command Reference: Commands A to C
24
clear ip access-list counters through crl-cache none
clear ipv6 access-list
clear ipv6 inspect
To remove a specific IPv6 session or all IPv6 inspection sessions, use the clear ipv6 inspectcommand in
privileged EXEC mode.
clear ipv6 inspect {session session-number| all}
Syntax Description Indicates the number of the session to clear.
session session-number
Clears all inspection sessions.all
Command Default Inspection sessions previously configured are unaffected.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.3(7)T
This command was introduced on Cisco ASR 1000 Series Routers.Cisco IOS XE Release 2.1
Examples The following example clears all inspection sessions:
Router# clear ipv6 inspect all
Related Commands DescriptionCommand
Applies a set of inspection rules to an interface.ipv6 inspect name
Cisco IOS Security Command Reference: Commands A to C
25
clear ip access-list counters through crl-cache none
clear ipv6 inspect
clear ipv6 snooping counters
To remove counter entries, use the clear ipv6 snooping counterscommand in privileged EXEC mode.
clear ipv6 snooping counters [interface type number]
Syntax Description (Optional) Clears the counter of entries that match
the specified interface type and number.
interface type number
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.12.2(50)SY
Usage Guidelines The clear ipv6 snooping counterscommand removes counters from all the configured interfaces. You can
use the optional interface type number keyword and argument to remove counters from the specified interface.
Examples The following example shows how to remove entries from the counter:
Router# clear
ipv6 snooping counters
Cisco IOS Security Command Reference: Commands A to C
26
clear ip access-list counters through crl-cache none
clear ipv6 snooping counters
clear kerberos creds
To delete the contents of the credentials cache, use the clear kerberos creds command in privileged EXEC
mode.
clear kerberos creds
Syntax Description This command has no arguments or keywords.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.11.1
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines Credentials are deleted when this command is issued.
Cisco supports Kerberos 5.
Examples The following example illustrates the clear kerberos creds command:
Router# show kerberos creds
Default Principal: chet@cisco.com
Valid Starting Expires Service Principal
18-Dec-1995 16:21:07 19-Dec-1995 00:22:24 krbtgt/CISCO.COM@CISCO.COM
Router# clear kerberos creds
Router# show kerberos creds
No Kerberos credentials.
Related Commands DescriptionCommand
Displays the contents of your credentials cache.show kerberos creds
Cisco IOS Security Command Reference: Commands A to C
27
clear ip access-list counters through crl-cache none
clear kerberos creds
clear ldap server
To clear the TCP connection with the Lightweight Directory Access Protocol (LDAP) server, use the clear
ldap server command in privileged EXEC mode.
clear ldap server server-name [statistics]
Syntax Description LDAP server name.
server-name
(Optional) Clears the statistical information.statistics
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.15.1(1)T
Usage Guidelines Statistics details are not cleared when the server is cleared. To clear the statistics information, use the statistics
keyword.
Examples The following example shows how to clear the statistical information:
Router# clear ldap server server1 statistics
Related Commands DescriptionCommand
Defines an LDAP server and enters LDAP server
configuration mode.
ldap server
Cisco IOS Security Command Reference: Commands A to C
28
clear ip access-list counters through crl-cache none
clear ldap server
clear logging ip access-list cache
To clear all the entries from the Optimized ACL Logging (OAL) cache and send them to the syslog, use the
clear logging ip access-list cache command in privileged EXEC mode.
clear logging ip access-list cache
Syntax Description This command has no arguments or keywords.
Command Default This command has no default settings.
Command Modes Privileged EXEC
Command History ModificationRelease
Support for this command was introduced on the Supervisor Engine
720.
12.2(17d)SXB
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
Usage Guidelines This command is supported on Cisco 7600 series routers that are configured with a Supervisor Engine 720
only.
Examples This example shows how to clear all the entries from the OAL cache and send them to the syslog:
Router#
clear logging ip access-list cache
Related Commands DescriptionCommand
Configures the OAL parameters globally.logging ip access-list cache (global configuration
)
Enables an OAL-logging cache on an interface that
is based on direction.
logging ip access-list cache (interface configuration
)
Displays information about the logging IP access list.show logging ip access-list
Cisco IOS Security Command Reference: Commands A to C
29
clear ip access-list counters through crl-cache none
clear logging ip access-list cache
clear parameter-map type protocol-info
To clear the Domain Name System (DNS) cache for name resolution of servers within a parameter map, use
the clear parameter-map type protocol-info command in privileged EXEC mode.
clear parameter-map type protocol-info dns-cache dns-name [ip-address ip-address]
Syntax Description Cache of the specified DNS server will be cleared.
dns-cache dns-name
(Optional) Specified IP address is removed from the
cache of the DNS server.
If an IP address is not specified, all IP addresses from
the specified DNS server are cleared from the cache.
ip-address ip-address
Command Default None
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.4(9)T
Examples The following example shows how to clear the cache of the DNS server “sdsc.msg.yahoo.com:
Router#
clear parameter-map type protocol-info dns-cache sdsc.msg.yahoo.com
Related Commands DescriptionCommand
Creates or modifies a parameter map.parameter-map type
Cisco IOS Security Command Reference: Commands A to C
30
clear ip access-list counters through crl-cache none
clear parameter-map type protocol-info
clear policy-firewall
To reset the information collected by the firewall, use the clear policy-firewall command in user EXEC or
privileged EXEC mode.
clear policy-firewall {session [session address|class-map class-map-name|policy-map policy-map-name]|
stats [drop-counters ]| summary-log| zone-pair}
Syntax Description Clears the session.
session session address
Clears the class map.
class-map class-map-name
Clears the policy map.
policy-map policy-map-name
Clears the statistics and the drop-counters.
stats [drop-counters]
Clears the summary log.summary-log
Clears the zone-pair.zone-pair
Command Default The firewall information is not cleared.
Command Modes EXEC (>) Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.15.1(1)T
Usage Guidelines Use this command to clear the information that is collected by the firewall. The cleared counters include
drop-counters, summary-log buffers, sessions and zone pairs.
Examples The following example shows how to clear the zone pair:
Router(mode-prompt
)# clear policy-firewall zone-pair
Cisco IOS Security Command Reference: Commands A to C
31
clear ip access-list counters through crl-cache none
clear policy-firewall
Related Commands DescriptionCommand
Displays the entire configuration of the firewall in
the router.
show policy-firewall config
Displays the details of the firewall sessions.show policy-firewall sessions
Displays the statistics of all firewall activities in the
router.
show policy-firewall stats
Displays the summary log of the firewall.show policy-firewall summary-log
Cisco IOS Security Command Reference: Commands A to C
32
clear ip access-list counters through crl-cache none
clear policy-firewall
clear policy-firewall stats global
To reset the global statistics collected by the firewall, use the clear policy-firewall stats global command in
user EXEC or privileged EXEC mode.
clear policy-firewall stats global
Syntax Description This command has no arguments or keywords.
Command Default The firewall global statistics are not cleared.
Command Modes User EXEC (>)
Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 3.4S
Usage Guidelines Use this command to clear the statistics collected by the firewall.
Examples The following example shows how to clear the global firewall statistics:
Router# clear policy-firewall stats global
Related Commands DescriptionCommand
Displays global firewall statistics.show policy-firewall stats global
Cisco IOS Security Command Reference: Commands A to C
33
clear ip access-list counters through crl-cache none
clear policy-firewall stats global
clear policy-firewall stats vrf
To clear the policy firewall statistics at a VPN Routing and Forwarding (VRF) level, use the clear
policy-firewall stats vrf command in privileged EXEC mode.
clear policy-firewall stats vrf vrf-name
Syntax Description Name of the VRF.
vrf-name
Command Default This command has no default settings.
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 3.3S
Examples The following example shows how to clear the configured policy firewall VRF statistics:
Router# clear policy-firewall stats vrf vrf1
Related Commands DescriptionCommand
Displays VRF-level policy firewall statistics.show policy-firewall stats vrf
Cisco IOS Security Command Reference: Commands A to C
34
clear ip access-list counters through crl-cache none
clear policy-firewall stats vrf
clear policy-firewall stats vrf global
To clear the global VPN Routing and Forwarding (VRF) policy firewall statistics, use the clear policy-firewall
stats vrf global command in privileged EXEC mode.
clear policy-firewall stats vrf global
Syntax Description This command has no arguments or keywords.
Command Default This command has no default settings.
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 3.3S
Examples The following example shows how to clear the global policy firewall statistics:
Router# clear policy-firewall stats vrf global
Related Commands DescriptionCommand
Displays information about the global VRF firewall
policies.
show policy-firewall stats vrf global
Cisco IOS Security Command Reference: Commands A to C
35
clear ip access-list counters through crl-cache none
clear policy-firewall stats vrf global
clear policy-firewall stats zone
To clear the policy firewall statistics at a zone level, use the clear policy-firewall stats zone command in
privileged EXEC mode.
clear policy-firewall stats zone zone-name
Syntax Description Name of the zone.
zone-name
Command Default This command has no default settings.
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 3.3S
Examples The following example shows how to clear the configured policy firewall zone statistics:
Router# clear policy-firewall stats zone zone1
Related Commands DescriptionCommand
Displays policy firewall statistics at a zone level.show policy-firewall stats zone
Cisco IOS Security Command Reference: Commands A to C
36
clear ip access-list counters through crl-cache none
clear policy-firewall stats zone
clear port-security
To delete configured secure MAC addresses and sticky MAC addresses from the MAC address table in the
Priveleged EXEC configuration command mode, use the clear port-securitycommand.
clear port-security dynamic [address mac-addr|interface interface-id] [vlan vlan-id]
Syntax Description (Optional) Deletes the specified secure MAC address
or sticky MAC address.
address mac-addr
(Optional) Deletes all secure MAC addresses and
sticky MAC addresses on the specified physical port
or port channel.
interface interface-id
(Optional) Deletes the specified secure MAC address
or sticky MAC address from the specified VLAN.
vlan vlan-id
Command Default This command has no default settings.
Command Modes Privileged EXEC
Command History ModificationRelease
Support for this command was introduced on the Supervisor Engine 720.12.2(14)SX
Support for this command on the Supervisor Engine 2 was extended to
Release 12.2(17d)SXB.
12.2(17d)SXB
The output of this command was changed to support sticky MAC addresses
on the Supervisor Engine 720 only.
12.2(18)SXE
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
Usage Guidelines This command is supported on negotiated trunks only.
If you enter the clear port-securitycommand without adding any keywords or arguments, the switch removes
all the secure MAC addresses and sticky MAC addresses from the MAC address table.
If you enter the clear port-security dynamic interfaceinterface-id command, all the secure MAC addresses
and sticky MAC addresses on an interface are removed from the MAC address table.
You can verify that the information was deleted by entering the show port-security command.
Cisco IOS Security Command Reference: Commands A to C
37
clear ip access-list counters through crl-cache none
clear port-security
Examples This example shows how to remove a specific secure address from the MAC address table:
Router# clear port-security dynamic address 0008.0070.0007
Router#
This example shows how to remove all the secure MAC addresses and sticky MAC addresses learned on a
specific interface:
Router# clear port-security dynamic interface gigabitethernet0/1
Router#
Related Commands DescriptionCommand
Displays information about the port-security setting.show port-security
Adds a MAC address to the list of secure MAC
addresses.
switchport port-security mac-address
Cisco IOS Security Command Reference: Commands A to C
38
clear ip access-list counters through crl-cache none
clear port-security
clear radius
To clear the RADIUS server information, use the clear radiuscommand in privileged EXEC mode.
clear radius {sg-stats| statistics}
Syntax Description Clears the RADIUS server group statistics.sg-stats
Clears the RADIUS statistics.statistics
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced in a release earlier than Cisco IOS Release
15.0(1)M.
15.0(1)M
This command was integrated into a release earlier than Cisco IOS Release
12.2(33)SRC.
12.2(33)SRC
This command was integrated into a release earlier than Cisco IOS Release
12.2(33)SXI.
12.2(33)SXI
This command was integrated into Cisco IOS XE Release 2.1 and
implemented on the Cisco ASR 1000 Series Aggregation Services Routers.
