A Publication of the

National Wildfire

Coordinating Group

Sponsored by

United States

Department of Agriculture

United States

Department of Interior

National Association of

State Foresters

SPARK ARRESTER

GUIDE

General Purpose and

Locomotive (GP/Loco)

Volume 1

Prepared by:

NWCG Fire Equipment

Working Team

PMS 430-1 MAY 2000

NATIONAL

WILDFIRE

DINAT

ING

NFES #1363

Additional copies of this publication may be ordered

by mail or FAX by sending a purchase order or requisition to:

NATIONAL INTERAGENCY FIRE CENTER

ATTN: Great Basin Cache Supply Office

3833 S. Development Ave.

Boise, ID 83705-5354

FAX: 208-387-5573

ORDER NFES #1363

You will be billed within 30 days of shipping.

When you receive your order,

discard the May 1998 Spark Arrester Guide

WE WANT YOUR COMMENTS....

We would like to know what you think of the Spark Arrester Guide.

Does it meet your needs?

What do you like best?

What needs to be improved?

How can these improvements be incorporated?

Your Name________________________________________________

Agency____________________________________________________

Address ___________________________________________________

Telephone No. ____________________________________________

PLEASE FOLD, STAPLE, STAMP AND MAIL

FOREST SERVICE—USDA

Technology & Development Center

444 East Bonita Avenue

San Dimas, CA 91773-3198

Attn: Spark Arrester Project Leader

The National Wildfire Coordinating Group (NWCG) had developed this information

for the guidance of cooperating Federal, State, and local agencies, and is not

responsible for the interpretation of this information by anyone except its member

agencies. The use of trade, firm, or corporation names in this publication is for the

information and convenience of the reader and does not constitute an endorsement

by the NWCG of any product or service to the exclusion of others that may be suitable.

SPARK ARRESTER

GUIDE

General Purpose and

Locomotive (GP/Loco)

Volume 1

Prepared by:

NWCG Fire Equipment Working Team

Foreword ...................................................... iii

General Instructions for Use of the Spark

Arrester Guide (SAG)...................................... v

Updates to the SAG........................................ v

Reprint Information ........................................ v

Basic Definitions and Test Standards............. vi

General Purpose Spark Arrester Inspection

Procedures .................................................... ix

Manufacturers Trademarks ............................. 1

Spark Arrester Brand Name/Manufacturer/

Address .......................................................... 2

2000 Qualified and Rated List—General

Purpose Spark Arresters.................................. 7

Engine Exhaust Flow Charts.......................... 53

GENERAL PURPOSE AND GENERAL PURPOSE

SCREEN TYPE SPARK ARESTERS

Acerbis......................................................... 58

Advanced Car Specialties............................. 59

AirMaze ....................................................... 60

Answer, J&R................................................. 61

A.P. Parts ..................................................... 62

Berkeley....................................................... 62

Bombardier/Bombardier-Krizman................. 62

Briggs & Stratton .......................................... 63

Burgess-Manning ......................................... 65

Cal Tube ...................................................... 67

Caterpillar .................................................... 67

CEDCO........................................................ 67

Chiyoda-Kinzoku Co., Ltd. ........................... 68

Clark ............................................................ 68

Cone ............................................................ 68

Coop............................................................ 69

Cycle Gear................................................... 70

Davis ........................................................... 70

Dometic....................................................... 71

Donaldson ................................................... 72

Echo............................................................. 79

ESS............................................................... 79

Farr .............................................................. 82

FMF ............................................................. 83

Forester ........................................................ 85

Fuji .............................................................. 85

Generac ....................................................... 89

Gill .............................................................. 92

Gilson .......................................................... 95

Gorman-Rupp .............................................. 95

Hale............................................................. 95

Hapco.......................................................... 96

Harley-Davidson........................................ 100

Harley-Davidson-Krizman.......................... 101

Hodaka ...................................................... 101

Honda........................................................ 102

Honda-Krizman ......................................... 115

Honda-Nelson ........................................... 122

Hooker....................................................... 123

Horstman ................................................... 124

Hutchins .................................................... 124

Husqvarna ................................................. 124

Husqvarna-Krizman ................................... 125

IHC ............................................................ 125

J&R Krizman .............................................. 126

John Deere................................................. 127

Kawasaki.................................................... 127

Kawasaki-Krizman ..................................... 131

Kerker ........................................................ 135

K.C.F.D. ..................................................... 135

Kittell ......................................................... 135

Kohler ........................................................ 137

Krizman ..................................................... 138

General Purpose and Locomotive

TABLE OF CONTENTS

KSI-WES-KRIZ ............................................ 138

KTM........................................................... 139

KTM Sportmotorcycle ................................ 139

Kubota ....................................................... 140

Magnum-Krizman ...................................... 142

Magnum Racing......................................... 142

Maremont .................................................. 142

Maxim ....................................................... 142

McCulloch ................................................. 143

Murphy ...................................................... 144

Nelson ....................................................... 144

Nelson-Burgess .......................................... 213

Onan ......................................................... 215

O&R .......................................................... 216

Pacific Pumpers ......................................... 216

PKM........................................................... 216

Polaris........................................................ 217

Powell........................................................ 223

Pro Circuit.................................................. 223

Reliable Industries...................................... 224

Riker .......................................................... 224

Rupp .......................................................... 225

Skyway ...................................................... 226

Skyway-Cobra............................................ 226

Soundmaster .............................................. 227

Sparester .................................................... 227

Stemco....................................................... 229

Strader ....................................................... 229

Super-Trapp ............................................... 230

Suzuki........................................................ 231

Suzuki-Krizman.......................................... 235

Suzuki-Sparester......................................... 237

Taylor ........................................................ 243

Tecumseh .................................................. 245

Teck........................................................... 248

Tillery ........................................................ 249

Toro ........................................................... 249

Torque ....................................................... 250

USDA FS.................................................... 250

Wacker ...................................................... 251

Wajax-Pacific............................................. 251

Walker ....................................................... 252

Washington Iron Works ............................. 252

White Brothers ........................................... 253

Wintec ....................................................... 253

Xducer ....................................................... 253

Yamaha...................................................... 253

Yamaha-Krizman ....................................... 260

Yamaha-Skyway......................................... 264

Yoshimura.................................................. 264

Yuba .......................................................... 264

LOCOMOTIVE-TYPE SPARK ARRESTERS

Standards for Locomotive-Type Spark

Arresters..................................................... 266

Locomotive-Type Spark Arrester Inspection

Procedures ................................................. 266

Inspection.......................................... 267

Identification Key............................... 267

Internal or Manifold-Type .......................... 267

Locomotive Spark Arresters Internal Spark

Arresters—Body Types ............................... 268

Locomotive Spark Arresters—Leg

Configurations............................................ 269

2000 Qualified List—Locomotive............... 271

2000 Locomotive Type Spark Arrester

Manufacturer List ....................................... 277

Helpful Hints ..............................................IBC

TABLE OF CONTENTS

General Purpose and Locomotive

iii

FOREWORD

In 1986 the National Wildfire Coordinating Group (NWCG) authorized the Fire Equipment

Working Team (FEWT) to establish a subcommittee to improve and update the Spark

Arrester Guide (SAG). The subcommittee reduced the size of the previous SAG and

redesigned it to improve its effectiveness and expand its applicability to more wildland

fire agencies and geographic regions. The SAG is published for the guidance of

cooperating Federal, State, and local agencies. Federal and State laws and administrative

requirements prescribe when and where spark arresters are required.

Appropriate Standards referenced in this SAG establish the minimum performance and

maintenance requirements of spark arresters for internal combustion engines to be

operated on or near grass, timber, brush, or other wildland fuels. During periods of very

high or extreme fire danger, spark arresters meeting these Standards will not give

complete protection against exhaust spark fires. Additional measures, including shutdown

of operations, may be required during such periods.

The U.S. Department of Agriculture maintains a spark arrester test facility at the Forest

Service, San Dimas Technology and Development Center, 444 East Bonita Avenue, San

Dimas, CA 91773. The camera-ready copy for the Spark Arrester Guide was produced

at the SDTDC for the NWCG by the following personnel:

Ralph Gonzales—Mechanical Engineer

Janie Ybarra—Visual Information Specialist

GENERAL PURPOSE SPARK ARRESTER

INSPECTION PROCEDURES

Standard 5100-1c requires that each arrester shall

be permanently marked with the model number

and the manufacturer’s name or trademark. The

model number must match exactly. The

identification must be stamped in the metal body

or on an attached metal plate. The words

“Qualified” or “Approved” are not required, and

do not indicate that the unit is in fact a qualified

arrester.

1. If identification of the manufacturer’s name

and model number is found, then refer to the

“Qualified and Rated” list.

2. Check the “Qualified and Rated” list to

establish if the arrester is qualified.

3. If not on the “Qualified and Rated” list, be

sure to check any SAG update information you

have received since the time of the printing of

your present SAG. The absence of an arrester

from these lists indicates that the arrester has not

been qualified.

4. After the arrester has been identified, turn to

the Drawing Section and check the spark arrester

illustration for an exact match on the

configuration, dimensions and cleanout devices.

The drawing must match the spark arrester you

are inspecting.

5. Suggested tools for inspections:

a. Handtools to open cleanout, screwdriver

and pliers.

b. Flashlight.

c. 1/8-inch wire rod or stick to probe inside

the arrester to determine if stationary fan

or vanes are in place.

d. Tape measure.

e. 0.024-inch wire gauge to determine

screen size.

6. Inspect to ensure that:

a. The spark arrester is correct for the

position of application.

b.The exhaust system between the engine

and the spark arrester is in good order.

c. The arrester is properly maintained and

cleaned out when necessary.

d. There are no modifications to the

exhaust system.

7. More detailed instructions are available in the

NWCG video, “Spark Arresters and the

Prevention of Wildland Fires".

8. Follow your agency policies when an

unqualified spark arrester system is encountered.

viii

Mufflers—Experience and tests have shown that

mufflers, in general, are inadequate as spark

arresters. Few muffler devices submitted for

formal tests meet the requirements of 5100-1c or

SAE J350. However, properly maintained

baffled mufflers constructed to automotive

industry standards, and installed on motor

vehicles other than motorcycles are accepted for

“on- highway” and “off-road” use in some

jurisdictions. Exceptions are for designated areas

where a spark arrester is required on cross-

country vehicles. Straight-through mufflers, such

as glass-pack designs without baffles, are not

acceptable. Consult your agency’s policy for

more specific guidelines.

Turbochargers qualify as effective spark

arresters when 100% of the exhaust gases pass

through the turbine wheel. The turbine wheel

must be turning at all times and there must be no

exhaust bypass to the atmosphere. Depending on

design, small enclosed system bypasses that

reroute some of the exhaust back through the

engine may be allowed. The illustration of the

exhaust-driven turbocharger shows the air intake

and the exhaust path through the turbine wheel.

The action of the rotating turbine wheel causes

carbon particles to remain within the confines of

the turbo-drive section until they are reduced to a

harmless size by attrition.

Superchargers, which are strictly mechanically

driven, do not qualify.

Exhaust System—The exhaust system consists

of the manifold (on multicylinder engines),

muffler or spark arrester or both, an exhaust pipe

between the engine cylinder exhaust outlet port,

and the end of the exhaust pipe which is open to

the atmosphere.

Exhaust Manifold—A chamber into which the

exhaust from each of the engine cylinders is

collected. The exhaust is then directed out of the

manifold to a muffler or spark arrester or both.

Most large locomotive engines have the spark

arrester designed into the exhaust manifold.

Small, single-cylinder engines do not have

manifolds.

Modification—Any modification or damage to

any part of the system as it was presented to

SDTDC for testing voids the qualifications of the

spark arrester on the equipment. Modifications

usually consist of removal of or damage to parts,

change in exhaust outlets, replacing the

fiberglass packing with steel wool, improper

mounting, and bypasses.

Follow your agency policies when a modified/

unqualified spark arrester system is encountered.

Air intake

Pressurized

oil line

Turbine

housing

Compressor

housing

Exhaust-driven Turbocharger

vii

The qualified positions listed include only those

tested. In some cases, the manufacturer may

claim other positions, but test information at this

time neither support or refute such claims. An

arrester tilted more than 60 degrees from its

qualified operating position may not adequately

arrest sparks. Therefore, arresters on mobile

equipment—other than screen type arresters—

shall not be mounted more than 45 degrees from

the qualified position. See column marked

“Appl Pos.”

Note that USDA Forest Service Standard 5100-

1c allows 60 degrees deviation, but at least 15

degrees should be reserved for deviations

because of road grade or slope.

(See illustration.)

Rated Flow of Arrester is the rate of test gas

flow in cubic feet per minute at which the

corresponding back pressure is 1 pound per

square inch. This is the maximum desirable back

pressure for most four-stroke cycle applications.

See column marked “Flow.” Note: General

Purpose Screen Type Spark Arresters are limited

to the listed rated flow, 2 or 4 cycle, and horse

power.

Some two-cylinder engines may require a higher

back pressure. An arrester may be used above its

rated flow—provided it maintains a qualifying

arresting effectiveness at all levels of use.

Arresters that do not have an adequate

effectiveness above their rated flow will be

designated in the “Remarks” column, and are not

qualified to operate in applications where they

may be ineffective. With this exception, a

qualified arrester properly installed and

maintained is acceptable legally regardless of

size or rated flow. It is the owner’s business if

he/she chooses an arrester too large or too small,

even though the cost may be excessive or the

back pressure too high.

Cleaning—The arrester shall have provision for

the easy disposal of the accumulated particles

without removal of the clamping or mounting

devices from the stack, pipe, or manifold

assembly. Screen-type devices shall provide for

the easy removal and cleaning or replacement of

the screen.

Marking and Labeling—Each arrester shall be

permanently marked with the manufacturer’s

model number designation and a trademark or

other identification of manufacturer. Where an

inverted installation is possible, the inlet or outlet

shall also be marked. In addition to the above

markings, screen-type devices must have the

words “Screen Type” clearly imprinted in 1/8-

inch or larger letters. The model number must

match exactly. The words “Qualified” or

“Approved” are not required, and do not

indicate that the unit is in fact a qualified arrester.

Discontinued Models will be called out under

“Remarks.”

3. Number of SAG updates which have been

issued.

4. Inventory at NIFC. Reprinting will be

done to meet supply and demand

requirements.

BASIC DEFINITIONS AND TEST

STANDARDS

Exhaust Particles—All internal combustion

engines produce exhaust particles which are

predominately carbon with contaminates. These

particles originate from deposits formed on the

internal surfaces of the engine or exhaust system

and, depending on their exact origin, may be

expelled at temperatures in excess of 3,000° F.

Depending on the nature of the contaminates,

these particles are capable of glowing or

sometimes flaming combustion. When expelled

through the exhaust system into the atmosphere,

the combustion process may continue oreven be

accelerated during flight. Such particles, if larger

than 0.023-inch in diameter and at temperatures

of 1,200° F are capable of igniting cellulose

materials upon contact.

A Spark Arrester is a device which traps or

pulverizes exhaust carbon particles to a size

below 0.023-inch in diameter, as they are

expelled from an exhaust system. Trap type

spark arresters must have a method for removal

of accumulated carbon particles. Most spark

arresters generally perform in the high 90 percent

spark arresting effectiveness range.

General Purpose Spark Arresters are tested

against USDA Forest Service Standard 5100-1c

or the latest revision of Society of Automotive

Engineers (SAE) Recommended Practice SAE

J350. Either of these documents establish the

minimum performance and maintenance

requirements of single-position application

general purpose spark arresters. Spark arresting

effectiveness shall be at least 80 percent for all

flow rates on the cold test which correlates to

90 percent on a hot engine.

Screen-Type Spark Arresters as defined by

USDA Forest Service Standard 5100-1c fall into

a special category. They are intended for use on

small engine applications. All exhaust products

must pass through the screen, which has

openings of 0.023-inch or less. The effective

exhaust area of the screen (total area of all

screen openings) shall not be less than 200

percent of the engine exhaust port area at its

smallest cross-section. Screen material shall be

heat and corrosion resistant, and shall provide at

least 100 hours of service life. These are

originally qualified for all the positions described

in the "Application Postions" section.

"Add-On" spark arresters are added onto an

existing muffler exhaust system. They are

typically used on Off-Highway-Vehicles. Add-

on spark arresters must have a method for

removal of accumulated carbon particles. Such

as a cleanout plug, snap ring, removable end cap

or a removable end cleanout. A removable end

cleanout is usually secured to the muffler by a

retaining band and/or several screws. In order to

empty out the accumulated carbon particles with

a removable end cleanout, the entire add-on must

be removed by loosening the retaining band or

screws, to shake out the carbon particles.

The retaining band or screw may not be replaced

by welding the removable end cleanout to the

existing muffler. This is considered a

modification and also does not allow for removal

of accumulated carbon particles. Any

modification to the spark arrester as compared to

the SAG line drawing in this SAG, voids

qualification.

Application Positions—Four general positions

are considered—vertical, horizontal, inverted,

and multiposition. The application is determined

by the attitude of the inlet pipe irrespective of the

main body position or direction of outlet. For

example:

GENERAL INSTRUCTIONS FOR USE OF

THE SPARK ARRESTER GUIDE (SAG)

The General Purpose and Locomotive (GP&L)

SAG is a compilation of information, lists, and

illustrations of qualified GP&L spark arrester

systems and engines—including their identifying

markings, design, and assembly.

The intent of the SAG is to provide field

inspectors with adequate information to

determine if an engine and exhaust system

combination have been tested and qualified by

the San Dimas Technology and Development

Center (SDTDC) as meeting the Standard for

spark arresting exhaust systems.

The SAG is printed as two publications. This

SAG covers General Purpose and Locomotive

(GP&L) arresters, and the other SAG covers

Multiposition Small Engine (MSE) arresters.

In each publication, there is a section for each

type of arrester with illustrations of spark

arresters listed in alphabetical order by the

manufacturer’s name, and lists of qualified and

rated spark arresters of that type. Inspectors can

use these sections to verify qualification status.

Specific instructions for use of each section

precedes the section.

Use of the SAG is also illustrated in the video

"Spark Arresters and the Prevention of Wildland

Fires" and may be used as a supplemental

instruction tool. The video contains five separate

modules titled, "Introduction, Multiposition

Small Engine, General Purpose, Off Highway,

and Railroad".

