SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-1

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

1234F

NEEDLE & SEAT

WASHER

45F

PUMP BODY

GASKET

93F

PUMP INJECTOR

SUPPORT GASKET

26F

BANJO UNION

WASHER

11F

BANJO UNION

BOLT WASHER

G365

STEP-UP JET

WASHER

2F

NEEDLE & SEAT

WASHER

397F

INLET FITTING

WASHER

824F

FUEL VALVE

WASHER

58F

BOWL COVER

GASKET

68F

THROTTLE CHAMBER

GASKET

219F

PUMP DIAPHRAGM

ASSEMBLY

35F

PUMP DIAPHRAGM

140F

BOWL COVER

GASKET

49F

FLANGE GASKET

ID .469 OD .874ID .484 OD .721

.032

THK.

.031

THK.

.032

THK.

.045

THK.

.032

THK.

.032

THK.

.032

THK.

ID .404 OD .554 ID .444 OD .584 ID .405 OD .490ID .369 OD .516ID .174 OD .310

KIT #15245

114F

AIR VALVE

DIAPHRAGM ASSEMBLY

31-216

NEEDLE & SEAT

ASSEMBLY

2.0 MM

ORIFICE

SEE KIT CATALOG FOR

SPECIFIC APPLICATIONS

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-2 WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

242F

THROTTLE BODY

GASKET

241F

BOWL COVER

GASKET

206F

FLANGE GASKET

243F

THERMOSTATIC

HOUSING GASKET

245F

MAIN JET

PLUG WASHER

G80

POWER JET

WASHER

.032

THK.

.032

THK.

ID .409 OD .577ID .446 OD .573

KIT #15280

246F

PLUNGER DIAPHRAGM

ASSEMBLY

31-214

NEEDLE & SEAT

ASSEMBLY

1.2 MM

ORIFICE

VOLKSWAGEN (4 cyl)........1967-64

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-3

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

279F

FLOAT PIN

RETAINER

923F

IDLE SHUT-OFF

SOLENOID WASHER

G275

FUEL VALVE

SEAT O-RING

705F

IDLE NEEDLE

SEAL O-RING

62-58

ROD RETAINER

32-11

COTTER PIN

942F

NYLON SCREW

SEALING PLUG

397F

INLET FITTING

WASHER

1234F

NEEDLE & SEAT

WASHER

265F

BOWL COVER

GASKET

283F

BOWL COVER

GASKET

.070

THK.

.063

THK. .020

THK.

ID .444 OD .584ID .404 OD .554

.031

THK.

.032

THK.

ID .412 OD .539

ID .364ID .092

52F

FLANGE GASKET

284F

FLANGE GASKET

285F

BOWL COVER GASKET

270F

BOWL COVER GASKET

KIT #15282C

260F

PLUNGER DIAPHRAGM

ASSEMBLY

239F

VACUUM DIAPHRAGM

ASSEMBLY

31-217

NEEDLE & SEAT

ASSEMBLY

1.5 MM

ORIFICE

VOLKSWAGEN (4 cyl)........1974-61

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-4 WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

562F

STAT COVER

GASKET

250F

MAIN NOZZLE

WASHER

563F

BOWL COVER

GASKET

248F

THROTTLE BODY

GASKET

49F

FLANGE GASKET

245F

MAIN JET

PLUG WASHER

.032

THK.

.032

THK.

ID .408 OD .566ID .328 OD .459

KIT #15434

433F

PLUNGER DIAPHRAGM

ASSEMBLY

31-217

NEEDLE & SEAT

ASSEMBLY

1.5 MM

ORIFICE

OPEL (4 cyl)........1971-65

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-5

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

.053

THK.

16-38F

IDLE ADJUSTING

SCREW

483F

NOZZLE TUBE

O-RING

G97-1

THERMOSTATIC

HOUSING GASKET

587F

HOT IDLE

COMPENSATOR GASKET

421F

ENRICHMENT BODY

GASKET

393F

BOWL COVER

GASKET

635F

THROTTLE BODY

GASKET

292F

FLANGE GASKET

ID .187

KIT #15446A

430F

PUMP DIAPHRAGM

ASSEMBLY

741F

CHOKE DIAPHRAGM

ASSEMBLY

31-216

NEEDLE & SEAT

ASSEMBLY

2.0 MM

ORIFICE

OPEL (4 cyl)........1972-65

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-6 WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

G274

SECONDARY JET

TUBE O-RING

21F

FUEL INLET

FITTING WASHER

G935

PUMP DISCHARGE

NOZZLE O-RING

705F

IDLE NEEDLE

SEAL O-RING

453F

CHOKE DIAPHRAGM

ASSEMBLY

408F

FLOAT BOWL

GASKET

ID .145ID .092 ID .326 OD .459

.055

THK.

