Cooling models with remote
control convenience
QUALITY
TOUGH l DURABLE l COOL
Thru-the-wall Air Conditioners
Friedrich Quality for thru-the-wall applications
IMPORTANT NOTE: Sleeves are sold and shipped separately to accommodate new construction and replacement requirements
RESIDENTIAL and COMMERCIAL applications.
New construction, retrofit and remodeling.
• Programmable models with remote control
• Ten ENERGYSTAR® models that save money on energy bills
• Cool only, heat pump and electric heat models
• Commercial grade quality
• Residential/ commercial
application
• Exact fit for Fedders A and B
sleeves. Sleeve measures 27"
W x 16 3/4" H
• Three-speed fan
• Mounts flush with the exterior
wall
• Magna 1 copper coils
• Efficient rotary compressor
• Easy-to-reach, top mount
controls
• Easy-to-clean filter with
antimicrobial treatment for
protection against fungal
and bacterial growth
• 24 hour programmable timer
• Money Saver® setting saves
energy by cycling the fan with
the compressor
• Smart Fan auto-adjusts fan
speed to maintain desired
temperature
• Auto-memory backup
COOLING ONLY, HEAT PUMP & ELECTRIC HEAT
REMOTE CONTROL FEATURES (cool only models)
COOLING ONLY & ELECTRIC HEAT
• High efficiency operation
saves on energy costs
• Rotary compressors provide
quiet, dependable perfor-
mance
• Cooling only and cooling with
electric heat models available
• 6-way air flow control
• Stale air exhaust
• Permanent filter
• Seacoast protection
• Auto re-start
COOLING MODELS feature elec-
tronic controls with remote and
3 cooling/ 3 fan-only speeds
HEAT/COOL MODELS feature 2
cooling and 2 heating speeds,
plus 1 fan-only setting
The Most Energy Efficient Solid-side Air Conditioner
Universal Fit for Easy Replacement
Sleeve Dimensions Friedrich Fedders Fedders
Friedrich/Fedders WSC Sleeve A B
Height (inches) 16 3/4 16 3/4 16 3/4
Width (inches) 27 27 27
Depth (inches) 16 3/4 16 3/4 19 3/4
Sleeve Dimensions Friedrich GE Amana Whirlpool Frigidaire
of Major Brands USC Sleeve Fedders
Height (inches) 15 17/32 15 5/8 15 5/8 15 3/4 15 7/16
Width (inches) 25 7/8 26 26 26 3/4 25 7/8
Depth (inches) 16 23/32 16 7/8 16 7/8 15 18
Units are shown installed in WSC sleeve
(sold and shipped separately)
Units are shown without USC sleeve
(sold and shipped separately)
Electronic
Timer
Remote Control
Antimicrobial
Filter
Money Saver®Remote Control
Smart Fan
Programmable
Timer
WALLMASTER HEAT PUMPS
Calculate the heat loss of the space to be heated. As long as the heat loss does not exceed
the resistance heating capacity rating of the unit, the heating performance will be
satisfactory.
Change-over from heat pump operation to resistance operation on models indicated is
automatic at a preset outside ambient temperature of approximately 35°F.
If condensate disposal is desired, an optional drain kit is available.
DEFROST CONTROL: Initiated at 20°F (outdoor coil temperature) and terminated at 43°F
(outdoor coil temperature). During defrost, the compressor stops and the electric heat
starts, then operates with the fan to maintain indoor comfort. Below 43°F, the unit
remains in electric heat mode. During electric heat mode, the unit will achieve the fol-
lowing ratings: 11000/9100 BTU/h, 16.0/14.7 amps, and 3550/2950 watts.
DEFROST DRAIN: Drain automatically opens at approximately 50°F in outdoor base pan
for defrost condensate disposal.
As an ENERGY STAR® partner, Friedrich Air Conditioning Co. has
determined that the selected ENERGY STAR® models ( ★ ) meet the
ENERGY STAR® guidelines for energy efficiency.
Thru-the-wall Air Conditioners
Plug Face/ Circuit Rating
Specifications ★ ENERGY STAR® models
Electrical Characteristics (60 Hertz)
★
★
★
★
★
★
★
★
★
★
Energy
Cooling Heating Efficiency Moisture Room Side Net
Capacity Capacity Volts Cooling Cooling Heating Heating Ratio Removal Air Circulation Weight
Model BTU/h BTU/h Rated Amps Watts Amps Watts EER Pints/Hr. CFM Lbs.
