ThinkGear SDK for .NET: Development Guide
and API Reference
Introduction
This guide will teach you how to use the ThinkGear SDK for .NET to write Windows apps that can
utilize bio-signal data from NeuroSky's bio-sensors. This will enable your Windows apps to receive and
use bio-signal data such as EEG acquired from NeuroSky's sensor hardware.
This guide (and the entire ThinkGear SDK for .NET) is intended for programmers who are already
familiar with standard .NET development using Microsoft Visual Studio. If you are not already familiar
with developing for .NET, please first visit http://www.microsoft.com/net to learn how to properly set
up your .NET development environment and create typical .NET apps.
If you are already familiar with creating typical .NET apps, then the next step is to make sure you
have downloaded the ThinkGear SDK for .NET. Chances are, if you're reading this document, then
you already have it and can access the full folder specific to the ThinkGear SDK for .NET.
ThinkGear SDK for .NET Contents
ThinkGear SDK for .NET: Development Guide and API Reference (this document)
●
libs/:
●
ThinkGear.dll library
❍
JayrockJson.dll supporting library
❍
NLog.dll supporting library
❍
NLog.xml and NLog.config configuration files
❍
NLog.LICENSE.txt and Jayrock.LICENSE.txt licence files
❍
TG-HelloEEG.exe - a reference build of the HelloEEG sample project
●
HelloEEG Sample Project source code
●
You will find the .dll, configuration files and 3rd party license documents in the libs/ folder. Copy
this entire folder into your project.
You will find the source code of the “HelloEEG Sample Project” in the Sample Projects/HelloEEG
folder.
Supported NeuroSky Hardware
The ThinkGear SDK for .NET can only be used with the following NeuroSky devices, chips, and
modules:
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
MindWave Mobile
●
MindWave (RF)
●
MindBand
●
ThinkCap
●
TGAM module
●
TGAT ASIC
●
Before using any Windows app that uses the ThinkGear SDK for .NET, make sure you have paired the
sensor hardware device to your Windows machine by carefully following the instructions in the User
Manual that came with each sensor hardware device! The sensor hardware device must properly
appear in your Windows machine's list of COM ports in Device Manager.
Your First Project: HelloEEG console
HelloEEG is a sample project we've included in the ThinkGear SDK for .NET that demonstrates how
to setup, connect, and handle data to a NeuroSky device. Add the project to your Visual Studio by
following these steps:
For Visual Studio:
from the Visual Studio Toolbar, select File –> New –> Project From Existing Code…1.
In the New Project From Existing Code wizard, select the project type of “Visual C#”2.
click the “Next >” button3.
browse to the place you have expanded the SDK files. (“ThinkGear SDK for .NET\Sample4.
Projects\HelloEEG”)
check the box to include subfolders.5.
enter a name of “HelloEEG”6.
choose Output type of “Console Application”7.
click the “Finish” button8.
at the Toolbar select Project –> HelloEEG Properties…9.
change the Assembly name to HelloEEG10.
set the Target framework to “.NET Framework 3.5”11.
if you are asked to Confirm the Framework change, click “Yes”12.
at the Toolbar select View –> Solution Explorer13.
in the Solution Explorer pane select and expand the “References” section14.
if you see a exclamation mark warning on “Microsoft.CSharp”, right click on the warning, and15.
“Remove” the reference to “Microsoft.CSharp”
select the “References” section, right click, pick “Add Reference..”16.
click the browse button, navigate to where you have expanded the SDK files, choose the folder17.
“neurosky” and then pick “ThinkGear.dll”
at the Toolbar select Build –> Build Solution18.
if there are no errors, you should be able to browse the code, make modifications, compile, and19.
run the app just like any typical .NET app.
2014/07/01 20:50 3/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
For Visual Studio Express:
From the Visual Studio Express Toolbar, select File –> Open Project1.
Navigate to where you have expanded the SDK files, and then to ThinkGear SDK for .NET\Sample2.
Projects\HelloEEG\
Select “HelloEEG.csproj” and click “Open”3.
From the Toolbar, select Build –> Build Solution4.
if there are no errors, you should be able to browse the code, make modifications, compile, and run5.
the app just like any typical .NET app.
These steps have been tested with Visual Studio and Visual Studio Express 2010/2013, if yours is
different you may have to adapt these instructions.
The TG-HelloEEG.exe reference program is built from these same sources and with the same process.
It is slightly different in that the Microsoft ILMerge program has been used to incorporate the dlls from
the /neurosky folder into the .exe so that it can function in a more standalone way.
Developing Your Own NeuroSky Sensor Apps
for .NET
Preparing Your .NET Project
The ThinkGear SDK for .NET's API is made available to your application via the
NeuroSky.ThinkGear namespace. The ThinkGear.dll gives your .NET application access to the
NeuroSky.ThinkGear namespace.
The ThinkGear.dll
To start with, add the ThinkGear.dll file to your .NET application's project workspace. The
ThinkGear.dll is a C# .NET library, and can only be used as part of .NET projects (it will not work in
native projects). This .dll contains the NeuroSky.ThinkGear namespace.
