FMU Export of a Python-driven
Simulation Program
Release 1.0.0rc15
LBNL - Building Technology and Urban Systems Division
Jun 22, 2018
CONTENTS
1 Introduction 1
2 Installation and Configuration 3
2.1 Software requirements .......................................... 3
2.2 Installation ................................................ 3
2.3 UnitTests ................................................. 4
2.4 Uninstallation .............................................. 5
3 Best Practice 7
3.1 Configuring the Simulator XML input file ................................ 7
3.2 Configuring the Python Wrapper Simulator ............................... 8
4 Creating an FMU 13
4.1 Command-line use ............................................ 13
4.1.1 Simulation model or configuration file ............................. 13
4.1.2 Reserved variable names .................................... 14
4.2 Outputs of SimulatorToFMU ....................................... 15
5 Development 17
6 Help 19
6.1 Compilation failed with Dymola ..................................... 19
6.2 Compilation failed with OpenModelica ................................. 19
6.3 Simulation failed when running Simulator.fmu .......................... 19
6.4 Simulation failed with Dymola FMUs .................................. 19
7 Notation 21
8 Glossary 23
9 Acknowledgments 25
10 Disclaimers 27
11 Copyright and License 29
11.1 Copyright ................................................. 29
11.2 License Agreement ............................................ 29
Python Module Index 31
i
ii
CHAPTER
ONE
INTRODUCTION
This user manual explains how to install and use SimulatorToFMU.
SimulatorToFMU is a software package written in Python which allows users to export a Python-driven simulation
program or script as a Functional Mock-up Unit (FMU) for model.simulator or co-simulation using the Functional
Mock-up Interface (FMI) standard version 1.0 or 2.0. This FMU can then be imported into a variety of simulation
programs that support the import of Functional Mock-up Units. In the remainder of this document, we define a
Python-driven simulation program, and a Python script as a Simulator.
Note: SimulatorToFMU generates FMUs that use the Python 2.7/ C API for interfacing with the simulators.
1
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
2 Chapter 1. Introduction
CHAPTER
TWO
INSTALLATION AND CONFIGURATION
This chapter describes how to install, configure, and uninstall SimulatorToFMU on Windows and Linux operating
systems. SimulatorToFMU is currently not supported on Mac OS.
Software requirements
To export a Simulator as an FMU, SimulatorToFMU needs:
1. Python and following dependencies:
• jinja2
• lxml
2. Modelica parser
3. C-Compiler
SimulatorToFMU has been tested with:
Python 2.7.12 (Linux) and 2.7.13 (Windows)
Three Modelica parsers
Dymola 2018 on Windows and Linux
JModelica 2.0 on Windows, and JModelica trunk version 9899 on Linux
OpenModelica 1.11.0 on Windows
C-Compiler: Microsoft Visual Studio 10 Professional
Installation
To install SimulatorToFMU, proceed as follows:
1. Add following folders to your system path:
Python installation folder (e.g. C:\Python27)
Python scripts folder (e.g. C:\Python27\Scripts),
Dymola executable folder (e.g. C:\Program Files(x86)\Dymola2018\bin)
JModelica installation folder (e.g. C:\JModelica.org-2.0)
3
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
OpenModelica executable folder (e.g. C:\OpenModelica1.11.0-32bit\bin)
You can add folders to your system path by performing following steps on Windows 8 or 10:
In Search, search for and then select: System (Control Panel)
Click the Advanced system settings link.
Click Environment Variables. In the section System Variables, find the PATH environment variable
and select it. Click Edit.
In the Edit System Variable (or New System Variable) window, specify the value of the PATH
environment variable (e.g. C:\Python27,C:\Python27\Scripts). Click OK. Close all
remaining windows by clicking OK.
Reopen Command prompt window for your changes to be active.
To check if the variables have been correctly added to the system path on Windows, type python,
dymola,pylab, or omc into a command prompt to see if the right version of Python, Dymola, JMod-
elica, or OpenModelica starts up.
Note:
To avoid adding Dymola, JModelica, or OpenModelica to the system path, provide the path to the
executables to SimulatorToFMU.py. See Command-line use for the lists of arguments of Simula-
torToFMU.
