1 Introduction

This guide covers the usage of the CP package, version 6.3, a core component of the Quantum

ESPRESSO distribution. Further documentation, beyond what is provided in this guide, can

be found in the directory CPV/Doc/, containing a copy of this guide.

Important notice: due to the lack of time and of manpower, this manual is only partially

updated and may contain outdated information.

This guide assumes that you know the physics that CP describes and the methods it im-

plements. It also assumes that you have already installed, or know how to install, Quantum

ESPRESSO. If not, please read the general User’s Guide for Quantum ESPRESSO, found

in directory Doc/ two levels above the one containing this guide; or consult the web site:

http://www.quantum-espresso.org.

People who want to modify or contribute to CP should read the Developer Manual:

Doc/developer man.pdf.

CP can perform Car-Parrinello molecular dynamics, including variable-cell dynamics, and

free-energy surface calculation at ﬁxed cell through meta-dynamics, if patched with PLUMED.

The CP package is based on the original code written by Roberto Car and Michele Parrinello.

CP was developed by Alfredo Pasquarello (EPF Lausanne), Kari Laasonen (Oulu), Andrea

Trave, Roberto Car (Princeton), Nicola Marzari (EPF Lausanne), Paolo Giannozzi, and others.

FPMD, later merged with CP, was developed by Carlo Cavazzoni, Gerardo Ballabio (CINECA),

Sandro Scandolo (ICTP), Guido Chiarotti, Paolo Focher, and others. We quote in particular:

•Federico Grasselli and Riccardo Bertossa (SISSA) for bug ﬁxes, extensions to Autopilot;

•Biswajit Santra, Hsin-Yu Ko, Marcus Calegari Andrade (Princeton) for SCAN functional;

•Robert DiStasio (Cornell)), Biswajit Santra, and Hsin-Yu Ko for hybrid functionals with

MLWF; (maximally localized Wannier functions);

•Manu Sharma (Princeton) and Yudong Wu (Princeton) for dynamics with MLWF;

•Paolo Umari (Univ. Padua) for ﬁnite electric ﬁelds and conjugate gradients;

•Paolo Umari and Ismaila Dabo for ensemble-DFT;

•Xiaofei Wang (Princeton) for META-GGA;

•The Autopilot feature was implemented by Targacept, Inc.

This guide has been mostly writen by Gerardo Ballabio and Carlo Cavazzoni.

CP is free software, released under the GNU General Public License.

See http://www.gnu.org/licenses/old-licenses/gpl-2.0.txt, or the ﬁle License in the

distribution).

We shall greatly appreciate if scientiﬁc work done using the Quantum ESPRESSO dis-

tribution will contain an acknowledgment to the following references:

P. Giannozzi, S. Baroni, N. Bonini, M. Calandra, R. Car, C. Cavazzoni, D. Ceresoli,

G. L. Chiarotti, M. Cococcioni, I. Dabo, A. Dal Corso, S. Fabris, G. Fratesi, S. de

Gironcoli, R. Gebauer, U. Gerstmann, C. Gougoussis, A. Kokalj, M. Lazzeri, L.

Martin-Samos, N. Marzari, F. Mauri, R. Mazzarello, S. Paolini, A. Pasquarello, L.

Paulatto, C. Sbraccia, S. Scandolo, G. Sclauzero, A. P. Seitsonen, A. Smogunov, P.

Umari, R. M. Wentzcovitch, J.Phys.: Condens.Matter 21, 395502 (2009)

and

P. Giannozzi, O. Andreussi, T. Brumme, O. Bunau, M. Buongiorno Nardelli, M.

Calandra, R. Car, C. Cavazzoni, D. Ceresoli, M. Cococcioni, N. Colonna, I. Carn-

imeo, A. Dal Corso, S. de Gironcoli, P. Delugas, R. A. DiStasio Jr, A. Ferretti, A.

Floris, G. Fratesi, G. Fugallo, R. Gebauer, U. Gerstmann, F. Giustino, T. Gorni, J

Jia, M. Kawamura, H.-Y. Ko, A. Kokalj, E. K¨u¸c¨ukbenli, M .Lazzeri, M. Marsili, N.

Marzari, F. Mauri, N. L. Nguyen, H.-V. Nguyen, A. Otero-de-la-Roza, L. Paulatto,

S. Ponc´e, D. Rocca, R. Sabatini, B. Santra, M. Schlipf, A. P. Seitsonen, A. Smo-

gunov, I. Timrov, T. Thonhauser, P. Umari, N. Vast, X. Wu, S. Baroni J.Phys.:

Condens.Matter 29, 465901 (2017)

Note the form Quantum ESPRESSO for textual citations of the code. Please also see

package-speciﬁc documentation for further recommended citations. Pseudopotentials should

be cited as (for instance)

[ ] We used the pseudopotentials C.pbe-rrjkus.UPF and O.pbe-vbc.UPF from

http://www.quantum-espresso.org.