The two SAG publications and the video may be

ordered, by purchase order or requisition, from:

National Interagency Fire Center (NIFC)

Attn: Great Basin Cache, Supply Office

3833 S. Development Avenue

Boise, ID 83705

FAX: 208-387-5573

You will be billed within 30 days of shipping.

Order numbers are:

NFES 2363—Multiposition Small Engine Spark

Arrester Guide (MSE) Volume 2, June 1999.

NFES 1363—General Purpose and Locomotive

Spark Arrester Guide (GP/LOCO) Volume 1,

May 2000.

NFES 2237—Spark Arresters and the Prevention

of Wildland Fires, (video) May 1998

When you receive your order, discard the old

SAG's.

UPDATES TO THE SAG

Testing of newly submitted spark arresters is an

ongoing process at SDTDC. The Center will be

responsible for notifying SAG users of newly

qualified and rated spark arresters. SDTDC will

send the information to appropriate Regional and

State offices for their distribution. Users should

contact these sources for updated information.

SAG Updates are usually mailed in July &

December.

For quick reference, updates should be inserted

in the publication for the appropriate type

arrester. These new qualified arresters will be

included with illustrations when the Guides are

reprinted. (See section that follows.)

REPRINT INFORMATION

SDTDC will determine when adequate

information has been compiled to require a

reprinting of each publication. The Center will

notify the Regional and State offices when a

reprinting is available. It is anticipated that a

reprinting may be required on odd numbered

years for the Multiposition Small Engine (MSE)

Guide and on even numbered years for the

General Purpose and Locomotive (GP&L)

Guide.

SDTDC will include the following criteria in

their reprint decision:

1. Determination of usable life of the SAG.

2. Volume and complexity of questions

received from field users. Major users will

be contacted periodically for feedback.

TRADEMARKS USED FOR MANUFACTURER IDENTIFICAITON

SPARK ARRESTER BRAND NAME/MANUFACTURER/ADDRESS

ACERBIS PLASTICA, USA

9402 Wheatlands Ct., Suite A

Santee, CA 92071

ADVANCED CAR SPECIALTIES (ACS)

114 Railside Road

Toronto, Ontario, Canada

AIR-MAZE

Air-Maze Division, Rockwell Standard Corp.

25000 Miles Road

Cleveland, OH 44120

ANSWER (J&R), AN KRIZMAN

J&R Answer Products, Inc.

27460 Avenue Scott

Valencia, CA 91355

AP PARTS

AP Parts Company

1801 Spielbusch Ave.

Toledo, OH 43694

BERKELEY

Sta-Rite Industries

293 Wright Street

Delavan, WI 53115

BOMBARDIER-KRIZMAN

Bombardier Limited

Valcourt, Quebec

Canada J0E 2L0

BRIGGS & STRATTON

Briggs & Stratton Corp.

P. O. Box 702

Milwaukee, WI 53201

BURGESS-MANNING

Burgess-Manning, Inc., Silencing Division

227 Thorn Ave.,

Orchard Park, NY 14127

CAL TUBE

California Tube Products, Inc.

7040 Lankersheim Blvd.,

N. Hollywood, CA 91605

CATERPILLAR

Caterpillar Tractor Co.

Peoria, IL 61611

CEDCO

Hale Fire Pump Co.

700 Spring Mill Ave.

Conshohocken, PA 19428

CHIYODA-KINZOKU CO., LTD.

Kawasaki Motor Corp.

9950 Jeronimo Road

Irvine, CA 92618-2084

CLARK

Clark Equipment Co. of Canada Ltd.

Talbot St., St. Thomas, Ontario,

Canada N5P 1H2

CONE

DbA Silencing, Ltd.

33 East 7th Ave.

Vancouver 10, BC, Canada

COOP

Coop Engineering Inc.

12924 Lakeland Rd.,

Santa Fe Springs, CA 90670

CYCLE GEAR, INC.

303 43rd Streeet

Richmond, CA 94805

DAVIS ENGINEERING CO.

(c/o Lanco Engine, Inc.)

12915 Weber Way, P.O. Box 136,

Hawthorne, CA 90252

DONALDSON

Donaldson Co., Inc.

P.O. Box 1299, 1400 West 94th Street

Minneapolis, MN 55440-1299

ECHO

Echo Incorporated

400 Oakwood Road

Lake Zurich, IL 60047-1564

SPARK ARRESTER BRAND NAME/MANUFACTURER/ADDRESS

ENGINEERING EXHAUST SYSTEM (EES)

126 W. Robin Lane

Brookfield, WI 53005

FARR, FARR ASPIRATOR

Farr Co.

P.O. Box 92187

Airport Station

Los Angeles, CA 90009

FMF RACING

25930 Belle Porte

Harbor City, CA 90710-3317

FMF/TRU-TEC

27930 Tyler #402

Canyon Country, CA 91351

FUJI

Fuji Heavy Industries,

940 Lively Blvd.

Wood Dale, IL 60191

GENERAC

Generac Corp.,

P.O. Box 8

Waukesha, WI 53187

GILL

Erickson Products Co.,

Koch Road

Corte Madera, CA 94925

GILSON

Gilson Brothers Co.

P.O. Box 152

Plymouth, WI 53073

GORMAN-RUPP

Gorman-Rupp Co.

P.O. Box 1217

Mansfield, OH 44901

HALE

Hale Fire Pump Co.

700 Spring Mill Ave.,

Conshohocken, PA 19248

HAPCO (HARCO)

Harco Manufacturing Co.

7700 S.W. 69th Avenue

Portland, OR 97233

HARLEY-DAVIDSON-KRIZMAN

Harley-Davidson Co., Inc.

3700 W. Juneau Avenue

Milwaukee, WI 53201

HODAKA, HODAKA-KRIZMAN

Pacific Basin Trading Co.

Athena, OR 97813

HONDA, HONDA-KRIZMAN, HONDA-

NELSON

American Honda Motor Co., Inc.

1919 Torrance Blvd.,

Torrance, CA 90501-2746

HOOKER

Hooker Industries, Inc.

1024 West Brooks St.

Ontario, CA 91762

HORSTMAN-KRIZMAN

Horstman Manufacturing Co., Inc.

730 E. Huntington Drive,

Monrovia, CA 91016

HUSQVARNA, HUSQVARNA-KRIZMAN

Cagiva North America

700 W. 190th St.

Gardena, CA 90248

HUTCHINS FREFLO

MCM Manufacturing Co.

601 S. East Street

Anaheim, CA 92805

IHC

J.I. Case

7 S. 600 County Line Rd.,

Hindsdale, IL 60521

J&R ANSWER, ANSWER (J&R)

J&R Answer Products, Inc.

27460 Avenue Scott

Valencia, CA 91355

SPARK ARRESTER BRAND NAME/MANUFACTURER/ADDRESS

J&R KRIZMAN

J&R Manufacturing Co.

7738 Scount Avenue

Bell Gardens, CA 90201

JOHN DEERE

John Deere Industrial Equipment Co.

61 Inverness Drive

E. Englewood, CO 80112

KAWASAKI, KAWASAKI-KRIZMAN

Kawasaki Motor Corps., USA

9950 Jeronimo Road

Irvine, CA 92618-2084

K.C.F.D.

Kern County Fire Dept.

1025 Golden State Hwy.,

Bakersfield, CA 93301

KERKER-KRIZMAN

3910 Seaport Blvd.

West Sacramento, CA 95691

KITTELL

Kittell, E.M. Products, Inc.

11975 Portland Avenue

S. Burnsville, MN 55337

KOHLER

Kohler Co.—Generator Division

N7650 County Road

Sheboygan, WI 53083

KRIZMAN, KRIZMAN-MAICO, KSI-WIS-

KRISMAN

KESCO Krizman Engineering & Sales Co.

23134 Round Valley Rd.,

Lindsay, CA 93247

KTM SPORT MOTORCYCLE USA, INC.

930 FESLER STREET

EL CAJON, CA 92020-1808

KUBOTA TRACTOR CORP.

3401 Del Amo Blvd.,

Torrance, CA 90509-2992

MAGNUM-KRIZMAN, MAGNUM RACING

Magnum Engineering

21215 Road 252

Lindsay, CA 93247

MAREMONT

Maremont Corp.

250 E. Kehoem

Carol Stream, IL 60188

MAXIM

Riley-Beard, Inc.

Maxim Silencer Divisiæ

P.O. Box 31115

Shreveport, LA 71130

MCCULLOCH

McCulloch Corp.

P.O. Box 11990, 6000 S. McCulloch Drive

Tucson, AZ 85706

MURPHY MUFFLER

Murphy Muffler Co., Inc.

9508 Rush

S. El Monte, CA 91733

NELSON

Nelson Division

1801 Highway 51/138

P.O. Box 428,

Stroughton, WI 53589

NELSON-BURGESS

Nelson-Burgess Ltd.,

Hinckley Leicestershire,

LE 10 2LN, England

O&R

O&R Engines, Inc.

3340 Emery Street,

Los Angeles, CA 90023

ONAN

Onan Division

1400 73rd North East

Minneapolis, MN 55432

SPARK ARRESTER BRAND NAME/MANUFACTURER/ADDRESS

PKM

Ralph Electric Plants, Inc.

836 Broadway

Chula Vista, CA 90210

POLARIS

Polaris Industries

301 5th Ave. SW

Roseau, MN 56751

POWELL

Powell Brothers

3180 Carlin Ave.

Lynwood, CA 90262

PRO-CIRCUIT

130 N. Sherman #A

Corona, CA 91720

RIKER

Riker Manufacturing

4901 Stickney Ave.

Toledo, OH 43612

RUPP

Rupp Industries, Inc.

P.O. Box 1217

Mansfield, OH 44903

SKYWAY

Skyway Recreational Products

4451 Caterpillar Rd.,

Redding, CA 96001

SKYWAY-COBRA

Cobra Engineering Corp.

4760 E. Bryson St.

Anaheim, CA 92807

SOUNDMASTER

DeKoven Manufacturing Co.

1201 Michigan Blvd.

Racine, WI 53402

SPARESTER

Hoei Industries, Inc.

9-10, 2-Chrome, Nishikamata Ota-Ku,

Tokyo 144,JAPAN

STEMCO

Stemco Manufacturing Co.

Box 1989

Longview, TX 75601

STRADER

Little Giant Engineering Inc.

6919 Deering Ave.,

Canoga Park, CA 91303

SUPERTRAPP

Supertrapp Industries,

Dreison International

3910 Seaport Blvd.

West Sacramento, CA 95691

SUZUKI,SUZUKI-KRIZMAN,

SUZUKI-SPARESTER

American Suzuki Motor Corp.

3251 E. Imperial Hwy.,

Brea, CA 92621-6722

TAGA CORP. AND JAPAN DESIGN

24747 Redlands Blvd

Suite F14

San Bernardino, CA 92408

TAYLOR,TECUMSEH

Tecumseh Products Co.

P.O. Box 700, 1604 Michigan Ave.

New Holstein, WI 53061-0700

TECK

Teck Industries Div.,

Central Ohio Products Co.

2733 Johnson Rd.

Columbus, OH 43219

TILLERY

Resources Conservation Equipment Co.

3776 Catalina Str.

Los Alamitos, CA 90720

TORO

The Toro Company

8111 Lyndale Ave.

S. Minneapolis, MN 55420

SPARK ARRESTER BRAND NAME/MANUFACTURER/ADDRESS

TORQUE

Torque Products,

Ocelot Engineering, Inc.

895 W. Mill Street

San Bernardino, CA 92410

USDA

USDA Forest Service,

San Dimas Technology & Development Ctr

444 E. Bonita Ave.

San Dimas, CA 91773

WACKER

Wacker Corp.

3808 West Elm

Milwaukee, WI 53209

WAJAX-PACIFIC

Wajax-Pacific

P.O. Box 88540

Seattle, WA 98188

WALKER

Walker Manufacturing Co.

1201 Michigan Blvd.

Racine, WI 83402

WASHINGTON IRON WORKS

Washington Iron Works

1500 Sixth Avenue

Seattle, WA 98134

WHITE BROTHERS

24845 Corbit Place

Yorba Linda, CA 92887

WINTEC

Fun'n Fast Inc.

18143 Napa Street,

Northridge, CA 91324

XDUCER

Supertrapp Industries,

Dreison International

3901 Seaport Blvd.

West Sacramento, CA 95691

YAMAHA,YAMAHA-KRIZMAN, YAMAHA-

SKYWAY

Yamaha Motor Co., USA

P.O.Box 6555

6555 Katella Avenue

Cypress, CA 90630-5101

YOSHIMURA RESEARCH AND

DEVELOPMENT

4555 Carter Court

Chino, CA 91710

YUBA

Ford Motor Co., Tractor Operations

2500 E. Maple Road

Birmingham, MI 48008

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

Acerbis 035 MFS-2 Horizontal 74 58 Retaining screws loosen easily

Acerbis 035 MFS-5 Horizontal 60 ~

Acerbis 035 MFS-6 Horizontal 64 ~

ACS D1-508-183-03 Horizontal 34.9 ~

Air-Maze 10-FA Vertical 1,270 60 Horizontal test # 387C Flows above 1270 cfm-not acceptable

Air-Maze 146-FA Horizontal 1,335 60 Flow at 0 psi back pressure. Unit not rated at 1 psi.

Air-Maze 4-FA Vertical 625 60 Horizontal test #387C/Not recommended for flow above

300 cfm-screen type, subject to plugging.

Air-Maze C19035-10 Vertical 640 ~

Air-Maze C19035-10 Horizontal 679 ~

Air-Maze C19035-3 Horizontal 120 ~

Air-Maze C19035-3 Vertical 140 ~

Air-Maze C19035-4 Vertical 118 ~

Air-Maze C19035-4 Horizontal 126 ~

Air-Maze C19035-5 Horizontal 217 ~

Air-Maze C19035-5 Vertical 220 ~

Air-Maze C19035-6 Vertical 238 ~

Air-Maze C19035-6 Horizontal 302 ~

Air-Maze C19035-7 Vertical 333 ~

Air-Maze C19035-8 Horizontal 332 ~

Air-Maze C19035-8 Vertical 333 ~

Air-Maze C19035-9 Vertical 640 ~

AN Krizman KS650-O Horizontal 99 ~

Answer Products AP650M Horizontal 156 61 Modified AP650 O & M

Answer, J&R AP-500-D Horizontal 91 61 See Husqvarna-Krizman KS-500D

Answer, J&R AP-650 Horizontal 186 61 See J&R Krizman KS-650

Answer, J&R AP-650-0 (Angle) Horizontal 71 61 Angled Body

Answer, J&R AP-650-4 Horizontal 60 61 Modified KS-650-A

Answer, J&R AP-650-A Horizontal 63 61 See J&R Krizman KS-650A

Answer, J&R AP-650-C Horizontal 63 61 Approved as J&R Krizman

Answer, J&R AP-650-C Horizontal 63 61 Angled body w/insert; band clamp may be replaced with screws

Answer, J&R AP-650-C Horizontal 97 61 With insert; Required on all AP-650 C

Answer, J&R AP-650-C (Angle) Horizontal 83 61 Angled Body with insert

Answer, J&R AP-650-D Horizontal 67 61 Straight muffler, modified AP-650-O

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

Answer, J&R AP-650-D Horizontal 67 61 AP-650-0 in a polygon shell

Answer, J&R AP-650-M Horizontal 156 61 Straight muffler, modified AP-650-O

Answer, J&R AP-650-M Horizontal 131 61 Angled muffler, modified AP-650-O

Answer, J&R AP-650-O Horizontal 74 61 See J&R Krizman KS-650-0

Answer, J&R AP-650-O Horizontal 63 61 See Answer AP-650-C, KS-650C in an oval muffler.

Answer, J&R SA-Pro-2 Horizontal 74 61 Same as J&R 650-0 Krizman may have an outlet stinger

angled down.

AP Parts 83931893 Horizontal 273 62 See Donaldson FCM06-0037

AP Parts 83931893 Vertical 296 62 See Donaldson FCM06-0037

AP Parts 83931908 Horizontal 427 62 See Donaldson FCM06-5030

AP Parts 83931908 Vertical 436 62 See Donaldson FCM06-5030

AP Parts 83931910 Horizontal 597 62 See Donaldson FCM07-0068

AP Parts 83931910 Vertical 644 62 See Donaldson FCM07-0068

AP Parts 83931921 Horizontal 842 62 See Donaldson FCM07-0069

AP Parts 83931921 Vertical 881 62 See Donaldson FCM07-0069

AP Parts 83931933 Horizontal 1,177 62 See Donaldson FCM08-0024

AP Parts 83931933 Vertical 1,200 62 See Donaldson FCM08-0024

AP Parts 83933880 Horizontal 1,630 62 See Donaldson FCM09-0091

AP Parts 83933880 Vertical 1,670 62 See Donaldson FCM09-0091

AP Parts 83933892 Horizontal 2,480 62 See Donaldson FCM10-0016

AP Parts 83933892 Vertical 2,660 62 See Donaldson FCM10-0016

Berkeley F70-01MC Horizontal 65 62 Primer-arrester/Main body of arrester vertical but not inverted.

Berkeley F70-02MC Horizontal 144 62 Primer-arrester/Main body of arrester vertical but not inverted.