SimulatorToFMU sets the hidden Dymola 2018’s flag Advanced.
AllowStringParametersForFMU to true when exporting a simulation program/script
as an FMU. The flag is not available in older versions of Dymola. The flag is required to allow a
master algorithm to set the path to the configuration file of an FMU. See section Command-line use
for more details.
2. Install SimulatorToFMU by running
> pip install --user SimulatorToFMU
Note: Use the --user command line option to install SimulatorToFMU
so it can be installed in your Python 2.7 user installation directory and can
write files to your disk. The Python 2.7 user installation directory is typically
C:\Users\YourUserName\AppData\Roaming\Python\Python27\site-packages
on Windows, and /home/YourUserName/.local/lib/python2.7/site-packages on
Linux where YourUserName is your system login user name.
The installation directory should contain the following subdirectories:
bin/ (Scripts for running unit tests)
doc/ (Documentation sources)
fmus/ (FMUs folder)
parser/ (Python scripts, Modelica templates and XML validator files)
UnitTests
To test your installation run from the installation bin folder
4 Chapter 2. Installation and Configuration
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
> python runUnitTest.py
Uninstallation
To uninstall SimulatorToFMU, run
> pip uninstall SimulatorToFMU
2.4. Uninstallation 5
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
6 Chapter 2. Installation and Configuration
CHAPTER
THREE
BEST PRACTICE
This section explains to users the best practice in configuring a Simulator XML input file, and implementing the
Python wrapper which will interface with the Simulator.
Configuring the Simulator XML input file
To export a Simulator as an FMU, the user needs to write an XML file which contains the list of inputs, outputs
and parameters of the FMU. The XML snippet below shows how a user has to write such an input file. A template
named SimulatorModeldescritpion.xml which shows such a file is provided in the parser/utilities
installation folder of SimulatorToFMU. This template should be adapted to create new XML input file.
The following snippet shows an input file where the user defines 1 input and 1 output variable.
1<?xml version="1.0" encoding="UTF-8"?>
2<SimulatorModelDescription
3xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
4fmiVersion="2.0"
5modelName="simulator"
6description="Input data for a Simulator FMU"
7generationTool="SimulatorToFMU">
8<ModelVariables>
9<ScalarVariable
10 name="v"
11 description="Voltage"
12 causality="input"
13 type="Real"
14 unit="V"
15 start="0.0">
16 </ScalarVariable>
17 <ScalarVariable
18 name="i"
19 description="Current"
20 causality="output"
21 type="Real"
22 unit="A">
23 </ScalarVariable>
24 </ModelVariables>
25 </SimulatorModelDescription>
To create such an input file, the user needs to specify the name of the FMU (Line 5). This is the modelName which
should be unique. The user then needs to define the inputs and outputs of the FMUs. This is done by adding a
ScalarVariable into the list of ModelVariables.
To parametrize the ScalarVariable as an input variable, the user needs to
7
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
define the name of the variable (Line 10),
give a brief description of the variable (Line 11)
give the causality of the variable (input for inputs, output for outputs) (Line 12)
define the type of variable (Currently only Real variables are supported) (Line 13)
give the unit of the variable (Currently only Modelica units are supported) (Line 14)
give a start value for the input variable (This is optional) (Line 15)
To parametrize the ScalarVariable as an output variable, the user needs to
define the name of the variable (Line 18),
give a brief description of the variable (Line 19)
give the causality of the variable (input for inputs, output for outputs) (Line 20)
define the type of variable (Currently only Real variables are supported) (Line 21)
give the unit of the variable (Currently only Modelica units are supported) (Line 22)
Note: If Modelica units can’t be used (Line 14 and Line 22), then remove the unit field from the input file when
defining new ScalarVariable.
Configuring the Python Wrapper Simulator
To export a Simulator as an FMU, the user needs to write the Python wrapper which will interface with the Simulator.
The wrapper will be embedded in the FMU when the Simulator is exported and used at runtime on the target machine.
The user needs to extend the Python wrapper provided in parser/utilities/simulator_wrapper.py and
implements the function .simulator‘.