2 Compilation

CP is included in the core Quantum ESPRESSO distribution. Instruction on how to install

it can be found in the general documentation (User’s Guide) for Quantum ESPRESSO.

Typing make cp from the main Quantum ESPRESSO directory or make from the CPV/

subdirectory produces the following codes in CPV/src:

•cp.x: Car-Parrinello Molecular Dynamics code

•cppp.x: (until v.6.3 only) postprocessing code for cp.x

•wfdd.x: utility code for ﬁnding maximally localized Wannier functions using damped

dynamics.

Symlinks to executable programs will be placed in the bin/ subdirectory.

As a ﬁnal check that compilation was successful, you may want to run some or all of the

tests and examples. Please see the general User’s Guide for their setup. Automated tests for

cp.x are in directory tests/ and can be run via the script check cp.x.j

You may take the tests and examples distributed with CP as templates for writing your

own input ﬁles. Input ﬁles for tests are contained in tests/ subdirectory with ﬁle type *.in1,

*.in2, ... . Input ﬁle for examples are produced if you run the examples in the results/

subdirectories, with names ending with .in.

For general information on parallelism and how to run in parallel execution, please see

the general User’s Guide. CP currently can take advantage of both MPI and OpenMP par-

allelization. The “plane-wave”, “linear-algebra” and “task-group” parallelization levels are

implemented.

3 Input data

Input data for cp.x is organized into several namelists, followed by other ﬁelds (“cards”)

introduced by keywords. The namelists are

&CONTROL: general variables controlling the run

&SYSTEM: structural information on the system under investigation

&ELECTRONS: electronic variables, electron dynamics

&IONS : ionic variables, ionic dynamics

&CELL (optional): variable-cell dynamics

The &CELL namelist may be omitted for ﬁxed-cell calculations. This depends on the value

of variable calculation in namelist &CONTROL. Most variables in namelists have default

values. Only the following variables in &SYSTEM must always be speciﬁed:

ibrav (integer) Bravais-lattice index

celldm (real, dimension 6) crystallographic constants

nat (integer) number of atoms in the unit cell

ntyp (integer) number of types of atoms in the unit cell

ecutwfc (real) kinetic energy cutoﬀ (Ry) for wavefunctions.

Explanations for the meaning of variables ibrav and celldm, as well as on alternative ways

to input structural data, are contained in ﬁles Doc/INPUT CP.*. These ﬁles are the reference

for input data and describe a large number of other variables as well. Almost all variables have

default values, which may or may not ﬁt your needs.

Comment lines in namelists can be introduced by a ”!”, exactly as in fortran code.

After the namelists, you have several ﬁelds (“cards”) introduced by keywords with self-

explanatory names:

ATOMIC SPECIES

ATOMIC POSITIONS

CELL PARAMETERS (optional)

OCCUPATIONS (optional)

The keywords may be followed on the same line by an option. Unknown ﬁelds are ignored. See

the ﬁles mentioned above for details on the available “cards”.

Comments lines in “cards” can be introduced by either a “!” or a “#” character in the ﬁrst

position of a line.

3.1 Data ﬁles

The output data ﬁles are written in the directory speciﬁed by variable outdir, with names

speciﬁed by variable prefix (a string that is prepended to all ﬁle names, whose default value is:

prefix=’pwscf’). The iotk toolkit is used to write the ﬁle in a XML format, whose deﬁnition

can be found in the Developer Manual. In order to use the data directory on a diﬀerent machine,

you need to convert the binary ﬁles to formatted and back, using the bin/iotk script.

The execution stops if you create a ﬁle prefix.EXIT either in the working directory (i.e.

where the program is executed), or in the outdir directory. Note that with some versions of

MPI, the working directory is the directory where the executable is! The advantage of this

procedure is that all ﬁles are properly closed, whereas just killing the process may leave data

and output ﬁles in an unusable state.

3.2 Format of arrays containing charge density, potential, etc.

The index of arrays used to store functions deﬁned on 3D meshes is actually a shorthand for

three indices, following the FORTRAN convention (”leftmost index runs faster”). An example

will explain this better. Suppose you have a 3D array psi(nr1x,nr2x,nr3x). FORTRAN

compilers store this array sequentially in the computer RAM in the following way:

psi( 1, 1, 1)

psi( 2, 1, 1)

...

psi(nr1x, 1, 1)

psi( 1, 2, 1)

psi( 2, 2, 1)

...

psi(nr1x, 2, 1)

...

psi(nr1x,nr2x, 1)

...

psi(nr1x,nr2x,nr3x)

etc

Let ind be the position of the (i,j,k) element in the above list: the following relation

ind = i + (j - 1) * nr1x + (k - 1) * nr2x * nr1x

holds. This should clarify the relation between 1D and 3D indexing. In real space, the (i,j,k)

point of the FFT grid with dimensions nr1 (≤nr1x), nr2 (≤nr2x), , nr3 (≤nr3x), is

rijk =i−1

nr1τ1+j−1

nr2τ2+k−1

nr3τ3

where the τiare the basis vectors of the Bravais lattice. The latter are stored row-wise in the

at array: τ1=at(:, 1),τ2=at(:, 2),τ3=at(:, 3).