The NeuroSky.ThinkGear Namespace
The ThinkGear SDK for .NET's API is made available to your application via the
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
NeuroSky.ThinkGear namespace. Once you have added the ThinkGear.dll file to your project,
you can then add the following code to the top of your application to access the
NeuroSky.ThinkGear namespace:
using NeuroSky.ThinkGear;
Using the NeuroSky.ThinkGear Namespace
The NeuroSky.ThinkGear namespace consists of two classes:
Connector - Connects to the computer's serial COM port and reads in the port's serial stream of
●
data as DataRowArrays.
TGParser - Parses a DataRowArray into recognizable ThinkGear Data Types that your application
●
can use.
To use the classes, first declare a Connector instance and initialize it:
private Connector connector;
connector = new Connector();
Next, create EventHandlers to handle each type of Connector Event, and link those handlers to the
Connector events.
connector.DeviceConnected += new EventHandler( OnDeviceConnected );
connector.DeviceFound += new EventHandler( OnDeviceFound );
connector.DeviceNotFound += new EventHandler( OnDeviceNotFound );
connector.DeviceConnectFail += new EventHandler( OnDeviceNotFound );
connector.DeviceDisconnected += new EventHandler( OnDeviceDisconnected );
connector.DeviceValidating += new EventHandler( OnDeviceValidating );
In the handler for the DeviceConnected event, you should create another EventHandler to handle
DataReceived events from the Device, like this:
void OnDeviceConnected( object sender, EventArgs e ) {
Connector.DeviceEventArgs deviceEventArgs = (Connector.DeviceEventArgs)e;
Console.WriteLine( "New Headset Created." + deviceEventArgs.Device.
DevicePortName );
deviceEventArgs.Device.DataReceived += new EventHandler( OnDataReceived );
}
Now, whenever data is received from the device, the DataReceived handler will process that data.
Here is an example OnDeviceReceived() that shows how it can do this, using a TGParser to parse
the DataRow[]:
2014/07/01 20:50 5/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
void OnDataReceived( object sender, EventArgs e ){
/* Cast the event sender as a Device object, and e as the Device's
DataEventArgs */
Device d = (Device)sender;
Device.DataEventArgs de = (Device.DataEventArgs)e;
/* Create a TGParser to parse the Device's DataRowArray[] */
TGParser tgParser = new TGParser();
tgParser.Read( de.DataRowArray );
/* Loop through parsed data TGParser for its parsed data... */
for( int i=0; i<tgParser.ParsedData.Length; i++ ) {
// See the Data Types documentation for valid keys such
// as "Raw", "PoorSignal", "Attention", etc.
if( tgParser.ParsedData[i].ContainsKey("Raw") ){
Console.WriteLine( "Raw Value:" + tgParser.ParsedData[i]["Raw"] );
}
if( tgParser.ParsedData[i].ContainsKey("PoorSignal") ){
Console.WriteLine( "PQ Value:" + tgParser.ParsedData[i][
"PoorSignal"] );
}
if( tgParser.ParsedData[i].ContainsKey("Attention") ) {
Console.WriteLine( "Att Value:" + tgParser.ParsedData[i][
"Attention"] );
}
if( tgParser.ParsedData[i].ContainsKey("Meditation") ) {
Console.WriteLine( "Med Value:" + tgParser.ParsedData[i][
"Meditation"] );
}
}
}
When you would like to begin the Mental Effort and/or Familiarity 1) calculations, use the connector
to enable them:
connector.setMentalEffortEnable(true);
connector.setTaskFamiliarityEnable(true);
Once you have the handlers set up as described above, you can have your Connector actually
connect to a device/headset/COM port by using one of the Connect methods described in Connect to a
device below. If the portName is valid and the connection is successful, then your OnDataReceived()
method will automatically be called and executed whenever data arrives from the headset.
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
Before exiting, your application must close the Connector's open connections by calling the
Connector's close() method.
connector.close();
If close() is not called on an open connection, and that connection's process is still alive (i.e. a
background thread, or a process that only closed the GUI window without terminating the process
itself), then the headset will still be connected to the process, and no other process will be able to
connect to the headset until it is disconnected.
Events
If you choose to connect by stating a specific COM port, it will take the following steps:
connector.Connect(portName);1.
connector.Connect in turn validates the COM port. So the DeviceValidating event is triggered2.
if the COM port was valid, it connects to the device. The DeviceFound event is never triggered3.
if the COM port was invalid, the DeviceNotFound event is triggered.4.
If you choose to connect by using the AUTO approach, it will take the following steps:
connector.Find();1.
if it is able to find a COM port with valid ThinkGear Packets, it triggers DeviceFound. Otherwise, the2.
DeviceNotFound event is triggered
the OnDeviceFound method in turn calls connector.Connect(tempPortName); where tempPortName3.
is the valid COM port. This in turn calls DeviceValidating.
if the COM port was valid, it connects to the device.4.
if the COM port was invalid, the DeviceNotFound event is triggered.5.