The following snippet shows the Simulator function.
1# Dummy Python-driven simulator
2class Simulator():
3"""
4Dummy simulator Python-driven simulator
5which increments in its doTimeSteo method the input values by 1.
6This class is for illustration purposes only.
7"""
8def __init__(self, configuration_file, time, input_names,
9input_values, output_names, write_results):
10 self.configuration_file =configuration_file
11 self.input_values =input_values
12
13
14 def doTimeStep(self, input_values):
15 """
16 This function increments the input variables by 1
17 """
18
19 return input_values +1
20
21 # Main Python function to be modified to interface with a simulator which has memory.
22 def.simulator(configuration_file, time, input_names,
8 Chapter 3. Best Practice
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
23 input_values, output_names, write_results,
24 memory):
25 """
26 Return a list of output values from the Python-based Simulator.
27 The order of the output values must match the order of the output names.
28
29 :param configuration_file (String): Path to the Simulator model or configuration
˓file
30 :param time (Float): Simulation time
31 :param input_names (Strings): Input names
32 :param input_values (Floats): Input values (same length as input_names)
33 :param output_names (Strings): Output names
34 :param write_results (Integers): Store results to file (1 to store, 0 else)
35 :param memory: Variable that stores the memory of a Python object
36
37 """
38
39 #######################################################################
40 # EDIT AND INCLUDE CUSTOM CODE FOR TARGET SIMULATOR
41 # Include body of the function used to compute the output values
42 # based on the inputs received by the simulator function.
43 # This will need to be adapted so it returns the correct output_values.
44 # If the list of output names has only one name, then only a scalar
45 # must be returned.
46 # The snippet shows how a Python object should be held in the memory
47 # This is done by getting the object from the.simulator function, modifying it,
48 # and returning it.
49 ########################################################################
50 # Since master algorithms need to some time call at the same time instant
51 # an FMU multiple times for event iteration. It is for efficient reasons
52 # good to catch the simulator input and outputs results, along with the current
53 # and past simulation times to determine when the Simulator needs to be
˓reinvoked.
54 if memory == None:
55 # Initialize the Python object
56 s=Simulator(configuration_file, time, input_names,
57 input_values, output_names, write_results)
58 memory ={'memory':s, 'tLast':time, 'outputs':None}
59 if not (input_values is None):
60 memory['inputsLast']=input_values
61 memory['outputs']=s.doTimeStep(input_values)
62 else:
63 # Return default output
64 memory['outputs']=1.0
65 memory['s']=s
66 else:
67 # Check if inputs values have changed
68 if not (input_values is None):
69 newInputs =sum([abs(m -n) for m, n in zip (input_values,
70 memory['inputsLast'])])
71 # Check if time has changed prior to updating the outputs
72 if(abs(time -memory['tLast'])>1e-6 or newInputs >0):
73 # Updtate the outputs of the Simulator
74 memory['outputs']=memory['s'].doTimeStep(memory['outputs'])
75 # Save last time
76 memory['tLast']=time
77 # Save last input values
78 memory['inputsLast']=input_values
3.2. Configuring the Python Wrapper Simulator 9
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
79 # Handle errors
80 if(memory['outputs']<0.0):
81 raise("The memory['outpus'] cannot be null")
82 # Save the output of the Simulator
83 output_values =memory['outputs']
84 #########################################################################
85 return [output_values, memory]
86
87 if __name__ == "__main__":
88 memory =None
89 print.simulator("dummy.csv",0.0,"v",None,"i",0, memory))
The arguments of the functions are in the next table
Arguments Description
configuration_fileThe Path to the Simulator model or configuration file
time The current simulation model time
input_names The list of input names of the FMU
input_values The list of input values of the FMU
output_names The list of output names of the FMU
output_values The list of output values of the FMU
write_results A flag for writing the simulation results to a file located in the working directory of the
importing tool.
memory A variable that holds the memory of a Python object This argument is required only if the
simulator has variables which have memory.
If the simulator does not have memory, then the function .simulator‘ will be defined as
1# Dummy Python-driven simulator
2class Simulator():
3"""
4Dummy simulator Python-driven simulator
5which increments in its doTimeSteo method the input values by 1.
