Visit www.dell.com for more information
Dell™ Latitude™ D430
The Dell Latitude D430 notebook is an ideal lightweight solution for
business users who travel frequently. This “road warrior” notebook
enhances the previous-generation Latitude D420 with a memory boost
(minimum 1GB of onboard memory), a brighter WXGA panel and new
levels of choice and customization.
Featuring long battery life and excellent connectivity, the Latitude
D430 offers users plenty of performance on the go. Back in the office,
integrated Dell docking and expandability options help boost usage
options and convenience. IT can take advantage of the D-family’s
robust security, durability and peripheral commonality, plus the
flexibility of OS offerings — Microsoft® Windows Vista™ or Microsoft®
Windows® XP. In addition, the optional Solid State Drive can provide
fast boot and application launch time on Microsoft Windows Vista.
Bright, light and
distinctly mobile
Smart Security: Strategic, comprehensive endpoint solutions
· Advanced user identification options: integrated Smart Cards, optional
integrated fingerprint reader and/or passwords (even at pre-boot level)
· TPM 1.2 security chip enables a personal virtual drive for all of your
encrypted files
· Wave EMBASSY® Trust Suite works with the TPM for robust file folder
encryption and much more
RoadReady™: Designed, tested and built for quality
· Full magnesium-alloy construction for years of reliable performance
· Optional Solid State Drive has no moving parts, which can help
improve durability and reliability
· Strike Zone™ hard drive offers 24/7 data protection against life’s
bumps and bruises
HyperConnect™: Keeps users connected virtually anytime, anywhere1
· Wireless-N, based on 802.11n technology, with up to 5X the speed and
2X the range of traditional Wi-Fi® when used with a Wireless-N router2
· HyperBand Diversity Antenna delivers superior multi-band wireless
performance for mobile broadband and Wi-Fi
· Integrated Bluetooth® 2.0 with Enhanced Data Rate makes it easy
to connect personal devices
· Take advantage of Dell’s support for industry-leading mobile
broadband carriers
· Built-in Wi-Fi Catcher™ switch lets you quickly find a network, even
when the notebook is closed
1 Where wireless access is available. Additional access charges apply in some locations.
2 Speed claim for comparative purposes only. Actual speed varies with environment, equipment and other factors and will be less, while range may vary due to number of users, interference, transmission barriers (such as walls and building material),
and other factors. Intel Wireless-N card: To achieve up to 5X the speed and twice the range of 802.11g, customer must use the Intel Wireless-N card with a 5GHz Wireless-N router; with a 2.4GHz Wireless-N router, speed will be less. Based on Intel
testing using Chariot network testing tools in November 2006 on a notebook with an Intel 4965 Wireless-N card. Dell Wireless-N card: Wireless-N speed and range claims based on tests conducted by a third party testing company commissioned
by Dell in June 2006 comparing the Dell Wireless 1500 Draft 802.11n and the Intel 3945 802.11a/g internal wireless cards in a Dell XPS M1210 notebook.
Innovative Design: Advanced options and new levels of customization
· The latest Intel® Core™ 2 Duo processors
· Choice of Microsoft Windows Vista or Microsoft Windows XP
· Designed for frequent travelers with wide-screen panels and a thin,
lightweight form factor
· Energy-efficient systems designed to meet or exceed the worldwide mutually
recognized Environmental Protection Agency’s (EPA) ENERGY STAR® Standard
SYSTEM
Processor Type
Processor Features
Operating systems
Chipset
Memory
Display
External Display
Graphics
Hard Drives
Keyboard
Pointing Device
Audio
Dimensions
Weight5
POWER
Power Supply
Batteries
CONNECTIVITY
Wired
Mobile Broadband11
Wi-Fi
Bluetooth
EXPANDABILITY
PC Card
PCI-Express Card
I/O Ports
Media Base I/O Ports
Media Base Options
Docking
Modular Options
SECURITY
Physical Security
User & System Security
Network Security
MANAGEABILITY
Dell Client Manager
ACCESSORIES
Accessories
SERVICE & SUPPORT
Service & Support
Intel® Core™ 2 Duo processors 533 MHz Front Side Bus & 2MB Smart L2 Cache, Intel® Core™ Solo processors 533MHz Front Side Bus & 2MB Smart L2 Cache
Intel® Core™ 2 Duo processor U7600 (1.2GHz), U7500 (1.06GHz), Intel® Core™ Solo processor U1400 (1.2GHz)
Microsoft® Windows Vista™ Ultimate, Microsoft® Windows Vista™ Business, Microsoft® Windows Vista™ Home Basic,
Microsoft® Windows® XP Professional SP2, Microsoft® Windows® XP Home SP2, FreeDOS
Intel® 945GMS (533MHz front side bus) with Intel® onboard graphics
Min: 1GB DDR2 single channel shared3 533MHz; Max: 2GB4 DDR2 single channel shared3 533MHz
Wide-aspect 12.1" WXGA (1280x800 resolution) 220 nits
Supports up to a maximum resolution of WUXGA (1920x1200)
Mobile Intel® Graphics Media Accelerator 950 (up to 224 shared)
40, 60, 80GB4, 32GB Solid State
87-Key US, Canada, China; 88-Key Europe; 89-Key Brazil; 91-Key Japan Key travel 2.5mm; Key spacing 18.5mm