Tips on using ThinkGear.NET
In order to connect quickly, your application should always remember across sessions the last COM
●
portName that was able to successfully connect, and try to connect to that same portName first
the next time a connection attempt is made. If that remembered portName is no longer valid or
unable to connect, then you can use ConnectScan( string portName ) method to find another
valid portName.
If an unexpected disconnection occurs, your application should try to reconnect automatically and
●
prompt the user to check their headset device for the following:
Battery is properly inserted into the headset device, and has sufficient charge (or try a new
❍
battery)
Headset device is turned on
❍
Headset device is properly paired in Bluetooth settings
❍
Headset device is within range of the Bluetooth receiver (within 10m unobstructed)
❍
2014/07/01 20:50 7/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
API Reference
Connector class
Methods
Connect to a device
void Connect(string portName)
Attempts to open a connection with the port name specified by portName. Calling this method results
in one of two events being broadcasted:
DeviceConnected - A connection was successfully opened on portName
●
DeviceConnectFail - The connection attempt was unsuccessful
●
void ConnectScan()
Attempts to open a connection to the first Device seen by the Connector. Calling this method results
in one of two events being broadcasted:
DeviceConnected - A connection was successfully opened on portName
●
DeviceConnectFail - The connection attempt was unsuccessful
●
void ConnectScan(string portName)
Same as ConnectScan but scans the port specified by portName first. Calling this method results in
one of two events being broadcasted:
DeviceConnected - A connection was successfully opened on portName
●
DeviceConnectFail - The connection attempt was unsuccessful
●
Disconnect from a device
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
void Disconnect()
Closes all open connections. Calling this method will result in the following event being broadcasted
for each open device:
DeviceDisconnected - The device was disconnected
●
void Disconnect(Connection connection)
Closes a specific Connection specified by connection. Calling this method will result in the following
event being broadcasted for a specific open device:
DeviceDisconnected - The device was disconnected
●
void Disconnect(Device device)
Closes a specific Device specified by device. Calling this method will result in the following event
being broadcasted for a specific open device:
DeviceDisconnected - The device was disconnected
●
Send bytes to a device
void Send(string portName, byte[] bytesToSend)
Sends an array of bytes to a specific port
Configure Mental Effort/Familiarity
void enableMentalEffort() DEPRECATED
Starts recording data for 60 seconds. Once the recording is complete, the Mental Effort will be
calculated. Note: the first time the Mental Effort 2) is calculated, the result is 0.
void enableFamiliarity() DEPRECATED
2014/07/01 20:50 9/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
Starts recording data for 60 seconds. Once the recording is complete, the Familiarity will be
calculated. Note: the first time the Familiarity is calculated, the result is 0.
Events
DeviceFound
Occurs when a ThinkGear device is found. This is where the application chooses to connect to that
port or not.
DeviceNotFound
Occurs when a ThinkGear device could not be found. This is usually where the application displays an
error that it did not find any device.
DeviceValidating
Occurs right before the connector attempts a serial port. Mainly used to notify the GUI which port it is
trying to connect.
DeviceConnected
Occurs when a ThinkGear device is connected. This is where the application links the OnDataReceived
for that device.
DeviceConnectFail
Occurs when the Connector fails to connect to that port specified.
DeviceDisconnected
Occurs when the Connector disconnects from a ThinkGear device.
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
DataReceived
Occurs when data is available from a ThinkGear device.
TGParser Class
The TGParser class is used to convert the received data into easily accessible data contained in a
Dictionary.
Methods
Dictionary<string, double>[] Read( DataRow[] dataRow )
Parses the raw headset data in dataRow and returns a dictionary of usable data. It also stores the
dictionary in the ParsedData property.
When connected to a MindWave, or MindWave Mobile headset, the Read() method can return the
following standard keys in its dictionary:
Key Description Data
Type
Time TimeStamps of packet received double
Raw Raw EEG data short
EegPowerDelta Delta Power uint
EegPowerTheta Theta Power uint
EegPowerAlpha1 Low Alpha Power uint
EegPowerAlpha2 High Alpha Power uint
EegPowerBeta1 Low Beta Power uint
EegPowerBeta2 High Beta Power uint
EegPowerGamma1 Low Gamma Power uint
EegPowerGamma2 High Gamma Power uint
Attention Attention eSense double
Meditation Meditation eSense double
PoorSignal Poor Signal double
BlinkStrength
Strength of detected blink. The Blink Strength ranges from 1 (small
blink) to 255 (large blink). Unless a blink occurred, nothing will be
returned. Blinks are only calculated if PoorSignal is less than 51.
uint
2014/07/01 20:50 11/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
Key Description Data
Type
Mental Effort (BETA)
Mental Effort measures how hard the subject’s brain is working, i.e.
the amount of workload involved in the task. Mental Effort algorithm
can be used for both within-trial monitoring (continuous real-time
tracking) and between-trial comparison. A trial can be of any length
equal to or more than 1 minute. In each trial, the first output index
will be given out after the first minute and new output indexes will
then be generated at time interval defined by the output rate
(default: 10s).