Cisco IOS XE Release 2.1
Examples The following example shows how to clear the RADIUS statistics information:
Router# clear radius statistics
Related Commands DescriptionCommand
Configures a RADIUS server host.radius-server host
Cisco IOS Security Command Reference: Commands A to C
39
clear ip access-list counters through crl-cache none
clear radius
clear radius local-server
To clear the display on the local server or to unblock a locked username, use the clear radius
local-servercommand in privileged EXEC mode.
clear radius local-server {statistics|user username}
Syntax Description Clears the display of statistical information.statistics
Unblocks the locked username specified.user
Locked username.
username
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced on the Cisco Aironet Access Point 1100 and the
Cisco Aironet Access Point 1200.
12.2(11)JA
This command was integrated into Cisco IOS Release 12.3(11)T and implemented
on the following platforms: Cisco 2600XM, Cisco 2691, Cisco 2811, Cisco 2821,
Cisco 2851, Cisco 3700, and Cisco 3800 series routers.
12.3(11)T
Examples The following example shows how to unblock the locked username “smith”:
Router# clear radius local-server user smith
Related Commands DescriptionCommand
Configures the parameters for locking out members
of a group to help protect against unauthorized
attacks.
block count
Displays the debug information for the local server.debug radius local-server
Enters user group configuration mode and configures
shared setting for a user group.
group
Adds an access point or router to the list of devices
that use the local authentication server.
nas
Cisco IOS Security Command Reference: Commands A to C
40
clear ip access-list counters through crl-cache none
clear radius local-server
DescriptionCommand
Specifies the remote RADIUS server host.radius-server host
Enables the access point or router to be a local
authentication server and enters into configuration
mode for the authenticator.
radius-server local
Specifies the time after which access points or
wireless-aware routers must reauthenticate the
members of a group.
reauthentication time
Displays statistics for a local network access server.show radius local-server statistics
Specifies up to 20 SSIDs to be used by a user group.ssid
Cisco IOS Security Command Reference: Commands A to C
41
clear ip access-list counters through crl-cache none
clear radius local-server
clear webvpn nbns
To clear the NetBIOS name service (NBNS) cache on a SSL VPN gateway, use the clear webvpn nbns
command in privileged EXEC mode.
clear webvpn nbns [context {name| all}]
Syntax Description (Optional) Clears NBNS statistics for a specific
context or all contexts.
context
Clears NBNS statistics for a specific context.
name
Clears NBNS statistics for all contexts.all
Command Default No default behavior or values.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.4(6)T
Usage Guidelines Entering this command without any keywords or arguments clears all NBNS counters on the network device.
Examples The following example clears all NBNS counters:
Router# clear webvpn nbns
Related Commands DescriptionCommand
Clears remote users sessions on a SSL VPN gateway.clear webvpn session
Clears application and access counters on a SSL VPN
gateway.
clear webvpn stats
Cisco IOS Security Command Reference: Commands A to C
42
clear ip access-list counters through crl-cache none
clear webvpn nbns
clear webvpn session
To clear SSL VPN remote user sessions, use the clear webvpn session command in privileged EXEC mode.
clear webvpn session [user name]context {name| all}
Syntax Description (Optional) Clears session information for a specific
user.
user name
Clears session information for a specific context or
all contexts.
context name |all
Command Default None
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.4(6)T
Usage Guidelines This command is used to clear the session for either the specified remote user or all remote users in the specified
context.
Examples The following example clears all session information:
Router# clear webvpn session context all
Related Commands DescriptionCommand
Clears the NBNS cache on a SSL VPN gateway.clear webvpn nbns
Clears application and access counters on a SSL VPN
gateway.
clear webvpn stats
Cisco IOS Security Command Reference: Commands A to C
43
clear ip access-list counters through crl-cache none
clear webvpn session
clear webvpn stats
To clear (or reset) SSL VPN application and access counters, use the clear webvpn stats command in privileged
EXEC mode.
clear webvpn stats [[cifs| citrix| mangle| port-forward| sso| tunnel] [context {name| all}]]
Syntax Description (Optional) Clears Windows file share (CIFS)
statistics.
cifs
(Optional) Clears Citrix application statistics.citrix
(Optional) Clears URL mangling statistics.mangle
(Optional) Clears port forwarding statistics.port-forward
(Optional) Clears statistics for Single SignOn (SSO)
activities.
sso
(Optional) Clears Cisco AnyConnect VPN Client
tunnel statistics.
tunnel
(Optional) Clears information for either a specific
context or all contexts.
context name |all
Command Default If no keywords are entered, all SSL VPN application and access counters are cleared.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.4(6)T
The sso keyword was added.12.4(11)T
Usage Guidelines This command is used to clear counters for Windows file shares, Citrix applications, URL mangling, application
port forwarding, SSO, and Cisco AnyConnect VPN Client tunnels. The counters are cleared for either the
specified context or all contexts on the SSL VPN gateway.
Cisco IOS Security Command Reference: Commands A to C
44
clear ip access-list counters through crl-cache none
clear webvpn stats
Examples The following example clears all statistics counters for all SSL VPN processes:
Router# clear webvpn stats
The following example clears statistics for SSO activities:
Router# clear webvpn stats sso
Related Commands DescriptionCommand
Clears the NBNS cache on a SSL VPN gateway.clear webvpn nbns
Clears remote users sessions on a SSL VPN gateway.clear webvpn session
Cisco IOS Security Command Reference: Commands A to C
45
clear ip access-list counters through crl-cache none
clear webvpn stats
clear xsm
To clear XML Subscription Manager (XSM) client sessions, use the clear xsm command in privileged EXEC
mode.
clear xsm [session number]
Syntax Description (Optional) Specifies an XSM client session to clear.session
(Optional) ID number of the specific XSM client
session to be cleared.
number
Command Default No XSM client sessions are cleared.
Command Modes Privileged EXEC
Command History ModificationRelease
This command was introduced.12.1(6)E
This command was integrated into Cisco IOS Release 12.2(9)YE.12.2(9)YE
This command was integrated into Cisco IOS Release 12.2(9)YO1.12.2(9)YO1
This command was integrated into Cisco IOS Release 12.2(13)T.12.2(13)T
This command was integrated into Cisco IOS Release 12.2(14)S.12.2(14)S
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set,
platform, and platform hardware.
12.2SX
Usage Guidelines This command disconnects all active client sessions (such as with a VPN Device Manager [VDM]) on the
XSM server, unless you state a specific session number. This command allows troubleshooting of the XSM
server and its active clients by allowing individual clients to be disconnected. Use the show xsm status
command to obtain specific session numbers.
When the optional session number keyword and argument are not used, the clear xsm command clears all
XSM client sessions.
Cisco IOS Security Command Reference: Commands A to C
46
clear ip access-list counters through crl-cache none
clear xsm
Examples The following example shows how to clear all XSM client sessions:
Router# clear xsm
The following example shows how to clear XSM client session 10:
Router# clear xsm session 10
Related Commands DescriptionCommand
Displays information and status about clients
subscribed to the XSM server.
show xsm status
Enables XSM client access to the router.xsm
Cisco IOS Security Command Reference: Commands A to C
47
clear ip access-list counters through crl-cache none
clear xsm
clear zone-pair
To clear the policy map counters, inspect sessions, or the URL filter cache on a zone-pair, use the clear
zone-pair command in privileged EXEC mode.
clear zone-pair [zone-pair-name ] {counter|inspect session|urlfilter cache}
Syntax Description (Optional) Name of the zone-pair on which counters,
inspect sessions, or the uRL filter cache are cleared.
zone-pair-name
Clears the policy-map counters. Resets the statistics
of the inspect type policy map on the specified
zone-pair.
counter
Deletes the inspect sessions on the specified
zone-pair.
inspect session
Clears the URL filter cache on the specified zone-pair.urlfilter cache
Command Default Disabled (it is not necessary to enter this command).
Command Modes Privileged EXEC (#)
Command History ModificationRelease
This command was introduced.12.4(6)T
This command was implemented on the following platforms: Cisco 881
and Cisco 888.
12.4(15)XZ
Usage Guidelines If you do not specify a zone-pair name, the policy map counters, sessions, or the URL filter cache are cleared
for all the configured zone-pairs.
Examples The following example deletes the inspect sessions on the zp zone-pair:
Router# clear zone-pair zp inspect session
The following example clears the URL filter cache on the zp zone-pair.
Router# clear zone-pair zp urlfilter cache
Cisco IOS Security Command Reference: Commands A to C
48
clear ip access-list counters through crl-cache none
clear zone-pair
clid
To preauthenticate calls on the basis of the Calling Line IDentification (CLID) number, use the clid command
in AAA preauthentication configuration mode. To remove the clid command from your configuration, use
the no form of this command.
clid [if-avail| required][accept-stop] [password password]
no clid [if-avail| required][accept-stop] [password password]
Syntax Description (Optional) Implies that if the switch provides the data,
RADIUS must be reachable and must accept the string
in order for preauthentication to pass. If the switch
does not provide the data, preauthentication passes.
if-avail
(Optional) Implies that the switch must provide the
associated data, that RADIUS must be reachable, and
that RADIUS must accept the string in order for
preauthentication to pass. If these three conditions
are not met, preauthentication fails.
required
(Optional) Prevents subsequent preauthentication
elements such as ctype or dnis from being tried once
preauthentication has succeeded for a call element.
accept-stop
(Optional) Defines the password for the
preauthentication element. The default password
string is cisco.
password password
Command Default The if-avail and required keywords are mutually exclusive. If the if-avail keyword is not configured, the
preauthentication setting defaults to required.
Command Modes AAA preauthentication configuration
Command History ModificationRelease
This command was introduced.12.1(2)T
Usage Guidelines You may configure more than one of the authentication, authorization and accounting (AAA) preauthentication
commands (clid,ctype,dnis) to set conditions for preauthentication. The sequence of the command
configuration decides the sequence of the preauthentication conditions. For example, if you configure dnis,
Cisco IOS Security Command Reference: Commands A to C
49
clear ip access-list counters through crl-cache none
clid
then clid, then ctype, in this order, then this is the order of the conditions considered in the preauthentication
process.
In addition to using the preauthentication commands to configure preauthentication on the Cisco router, you
must set up the preauthentication profiles on the RADIUS server.
Examples The following example specifies that incoming calls be preauthenticated on the basis of the CLID number:
aaa preauth
group radius
clid required
Related Commands DescriptionCommand
Preauthenticates calls on the basis of the call type.ctype
Preauthenticates calls on the basis of the DNIS
number.
dnis (RADIUS)
Specifies a group of DNIS numbers that will be
bypassed for preauthentication.
dnis bypass (AAA preauthentication configuration)
Specifies the AAA RADIUS server group to use for
preauthentication.
group (RADIUS)
Cisco IOS Security Command Reference: Commands A to C
50
clear ip access-list counters through crl-cache none
clid
client
To specify a RADIUS client from which a device can accept Change of Authorization (CoA) and disconnect
requests, use the client command in dynamic authorization local server configuration mode. To remove this
specification, use the no form of this command.
client {hostname |ip-address} [server-key {0string |6string |7string |string} | vrf vrf-id]
no client {hostname |ip-address} [server-key {0string |6string |7string |string} | vrf vrf-id]
Syntax Description Hostname of the RADIUS client.
hostname
IP address of the RADIUS client.
ip-address
(Optional) Configures the RADIUS key to be shared
between a device and a RADIUS client.
server-key
Specifies that an unencrypted key follows.
•string—The unencrypted (clear text) shared key.
0string
Specifies that an encrypted key follows.
•string—The advanced encryption scheme [AES]
encrypted key.
6string
Specifies that a hidden key follows.
•string—The hidden shared key.
7string
The unencrypted (clear text) shared key.
string
(Optional) Virtual routing and forwarding (VRF) ID
of the client.
vrf vrf-id
Command Default CoA and disconnect requests are dropped.
Command Modes Dynamic authorization local server configuration (config-locsvr-da-radius)
Command History ModificationRelease
This command was introduced.12.2(28)SB
Cisco IOS Security Command Reference: Commands A to C
51
clear ip access-list counters through crl-cache none
client
ModificationRelease
This command was integrated into Cisco IOS XE Release 2.6.Cisco IOS XE Release 2.6
This command was integrated into Cisco IOS Release 15.4(1)T. The
6keyword was added.
15.4(1)T
Usage Guidelines A device (such as a router) can be configured to allow an external policy server to dynamically send updates
to the router. This functionality is facilitated by the CoA RADIUS extension. CoA introduced peer-to-peer
capability to RADIUS, enabling a router and external policy server each to act as a RADIUS client and server.
Use the client command to specify the RADIUS clients for which the router can act as server.