Touch pad - PS/2 compatible; Track stick-PS/2 compatible
High Definition Audio codec speaker, mono speaker, 1.0W, integrated omni-directional microphone
295mm x 209.8mm x 25.4mm (11.6" x 8.25" x 1")
Preliminary - Starting at ~1.36kg (~3.0lbs) with 4-cell battery
65 Watt or 90 Watt AC adapter with cord wrapping
Primary 4-cell/28 WHr "Smart" Lithium Ion battery featuring ExpressCharge™; Primary 6-cell/42 WHr "Smart" Lithium Ion battery featuring
ExpressCharge; Primary 9-cell/68 WHr "Smart" Lithium Ion battery, supports ExpressCharge with 90 watt AC adapter
56K6 v.92 Internal Modem; 10/100/1000 Gigabit7 Ethernet network interface adapter
Dell Wireless 5520 Mobile Broadband (Tri-band HSDPA 3.6) Mini-Card with service from AT&T (US) and Vodafone (select countries in Europe)
Dell Wireless 5720 Mobile Broadband (EVDO Rev A) Mini-Card with service from Verizon Wireless (US), Sprint (US) and Telus (Canada)
Dell Wireless 1390 (802.11g), Dell Wireless 1490 (802.11a/g), Dell Wireless 1505 (802.11a/g/Draft n), Intel PRO/Wireless 3945AG (802.11a/g),
Intel PRO/Wireless 4965AGN (802.11a/g/Draft n)
Dell Wireless 360 Bluetooth® internal wireless card (upgradable to Bluetooth® 2.1 EDR)
One Type I or Type II
34mm ExpressCard via USB interface through PCMCIA adapter
SD card slot, IEEE-1394, docking connector, 3 USB (one powered), VGA, headphone/speaker out, RJ-11, RJ-45, AC power
Serial, Parallel, VGA, DVI, 4 USB 2.0, RJ-45, HP out
9.5mm slim 24X CD-ROM or 8X DVD+/-RW9
D/Port , D/Dock, D/View Notebook Stand, D/Monitor Stand
24X CD-ROM, 8X DVD-ROM8, 24X CDRW/DVD, 8X DVD+/-RW9, Floppy Disk Drive, 80GB5 Hard Drive
Steel-reinforced Cable Lock Slot, Hard Drive locks
Integrated Smart Card reader; Trusted Platform Module (TPM) 1.2 and optional UPEK® fingerprint reader. Wave EMBASSY® Trust Suite by Wave
Systems security software
802.11 Wi-Fi Protected Access (WPA), 802.11i (WPA2), 802.1x with EAP modes, Single Sign On and compatible CCX 4.0
Helps make our workstations, desktops and notebooks some of the easiest and most cost-effective client systems you can own. DCM provides
centralized, remote control and automates common tasks associated with owning client systems. The results can be powerful: fewer deskside visits and
repetitive tasks, greater visibility and control of client inventory and usage, and improved consistency and compliance in the way client systems
are configured.
Latitude carrying cases and backpack, external USB keyboard and mouse, CRT and flat panel monitors
Service options may vary. Options may include Next Business Day On-Site Service10 and/or Mail-In-Service.
Dell™ Latitude™ D430
3 Up to 224MB of system memory may be allocated to support graphics, depending on system memory size and other factors.
4 For hard drives, GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
5 Preliminary starting weight with 4-cell battery, integrated graphics and 12.1" WXGA display. Weights vary depending on configurations and manufacturing variability.
6 Modem download speeds are limited to 56Kbps. Upload speeds are less (about 30Kbps). Speeds can vary by line condition and modem manufacturer. Analog phone line and service required.
7 The term Gigabit Ethernet does not connote an actual operating speed of 1GB/sec. For high speed transmission, connection to a Gigabit ethernet server and network infrastructure is required.
8 DVD-ROM drives may have write-capable hardware that has been disabled via firmware modifications.
9 Discs burned with this drive may not be compatible with some existing drives and players; using DVD+R media provides maximum compatibility.
10 Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts availability, geographical restrictions and terms of service contract. Service timing dependent upon time
of day call placed to Dell. U.S. only.
11 You must be a Sprint, Verizon Wireless or AT&T subscriber. Actual connectivity is subject to wireless service provider's coverage area and may be affected by equipment, topography, signal strength, environmental considerations, and other factors.
Service may vary significantly within buildings. Dell does not guarantee coverage.
Dell, the Dell logo, Latitude, RoadReady, HyperConnect, Wi-Fi Catcher, QuickSet, ExpressCharge, StrikeZone and CompleteCare are trademarks of Dell Inc. Intel and Core are trademarks or registered trademarks of Intel Corporation in the U.S. and
other countries. Microsoft, Windows and Windows Vista are trademarks or registered trademarks of Microsoft Corporation. ENERGY STAR is a registered trademark of the US Environmental Protection Agency. EMBASSY is a registered trademark of
Wave Systems Corp. UPEK is a registered trademark of UPEK, Inc. Other trademarks and trade names may be used in this document to refer to either entities claiming the marks and names of their products. Dell disclaims proprietary interest in the
names and marks of others. Copyright 2007 Dell Inc. All rights reserved. June 2007. A2G. 06DCPG168_0507