.070

THK.

.063

THK.

ID .208

KIT #15546

433F

PLUNGER DIAPHRAGM

ASSEMBLY

741F

CHOKE DIAPHRAGM

ASSEMBLY

31-216

NEEDLE & SEAT

ASSEMBLY

635F

THROTTLE BODY GASKET 292F

FLANGE GASKET

421F

ENRICHMENT BODY

GASKET

G97-1

THERMOSTATIC

HOUSING GASKET

2.0 MM

ORIFICE

.030

THK.

ID .165 OD .365

434F

POWER SYSTEM

VALVE WASHER

ID .171 OD .343

1065F

VACUUM PASSAGE

WASHER

.070

THK.

.017

THK.

OPEL (4 cyl)........1974-73

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-7

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

KIT #15552

245F

MAIN JET

PLUG WASHER

G275

FUEL VALVE

SEAT O-RING

G992

MAIN JET

O-RING

705F

IDLE NEEDLE

SEAL O-RING

G1129

IDLE CUT-OFF

VALVE SEAL WASHER

.063

THK. .070

THK.

ID .092 ID .364ID .228 ID .408 OD .566

.040

THK. .032

THK.

G97-1

THERMOSTATIC

HOUSING GASKET

587F

HOT IDLE

COMPENSATOR GASKET

588F

CHOKE HOUSING

GASKET

300F

BOWL COVER

GASKET

582F

THROTTLE BODY

GASKET

284F

FLANGE GASKET

206F

FLANGE GASKET

433F

PLUNGER DIAPHRAGM

ASSEMBLY

389F

VACUUM DIAPHRAGM

ASSEMBLY

31-214

NEEDLE & SEAT

ASSEMBLY

1.2 MM

ORIFICE

VOLKSWAGEN (4 cyl)........1974-72

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-8 WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

G654

PUMP DIAPHRAGM

NOZZLE WASHER

250F

MAIN NOZZLE

WASHER

245F

MAIN JET

PLUG WASHER

710F

CHOKE COVER

O-RING

475F

CHOKE DIAPHRAGM

GASKET

588F

CHOKE HOUSING

GASKET

G97-1

THERMOSTATIC

HOUSING GASKET

1323F

BOWL COVER

GASKET

388F

THROTTLE BODY

GASKET

G1134

FLANGE GASKET

G1398

MAIN JET

WASHER

ID .408 OD .566ID .328 OD .459

.032

THK.

.032

THK.

.032

THK.

.020

THK.

ID .251 OD .352 ID .216 OD .385

KIT #15570

260F

PLUNGER DIAPHRAGM

ASSEMBLY

31-216

NEEDLE & SEAT

ASSEMBLY

2.0 MM

ORIFICE

BMW (4 cyl)........1972-63

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-9

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

KIT #15571

705F

IDLE NEEDLE

SEAL O-RING

G274

SECONDARY JET

TUBE O-RING

G1158

PUMP DISCHARGE

NOZZLE WASHER

G935

PUMP DISCHARGE

NOZZLE O-RING

920F

CHANNEL PLUG

WASHER

G1115

THERMOSTATIC

HOUSING GASKET

917F

BOWL COVER

GASKET

292F

FLANGE GASKET 919F

FLANGE GASKET

.046

THK.

.070

THK.

.032

THK.

.070

THK.

.063

THK.

ID .092 ID .145 ID .199 OD .326 ID .208 ID .195 OD .313

294F

PUMP DIAPHRAGM

ASSEMBLY

31-603

NEEDLE & SEAT

ASSEMBLY

.032

THK.

ID .216 OD .385

709F

CHOKE CHAMBER

O-RING

G654

PUMP DIAPHRAGM

NOZZLE WASHER

21F

FUEL INLET

FITTING WASHER

.055

THK.