The distinction between the dimensions of the FFT grid, (nr1,nr2,nr3) and the physical

dimensions of the array, (nr1x,nr2x,nr3x) is done only because it is computationally conve-

nient in some cases that the two sets are not the same. In particular, it is often convenient to

have nrx1=nr1+1 to reduce memory conﬂicts.

4 Using CP

It is important to understand that a CP simulation is a sequence of diﬀerent runs, some of

them used to ”prepare” the initial state of the system, and other performed to collect statistics,

or to modify the state of the system itself, i.e. modify the temperature or the pressure.

To prepare and run a CP simulation you should ﬁrst of all deﬁne the system:

atomic positions

system cell

pseudopotentials

cut-oﬀs

number of electrons and bands (optional)

FFT grids (optional)

An example of input ﬁle (Benzene Molecule):

&control

title = ’Benzene Molecule’,

calculation = ’cp’,

restart_mode = ’from_scratch’,

ndr = 51,

ndw = 51,

nstep = 100,

iprint = 10,

isave = 100,

tstress = .TRUE.,

tprnfor = .TRUE.,

dt = 5.0d0,

etot_conv_thr = 1.d-9,

ekin_conv_thr = 1.d-4,

prefix = ’c6h6’,

pseudo_dir=’/scratch/benzene/’,

outdir=’/scratch/benzene/Out/’

&system

ibrav = 14,

celldm(1) = 16.0,

celldm(2) = 1.0,

celldm(3) = 0.5,

celldm(4) = 0.0,

celldm(5) = 0.0,

celldm(6) = 0.0,

nat = 12,

ntyp = 2,

nbnd = 15,

ecutwfc = 40.0,

nr1b= 10, nr2b = 10, nr3b = 10,

input_dft = ’BLYP’

&electrons

emass = 400.d0,

emass_cutoff = 2.5d0,

electron_dynamics = ’sd’

&ions

ion_dynamics = ’none’

&cell

cell_dynamics = ’none’,

press = 0.0d0,

ATOMIC_SPECIES

C 12.0d0 c_blyp_gia.pp

H 1.00d0 h.ps

ATOMIC_POSITIONS (bohr)

C 2.6 0.0 0.0

C 1.3 -1.3 0.0

C -1.3 -1.3 0.0

C -2.6 0.0 0.0

C -1.3 1.3 0.0

C 1.3 1.3 0.0

H 4.4 0.0 0.0

H 2.2 -2.2 0.0

H -2.2 -2.2 0.0

H -4.4 0.0 0.0

H -2.2 2.2 0.0

H 2.2 2.2 0.0

You can ﬁnd the description of the input variables in ﬁle Doc/INPUT CP.*.

4.1 Reaching the electronic ground state

The ﬁrst run, when starting from scratch, is always an electronic minimization, with ﬁxed ions

and cell, to bring the electronic system on the ground state (GS) relative to the starting atomic

conﬁguration. This step is conceptually very similar to self-consistency in a pw.x run.

Sometimes a single run is not enough to reach the GS. In this case, you need to re-run

the electronic minimization stage. Use the input of the ﬁrst run, changing restart mode =

’from scratch’ to restart mode = ’restart’.

NOTA BENE: Unless you are already experienced with the system you are studying or

with the internals of the code, you will usually need to tune some input parameters, like emass,

dt, and cut-oﬀs. For this purpose, a few trial runs could be useful: you can perform short

minimizations (say, 10 steps) changing and adjusting these parameters to ﬁt your needs. You

can specify the degree of convergence with these two thresholds:

etot conv thr: total energy diﬀerence between two consecutive steps

ekin conv thr: value of the ﬁctitious kinetic energy of the electrons.

Usually we consider the system on the GS when ekin conv thr <10−5. You could check

the value of the ﬁctitious kinetic energy on the standard output (column EKINC).

Diﬀerent strategies are available to minimize electrons, but the most used ones are:

•steepest descent: electron dynamics = ’sd’

•damped dynamics: electron dynamics = ’damp’,electron damping = a number typ-

ically ranging from 0.1 and 0.5

See the input description to compute the optimal damping factor.

4.2 Relax the system

Once your system is in the GS, depending on how you have prepared the starting atomic

conﬁguration:

1. if you have set the atomic positions ”by hand” and/or from a classical code, check the

forces on atoms, and if they are large (∼0.1÷1.0 atomic units), you should perform an

ionic minimization, otherwise the system could break up during the dynamics.