Bombardier 1980 Horizontal 62 62 22 mm resonator

Bombardier 1980 Horizontal 66 62 16 mm resonator

Bombardier 1980 Horizontal 66 62 28 mm resonator

Bombardier 707 600 066 Multiple 186 62

Bombardier CA-952 Horizontal 100 62 30 mm resonator

Bombardier CA-952 Horizontal 66 62 26 mm resonator

Bombardier CA-952-1 Horizontal 72 ~

Bombardier-Krizman CA-950 Horizontal 186 ~

Bombardier-Krizman CA-953 Horizontal 114 62 30 mm resonator

Bombardier-Krizman KS-250 Horizontal 17 ~

Briggs & Stratton 391911 Multiple 25 63 Screen; 4-cycle, 4 hp or smaller

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

Briggs & Stratton 391912 Multiple 25 63 Screen; 4-cycle, 4 hp or smaller

Briggs & Stratton 391913 Multiple 50 63 Screen; 4-cycle, 8 hp or smaller

Briggs & Stratton 391915 Horizontal 69 63 See Nelson T-14106

Briggs & Stratton 392154 Multiple 81 64 Screen; 4-cycle,16 hp or smaller

Briggs & Stratton 392154A Multiple 99 64 Screen; 4-cycle, 16 hp or smaller, replacement for B&S 391254

Briggs & Stratton 396800 Multiple 25 64 Screen; 4-cycle,4 hp or smaller/Outlet deflector is not

permanently attached. (See 391911 or 391912)

Briggs & Stratton 802502 Multiple 41 65 Screen; 4-cycle, 4 hp or smaller

Briggs & Stratton 494486 Multiple 29 64 Screen; 4-cycle, 5.5 hp or less

Burgess-Manning SAT-4 Horizontal 790 65

Burgess-Manning SAT-4 Vertical 795 65

Burgess-Manning SDMC-4 Horizontal 965 66

Burgess-Manning SDMC-4 Vertical 1,069 66

Burgess-Manning SDMC-LP-4 Horizontal 1,070 66

Burgess-Manning SDMC-LP-4 Vertical 1,332 66

Cal Tube 12853 Multiple 74 67 Screen; 4-cycle 14.1hp or smaller

Caterpillar 3B5498 Vertical 380 67 Replaced 2F62229

Caterpillar 3B7942 Horizontal 597 67 See Donaldson FCM07-0068

Caterpillar 3B7942 Vertical 640 67 See Donaldson FCMO7-0068

Caterpillar 3B7964 Vertical 680 67

Caterpillar 8N7074-1 Horizontal 498 67 See Donaldson FMM 12-0303

CEDCO Primer-Arrester No. 1 Horizontal 65 67 Primer-arrester. Main body of arrester vertical but not inverted.

CEDCO Primer-Arrester No. 2 Horizontal 144 67 Primer-arrester. Main body of arrester vertical but not inverted.

Chiyoda Kinzoku Co., Ltd. 18077-2115 Multiple 29 68 Screen type

Clark 6547049 Horizontal 180 68

Clark 6551409 Vertical 205 68

Clark 6552340 Vertical 209 68

Clark CAC-2000 Horizontal 1,584 68

Cone 10-D Vertical 295 68

Cone 1100 Vertical 310 69 Pulverizer type spark arrester

Cone 12-D Vertical 432 68

Cone 1500 Vertical 350 69

Cone 390 Vertical 275 69

Cone 8-D Vertical 182 68

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

Coop 400A Horizontal 53 69

Coop 500A Horizontal 78 69

Coop 500A-for LT 125 Horizontal 90 69

Coop 500B Horizontal 103 69

Cycle Gear #1 Multiple 225 70 Screen; 4-cycle, 35 HP

Davis D-L260 Horizontal 140 70

Discojet; See SUPERTRAPP ~ ~ See SUPERTRAPP

Dometic 17510-87232 Inverted 32 71

Donaldson 197297A1 Vertical 532 77

Donaldson FMM050132 Vertical 146 78

Donaldson FMM065106 Vertical 213 78

Donaldson FMM090843 Vertical 1423 78

Donaldson 142-8811 Vertical Inlet 177.2 77

Donaldson 142-8845 Vertical Inlet 177 77 See also 142-8811

Donaldson 181590A1 Vertical 699 77

Donaldson 252996A1 ~ Body Horiz. outlet vertical 1110.5 Inlet modified for

horizontal mounting.

Donaldson 254334A1 Horizontal 557 ~

Donaldson 280811A1 Horizontal 394.7 77

Donaldson 299455A3 Vertical 292.9 ~

Donaldson A184241 Vertical 259 72

Donaldson FCM04-5123 Horizontal 131 72

Donaldson FCM04-5123 Vertical 146 72

Donaldson FCM04-5214 Horizontal 131 72

Donaldson FCM04-5214 Vertical 146 72 See Donaldson FCMO4-5123

Donaldson FCM04-5220 Horizontal 131 72 See Donaldson FCM04-5123

Donaldson FCM04-5220 Vertical 146 72 See Donaldson FCM04-5123

Donaldson FCM06-0037 * Horizontal 273 72

Donaldson FCM06-0037 * Vertical 296 72

Donaldson FCM06-0038 * Vertical 120 72

Donaldson FCM06-0038 * Horizontal 126 72

Donaldson FCM06-5030 * Horizontal 427 72

Donaldson FCM06-5030 * Vertical 436 72

Donaldson FCM07-0068 * Horizontal 597 73

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

Donaldson FCM07-0068 * Vertical 644 73

Donaldson FCM07-0069 * Horizontal 842 73

Donaldson FCM07-0069 * Vertical 881 73 Flow amended from 1000 to 881 cfm 3/67

Donaldson FCM07-0118 Horizontal 597 73

Donaldson FCM07-0118 Vertical 644 73 Modified FCM07-0068

Donaldson FCM07-0122 Horizontal 597 73 Modified FCM07-0068

Donaldson FCM07-0122 Vertical 644 73 Modified FCM07-0068

Donaldson FCM07-0126 Horizontal 597 73 Model class FCM07-0068

Donaldson FCM07-0126 Vertical 644 73 Model class FCM07-0068

Donaldson FCM07-0139 Horizontal 597 73 Model class FCM07-0068

Donaldson FCM07-0139 Vertical 644 73 Model class FCM07-0068

Donaldson FCM07-0249-1 Vertical 638 73 Modified FCM07-0068

Donaldson FCM07-0304 Horizontal 731 74

Donaldson FCM07-0304 Vertical 821 74

Donaldson FCM07-0305 Vertical 1023 74

Donaldson FCM08-0024 * Horizontal 1,177 73

Donaldson FCM08-0024 * Vertical 1,200 73

Donaldson FCM09-0091 * Horizontal 1,630 73

Donaldson FCM09-0091 * Vertical 1,670 73

Donaldson FCM09-1009 Horizontal 1,630 73 See Donaldson FCMO9-0091

Donaldson FCM09-1009 Vertical 1,670 73 See Donaldson FCM09-0091

Donaldson FCM10-0016 * Horizontal 2,480 75

Donaldson FCM10-0016 * Vertical 2,660 75

Donaldson FMM03-2515 Vertical 27 75

Donaldson FMM05-0073 Vertical 66 75

Donaldson FMM06-0175 Vertical 207 76

Donaldson FMM09-0510 Horizontal 510 76

Donaldson FMM09-0638 Vertical 221 76

Donaldson FMM12-0303 Horizontal 498 76 See Caterpillar 8N7074-1

Donaldson M-07-0285 Vertical 512 76

Donaldson M070378 Vertical 292.9 76

Donaldson M090955 Horizontal 212.2 76

Donaldson SAU01-5068 Horizontal 126 72 See Donaldson FCM06-0038

Donaldson SAU01-5068 Vertical 120 72 See Donaldson FCM06-0038

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

Donaldson SAU02-0170 Horizontal 273 72 See Donaldson FCM06-0037

Donaldson SAU02-0170 Vertical 296 72 See Donaldson FCM06-0037

Donaldson SAU02-5113 Horizontal 427 72 See Donaldson FCM06-5030

Donaldson SAU02-5113 Vertical 436 72 See Donaldson FCM06-5030

Donaldson SAU03-0196 Horizontal 597 73 See Donaldson FCM07-0068

Donaldson SAU03-0196 Vertical 644 73 See Donaldson FCM07-0068

Donaldson SAU03-5126 Horizontal 842 73 See Donaldson FCM07-0069

Donaldson SAU03-5126 Vertical 881 73 See Donaldson FCM07-0069

Donaldson SAU04-0369 Horizontal 1,177 73 See Donaldson FCM08-0024

Donaldson SAU04-0369 Vertical 1,200 73 See Donaldson FCM08-0024

Donaldson SAU05-0366 Horizontal 1,630 73 See Donaldson FCM09-0091

Donaldson SAU05-0366 Vertical 1,670 73 See Donaldson FCM09-0091

Donaldson SAU06-0467 Horizontal 2,480 75 See Donaldson FCM10-0016

Donaldson SAU06-0467 Vertical 2,660 75 See Donaldson FCM10-0016

Echo 11620 Multiple 42 79 Screen; 2-cycle, 4.1 hp or smaller

EES 0053371 Multi 24 81 Screen, 2-cycle, 2 hp

EES 16009 Multiple 110 79 Screen; 4-cycle, 25 hp or smaller

EES 56378 Multiple 24 ~

EES 89011-9 Multiple 20 80 Screen; 4-cycle, 3 hp or smaller

EES 92675 Horizontal 41 80 Screen type, 4-cycle, 35 hp or smaller

EES 92675A Horizontal 41 81 Screen type, 4-cycle, 35 hp or smaller

Farr 20B Vertical 435 82 Not qualified above 435 cfm

Farr 30B Vertical 605 82

Farr 40B Vertical 1,060 82

Farr 50B Vertical 1,730 82

Farr Aspirator B16647-1 Vertical 625 82

Farr Aspirator B17345 Vertical 560 82

Farr Aspirator B18854 Vertical 615 82

Farr Aspirator C15626 Vertical 221 82

Farr Aspirator C16085 Vertical 221 82

Farr Aspirator C22001 Vertical 270 82

FMF ISDE Model 1000 Horizontal 186 84

FMF Racing S2000 Multiple 177.5 ~

FMF TDS-1 Horizontal 123 84

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

FMF TDS-2 Horizontal 123 84

FMF /Tru-Tec TDS-1 Horizontal 123 83

FMF /Tru-Tec TDS-2 Horizontal 123 84

FMF Racing TDS-3 Horizontal 123 83

Forester 12 x 330 Vertical 1,350 85 4 inch inlet

Fuji DY 41 Multiple 63 85 Screen; 4-cycle, 8.5 hp or smaller

Fuji EH 25 Horizontal 41 85 Screen; 4-cycle, 8.5 hp or smaller

Fuji EH 34 Horizontal 51 86 Screen, 4-cycle, 11.0 hp or smaller

Fuji EH 43 Multiple 1,057 86 Screen; 4-cycle, 13 hp or smaller

Fuji EH 17 Multiple 29 85 Screen, 4 Cycle, 6 HP

Fuji EH 25 Multiple 41 85 Screen, 4 Cycle, 8.5 HP

Fuji EY 20 Multiple 30 87 Screen; 4-cycle, 5 hp or smaller

Fuji EY 20 Horizontal 29 87 Screen; 4-cycle, 6.0 hp or smaller

Fuji EY 20-STD Multiple 31 87 Screen; 4-cycle, 5 hp or smaller

Fuji EY 20V Multiple 27 88 Screen; 4-cycle, 3.5 hp or smaller

Fuji EY 28 Multiple 41 88 Screen; 4-cycle, 5.5 hp or smaller

Fuji EY 35 Horizontal 58 88 Screen; 4-cycle, 10 hp or smaller

Fuji EY 40W Horizontal 58 88 “Screen; 4-cycle, 10 hp or smaller

Fuji RGO 051 Multiple 12 89 Screen; 4-cycle, 1.2 hp or smaller

Fuji RGO 120 Horizontal 22 89 Screen; 4-cycle, 3.3 hp or smaller

Generac 30699 Inverted 47 89

Generac 31145 Inverted 24 89

Generac 33232 Horizontal 43 89 See Nelson T-11606

Generac 37924 Horizontal 50 89 NMC T-13304 approved as NMC T-9458

Generac 37936 Inverted 21 89

Generac 38560 Inverted 33 89

Generac 39081 Inverted 18 89

Generac 39247 Horizontal 50 89 NMC T-13304 approved as NMC T-9458

Generac 43951 Inverted 68 89

Generac 43952 Horizontal 74 89

Generac 43953 Inverted 25 89

Generac 72082 Multiple 22 90 Screen; 4-cycle, 3 hp or smaller

Generac 72083 Multiple 32 90 Screen; 4-cycle, 5 hp or smaller

Generac 72084 Multiple 48 90 Screen; 4-cycle, 8 hp or smaller

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

Generac 72279 Multiple 48 90 Screen; 4-cycle, 8 hp or smaller

Generac 72281 Multiple 22 90 Screen; 4-cycle, 3 hp or smaller

Generac 75788 Multiple 22 90 Screen; 4-cycle, 3 hp or smaller

Generac 83083 Multiple 30 91 Screen; 4-cycle, 6 hp or smaller

Generac 83083 Multiple 54 91 Screen type; 4-cycle, 13 hp or smaller

Generac 89680 Multiple 36 91 Screen type; 4-cycle, 7.8 hp or smaller

Generac A7433 Multiple 63

Gill 3C Vertical 85 93

Gill 3C (Mod. by FS) Vertical 103 93

Gill 3C IP Horizontal 85 93

Gill 4C IP Horizontal 79 93

Gill 5-C-20A Inverted 185 93

Gill 5-C-20A Vert & Hor 240 93

Gill 5-C-20B Vert & Hor 257 93

Gill 5-C-23B Vertical 255 93

Gill 5-C-23B Horizontal 355 93

Gill 5-C-26B Vertical 315 94 Discontinued

Gill 5-CV-20 Vertical 268 93

Gill 5-CV-23 Vertical 300 93

Gill 5-CV-24 Vertical 300 93

Gill 6-C-2030 Vert & Hor 527 94 12 inch inlet

Gill 6-C-24 Horizontal 601 94 12 inch inlet

Gill 6-C-24 Vertical 615 94 12 inch inlet

Gill 6-C-24 Inverted 680 94 12 inch inlet

Gill 6-C-24 Vertical 540 94 Discontinued, 9 inch inlet

Gill 6-C-26 Horizontal 628 94

Gill 6-C-26 Vertical 655 94

Gill 6-C-30 Vert & Hor 625 94

Gill 6-C-30 Inverted 665 94

Gill 6-C-34 Vertical 660 94

Gill 6-C-34 Horizontal 685 94

Gill 6-C-34 Inverted 808 94

Gill 6-CV-24 Vertical 720 94

Gill 6-CV-26 Vertical 650 94

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

Gill 6-CV-30 Vertical 600 94

Gill 6-CV-34 Vertical 625 94

Gill 8-C-40 Hor & Inv 1,170 95

Gill 8-CV-34 Vertical 800 94

Gill 8-CV-40 Vertical 1,285 95

Gill 8-CV-50 Vertical 1,405 95

Gill 8-CV-60 Vertical 1,466 95

Gill GSF-200 Vertical 355 92

Gill GSF-300 Vertical 675 92 Discontinued

Gill GSF-400 Vertical 1,050 92 Discontinued

Gill GSH-200 Horizontal 340 92

Gill GSH-300 Horizontal 730 92 Discontinued

Gill GSO-300 Vertical 1,030 92 Discontinued

Gilson 36742 Multiple 81 95 Screen; 4-cycle, 16 hp or smaller

Gorman-Rupp 46211-018 Multiple 84 95 Screen; 2-cycle, 10 hp or smaller

Hale 108-0230-02 Multiple 80 95 Screen; 4-cycle, 16 hp or smaller

Hale 108-0230-06 Multiple 80 95 Screen; 4-cycle, 16 hp or smaller. Is a modified 108-0230-02

for use on one cylinder of an engine. Elbow added/inlet.