6This class is for illustration purposes only.
7"""
8def __init__(self, configuration_file, time, input_names,
9input_values, output_names, write_results):
10 self.configuration_file =configuration_file
11 self.input_values =input_values
12
13
14 def doTimeStep(self, input_values):
15 """
16 This function increments the input variables by 1
17 """
18
19 return input_values +1
20
21 # Main Python function to be modified to interface with a simulator which has memory.
22 def.simulator(configuration_file, time, input_names,
23 input_values, output_names, write_results):
24 """
25 Return a list of output values from the Python-based Simulator.
26 The order of the output values must match the order of the output names.
27
28 :param configuration_file (String): Path to the Simulator model or configuration
˓file
10 Chapter 3. Best Practice
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
29 :param time (Float): Simulation time
30 :param input_names (Strings): Input names
31 :param input_values (Floats): Input values (same length as input_names)
32 :param output_names (Strings): Output names
33 :param write_results (Integers): Store results to file (1 to store, 0 else)
34
35 """
36
37 #######################################################################
38 # EDIT AND INCLUDE CUSTOM CODE FOR TARGET SIMULATOR
39 # Include body of the function used to compute the output values
40 # based on the inputs received by the simulator function.
41 # This will need to be adapted so it returns the correct output_values.
42 # If the list of output names has only one name, then only a scalar
43 # must be returned.
44 ########################################################################
45 # Since master algorithms need to some time call at the same time instant
46 # an FMU multiple times for event iteration. It is for efficient reasons
47 # good to catch the simulator outputs results, and use the current and past
48 # simulation times to determine when the Simulator needs to be reinvoked
49
50 # Call the Simulator
51 s=Simulator(configuration_file, time, input_names,
52 input_values, output_names, write_results)
53 if not (input_values is None):
54 output_values=s.doTimeStep(input_values)
55 else:
56 # Return default output value
57 output_values =1.0
58
59 # Handle errors
60 if(output_values <0.0):
61 raise("The memory['outpus'] cannot be negative.")
62 # Save the output of the Simulator
63 #########################################################################
64 return output_values
65
66 #if __name__ == "__main__":
67 # print.simulator("dummy.csv", 0.0, "v", 1.0, "i", 0))
Note:
The function .simulator‘ must return a list of output values which matches the order of the output names.
If the simulator has memory, then the function .simulator‘ must also return the memory.
The function .simulator‘ can be used to invoke external programs/scripts which do not ship with the FMU. The
external programs/scripts will have to be installed on the target machine where the FMU is run. See Creating
an FMU for details on command line options.
Once simulator_wrapper.py is implemented, it must be saved under a name of the form "modelname"
+"_wrapper.py", and its path used as required argument for SimulatorToFMU.py.
3.2. Configuring the Python Wrapper Simulator 11
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
12 Chapter 3. Best Practice
CHAPTER
FOUR
CREATING AN FMU
This chapter describes how to create a Functional Mockup Unit. It assumes you have followed the Installation and
Configuration instructions, and that you have created the Simulator model description file as well as the Python script
required to interface the Simulator following the Best Practice guidelines.
Command-line use
To create an FMU, open a command-line window (see Notation). The standard invocation of the SimulatorToFMU
tool is:
> python <scriptDir>SimulatorToFMU.py -s <python-scripts-path>
where scriptDir is the path to the scripts directory of SimulatorToFMU. This is the parser subdirectory of the
installation directory. See Installation and Configuration for details.
An example of invoking SimulatorToFMU.py on Windows is
# Windows:
> python parser\SimulatorToFMU.py -s parser\utilities\simulator_wrapper.py,d:\calc.py
Following requirements must be met when using SimulatorToFMU
All file paths can be absolute or relative.
If any file path contains spaces, then it must be surrounded with double quotes.
SimulatorToFMU.py supports the following command-line switches:
The main functions of SimulatorToFMU are
reading, validating, and parsing the Simulator XML input file. This includes removing and replacing invalid
characters in variable names such as *+- with _,
writing Modelica code with valid inputs and outputs names,
invoking a Modelica compiler to compile the Modelica code as an FMU for model.simulator or co-simulation
1.0 or 2.0.