2. if you have taken the positions from a previous run or a previous ab-initio simulation,

check the forces, and if they are too small (∼10−4atomic units), this means that atoms

are already in equilibrium positions and, even if left free, they will not move. Then you

need to randomize positions a little bit (see below).

Let us consider case 1). There are diﬀerent strategies to relax the system, but the most

used are again steepest-descent or damped-dynamics for ions and electrons. You could also

mix electronic and ionic minimization scheme freely, i.e. ions in steepest-descent and electron

in with damped-dynamics or vice versa.

(a) suppose we want to perform steepest-descent for ions. Then we should specify the follow-

ing section for ions:

&ions

ion_dynamics = ’sd’

Change also the ionic masses to accelerate the minimization:

ATOMIC_SPECIES

C 2.0d0 c_blyp_gia.pp

H 2.00d0 h.ps

while leaving other input parameters unchanged. Note that if the forces are really high

(>1.0 atomic units), you should always use steepest descent for the ﬁrst (∼100 relaxation

steps.

(b) As the system approaches the equilibrium positions, the steepest descent scheme slows

down, so is better to switch to damped dynamics:

&ions

ion_dynamics = ’damp’,

ion_damping = 0.2,

ion_velocities = ’zero’

A value of ion damping around 0.05 is good for many systems. It is also better to specify

to restart with zero ionic and electronic velocities, since we have changed the masses.

Change further the ionic masses to accelerate the minimization:

ATOMIC_SPECIES

C 0.1d0 c_blyp_gia.pp

H 0.1d0 h.ps

especially because, since we are moving electron and ions together, the ionic forces are

not properly correct, then it is often better to perform a ionic step every N electronic

steps, or to move ions only when electron are in their GS (within the chosen threshold).

This can be speciﬁed by adding, in the ionic section, the ion nstepe parameter, then the

&IONS namelist become as follows:

&ions

ion_dynamics = ’damp’,

ion_damping = 0.2,

ion_velocities = ’zero’,

ion_nstepe = 10

Then we specify in the &CONTROL namelist:

etot_conv_thr = 1.d-6,

ekin_conv_thr = 1.d-5,

forc_conv_thr = 1.d-3

As a result, the code checks every 10 electronic steps whether the electronic system satisﬁes

the two thresholds etot conv thr,ekin conv thr: if it does, the ions are advanced by

one step. The process thus continues until the forces become smaller than forc conv thr.

Note that to fully relax the system you need many runs, and diﬀerent strategies, that

you should mix and change in order to speed-up the convergence. The process is not

automatic, but is strongly based on experience, and trial and error.

Remember also that the convergence to the equilibrium positions depends on the energy

threshold for the electronic GS, in fact correct forces (required to move ions toward the

minimum) are obtained only when electrons are in their GS. Then a small threshold on

forces could not be satisﬁed, if you do not require an even smaller threshold on total

energy.

Let us now move to case 2: randomization of positions.

If you have relaxed the system or if the starting system is already in the equilibrium po-

sitions, then you need to displace ions from the equilibrium positions, otherwise they will not

move in a dynamics simulation. After the randomization you should bring electrons on the

GS again, in order to start a dynamic with the correct forces and with electrons in the GS.

Then you should switch oﬀ the ionic dynamics and activate the randomization for each species,

specifying the amplitude of the randomization itself. This could be done with the following

&IONS namelist:

&ions

ion_dynamics = ’none’,

tranp(1) = .TRUE.,

tranp(2) = .TRUE.,

amprp(1) = 0.01

amprp(2) = 0.01

In this way a random displacement (of max 0.01 a.u.) is added to atoms of species 1 and 2.

All other input parameters could remain the same. Note that the diﬀerence in the total energy

(etot) between relaxed and randomized positions can be used to estimate the temperature that

will be reached by the system. In fact, starting with zero ionic velocities, all the diﬀerence

is potential energy, but in a dynamics simulation, the energy will be equipartitioned between

kinetic and potential, then to estimate the temperature take the diﬀerence in energy (de),

convert it in Kelvin, divide for the number of atoms and multiply by 2/3. Randomization

could be useful also while we are relaxing the system, especially when we suspect that the ions

are in a local minimum or in an energy plateau.

4.3 CP dynamics

At this point after having minimized the electrons, and with ions displaced from their equi-

librium positions, we are ready to start a CP dynamics. We need to specify ’verlet’ both

in ionic and electronic dynamics. The threshold in control input section will be ignored, like

any parameter related to minimization strategy. The ﬁrst time we perform a CP run after a

minimization, it is always better to put velocities equal to zero, unless we have velocities, from

a previous simulation, to specify in the input ﬁle. Restore the proper masses for the ions. In

this way we will sample the microcanonical ensemble. The input section changes as follow:

&electrons

emass = 400.d0,

emass_cutoff = 2.5d0,

electron_dynamics = ’verlet’,

electron_velocities = ’zero’

&ions

ion_dynamics = ’verlet’,

ion_velocities = ’zero’

ATOMIC_SPECIES

C 12.0d0 c_blyp_gia.pp

H 1.00d0 h.ps

If you want to specify the initial velocities for ions, you have to set ion velocities

=’from input’, and add the IONIC VELOCITIES card, after the ATOMIC POSITION card,

with the list of velocities in atomic units.