Examples The following example shows how to configure the router to accept requests from the RADIUS client at IP
address 10.0.0.1:
aaa server radius dynamic-author
client 10.0.0.1 key cisco
Related Commands DescriptionCommand
Configures an ISG as a AAA server to facilitate
interaction with an external policy server.
aaa server radius dynamic-author
Cisco IOS Security Command Reference: Commands A to C
52
clear ip access-list counters through crl-cache none
client
client authentication list
To configure Internet Key Exchange (IKE) extended authentication (Xauth) in an Internet Security Association
and Key Management Protocol (ISAKMP) profile, use the client authentication listcommand in ISAKMP
profile configuration mode. To restore the default behavior, which is that Xauth is not enabled, use the no
form of this command.
client authentication list list-name
no client authentication list list-name
Syntax Description Character string used to name the list of authentication
methods activated when a user logs in. The list name
must match the list name that was defined during the
authentication, authorization, and accounting (AAA)
configuration.
list-name
Command Default No default behaviors or values
Command Modes ISAKMP profile configuration (config-isakmp-profile)
Command History ModificationRelease
This command was introduced.12.2(15)T
This command was integrated into Cisco IOS Release 12.2(18)SXD.12.2(18)SXD
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
Xauth no longer has to be disabled globally for it to be enabled on a
profile basis.
12.4(11.5)
This command was integrated into Cisco IOS XE Release 2.6.Cisco IOS XE Release 2.6
Usage Guidelines
Security threats, as well as the cryptographic technologies to help protect against them, are constantly
changing. For more information about the latest Cisco cryptographic recommendations, see the Next
Generation Encryption (NGE) white paper.
Note
Before configuring Xauth, you must set up an authentication list using AAA commands.
Cisco IOS Security Command Reference: Commands A to C
53
clear ip access-list counters through crl-cache none
client authentication list
Xauth can be enabled on a profile basis if it has been disabled globally.
Effective with Cisco IOS Release 12.4(11.5), Xauth on either a server or client does not need to be disabled
globally to enable it on profile basis.
Examples The following example shows that user authentication is configured. User authentication is a list of
authentication methods called “xauthlist”in an ISAKMP profile called “vpnprofile.”
crypto isakmp profile vpnprofile
client authentication list xauthlist
The following example shows that Xauth has been disabled globally and enabled for the profile “nocerts”:
no crypto xauth FastEthernet0/0
!
crypto isakmp policy 1
encr aes
group 14
!
crypto isakmp policy 10
encr aes
authentication pre-share
group 14
crypto isakmp client configuration group HRZ
crypto isakmp client configuration group vpngroup
key cisco123
pool vpnpool
crypto isakmp profile cert_sig
match identity group HRZ
isakmp authorization list isakmpauth
client configuration address respond
client configuration group HRZ
crypto isakmp profile nocerts
match identity group vpngroup
client authentication list vpn-login
isakmp authorization list isakmpauth
client configuration address respond
Related Commands DescriptionCommand
Sets AAA authentication at login.aaa authentication login
Cisco IOS Security Command Reference: Commands A to C
54
clear ip access-list counters through crl-cache none
client authentication list
client configuration address
To configure Internet Key Exchange (IKE) configuration mode in the Internet Security Association and Key
Management Protocol (ISAKMP) profile, use the client configuration addresscommand in ISAKMP profile
configuration mode. To disable IKE configuraton mode, use the no form of this command.
client configuration address {initiate| respond}
no client configuration address {initiate| respond}
Syntax Description Router will attempt to set IP addresses for each peer.initiate
Router will accept requests for IP addresses from any
requesting peer.
respond
Command Default IKE configuration is not enabled.
Command Modes ISAKMP profile configuration (config-isa-prof)
Command History ModificationRelease
This command was introduced.12.2(15)T
This command was integrated into Cisco IOS Release 12.2(18)SXD.12.2(18)SXD
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command was integrated into Cisco IOS XE Release 2.6.Cisco IOS XE Release 2.6
Usage Guidelines Before you can use this command, you must enter the crypto isakmp profile command.
Examples The following example shows that IKE mode is configured to either initiate or respond in an ISAKMP profile
called “vpnprofile”:
crypto isakmp profile vpnprofile
client configuration address initiate
client configuration address respond
Cisco IOS Security Command Reference: Commands A to C
55
clear ip access-list counters through crl-cache none
client configuration address
Related Commands DescriptionCommand
Defines an ISAKMP profile.crypto isakmp profile
Cisco IOS Security Command Reference: Commands A to C
56
clear ip access-list counters through crl-cache none
client configuration address
client configuration group
To associate a group with the peer that has been assigned an Internet Security Association Key Management
Protocol (ISAKMP) profile, use the client configuration group command in crypto ISAKMP profile
configuration mode. To disable this option, use the no form of this command.
client configuration group group-name
no client configuration group group-name
Syntax Description Name of the group to be associated with the peer.
group-name
Command Default No default behavior or values
Command Modes Crypto ISAKMP profile configuration (conf-isa-prof)
Command History ModificationRelease
This command was introduced.12.3(8)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command was integrated into Cisco IOS Release 12.2(33)SXH.12.2(33)SXH
Usage Guidelines The client configuration group command is used after the crypto map has been configured and the ISAKMP
profiles have been assigned to them.
Examples The following example shows that the group “some_group”is to be associated with the peer:
crypto isakmp profile id_profile
ca trust-point 2315
match identity host domain cisco.com
client configuration group some_group
Related Commands DescriptionCommand
Assigns an ISAKMP profile to a peer on the basis of
the contents of arbitrary fields in the certificate.
match certificate (ISAKMP)
Cisco IOS Security Command Reference: Commands A to C
57
clear ip access-list counters through crl-cache none
client configuration group
client inside
To specify the inside interface for the FlexVPN client, use the client inside command in IKEv2 FlexVPN
client profile configuration mode. To disable the inside interface, use the no form of this command.
client inside interface-type number
no client inside interface type number
Syntax Description Interface type and number.
interface-type number
Command Default The inside interface is not specified.
Command Modes IKEv2 FlexVPN client profile configuration (config-ikev2-flexvpn)
Command History ModificationRelease
This command was introduced.15.2(1)T
This command was integrated into Cisco IOS XE Release 3.7S.Cisco IOS XE Release 3.7S
Usage Guidelines Before you enable this command, you must configure the crypto ikev2 client flexvpn command.
You can specify more than one inside interface in a FlexVPN client profile. The inside interfaces can be shared
across FlexVPN client profiles.
Enabling this command is optional. Any changes to this command terminates the active session.Note
Examples The following example shows how to specify the inside interface:
Router(config)# crypto ikev2 client flexvpn client1
Router(config-ikev2-flexvpn)# peer 1 10.0.0.1
Router(config-ikev2-flexvpn)# client inside Ethernet 1
Related Commands DescriptionCommand
Defines an IKEv2 FlexVPN client profile.crypto ikev2 client flexvpn
Cisco IOS Security Command Reference: Commands A to C
58
clear ip access-list counters through crl-cache none
client inside
client pki authorization list
To specify the authorization list of AAA servers that will be used to obtain per-user AAA attributes on the
basis of the username that is constructed from the certificate, use the client pki authorization list command
in crypto ISAKMP profile configuration mode. To disable the list name, use the no form of this command.
client pki authorization list listname
no client pki authorization list listname
Syntax Description Definition of the argument needed, including
syntax-level defaults, if any.
listname
Command Default User attributes are not pushed to the remote device.
Command Modes Crypto ISAKMP profile configuration (config-isakmp-profile)
Command History ModificationRelease
This command was introduced.12.4(4)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS 12.2SX family of releases.
Support in a specific 12.2SX release is dependent on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines This command is used inside the crypto Internet Security Association and Key Management Protocol (ISAKMP)
profile.
Examples The following example shows that user attributes are to be obtained from the AAA server (list name “usrgrp”)
and pushed to the remote device:
crypto isakmp profile ISA-PROF
match certificate CERT-MAP
isakmp authorization list usrgrp
client pki authorization list usrgrp
client configuration address respond
client configuration group pkiuser
virtual-template 2
Cisco IOS Security Command Reference: Commands A to C
59
clear ip access-list counters through crl-cache none
client pki authorization list
Related Commands DescriptionCommand
Defines an ISAKMP profile and audits IPsec user
sessions.
crypto isakmp profile
Cisco IOS Security Command Reference: Commands A to C
60
clear ip access-list counters through crl-cache none
client pki authorization list
client recovery-check interval
To set the interval of time for the client group member (GM) to monitor for control-plane errors, use the client
recovery-check interval command in GDOI group configuration mode. To remove the control-plane error
monitoring, use the no form of this command.
client recovery-check interval interval
no client recovery-check interval interval
Syntax Description Specifies the waiting period in seconds between
consecutive recovery registrations. The range is from
100 to 1000 seconds.
interval
Command Default Control-plane error monitoring is disabled.
Command Modes GDOI group configuration (config-gdoi-group)
Command History ModificationRelease
This command was introduced.15.3(3)M
Usage Guidelines Use the client recovery-check interval command to ensure GMs reactively try to recover from data plane
errors, such as invalid stateful packet inspection (SPI) and Time-Based Anti-Replay (TBAR) errors, by
registering to the configured key servers (KSs) to obtain the latest policies.
Examples The following example shows how to enable the GM to monitor for control-plane errors every 300 seconds:
Device# configure terminal
Device(config)# crypto gdoi group GETVPN
Device(config-gdoi-group)# client recovery-check interval 300
Related Commands DescriptionCommand
Creates a GDOI group and enters GDOI group
configuration mode.
crypto gdoi group
Cisco IOS Security Command Reference: Commands A to C
61
clear ip access-list counters through crl-cache none
client recovery-check interval
client connect
To assign a tunnel interface to the FlexVPN client, use the client connect command in IKEv2 FlexVPN client
profile configuration mode. To remove the tunnel interface, use the no form of this command.
client connect tunnel number
no client connect tunnel number
Syntax Description Tunnel interface.tunnel
Tunnel interface number.
number
Command Default A tunnel interface is not assigned to the FlexVPN client.
Command Modes IKEv2 FlexVPN client profile configuration (config-ikev2-flexvpn)
Command History ModificationRelease
This command was introduced.15.2(1)T
This command was integrated into Cisco IOS XE Release 3.7S.Cisco IOS XE Release 3.7S
Usage Guidelines Before you enable this command, you must configure the crypto ikev2 client flexvpn and the interface
command with the tunnel keyword.
You can configure only one tunnel interface for a FlexVPN client profile.
Any changes to this command terminates the active session.Note
Examples The following example shows how to assign the tunnel interface 1 to the FlexVPN client profile "client1":
Router(config)# crypto ikev2 client flexvpn client1
Router(config-ikev2-flexvpn)# client inside Ethernet 1
Router(config-ikev2-flexvpn)# client connect tunnel 1
Related Commands DescriptionCommand
Defines an IKEv2 FlexVPN client profile.crypto ikev2 client flexvpn
Cisco IOS Security Command Reference: Commands A to C
62
clear ip access-list counters through crl-cache none
client connect
DescriptionCommand
Specifies an interface.interface
Cisco IOS Security Command Reference: Commands A to C
63
clear ip access-list counters through crl-cache none
client connect
client rekey encryption
To set the client acceptable rekey ciphers for the key-encryption-key (KEK), use the client rekey encryption
command in GDOI group configuration mode. To remove the client acceptable rekey ciphers, use the no form
of this command.
client rekey encryption cipher [... [ cipher ]]
no client rekey encryption
Syntax Description Any of the following ciphers:
•3des-cbc —Specifies triple Data Encryption
Standard (3DES) in Cipher-block chaining
(CBC) mode (no longer recommended).
•aes 128 —Specifies 128-bit Advanced
Encryption Standard (AES).
•aes 192 —Specifies 192-bit AES.
•aes 256 —Specifies 256-bit AES.
•des-cbc —Specifies DES in CBC mode (no
longer recommended).
cipher
Command Default Any cipher assigned by the key server is accepted.
Command Modes GDOI group configuration (config-gdoi-group)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 2.4.1
This command was integrated into Cisco IOS Release
15.1(1)T.
Cisco IOS Release 15.1(1)T
Usage Guidelines
Security threats, as well as the cryptographic technologies to help protect against them, are constantly
changing. For more information about the latest Cisco cryptographic recommendations, see the Next
Generation Encryption (NGE) white paper.