The next section discusses requirements of some of the arguments of SimulatorToFMU.
Simulation model or configuration file
An FMU exported by SimulatorToFMU needs in certain cases a configuration file to run. There are two ways of
providing the configuration file to the FMU:
13
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
1. The path to the configuration file is passed as the command line argument "-c" of SimulatorToFMU.py. In this
situation, the configuration file is copied in the resources folder of the FMU.
2. The path to the configuration is set by the master algorithm before initializing the FMU.
Note: The name of the configuration variable is _configurationFileName. This name is reserved and should
not be used for FMU input and output names.
Depending on the tool used to export the FMU, following requirements/restrictions apply:
Dymola
If the path to the configuration file is provided, then Dymola copies the file to its resources folder and uses the
configuration file at runtime. In this case, the path to the configuration file can’t be set and changed by the
master algorithm.
If the configuration file is not provided, then the path to the configuration file must be set by the master algorithm
prior to initializing the FMU.
JModelica
If the path to the configuration file is provided, then JModelica will not copy it to the resources folder of the
FMU. Instead, the path to the configuration is hard-coded in the FMU. As a further restriction, the path to the
configuration file can’t be set and changed by the master algorithm.
These are known limitations in JModelica 2.0. The workaround is to make sure that the path of the configuration
file is the same on the machine where the FMU will be run.
If the configuration file is not provided, then SimulatorToFMU will issue a warning.
OpenModelica
If the path to a configuration file is provided, then OpenModelica will not copy it to the resources folder of the
FMU. Instead, the path to the configuration is hard-coded in the FMU. However, the path to the configuration
file can be set and changed by the master algorithm.
This is a known limitation in OpenModelica 1.11.0. The workaround is to either make sure that the path of the
configuration file is the same on the machine where the FMU will be run, or set the path of the configuration file
when running the FMU.
If the configuration file is not provided, then the path to the configuration file must be set by master algorithm
prior to initializing the FMU.
Reserved variable names
Following variables names are not allowed to be used as FMU input, output, or parameter names.
_configurationFileName: String variable name used to set the path to the Simulator model or configu-
ration file.
_saveToFile: Boolean variable used to set the flag for storing simulation results (true for storing, false else).
time: Internal FMU simulation time.
14 Chapter 4. Creating an FMU
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
If any of these variables is used for an FMU input, output, or parameter name, SimulatorToFMU will exit with an
error.
Outputs of SimulatorToFMU
The main outputs from running SimulatorToFMU.py consist of an FMU named after the modelName specified
in the input file, a zip file called "modelname" +".scripts.zip", and a zip file called "modelname" +".
binaries.zip". That is, if the modelName is called Simulator, then the outputs of SimulatorToFMU will
be Simulator.fmu,Simulator.scripts.zip, and Simulator.binaries.zip.
The FMU and the zip file are written to the current working directory, that is, in the directory from which you entered
the command.
"modelname" +".scripts.zip" contains the Python scripts that are needed to interface with the Simulator.
The unzipped folder must be added to the PYTHONPATH of the target machine where the FMU will be used.
"modelname" +".binaries.zip" contains subdirectories with binaries files that are needed to interface with
the Simulator. Subdirectories with binaries to be supported by the FMU must be added to the system PATH on
Windows or the LD_LIBRARY_PATH on Linux. That is, if the FMU is exported for Windows 32 bit, then the
subdirectory "win32" must be added to the system PATH of the target machine where the FMU is run.
Any secondary output from running the SimulatorToFMU tools can be deleted safely.
Note that the FMU itself is a zip file. This means you can open and inspect its contents. To do so, it may help to
change the “.fmu” extension to “.zip”.
Note:
FMUs exported using OpenModelica 1.11.0 needs significantly longer compilation/simulation time compared
to the tested versions of Dymola and JModelica.
FMUs exported using Dymola 2018 needs a Dymola runtime license to run. A Dymola runtime license is not
be needed if the FMU is exported with a version of Dymola which has the Binary Model Export license.
