A Space-saving Document Solution
for Busy Workgroups
AR-5731 / AR-5726
Digital Multifunctional System
Optional Job
SeparatorMax 31/26 PPM
AR-5731 / AR-5726 - A Space-saving Document Solution
A3 printing and copying plus a compact,
productive inner finisher option
The new Sharp AR-5731 and AR-5726 have more
than enough power and performance to satisfy the
demands of any small office or busy workgroup.
Capable of copying and printing at speeds of up to
31 and 26 pages a minute respectively, and supplied
with advanced productivity features, including
automatic double-sided printing and Sharp Printer
Language with Compression (SPLC) as standard for
faster data transfer, these MFPs are an ideal choice
for every modern office.
Complex jobs can be handled with ease, thanks to
a generous paper capacity, a handy 8.1-inch touch
screen LCD panel, powerful productivity tools and
the innovative space-saving inner finisher option for
automatic sorting, stapling and offset stacking.
An optional 100-sheet Reversing Single Pass Feeder
offers effortless two-sided copying, there’s a Job
Build function for scanning documents in convenient
batches before combining them into a single job, and
a whole range of powerful image editing functions
for even more control and versatility.
Designed with the environment in mind
The compact and contemporary design makes these new MFPs a
perfect choice for any modern office. And both machines have
impeccable environmental credentials and comply with the latest
Energy Star Version 1.1 criteria.
Space-saving
Inner Finisher
Up to
2,100-sheet
capacity
for Busy Workgroups
AR-5731 / AR-5726 - Key Features
Efficient copying
• Speedyoutputofmax.31/26cpmand
fast first copy time of 4.5/4.8 seconds
• Compactinnernisheroptionsortsand
staples documents
• Optional100-sheetReversingSinglePass
Feeder and built-in stackless duplex
module for efficient two-sided copying
• ElectronicSortingautomaticallycollates
multiple sets of copies in page order
without the aid of a sorter
• Versatileeditingfunctionsincludecard
shot, dual page copy, multi shot, and
edge/centre erase, and B&W reverse
• JobBuildfunctionforlarge-volume
documents
High-Quality Printing
• SharpPrinterLanguagewith
Compression (SPLC) speeds up the data
transfer time and printing process
• RIPOnce/PrintManyfunctionforefcient
printing of max. 31/26 ppm
• 600dpiresolution;canbeenhancedtoa
resolution equivalent to 1,200 dpi (with
digital smoothing technology)
• Convenientprintfunctionsinclude
duplex print, N-up, fit to page,
and watermarks
User- and environmentally-friendly
• Large,8.1-inchtouch-screenLCD
control panel
• Standard1,100-sheetpapercapacity,
expandable to max. 2,100 sheets
• JobSeparator(option)outputscopies
and printouts onto separate trays
• CertiedforlatestversionofEnergyStar
Version 1.1
Specifications
Design and specifications are subject to change without prior notice. All information was correct at time of print.
The ENERGY STAR logo is a certification mark and may only be used to certify specific products that have been
determined to meet the ENERGY STAR programme requirements. ENERGY STAR is a US registered mark. Windows,
Windows XP, Windows Server and Windows Vista are registered trademarks of Microsoft Corporation. ©Sharp
Corporation 2009 Ref: BR_AR-5731/5726. All trademarks acknowledged. E&OE
General
Engine speed (max.) A4 portrait A3
AR-5731 31 cpm/ppm 17 cpm/ppm
AR-5726 26 cpm/ppm 15 cpm/ppm
Paper size Max. A3, min. A5
Paper weight Drawer: 56g/m2 – 105g/m2
Bypass: 56g/m2 – 200 g/m2
Paper capacity Standard: 1,100 sheets
(2 x 500-sheet drawers and 100-sheet multi-bypass tray)
Maximum: 2,100 sheets
(4 x 500-sheet drawers and 100-sheet multi-bypass tray)
Warm-up time*1
AR-5731 25 sec. or less
AR-5726 23 sec. or less
Memory Standard: 32MB
Maximum: 1,056MB
Power requirements Rated local AC voltage ±10%, 50/60 Hz
Power consumption (max.) 1.45 kW (220 to 240V)
Dimensions*2 (W x D x H) 623 x 628 x 653 mm
Weight*2 (approx.) 46 kg
Copier
Original paper size Max. A3
First copy time*3
AR-5731 4.5 sec.
AR-5726 4.8 sec.
Continuous copy Max. 999 copies
Resolution Scan: 400 x 600 dpi
Print: 600 x 600 dpi
Gradation Scan: 256 levels Print: 2 levels
Zoom range 25 to 400% (50 to 200% using RSPF) in 1% increments
Preset copy ratios 10 ratios (5R/5E)
Printer (standard SPLC driver)
Resolution 600 x 600 dpi
Enhanced resolution 600 x 1,200 dpi equivalent with smoothing
Memory Shared
Interface USB 2.0
Supported OS Windows® 2000/XP, Windows Vista®, Windows 7*4
PDL Emulation SPLC (Sharp Printer Language with Compression)
AR-5731 / AR-5726
Digital Multifunctional System
AR-5731/AR-5726
Options
1. MX-FN13 Inner Finisher
A3 to A5
Paper capacity:
500 sheets (A4, 80 g/m2),
250 sheets (A3, 80 g/m2)
Stapling capacity:
50 Sheets (A4), 30 sheets (A3)
Staple position: 1 location
2. MX-TR11 Job Separator Tray
Separates output according to
the type of job (print/copy)
A3 to A5
Paper capacity:
Upper tray: 100 sheets
Lower tray (MFP): 500 sheet
3. MX-VR10 Document Cover
4. MX-RP10 Reversing Single
Pass Feeder
A3 to A5, 100 sheets (90 g/m2),
35 to 128 g/m2 (simplex),
52 to 105 g/m2 (duplex)
5. MX-TE10 Exit Tray
A3 to B5R, 100 sheets,
56 to 105 g/m2
Optional MX-FN13 required
6. MX-DE10 500-Sheet Paper
Drawer
A3 to B5R, 500 sheets (80 g/m2),
56 to 105 g/m2
7. MX-DE11 2 x 500-Sheet
Paper Drawer
A3 to B5R, 1,000 sheets
(80 g/m2), 56 to 105 g/m2
8. Cabinet
There are two cabinets available,
depending upon the paper
drawer configuration used.
MX-DS11 High cabinet
MX-DS12 Low cabinet
AR-SM5 256MB Memory
AR-SM6 512MB Memory
3. MX-VR10
1. MX-FN13
2. MX-TR11
6. MX-DE10 7. MX-DE11
8. MX-DS11 8. MX-DS12
4. MX-RP10
5. MX-TE10
Shown with options.
628 mm
1,103 mm
623 mm
*1 At rated voltage. May vary depending on machine conditions and operating environment.
*2 Dimensions and weight do not include document cover or RSPF.
*3 Best achieved time based on A4 copy, long-edge feeding from 1st paper drawer, using document glass,
when machine is ready. May vary depending on machine conditions and operating environment.
*4 Available at a later date.