NOTA BENE: in restarting the dynamics after the ﬁrst CP run, remember to remove or

comment the velocities parameters:

&electrons

emass = 400.d0,

emass_cutoff = 2.5d0,

electron_dynamics = ’verlet’

! electron_velocities = ’zero’

&ions

ion_dynamics = ’verlet’

! ion_velocities = ’zero’

otherwise you will quench the system interrupting the sampling of the microcanonical ensemble.

Varying the temperature It is possible to change the temperature of the system or to

sample the canonical ensemble ﬁxing the average temperature, this is done using the Nos´e

thermostat. To activate this thermostat for ions you have to specify in namelist &IONS:

&ions

ion_dynamics = ’verlet’,

ion_temperature = ’nose’,

fnosep = 60.0,

tempw = 300.0

where fnosep is the frequency of the thermostat in THz, that should be chosen to be comparable

with the center of the vibrational spectrum of the system, in order to excite as many vibrational

modes as possible. tempw is the desired average temperature in Kelvin.

Note: to avoid a strong coupling between the Nos´e thermostat and the system, proceed

step by step. Don’t switch on the thermostat from a completely relaxed conﬁguration: adding

a random displacement is strongly recommended. Check which is the average temperature

via a few steps of a microcanonical simulation. Don’t increase the temperature too much.

Finally switch on the thermostat. In the case of molecular system, diﬀerent modes have to

be thermalized: it is better to use a chain of thermostat or equivalently running diﬀerent

simulations with diﬀerent frequencies.

No´se thermostat for electrons It is possible to specify also the thermostat for the

electrons. This is usually activated in metals or in systems where we have a transfer of energy

between ionic and electronic degrees of freedom. Beware: the usage of electronic thermostats

is quite delicate. The following information comes from K. Kudin:

”The main issue is that there is usually some ”natural” ﬁctitious kinetic energy that electrons

gain from the ionic motion (”drag”). One could easily quantify how much of the ﬁctitious energy

comes from this drag by doing a CP run, then a couple of CG (same as BO) steps, and then

going back to CP. The ﬁctitious electronic energy at the last CP restart will be purely due to

the drag eﬀect.”

”The thermostat on electrons will either try to overexcite the otherwise ”cold” electrons, or

it will try to take them down to an unnaturally cold state where their ﬁctitious kinetic energy

is even below what would be just due pure drag. Neither of this is good.”

”I think the only workable regime with an electronic thermostat is a mild overexcitation of

the electrons, however, to do this one will need to know rather precisely what is the ﬁctitious

kinetic energy due to the drag.”

4.4 Advanced usage

4.4.1 Self-interaction Correction

The self-interaction correction (SIC) included in the CP package is based on the Constrained

Local-Spin-Density approach proposed my F. Mauri and coworkers (M. D’Avezac et al. PRB

71, 205210 (2005)). It was used for the ﬁrst time in Quantum ESPRESSO by F. Baletto, C.

Cavazzoni and S.Scandolo (PRL 95, 176801 (2005)).

This approach is a simple and nice way to treat ONE, and only one, excess charge. It

is moreover necessary to check a priori that the spin-up and spin-down eigenvalues are not

too diﬀerent, for the corresponding neutral system, working in the Local-Spin-Density Ap-

proximation (setting nspin = 2). If these two conditions are satisﬁed and you are interest in

charged systems, you can apply the SIC. This approach is a on-the-ﬂy method to correct the

self-interaction with the excess charge with itself.

Brieﬂy, both the Hartree and the XC part have been corrected to avoid the interaction of

the excess charge with itself.

For example, for the Boron atoms, where we have an even number of electrons (valence

electrons = 3), the parameters for working with the SIC are:

&system

nbnd= 2,

tot_magnetization=1,

sic_alpha = 1.d0,

sic_epsilon = 1.0d0,

sic = ’sic_mac’,

force_pairing = .true.,

The two main parameters are:

force pairing = .true., which forces the paired electrons to be the same;

sic=’sic mac’, which instructs the code to use Mauri’s correction.

Warning: This approach has known problems for dissociation mechanism driven by excess

electrons.

Comment 1: Two parameters, sic alpha and sic epsilon’, have been introduced follow-

ing the suggestion of M. Sprik (ICR(05)) to treat the radical (OH)-H2O. In any case, a complete

ab-initio approach is followed using sic alpha=1,sic epsilon=1.