4.2. Outputs of SimulatorToFMU 15
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
16 Chapter 4. Creating an FMU
CHAPTER
FIVE
DEVELOPMENT
The development site of this software is at https://github.com/LBNL-ETA/SimulatorToFMU.
To clone the master branch, type
git clone https://github.com/LBNL-ETA/SimulatorToFMU.git
17
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
18 Chapter 5. Development
CHAPTER
SIX
HELP
This chapter lists potential issues encountered when using SimulatorToFMU.
Compilation failed with Dymola
If the export of the Simulator failed when compiling the model with Dymola, comment out "exit()"
in parser/utilities/SimulatorModelica_Template_Dymola.mos with "//exit()", and re-run
SimulatorToFMU.py to see why the complation has failed.
Compilation failed with OpenModelica
If the export of the Simulator failed when compiling the model with OpenModelica, check if the variable
OPENMODELICALIBRARY is defined in the Windows Environment Variables.
Note: OPENMODELICALIBRARY is the path to the libraries which are required by OpenModelica to compile
Modelica models.
Simulation failed when running Simulator.fmu
If the simulation failed with the exported FMU, check if the unzipped "modelname" +".scripts.zip", and the
subdirectories of "modelname" +".binaries.zip" were added to the PYTHONPATH, and the system PATH
(Windows) /LD_LIBRARY_PATH (Linux) respectively as described in Outputs of SimulatorToFMU.
Note: Any software or Python 2.7 module which is required to run the exported FMU will need to be installed on the
target machine where the FMU is run.
Simulation failed with Dymola FMUs
If an FMU exported using Dymola fails to run, check if the version of Dymola which exported the FMU had the
Binary Model Export license. The Binary Model Export license is required to export FMUs which can
be run without requiring a Dymola runtime license. You can also inspect the model description of the FMU to see if a
Dymola runtime license is required to run the FMU.
19
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
20 Chapter 6. Help
CHAPTER
SEVEN
NOTATION
This chapter shows the formatting conventions used throughout the User Guide.
The command-line is an interactive session for issuing commands to the operating system. Examples include a DOS
prompt on Windows, a command shell on Linux, and a Terminal window on MacOS.
The User Guide represents a command window like this:
# This is a comment.
> (This is the command prompt, where you enter a command)
(If shown, this is sample output in response to the command)
Note that your system may use a different symbol than “>” as the command prompt (for example, “$”). Furthermore,
the prompt may include information such as the name of your system, or the name of the current subdirectory.
21
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
22 Chapter 7. Notation
CHAPTER
EIGHT
GLOSSARY
Dymola Dymola, Dynamic Modeling Laboratory, is a modeling and simulation environment for the Modelica lan-
guage.
Functional Mock-up Interface The Functional Mock-up Interface (FMI) is the result of the Information Technology
for European Advancement (ITEA2) project MODELISAR. The FMI standard is a tool independent standard to
support both model.simulator and co-simulation of dynamic models using a combination of XML-files, C-
header files, C-code or binaries.
Functional Mock-up Unit A simulation model or program which implements the FMI standard is called Functional
Mock-up Unit (FMU). An FMU comes along with a small set of C-functions (FMI functions) whose input
and return arguments are defined by the FMI standard. These C-functions can be provided in source and/or
binary form. The FMI functions are called by a simulator to create one or more instances of the FMU. The
functions are also used to run the FMUs, typically together with other models. An FMU may either require the
importing tool to perform numerical integration (model.simulator) or be self-integrating (co-simulation). An
FMU is distributed in the form of a zip-file that contains shared libraries, which contain the implementation of
the FMI functions and/or source code of the FMI functions, an XML-file, also called the model description file,
which contains the variable definitions as well as meta-information of the model,additional files such as tables,
images or documentation that might be relevant for the model.
Modelica Modelica is a non-proprietary, object-oriented, equation-based language to conveniently model complex
physical systems containing, e.g., mechanical, electrical, electronic, hydraulic, thermal, control, electric power
or process-oriented subcomponents.
MODELISAR MODELISAR is an ITEA 2 (Information Technology for European Advancement) European project
aiming to improve the design of systems and of embedded software in vehicles.