double
Familiarity (BETA)
Familiarity measures how well the subject is learning a new task or
how well his performance is with certain task. Familiarity algorithm
can be used for both within-trial monitoring (continuous real-time
tracking) and between-trial comparison. A trial can be of any length
equal to or more than 1 minute. In each trial, the first output index
will be given out after the first minute and new output indexes will
then be generated at time interval defined by the output rate
(default: 10s).
double
When connected to a ThinkCap, the Read() method can return the following keys in its dictionary:
Key Description Data Type
Time TimeStamps of packet received double
RawCh1 EEG Channel 1 short
RawCh2 EEG Channel 2 short
RawCh3 EEG Channel 3 short
RawCh4 EEG Channel 4 short
RawCh5 EEG Channel 5 short
RawCh6 EEG Channel 6 short
RawCh7 EEG Channel 7 short
RawCh8 EEG Channel 8 short
ThinkGear Data Types
The ThinkGear data types are generally divided into two groups: data types that are only applicable
for EEG sensor devices, and data types that are typically applicable to all ThinkGear-based devices.
General
These data types are generally available from most or all types of ThinkGear hardware devices.
POOR_SIGNAL/SENSOR_STATUS
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
This integer value provides an indication of how good or how poor the bio-signal is at the sensor. This
value is typically output by all ThinkGear hardware devices once per second.
This is an extremely important value for any app using ThinkGear sensor hardware to always read,
understand, and handle. Depending on the use cases for your app and users, your app may need to
alter the way it uses other data values depending on the current value of
POOR_SIGNAL/SIGNAL_STATUS. For example, if this value is indicating that the bio-sensor is not
currently contacting the subject, then any received RAW_DATA or EEG_POWER values during that
time should be treated as floating noise not from a human subject, and possibly discarded based on
the needs of the app. The value should also be used as a basis to prompt the user to possibly adjust
their sensors, or to put them on in the first place.
This updated version converts poorSignal values read from different hardware devices. It converts
them into a uniform format. (unlike earlier version of the SDK) If you have software that reacts to the
poorSignal value, you should evaluate that software to see if changes need to be made
Poor signal may be caused by a number of different things. In order of severity, they are:
Sensor, ground, or reference electrodes not being on a person's head/body
●
Poor contact of the sensor, ground, or reference electrodes to a person's skin
●
Excessive motion of the wearer (i.e. moving head or body excessively, jostling the headset/sensor).
●
Excessive environmental electrostatic noise (some environments have strong electric signals or
●
static electricity buildup in the person wearing the sensor).
Excessive biometric noise
●
For EEG modules, a certain amount of noise is unavoidable in normal usage of ThinkGear sensor
hardware, and both NeuroSky's filtering technology and algorithms have been designed to detect,
correct, compensate for, account for, and tolerate many types of signal noise. Most typical users who
are only interested in using the eSense™ values, such as Attention and Meditation, do not need to
worry as much about the POOR_SIGNAL Quality value, except to note that the Attention and
Meditation values will not be updated while POOR_SIGNAL is greater than zero, and that the headset
is not being worn while POOR_SIGNAL is higher than 128. The POOR_SIGNAL Quality value is more
useful to some applications which need to be more sensitive to noise (such as some medical or
research applications), or applications which need to know right away when there is even minor noise
detected.
RAW_DATA
This data type supplies the raw sample values acquired at the bio-sensor. The sampling rate (and
therefore output rate), possible range of values, and interpretations of those values (conversion from
raw units to volt) for this data type are dependent on the hardware characteristics of the ThinkGear
hardware device performing the sampling. You must refer to the documented development specs of
each type of ThinkGear hardware that your app will support for details.
As an example, the majority of ThinkGear devices sample at 512Hz, with a possible value range of
-32768 to 32767.
2014/07/01 20:50 13/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
As another example, to convert TGAT-based EEG sensor values (such as TGAT, TGAM, MindWave,
MindWave Mobile) to voltage values, use the following conversion:
(rawValue * (1.8/4096)) / 2000
RAW_MULTI
This data type is not currently used by any current commercially-available ThinkGear products. It is
kept here for backwards compatibility with some end-of-life products, and as a placeholder for
possible future products.
EEG
These data types are only available from EEG sensor hardware devices, such as the MindWave,
MindWave Mobile, MindBand, and TGAM chips and modules.
ATTENTION
This int value reports the current eSense™ Attention meter of the user, which indicates the intensity
of a user's level of mental “focus” or “attention”, such as that which occurs during intense
concentration and directed (but stable) mental activity. Its value ranges from 0 to 100. Distractions,
wandering thoughts, lack of focus, or anxiety may lower the Attention meter levels. See eSense
Meters below for details about interpreting eSense™ levels in general.
By default, output of this Data Value is enabled. It is typically output once a second.
MEDITATION
This unsigned one-byte value reports the current eSense™ Meditation meter of the user, which
indicates the level of a user's mental “calmness” or “relaxation”. Its value ranges from 0 to 100. Note
that Meditation is a measure of a person's mental levels, not physical levels, so simply relaxing all
the muscles of the body may not immediately result in a heightened Meditation level. However, for
most people in most normal circumstances, relaxing the body often helps the mind to relax as well.