Comment 2: When you apply this SIC scheme to a molecule or to an atom, which are

neutral, remember to add the correction to the energy level as proposed by Landau: in a

neutral system, subtracting the self-interaction, the unpaired electron feels a charged system,

even if using a compensating positive background. For a cubic box, the correction term due to

the Madelung energy is approx. given by 1.4186/Lbox −1.047/(Lbox)3, where Lbox is the linear

dimension of your box (=celldm(1)). The Madelung coeﬃcient is taken from I. Dabo et al.

PRB 77, 115139 (2007). (info by F. Baletto, francesca.baletto@kcl.ac.uk)

4.4.2 ensemble-DFT

The ensemble-DFT (eDFT) is a robust method to simulate the metals in the framework of

”ab-initio” molecular dynamics. It was introduced in 1997 by Marzari et al.

The speciﬁc subroutines for the eDFT are in CPV/src/ensemble dft.f90 where you de-

ﬁne all the quantities of interest. The subroutine CPV/src/inner loop cold.f90 called by

cg sub.f90, control the inner loop, and so the minimization of the free energy Awith respect

to the occupation matrix.

To select a eDFT calculations, the user has to set:

calculation = ’cp’

occupations= ’ensemble’

tcg = .true.

passop= 0.3

maxiter = 250

to use the CG procedure. In the eDFT it is also the outer loop, where the energy is minimized

with respect to the wavefunction keeping ﬁxed the occupation matrix. While the speciﬁc

parameters for the inner loop. Since eDFT was born to treat metals, keep in mind that we

want to describe the broadening of the occupations around the Fermi energy. Below the new

parameters in the electrons list, are listed.

•smearing: used to select the occupation distribution; there are two options: Fermi-Dirac

smearing=’fd’, cold-smearing smearing=’cs’ (recommended)

•degauss: is the electronic temperature; it controls the broadening of the occupation

numbers around the Fermi energy.

•ninner: is the number of iterative cycles in the inner loop, done to minimize the free

energy Awith respect the occupation numbers. The typical range is 2-8.

•conv thr: is the threshold value to stop the search of the ’minimum’ free energy.

•niter cold restart: controls the frequency at which a full iterative inner cycle is done.

It is in the range 1÷ninner. It is a trick to speed up the calculation.

•lambda cold: is the length step along the search line for the best value for A, when

the iterative cycle is not performed. The value is close to 0.03, smaller for large and

complicated metallic systems.

NOTE: degauss is in Hartree, while in PWscfis in Ry (!!!). The typical range is 0.01-0.02 Ha.

The input for an Al surface is:

&CONTROL

calculation = ’cp’,

restart_mode = ’from_scratch’,

nstep = 10,

iprint = 5,

isave = 5,

dt = 125.0d0,

prefix = ’Aluminum_surface’,

pseudo_dir = ’~/UPF/’,

outdir = ’/scratch/’

ndr=50

ndw=51

&SYSTEM

ibrav= 14,

celldm(1)= 21.694d0, celldm(2)= 1.00D0, celldm(3)= 2.121D0,

celldm(4)= 0.0d0, celldm(5)= 0.0d0, celldm(6)= 0.0d0,

nat= 96,

ntyp= 1,

nspin=1,

ecutwfc= 15,

nbnd=160,

input_dft = ’pbe’

occupations= ’ensemble’,

smearing=’cs’,

degauss=0.018,

&ELECTRONS

orthogonalization = ’Gram-Schmidt’,

startingwfc = ’random’,

ampre = 0.02,

tcg = .true.,

passop= 0.3,

maxiter = 250,

emass_cutoff = 3.00,

conv_thr=1.d-6

n_inner = 2,

lambda_cold = 0.03,

niter_cold_restart = 2,

&IONS

ion_dynamics = ’verlet’,

ion_temperature = ’nose’

fnosep = 4.0d0,

tempw = 500.d0

ATOMIC_SPECIES

Al 26.89 Al.pbe.UPF

NOTA1 remember that the time step is to integrate the ionic dynamics, so you can choose

something in the range of 1-5 fs.

NOTA2 with eDFT you are simulating metals or systems for which the occupation number is

also fractional, so the number of band, nbnd, has to be chosen such as to have some empty

states. As a rule of thumb, start with an initial occupation number of about 1.6-1.8 (the more

bands you consider, the more the calculation is accurate, but it also takes longer. The CPU

time scales almost linearly with the number of bands.)

NOTA3 the parameter emass cutoff is used in the preconditioning and it has a completely

diﬀerent meaning with respect to plain CP. It ranges between 4 and 7.

All the other parameters have the same meaning in the usual CP input, and they are discussed

above.