Hapco 12AC12LP Vertical 7,000 97 May be used on a round or oval stack

Hapco 1AA Vertical 96 96

Hapco 1AA S.A.M. 13-18 Vertical 94 96

Hapco 1AAXH Horizontal 76 96

Hapco 2AA Vertical 167 97

Hapco 2AA S.A.M. 24-112 Vertical 110 97

Hapco 2AAH Horizontal 112 97

Hapco 3AA Vertical 205 97

Hapco 3AA S.A.M. 36-2 Vertical 174 97

Hapco 3AAXH Horizontal 258 97 Not qualified above 258 cfm

Hapco 3H Horizontal 200 97 Discontinued

Hapco 4AA Vertical 395 97 Discontinued

Hapco 4AA (Step Design Top) Vertical 485 97

Hapco 4AA S.A.M. 48-3 Vertical 317 98

Hapco 4AAH Horizontal 417 98

Hapco 5AA Vertical 705 98

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

Hapco 5AA (Altered 5A) Vertical 680 98

Hapco 5AA (Step Design Top) Vertical 660 98

Hapco 5AA S.A.M. 59-3 Vertical 466 98

Hapco 5AAH Horizontal 620 98

Hapco 5AAH S.A.M. 59-3 Horizontal 527 98

Hapco 6A Vertical 900 98 Discontinued

Hapco 6AA Vertical 717 99 4 inch outlet

Hapco 6AA S.A.M. 69-4 Vertical 678 99

Hapco 6AAH Horizontal 848 99

Hapco 6AB Vertical 1,168 99 5 inch outlet

Hapco 6H Vertical 900 98 Discontinued

Hapco 7A Vertical 1,410 99 Discontinued

Hapco 7AB Vertical 1,555 99

Hapco 7AC Vertical 1,210 99 Modified 7AB

Hapco 7AC1 Vertical 1,801 99

Hapco 7AC1 Horizontal 1,944 99

Hapco 7H Vertical 1,410 99 Discontinued

Hapco 8AB Vertical 2,930 99

Hapco SAM-712 Vertical 1,555 96 AB w/muffler section added

Hapco SASR-36H-3AAXH Horizontal 172 96 AAXH w/muffler section added

Hapco SASR-48 Vertical 200 96

Hapco SASR-48H Horizontal 252 96

Hapco SASR-559 Vertical 880 96

Hapco SASR-59 Vertical 393 96 Inlet may be offset 2 inches

Hapco SASR-69H Horizontal 454 96 AAH w/muffler section added

Harley-Davidson 65234-75P Horizontal 24 100

Harley-Davidson 65241-75P Horizontal 24 101

Harley-Davidson 65463-75P Horizontal 24 101

Harley-Davidson-Krizman H.D.-1 Horizontal 24 100

Harley-Davidson-Krizman H.D.-2 Horizontal 24 100

Harley-Davidson-Krizman H.D.-3 Horizontal 24 100

Harley-Davidson-Krizman KS-400 Horizontal 49 101

Hodaka Ace 90D Horizontal 26 101 Not qualified above 26 cfm

Hodaka-Krizman ACE 100 Horizontal 24 101

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

357

358

359

360

361

362

363

364

365

366

367

368

369

370

Honda S-418 Multiple 15

Honda 1063 Horizontal 12 ~

Honda 113 Horizontal 6 ~

Honda 175 Horizontal 18 ~

Honda 200 Horizontal 14 ~

Honda 405 Horizontal 21 ~

Honda 405A Horizontal 21 ~

Honda 408 Horizontal 32 ~

Honda 503 Horizontal 47 ~

Honda 72 Horizontal 25 Not qualified above 25 cfm

Honda E-300 Horizontal 10 102 Not qualified above 10 cfm

Honda E-400 Horizontal 25 102

Honda E-600 Horizontal 14 102

Honda HM GCF A1 Horizontal 25 105 Screen, 4-cycle, 4.72 hp

Honda HM HN1 A1 Multiple 117 102

Honda HM KCE A1 Horizontal 74 Screen type, 4-cycle, 22.4 hp or smaller

Honda HM KCY A1 Multiple 116 ~

Honda HM KCY A2 Multi 125 Screen, 4-cycle, 34.6 hp

Honda HM-KV6-A1 Horizontal 51 Modified Honda Krizman 508

Honda HM-MY6-A1 Horizontal 55 ~

Honda Nelson 23066 Horizontal 64 ~

Honda Nelson 23930 Horizontal 65 Modified Honda Nelson 23066

Honda Nelson 24075 Horizontal 52 ~

Honda S-350 Multiple 22 106 Screen; 4-cycle, 3.5 hp or smaller

Honda S-351 Multiple 22 106 Screen; 4-cycle, 3.2 hp or smaller

Honda S-352 Multiple 62 106 Screen; 4-cycle, 10 hp or smaller

Honda S-353 Multiple 65 106 Screen; 4-cycle, 11 hp or smaller

Honda S-354 Multiple 30 107 Screen; 4-cycle, 5.5 hp or smaller

Honda S-355 Multiple 9 107 Screen; 4-cycle, 1.3 hp or smaller

Honda S-356 Multiple 30 107 Screen; 4-cycle, 5 hp or smaller

Honda S-356A Multiple 30 108 Screen; 4-cycle, 5 hp or smaller

Honda S-357 Multiple 62 108 Screen; 4-cycle, 11 hp or smaller

Honda S-358 Multiple 14 109 Screen; 4-cycle, 2.2 hp or smaller

Honda S-358 Multiple 15 109 Screen; 4-cycle, 2.2 hp or smaller

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

386

387

388

389

390

391

392

393

394

395

396

397

398

399

400

401

402

403

404

Honda S-359 Multiple 25 110 Screen; 4-cycle, 5.5 hp or smaller

Honda S-359 Multiple 30 110 Screen; 4-cycle, 10 hp or smaller

Honda S-360 Multiple 62 110 Screen; 4-cycle, 12 hp or smaller

Honda S-361 Multiple 54 110 Screen; 4-cycle, 14 hp or smaller

Honda S-361 Multiple 96 110 Screen; 4-cycle, 18 hp or smaller

Honda S-361A Multiple 54 111 Screen; 4-cycle, 13 hp or smaller

Honda S-361A Multiple 59 111 Screen; 4 cycle, 13 hp (new Muffler)

Honda S-362 Multiple 22 112 Screen; 4-cycle, 5 hp or smaller

Honda S-362 Multiple 25 112 Screen; 4-cycle, 5.5 hp or smaller

Honda S-363 Multiple 22 112 Screen; 4-cycle, 5 hp or smaller

Honda S-363 Multiple 25 112 Screen; 4-cycle, 5.5 hp or smaller

Honda S-364 Multiple 36 112 Screen; 4-cycle, 8 hp or smaller

Honda S-364 Multiple 41 112 Screen; 4-cycle, 9 hp or smaller

Honda S-365 Multiple 51 112,113 Screen; 4-cycle, 11 hp or smaller

Honda S-365 Multiple 59 112,113 Screen; 4-cycle, 13 hp (increased hp)

Honda S-365-A Multiple 59 113 Screen; 4-cycle, 13 hp or smaller

Honda S-366 Multiple 51 113 Screen; 4-cycle, 11 hp or smaller

Honda S-366-A Multiple 51 113 Screen; 4-cycle, 11 hp or smaller

Honda S-366-A Multiple 59 113 Screen; 4-cycle, 13 hp or smaller

Honda S-366-B Multiple 110 113 Screen in each exhaust port; 4cly, 22 hp

Honda S-367 Multiple 13 113 Screen; 2-cycle, 0.9 hp or smaller

Honda S-368 Multiple 62 113 Screen; 4-cycle, 9 hp or smaller

Honda S-415 Multiple 30 113 Screen type

Honda S-417 Multiple 24 113 Screen, 4-cycle, 4.1 hp

Honda S-418 Multiple 15 ~

Honda-Krizman 103 Horizontal 18 115

Honda-Krizman 104 Horizontal 27 115 Not qualified above 27 cfm

Honda-Krizman 105 Horizontal 27 115

Honda-Krizman 106 Horizontal 12 115

Honda-Krizman 107 Horizontal 27 115

Honda-Krizman 108 Horizontal 16 115

Honda-Krizman 109 Horizontal 42 115

Honda-Krizman 111 Horizontal 27 115

Honda-Krizman 112 Horizontal 18 115

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

405

406

407

408

409

410

411

412

413

414

415

416

417

418

419

420

421

422

423

424

425

426

427

428

429

430

431

432

433

434

435

436

437

438

Honda-Krizman 115 Horizontal 19 116

Honda-Krizman 116 Horizontal 15 116

Honda-Krizman 203 Horizontal 27 116

Honda-Krizman 204 Horizontal 27 116

Honda-Krizman 205 Horizontal 27 116

Honda-Krizman 206 Horizontal 27 116

Honda-Krizman 207 Horizontal 20 117

Honda-Krizman 209 Horizontal 27 117

Honda-Krizman 210 Horizontal 35 117

Honda-Krizman 300 Horizontal 27 117

Honda-Krizman 301 Horizontal 22 117

Honda-Krizman 302 Horizontal 27 117

Honda-Krizman 303 Horizontal 31 117

Honda-Krizman 304 Horizontal 46 117

Honda-Krizman 305 Horizontal 33 118

Honda-Krizman 306 Horizontal 38 118

Honda-Krizman 400 Horizontal 42 118

Honda-Krizman 401 Horizontal 42 118

Honda-Krizman 402 Horizontal 33 118

Honda-Krizman 404 Horizontal 42 118

Honda-Krizman 406 Horizontal 48 118

Honda-Krizman 407 Horizontal 80 118

Honda-Krizman 409 Horizontal 69 119

Honda-Krizman 409-A Horizontal 71 119 Modified 409

Honda-Krizman 410 Horizontal 70 119

Honda-Krizman 411 Horizontal 86 119

Honda-Krizman 412 Horizontal 87 119

Honda-Krizman 413 66 119

Honda-Krizman 500 Horizontal 42 119 With or without heat shield

Honda-Krizman 501 Horizontal 78 119

Honda-Krizman 502 Horizontal 36 120

Honda-Krizman 504 Horizontal 85 120

Honda-Krizman 505 Horizontal 46 120

Honda-Krizman 506 Horizontal 111 120

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

439

440

441

442

443

444

445

446

447

448

449

450

451

452

453

454

455

456

457

458

459

460

461

462

463

464

465

466

467

468

469

470

471

472

Honda-Krizman 507 Horizontal 58 120

Honda-Krizman 508 Horizontal 97 120 in a muffler shell

Honda-Krizman 508 Horizontal 97 120 With curved outlet

Honda-Krizman 508 Horizontal 102 120

Honda-Krizman 508 Horizontal 60 120 With diffuser

Honda-Krizman 508 Horizontal 153 120 Diffuser fixing screws must be in place

Honda-Krizman 508 Horizontal 79 120 installed in a new muffler

Honda-Krizman 509 Horizontal 53 121

Honda-Krizman 600 Horizontal 26 121

Honda-Krizman 601 Horizontal 48 121

Honda-Krizman 700 Horizontal 52 121

Honda-Krizman 701 Horizontal 25 121 With diffuser

Honda-Krizman 701 Horizontal 281 121 Diffuser fixing screws must be in place

Honda-Nelson 26296 Horizontal 122

Hooker 26281 Multiple 230 123 Screen; 2-cycle, 44 hp or smaller

Hooker 26282 Multiple 192 123 Screen; 2-cycle, 30 hp or smaller

Hooker 26283 Multiple 114 123 Screen; 2-cycle, 15.6 hp or smaller

Horstman-Krizman HE Horizontal 27 124 Types A through E provide various inlet dimensions and shapes.

Husqvarna F15-1041 Horizontal 94 124

Husqvarna-Krizman KS-500D Horizontal 91 125

Hutchins Freflo No. 1 Horizontal 135 ~

IHC 1275835C1 Vertical 405 125 See Nelson 19853

IHC 561217C92 Vertical 485 125

IHC 563507C91 Vertical 380 125

IHC 677817R91 Vertical 176 125

IHC 70769C1 Vertical 305 125

IHC 829176C91 Inverted 178 125

IHC 829640C91 Inverted 213 125

J&R Answer- SEE Answer ~ ~ ~

J&R Krizman KS-350 Horizontal 58 126

J&R Krizman KS-500-A Horizontal 104 126

J&R Krizman KS-500-C Horizontal 86 126

J&R Krizman KS-650 Horizontal 186 126

J&R Krizman KS-650-0 Horizontal 74 126

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

473

474

475

476

470

471

472

473

474

475

476

477

478

479

480

481

482

483

484

485

486

487

488

489

490

491

492

493

494

495

496

497

498

499

J&R Krizman KS-650-A Horizontal 63 126

J&R Krizman KS-650-C Horizontal 63 126 KS-650A in an oval muffler

J&R Krizman KS-650-V Vertical 180 126

J&R Krizman KS-800 Horizontal 122 126

John Deere AH-75693 Horizontal 213 127

John Deere AH-75694 Horizontal 348 127

John Deere AH-75695 Horizontal 394 127

John Deere AH-80388 Vertical 382 127

John Deere AH-84965 Horizontal 505 127

John Deere AH-87289 Horizontal 324 127

John Deere AT-32701 Vertical 148 127

John Deere AT-33686 Horizontal 148 127

Kawasaki 18077-2110 Multiple 22 ~

Kawasaki 3951 Horizontal 32 ~

Kawasaki 3951 Multiple 20 Screen; 4-cycle, 3.2 hp or smaller

Kawasaki 3952 Horizontal 32 Screen; 4-cycle, 7.5 hp or smaller

Kawasaki 3952-A Multiple 20 Screen; 4-cycle, 7.5 hp or smaller

Kawasaki 3964 Multiple 46 Screen; 4-cycle, 7.5 hp or smaller

Kawasaki 3965 Multiple 46 ~

Kawasaki 3966 Multiple 46 ~

Kawasaki KD 080N2 Horizontal 21 128

Kawasaki KDX200H Horizontal 62 129

Kawasaki KF-150 Multiple 88 129 Screen; 4-cycle, 14 hp or smaller

Kawasaki KG-4000 Multiple 51 129 Screen; 4-cycle, 8.2 hp or smaller

Kawasaki KG-5000 Multiple 60 129 Screen; 4-cycle, 10 hp or smaller

Kawasaki KG-550 Horizontal 22 ~

Kawasaki KHI LF 400 Horizontal 38 130 Removable outlet tube; 2 cleanout plugs

Kawasaki KHI LX 650 Horizontal 19 130

Kawasaki KHI LX 650C Horizontal 62 130

Kawasaki KHI-KL250 Horizontal 42 ~

Kawasaki KLX-250D Horizontal 17 130

Kawasaki X171 Multiple 12 130 Screen; 4-cycle, 1.7 hp or smaller

Kawasaki X171A Multiple 12 130 Screen; 4-cycle, 1.7 hp or smaller

Kawasaki 18077-2110 Multiple 22 ~

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

500

501

502

503

504

505

506

507

508

509

510

511

512

513

514

515

516

517

518

519

520

521

522

523

524

525

526

527

528

529

530

531

532

533

Kawasaki DX 200 Horizontal 32 127

Kawasaki DX 250D Horizontal 79 127 Angled muffler; arrester horizontal

Kawasaki FA 130D Multiple 20 128 Screen; 4-cycle, 2.6 hp or smaller

Kawasaki FA 210D Multiple 30 128 Screen; 4-cycle, 4.5 hp or smaller

Kawasaki FA 76D Multiple 12 127 Screen; 4-cycle, 1.4 hp or smaller

Kawasaki FE 290D Multiple 43 128 Screen; 4-cycle, 9 hp or smaller

Kawasaki FE170D Multiple 29 Screen type

Kawasaki FG 200D Multiple 49 128 Screen; 4-cycle, 6.8 hp or smaller

Kawasaki FG 300D Multiple 49 128 Screen; 4-cycle, 6.8 hp or smaller

Kawasaki KL250G 10o Horizontal 46 ~

Kawasaki-Krizman DX-200 Horizontal 78 131

Kawasaki-Krizman DX-250 Horizontal 73 131

Kawasaki-Krizman KD-400 Horizontal 42 131

Kawasaki-Krizman KG-250C Horizontal 91 132

Kawasaki-Krizman KHI KE-250B Horizontal 45 132

Kawasaki-Krizman KHI-KL6 Horizontal 70 132

Kawasaki-Krizman KS-250 Horizontal 27 132 See Suzuki-Krizman KS-250

Kawasaki-Krizman KS-350 KHI-DX080A Horizontal 46 132

Kawasaki-Krizman KS-350 KHI-DX080C Horizontal 34 132

Kawasaki-Krizman KS-350 KHI-DX080C1 Horizontal 23 133

Kawasaki-Krizman KS-500 KDX 175 Horizontal 49 ~

Kawasaki-Krizman KS-500 KHI KL65 Horizontal 60 133

Kawasaki-Krizman KS-500 KHI-DX200A Horizontal 64 133

Kawasaki-Krizman KS-500 KHI-DX200C Horizontal 61 133

Kawasaki-KrizmanKS-500 KHI-KL600 Horizontal 28 133

Kawasaki-Krizman KS-500 KHI-KSF250 Horizontal 38 133

Kawasaki-Krizman KS-500 KHI-LF110 Horizontal 27 134

Kawasaki-Krizman KS-500 KHI-LF220 Horizontal 44 134

Kawasaki-Krizman KS-500 KHI-LF300C Horizontal 44 134

Kawasaki-Krizman KS-500 KHI-LT110A Horizontal 27 134

Kawasaki-Krizman KS-500 KHI-LT160 Horizontal 27 134 See KHI LT110A

Kawasaki-Krizman KS-500 KHI-LT200A Horizontal 48 134 See DX200A

Kawasaki-Krizman KS-500 KHI-LT250A Horizontal 50 134

Kawasaki-Krizman KS-500 KHI-XT250 Horizontal 70 134

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

534

535

536

537

538

539

540

541

542

543

544

545

546

547

548

549

550

551

552

553

554

555

556

557

558

559

560

561

562

563

564

565

566

567

Kawasaki-Krizman KS-500 KHI-XT250B2 Horizontal 65 134

Kawasaki-Krizman YS-80 Horizontal 24 134

Kawasaki-Krizman KG-250 Horizontal 18 ~

Kawasaki-Krizman KG-250A Horizontal 23 ~

Kerker-Krizman KS-650-K Horizontal 187 135

Kern County Fire Department 1 Horizontal 65 135 See CEDCO Primer-Arrester No. 1

Kittell 1010 HT Vertical 500 136

Kittell 3510-SA 1-1/4 Horizontal 60 136

Kittell S 1-1/2A Vertical 146 135

Kittell S 2-1/2A Vertical 370 136

Kittell S-2A Vertical 150 136

Kittell S-3 Vertical 415 136

Kittell S-3A Vertical 468 136

Kittell S-4 Vertical 935 136

Kittell S-4A Vertical 1,008 136

Kittell S-5 Vertical 1,100 136

Kittell S-5A Vertical 1,150 136 Not qualified above 1,150 cfm

Kittell S-T-1 1/2 Vertical 136 135

Kittell S-T-2 Vertical 211 135

Kittell S-T-3 Vertical 497 135

Kittell S-T-3 1/2 Vertical 616 135

Kittell S-T-4 Vertical 960 135

Kittell S-T-5 Vertical 1,312 135

Kittell S-T-2 1/2 Vertical 406 135

Kohler 228173 Inverted 27 137 See Nelson 20788

Kohler 228218 Multiple 30 137 Screen; 4-cycle, 4 hp or smaller

Kohler 239724 Horizontal 43 137

Kohler 278189 Horizontal 40 137 Modified Kohler 278223

Kohler 278218 Horizontal 40 137

Kohler 278223 Inverted 40 137

Kohler 278224 Inverted 44 137

Kohler 278232 Horizontal 40 137 Modified Kohler 278223

Kohler 278402 Horizontal 44 137 Modified Kohler 278224; Body/arrester Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