Note
Cisco IOS Security Command Reference: Commands A to C
64
clear ip access-list counters through crl-cache none
client rekey encryption
Use the client rekey encryption command to specify the acceptable ciphers for KEK. Multiple ciphers can
be specified. If a cipher is not set using this command, the cipher assigned by the key server is accepted.
Examples The following example shows how to set the acceptable ciphers for KEK:
Router# configure terminal
Router(config)# crypto gdoi group GETVPN
Router(config-gdoi-group)# identity number 1111
Router(config-gdoi-group)# server address ipv4 192.10.2.10
Router(config-gdoi-group)# client rekey encryption aes 128 aes 192 aes 256
Related Commands DescriptionCommand
Identifies a GDOI group and enters GDOI group
configuration mode.
crypto gdoi group
Cisco IOS Security Command Reference: Commands A to C
65
clear ip access-list counters through crl-cache none
client rekey encryption
client rekey hash
To set acceptable hash algorithms for rekey message signing, use the client rekey hash command in GDOI
group configuration mode. To remove acceptable hash algorithms, use the no form of this command.
client rekey hash hash1 [...[hash4]]
no client rekey hash hash1 [...[hash4]]
Syntax Description Hash for rekey message signing. You can use any
combination of the following values: sha,sha256,
sha384, and sha512.
hash
Command Default Any hash selected by the key server (KS) is accepted.
Command Modes GDOI group configuration (config-gdoi-group)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 2.4.1
This command was integrated into Cisco IOS Release 15.1(1)T.15.1(1)T
This command was modified. The sha256,sha384, and sha512
keywords were added.
15.2(4)M
Usage Guidelines Use the client rekey hash command to select the acceptable hash for the rekey message signing. If a hash is
not set using this command, the hash selected by the KS is accepted.
Suite B requires SHA-256, SHA-384, or SHA-512. Suite B is a set of cryptographic algorithms that includes
Galois Counter Mode Advanced Encryption Standard (GCM-AES) as well as algorithms for hashing, digital
signatures, and key exchange.
Examples The following example shows how to set the acceptable hash for rekey message signing:
Device# configure terminal
Device(config)# crypto gdoi group GETVPN
Device(config-gdoi-group)# identity number 1111
Device(config-gdoi-group)# server address ipv4 192.10.2.10
Device(config-gdoi-group)# client rekey hash sha512
Cisco IOS Security Command Reference: Commands A to C
66
clear ip access-list counters through crl-cache none
client rekey hash
Related Commands DescriptionCommand
Identifies a GDOI group and enters GDOI group
configuration mode.
crypto gdoi group
Cisco IOS Security Command Reference: Commands A to C
67
clear ip access-list counters through crl-cache none
client rekey hash
client transform-sets
To specify up to 6 acceptable transform-set tags used by the traffic-encryption-key (TEK) for data encryption
or authentication, use the client transform-setscommand in GDOI group configuration mode. To remove
the acceptable transform-set tags, use the no form of this command.
client transform-sets transform-set-name1 [... [ transform-set-name6 ]]
no client transform-sets
Syntax Description Transform-tags used by the TEK for data encryption
or authentication.
transform-set-name
Command Default The transform-set selected by the key server is accepted.
Command Modes GDOI group configuration (config-gdoi-group)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 2.4.1
This command was integrated into Cisco IOS Release
15.1(1)T.
Cisco IOS Release 15.1(1)T
Usage Guidelines Use the client transform-sets command to specify up to 6 transform-set tags used by the TEK for data
encryption or authentication. If this command is not issued, the transform-set selected by the key server is
accepted. The security protocol configured in the transform set must be Encapsulating Security Payload (ESP),
which is the only protocol supported by GETVPN in Cisco IOS XE Release 2.4.1.
Examples The following example shows how to set the transform-set tags used by TEK for data encryption or
authentication:
Router# configure terminal
Router(config)# crypto ipsec transform-set g1 esp-aes 192 esp-sha-hmac
Router(cfg-crypto-trans)# exit
Router(config)# crypto gdoi group GETVPN
Router(config-gdoi-group)# client transform-sets g1
Cisco IOS Security Command Reference: Commands A to C
68
clear ip access-list counters through crl-cache none
client transform-sets
Related Commands DescriptionCommand
Identifies a GDOI group and enters GDOI group
configuration mode.
crypto gdoi group
Defines a transform set--an acceptable combination
of security protocols and algorithms.
crypto ipsec transform-set
Cisco IOS Security Command Reference: Commands A to C
69
clear ip access-list counters through crl-cache none
client transform-sets
commands (view)
To add commands or an interface to a command-line interface (CLI) view, use the commandscommand in
view configuration mode. To delete a command or an interface from a CLI view, use the no form of this
command.
Syntax for Adding and Deleting Commands to a View
commands parser-mode {include| include-exclusive| exclude}[all] [command ]
no commands parser-mode {include| include-exclusive| exclude}[all] [command ]
Syntax for Adding and Deleting Interfaces to a View
commands parser-mode {include| include-exclusive}[all] [interface name] [ command ]
no commands parser-mode {include| include-exclusive}[all] [interface name] [ command ]
Syntax Description Mode in which the specified command exists. See
the table in the “Usage Guidelines”section for a list
of available options for this argument.
parser-mode
Adds a specified command or a specified interface to
the view and allows the same command or interface
to be added to a view.
include
Adds a specified command or a specified interface to
the view and excludes the same command or interface
from being added to all other views.
include-exclusive
Denies access to commands in the specified parser
mode.
This keyword is available only for
command-based views.
Note
exclude
(Optional) A “wildcard”that allows every command
in a specified configuration mode that begins with
the same keyword or every subinterface within a
specified interface to be part of the view.
all
(Optional) Command that is added to the view.
If no commands are specified, all commands
within the specified parser mode are included
or excluded, as appropriate.
Note
command
(Optional) Interface that is added to the view.
interface name
Cisco IOS Security Command Reference: Commands A to C
70
clear ip access-list counters through crl-cache none
commands (view)
Command Default If this command is not enabled, a view will not have adequate information to deny or allow access to users.
Command Modes View configuration (config-view)
Command History ModificationRelease
This command was introduced.12.3(7)T
The exclude keyword and the interface interface-name option were
added.
12.3(11)T
This command was integrated into Cisco IOS Release 12.2(33)SRB.12.2(33)SRB
This command was integrated into Cisco IOS XE Release 2.1.Cisco IOS XE Release 2.1
This command was integrated into Cisco IOS Release 12.2(33)SXI.12.2(33)SXI
Usage Guidelines If a network administrator does not enter a specific command (via the command argument) or interface (via
the interface interface-name option), users are granted access (via the include or include-exclusive keyword)
or denied access (via the exclude keyword) to all commands within the specified parser mode.
parser-mode Options
The table below shows some of the keyword options for the parser-modeargument in the commandscommand.
The available mode keywords vary depending on your hardware and software version. To display a list of
available mode options on your system, use the commands ?command.
Table 1: parser-mode Argument Options
DescriptionCommand
VPDN accept-dialin group configuration modeaccept-dialin
VPDN accept-dialout group configuration modeaccept-dialout
Address family configuration modeaddress-family
ALPS ASCU configuration modealps-ascu
ALPS circuit configuration modealps-circuit
ATM bundle member configuration modeatm-bm-config
ATM bundle configuration modeatm-bundle-config
ATM virtual circuit configuration modeatm-vc-config
Cisco IOS Security Command Reference: Commands A to C
71
clear ip access-list counters through crl-cache none
commands (view)
DescriptionCommand
ATMSIG E164 Tableatmsig_e164_table_mode
Channel-associated signaling (cas) custom
configuration mode
cascustom
RTR HTTP raw request configuration modeconfig-rtr-http
Global configuration modeconfigure
Controller configuration modecontroller
Crypto map configuration modecrypto-map
Crypto transform configuration modecrypto-transform
DHCP pool configuration modedhcp
DSP farm configuration modedspfarm
EXEC modeexec
Flow aggregation cache configuration modeflow-cache
Gateway configuration modegateway
Interface configuration modeinterface
Frame Relay DLCI configuration modeinterface-dlci
IP named extended access-list configuration modeipenacl
IP named simple access-list configuration modeipsnacl
Configure IP VRF parametersip-vrf
ATM Lan Emulation Lecs Configuration Tablelane
Line configuration modeline
Map-class configuration modemap-class
Map-list configuration modemap-list
MPOA clientmpoa-client
MPOA servermpoa-server
Null interface configuration modenull-interface
Cisco IOS Security Command Reference: Commands A to C
72
clear ip access-list counters through crl-cache none
commands (view)
DescriptionCommand
AAA Preauth definitionspreaut
VPDN accept-dialin group configuration moderequest-dialin
VPDN accept-dialout group configuration moderequest-dialout
Route-map configuration moderoute-map
Router configuration moderouter
RSVP local policy configuration modersvp_policy_local
RTR entry configuration modertr
RADIUS server group definitionsg-radius
TACACS+ server groupsg-tacacs+
SIP UA configuration modesip-ua
Subscriber policy configuration modesubscriber-policy
Tcl modetcl
TDM connection configuration modetdm-conn
Template configuration modetemplate
Translation Rule configuration modetranslation-rule
VC class configuration modevc-class
Voice class configuration modevoiceclass
Voice configuration modevoiceport
Dial peer configuration modevoipdialpeer
VPDN group configuration modevpdn-group
Examples The following example shows how to add the privileged EXEC command show version to both CLI views
“first”and “second.”Because the include keyword was issued, the show version command can be added to
both views.
Router(config)# parser view first
Router(config-view)# secret 5 secret
Router(config-view)# commands exec include show version
Cisco IOS Security Command Reference: Commands A to C
73
clear ip access-list counters through crl-cache none
commands (view)
!
Router(config)# parser view second
Router(config-view)# secret 5 myview
Router(config-view)# commands exec include show version
The following example shows how to allow users in the view “first”to execute all commands that start with
the word “show”except the show interfaces command, which is excluded by the view “second”:
Router(config)# parser view first
Router(config-view)# secret 5 secret
Router(config-view)# commands exec include all show
!
Router(config)# parser view second
Router(config-view)# secret 5 myview
Router(config-view)# commands exec include-exclusive show interfaces
Related Commands DescriptionCommand
Creates or changes a CLI view and enters view
configuration mode.
parser view
Associates a CLI view or a superview with a
password.
secret 5
Cisco IOS Security Command Reference: Commands A to C
74
clear ip access-list counters through crl-cache none
commands (view)
configuration url
To specify on a server the URL that an Easy VPN remote device must use to get a configuration in a Mode
Configuration Exchange, use the configuration url command in global configuration or IKEv2 authorization
policy configuration mode. To delete the URL, use the no form of this command.
configuration url url
no configuration url url
Syntax Description Specifies the URL the Easy VPN remote device must
use to get the configuration from the server.
•The URL must be a non-NULL terminated
ASCII string that specifies the complete path of
the configuration file.
url
Command Default An Easy VPN remote device cannot request a configuration from a server in a Mode Configuration Exchange.
Command Modes Global configuration (config)
IKEv2 authorization policy configuration (config-ikev2-author-policy)
Command History ModificationRelease
This command was introduced.12.4(4)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS 12.2SX family of releases.
Support in a specific 12.2SX release is dependent on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines After the server “pushes”the URL to a Cisco Easy VPN remote device, the remote device can download the
content located at the URL site and apply the configuration content to its running configuration.
Before this command can be configured, the crypto isakmp client configuration group or crypto ikev2
authorization policy command must already have been configured.
Examples The file served by the configuration URL should have a Cisco IOS command-line interface( CLI) listing. The
listing can have an optional “transient”section. The keyword to begin the transient section is “!%transient,”
Cisco IOS Security Command Reference: Commands A to C
75
clear ip access-list counters through crl-cache none
configuration url
and the keyword should be on a single line. A persistent section can be optionally identified by the keyword
“!%persistent,”also shown on a single line. An example of a CLI listing follows:
ip cef
cdp advertise-v2
!%transient
ip domain-name example.com
ntp server 10.2.3.4
ntp update-calendar
In the above example, the first two lines stay in the configuration even after the tunnel is disconnected (but
they are not written into the nonvolatile configuration). The last three lines are effective only as long as the
tunnel is “up.”