Meditation is related to reduced activity by the active mental processes in the brain, and it has long
been an observed effect that closing one's eyes turns off the mental activities which process images
from the eyes, so closing the eyes is often an effective method for increasing the Meditation meter
level. Distractions, wandering thoughts, anxiety, agitation, and sensory stimuli may lower the
Meditation meter levels. See eSense Meters below for details about interpreting eSense™ levels in
general.
By default, output of this Data Value is enabled. It is typically output once a second.
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
eSense Meters
For all the different types of eSense™ (i.e. Attention, Meditation), the meter value is reported on a
relative eSense™ scale of 1 to 100. On this scale, a value between 40 to 60 at any given moment in
time is considered “neutral”, and is similar in notion to “baselines” that are established in
conventional EEG measurement techniques (though the method for determining a ThinkGear baseline
is proprietary and may differ from conventional EEG). A value from 60 to 80 is considered “slightly
elevated”, and may be interpreted as levels being possibly higher than normal (levels of Attention or
Meditation that may be higher than normal for a given person). Values from 80 to 100 are considered
“elevated”, meaning they are strongly indicative of heightened levels of that eSense™.
Similarly, on the other end of the scale, a value between 20 to 40 indicates “reduced” levels of the
eSense™, while a value between 1 to 20 indicates “strongly lowered” levels of the eSense™. These
levels may indicate states of distraction, agitation, or abnormality, according to the opposite of each
eSense™.
BLINK
This int value reports the intensity of the user's most recent eye blink. Its value ranges from 1 to 255
and it is reported whenever an eye blink is detected. The value indicates the relative intensity of the
blink, and has no units.
The Detection of Blinks must be enabled.
if (setBlinkDetectionEnabled(true)) {
// return true, means success
Console.WriteLine("HelloEEG: BlinkDetection is Enabled");
}
else {
// return false, meaning not supported because:
// + connected hardware doesn't support
// + conflict with another option already set
// + not support by this version of the SDK
Console.WriteLine("HelloEEG: BlinkDetection can not be Enabled");
}
The current configuration can be retrieved.
if (getBlinkDetectionEnabled()) {
// return true, means it is enabled
Console.WriteLine("HelloEEG: BlinkDetection is configured");
}
2014/07/01 20:50 15/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
else {
// return false, meaning not currently configured
Console.WriteLine("HelloEEG: BlinkDetection is NOT configured");
}
If these methods are called before the MSG_MODEL_IDENTIFIED has been received, it is considered
a request to be processed when the connected equipment is identified. It is possible to Enable this
feature and later find that it is no longer enabled. Once the connected equipment has been identified,
if the request is incompatible with the hardware or software it will be overridden and the
MSG_ERR_CFG_OVERRIDE message sent to provide notification.
EEG_POWER
This Data Value represents the current magnitude of 8 commonly-recognized types of EEG frequency
bands.
The eight EEG powers are: delta (0.5 - 2.75Hz), theta (3.5 - 6.75Hz), low-alpha (7.5 - 9.25Hz),
high-alpha (10 - 11.75Hz), low-beta (13 - 16.75Hz), high-beta (18 - 29.75Hz), low-gamma (31 -
39.75Hz), and mid-gamma (41 - 49.75Hz). These values have no units and are only meaningful for
comparison to the values for the other frequency bands within a sample.
By default, output of this Data Value is enabled, and it is output approximately once a second.
THINKCAP_RAW
This data type is not currently used by any current commercially-available ThinkGear products. It is
kept here for backwards compatibility with some end-of-life products, and as a placeholder for
possible future products.
MENTAL EFFORT (BETA)
Mental Effort is included in a Beta form. The Mental Effort Algorithm is not a formal inclusion of the
Developer Tools 2.5 release but can still be tested in your application design. Questions or feedback?
Email: support@neurosky.com
For the most up to date versions of this algorithm and the corresponding documentation, please refer
to http://developer.neurosky.com and any specific new algorithm preview packages.
When applied to single-channel EEG data collected from forehead area, the Mental Effort algorithm
measures the amount of workload exerted by subject's brain while performing a task (how hard the
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
subject’s brain is working while performing the task). The Mental Effort algorithm works well with both
motor (e.g. drawing) and mental (e.g. reciting) tasks. The algorithm can be used for monitoring a
subject's Mental Effort curve and changes in realtime (to see how their Mental Effort Index changes as
they're performing the task), or it can be used for studying their Mental Effort levels on a task across
separate sessions or days.
The Mental Effort algorithm must be applied to at least 1 minute of EEG data. A Mental Effort Index
will be output by the algorithm after the first 60s, and then every N seconds after that (N is the
predefined output rate; default: 10s).
A typical way to use the Mental Effort algorithm is for an application to prompt a subject to be
relaxing, with their eyes open, doing nothing, for the first 60s while taking the initial measurement.