568

569

570

571

572

573

574

575

576

577

578

579

580

581

582

583

584

585

586

587

588

589

590

591

592

593

594

595

596

597

598

599

600

Kohler 278403 Horizontal 44 137 Modified Kohler 278224; Body/arrester Horizontal

Kohler 278416 Horizontal 40 137 Modified Kohler 278224; Body/arrester Horizontal

Krizman 11-5H.34B Horizontal 21 138 Not qualified above 21 cfm Models that lack the letter “B”

are not qualified

Krizman KS-650-A Horizontal 63 See J&R Krizman KS-650A

Krizman T-H100 or T-H100M Horizontal 22 138

Krizman V-H 11 Horizontal 186 138

Krizman V-H-1 Horizontal 92 138

Krizman-Maico KS-500/250.28505.01 Horizontal ~ 138

KSI-WIS-Krizman KS-650-K Horizontal 69 138 Modified Krizman KS-650-0

KTM K-300 Horizontal 65 139

KTM K-620 Horizontal 83 139 See KTM K-300

Kubota 8501A Horizontal 83 140

Kubota 8502C Multiple 14 140 Screen; 4-cycle, 3.4 hp or smaller

Kubota 8503C Multiple 21 140 Screen; 4-cycle, 5.2 hp or smaller

Kubota 8504C Multiple 32 140 Screen; 4-cycle, 7.4 hp or smaller

Kubota 8505B Multiple 43 140 Screen; 4-cycle, 4.0 hp or smaller

Kubota 8906A Multiple 30 140 Screen; 4-cycle, 7.87 hp or smaller

Kubota 8907A Multiple 59 140 Screen; 4-cycle, 6.08 hp or smaller

Kubota 8908A Multiple 37 141 Screen; 4-cycle, 8.9 hp or smaller

Kubota 8909A Multiple 49 141 Screen; 4-cycle, 6.6 hp or smaller

Kubota 8910A Multiple 41 141 Screen; 4-cycle, 1.15 hp or smaller

Kubota 9001B Multiple 13 141 Screen; 4-cycle, 8.9 hp or smaller

Magnum Krizman KS650-M Horizontal 90 142

Magnum-Krizman KS-650-A Horizontal 60 142 See J&R Krizman 650A

Maremont 4305 Horizontal 63 142

Maremont 4305 Vertical 273 142

Maremont 4306 Horizontal 296 142

Maremont 4306 Vertical 436 142

Maremont 4307 Horizontal 597 142

Maremont 4307 Vertical 644 142

Maremont 4308 Horizontal 842 142

Maremont 4308 Vertical 881 142

Maremont 4604 Horizontal 1,177 142

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

601

602

603

604

605

606

607

608

609

610

611

612

613

614

615

616

617

618

619

620

621

622

623

624

625

626

627

628

629

630

631

632

633

634

Maremont 4604 Vertical 1,200 142

Maremont 4605 Horizontal 1,630 142

Maremont 4605 Vertical 1,670 142

Maxim 2 MSA1 Horizontal 218 142

McCulloch MPP 1500E Multiple 21 143 Screen; 4-cycle, 2.7 hp or smaller

McCulloch MPP 2300E Multiple 30 143 Screen; 4-cycle, 5.5 hp or smaller

McCulloch MPP 3500E Multiple 42 143 Screen; 4-cycle, 5.5 hp or smaller

McCulloch MPP 600E/800E Multiple 12 143 Screen; 4-cycle, 1.4 hp or smaller

Murphy Muffler MM3S 2.5 Multiple 240 Screen; 2-cycle, 29.4 hp or smaller

Nelson 14110 Vertical 435 160

Nelson 14113 Vertical 182 160 Body Horizontal

Nelson 14217 Horizontal 186 160

Nelson 14390 Vertical 111 161

Nelson 14572 Horizontal 167 161

Nelson 15064A Vertical 244 ~

Nelson 15514 Inverted 615 162 Two inlets; One outlet

Nelson 15567 Inverted 35 162

Nelson 15730 Horizontal 35 162 Modified T-14321

Nelson 15731 Horizontal 42 162

Nelson 15818 Vertical 112 162

Nelson 15870 Inverted 99 163 Modified T-14123

Nelson 15876 Vertical 348 163

Nelson 15893 Inverted 42 163 See Onan 155-1520

Nelson 15934 Horizontal 95 163 Body Horizontal

Nelson 15935 Horizontal 71 163 Two inlets; One outlet. Body Horizontal

Nelson 15982 Horizontal 63 163 Body Horizontal

Nelson 16001 Vertical 750 163

Nelson 16006 Horizontal 112 164

Nelson 16011 Horizontal 50 164

Nelson 16025 Vertical 196 164 Body Horizontal

Nelson 16068 Horizontal 325 164

Nelson 16152 Horizontal 148 164 Two inlets; One outlet. Body Horizontal

Nelson 16170 Vertical 588 164 Two inlets; One outlet. Body Horizontal

Nelson 16297 Horizontal 71 165 Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

635

636

637

638

639

640

641

642

643

644

645

646

647

648

649

650

651

652

653

654

655

656

657

658

659

660

661

662

663

664

665

666

667

Nelson 16300 Horizontal 81 165 Body Horizontal

Nelson 16301 Horizontal 59 165 Body Horizontal

Nelson 16302 Horizontal 150 165

Nelson 16304 Horizontal 62 165

Nelson 16361 Inverted 43 165

Nelson 16362 Inverted 46 165

Nelson 16460 Inverted 61 165

Nelson 16504 Vertical 640 166

Nelson 16506A Vertical 258 166

Nelson 16507A Vertical 440 166

Nelson 16538 Vertical 282 166

Nelson 16547 Vertical 194 166 Body Horizontal

Nelson 16572 Horizontal 108 166 Two inlets; One outlet

Nelson 16619 Inverted 105 167 Body Horizontal

Nelson 16628 Horizontal 105 167 Two inlets; 36 outlet holes/Body Horizontal

Nelson 16667 Inverted 35 167 Body Horizontal

Nelson 16752 Vertical 75 167 Body Horizontal

Nelson 16825 Horizontal 79 167 Body Horizontal

Nelson 16828 Horizontal 87 167 Body Horizontal

Nelson 16868 Horizontal 206 168

Nelson 16888 Vertical 140 168 Body Horizontal

Nelson 16909 Inverted 243 168

Nelson 16932 Horizontal 160 168 Body Horizontal

Nelson 16956 Horizontal 108 168 Body Horizontal

Nelson 16986 Vertical 102 168 2 vertical inlets; 1 outlet/Body Horizontal

Nelson 16988 Horizontal 116 169 Body Horizontal

Nelson 16989 Horizontal 54 169 Not qualified above 54 cfm

Nelson 16990 Vertical 100 169 Body Horizontal

Nelson 16990A Vertical 100 169 Same as 16990 except for outlet rotational angle length.

Body Horizontal

Nelson 17005 Vertical 558 169 Body Horizontal

Nelson 17043 Horizontal 68 169 Body Horizontal

Nelson 17088 Horizontal 57 169 Body Horizontal

Nelson 17112 Inverted 31 170 Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

668

669

670

671

672

673

674

675

676

677

678

679

680

681

682

683

684

685

686

687

688

689

690

691

692

693

694

695

696

697

698

699

700

701

Nelson 17123 Vertical 192 170 Body Horizontal

Nelson 17185 Inverted 170 170 Body Horizontal

Nelson 17254 Horizontal 386 170 Body Horizontal

Nelson 17318 Multiple 81 170 Adapter for Nelson 35347 screen assembly

Nelson 17334 Horizontal 122 170

Nelson 17371 Vertical 131 171 Two inlets; One outlet

Nelson 17410 Horizontal 95 171 Body Horizontal. Inlet may be smaller

Nelson 17470 Horizontal 65 171 Body Horizontal

Nelson 17480 Horizontal 420 171

Nelson 17533 Horizontal 69 171

Nelson 17622 Horizontal 89 171 Two inlets; One outlet. Body Horizontal

Nelson 17622-C Horizontal 89 Modified Nelson 17622

Nelson 17657 Vertical 226 ~

Nelson 17674 Inverted 150 Body Horizontal

Nelson 17695 Vertical 143 Body Horizontal

Nelson 17701 Horizontal 1,044 Two inlets; One outlet. Body Horizontal

Nelson 17746 Vertical 107 Body Horizontal

Nelson 17747 Horizontal 89 Body Horizontal

Nelson 17749 Horizontal 97 Body Horizontal

Nelson 17750 Horizontal 141 Body Horizontal

Nelson 17765 Vertical 81 Body Horizontal

Nelson 17898 Horizontal 46 ~

Nelson 17899 Horizontal 754 Two inlets, One outlet. Body Horizontal

Nelson 17973 Vertical 357 ~

Nelson 17974 Vertical 454 ~

Nelson 17998 Vertical 78 174 Body Horizontal

Nelson 18012 Horizontal 94 174 See 17410 for drawing & photo/Body Horizontal

Nelson 18018 Vertical 455 174 May have side or bottom clean out plug

Nelson 18031 Inverted 110 174 Body Horizontal

Nelson 18090 Horizontal 700 174 Two inlets; One outlet. Body Horizontal

Nelson 18289 Inverted 75 174 Body Horizontal

Nelson 18433 Vertical 165 175

Nelson 18493 Horizontal 94 175 See Nelson 17410 for drawing & photo

Nelson 18528 Horizontal 74 175 Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

702

703

704

705

706

707

708

709

710

711

712

713

714

715

716

717

718

719

720

721

722

723

724

725

726

727

728

729

730

731

732

733

734

735

Nelson 18528A Horizontal 70 175 Body Horizontal

Nelson 18613 Vertical 196 175 Body Horizontal

Nelson 18631 Vertical 83 175 Body Horizontal

Nelson 18642 Horizontal 576 175 Outlet length may vary. Body Horizontal

Nelson 18731 Horizontal 90 175 Two inlets; One outlet. Body Horizontal

Nelson 18753 Multiple 81 176 Adapter for Nelson 35347 screen assembly

Nelson 18798 Vertical 77 176

Nelson 18875 Horizontal 77 176

Nelson 18885 Vertical 50 176 Body Horizontal

Nelson 19005 Vertical 213 176

Nelson 19051 Vertical 225 176 Approved as T-14222

Nelson 19052 Vertical 225 176 Approved as T-14222

Nelson 19053 Vertical 225 176 Approved as T-14222

Nelson 19062 Horizontal 576 176 Approved as T-18642

Nelson 19068 Vertical 133 176

Nelson 19125 Vertical 350 177

Nelson 19126 Vertical 238 177

Nelson 19139 Vertical 93 177 Two inlets; One outlet

Nelson 19269 Vertical 225 177 Approved as 19053

Nelson 19273 Vertical 300 177 Approved as T-14219

Nelson 19341 Horizontal 193 177 Body Horizontal

Nelson 19382 Vertical 124 177 Body Horizontal

Nelson 19383 Vertical 225 177 Approved as 19052, See Nelson T-14222

Nelson 19453 Inverted 505 178

Nelson 19578 Horizontal 198 178

Nelson 19705 Vertical 213 178 Body Horizontal

Nelson 19773 Vertical 243 178

Nelson 19820 Horizontal 36 178 Also identified as ONAN 155-2048

Nelson 19822 Horizontal 38 178 Also identified as ONAN 155-2047

Nelson 19825 Horizontal 18 179 Body vertical

Nelson 19826 Horizontal 28 179 Body vertical

Nelson 19830 Vertical 345 179 Not qualified above 345 cfm

Nelson 19853 Vertical 405 179 Also identified as IHC1275825C, Body Horizontal

Nelson 19941 Horizontal 94 179 Two inlets; One outlet. Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

736

737

738

739

740

741

742

743

744

745

746

747

748

749

750

751

752

753

754

755

756

757

758

759

760

761

762

763

764

765

766

767

Nelson 19973 Horizontal 45 180 Body Horizontal

Nelson 19975 Horizontal 95 180 Two inlets; One outlet

Nelson 19976 Horizontal 125 180 Two inlets; One outlet. Body Horizontal

Nelson 19994 Vertical 94 180 Two inlets; One outlet

Nelson 20069 Horizontal 470 Body Horizontal

Nelson 20072 Vertical 392 181 Body Horizontal

Nelson 20147 Horizontal 78 181 Body Horizontal

Nelson 20343 Horizontal 46 181 Same as 17898 except two cleanout plugs

Nelson 20490 Horizontal 23 181 Approved as Wacker WM80-58406

Nelson 20513 Horizontal 66 181 Also identified as ONAN 155-2098

Nelson 20519 Vertical 460 181 Body Horizontal

Nelson 20539 Horizontal 207 181 Body Horizontal

Nelson 20578 Multiple 30 181 Screen; 4-cycle, 4 hp or smaller

Nelson 20578B Multi 30 Screen; 4-cycle, 4 hp or smaller

Nelson 20578-B Multiple 30 Screen; 4-cycle, 4 hp or smaller

Nelson 20608 Vertical 160 182 Body Horizontal

Nelson 20665 Horizontal 36 182 Approved as 19820

Nelson 20666 Horizontal 38 182 Approved as 19822

Nelson 20687 Horizontal 33 182 Not qualified above 32.5 cfm Body Horiz

Nelson 20710 Vertical 252 182

Nelson 20710 Horizontal 268 182

Nelson 20788 Inverted 27 182 See Kohler 228173

Nelson 20892A Horizontal 48 182 Same as 19822 except for inlet and outlet rotational

angle length/Body Horizontal

Nelson 20892B Horizontal 48 182 Star plug closure cleanout

Nelson 20952 Horizontal 111 182 Unit equipped with catalytic converter,/Body Horizontal

Nelson 20953 Vertical 166 182 Body Horizontal

Nelson 20954 Horizontal 257 183 Body Horizontal

Nelson 20965 Horizontal 108 Distance between inlet and outlet maybe 10.2 or 12

inches. Body Horizontal

Nelson 20990 Horizontal 64 183 Body Horizontal

Nelson 20990B Horizontal 64 183 Modified Nelson 20990

Nelson 21079 Horizontal 40 183 Modified Kohler 278223, Body Horizontal

Nelson 21140 Horizontal 267 183 Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

768

769

770

771

772

773

774

775

776

777

778

779

780

781

782

783

784

785

786

787

788

789

790

791

792

793

794

795

796

797

798

799

800

801

Nelson 21161 Inverted 154 183 Body Horizontal

Nelson 21278 Inverted 40 183 See Kohler 278223, Body Horizontal

Nelson 21279 Horizontal 49 183 Also identified as ONAN 155-2065

Nelson 21315 Horizontal 900 183 Body and outlet vertical

Nelson 21341 Inverted 106 183

Nelson 21422 Horizontal 40 184 See Kohler 278218, Body Horizontal

Nelson 21423 Inverted 44 184 See Kohler 278224, Body Horizontal

Nelson 21423B Horizontal 44 184 See Kohler 278224:Body of arrester Horizontal

Nelson 21517 Vertical 245 184

Nelson 21549 Horizontal 57 184

Nelson 21616 Vertical 107 184 Body Horizontal

Nelson 21645 Horizontal 40 184 Modified Kohler 278223, Body Horizontal

Nelson 21709 Horizontal 82 184

Nelson 21721 Horizontal 36 185

Nelson 21758 Horizontal 571 185

Nelson 21800 Horizontal 128 185 Horizontal inlet & body; Vertical outlet

Nelson 21800A Horizontal 128 186 Modified Nelson 21800. Body Horizontal

Nelson 21800C Horizontal 128 186 Modified Nelson 21800. Body Horizontal

Nelson 21863 Horizontal 255 Inlet & outlet Horizontal; Body vertical

Nelson 21884 Vertical 178 186 Body Horizontal

Nelson 21928 Horizontal 82 186 Body Horizontal

Nelson 21950 Vertical 188 186 Body Horizontal

Nelson 21950B Vertical 188 Modified Nelson 21950

Nelson 22157 Inverted 46 186 Modified Nelson 16362. Body Horizontal

Nelson 22171B Horizontal 54 186 See Onan 155-2416

Nelson 22255 Vertical 250 187 Outlet vertical, Body Horizontal

Nelson 22389 Horizontal 67 187 Body Horizontal

Nelson 22416 Vertical 160 Modified Nelson 20608

Nelson 22506 Vertical 62 187 Body Horizontal

Nelson 22506A Vertical 62 187 Body Horizontal

Nelson 22627 Vertical 111 187 Body Horizontal

Nelson 22671 Horizontal 84 Modified Nelson 22672

Nelson 22672 Horizontal 84 187 Horizontal inlet, body & outlet

Nelson 22737 Horizontal 44 188 See Kohler 278224; Body of arrester Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

802

803

804

805

806

807

808

809

810

811

812

813

814

815

816

817

818

819

820

821

822

823

824

825

826

827

828

829

830

831

832

833

834

835

Nelson 22755 Horizontal 43 188 See Kohler 239724

Nelson 22777 Horizontal 40 188 See Kohler 278223; Body of arrester Horizontal

Nelson 22801A Horizontal 54 188 Modified Nelson 22171-B

Nelson 22807A Vertical 405 188

Nelson 22823 Horizontal 71 188

Nelson 22836 Horizontal 36 188 Modified Nelson 21721

Nelson 22904 Inverted 36 188 Modified Nelson 19820

Nelson 22917 Horizontal 55 188

Nelson 22992 Vertical 183 188 Body and outlet Horizontal

Nelson 22992A Vertica 205 188 Vertical inlet, horizontal body

Nelson 23069 Horizontal 28 189 Modified Nelson 19826

Nelson 23094 Vertical 124 189 Modified Nelson 19382, Body/Arrester Horizontal”

Nelson 23096 Vertical 206 189

Nelson 23137 Vertical 64 189 Body Horizontal, outlet down

Nelson 23162 Inverted 106 189 Modified N-21341 diff. support bracket

Nelson 23259A Multiple 30 189 Screen; 4-cycle, 4 hp or smaller, Onan 155-2514

Nelson 23483 Horizontal 31 189 Modified Nelson 21721

Nelson 23511A Vertical 87 189 Body horizontal, inlet inverted

Nelson 23516A Multiple 30 189 Screen; 4-cycle, 4hp or smaller; see Nelson 20578

Nelson 23643 Vertical 112 190 Vertical, body horizontal

Nelson 23697 Vertical 127 190 Body Horizontal

Nelson 23718 Horizontal 64 ~ Modified Nelson 20990

Nelson 23726 Horizontal 85 190 Two horizontal inlets, one outlet

Nelson 23727 Vertical 92 190 Modified Nelson 38195-A

Nelson 23746 Vertical 152 190

Nelson 23843 Horizontal 32 190

Nelson 23852 45o from inv 148 190 Cleanout plug 45 deg. from outlet

Nelson 23860 Horizontal 33 190

Nelson 23893 Horizontal 228 191 Body Inverted

Nelson 23893 Horizontal 228 191 Body Vertical

Nelson 24035 Vertical 159 191

Nelson 24083 Vertical 223 191

Nelson 24108A Multi 30 ~ Screen; 4-cycle, 4.0 hp or smaller

Nelson 24148 Horizontal 1,027 192

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

836

837

838

839

840

841

842

843

844

845

846

847

848

849

850

851

852

853

854

855

856

857

858

859

860

861

862

863

864

865

866

867

868

Nelson 24180 Horizontal 281 192

Nelson 24304 Vertical 131 192

Nelson 24379 Vertical 168 192 Qualified with or without the catalytic converter can in place

Nelson 24459 Vertical 895 192

Nelson 24707 Vertical 177 193

Nelson 24710 Vertical 159 193 Body horizontal

Nelson 24711 Vertical 131 193 Body horizontal

Nelson 24745 Horizontal 121 193

Nelson 24752 Vertical 168 194 Body horizontal, qualified with or without the catalytic

converter can in place.