The following example shows that a server has specified the URL the Easy VPN remote device must use to
download the URL:
crypto isakmp client configuration group group1
configuration url http://10.10.8.8/easy.cfg
Related Commands DescriptionCommand
Specifies an IKEv2 authorization policy group.crypto ikev2 authorization policy
Specifies to which group a policy profile will be
defined.
crypto isakmp client configuration group
Cisco IOS Security Command Reference: Commands A to C
76
clear ip access-list counters through crl-cache none
configuration url
configuration version
To specify on a server the version that a Cisco Easy VPN remote device must use to get a particular
configuration in a Mode Configuration Exchange, use the configuration version command in global
configuration or IKEv2 authorization policy configuration mode. To delete the version number, use the no
form of this command.
configuration version version-number
no configuration version version-number
Syntax Description Specifies the version of the configuration.
•The version number will be an unsigned integer
in the range 1 through 32767.
version-number
Command Default A version number is not sent.
Command Modes Global configuration (config)
IKEv2 authorization policy configuration (config-ikev2-author-policy)
Command History ModificationRelease
This command was introduced.12.4(4)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS 12.2SX family of releases.
Support in a specific 12.2SX release is dependent on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines Before this command can be configured, the crypto isakmp client configuration group or crypto ikev2
authorization policy command must already have been configured.
Examples The following example shows that a server has specified the version number a Cisco Easy VPN remote device
must use to obtain that particular configuration version:
crypto isakmp client configuration group group1
configuration version 10
Cisco IOS Security Command Reference: Commands A to C
77
clear ip access-list counters through crl-cache none
configuration version
Related Commands DescriptionCommand
Specifies an IKEv2 authorization policy group.crypto ikev2 authorization policy
Specifies to which group a policy profile will be
defined.
crypto isakmp client configuration group
Cisco IOS Security Command Reference: Commands A to C
78
clear ip access-list counters through crl-cache none
configuration version
config-exchange
To enable the configuration exchange options, use the config-echange command in IKEv2 profile configuration
mode. To disable sending, use the no form of this command.
config-exchange{request|set{accept| send}}
no config-exchange{request|set{accept| send}}
Syntax Description Enables configuration exchange request.request
Enables configuration exchange request set options.set
Accepts configuration exchange request set.accept
Enables sending of configuration exchange set.send
Command Default The configuration exchange options is enabled by default.
Command Modes IKEv2 profile configuration (config-ikev2-profile)
Command History ModificationRelease
This command was introduced. This command replaces the config-mode
set command.
15.2(2)T
Usage Guidelines Before using this command, you must first configure the crypto ikev2 profile command. Use this command
to enable the exchange of configuration options. The acceptance of configuration exchange options is enabled
by default.
Examples The following example show how to set the acceptance of configuration exchange request for the IKEv2
profile “profile2”:
Router(config)# crypto ikev2 profile profile2
Router(config-ikev2-profile)# config-exchange set accept
Related Commands DescriptionCommand
Defines an IKEv2 profile.crypto ikev2 profile
Cisco IOS Security Command Reference: Commands A to C
79
clear ip access-list counters through crl-cache none
config-exchange
config-mode set
Effective with Cisco IOS Release 15.2(2)T, the config-mode set command is replaced by the
config-exchange command. See the config-exchange command for more information.
Note
To enable sending the configuration mode set, use the config-mode set command in IKEv2 profile configuration
mode. To disable sending, use the no form of this command.
config-mode set
no config-mode set
Syntax Description This command has no keywords or arguments.
Command Default The configuration mode set is enabled by default.
Command Modes IKEv2 profile configuration (config-ikev2-profile)
Command History ModificationRelease
This command was introduced.15.2(1)T
This command was replaced by the config-exchange command.15.2(2)T
Usage Guidelines Before using this command, you must first configure the crypto ikev2 profile command. Use this command
to enable sending of configuration mode set. The acceptance of configuration mode set is enabled by default.
Examples The following example show how to configure the configuration mode set for the IKEv2 profile “profile1”:
Router(config)# crypto ikev2 profile profile1
Router(config-ikev2-profile)# config-mode set
Related Commands DescriptionCommand
Defines an IKEv2 profile.crypto ikev2 profile
Cisco IOS Security Command Reference: Commands A to C
80
clear ip access-list counters through crl-cache none
config-mode set
connect
To connect the FlexVPN client to the tunnel, use the connect command in IKEv2 FlexVPN client profile
configuration mode. To disable the connection, use the no form of this command.
connect {manual| auto|track track-number [up| down]}
no connect {manual| auto| track}
Syntax Description Manually establishes connection with the tunnel.manual
Automatic connection. This is the default mode.auto
Estalishes a connection based on state of the track
object.
track track-number
Establishes a connection when the state of the track
object is up.
up
Establishes a connection when the state of the track
object is down.
down
Command Default The default connect mode is auto.
Command Modes IKEv2 FlexVPN client profile configuration (config-ikev2-flexvpn)
Command History ModificationRelease
This command was introduced.15.2(1)T
This command was integrated into Cisco IOS XE Release 3.7S.Cisco IOS XE Release 3.7S
Usage Guidelines Before you enable this command, you must configure the crypto ikev2 client flexvpn command.
Any changes to this command terminates the active session.Note
Cisco IOS Security Command Reference: Commands A to C
81
clear ip access-list counters through crl-cache none
connect
Examples The following examples shows how to set the tunnel connection to auto.
Router(config)# crypto ikev2 client flexvpn client1
Router(config-ikev2-flexvpn)# peer 1 10.0.0.1
Router(config-ikev2-flexvpn)# connect track 10 up
Related Commands DescriptionCommand
Defines an IKEv2 FlexVPN client profile.crypto ikev2 client flexvpn
Cisco IOS Security Command Reference: Commands A to C
82
clear ip access-list counters through crl-cache none
connect
content-length
To permit or deny HTTP traffic through the firewall on the basis of message size, use the content-length
command in appfw-policy-http configuration mode. To remove message-size limitations from your
configuration, use the no form of this command.
content-length {min bytes max bytes|min bytes|max bytes}action {reset| allow}[alarm]
no content-length {min bytes max bytes|min bytes|max bytes}action {reset| allow}[alarm]
Syntax Description Minimum content length, in bytes, allowed per
message. Number of bytes range: 0 to 65535.
min bytes
Maximum content length, in bytes, allowed per
message. Number of bytes range: 0 to 65535.
max bytes
Messages whose size do not meet the minimum or
exceed the maximum number of bytes are subject to
the specified action (reset or allow).
action
Sends a TCP reset notification to the client or server
if the HTTP message fails the mode inspection.
reset
Forwards the packet through the firewall.allow
(Optional) Generates system logging (syslog)
messages for the given action.
alarm
Command Default If this command is not enabled, message size is not considered when permitting or denying HTTP messages.
Command Modes appfw-policy-http configuration
Command History ModificationRelease
This command was introduced.12.3(14)T
Usage Guidelines All messages exceeding the specified content-length range, will be subjected to the configured action (reset
or allow).
Cisco IOS Security Command Reference: Commands A to C
83
clear ip access-list counters through crl-cache none
content-length
Examples The following example, which shows how to define the HTTP application firewall policy “mypolicy,”will
not permit HTTP messages longer than 1 byte. This policy includes all supported HTTP policy rules. After
the policy is defined, it is applied to the inspection rule “firewall,”which will inspect all HTTP traffic entering
the FastEthernet0/0 interface.
! Define the HTTP policy.
appfw policy-name mypolicy
application http
strict-http action allow alarm
content-length max 1 action allow alarm
content-type-verification match-req-resp action allow alarm
max-header-length request 1 response 1 action allow alarm
max-uri-length 1 action allow alarm
port-misuse default action allow alarm
request-method rfc default action allow alarm
request-method extension default action allow alarm
transfer-encoding type default action allow alarm
!
!
! Apply the policy to an inspection rule.
ip inspect name firewall appfw mypolicy
ip inspect name firewall http
!
!
! Apply the inspection rule to all HTTP traffic entering the FastEthernet0/0 interface.
interface FastEthernet0/0
ip inspect firewall in
!
!
Cisco IOS Security Command Reference: Commands A to C
84
clear ip access-list counters through crl-cache none
content-length
content-scan out
Effective with Cisco IOS Release 15.4(2)T, the content-scan out command is replaced by the cws out
command. See the cws out command for more information.
Note
To enable content scanning on an egress interface, use the content-scan out command in interface configuration
mode. To disable content scanning, use the no form of this command.
content-scan out
no content-scan out
Syntax Description This command has no arguments or keywords.
Command Default Content scanning is disabled.
Command Modes Interface configuration (config-if)
Command History ModificationRelease
This command was introduced.15.2(1)T1
This command was replaced by the cws out command.15.4(2)T
Usage Guidelines The content scanning process redirects client web traffic to ScanSafe. Content scanning is enabled on an
Internet-facing WAN interface to protect the web traffic going out.
In case you enable content scanning on a interface that has Wide Area Application Services (WAAS) configured,
you must not apply both the WAAS and the content scanning feature on the same TCP session.
Examples The following example shows how to enable content scanning on a Gigabit Ethernet interface:
Device(config)# interface gigabitethernet 0/0
Device(config-if)# content-scan out
Related Commands DescriptionCommand
Enables content scan whitelisting and enters
content-scan whitelisting configuration mode.
content-scan whitelisting
Cisco IOS Security Command Reference: Commands A to C
85
clear ip access-list counters through crl-cache none
content-scan out
DescriptionCommand
Configures an interface and enters interface
configuration mode.
interface
Cisco IOS Security Command Reference: Commands A to C
86
clear ip access-list counters through crl-cache none
content-scan out
content-scan whitelisting
Effective with Cisco IOS Release 15.4(2)T, the content-scan whitelisting command is replaced by the
cws whitelisting command. See the cws whitelisting command for more information.
Note
To enable whitelisting of incoming traffic and to enter content-scan whitelisting configuration mode, use the
content-scan whitelisting command in global configuration mode. To disable the whitelisting of traffic, use
the no form of this command.
content-scan whitelisting
no content-scan whitelisting
Syntax Description This command has no arguments or keywords.
Command Default Whitelisting of traffic is disabled.
Command Modes Global configuration (config)
Command History ModificationRelease
This command was introduced.15.2(1)T1
This command was replaced by the cws whitelisting command.15.4(2)T
Usage Guidelines A whitelist is an approved list that contains entities that are provided a particular privilege, service, mobility,
access, or recognition. Whitelisting means to grant access.
The web traffic that you have configured for whitelisting will bypass the content scanning by ScanSafe.
Examples The following example shows how to enable content scan whitelisting and enter content-scan whitelisting
configuration mode:
Device(config)# content-scan whitelisting
Device(config-cont-scan-wl)#
Cisco IOS Security Command Reference: Commands A to C
87
clear ip access-list counters through crl-cache none
content-scan whitelisting
Related Commands DescriptionCommand
Configures a global content-scan parameter map and
enters parameter-map type inspect configuration
mode.
parameter-map type content-scan global
Cisco IOS Security Command Reference: Commands A to C
88
clear ip access-list counters through crl-cache none
content-scan whitelisting
content-type-verification
To permit or deny HTTP traffic through the firewall on the basis of content message type, use the
content-type-verification command in appfw-policy-http configuration mode. To disable this inspection
parameter, use the no form of this command.
content-type-verification [match-req-resp] action {reset| allow}[alarm]
no content-type-verification [match-req-resp] action {reset| allow}[alarm]
Syntax Description (Optional) Verifies the content type of the HTTP
response against the accept field of the HTTP request.
match-req-resp
Messages that match the specified content type are
subject to the specified action (reset or allow).
action
Sends a TCP reset notification to the client or server
if the HTTP message fails the mode inspection.
reset
Forwards the packet through the firewall.allow
(Optional) Generates system logging (syslog)
messages for the given action.
alarm
Command Default If this command is not issued, all traffic will be allowed.
Command Modes appfw-policy-http configuration
Command History ModificationRelease
This command was introduced.12.3(14)T
Usage Guidelines After the content-type-verification command is issued, all HTTP messages are subjected to the following
inspections:
•Verify that the content type of the message header is listed as a supported content type. (See the table
below.)
•Verify that the content type of the header matches the content of the message data or entity body portion
of the message.
The table below contains a list of supported content types.
