Socket®Go Wi-Fi!™P500
If your Pocket PC doesn’t have built-in Wi-Fi, and
you want a wireless connection that doesn’t take
forever to load email attachments and webpages,
the Socket Go Wi-Fi! P500 is the perfect tool for
fast Wi-Fi access. Connect to enterprise, public, and
residential Wi-Fi 802.11b/g systems to access the
Web, email, and corporate servers at top speed.
You can also use the card to create peer-to-peer
networks, connect to other Wi-Fi users, and share files.
Included is Socket Wi-Fi Companion, an intuitive and graphical software utility
that makes it easy to find and connect to networks from a Pocket PC. Advanced
tools such as ping and trace route are provided for the power user.
Bring Go Wi-Fi! Wherever You Go
At work, connect to the backend server from your company
warehouse, or tap into your corporate WLAN from a lobby
or conference room. Also connect at public hot spots such
as airports, hotels, fast food restaurants, and cafés, which
typically offer wireless Internet based on the Wi-Fi 802.11b
standard. At home, enjoy the comfort and convenience of
wireless Internet whether you’re working in your home
office or relaxing on the sofa. Because 802.11g was
designed for backwards compatibility, the card interfaces
directly with 802.11b access points and vice versa.
Fast Roaming
Socket has implemented a fast roaming feature that enables you to roam from
one access point to another in less than 200 ms. This will enhance the overall
VoIP over WLAN experience for mobile users in a closed Wi-Fi environment
Security and Authentication
The Socket Go Wi-Fi! P500 works with a variety of WLAN security protocols,
including open systems, 40/64-bit and 128-bit WEP encryption, and networks
with enhanced security, such as AES, WPA2-Enterprise, WPA, WPA-PSK and
802.1x with EAP-TLS/PEAP authentication.*
Low Power Design
The Battery Friendly® Go Wi-Fi! card uses minimal power, so you can stay con-
nected longer without recharging your mobile computer. When connected to a
WLAN, the card is in listening mode about 90% of the time with occasional
short bursts of data and draws less than 20 mA. Socket’s software also has a
Power Save utility with an automatic power save option.
Wireless LAN Connectivity for your Pocket PC FEATURES
• Wi-Fi certified, Enterprise Edition —
compatible with 802.11b/g Wi-Fi
approved WLAN products
• Supports infrastructure WLAN and
Ad Hoc peer-to-peer connectivity
• Radio on/off feature (airplane mode)
• Supports AES, WPA2-Enterprise, WPA,
WPA-PSK, 802.1x (EAP-TLS/PEAP),
40/64 and 128-bit WEP encryption and
open systems*
• Compatible with devices running
Windows Mobile 2003, 2003SE and 5.0
• Power saving mode minimizes power
usage while maximizing data
throughput when needed
• LEDs on the card show power and
WLAN connection status
• Supports voice over Wi-Fi feature with
Skype software (service not included)
• Fast roaming enables users to roam
between access points in <200 ms,
great for VoIP over Wi-Fi
• SDK supports third party application
developers to rapidly create and
integrate Wi-Fi
SOFTWARE FEATURES
• User-friendly graphical interface shows
connection properties at a glance. Tap on
icons to quickly view IP addresses, find
networks or perform other basic functions
• Wi-Fi Finder provides detailed information
about networks in range and allows you
to filter and sort through the WLAN list
• Power Save utility includes automatic
power management option
• Ping and trace route utilities are useful
troubleshooting tools for advanced
users. Comprehensive statistics are
displayed in handy graphs and tables
*In order to use AES and WPA2 functionality with this card
you will need the mtghouse AEGIS Client:
(http://www.mtghouse.com/products/free_trial_form.asp)
802.11g CF Wi-Fi Card
SPECIFICATIONS:
Frequency Range, Operating Channels:
- North America:
2.412-2.462 GHz, channels 1-11
- Europe ETSI:
2.412-2.472 GHz, channels 1-13
Access Protocol:
Carrier Sense Multiple Access with Collision
Avoidance Protocol (CSMA/CA)
Indoor Range: ~ 300 feet (typ. office env.)
Operating Temp: 0 to 70° C (32 to 158° F)
Storage Temp: -20 to +85° C (5 to 185° F)
Software Features:
Download software from Socket’s web:
www.socketcom.com/support/support_
wlan.asp
- Compatible with Windows Mobile 2003,
2003SE and 5.0
- Works well with all WLAN security proto-
cols supported by Windows Mobile:
- 40/64-bit and 128-bit WEP encryption
- 802.1x with EAP-TLS or PEAP
authentication
- AES, WPA2, WPA and WPA-PSK
For information about the P500x (External
Antenna version) or MontaVista Linux and
Real-Time Operating Systems support,
submit an inquiry online:
www.socketcom.com/contact/note_contact.
asp?EmailID=4&Status=Sales&Product=WiFi
Warranty: Three years
Socket Go Wi-Fi! P500
802.11g CF Wi-Fi Card
© 2006, Socket Communications, Inc. Socket Communications, Socket, Go Wi-Fi!, Wi-Fi Companion and Battery Friendly are registered trademarks or
trademarks of Socket Communications, Inc. Microsoft is a registered trademark of Microsoft Corporation in the United States and other countries.
Wi-Fi is a registered trademark of the Wi-Fi Alliance. All other brand and product names are trademarks of their respective holders.
6450-00135 E 10/2006
Physical Characteristics:
Card Size: 56.1 x 42.8 x 3.3 mm
Weight: 0.5 oz (14 g)
Inserted portion of card is Type I CF
Power Consumption (3.3 V Supply):
Idle: <20 mA
Transmission: 265 mA (peak)
Transmit Power:
CCK: 18.9 dBm typical
OFDM: 15.5 dBm typical
Hardware Support:
Type I CompactFlash slot of Pocket PCs
running Windows Mobile 2003, 2003SE
and 5.0, including devices from Asus, DAP,
Datastrip Dell, HP, TDS, etc.
Standards Conformance:
- Wi-Fi Certified — Enterprise Edition
- Meets 802.1x requirements
- WPA2-Enterprise
- IEEE 802.11b and 802.11g
- CompactFlash Specification 2.0
802.11g: Data rate dynamically shifts
between 54, 48, 36, 24, 18, 12, 9 and 6
Mbps.* (802.11g: OFDM with BPSK, QPSK,
16-QAM and 54-QAM (at 6/9, 12/18,
24/36, and 48/54 Mbps, respectively))
802.11b: Data rate dynamically shifts
between 11, 5, 5M, 2M, and 1 Mbps.*
(802.11g: DSSS with BPSK, QPSK, and CCK
(at 1, 2, and 5.5/11 Mbps, respectively))
Certification/Compliance:
FCC: Part 15, Class B
CE: EN55024:1998
Industry Canada: RSS210
TELEC
The graphical main screen displays
connection properties at a glance.
Tap icons to quickly perform related
functions.
FOR ADDITIONAL PRODUCT INFORMATION:
Website: www.socketcom.com
Ordering Information:
North America SKU# WL6010-676
International SKU# WL6012-678
Sales Offices - Corporate Headquarters:
37400 Central Court, Newark, CA 94560 USA
Phone: 510-744-2700
Domestic Toll Free: 800-552-3300
Fax: 510-744-2727
Online: www.socketcom.com/contact
Tap on a WLAN in the list to
quickly connect.