Nelson 24756N Horizontal 49 194

Nelson 24800 Vertical 117 194

Nelson 24839 Vertical 242.4 195

Nelson 24842 Vertical 280 195 Body horizontal

Nelson 24866-B Inverted 25 195 Body horizontal

Nelson 24931 Horizontal 92 195

Nelson 24953 Vertical 69 196

Nelson 25007 Horizontal 52 196

Nelson 25012 Vertical 135 196

Nelson 25026 Vertical 231 196

Nelson 25133 Vertical 894 196

Nelson 25191 Inverted 38 197

Nelson 25237 Horizontal 71 197

Nelson 25239-A Horizontal 118 197

Nelson 25602A Horizontal 36 198

Nelson 25640 Vertical 43 198

Nelson 25766 Multiple 48 199 Screen; 4-cycle, 8 hp or smaller

Nelson 25771 Horizontal 160 199 Inlet 49o off vertical

Nelson 25868N Horizontal 46.6 200

Nelson 25986 Horizontal 83.5 200

Nelson 26054A Horizontal 47.7 200

Nelson 26147 Horizontal 113 200

Nelson 26201A Horizontal 105.2 200

Nelson 26252 Vertical 234 200

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

869

870

871

872

873

874

875

876

877

878

879

880

881

882

883

884

885

886

887

888

889

890

891

892

893

894

895

896

897

898

899

Nelson 26281 Horizontal 82.7 201

Nelson 26294 Horizontal 79.8 201

Nelson 26296 Horizontal 74.5 201

Nelson 26359 Horizontal 101 201

Nelson 26438 Horizontal 66.3

Nelson 26454 Horizontal 88 ~

Nelson 26465 Horizontal 177.2

Nelson 26503 Horizontal 46 202

Nelson 26617 Horizontal 13 202

Nelson 26710 Horizontal 66 202

Nelson 26710N Horizontal 77.3 202

Nelson 26749 Horizontal 69 202

Nelson 26875 Horizontal 435 203

Nelson 26876 Horizontal 1,056 203

Nelson 26897 Horizontal 63.2 203 See Onan 155-3151

Nelson 27021 Horizontal 71 203

Nelson 27137 Horizontal 32 ~

Nelson 27173 Horizontal 234.4 204

Nelson 27174 Horizontal 67 204

Nelson 27196A Horizontal 63.4 204

Nelson 27222 Horizontal 73 204

Nelson 27258 Horizontal 72 204

Nelson 27404A Horizontal 484 205

Nelson 27453 Vertical inlet, 205

horizontal body 258

Nelson 27453A Vertical inlet,

horizontal body 234

Nelson 27475 Horizontal 217.5 205

Nelson 27522 Horizontal 89 205

Nelson 27543A Horizontal 262 206

Nelson 27692 Vertical inlet 206

horizontal body 254 206

Nelson 27780 Horizontal 72

Nelson 27890 Horizontal 67

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

900

901

902

903

904

905

906

907

908

909

910

911

912

913

914

915

916

917

918

919

920

921

922

923

924

925

926

927

928

929

930

931

932

Nelson 27901 Horizontal 102.8 206

Nelson 28057N Horizontal 737.3 206

Nelson 28061N Horizontal 560 207

Nelson 28070N Horizontal 608 207

Nelson 28151 Horizontal 75

Nelson 28186 Horizontal 130 207

Nelson 30134 Vertical 298 207

Nelson 30670 Vertical 352 208

Nelson 35347 Multiple 81 208 Screen; 4-cycle, 23 hp for use on Nelson 16184, 16348,

17605, 17814, 18672 and 21146 mufflers.

Nelson 38195 Vertical 104 208 Outlet horizontal. Body horizontal

Nelson 38196 Horizontal 111 209 2 inlets, body horizontal, outlet inverted

Nelson 49013 Multiple 118 209 Screen; 4-cycle, 20 hp or smaller

Nelson 49017 Multiple 48 209 Screen; 4-cycle, 8hp 19.44 cu. in. or smaller

Nelson 49019 Multiple 48 209 Screen; 4-cycle, 8hp 19.44 cu. in. or smaller

Nelson 49020 Multiple 54 210 Screen; 4-cycle, 10hp or smaller

Nelson 49021 Multiple 67 210 Screen; 4-cycle, 12.5 hp or smaller

Nelson 49022 Multiple 89 210 Screen; 4-cycle, 18hp or smaller

Nelson 49022 G Multiple 95 210 Reverse screen cone

Nelson 49024 Multiple 118 210 Screen; 4-cycle, 20 hp or smaller

Nelson 49025 Multiple 222 210 Screen; 4-cycle, 35 hp or smaller

Nelson 49026 Multiple 222 211 Screen, 4-cycle, 35 hp or smaller

Nelson 49110 Horizontal 50 Approved as T-9458

Nelson 49110 Vertical 75 Approved as T-9458

Nelson 49114 Vertical 105 Approved as T-14123

Nelson 49114 Horizontal 99 ~

Nelson 49115 Horizontal 123 211

Nelson 49115 Vertical 24 211

Nelson 49115C Vert & Hor 124 211 49115 with 1 inch pipe inlet, curved outlet

Nelson 49119 Horizontal 237 211

Nelson 49119 Vertical 240 211

Nelson 49120 Vertical 255 211

Nelson 49120-F Vertical 255 211 Inlet may vary 2 inch I.D. to 2- inch I.D.

Nelson 49120-F Horizontal 260 211 Outlet may vary 2 inch O.D. to 2-inch I.D. See Nelson U-49120

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

933

934

935

936

937

938

939

940

941

942

943

944

945

946

947

948

949

950

951

952

953

954

955

956

957

958

959

960

961

962

963

964

965

966

Nelson 49124 Vertical 302 211

Nelson 49125 Vertical 344 212

Nelson 49125 Horizontal 347 212

Nelson 49130 Horizontal 655 212

Nelson 49130 Vertical 663 212

Nelson 49135 Vertical 830 212

Nelson 49135 Horizontal 950 212

Nelson 49140 Vertical 760 212

Nelson 49140 Horizontal 920 212

Nelson 49150 Vertical 1,275 212

Nelson 49150 Horizontal 1,275 212

Nelson 49150U Horizontal 1,275 212 See also Nelson 49150

Nelson 49150U Vertical 1,275 212 See also Nelson 49150

Nelson 49160 Horizontal 2,020 213

Nelson 49160 Vertical 2,040 213

Nelson 613313 Multiple 60 213 Screen; 4-cycle, 12.5 hp or smaller

Nelson 614338 Multiple 87 213 Screen, 4-cycle, 20 hp

Nelson NM615351 Multiple 125 213

Nelson T-10093 Horizontal 20 Not qualified above 20 cfm

Nelson T-10115 Vertical 227 146

Nelson T-10115 Horizontal 232 146

Nelson T-10126 Vertical 122 146

Nelson T-10213 Horizontal 213 146 Body Horizontal

Nelson T-10214 Horizontal 348 146 Body Horizontal

Nelson T-10215 Horizontal 394 147 Body Horizontal

Nelson T-10244 Horizontal 520 147

Nelson T-10291 Horizontal 33 147

Nelson T-10374 Vertical 176 147 Body Horizontal

Nelson T-10409 Horizontal 21 147

Nelson T-10705 Horizontal 24 147

Nelson T-10792 Horizontal 67 147 Body Horizontal

Nelson T-10860 Horizontal 100 147

Nelson T-10895 Horizontal 18 148

Nelson T-10897 Vertical 112 148 Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

967

968

969

970

971

972

973

974

975

976

977

978

979

980

981

982

983

984

985

986

987

988

989

990

991

992

993

994

995

996

997

998

999

Nelson T-10898 Horizontal 20 148

Nelson T-10956 Inverted 808 148

Nelson T-10968 Vertical 148 148 Body Horizontal

Nelson T-11068C Inverted 47 148 Body Horizontal

Nelson T-11145 Vertical 382 149

Nelson T-11159 Inverted 24 149

Nelson T-11336 Horizontal 239 149 Body Horizontal

Nelson T-11337 Vertical 308 149 Body Horizontal

Nelson T-11424 Inverted 63 149 Body Horizontal

Nelson T-11601C Horizontal 26 149

Nelson T-11606 Horizontal 43 149 See Generac 33232

Nelson T-11668 Vertical 164 149

Nelson T-11708 Vertical 31 149 P/N NMC-T-11892, Body horizontal

Nelson T-11730H Horizontal 13 149

Nelson T-11842 Inverted 808 150 Same as T-10956

Nelson T-11915 Horizontal 30 150 Body vertical

Nelson T-11927 Horizontal 324 150

Nelson T-11976 Vertical 125 150

Nelson T-12499 Horizontal 505 150 Body Horizontal

Nelson T-12502 Vertical 227 150 Approved as T-10115

Nelson T-12502 Horizontal 232 150 Approved as T-10115

Nelson T-12760B Inverted 21 150 Body Horizontal

Nelson T-12761 Inverted 38 150 Body Horizontal

Nelson T-12818 Vertical 305 150

Nelson T-12825F Inverted 28 150 Centerline or offset outlet tube, one or two, clean out

plugs. Body Horizontal

Nelson T-12863 Horizontal 92 150

Nelson T-13109 Horizontal 210 151

Nelson T-13265 Inverted 23 151

Nelson T-13300 Horizontal 11 151

Nelson T-13304 Horizontal 50 151 Approved as T-9458

Nelson T-13376 Horizontal 50 151 Approved as T-9458

Nelson T-13473 Horizontal 180 151 Body Horizontal

Nelson T-13502 Horizontal 640 151 Two horizontal inlets. Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1000

1001

1002

1003

1004

1005

1006

1007

1008

1009

1010

1011

1012

1013

1014

1015

1016

1017

1018

1019

1020

1021

1022

1023

1024

1025

1026

1027

1028

1029

1030

1031

1032

1033

Nelson T-13529 Horizontal 69 151

Nelson T-13559 Horizontal 17 151 Body Horizontal

Nelson T-13572 Inverted 18 151 Body Horizontal

Nelson T-13651 Vertical 485 152

Nelson T-13716 Vertical 425 152 Body Horizontal

Nelson T-13846 Vertical 176 152 Body Horizontal

Nelson T-13919 Vertical 216 152 Body Horizontal

Nelson T-13933 Inverted 93 152 Body Horizontal

Nelson T-13934 Vertical 206 152

Nelson T-13935 Vertical 219 152 New Holland No.285187, Body Horizontal

Nelson T-13940 Inverted 125 152 Body Horizontal

Nelson T-13944 Horizontal 33 152 Approved as T-10291

Nelson T-13977 Vertical 205 153

Nelson T-13978 Vertical 166 153

Nelson T-13979 Vertical 166 153

Nelson T-13994 Inverted 213 153 Body Horizontal

Nelson T-13995 Vertical 382 153

Nelson T-13995 Horizontal 388 153

Nelson T-13999 Inverted 30 153 Body Horizontal

Nelson T-14000 Inverted 42 153 Two inlets. Body Horizontal

Nelson T-14002 Horizontal 11 154 Body vertical

Nelson T-14005 Vertical 380 154

Nelson T-14066 Vertical 204 154 Approved as T-9213

Nelson T-14066 Horizontal 208 154 Approved as T-9213

Nelson T-14090 Horizontal 59 154 Body Horizontal

Nelson T-14099 Inverted 178 154 Body Horizontal

Nelson T-14105 Horizontal 169 154

Nelson T-14106 Horizontal 69 154 Approved as T-1352

Nelson T-14110B Vertical 421 154

Nelson T-14116 Horizontal 51 155 Body Horizontal

Nelson T-14123 Horizontal 99 155 Body Horizontal

Nelson T-14125 Inverted 50 155 Body Horizontal

Nelson T-14214 Horizontal 153 155

Nelson T-14217 Horizontal 183 155

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1034

1035

1036

1037

1038

1039

1040

1041

1042

1043

1044

1045

1047

1048

1049

1050

1051

1052

1053

1054

1055

1056

1057

1058

1059

1060

1061

1062

1063

1064

1065

1066

1067

Nelson T-14219 Vertical 300 155

Nelson T-14220 Vertical 683 155 Two inlets; one outlet

Nelson T-14222 Vertical 225 156

Nelson T-14223 Horizontal 150 156

Nelson T-14223 Vertical 160 156

Nelson T-14224 Vertical 170 156

Nelson T-14315 Inverted 68 156 Body Horizontal

Nelson T-14316 Horizontal 74 156 Body Horizontal

Nelson T-14321 Inverted 25 156 Body Horizontal

Nelson T-14327 Vertical 505 156 Approved as T-12499

Nelson T-14334 Horizontal 543 156 Body Vertical

Nelson T-14334 Vertical 561 156 With eductor tube, Body Horizontal

Nelson T-14382 Horizontal 520 156 Approved as T-10244

Nelson T-14390 Vertical 111 ~

Nelson T-14402 Horizontal 147 157

Nelson T-14403 Horizontal 155 157

Nelson T-14406 Horizontal 69 157 Approved as T-13529

Nelson T-14415 Vertical 205 157 Body Horizontal

Nelson T-14425 Horizontal 99 157 Approved as T-14123

Nelson T-14529 Vertical 275 157

Nelson T-14630 Horizontal 240 157 Body Horizontal

Nelson T-14631 Vertical 315 157 Body Horizontal

Nelson T-14671 Horizontal 147 158

Nelson T-14688 Horizontal 75 158 Body Vertical

Nelson T-14754 Horizontal 261 158

Nelson T-14816 Horizontal 210 158

Nelson T-14853 Inverted 69 158 See ONAN 155-1485

Nelson T-14907 Vertical 209 158 Body Horizontal

Nelson T-15077 Inverted 47 158

Nelson T-15078 Horizontal 48 159 Body Horizontal

Nelson T-15079 Horizontal 57 159 Body Horizontal

Nelson T-15080 Horizontal 67 159 Body Horizontal

Nelson T-15215 Horizontal 136 159

Nelson T-15341 Horizontal 92 159 Two inlets; One outlet. Body Horizontal

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1068

1069

1070

1071

1072

1073

1074

1075

1076

1077

1078

1079

1080

1081

1082

1083

1084

1085

1086

1087

1088

1089

1090

1091

1092

1093

1094

1095

1096

1097

1098

1099

1100

1101

Nelson T-15611 Horizontal 65 160 Body Horizontal

Nelson T-15688 Horizontal 513 160 Body Vertical

Nelson T-15689 Horizontal 618 160 Body Vertical

Nelson T-6277 Vertical 154 144

Nelson T-7033 Vertical 250 144

Nelson T-7359 Vertical 245 144

Nelson T-7515 Vertical 335 144

Nelson T-8680 Vertical 262 144

Nelson T-8714 Horizontal 417 144

Nelson T-8714 Vertical 429 144

Nelson T-9098 Horizontal 141 144 Not qualified above 141 cfm

Nelson T-9099 Horizontal 194 144

Nelson T-9099 Vertical 196 144

Nelson T-9213 Vertical 204 145

Nelson T-9213 Horizontal 208 145

Nelson T-9219 Vertical 164 145 Body Horizontal

Nelson T-9220 Vertical 170 145 Body Horizontal

Nelson T-9304 Vertical 438 145

Nelson T-9356 Vertical 450 145

Nelson T-9356 Horizontal 474 145

Nelson T-9370 Vertical 198 145

Nelson T-9457 Horizontal 50 145

Nelson T-9458 Horizontal 50 145

Nelson T-9460 Horizontal 37 145

Nelson T-9489 Inverted 76 145

Nelson T-9605 Vertical 146 146 See John Deere AT-33686

Nelson T-9605 Horizontal 148 146 See John Deere AT-33686

Nelson T-9932 Horizontal 415 146

Nelson T-9932 Vertical 426 146

Nelson T-9995 Vertical 31 146 Body Horizontal

Nelson-Burgess 17AE07 Vertical 213 213 Also identified as 10420A

Nelson-Burgess 17AE08 Vertical 227 213 Also identified as 10250A

Nelson-Burgess 17AE10 Vertical 219 214 Also identified as 10255A

Nelson-Burgess 17AE12 Vertical 226 214 Also identified as 10415A

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1102

1103

1104

1105

1106

1107

1108

1109

1110

1111

1112

1113

1114

1115

1116

1117

1118

1119

1120

1121

1122

1123

1124

1125

1126

1127

1128

1129

1130

1131

1132

1133

1134

Nelson-Burgess 17AE14 Vertical 258 214 Also identified as 10421A

Nelson-Burgess 20965 Horizontal 108 214 Distance between inlet and outlet may be10.2 or 12

inches. Body Horizontal.