Cisco IOS Security Command Reference: Commands A to C
89
clear ip access-list counters through crl-cache none
content-type-verification
Table 2: HTTP Header Supported Content Types
Supported Content Types
audio/*
audio/basic
audio/midi
audio/mpeg
audio/x-adpcm
audio/x-aiff
audio/x-ogg
audio/x-wav
application/msword
application/octet-stream
application/pdf
application/postscript
application/vnd.ms-excel
application/vnd.ms-powerpoint
application/x-gzip
application/x-java-arching
application/x-java-xm
application/zip
image/*
image/cgf
image/gif
image/jpeg
image/png
image/tiff
Cisco IOS Security Command Reference: Commands A to C
90
clear ip access-list counters through crl-cache none
content-type-verification
Supported Content Types
image/x-3ds
image/x-bitmap
image/x-niff
image/x-portable-bitmap
image/x-portable-greymap
image/x-xpm
text/*
text/css
text/html
text/plain
text/richtext
text/sgml
text/xmcd
text/xml
video/*
video/-flc
video/mpeg
video/quicktime
video/sgi
video/x-avi
video/x-fli
video/x-mng
video/x-msvideo
Cisco IOS Security Command Reference: Commands A to C
91
clear ip access-list counters through crl-cache none
content-type-verification
The following example shows how to define the HTTP application firewall policy “mypolicy.”This policy
includes all supported HTTP policy rules. After the policy is defined, it is applied to the inspection rule
“firewall,”which will inspect all HTTP traffic entering the FastEthernet0/0 interface.
! Define the HTTP policy.
appfw policy-name mypolicy
application http
strict-http action allow alarm
content-length max 1 action allow alarm
content-type-verification match-req-resp action allow alarm
max-header-length request 1 response 1 action allow alarm
max-uri-length 1 action allow alarm
port-misuse default action allow alarm
request-method rfc default action allow alarm
request-method extension default action allow alarm
transfer-encoding type default action allow alarm
!
!
! Apply the policy to an inspection rule.
ip inspect name firewall appfw mypolicy
ip inspect name firewall http
!
!
! Apply the inspection rule to all HTTP traffic entering the FastEthernet0/0 interface.
interface FastEthernet0/0
ip inspect firewall in
!
!
Cisco IOS Security Command Reference: Commands A to C
92
clear ip access-list counters through crl-cache none
content-type-verification
control
To configure the control interface type and number for a redundancy group, use the controlcommand in
redundancy application group configuration mode. To remove the control interface for the redundancy group,
use the no form of this command.
control interface-type interface-number protocol id
no control
Syntax Description Interface type.
interface-type
Interface number.
interface-number
Specifies redundancy group protocol media.protocol
Redundancy group protocol instance. The range is
from 1 to 8.
id
Command Default The control interface is not configured.
Command Modes Redundancy application group configuration (config-red-app-grp)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 3.1S
Examples The following example shows how to configure the redundancy group protocol media and instance for the
control Gigabit Ethernet interface:
Router# configure terminal
Router(config)# redundancy
Router(config-red)# application redundancy
Router(config-red-app)# group 1
Router(config-red-app-grp)# control GigabitEthernet 0/0/0 protocol
1
Related Commands DescriptionCommand
Enters redundancy application configuration mode.application redundancy
Cisco IOS Security Command Reference: Commands A to C
93
clear ip access-list counters through crl-cache none
control
DescriptionCommand
Configures clear text authentication and MD5
authentication for a redundancy group.
authentication
Configures the data interface type and number for a
redundancy group.
data
Enters redundancy application group configuration
mode.
group(firewall)
Configures the redundancy group with a name.name
Enables preemption on the redundancy group.preempt
Defines a protocol instance in a redundancy group.protocol
Cisco IOS Security Command Reference: Commands A to C
94
clear ip access-list counters through crl-cache none
control
copy (consent-parameter-map)
To configure a consent page to be downloaded from a file server, use the copy command in parameter-map
type consent configuration mode.
copy src-file-name dst-file-name
Syntax Description Source file location in which the specified file will
be retrieved. The source file location must b e TFTP;
for example, tftp://10.1.1.1/username/myfile.
src-file-name
Destination location in which a copy of the file will
be stored. The destination file should be copied to
Flash; for example, flash. username .html.
dst-file-name
Command Default The consent page that is specified via the default parameter-map will be used.
Command Modes Parameter-map-type consent (config-profile)
Command History ModificationRelease
This command was introduced.12.4(15)T
Usage Guidelines Use the copy command to transfer a file (consent web page) from an external server to a local file system on
a device. Thus, the file name specified via the copy command is retrieved from the destination file location
and displayed to the end user as the consent page.
When a consent webpage is displayed to an end user, the filename specified via the file command is used. If
the file command is not configured, the destination location specified via the copy command is used .
Examples In the following example, both parameter maps are to use the consent file
“tftp://192.168.104.136/consent_page.html”and store it in “flash:consent_page.html”:
parameter-map type consent consent_parameter_map
copy tftp://192.168.104.136/consent_page.html flash:consent_page.html
authorize accept identity consent_identity_policy
timeout file download 35791
file flash:consent_page.html
logging enabled
exit
!
parameter-map type consent default
copy tftp://192.168.104.136/consent_page.html flash:consent_page.html
authorize accept identity test_identity_policy
Cisco IOS Security Command Reference: Commands A to C
95
clear ip access-list counters through crl-cache none
copy (consent-parameter-map)
timeout file download 35791
file flash:consent_page.html
logging enabled
exit
!
Related Commands DescriptionCommand
Specifies a local filename that is to be used as the
consent webpage.
file (consent-parameter-map)
Cisco IOS Security Command Reference: Commands A to C
96
clear ip access-list counters through crl-cache none
copy (consent-parameter-map)
copy idconf
To load a signature package in Cisco IOS Intrusion Prevention System (IPS), use the copy idconfcommand
in EXEC mode.
copy url idconf
Syntax Description Specifies the location from which the router loads the
signature file.
Available URL locations are as follows:
•Local flash, such as flash:sig.xml
•FTP server, such as
ftp://myuser:mypass@ftp_server.sig.xml
•rcp, such as rcp://myuser@rcp_server/sig.xml
•TFTP server, such as tftp://tftp_server/sig.xml
url
Command Default None
Command Modes EXEC
Command History ModificationRelease
This command was introduced.12.4(11)T
Usage Guidelines Use the copy url idconfcommand to load a signature package into Cisco IOS IPS. You may wish to load a
new signature package into Cisco IOS IPS if a signature (or signatures) with the current signature file is not
providing your network with adequate protection from security threats. After the signature package has been
loaded into the router, Cisco IOS IPS saves all signature information to the location specified via the ip ips
config location command.
Signatures are loaded into the scanning table on the basis of importance. Parameters such as signature severity,
signature fidelity rating, and time lapsed since signatures were released enable Cisco IOS IPS to compile the
most important signatures first, followed by less important signatures, thereby, creating a load order and
prioritizing which signatures are loaded first.
The copy url idconf command replaces the copy ips-sdf command.
Note
Cisco IOS Security Command Reference: Commands A to C
97
clear ip access-list counters through crl-cache none
copy idconf
Examples The following example shows how to load a signature package into Cisco IOS IPS from the location
“flash:IOS-S258-CLI-kd.pkg”:
Router# copy flash:IOS-S258-CLI-kd.pkg idconf
*Nov 14 2006 17:19:47 MST: %IPS-6-ENGINE_BUILDS_STARTED: 17:19:47 MST Nov 14 2006
*Nov 14 2006 17:19:47 MST: %IPS-6-ENGINE_BUILDING: multi-string - 3 signatures - 1 of 13
engines
*Nov 14 2006 17:19:47 MST: %IPS-6-ENGINE_READY: multi-string - build time 4 ms - packets
for this engine will be scanned
*Nov 14 2006 17:19:47 MST: %IPS-6-ENGINE_BUILDING: service-http - 611 signatures - 2 of 13
engines
*Nov 14 2006 17:20:00 MST: %IPS-6-ENGINE_READY: service-http - build time 12932 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:00 MST: %IPS-6-ENGINE_BUILDING: string-tcp - 864 signatures - 3 of 13
engines
*Nov 14 2006 17:20:02 MST: %IPS-6-ENGINE_READY: string-tcp - build time 2692 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:02 MST: %IPS-6-ENGINE_BUILDING: string-udp - 74 signatures - 4 of 13
engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: string-udp - build time 316 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: state - 28 signatures - 5 of 13 engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: state - build time 24 ms - packets for this
engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: atomic-ip - 252 signatures - 6 of 13
engines
*Nov 14 2006 17:20:03 MST: %IPS-4-META_ENGINE_UNSUPPORTED: atomic-ip 2154:0 - this signature
is a component of the unsupported META engine
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: atomic-ip - build time 232 ms - packets for
this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: string-icmp - 3 signatures - 7 of 13 e
Router# engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: string-icmp - build time 12 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: service-ftp - 3 signatures - 8 of 13
engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: service-ftp - build time 8 ms - packets for
this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: service-rpc - 75 signatures - 9 of 13
engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: service-rpc - build time 80 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: service-dns - 38 signatures - 10 of 13
engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: service-dns - build time 20 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: normalizer - 9 signatures - 11 of 13
engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: normalizer - build time 0 ms - packets for
this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_BUILDING: service-msrpc - 22 signatures - 12 of
13 engines
*Nov 14 2006 17:20:03 MST: %IPS-6-ENGINE_READY: service-msrpc - build time 8 ms - packets
for this engine will be scanned
*Nov 14 2006 17:20:03 MST: %IPS-6-ALL_ENGINE_BUILDS_COMPLETE: elapsed time 16344 ms
Related Commands DescriptionCommand
Specifies the location in which the router will save
signature information.
ip ips config-location
Cisco IOS Security Command Reference: Commands A to C
98
clear ip access-list counters through crl-cache none
copy idconf
copy ips-sdf
In Cisco IOS Release 12.4(11)T, the copy ips-sdf command was replaced with the copy idconf command.
For more information, see the copy idconf command.
Note
To load or save the signature definition file (SDF) in the router, use the copy ips-sdfcommand in EXEC mode.
Syntax for Loading the SDF
copy [/erase]url ips-sdf
Syntax for Saving the SDF
copy ips-sdf url
Syntax Description (Optional) Erases the current SDF in the router before
loading the new SDF.
This option is typically available only on
platforms with limited memory.
Note
/erase
Description for the url argument is one of the
following options:
•If you want to load the SDF in the router, the
url argument specifies the location in which to
search for the SDF.
•If you are saving the SDF, the url argument
represents the location in which the SDF is
saved after it has been generated.
Regardless of what option the URL is used for,
available URL locations are as follows:
•local flash, such as flash:sig.xml
•FTP server, such as
ftp://myuser:mypass@ftp_server.sig.xml
•rcp, such as rcp://myuser@rcp_server/sig.xml
•TFTP server, such as tftp://tftp_server/sig.xml
url
Command Modes EXEC
Cisco IOS Security Command Reference: Commands A to C
99
clear ip access-list counters through crl-cache none
copy ips-sdf
Command History ModificationRelease
This command was introduced.12.3(8)T
This command was replaced with the copy idconf command.12.4(11)T
Usage Guidelines Loading Signatures From the SDF
Issue the copy url ips-sdf command to load the SDF in the router from the location specified via the url
argument. When the new SDF is loaded, it is merged with the SDF that is already loaded in the router, unless
the /erase keyword is issued, which overwrites the current SDF with the new SDF.
Cisco IOS Intrusion Prevention System (IPS) will attempt to retrieve the SDF from each specified location
in the order in which they were configured in the startup configuration. If Cisco IOS IPS cannot retrieve the
signatures from any of the specified locations, the built-in signatures will be used.
If the no ip ips sdf built-in command is used, Cisco IOS IPS will fail to load. IPS will then rely on the
configuration of the ip ips failcommand to either fail open or fail closed.
For Cisco IOS Release 12.3(8)T, the SDF should be loaded directly from Flash.Note
After the signatures are loaded in the router, the signature engines are built. Only after the signature engines
are built can Cisco IOS IPS beginning scanning traffic.
Whenever signatures are replaced or merged, the router is suspended while the signature engines for the
newly added or merged signatures are being built. The router prompt will be available again after the
engines are built. Depending on your platform and how many signatures are being loaded, building the
engine can take up to several minutes. It is recommended that you enable logging messages to monitor
the engine building status.
Note
The ip sdf ips location command can also be used to load the SDF. However, unlike the copy ips-sdfcommand,
this command does not force and immediately load the signatures. Signatures are not loaded until the router
reboots or IPS is initially applied to an interface (via the ip ipscommand).
Saving a Generated or Merges SDF
Issue the copy ips-sdf url command to save a newly created SDF file to a specified location. The next time
the router is reloaded, IPS can refer to the SDF from the saved location by including the ip ips sdf location
command in the configuration.