PyFMI PyFMI is a package for loading and interacting with Functional Mock-Up Units (FMUs), which are compiled
dynamic models compliant with the Functional Mock-Up Interface (FMI).
Python Python is a dynamic programming language that is used in a wide variety of application domains.
23
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
24 Chapter 8. Glossary
CHAPTER
NINE
ACKNOWLEDGMENTS
The development of this documentation was supported by the Assistant Secretary for Energy Efficiency and Renewable
Energy, Office of Building Technologies of the U.S. Department of Energy, under contract No. DE-AC02-05CH11231.
The following people contributed to the development of this program:
Thierry Stephane Nouidui, Lawrence Berkeley National Laboratory
Michael Wetter, Lawrence Berkeley National Laboratory
25
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
26 Chapter 9. Acknowledgments
CHAPTER
TEN
DISCLAIMERS
This document was prepared as an account of work sponsored by the United States Government. While this document
is believed to contain correct information, neither the United States Government nor any agency thereof, nor The
Regents of the University of California, nor any of their employees, makes any warranty, express or implied, or
assumes any legal responsibility for the accuracy, completeness, or usefulness of any information, apparatus, product,
or process disclosed, or represents that its use would not infringe privately owned rights. Reference herein to any
specific commercial product, process, or service by its trade name, trademark, manufacturer, or otherwise, does not
necessarily constitute or imply its endorsement, recommendation, or favoring by the United States Government or any
agency thereof, or The Regents of the University of California. The views and opinions of authors expressed herein
do not necessarily state or reflect those of the United States Government or any agency thereof or The Regents of the
University of California.
27
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
28 Chapter 10. Disclaimers
CHAPTER
ELEVEN
COPYRIGHT AND LICENSE
Copyright
Copyright (c) 2017, The Regents of the University of California, through Lawrence Berkeley National Laboratory
(subject to receipt of any required approvals from the U.S. Dept. of Energy). All rights reserved.
If you have questions about your rights to use or distribute this software, please contact Berkeley Lab’s Innovation &
Partnerships Office at IPO@lbl.gov.
NOTICE. This Software was developed under funding from the U.S. Department of Energy and the U.S. Government
consequently retains certain rights. As such, the U.S. Government has been granted for itself and others acting on its
behalf a paid-up, nonexclusive, irrevocable, worldwide license in the Software to reproduce, distribute copies to the
public, prepare derivative works, and perform publicly and display publicly, and to permit others to do so.
License Agreement
Copyright (c) 2017, The Regents of the University of California, through Lawrence Berkeley National Laboratory
(subject to receipt of any required approvals from the U.S. Dept. of Energy). All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the
following conditions are met:
(1) Redistributions of source code must retain the above copyright notice, this list of conditions and the following
disclaimer.
(2) Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following
disclaimer in the documentation and/or other materials provided with the distribution.
(3) Neither the name of the University of California, Lawrence Berkeley National Laboratory, U.S. Dept. of Energy
nor the names of its contributors may be used to endorse or promote products derived from this software without
specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, IN-
CIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED
TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSI-
NESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CON-
TRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY
WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAM-
AGE.
29
FMU Export of a Python-driven Simulation Program, Release 1.0.0rc15
You are under no obligation whatsoever to provide any bug fixes, patches, or upgrades to the features, functionality
or performance of the source code (“Enhancements”) to anyone; however, if you choose to make your Enhancements
available either publicly, or directly to Lawrence Berkeley National Laboratory, without imposing a separate written
license agreement for such Enhancements, then you hereby grant the following license: a non-exclusive, royalty-free,
perpetual license to install, use, modify, prepare derivative works, incorporate into other computer software, distribute,
and sublicense such enhancements or derivative works thereof, in binary and source code form.
30 Chapter 11. Copyright and License
PYTHON MODULE INDEX
p
parser.SimulatorToFMU,13
31
INDEX
D
Dymola, 23
F
Functional Mock-up Interface, 23
Functional Mock-up Unit, 23
M
Modelica, 23
MODELISAR, 23
P
parser.SimulatorToFMU (module), 13
PyFMI, 23
Python, 23
32

Navigation menu
