64/65
APARTMENT
STATIONS
1740/83 YES NO NO NO NO
1740/954 NO NO NO NO YES
1740/95 NO YES NO NO NO
1740/90 NO NO YES NO NO
1740/955 NO NO NO YES NO
1740/86 NO NO YES NO NO
1083/96 YES NO NO NO NO
BRACKET-LESS VIDEO DOOR PHONES COMPATIBLE WITH ALL SYSTEMS
VIDEOCITOFONI SENZA STAFFA COMPATIBILI SU TUTTI I SISTEMI
1740/40* 225 x 205 x 50 White
1740/41* 225 x 205 x 50 Anthracite
1740/42* 225 x 205 x 50 Platinum
1740/1 225 x 205 x 50 White B/W
1740/18 225 x 205 x 50 White B/W - As 1740/1 but for 60Hz
1740/20 225 x 205 x 50 White Signo video door phone retrot
version.
CODE DIMENSIONS COLOUR VERSION
(HxWxD) mm
VIDEO DOOR PHONE WITH 2VOICE SYSTEM BRACKET
1740/753 225 x 205 x 50 White
1740/713 225 x 205 x 50 White
B/W
CODE DIMENSIONS COLOUR VERSION
(HxWxD) mm
Colour
SYSTEM BRACKETS
CODE FEATURES
2 VOICE
IPERVOICE
COAX
5 WIRES
BIBUS VOP
Ready for oor call connection
Bracket with button add-on consisting of six buttons for
intercom service and two LEDs for indicating system state:
door open (red LED) and call transfer (green LED). White.
Dimensions (W x H x D) mm 246 x 225 x 50.
Add-on to be combined with the 2Voice bracket.
For managing intercom calls. White.
1740/1
1740/40
1740/41
1740/42
1740/86
COD. 1740
* For 50 and 60 Hz systems.
COD. 1140
/65
CODE DIMENSIONS
(HxWxD) mm FEATURES
2 VOICE
IPERVOICE
4+N
BIBUS VOP
225 x 85 x 42 NO NO YES
225 x 85 x 42 NO NO YES
225 x 85 x 42 NO NO YES
225 x 106 x 42 NO NO YES
225 x 85 x 42 NO YES NO
225 x 85 x 42 YES NO NO
225 x 85 x 42 NO NO NO
225 x 85 x 42 NO NO NO
NO
NO
NO
NO
NO
NO
YES
YES
1140/1
1140/41
1140/42
1140/12
1139/2
1183/2
1172/50
1172/55
DOOR PHONES FOR SYSTEMS
Door phone set up with three supplementary buttons,
of which one is already available. White.
Door phone with three supplementary buttons. Anthracite.
Door phone with three supplementary buttons. Platinum.
Door phone with 10 supplementary buttons for intercom
calls. White.
Provided with three supplementary buttons.
Provided with door opener button and 3 supplementary
buttons.
Door phone with two supplementary buttons for calling the
switchboard and switching on staircase lights. White.
Door phone with three supplementary buttons,
call adjustment, oor call, 6 selectable ring tones
and LEDs for indicating door open conditions. White.
1140/1 1140/41
1140/42 1140/12
1740/92
1740/92 Transparent Plexiglas table stand kit for Signo video door phone
With socket and 1,5m long wire, for use with brackets without button add-on.
Dimensions (W x H x D) mm 152 x 222 x 185.
1740/93 Transparent Plexiglas table stand kit for Signo video door phone with add-on
With socket and 1,5m long wire, for use with brackets with button add-on.
Dimensions (W x H x D) mm 152 x 222 x 190.
1140/50 Transparent Plexiglas table stand kit for Signo video door phone with socket and 1.5 m wire
Provided with socket and 1.5m wire. Dimensions (W x H x D) mm 200 x 95 x 158.
1140/51 Transparent Plexiglas table stand kit for Signo door phone with button add-on 1140/12
Provided with socket and 1.5m wire.
Dimensions (W x H x D) mm 200 x 110 x 158.
1140/56 Mute button kit and two LEDs for door phone
This is used to transfer the call to a second device, to check if the entrance door
is open and to automatically open a lock after receiving a call.
1140/53 Adjustable calling volume kit for Signo door phone
Insert in door phone to adjust calling volume intensity to three positions:
min, medium, max.
1140/55 8-button add-on kit for door phone
For use with door phones ready for tting supplementary buttons. White colour.
9854/56 Additional electronic buzzer for Signo video door phone
Installed on monitor bracket, it acts as an additional chime to differentiate calls.
Power supply: 12 Vdc; current draw during call 60 mA.
9854/55 Supplementary electronic buzzer for Signo door phone
Fitted inside the door phone, can be used as supplementary ringer
for differentiating calls. Power: 12Vcc; calling consumption 60mA.
SIGNO DOOR PHONE AND VIDEO DOOR PHONE ACCESSORIES
APARTMENT
STATIONS