WALLMASTER
WS08B10A 8000 — 115 6.8 762 — — 10.5 1.3 245 93
WS10B10A 10000 — 115 8.7 954 — — 10.5 2.4 245 103
WS14B10A 13500 — 115 12.0 1415 — — 9.5 3.3 295 112
WS10B30A 10000/10000 — 230/208 4.6/5.0 1005/996 — — 10.0/10.0 2.1 260 101
WS13B30A 13200/12800 — 230/208 6.3/6.7 1389/1347 — — 9.5/9.5 3.3 280 109
WS16B30A 15800/15000 — 230/208 7.8/8.5 1756/1705 — — 9.0/8.8 4.2 290 119
WE10B33A 10000/10000 11000/9100 230/208 4.6/5.0 1005/996 16.0/14.7 3550/2950 10.0/10.0 2.1 260 103
WE13B33A 13200/12800 11000/9100 230/208 6.3/6.7 1389/1347 16.0/14.7 3550/2950 9.5/9.5 3.3 280 111
WE16B33A 15800/15000 11000/9100 230/208 7.8/8.5 1756/1705 16.0/14.7 3550/2950 9.0/8.8 4.2 290 121
WY10B33A 10100/9800 8100/7800 230/208 4.6/4.8 1013/976 3.9/4.0 857/821 10.0/10.0 2.5 230 107
WY13B33A 12500/12100 10400/10000 230/208 6.4/6.8 1389/1352 5.4/5.7 1182/1136 9.0/9.0 3.2 280 116
UNI-FIT
US08B10A 8000 — 115 7.5 825 — — 9.6 2.2 260 73
US10B10A 10000 — 115 9.8 1060 — — 9.4 3.2 285 78
US10B30A 10000/9800 — 230/208 4.7/5.2 1060/1040 — — 9.4/9.4 3.2 285 78
US12B10A 11700 — 115 11.6 1250 — — 9.4 3.8 290 80
US12B30A 11700/11400 — 230/208 5.8/6.2 1250/1210 — — 9.4/9.4 3.8 290 80
UE08A13B 8000 3850 115 7.5 825 10.7 1230 9.6 2.2 260 73
UE10A33B 10000/9800 11200/9200 230/208 4.7/5.2 1060/1040 15.3/14.0 3500/2900 9.4/9.4 3.2 285 78
UE12A33B 11700/11400 11200/9200 230/208 5.8/6.2 1250/1210 15.3/14.0 3500/2900 9.4/9.4 3.8 290 80
Circuit Rating Plug Face Appearance
WallMaster Uni-Fit Breaker (NEMA#) (Facing
Model Number Model Number or T-D Fuse Blades)
WS08B10A, WS10B10A, US08B10A, UE08A13B 125V - 15A
5 - 15P
WS14B10A US10B10A, US12B10A
WS10B30A, WS13B30A, US10B30A, US12B30A 250V - 15A 6 - 15P
WS16B30A
WE10, WE13, WE16 UE10A33B, UE12A33B 250V - 20A
6 - 20P
WY10, WY13
Friedrich Air Conditioning Co. | P.O. Box 1540 | San Antonio, TX 78295-1540 | (800) 541-6645 | fax (210) 357-4480 | www.friedrich.com
TW-06 (Rev 11-05) Printed in USA
Installation Accessories (WallMaster only)
DK / Drain Kit
Installed at the back of the unit and allows for attach-
ment to permanent condensate disposal system, if
disposal is necessary or desired.
SB / Sub Base
Used as a base for the unit when it is desired
to place the cord and receptacle within the
installation, or simply as a base for the unit
when mounted low in the wall.
BAK / Baffle Adapter Kit
Necessary when installing in a sleeve deeper
than 16 3/4" deep (such as Fedders B sleeve
which is 19 3/4" deep.
IDK / Internal Drain Kit
New construction applications with reverse cycle
units where a condensate drain system has been
built into the wall interior.
Sleeve/ Chassis Dimensions
Exterior Grilles
USC Sleeve /Standard Grille USC Sleeve/Replacement Grille*
Exterior Grilles
IMPORTANT:
Operating the air conditioner with incorrect rear grille or without Baffle Adapter Kit (on 19 3/4”
deep sleeve) will recirculate discharge air and cause compressor overload to trip.
CORRECT Vertical Louvers INCORRECT Horizontal Louvers
WSC Sleeve /Standard Grille WSC Sleeve/ optional Architectural Grille
Thru-the-wall Air Conditioners
IMPORTANT:
• Sleeves are sold and shipped separately to accommodate new
construction and replacement requirements
• UE models do not fit Westinghouse/Frigidaire sleeves.
• US models do fit Westinghouse/Frigidaire sleeves.
*REPLACEMENT GRILLE – high-tech plastic
For use on existing sleeves without any grille.
Important Note: When installing into an existing sleeve consult Installation
Section of Operation Manual to determine whether or not the grille needs
to be replaced and/or a baffle adapter should be used.
Depth Minimum Minimum Thru-the-wall
with Extension Extension Finished Hole
Model Height Width Depth Front Into Room Outside Height Width
WALLMASTER
WSC Sleeve 16 3/4" 27" 16 3/4" 23" 7 1/2" 9/16" 17 1/4" 27 1/4"
Chassis 15 3/4" 26 1/2" 21" – – – – –
UNI-FIT
USC Sleeve 15 17/32" 25 7/8" 16 23/32" 20 1/2" – 1/2" 16 25/32" 26 1/8"
US Chassis 14 13/32" 24" 20 3/32" 3 3/4" – – –
UE Chassis 14 13/32" 24 21/32" 19 21/32" 3 1/2" – – –
