TX

Powered Series TX9S

Overview

The TX9S is a large format, high output subwoofer with a full frequency

response (down to 30Hz) and longer excursion voice coils. The dual 18"

front loaded TX9S handles bundles of power and is perfect for those who

are looking for lots of low, low bass. The cost effective TX9S incorporates

rear mounted wheels for ease of transportation. The frequency response

of the TX9S makes it appropriate for use with all boxes in the TX line

including the TX4 and TX8. The TX9S is especially well suited as a music

playback subwoofer.

Features

• High efficiency, compact enclosure designs

• Dual 18" low frequency drivers

• Ultra-low distortion at extreme sound pressure levels

• Rock solid 13-ply Baltic birch enclosures with rigid bracing

• Excellent long distance projection

• Consistent box to box production using advanced quality

assurance methodology & CAD/CAM technology

• Fool proof protection & crossover networks using dependable and

simple to use yet advanced analog signal processors

• Speakon™ four and eight pin interconnects throughout

yorkville.com

TX

Powered Series

yorkville.com

Specifications

System Type Rectangular Subwoofer

Active or Passive Passive

Program Power (Watts) 1700

Nominal Impedance (Ohms) 4

Sensitivity (dB @1Watt/1m) 98

Max SPL (dB) 131

Frequency Response (Hz +/- 3dB) 30-130

LF Driver(s) 2 x 18 inch, cast frame

Inputs - Speakon 4-pin 2

Wheels 2

Bar Handles 8

Enclosure Materials 18mm / .71 inch - 13-ply baltic birch plywood

Grille 16 gauge perforated metal

Covering / Finish Black Ultrathane Paint

Dimensions (DWH xbackW, inches) 24.8 x 24 x 51

Dimensions (DWH xbackW,cm) 63 x 61 x 130

Weight (lbs/kg) 191.8 / 87

Specifications subject to change without notice

TX9S