The first Mental Effort Index value (reported after the first 60s) is kept by the application as a baseline,
against which subsequent Mental Effort Index values (by default received every 10s) can be
compared to determine relative percent changes (e.g. after relaxing for the first minute, the user
starts doing a specific task. Their Mental Effort Index decreases by -20% in the first 10s of the task
compared to the first minute baseline, and then goes down further to -35% in the next 10s of the task
compared to the first minute baseline, indicating their brain is doing less and less work in the first 20s.
After 40s, their Mental Effort Index goes back up to -5% from the first minute baseline, which may
indicate their brain is starting to do more work again at that point.)
Alternatively, another possible baseline measurement could be, instead of relaxing and doing nothing
during the first 60s, to rather have the subject start doing the task right away and regard the initial
part of the task as the baseline. You would then interpret the percentage changes accordingly,
knowing that the baseline is based on the initial 60s engaging in the task.
For presenting, studying, and interpreting the data, each reported Mental Effort Index (MEI) value can
be compared for percent changes either (1) against the baseline value, or (2) against the MEI value
immediately preceding it.
The Mental Effort Index is a floating point number with arbitrary units. This means the MEI numbers
have no meaning on their own, and take on meaning only when comparing percentage changes
between two or more values.
An example on how to use the algorithm could be found in the sample application – “HelloEEG”.
A few example tasks that the algorithm can to: arithmetic calculation (“Math 24” available in
http://www.24theory.com/, and “Addition Aliens Attack” available in <
http://www.imathgame.com/ChromeAddition.php>)
To use the Mental Effort algorithm 3) in the NeuroSky SDK/API library, it must first be enabled:
if (setMentalEffortEnable(true)) {
// return true, means success
Console.WriteLine("HelloEEG: MentalEffort is Enabled");
}
else {
// return false, meaning not supported because:
// + connected hardware doesn't support
// + conflict with another option already set
2014/07/01 20:50 17/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
// + not support by this version of the SDK
Console.WriteLine("HelloEEG: MentalEffort can not be Enabled");
}
At any time, the status of the algorithm (whether it is enabled) can be queried:
if (getMentalEffortEnable()) {
// return true, means it is enabled
Console.WriteLine("HelloEEG: MentalEffort is configured");
}
else {
// return false, meaning not currently configured
Console.WriteLine("HelloEEG: MentalEffort is NOT configured");
}
Using just setMentalEffortEnable(true), the algorithm will be executed exactly one time. The
execution begins as soon as 60 seconds of good data has been collected. After the results have been
reported, the algorithm becomes automatically disabled.
It is possible to configure the algorithm to run continuously:
if (setMentalEffortRunContinuous(true)) {
// return true, means success
Console.WriteLine("HelloEEG: MentalEffort Continuous operation");
}
else {
// return false, meaning not supported because:
// + connected hardware doesn't support
// + conflict with another option already set
// + not support by this version of the SDK
Console.WriteLine("HelloEEG: MentalEffort normal operation ");
}
Enabling Continuous Mode does not automatically also enable the algorithm itself; you must still call
setMentalEffortEnable(true) yourself.
The current Continuous Mode configuration can be retrieved.
if (getMentalEffortRunContinuous()) {
// return true, means it is enabled
Console.WriteLine("HelloEEG: MentalEffort Continuous operation");
}
else {
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
// return false, meaning not currently configured
Console.WriteLine("HelloEEG: MentalEffort normal operation");
}
If these methods are called before the MSG_MODEL_IDENTIFIED has been received, it is considered
a request to be processed when the connected equipment is identified. It is possible to Enable this
feature and later find that it is no longer enabled. Once the connected equipment has been identified,
if the request is incompatible with the hardware or software it will be overridden and the
MSG_ERR_CFG_OVERRIDE message sent to provide notification.
This algorithm is resource and computation intensive. If you need to run with the Debugger, be aware
that this calculation may take many minutes to complete when the debugger is engaged. It will
output its results only after its calculations are complete.
FAMILIARITY (BETA)
Familiarity is included in a Beta form. The Familiarity Algorithm is not a formal inclusion of the
Developer Tools 2.5 release but can still be tested in your application design. Questions or feedback?
Email: support@neurosky.com
When applied to single-channel EEG data collected from the forehead area, the Familiarity algorithm
measures how well a subject is learning a task, and correlates with how well his performance is with
certain tasks. The Familiarity algorithm works well with both motor (e.g. drawing) and mental (e.g.
reciting) tasks. The algorithm can be used for monitoring a subject's mental Familiarity curve and
changes in realtime (to see how their Familiarity Index changes as they're performing the task), or it
can be used for studying their Familiarity levels on a task across separate sessions or days.
The Familiarity algorithm must be applied to at least 1 minute of EEG data. A Familiarity Index will be
output by the algorithm after the first 60s, and then every N seconds after that (N is the predefined
output rate; default: 10s).