Nelson-Burgess 20965 Horizontal 108 214 Horizontal Inlet, Body & Outlet

Nelson-Burgess 39616 Horizontal 323 214

O&R 76 Multiple 16 216 Screen; 2-cycle 1 hp or smaller

Onan 0155-3110 Horizontal 46 215

Onan 155-1254 Horizontal 92 215 See Nelson T-12863

Onan 155-1258 Inverted 28 215 See Nelson T-12825F

Onan 155-1485 Inverted 69 215 See Nelson T-14853

Onan 155-1520 Inverted 42 215 See Nelson 15893

Onan 155-1698 Vertical 75 215 See Nelson 16752

Onan 155-2047 Horizontal 38 215 See Nelson 19822

Onan 155-2048 Horizontal 36 215 See Nelson 19820

Onan 155-2065 Horizontal 49 215 See Nelson 21279

Onan 155-2085 Horizontal 36 215 See Nelson 20665

Onan 155-2086 Horizontal 38 215 See Nelson 20666

Onan 155-2098 Horizontal 66 215 See Nelson 20513

Onan 155-2186 Multi 30 215 Screen; 4-cycle, 4 hp or smaller; Nelson 20578

Onan 155-2186 Multiple 30 215 Screen; 4-cycle, 4 hp or smaller

Onan 155-2262 Horizontal 82 215 See Nelson 21709

Onan 155-2416 Horizontal 54 215

Onan 155-2514 Multi 30 215 Screen; 4-cycle, 4hp or smaller; Nelson 23295A

Onan 155-2783 Inverted 25 215 Body horizontal

Onan 155-2885 Vertical 43 215 See Nelson 25640

Onan 155-2951 Horizontal 71 215 See Nelson 25191

Onan 155-3151 Horizontal 63.2 215 See Nelson 26897

Pacific Pumper 216 See WAJAX-PACIFIC

PKM II Special purpose 38 216 For use on 7 hp, 4-cycle engine-driven generator only

Polaris 1206702 Horizontal 44 218 Modified Polaris 1260588

Polaris 1206741 Horizontal 75 218 See Polaris 1260535

Polaris 1260510 Horizontal 41 217

Polaris 1260520 Horizontal 65 217

Polaris 1260535 Horizontal 75 217

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1135

1136

1137

1138

1139

1140

1141

1142

1143

1144

1145

1146

1147

1148

1149

1150

1151

1152

1153

1154

1155

1156

1157

1158

1159

1160

1161

1162

1163

1164

1165

1166

1167

1168

Polaris 1260535-5 Horizontal 75 217 Modified Polaris 1260535

Polaris 1260544 Horizontal 75 217 Modified Polaris 1260535

Polaris 1260576 Horizontal 75 217 Modified Polaris 1260535

Polaris 1260588 Horizontal 44 217

Polaris 1260616 Horizontal 44 Modified Polaris 1260588

Polaris 1260629 Horizontal 61 217

Polaris 1260702 Horizontal 44 218 Modified Polaris 1260588

Polaris 1260715 Horizontal 55 218

Polaris 1260741 Horizontal 75 218 See Polaris 1260535

Polaris 1260742 Horizontal 61 218 See Polaris 1260629

Polaris 1260745 Horizontal 85.9 219

Polaris 1260807 Horizontal 55 219

Polaris 1260843 Horizontal 55 219

Polaris 1260869 Horizontal 73.5 220

Polaris 1260884 Horizontal 100 220

Polaris 1260891 Horizontal 73 220

Polaris 1260894 Horizontal 73 220 See Polaris 1260891

Polaris 1260903 Horizontal 73.5 221 See Polaris 1260869

Polaris 1260903 Horizontal 74 221 See Polaris 1260869

Polaris 1260910 Horizontal 75 221 See Polaris 1260535

Polaris 1260930 Horizontal 73.6 221

Polaris 1260961 Horizontal 73 221 See also 1260977

Polaris 1260968 Horizontal 73 222

Polaris 1260977 Horizontal 73 222

Polaris 1260989 Horizontal 55 222 See also 1260715

Polaris 1261006 Horizontal 74 222

Polaris 1261022 Horizontal 75 ~

Polaris 1261042 Horizontal 55 ~ See Polaris 1260715

Powell No. F Horizontal 27 223

Pro-Circuit PC-0070-0 Horizontal 89.8 223

Pro-Circuit PC-007-R Horizontal 89.8 224

Reliable M-07-0285 Vertical 512 224

Riker SA-200 Vertical 208 224

Riker SA-200 Horizontal 208 224

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1169

1170

1171

1172

1173

1174

1175

1176

1177

1178

1179

1180

1181

1182

1183

1184

1185

1186

1187

1188

1189

1190

1191

1192

1193

1194

1195

1196

1197

1198

1199

1200

1201

1202

Riker SA2009 Horizontal 273 See Donaldson FCM0600037

Riker SA2009 Vertical 296 See Donaldson FCM0600037

Riker SA2059 Horizontal 427 See Donaldson FCM065030

Riker SA2059 Vertical 436 See Donaldson FCM065030

Riker SA-250 Vertical 345 224

Riker SA-250 Horizontal 369 224

Riker SA-300 Vert & Hor 400 224

Riker SA3009 Horizontal 597 See Donaldson FCM070068

Riker SA3009 Vertical 644 See Donaldson FCM070068

Riker SA-350 Vertical 545 224

Riker SA-350 Horizontal 587 224

Riker SA-350-1 Vertical 381 224 Modified SA-350

Riker SA3509 Horizontal 842 See Donaldson FCM070069

Riker SA3509 Vertical 881 See Donaldson FCM070069

Riker SA-353 Horizontal 517 224

Riker SA-400 Vertical 585 224

Riker SA4009 Horizontal 1,177 See Donaldson FCM080024

Riker SA4009 Vertical 1,200 See Donaldson FCM080024

Riker SA-400A Horizontal 582 224

Riker SA-400A Vertical 600 224

Riker SA-401 Vertical 680 225

Riker SA-401 Horizontal 723 225

Riker SA-408 Horizontal 860 225

Riker SA-408 Vertical 900 225

Riker SA-409 Horizontal 809 225 Modified SA-408

Riker SA-500 Vertical 979 225

Riker SA-500 Horizontal 989 225

Riker SA5009 Horizontal 1,630 See Donaldson FCM090091

Riker SA5009 Vertical 1,670 See Donaldson FCM090091

Riker SA6009 Horizontal 2,480 See Donaldson FCM100016

Riker SA6009 Vertical 2,660 See Donaldson FCM100016

Riker SA-6762 Vertical 550 225 Modified SA-408 in muffler shell.

Rupp 32004 Horizontal 24 225

Skyway 1000 Horizontal 40 226

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1203

1204

1205

1206

1207

1208

1209

1210

1211

1212

1213

1214

1215

1216

1217

1218

1219

1220

1221

1222

1223

1224

1225

1226

1227

1228

1229

1230

1231

1232

1233

1234

1235

1236

Skyway 2500 Horizontal 74 226

Skyway 300 Series Horizontal 107 226

Skyway 510 Series 300 Horizontal 60 226 Body length may vary from 8.5 to 16.5 inches

Skyway-Cobra 300 Horizontal 176 226 Modified Skyway-Cobra 300 add-on w/angled body

Skyway-Cobra 300-1 Horizontal 161 226 Motorcycle

Soundmaster 1578 Vertical 296 ~

Soundmaster 21578 Horizontal 273 227

Soundmaster 21579 Vertical 436 227

Soundmaster 21579 Horizontal 427 227

Soundmaster 21580 Horizontal 597 227

Soundmaster 21580 Vertical 644 227

Soundmaster 21581 Vertical 881 227

Soundmaster 21581 Horizontal 842 227

Soundmaster 21582 Vertical 1,200 227

Soundmaster 21582 Horizontal 1,177 227

Soundmaster 21584 Vertical 1,670 227

Soundmaster 21584 Horizontal 1,630 227

Soundmaster 21585 Inverted 28 227 See Nelson 12825F

Soundmaster 22005 Horizontal 2,020 227

Soundmaster 22005 Vertical 2,040 227

Soundmaster 35807 Horizontal 123 227

Soundmaster 35807 Vertical 124 227

Sparester 601 Horizontal 53 228

Sparester 602 Inverted 47 228

Sparester 801 Horizontal 97 228

Sparester SA-100 Horizontal 147 227

Sparester SA-120 Horizontal 233 227

Sparester SA-140 Horizontal 285 227

Sparester SA-160 Horizontal 350 227

Sparester SA-190 Horizontal 541 228

Sparester SA-240 Horizontal 669 228

Sparester SA-280 Horizontal 995 228

Sparky Horizontal 176 ~

Stemco 262-1059 Horizontal 273 229 See Donaldson FCM06-0037

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1237

1238

1239

1240

1241

1242

1243

1244

1245

1246

1247

1248

1249

1250

1251

1252

1253

1254

1255

1256

1257

1258

1259

1260

1261

1262

1263

1264

1265

1266

1267

1268

1269

1270

Stemco 262-1059 Vertical 296 229 See Donaldson FCM06-0037

Stemco 262-1060 Horizontal 427 229 See Donaldson FCM06-5030

Stemco 262-1060 Vertical 436 229 See Donaldson FCM06-5030

Stemco 262-1061 Horizontal 597 229 See Donaldson FCM07-0068

Stemco 262-1061 Vertical 644 229 See Donaldson FCM07-0068

Stemco 262-1062 Horizontal 842 229 See Donaldson FCM07-0069

Stemco 262-1062 Vertical 881 229 See Donaldson FCM07-0069

Stemco 262-1063 Horizontal 1,177 229 See Donaldson FCM08-0024

Stemco 262-1063 Vertical 1,200 229 See Donaldson FCM08-0024

Stemco 262-1064 Horizontal 1,630 229 See Donaldson FCM09-0091

Stemco 262-1064 Vertical 1,670 229 See Donaldson FCM09-0091

Stemco 262-2020 Horizontal 260 229 See Nelson U-49120

Stemco 262-2025 Horizontal 347 229 See Nelson U-49125

Stemco 262-2030 Vertical 633 229 See Nelson U-49130

Stemco 262-2035 Vertical 830 229 See Nelson 49135

Stemco 262-2035 Horizontal 950 229 See Nelson 49135

Stemco 262-2040 Horizontal 920 229 See Nelson 49140

Stemco 262-2050 Horizontal 1,275 229 See Nelson 49150

Stemco 262-2050 Vertical 1,275 229 See Nelson 49150

Stemco 595M Inverted 675 229 See Stemco 595M

Strader 200 Horizontal 29 229

Strader 400 Horizontal 46 229 Not qualified above 46 cu ft/min

Supertrapp T-100 ** Multiple 243 230

Supertrapp T-101 ** Multiple 170 230

Supertrapp T-102 ** Multiple 64 230

Supertrapp T-99 ** Multiple 31 230

Suzuki HS-050 Multiple 36 Screen type

Suzuki HS-1 Horizontal 5 231

Suzuki HS-10 Multi 68 233 Screen; 4-cycle, 14 hp or less

Suzuki HS-11 Multiple 15 ~

Suzuki HS-2 Multiple 13 231 Screen; 4-cycle, 1.6 hp or less

Suzuki HS-3 Multiple 51 231 Screen; 4-cycle, 7.8 hp or less

Suzuki HS-4 Multiple 22 231 Screen; 2-cycle, 1.8 hp or less

Suzuki HS-5 Multiple 25 232 Screen; 4-cycle, 4.2 hp or less

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1271

1272

1273

1274

1275

1276

1277

1278

1279

1280

1281

1282

1283

1284

1285

1286

1287

1288

1289

1290

1291

1292

1293

1294

1295

1296

1297

1298

1299

1300

1301

1302

1303

Suzuki HS-5A Multiple 25 232 Screen; 4-cycle, 3.8 hp or smaller

Suzuki HS-5AB Multi 30 232 Screen, 4-cycle, 6.0 hp

Suzuki HS-6 Multiple 25 232 Screen; 4-cycle, 4.2 hp or less

Suzuki HS-7 Multiple 41 232 Screen; 4-cycle, 9.0 hp or smaller

Suzuki HS-7A Multiple 41 233 Screen; 4-cycle, 9.0 hp or smaller

Suzuki HS-7B Multi 44 ~ Screen, 4-cycle, 9.0 hp

Suzuki HS-8 Multiple 22 ~ Screen; 2-cycle, 1.8 hp hp or smaller

Suzuki HS-9 Multi 68 233 Screen; 4-cycle, 14 hp or less

Suzuki KS-450 Horizontal 82 234

Suzuki KS-450-1 Horizontal 42 234

Suzuki KS-450-2 Horizontal 83 234

Suzuki KS-450-3 Horizontal 48 234

Suzuki-Krizman K-15 Horizontal 20 235

Suzuki-Krizman KS-250 Horizontal 27 235 Additional cross reference 345/419

Suzuki-Krizman KS-250 Horizontal 26 235 For SE 1500 & SE 2500

Suzuki-Krizman KS-250 (for TM 75) Horizontal 20 235

Suzuki-Krizman KS-250 (for TS 80) Horizontal 23 235

Suzuki-Krizman KS-250 (for Alt 50) Horizontal 17 235

Suzuki-Krizman KS-250M Horizontal 25 236 TM 75&TC 100K Motorcycle cycle muffler

Suzuki-Krizman KS-350-3 Horizontal 39 236

Suzuki-Krizman KS-350-3 Horizontal 30 236 For LT 185

Suzuki-Krizman KS-350-3 Horizontal 30 236 For LT 250

Suzuki-Krizman KS-351 Horizontal 50 236

Suzuki-Krizman KS-400 Horizontal 84 236

Suzuki-Krizman KS-400 (for PE 250) Horizontal 39 237

Suzuki-Krizman KS-400-1 Horizontal 47 237 Modified KS-400

Suzuki-Sparester 2-1 Horizontal 72.6 241

Suzuki-Sparester 2-2 Horizontal 73 241

Suzuki-Sparester-1 X02C0X Horizontal 33 242

Suzuki-Sparester-2-3 Horizontal 69.1 241 Suzuki-Sparester 801 Horizontal 97 ~

Suzuki-Sparester 801 LT500R Horizontal 73 242

Suzuki-Sparester 801 X19AOX Horizontal 97 242 Suzuki LT250RATV

Suzuki-Sparester 801 X19BOX Horizontal 53 242

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1304

1305

1306

1307

1308

1309

1310

1311

1312

1313

1314

1315

1316

1317

1318

1319

1320

1321

1322

1323

1324

1325

1326

1327

1328

1329

1330

1331

1332

1333

1334

1335

1336

Suzuki-Sparester 801 X22AOX Horizontal 97 242 On Suzuki LT120SATV, one clean out plug; On Suzuki

LT230EATV, two clean out plugs.

Suzuki-Sparester 801-X0523X Horizontal 46 242

Suzuki-Sparester-1 Horizontal 81 239

Suzuki-Sparester-1 DR-400 Horizontal 87 237

Suzuki-Sparester-1 LT-80 Horizontal 25 237

Suzuki-Sparester-1 PE-175 Horizontal 87 237

Suzuki-Sparester-1 PE-250 Horizontal 87 237

Suzuki-Sparester-1 PE-400 Horizontal 87 ~

Suzuki-Sparester-1-1 Horizontal 61 239

Suzuki-Sparester-1-2 Horizontal 42 240

Suzuki-Sparester-1-3 Horizontal 42 240 Enlarged inlet bell

Suzuki-Sparester-2-1 Horizontal 72.6 241

Suzuki-Sparester-801-1 Horizontal 61 ~

Suzuki-Sparester-850 Horizontal 57 ~

Suzuki-Sparester-850-1 Horizontal 49 ~

Taga Corporation & Japan Design Horizontal 370 ~ Muffler body must be labeled screen type

Taylor 100 Multiple 26 243 Screen; 4-cycle, 4 hp or less

Taylor 200 Multiple 46 243 Screen; 4-cycle, 8 hp or less

Taylor 300 Multiple 46 243 Screen; 4-cycle, 7 hp or less

Taylor 400 Multiple 26 243 Screen; 4-cycle, 4 hp or less

Taylor 400A Multiple 26 243 Screen; 4-cycle, 4 hp or less

Taylor 750 Multiple 30 243 Screen; 4-cycle, 10 hp or less

Taylor 750A Multiple 46 243 Screen; 4-cycle, 8 hp or less

Taylor 751 Multiple 61 244 Screen; 4-cycle, 10 hp or less

Taylor 800 Multiple 46 244 Screen; 4-cycle, 8 hp or less

Taylor 80 Multiple 64 ~ Screen; 2-cycle, 5.5 hp or less

Taylor 90 Multiple 57 ~ Screen; 4-cycle, 10 hp or less

Taylor 95 Multiple 50 ~ Screen; 4-cycle, 10 hp or less

Teck 1-6250- C Vertical 259 248

Teck SS-860-2 Horizontal 181 248

Teck SS-860-2 Vertical 204 248

Teck SS-860-25 Horizontal 205 248

Teck SS-860-25 Vertical 208 248

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1337

1338

1339

1340

1341

1342

1343

1344

1345

1346

1347

1348

1349

1350

1351

1352

1353

1354

1355

1356

1357

1358

1359

1360

1361

1362

1363

1364

1365

1366

1367

1368

1369

1370

Teck SS-860-3 Vertical 238 248

Teck SS-860-3 Horizontal 245 248

Teck SS-860-35 Horizontal 372 248

Teck SS-860-35 Vertical 377 248

Teck SS-860-4A Horizontal 383 248

Teck SS-860-4A Vertical 386 248

Teck SS-860-5 Vertical 532 248

Tecumseh 35352 Multiple 70 245 Screen; 4-cycle, 12 hp or less

Tecumseh 35352 Multiple 54 245 Screen; 4-cycle, 13 hp or smaller

Tecumseh 36085 Multiple 31 246 Screen; 4-cycl, 5 hp or smaller

Tecumseh 36411 Multiple 110 ~ Screen; 4-cycle, 2.5 hp or smaller

Tecumseh 390301A Multiple 16 246 Screen; 2-cycle, 2 hp or smaller

Tecumseh 390309 Multiple 42 247 Screen; 2-cycle, 4 hp or smaller

Tecumseh 400B Multiple 26 245 Screen; 4-cycle, 4 hp or less

Tecumseh 751A Multiple 26 245 Screen; 4-cycle, 5 hp or smaller

Tillery T-134 Multiple 45 249 Screen; 2-cycle, 6.5 hp or less

Tillery T-234 Multiple 26 249 Screen; 4-cycle, 4 hp or less

Toro 36-4750 Multiple 19 249 Screen; 4-cycle, 2.27 hp or less

Toro 56-6730 Multiple 21 249 Screen; 4-cycle, 3.7 hp or less

Toro 81-0200 Multiple 31 249 Screen; 2-cycle, 3.5 hp or less

Torque TQ 1000 Horizontal 24 250

Torque TQ 2000 Horizontal 34 250

Torque TQ 3000 Horizontal 43 250

Torque TQ 3000A Horizontal 42 250

Torque TQ 3000B Horizontal 46 250

USDA FS-3 Vertical 530 250 Prototype

USDA FS-3 Horizontal 614 250 Prototype

USDA FS-3 Horizontal 622 250 Prototype

USDA FS-4 Horizontal 164 250 Prototype

Wacker WM80-58406 Horizontal 23 ~

Wajax-Pacific PB-1196 Horizontal 69 252 Primer-arrester

Wajax-Pacific PC-1216 Horizontal 56 252 Primer-arrester

Wajax-Pacific Pumper D-4479 Horizontal 57 251 Primer-arrester. Also called Pacific, Pumper or Wajax.

Wajax-Pacific Pumper Model 2 Multiple 103 251 Screen; 2-cycle, 8.5 hp or less. Also called Pacific Pumper or Wajax.