4.4.3 Free-energy surface calculations

Once CP is patched with PLUMED plug-in, it becomes possible to turn-on most of the PLUMED

functionalities running CP as: ./cp.x -plumed plus the other usual CP arguments. The

PLUMED input ﬁle has to be located in the speciﬁed outdir with the ﬁxed name plumed.dat.

4.4.4 Treatment of USPPs

The cutoﬀ ecutrho deﬁnes the resolution on the real space FFT mesh (as expressed by nr1,

nr2 and nr3, that the code left on its own sets automatically). In the USPP case we refer

to this mesh as the ”hard” mesh, since it is denser than the smooth mesh that is needed to

represent the square of the non-norm-conserving wavefunctions.

On this ”hard”, ﬁne-spaced mesh, you need to determine the size of the cube that will

encompass the largest of the augmentation charges - this is what nr1b,nr2b,nr3b are. hey

are independent of the system size, but dependent on the size of the augmentation charge

(an atomic property that doesn’t vary that much for diﬀerent systems) and on the real-space

resolution needed by augmentation charges (rule of thumb: ecutrho is between 6 and 12 times

ecutwfc).

The small boxes should be set as small as possible, but large enough to contain the core of

the largest element in your system. The formula for estimating the box size is quite simple:

nr1b = 2Rc/Lx×nr1

and the like, where Rcut is largest cut-oﬀ radius among the various atom types present in the

system, Lxis the physical length of your box along the xaxis. You have to round your result

to the nearest larger integer. In practice, nr1b etc. are often in the region of 20-24-28; testing

seems again a necessity.

The core charge is in principle ﬁnite only at the core region (as deﬁned by some Rrcut )

and vanishes out side the core. Numerically the charge is represented in a Fourier series which

may give rise to small charge oscillations outside the core and even to negative charge density,

but only if the cut-oﬀ is too low. Having these small boxes removes the charge oscillations

problem (at least outside the box) and also oﬀers some numerical advantages in going to higher

cut-oﬀs.” (info by Nicola Marzari)

4.4.5 Hybrid functional calculations using maximally localized Wannier functions

In this section, we illustrate some guidelines to perform exact exchange (EXX) calculations

using Wannier functions eﬃciently.

The references for this algorithm are:

(i) Theory: X. Wu , A. Selloni, and R. Car, Phys. Rev. B 79, 085102 (2009).

(ii) Implementation: H.-Y. Ko, B. Santra, R. A. DiStasio, L. Kong, Z. Li, X. Wu, and R.

Car, arxiv.

The parallelization scheme in this algorithm is based upon the number of electronic states.

In the current implementation, there are certain restrictions on the choice of the number of

MPI tasks. Also slightly diﬀerent algorithms are employed depending on whether the number

of MPI tasks used in the calculation are greater or less than the number of electronic states. We

highly recommend users to follow the notes below. This algorithm can be used most eﬃciently

if the numbers of electronic states are uniformly distributed over the number of MPI tasks.

For a system having N electronic states the optimum numbers of MPI tasks (nproc) are the

following:

(a) In case of nproc ≤N, the optimum choices are N/m, where m is any positive integer.

–Robustness: Can be used for odd and even number of electronic states.

–OpenMP threads: Can be used.

–Taskgroup: Only the default value of the task group (-ntg 1) is allowed.

(b) In case of nproc >N, the optimum choices are N*m, where m is any positive integer.

–Robustness: Can be used for even number of electronic states.

–Largest value of m: As long as nj max (see output) is greater than 1, however beyond

m=8 the scaling may become poor. The scaling should be tested by users.

–OpenMP threads: Can be used and highly recommended. We have tested number of

threads starting from 2 up to 64. More threads are also allowed. For very large cal-

culations (nproc >1000 ) eﬃciency can largely depend on the computer architecture

and the balance between the MPI tasks and the OpenMP threads. User should test

for an optimal balance. Reasonably good scaling can be achieved by using m=6-8

and OpenMP threads=2-16.

–Taskgroup: Can be greater than 1 and users should choose the largest possible

value for ntg. To estimate ntg, ﬁnd the value of nr3x in the output and compute

nproc/nr3x and take the integer value. We have tested the value of ntg as 2m, where

m is any positive integer. Other values of ntg should be used with caution.

–Ndiag: Use -ndiag X option in the execution of cp.x. Without this option jobs may

crash on certain architectures. Set X to any perfect square number which is equal

to or less than N.

•DEBUG: The EXX calculations always work when number of MPI tasks = number of

electronic states. In case of any uncertainty, the EXX energy computed using diﬀerent

numbers of MPI tasks can be checked by performing test calculations using number of

MPI tasks = number of electronic states.