A typical way to use the Familiarity algorithm is for an application to prompt a subject to be relaxing,
with their eyes open, doing nothing, for the first 60s while taking the initial measurement. The first
Familiarity Index value (reported after the first 60s) is kept by the application as a baseline, against
which subsequent Familiarity Index values (by default received every 10s) can be compared to
determine relative percent changes (e.g. after relaxing for the first minute, the user starts doing a
specific task. Their Familiarity Index goes up to +20% in the first 10s of the task compared to the first
minute baseline, and then goes up to +35% in the next 10s of the task compared to the first minute
baseline. After 40s, their Familiarity Index may dip to -15% from the first minute baseline, which may
indicate they are no longer learning and absorbing the task as well, or may no longer be performing
optimally at the task.)
2014/07/01 20:50 19/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
Alternatively, another possible baseline measurement could be, instead of relaxing and doing nothing
during the first 60s, to rather have the subject start doing the task right away and regard the initial
part of the task as the baseline. You would then interpret the percentage changes accordingly,
knowing that the baseline is based on the initial 60s engaging in the task.
For presenting, studying, and interpreting the data, each reported Familiarity Index (FI) value can be
compared for percent changes either (1) against the baseline value, or (2) against the FI value
immediately preceding it.
The Familiarity Index is a floating point number with arbitrary units. This means the FI numbers have
no meaning on their own, and take on meaning only when comparing percentage changes between
two or more values.
A few example tasks that the algorithm can to: painting (“Color Pages” available in <
http://coloringkid.net/>) and dancing (“Just Dance” available in <
http://www.youtube.com/watch?v=4Hh7FY3n3wM>).
To use the Familiarity algorithm in the NeuroSky SDK/API library, it must first be enabled:
if (setTaskFamiliarityEnable(true)) {
// return true, means success
Console.WriteLine("HelloEEG: Familiarity is Enabled");
}
else {
// return false, meaning not supported because:
// + connected hardware doesn't support
// + conflict with another option already set
// + not support by this version of the SDK
Console.WriteLine("HelloEEG: Familiarity can not be Enabled");
}
At any time, the status of the algorithm (whether it is enabled) can be queried:
if (getTaskFamiliarityEnable()) {
// return true, means it is enabled
Console.WriteLine("HelloEEG: TaskFamiliarity is configured");
}
else {
// return false, meaning not currently configured
Console.WriteLine("HelloEEG: TaskFamiliarity is NOT configured");
}
Using just setTaskFamiliarityEnable(true), the algorithm will be executed exactly one time.
The execution begins as soon as 60 seconds of good data has been collected. After the results have
been reported, the algorithm becomes automatically disabled.
It is possible to configure the algorithm to run continuously:
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
if (setTaskFamiliarityRunContinuous(true)) {
// return true, means success
Console.WriteLine("HelloEEG: Familiarity Continuous operation");
}
else {
// return false, meaning not supported because:
// + connected hardware doesn't support
// + conflict with another option already set
// + not support by this version of the SDK
Console.WriteLine("HelloEEG: Familiarity normal operation ");
}
Enabling Continuous Mode does not automatically also enable the algorithm itself; you must still call
setTaskFamiliarityEnable(true) yourself.
The current Continuous Mode configuration can be retrieved:
if (getTaskFamiliarityRunContinuous()) {
// return true, means it is enabled
Console.WriteLine("HelloEEG: Familiarity Continuous operation");
}
else {
// return false, meaning not currently configured
Console.WriteLine("HelloEEG: Familiarity normal operation");
}
If these methods are called before the MSG_MODEL_IDENTIFIED has been received, it is considered
a request to be processed when the connected equipment is identified. It is possible to Enable this
feature and later find that it is no longer enabled. Once the connected equipment has been identified,
if the request is incompatible with the hardware or software it will be overridden and the
MSG_ERR_CFG_OVERRIDE message sent to provide notification.
This algorithm is resource and computation intensive. If you need to run with the Debugger, be aware
that this calculation may take many minutes to complete when the debugger is engaged. It will
output its results only after its calculations are complete.
2014/07/01 20:50 21/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
Proper App Design
Before releasing an app for real-world use, make sure your app considers or handles the following:
If your app's Handler receives a MSG_STATE_CHANGE Message with any value other than
●
STATE_CONNECTING or STATE_CONNECTED, it should carefully handle each possible error situation
with an appropriate message to the user via the app's UI. Not handling these error cases well in the
UI almost always results in an extremely poor user experience of the app. Here are some examples:
If a STATE_ERR_BT_OFF Message is received, the user should be prompted to turn on their
❍
Bluetooth adapter, and then they can try again.
If a STATE_ERR_NO_DEVICE Message is received, the user should be reminded to first pair their
❍
ThinkGear hardware device to their Android device's Bluetooth, according to the instructions they
received with their ThinkGear hardware device.
If a STATE_NOT_FOUND Message is received, the user should be reminded to check that their
❍
ThinkGear hardware device is properly paired to their Android device (same as the
STATE_ERR_NO_DEVICE case), and if so, that their ThinkGear hardware device is turned on, in
range, and has enough battery or charge.
See TGDevice States for more info.