ID .326 OD .459

AUDI (4 cyl)........1973-70

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-10 WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

942F

PLASTIC SCREW

SEALING PLUG

705F

IDLE NEEDLE

SEAL O-RING

G274

SECONDARY JET

TUBE O-RING

1065F

VACUUM PASSAGE

WASHER

G654

PUMP DIAPHRAGM

NOZZLE WASHER

21F

FUEL INLET

FITTING WASHER

G275

FUEL VALVE

SEAT O-RING

1234F

NEEDLE SEAT

WASHER

709F

CHOKE CHAMBER

O-RING

G97-1

THERMOSTATIC

HOUSING GASKET

325F

VACUUM DIAPHRAGM

GASKET

503F

BOWL COVER

GASKET

706F

THROTTLE BODY

GASKET

292F

FLANGE GASKET

ID .171 OD .343 ID .326 OD .459

ID .092 ID .145

.055

THK.

.032

THK.

.017

THK.

.070

THK.

.063

THK.

ID .444 OD .584

ID .364

.031

THK.

.070

THK.

ID .216 OD .385

KIT #15572A

324F

PUMP DIAPHRAGM

ASSEMBLY

31-603

NEEDLE & SEAT

ASSEMBLY

AUDI (4 cyl).................1974-73

VOLKSWAGEN (4 cyl)........1974

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-11

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

KIT #15644A

279F

FLOAT PIN

RETAINER

ID .412 OD .539

ID .364ID .092

.020

THK.

.070

THK.

.063

THK.

302F

PUMP DIAPHRAGM

ASSEMBLY

239F

VACUUM DIAPHRAGM

ASSEMBLY

31-217

NEEDLE & SEAT

ASSEMBLY

241F

BOWL COVER GASKET 284F

FLANGE GASKET

285F

BOWL COVER GASKET

942F

PLASTIC SCREW

SEALING PLUG

705F

IDLE NEEDLE

SEAL O-RING

G275

FUEL VALVE

SEAT O-RING

923F

MAIN JET

PLUG WASHER

1.5 MM

ORIFICE

VOLKSWAGEN (4 cyl)........1974

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-12 WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

942F

PLASTIC SCREW

SEALING PLUG

705F

IDLE NEEDLE

SEAL O-RING

G274

SECONDARY JET

TUBE O-RING

1065F

VACUUM PASSAGE

WASHER

G654

PUMP DIAPHRAGM

NOZZLE WASHER

21F

FUEL INLET

FITTING WASHER

.017

THK.

.070

THK.

.080

THK. .032

THK.

ID .145ID .092

.055

THK.

.031

THK.

.070

THK.

ID .444 OD .584

ID .364

ID .216 OD .385 ID .326 OD .459ID .173 OD .344

433F

PLUNGER DIAPHRAGM

ASSEMBLY

31-603

NEEDLE & SEAT

ASSEMBLY

1067F

THROTTLE BODY

GASKET

292F

FLANGE GASKET

917F

BOWL COVER

GASKET

325F

VACUUM DIAPH.

GASKET

710F

CHOKE COVER

O-RING

243F

THERMOSTATIC

HOUSING GASKET

G275

FUEL VALVE

SEAT O-RING

1234F

NEEDLE SEAT

WASHER

609F

ALUM. BANJO

BOLT WASHER

ID .542 OD .673

.038

THK.

KIT #15646 BMW (4 cyl)........1974-73

SOLEX "APPLICATION"

REFERENCE

WALKER CARBURETOR

SOLEX-13

WALKER PRODUCTS INC. PHONE (323) 232-3359 FAX (323) 232-3332

KIT #15647

942F

PLASTIC SCREW

SEALING PLUG

705F

IDLE NEEDLE

SEAL O-RING

G274

SECONDARY JET

TUBE O-RING

1065F

VACUUM PASSAGE

WASHER

1234F

NEEDLE SEAT

WASHER

G243F

THERMOSTATIC

HOUSING GASKET

710F

CHOKE COVER

O-RING

325F

VACUUM DIAPH.

GASKET

G275

FUEL VALVE

SEAT O-RING

917F

BOWL COVER

GASKET

1067F

THROTTLE BODY

GASKET

292F

FLANGE GASKET

ID .444 OD .584

ID .364

G654

PUMP DIAPHRAGM

NOZZLE WASHER

21F

FUEL INLET

FITTING WASHER

ID .145

ID .092

.055

THK.

.032

THK.

.032

THK.

.070

THK.

.063

THK.

.031

THK.

.070

THK.

ID .326 OD .459ID .173 OD .385 ID .216 OD .385

260F

PLUNGER DIAPHRAGM

ASSEMBLY

31-603

NEEDLE & SEAT

ASSEMBLY

BMW (4 cyl)........1976-75