An example input is listed as following:

&CONTROL

calculation = ’cp-wf’,

title = "(H2O)32 Molecule: electron minimization PBE0",

restart_mode = "from_scratch",

pseudo_dir = ’./’,

outdir = ’./’,

prefix = "water",

nstep = 220,

iprint = 100,

isave = 100,

dt = 4.D0,

ekin_conv_thr = 1.D-5,

etot_conv_thr = 1.D-5,

&SYSTEM

ibrav = 1,

celldm(1) = 18.6655,

nat = 96,

ntyp = 2,

ecutwfc = 85.D0,

input_dft = ’pbe0’,

&ELECTRONS

emass = 400.D0,

emass_cutoff = 3.D0,

ortho_eps = 1.D-8,

ortho_max = 300,

electron_dynamics = "damp",

electron_damping = 0.1D0,

&IONS

ion_dynamics = "none",

&WANNIER

nit = 60,

calwf = 3,

tolw = 1.D-6,

nsteps = 20,

adapt = .FALSE.

wfdt = 4.D0,

wf_q = 500,

wf_friction = 0.3D0,

exx_neigh = 60, ! exx related optional

exx_dis_cutoff = 8.0D0, ! exx related optional

exx_ps_rcut_self = 6.0D0, ! exx related optional

exx_ps_rcut_pair = 5.0D0, ! exx related optional

exx_me_rcut_self = 9.3D0, ! exx related optional

exx_me_rcut_pair = 7.0D0, ! exx related optional

exx_poisson_eps = 1.D-6, ! exx related optional

ATOMIC_SPECIES

O 16.0D0 O_HSCV_PBE-1.0.UPF

H 2.0D0 H_HSCV_PBE-1.0.UPF

5 Performances

cp.x can run in principle on any number of processors. The eﬀectiveness of parallelization is

ultimately judged by the ”scaling”, i.e. how the time needed to perform a job scales with the

number of processors, and depends upon:

•the size and type of the system under study;

•the judicious choice of the various levels of parallelization (detailed in Sec.??);

•the availability of fast interprocess communications (or lack of it).

Ideally one would like to have linear scaling, i.e. T∼T0/Npfor Npprocessors, where T0is

the estimated time for serial execution. In addition, one would like to have linear scaling of

the RAM per processor: ON∼O0/Np, so that large-memory systems ﬁt into the RAM of each

processor.

As a general rule, image parallelization:

•may give good scaling, but the slowest image will determine the overall performances

(”load balancing” may be a problem);

•requires very little communications (suitable for ethernet communications);

•does not reduce the required memory per processor (unsuitable for large-memory jobs).

Parallelization on k-points:

•guarantees (almost) linear scaling if the number of k-points is a multiple of the number

of pools;

•requires little communications (suitable for ethernet communications);

•does not reduce the required memory per processor (unsuitable for large-memory jobs).

Parallelization on PWs:

•yields good to very good scaling, especially if the number of processors in a pool is a

divisor of N3and Nr3(the dimensions along the z-axis of the FFT grids, nr3 and nr3s,

which coincide for NCPPs);

•requires heavy communications (suitable for Gigabit ethernet up to 4, 8 CPUs at most,

specialized communication hardware needed for 8 or more processors );

•yields almost linear reduction of memory per processor with the number of processors in

the pool.

A note on scaling: optimal serial performances are achieved when the data are as much as

possible kept into the cache. As a side eﬀect, PW parallelization may yield superlinear (better

than linear) scaling, thanks to the increase in serial speed coming from the reduction of data

size (making it easier for the machine to keep data in the cache).

VERY IMPORTANT: For each system there is an optimal range of number of processors on

which to run the job. A too large number of processors will yield performance degradation. If

the size of pools is especially delicate: Npshould not exceed N3and Nr3, and should ideally be

no larger than 1/2÷1/4N3and/or Nr3. In order to increase scalability, it is often convenient

to further subdivide a pool of processors into ”task groups”. When the number of processors

exceeds the number of FFT planes, data can be redistributed to ”task groups” so that each

group can process several wavefunctions at the same time.

The optimal number of processors for ”linear-algebra” parallelization, taking care of mul-

tiplication and diagonalization of M×Mmatrices, should be determined by observing the

performances of cdiagh/rdiagh (pw.x) or ortho (cp.x) for diﬀerent numbers of processors in

the linear-algebra group (must be a square integer).

Actual parallel performances will also depend on the available software (MPI libraries) and

on the available communication hardware. For PC clusters, OpenMPI (http://www.openmpi.org/)

seems to yield better performances than other implementations (info by Kostantin Kudin). Note

however that you need a decent communication hardware (at least Gigabit ethernet) in order

to have acceptable performances with PW parallelization. Do not expect good scaling with

cheap hardware: PW calculations are by no means an ”embarrassing parallel” problem.

Also note that multiprocessor motherboards for Intel Pentium CPUs typically have just one

memory bus for all processors. This dramatically slows down any code doing massive access to

memory (as most codes in the Quantum ESPRESSO distribution do) that runs on processors

of the same motherboard.

User Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