❍
Always make sure your app is handling the POOR SIGNAL/SENSOR STATUS Data Type. It is output by
●
almost all ThinkGear devices, and provides important information about whether the sensor is
properly in contact with the user. If it is indicating some sort of problem (problem == not 0), then
your app should notify the user to properly wear the ThinkGear hardware device, and/or disregard
any other reported data values while the POOR SIGNAL/SENSOR STATUS continues to indicate a
problem, as appropriate for your app.
To make the user experience consistent, familiar, and easy-to-learn and use for end customers
●
across platforms and devices, your app should be designed to follow the guidelines and conventions
described in NeuroSky's App Standards.
Troubleshooting
There are currently no known issues. If you encounter any bugs or issues, please visit
http://support.neurosky.com, or contact support@neurosky.com.
If you need further help, you may visit http://developer.neurosky.com to see if there is any new
information.
To contact NeuroSky for support, please visit http://support.neurosky.com, or send email to
support@neurosky.com.
For developer community support, please visit our community forum on
http://www.linkedin.com/groups/NeuroSky-Brain-Computer-Interface-Technology-3572341
Last
update:
2014/07/01
20:49
thinkgear.net_sdk_dev_guide_and_api_reference http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
http://developer.neurosky.com/docs/ Printed on 2014/07/01 20:50
Important Notices
The algorithms included in this SDK are solely for promoting the awareness of personal wellness and
health and are not a substitute for medical care. The algorithms are not to be used to diagnose, treat,
cure or prevent any disease, to prescribe any medication, or to be a substitute for a medical device or
treatment. In some circumstances, the algorithm may report false or inaccurate results. The
descriptions of the algorithms or data displayed in the SDK documentation, are only examples of the
particular uses of the algorithms, and NeuroSky disclaims responsibility for the final use and display of
the algorithms internally and as made publically available.
The algorithms may not function well or may display accurate data if the user has a pacemaker.
Warnings and Disclaimer of Liability
THE ALGORITHMS MUST NOT BE USED FOR ANY ILLEGAL USE, OR AS COMPONENTS IN LIFE SUPPORT
OR SAFETY DEVICES OR SYSTEMS, OR MILITARY OR NUCLEAR APPLICATIONS, OR FOR ANY OTHER
APPLICATION IN WHICH THE FAILURE OF THE ALGORITHMS COULD CREATE A SITUATION WHERE
PERSONAL INJURY OR DEATH MAY OCCUR. YOUR USE OF THE SOFTWARE DEVELOPMENT KIT, THE
ALGORITHMS AND ANY OTHER NEUROSKY PRODUCTS OR SERVICES IS “AS-IS,” AND NEUROSKY DOES
NOT MAKE, AND HEREBY DISCLAIMS, ANY AND ALL OTHER EXPRESS AND IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, AND ANY WARRANTIES ARISING FROM A COURSE OF DEALING, USAGE, OR
TRADE PRACTICE.
IN NO EVENT SHALL NEUROSKY BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PROFITS OR INCOME, WHETHER OR NOT
NEUROSKY HAD KNOWLEDGE, THAT SUCH DAMAGES MIGHT BE INCURRED.
1) you may see older documents refer to this as “Task Difficulty”, which is the former name of the
Mental Effort algorithm
2) older documents refer to “Task Difficulty”, this name is replaced by “Mental Effort” which more
plainly describes the functionality
3) older documents may refer to the “Mental Effort” algorithm as “Task Difficulty”. The algorithm was
renamed because “Mental Effort” more accurately described what it was measuring and calculating.
From:
http://developer.neurosky.com/docs/ - NeuroSky Developer - Docs
Permanent link:
http://developer.neurosky.com/docs/doku.php?id=thinkgear.net_sdk_dev_guide_and_api_reference
Last update: 2014/07/01 20:49
2014/07/01 20:50 23/23 Introduction
NeuroSky Developer - Docs - http://developer.neurosky.com/docs/
Warnings and Disclaimer of Liability
THE ALGORITHMS MUST NOT BE USED FOR ANY ILLEGAL USE, OR AS COMPONENTS IN LIFE SUPPORT OR SAFETY DEVICES
OR SYSTEMS, OR MILITARY OR NUCLEAR APPLICATIONS, OR FOR ANY OTHER APPLICATION IN WHICH THE FAILURE OF THE
ALGORITHMS COULD CREATE A SITUATION WHERE PERSONAL INJURY OR DEATH MAY OCCUR. YOUR USE OF THE SOFTWARE
DEVELOPMENT KIT, THE ALGORITHMS AND ANY OTHER NEUROSKY PRODUCTS OR SERVICES IS “AS-IS,” AND NEUROSKY
DOES NOT MAKE, AND HEREBY DISCLAIMS, ANY AND ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND ANY WARRANTIES ARISING
FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL NEUROSKY BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT
NOT LIMITED TO LOSS OF PROFITS OR INCOME, WHETHER OR NOT NEUROSKY HAD KNOWLEDGE, THAT SUCH DAMAGES
MIGHT BE INCURRED.

Navigation menu
