REPLACEMENT PARTS LIST

RESIDENTIAL ELECTRIC WATER HEATERS

WITH TECHNOLOGY

MODELS 172BPS (Cascade), 172EPS (Super Cascade)

I.D. Part # Description For Use With

Models Pg

1 TH3ZX006 Upper thermostat with reset all 6

2a TH3ZX001 High limit reset control all 6

2b TH3ZX002 Upper thermostat all 6

3 99001204-A Twist-lock flange all 6

4 18G0002 Square flange gasket all 6

5 10G38/80 Upper square flange element all 4

6 10G30/80 Middle square flange element all 4

7 18G0001 Thermostat bracket all 6

8 45000026-A Hexagonal head screw all 6

9 TH3ZX004 Middle thermostat all 6

10 18G0020 Plastic drain valve 172BPS 12

15000028-A Brass drain valve 172EPS

11 99000060-A Element access cover all 6

12 10G08/15 Lower square flange element all

13 TH3ZX004 Lower thermostat all 6

14 16000011-A Inlet nipple all 12

15 MS145510 Magnesium anode rod 172BPS 13

MS155520 Magnesium anode rod 172EPS

16 NP022302 Outlet nipple all 12

17 9000000 Brass tee fitting all

18 18G0022 T&P relief valve all 12

16

10

13

8

11

12 14

15

18

4

3

4

3

4

3

6

5

9

7

7

7

12a

2b

giantinc.com

40 Lesage Av, Montreal-East (Quebec) Canada H1B 5H3 • Telephone : 514 645-8893

• Fax : 514 640-0969