It is recommended that you save the SDF back out to Flash. Also, you should save the file to a different
name than the original attack-drop.sdf file; otherwise, you risk loosing the original file.
Tip
Cisco IOS Security Command Reference: Commands A to C
100
clear ip access-list counters through crl-cache none
copy ips-sdf
Examples The following example shows how to configure the router to load and merge the attack-drop.sdf file with the
default signatures. After you have merged the two files, it is recommended to copy the newly merged signatures
to a separate file. The router can then be reloaded (via the reload command) or reinitalized to so as to recognize
the newly merged file (as shown the following example)
!
ip ips name MYIPS
!
interface GigabitEthernet0/1
ip address 10.1.1.16 255.255.255.0
ip ips MYIPS in
duplex full
speed 100
media-type rj45
no negotiation auto
!
!
! Merge the flash-based SDF (attack-drop.sdf) with the built-in signatures.
copy disk2:attack-drop.sdf ips-sdf
! Save the newly merged signatures to a separate file.
copy ips-sdf disk2:my-signatures.sdf
!
! Configure the router to use the new file, my-signatures.sdf
configure terminal
ip ips sdf location disk2:my-signatures.sdf
! Reinitialize the IPS by removing the IPS rule set and reapplying the rule set.
interface gig 0/1
no ip ips MYIPS in
!
*Apr 8 14:05:38.243:%IPS-2-DISABLED:IPS removed from all interfaces - IPS disabled
!
ip ips MYIPS in
!
exit
Related Commands DescriptionCommand
Specifies the location in which the router should load
the SDF.
ip ips sdf location
Cisco IOS Security Command Reference: Commands A to C
101
clear ip access-list counters through crl-cache none
copy ips-sdf
consent email
To request a user’s e-mail address on the consent login web page, use the consent email command in parameter
map webauth configuration mode. To remove the consent parameter file from the map, use the no form of
this command.
consent email
no consent email
Syntax Description This command has no arguments or keywords.
Command Default The e-mail address is not requested on the consent login page.
Command Modes Parameter map webauth configuration (config-params-parameter-map)
Command History ModificationRelease
This command was introduced.Cisco IOS XE Release 3.2SE
Usage Guidelines Use the consent email command to display a text box on the consent login page prompting the user to enter
his or her e-mail address for identification. The device sends this e-mail address to the authentication,
authorization, and accounting (AAA) server instead of sending the client’s MAC address.
The consent feature allows you to provide temporary Internet and corporate access to end users through their
wired and wireless networks by presenting a consent web page. This web page lists the terms and conditions
under which the organization is willing to grant access to end users. Users can connect to the network only
after they accept the terms on the consent web page.
If you create a parameter map with the type command set to consent, the device does not prompt the user for
his or her username and password credentials. Users instead get a choice of two radio buttons: accept or do
not accept. For accounting purposes, the device sends the client’s MAC address to the AAA server if no
username is available (because consent is enabled).
This command is supported in named parameter maps only.
Examples The following example shows how to enable the consent e-mail feature in a parameter map:
parameter-map type webauth PMAP_1
type consent
consent email
banner file flash:consent_page.htm
Cisco IOS Security Command Reference: Commands A to C
102
clear ip access-list counters through crl-cache none
consent email
Related Commands DescriptionCommand
Displays a banner on the web-authentication login
web page.
banner (parameter-map webauth)
Displays custom web pages during web authentication
login.
custom-page
Defines the methods supported by a parameter map.type (parameter-map webauth)
Cisco IOS Security Command Reference: Commands A to C
103
clear ip access-list counters through crl-cache none
consent email
crl
To specify the certificate revocation list (CRL) query and CRL cache options for the public key infrastructure
(PKI) trustpool, use the crl command in ca-trustpool configuration mode. To return to the default behavior
in which the router checks the URL that is embedded in the certificate, use the no form of this command.
crl {cache {delete-after {minutes| none}| query url}
no crl {cache {delete-after {minutes| none}| query url}
Syntax Description Specifies CRL cache options.cache
Removes the CRL from cache after a timeout.delete-after
The number of minutes from 1 to 43200 to wait before
deleting CRL from cache.
minutes
Specifies that CRLs are not cached.none
Specifies the URL published by the certification
authority (CA) server to query the CRL.
query url
Command Default The CRL is not queried and no CRL cache parameters are configured.
Command Modes Ca-trustpool configuration (ca-trustpool)
Command History ModificationRelease
This command was introduced.15.2(2)T
This command was integrated into Cisco IOS Release 15.1(1)SY.15.1(1)SY
Usage Guidelines Before you can configure this command, you must enable the crypto pki trustpool policy command, which
enters ca-trustpool configuration mode.
The crl query command is used if the CDP is in Lightweight Directory Access Protocol (LDAP) form, which
means that the CDP location in the certificate indicates only where the CRL distribution point (CDP) is located
in the directory; that is, the CDP does not indicate the actual query location for the directory.
The Cisco IOS software queries the CRL to ensure that the certificate has not been revoked in order to verify
a peer certificate (for example, during Internet Key Exchange (IKE) or Secure Sockets Layer (SSL) handshake).
The query looks for the CDP extension in the certificate, which is used to download the CRL. If this query is
Cisco IOS Security Command Reference: Commands A to C
104
clear ip access-list counters through crl-cache none
crl
unsuccessful, then the Simple Certificate Enrollment Protocol (SCEP) GetCRL mechanism is used to query
the CRL from the CA server directly (some CA servers do not support this method).
Cisco IOS software supports the following CDP entries:
•HTTP URL with a hostname. For example: http://myurlname/myca.crl
•HTTP URL with an IPv4 address. For example: http://10.10.10.10:81/myca.crl
•LDAP URL with a hostname. For example: ldap://CN=myca, O=cisco
•LDAP URL with an IPv4 address. For example: ldap://10.10.10.10:3899/CN=myca, O=cisco
•LDAP/X.500 DN. For example: CN=myca, O=cisco
The Cisco IOS needs a complete URL in order to locate the CDP.
Examples Router(config)# crypto pki trustpool policy
Router(ca-trustpool)# crl query http://www.cisco.com/security/pki/crl/crca2048.crl
Related Commands DescriptionCommand
Configures the URL from which
the PKI trustpool CA bundle is
downloaded.
cabundle url
Enables chain validation from the
peer's certificate to the root CA
certificate in the PKI trustpool.
chain-validation
Manually imports (downloads) the
CA certificate bundle into the PKI
trustpool to update or replace the
existing CA bundle.
crypto pki trustpool import
Configures PKI trustpool policy
parameters.
crypto pki trustpool policy
Resets the value of a ca-trustpool
configuration command to its
default.
default
Enables the use of certificate maps
for the PKI trustpool.
match
Specifies OCSP settings for the
PKI trustpool.
ocsp
Disables revocation checking when
the PKI trustpool policy is being
used.
revocation-check
Cisco IOS Security Command Reference: Commands A to C
105
clear ip access-list counters through crl-cache none
crl
DescriptionCommand
Displays the PKI trustpool policy
of the router in ca-trustpool
configuration mode.
show
Specifies the source interface to be
used for CRL retrieval, OCSP
status, or the downloading of a CA
certificate bundle for the PKI
trustpool.
show crypto pki trustpool
Specifies the source interface to be
used for CRL retrieval, OCSP
status, or the downloading of a CA
certificate bundle for the PKI
trustpool.
source interface
Specifies a file system location
where PKI trustpool certificates are
stored on the router.
storage
Specifies the VRF instance to be
used for CRL retrieval.
vrf
Cisco IOS Security Command Reference: Commands A to C
106
clear ip access-list counters through crl-cache none
crl
crl (cs-server)
To specify the certificate revocation list (CRL) public key infrastructure (PKI) certificate server (CS), use the
crl command in certificate server configuration mode. To return to the default behavior in which the router
checks the URL that is embedded in the certificate, use the no form of this command.
crl CRL-serial-number
no crl
Syntax Description Specifies CRL serial number of the PKI CS.
CRL-serial-number
Command Default The CRL is not queried and no CRL cache parameters are configured.
Command Modes Certificate server configuration (cs-server)
Command History ModificationRelease
This command was introduced.12.3(4)T
Usage Guidelines You must configure the crypto pki server command with the name of the certificate server in order to enter
certificate server configuration mode and configure this command.
The crl command is used with the CRL-serial-number argument to identify the serial number of the PKI CS.
If the crl command is entered without this argument, then PKI hexmode is entered. In this mode, the hexidecimal
data can be specified for the CS so that it can be appended to the parse buffer.
To exit this mode and return to global configuration mode, use the quit command.Note
Examples Router(config)# crypto pki server CA
Router(ca-server)# crl 0x0-0xFFFFFFFF
Related Commands DescriptionCommand
Enables the automated CA
certificate rollover functionality.
auto-rollover
Cisco IOS Security Command Reference: Commands A to C
107
clear ip access-list counters through crl-cache none
crl (cs-server)
DescriptionCommand
Specifies a CDP to be used in
certificates that are issued by the
certificate server.
cdp-url
Enables a CS and enters certificate
server configuration mode, or
immediately generates shadow CA
credentials
crypto pki server
Specifies the CA certificate and CA
key archive format--and the
password--to encrypt this CA
certificate and CA key archive file.
database archive
Controls what type of data is stored
in the certificate enrollment
database.
database level
Specifies the location where
database entries for the CS is stored
or published.
database url
Specifies the requirement of a
username or password to be issued
when accessing the primary
database location.
database username
Resets the value of the CS
configuration command to its
default.
default (cs-server)
Enables automatic granting of
certificate reenrollment requests
for a Cisco IOS subordinate CA
server or RA mode CA.
grant auto rollover
Specifies the CA trustpoint of
another vendor from which the
Cisco IOS certificate server
automatically grants certificate
enrollment requests.
grant auto trustpoint
Specifies all certificate requests to
be rejected.
grant none
Specifies that all enrollment
requests from an RA be granted
automatically.
grant ra-auto
Cisco IOS Security Command Reference: Commands A to C
108
clear ip access-list counters through crl-cache none
crl (cs-server)
DescriptionCommand
Specifies the cryptographic hash
function the Cisco IOS certificate
server uses to sign certificates
issued by the CA.
hash (cs-server)
Specifies the DN as the CA issuer
name for the CS.
issuer-name
Specifies the lifetime of the CA or
a certificate.
lifetime (cs-server)
Enters the PKI server into RA
certificate server mode.
mode ra
Enters the PKI server into
sub-certificate server mode
mode sub-cs
Specifies that the active CS is
synchronized to the standby CS.
redundancy (cs-server)
Specifies whether the router serial
number should be included in the
certificate request.
serial-number (cs-server)
Displays the PKI CS configuration.show (cs-server)
Allows a CS to be disabled without
removing the configuration.
shutdown (cs-server)
Cisco IOS Security Command Reference: Commands A to C
109
clear ip access-list counters through crl-cache none
crl (cs-server)
crl query
To query the certificate revocation list (CRL) to ensure that the certificate of the peer has not been revoked,
use the crl query command in ca-trustpoint configuration mode. To return to the default behavior in which
the router checks the URL that is embedded in the certificate, use the no form of this command.
crl query ldap://url:[port]
no crl query
Syntax Description The Lightweight Directory Access Protocol (LDAP)
URL published by the certification authority (CA)
server to query the CRL; for example,
ldap://another_server.
If a port number is not specified, then the
default LDAP server port 389 is used.
The URL can be the LDAP server hostname,
IPv4 address.
Note
ldap://url:[port]
Command Default The CRL is not queried.
Command Modes Ca-trustpoint configuration
Command History ModificationRelease
This command was introduced.12.2(1)T
This command was integrated into Cisco IOS Release 12.2(18)SXD.12.2(18)SXD
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
Usage Guidelines The crl query command is disabled, the router checks the CRL distribution point (CDP) that is embedded
in the certificate. The crl query command does not need to be configured if the CDP that is in the certificate
is formatted as a URL (for example, http://url or ldap://url, including the fully qualified domain name (FQDN)
of the host where the CRL is held.
The crl query command is used if the CDP is in LDAP form, which means that the CDP location in the
certificate indicates only where the CDP is located in the directory; that is, the CDP does not indicate the
actual query location for the directory.