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1371

1372

1373

1374

1375

1376

1377

1378

1379

1380

1381

1382

1383

1384

1385

1386

1387

1388

1389

1390

1391

1392

1394

1395

1396

1397

1398

1399

1400

1401

1402

1403

1404

1405

Walker 21578 Vertical 296 252

Walker 21578 Horizontal 273 252

Walker 21579 Horizontal 427 252

Walker 21579 Vertical 436 252

Walker 21580 Horizontal 597 252

Walker 21580 Vertical 644 252

Walker 21581 Vertical 881 252

Walker 21581 Horizontal 842 252

Walker 21582 Vertical 1,200 252

Walker 21582 Horizontal 1,177 252

Walker 21584 Vertical 1,630 252

Walker 21584 Horizontal 1,275 252

Walker 21585 Inverted 28 252 See Nelson T-12825F

Walker 22005 Horizontal 2,020 252

Walker 22005 Vertical 2,040 252

Walker 35807 Horizontal 123 252

Walker 35807 Vertical 124 252

Washington Iron Works No.3 Vertical 615 252 Discontinued

White Brothers E-Series #2000 Horizontal 300 253 Disc type, closed endcap disc must be in place

Wintec 500 Horizontal 71 253

Xducer See SUPERTRAPP ~ ~ 253 See SUPERTRAPP

Xdusor ll Horizontal 155 253 Modified Xdusor X-100

Xdusor X-100 Horizontal 102 253

Yamaha EG 100A Horizontal 33 253

Yamaha EG 100B Horizontal 26 253

Yamaha EG 102A Horizontal 46 253 Not qualified for use above rated flow

Yamaha EG 102B Horizontal 45 253 Not qualified for use above rated flow

Yamaha EG 103A Vertical 27 254

Yamaha EG 103B Vertical 27 254

Yamaha EG 104A Vertical 22 254 Not qualified for use above rated flow

Yamaha EG 104B Vertical 20 254

Yamaha EG 105A Inverted 19 254 Not qualified for use above rated flow

Yamaha EG 106 Horizontal 13 254

Yamaha EG 107 Horizontal 44 252

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

Yamaha EG 108 Horizontal 29 255

Yamaha EG 109 Horizontal 25 255

Yamaha EG 110 Inverted 72 255

Yamaha EG 111 Horizontal 15 255

Yamaha EG 113 Multiple 26 255 Screen; 4-cycle, 5 hp or smaller

Yamaha EG 114 Multiple 54 255 Screen; 4-cycle, 11 hp or smaller

Yamaha EG 116 Multiple 25 256 Screen; 4-cycle, 5 hp or smaller

Yamaha EG 117 A Multiple 37 256 Screen; 4-cycle, 6.6 hp or smaller

Yamaha EG 118 Multiple 26 256 Screen type, 4-stroke, 4.5 hp or smaller

Yamaha EG 119 Multiple 26 256 Screen type, 4-stroke, 4.5 hp or smaller

Yamaha EG 120 Multiple 54 257 Screen type

Yamaha LG 101 Multiple 60 257 Screen; 4-cycle, 12 hp or smaller

Yamaha LG 102 Multiple 87 257 Screen; 4-cycle, 18 hp or smaller

Yamaha YHM 167A Horizontal 35 258

Yamaha YHM 167B Horizontal 31 258

Yamaha YHM 200 Horizontal 50 258

Yamaha YHM 200A Horizontal 49 258

Yamaha YHM 200B Horizontal 64 258

Yamaha YHM 220 Horizontal 45 258

Yamaha YHM 220A Horizontal 44 258

Yamaha YHM 220B Horizontal 53 ~

Yamaha YHM 220C Horizontal 57 ~

Yamaha YHM 238 Horizontal 64 ~

Yamaha YHM 238A Horizontal 63 ~

Yamaha YHM 238B Horizontal 41 ~

Yamaha YHM 238C Horizontal 41 ~

Yamaha YHM 238D Horizontal 54 ~

Yamaha YHM 238E Horizontal 72 ~

Yamaha YHM 238G Horizontal 63 258 See YHM 238A & YHM 238F

Yamaha YHM 270 Horizontal 77 ~

Yamaha YHM 270A Horizontal 100 259

Yamaha YHM 270B Horizontal 100 259

Yamaha YMS 125 Multiple 62 ~ Screen type

1406

1407

1408

1409

1420

1421

1422

1423

1424

1425

1426

1427

1428

1429

1430

1431

1432

1433

1434

1435

1436

1437

1439

1440

1441

1442

1443

1444

1445

1446

1447

1448

1449

2000 QUALIFIED AND RATED LIST—GENERAL PURPOSE SPARK ARRESTER

MANUFACTURER AND MODEL APPL POS FLOW PAGE REMARKS

1450

1451

1452

1454

1455

1456

1457

1458

1459

1460

1461

1462

1463

1464

1465

1466

1467

1468

1469

1470

1471

1472

1473

1474

1475

Yamaha YMS 50 Multiple 28 ~ Screen; 2-cycle, 5.8 hp or smaller

Yamaha YMS 50A Multiple 27 ~ Screen; 2-cycle, 5.8 hp or smaller

Yamaha YMS 400 Multiple 150 260 Screen type

Yamaha YMS 400A Multiple 150 260 Screen type

Yamaha-Krizman KS-250 Horizontal 24 261

Yamaha-Krizman KS-250A Horizontal 20 261

Yamaha-Krizman KS-350 Horizontal 58 261

Yamaha-Krizman KS-350A Horizontal 54 261

Yamaha-Krizman KS-350B Horizontal 32 261

Yamaha-Krizman KS-350C Horizontal 23 261

Yamaha-Krizman KS-375 Horizontal 79 261 Modified KS-400

Yamaha-Krizman KS-375A Horizontal 75 262

Yamaha-Krizman KS-375B Horizontal 55 262

Yamaha-Krizman KS-375C Horizontal 70 262

Yamaha-Krizman KS-375D Horizontal 71 262

Yamaha-Krizman KS-375E Horizontal 63 262

Yamaha-Krizman KS-375F Horizontal 54 262

Yamaha-Krizman KS-375G Horizontal 47 263

Yamaha-Krizman YS-80 Horizontal 24 263 Discontinued

Yamaha-Krizman YS-125 Horizontal 42 263 Discontinued

Yamaha-Krizman YS-250 Horizontal 20 263 Discontinued

Yamaha-Krizman YSU-80 Horizontal 24 263 Discontinued

Yamaha-Skyway Series 300 Mod 520 Horizontal 89 264 Not qualified for use above rated flow

Yoshimura YRD-1Q Horizontal 176 ~ Fiberglass packing must be in place for the full length of

the perforated tube.

Yoshimura YRD-2L Horizontal 176 264 Fiberglass packing must be in place for the full length of

the perforated tube.

Yuba 8000 Vertical 740 264

2000 QUALIFIED AND RATED LIST FOOTNOTES—GENERAL

PURPOSE SPARK ARRESTER

* = Donaldson Company, Inc., Early models may carry a “-1”

at the end of this number.

** = Super Trapp Industries, Units qualify regardless of the number

of discs used. The assigned flow rates were obtained using 18

discs. Fewer discs will give a lower flow rate and more discs will

give a higher flow rate. Nest discs so dimples interlock and tighten

retainer bolt so discs are not loose. Frequent cleaning may be

necessary to avoid plugging.

Note: Hapco models were formerly labeled Harco. Model

designations may contain a dash followed by number(s) and

letters. These signify the inlet size opening, application, and/

or thread type. Moderate inlet size differences are acceptable

from the dimensions indicated on the drawings for

identification in the next section.

A DESCRIPTION OF THE TERMS USED IN THE GENERAL

PURPOSE SPARK ARRESTER 1994 QUALIFIED

AND RATED LIST FOLLOWS:

Manufacturer Manufacturer of the spark arrester.

Model Assigned approved arrester model number, not to be

confused with the manufacturer's stock number.

Appl Pos Only qualified position of application.

Flow Rated flow of the arrester in cubic feet per minute

(cfm).

Remarks Additional information needed to identify the ar-

rester.

Screen Screen with openings of 0.023-inch or smaller,

should be present if indicated.

Cycle Number of engine stroke cyles; ie. four cycle en-

gine.

CHART I EXHAUST FLOW IN CUBIC FEET PER MINUTE AT MAXIMUM RATINGS1

FOR 4-CYCLE DIESEL ENGINES2

RPM3

Revolutions Per Minute

16 1

33 2

49 3

66 4

82 5

94 6

115 7

131 8

148 9

164 10

328 20

492 30

656 40

820 50

984 60

1,148 70

1,312 80

1,475 90

1,639 100

3,279 200

4,918 300

6,557 400

8,197 500

9,836 600

11,475 700

13,115 800

14,754 900

16,393 1,000

cm. inches 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 Differential

011111 111 12 2 0

111222 223 33 3 0

122233 344 45 5 0

223344 455 66 7 0

233445 667 78 8 1

334556 778 9910 1

345567 899101112 1

4 4 5 6 7 8 9 10 11 12 13 13 1

4 5 678 9101112131415 1

4 6 7 8 9 10 11 12 13 15 16 17 1

9 11 131618 20 22 25 27 2931 34 2

13 17 20 24 27 30 34 37 40 44 47 51 3

18 22 27 31 36 40 45 49 54 58 63 67 4

22 28 34 39 45 51 56 62 67 73 79 84 6

27 34 40 47 54 61 67 74 81 88 94 101 7

31 39 47 55 63 71 79 87 94 102 110 118 8

36 45 54 63 72 81 90 99 108 117 126 135 9

40 51 61 71 81 91 101 111 121 131 142 152 10

45 56 67 79 90 101 112 124 135 146 157 169 11

90 112 135 157 180 202 225 247 270 292 314 337 22

135 168 202 236 270 303 337 371 404 438 472 506 34

180 225 270 315 360 404 449 494 539 584 629 674 45

224 281 337 393 449 505 562 618 674 732 786 843 56

269 337 405 472 539 606 674 742 809 876 944 1,011 67

314 393 472 550 629 708 786 865 944 1,023 1,101 1,180 79

359 449 540 629 719 809 899 989 1,079 1,169 1,258 1,348 90

404 506 607 708 809 910 1,011 1,113 1,213 1,315 1,415 1,517 101

449 562 674 786 899 1,011 1,124 1,236 1,348 1,461 1,573 1,685 112

Engine

Displacement

cubic cubic

1Volumetric efficiency 80%; exhaust temperatures 900°F.

2For 2-cycle engines, multiply value by 2; for 2-cycle supercharged engines, multiply value by 3.25; for 4-cycle supercharged

engines, multiply value by 1.25.

3The "RPM Differential" column gives the difference between RPM columns for interpolation purposes. Entries are

to the nearest whole number.

General— All chart values are proportional, so a flow can be calculated for a 1000-cubic-inch engine by doubling

the flow figure for an identical engine but with 500-cubic-inch displacement. The same rule applies to revolutions

per minute. Therefore, a flow can be calculated for a 3000 maximum rpm engine by doubling the flow value of an

identical engine but with 1500 maximum rpm.

This chart may also be used like an interest table. If the engine has a cubic inch displacement of 438 at 2600 revolutions

per minute select readings from 400, 30, and 8 at 2600 rpm. The sum of these is the flow rate. When revolutions

per minute fall between columns, ie., 1600 to 1800. 1800 to 2000, etc., take the next highest rpm column. To be

more exact interpolate by using the "RPM Differential" value.

EXAMPLE: A 4-cycle diesel engine has a total displacement of 633 cubic inches. If its maximum rpm is 2600, what

is the maximum exhaust flow?

Solution— 600 cu. in. displacement @ 2600 rpm=876; 30=44; and 3=4; Sum=924 cfm.

1600 1800 2000 2200 2400 2600 2800 3000 3200 3400 3600

Revolutions Per Minute RPM3

Differ-

ential

Engine

Displacement

cubic cubic

11122222222 0

22333444455 0

34455566777 0

4556778891011 1

5678891010111212 1

778910111212131415 1

8 9 10 11 12 12 13 14 15 16 17 1

910111213141516181920 1

10 11 12 14 15 16 17 18 20 21 22 1

11 12 14 15 16 18 19 21 22 23 25 1

22 25 28 30 33 36 38 41 44 47 49 3

33 37 41 45 49 54 58 62 66 70 74 4

44 49 55 60 66 71 77 82 88 93 99 6

55 62 69 75 82 89 96 103 110 117 123 7

66 74 82 90 99 107 115 123 132 140 148 8

77 86 96 106 115 125 134 144 153 163 173 10

88 99 110 121 132 143 153 164 175 186 197 11

99 111 123 136 148 160 173 185 197 210 222 12

110 123 137 151 164 178 192 206 219 233 247 14

219 247 275 301 329 356 383 411 438 466 493 27

329 370 411 452 493 536 575 617 658 699 740 41

438 493 548 603 658 712 767 822 877 931 986 55

548 617 685 754 822 891 959 1,028 1,096 1,165 1,233 69

658 740 822 904 986 1,068 1,151 1,233 1,315 1,397 1,479 82

767 863 959 1,055 1,151 1,247 1,343 1,439 1,534 1,630 1,726 96

877 986 1,096 1,205 1,315 1,425 1,534 1,644 1,753 1,863 1,973 110

986 1,110 1,233 1,356 1,480 1,603 1,726 1,850 1,973 2,096 2,219 123

1,096 1,233 1,370 1,507 1,644 1,781 1,918 2,055 2,192 2,329 2,466 137

cm. inches

CHART II EXHAUST FLOW IN CUBIC FEET PER MINUTE AT MAXIMUM RATINGS1

FOR 4-CYCLE GASOLINE OR PROPANE NATURALLY ASPIRATED ENGINES2

16 1

33 2

49 3

66 4

82 5

94 6

115 7

131 8

148 9

164 10

328 20

492 30

656 40

820 50

984 60

1,148 70

1,312 80

1,475 90

1,639 100

3,279 200

4,918 300

6,557 400

8,197 500

9,836 600

11,475 700

13,115 800

14,754 900

16,393 1,000

1Volumetric efficiency 80%; exhaust temperatures 1200°F.

2For 2-cycle engines, multiply value by 2 and for 4-cycle supercharged engines, multiply value by 1.25.

3The "RPM Differential" column gives the difference between RPM columns for interpolation purposes. Entries are

to the nearest whole number.

General— All chart values are proportional, so a flow can be calculated for a 1000-cubic-inch engine by doubling

the flow figure for an identical engine but with 500-cubic-inch displacement. The same rule applies to revolutions

per minute. Therefore, a flow can be calculated for a 3600 maximum rpm engine by doubling the flow value of an

identical engine but with 1800 maximum rpm.

This chart may also be used like an interest table. If the engine has a cubic inch displacement of 438 at 2600 revolutions

per minute select readings from 400, 30, and 8 at 2600 rpm. The sum of these is the flow rate. When revolutions

per minute fall between columns, ie., 1600 to 1800. 1800 to 2000, etc., take the next highest rpm column. To be

more exact interpolate by using the "RPM Differential" value.

EXAMPLE: A 4-cycle gasoline engine has a total displacement of 133 cubic inches. If its maximum rpm is 3200,

what is the maximum exhaust flow?

Solution— 100 cu. in. displacement @ 3200 rpm=219; 30=66; and 3=7; Sum=292 cfm.

CHART III EXHAUST FLOW IN CUBIC FEET PER MINUTE AT MAXIMUM RATINGS1

FOR 4-CYCLE GASOLINE OR PROPANE NATURALLY ASPIRATED ENGINES2

SUCH AS MOTORCYCLES, TRAIL BIKES, AND SMALL ENGINES

ENGINE DISPLACEMENT IN CUBIC CENTIMETERS; RPM 3,400 TO 14,000 INCLUDED

Revolutions Per Minute

Engine

Displacement

cubic cubic

1Volumetric efficiency 80%; exhaust temperatures 1200°F.

2For 2-cycle engines, multiply value by 2.

General. —All chart values are proportional, so a flow can be calculated for a 1000-cubic-inch engine by doubling

the flow figure for an identical engine but with 500-cubic-inch displacement. The same rule applies to revolutions

per minute. Therefore, a flow can be calculated for a 3000 maximum rpm engine by doubling the flow value of an

identical engine but with 1500 maximum rpm.

The chart may also be used like an interest table. If a 2-cycle motorcycle has a cubic centimeter displacement of

125 at 7500 revolutions per minute, select readings from 100, 20, and 5 in the 8000 rpm column. The sum of these

is the flow rate for a 4-cycle engine. When revoltions per minute fall between columns, ie., 7000 to 8000, etc., take

the next highest column. To be more exact, interpolate. For the 2-cycle engine, multiply the chart value by two.

cm inches 3400 3600 3800 4000 5000 6000 7000 8000 9000 10000 12000 14000

1 .061 0 0 0000000 0 11

2 .122 0 0 0001111 1 11

3 .183 0 0 0111111 1 22

4 .244 1 1 1111112 2 22

5 .305 1 1 1111122 2 33

6 .366 1 1 1112222 3 34

7 .427 1 1 1112223 3 44

8 .488 1 1 1122233 3 45

9 .549 1 1 1222333 4 55

10 .610 1 2 2223334 4 56

16.1 1.00 2 2 3334556 7 89

20 1.22 3 3 3345678 81012

30 1.83 4 5 556891011131518

40 2.44 6 6 6 7 8 10 12 13 15 17 20 23

50 3.05 7 8 8 8 11 13 15 17 19 21 25 30

60 3.66 9 9 10 10 13 15 18 20 23 25 30 35

70 4.27 10 11 11 12 15 18 20 24 26 29 35 41

80 4.88 11 12 13 13 17 20 23 27 30 34 40 47

90 5.49 13 14 14 15 19 23 26 30 34 38 45 53

100 6.10 14 15 16 17 21 25 29 33 38 42 50 59

163.9 10.00 23 25 26 27 34 41 48 54 61 68 82 95

200 12.20 29 30 32 33 42 50 59 67 75 84 101 117

300 18.31 43 45 48 50 63 75 89 100 113 126 151 176

400 24.41 57 61 64 67 84 101 117 134 150 168 201 234

500 30.51 71 76 80 84 105 126 146 167 188 210 251 293

600 36.61 86 91 96 100 126 151 176 201 225 252 302 351

700 42.71 100 106 112 117 147 176 205 234 263 294 352 410

800 48.82 114 121 128 134 168 201 234 267 301 336 402 469

900 54.92 128 136 144 150 189 226 264 301 339 378 453 527

1,000 61.02 143 151 161 167 210 251 293 334 376 420 503 596

1,639 100.00 232 247 261 272 342 410 477 545 612 685 820 955

387 Sparkguide1

Navigation menu

Versions of this User Manual:

Views

Navigation
