PRODUCT GUIDE
Epson EB-S10
A combination of aordability, lightweight design and great
functionality make this the ideal projector for any meeting room.
Keep the lights on so the audience can comfortably take notes, this projector
series combines a high White and Colour Light Output (CLO) of 2,600 lumens with
3LCD technology for outstanding picture quality, natural colours and brightness.
Ideal for even the smallest meeting room, users can project large images from a
short distance, and easily align slides and correct distortion with manual vertical
keystone correction.
Set-up time is kept to a minimum with features such as quick-start and instant-o.
Weighing in at only 2.3kgs, it is also light enough to carry between meeting rooms.
The projector’s exceptional value is complemented by the low-running costs of the
E-TORL lamp, which lasts 5,000 hours.
For ease of use, you can display images and control the mouse from either a PC
or Mac with a single USB cable.
INPUT / OUTPUT
Computer/Component video
Audio in
Audio out
S-Video
Composite video USB Type B




KEY FEATURES
• USB Display for fuss-free presenting
• Compact and lightweight
• 5000 hours E-TORL long-life lamp
PROJECTION TECHNOLOGY 3LCD Technology
0.55 inch with MLA
RESOLUTION SVGA – 800 x 600 (4/3 aspect ratio)
Up to 1080i
WHITE LIGHT OUTPUT *
Normal / Eco 2600 / 2040 Lumens
COLOUR LIGHT OUTPUT *
Normal / Eco 2600 / 2040 Lumens
CONTRAST 2000:1
IMAGE SIZE 23 inch to 350 inch
60-inch screen: 1.80 - 2.4m (projection distance)
THROW RATIO 1.45 - 1.96:1
ZOOM RATIO Digital zoom 1 - 1.35
KEYSTONE CORRECTION Manual, Vertical ±30°
LENS TYPE
F-number
Focal Length
Oset
1.44
16.6mm
8:1
LAMP
Life (Normal / Eco)
Type
4000 / 5000 hours
200W UHE E-TORL (ELPLP58)
VISUAL INPUT
Computer
Video
1 x D-sub 15-pin, 1 x USB 2.0 type B
1 x RCA, 1 x S-Video, 1 x Component (D-sub 15-pin)
AUDIO INPUT
Computer / Video 1 x Stereo mini-jack
AUDIO OUTPUT
Computer 1 x Stereo mini-jack
ADVANCED FEATURES
Security
Operation
Display
Padlock and security cable hole, Kensington lock hole, password protection,
key lock, user logo
Direct power on, instant o, quick startup, source search, 2-in-1 USB Display
(Win & Mac), easy lamp and air filter replacement
8 colour modes, e-zoom, A/V mute, freeze, Help function
LANGUAGES English / French / German / Italian / Spanish / Dutch / Portuguese / Russian /
Swedish / Norwegian / Finnish / Danish / Bulgarian / Polish / Hungarian / Czech /
Slovak / Romanian / Croatian / Slovenian / Ukrainian / Catalan / Greek / Turkish /
Arabic / Hebrew / Hindi / Japanese / Simplified Chinese / Traditional Chinese /
Korean / Thai / Indonesian / Malay / Vietnamese
NOISE LEVEL
Normal / Eco 37dB / 29dB
SOUND 1 x 1 Watt
WEIGHT 2.3kg
DIMENSIONS 228 x 295 x 77mm
POWER CONSUMPTION
Normal / Eco
Standby
265W / 220W
0.4W
SAFETY REGULATIONS IEC 60950-1 1st edition (CE marking)
EMC directive (89/336/EEC)
Recycling regulations
WARRANTY** 2 years on main unit; 1 year on lamp
PRODUCT SPECIFICATIONS
Epson EB-S10
OPTIONAL ACCESSORIES
• Spare lamp (ELPL58)
• Air Filter Set (ELPAF25)
• 80-inch Mobile screen 16:9 (ELPSC21)
• 80-inch Pull-up screen 16:10 (ELPSC24)
• Multi-aspect screen 65 inch/74 inch/
80 inch (ELPSC26)
• Epson USB Visualiser (ELPDC06)
• Ceiling Mount (ELPMB23)
• Ceiling Pipe 450mm (ELPFP13)
• Ceiling Pipe 700mm (ELPFP14)
WHAT’S IN THE BOX
• Power cable 1.8m
• Computer cable 1.8m
• USB cable 1.8m
• Remote control and batteries
• Soft carrying case
• Password protected sticker
• User’s manual set
EB-S10_ds_1EN-INT_08/10
* ISO 21118 based measurement
** Warranty oers are not available for all countries. Please contact your local Epson representative.
