1
D-Cube: Dense-Block Detection in Terabyte-Scale Tensors
Aug-6-2016
Kijung Shin
1 General Information
Version: 1.0
Date: Aug-6-2016
Authors: Kijung Shin, Bryan Hooi, Jisu Kim, and Christos Faloutsos
2 Introduction
D-Cube (Disk-based Dense-block Detection) is an algorithm for detecting dense blocks in web-scale
tensors. D-Cube has the following properties:
Scalable: D-Cube can handle large data not fitting in memory or even on a disk.
Fast: Even when data fit in memory, D-Cube outperforms its competitors in terms of speed.
Accurate: D-Cube gives high accuracy in real-world data as well as theoretical accuracy guarantees.
Detailed information about the method is explained in the following paper
Kijung Shin, Bryan Hooi, Jisu Kim, and Christos Faloutsos, “D-Cube: Dense-Block Detection in
Terabyte-Scale Tensors”, ACM International Conference on Web Search and Data Mining (WSDM)
2017, Cambridge, UK
3 Installation
This package requires the following software to be installed in the system and set in PATH.
Hadoop 1.x.x. from http://hadoop.apache.org
Java 1.6.x. or higher, preferably from sun
For compilation (optional), type ./compile.sh
For packaging (optional), type ./package.sh
For demo (optional), type make
2
4 Input File Format
The input file lists all tuples in a relation. Each line corresponds to a tuple and consists of dimension
attributes values and a measure attribute value, which are separated by a comma. Additionally, we assume
the followings:
Dimension attributes values are integers between 0 and (cardinality -1).
Measure attribute values are in the last column of each row
Measure attribute values are integers
example_data.txt is an example input file.
5 Output Files Format
For each found block, two files are created. For example, for the n-th found block, the following two files are
created:
block_n.tuples: this file lists tuples included in the n-th block. This file has the same format with
the input file.
block_n.attributes: this file lists attribute values included in the n-th block. Each line consists of the
order of an attribute and a value of the attribute.
output directory contains the examples of the output files. Statistics, including the volumes, masses, and
densities of found blocks, are printed in the console.
6 Running D-Cube Serial Version
How to Run
./run_single.sh input_path output_path dimension density_measure policy num_of_blocks
Parameters
input_path: path of the input file. See 4 for the detailed format of the input file
output_path: path of the local directory for output files. See 5 for the detailed format of the output
files
dimension: number of dimension attributes
density_measure: density measure to use. This parameter should be one among [ari, geo, susp]
policy: policy to use for selecting attribute from which values are removed: This parameter should
be one among [density, cardinality]
num_of_blocks: number of blocks to find
3
7 Running D-Cube Hadoop Version
How to Run
./run_hadoop.sh input_path output_path dimension density_measure policy num_of_blocks
num_of_reducers log_path
Parameters
input_path: path of the input file in HDFS. See 4 for the detailed format of the input file
output_path: path of the HDFS directory for output files. See 5 for the detailed format of the output
files
dimension: number of dimension attributes
density_measure: density measure to use. This parameter should be one among [ari, geo, susp]
policy: policy to use for selecting attribute from which values are removed: This parameter should
be one among [density, cardinality]
num_of_blocks: number of blocks to find
num_of_redcuers: number of reducers to use
log_path: path of the local directory for logs.