When Cisco IOS software tries to verify a peer certificate (for example, during Internet Key Exchange [IKE]
or Secure Sockets Layer [SSL] handshake), it queries the CRL to ensure that the certificate has not been
Cisco IOS Security Command Reference: Commands A to C
110
clear ip access-list counters through crl-cache none
crl query
revoked. To locate the CRL, it first looks for the CDP extension in the certificate. If the extension exists, it
is used to download the CRL. Otherwise, the Simple Certificate Enrollment Protocol (SCEP) GetCRL
mechanism is used to query the CRL from the CA server directly (some CA servers do not support this
method).
Cisco IOS software supports the following CDP entries:
•HTTP URL with a hostname. For example: http://myurlname/myca.crl)
•HTTP URL with an IPv4 address. For example: http://10.10.10.10:81/myca.crl
•LDAP URL with a hostname. For example: ldap:///CN=myca, O=cisco)
•LDAP URL with an IPv4 address. For example: ldap://10.10.10.10:3899/CN=myca, O=cisco
•LDAP/X.500 DN. For example: CN=myca, O=cisco
To locate the CRL, a complete URL needs to be formed. The ldap:// hostname:[port] keywords and arguments
are used to provide this information.
The crypto ca trustpoint command replaces the crypto ca identity and crypto ca trusted-root commands
and all related commands (all ca-identity and trusted-root configuration mode commands). If you enter a
ca-identity or trusted-root command, the configuration mode and command is written back as ca-trustpoint.
Note
The crypto ca trustpoint command deprecates the crypto ca identity and crypto ca trusted-root
commands and all related commands (all ca-identity and trusted-root configuration mode commands).
Note
Examples The following example shows how to configure your router to query the CRL with the LDAP URL that is
published by the CA named “bar”:
crypto ca trustpoint mytp
enrollment url http://bar.cisco.com
crl query ldap://bar.cisco.com:3899
Related Commands DescriptionCommand
Declares the CA that your router should use.crypto ca trustpoint
Specifies the enrollment parameters of a CA.enrollment url (ca-trustpoint)
Specifies the URL of an OCSP server to override the
OCSP server URL (if one exists) in the AIA extension
of the certificate.
ocsp url
Checks the revocation status of a certificate.revocation-check
Cisco IOS Security Command Reference: Commands A to C
111
clear ip access-list counters through crl-cache none
crl query
crl best-effort
Effective with Cisco IOS Release 12.3(2)T, this command was replaced by the revocation-check command.Note
To download the certificate revocation list (CRL) but accept certificates if the CRL is not available, use the
crl best-effortcommand in ca-identity configuration mode. To return to the default behavior in which CRL
checking is mandatory before your router can accept a certificate, use the no form of this command.
Syntax Description This command has no arguments or keywords.
Command Default If this command is not configured, CRL checking is mandatory before your router can accept a certificate.
That is, if CRL downloading is attempted and it fails, the certificate will be considered invalid and will be
rejected.
Command Modes Ca-identity configuration
Command History ModificationRelease
This command was introduced.12.2(8)T
This command was replaced by the revocation-check command.12.3(2)T
Usage Guidelines When your router receives a certificate from a peer, it will search its memory for the appropriate CRL. If the
appropriate CRL is in the router memory, the CRL will be used. Otherwise, the router will download the CRL
from either the certificate authority (CA) or from a CRL distribution point (CDP) as designated in the certificate
of the peer. Your router will then check the CRL to ensure that the certificate that the peer sent has not been
revoked. (If the certificate appears on the CRL, your router will not accept the certificate and will not
authenticate the peer.)
When a CA system uses multiple CRLs, the certificate of the peer will indicate which CRL applies in its CDP
extension and should be downloaded by your router.
If your router does not have the applicable CRL in memory and is unable to obtain one, your router will reject
the certificate of the peer--unless you include the crl best-effort command in your configuration. When the
crl best-effort command is configured, your router will try to obtain a CRL, but if it cannot obtain a CRL, it
will treat the certificate of the peer as not revoked.
When your router receives additional certificates from peers, the router will continue to attempt to download
the appropriate CRL if it was previously unsuccessful. The crl best-effort command specifies only that when
the router cannot obtain the CRL, the router will not be forced to reject the certificate of a peer.
Cisco IOS Security Command Reference: Commands A to C
112
clear ip access-list counters through crl-cache none
crl best-effort
Examples The following configuration example declares a CA and permits your router to accept certificates when CRLs
are not obtainable:
crypto ca identity myid
enrollment url http://mycaserver
crl best-effort
Related Commands DescriptionCommand
Declares the CA your router should use.crypto ca identity
Cisco IOS Security Command Reference: Commands A to C
113
clear ip access-list counters through crl-cache none
crl best-effort
crl optional
Effective with Cisco IOS Release 12.3(2)T, this command was replaced by the revocation-check command.Note
To allow the certificates of other peers to be accepted without trying to obtain the appropriate CRL, use the
crl optional command in ca-identity configuration mode. To return to the default behavior in which CRL
checking is mandatory before your router can accept a certificate, use the no form of this command.
crl optional
no crl optional
Syntax Description This command has no arguments or keywords.
Command Default The router must have and check the appropriate CRL before accepting the certificate of another IP Security
peer.
Command Modes Ca-identity configuration
Command History ModificationRelease
This command was introduced.11.3 T
This command was replaced by the revocation-check command.12.3(2)T
This command was integrated into Cisco IOS Release 12.2(33)SRA.12.2(33)SRA
This command is supported in the Cisco IOS Release 12.2SX train. Support
in a specific 12.2SX release of this train depends on your feature set, platform,
and platform hardware.
12.2SX
Usage Guidelines When your router receives a certificate from a peer, it will search its memory for the appropriate CRL. If the
router finds the appropriate CRL, that CRL will be used. Otherwise, the router will download the CRL from
either the certificate authority (CA) or from a CRL distribution point (CDP) as designated in the certificate
of the peer. Your router will then check the CRL to ensure that the certificate that the peer sent has not been
revoked. (If the certificate appears on the CRL, your router will not accept the certificate and will not
authenticate the peer.) To instruct the router not to download the CRL and treat the certificate as not revoked,
use the crl optional command.
Cisco IOS Security Command Reference: Commands A to C
114
clear ip access-list counters through crl-cache none
crl optional
If the CRL already exists in the memory (for example, by using the crypto ca crl request command to
manually download the CRL), the CRL will still be checked even if the crl optional command is configured.
Note
Examples The following example declares a CA and permits your router to accept certificates without trying to obtain
a CRL. This example also specifies a nonstandard retry period and retry count.
crypto ca identity myca
enrollment url http://ca_server
enrollment retry-period 20
enrollment retry-count 100
crl optional
Related Commands DescriptionCommand
Declares the CA your router should use.crypto ca identity
Cisco IOS Security Command Reference: Commands A to C
115
clear ip access-list counters through crl-cache none
crl optional
crl-cache delete-after
To configure the maximum time a router will cache a certificate revocation list (CRL), use the crl-cache
delete-after command in ca-trustpoint configuration mode. To enable default CRL caching, use the no form
of this command.
crl-cache delete-after time
no crl-cache delete-after time
Syntax Description The maximum lifetime of a CRL in minutes.
time
Command Default A CRL is deleted from the cache when the CRL default lifetime expires.
Command Modes Ca-trustpoint configuration (ca-trustpoint)
Command History ModificationRelease
This command was introduced.12.4(9)T
This command was implemented on the Cisco ASR 1000 series
routers.
Cisco IOS XE Release 2.4
Usage Guidelines Use this command to limit the amount of time a router will cache a CRL. You may use the crl-cache
delete-after command to force a router to download a CRL before the existing CRL expires by configuring
a value shorter than the default lifetime of the CRL.
By default, a new CRL will be downloaded after the currently cached CRL expires. The crl-cache delete-after
command does not effect any currently cached CRLs. The configured lifetime will only effect CRLs downloaded
after this command is configured.
When the maximum CRL time expires, the cached CRL will be deleted from the router cache. A new copy
of the CRL will be downloaded from the issuing certificate authority (CA) the next time the router has to
validate a certificate.
Only the crl-cache none command or the crl-cache delete-after command may be specified. If both
commands are entered for a trustpoint, the last command executed will take effect and a message will be
displayed to the user.
Note
Cisco IOS Security Command Reference: Commands A to C
116
clear ip access-list counters through crl-cache none
crl-cache delete-after
Examples The following example shows how to configure a maximum lifetime of 2 minutes for all CRLs associated
with the CA1 trustpoint:
crypto pki trustpoint CA1
enrollment url http://CA1:80
ip-address FastEthernet0/0
crl query ldap://ldap_CA1
revocation-check crl
crl-cache delete-after 2
The current CRL is still cached immediately after executing the example configuration shown above:
Router# show crypto pki crls
CRL Issuer Name:
cn=name Cert Manager,ou=pki,o=company.com,c=US
LastUpdate: 18:57:42 GMT Nov 26 2005
NextUpdate: 22:57:42 GMT Nov 26 2005
Retrieved from CRL Distribution Point:
ldap://ldap.company.com/CN=name Cert Manager,O=company.com
When the current CRL expires, a new CRL is then downloaded to the router at the NextUpdate
time and the crl-cache delete-after
command takes effect. This newly cached CRL and all subsequent CRLs will be deleted after
a maximum lifetime of 2 minutes.
You can verify that the CRL will be cached for 2 minutes by executing the show crypto pki
crls
command. Note that the NextUpdate time is 2 minutes after the LastUpdate time.
Router# show crypto pki crls
CRL Issuer Name:
cn=name Cert Manager,ou=pki,o=company.com,c=US
LastUpdate: 22:57:42 GMT Nov 26 2005
NextUpdate: 22:59:42 GMT Nov 26 2005
Retrieved from CRL Distribution Point:
ldap://ldap.company.com/CN=name Cert Manager,O=company.com
Related Commands DescriptionCommand
Disables CRL caching.crl-cache none
Cisco IOS Security Command Reference: Commands A to C
117
clear ip access-list counters through crl-cache none
crl-cache delete-after
crl-cache none
To disable certificate revocation list (CRL) caching, use the crl-cache none command in ca-trustpoint
configuration mode. To enable default CRL caching, use the no form of this command.
crl-cache none
no crl-cache none
Syntax Description This command has no arguments or keywords.
Command Default CRL caching is enabled.
Command Modes Ca-trustpoint configuration (ca-trustpoint)
Command History ModificationRelease
This command was introduced.12.4(9)T
This command was implemented on the Cisco ASR 1000 series
routers.
Cisco IOS XE Release 2.4
Usage Guidelines Use this command to disable CRL caching for all CRLs associated with a trustpoint. By default, a new CRL
is issued when the currently cached CRL expires.
The crl-cache none command does not effect any currently cached CRLs. All CRLs downloaded after this
command is configured will not be cached.
This functionality is useful is when a certification authority (CA) issues CRLs with no expiration date or with
expiration dates far into the future-days or weeks.
Only the crl-cache none command or the crl-cache delete-after command may be specified. If both
commands are entered for a trustpoint, the last command executed will take effect and a message will be
displayed.
Note
Examples The following example shows how to disable CRL caching for all CRLs associated with the CA1 trustpoint:
crypto pki trustpoint CA1
enrollment url http://CA1:80
ip-address FastEthernet0/0
crl query ldap://ldap_CA1
revocation-check crl
crl-cache none
Cisco IOS Security Command Reference: Commands A to C
118
clear ip access-list counters through crl-cache none
crl-cache none
The current CRL is still cached immediately after executing the example configuration shown above:
Router# show crypto pki crls
CRL Issuer Name:
cn=name Cert Manager,ou=pki,o=company.com,c=US
LastUpdate: 18:57:42 GMT Nov 26 2005
NextUpdate: 22:57:42 GMT Nov 26 2005
Retrieved from CRL Distribution Point:
ldap://ldap.company.com/CN=name Cert Manager,O=company.com
When the current CRL expires, a new CRL is then downloaded to the router at the NextUpdate time. The
crl-cache nonecommand takes effect and all CRLs for the trustpoint are no longer cached; caching is disabled.
You can verify that no CRL is cached by executing the show crypto pki crls command. No output will be
shown because there are no CRLs cached.
Related Commands DescriptionCommand
Configures the maximum lifetime of a CRL.crl-cache delete-after
Cisco IOS Security Command Reference: Commands A to C
119
clear ip access-list counters through crl-cache none
crl-cache none
Cisco IOS Security Command Reference: Commands A to C
120
clear ip access-list counters through crl-cache none
crl-cache none

Navigation menu
